’s Manual for LPile 2016 (Using Data Format Version 9) A Program to Analyze Deep Foundations Under Lateral Loading

by

William M. Isenhower, Ph.D., P.E. Shin-Tower Wang, Ph.D., P.E.

January 5, 2016

Copyright © 2016 by Ensoft, Inc. All rights reserved. This book or any part thereof may not be reproduced in any form without the written permission of Ensoft, Inc.

Date of Last Revision: January 5, 2016

Program License Agreement

IMPORTANT NOTICE: Please read the of the following license agreement carefully. You signify full acceptance of this Agreement by using the software product. Single- versions of this software product is licensed only to the (company office or individual) whose name is ed with Ensoft, Inc., or to s at the ed company office location, on only one computer at a time. Additional installations of the software product may be made by the , as long as the number of installations in use is equal to the total number of purchased and ed licenses. s of network-licensed versions of this software product are entitled to install on all computers on the network at their ed office locations, but are not permitted to install the program on virtual servers unless the virtual server license has been purchased. This software can be used simultaneously by as many s as the total number of purchased and ed licenses. The is not entitled to copy this software product unless for backup purposes. Past and current versions of the software may be ed from www.ensoftinc.com. The license for this software may not loan, rent, lease, or transfer this software package to any other person, company, t venture partner, or office location. This software product and documentation are copyrighted materials and should be treated like any other copyrighted material (e.g. a book, motion picture recording, or musical recording). This software is protected by United States Copyright Law and International Copyright Treaty.

iii

Copyright © 1987, 1997, 2004, 2010, 2012, 2013, 2015 by Ensoft, Inc. All rights reserved. Except as permitted under United States Copyright Act of 1976, no part of this publication may be reproduced, translated, or distributed without the prior consent of Ensoft, Inc. Although this software product has been used with apparent success in many analyses, new information is developed continuously and new or updated versions of the software product may be written and released from time to time. All s are requested to inform Ensoft, Inc. immediately of any suspected errors found in the software product. No warrantee, expressed or implied, is offered as to the accuracy of results from software products from Ensoft, Inc. The software products should not be used for design unless caution is exercised in interpreting the results and independent calculations are available to the general correctness of the results. s are assumed to be knowledgeable of the information in the program documentation (’s Manual and Technical Manual) distributed with the program package. s are assumed to recognize that variances in input values can have significant effect on the computed solutions and that input values must be chosen carefully. s should have a thorough understanding of the relevant engineering principles, relevant theoretical criteria (appropriate references are contained in the software documentation), and design standards.

iv

Table of Contents

List of Figures ................................................................................................................................ xi List of Tables ............................................................................................................................... xvi Chapter 1 Introduction .................................................................................................................... 1 1-1 General Description .............................................................................................................. 1 1-2 Program Development History ............................................................................................. 1 1-2-1 LPile 1.0 for MS-DOS (1986) ....................................................................................... 1 1-2-2 LPile 2.0 for MS-DOS (1987) ....................................................................................... 1 1-2-3 LPile 3.0 for MS-DOS (1989) ....................................................................................... 2 1-2-4 LPile 4.0 for MS-DOS (1993) ....................................................................................... 2 1-2-5 LPile Plus 1.0 for MS-DOS (1993) ............................................................................... 2 1-2-6 LPile Plus 1.0 for Windows (1994) ............................................................................... 2 1-2-7 LPile Plus 2.0 for Windows (1995) ............................................................................... 2 1-2-8 LPile Plus 3.0 for Windows (1997) ............................................................................... 3 1-2-9 LPile Plus 3.0M (Soil Movement Version) for Windows (1998).................................. 4 1-2-10 LPile Plus 4.0/4.0M for Windows (2000).................................................................... 4 1-2-11 LPile Plus 5.0 for Windows (2004) ............................................................................. 4 1-2-12 LPile 6 for Windows (2010) ........................................................................................ 5 1-2-13 LPile 2012 for Windows, Data Format 6 ..................................................................... 5 1-2-14 LPile 2013 for Windows, Data Format 7 ..................................................................... 6 1-2-15 LPile 2015 for Windows, Data Format 8 ..................................................................... 6 1-2-16 LPile 2016 for Windows, Data Format 9 ..................................................................... 7 1-3 Technical ................................................................................................................. 7 1-3-1 Upgrade Notifications and Ensoft’s Website................................................................. 7 1-3-2 Renewal of Program Maintenance ................................................................................. 8 1-3-3 Changes of Policy ............................................................................................ 8 Chapter 2 Installation and Getting Started ...................................................................................... 9 2-1 Installation and Computing Hardware Requirements ........................................................... 9 2-1-1 Single Version ....................................................................................................... 9 2-1-2 Network Version ............................................................................................................ 9 2-1-3 Software Updates ......................................................................................................... 10 2-1-4 Installation of Software Updates.................................................................................. 11 2-2 Getting Started .................................................................................................................... 11 2-2-1 File Menu and Buttons ................................................................................................. 12 2-2-2 Data Menu and Buttons ............................................................................................... 13 2-2-3 Computation Menu and Buttons .................................................................................. 13 2-2-4 Graphics Menu and Buttons ........................................................................................ 16 v

2-2-5 Tools Menu .................................................................................................................. 16 2-2-6 Window Menu ............................................................................................................. 17 2-2-7 Help Menu ................................................................................................................... 17 Chapter 3 Input of Data................................................................................................................. 21 3-1 Data Menu ........................................................................................................................... 22 3-2 Speed Buttons for Data Entry ............................................................................................. 22 3-3 Project Information Dialog ................................................................................................. 23 3-4 Program Options and Settings Dialog................................................................................. 23 3-4-1 Computational Options ................................................................................................ 24 3-4-2 Engineering Units of Input Data and Computations .................................................... 25 3-4-3 Analysis Control Options............................................................................................. 26 3-4-4 Loading Type and Number of Cycles of Loading ....................................................... 27 3-4-5 Output Options ............................................................................................................. 27 3-4-6 Text Viewer Options .................................................................................................... 28 3-4-7 Input of Data from Load Testing ................................................................................. 28 3-4-8 Internet Update Notice Query ...................................................................................... 28 3-5 Structural Dimensions and Material Properties .................................................................. 28 3-5-1 General Description of Input ....................................................................................... 28 3-5-2 Section Type and Shape ............................................................................................... 29 3-5-3 Warning and Design Error Messages .......................................................................... 29 3-5-4 Elastic Sections ............................................................................................................ 30 3-5-5 Elastic Sections with Specified Moment Capacity ...................................................... 31 3-5-6 Rectangular Concrete Piles .......................................................................................... 31 3-5-7 Round Concrete Shafts (Bored Piles) .......................................................................... 34 3-5-8 Round Concrete Shaft with Permanent Casing............................................................ 36 3-5-9 Round Concrete Shaft with Permanent Casing and Core ............................................ 38 3-5-10 Steel Pipe Pile ............................................................................................................ 40 3-5-11 Round Prestressed Concrete Pile ............................................................................... 42 3-5-12 Round Prestressed Concrete Pile with Void .............................................................. 44 3-5-13 Square Prestressed Concrete Pile ............................................................................... 44 3-5-14 Square Prestressed Concrete Pile with Void.............................................................. 44 3-5-15 Octagonal Prestressed Concrete Pile ......................................................................... 45 3-5-16 Octagonal Prestressed Concrete Pile with Void ........................................................ 45 3-5-17 Pile with Defined Nonlinear Bending ........................................................................ 45 3-6 Lateral Load Transfer Relationships ................................................................................... 47 3-6-1 Soil Layering and p-y Curve Models ........................................................................... 48 3-6-2 Input p-y Curves .................................................................................................. 52 3-7 Pile Batter and Ground Slope ............................................................................................. 53 3-8 p-y Modification Factors ..................................................................................................... 53 3-9 Tip Shear-Resistance .......................................................................................................... 55

vi

3-10 Shift Pile or Soil Elevations .............................................................................................. 56 3-11 Input of Output Depths for p-y Curves ............................................................................. 57 3-12 Conventional Loading Analysis ........................................................................................ 58 3-12-1 Pile-head Loading and Options.................................................................................. 58 3-12-2 Distributed Lateral Loading ....................................................................................... 60 3-12-3 Loading by Lateral Soil Movements ......................................................................... 64 3-12-4 Computation of Pile-head Stiffness Matrix Components .......................................... 65 3-12-5 Pushover Analysis...................................................................................................... 66 3-12-6 Pile Buckling Analysis............................................................................................... 68 3-13 Input of Load Testing Data ............................................................................................... 72 3-13-1 Controls for Input of Load Test Data......................................................................... 72 3-13-2 Input of Load Test Data without Data for Bending Moments ................................... 73 3-13-3 Input of Load Test Data for Bending Moments and Deflection versus Depth .......... 73 3-14 Load and Resistance Factor Design .................................................................................. 76 3-14-1 Unfactored Loads ....................................................................................................... 77 3-14-2 Load Cases and Resistance Factors ........................................................................... 78 3-14-3 Summary of Factored Load Cases ............................................................................. 79 3-15 Computation of Nonlinear EI Only................................................................................... 79 3-15-1 Axial Thrust Loads for Interaction Diagram ............................................................. 79 Chapter 4 Display of Graphics ...................................................................................................... 81 4-1 Introduction ......................................................................................................................... 81 4-2 Types of Graphics ............................................................................................................... 81 4-3 Graphics Mouse Commands ............................................................................................... 81 4-4 Graphics Buttons ................................................................................................................. 81 4-5 Graphics Menu .................................................................................................................... 81 4-6 Plot Menu ............................................................................................................................ 82 4-7 Graphics of Input Data ........................................................................................................ 83 4-7-1 View Pile-Soil Geometry ............................................................................................. 83 4-7-2 Summary Charts of Soil Properties ............................................................................. 84 4-7-3 -Input p-y Curves .................................................................................................. 84 4-7-4 Distributed Lateral Loads vs. Depth ............................................................................ 84 4-7-5 p and y Modifiers versus Depth ................................................................................... 84 4-8 Graphics of Computational Results .................................................................................... 85 4-8-1 View Results ................................................................................................................ 85 4-8-2 p-y Curves at -specified Depths ........................................................................... 85 4-8-3 Lateral Deflection versus Depth .................................................................................. 85 4-8-4 Bending Moment versus Depth ................................................................................... 86 4-8-5 Shear Force versus Depth ............................................................................................ 86 vii

4-8-6 Mobilized Soil Reaction versus Depth ........................................................................ 86 4-8-7 Deflection, Moment, and Shear Force versus Depth ................................................... 86 4-8-8 Deflection, Curvature, and Moment versus Depth ...................................................... 86 4-8-9 Mobilized Pile EI versus Depth ................................................................................... 86 4-8-10 Load versus Top Deflection ....................................................................................... 86 4-8-11 Load versus Max Moment ......................................................................................... 87 4-8-12 Top Deflection versus Pile Length ............................................................................ 87 4-8-13 Moment versus Curvature .......................................................................................... 87 4-8-14 EI versus Moment ...................................................................................................... 87 4-8-15 Interaction Diagram ................................................................................................... 87 4-8-16 All K’s versus Deflection and Rotation ..................................................................... 87 4-8-17 All K’s versus Shear and Moment ............................................................................. 87 4-8-18 Individual K’s versus Force and Moment .................................................................. 88 4-8-19 Individual K’s versus Pile-head Deflection and Rotation .......................................... 88 4-8-20 Pushover Shear Force versus Top Deflection ............................................................ 89 4-8-21 Pushover Moment versus Top Deflection ................................................................. 89 4-8-22 Pile Buckling Thrust versus Top Deflection.............................................................. 89 4-8-23 Deflection and Soil Movement versus Depth ............................................................ 90 4-9 Presentation Charts ............................................................................................................. 90 4-9-1 Saving and Applying Presentation Chart Templates ................................................... 90 4-9-2 Exporting Presentation Charts ..................................................................................... 90 4-9-3 Creating Graphs for Reports ........................................................................................ 90 Chapter 5 Tools Menu .................................................................................................................. 93 5-1 Simple Calculator................................................................................................................ 93 5-2 Battered Pile Load Calculator ............................................................................................. 94 5-3 Custom Reinforcing Bar Data Entry and Editing ............................................................... 95 5-4 Multi-File Analysis (Batch Run Utility) ............................................................................. 96 Chapter 6 Example Problems........................................................................................................ 99 6-1 Example 1 – Steel Pile in Sloping Ground ....................................................................... 101 6-2 Example 2 – Drilled Shaft in Sloping Ground .................................................................. 107 6-3 Example 3 – Offshore Pipe Pile ........................................................................................ 113 6-4 Example 4 - Buckling of a Pile-Column ........................................................................... 117 6-5 Example 5 – Computation of Nominal Moment Capacity and Interaction Diagram ....... 119 6-6 Example 6 – Pile-head Stiffness Matrix ........................................................................... 121 6-7 Example 7 – Pile with -Input p-y Curves and Distributed Load ............................... 123 6-8 Example 8 – Pile in Cemented Sand ................................................................................. 125 6-9 Example 9 – Drilled Shaft with Tip Resistance ................................................................ 127 6-10 Example 10 – Drilled Shaft in Soft Clay ........................................................................ 130

viii

6-11 Example 11 – LRFD Analysis ........................................................................................ 131 6-12 Example 12 – Pile in Liquefied Sand with Lateral Spread ............................................. 133 6-13 Example 13 – Square Elastic Pile with Top Deflection versus Length .......................... 135 6-14 Example 14 – Pushover Analysis of Prestressed Concrete Pile ..................................... 137 6-15 Example 15 – Pile with Defined Nonlinear Bending Properties .................................... 139 6-16 Example 16 – Pile with Distributed Lateral Loadings .................................................... 139 6-17 Example 17 – Analysis of a Drilled Shaft ...................................................................... 140 6-18 Example 18 – Analysis of Drilled Shaft with Permanent Casing ................................... 141 6-19 Example 19 – Analysis of Drilled Shaft with Casing and Core ..................................... 141 6-20 Example 20 – Analysis of Embedded Pole ..................................................................... 143 6-21 Example 21 – Analysis of Tapered Elastic Pile .............................................................. 144 6-22 Example 22 – Analysis of Tapered Elastic-Plastic Pile .................................................. 145 6-23 Example 23 – Output of p-y Curves ............................................................................... 146 6-24 Example 24 – Analysis with Lateral Soil Movements .................................................... 149 6-25 Example 25- Verification of Elastic Pile in Elastic Subgrade Soil ................................. 152 6-26 Example 26 – Verification of P-Delta Effect ................................................................. 152 Chapter 7 Validation ................................................................................................................... 155 7-1 Introduction ....................................................................................................................... 155 7-2 Case Histories ................................................................................................................... 155 7-3 Verification of Accuracy of Solution ................................................................................ 157 7-3-1 Solution of Example Problems .................................................................................. 157 7-3-2 Numerical Precision Employed in Internal Computations ........................................ 158 7-3-3 Selection of Convergence Tolerance and Length of Increment ................................ 158 7-3-4 Check of Soil Resistance ........................................................................................... 160 7-3-5 Check of Equilibrium................................................................................................. 160 7-3-6 Use of Non-Dimensional Curves ............................................................................... 162 7-3-7 Use of Closed-form Solutions.................................................................................... 162 7-3-8 Concluding Comments on Verification ..................................................................... 164 Chapter 8 Line-by-Line Guide for Input ..................................................................................... 167 8-1 Key Words for Input Data File ......................................................................................... 167 8-2 TITLE Command .............................................................................................................. 168 8-3 OPTIONS Command ........................................................................................................ 168 8-4 SECTIONS Command ...................................................................................................... 169 8-5 SOIL LAYERS Command ............................................................................................... 179 ix

8-6 PILE BATTER AND SLOPE Command ......................................................................... 186 8-7 TIP SHEAR Command ..................................................................................................... 186 8-8 GROUP EFFECT FACTORS Command ......................................................................... 187 8-9 LRFD LOADS Command ................................................................................................ 187 8-10 LRFD FACTORS AND CASES Command................................................................... 188 8-11 LOADING Command ..................................................................................................... 188 8-12 P-Y OUTPUT DEPTHS Command................................................................................ 189 8-13 SOIL MOVEMENTS Command .................................................................................... 189 8-14 AXIAL THRUST LOADS Command............................................................................ 189 8-15 FOUNDATION STIFFNESS Command ....................................................................... 190 8-16 PILE PUSHOVER ANALYSIS DATA Command ....................................................... 190 8-17 PILE BUCKLING ANALYSIS DATA Command ........................................................ 191 8-18 LRFD Data File............................................................................................................... 191 References ................................................................................................................................... 193 Appendix 1 Input Error Messages .............................................................................................. 195 Appendix 2 Runtime Error Messages ......................................................................................... 199 Appendix 3 Warning Messages .................................................................................................. 201

x

List of Figures

Figure 1-1 Pile-head Stiffness Components ................................................................................... 3 Figure 2-1 Options for Type of License Installation .................................................................... 10 Figure 2-2 Options for Type of Network Installation ................................................................... 10 Figure 2-3 Check for Update Query ............................................................................................. 11 Figure 2-4 Principal Operations of LPile ...................................................................................... 11 Figure 2-5 Main Window of LPile................................................................................................ 12 Figure 2-6 File Menu .................................................................................................................... 12 Figure 2-7 File Speed Buttons ...................................................................................................... 13 Figure 2-8 Speed Buttons for Data Input for Different Analysis Modes ...................................... 13 Figure 2-9 Input Data Review Buttons ......................................................................................... 13 Figure 2-10 Computation Menu.................................................................................................... 14 Figure 2-11 Run Analysis and View Report Buttons ................................................................... 14 Figure 2-12 Graphics Buttons ....................................................................................................... 16 Figure 2-13 Tools Menu ............................................................................................................... 16 Figure 2-14 Help Menu ................................................................................................................. 17 Figure 2-15 Example of About LPile Dialog ................................................................................ 19 Figure 3-1 Data Menu ................................................................................................................... 22 Figure 3-2 Buttons for Data Entry and Manipulation for Conventional Analysis ........................ 22 Figure 3-3 Buttons for Data Entry and Manipulation for Computation of Nonlinear EI Only .... 23 Figure 3-4 Buttons for Data Entry and Manipulation for LRFD Analysis ................................... 23 Figure 3-5 Example of Project Information Input Dialog ............................................................ 23 Figure 3-6 Program Options and Settings Dialog ......................................................................... 24 Figure 3-7 Pile Section, Section Type Tab ................................................................................... 29 Figure 3-8 Dimensions Tab Page for Rectangular Concrete Section ........................................... 32 Figure 3-9 Concrete Tab Page for Rectangular Concrete Section ................................................ 32 Figure 3-10 Rebars Tab Page for Rectangular Concrete Section ................................................. 33 Figure 3-11 Rebar Layout Table for Rectangular Concrete Section ............................................ 33 Figure 3-12 Section Type, Dimensions, and Cross-section Properties Dialog for Rectangular Concrete Section Showing Rebar Layout After Definition ................. 34 Figure 3-13 Tab Sheet for Selection of Section Type Showing Current Cross-section ............... 35 Figure 3-14 Tab Sheet for Reinforcing Bar Properties ................................................................. 36 Figure 3-15 Tab Sheet for Shaft Dimensions for Drilled Shaft with Permanent Casing .............. 37 Figure 3-16 Tab Sheet for Rebars for Drilled Shaft with Permanent Casing ............................... 37 Figure 3-17 Tab Sheet for Casing Material Properties for Drilled Shaft with Permanent Casing ....................................................................................................................... 38 Figure 3-18 Tab Sheet forShaft Dimensions of Drilled Shaft with Casing and Core................... 39 Figure 3-19 Tab Sheet for Casing and Core Material Properties .................................................. 40 Figure 3-20 Dimensions Tab Page for Steel Pipe Piles ................................................................ 41 Figure 3-21 Pipe-Casing-Core Properties Tab Page for Steel Pipe Pile ....................................... 41 Figure 3-22 Comparison of Moment vs. Curvature for (a) Steel Pipe Pile and (b) Elastilastic Pipe Pile with Similar Properties .................................................................. 42 xi

Figure 3-23 Prestressing Tab Page Common to All Prestressed Pile Types ................................ 43 Figure 3-24 Automatic Prestressing Arrangements for Square Prestressed Piles ........................ 44 Figure 3-25 Nonlinear EI Tab Page .............................................................................................. 46 Figure 3-26 Table for Entering Axial Thrust Forces for Nonlinear Bending Data ...................... 46 Figure 3-27 Tables for Entry of (a) Nonlinear Moment versus Curvature Data and (b) Nonlinear Moment versus Bending Stiffness ........................................................... 47 Figure 3-28 Dialog for Definition of Soil Layering and Soil Properties ...................................... 48 Figure 3-29 Dialog for Properties of Weak Rock ......................................................................... 51 Figure 3-30 Dialog for Properties of Massive Rock ..................................................................... 51 Figure 3-31 Dialog for Effective Unit Weights of -input p-y Curves ................................... 52 Figure 3-32 Dialog for -input p-y Curve Values ................................................................... 52 Figure 3-33 Dialog for Definition of Pile Batter and Slope of Ground Surface ........................... 54 Figure 3-34 Dialog for p-Multipliers and y-Multipliers versus Depth Below Pile Head ............. 54 Figure 3-35 Dialog for Tip Shear Resistance versus Lateral Tip Displacement .......................... 55 Figure 3-36 Dialog for Shifting of Pile Elevation Relative to Input Soil Profile Showing a Pile Head at the Top of the Soil Profile .................................................................... 56 Figure 3-37 Dialog for Shifting of Pile Elevation Relative to Input Soil Profile After Shifting a Pile Head To Be Below the Ground Surface ........................................... 57 Figure 3-38 Output Depths of p-y Curves Below Pile Head, (a) Dialog for p-y Curve Output Depths, (b) Measurement of Vertical Depths ............................................... 58 Figure 3-39 Dialog for Definition of Conventional Pile-head Loading ....................................... 59 Figure 3-40 Dialogs for Multiple Distributed Lateral Loads for Conventional Loading, (a) 3 Load Cases, (b) Distributed Load Profile Data for Load Case 1 ........................... 61 Figure 3-41 Dialog of Values of Distributed Lateral Loads versus Depth ................................... 62 Figure 3-42 Recommendation for Modeling of Lateral Force Applied Below the Pile Head ...... 63 Figure 3-43 Recommendation for Modeling of Moment Applied Below the Pile Head.............. 64 Figure 3-44 Dialog for Input of Soil Movements versus Depth Below Pile Head ....................... 65 Figure 3-45 Dialog for Controls for Computation of Stiffness Matrix ......................................... 66 Figure 3-46 Dialog for Controls for Pushover Analysis ............................................................... 67 Figure 3-47 Pile-head Shear Force versus Displacement from Pushover Analysis...................... 68 Figure 3-48 Maximum Moment in Pile versus Displacement from Pushover Analysis .............. 68 Figure 3-49 Dialog for Controls for Pile Buckling Analysis ........................................................ 69 Figure 3-50 Typical Results for a Pile Buckling Analysis ........................................................... 70 Figure 3-51 Computed Pile Buckling Result Shifted to the Left .................................................. 70 Figure 3-52 Redrawn Pile Buckling Results Used for Curve Fitting ........................................... 70 Figure 3-53 Results from Pile Buckling Analysis ........................................................................ 71 Figure 3-54 Example of Correct (green symbols) and Incorrect (red symbols) Pile Buckling Analyses .................................................................................................... 72 Figure 3-55 Dialog for Control of Input and Saving of Load Testing Data ................................. 73 Figure 3-56 Dialog for Input of Pile-head Shear Force versus Lateral Deformation from Load Testing, if input of Bending Moment and/or Lateral Movement versus Depth is not specified. .............................................................................................. 74 Figure 3-57 Dialog for Input of Pile-head Shear Force versus Lateral Deformation from Load Testing, if input of Bending Moment and Lateral Deflection versus Depth are specified. .................................................................................................. 75

xii

Figure 3-58 Dialogs for Input of Bending Moment and Lateral Deflection versus Depth from Load Testing. ................................................................................................... 76 Figure 3-59 Dialog for Definition of Unfactored Pile-head Loadings for LRFD Analysis.......... 77 Figure 3-60 Dialog for LRFD Load Combinations and Structural Resistance Factors ................ 78 Figure 3-61 Summary Report of Computed Factored Load Combinations for LRFD Analysis .................................................................................................................... 79 Figure 3-62 Dialog for Axial Thrust Forces for Computation of Interaction Diagram ................ 80 Figure 4-1 Speed Buttons for Graphics ........................................................................................ 81 Figure 4-2 Graphics Menu ............................................................................................................ 82 Figure 4-3 Plot Drop-Down Menu ................................................................................................ 83 Figure 4-4 Example of Summary Graphs of Soil Properties ........................................................ 84 Figure 4-5 Example of View Results Window ............................................................................. 85 Figure 4-6 Sub-menu for Pile-head Stiffnesses versus Pile-head Force and Moment ................. 88 Figure 4-7 Submenu for Pile-head Stiffnesses versus Deflection and Rotation ........................... 88 Figure 4-8 Example of Table for a Report Graph ......................................................................... 91 Figure 5-1 Tools Menu ................................................................................................................. 93 Figure 5-2 Simple Calculator ........................................................................................................ 93 Figure 5-3 Battered Load Calculator ............................................................................................ 95 Figure 5-4 Dialog for Editing of Custom Rebar Data................................................................... 96 Figure 5-5 Dialog for Multi-File Analysis Controls ..................................................................... 97 Figure 6-1 General Description of Example 1 ............................................................................ 102 Figure 6-2 Dimensions and Properties Entered for Example 1 .................................................. 103 Figure 6-3 Generated Curve of Lateral Load versus Maximum Moment for Example 1. ......... 105 Figure 6-4 Generated Curve of Lateral Load versus Top Deflection for Example 1. ................ 105 Figure 6-5 Curve of Deflection versus Depth for Example 1, Second Analysis ........................ 106 Figure 6-6 Bending Moment versus Depth for Example 1, Second Analysis ............................ 107 Figure 6-7 Cross-section of Drilled Shaft for Example 2. .......................................................... 108 Figure 6-8 Factored Interaction Diagram for Example 2a. ......................................................... 109 Figure 6-9 Moment-Curvature Diagram for Example 2a. .......................................................... 109 Figure 6-10 Bending Stiffness versus Bending Moment for Example 2a. ................................. 110 Figure 6-11 Shear Force versus Top Deflection and Maximum Bending Moment versus Top Shear Load for Free-head Conditions in Example 2b. .................................... 111 Figure 6-12 Shear Force versus Top Deflection and Maximum Bending Moment versus Top Shear Load for Fixed-head Conditions in Example 2c. .................................. 111 Figure 6-13 Results for Free-head and Fixed-head Loading Conditions for Example 2d .......... 112 Figure 6-14 Top Deflection versus Pile Length for Example 2d ................................................ 112 Figure 6-15 Idealized View of an Offshore Platform Subjected to Wave Loading, Example 3 .............................................................................................................................. 113 Figure 6-16 Superstructure and Pile Details, Example 3 ............................................................ 114 Figure 6-17 Moment versus Curvature, Example 3 .................................................................... 115 Figure 6-18 Results of Initial Computation with p-y Curves, Example 3 .................................. 116 Figure 6-19 Pile Deflection and Bending Moment versus Depth for Vtop = 500 kN, Example 3 ............................................................................................................... 117 Figure 6-20 Pile-head Deflection and Maximum Bending Moment versus Axial Thrust Loading ................................................................................................................... 118 Figure 6-21 Results from LPile Solution for Buckling Analysis, Example 4 ............................ 119 xiii

Figure 6-22 Moment versus Curvature for Example 5 ............................................................... 120 Figure 6-23 Bending Stiffness versus Bending Moment, Example 5......................................... 121 Figure 6-24 Factored Interaction Diagram of Reinforced-concrete Pile, Example 5 ................. 121 Figure 6-25 Stiffness Matrix Components versus Displacement and Rotation, Example 6 ....... 122 Figure 6-26 Stiffness Matrix Components versus Force and Moment, Example 6 .................... 123 Figure 6-27 Pile and soil details for Example 7 .......................................................................... 124 Figure 6-28 -input p-y Curves for Example 7 (Lower curve for Layer 7 not shown) ......... 124 Figure 6-29 Soil details for Example 8 ....................................................................................... 125 Figure 6-30 Comparison between Measured and Predicted Pile-head Load versus Deflection Curves for the 5-m Pile of Example 8 .................................................. 126 Figure 6-31 Comparison between Measured and Computed Bending Moment versus Depth for the 5-m Pile of Example 8 ................................................................................ 126 Figure 6-32 Shaft Geometry and Soil Properties for Example 9 ................................................ 127 Figure 6-33 Moment versus Curvature for Sections 1 and 2, Example 9 ................................... 129 Figure 6-34 Lateral Deflection and Bending Moment versus Depth, Example 9 ...................... 129 Figure 6-35 Top Deflection versus Pile Length, Example 9 ...................................................... 130 Figure 6-36 Summary Plots of Results for Example 10 ............................................................. 131 Figure 6-37 Example from Summary Report of LRFD Loadings, Example 11 ......................... 132 Figure 6-38 Message for Successful LRFD Analysis for Example 11 ....................................... 132 Figure 6-39 Pile and Soil Profile for Example 12....................................................................... 133 Figure 6-40 Lateral Spread Profile versus Depth for Example 12.............................................. 134 Figure 6-41 Summary Graphs for Example 12 ........................................................................... 135 Figure 6-42 Pile-head Load versus Deflection Curves Using Original and Modified p-y Curves for Stiff Clay without Free Water and Percentage Reduction in Stiffness for Example 13 ........................................................................................ 136 Figure 6-43 Curves of Pile Top Deflection versus Pile Length for Example 13 ........................ 136 Figure 6-44 Reinforcement Details for Prestressed Concrete Pile of Example 14 ..................... 137 Figure 6-45 Moment versus Curvature of Prestressed Pile for Example 14............................... 138 Figure 6-46 Results of Pushover Analysis of Prestressed Concrete Pile of Example 14 ........... 139 Figure 6-47 Pile and Soil Profile for Example 17....................................................................... 140 Figure 6-48 Moment versus Curvature for Dual Section Drilled Shaft of Example 17 ............. 141 Figure 6-49 Moment versus Curvature for Dual Section Drilled Shaft with Permanent Casing of Example 18 ............................................................................................ 142 Figure 6-50 Moment versus Curvature for Dual Section Drilled Shaft with Permanent Casing and Core of Example 19 ............................................................................. 142 Figure 6-51 Pile and Soil Profile for Embedded Pole of Example 20 ........................................ 143 Figure 6-52 Bending Moment and Plastic Moment Capacity versus Depth for Example 22..... 145 Figure 6-53 Program and Setting Dialog Showing Check for Generation of p-y Curves .......... 146 Figure 6-54 Pile and Soil Profile for Example 23....................................................................... 147 Figure 6-55 Standard Output of 17-point p-y Curves for Example 23 ....................................... 147 Figure 6-56 -input p-y Curves Interpolated with Depth Using 17 Points for Example 23 ............................................................................................................................ 148 Figure 6-57 Output of -input p-y Curves with Five Points for Example 23 ........................ 149 Figure 6-58 Pile and Soil Profile for Example 24....................................................................... 150 Figure 6-59 Program and Setting Dialog Showing Check for Inclusion of Loadings by Lateral Soil Movements ......................................................................................... 150

xiv

Figure 6-60 Input Dialog for Lateral Soil Movements versus Depth for Example 24 ............... 151 Figure 6-61 Results of Analysis for Example 24 ........................................................................ 151 Figure 6-62 Pile and Soil Profile for Verification of P-Delta Effect .......................................... 152 Figure 7-1 Comparison of Maximum Bending Moments from Computations and from Experimental Case Histories .................................................................................. 156 Figure 7-2 Comparison of Experimental and Computed Pile-head Deflections at Service Load ........................................................................................................................ 157 Figure 7-3 Influence of Number of Increments on Computed Values of Pile-head Deflection and Maximum Bending Moment .......................................................... 159 Figure 7-4 Plot of Mobilized Soil Resistance versus Depth ....................................................... 162 Figure 7-5 Verification of Pile Deflections ................................................................................ 164 Figure 7-6 Verification of Bending Moments ............................................................................ 165 Figure 7-7 Verification of Shear Forces ..................................................................................... 166

xv

List of Tables

Table 2-1 File Types and File Extensions..................................................................................... 14 Table 3-1 Mathematical Operators and Numerical Constants Used in LPile Input Dialogs ........ 21 Table 3-2 Recommended Ranges for Maximum Number of Iterations ....................................... 26 Table 6-1 Dimensions, Cross-sectional Area, and Bending Stiffness of Tapered Pile............... 144 Table 6-2 Interpolated Dimensional Properties, Cross-sectional Area, Moment of Inertia, Bending Moment of Tapered Pile Computed by LPile .......................................... 145 Table 7-1 Comparison of Bending Moments and Deflections from Computer Analyses and Experimental Case Histories .................................................................................. 155 Table 8-1 Key Words for Definition of Input Data .................................................................... 167 Table 8-2 Program Options and Settings .................................................................................... 168 Table 8-3 Pile Section Data ........................................................................................................ 169 Table 8-4 Properties for Rectangular Sections ........................................................................... 170 Table 8-5 Properties for Drilled Shafts ....................................................................................... 170 Table 8-6 Properties of Drilled Shafts with Casing .................................................................... 171 Table 8-7 Properties of Drilled Shafts with Casing and Core .................................................... 171 Table 8-8 Properties for Steel Pipe Piles .................................................................................... 171 Table 8-9 Properties for Circular Solid Prestressed Piles ........................................................... 172 Table 8-10 Properties for Circular Hollow Prestressed Piles ..................................................... 172 Table 8-11 Properties for Square Solid Prestressed Piles ........................................................... 172 Table 8-12 Properties for Square Hollow Prestressed Piles ....................................................... 172 Table 8-13 Properties for Octagonal Solid Prestressed Piles...................................................... 173 Table 8-14 Properties for Square Hollow Prestressed Piles ....................................................... 173 Table 8-15 Properties for Elastic Piles........................................................................................ 173 Table 8-16 Properties for Elastic Piles with Specified Moment Capacity.................................. 175 Table 8-17 Properties for Piles with Nonlinear Bending Properties........................................... 177 Table 8-18 Concrete Properties .................................................................................................. 177 Table 8-19 Reinforcing Steel Properties ..................................................................................... 177 Table 8-20 Prestressing Strand Properties .................................................................................. 178 Table 8-21 Soil Layer Properties ................................................................................................ 179 Table 8-22 Properties for Soft Clay ............................................................................................ 180 Table 8-23 Properties for API Soft Clay..................................................................................... 181 Table 8-24 Properties for Stiff Clay with Free Water................................................................. 181 Table 8-25 Properties for Stiff Clay without Free Water ........................................................... 181 Table 8-26 Properties for Stiff Clay with Free Water Using k ................................................... 182 Table 8-27 Properties for Sand ................................................................................................... 182 Table 8-28 Properties for API Sand ............................................................................................ 182 Table 8-29 Properties for Liquefied Sand ................................................................................... 183 Table 8-30 Properties for Liquefied Sand Hybrid Model ........................................................... 183 Table 8-31 Properties for Weak Rock ........................................................................................ 183 Table 8-32 Properties for Vuggy Limestone .............................................................................. 184 Table 8-33 Properties for Piedmont Residual Soil ..................................................................... 184 Table 8-34 Properties for Massive Rock .................................................................................... 184 xvi

Table 8-35 Properties for Loess .................................................................................................. 185 Table 8-36 Properties for Cemented Silt .................................................................................... 185 Table 8-37 Properties for Elastic Subgrade ................................................................................ 186 Table 8-38 Properties for -Input p-y Curves ....................................................................... 186 Table 8-39 Pile Batter and Ground Slope Properties .................................................................. 186 Table 8-40 Tip Shear Curve Properties ...................................................................................... 186 Table 8-41 Group Effect Properties ............................................................................................ 187 Table 8-42 LRFD Load Properties ............................................................................................. 187 Table 8-43 LRFD Load Factors and Loading Case Properties ................................................... 188 Table 8-44 Conventional Loading Properties ............................................................................. 188 Table 8-45 p-y Output Depth Properties ..................................................................................... 189 Table 8-46 Soil Movement Properties ........................................................................................ 189 Table 8-47 Axial Thrust Loads for EI Computations Only ........................................................ 189 Table 8-48 Foundation Stiffness Computations ......................................................................... 190 Table 8-49 Pushover Analysis Computations ............................................................................. 190 Table 8-50 Pile Buckling Analysis Data ..................................................................................... 191

xvii

Chapter 1 Introduction 1-1 General Description LPile is a special purpose program that can analyze a pile or drilled shaft under lateral loading. The program computes deflection, shear, bending moment, and soil response with respect to depth in nonlinear soils. The program has graphical features for presentation of results and has additional features for special analyses. The soil and rock is modeled using lateral load-transfer curves (p-y curves) based on published recommendations for various types of soils and rocks. The p-y curves are internally generated by the program. Alternatively, the can input values for p-y curves for a soil layer. The program also contains specialized procedures for computing p-y curves in layered soil profiles. Several types of pile-head loading conditions may be selected, and the structural properties of the pile may be varied along the pile length. Additionally, LPile can compute the nominal-moment capacity and provide design information for rebar arrangements.

