2.3.1.2 Packet Tracer - Skills Integration Challenge Instructions 7w6r

Packet Tracer - Skills Integration Challenge Topology

Addressing Table Device

Interface

IP Address

Subnet Mask

S1

VLAN 1

10.10.10.2

255.255.255.0

PC1

NIC

10.10.10.10

255.255.255.0

PC2

NIC

10.10.10.11

255.255.255.0

Scenario The network asked you to configure a new switch. In this activity, you will use a list of requirements to configure the new switch with initial settings, SSH, and port security.

Requirements 





Configure S1 with the following initial settings: -

Hostname

-

Banner that includes the word warning

-

Console port and cisco

-

Encrypted enable of class

-

Encrypt plain text s

-

Management interface addressing

Configure SSH to secure remote access with the following settings: -

Domain name of cisco.com

-

RSA key-pair parameters to SSH version 2

-

Set SSH version 2

-

with secret ccna

-

VTY lines only accept SSH connections and use local for authentication

Configure the port security feature to restrict network access: -

Disable all unused ports.

© 2014 Cisco and/or its s. All rights reserved. This document is Cisco Public.

Page 1 of 2

Packet Tracer - Skills Integration Challenge -

Set the interface mode to access.

-

Enable port security to allow only two hosts per port.

-

Record the MAC address in the running configuration.

-

Ensure that port violations disable ports.

© 2014 Cisco and/or its s. All rights reserved. This document is Cisco Public.

Page 2 of 2
