SCHEUERLE SPMT (PLATFORM TRAILER) – 4th GENERATION TECHNICAL DATA PEKZ 210.12.4 X24 • • • • • • • • • • • • •
Longitudinally and laterally combinable trailer units Extremely robust and high load-bearing vehicle design Hydraulic Axle Suspension and Compensation SADESS Electronic Steering / Control Technology One man remote control / central control unit Operation in Open Compound Mechanically, Hydraulically and Electronically linkable trailer units Optimal ratio between dead weight and payload of 1:11 24 x 355/65 – 15 PR24, Continental IC40 tires with poly-fill (foam filled) Maximum steering angle of ±130º for all steering heights Hydraulic safety valves to prevent the hose to the cylinder burst Pressurised hydraulic/spring brake system Availability of the most and maximum steering systems and drives.
Speed (km/h)
Axle load (kg)
Dead weight (kg)
Payload** (kg)
Gross weight (kg)
5
36.000
25.850
190.150
216.000
3
40.000*
25.850
214.150
240.000
1
48.000*
25.850
262.150
288.000
0.5
48.000*
25.850
262.150
288.000
*issible axle load @ max. 2000m (6561ft) driving distance **Stated payload without the dead weight of the PPU or any accessories
SCHEUERLE SPMT (PLATFORM TRAILER) – 4th GENERATION TECHNICAL DATA PEKZ 210.12.4 X24 [km/h]
Driving speed
5
3
1
0.5
Dead weight
[kg]
Payload**
[kg]
190,150
214,150
262,150
262,150
Permissible total weight
[kg]
216,000
240,000
288,000
288,000
Permissible axle load
[kg]
36,000
40,000*
48,000*
48,000*
Pendulum axle load
[kg]
18,000
20,000
24,000
24,000
Wheel load
[kg]
9,000
10,000
12,000
12,000
Pendulum axles [total / driven / braked] Brake force max.
25,850
12 / 4 / 6 [kN]
Service / parking brake for dimensioning of load securing Service / parking brake for driving / driving on gradients
330 240
Tractive force [kN] Permissible suspension pressure at middle platform height
240
Wheel load 10,000 kg (22,046 lbs) Wheel load 12,000 kg (26,455 lbs)
[bar] / [psi] [bar] / [psi]
247 / 3,583 300 / 4,352
*issible axle load @ max. 5000m driving distance **Stated payload without the dead weight of the PPU or any accessories
`
SCHEUERLE SPMT (PLATFORM TRAILER) – 4th GENERATION
PEKZ 210.12.4 X24
PLATFORM TRAILER DYNAMICS Driving speed empty max.
[km/h] / [mph]
11.5 / 7.1
Driving speed with remote control
[km/h] / [mph]
6 / 3.7
Steering angle
[°]
Operating temperature
[°C] / [°F]
Navigable water depth
[mm] / [in]
+/- 130 -20 to +40 / 25 to 104 100 / 4
DIMENSIONS Overall length Coupling length
[mm] [mm]
6 axles 8730 8400
Total width
[mm]
2430
Minimum
[mm]
1150
Middle
[mm]
1500
Maximum
[mm]
1850
Axle base
[mm]
1400
Track
[mm]
1450
Platform height
Polyfill filling / manufacturer
355/65-15 PR24 IC40 / Continental
Tire pressure
[bar] / [psi]
Ground pressure for tire pressure of 10 bar (145 psi)
[N/cm²] / [lbf/in²]
Noise Level
10 / 145 95 / 130.5 70 – 95 dB(A)
SCHEUERLE SPMT (PLATFORM TRAILER) – 4th GENERATION TECHNICAL DATA Dead weight with fluids: [kg] / [lb] Total number of pendulum axles: Number of pendulum axles with drive: issible tilted position – lengthwise / crosswise Total length: [mm] / [in] Coupled length: [mm] / [in] Total width: [mm] / [in] Total height: [mm] / [in] Total height with rollers [mm] / [in] Operating temperature, measured in front of cooler: [°C] / [°F] Engine Manufacturer / Type Cooling System Number of Cylinders / Design / Capacity Power [KW/rpm] # [hp/rpm] Torque Exhaust stage Hydraulic tank - volume [L] / [gal] Hydraulic tank - available volume [L] / [gal] 1. Variable pump drive propulsion 2. Variable pump drive propulsion 3. Variable pump steering Fuel tank – volume [L] / [gal] Fuel Consumption Batteries: Generator voltage/amperage: Generator Performance Starter Voltage Starter Performance Noise Level
