SEMINAR ON “MHD POWER GENERATION” PRESENTED BY:-

RICHA RAI TH EEE-B ,6 SEM 1015321077

CONTENTS  INTRODUCTION  PRINCIPLE  VARIOUS SYSTEMS  ADVANTAGES  DISADVANTAGES  FUTURE PROSPECTS

INTRODUCTION  Magneto hydrodynamics (MHD)

(magneto fluid dynamics or hydro magnetic) is the academic discipline which studies the dynamics of electrically conducting fluids. Examples of such fluids include plasmas, liquid metals, and salt water. The word magneto hydro dynamics (MHD) is derived from magnetomeaning magnetic field, and hydro- meaning liquid, and dynamics meaning movement. The field of MHD was initiated by Hannes Alfvén , for which he received the Nobel Prize in Physics in 1970

Hannes Alfvén

INTRODUCTION  80 % of total electricity produced in the world is hydal, while

remaining 20% is produced from nuclear, thermal, solar, geothermal energy and from magneto hydro dynamic (mhd) generator.  MHD power generation is a new system of electric power generation which is said to be of high efficiency and low pollution. In advanced countries MHD generators are widely used but in developing countries like INDIA, it is still under construction, this construction work is in progress at TRICHI in TAMIL NADU, under the t efforts of BARC (Bhabha atomic research center), Associated cement corporation (ACC) and Russian technologists.  As its name implies, magneto hydro dynamics (MHD) is concerned with the flow of a conducting fluid in the presence of magnetic and electric field. The fluid may be gas at elevated temperatures or liquid metals like sodium or potassium.

INTRODUCTION  An MHD generator is a device for converting heat energy of a fuel directly into electrical energy without conventional electric generator.  In this system. An MHD converter system is a heat engine in which heat taken up at a higher temperature is partly converted into useful work and the remainder is rejected at a temperature. Like all heat engines, the thermal efficiency of an MHD converter is increased by supplying the heat at the highest practical temperature and rejecting it at the lowest practical temperature.

PRINCIPLES OF MHD POWER GENERATION  When an electric conductor moves across a magnetic field, a voltage is

induced in it which produces an electric current.  This is the principle of the conventional generator where the conductors consist of copper strips.  In MHD generator, the solid conductors are replaced by a gaseous conductor, an ionized gas. If such a gas is ed at a high velocity through a powerful magnetic field, a current is generated and can be extracted by placing electrodes in suitable position in the stream.  The principle can be explained as follows. An electric conductor moving through a magnetic field experiences a retarding force as well as an induced electric field and current.

PRINCIPLES OF MHD POWER GENERATION

PRINCIPLES OF MHD POWER GENERATION

PRINCIPLES OF MHD POWER GENERATION  This effect is a result of FARADAYS LAWS OF ELECTRO

MAGNETIC INDUCTION.  The induced EMF is given by Eind = u x B where u = velocity of the conductor. B = magnetic field intensity.  The induced current is given by, Jind = C x Eind where C = electric conductivity  The retarding force on the conductor is the Lorentz force given by Find = Jind X B

PRINCIPLES OF MHD POWER GENERATION  The electro magnetic induction principle is not limited to

solid conductors. The movement of a conducting fluid through a magnetic field can also generate electrical energy.  When a fluid is used for the energy conversion technique,

it is called MAGNETO HYDRO DYNAMIC (MHD), energy conversion.  The flow direction is right angles to the magnetic fields

direction. An electromotive force (or electric voltage) is induced in the direction at right angles to both flow and field directions, as shown in the next slide.

PRINCIPLES OF MHD POWER GENERATION

PRINCIPLES OF MHD POWER GENERATION  The conducting flow fluid is forced between the plates with a kinetic energy and pressure differential sufficient to over come the magnetic induction force Find.  The end view drawing illustrates the construction of the flow channel.  An ionized gas is employed as the conducting fluid.  Ionization is produced either by thermal means I.e. by an elevated temperature or by seeding with substance like cesium or potassium vapors which ionizes at relatively low temperatures.  The atoms of seed element split off electrons. The presence of the negatively charged electrons makes the gas an electrical conductor.