1-2 Program Development History 1-2-1 LPile 1.0 for MS-DOS (1986) When the IBM XT® personal computer was introduced in 1984, Dr. Lymon C. Reese, the founder of Ensoft, Inc., foresaw the benefits and improvements in analysis and design of pile foundations from using improved computer software. The development of LPile for its first commercial distribution was begun in 1985 and was completed in 1986. The general theory and methodology of LPile 1.0 was similar in features to COM624, which was run on large mainframe computers. LPile was completely rewritten using a new solver and features were provided for interactive input. LPile was developed for analyzing single piles and drilled shafts under lateral loading. This version of LPile was compiled using the IBM Fortran compiler to run on the IBM XT personal computer. LPile Version 1.0 had the following features:     

The program could generate p-y curves internally for soft clay, stiff clay with free water, stiff clay without free water, and sand. The program also allowed s to input defined p-y curves for a selected layer. Modifications of the p-y curves for layered soils were introduced in the program based on the recommendations of Georgiadis (1983). A total of four boundary conditions and loading types were available for the pile head. Distributed loading could also be specified at any pile depth. An interactive input was provided for the to prepare the input data step-by-step. An analysis feature was provided for including tip-resistance curves.

1-2-2 LPile 2.0 for MS-DOS (1987) With the introduction of improved graphics hardware for personal computers such as color graphics monitors and an improved processor on IBM® AT-class computers, the features for graphical display of computed pile deflection, bending moment, shear, and soil resistance 1

Chapter 1 – Introduction became desirable for engineering software. LPile 2.0 was introduced in 1987 with a companion graphics program. Improvements were also made on the main program and input data editor. 1-2-3 LPile 3.0 for MS-DOS (1989) With the wide adoption of LPile by government agencies, universities, and engineering firms during the first three years, improvements in ease-of-use were considered essential. LPile 3.0 was introduced in 1989 with an input data editor featuring pull-down menus, input tables, and on-screen help commands. Color graphics for CGA, EGA, and VGA displays were added to the output graphics post-processor program. The main program also added the new technical features:   

New p-y criteria for vuggy limestone/rock. Options for modifying internally-generated p-y curves for group action effects. The pile head could be positioned either above or below the ground surface.

1-2-4 LPile 4.0 for MS-DOS (1993) LPile 4.0 was released in 1993, about four years after the previous upgrade. Features added to this version were:    

New p-y criteria for cemented soils whose strength is represented using both cohesion and friction angle. New p-y criteria for sand based on the recommendations of the American Petroleum Institute’s API-RP2A (1987). New p-y procedures for including the effect of sloping ground on p-y curves for clays and sands. New graphic plots for representing load versus deflection at the pile head and load versus maximum bending moment.

1-2-5 LPile Plus 1.0 for MS-DOS (1993) New technology for pile foundations enabled the incorporation of nonlinear properties for the pile’s flexural rigidity during analysis of their lateral deflections. Earlier, a companion computer program named STIFF was developed in 1987 to compute the relationship of applied moment versus flexural rigidity of a pile, and to compute the ultimate bending capacity for a specified structural section. LPile Plus was thus developed in 1993 by combining the capabilities of LPile 4.0 and STIFF. With the added functionality obtained from STIFF, LPile Plus had the capability to take into the flexural rigidity of uncracked and cracked sections, which led to a improved solution for the flexibility of a pile under lateral loading. 1-2-6 LPile Plus 1.0 for Windows (1994) The introduction of Windows 3.1 from Microsoft, Inc. as the new platform for personal computers pushed software development into a new era with a demand for -friendly features. LPile Plus 1.0 for Windows was released in 1994 with input preprocessor and output postprocessor developed specifically for the Windows operating system. 1-2-7 LPile Plus 2.0 for Windows (1995) The initial windows version for LPile Plus was released in 1994. The preprocessor program used a mouse with pull-down menu, dialog boxes, grid tables, and push buttons to improve the process of data entry. The graphics program, also running within the Windows 2

Chapter 1 – Introduction platform, ed any printer device recognized by the Windows environment. The main program added a feature for s to specify the rebar area at each location. 1-2-8 LPile Plus 3.0 for Windows (1997) With the 32-bit operating systems provided by Microsoft Windows 95 and Windows NT, software developers were provided with tools to develop interfaces with advanced, highresolution graphics. LPile Plus 3.0 was developed based on the technological advances for new interfaces. The significant new features of this upgrade are summarized as follows:   

A new soil criterion for weak rock was added to the previously existing eight soil types. The p-y criterion for weak rock is primarily applicable to the weathered sandstone, claystone, and limestone with uniaxial compressive strengths of less than 1,000 psi. An option was added to compute pile-head deflection versus pile length. This option generated a graph of pile length versus pile-head deflection that is helpful for determining the critical pile length. A feature was added to compute values for a foundation stiffness matrix that may be used in structural analysis models for a certain range of loads. In this new feature, the program creates curves of incremental loading versus foundation stiffness components K22, K23, K32, and K33, as shown in Figure 1-1. K33 K22

K11

Moment

M

K33 Rotation q

 K11 0  0 K 22   0 K 32

0   Q   x      K 23   H    y  K 33  M   q 

Figure 1-1 Pile-head Stiffness Components    

Improved features for file-management were also included to help the . The could use menu commands for data entry, computation, review of output, and display of graphics in a single computer program. Data could be input in either SI units or US customary units and existing data could be converted to the other system of units. All grid tables and entry fields for data entry were developed with functions that understand mathematics formulas and were aware of the current system of units. The graphical display of output curves features a new interface that provided the ability to zoom in on areas of particular interest. The may thus observe detailed behavioral measurements of any portion of the modeled pile.

3

Chapter 1 – Introduction 1-2-9 LPile Plus 3.0M (Soil Movement Version) for Windows (1998) An advanced version for LPile Plus was developed and was released in 1998 as Version 3.0M. The LPile Plus 3.0M software is the standard LPile Plus 3.0 version with the addition of two additional capabilities: 



The is able to input a profile of soil movements versus depth as additional loading on the pile. The soil movements of the soil may be produced from any action that causes soil movements, such as movements due to slope instability, lateral spreading during earthquakes, and seepage forces. Version 3.0M uses an alternative solver for the governing differential equation to for the lateral movement of the soils. The can input data for nonlinear curves of bending stiffness versus bending moment for different pile sections. This feature is useful for cases where the pile has different structural properties along its depth.

1-2-10 LPile Plus 4.0/4.0M for Windows (2000) LPile 4.0/4.0M was developed for compatibility with Windows NT, 95, 98, and 2000. Modules used for computations were compiled as dynamic link library functions, which significantly improved performance. The new features for this upgrade can be summarized as follows: 

    

The program has the capability to generate and take into nonlinear values of flexural stiffness (EI). These values are generated internally by the program based on cracked/uncracked concrete behavior and -specified pile dimensions, and material properties for reinforced concrete sections. The program adds a new feature for analyzing prestressed concrete sections in Version 4.0. The can specify both deflection and rotation at the pile as a new set of boundary conditions in Version 4.0. LPile Plus 4.0 can perform pushover analyses and analyze the pile behavior after a plastic hinge (yielding) develops. Soil-layer data structures and input dialogs are improved in Version 4 to help the enter data conveniently with default values provided. More than 100 error-checking messages are added into Version 4.0 Files opened recently will be listed under File Menu. New options for graphics title, legends and plot of rebar arrangement are incorporated into Version 4.0. New data and formats are added to the output file in Version 4.0

1-2-11 LPile Plus 5.0 for Windows (2004) LPile Plus 5.0 was developed to meet needs for more versatility. Two more p-y criteria were added into the program. The feature of specifying soil movement became a standard in the program. The can use a presentation graphics utility to prepare various engineering plots in high quality for presentations and reports. The new features for this version can be summarized as follows: 

Version 5 allows the to define multiple sections with nonlinear bending properties. This feature permits the designer to place reinforcing steel on sections of a drilled shaft as needed, depending on the computed values of bending moment and shear.

4

Chapter 1 – Introduction     

Version 5 allows the to enter externally computed moment vs. EI curves for multiple sections. Version 5 can analyze the behavior of piles subjected to free-field soil movement in lateral direction. Free field displacements are soil motions that may be induced by earthquake, nearby excavations, or induced by unstable soils. The p-y criteria for liquefiable sand developed by Rollins, et al. (2005a, 2005b), and p-y criteria for stiff clay with -specified initial k values, recommended by Brown (2002), were added into Version 5.0. The types and number of graphs generated by Version 5 have increased over previous versions. More importantly, the graphs may now be edited and modified by the in an almost unlimited number of ways. Many hints and notes were added into input windows to assist the in selecting proper data for each entry.

1-2-12 LPile 6 for Windows (2010) The procedures for computation of flexural rigidity (EI) of pile were completely rewritten and introduced for Version 6. The new procedures are more numerically robust and generally produce moment-curvature relationships that are smoother and, in the case of reinforced concrete sections, slightly stiffer and stronger. The input dialogs for structural sections now show the cross-section of the pile that updates to illustrate the current section data. The cross-section, number, and type of reinforcement are drawn to scale. The can specify either US customary units (pounds, inches, and feet) or SI units (kilonewtons, millimeters, and meters) for entering and displaying data. Most commonly used customary units such as lbs/ft2 for shear strength and lbs/ft3 for effective unit weight are used in Version 6.0. In general, units of inches or millimeters are used for cross-section dimensions, feet or meters are used for depth and length dimensions, and pounds or kilonewtons are used for force dimensions Twelve p-y criteria for different types of soil and rock are included in Version 6.0. The input dialogs for definition of soil properties have been improved to aid the . Default values for some input properties are provided. Hints and notes are also shown on input dialogs to assist the for data entry. Over 175 error and warning messages have been provided, making it easy for occasional s to run the program and to solve run-time errors. LPile Version 6 has the capability of performing analyses for Load and Resistance Factor Design. Up to 100 load combinations may be defined and up to 100 unfactored loads may be defined. Load case combinations are defined by entering the load factors for each load type and the resistance factors for both flexure and shear. Optionally, the may enter the load and resistance factor combinations by reading an external plain-text file. 1-2-13 LPile 2012 for Windows, Data Format 6 LPile is currently being sold with a software maintenance contract. s with active maintenance contracts may receive all updates and maintenance releases of LPile. In this system,

5

Chapter 1 – Introduction the use of version numbers has been modified to permit the to understand the basic differences between different releases of the program. The first number is the calendar year of the release of the program. The second number is the data file format version number. Thus, all versions of the program that have the same data file format number can exchange data files without modification. The third number in the version number is the release version of the program since the data file format number was introduced. The should recognize that while all versions of the program with the same data file format number are largely compatible with one another, that the later release numbers of the program will often have additional features that earlier releases may lack. Thus, all s are encouraged to use the latest version of the program. 1-2-14 LPile 2013 for Windows, Data Format 7 LPile 2013-7-01 introduced three analysis features to LPile. The first analysis feature was a modification of the controls used for pile-head stiffness matrix values to permit more choices by the over how the computations were controlled. The second analysis feature added was an automatic pushover analysis control that permitted the to perform pushover analyses using pile-head fixity options that were either free-head, fixed-head, or both for a range of pilehead displacements controlled by the . The third analysis feature was an automatic pile buckling analysis with options for different pile-head fixity conditions. Additional changes were made the -interface. More speed buttons were provides to enable quick access to input and editing of all types of data and for display of graphics. In addition, new features were provided to check the Internet for new versions of the software and to open the ’s Manual and Technical Manual. 1-2-15 LPile 2015 for Windows, Data Format 8 LPile 2015 introduced several new features, along with general improvements in the interface. The first analysis feature was the addition of  

  

The p-y curve for massive rock developed by Liang et al. (2009). Features to analyze multiple distributed loading profiles and multiple soil movement profiles defined for different load cases in conventional analysis. The original features to apply a single distributed load profile or a single soil movement profile to all cases were retained. The addition of input of a section’s shear capacity for evaluation in Load and Resistance Factor Design analysis. Soil layer profiles were added to all speed graphs displaying pile performance results versus depth. The ability to import load test data for pile-head shear versus lateral deflection and bending moment versus depth for comparison to computed results.

Changes to the interface included combination graphs of pile deflection, bending moment, and shear force versus depth and pile deflection, pile curvature, and bending moment versus depth, and modification of the existing graphs of soil movements versus depth to show multiple soil movement profiles.

6

Chapter 1 – Introduction 1-2-16 LPile 2016 for Windows, Data Format 9 LPile 2016 introduced several new features. These features include:   

The p-y curve for the hybrid model for liquefied sand developed by Franke and Rollins (2013). A feature to add additional sizes of reinforcing steel, including hollow bars and pipes. This feature is included under the Tools Menu. A feature for running a list of data files sequentially (also called batch run mode). This feature is included under the Tools Menu. The interface and program options and settings remain similar to those used in LPile

2015.

1-3 Technical Although LPile was programmed for ease of use and increased to the , some s may still have questions with regard to technical issues. The Ensoft technical staff recommends s to request technical via email. In all technical requests via email, please include the following information:    

Software version, including maintenance release number (obtained from the Help/About dialog), a description of the ’s problem or concern, attach a copy of input-data file (files with extension .lp9d) to the email, and name and telephone number of the person and of the ed (or name and office location of the ed company).

Although immediate answers are offered on most technical requests, please allow up to two business days for a response in case of difficulties or schedule conflicts. Technical help by means of direct calls to our local telephone number, (512) 244-6464, is available, but is limited to the business hours of 9 a.m. to 5 p.m. (US central time zone, UTC −6:00). The current policy of Ensoft is that all telephone calls for software will be answered free of charge if the has a valid maintenance contract. The maintenance is free of charge within the first year of the software purchase. One calendar year of maintenance is in effect for the first year after purchase. Annual maintenance policy and the invoice will be sent to the in advance before the maintenance contract expired. 1-3-1 Upgrade Notifications and Ensoft’s Website Subscriptions for software updates are available for a fee ( Ensoft for latest pricing). All s who are subscribed to the software update compact disk service and who keep their current address on file with Ensoft will receive update compact disks by mail quarterly when new versions become available. All s with active maintenance subscriptions may also obtain updates from Internet via the Ensoft website at http://www.ensoftinc.com, plus additional information on software updates, program demos, and new applications; technical news, and company information.

7

Chapter 1 – Introduction 1-3-2 Renewal of Program Maintenance The cost to renew program maintenance will depend on the length of time for which the program maintenance has been expired. The pricing policy for renewing program maintenance can be found on the Ensoft website at http://www.ensoftinc.com. 1-3-3 Changes of Policy The software policy and associated expenses are subject to change without notice, as many of the costs associated with technical are outside of Ensoft’s direct control. However, any change of policy will be provided during telephone calls for software .

8

Chapter 2 Installation and Getting Started 2-1 Installation and Computing Hardware Requirements LPile is distributed with a black USB security device. This method of distribution is compatible with Windows operating systems from Windows 95 through Windows Seven, has better capabilities over other alternatives, and allows s to obtain software updates or replacements via the Internet. Before installing, your personal computer should be equipped with the following:      

An open USB port At least 50MB of free space on the hard disk drive At least 2 GB of random access memory (RAM) At least 128 MB of video memory A monitor with a display resolution of 1,280 by 1,028 pixels or greater Windows 2000, Windows XP, Windows Vista, Windows 7, or Windows 8 operating systems with the latest service packs installed. While LPile is compiled as a 32-bit application, it is compatible with both 32-bit and 64-bit operating systems. To install the software from the distribution CD-ROM:

1. Insert the Ensoft USB security device into any open USB port. 2. Insert the compact disk from Ensoft. If the Autoplay disk feature is enabled, Windows will ask you if you want to run Setup.exe. If Autoplay is not enabled then from My Computer, double-click the drive into which the installation compact disk is inserted. 3. Select to install LPile, and then select on the radio button in the dialog shown in Figure 2-1 for “Single- License” if installing a single- version of the software or select “Network License” if installing a network version of the software. Note: if the wrong version for the license is selected and program installation is completed, it will be necessary to completely uninstall the software prior to re-installation for the correct license version 2-1-1 Single Version If your license is for a single-, select that option and click next. Follow the directions in the dialog boxes until the installation is completed. 2-1-2 Network Version At the following dialog shown in Figure 2-2, choose the appropriate option for either “Client Computer” or “Software Server.” Note that the “Server” version should be installed by the network while logged in with full istrative privileges enabled and must be installed only on one server computer. The USB security device must be plugged in to the software server after the software installation is completed, and the Server computer must be logged onto the network in order for “Client” s to access LPile.

9

Chapter 2 – Installation and Getting Started Follow the displayed instructions until the installation process is complete.

Figure 2-1 Options for Type of License Installation

Figure 2-2 Options for Type of Network Installation 2-1-3 Software Updates Ensoft will maintain the software, produce software improvements and/or fixes and place the latest software programs on Ensoft’s website. s with current maintenance contracts may the latest program update from http://www.ensoftinc.com. s are free for the during the maintenance contract period.

10

Chapter 2 – Installation and Getting Started 2-1-4 Installation of Software Updates LPile can display a query to check the Internet during program start up to see if there is a newer version of the program, as shown in Figure 2-3. The may turn off the automatic display of this query during program start up by checking the box labeled “Do not show this message again.” The may restore the setting to display this query automatically using the Program Options and Settings dialog.

Figure 2-3 Check for Update Query If the clicks Yes, LPile will start the default Internet browser on the computer, connect to the Internet, and check the current version of the program against the latest update version available for from www.ensoftinc.com.

2-2 Getting Started A flow chart showing the menu choices and features of LPile is presented in Figure 2-4. The following paragraphs provide a description of the program functions and will guide the in using the program. File Menu

Computation Menu

Data Menu

Help Menu

Tools Menu

Graphics Menu

Most menu commands are accessible via the button bar

Figure 2-4 Principal Operations of LPile Start the program by navigating to the shortcut in the start menu and clicking on it. The main program window will appear, as shown in Figure 2-5. You should see a program window with a toolbar at the top with the following choices: File, Data, Computation, Graphics, Tools, Window, and Help. A button bar is displayed under the menu bar that provides quick access to most of the features of LPile. 11

Chapter 2 – Installation and Getting Started

Figure 2-5 Main Window of LPile As a standard Windows feature, pressing Alt displays the menu operations with underlined letters. Pressing the underlined letter after pressing Alt is the same as clicking the operation. For example, to open a New File, the could press Alt-F, N, in sequence, Ctrl+N, or click File then New. Additionally, holding the mouse cursor over a button will show a help bubble that describes the button’s function. 2-2-1 File Menu and Buttons The File Menu shown in Figure 2-6 is used to control basic file operations for input data files. Most of these program functions are also available from the button bar by pressing the button with the identical icon.

Figure 2-6 File Menu A list of most-recently-used files is displayed in between Save As… and Exit.  

   

New: Create a new data file. Open…: Open an existing data file. If a partially completed LPile input file, or an invalid data file is opened, an information dialog reporting that an “invalid or incomplete” file is being opened. Clicking OK dismisses the message, and the previously saved data should be available. If a complete input file is loaded, an information dialog reporting that “Data File: (name of file), has been read by LPile” should appear, and the should click OK. Save: Save input data under the current file name. Save As…: Save input data under a different file name. Save LRFD Combos…: Save LRFD Combinations in separate data file (visible only when in LRFD mode) Exit: Exit the program. If the input file was modified but unsaved, a prompt will appear asking if the would like to save changes.

The group of four speed buttons at the left side of the button bar (shown in Figure 2-7) provide access to the New, Open, Save, and Save As commands.

12

Chapter 2 – Installation and Getting Started

Figure 2-7 File Speed Buttons 2-2-2 Data Menu and Buttons Please refer to Section 3-1 for a detailed discussion of this pull-down menu. The group of buttons shown in Figure 2-8 provides access to the data editing commands in the different modes of analysis.

(a) Buttons Available for Conventional Analysis

(b) Buttons Available for LRFD Analysis

(c) Buttons Available for Compute Nonlinear EI Only Analysis Figure 2-8 Speed Buttons for Data Input for Different Analysis Modes Four buttons are provided to review the input data in graphical form. The upper left button shown in Figure 2-9 displays the pile and soil layer profile and the lower left button presents a set of charts for reviewing the input soil and rock properties. The upper right button presents a graph of distributed lateral loading versus depth. The lower right button presents a three- graph of the p-modifier versus depth, y-modifier versus depth, and the ratio of pmodifier over y-modifier versus depth.

Figure 2-9 Input Data Review Buttons 2-2-3 Computation Menu and Buttons The Computation Menu shown in Figure 2-10 is provided to access commands to analyze the input data and to view the input and output report files generated during an analysis.

13

Chapter 2 – Installation and Getting Started

Figure 2-10 Computation Menu The Run Analysis Button shown in Figure 2-11 analyzes the current input data and the View Report button displays the current output report. Analyses can be performed successfully only after all data has been entered and saved. If the data has not been saved, LPile will prompt the to save the file. If the data file has been named, the existing data set will automatically be re-saved to disk prior to running an analysis.

Figure 2-11 Run Analysis and View Report Buttons 2-2-3-1 Run Analysis: The Run Analysis command processes the current input data. Analyses can be performed successfully only after all data has been entered and saved. If the data has not been saved, LPile will prompt the to save the file. If the data file has been named, the existing data set will automatically be re-saved to disk prior to running an analysis. The following files are produced by LPile: Table 2-1 File Types and File Extensions File Description

File Extension*

Input file for LPile

*.lp#d

Output report file

*.lp#o

Processor run notes file

*.lp#r

Graphics titles file

*.lp#t

LRFD load and resistance combinations

*.lrfd

Moment-curvature output files *.txt * Where # denotes the file format version number. All output files will be created in the same directory folder as the input file. If there are input or runtime errors during execution, appropriate error messages will appear in the dialog box. In most cases, the program will display information that explains the causes of error and suggest corrective actions. If the analysis is completed, but non-fatal warning messages for unusual situations warranting the attention of the are generated, the appropriate warning will be shown prior to displaying a summary graph of the analytical results. 14

Chapter 2 – Installation and Getting Started If no error or warning messages are generate, the summary graph of results will be displayed after the analysis is completed. 2-2-3-2 View Input Text: This command activates the -specified text editor to display the analytical input data in plain-text format. This command is available after the input data has been saved to disk, or when opening an existing input-data file. It is useful for experienced s who may just want to change quickly one or two parameters using the text editor, or for s wishing to observe the prepared input data in text mode. 2-2-3-3 View Processor Run Notes: The program begins each analysis by first saving the current data to disk, then starting the analysis routine that reads the input data from the saved disk file. If an error is detected, the program will display a message dialog that informs the about the type of error and, in many cases, will suggest a solution for the error. Input errors may consist of missing data, erroneous data, or inconsistent data. Usually, the content of the error message dialog is copied to the processor run notes file. If the processor-run notes end without listing the line “The Execution is in progress…,” the should check the input corresponding to the last line read and the line that immediately follows (that was not read). In some cases, the processor-run notes will also include an error message. 2-2-3-4 View Output Report: This command opens the output report in the text editor. This command becomes available only after a successful run has been made. Some output files may be too large for Microsoft Notepad to handle, so other text editors (Microsoft WordPad, for example) might need to be used. Often, some versions of Microsoft Windows will automatically switch to the alternative program without intervention by the . Output report files usually contain the following information: 1. Authorized name, company, and security device serial number information. 2. The date and time of the analysis. 3. When nonlinear bending sections are part of the data, the output will contain results of computations of nominal bending moment capacity and nonlinear moment curvature, including bending stiffness as a function of axial thrust force, including a report of the input data as well as tables of the computational results. 4. A report of input data for pile analysis. s are strongly recommended to check this report of input data for mistakes. 5. If selected, reports for selected p-y curves at -specified output depths. 6. Tables of computed values of deflection, bending moment, shear, soil resistance, and related information, as a function of depth for the pile. 7. Reports of convergence performance of the finite-difference approximations, providing data about the maximum moment and lateral force imbalances observed during execution (maximum imbalances should usually consist of small numbers). 8. Summary tables, containing information about the results and number of iterations performed until convergence was reached. 9. An optional summary table of pile-head deflection versus pile length. 10. An optional summary table of foundation stiffness matrix components. 15

Chapter 2 – Installation and Getting Started 2-2-4 Graphics Menu and Buttons Please refer Chapter 4 of this manual for a detailed discussion of the Graphics Menu. The group of buttons shown in Figure 2-12 provides access to the graphs generated by LPile. The enabling of buttons depends on the options selected and the output generated in the analysis.

Figure 2-12 Graphics Buttons 2-2-5 Tools Menu The Tools Menu has the five entries shown in Figure 2-13.

Figure 2-13 Tools Menu The first entry provides a simple calculator for the ’s convenience. The second entry provides a special calculator to compute axial and transverse forces acting on battered piles from horizontal and vertical loadings. The third to fifth entries provide a means of entering addition sizes of reinforcing steel bar sizes to LPile. Note that this feature provides a means of entering hollow bars and steel access tubes. The third entry displays an input table to enter and edit the data for the custom reinforcing bar sizes. The fourth entry will transfer the data for custom reinforcing bars into the memory of LPile and enter the names of the bars into the drop-down combination edit controls for selection of the size of reinforcing bars. Note that the custom bar sizes are at the bottom of the drop-down lists for bar sizes available for normally reinforced concrete sections. The fifth entry saves the custom bar sizes to a data file named Custom_Rebar.dat. This data file is stored in the same program folder as the main LPile program. When LPile is started, LPile checks the program folder for a file with this name. If the file is found, it is read and the data is stored into program memory. Thus, it is not necessary for the to re-enter the custom bar data each time the program is run. Whenever the wishes to exchange data files with another , the data file for custom bar sizes should also be provided to the other , as the list of custom bar sizes is not included as part of the LPile data file. 16

Chapter 2 – Installation and Getting Started The sixth entry provides a feature to define a list of existing LPile data files to be run as a batch and the command to perform the batch analysis. This feature is discussed in more detail in the chapter on the Tools Menu. 2-2-6 Window Menu The Cascade command on the Windows Menu organizes all open windows so that they are all visible. 2-2-7 Help Menu The Help Menu provides commands to view the manuals for LPile, descriptions of messages, information on technical , and program updates to LPile. The Help pull-down menu is shown in Figure 2-14. Descriptions of the pull-down menu commands are described in the following sections.

Figure 2-14 Help Menu 2-2-7-1 Contents: The on-line help system is accessed through this command. 2-2-7-2 LPile Manuals This command opens a side menu to commands to view the ’s Manual and Technical Manual for LPile. These manuals can also be opened from the Windows Start Menu. 2-2-7-3 List of Input Error Messages This command opens a dialog that lists the input error messages generated by LPile. The full list of input error messages is listed in Appendix 1. 2-2-7-4 List of Runtime Error Messages This command opens a dialog that lists the runtime error messages generated by LPile. The full list of runtime error messages is listed in Appendix 2. 2-2-7-5 List of Warning Messages This command opens a dialog that lists the warning messages generated by LPile. Note that when warning message are displayed computations can be performed by LPile, but that the results of the computations may be in error due to input values that may not be appropriate. The

17

Chapter 2 – Installation and Getting Started purpose of the warning messages is to call the ’s attention to input values that may not be correct. The full list of warning messages is listed in Appendix 3. 2-2-7-6 About the Version Numbers Displays information about how the version numbers current used for LPile are defined. 2-2-7-7 Technical Information Displays information about eligibility for receiving technical and how to receive technical from Ensoft. 2-2-7-8 Check for Updates Opens the LPile update page in the ’s default browser. Note that some anti-virus programs may require the to grant permission to LPile to open the Internet browser program. 2-2-7-9 About LPile This command provides a dialog describing the program version, date, and methods for accessing technical . Other information about the program licensing and maintenance expiration date, program version, and program release date are also shown. An example is shown below.

18

Chapter 2 – Installation and Getting Started

Figure 2-15 Example of About LPile Dialog

19

Chapter 3 Input of Data The input of required data for an analysis is controlled by the options chosen in the Program Options and Settings dialog. It is recommended that the select and enter data in a progressive manner, starting from the top of the Data Menu. Most Windows may optionally be left open on the screen. The selection of other menu commands will then open additional windows on top of those that were left open. Many of the input dialogs will have buttons to add, delete, or insert rows for data. The Add Row button always adds a new row to the end of all existing rows, and the Delete Row button deletes the row where the cursor is currently located. All entry cells that require numeric data may accept mathematical expressions as entries. In general, one may enter numerical expressions in the same manner as most spreadsheet programs allow, but one must omit the leading equal sign. Entering a mathematical expression works similarly to entering normal numeric data; the simply types the expression then presses the “Enter” key. A list of ed operations and numerical constants are shown in Table 3-1, along with the order of precedence of operations. Implicit mathematical operations using constants is not inferred. Instead, the must enter an expression with an operator, e.g. 2*pi instead of 2pi. Negation of the constants  or e is not allowed directly, but these constants may be bracketed by parentheses. For instance, instead of entering –pi the must enter (pi). Scientific notation is inferred by the program if “e” or “E” is immediately following by a number (e.g. 29e6 or 0.5e5) for input of large or small numbers. After an expression is evaluated, the computed numbers will be displayed using standard numerical notation. Table 3-1 Mathematical Operators and Numerical Constants Used in LPile Input Dialogs Mathematical Operator (listed in order of precedence

Description

()

Parenthesis (may be nested)

^

Exponentiation

*

Multiplication

/

Division

+

Addition

–

Subtraction/Negation

Mathematical Constant

Value

pi ()

3.14159265358979324…

e (base of natural logarithms)

2.71828182845904524…

21

Chapter 3 – Input of Data

3-1 Data Menu The editing commands are presented on the Data Menu shown in Figure 3-1. The commands in the upper three sections of the Data Menu are enabled by default when LPile is started. The commands in the bottom section of the Data Menu are enabled by activation of the relevant program options.

Figure 3-1 Data Menu The icons shown in the Data Menu are the same as those used to access the same editing dialogs via the button bar.

3-2 Speed Buttons for Data Entry The button bar contains a set of buttons to open the dialogs for the entry and manipulation of data. The buttons for data entry for conventional analysis are shown in Figure 3-2, for Computation of EI only are shown in Figure 3-3, and for LRFD Analysis are shown in Figure 3-4.

Figure 3-2 Buttons for Data Entry and Manipulation for Conventional Analysis

22

Chapter 3 – Input of Data

Figure 3-3 Buttons for Data Entry and Manipulation for Computation of Nonlinear EI Only

Figure 3-4 Buttons for Data Entry and Manipulation for LRFD Analysis

3-3 Project Information Dialog The Project Information dialog, shown in Figure 3-5, is used to enter identifying information for the current analysis. Entry of Project Information is optional. Five lines of information can be entered. Default prompts for project, job number, client, engineer’s name, and description are provided, but may be over-written with any information provided by the . Also shown in the dialog is additional information on file path, input and output filenames, date and time of analysis that is routinely written in the output report file.