7,200 / 15,873 80 (or 40 axle lines) 26 Max. 13º / 5º 4,350 / 171.26 4,200 / 165.35 2,310 / 90.94 1,100 / 43.31 1,157 / 45.55 -20 to +40 / 24.8 to 104 Daimler / OM 502LA Liquid cool – charge air cooling 8 / V-type / 15930 cm3 350 (476PS)/1.800 2300Nm at 1.200rpm Euromot 3A; TIER 3; EPA 3 800 / 211 520 / 137 Q max = 345 l/min, p max = 400 bar Q max = 240 l/min, p max = 400 bar Q max = 370 l/min, p max = 360 bar 400 / 106 Approx 10 to 84l/h 4x12V 24 (28) V / 225 Ah 2.800 W 24 V 6.2kW 70 – 95 dB(A)
PPU (Z350 DA)
`
SCHEUERLE SPMT (PLATFORM TRAILER) – 4th GENERATION STABILITY Each trailer unit can be separated into 3 and 4 hydraulic fields. Each field can maintain hydraulic pressure to each axle in that field. This allows the trailer to adjust for uneven surfaces increasing stability of the loads.
PEKZ 210.12.4 X24
LOADING CAPACITY
POWER
Platforms are torsion-free and bending resistant, designed for direct loading. Platform design and hydraulics allow for a maximum 48,000 kg per axle line.
Power Pack Units (PPU) provides power to the hydraulic systems controlling axle height, steering, braking as well as powering the electrical systems. Each Diesel engine (Z350 DA) is rated at 350 kW (476PS) at 1800rpm.
AXLE CONTROL Each axle is controlled independently by the computer steering system allowing the trailers to move in several pre-programmed steering modes, or manual control modes. With this system trailers can be combined mechanically or separated, still acting as one unit. This allows for any conceivable steering movement. Trailer can also be raised or lowered up to 350mm. These functions are operated by a remote control unit.
CONFIGURATIONS
AXLE TYPES
TRANSPORT
All trailers are completely modular, meaning they can be coupled together end to end or side by side to create many transport configurations.
Self propelled modular trailers that we own is mainly 6 axle (PEKZ 210.12.4 x24). Axles consist of 3 types: propelled, braked and free-wheeling.
Components dimensions and weights are container-capable for cost-effective transport throughout the world.
SCHEUERLE Scheuerle 4th Gen Self Propelled Modular Transporter
SCHEUERLE 4th GEN Self Propelled Modular Transporter
1 of 6
SCHEUERLE 6 axle line self propelled modular transporter
SCHEUERLE 4th GEN Self Propelled Modular Transporter
2 of 6
SCHEUERLE 12 axle line self propelled modular transporter
SCHEUERLE 4th GEN Self Propelled Modular Transporter
3 of 6
SCHEUERLE Sample combinations
SCHEUERLE 4th GEN Self Propelled Modular Transporter
4 of 6
SCHEUERLE Sample combinations
SCHEUERLE 4th GEN Self Propelled Modular Transporter
5 of 6
SCHEUERLE Sample combinations
SCHEUERLE 4th GEN Self Propelled Modular Transporter
6 of 6
SCHEUERLE Scheuerle 4th Gen Self Propelled Modular Transporter
SCHEUERLE 4th GEN Self Propelled Modular Transporter
1 of 6
SCHEUERLE Steering Modes
SCHEUERLE 4th GEN Self Propelled Modular Transporter
2 of 6
SCHEUERLE Steering Modes
SCHEUERLE 4th GEN Self Propelled Modular Transporter
3 of 6
SCHEUERLE Steering Modes
SCHEUERLE 4th GEN Self Propelled Modular Transporter
4 of 6
SCHEUERLE Steering Modes
SCHEUERLE 4th GEN Self Propelled Modular Transporter
5 of 6
SCHEUERLE Steering Modes
SCHEUERLE 4th GEN Self Propelled Modular Transporter
6 of 6
Longitudinally and laterally combinable trailer units Extremely robust and high load-bearing vehicle design Hydraulic Axle Suspension and Compensation SADESS Electronic Steering / Control Technology One man remote control / central control unit Operation in Open Compound Mechanically, Hydraulically and Electronically linkable trailer units Optimal ratio between dead weight and payload of 1:11 24 x 355/65 – 15 PR24, Continental IC40 tires with poly-fill (foam filled) Maximum steering angle of ±130º for all steering heights Hydraulic safety valves to prevent the hose to the cylinder burst Pressurised hydraulic/spring brake system Availability of the most and maximum steering systems and drives.
