Why It’s Important to Always Use Tolerances January 16, 2012 Design World Staff : 0 Comments By Stefan Menin, Mechanical Engineer, Ondrives U.S. Corp.

Reprint Info >> Ambiguity is not your friend. If you leave a dimension without a tolerance, no one else will know the importance, or the unimportance, of that dimension. Not only can a lack of tolerances lead to improper fits, it will also add to delays and higher costs. Imagine you are working on a design for a high efficiency windmill. Due to its complexities you need various custom parts, so you send out manufacturing drawings to various vendors for them to be made. Several weeks later you receive all the parts, but some do not fit. One of your special shafts that should be 7/8 in. in diameter does not fit in its mating bearing. What happened? All the manufacturers were reputable and dealt with precision components, often used in aerospace applications. So, you grab your Vernier caliper and measure the section of the shaft only to discover that it has a diameter greater than what you requested, but by only 0.004 in. Yes, four thousandths of an inch can make a difference. Any interference, defined here as the diameter of a hole that is smaller than the diameter of a shaft, will prevent parts from sliding together. They might have to be pressed on. If too large of an interference exists, it will degrade system performance, especially in bearings. You specified the diameter of the shaft as 0.875 in., but the machine shop made the part to a 0.879 in. diameter. Why the difference? Some machine shops will apply a standard tolerance of 3 decimal places (±0.005) to un-toleranced dimensions, especially if they do not know the design intent. Now, you’ve lost weeks of time while you wait for reworked parts. Such a scenario can be avoided. While many machine shops use due diligence to non-toleranced dimensions, it is critical to understand the importance of tolerances, and how to use them correctly. Since parts need to be made either from larger pieces of material or built up from a powder or liquid, there’s no guarantee they will be exactly the size you want.