Figure 3-5 Example of Project Information Input Dialog

3-4 Program Options and Settings Dialog Almost all program options have been consolidated into a single input dialog box. Two options not included in this dialog are the option to enter distributed lateral loading for conventional analysis and the option to compute top deflection versus pile length for individual load cases for conventional analysis. 23

Chapter 3 – Input of Data The Program Options and Settings dialog is used by the to select options and settings for each set of data being analyzed by LPile. This input dialog provides options that are grouped into Computational Options, Engineering Units Options, Analysis-Control Options, Output options, Loading Options, and Text Viewer Options. There are default settings provided if the does not have any desire to make a change. The should to click the OK button in order to save the accepted selections; otherwise, the selections will not be stored when the dialog is closed. 3-4-1 Computational Options There are twelve computational options displayed in the upper left corner of the Program Options and Settings dialog shown in Figure 3-6. These options are:

Figure 3-6 Program Options and Settings Dialog

These options are:  Use Conventional Analysis If checked, LPile permits input of up to 100 load cases for various pile-head loading and displacement conditions. When conventional analysis is selected, the additional options for distributed lateral loading and loading by soil movement, computation of pile head stiffness, push-over analysis, and pile buckling analysis become active. 24

Chapter 3 – Input of Data  Use Load and Resistance Factors If checked, LPile will perform Load and Resistance Factor Design (LRFD) computations. In this mode, the may enter up to 100 unfactored shear and moment loads of various loading types (dead load, live load, etc.). All loads are assumed to be for shear and moment pile-head loading conditions. The program will then add all loads of the same load type to obtain the total unfactored load for each loading type. Optionally, the LRFD case load combinations may be either read from or saved to an external file (with the file type of lrfd) or may be entered by the .  Compute Nonlinear EI Only If checked, LPile will compute nonlinear moment-curvature relations and nominal (unfactored) and ultimate (factored) moment capacities of the pile sections for the specified axial thrust force values.  Include Modification Factors for Group Action: Activates p-y Modification Factors for Group Action under the Data Menu.  Include Shearing Resistance at Pile Tip: Activates Shear Resistance Curve at Pile-Tip under the Data Menu. The following options become active only when using conventional analysis.     

Use loading by single distributed lateral loading profile Use separate distributed loading profiles per load case Use loading by single soil movement profile. Use separate soil movement profiles per load case. Compute Pile-Head Stiffness Matrix Values If this option is selected, LPile computes the pile-head stiffness matrix values according to the control values set by the in the Controls for Computation of Stiffness Matrix dialog discussed in Section 3-12-4.  Compute pushover analysis If this option is selected, LPile computes the pushover analysis according to the controls set by the use in the Controls for Pushover Analysis dialog discussed in Section 3-12-5.  Compute pile buckling analysis If this option is selected, LPile computes the pile-buckling analysis according to the controls set by the in the Controls for Pile Buckling analysis discussed in Section 312-6. 3-4-2 Engineering Units of Input Data and Computations Here the can specify either US Customary System (USCS) units using pounds, inches, and feet or the International System of Units (Système international d’unités or SI) units using millimeters, meters, and kilonewtons for entering and displaying data. The prior setting for engineering units is ed by the program. Thus, when LPile is started, the default units are the engineering units used in the prior analysis. If a data file is read by LPile, the engineering units are switched to the units specified in the data file. All input data is converted to consistent units of length and force before computations are made. The consistent units are either pounds and inches or kilonewtons and meters.

25

Chapter 3 – Input of Data 3-4-3 Analysis Control Options The Analysis Control Options are used to specify the number of pile increments, the maximum number of iterations, the convergence tolerance on deflections, the limit on excessive deflection of the pile head, and the number of pile increments. 3-4-3-1 Number of Pile Increments The quality of the finite-difference numerical solution obtained by LPile is proportional to the square of the length of the pile increment. The length of the pile increment is computed by dividing the length of the pile by the number of pile increments. The error in the solution computed by LPile is defined as the difference between the approximation and the exact analytical solution. The two sources of error in finite difference methods are round-off error, the loss of precision due to computer rounding of decimal quantities, and truncation error or discretization error, the difference between the exact solution of the finite difference equation and the exact quantity assuming perfect arithmetic (that is, assuming no round-off error). The default number of pile increments is 100, the minimum number of pile increments is 40, and maximum number of pile increments is 500. Often the may opt to use an odd number of increments to obtain computed results at specific rounded valued of depth. For example, a may opt to use 140 increments to obtain results for every 0.5 feet of depth for a 70-ft-long pile. 3-4-3-2 Maximum Number of Iterations The maximum number of iterations performed by the program for the pile solution can be set by the . Many problems will converge in fewer than 50 iterations unless a plastic hinge is being developed in an analysis using nonlinear EI. If a pushover analysis is being performed using the displacement and moment pile-head boundary condition, the iterations limit should be set to the maximum value of 1,000 iterations to allow plastic hinges to develop in the pile. Table 3-2 Recommended Ranges for Maximum Number of Iterations Recommended

500 to 750

Lower Limit

100

Upper Limit:

1,000

The should be aware that specifying 1,000 iterations has a special feature. If the problem is solved using fewer than 1,000 iterations, the solution has met the convergence tolerance and excessive deflection criteria. However, if the program reached the limit of 1,000 iterations, the program is highly unlikely to obtain convergence. Instead, the program outputs the last iterative solution obtained and the solution stops. 3-4-3-3 Convergence Tolerance The value entered for convergence tolerance is used to stop an analysis when the absolute value of the change in deflection of every nodal point on the pile is less than the convergence 26

Chapter 3 – Input of Data tolerance. The default value for convergence tolerance is 0.00001 inches or 2.54×10–7 meters. Using a smaller value for convergence tolerance usually does not improve the quality of the solution and in some conditions may result in failure to obtain a solution. Using a larger convergence tolerance is sometimes required, but the should cautious when using values larger the 0.0001 inches or 2.54×10–6 meters. 3-4-3-4 Limit on Excessive Lateral Pile Deflection The limit on excessive lateral pile deflection is used to end analyses in which the iterative solution is diverging without limit. The should enter a value of deflection for the pile head that is grossly excessive to stop the analysis. The default value is 100 inches or 2.54 meters. If the wished to modify this value, a recommended value is 10 times the pile diameter. Lowering the Excessive Deflection Value to less than 100 inches or 2.54 meters is not recommended. 3-4-4 Loading Type and Number of Cycles of Loading The can specify either static or cyclic loading in the option group for Loading Type and Number of Cycles of Loading. Selection of type of loading is important when analyzing piles under lateral forces. Further information on the influence of loading type is included in the Technical Manual. In general, cyclic loading is primarily used for low frequency, large amplitude storm wave or wind loads. Dynamic loading from earthquakes and machine vibrations are not the same as cyclic loads considered in LPile. When cyclic loading is selected, the must also specify the number of cycles of loading, ranging from 2 to 5,000 cycles. The effect of cyclic loading is to change how the soil resistance is computed for the p-y curves, as described in the Technical Manual. Dynamic loading from earthquakes can be analyzed by LPile if equivalent pseudo-static loads are input. Pseudo-static loads are sized in a manner that results in computed moments and deflections that roughly equivalent to those developed during seismic loading events. Dynamic loading from machine vibrations or most other sources of harmonic loading should not be analyzed using LPile because LPile is not capable of determining the frequency response of the foundation and other inertial effects. Instead, the is directed to the use of the DynaN, DynaPile, or DynaMat programs from Ensoft or some other program for performing dynamic response analyses. 3-4-5 Output Options Several options are provided to control the output reports generated during LPile analyses. These options are enabled by checking the check boxes described below. 3-4-5-1 Generate p-y Curves at -Specified Depths Checking activates the feature to output p-y curves at the depths specified by the . Note that for battered piles, the specified depth is the vertical depth below the pile head, not the distance along the axis of the pile.

27

Chapter 3 – Input of Data 3-4-5-2 Print Summary Tables Only Checking this option activates the printing of summary tables only for computations of pile bending stiffness and pile response. 3-4-5-3 Printing Increment The may also specify the output increment for where results will be printed in the table of output. As a default, results are printed at every finite increment of pile length. This option is disabled if the has a check mark on the Only Print Summary Tables option. A value of 1 prints the values at every node; 2 prints values at every other nodes, etc. Note that the printing increment is used only for the generation of the output report, but not for the generation of output graphs. 3-4-5-4 Use Narrow Output Report Format This option controls the printed width of the output reports, permitting printing on lettersize paper without word wrapping of long lines. It is necessary to specify a fixed-pitch font of 10 point or smaller size to display the output correctly. The should be aware that only the most important columns of output results are displayed when this option is selected. 3-4-6 Text Viewer Options The should enter the complete path and command line for their preferred text editor or word processor. As a default, the command line c:\windows\notepad.exe sets Microsoft Notepad as the default text editor. An internal text editor can also be selected. The selected text editor will be used for View Input Text File, View Processor Run Notes, View Output Text File, and Text Viewer under the Computation Menu. 3-4-7 Input of Data from Load Testing It is possible to enter and save load test data input into LPile and to display the load test data along with the results computed by LPile on the graphs of pile-head shear force versus pilehead deflection and bending moment versus depth. The ability to enter and save load test data is enabled by checking this option. 3-4-8 Internet Update Notice Query Checking the Show Internet Update Notice Query on Program Startup restores the automatic display of this query dialog if this option has been turned off.

3-5 Structural Dimensions and Material Properties 3-5-1 General Description of Input LPile has features to evaluate the nominal moment capacity and nonlinear bending stiffness relationships for deep foundations made from normally-reinforced concrete, pipe sections, and prestressed concrete. These features can determine how the effective bending stiffness will vary as the concrete cracks in tension and the reinforcing steel yields. Use of the features to evaluate ultimate moment capacity and nonlinear bending stiffness is essential when analyzing the behavior of drilled shafts under lateral loading. The must click the OK button in order to save the accepted selections; otherwise, the selections will not be saved when the input dialog is closed. 28

Chapter 3 – Input of Data 3-5-2 Section Type and Shape The tab page for Section Type and Shape is shown in Figure 3-7. There are 14 general types of sections and a pile may have up to 20 different sections of different section types. The default section type is an elastic (non-yielding) section. All other section types have either specified or computed structural moment capacities and will have non-linear moment-curvature relationships. The dialog box shown in Figure 3-7 is for an H-pile defined as an elastic section, after definition of the structural shape. Once the section shape and dimensions have been properly defined, a scale drawing of the section or section profile is displayed, as shown below. The should note the tab pages shown in the input dialog. For an elastic section, only two tabs are shown. For other types of sections, the number of tab pages shown will depend on the types of materials used in the section type selected. The light yellow memo shown below the tab pages gives a general description of the section type and may provide special guidance in its use and construction.

Figure 3-7 Pile Section, Section Type Tab 3-5-3 Warning and Design Error Messages LPile provides warning messages and advice for design for several of the structural types. The purpose for these warning messages is to alert the either to design geometries that may be difficult to construct and to alert the if inappropriate design parameters have been specified by the . A short discussion of several types of the warning messages follows.

29

Chapter 3 – Input of Data 3-5-3-1 Spacing of Reinforcement Warning and design error messages are displayed for the drilled shaft sections when the spacing between reinforcing bars is less than five times the size of the coarse aggregate specified by the . If the spacing is smaller than this limit, the likelihood of the occurrence of voids in the concrete is increased due to the inability of the fluid concrete to flow around the bars. 3-5-3-2 Percentage of Reinforcement Design error messages are displayed for the drilled shaft sections when the percentage of axial reinforcement is either less than 0.5 percent or greater than 8 percent. Warning messages will be displayed if the percentage of axial reinforcement is between 0.5 and 0.95 percent. The lower limits for axial reinforcement are discussed on page 362 of O’Neill and Reese (1999). In cases where the moments and shear forces developed in the shaft are very small (i.e. deep in long shafts), the minimum steel percentage can be less than 1 percent. Section 10.9.1 of ACI 318 states that the minimum area of longitudinal stress must not be less than 1 percent of the gross concrete area. However, if the cross-section is larger than that required by consideration of structural resistance, then Section 10.8.4 of ACI 318 allows a reduced effective area not less than one half of the total area to be used to determine the minimum reinforcement and design strength. This criterion can be used in many cases where drilled shafts are designed with large diameters in order to develop large enough geotechnical side and base resistance in soils and some soft rocks. The upper limit of 8 percent reinforcement is not attainable in all shaft sizes. From a practical perspective, it is necessary to use bundled bar arrangements to attain reinforcement ratios greater than 4.5 percent in many shaft diameters. 3-5-3-3 Level of Prestressing After Losses LPile is capable of computing the level of prestress after losses for prestressed sections. LPile will display design error messages if the prestress after losses is less than 600 psi or more than 1,200 psi. Note that the value of prestress after losses depends on the types of piles available and generally cannot be specified ahead of time by the design engineer, so it is imperative that the design engineer obtain this information from the pile supplier. 3-5-4 Elastic Sections Elastic sections require input for the section length in feet or meters, section shape (rectangular, circular, pipe, strong or weak H-pile, or embedded circular pole), sectional dimensions in inches or millimeters at the top and bottom of the section, and the modulus of elasticity in psi or kPa for the full section. Six cross-sectional shapes are available for elastic sections. These shapes are:      

Rectangular shape defined by the width and depth of section at top and bottom of section. Circular shape without void defined by diameter at top and bottom of section. Pipe shape defined by outer diameter and wall thickness at top and bottom of section. Strong H-pile shape (web perpendicular to neutral axis). Weak H-pile shape (web aligned with neutral axis). Embedded pile defined by diameter of drilled hole and bending properties of the embedded pole. 30

Chapter 3 – Input of Data The rectangular, circular and pipe sections may be tapered with depth. The H-pile sections and embedded pole sections cannot be tapered with depth. In the case of tapered sections, the section dimensions at top and bottom of section are check to determine if the section is tapered or not. If the section is tapered, values of crosssectional area and moment of inertia are recomputed from the cross-sectional dimensions interpolated with depth and the input values for cross-sectional area and moment of inertia are ignored. If the section is not tapered, the input values for cross-sectional area and moment of inertia are used in computations. In the case of the embedded pole section, the p-y curves are computed using the diameter of the drilled hole and the bending stiffness is defined by the properties of the embedded pole. In general, it is advised that the embedded pole option be used only if the backfill placed around the pile has a shear strength that is more than ten times the shear strength of the surrounding soil profile. The purpose of the input is to define the bending stiffness of the pile. LPile is capable of computing the moment of inertia at each nodal point in the section from the structural dimensions interpolated over the length of the pile. Thus, for many tapered sections the moment of inertia varies nonlinearly with depth. The elastic sections are the only type of section that does not have a defined moment capacity. As such, elastic sections are often used when it is desired to determine the lateral geotechnical capacity of the soil profile. In such cases, it is best to model the loading of the pile using the pushover analysis feature discussed in Section 3-12-5. 3-5-5 Elastic Sections with Specified Moment Capacity The elastic section with specified moment capacity is similar to the elastic section, with the additional feature of a specified moment capacity. The resulting moment versus curvature relation is elastic-plastic, so if the moment in the pile does not reach the moment capacity, the results of computations will be the same as for an elastic section with the same dimensional properties. The rectangular, circular and pipe sections may be tapered with depth. The H-pile sections and embedded pole sections cannot be tapered with depth. In the case of tapered sections, the section dimensions at top and bottom of section are check to determine if the section is tapered or not. If the section is tapered, values of crosssectional area and moment of inertia are recomputed from the cross-sectional dimensions interpolated with depth and the input values for cross-sectional area and moment of inertia are ignored. If the section is not tapered, the input values for cross-sectional area and moment of inertia are used in computations. In the case of tapered elastic sections with specified moment capacity, the assumption is made that the yield stress of the pile material is uniform over the length of the section. The yield stress of the pile material is computed from the specified moment capacity at the top of the section and is used to compute the plastic moment capacity along the length of the section. 3-5-6 Rectangular Concrete Piles The bending stiffness and nominal moment capacity of the section are computed using the methods discussed in Chapter 5 of the LPile Technical Manual. 31

Chapter 3 – Input of Data The properties for the rectangular concrete pile are defined by the length, width, and depth of section; the compressive strength of concrete; and the number, positions, yield stress, and modulus of elasticity of the reinforcing steel bars. The tab pages for this data are shown in Figure 3-8 through Figure 3-10.

Figure 3-8 Dimensions Tab Page for Rectangular Concrete Section

Figure 3-9 Concrete Tab Page for Rectangular Concrete Section The positions of the reinforcing steel bars are defined using an x-y coordinate system with the origin positioned at the centroid of the section. The must enter the positions of the bars and must select the size of bars from the available sizes programmed in LPile. The rebar layout table is shown in Figure 3-11. Once the position and size of reinforcing steel has been entered, LPile will display a scale drawing of the section as shown in Figure 3-12.

32

Chapter 3 – Input of Data

Figure 3-10 Rebars Tab Page for Rectangular Concrete Section

Figure 3-11 Rebar Layout Table for Rectangular Concrete Section

33

Chapter 3 – Input of Data

Figure 3-12 Section Type, Dimensions, and Cross-section Properties Dialog for Rectangular Concrete Section Showing Rebar Layout After Definition 3-5-7 Round Concrete Shafts (Bored Piles) The properties of drilled shafts (also called bored piles) are defined by the length and outer diameter of the shaft; the number, positions, yield stress, and modulus of elasticity of the reinforcing steel bars; and the compressive strength of concrete. Features are provided in LPile to compute the positions of circular bar arrangements with single-bar, two-bar, and three-bar bundles utilizing the clear cover dimension and any offset of the bar cage from the shaft center. In addition, the position and size of bars can be manually edited if desired. The dialog shown in Figure 3-13 is an example of the Section Type page after the Round Concrete Shaft (Bored Pile) option has been selected. This drawing of the cross-section shows the current size, number, bundling, and positions of the reinforcing bars selected. The Shaft Dimensions tab page shows the shaft dimensions. All data entry cells for which input is not required are disabled. In the case of a round concrete shaft, the only required dimensions are the section length in feet or meters and diameter in inches or millimeters. The Concrete tab page, shown before in Figure 3-9, shows the compressive strength of concrete and the maximum size of coarse aggregate. The maximum size of coarse aggregate is used when LPile checks the spacing dimension between bars to ensure that sufficient space is provided for the concrete to flow during placement of concrete.

34

Chapter 3 – Input of Data

Figure 3-13 Tab Sheet for Selection of Section Type Showing Current Cross-section The layout of reinforcement is defined by specifying the size of reinforcement, number of bars, bar bundle size, concrete cover thickness, and offset of the reinforcement cage from the centroid (if any) as shown in Figure 3-14. The drawing of the cross-section automatically updates to indicate any changes in the geometric properties of the reinforcing bars. When entering data for the arrangement of reinforcing steel, the ’s attention is drawn to the advice of the comment note in the lower third of the dialog shown above. It is important for the designer to anticipate whether or not temporary casing is used. When temporary casing is used in construction, best design practice is to specify a concrete cover thickness of 4 inches (100 mm) so that standard size shaft spacers (typically 3 inches or 75 mm) can be used to center the reinforcing steel inside the temporary casing. After concrete is placed and the temporary casing is removed, the concrete in the shaft will flow outward to fill the volume left by the casing and the annular space outside of the casing.

35

Chapter 3 – Input of Data

Figure 3-14 Tab Sheet for Reinforcing Bar Properties 3-5-8 Round Concrete Shaft with Permanent Casing The properties of round concrete drilled shafts with permanent casing are defined by the length and outer diameter of the casing; the wall thickness of the casing; the yield stress and modulus of elasticity of the casing; the number, positions, yield stress, and modulus of elasticity of the reinforcing steel bars; and the compressive strength of concrete. The Dimensions tab page, shown in Figure 3-15 shows the dimensions for the outer diameter and wall thickness of the permanent casing. The drawing of the cross-section will automatically update to show any changes in the shaft geometric properties for casing or reinforcing bars.

36

Chapter 3 – Input of Data

Figure 3-15 Tab Sheet for Shaft Dimensions for Drilled Shaft with Permanent Casing The tab page for reinforcement is similar to that used for drilled shafts, except that the label for the entry cell for concrete cover has be modified to indicate that the cover dimension is measured inside the permanent casing as shown in Figure 3-16.

Figure 3-16 Tab Sheet for Rebars for Drilled Shaft with Permanent Casing The tab page for casing material properties, shown in Figure 3-17, is visible only for the drilled shaft sections that utilize permanent casing. The material properties required for permanent casing are the yield stress and modulus of elasticity.

37

Chapter 3 – Input of Data

Figure 3-17 Tab Sheet for Casing Material Properties for Drilled Shaft with Permanent Casing 3-5-9 Round Concrete Shaft with Permanent Casing and Core The properties of round concrete drilled shafts with permanent casing and core are defined by:     

the length and outer diameter of the casing; the wall thicknesses of the casing and core; the yield stress and modulus of elasticity of the casing and core; the number, positions, yield stress, and modulus of elasticity of the reinforcing steel bars; and the compressive strength of concrete.

In addition, the may specify if the core is filled with concrete by checking the box on the casing and core materials tab page. The Shaft Dimensions tab page for a drilled shaft with casing and core is shown in Figure 3-18. The drawing of the cross-section will automatically update to show any changes in the shaft geometric properties for casing, core, or reinforcing bars. The values entered for the wall thickness values of the casing and core may be zero to model a shaft without a casing or core. This feature enables one to model a drilled shaft with a structural steel insert. This is done by entering a set of core diameter and wall thickness that has a moment of inertia equal to that for the structural steel insert. The values entered for the wall thickness values of the casing and core may be zero to model a shaft without a casing or core. This feature enables one to model a drilled shaft with a structural steel insert. This is done by entering a set of core diameter and wall thickness that has a moment of inertia equal to that for the structural steel insert.

38

Chapter 3 – Input of Data

Figure 3-18 Tab Sheet forShaft Dimensions of Drilled Shaft with Casing and Core An example of the computation of an equivalent wall thickness is as follows. Suppose that a 14x89 H-pile is being used as a structural insert. The flange width is 14.7 inches and the moment of inertia is 904 in4. The equivalent wall thickness of a pipe section of the same width and moment of inertia is

t

d o  4 d o4  2

64 I



14.7  4 14.7 4  

2

(64)(904)



 0.866 in.

The moment of inertia will be computed as a check on the computation for t. A check computation yields a result of 903.90 in4, which is acceptable because a closer match would have required more significant digits for t. The tab page for material properties of the casing and core is shown in Figure 3-19. Also shown on this tab page is the check box to indicate if the core is filled or unfilled with concrete.

39

Chapter 3 – Input of Data

Figure 3-19 Tab Sheet for Casing and Core Material Properties In most problems, the influence of the concrete inside the core has little effect on the computed bending stiffness, but may have a noticeable effect on the computed axial compressive structural capacity of the section. The tab page for rebar is identical to that shown for drilled shaft with permanent casing. It is not necessary to include reinforcing bars when modeling a section with a structural insert. To omit the bars, enter zero for the number of bars. 3-5-10 Steel Pipe Pile The properties of steel pipe piles are defined by the length, outside diameter, and wall thickness of the pile section as shown in Figure 3-20. The material properties are the yield stress and modulus of elasticity as shown in Figure 3-21. The computed curve of moment versus curvature for a steel pipe pile is shown in Figure 3-22(a). Alternatively, a steel pile section could be modelled as an elastic-plastic section. However, the development of plastic yielding across the cross-section will not be modelled and the utilized moment versus curvature relationship is bilinear as shown in Figure 3-22(b).

40

Chapter 3 – Input of Data

Figure 3-20 Dimensions Tab Page for Steel Pipe Piles

Figure 3-21 Pipe-Casing-Core Properties Tab Page for Steel Pipe Pile

41

Chapter 3 – Input of Data

6,500 6,000 5,500

Moment, in-kips

5,000 4,500 4,000 3,500 3,000 2,500 2,000 1,500 1,000 500 0 0.0

0.0002

0.0004

0.0006

Curvature, radians/inch LPile 2015.8.03, © 2015 by Ensoft, Inc.

(a) 6,500 6,000 5,500

Moment, in-kips

5,000 4,500 4,000 3,500 3,000 2,500 2,000 1,500 1,000 500 0 0.0

0.0002

0.0004

0.0006

Curvature, radians/inch LPile 2015.8.03, © 2015 by Ensoft, Inc.

(b) Figure 3-22 Comparison of Moment vs. Curvature for (a) Steel Pipe Pile and (b) Elastic-Plastic Pipe Pile with Similar Properties 3-5-11 Round Prestressed Concrete Pile The properties of round prestressed concrete piles are defined by the length and diameter of the pile, the compressive strength of concrete, the prestressing reinforcement details, and the loss of prestress.

42

Chapter 3 – Input of Data The usual procedure for the LPile is to enter the pile dimensions, compressive strength of concrete, the number and size of prestress reinforcement strands, and concrete cover dimension. The Prestressing tab page for entering prestressing data for all types of prestressed concrete piles is shown in Figure 3-23. Once the prestressing size, number, and geometry are entered, the cross-section of the pile should be drawn by LPile. If the cross-section is not drawn properly, there is an error in the input data.

Figure 3-23 Prestressing Tab Page Common to All Prestressed Pile Types As a designer, the engineer can specify the length, diameter, concrete compressive strength, and reinforcement of a prestressed pile, but must find out from the pile supplier what value the expected fraction of loss of prestress is expected to be. Sometimes, the supplier will provide the final prestress after losses. The engineer can then determine what the fraction of loss of prestress is, provided the initial prestressing forces before losses is provided. The common practice for pile suppliers is to use 70 percent of the rated prestressing capacity of the reinforcement as the prestress force. This value is programmed in LPile for the listed sizes and types or prestress reinforcement. Next, the enters the fraction of loss provided by the pile supplier. For preliminary computations prior to selecting a pile supplier, the may enter a value in the typical range between 0.10 and 0.20. The value of prestress after losses is computed by LPile by pressing the button to Compute 70% Prestress Force and Stress. The value computed by LPile will be shown in the dialog and will be classified as OK if the prestress after losses is in the range of 600 to 1,200 psi (4.14 to 8.27 MPa), or as too high or too low if outside of this range.

43

Chapter 3 – Input of Data 3-5-12 Round Prestressed Concrete Pile with Void The properties of round prestressed concrete piles with void are defined by the length and diameter of the pile, the diameter of the hollow core void, the compressive strength of concrete, and the prestressing reinforcement and loss of prestress. The input for the round prestressed concrete pile with void is the same as for the round prestressed pile without void, with the exception of the entry of the diameter of the core void. Please refer to the discussion in Section 3-5-11 for information about the computation of prestress after losses. 3-5-13 Square Prestressed Concrete Pile The properties of square prestressed concrete piles are defined by the length and width of the pile, the size of the corner chamfer, the compressive strength of concrete, and the prestressing reinforcement and loss of prestress. The input for the square prestressed concrete pile is the largely same as for the round prestressed pile without void, with the exception of the entry of the dimensions for the pile width and corner chamfer. Please refer to the discussion in Section 3-5-11 for information about the computation of prestress after losses. An additional feature for the square prestressed pile is the feature to generate automatically rectangular strand layouts with circular, square, or weak square arrangements as shown in Figure 3-24. The different layout patterns will be displayed in the cross-section drawing when the number of prestressing strands is varied.

(a) Circular

(b) Square

(c) Weak Square

Figure 3-24 Automatic Prestressing Arrangements for Square Prestressed Piles

3-5-14 Square Prestressed Concrete Pile with Void The properties of square prestressed concrete piles with void are defined by the length and width of the pile, the size of the corner chamfer, the diameter of the hollow core void, the compressive strength of concrete, and the prestressing reinforcement and loss of prestress. The input for the square prestressed concrete pile with void is the largely same as for the round prestressed pile with void, with the exception of the entry of the dimensions for the pile 44

Chapter 3 – Input of Data width and corner chamfer. Please refer to the discussion in Section 3-5-11 for information about the computation of prestress after losses and to Section 3-5-13 for information about automatic prestressing strand arrangements. 3-5-15 Octagonal Prestressed Concrete Pile The properties of octagonal prestressed concrete piles are defined by the length and width of the pile, the compressive strength of concrete, and the prestressing reinforcement and loss of prestress. The procedures used to compute the nonlinear bending properties for the octagonal shape are identical to those used for the square prestressed pile except that the size of the corner chamfer is defined internally to produce the octagonal shape. 3-5-16 Octagonal Prestressed Concrete Pile with Void The properties of octagonal prestressed concrete piles with void are defined by the length and width of the pile, the diameter of the hollow core void, the compressive strength of concrete, and the prestressing reinforcement and loss of prestress. The procedures used to compute the nonlinear bending properties for the octagonal shape are identical to those used for the square prestressed pile with void except that the size of the corner chamfer is defined internally to produce the octagonal shape. 3-5-17 Pile with Defined Nonlinear Bending The properties of piles with nonlinear bending are defined by the length and width of the pile and the defined nonlinear bending properties. Nonlinear bending properties are defined by levels of axial thrust force and associated curves of either nonlinear bending stiffness versus bending moment or nonlinear bending moment versus bending curvature. The type of nonlinear data is selected by the by checking the appropriate radio button for the Type of Nonlinear Bending Input Data on the Nonlinear EI tab page shown in Figure 3-25. The buttons used to enter nonlinear bending data are enabled once the type of nonlinear bending data has been selected. Next, the enters the values of axial thrust force for which curves for nonlinear bending are to be entered in the data table shown in Figure 3-26. If more than one section with defined nonlinear bending is being defined, the values of axial thrust force of Section 1 are copied to the other section(s). A curve of nonlinear bending data is required for each input value for axial thrust force by pressing the button to the right of the thrust force value shown in Figure 3-26 to open the input tables shown in Figure 3-27. . The table shown will depend on the type of nonlinear bending data that was selected. It is possible to enter nonlinear bending data by either reading an external text file or pasting values from the Windows clipboard.

45

Chapter 3 – Input of Data

Figure 3-25 Nonlinear EI Tab Page

Figure 3-26 Table for Entering Axial Thrust Forces for Nonlinear Bending Data

46

Chapter 3 – Input of Data

(a)

(b)

Figure 3-27 Tables for Entry of (a) Nonlinear Moment versus Curvature Data and (b) Nonlinear Moment versus Bending Stiffness To enter data from an external text file, the located the text file using the browse button and then pressing the Read Values from File button. The format of the external text file requires that values are entered with the moment value first and either the EI or curvature value second with one data pair per line. A maximum of 150 data points may be entered. It is important for the to understand that LPile cannot validate the input data for nonlinear bending. Consequently, it is left to the to examine the charts of the input data and to that the input data is correct.

3-6 Lateral Load Transfer Relationships Three types of data can be entered in LPile to define the lateral load-transfer relationships between the pile and soil. Most basic of these are the definitions of soil layering, soil types, and soil properties used to compute the lateral load-transfer (p-y) curves. The soil layering and p-y curves are discussed in Section 3-6-1. The p-y curves can be affected by the combined pile batter and ground slope. The input of pile batter and ground slope angles is discussed in Section 3-7

47

Chapter 3 – Input of Data The p-y curves may be modified by the p-y modification factors to for the effects of group action for pile groups and earth retaining structures. The input of p-y modification factors is discussed in Section 3-8. It is also possible to define lateral load-transfer at the tip of the pile in addition to p-y curves that define lateral load-transfer along the length of the pile. The tip shear versus tip movement curves are generally important only for short piles for which significant movement of the pile tip can develop. The development of tip shear is highly dependent on the construction practices used to install the pile. Consequently, no dependable methods have been developed to compute the curves of tip shear resistance and most relationships are determined from the results of site-specific load testing programs. The input of tip shear resistances is discussed in Section 39 A key concept in LPile is the definition of the vertical coordinate system used to define soil layering and pile properties. The origin of this coordinate system is always located at the pile head. If it is desired to vary the vertical position of the pile head relative to the soil layering, it will be necessary to correct the data defining the soil layering. A utility function is included in LPile to assist in this task and is discussed in Section 3-10. 3-6-1 Soil Layering and p-y Curve Models This dialog for Soil Layers is used to specify the different types of soil to be used for the automatic generation of lateral load-transfer curves (p-y curves). LPile will automatically generate the selected curves unless the specifies and enters -input p-y curves. An example of this dialog is shown in Figure 3-28.

Figure 3-28 Dialog for Definition of Soil Layering and Soil Properties The following is a description of the input data for this dialog. Layer Number: The soil layer number is assigned automatically to each soil layer with Layer 1 being the uppermost layer. This number is automatically provided by the program as additional rows of soil layers are created. The maximum number of soil layers that may be entered is 40. p-y Curve Model: There are 14 internal types of soils plus -input p-y curves that can be specified in LPile using the dropdown box, plus -input p-y curves. These types are: 1. Soft Clay (Matlock) 2. Stiff Clay with Free Water (Reese) 3. Stiff Clay without Free Water (Reese) 48

Chapter 3 – Input of Data 4. Modified Stiff Clay without Free Water 5. Sand (Reese) 6. API Sand (O’Neill) 7. Liquefied Sand (Rollins) 8. Weak Rock (Reese) 9. Strong Rock (Vuggy Limestone) 10. Piedmont Residual 11. Silt (cemented c-) 12. Loess 13. Elastic Subgrade 14. -input p-y curves 15. API soft clay with J 16. Massive rock. Top of Soil Layer Below Pile Head: Values for the top of the soil layer are entered relative to the origin of the depth coordinates. The origin of depth coordinates is the pile head, which is the point of application of boundary conditions and corresponding loads. A positive value for the Top Layer entry indicates a distance measured downward from the top of the pile. A negative value indicates a distance measured above the top of the pile (only used for when the pile head is embedded below the ground surface). The value of zero may be used in the first layer if the pile head is at the level of the ground line. Bottom of Soil Layer Below Pile Head: Values for the bottom of the soil layer are also entered according to the origin of coordinates. The coordinate of the bottom of each layer should always be equal to the coordinate of the top of the immediately consecutive layer. The bottom of the last soil layer must at least reach the same depth as the bottom of the modeled pile Soil Properties: The last column contains a context-sensitive button that varies depending on the p-y curve soil type selected. The table button activates a soil type specific data entry dialog where the enters effective unit weight, shear strength parameters, and any other required soil/rock property parameters, depending on the soil type selected. Descriptions follow: 3-6-1-1 Comments on p-y Curve Models The following comments are made above the different p-y curve models. With the exception of the silt model for cemented c- materials, all of the models are based on load tests of full sized piles in which the pile diameter is typically in the range of 300 to 1,200 mm (12 to 48 inches). While it is possible to test piles with larger diameters, it is usually not possible to load such large diameter pile to failure. Consequently, if a significant variation of lateral load transfer characteristics due to pile diameter exists, it may not be accurately modeled by the p-y curve formulations. The p-y curve for silt (cemented c- soil) was not based on a load-testing program on full-sized piles. Consequently, reliable recommendations for k and 50 cannot be made for this model. However, if it is possible to perform a lateral load test in the field, it may be possible to fit these parameters to a site-specific load test to calibrate the model. In such cases, the performance of the model may be significantly improved.