Speed (km/h)
Axle load (kg)
Dead weight (kg)
Payload** (kg)
Gross weight (kg)
5
36.000
25.850
190.150
216.000
3
40.000*
25.850
214.150
240.000
1
48.000*
25.850
262.150
288.000
0.5
48.000*
25.850
262.150
288.000
*issible axle load @ max. 2000m (6561ft) driving distance **Stated payload without the dead weight of the PPU or any accessories
SCHEUERLE SPMT (PLATFORM TRAILER) – 4th GENERATION TECHNICAL DATA PEKZ 210.12.4 X24 [km/h]
Driving speed
5
3
1
0.5
Dead weight
[kg]
Payload**
[kg]
190,150
214,150
262,150
262,150
Permissible total weight
[kg]
216,000
240,000
288,000
288,000
Permissible axle load
[kg]
36,000
40,000*
48,000*
48,000*
Pendulum axle load
[kg]
18,000
20,000
24,000
24,000
Wheel load
[kg]
9,000
10,000
12,000
12,000
Pendulum axles [total / driven / braked] Brake force max.
25,850
12 / 4 / 6 [kN]
Service / parking brake for dimensioning of load securing Service / parking brake for driving / driving on gradients
330 240
Tractive force [kN] Permissible suspension pressure at middle platform height
240
Wheel load 10,000 kg (22,046 lbs) Wheel load 12,000 kg (26,455 lbs)
[bar] / [psi] [bar] / [psi]
247 / 3,583 300 / 4,352
*issible axle load @ max. 5000m driving distance **Stated payload without the dead weight of the PPU or any accessories
`
SCHEUERLE SPMT (PLATFORM TRAILER) – 4th GENERATION
PEKZ 210.12.4 X24
PLATFORM TRAILER DYNAMICS Driving speed empty max.
[km/h] / [mph]
11.5 / 7.1
Driving speed with remote control
[km/h] / [mph]
6 / 3.7
Steering angle
[°]
Operating temperature
[°C] / [°F]
Navigable water depth
[mm] / [in]
+/- 130 -20 to +40 / 25 to 104 100 / 4
DIMENSIONS Overall length Coupling length
[mm] [mm]
6 axles 8730 8400
Total width
[mm]
2430
Minimum
[mm]
1150
Middle
[mm]
1500
Maximum
[mm]
1850
Axle base
[mm]
1400
Track
[mm]
1450
Platform height
Polyfill filling / manufacturer
355/65-15 PR24 IC40 / Continental
Tire pressure
[bar] / [psi]
Ground pressure for tire pressure of 10 bar (145 psi)
[N/cm²] / [lbf/in²]
Noise Level
10 / 145 95 / 130.5 70 – 95 dB(A)
SCHEUERLE SPMT (PLATFORM TRAILER) – 4th GENERATION TECHNICAL DATA Dead weight with fluids: [kg] / [lb] Total number of pendulum axles: Number of pendulum axles with drive: issible tilted position – lengthwise / crosswise Total length: [mm] / [in] Coupled length: [mm] / [in] Total width: [mm] / [in] Total height: [mm] / [in] Total height with rollers [mm] / [in] Operating temperature, measured in front of cooler: [°C] / [°F] Engine Manufacturer / Type Cooling System Number of Cylinders / Design / Capacity Power [KW/rpm] # [hp/rpm] Torque Exhaust stage Hydraulic tank - volume [L] / [gal] Hydraulic tank - available volume [L] / [gal] 1. Variable pump drive propulsion 2. Variable pump drive propulsion 3. Variable pump steering Fuel tank – volume [L] / [gal] Fuel Consumption Batteries: Generator voltage/amperage: Generator Performance Starter Voltage Starter Performance Noise Level
