11.4.1.2 Packet Tracer - Skills Integration Challenge 604l4j

Packet Tracer – Skills Integration Challenge Topology

© 2015 Cisco and/or its s. All rights reserved. This document is Cisco Public.

Page 1 of 4

Packet Tracer - Skills Integration Challenge

Addressing Table Device

IPv4 Address

Subnet Mask

IPv6 Address/Prefix

IPv6 Link-local

Interface

Default Gateway

N/A G0/0

2001:DB8:ACAD::1/64

FE80::1

N/A N/A

G0/1

2001:DB8:ACAD:1::1/64

R1

FE80::1

N/A N/A

G0/2

2001:DB8:ACAD:2::1/64

FE80::1

N/A

172.16.1.2

255.255.255.252

N/A

2001:DB8:2::1/64

FE80::1

N/A

209.165.200.226

255.255.255.252

N/A

2001:DB8:1::1/64

FE80::2

N/A

172.16.1.1

255.255.255.252

N/A

2001:DB8:2::2/64

FE80::2

N/A

2001:DB8:ACAD::2/64

FE80::2

FE80::1

2001:DB8:ACAD:1::2/64

FE80::2

FE80::1

2001:DB8:ACAD:2::2/64

FE80::2

FE80::1

64.100.0.3

255.255.255.248

64.100.0.1

2001:DB8:CAFE::3/64

FE80::2

FE80::1

S0/0/1

S0/0/0

Central S0/0/1

S1

VLAN 1

S2

VLAN 1

S3

VLAN 1

Staff

NIC

Sales

IT

Web

NIC

NIC

NIC

Scenario / Background The router Central, ISP cluster and the Web server are completely configured. You have been tasked with creating a new IPv4 addressing scheme that will accommodate 4 subnets using 192.168.0.0/24 network. The IT department requires 25 hosts. The Sales department needs 50 hosts. The subnet for the rest of the staff requires 100 hosts. A Guest subnet will be added in the future to accommodate 25 hosts. You are also tasked with finishing the basic security settings and interface configurations on R1. Furthermore, you will configure the SVI interface and basic security setting on switches S1, S2 and S3.

© 2015 Cisco and/or its s. All rights reserved. This document is Cisco Public.

Page 2 of 4

Packet Tracer - Skills Integration Challenge

Requirements IPv4 Addressing 

Create subnets that meet the host requirements using 192.168.0.0/24. 

Staff: 100 hosts



Sales: 50 hosts



IT: 25 hosts



Guest network to be added later: 25 hosts



Document the assigned IPv4 addresses in the Addressing Table.



Record the subnet for Guest network:

PC Configurations 

Configure the assigned IPv4 address, subnet mask, and default gateway settings on the Staff, Sales and IT PCs using your addressing scheme.



Assign IPv6 unicast and link local addresses and default gateway to the Staff, Sales, and IT networks according to the Addressing Table.

R1 Configurations 

Configure the device name according to the Addressing Table.



Disable DNS lookup.



Assign Ciscoenpa55 as the encrypted privileged EXEC mode .



Assign Ciscoconpa55 as the console and enable .



Require that a minimum of 10 characters be used for all s.



Encrypt all plaintext s.



Create a banner that warns anyone accessing the device that unauthorized access is prohibited. Make sure to include the word Warning in the banner.



Configure all the Gigabit Ethernet interfaces.





Configure the IPv4 addresses according to your addressing scheme.



Configure the IPv6 addresses according to the Addressing Table.

Configure SSH on R1: 

Set the domain name to CCNA-lab.com



Generate a 1024-bit RSA key.



Configure the VTY lines for SSH access.



Use the local profiles for authentication.



Create a 1 with a privilege level of 15 using the encrypted for 1pa55.



Configure the console and VTY lines to log out after five minutes of inactivity.



Block anyone for three minutes who fails to after four attempts within a two-minute period.

Switch Configurations 

Configure the device name according to the Addressing Table.



Configure the SVI interface with the IPv4 address and subnet mask according your addressing scheme.

© 2015 Cisco and/or its s. All rights reserved. This document is Cisco Public.

Page 3 of 4

Packet Tracer - Skills Integration Challenge 

Configure the default gateway.



Disable DNS lookup.



Assign Ciscoenpa55 as the encrypted privileged EXEC mode .



Assign Ciscoconpa55 as the console and enable .



Configure the console and VTY lines to log out after five minutes of inactivity.



Encrypt all plaintext s.

Connectivity 

Using the web browser from Staff, Sales, and IT PCs, navigate to www.cisco.pka.



Using the web browser from Staff, Sales, and IT PCs, navigate to www.cisco6.pka.



All PCs should be able to ping all the devices.

© 2015 Cisco and/or its s. All rights reserved. This document is Cisco Public.

Page 4 of 4