49

Chapter 3 – Input of Data Stiff clay with free water, in general, is used to represent soil conditions where stiff clay is the top layer in the soil profile and there is water existing above the ground line or in any conditions where it is believed that any annular space between the pile and soil may fill with water. A discussion of the theory of p-y curves for different types of soils is included in the Technical Manual. 3-6-1-2 Common Soil Properties for p-y Curves 





 

Effective Unit Weight: Values of effective unit weight for each soil depth are entered in units of force per unit volume. The program will linearly interpolate values of unit weight located between the top and bottom depths of the layer. Soil layers should be sub-divided anywhere step changes in values are needed, such as at the depth of the water table. k Value for Soil Layers: This is the value for k used in the equation Es = k x. This constant is in units of force per cubic length and depends on the type of soil and lateral loading imposed to the pile group. It has two different uses: (1) to define the initial (maximum) value of Es on internally generated p-y curves of stiff clays with free water and/or sands; and (2) to initialize the Es array for the first iteration of pile analysis. Undrained Shear Strength: Values of undrained shear strength (cu) for clays and silts at each depth are entered in standard units of force per unit area. The undrained shear strength is not needed for sand layers. The undrained shear strength is generally taken as half of the unconfined compressive strengths. Internal Friction (degrees): Values of the angle of internal friction  for sands and/or silts at each soil depth are entered in degrees. Strain Factor E50: Values of 50 strain at 50% of the maximum stress. The strain factor 50 for clays and/or silts at each soil depth are entered in dimensionless units of strain.

If soil test data are available, the may enter the value based on the stress-strain curves measured in the soil laboratory. The p-y curves for weak rocks need a strain parameter krm which is analogous to 50. More information regarding krm and 50 can be found in the Technical Manual. Initial Mass Modulus for Weak Rock: The initial mass modulus for weak rock should be entered for this value. This value may be measured in the field using an appropriate test or may be obtained from the product of the modulus reduction ratio and Young’s modulus measured on intact rock specimens in the laboratory Uniaxial Compressive Strength: This value is the uniaxial compressive strength of weak rock at the specified depth. Values at elevations between the top and bottom elevations will be determined by linear interpolation. Any input values that are considered unreasonable are flagged in the output file and a warning dialog box is displayed. However, the analysis is performed normally. Rock Quality Designation: The secondary structure of the weak rock is described using the Rock Quality Designation (RQD). Enter the value of RQD in percent for the weak rock. Strain Factor krm: The parameter krm for weak rock typically ranges between 0.0005 and 0.00005. The input dialog for weak rock is shown in Figure 3-29 as an example.

50

Chapter 3 – Input of Data

Figure 3-29 Dialog for Properties of Weak Rock The input for massive rock requires strength parameters defined using the Hoek-Brown strength criterion. In addition to effective unit weight and uniaxial compressive strength, these parameters include: Hoek-Brown Material index, mi, is a dimensionless number ranging from 4 to 32 that depends on the type of rock. Poisson’s Ratio. Guidance for selecting a value for Poisson’s ratio as a function of the compression and shear wave velocities in rock is discussed in the Technical Manual. Geologic Strength Index, GSI, is a dimensionless number ranging from zero to 100 that depends on the quality of the massive rock. Two options are provided for determining the rock mass modulus for massive rock. For Option 1, the inputs a value for the intact rock modulus and leaves the input for rock mass modulus equal to zero. In Option 1, the program computes a value of rock mass modulus based in the input data. For Option 2, the inputs a non-zero value for rock mass modulus. In Option 2, the program will ignore any value input for the intact rock modulus. The input dialog for massive rock is shown in Figure 3-30 as an example.

Figure 3-30 Dialog for Properties of Massive Rock

51

Chapter 3 – Input of Data 3-6-2 Input p-y Curves Data for -input p-y curves are input using two linked dialog boxes. The first dialog box is used to enter values of effective unit weight at the top and bottom of the soil layer and to open the input dialog box for entry of the p-y curve data.

Figure 3-31 Dialog for Effective Unit Weights of -input p-y Curves The second input dialog box is used to enter the p-y curve data. The may enter data in one of three ways. The may add enough rows to accommodate the data and enter the data manually, the by paste the data into the table via the Windows clipboard, or read an external text data file. The input dialog is shown below. The graph in the dialog shows the current data. It may be necessary for the to move the cursor to an adjacent cell to update the graph of the py curve. An example of the input dialog for a -input p-y curve is shown in Figure 3-32.

Figure 3-32 Dialog for -input p-y Curve Values

52

Chapter 3 – Input of Data This layer type allows the to enter specific relationships of soil resistance (p) and lateral movement of the pile (y) at specified depths. These cases usually arise when local data for the soil response are available. To use external p-y curves, the needs to select Input p-y Curves under the p-y Curve Soil Model column in the Soil Layers dialog. Then, clicking on the context-sensitive button in the far right column opens a dialog where the can input the effective unit weight of the soil. Finally, the can define lateral deflection and soil resistance values for points in the upper and lower curves by clicking on the corresponding External p-y Curve for Layer button in the far right column. A general description for the data needed for -Input p-y Curves is listed below: 1. Lateral Deflection: y-values of lateral movement must be entered in units of length. As a reference, a review of the theory of “Soil Response” is included in Part II, Chapter 3 of the Technical Manual. 2. Soil Resistance: p-values of lateral load intensity must be entered in units of load per unit depth. As a reference, a review of the theory of “Soil Response” is included in Part II, Chapter 3 of the Technical Manual.

3-7 Pile Batter and Ground Slope The specifies the ground slope and batter angles using the Ground Slope and Batter dialog shown in Figure 3-33. The drawing in the dialog realistically illustrates the ground slope and pile batter angles along with the sign convention for loading. If flat ground slope is selected and the pile is vertical, the angles will be zero. 



Slope Angle: This is the angle, in degrees, formed between a sloped ground surface and the horizontal surface. As indicated in the following figure, the value of the slope angle is positive if the pile tends to move downhill upon application of the lateral load. The lateral capacity provided by soils in a positive slope is thus reduced. Piles that tend to move uphill in a sloping ground use negative values of slope angle. The lateral capacity provided by soils in a negative slope is thus increased. Batter Angle: The sign convention that is used to for battered piles also depends on the direction of the applied lateral load and is shown in the figure.

3-8 p-y Modification Factors This input dialog allows the to enter modification factors for soil resistance (p) and/or lateral movement of the pile (y) at specified depths. A maximum of 80 entries of modification factors for p-y curves may be used in an analysis. The program allows the input of modification factors for any depths of the soil profile. The p-y modification factors only apply to p-y curves that are internally generated by the program. If the requests a report of internallygenerated p-y curves, the output curves will include the changes produced by the specified p-y modification factors. An example of this input dialog is shown in Figure 3-34.

53

Chapter 3 – Input of Data

Figure 3-33 Dialog for Definition of Pile Batter and Slope of Ground Surface

Figure 3-34 Dialog for p-Multipliers and y-Multipliers versus Depth Below Pile Head Distance from Pile Head: These values represent the depths where modification factor for p-y curves are being specified. Intermediate values of p-y modification factors located between two specified depths are obtained by linear interpolation of the specified factors. It is therefore necessary to have at least two entries of modification factors. Modification factors must be entered in ascending order of depths. p-Multiplier: The p-multiplier values may be larger or smaller than one. However, in most cases these values are smaller than one to for group effect of closely-spaced piles or drilled shafts. A large reduction in p-values (and/or increase of y-values) may also be used to represent liquefiable layers of sand.

54

Chapter 3 – Input of Data y-Multiplier: The y-multiplier values may be larger or smaller than one. However, in most cases these values are larger than one to for group effect of closely-spaced piles. A large increase in y-values (and/or reduction of p-values) may also be used to represent liquefiable layers of sand.

3-9 Tip Shear-Resistance This input dialog allows the to enter a shear-resistance curve at the bottom of the pile. This input dialog is inactive under default conditions. A maximum of 50 points may be defined in the shear-resistance curve at the pile tip. A minimum of two points are required to form a curve. An example of this input dialog is shown in Figure 3-35.

Figure 3-35 Dialog for Tip Shear Resistance versus Lateral Tip Displacement In general, shearing resistance at the pile tip would only be applicable to those cases where the pile is short (with only one point of zero deflection along their depth). In addition, these curves are likely to make noticeable differences only when using large diameter shafts that deform largely by rotation without large amounts of bending. The may enter data in one of three ways. The may add enough rows to accommodate the data and enter the data manually, the by paste the data into the table via the Windows clipboard, or read an external text data file. The input dialog is shown below. The 55

Chapter 3 – Input of Data graph in the dialog shows the current data. It may be necessary for the to move the cursor to an adjacent cell to update the graph of the tip shear curve.

3-10 Shift Pile or Soil Elevations Occasionally the may have the need to raise or lower the position of the pile in the soil profile or may desire to check the entry depths of soil and rock layers against elevation data for the project site. These actions can be performed by using the Shift Pile Elevation command under the Data Menu. An example of the Shift Pile Elevation input dialog is shown in Figure 3-36. In this example, the pile head is initially positioned at the ground surface, so the depth of the top of layer 1 is zero ( that the position of the pile head is the origin of the vertical coordinate system used in LPile).

Figure 3-36 Dialog for Shifting of Pile Elevation Relative to Input Soil Profile Showing a Pile Head at the Top of the Soil Profile If the wishes to move the pile vertically within an entered soil profile, the enters the elevation shift in the upper data edit box and presses the Shift Pile Elevation button. To move the pile downwards, the enters a positive number and to move the pile upwards the enters a negative number. The Shift Pile Elevation dialog shown below shows the results for a case in which the pile was moved down by 2 meters. The summary report shown in Figure 3-37 shows that the top of the first layer has been moved to −2 meters, but that the thicknesses of the layers are unchanged.

56

Chapter 3 – Input of Data

Figure 3-37 Dialog for Shifting of Pile Elevation Relative to Input Soil Profile After Shifting a Pile Head To Be Below the Ground Surface If the wishes to compare the depths of the soil layer profile to elevation data, the enters a value for the elevation of the ground surface and presses the View Elevations Report button. The Shift Pile or Soil Elevations dialog can display the report in two formats that are selected by pressing the appropriate Elevation Coordinate Type radio button. The default format is the LPile Depth Coordinates and the other format is the Elevations Relative to Datum. The dialog box shown below is an example where the ground surface elevation is 6 meters and the Elevations Relative to Datum option has been selected.

3-11 Input of Output Depths for p-y Curves The may generate and plot p-y curves at -specified depths. These curves are not used in the analysis, as LPile computes exact values of p for every corresponding value of y for every node along the length of the pile. Many of the various parameters needed to compute the output p-y curves are output in the output report file from LPile. The depths can be entered in any order. LPile will sort the depth values from top to bottom and eliminate duplicate entries prior to performing computations. No p-y curves will be computed if an output depth is either above the ground surface or below the pile tip and a warning message will be output by the program. An example of the input dialog for p-y Output Depths is shown in Figure 3-38. It should be noted that the depth is the vertical depth below the pile head, not the depth along the axis of the pile.

57

Chapter 3 – Input of Data

(a)

(b)

Figure 3-38 Output Depths of p-y Curves Below Pile Head, (a) Dialog for p-y Curve Output Depths, (b) Measurement of Vertical Depths

3-12 Conventional Loading Analysis The conventional loading analysis is the same type of analysis used in all versions of LPile older than Version 6. In this type of analysis, up to 100 pile-head loadings of various types can be specified. In addition, distributed lateral loading can be specified and the distributed lateral loading will be applied to all pile-head loading cases. 3-12-1 Pile-head Loading and Options The Pile-head Loading and Options dialog shown in Figure 3-39 allows the to enter the desired boundary conditions and corresponding loading at the pile head. There are five options for boundary conditions at the pile head. The selects the desired boundary condition using a dropdown list of the choices described below. The program allows up to 100 rows of boundary conditions and corresponding loading at the pile head. In addition, the may specify the computation of pile top deflection versus pile length for any of the specified load cases. In general, should restrict use of this option to cases using any of the first three pilehead conditions, as the pile-head deflection will not vary for the fourth and fifth pile-head loading conditions. 3-12-1-1 Pile-Head Loading Types Shear and Moment: This boundary condition is selected to specify values of applied lateral load in units of force and applied moment in units of force  length at the pile head. This condition implies that the pile head is free to rotate and move laterally. The lateral force is considered positive when applied from left-to-right. The moment is considered positive when applied clockwise. Shear and Slope: In this boundary condition, the defines the applied lateral load in units of force and the slope in radians at the pile head. The lateral force is considered positive when applied from left-to-right. The slope is positive when the pile head rotates counterclockwise. A fixed-head condition (with no restrictions to lateral movements) may be modeled by specifying a slope equal to zero. Shear and Rotational Stiffness: For this boundary condition, the defines the applied lateral load in units of force and a value for rotational stiffness (moment per radian of rotation) at 58

Chapter 3 – Input of Data the pile head. The lateral force is considered positive applied from left-to-right. The values for rotational stiffness are always positive. A fixed-head condition (with no restrictions to lateral movements) may optionally be modeled by specifying a large value of rotational stiffness. This boundary condition should be selected if the wants to model an elastically restrained pilehead connection.

Figure 3-39 Dialog for Definition of Conventional Pile-head Loading Displacement and Moment: This is selected to specify values of lateral displacement and moment at the pile head. The displacement is considered positive applied from left-to-right. The moment is considered positive when applied clockwise. Displacement and Slope: This is selected to specify values of lateral displacement and the pile-head slope in radians. The displacement is considered positive applied from left-to-right. The slope is positive when the pile head rotates counterclockwise. 3-12-1-2 Condition 1 This value is the first load in the loading type description; shear force for the first three loading type conditions and displacement for the last two loading type conditions. 3-12-1-3 Condition 2 This value is the second load in the loading type description.

59

Chapter 3 – Input of Data 3-12-1-4 Axial Load This value is input in units of force. It is applied at the pile head and may be entered after specifying the boundary conditions as well as the corresponding loading. Axial loads entered in this column are used in two parts of the computations. Firstly, the axial thrust force is used in the computations of nonlinear moment-curvature behavior. Secondly, the axial force is used to for secondary moments produced when the pile deflects (also known as P- effects). 3-12-1-5 Compute Top y versus L This column contains a drop-down yes/no option for performing computations of top deflection versus pile length for this pile-head loading condition if pile-head loading condition does not prescribe the pile-head lateral deflection value. No computations of top deflection versus pile length will be made if either of the displacement-moment or displacement-slope pilehead conditions is specified. 3-12-2 Distributed Lateral Loading The data entry for distributed lateral loading for conventional analysis is controlled either using a single input dialog if a single distributed load profile is used for all conventional loading cases or using two linked input dialogs if distributed loading profiles are defined independently for the various conventional loading cases. In the first dialog, the checks whether to include distributed lateral loads. If the option is checked, the button to show the input dialog is enabled and the may display the input dialog for distributed lateral loading. Examples of these dialogs are shown in Figure 3-40. The program allows up to 50 different input points of lateral load values, which are placed in units of load per unit length of pile. The must enter values in increasing magnitudes of depth. The program linearly interpolates the values of lateral loads existing between specified depths. A minimum of two entries (two depths) of distributed lateral loading are needed. The may enter data in three ways. The may add enough rows to the table and enter the data manually, the may paste the data into the table via the Windows clipboard, or the may direct LPile to read an external text file containing the data. The Distributed Lateral Loads dialog is shown in Figure 3-41. The graph in the dialog shows the current data. It may be necessary for the to move the cursor to a different cell to update the graph of the distributed lateral loading. It is not possible for LPile to data. It is left to the to view the graph of the distributed load data and to its correctness.

60

Chapter 3 – Input of Data

(a)

(b)

Figure 3-40 Dialogs for Multiple Distributed Lateral Loads for Conventional Loading, (a) 3 Load Cases, (b) Distributed Load Profile Data for Load Case 1

61

Chapter 3 – Input of Data

Figure 3-41 Dialog of Values of Distributed Lateral Loads versus Depth 3-12-2-1 Modeling of Point Shear Forces Below Pile Head This modeling technique is useful to model the application of point shear loads and moments below the pile head. It is necessary for the to understand how LPile applies the distributed lateral loads to the pile in order to model these loadings accurately. In performing the computations, LPile integrates along the distributed lateral load profile for each pile node from one-half a pile increment above the node to one-half a pile increment below the node. At the top and bottom nodes on the pile, the integration spans only one-half a pile increment either above or below the top or bottom increment as needed. The result of the integral is applied as a point force at the node in question. In the case of an applied point shear value, the use may specify the distributed lateral load intensity acting over a small increment spanning the point of application. For example, if the pile is 50 feet long (600 inches) and has 100 increments, each pile increment is six inches long and the nodes are spaced at 0 inches, 6 inches, 12 inches, 18 inches, and so on down to the pile tip at 600 inches. If the point load is to be applied at 4 feet, 10 inches (58 inches), it is necessary to apply the distributed load in a way that effectively centers the applied load at the preferred location, while extending to the closest nodal point. In this example, the distributed lateral load should extend from the point of application (58 inches) to the closest nodal point (at 60 inches). The upper boundary of the applied zone should extend an equal distance above the point of application to 56 inches (see Figure 3-42). When LPile computes the equivalent nodal point

62

Chapter 3 – Input of Data loads for this example, one-third of the applied force result is a applied at the nodal point above the point of load application and the remain two-thirds is applied at the closest node.

h

Uniform distributed load p is centered about point of load application and extends to closest nodal point.

dx

V = p dx p

Figure 3-42 Recommendation for Modeling of Lateral Force Applied Below the Pile Head It is important for the to recognize that if the nodal point spacing changes for any reason, the boundaries of the equivalent loading zone must be re-computed by the . 3-12-2-2 Modeling of Moments Below Pile Head There are more restrictions in modeling in the case of modeling concentrated moments in the pile. It is only possible to apply a concentrated moment about a nodal point, not any arbitrary location. To model concentrated moments, it is necessary to apply equal and opposite in action distributed lateral loads to the nodal increments above and below the nodal point where the moment is to be applied. The reason for this is the integration of distributed lateral loads is performed for each nodal point. If the two distributed loads were applied over a single increment, the equal and opposite forces would cancel each other. Figure 3-43 illustrates the principle of applying equal and opposite equivalent forces to model a concentrated moment in the pile.

63

Chapter 3 – Input of Data p

Double uniform distributed loads are applied and centered about nodes above and below node where moment is applied.

h

M = 2 (p dx) h dx −p

Figure 3-43 Recommendation for Modeling of Moment Applied Below the Pile Head 3-12-3 Loading by Lateral Soil Movements LPile provides two options for specifying free-field soil movement in the soil profile. Either a single soil movement profile can be applied to all load cases or independent soil movement profiles can be specified for each conventional loading case. The soil movement profile may be defined only along a portion of the pile length if desired. In general, a pile under lateral load moves against a soil mass. However, in some cases, the soil itself will move and the soil loading or reaction must be considered by taking into the relative movement between the soil and the pile. LPile will automatically generate the soil reaction at each pile node consistent with the relative movement between the soil and pile at that particular depth. A maximum of 50 entries is allowed for definition of the soil movement profile in an analysis. The input dialog for soil movements versus depth is shown in Figure 3-44. The may enter data in one of three ways. The may add enough rows to accommodate the data and enter the data manually, the by paste the data into the table via the Windows clipboard, or read an external text data file. The input dialog is shown below. The graph in the dialog shows the current data. It may be necessary for the to move the cursor to an adjacent cell to update the graph of lateral soil movement. Depth Below Pile Head: These values represent the x-coordinate corresponding to the depths where the soil movement occurs. Intermediate values of soil movement located between two specified depths are obtained by linear interpolation of the specified values. It is therefore necessary to have at least two entries of depths. Soil movement must be entered in ascending order of depths. Lateral Soil Movement: The soil movement values may be positive for soil moving from left to right or negative for soil moving from right to left. However, it is critical that the soil movement occurs in the same direction of as the applied loads.

64

Chapter 3 – Input of Data

Figure 3-44 Dialog for Input of Soil Movements versus Depth Below Pile Head 3-12-4 Computation of Pile-head Stiffness Matrix Components The feature for computation of pile-head stiffness matrix values has three options to control how the values are computed. In the first method, which is identical to the method used in versions of LPile prior to LPile 2013, the loads used for computation of pile-head stiffness are those specified in load case 1 for conventional loading. This method does not allow the to control the lateral displacement and pile-head rotation, so the second and third options were added to provide this capability. In the second method, the maximum displacement and rotation are set by the values computed for load case 1 for conventional loading. In the third method, the may specify the maximum pile-head displacement and rotation. The dialog for Controls for Computation of Stiffness Matrix is shown in Figure 3-45.

65

Chapter 3 – Input of Data

Figure 3-45 Dialog for Controls for Computation of Stiffness Matrix The definitions of the pile-head stiffness values and their engineering units computed by LPile are the following: pile - head shear force reaction lbs kN  or pile - head deflection inch meter pile - head moment reaction in - lbs kN - m K 32   or pile - head deflection inch meter pile - head shear force reaction lbs kN K 23   or pile - head rotation radian radian pile - head moment reaction in - lbs kN - m K 33   or pile - head rotation radian radian

K 22 

3-12-5 Pushover Analysis The program feature for pushover analysis has options for different pile-head fixity options and the setting of the range and distribution of pushover deflection. The output of the pushover analysis is displayed in graphs of pile-head shear force versus deflection and maximum moment developed in the pile versus deflection. The pushover analysis is performed by running a series of analyses for displacement-zero moment pile-head conditions for pinned head piles and analyses for displacement-zero slope pile-head conditions for fixed head piles. The displacements used are controlled by the maximum and minimum displacement values specified and the displacement distribution method. The displacement distribution method may be either logarithmic (which requires a non-zero, positive minimum and maximum displacement values), arithmetic, or a set of -specified pile-head displacement values. The number of loading steps sets the number of pile-head displacement values generated for the pushover analysis. The axial thrust force used in the pushover analysis must be entered in the dialog. If the pile being analyzed is not an elastic pile, the should make sure that the axial thrust force 66

Chapter 3 – Input of Data entered matches one the values for axial thrust entered in the conventional pile-head loadings table to make sure that the correct nonlinear bending properties are used in the pushover analysis. If the values do not match, the nonlinear bending properties for the next closest axial thrust will be used by LPile for the pushover analysis. The pushover analysis feature is enabled by checking the appropriate check box in the Program Options and Settings dialog box (see Figure 3-6 on page 24). The dialog for Controls for Pushover Analysis is opened by selecting from the Data Menu or by pressing the button on the button bar of the main program Window. The dialog for Controls for Pushover Analysis is presented in Figure 3-46.

Figure 3-46 Dialog for Controls for Pushover Analysis Some typical results from a pushover analysis are presented in the following two figures. Figure 3-47 presents the pile-head shear force versus displacement for pinned and fixed head conditions and indicates the maximum level of shear force that can be developed for the two conditions. Similarly, Figure 3-48 presents the maximum moment developed in the pile (a prestressed concrete pile in this example) versus displacement and shows that a plastic hinge develops in the fixed head pile at a lower displacement than for the pinned head pile. Often is not possible to identify the displacement at which a plastic hinge forms in the graph of pile-head shear force versus displacement. Instead, the should examine the graph of maximum moment developed in the pile versus displacement to determine the lateral pile-head displacement at which the maximum developed moment is reached. The lateral displacements at which the plastic moment forms are indicated in Figure 3-47 and Figure 3-48. In general, it is not possible to develop more than one plastic hinge in a pile if the pilehead condition is pinned. It is sometimes possible to develop two plastic hinges in the pile if the pile-head condition is fixed head.

67

Chapter 3 – Input of Data

Formation of plastic hinge

Figure 3-47 Pile-head Shear Force versus Displacement from Pushover Analysis

Formation of plastic hinge

Figure 3-48 Maximum Moment in Pile versus Displacement from Pushover Analysis 3-12-6 Pile Buckling Analysis The feature for performing an analysis of pile buckling has options for the pile-head fixity condition, pile-head loadings, maximum compression loading, and number of loading steps. The pile buckling analysis is performed by applying the pile-head loading conditions, then increasing the axial thrust loading from zero to the maximum compression load in the number of loading steps specified. The dialog for the Controls for Pile Buckling Analysis is shown in Figure 3-49. 68

Chapter 3 – Input of Data

Figure 3-49 Dialog for Controls for Pile Buckling Analysis The results of the pile buckling analysis are presented in a graph along with an estimate of the axial buckling capacity for the pile-head loading condition. This graph displays the pilehead lateral deflection versus axial thrust force, a fitted hyperbolic curve, and the estimated pile buckling capacity. The hyperbolic curve is fitted to the computed results using the following procedure. The typical results from the pile buckling analysis are similar to those shown in Figure 3-50. In this figure, P is the axial thrust force and y0 is the pile-head deflection for the case of zero axial load. These results are then redrawn with every deflection value shifted to the left by an amount equal to y0, as shown in Figure 3-51. The form of the hyperbolic curve to be fitted is

P

y  y0 b  a  y  y0 

This may be rearranged in the form of straight line with a slope a and intercept b as y  y0  b  a  y  y0  P

The computed results are then redrawn as in Figure 3-52 and least-squares curve fitting is used to compute the curve fitting parameters a and b. The estimate pile buckling capacity Pcrit is computed using Pcrit 

1 a

LPile can graph the computed results, the fitted curve, and the estimated pile buckling capacity. A typical graph is shown in Figure 3-53.

69

Chapter 3 – Input of Data P

y

y0

Figure 3-50 Typical Results for a Pile Buckling Analysis P

1/a

b

y – y0

Figure 3-51 Computed Pile Buckling Result Shifted to the Left y  y0 P

a 1

b y – y0

Figure 3-52 Redrawn Pile Buckling Results Used for Curve Fitting 70

Chapter 3 – Input of Data

Axial Thrust Load, kN

Free-head Condition 10,500 10,000 9,500 9,000 8,500 8,000 7,500 7,000 6,500 6,000 5,500 5,000 4,500 4,000 3,500 3,000 2,500 2,000 1,500 1,000 500 0 0

0.02

0.04

0.06

Top Deflection, m g b c d e f b c d e f g

Pile Response Computed by LPile f g b c d e Buckling Capacity = 10,531 kN

Fitted Hyperboloic Buckling Curve

Figure 3-53 Results from Pile Buckling Analysis In this graph, the response curve is plotted with symbols and the fitted curve is drawn without symbols. The filled curve overlies the curve for computed pile response, so the line for computed pile response is not visible but the symbols on the response curve are visible. When performing a pile buckling analysis, the must guard against specifying a maximum axial load that is too high. This can be checked by examining the sign of deflection of the lateral deflection value for zero axial load. In a proper analysis, the magnitude of lateral deflection at higher values of axial thrust will have the same sign as that for zero axial thrust and the deflection values will be larger in magnitude, as shown in Figure 3-53. The estimated pile buckling capacity for elastic piles is computed from the shape of the pile-head response curve and is not based on the magnitude of maximum moment compared to the plastic moment capacity of the pile. For nonlinear piles, the buckling capacity may be determined by either the maximum axial compression capacity or plastic moment capacity of the pile. For piles with nonlinear bending behavior, the buckling capacity estimated by the hyperbolic curve may over-estimate the actual buckling capacity if the buckling capacity is controlled by the pile’s plastic moment capacity. Thus, for analyses of nonlinear piles, the should compare the maximum moment developed in the pile to the plastic moment capacity. If the two values are close, the buckling capacity should be reported as the last axial thrust value for which a solution was reported. If the section is either a drilled shaft (bored pile) or prestressed concrete pile with low levels of reinforcement, it may be possible to obtain buckling results for axial thrust values higher than the axial buckling capacity, but the sign will be reversed. The reason for this is a large axial thrust value will create compression over the full section. This causes the moment 71

Chapter 3 – Input of Data capacity to be controlled by crushing of the concrete and not by yield of the reinforcement. An example of a pile buckling analysis that used axial thrust values that were too high is shown in Figure 3-54. 450 Correct 400

Incorrect

Axial Thrust Force, kN

350 300 250

200 150 100

50 0 -0.5

-0.4

-0.3

-0.2

-0.1

0

0.1

0.2

Pile-head Deflection, meters

Figure 3-54 Example of Correct (green symbols) and Incorrect (red symbols) Pile Buckling Analyses

3-13 Input of Load Testing Data Data for pile response measured during lateral load testing may be entered into LPile and displayed along with computed results. When this option is selected, the is required to enter values of pile-head shear force loading versus lateral deformation. Optionally, the may enter values of moment developed in the pile versus depth below the pile head for each pile-head shear force value. 3-13-1 Controls for Input of Load Test Data Entry of load test data is controlled using the dialog box shown in Figure 3-55. The basic data entered are the pile-head shear versus displacement data. Optionally, the may also enter values of bending moment and/or lateral displacement versus depth. Lastly, the may select whether or not the load test values are included in the graphs generated by LPile. It is also possible for LPile to save load test data that has been entered as a text file and to read a text file containing the load test data.

72

Chapter 3 – Input of Data The should note that load test data is not saved as part of the LPile input data. Thus, each time LPile is restarted for a new analysis, it will be necessary to re-enter the load test data either by reading from the previously saved text file or by re-entering the data to LPile.

Figure 3-55 Dialog for Control of Input and Saving of Load Testing Data 3-13-2 Input of Load Test Data without Data for Bending Moments An example of the dialog for entering pile-head shear force versus lateral deformation is shown in Figure 3-56. Data must be entered directly in the current system of units being used by LPile. However, if an existing file of load test data is being read via the load test data controls shown in Figure 3-55, the engineering units of the load test data is saved in the text file and the data will be converted, if needed, to the current system of units being used by LPile. 3-13-3 Input of Load Test Data for Bending Moments and Deflection versus Depth If input of bending moment and/or lateral deflection data versus depth may be specified by marking the check boxes in Figure 3-55 to include data versus depth. The may input a profile of bending moment and/or lateral deflection versus depth for each pile head loading level for which data is available via the data controls shown in Figure 3-57. The columns displayed will depend on the check boxes marked in the controls dialog. The input dialogs for bending moment and lateral deflections versus depth are shown in Figure 3-58.

73

Chapter 3 – Input of Data

Figure 3-56 Dialog for Input of Pile-head Shear Force versus Lateral Deformation from Load Testing, if input of Bending Moment and/or Lateral Movement versus Depth is not specified.

74

Chapter 3 – Input of Data

Figure 3-57 Dialog for Input of Pile-head Shear Force versus Lateral Deformation from Load Testing, if input of Bending Moment and Lateral Deflection versus Depth are specified.

75

Chapter 3 – Input of Data

Figure 3-58 Dialogs for Input of Bending Moment and Lateral Deflection versus Depth from Load Testing.

3-14 Load and Resistance Factor Design Data for load and resistance design computations is entered using two input dialogs. Unfactored loads are entered in one dialog and the definitions of load and resistance factors to be used are entered in the second dialog. A summary report of computed load cases is also provided to aid the in ing the factored loads computed for the defined load cases. The following sections describe these dialogs and the summary report. 76

Chapter 3 – Input of Data 3-14-1 Unfactored Loads The input dialog for unfactored loads shown in Figure 3-59 allows the to define the type of load, horizontal force, vertical force, overturning moment, and to control the use and input of distributed loading data. All unfactored loads must be defined as combinations of horizontal shear force, over-turning moment, axial thrust force, and distributed lateral loads normal to the axis of the pile.

Figure 3-59 Dialog for Definition of Unfactored Pile-head Loadings for LRFD Analysis The unfactored load definition includes the type of load. The load types are:        

Dead load Live load Earthquake Impact Wind Water Ice Horizontal Soil Pressure

77

Chapter 3 – Input of Data     

Live Roof Rain Snow Temperature Special (for any type of load not listed above)

If the wishes to enter data for a distributed lateral loading, an input dialog identical to that shown in Figure 3-41 on page 62 is displayed. 3-14-2 Load Cases and Resistance Factors The controls the definition of load cases either by reading the LRFD load case data file from the Program Options and Settings dialog box or by entering the specific load case in the dialog shown in Figure 3-60. To include a load type in a load case combination, the enters a positive, non-zero value. In addition, the may enter the resistance factors for structure resistance in bending and shear capacity and may enter a descriptive name for the load case combination.

Figure 3-60 Dialog for LRFD Load Combinations and Structural Resistance Factors The current version of LPile does not compute structural shear capacity, but allows the to input a value of shear capacity for each pile section. So, the factored shear capacity is computed by LPile by multiplying the resistance factor for shear by the input value for shear capacity. If the value of factored shear capacity is non-zero, LPile will evaluate the shear in the pile section by comparing the maximum developed shear force to the factored shear capacity in each pile section. In the case of pile sections defined as elastic-plastic piles with tapered dimensions, the value of shear capacity at each pile nodal point is computed by interpolation between the values at the top and bottom of the section and the developed shear force is compared to the shear capacity at every nodal point in the section.

78

Chapter 3 – Input of Data 3-14-3 Summary of Factored Load Cases The summary of factored load cases is provided for the to view the factored loads computed by LPile. LPile computes this summary by first adding all pile-head loading of the same type together, then multiplying the sum by relevant load factor. In the case of distributed loads, the program integrates the individual distributed load profiles and computes the equivalent concentrated forces at nodes on the pile, adds all forces from the same load type together, and then multiplies the sum by the relevant load factor. The summary report has three general sections. The first section shows the totals of the unfactored loads. The second part shows the computed factored loads for each load case in turn. The third part shows the factored load cases in tabular form. The content of the summary report is saved under the filename of the data file with the file extension of LRFD_Summary_Report. An example of the summary report is shown in Figure 3-61.