7,200 / 15,873 80 (or 40 axle lines) 26 Max. 13º / 5º 4,350 / 171.26 4,200 / 165.35 2,310 / 90.94 1,100 / 43.31 1,157 / 45.55 -20 to +40 / 24.8 to 104 Daimler / OM 502LA Liquid cool – charge air cooling 8 / V-type / 15930 cm3 350 (476PS)/1.800 2300Nm at 1.200rpm Euromot 3A; TIER 3; EPA 3 800 / 211 520 / 137 Q max = 345 l/min, p max = 400 bar Q max = 240 l/min, p max = 400 bar Q max = 370 l/min, p max = 360 bar 400 / 106 Approx 10 to 84l/h 4x12V 24 (28) V / 225 Ah 2.800 W 24 V 6.2kW 70 – 95 dB(A)
PPU (Z350 DA)
`
SCHEUERLE SPMT (PLATFORM TRAILER) – 4th GENERATION STABILITY Each trailer unit can be separated into 3 and 4 hydraulic fields. Each field can maintain hydraulic pressure to each axle in that field. This allows the trailer to adjust for uneven surfaces increasing stability of the loads.
PEKZ 210.12.4 X24
LOADING CAPACITY
POWER
Platforms are torsion-free and bending resistant, designed for direct loading. Platform design and hydraulics allow for a maximum 48,000 kg per axle line.
Power Pack Units (PPU) provides power to the hydraulic systems controlling axle height, steering, braking as well as powering the electrical systems. Each Diesel engine (Z350 DA) is rated at 350 kW (476PS) at 1800rpm.
AXLE CONTROL Each axle is controlled independently by the computer steering system allowing the trailers to move in several pre-programmed steering modes, or manual control modes. With this system trailers can be combined mechanically or separated, still acting as one unit. This allows for any conceivable steering movement. Trailer can also be raised or lowered up to 350mm. These functions are operated by a remote control unit.
CONFIGURATIONS
AXLE TYPES
TRANSPORT
All trailers are completely modular, meaning they can be coupled together end to end or side by side to create many transport configurations.
Self propelled modular trailers that we own is mainly 6 axle (PEKZ 210.12.4 x24). Axles consist of 3 types: propelled, braked and free-wheeling.
Components dimensions and weights are container-capable for cost-effective transport throughout the world.
SCHEUERLE Scheuerle 4th Gen Self Propelled Modular Transporter
SCHEUERLE 4th GEN Self Propelled Modular Transporter
1 of 6
SCHEUERLE 6 axle line self propelled modular transporter
SCHEUERLE 4th GEN Self Propelled Modular Transporter
2 of 6
SCHEUERLE 12 axle line self propelled modular transporter
SCHEUERLE 4th GEN Self Propelled Modular Transporter
3 of 6
SCHEUERLE Sample combinations
SCHEUERLE 4th GEN Self Propelled Modular Transporter
4 of 6
SCHEUERLE Sample combinations
SCHEUERLE 4th GEN Self Propelled Modular Transporter
5 of 6
SCHEUERLE Sample combinations
SCHEUERLE 4th GEN Self Propelled Modular Transporter
6 of 6
SCHEUERLE Scheuerle 4th Gen Self Propelled Modular Transporter
SCHEUERLE 4th GEN Self Propelled Modular Transporter
1 of 6
SCHEUERLE Steering Modes
SCHEUERLE 4th GEN Self Propelled Modular Transporter
2 of 6
SCHEUERLE Steering Modes
SCHEUERLE 4th GEN Self Propelled Modular Transporter
3 of 6
SCHEUERLE Steering Modes
SCHEUERLE 4th GEN Self Propelled Modular Transporter
4 of 6
SCHEUERLE Steering Modes
SCHEUERLE 4th GEN Self Propelled Modular Transporter
5 of 6
SCHEUERLE Steering Modes
SCHEUERLE 4th GEN Self Propelled Modular Transporter
6 of 6