PRINCIPLES OF MHD POWER GENERATION

VARIOUS MHD SYSTEMS  The MHD systems are broadly classified into two types.  OPEN CYCLE SYSTEM  CLOSED CYCLE SYSTEM  Seeded inert gas system  Liquid metal system

OPEN CYCLE SYSTEM  The fuel used maybe oil through an oil tank or gasified

coal through a coal gasification plant  The fuel (coal, oil or natural gas) is burnt in the combustor

or combustion chamber.  The hot gases from combustor is then seeded with a small

amount of ionized alkali metal (cesium or potassium) to increase the electrical conductivity of the gas.  The seed material, generally potassium carbonate is

injected into the combustion chamber, the potassium is then ionized by the hot combustion gases at temperature of roughly 2300’ c to 2700’c.

OPEN CYCLE SYSTEM  To attain such high temperatures, the compressed air is

used to burn the coal in the combustion chamber, must be adequate to at least 1100’c. A lower preheat temperature would be adequate if the air is enriched in oxygen. An alternative is used to compress oxygen alone for combustion of fuel, little or no preheating is then required. The additional cost of oxygen might be balanced by saving on the preheated.  The hot pressurized working fluid living in the combustor flows through a convergent divergent nozzle. In ing through the nozzle, the random motion energy of the molecules in the hot gas is largely converted into directed, mass of energy. Thus , the gas emerges from the nozzle and enters the MHD generator unit at a high velocity.

OPEN CYCLE SYSTEM  The MHD generator is a divergent channel made of a heat

resistant alloy with external water cooling. The hot gas expands through the rocket like generator surrounded by powerful magnet. During motion of the gas the +ve and –ve ions move to the electrodes and constitute an electric current.  The arrangement of the electrode connection is

determined by the need to reduce the losses arising from the Hall effect. By this effect, the magnetic field acts on the MHD-generated current and produces a voltage in flow direction of the working fluid.

CLOSED CYCLE SYSTEM  Two general types of closed cycle MHD generators are being investigated.  Electrical conductivity is maintained in the working fluid by ionization of a seeded material, as in open cycle system.  A liquid metal provides the conductivity.  The carrier is usually a chemical inert gas, all through a liquid carrier is been used with a liquid metal conductor. The working fluid is circulated in a closed loop and is heated by the combustion gases using a heat exchanger. Hence the heat sources and the working fluid are independent. The working fluid is

helium or argon with cesium seeding.

ADVANTAGES  The conversion efficiency of a MHD system can be around 50% much

higher compared to the most efficient steam plants. Still higher efficiencies are expected in future, around 60 – 65 %, with the improvements in experience and technology.  Large amount of power is generated.  It has no moving parts, so more reliable.  The closed cycle system produces power, free of pollution.  It has ability to reach the full power level as soon as started.  The size if the plant is considerably smaller than conventional fossil

fuel plants.

DISADVANTAGES  MHD Systems suffer from the reverse flow (short circuits)

of electrons through the conducting fluids around the ends of the magnetic field. ‡  There will be high friction losses and heat transfer losses. The

friction loss may be as high as 12% input. ‡  The MHD system needs very large magnets and this is a

major expense.

‡  Coal, when used as a fuel, poses the problem of molten ash which

may short circuit the electrodes. Hence, The restriction on the use of fuel makes the operation more expensive.

FUTURE PROSPECTS  It is estimated that by 2020, almost 70 % of the total

electricity generated in the world will be from MHD generators.  Research and development is widely being done on MHD by different countries of the world.  Nations involved:  USA  Former USSR  Japan  India  China  Yugoslavia  Australia  Italy

CONCLUSION  The threat of disappearing of the fossil fuels within few decades

compel the human beings to search for new energy sources will last for a longer time. Extensive research is going on in different countries through out the world to find out the new resources to replace the conventional fossil one. With the present research and development programmes, the non-conventional power resources play an important role in the power industry . The magneto hydro dynamic power generation is one of the examples of a new unique method of generation of electricity. This power resource play a minor role presently and its use on a vast scale is yet to be confirmed as it is in its childhood stage. Man being optimistic should not leave the hopes on the success of this MHD generator as the technology took the man to moon which was a dream long time back, the same technology will help the human being to survive from the present crisis of power shortage.