Figure 3-61 Summary Report of Computed Factored Load Combinations for LRFD Analysis

3-15 Computation of Nonlinear EI Only 3-15-1 Axial Thrust Loads for Interaction Diagram If the selects the program option to Compute Nonlinear EI Only, the may generate a structural interaction diagram by entering multiple axial thrust values. The thrust 79

Chapter 3 – Input of Data values may be entered in any order and LPile will sort the values from lowest to highest and remove duplicate entries before performing computations. An example of the input dialog for entering axial thrust force values is shown in Figure 3-62. Example 5, discussed in Section 6-5, demonstrates how to compute nonlinear EI only and how to produce both unfactored and factored interaction diagrams. Note that factored interaction diagrams can only be produced using the Presentation Charts utility discussed in Section 4-9.

Figure 3-62 Dialog for Axial Thrust Forces for Computation of Interaction Diagram

80

Chapter 4 Display of Graphics 4-1 Introduction The Graphics Menu is used to display graphs of output data after a successful analysis. Options for the display of graphs under the Graphics Menu are only enabled after a successful analysis has been made. Even after performing a successful analysis, some graphing options may be disabled since the types of graphical output are controlled by the selected program options.

4-2 Types of Graphics Two types of graphics are provided by LPile; fast graphics and presentation graphics. Fast graphics are graphs that can be displayed either from the Graphics Menu or by clicking a button on the button bar. Fast graphics have limited features for modifying the graphs and their contents. Presentation charts are displayed using the Presentation Charts command from the Graphics Menu or by pressing the button on the button bar.

4-3 Graphics Mouse Commands The following mouse commands are available within a graphic window: Mouse Action

Event Description

Left click and drag down and right

Magnifies the area within the drag/release

Right click

Zoom out

Double click on legend entry

Turns the selected curve on or off

4-4 Graphics Buttons The buttons shown in Figure 4-1 will display charts of the computed results when enabled after an analysis. If the program feature required to generate a graph is not activated, the corresponding button will not be enabled.

Figure 4-1 Speed Buttons for Graphics

4-5 Graphics Menu The Graphics Menu is shown in Figure 4-2. Graphs for which buttons exist on the button bar have the identical icon as shown in the Graphics Menu entries.

81

Chapter 5 – Tools Menu

Figure 4-2 Graphics Menu

4-6 Plot Menu The Plot Menu is visible only when a fast graphic is being displayed. The Plot Menu is shown below.

82

Chapter 5 – Tools Menu

Figure 4-3 Plot Drop-Down Menu Show Legend turns the display of the graph’s legend on or off. Show Soil Layer turns the display of the soil profile on or off on graphs of pile response versus depth. The soil profile is not shown on other types of graphs Show Markers can either turn the display of data point markers on or off or change the increment for the display of the markers. Markers can be displayed at every point, second point, fifth point, or tenth point. Font Size is used to change the size of the fonts used on the graph. Line Width is used to change the width of the graph lines. Graph Title is used to enter a graph title and to specify the position of the graph title. Edit Legend is used to edit the curve names displayed in the graph’s legend. Active Curves is used to turn the display of individual curves on or off. Print is used to print the graph on the active printer. Page Setup is used to change the active printer and to configure the page margins. Save To Disk is used to save the currently displayed graph to disk as a bitmap file. The Presentation Charts utility is used to save the graph in other graphics file formats. See Section 49 for more information about the Presentation Charts utility.

4-7 Graphics of Input Data 4-7-1 View Pile-Soil Geometry This Graphics Menu command displays a graphical representation of the side view of the modeled pile and soil layers. This command becomes active after data of Pile Properties, Soil Layers, Soil Weight, and Soil Strength have been entered under the Data Menu, or when opening previously-executed data files. The angles of ground slope and pile batter and the proportions of the pile sections are accurately portrayed in this view. 83

Chapter 5 – Tools Menu 4-7-2 Summary Charts of Soil Properties This Graphics Menu command displays summary charts of soil properties. The number of charts varies from four to eight charts, depending on the soil layer types contained in the soil profile. An example of the Summary Charts of Soil Properties is shown in Figure 4-4.

Figure 4-4 Example of Summary Graphs of Soil Properties 4-7-3 -Input p-y Curves This Graphics Menu command displays charts of any -input p-y curves entered as data. If no curves are input, this Graphics command will not be enabled. The -input p-y curves displayed by this graphics command are plotted using the input data for the curves at the top and bottom of the soil layer. The curves displayed with this graphics command are not interpolated with depth. 4-7-4 Distributed Lateral Loads vs. Depth This Graphics Menu command displays charts of distributed lateral loads versus depth for both conventional analysis and LRFD analysis modes of computation. 4-7-5 p and y Modifiers versus Depth This Graphics Menu command displays charts of p and y modifiers versus depth and the ratio of the p and y modifiers versus depth. In computations, the ratio of the p and y modifiers is used to adjust the p-y curves when computing the effective soil modulus. Thus, if the ratio is equal to the default ratio of 1, the p-y curves are not modified in the computations.

84

Chapter 5 – Tools Menu

4-8 Graphics of Computational Results 4-8-1 View Results The View Results button displays summary charts of the principal results from the last computation. The type and number of charts displayed in the View Results window depends on the Program Options selected for the computation. The minimum number of charts displayed is three and the maximum number of charts displayed is eight. An example of the View Results window is shown in Figure 4-5.

Figure 4-5 Example of View Results Window 4-8-2 p-y Curves at -specified Depths LPile is capable of generating graphs of internally generated p-y curves at -specified depths located between the lower of the ground surface or top of pile and the pile tip. This graphics command is enabled if the asked the program to print p-y curves for verification purposes by checking in the Program Options and Settings dialog (see Section 3-4-4 for further information). When specified, the graphics dialog will show the p-y curves for all specified depths. If no p-y curves were output, this Graphics command will not be enabled (grayed out). 4-8-3 Lateral Deflection versus Depth This Graphics Menu command displays a graph lateral deflection versus depth for the modeled pile. This curve is automatically generated in all analytical runs for a laterally loaded pile. The number of points on the deflection curve is equal to the selected number of pile increments. Several curves may be contained in this graphics if the selects to input several load cases.

85

Chapter 5 – Tools Menu 4-8-4 Bending Moment versus Depth This Graphics Menu command displays a graph bending moment versus depth along the pile. This curve is automatically generated in all analytical runs for a laterally loaded pile. The number of points on the moment curve is equal to the selected number of pile increments. Several curves may be contained in this graphics if the selects to input several load cases. 4-8-5 Shear Force versus Depth This Graphics Menu command displays a graph of shear force versus depth along the pile. This curve is automatically generated in all analytical runs for a laterally loaded pile. The number of points on the shear curve is equal to the selected number of pile increments. Several curves may be contained in this graphics if the selects to input several load cases. 4-8-6 Mobilized Soil Reaction versus Depth This Graphics Menu command displays a graph of soil reaction versus depth along the pile. This curve is automatically generated in all analytical runs for a laterally loaded pile. The number of points on the soil-reaction curve is equal to the selected number of pile increments. Several curves may be contained in this graphics if the selects to input several load cases. 4-8-7 Deflection, Moment, and Shear Force versus Depth This Graphics Menu command displays three side-by-side graphs of pile deflection, bending moment, and shear force versus depth along the pile. This graphical display can be shown for all analytical runs for a laterally loaded pile. The scaling for the depth axis is the same for all three graphs and allows for comparison of pile deflection, bending moment and shear force values versus depth along the pile. 4-8-8 Deflection, Curvature, and Moment versus Depth This Graphics Menu command displays three side-by-side graphs of pile deflection, bending curvature, and bending moment versus depth along the pile. This graphical display can be shown for all analytical runs for a laterally loaded pile. The scaling for the depth axis is the same for all three graphs and allows for comparison of pile deflection, bending curvature, and bending moment values versus depth along the pile. This graph may be useful in analyses of pile response due to loading by lateral spread of soil after seismic events. 4-8-9 Mobilized Pile EI versus Depth This Graphics Menu command is available when the pile has a nonlinear momentcurvature relationship. This chart shows the value of mobilized EI along the length of the pile. This chart is useful to display the sections with either cracked-section EI or where plastic hinges develop. 4-8-10 Load versus Top Deflection This Graphics Menu command is enabled if the specifies two or more load cases in the input data. The specified load cases must have varying lateral loads with or without changes in applied moments or applied axial loads. The may select this Graphics command to display a graph of curve of applied lateral load versus pile-top deflection.

86

Chapter 5 – Tools Menu 4-8-11 Load versus Max Moment This Graphics Menu command is enabled if the specifies two or more load cases in the input data. The specified load cases must have varying lateral loads with or without changes in applied moments or applied axial loads. The may select this Graphics command to display a graph of applied lateral load versus maximum bending moment along the pile length. 4-8-12 Top Deflection versus Pile Length This Graphics Menu command is enabled if the selects Generate Pile Length versus Top Deflection option for a load case for conventional loading. The may select this Graphics command to display a graph of pile length versus pile-head deflection for the load cases evaluated with this option. 4-8-13 Moment versus Curvature This Graphics Menu command is enabled whenever the nonlinear bending is evaluated for a pile section. The may select this Graphics command to display a graph of bending moment versus curvature. These curves are helpful to find the ultimate bending moment of the modeled cross section. The number of curves depends on the number of axial loads used for section analysis or the number of axial thrust forces defined by the pile-head loading conditions. 4-8-14 EI versus Moment This Graphics Menu command is enabled whenever the nonlinear bending is evaluated for a pile section. The may select this Graphics command to display a graph of bending stiffness versus bending moment. Values of bending stiffness shown in these curves are used internally in each finite increment of pile analysis when the selects the analysis of pile response with nonlinear EI. The number of curves depends on the number of axial loads specified for section analysis. 4-8-15 Interaction Diagram This Graphics Menu command is enabled if the selected to perform a section analysis and inputs several axial thrust load cases for the analysis. The may select this Graphics command to display an unfactored interaction diagram (ultimate bending moment versus axial load) of the modeled cross section. These curves are helpful to find the ultimate bending moment for several axial load cases in the modeled cross section. The number of curves depends on the number of axial loads used for section analysis or the number of axial thrust loads defined by the pile-head loading conditions. 4-8-16 All K’s versus Deflection and Rotation This Graphics Menu command displays six charts simultaneously of K22, K23, K32, K33 versus pile-head displacement and rotation plus pile-head reactions and displacements for freehead and fixed-head pile fixity conditions. 4-8-17 All K’s versus Shear and Moment The Graphics Menu command displays six charts simultaneously of K22, K23, K32, K33 versus pile-head shear and moment plus pile-head reactions and displacements for free-head and fixed-head pile fixity conditions.

87

Chapter 5 – Tools Menu 4-8-18 Individual K’s versus Force and Moment This Graphics Menu command opens a submenu for displaying the individual curves of pile-head stiffnesses versus force and moments. The submenu is shown in Figure 4-6.

Figure 4-6 Sub-menu for Pile-head Stiffnesses versus Pile-head Force and Moment 4-8-18-1 K22 versus Pile-head Shear Force This Graphics Menu command is enabled when the Generate Foundations Stiffness option is selected. When enabled, the selection of this command will show a curve of the K22 (shear force/deflection) component of a 66 foundation stiffness matrix. The should refer to Section 3-12-4 for more information about the feature for computing pile-head stiffnesses. 4-8-18-2 K23 versus Pile-head Shear Force This Graphics Menu command is enabled when the Generate Foundations Stiffness option is selected. When enabled, the selection of this command will show a curve of the K23 (shear force/rotation) component of a 66 foundation stiffness matrix. The should refer to Section 3-12-4 for more information about the feature for computing pile-head stiffnesses. 4-8-18-3 K32 versus Pile-head Moment This Graphics Menu command is enabled when the Generate Foundations Stiffness option is selected. When enabled, the selection of this command will show a curve of the K32 (moment/deflection) component of a 66 foundation stiffness matrix. The should refer to Section 3-12-4 for more information about the feature for computing pile-head stiffnesses. 4-8-18-4 K33 versus Pile-head Moment This Graphics Menu command is enabled when the Generate Foundations Stiffness option is selected. When enabled, the selection of this command will show a curve of the K33 (moment/rotation) component of a 6×6 foundation stiffness matrix. The should refer to Section 3-12-4 for more information about the feature for computing pile-head stiffnesses. 4-8-19 Individual K’s versus Pile-head Deflection and Rotation This Graphics Menu command opens a submenu for displaying the individual curves of pile-head stiffnesses versus pile-head deflection and rotation. The submenu is shown in Figure 4-7.

Figure 4-7 Submenu for Pile-head Stiffnesses versus Deflection and Rotation

88

Chapter 5 – Tools Menu 4-8-19-1 K22 versus Pile-head Deflection This Graphics Menu command is enabled when the Generate Foundations Stiffness option is selected. When enabled, the selection of this command will show a curve of the K22 (shear force/deflection) versus pile top deflection. 4-8-19-2 K23 versus Pile-head Rotation This Graphics Menu command is enabled when the Generate Foundations Stiffness option is selected. When enabled, the selection of this command will show a curve of the K23 (shear force/rotation) versus pile top rotation. 4-8-19-3 K32 versus Pile-head Deflection This Graphics Menu command is enabled when the Generate Foundations Stiffness option is selected. When enabled, the selection of this command will show a curve of the K32 (moment/deflection) versus pile top deflection. 4-8-19-4 K33 versus Pile-head Rotation This Graphics Menu command is enabled when the Generate Foundations Stiffness option is selected. When enabled, the selection of this command will show a curve of the K33 (moment/rotation) versus pile top rotation. 4-8-20 Pushover Shear Force versus Top Deflection This Graphics Menu command is available only if the Pushover Analysis option was selected. This graph may contain either one or two curves depending on the pile-head fixity condition selected in the Controls for Pushover Analysis. This graph shows the pile-head shear force developed as a function of pile-head deflection. For piles with nonlinear bending, it may be possible to see the point at which a plastic hinge develops, but this point may be more easily seen in the graph of pushover moment versus top deflection, discussed subsequently. 4-8-21 Pushover Moment versus Top Deflection This Graphics Menu command is available only if the Pushover Analysis feature was activated. This graph may contain either one or two curves depending on the pile-head fixity condition selected in the Controls for Pushover Analysis. The moment value displayed in the graph is the maximum moment developed in the pile. If the pile has a single section with nonlinear bending properties, it is possible to see at which value of top deflection the moment capacity is reached by where the curve becomes horizontal. If the pile has more than one section with different moment capacities, it may not be possible to determine when the moment capacity is reached in sections with lower moment capacities. 4-8-22 Pile Buckling Thrust versus Top Deflection This Graphics Menu command is available only in the Pile Buckling Analysis feature was activated. LPile can graph both the pile buckling thrust versus computed pile top deflection, the fitted hyperbolic curve, and the estimated pile buckling capacity determined from the fitted hyperbolic curve. A typical graph for pile buckling analysis is shown in Figure 3-53.

89

Chapter 5 – Tools Menu 4-8-23 Deflection and Soil Movement versus Depth This Graphics Menu command displays a combined chart of lateral pile deflection and input soil movements versus depth.

4-9 Presentation Charts This Graphics Menu command opens a graphing tool to customize the various aspects of a presentation chart, such as font type, size, and style, line colors, styles, and widths, data point markers, legend text and font, and axis and grid scaling. A detailed description of each function and options are given in the associated Help file for the Presentation Charts tool. The Presentation Charting utility can generate up to 28 different types of graphs. The type of chart is selected from the drop-down combo box above the chart. Note that only the charts capable of being drawn are offered in the drop-down combo box. If desired by the , two graphs can be displayed side-by-side. While both graphs may be edited and exported, chart templates can be saved and applied to only the left chart. 4-9-1 Saving and Applying Presentation Chart Templates After the left chart has been edited for export, a chart template with these chart features and font styles may be saved for later application for each type of chart (i.e. use separate templates for graphs of p-y curves, lateral deflection vs. depth, moment vs. depth, etc.). The chart template files are saved in the same folder as the other data and output files for LPile. The chart template files will have the filename extension “tee.” The chart settings saved in the chart template include the axis scaling settings. If a chart template contains fixed axis scaling settings, the chart may not display the complete range of results after it has been applied and require some editing to restore the display of the full range of results. Thus, it is recommended that the chart axis scaling remain in the automatic mode prior to saving the chart template. 4-9-2 Exporting Presentation Charts It is possible to export and save the presentation charts in several graphics formats. In addition, it is possible to copy graphs to the Windows clipboard for pasting into word processing or graphical presentation programs such as Microsoft Word and Microsoft PowerPoint. Most s find using the Enhanced Windows Metafile graphics format to be most flexible in use, highest in quality, and to result in the smallest word processing file size. 4-9-3 Creating Graphs for Reports The following procedure has been found to be useful to prepare graphics for reports that are uniform in format. 1.

2. 3. 4.

Create an empty table to contain each graph. This table should contain one cell for the graph that is formatted with fixed dimensions to be the standard size for the report graph. Cell borders and title blocks to contain graph title information and company logos can also be included and be formatted to the desired dimensions and styles. Save the empty table as a separate file for re-use later. Copy the empty table for each required graph. Fill in the cells with the necessary title blocks and company logos.

90

Chapter 5 – Tools Menu

6. 7. 8. 9. 10. 11. 12.

Create the graphs using the Presentation Graphics utility in LPile, applying a presentation chart template to assure uniformity in appearance. Click the button to Edit or Print Chart. Modify the graph as desired (this may not be required if a presentation chart template is being applied. Click the Export tab on the top tab row. Select “as Metafile” and check the box for Enhanced Click the Copy button to copy the graph to the Windows Clipboard. Switch back to the word processing program and position the cursor in the cell for the graph. Paste the graph into the cell. The size of the graph may need to be resized to fit the table cell. An example of a report graph prepared using the procedure above is shown in Figure 4-8.

Lateral Deflection vs. Depth Deflection, in. -0.1 0

0

0.1

0.2

0.3

0.4

0.5

0.6

0.7

5

10

Depth, ft

5.

15

20

25

b c d e f g

Loading Case 1 g b c d e f

Loading Case 2

Insert Title for Figure Here

Insert Project Title Block Here

Insert Figure Numbering Here

Insert Company Logo Figure 4-8 Example of Table for a Report Graph 91

Chapter 5 – Tools Menu

(This page was deliberately left blank)

92

Chapter 5 Tools Menu The Tools Menu is activated from the Main Menu bar of the program. The Tools Menu has six entries. The functions of these entries are discussed in the following sections of this chapter. The Tools Menu has the six entries shown in Figure 5-1.

Figure 5-1 Tools Menu

5-1 Simple Calculator The first entry of the Tools Menu provides a simple calculator for the ’s convenience. When active, the simple calculator appears as shown in Figure 5-2.

Figure 5-2 Simple Calculator

93

Chapter 5 – Tools Menu The calculator has two display areas. A “tape” display is shown on top. The tape display shows the sequence of calculator operations. The answer display is shown below the tape display. The buttons on the top of the calculator buttons have the following functions:    

CT Back CE C

Clears the content of the tape display, Deletes the last digit entered (a backspace key), Clears the last full number entered into the calculator, and Clears all the numbers entered into the calculator.

The function buttons on the right-hand side of the calculator have the following functions:   

Sqrt % 1/x

Computes the square root of the current number, Divides the current number by 100 to express the number as a percentage, and Computes the reciprocal of the current number.

The buttons on the left-hand side of the calculator control the memory functions. The memory functions are:     

MS M+ M– MC MR

Store a number to memory, Add the current number to the number stored in memory, Subtract the current number from the number stored in memory, Clear (erase) the number stored in memory, and Recall the number stored in memory.

Note that the MC and MR buttons are enabled only when a number is stored in memory.

5-2 Battered Pile Load Calculator The second entry of the Tools Menu provides a special-purpose calculator to compute axial and transverse forces acting on battered piles from horizontal and vertical loadings. This calculator is intended only for use with conventional analyses in which lateral loading is applied perpendicular to the axis of the unbent pile and axial loads are applied along the axis of the pile. This calculator obtains the batter angle of the pile from the input value for pile batter and the values of horizontal and vertical loading from the input fields of the calculator. Values of transverse shear force and axial force for the specified batter angle are computed when the presses the button to Compute and Chart Rotated Forces. The Chart that is generated shows how the rotated forces vary over batter angles ranging from –45 to +45 degrees. The symbols on the curves indicate the values for the specified batter angle. The computation performed by the calculator is VT   cos    PA   sin 

94

sin   VH    cos    Pv 

Chapter 5 – Tools Menu

Figure 5-3 Battered Load Calculator Where:



is the batter angle in radians,

VH

is the horizontal force,

PV

is the vertical force,

VT

is the shear force perpendicular to the pile axis, and

PA

is the axial force along the pile axis.

5-3 Custom Reinforcing Bar Data Entry and Editing The third to fifth entries provide a means of entering addition sizes of reinforcing steel bar sizes to LPile. Note that this feature provides a means of entering hollow bars and steel access tubes.

95

Chapter 5 – Tools Menu

Figure 5-4 Dialog for Editing of Custom Rebar Data The third entry displays an input table to enter and edit the data for the custom reinforcing bar sizes. The fourth entry will transfer the data for custom reinforcing bars into the memory of LPile and enter the names of the bars into the drop-down combination edit controls for selection of the size of reinforcing bars. Note that the custom bar sizes are at the bottom of the drop-down lists for bar sizes available for normally reinforced concrete sections. The fifth entry saves the custom bar sizes to a data file named Custom_Rebar.dat. This data file is stored in the same program folder as the main LPile program. When LPile is started, LPile checks the program folder for a file with this name. If the file is found, it is read and the data is stored into program memory. Thus, it is not necessary for the to re-enter the custom bar data each time the program is run. Whenever the wishes to exchange data files with another , the data file for custom bar sizes should also be provided to the other , as the full list of custom bar sizes is not included as part of the LPile data file.

5-4 Multi-File Analysis (Batch Run Utility) The sixth entry provides a feature to define a list of existing LPile data files to be run as a batch and the command to perform the batch analysis. The control dialog for multi-file analysis is shown in Figure 5-5. The dialog is operated by adding a file to the list by pressing the Add File to List button. The Add File to List button will open an input dia which either single or multiple files can be selected from any folder. The list of selected files is shown in the upper text pane of the control dialog. 96

Chapter 5 – Tools Menu

Figure 5-5 Dialog for Multi-File Analysis Controls If needed, files can be deleted from the list by entering the file number and pressing the Delete File No. button. The file list may be cleared by pressing the Clean the File List button. Once the file list is complete, the directs LPile to process the list of files by pressing the Run All Analyses button. The processing time for each file and the warning or error message status of each file is shown in the lower text pane of the control dialog. This text pane displays the Run Messages If desired the file list can be saved and re-opened by pressing the appropriate buttons. Lastly, if the wishes to save the Run Messages, he may do so by pressing the Save Run Msg File button.

97

Chapter 5 – Tools Menu

(This page was deliberately left blank)

98

Chapter 6 Example Problems The problems in this chapter are provided as examples of the types of applications that may be solved using LPile. Each example focuses on a particular computational feature of the program. The input files for the examples are automatically copied to a sub-folder named Lpile2013-Examples under the common Ensoft folder on the root directory of the computer during installation. The data files are named with descriptive names and are copied to separate sub-folders. For example, the path to Example 1 is C:\Ensoft\Lpile2013-Examples\Example 1 Elastic Steel Pile in Sloping Ground\ Example problems provide information on input and output of various cases, and present a quick tutorial for different applications. The is encouraged to study these examples and, with modifications, may use them to solve similar problems. However, by no means can these limited examples explore the full functions and features provided by LPile. The main features of each example included with LPile are summarized as follows. Example 1 – Steel pile ing a retaining wall. Among other aspects, this problem uses sample applications of the following program features:     

pile made of a standard structural steel shape, modeled as elastic pile with specified moment capacity, pile-head fixed against rotation, report of internally-generated p-y curves at different depths for verification purposes, application of several lateral loads, and sloping ground surface.

Example 2 – Bored pile ing a retaining wall. This example includes the following program features:     

pile is a drilled shaft, comparison of values obtained with pile head fixed and free against rotations, application of several lateral loads, analysis with nonlinear bending stiffness, and usage of sloping ground surface.

Example 3 – Steel pile ing an offshore platform. Includes the following program features:   

pile made of two different steel sections, pile with head elastically restrained against rotations, and cyclic loading.

Example 4 – Buckling of a pile column. This example includes the following program features:   

steel pipe pile, pile head free to rotate, and application of several axial loads.

Example 5 – Ultimate bending moment for bored piles. Includes the following program features: 99

Chapter 6 – Example Problems    

reinforced concrete pile of circular cross section, nonlinear materials, report of interaction diagram, and report of nonlinear flexural rigidity.

Example 6 – Foundation Stiffness of Concrete Pile with Nonlinear Flexural Rigidity. Includes the following program features:      

reinforced concrete pile of circular cross section, pile with head free to rotate, nonlinear materials, report of interaction diagram, report of nonlinear flexural rigidity, and generation of foundation stiffness components.

Example 7 – Input of Distributed Load and External p-y Curves. Includes the following program features:    

reinforced concrete pile of circular cross section with two different section properties, pile with head free to rotate, input of distributed lateral load on a section length of pile with linear variation, and input of externally-specified p-y curves.

Example 8 – Case Study of Piles in Cemented Sands. Includes the following program features:    

reinforced concrete pile of circular cross section, pile with head free to rotate, input of several lateral loads, and use of internal p-y curves for silts.

Example 9 – Sample of Various Program Options. Includes the following program features:       

drilled shaft with reinforced concrete cross-section and belled bottom, pile with head free to rotate, sample coordinates for embedded pile head, use of p-reduction factors assuming closely spaced piles, use of several soil layers, input of shear-resistance curve at pile tip, and determination of top deflections versus varying pile lengths.

Example 10 – Drilled shaft in soft clay  

multi-section drilled shaft with under-ream and toe, and uniform rebar cage in upper sections.

Example 11 – LRFD analysis  

input of unfactored loads input of load and resistance factor combinations

Example 12 – Liquefied sand with lateral spread 

lateral spread modelled using lateral soil movement versus depth 100

Chapter 6 – Example Problems Example 13 – Top y versus pile length for square elastic pile  

example compares standard and modified versions of p-y curves for stiff clay without free water, and computation of curves of top deflection versus pile length for multiple levels of loading.

Example 14 – Pushover analysis of prestressed concrete pile Example 15 – Pile with input nonlinear bending properties Example 16 – Analysis of pile loaded by distributed lateral loads Example 17 – Analysis of double-section, rock socketed drilled shaft Example 18 – Analysis of drilled shaft with permanent casing Example 19 – Analysis of drilled shaft with permanent casing and core Example 20 – Design analysis of embedded pole Example 21 – Analysis of a tapered elastic pile Example 22 – Analysis of a tapered elastic-plastic pile Example 23 – Output of p-y curves at specified depths Example 24 – Analysis of pile loaded by soil movements Example 25 – Verification of elastic pile in elastic subgrade Example 26 – Verification of the P- effect

6-1 Example 1 – Steel Pile in Sloping Ground The general description and geometrical configuration of Example 1 is shown in 5-1. The pile is a standard structural steel shape (HP14×89), two layers of soil are present, and the ground surface is sloping downward with respect to the lateral loading. In an actual design, the data shown in this example problem might be for a particular trial run. That is, the selection of the particular section for the pile and its length might change in the course of the computations. Furthermore, the soil profile has been idealized and in an actual case there would almost certainly be a need for consideration of the variation of the soil properties with depth and across the site. The axial service load on the pile axis is 88.8 kN (20 kips). If the load factor (global factor of safety) is taken as 2.5, the axial load P to be used in the computations is 222 kN (50 kips). As it will be seen, the bending moment capacity is affected only slightly by the presence of the axial load. The sketch of the pile in Figure 6-1 shows that its top is fixed against rotation. Thus, it is assumed that the top of the steel section projects a sufficient distance into the reinforced-concrete base of the retaining wall so that no rotation of the top of the pile will occur. This assumption is not strictly true, but research is yet to be done to yield expressions for the rotation of an embedded steel member into a concrete mat. The assumption of pile-head fixity is conservative because the maximum bending moment will occur at the top of the pile and any rotation of the pile head will cause a decrease in the maximum moment.

101

Chapter 6 – Example Problems The computations that follow are aimed at finding the lateral load V that will cause a plastic hinge to develop at the top of the pile. Secondly, the computations should reveal if there is a possibility of excessive deflection, which is thought to be unlikely for most retaining walls.

P 10 V Stiff Clay g = 18.7 kN/m3 c = 96.5 kPa 50 = 0.007

15.2 m

HP14 89 Ix = 3.76 10-4 m4 fy = 276 MPa

Sand g ‘ =9.9 kN/m3 f = 35

Figure 6-1 General Description of Example 1 The pile section type selected for the analysis is the Elastic Pile with Specified Moment Capacity. With this type of section, it is possible to have the pile behave elastically up to the specified moment capacity then form a plastic-hinge when the moment in the pile equals the specified moment capacity. The strong axis of the H-pile is perpendicular to the direction of loading, and data for this axis were included in Figure 6-1. From the steel handbook, the width of the section is 373 mm (14.696 in.) and the depth is 352 mm (13.86 in.). The first consideration is the “diameter” to assign to the shape because the recommendations for p-y curves are based strongly on the results of experiments with cylindrical shapes. At the outset, it can be assumed that the soil in the flanges will move with the pile and that it will behave as a rectangular shape. Secondly, the equivalent diameter of the pile can be computed, as a first approximation, by finding a circular section with the same area as the rectangular section. Thus,

d e 2 4 de 

 (373 mm)(351 mm) 4(373 mm)(351 mm)



102

 408 mm  16.1 inches

Chapter 6 – Example Problems As shown above, this computation yields a diameter that is less than 10 percent larger than the width of the steel section. The equivalent diameter may be entered as the width of the pile, or, conservatively, the actual width of 373 mm (14.686 in.) may be entered. The decision of which value to be entered is left to the , but the actual width will be used in this example. The values used in this example are shown in Figure 6-2 below.

Figure 6-2 Dimensions and Properties Entered for Example 1 The should understand how the values entered for Dimensions and Properties can be manipulated to enter the desired data to LPile. LPile is programmed to compute values of crosssectional area and moment of inertia from the input dimension values when the presses the button to Compute Moment of Inertia and Areas and Draw Section. In the case of H-piles, often the computed areas of area and moment of inertia differ from the standard values published for design. If the wishes to replace the computed value, the may enter the standard values directly, but must not to the button to compute values. If the presses the button to compute values, the manually entered values will be replaced by the computed values. The yield moment for the section may be computed by a procedure proposed by Horne (1978). With no axial compression load and with bending about the strong axis, the plastic moment strength is computed the product of the yield stress and plastic modulus as follows:

103

Chapter 6 – Example Problems

M p  Fy Z



M p  276 2.39  10 3



M p  0.660 M N - m M p  660 kN - m Considering the effect of axial load: a

Px 2t w f y

222 (2)(0.0156)(276,000) a  0.0258 mm

a

M p  M p  twa f y M p  660  (0.0156)(0.0258) 2 (276,000) M p  657 kN - m  5,815 in - kips

In other cases where the pile extends above the ground surface, the deg engineer will need to consider the compact section properties of the pile. In some H-pile sections, the pile flanges may buckle at stress levels below the yield stress of steel and the section is called “noncompact.” For this pile section, the compact section stress criterion is 131.7 MPa. To consider the compact section criterion one substitutes the compact section stress for the yield stress. The loading from a retaining wall is a sustained static loading, not a cyclic load. In some cases, the designer is faced with the problem of estimating the consolidation and creep of the clay and/or the additional deflection due to vibration of the sand. The value of shear strength indicates that the clay is overconsolidated; thus, as a first approximation, no significant consolidation or creep is assumed. In addition, the sand, well below the ground surface, is assumed not to densify due to possible vibration. These assumptions will need to be carefully reviewed after a preliminary solution is obtained. The above discussion shows that static loading is appropriate for both the clay and the sand. Further, the recommendations for stiff clay above the water table are most appropriate. The next step is to find the value of pile-head shear force, V, that will develop a bending moment in the pile of 657 kN-m (5,815 in.-kips). The results of the preliminary computations using the displacement-slope pile-head condition are shown in Figure 6-3 and Figure 6-4. As may be seen, the computations show that the pile will fail structurally when the axial load is held at 222 kN (50 kips) and the lateral load reaches a value of 410 kN (92 kips). The pile-head deflection at the failure loading was computed to be about 27 mm (1.06 in.). This deflection is considered tolerable; therefore, the failure of the pile is taken to be due to the development of a plastic hinge.

104

Chapter 6 – Example Problems Maximum Moment vs. Top Shear 660

Maximum Moment, kN-m

640 620 600 580 560 540 520 500 480 460 440 420 400 380 360 340 320 300 280 260 240 220 200 160

180

200

220

240

260

280

300

320

340

360

380

400

420

440

Top Shear, kN LPile 2013.7.01, © 2013 by Ensoft, Inc.

Figure 6-3 Generated Curve of Lateral Load versus Maximum Moment for Example 1. Shear Force vs. Top Deflection 440 420 400 380

Shear Force, kN

360 340 320 300 280 260 240 220 200

0.005

0.01

0.015

0.02

0.025

0.03

0.035

0.04

Top Deflection, m LPile 2013.7.01, © 2013 by Ensoft, Inc.

Figure 6-4 Generated Curve of Lateral Load versus Top Deflection for Example 1. The safe loading level is found by dividing the loading at failure by 2.5, the global factor of safety, or V = 164 kN (37 kips) and P = 88.8 kN (20 kips). The output report contains a summary of the input data, along with the values of four computed p-y curves that the specified for output. The bottom section of the output report contains a table of pile response with the principal information needed by the engineer, where 105

Chapter 6 – Example Problems computed values are given as a function of depth. The table indicates that the length of the pile may be decreased to 10 m (33 ft) and that there will be three points of zero deflection, a sufficient number to ensure that the pile behaves as a long pile. By reducing the length of the pile, some unneeded output can be eliminated and, further, the amount of internal computations performed by the computer is reduced. Plots of lateral deflection and bending moment as a function of depth are shown in Figure 6-5 and Figure 6-6. The loadings for the second analysis were a V of 164 kN (37 kips) and P of 88.8 kN (20 kips). The computed deflection at the top of the pile was to be 4.0 mm (0.16 in.) and the maximum bending moment was 186 kN-m (138.5 ft-kips), a value that is well below 657 kNm (485 ft-kips) that would cause the pile to fail. The next step is to find the value of Pt that will develop a bending moment in the pile of 657 kN-m (5,815 in.-kips). Lateral Deflection vs. Depth Deflection, m -0.0005 0

0

0.0005

0.001

0.0015

0.002

0.0025

0.003

0.0035

0.004

1 2 3 4

Depth, m

5 6 7 8 9 10 11 12 13 14 15 Loading Case 1 bDepth c d e f Figure 6-5 Curve of Deflection versusg for Example 1, Second Analysis LPile 2013.7.01, © 2013 by Ensoft, Inc.

The curve shown in Figure 6-6 shows that the maximum bending moment occurs at the top of the pile, where it is fixed against rotation. If the pile head is permitted to rotate slightly, the negative moment at the pile head will decrease and the value of the maximum positive moment, now at a depth of 2.9 m (9.5 ft), will increase. Further, it is of interest to note that the bending moment is virtually zero at depths of 5 m (16.4 ft) and below. The input data and output files have the filename Example 1a HP 14x89 in sloping ground.lp9d. These files are found in the Examples folder with the program. The filename extensions for the files are shown in Table 2-1. The output files are not shown in this ’s Manual due to their length. The filename for the second run is named Example 1b HP 14x89 in sloping ground, second run.lp9d. The input and output files are not shown here due to their length.

106

Chapter 6 – Example Problems Bending Moment vs. Depth Bending Moment, kN-m -200 0

-180

-160

-140

-120

-100

-80

-60

-40

-20

0

20

40

60

80

1 2 3 4

Depth, m

5 6 7 8 9 10 11 12 13 14 15 Loading Case 1 b c d e f g Figure 6-6 Bending Moment versus Depth for Example 1, Second Analysis LPile 2013.7.01, © 2013 by Ensoft, Inc.

6-2 Example 2 – Drilled Shaft in Sloping Ground This example is similar to Example 1, but in this case, the pile is replaced by a drilled shaft (bored pile). The soil properties and ground slope angle are the same as those used in Example 1. The design issue with a reinforced-concrete pile is to find the nominal bending moment capacity and an appropriate value of flexural stiffness (EI) to use in the computations. As in Example 1, an axial thrust load of 88.8 kN (20 kips) is assumed. The pile head is assumed fixed against rotation in the first loading case and free to rotate in the second loading case. The problem is to find the lateral load for each case that will cause the shaft to fail. Both of these loading cases might be used in a practical problem to establish the bounds for the solution if the rotational restraint caused by embedment of the top of the pile causes the pile head to be between fixed and free. A drilled shaft with an outside diameter of 760 mm (30 in.) and a length of 15.2 m (50 ft) is used in this example. The reinforcing steel consists of 12 bars with outside diameter of 25 mm (corresponding to No. 8 bars in US practice) and spaced equally around a 610 mm (24 in.) diameter circle as shown in Figure 6-7. The ultimate strengths of the reinforcing steel and the concrete are 414 MPa (60 ksi) and 27.6 MPa (4.0 ksi), respectively. Example 2a is the computation and plotting of the unfactored interaction diagram. This problem is configured by selecting the Compute Nonlinear EI Only option in the Program Options and Settings dialog and by entering the structural dimensions and material properties of the pile’s cross-section. When computing an interaction diagram, the must enter the axial thrust forces for the analysis. This means that the must determine the maximum compressive and tensile axial capacities along with a number of intermediate axial thrust values. Usually, a bored pile in soil will fail by axial bearing capacity before the pile section will fail by crushing, so the upper limit may be limited by the computed axial bearing capacity, if this value is available. Otherwise, the may opt to make two analyses, the first with zero axial thrust and the second with a 107

Chapter 6 – Example Problems number of axial thrust loads. After the first run, the may read the estimated axial capacities of the pile section in compression and tension from the output report and use these values to set the upper and lower values of axial thrust for the second analysis.

Figure 6-7 Cross-section of Drilled Shaft for Example 2. An excerpt from the output report for Example 2a for the axial structural capacities is shown below: Axial Structural Capacities: ---------------------------Nom. Axial Structural Capacity = 0.85 Fc Ac + Fy As Tensile Load for Cracking of Concrete Nominal Axial Tensile Capacity

= = =

13031.123 kN -1424.929 kN -2532.072 kN

Using these values, axial thrust values were entered ranging from -2,500 to 13,000 kN. The resulting factored interaction diagram generated by the Presentation Graphics feature is shown in Figure 6-8. The curves for moment versus curvature for multiple axial thrust forces are shown in Figure 6-9 and the curves for EI versus bending moment are shown in Figure 6-10. Computations of nominal bending moment capacities are determined when the concrete compressive strain at failure equals 0.003. For the axial load of 88.8 kN, the nominal bending moment capacity, Mnom, was taken from the curve as 731.8 kN-m. For design, a resistance factor for moment capacity equal to 0.65 was assumed, which gives a factored (ultimate) moment capacity of 475.7 kN-m. The computations for nominal moment capacity could have been done for only the one axial load level, however, the full interaction diagram was developed to demonstrate the influence of axial load for this particular problem. As seen in Figure 6-8, an increase in the axial load up to a point will increase the value of the moment capacity so the axial thrust load was not multiplied by the global factor of safety to get the moment capacity.

108

Chapter 6 – Example Problems Factored Interaction Diagram 13,000 12,000 11,000

Axial Thrust Force, kN

10,000 9,000 8,000 7,000 6,000 5,000 4,000 3,000 2,000 1,000 0 -1,000 -2,000 0

100

200

300

400

500

600

700

800

900

1,000

1,100

1,200

1,300

Bending Moment Capacity, kN-m g b c d e f b c d e f g

Section 1, Rf = 1.00 f g b c d e Section 1, Rf = 0.75

Section 1, Rf = 0.65 g b c d e f

Section 1, Rf = 0.70

LPile 2013.7.01, © 2013 by Ensoft, Inc.

Figure 6-8 Factored Interaction Diagram for Example 2a.

Moment, kN-meters

Moment vs. Curvature - All Sections 1,300 1,250 1,200 1,150 1,100 1,050 1,000 950 900 850 800 750 700 650 600 550 500 450 400 350 300 250 200 150 100 50 0 0.0

0.01

0.02

0.03

0.04

0.05

0.06

0.07

0.08

Curvature, radians/meter g b c d e f b c d e f g b c d e f g b c d e f g b c d e f g

Thrust = -2500.00 kN f g b c d e Thrust = 0.00 kN b c d e f g

Thrust = -2000.00 kN f g b c d e Thrust = 1000.00 kN g b c d e f

Thrust = -1425.00 kN f g b c d e Thrust = 2000.00 kN g b c d e f

Thrust = -1000.00 kN

Thrust = 4000.00 kN f g b c d e Thrust = 8000.00 kN g b c d e f

Thrust = 5000.00 kN f g b c d e Thrust = 9000.00 kN g b c d e f

Thrust = 6000.00 kN f g b c d e Thrust = 10000.00 kN g b c d e f

Thrust = 7000.00 kN

Thrust = 12000.00 kN g b c d e f

Thrust = 13000.00 kN

Thrust = 3000.00 kN Thrust = 11000.00 kN

LPile 2013.7.01, © 2013 by Ensoft, Inc.

Figure 6-9 Moment-Curvature Diagram for Example 2a.

109

0.09

Chapter 6 – Example Problems

EI, kN-m²

EI vs. Moment - All Sections 520,000 500,000 480,000 460,000 440,000 420,000 400,000 380,000 360,000 340,000 320,000 300,000 280,000 260,000 240,000 220,000 200,000 180,000 160,000 140,000 120,000 100,000 80,000 60,000 40,000 20,000 0 0

100

200

300

400

500

600

700

800

900

1,000

1,100

1,200

1,300

Bending Moment, kN-m g b c d e f b c d e f g b c d e f g b c d e f g b c d e f g

Thrust = -2500.00 kN f g b c d e Thrust = 0.00 kN b c d e f g

Thrust = -2000.00 kN f g b c d e Thrust = 1000.00 kN g b c d e f

Thrust = -1425.00 kN f g b c d e Thrust = 2000.00 kN g b c d e f

Thrust = -1000.00 kN

Thrust = 4000.00 kN f g b c d e Thrust = 8000.00 kN g b c d e f

Thrust = 5000.00 kN f g b c d e Thrust = 9000.00 kN g b c d e f

Thrust = 6000.00 kN f g b c d e Thrust = 10000.00 kN g b c d e f

Thrust = 7000.00 kN

Thrust = 12000.00 kN g b c d e f

Thrust = 13000.00 kN

Thrust = 3000.00 kN Thrust = 11000.00 kN

LPile 2013.7.01, © 2013 by Ensoft, Inc.

Figure 6-10 Bending Stiffness versus Bending Moment for Example 2a. In earlier versions of LPile, the had to select a constant value of bending stiffness to use in an analysis. This is no longer needed, as LPile will automatically vary the value of bending stiffness in proportion to the bending curvature developed in the pile. The load-deflection curves and moment versus shear force curves for free-head conditions are shown in Figure 6-11 and for fixed-head conditions are shown in Figure 6-12. The scales of the two figures have been set equal to aid comparing the two sets of graphs. The free-head shaft reaches its nominal moment capacity at a shear load of approximately 530 kN and its factored moment capacity at a shear load of 346 kN at a deflection of 0.035 m. The fixed-head shaft reaches it nominal moment capacity at a shear load of 550 kN and its factored moment capacity at a shear load of 352 kN at a deflection of 0.0076 m. By happenstance, the load-carrying capacity of the two pile-head conditions are nearly equal. However, the load-deflection response of the fixed-head shaft is substantially stiffer. To illustrate the differences in deflection and bending moment versus depth for the two pile-head fixity conditions, a fourth analysis was performed for pile-head shear loads equal to 346 for the free-head shaft and 352 kN for the fixed-head shaft. The results of this analysis are shown in Figure 6-13. The length of the pile may be reduced if there are more than two points of zero deflection, which ensures that the pile acts as a stable pile. The LPile can perform a series of analyses with different lengths of piles, so the can compare pile length versus deflection at the pile head. The curves of top deflection versus pile length for free and fixed-head conditions is shown in Figure 6-14.

110

Chapter 6 – Example Problems

Maximum Moment vs. Top Shear

Shear Force vs. Top Deflection 800

750

750

700

700

650

650

600

Maximum Moment, kN-m

600

Shear Force, kN

550 500 450 400 350 300 250

550 500 450 400 350 300 250

200

200

150

150

100

100

50

50

0 0

0.01 0.02 0.03 0.04 0.05 0.06 0.07 0.08 0.09

0.1

0 0

0.11 0.12 0.13 0.14 0.15

50

Top Deflection, m

100 150 200 250 300 350 400 450 500 550 600 650 700 750 800

Top Shear, kN

Figure 6-11 Shear Force versus Top Deflection and Maximum Bending Moment versus Top Shear Load for Free-head Conditions in Example 2b. Shear Force vs. Top Deflection

Maximum Moment vs. Top Shear

800

750

750

700

700

650

650

600

Maximum Moment, kN-m

600

Shear Force, kN

550 500 450 400 350 300 250

550 500 450 400 350 300 250

200

200

150

150

100

100

50

50

0 0

0.01 0.02 0.03 0.04 0.05 0.06 0.07 0.08 0.09

0.1

0.11 0.12 0.13 0.14 0.15

0 0

50

100 150 200 250 300 350 400 450 500 550 600 650 700 750 800

Top Shear, kN

Top Deflection, m

Figure 6-12 Shear Force versus Top Deflection and Maximum Bending Moment versus Top Shear Load for Fixed-head Conditions in Example 2c.

111

Chapter 6 – Example Problems

Bending Moment, kN-m

Deflection, m 0

0.005

0.01

0.015

0.02

0.025

0.03

-500 0

0.035

1

1

2

2

3

3

4

4

Depth, m

Depth, m

-0.005 0

5

6

7

7

8

8

9

9

10

10 Free-head Shaft g b c d e f

-300

-200

-100

0

100

200

300

400

500

5

6

b c d e f g

-400

b c d e f g

Fixed-head Shaft

Free-head Shaft g b c d e f

Fixed-head Shaft

Figure 6-13 Results for Free-head and Fixed-head Loading Conditions for Example 2d 0.17 0.16 0.15 0.14 0.13

Top Deflection, m

0.12 0.11 0.1 0.09 0.08 0.07 0.06 0.05 0.04 0.03 0.02 0.01 0

1

2

3

4

5

6

7

8

9

10

Pile Length, m b c d e f g

Free-head Shaft g b c d e f

Fixed-head Shaft

Figure 6-14 Top Deflection versus Pile Length for Example 2d Perhaps it is of interest to note that the lateral loads that were computed for the steel pile and for the bored pile were of significant magnitude, indicating that different types of piles can be used economically to sustain lateral loads.

112

Chapter 6 – Example Problems

6-3 Example 3 – Offshore Pipe Pile The illustration in Figure 6-15 shows an offshore platform of the type used in water depths of 100 m or more. Thousands of such structures have been built where a structure is fabricated on shore, barged or floated to the site, and placed by lifting or controlled submergence. For the case indicated, the weight of the jacket causes the extensions of the legs to push into the soil. With the top of the template above still water, piles are stabbed and driven through the main legs. The tops of the piles are trimmed, and welded to the jacket, and the annular space between the outside of the piles and the inside of the jacket leg is filled with grout. Finally, a deck section is lifted and its columns are stabbed into the tops of the main legs and then welded.

Figure 6-15 Idealized View of an Offshore Platform Subjected to Wave Loading, Example 3 The soil profile at the site is not shown in the sketch. In this example, it is soft clay with some overconsolidation due to wave action at the mudline, but with an increase in strength with depth as for normal consolidation. An assumption is made that some scour will occur around the piles to a depth of 1.5 meters (5 feet). The undrained strength of the clay at that depth is 24 kPa (500 psf) and the strength at 30 m is 72 kPa (1,500 psf). The submerged unit weight is 9.00 kN/m3 (57 pcf); 50 is 0.02 at 1.5 m (5.0 ft) and decreases to 0.01 at 30 meters (98 feet). The sketches of Figure 6-16 show one of the piles from the structure with the rotational restraint given approximately by an equation. The number 3.5 indicates that the bracing has been discounted and that the member is acting as one whose far end is intermediate between fixed and free. The approximation is adequate for a preliminary solution but, for the final analysis, the superstructure and the piles should be considered as continuous, and the piles analyzed as a group. 113

Chapter 6 – Example Problems

h = 6.1 m

St 

d = 838 mm Ic = 5.876 x 10-3 m4

h Mt 3.5EI c

M 4m

V

V

M

d = 762 mm Ip = 3.07 x 10-3 m4 E = 2 x 108 kPa

Figure 6-16 Superstructure and Pile Details, Example 3 The critical loading occurs during a severe storm, and Figure 6-15 shows the approximate position of a wave as it moves past the structure. The selection of a particular wave height and velocity of the wind is a problem in statistics, and the factor of safety to be employed is related to those selections. For this problem, it is assumed that a load factor of 2.4 is appropriate. The axial loading of the pile that is analyzed is 1,250 kN (281 kips); thus, the load in the design computations is 3,000 kN (674 kips). A solution consists of finding the lateral loading that will cause a plastic hinge to develop in the pile, and the safe load by dividing that load by the global factor of safety. The sketch in Figure 6-16 shows that the pile to a distance of 4.0 m (13.1 ft) from its top consists of two pipes that are acting together. The outside diameter of this combined section is 838 mm (33 in.), the wall thickness is 28.14 mm (1.11 in.), and its moment of inertia is 5.87610-3 m4 (4,117 in4). The lower section has an outside diameter of 762 mm (30 in.), a wall thickness of 19.05 mm (0.75 in.), and a moment of inertia of 3.07010-3 m4 (7,376 in4). The ultimate strength of the steel for the piles is assumed is 0.395 MPa (57,290 psi). Figure 6-17 shows the results of computations for the moment versus curvature analysis of the sections of the pile in the example. As shown in the Technical Manual, the stress-strain curve for the steel is assumed as bilinear; thus, the ultimate bending moment will continue to increase slightly as the full section of the pile approaches the plastic range. It was decided to accept the value of Mnom as the value where the maximum curvature is 0.015 radians/meter. For the upper section, a nominal moment capacity of 7,140 kN-m was computed. The corresponding value for the lower section of the pile was 4,040 kN-m.

114

Chapter 6 – Example Problems

7,500 7,000 6,500 6,000

Moment, kN-m

5,500 5,000 4,500 4,000 3,500 3,000 2,500 2,000 1,500 1,000 500 0 0.0

0.0025

0.005

0.0075

0.01

0.0125

0.015

0.0175

0.02

0.0225

0.025

Curvature, radians/meter b c d e f g

Section 1, Thrust = 1250.00 kN g b c d e f

Section 2, Thrust = 1250.00 kN

Figure 6-17 Moment versus Curvature, Example 3 The soil conditions at the site are in the range of soft clay below the water, and the recommendations for that soil are employed in the computations. Cyclic loading is employed because the design is to reflect the response of the structure to a storm. Some comment is needed about the number of cycles of loading. If the documentation is reviewed for the experiments that resulted in the development of the recommendations, it will be noticed that the cycles of loading were continued until an apparent equilibrium was reached; thus, the criteria reflect the limiting condition (or worst condition). However, during a particular storm, there may be only a small number of loads of the largest magnitude during the peak of the storm. Therefore, the recommendations may be somewhat more conservative than necessary, but at the present, recommendations are unavailable to allow the introduction of the number of cycles into the procedure. In reference to the previously shown Figure 6-16, initial computations were necessary to learn if the lateral loading on the selected pile would cause a critical moment in the upper or lower section. A series of computer runs and plots were made of the maximum moment as a function of Vtop for both the upper and lower sections. Figure 6-18 shows that the maximum moment for the upper section, 7,140 kN-m and negative in sign, occurred with a lateral load of 1,200 kN. At that value of Vtop, the maximum moment for the lower section was about 2,500 kNm, which was far less than the yield value of 4,040 kN-m. Thus, the upper section of the pile controls the loading. The deflection of the top of the pile, ytop, for the failure loading of 1,200 kN was computed to be 339 mm and, in some designs, the deflection might have controlled the loading. However, the computed deflection will be much less when the factored load is used; furthermore, excessive deflection is rarely a problem in the design of an offshore platform. It is true that personnel could experience distress on a deck that was moving radically; however, in normal

115

Chapter 6 – Example Problems circumstances, the personnel are removed from the platform during the occurrence of the design storm. 8,000

7,000 Sect. 1 Mmax

Moment, kN-m

6,000

Sect. 2 Mmax Sect. 1 Mnom

5,000

Sect. 2 Mnom

4,000 3,000 2,000 1,000

0 0

250

500

750

1,000

1,250

Pile-head Shear, kN

Figure 6-18 Results of Initial Computation with p-y Curves, Example 3 Employing a load factor of 2.4 (global factor of safety), the service value of pile-head shear force Vtop is 500 kN and, as noted before, the axial thrust force Q is 1,250 kN. The resulting moment diagram is shown in Figure 6-19. The computed value of pile-head deflection ytop, not plotted here, was 62 mm, which is acceptable. An examination of Figure 6-19 finds that the moment diagram is virtually zero below a depth of 21 m; therefore, the selection of the thickness of the wall of the pile below this depth will be based on the requirements of pile driving analysis and axial pile capacity, rather than lateral loading. Additionally, it is evident that the maximum bending moment could be reduced significantly if the designer has some control over the value of the rotational restraint at the mudline. Thus, the opportunity exists for minimizing the cost of the foundation by a judicious selection of the manner in which the piles are connected to the superstructure. For example, a less expensive solution could have been achieved if shims had been used at the bottom of jacketleg extension and at the ts, with the result that no grouting would have been needed. Finally, the thick-walled section of the pile, whatever the final design, will be needed in the upper 21 m; therefore, the methods of installation must be such that the pile can be installed to the required penetration into the soil profile.

116

Chapter 6 – Example Problems

Bending Moment, kN-m

Deflection, m 0

0.01

0.02

0.03

0.04

0.05

0.06

-2,500 0

0.07

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11 12 13 14

Depth, m

Depth, m

-0.01 0

-2,000

-1,500

-1,000

-500

0

500

1,000

11 12 13 14

15

15

16

16

17

17

18

18

19

19

20

20

21

21

22

22

23

23

24

24

25

25

Figure 6-19 Pile Deflection and Bending Moment versus Depth for Vtop = 500 kN, Example 3

6-4 Example 4 - Buckling of a Pile-Column One analytical feature of LPile is an automatic analysis for buckling capacity of a pile. It is not often that such a problem is encountered in practice, but a rational solution is desired if such a problem occurs. In this example, the lateral load at the pile head is 44.5 kN (10 kips) and the loading was static. The lateral load and the axial load are applied at the top of the pile, which was 2.5 m (8.3 ft) above the groundline. The bending moment at the pile head is zero. The solution to the problem seeks the same answer as does the Euler solution for a column, but, because the response of the soil is nonlinear, an Eigen value solution is not applicable. Rather, the answer is obtained by successive solutions of the nonlinear, beam-column equation with the axial load being increased until excessive lateral deflection is computed or the bending moment capacity of the pile is fully mobilized. The example pile is an elastic steel pipe, 610 mm (24 in.) in outside diameter, and with a wall thickness of 22.2 millimeters (0.875 inch). The EI is 354,312 kN-m2 (1.2351011 lb-in2). The length is 15.2 meters (50 feet). Had the portion of the pile above the groundline been greater than 2.54 m (8.33 ft), the buckling load that was found would have been much less than the computed value. The soil profile is sand with an angle of internal friction of 35 degrees. The water table is below the tip of the pile. The effective unit weight of the sand is 19 kN/m3 (121 pcf). The p-y curves for static loading of sand above the water table are appropriate for the problem. Presumably, the soil properties are those that exist after the pile has been installed. The results from the pile buckling analysis are shown in Figure 6-20. Note that this figure was drawn for this manual and was not generated by LPile, The deflection at the top of the pile,

117

Chapter 6 – Example Problems as a function of the axial thrust force is shown as the black line and the maximum bending moment as the blue line. The estimated buckling capacity is shown by the red line (19,592 kN). 900

0.045 Top Deflection Max. Moment Est. Buckling Cap.

0.04

700

0.035

600

0.03

500

0.025

400

0.02

300

0.015

200

0.01

100

0.005

0 0

5,000

10,000

15,000

Pile Top Deflection, meters

Maximum Moment, kN-m

800

0 20,000

Axial Thrust Force, kN

Figure 6-20 Pile-head Deflection and Maximum Bending Moment versus Axial Thrust Loading LPile estimates the pile buckling capacity by fitting a hyperbolic curve to the computed results of top deflection versus axial thrust force. The procedure used to fit the hyperbolic curve is discussed in Section 3-12-6. A graph of the pile buckling analysis results generated by LPile for Example 4 is shown in Figure 6-21. While the solution to the problem appears to be rather straightforward using LPile, there presently are no other analytical solutions for pile buckling available to take the nonlinear load transfer from the pile to the soil into . It is also important to note that the pile buckling analysis feature of LPile can also be used to investigate the effects of the eccentric application of axial loading and the effect of accidental batter.

118

Chapter 6 – Example Problems

Free-head Condition

Axial Thrust Load, kN

20,000 19,000 18,000 17,000 16,000 15,000 14,000 13,000 12,000 11,000 10,000 9,000 8,000 7,000 6,000 5,000 4,000 3,000 2,000 1,000 0 0

0.01

0.02

0.03

0.04

Top Deflection, m Pile Response Computed by LPile Buckling Capacity = 19,592 kN

Fitted Hyperbolic Buckling Curve

LPile 2013.7.07, © 2014 by Ensoft, Inc.

Figure 6-21 Results from LPile Solution for Buckling Analysis, Example 4

6-5 Example 5 – Computation of Nominal Moment Capacity and Interaction Diagram Example 5 is presented to illustrate a feature of LPile for computation of the nominal bending moment capacity and to display an interaction diagram. A total of 17 axial loads were specified for the program to compute the ultimate bending moment at each axial load and to construct the interaction diagram (ultimate bending moment versus axial load). The ultimate bending moment of a reinforces-concrete section is taken at a maximum compressive strain in concrete of 0.003 based on the ACI 318 code. It should be noted that the bending stiffness (EI), corresponding to the ultimate bending moment, is significantly lower than that of the uncracked EI value. Therefore, the should also pay attention to the variation of EI versus moment for nonlinear piles. In general, the moment distribution in the pile is not affected much by the EI used in the computation. However, if the deflection is more critical for the design, then analysis using nonlinear values of EI should be done. Curves showing the development of moment versus curvature for various axial thrust values are shown in Figure 6-22. The curves showing the greatest amount of ductility are the curves with tensile axial thrust loadings. In general, the amount of ductility decreases as the axial thrust level increases. 119

Chapter 6 – Example Problems

Moment vs. Curvature - All Sections 11,000 10,000

Moment, in-kips

9,000 8,000 7,000 6,000 5,000 4,000 3,000 2,000 1,000 0 0.0

0.0002

0.0004

0.0006

0.0008

Curvature, radians/inch g b c d e f b c d e f g b c d e f g b c d e f g b c d e f g b c d e f g

Thrust = -250.00 kips f g b c d e Thrust = 200.00 kips g b c d e f

Thrust = -125.00 kips f g b c d e Thrust = 400.00 kips g b c d e f

Thrust = 0.00 kips

b c d e f g

Thrust = 1000.00 kips f g b c d e Thrust = 1600.00 kips g b c d e f

Thrust = 1200.00 kips

Thrust = 2200.00 kips f g b c d e Thrust = 2800.00 kips

Thrust = 2439.00 kips

Thrust = 800.00 kips

Thrust = 1400.00 kips f g b c d e Thrust = 2000.00 kips g b c d e f Thrust = 2600.00 kips g b c d e f

Thrust = 600.00 kips Thrust = 1800.00 kips

2013.7.01, © 2013 by Ensoft, Inc. Figure 6-22 LPile Moment versus Curvature for Example 5

Curves of bending stiffness versus bending moment are shown in Figure 6-23. In general, three ranges of EI magnitude can be found in the output. The first range of EI magnitude is associated with the uncracked stage. The concrete is uncracked and the EI is more-or-less constant and is equal to the calculated EI for the gross section. The second range of EI magnitude is for the cracked stage. A significant decrease in the EI value takes place as cracks continue propagating. The third range of EI magnitude is for the cracked and large strain stage. The EI value is further reduced because the concrete stress-strain curve (shown in the Technical Manual) is softened at large strains. The curves for tensile axial thrust show a behavior that is not found for compressive axial thrusts. For these curves (see the blue and black curves in the lower left corner of the graph), the bending stiffness rises at higher levels of bending moment. The reason for this is the cracking and tensile thrust decreases the size of the compression zone in the cross-section. This causes a larger fraction of the moment to be carried by the reinforcing steel. Since the steel has a higher modulus than that for the concrete, the bending stiffness is seen to increase at higher levels of moment. The resulting interaction diagram for the reinforced concrete section is shown in Figure 6-24. Note that this graph was produced using the presentation graph utility in order to show the factored curves.

120

Chapter 6 – Example Problems EI vs. Moment - All Sections 180,000,000 160,000,000

EI, kips-in.²

140,000,000 120,000,000 100,000,000 80,000,000 60,000,000 40,000,000 20,000,000 0 0

1,000

2,000

3,000

4,000

5,000

6,000

7,000

8,000

9,000

10,000

11,000

Bending Moment, kips-in. g b c d e f b c d e f g b c d e f g b c d e f g b c d e f g b c d e f g

Thrust = -250.00 kips f g b c d e Thrust = 200.00 kips g b c d e f

Thrust = -125.00 kips f g b c d e Thrust = 400.00 kips g b c d e f

Thrust = 0.00 kips

g b c d e f Thrust = 1400.00 kips g b c d e f Thrust = 2000.00 kips g b c d e f Thrust = 2600.00 kips g b c d e f

Thrust = 1000.00 kips f g b c d e Thrust = 1600.00 kips g b c d e f

Thrust = 1200.00 kips

Thrust = 2200.00 kips f g b c d e Thrust = 2800.00 kips

Thrust = 2439.00 kips

Thrust = 800.00 kips

Thrust = 600.00 kips Thrust = 1800.00 kips

LPile 2013.7.01, © 2013 by Ensoft, Inc.

Figure 6-23 Bending Stiffness versus Bending Moment, Example 5 Factored Interaction Diagram 2,800 2,600 2,400

Axial Thrust Force, kips

2,200 2,000 1,800 1,600 1,400 1,200 1,000 800 600 400 200 0 -200 0

1,000

2,000

3,000

4,000

5,000

6,000

7,000

8,000

9,000

10,000

11,000

Bending Moment Capacity, lb-in. g b c d e f b c d e f g

Section 1, Rf = 1.00 f g b c d e Section 1, Rf = 0.75

Section 1, Rf = 0.65 g b c d e f

Section 1, Rf = 0.70

LPile 2013.7.01, © 2013 by Ensoft, Inc.

Figure 6-24 Factored Interaction Diagram of Reinforced-concrete Pile, Example 5

6-6 Example 6 – Pile-head Stiffness Matrix This example is presented to illustrate the capability of LPile to perform analyses that can yield results of direct benefit to the designer of a reinforced-concrete pile. The pile is 30-inches in diameter and 25-ft in length. The pile is embedded in dense sand with an angle of internal friction of 38 degrees. The program will compute the nonlinear moment-curvature behavior and bending moment capacity as the first step. Loading and preliminary data on piles are selected, 121

Chapter 6 – Example Problems and the program yields values of pile deflection, moment, shear, and soil resistance as the second step. The third step in the analysis is to compute the optional special analyses, such as pile-head stiffness, pushover analysis, or pile buckling analysis. The can compute the ratio of the bending moment capacity computed in the first step to the maximum bending moment computed in the second step to compare to an allowable factor of safety. The properties of the pile can then be changed, if necessary, and further computations made to achieve the final selection of the properties of the pile. The nonlinear EI values computed for a given pile may have a significant effect on the resulting deflections of the modeled pile. The relationship between bending moment, curvature in the pile, and EI is computed during the first part of the analysis. In many computer programs used for superstructure analyses, the is allowed to input spring stiffnesses in the form of a stiffness matrix to represent foundations under column bases. To demonstrate another useful tool of LPile, this example problem includes a check mark on the option to generate the foundation stiffness matrix. Since the program only deals with lateral loading, only four components of a 6×6 stiffness matrix are generated. Values for the axial spring stiffness and torsional pile response should be generated using other tools. In general, values are nonlinear in nature and only valid for a certain range of loading. Iterations might be necessary to achieve convergence between superstructure and pile analyses. Output curves obtained from this example problem for stiffness matrix components are shown versus displacements in Figure 6-25 and versus forces in Figure 6-26.

Figure 6-25 Stiffness Matrix Components versus Displacement and Rotation, Example 6

122

Chapter 6 – Example Problems

Figure 6-26 Stiffness Matrix Components versus Force and Moment, Example 6

6-7 Example 7 – Pile with -Input p-y Curves and Distributed Load This example is included to illustrate a common case in which a 16-in. (406 mm)diameter pipe pile is subjected to both, concentrated loads at the pile head and distributed loads along the pile. The head of the pile will be assumed unrestrained against rotations (free-head case) with no applied moment. A lateral load of 5,000 lbs (22 kN) will be applied at the pile head. The non-uniform distributed loads are 20 lbs/in (3.5kN/m) at the depth of 2 ft (0.6 m) and linearly increase to 100 lbs/in. (17.5 kN/m) at the depth of 5 feet (1.5 meters). Figure 6-27 shows a general view of the pile and soil. The distributed load in this case occurs over a pile length of 3 feet (0.9 meters), and an increment length of 0.25 feet (0.075 meters); therefore, the distributed lateral load can be properly reflected by the 12 increments of length of the pile. To demonstrate another feature of LPile, the p-y curves shown in Figure 6-28 will be entered for this problem. The program interpolates linearly between points on a p-y curve and between depths of p-y curves.

123

Chapter 6 – Example Problems

16-in. O.D. Pipe Pile E = 29,000,000 psi t = 0.75 in. I = 1,047 in4

5 ft Soft Clay

20 ft Loose Sand 16-in. O.D. Pipe Pile E = 29,000,000 psi t = 0.5 in. I = 732 in4

30 ft

Medium Clay

Figure 6-27 Pile and soil details for Example 7 400

Load Intensity p, lb/in.

350

300

250

200

150

100

50

0 0.0

1.0

2.0

3.0

4.0

5.0

6.0

Lateral Deflection y, in. Layer Layer Layer Layer Layer Layer Layer

1, Upper 2, Upper 3, Upper 4, Upper 5, Upper 6, Upper 7, Upper

p-y p-y p-y p-y p-y p-y p-y

Curve, Depth = 5.00 ft Curve, Depth = 6.33 ft Curve, Depth = 7.67 ft Curve, Depth = 9.00 ft Curve, Depth = 11.67 ft Curve, Depth = 15.67 ft Curve, Depth = 17.83 ft

Layer Layer Layer Layer Layer Layer

1, Low er 2, Low er 3, Low er 4, Low er 5, Low er 6, Low er

p-y p-y p-y p-y p-y p-y

Curve, Depth = 6.33 ft Curve, Depth = 7.67 ft Curve, Depth = 9.00 ft Curve, Depth = 11.67 ft Curve, Depth = 15.67 ft Curve, Depth = 17.83 ft

Figure 6-28 -input p-y Curves for Example 7 (Lower curve for Layer 7 not shown) 124

Chapter 6 – Example Problems

6-8 Example 8 – Pile in Cemented Sand A field test for behavior of laterally loaded, bored piles in cemented sands (c- soil) was conducted in Kuwait (Ismael, 1990). Twelve bored piles that were 0.3-m in diameter were tested. Piles 1 to 4 were 3-m long, while piles 5 to 12 were 5-m long. The study was on the behavior of both single piles and piles in a group. The measured load versus deflection curves at the pile head for a 3-m long single pile and a 5-m long single pile are presented in the paper and can be studied by using the soil criteria for c- soils. The piles were reinforced with a 0.25-m diameter cage made of four 22-mm bars for the 3 m-long piles and six 22-mm bars for the 5 m-long piles. In addition, a 36-mm reinforcing bar was positioned at the center of each pile. The Young’s modulus for concrete was measured during a cylinder test and a representative value of 3,200 psi (22 MPa) was selected. The flexural rigidity EI varies with the applied moment but a constant value was reported. After lateral-load tests were completed, the soil to a depth of 2 m was excavated to expose the level of the strain gauges for a calibration test. The pile was reloaded and the curvature was calculated from the measurements of strain. The moment in the pile at the strain gauges was determined from statics and the moment versus curvature relationship was determined. The reported flexural rigidity was calculated from the initial slope of the moment-curvature curves as 20.2 MN-m2, which seems to be on the upper extreme of the normal range for a bored pile with the reported concrete and reinforcing properties. The subsurface profile at the test site consisted of two layers as shown in Figure 6-29. The upper layer, described as medium dense cemented silty sand, was about 3 m in thickness. The values of c and  for this layer were found by drained triaxial compression tests and were 20 kPa and 35 degrees respectively. The upper layer was underlain by medium dense to very dense silty sand with cemented lumps. The values of c and  were zero kPa and 43 degrees, respectively. Depth (m)

Soil Description

0 1

2

Medium Dense Cemented Silty Sand (SM)

3 4

5

Medium Dense to Very Dense Silty Sand with Cemented Lumps (SM)

N60

w%

g

LL

PI

0

13

1.4

1.81

30.5

7.0

22.5

24

2.7

1.83

25.2

4.0

17.7

26

3.8

1.87

26.0

NP

18

21

3.9

1.80 none

NP

−

60

3.1

1.90 none

NP

−

90

4.4

1.99 none

NP

−

End of Borehole

Figure 6-29 Soil details for Example 8 125

Soil Composition Percent of Total

SL

Mg/m3

50

Sand

Silt

Clay

100

Chapter 6 – Example Problems LPile, employing the c- criteria was used to predict curves of load versus deflection at the pile head for 5-m pile. Good agreement was found between measured and predicted behavior, for pile-head load versus deflection and is shown in Figure 6-30. A comparison between measured and predicted behavior for bending moment versus depth is shown in Figure 6-31. 180

160

Shear Force, kN

140 120 100

Computed by LPile Load Test

80 60 40 20

0 0.000

0.005

0.010

0.015

0.020

0.025

Deflection, meters

Figure 6-30 Comparison between Measured and Predicted Pile-head Load versus Deflection Curves for the 5-m Pile of Example 8 Bending Moment, kN-m -5

0

5

10

15

20

25

30

35

0

Depth, meters

1

2

Computed by LPile Load Test 3

4

5

Figure 6-31 Comparison between Measured and Computed Bending Moment versus Depth for the 5-m Pile of Example 8

126

Chapter 6 – Example Problems

6-9 Example 9 – Drilled Shaft with Tip Resistance This example application has been prepared for an idealized drilled shaft whose head is embedded 1 foot in soil. The general pile geometry and soil profile is shown in Figure 6-32. The soil stratigraphy is composed of three different layers of sand, soft clay, and stiff clay. The soil properties are also shown in Figure 6-32. In addition, there is a water-bearing sand layer at a depth of 60 feet not shown in the figure.

P

−1 ft

M

M = 4  106 in-lbs V = 70,000 lbs P = 800,000 lbs

1 ft

V 3.5 ft

6 ft

6 ft

5 ft

13 ft

3 ft

Sand  = 35, k = 90 pci g = 130 pcf

Soft clay, c = 800 psf, 50 = 0.02 g = 58.1 pcf

19 ft 18 ft

11.5 ft

Stiff clay c = 2,160 psf, 50 = 0.005 g = 63.4 pcf

4 ft 11 ft Toe height = 0.5 ft

Figure 6-32 Shaft Geometry and Soil Properties for Example 9 The construction procedure for the shaft is to set a temporary surface casing through the upper sand layer and to seal the casing in the soft clay layer. Drilling through the soft clay layer into the stiff clay layer is accomplished in the dry. The use of the enlarged base was selected to avoid tipping the shaft in the underlying water-bearing sand layer. Had a straight-sided shaft 127

Chapter 6 – Example Problems been used, the overall shaft length would have been 30 feet longer and drilling with slurry would have been required. In this case, the use of a shorter shaft with an enlarged base would result in faster and more economical construction. The final shaft dimensions consists of four sections, which are a 6-ft long straight section of 42-in. diameter, 19-ft long straight section of 3-ft (0.91m) diameter, a 4-ft (1.22-m) long section with a 11-ft (3.35-m) diameter enlarged base at the bottom with a 0.5-ft toe section. The loads shown acting at the top of the pile are primarily axial and the axial bearing capacity and settlement must be checked to withstand the axial load using a separate analysis. The analysis using LPile is performed to check the lateral performance and to design the shaft reinforcement. The reinforcement in the shaft was sized so that one reinforcement cage could be placed over the full length of the shaft. The reinforcement chosen was 14 No. 9 bars, sized with a diameter that had a 6-inch cover in the upper 42-inch section and a 3-inch cover in the 36 inch section. This amount of reinforcement provided 1.01% reinforcement in the 42-inch section and 1.38% reinforcement in the 36-inch section. The enlarged base sections were modeled as elastic sections, with the specified dimensions and an elastic modulus of 3,500,000 psi. A first run of the problem showed that the shaft acted mainly as a short pile with lateral movements observed at the bottom of the shaft. The design engineer then decided to for the additional amount of soil resistance provided by the large shear forces developed at the enlarged base of the shaft. This was accomplished by checking the option in the Program Options and Settings dialog to include shear resistance at pile tip. Inclusion of tip shear resistance had little effect on the top deflection, reducing the top deflection from 0.994 inches without tip shear to 0.909 inches with tip shear. The computer-generated p-y curves were adjusted to for closely spaced piles by utilizing p-reduction factors that varied with depth from 0.75 for the straight shaft down to 0.3 at the bottom of the enlarged base. Curves of moment versus curvature for Sections 1 (42-inch) and 2 (36-inch) are shown in Figure 6-33. The factored moment capacities for these two sections for a resistance factor of 0.65 are 14,000 and 11,600 in-kips respectively The curves of lateral deflection and bending moment versus depth are shown in Figure 6-34. In addition, the program was asked to generate a plot of pile length versus pile-top deflections in order to optimize the design length. The resulting plot included in Figure 6-35 shows that the pile length should not be further reduced in order to have an appreciable factor of safety from the critical length nor could the length of shaft be increased without the base of the shaft coming too close to the water-bearing sand layer below.

128

Chapter 6 – Example Problems

Figure 6-33 Moment versus Curvature for Sections 1 and 2, Example 9 Bending Moment, in-kips

Deflection, in. 0

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

0 0

1

2

2

4

4

6

6

8

8

10

10

12

12

14 16

Depth, ft

Depth, ft

-0.1 0

1,000

2,000

3,000

4,000

5,000

6,000

14 16

18

18

20

20

22

22

24

24

26

26

28

28

Figure 6-34 Lateral Deflection and Bending Moment versus Depth, Example 9

129

7,000

8,000

Chapter 6 – Example Problems

1.8

1.7 1.6 1.5 1.4

Top Deflection, in.

1.3 1.2 1.1 1.0

0.9 0.8 0.7 0.6 0.5 0.4 0.3 0.2 0.1 0

0

5

10

15

20

25

30

Pile Length, ft

Figure 6-35 Top Deflection versus Pile Length, Example 9

6-10 Example 10 – Drilled Shaft in Soft Clay This drilled shaft in this example is a 24-inch diameter drilled shaft with eight US#7 reinforcing bars. Often designers elect to use fewer than eight bars in small diameter drilled shafts. In general, using fewer than eight bars is not recommended because when fewer than eight bars are used there is a direction of loading effect on the moment capacity of the drilled shaft. When the number of bars is eight or more, the effect of the direction of loading is largely eliminated. The summary plots of this analysis are shown in Figure 6-36. This analysis was made using the displacement-moment pile-head loading condition. By examining these graphs, can see that the pile in not overloaded at the maximum deflection of 1.25 inches and that the moment developed in the shaft is sufficiently large for the cracked-section bending stiffness to be in effect for almost one half of the shaft length. Also, shown are the p-y curves for static loading at specified depths for output by the program.

130

Chapter 6 – Example Problems

Figure 6-36 Summary Plots of Results for Example 10

6-11 Example 11 – LRFD Analysis This example is provided as a demonstration of the LRFD analysis features of LPile. The LRFD features of LPile are discussed in Section 3-14. The computational procedures for making an analysis in LRFD mode are the same as for conventional analysis, except for how the unfactored loads and the load and resistance factor combinations are entered. The entry of data for pile structural properties and for soil layering and properties is the same as for conventional analysis. The switches to LRFD mode by marking the check box for LRFD Analysis Mode in the Computational Options group of the Program Options and Settings dialog. The should be aware that it is possible to store the load and resistance factor combinations in a separate data file that can be re-used in subsequent analyses. The feature for reading of the load and resistance factor combinations is activated through the Program Options and Settings dialog. The saving of the load and resistance factor combinations is activated by the command on the File Menu. Please note that the File Menu command to save the load and resistance factor combinations is visible only when LPile is operating in LRFD Analysis Mode. All load conditions must be horizontal shear, vertical load, and moment in the LRFD mode combined with distributed lateral loading. The pile-head loads will be converted to their axial and transverse components for battered piles. One of the features of LPile is the capability to compute the factored load combinations. Once all unfactored loads are entered, LPile will sum all unfactored loads of the same type, including distributed loads, and compute the factored load combination. The factored load 131

Chapter 6 – Example Problems combinations can be reviewed prior to analysis by pressing the Display Summary of LRFD Loadings (the  button on the button bar). An excerpt from an example of a summary report is shown in Figure 6-37.

Figure 6-37 Example from Summary Report of LRFD Loadings, Example 11 After running the LRFD analysis, an information message will be displayed to alert the whether or not all load case combinations have been met. The message for a successful analysis is displayed as Figure 6-38.

Figure 6-38 Message for Successful LRFD Analysis for Example 11

132

Chapter 6 – Example Problems The LRFD analysis of LPile is currently limited to checking mobilized bending moment values in every pile section against the factored moment capacity of the section and mobilized shear force against input values of structural shear capacity. Checks for displacements and pilehead rotations (i.e. serviceability checks) depend on the purpose of the foundation and are left to the . Internally computed values of structural shear capacity of the pile are not computed by LPile because standardized methods for computing shear capacity of all section types are between the design standards being followed. However, the may enter an input value for structural shear capacity and LPile will check the mobilized shear force in the pile against the input value. If the input structural shear capacity is left equal to zero, the checks for shear capacity will be skipped.

6-12 Example 12 – Pile in Liquefied Sand with Lateral Spread This example is provided as an example of seismic lateral spread loading of a pile. In this example, the pile-head is loaded only by axial load and all lateral loading on the pile is due to seismic lateral spread. The pile is a 15.2 m-long pipe pile with a diameter of 373 mm and a wall thickness of 10 mm. The soil profile has liquefied sand in the upper 5 meters and a lateral spread profile with a maximum movement of 300 mm that is greatest at the ground surface and decreases down to zero at a depth of 5 meters. The pile and soil profile is shown in Figure 6-39 and the lateral spread profile versus depth is shown in Figure 6-40.

Figure 6-39 Pile and Soil Profile for Example 12

133

Chapter 6 – Example Problems

Soil Movement, m 0

0.02

0.04

0.06

0.08

0.1

0.12

0.14

0.16

0.18

0.2

0.22

0.24

0.26

0.28

0.3

0.0

0.5

1.0

1.5

Depth, m

2.0

2.5

3.0

3.5

4.0

4.5

5.0

Figure 6-40 Lateral Spread Profile versus Depth for Example 12 The summary graphs of the analysis are shown in Figure 6-41. The graph of moment versus curvature indicates that the plastic moment capacity of the pile is 320 kN-m and the maximum moment developed in the pile is about 165 kN-m, so the pile remains elastic. The graph of lateral spread and pile deflection versus depth shows that the soil flows around the upper portion of the pile. The lateral deflection of the pile head is about 50 mm and the maximum lateral spread displacement is 300 mm, about six times higher. The performance of the pile would have been significantly worse is a non-liquefied layer were present at the ground surface. In such a case, the non-liquefied layer would move on top of the liquefied layer, thereby creating a large displacement relative to the position of the pile. The lateral loading on the pile would depend on the load-transfer properties of the non-liquefied layer, but failure of the pile by formation of a plastic hinge would be probable.

134

Chapter 6 – Example Problems

Figure 6-41 Summary Graphs for Example 12

6-13 Example 13 – Square Elastic Pile with Top Deflection versus Length This example is to demonstrate the feature to compute pile top deflection versus pile length and the use of the modified stiff clay without water p-y curve. The pile is modeled as a 25foot long, 14-inch square elastic pile with a Young’s modulus of 3,500,000 psi. The pile-head loads are shear forces of 5,000, 10,000, 20,000, 30,000, and 40,000 lbs, zero moment, and an axial thrust load of 150,000 lbs. The option to compute pile top deflection versus pile length is turned on in the Pile-head Loadings and Options dialog. The properties of the modified stiff clay without free water are an effective unit weight of 108 pcf, undrained shear strength of 2,000 psf, k of 500 pci, and 50 of 0.005. The primary use of the modified stiff clay without free water is to generate a p-y curve with a softened initial slope. In some areas, load testing has found that the original p-y curve computations result in p-y curves that have initial slopes that are too stiff. As an example, pilehead load versus deflection curves were computed using both the original and modified p-y curve formulations. Theses curves along with the percentage of reduction in stiffness are graphed in Figure 6-42.

135

50000

100%

45000

90%

40000

80%

35000

70%

30000

60%

25000

50%

20000

40%

15000

30% Original Modified % Reduction

10000 5000

20%

% Reduction in Stiffness

Axis Title

Chapter 6 – Example Problems

10% 0%

0 0

0.2

0.4

0.6

0.8

1

1.2

Axis Title

Figure 6-42 Pile-head Load versus Deflection Curves Using Original and Modified p-y Curves for Stiff Clay without Free Water and Percentage Reduction in Stiffness for Example 13 The curves of pile top deflection versus pile length are shown in Figure 6-43. 2.00

1.75

Top Deflection, in.

1.50

1.25

1.00

0.75

0.50

0.25

0.00 0

1

2

3

4

5

6

7

8

9

10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25

Pile Length, ft g b c d e f b c d e f g

Loading Case 1 f g b c d e Loading Case 5

Loading Case 2 g b c d e f

Loading Case 3 g b c d e f

Loading Case 4

Figure 6-43 Curves of Pile Top Deflection versus Pile Length for Example 13

136

Chapter 6 – Example Problems It should be noted that the length of pile needed to reach the “long pile” behavior (i.e. when the curve becomes horizontal) is depended on the level of loading being consider. Thus, it is important to specify the generation of the pile top deflection versus pile length curve for the maximum loading being considered. It should also be noted that if the pile top deflection is too large for the “long pile” portion of the curve, the deflection can be lowered only by reconfiguring the foundation to use either larger diameter piles or more piles.

6-14 Example 14 – Pushover Analysis of Prestressed Concrete Pile This example is provided as an example of a pushover analysis of a prestressed concrete pile. The pile is a 25-foot long, 14-inch wide, prestressed concrete pile with 1-inch chamfered corners. The reinforcement details for the pile are shown in Figure 6-44.

Figure 6-44 Reinforcement Details for Prestressed Concrete Pile of Example 14 It should be noted that the value for Fraction of Loss of Prestressed must be obtained from the pile manufacturer and that this number can vary from supplier to supplier because the procedures and materials used for the pile vary. The magnitude of prestressed after losses typically varies from 600 to 1,200 psi in the United States, with pile driven in softer soils typically having higher prestress values to permit higher resistance to tensile stresses during pile driving. The use of higher levels of prestress also permits lifting of longer piles without damage. This example uses the Pushover Analysis option available in the Program Options and Settings dialog. One useful feature of the pushover analysis is to determine the lateral deflection and load required to fail a pile under lateral loading. As will all LPile analyses for piles with nonlinear bending properties, LPile computes the curve of nonlinear bending versus curvature. The curve generated for Example 14 is shown in 137

Chapter 6 – Example Problems Figure 6-45 for the two values of axial thrust specified in the Pile-head Loading and Options dialog. The curve shown here indicates that the plastic moment capacity for the pile is approximately 2,100 in-kips. 2,250

2,000

1,750

Moment, in-kips

1,500

1,250

1,000

750

500

250

0 0.0

0.0001

0.0002

0.0003

0.0004

0.0005

0.0006

Curvature, radians/inch b c d e f g

Thrust = 100.00 kips g b c d e f

Thrust = 125.00 kips

Figure 6-45 Moment versus Curvature of Prestressed Pile for Example 14 The results of the pushover analysis are shown in the two graphs of Figure 6-46. These graphs shown the results for both fixed-head and free-head loading conditions for lateral displacements up to 5 inches. For fixed-head conditions, the plastic moment capacity is mobilized at a pile top deflection of 0.625 inches and a shear load of 60,900 lbs. For free-head conditions, the plastic moment capacity is mobilized at a pile top deflection of 2.75 inches and a shear load of 56,300 lbs. Other information gained from these graphs is maximum lateral capacity is approximately 85,000 lbs for fixed-head conditions and is 58,400 lbs for free-head conditions. When interpreting these results, the designer is faced with the decision about which curve is most representative of the pile design being analyzed. For prestressed concrete pile, the answer depends on the pile-head connection conditions utilized for the pile. If the pile is attached to the pile cap with dowels and an inset of a few inches, the pile-head fixity condition is very close to the free-head condition. If the pile is deeply embedded into the pile cap, say 2.5 pile widths or more, the pile-head fixity condition is very close to the fixed-head condition. For pile-head embedments in between the two conditions discussed above, the pile-head fixity condition is likely to be elastically restrained. Evaluation of the stiffness of the elastic restraint will depend on the structural properties of the pile cap and the pile to pile cap

138

Chapter 6 – Example Problems reinforcement details. It will be necessary to use a special computer program to evaluate these conditions. Free-head and Fixed-head Conditions

85,000 2,100,000 80,000

2,000,000 1,900,000

70,000

1,800,000

Maximum Moment, in-lbs

75,000

Shear Force, kips

65,000 60,000 55,000 50,000 45,000 40,000 35,000

1,700,000 1,600,000 1,500,000 1,400,000 1,300,000 1,200,000 1,100,000 1,000,000 900,000 800,000

30,000

700,000

25,000

600,000 20,000

500,000 1

2

3

4

1

5

b c d e f g

Fixed-head Response g b c d e f

2

3

4

5

Top Deflection, inches

Top Deflection, in. b c d e f g

Free-head Response

Fixed-head Response g b c d e f

Free-head Response

Figure 6-46 Results of Pushover Analysis of Prestressed Concrete Pile of Example 14

6-15 Example 15 – Pile with Defined Nonlinear Bending Properties This example was provided as an example of a pile with defined nonlinear bending properties. Two analyses were made. The first analysis was of a drilled shaft with internally generated nonlinear bending properties. The second analysis was of a pile with defined nonlinear bending properties in which the output file of curvature and moment values was input. Both SI and USCS unit versions of these data files are provided. A check of the pile response computed by LPile for the two types of piles found that the pile responses were identical, as they should be.

6-16 Example 16 – Pile with Distributed Lateral Loadings This example was provided as an example of pile with distributed lateral loading. In this example, the pile extends 20 feet above the ground surface and the distributed lateral load is a uniform loading of 50 lbs/inch. The uniform distributed loading can be checked by evaluating the computed shear force and bending moment at the ground line. The computed shear force at the ground line is 20

V   p DL dx  p DL x 0

(50) (240) (50) (0)

 12,000 lbs

The computed bending moment at the ground line is

L  240  M   p DL L    (50)(240)   1,440,000 in - lbs 2  2 

139

Chapter 6 – Example Problems A check of the output report for values of shear and moment at a depth of 20 feet (240 inches) finds that the compute shear and moment are 12,000 lbs and 1,440,000 in-lbs as expected.

6-17 Example 17 – Analysis of a Drilled Shaft This example is provided as an example of an analysis of a drilled shaft (bored pile) that was constructed with two sections of different diameters; 42 and 36 inches. The pile and soil profile for this example are shown in Figure 6-47. This is an example of a drilled shaft that was constructed using a temporary casing that extended through the upper sand layer and was sealed into the underlying clay layer. A single-diameter cage was inserted the full length of the shaft, with the diameter of the upper section six inches larger than the drilled diameter of the lower section. This results in the clear cover over the reinforcing steel to be 6 inches in the upper section and 3 inches in the lower section.

Figure 6-47 Pile and Soil Profile for Example 17 For this example, it was desired that the percent of steel in the shaft be no less than 1 percent. This resulted in a cage with 14 No. 9 bars that resulted in 1.01% steel in the upper section and 1.38% steel in the lower section. The curves of moment versus curvature for the two sections are shown in Figure 6-48. The nominal moment capacity of the upper and lower sections are 14,280 and 12,200 in-kips and the ultimate (factored using a resistance factor of 0.65) are 9,280 and 7,950 in-kips.

140

Chapter 6 – Example Problems 15,000 14,000 13,000 12,000 11,000

Moment, in-kips

10,000 9,000 8,000 7,000 6,000 5,000 4,000 3,000 2,000 1,000 0 0.0

0.0001

0.0002

0.0003

0.0004

Curvature, radians/inch b c d e f g

Section 1, Thrust = 100.00 kips g b c d e f

Section 2, Thrust = 100.00 kips

Figure 6-48 Moment versus Curvature for Dual Section Drilled Shaft of Example 17

6-18 Example 18 – Analysis of Drilled Shaft with Permanent Casing This example is based on Example 17, except that a permanent casing is modeled for the upper section. The nominal moment capacities of the upper and lower sections are 47,900 and 12,200 in-kips and the ultimate (factored using a resistance factor of 0.65) are 31,100 and 7,950 in-kips. The moment capacity of the second section is identical to the second section of Example 17 because the section properties are identical. The curves of moment versus capacity are shown in Figure 6-49.

6-19 Example 19 – Analysis of Drilled Shaft with Casing and Core This example is based on Example 18, except that a permanent core has been added. In modeling of this pile, it was assumed that the core extended over the full length of the shaft and that the interior of the core was void of concrete. When modeling the lower section, the section type was drilled shaft with casing and core, but the wall thickness of the casing was set equal to zero to model the section with an interior core only. The nominal moment capacity of the upper and lower sections are 51,900 and 16,990 inkips and the ultimate (factored using a resistance factor of 0.65) are 33,700 and 11,040 in-kips. The curves of moment versus curvature are shown in Figure 6-50.

141

Moment, in-kips

Chapter 6 – Example Problems 50,000 48,000 46,000 44,000 42,000 40,000 38,000 36,000 34,000 32,000 30,000 28,000 26,000 24,000 22,000 20,000 18,000 16,000 14,000 12,000 10,000 8,000 6,000 4,000 2,000 0 0.0

0.0001

0.0002

0.0003

0.0004

Curvature, radians/inch b c d e f g

Section 1, Thrust = 100.00 kips g b c d e f

Section 2, Thrust = 100.00 kips

Figure 6-49 Moment versus Curvature for Dual Section Drilled Shaft with Permanent Casing of Example 18 55,000 50,000 45,000

Moment, in-kips

40,000 35,000 30,000 25,000 20,000 15,000 10,000 5,000 0 0.0

0.00005

0.0001

0.00015

0.0002

0.00025

0.0003

Curvature, radians/inch b c d e f g

Section 1, Thrust = 100.00 kips g b c d e f

Section 2, Thrust = 100.00 kips

Figure 6-50 Moment versus Curvature for Dual Section Drilled Shaft with Permanent Casing and Core of Example 19 142

Chapter 6 – Example Problems

6-20 Example 20 – Analysis of Embedded Pole This example is provided as an example of the embedded pole option. Embedded poles are commonly used in the electrical utility industry. The typical utility pole in the United States is embedded to a depth of 10 percent of the overall pole length, plus 2 feet. Thus, the embedded pole of Example 20 has an overall length of 40 feet and an embedment of 6 feet. The pile and soil profile for this example is shown in Figure 6-51.

Figure 6-51 Pile and Soil Profile for Embedded Pole of Example 20 The output computed using LPile for this problem is conservative because there are loadtransfer mechanisms between the foundation and soil that not included in the LPile analysis. These mechanisms are any vertical shear stresses developed along the sides of the pile and any shear that might develop at the tip of the pole. In practice, the computation of these additional load-transfer mechanisms present some difficulties because of uncertainties related to how the poles are constructed. In some applications, an oversize hole is drilled, the pole is inserted on one side of the hole, and backfill is compacted in the open void on one side of the pole. In other applications, the pole is placed in the center of an oversized hole and a cemented-stabilized, flowable fill is placed in the annular space around the pole. The loading on the pole is representative of a 100-mph wind loading on the pile and transformer mounted on top of the pole (the transformer is not shown in the above figure). The wind load is equivalent to a uniform pressure of 40 psf acting over the projected area of the pole and transformer. The weight of the transformer is in pile-head loading for the pole. The computed pile-head deflection is 3.14 inches and the ground line deflection is 0.0127 inches.

143

Chapter 6 – Example Problems

6-21 Example 21 – Analysis of Tapered Elastic Pile This example is provided to demonstrate the modeling of a tapered elastic pile and to show that the values of cross-sectional area and moment of inertia are computed from the interpolated dimensional properties along the length of the tapered section. It is possible to check two different results computed by LPile; the computed values of total stress and bending stiffness. The pile in this example is a 30-foot long tapered pipe pile with a top diameter of 16 inches, a tip diameter of 10 inches, a wall thickness of 0.5 inches, and a modulus of elasticity of 29,000,000 psi. Values of cross-sectional area and moment of inertia are computed using: d o2  d o  2t  4 4 4 d  d o  2t  I  o 64

2

A

The table below shows the values of interpolated dimensional properties, cross-sectional area, moment of inertia, theoretical bending stiffness EI, and bending stiffness computed by LPile. The values of theoretical bending stiffness and bending stiffness computed by LPile are identical. Table 6-1 Dimensions, Cross-sectional Area, and Bending Stiffness of Tapered Pile Depth, ft

do, in.

t, in.

A, in2

I, in4

0 5 10 15 20 25 30

16 15 14 13 12 11 10

0.5 0.5 0.5 0.5 0.5 0.5 0.5

24.347 22.776 21.205 19.634 18.064 16.493 14.923

731.942 599.308 483.756 384.109 299.188 227.815 168.812

EI, lb-in2 2.123×1010 1.738×1010 1.403×1010 1.114×1010 8.676×109 6.607×109 4.896×109

LPile EI, lb-in2 2.123×1010 1.738×1010 1.403×1010 1.114×1010 8.676×109 6.607×109 4.896×109

Values of maximum total stress are computed utilizing the absolute value of bending moment and using

 total 

P Mc  A I

The axial thrust specified in this example is 30,000 lbs. The table below shows values of interpolated dimensional properties, cross-sectional area, moment of inertia, bending moment computed by LPile, theoretical total stress, and total stress computed by LPile. The values of total stress computed by LPile are identical to the theoretical values, with the exception of the value shown for a depth of 5 feet, where the difference is due to the limited output precision of LPile. The internal value computed by LPile is identical.

144

Chapter 6 – Example Problems Table 6-2 Interpolated Dimensional Properties, Cross-sectional Area, Moment of Inertia, Bending Moment of Tapered Pile Computed by LPile Depth, ft

do, inches

c, inches

A, in2

I, in4

M, in-lbs

, psi

0 5 10 15 20 25 30

16 15 14 13 12 11 10

8.0 7.5 7.0 6.5 6.0 5.5 5.0

24.347 22.777 21.206 19.635 18.064 16.493 14.923

731.942 599.308 483.756 384.109 299.188 227.815 168.812

720,000 1,004,361 341,233 -28,547 -12,814 1,395 0

9101.64 13886.16 6352.39 2010.97 1917.72 1852.60 2010.38

LPile , psi 9101.64 13886.00 6352.39 2010.97 1917.72 1852.60 2010.38

6-22 Example 22 – Analysis of Tapered Elastic-Plastic Pile This example is a variation of Example 21, except that the pile section type has been changed to an “Elastic Section with Specified Moment Capacity” with a plastic moment capacity at the pile head equal to 3,293,739 in-lbs. The plastic moment capacity was computed as the yield moment for a pipe section with 16-inch diameter, 0.5-inch wall thickness, and 36,000-psi yield stress. A graph of moment and computed yield moment versus depth is shown in Figure 6-52. Bending Moment, in-lbs -1,000,000 0

0

1,000,000

2,000,000

3,000,000

4,000,000

5

Depth, feet

10

15

20

25

LPile Moment Moment Capacity 30

Figure 6-52 Bending Moment and Plastic Moment Capacity versus Depth for Example 22 145

Chapter 6 – Example Problems A close examination of Figure 6-52 will find that the variation in plastic moment capacity is nonlinear with depth due to the tapered dimensions. This is because LPile will compute the yield stress of the pile material from the dimensional properties and input value of plastic moment capacity at the top of the section. LPile then computes the plastic moment capacity at other points in the section using the dimensions interpolated with depth and the interpreted value of yield stress. LPile does not perform computations for tapered sections if the geometric shape is specified as an H-pile section. In those cases, the plastic moment capacity of the full section is set equal to the input value for plastic moment capacity for the section.

6-23 Example 23 – Output of p-y Curves LPile is capable of generating 17-point p-y curves at -specified depths. Example 23 is provided as a demonstration of this feature of LPile. The feature to generate p-y curves for output is enabled by checking the box in the Output Options of the Program Options and Settings dialog as shown in Figure 6-53.

Figure 6-53 Program and Setting Dialog Showing Check for Generation of p-y Curves The pile and soil profile for Example 23 is shown in Figure 6-54. The soil profile is composed of a number of different soil types, plus the lowest layer is defined as having input p-y curves. When the graph of p-y curves is created, 17-points along the curves are generated. The spacing of the points depends on the formulation of the p-y curves. For most types of p-y curves, the points are representative of the shape of the curves, but for others, the y-values are chosen as 146

Chapter 6 – Example Problems fixed fractions of the pile diameter. In these cases, the plotted shape of the p-y curve is accurate only at the data points. The graph of p-y curves for Example 23 is shown in Figure 6-55.

Figure 6-54 Pile and Soil Profile for Example 23 p-y Curves 7,000 6,500 6,000

Load Intensity p, lb/in.

5,500 5,000 4,500 4,000 3,500 3,000 2,500 2,000 1,500 1,000 500 0 0.0

0.5

1.0

1.5

2.0

2.5

3.0

3.5

4.0

4.5

5.0

Lateral Deflection y, in.

Figure 6-55 g Standard Curves Example 23 Depth =Output 2.00 ft g Depth = 4.00p-y ft g Depthfor = 6.00 ft b c d e f bof 17-point c d e f b c d e f g b c d e f b c d e f g b c d e f g b c d e f g

Depth = 8.00 ft

b c d e f g

Depth = 14.00 ft f g b c d e Depth = 22.50 ft g b c d e f Depth = 33.00 ft g b c d e f

b c d e f g

Depth = 12.00 ft

Depth = 16.00 ft f g b c d e Depth = 27.00 ft g b c d e f

Depth = 18.00 ft

Depth = 9.90 ft

147 Depth = 40.00 ft g b c d e f

LPile 2013.7.01, © 2013 by Ensoft, Inc.

Depth = 31.00 ft Depth = 49.00 ft

Chapter 6 – Example Problems Figure 6-56 is the same as Figure 6-55 except that the display of the curves for the upper depths is turned off. The -input curves are defined using only five points, not 17 and the curves are defined at the top and bottom of the layer at 35 and 75 feet below the pile head. The curves displayed in Figure 6-56 are composed of 17 points and the curves are interpolated with depth at 40 and 49 feet below the pile head. p-y Curves 4,000 3,800 3,600 3,400 3,200

Load Intensity p, lb/in.

3,000 2,800 2,600 2,400 2,200 2,000 1,800 1,600 1,400 1,200 1,000 800 600 400 200 0 0.0

0.2

0.4

0.6

0.8

1.0

1.2

1.4

1.6

1.8

2.0

2.2

2.4

Lateral Deflection y, in.

Figure 6-56 -input p-y Interpolated with for Example 23 Depth = 2.00 ft g Depth = 4.00Depth ft g Depth =17 6.00Points ft c Curves d e f g c d e f c Using d e f Depth = 8.00 ft g Depth = 9.90 ft g Depth = 12.00 ft g c d e f c d e f c d e f Depth = 14.00 ft Depth = 16.00 ft Depthdefined = 18.00 ft points at c d e f g c d e f g c d e f g LPile can also output the -input p-y curves using the Depth = 22.50 ft g Depth = 27.00 ft g Depth = 31.00 ft c d e f g c d e f c d e f bottom of the layer defined as aDepth -input p-y curve. An example of the input = 33.00 ft g Depth = 40.00 ft g Depth = 49.00 ft c d e f g b c d e f b c d e f

the top and p-y curve is

shown as Figure 6-57.

LPile 2013.7.01, © 2013 by Ensoft, Inc.

A common feature of all output p-y curves is a truncation of the curve once it becomes horizontal. This is done to avoid hiding the shorter curves. The should be aware how LPile uses p-y curves in computations. LPile generates the p-values from the p-y curve formulation at every y-value at every node on the pile for every iterative solution of pile response. In other words, no interpolation along or in between curves is performed, except in the layer defined as -input p-y curves. Thus, the p-values used by the program are the most accurate values possible.

148

Chapter 6 – Example Problems

-input p-y Curves 4,000 3,800 3,600 3,400 3,200

Load Intensity p, lb/in.

3,000 2,800 2,600 2,400 2,200 2,000 1,800 1,600 1,400 1,200 1,000 800 600 400 200 0 0.0

0.2

0.4

0.6

0.8

1.0

1.2

1.4

1.6

1.8

2.0

2.2

2.4

Lateral Deflection y, in.

Figure 6-57 Output of -input p-y Curves with Five Points for Example 23 Layer 8, Upper p-y Curve, Depth = 35.00 ft b c d e f g b c d e f g

Layer 8, Low er p-y Curve, Depth = 75.00 ft

6-24 Example 24 – Analysis with Lateral Soil Movements LPile 2013.7.01, © 2013 by Ensoft, Inc. This example is provided as a demonstration of how to model a pile foundation subjected to lateral spreading. The pile and soil profile for this problem is shown in Figure 6-58. The soil profile is composed of a stiff clay crust, overlying a layer of liquefied sand, overlying a deep layer of stiff clay with free water. This soil profile was used because it represents the type of soil profile for which lateral spread problems are most severe. The pile is a 48-inch drilled shaft with 18 No. 9 reinforcing bars. This reinforcement provides 0.99 percent steel. The nominal moment capacity of the shaft was computed to be 21,360,000 in-lbs and the factored moment capacities ranged from 13,880,000 in-lbs to 16,020,000 in-lbs for resistance factors of 0.65 to 0.75. The option for loading by soil movements is enabled by checking the box for “Include Loading by Lateral Soil Movements” in the Program Options and Settings dialog, shown in Figure 6-59. Once this box is checked, the input of the lateral soil movement profile versus depth is activated. The input dialog for lateral soil movements is shown in Figure 6-60.

149

Chapter 6 – Example Problems

Figure 6-58 Pile and Soil Profile for Example 24

Figure 6-59 Program and Setting Dialog Showing Check for Inclusion of Loadings by Lateral Soil Movements

150

Chapter 6 – Example Problems

Figure 6-60 Input Dialog for Lateral Soil Movements versus Depth for Example 24 The results of the analysis with loading by soil movements are shown in Figure 6-61. In this problem, the upper clay crust moves along with the spreading liquefied sand layer. As a result, the maximum moment developed in the drilled shaft is 17,990,000 in-lbs and the factored moment capacity of the shaft is exceeded.

Figure 6-61 Results of Analysis for Example 24 151

Chapter 6 – Example Problems The important factor to recognize in this example is the presence of the clay crust above the layer of spreading liquefied sand can result in loading conditions that are severe and that these conditions loading will fail all but the strongest of foundations.

6-25 Example 25- Verification of Elastic Pile in Elastic Subgrade Soil See Section 7-3-7 for the discussion of this example.

6-26 Example 26 – Verification of P-Delta Effect LPile includes the P-Delta (P-) effect in its computations of bending moment for axially loaded piles subjected to lateral loading. Example 26 is a simple verification of the P- effect. The pile geometry and soil profile for the verification problem is shown in Figure 6-62. The pile is an elastic pipe section, 36 inches in diameter with a wall thickness of 0.5 inches. The pile length is 60 feet and the pile extends 300 inches above the ground surface (Le). The upper soil layer is soft clay and the lower soil layer is sand. The pile is modeled using 240 increments with a convergence tolerance of 0.00001 inches. In this problem, the axial load on the pile is 100,000 lbs. The pile is loaded using the displacement-moment loading condition with a pile-head deflection specified equal to 1.0 inches and the pile-head moment equal to zero. The computed pile-head shear force, Vtop, is 8,859.8755 lbs and the ground line deflection, yGL, is 0.14478516 inches (these numbers were retrieved from the plot output file in order to obtain the maximum number of significant digits).

Figure 6-62 Pile and Soil Profile for Verification of P-Delta Effect 152

Chapter 6 – Example Problems The moment at the ground line, MV, from the pile-head shear force is

M V  Vtop Le  (8,859.8755 lb)(300 in.)  2,657,962.65 in - lbs The P- moment due to the eccentricity of the axial load, MP, is equal to the relative displacement of the pile-head to the ground line displacement multiplied by the axial thrust force.

M P  P( ytop  yGL )  100,000. lbs(1.0 in.  0.14478516 in.)  85,521.484 in - lbs The total moment at the ground line due to the shear force and eccentric axial load is

M total  M V  M P  2,743,484.134 in - lbs The computed moment by LPile at the ground line is 2,743,484.100 in-lbs. The error in the computed moment is −0.034 in-lbs. This is an error of 1.24×10−6 percent.

153

Chapter 6 – Example Problems

(This page was deliberately left blank)

154

Chapter 7 Validation 7-1 Introduction Two approaches are used to validate the computations of the computer program. Firstly, case studies are shown that give the comparison of maximum bending moments from experiment and from computation. Secondly, suggestions are made for checking the output to ensure that the equations of mechanics are satisfied.

7-2 Case Histories The engineering literature contains a number of papers that present the results of load tests of piles under lateral load; however, in only a small number of these paper present values of bending moment measured by instrumentation along the length of the pile. The case studies presented herein are concerned with these latter cases because the failure of a pile is frequently due to the development of a plastic hinge. A list of case histories where bending moment was measured is presented in Table 7-1. The table shows the location of the experiment, the reference citation, a general description of the soil and the position of the water table, the computed lateral load at a load factor of 2.5, and the kind and size of pile. For each of the cases, a preliminary computation was made, using the analytical methods presented herein, to find the lateral load Pult that would cause the maximum bending moment to occur. The next step was to find the experimental bending moment and the computed bending moment at the load of Pult/2.5. The reason for the comparison at the reduced loading is that the load actually applied to the pile would be reduced by a factor of safety and a value of 2.5 is reasonable. Table 7-1 Comparison of Bending Moments and Deflections from Computer Analyses and Experimental Case Histories Case Bagnolet 2 Bagnolet 3 Houston Static Houston Cyclic Japan Lake Austin Static Lake Austin Cyclic Sabine Static Sabine Cyclic Manor Static Manor Cyclic Mustang Island Static Mustang Island Cyclic Garston Los Angeles San Francisco

Mmax, kN-m 204 204 2030 2030 55.9 231 231 231 231 1757 1757 640 640 15900 4400 17740

Pt,fail, kN 138 130 950 900 50 145 113 99 72 693 543 324 295 4520 1779 8670

Pt,serv, kN 76.7 72.2 432 409 28 81 63 55 40 385 302 180 164 2055 809 3940

yt,comp, mm 9.6 9.4 20.2 26 22 35 22 49 27 11 13.1 16 15 33 21 2

yt,exp, mm 9.6 9.5 26 34 28 35 46 36 41 9.7 10.2 16 15 40 22 3

Mcomp, kN-m 104 105 702 742 19.6 110 79 103 68 760 710 305 320 6600 1640 7030

Mexp, kN-m 95 112 600 642 21.9 106 110 96 82 715 610 305 320 7500 1890 6640

Factor of Safety 2.15 1.82 3.38 3.16 2.55 2.18 2.10 2.41 2.82 2.46 2.88 2.10 2.00 2.12 2.33 2.67

A comparison of maximum bending moments from computations and from experiment is presented in Figure 7-1. As it may be seen in the figure, the agreement is excellent over three orders of magnitude. However, it is important to indicate that some of the experiments were used to develop the criteria for the response of soils under lateral loading that are used in the analyses. 155

Chapter 7 – Validation Nevertheless, the validity of those experiments cannot be questioned as reflecting the behavior of piles under lateral loading, particularly where the loading was cyclic.

Computed Maximum Service Moment, kN-m

10,000 Bagnolet 2 Houston Static Japan Lake Austin Cyclic Sabine Cyclic Manor Cyclic Mustang Island Cyclic Los Angeles

Bagnolet 3 Houston Cyclic Lake Austin Static Sabine Static Manor Static Mustang Island Static Garston San Francisco

1,000

100

10 10

100

1,000

10,000

Maximum Moment from Experiment, kN-m

Figure 7-1 Comparison of Maximum Bending Moments from Computations and from Experimental Case Histories A comparison of experimental and computed pile-head deflection values at service load levels is presented in Figure 7-2. The agreement is fair for this comparison, but with fewer tests showing larger computed values as smaller computed values. The worst agreement is for the cyclic test at Lake Austin. Except for that test, the differences probably would not lead to difficulties.

156

Chapter 7 – Validation 60 Bagnolet 2 Bagnolet 3 Houston Static Houston Cyclic Japan Lake Austin Static Lake Austin Cyclic Sabine Static Sabine Cyclic Manor Static Manor Cyclic Mustang Island Static Mustang Island Cyclic Garston Los Angeles San Francisco

Computed Top Deflection, mm

50

40

30

20

10

0

0

10

20

30

40

50

60

Top Deflection from Experiment, mm

Figure 7-2 Comparison of Experimental and Computed Pile-head Deflections at Service Load

7-3 Verification of Accuracy of Solution The best policy for a of a computer program is to assume that the output is in error unless a check is made. There are many stories about engineers accepting computer output as valid only to learn later, perhaps after some kind of failure, that the output was in error. One kind of check that is valid is that the has made many solutions with the computer and has a good idea of what the output should be. Other kinds of checks that can be made are shown in the following paragraphs. 7-3-1 Solution of Example Problems A number of example problems have been solved using LPile and the results are included in Chapter 5 of the LPile ’s Manual. The should code some of the example problems on occasion to see if identical results, or nearly identical, are obtained.

157

Chapter 7 – Validation Another example problem was analyzed and the results are shown in the following pages. The output from this example problem will be checked to illustrate some of the procedures employed for verification. 7-3-2 Numerical Precision Employed in Internal Computations All real values are programmed as IEEE 64-bit reals, ranging in magnitude from 5.0×10−324 to 1.7×10308, with a mantissa of 16 significant figures. This numerical precision was chosen because the difference-equation method requires that a relatively large number of significant figures be employed in order to avoid significant round-off errors. 7-3-3 Selection of Convergence Tolerance and Length of Increment The convergence tolerance is a number that is input to control the accuracy of the solution. The values of deflection for successive iterations are retained in memory and the differences at corresponding depths are computed. All of the differences must be less than the convergence tolerance to end the iterative computations. The convergence tolerance used in most of the example problems of Chapter 5 of the LPile ’s Manual, and in the study of this Chapter, was l10–5 in. (2.5410–7 m), which is the default value provided by the computer program. The has control over the convergence tolerance, but the default value appears to be a good selection for the majority of problems. If a significantly larger value had been selected, inaccurate computations could have resulted; had a significantly smaller value been selected, the number of iterations would be increased and, in fact, a very small value could prevent the achievement of convergence. Verification of accuracy in the solution of the difference equations has been demonstrated and results agree closely with those from the closed-form solution. In addition, the exercise presented below demonstrates to a certain extent that accurate solutions are being obtained. Convergence is usually obtained with 30 or fewer iterations when the pile is in the elastic range, which does not require much time on most computers. The must select the length of the increments into which the pile is divided by specifying the number of pile increments. The total length of the pile is the embedded length plus the portion of the pile extending above the ground surface. In cases where the pile being analyzed is extremely long, such as an oil well conductor, one may decide to shorten the length of the modeled pile to where there are just a few points of zero deflection. The behavior of the upper portion of the pile is unaffected as the length is reduced to the point where there are at least two or three points of zero deflection. The number of points of zero deflection is listed on the output for convenience. A possible exception to shortening the pile to facilitate the computations may occur if the lower portion of the pile is embedded in rock or very strong soil. In such a case, small deflection could generate large values of soil resistance that in turn could influence the behavior of the upper portion of the pile. With the length of the pile adjusted so that there is no exceptionally long portion at the bottom where the computed pile deflection is oscillating about the axis with extremely small deflections and soil resistances, the may wish to make a few runs with the pile subdivided into various numbers of increments. Such a study was done for the example shown in this chapter. Figure 7-3 shows a plot of the computed values of groundline deflection and maximum bending moment as a function of the number of increments into which the pile is subdivided. 158

Chapter 7 – Validation These values become virtually constant with the pile subdivided into 50 increments or more. Errors are introduced if the number of increments is 40 or less.

Top Deflection, inches

0.5523 0.5522 0.5521 0.5520 0.5519 0.5518 0.5517 0.5516 0.5515 0.5514 0

100

200

300

400

500

Maximum Moment, in-lbs

Number of Increments 9,451,000.0000

9,450,000.0000 9,449,000.0000 9,448,000.0000 9,447,000.0000

9,446,000.0000 9,445,000.0000 0

100

200

300

400

500

Number of Increments Figure 7-3 Influence of Number of Increments on Computed Values of Pile-head Deflection and Maximum Bending Moment Errors would have been introduced if solutions had been made for large numbers of increments, at some point beyond 500. The computed deflections at successive increments would have been so close to each other that differences would have disappeared and round-off errors would have been introduced. The number of increments at which such errors are introduced will depend, of course, on the number of significant figures employed in the computations of the particular computer being used. The computer used for the examples presented herein, with the computer program using double-precision arithmetic, employs 8 bytes of storage for a number, which translates into a word length of approximately 16 decimal digits. For the particular problem that was solved, the pile length was 12.7 m (42 ft) and the diameter was 0.914 meters (36 inches). The increment length at which good results apparently were obtained was 0.25 m (10 in.) (equal to 50 increments) which is about one-third or one-fourth of the pile diameter. However, it

159

Chapter 7 – Validation is not only the pile diameter, but also the relative stiffness of the pile compared to the stiffness of the soil that controls the results. 7-3-4 Check of Soil Resistance A drilled shaft, with a length of 12.7 m and a diameter of 0.9144 m, was constructed in sand with an angle of internal friction of 35 degrees and a unit weight of 18.7 kN/m 3. The top of the pile is unrestrained, a lateral load of 445 kN is applied, and the loading is static. A p-y curve was printed for a depth of 1.524 meters. Initially, it will be assumed that the curve is correct. The computed deflection at a depth of 1.524 m is reported as 0.007032m (0.28 in.) and the soil reaction is 204.6997 kN/m. The linear interpretation of the p-y curve that is reported for the depth of 1.524 m is p = 204.1049 kN/m The close agreement in the tabulated and computed values of soil resistance is reassuring. Some difference would have been expected between the two values of p because the computer uses the equations for the p-y relationship and the check was done by linear interpolation. The next step is to ascertain that the p-y values that are printed are consistent with the equations that are given in the Technical Manual. As noted in the computer output, the loading is static, the soil is sand with an angle of internal friction of 35 degrees, and a unit weight of 18.7 kN/m3. The pile has a diameter of 0.9144 m and the initial modulus of subgrade reaction of 24,400 kN/m3. Computations of the ultimate resistance, using the equations in the Technical Manual for response of the near-surface soils, yields 217.2 kN/m for pu and for the soils at depth pu is 1,398.1 kN/m. The former value controls. The deflection at yu is equal to 3b/80 and is 0.0343 m. The value of pu is computed by multiplying 217.2 by the value of As (equal to 1.67, found from Figure 3-25, of the Technical Manual) and becomes 362 kN/m (2,069 lbs/in.). These values confirm the last four values in the output for p shown in the computer listing. The value of ym is b/60 and is 0.0152 meter. The value of pm is found from Bs ps and is found to be 260 kN/m (reading a value of Bs = 1.20 from Figure 3-26 of the Technical Manual). This value confirms another point on the computer output. By referring to the curves giving the characteristic shape of the p-y curves for sand, it can be seen that two significant points on the py curve have been confirmed. Other points can be checked, but it will be assumed here that those points are also correct. 7-3-5 Check of Equilibrium The values of soil resistance that are listed in the computer output were plotted as a function of depth along the pile, and the plot is shown in Figure 7-4. The squares were counted and the forces that were computed from the area under the curve are shown in the figure. The following check was made of the summation of the forces in the horizontal direction. Fh = 445  657 + 227  15 = 0

160

Chapter 7 – Validation The forces are in equilibrium, which is quite fortuitous in view of the lack of precision in the procedure for numerical integration. The next step is to make a check of the position of the point of the maximum moment. As shown in Figure 7-4, the curve of soil resistance was integrated numerically and the position of zero shear force (where the area under the soil-resistance curve is 445 kN) was at approximately 2.8 m from the top of the pile. The output in the appendix shows that the depth to zero shear force is between 2.71 m and 2.88 m, which confirm the results of the numerical integration. To obtain a rough check of the value of the maximum moment, the centroid of the area under the curve equal to 445 kN is assumed to be approximately 1.8 m from the top of the pile or 1.0 m from the point of maximum moment; thus, the following equation can be written: Mmax = (445)(2.8) − (445)(1.0) Mmax = 806 kN-m The tabulated value of the maximum moment is 711kN-m, and the rough check shown above is considered acceptable. The next step in ing the mechanics is to make an approximate solution for the deflection. Several assumptions are made, as will be seen. Figure 7-4 shows that zero deflection occurs at depths of approximately 4.9 m and 10.9 m (where the soil resistance is zero), so the assumption is made that a zero slope exists in the deflection curve at midway between these two points, or at a depth of 7.9 meters. The deflection at the top of the pile can be computed by taking moments of the M/EI diagram about the top and down to the point of zero slope. In order to simplify the computations, a further assumption is made that concentrated loads can be used to obtain the moment diagram instead of the distributed loads. Referring to Figure 7-4, the concentrated loads to be used in the analysis are a pile-head shear load of 445 kN, a resisting load of 657 kN at approximately 2.2 m from the top of the pile, and a resisting load of 165 kN at approximately 6.8 m from the top of the pile. The following equation results: yt 

 1 (7.9) 3 (5.7) 2  657 445 734,000  3 2

(2)(5.7)  (1.1)  (2)(1.1)    165  6.8   2.2   3  2  3  2

1 73,134  64,038  742 734,000  0.0134 m  0.053 in. 

The analysis found yt to be 0.0134 meters (0.52 inch). The agreement is close, in view of the assumptions that were made. This computation completes the checking of the mechanics of the output from a computer run. While the results are not fully definitive, there is ample reason to trust the coding if a proper selection is made of a computer, the number of increments for a particular run, and the value of the tolerance used for concluding the iterations.

161

Chapter 7 – Validation Mobilized Soil Reaction, p , kN/m -300 0

-200

-100

445

0

100

200

300

2.2 2

445

657 7.9

Depth, m

4

6

165

227

1.1

8

10

15

12

Figure 7-4 Plot of Mobilized Soil Resistance versus Depth 7-3-6 Use of Non-Dimensional Curves Another type of verification can be made by using the p-y curves as tabulated by the computer. These curves should be checked by the engineer to be sure that they are accurate. Then nondimensional curves can be employed to solve the problem. These curves are presented by Matlock and Reese (1962) and in Reese (1984). 7-3-7 Use of Closed-form Solutions Closed-form solutions for the behavior of a semi-infinite elastic beam on an elastic foundation have been presented by numerous authors. These solutions are the only means of checking the solutions obtained using LPile by hand computation because any problem that involves either a nonlinear p-y curve or a beam with nonlinear moment-curvature behavior does not have a corresponding closed-form solution. For the case of a semi-infinite beam with shear and moment applied to the end, the closeform solutions for deflection, bending moment, and shear force in the beam are the following.

162

Chapter 7 – Validation Define the modulus of elasticity, E, and moment of inertia, I, of the beam, and the subgrade constant, k. Compute the constant  as

 4

k 4EI

Timoshenko (1941) states that the pile is considered “long” if the product of  and the pile length (L) is greater than 4. The closed-form solution for pile deflection, y, moment, M, and shear force, V, along the length of the pile (x) as a function of pile-head shear, Vt, and pile-head moment, Mt, is

y

 e  x Vt cos x  M t cos x  sin x  2  2 EI   

V  M  e x  t sin x  M t sin x  cos x    V  e x Vt cos x  sin x   2M t  sin x Analyses of elastic piles in elastic soils can be performed using LPile using the elastic subgrade soil model. The elastic subgrade constant k is computed as the product of the pile diameter times the elastic modulus of subgrade reaction. For the verification problem, define the following input for LPile. 

An elastic pile with diameter = 12 inches, a wall thickness of 0.5 inch, and a Young’s modulus of elasticity of 29,000,000 psi. This results in a moment of inertia of

d o4  d i4 12 4  114 I    299.187613 in4 64 64 

Use the elastic subgrade soil model in LPile with a subgrade modulus of 500 pci. Compute the elastic subgrade constant k using

k  Es d  (500)(12)  6,000 psi 

Define Vt = 10,000 lbs and Mt = 250,000 in-lbs The data file for this verification is provided as Example 25.

To provide the best check on the accuracy of the computations performed by LPile, the equations above were programed in an electronic spreadsheet program and the computed results were imported into the spreadsheet program from the plot output file in which all output is written in scientific notation. Graphs of closed-form versus computed solutions were prepared for lateral deflection, bending moment, and shear force. The graphs of the closed-form versus computed results are presented in Figure 7-5 through Figure 7-7, along with regression 163

Chapter 7 – Validation equations. As can be seen, for a linear regression, the coefficient of determination, R2, is 1.0 in all cases, indicating that the accuracy of the solution is excellent.

Deflection Computed by LPile, inches

0.12

0.1

0.08

0.06

0.04

0.02

0

-0.02 -0.02

0

0.02

0.04

0.06

0.08

0.1

0.12

Deflection Computed by Theory, inches

Figure 7-5 Verification of Pile Deflections 7-3-8 Concluding Comments on Verification The discussion above presents some procedures that can be used for ing the accuracy of the output from the computer. The point cannot be made too strongly that the engineer should make verification a priority in working with LPile. The , if desired, may easily perform some of the elementary computations shown in this chapter. With regard to the static equilibrium of the lateral force on a single pile, the values of soil resistance can be computed and plotted along the length of the pile. With the lateral loads at the top of the pile, a check on the equilibrium of lateral forces can be made. A satisfactory check has been made by estimation; a more comprehensive check can be made by use of numerical integration of the distributed loads. The program will also conduct such checks internally to ensure the force equilibrium.

164

Chapter 7 – Validation

Moment Computed by LPile, in-lbs

400,000

300,000

200,000

100,000

0

-100,000 -100,000

0

100,000

200,000

300,000

400,000

Moment Computed by Theory, in-lbs

Figure 7-6 Verification of Bending Moments The final internal check relates to the computed movement of the system. The first step is to refer to the computer output to confirm that the distributed load (soil resistance) and the distributed deflections along the length of the pile are consistent with the p-y curves that were input. If equations were used to compute the values of p and y, it is necessary to interpret the equations at a sufficient number of points to shown that the soil criteria for lateral load was followed. The second step with respect to lateral load is to employ the diagram is Step 1 and to use principles of mechanics to ascertain that the deflection of the individual piles was computed correctly. While employing the steps shown above have confirmed the internal functioning of LPile, the application of the program to results of field experiments is useful. The book by Reese and Van Impe (2011) presents a discussion of the development of the methods used in LPile and applies the methods to several cases.

165

Chapter 7 – Validation

Shear Force Computed by LPile, lbs

15,000

10,000

5,000

0

-5,000

-10,000 -10,000

-5,000

0

5,000

10,000

Shear Force Computed by Theory, lbs

Figure 7-7 Verification of Shear Forces

166

15,000

Chapter 8 Line-by-Line Guide for Input The input file for LPile Format Version 8 is an ASCII text file. The data file is updated with the latest data contained in the data editing dialogs of LPile immediately before every analysis is made. The computation functions in LPile begin by reading the input data file. The general format is a series of key words that denote the start of a section of data. The key words may be entered in any order, but the order of input in each section must follow a specific sequence. The content of the input data file is designed to be easily understandable by the .

8-1 Key Words for Input Data File The following table lists the key words that define sections of data. The key words may be entered in any order. Table 8-1 Key Words for Definition of Input Data Input Command Word LPILEP8 TITLE OPTIONS SECTIONS AXIAL THRUST LOADS SOIL LAYERS TIP SHEAR PILE BATTER AND SLOPE LRFD LOADS LRFD FACTORS AND CASES LOADING SOIL MOVEMENTS GROUP EFFECT FACTORS P-Y OUTPUT DEPTHS FOUNDATION STIFFNESS PILE PUSHOVER ANALYSIS DATA PILE BUCKLING ANALYSIS DATA END

Data Type Defined by Key Word Input file format version number Title lines for data file (five lines) Program and analysis options Pile section and material properties Axial thrust loads used in nonlinear moment-curvature computations Soil profile dimension and soil properties used for p-y curve computations Tip shear versus lateral tip movement data Pile batter and slope data Unfactored loads for LRFD analysis Load and resistance factors and load combination data Pile-head boundary conditions and loading data for conventional analysis Soil movement versus depth data Group effect factors (p and y-multiplier) data Output depths for reported p-y curves Control data for computation of foundation stiffness Control data for computation of pile pushover analysis Control data for computation of pile buckling analysis Terminates reading of input data

167

8-2 TITLE Command The TITLE keyword indicated that the following five lines of text are entered for the problem title. Entering fewer or more than five lines of text will result in an execution error and input of data is ended. By default, the following lines of text are predefined in LPile, but may be changed to anything that the wishes to enter. The default lines are: Project Name: Job Number: Client: Engineer: Description:

8-3 OPTIONS Command The OPTIONS keyword begins the definition of program options selected by the . Some options are either Yes or No options and the other options require numerical input. The order of the options must be in the following sequence. Table 8-2 Program Options and Settings Options Keyword (without spaces) Units UseLRFD ComputeKmatrix UseTipShear

Defines Option for

Permissible Values

Engineering units Perform LRFD analysis Compute pile-head stiffness matrix component values Use tip shear resistance curve

USCS, SI YES, NO

UseDistributedLoading

Include loading by distributed lateral loading

UseSoilMovement

Include loading by soil movements

168

YES, NO YES, NO ALL, ONE, NO To enter multiple distributed load profiles for every load case enter “ALL.” To enter a single distributed lateral load profile to apply to all load cases enter “ONE.” To omit distributed lateral loading enter “NO.” ALL, ONE, NO To enter multiple soil movement profiles for every load case enter “ALL.” To enter a single soil movement profile to apply to all load cases enter “ONE.”

Options Keyword (without spaces)

Defines Option for

Permissible Values To omit soil movements enter “NO.”

UsePYModifiers ComputeEIOnly

Loading

IterationsLimit ConvergenceTolerance NumberPileIncrements PrintSummaryOnly PrintIncrement PrintPYCurves ComputeInteration ComputePushover ComputePileBuckling

Use p-y modifiers for group action Compute nonlinear momentcurvature values and nominal moments capacity only

Number of cycles of loading

Maximum number of iterations for numerical solution Convergence tolerance for numerical solution Number of pile increments for numerical solution Print summary tables only Printing increment for pile response Report p-y curves at specified depths Compute interaction diagram only Compute pushover analysis Compute pile buckling analysis

YES, NO YES, NO If for static loading enter: “STATIC”, followed by 5 spaces, then “1” If for cyclic loading enter: “CYCLIC”, followed by number of cycles of loading, 5000 = maximum 500 = default value, 1,000 = maximum value 1.0105 inches = default value 100 = default, 40 = minimum, 500 = maximum YES, NO 1 = default value YES, NO YES, NO YES, NO YES, NO

8-4 SECTIONS Command The SECTIONS keyword begins the definition of structural properties of the pile to be analyzed. The order of the input data must be in the following sequence. The input data consists of one or more numbers followed by an optional comment. Data written by LPile will be followed by a comment that describes the input data and the engineering units of the data. Table 8-3 Pile Section Data SECTIONS Line Number 1 Total Number of Sections 2 Section number

Input Value 1 = minimum, 10 = maximum 1 = top section, sections number consecutively from top to bottom of pile

169

SECTIONS Line Number

Input Value 0 = rectangular, 1 = drilled shaft, 2 = drilled shaft with casing, 3 = drilled shaft with casing and core filled with concrete, -3 = drilled shaft with casing and void core 4 = steel pipe 5 = circular solid prestressed pile, 6 = circular hollow prestressed pile 7 = square solid prestressed pile, 8 = square hollow prestressed pile, 9 = octagonal solid prestressed pile, 10= octagonal hollow prestressed pile, 11 = elastic pile, 12 = elastic-plastic pile 13 = pile with -defined nonlinear bending properties in of EI and moment values -13 = pile with -defined nonlinear bending properties in of moment and curvature values

3 Section Type

Follow by section dimensions for specific Section Type Table 8-4 Properties for Rectangular Sections Properties for rectangular sections 3.0.1 Section dimension 3.0.2 Shear capacity 3.0.3 Section dimension 3.0.4 Section dimension

Lines 3.0 Length of section, ft or m Shear capacity of section, lbs or kN Section depth, inches or mm Section width inches or mm

Follow with concrete properties (Lines 4) and rebar properties (Lines 5) to complete section data.

Table 8-5 Properties for Drilled Shafts Properties for Drilled Shaft Sections 3.1.1 Section dimension 3.1.2 Shear capacity 3.1.3 Section dimension 3.1.4 Section dimension

Lines 3.1 Length of section, ft or m Shear capacity of section, lbs or kN Section diameter, inches or mm Section width inches or mm

Follow with concrete properties (Lines 4) and rebar properties (Lines 5) to complete section data. 170

Table 8-6 Properties of Drilled Shafts with Casing Properties of Drilled Shafts with Casing 3.2.1 Section dimension 3.2.2 Shear capacity 3.2.3 Section dimension 3.2.4 Section dimension 3.2.5 Casing property 3.2.6 Casing property

Lines 3.2 Length of section, ft or m, Shear capacity of section, lbs or kN Section diameter, inches or mm Casing wall thickness, inches or mm Yield stress of casing, psi or kPa Young’s modulus of casing, psi or kPa

Follow with concrete properties (Lines 4) and rebar properties (Lines 5) to complete section data. Table 8-7 Properties of Drilled Shafts with Casing and Core Properties for Drilled Shafts with Casing and Core 3.3.1 Section dimension 3.3.2 Shear capacity 3.3.3 Section dimension 3.3.4 Section dimension 3.3.5 Casing property 3.3.6 Casing property Properties for Drilled Shafts with Casing and Core 3.3.7 Core property 3.3.7 Core property 3.3.8 Core property 3.3.9 Core property Follow with concrete properties (Lines section data.

Lines 3.3 Length of section, ft or m, Shear capacity of section, lbs or kN Section diameter, inches or mm Casing wall thickness, inches or mm Yield stress of casing, psi or kPa Young’s modulus of casing, psi or kPa Lines 3.3 Core diameter, inches or mm Core wall thickness, inches or mm Yield stress of core, psi or kPa Young’s modulus of core, psi or kPa 4) and rebar properties (Lines 5) to complete

Table 8-8 Properties for Steel Pipe Piles Properties for Steel Pipe Piles 3.4.1 Section dimension 3.4.2 Shear capacity 3.4.3 Pipe pile property 3.4.4 Pipe pile property 3.4.5 Pipe pile property 3.4.6 Pipe pile property

Lines 3.4 Length of section, ft or m Shear capacity of section, lbs or kN Core diameter, inches or mm Core wall thickness, inches or mm Yield stress of core, psi or kPa Young’s modulus of core, psi or kPa

This completes the definition of section properties for steel pipe sections.

171

Table 8-9 Properties for Circular Solid Prestressed Piles Properties for Circular Solid Prestressed Piles Lines 3.5 3.5.1 Section dimension Length of section, ft or m 3.5.2 Shear capacity Shear capacity of section, lbs or kN 3.5.3 Section dimension Section diameter, inches or mm Follow with concrete properties (Lines 4) and prestressing strand properties (Lines 6) to complete section data. Table 8-10 Properties for Circular Hollow Prestressed Piles Properties for Circular Hollow Prestressed Lines 3.6 Piles 3.6.1 Section dimension Length of section, ft or m 3.6.2 Shear capacity Shear capacity of section, lbs or kN 3.6.3 Section dimension Section diameter, inches or mm 3.6.4 Section core diameter Core void diameter, inches or mm Follow with concrete properties (Lines 4) and prestressing strand properties (Lines 6) to complete section data. Table 8-11 Properties for Square Solid Prestressed Piles Properties for Square Solid Prestressed Piles 3.7.1 Section dimension 3.7.2 Shear capacity 3.7.3 Section dimension 3.7.4 Section chamfer

Lines 3.7 Length of section, ft or m Shear capacity of section, lbs or kN Section diameter, inches or mm Corner chamfer, inches or mm

Follow with concrete properties (Lines 4) and prestressing strand properties (Lines 6) to complete section data. Table 8-12 Properties for Square Hollow Prestressed Piles Properties for Square Hollow Prestressed Lines 3.8 Piles 3.8.1 Section dimension Length of section, ft or m 3.8.2 Shear capacity Shear capacity of section, lbs or kN 3.8.3 Section dimension Section diameter, inches or mm 3.8.4 Section core diameter Core void diameter, inches or mm 3.8.5 Section chamfer Corner chamfer, inches or mm Follow with concrete properties (Lines 4) and prestressing strand properties (Lines 6) to complete section data.

172

Table 8-13 Properties for Octagonal Solid Prestressed Piles Properties for Octagonal Solid Prestressed Lines 3.9 Piles 3.9.1 Section dimension Length of section, ft or m 3.9.2 Section dimension Section diameter, inches or mm Follow with concrete properties (Lines 4) and prestressing strand properties (Lines 6) to complete section data. Table 8-14 Properties for Square Hollow Prestressed Piles Properties for Square Hollow Prestressed Lines 3.10 Piles 3.10.1 Section dimension Length of section, ft or m 3.10.2 Shear capacity Shear capacity of section, lbs or kN 3.10.3 Section dimension Section diameter, inches or mm 3.10.4 Section core diameter Core void diameter, inches or mm Follow with concrete properties (Lines 4) and prestressing strand properties (Lines 6) to complete section data. Table 8-15 Properties for Elastic Piles Properties for Elastic Piles 3.11.1 Section dimension

3.11.2 Geometric shape code

Properties of elastic rectangular sections 3.11.3.1.1 Section property 3.11.3.1.2 Section dimension 3.11.3.1.3 Section dimension 3.11.3.1.4 Section dimension 3.11.3.1.5 Section dimension 3.11.3.1.6 Section dimension 3.11.3.1.7 Section dimension 3.11.3.1.8 Section property 3.11.3.1.9 Section property

Lines 3.11 Length of section, ft or m Enter: 1 = rectangular, follow by Lines 3.11.3.1 2 = circular solid, follow by Lines 3.11.3.2 3 = pipe , follow by Lines 3.11.3.3 4 = strong H-pile, follow by Lines 3.11.3.4 5 = weak H-pile, follow by Lines 3.11.3.5 6 = embedded pole, follow by Lines 3.11.3.6 Lines 3.11.3.1 Young’s modulus, psi or kPa Width at top, inches or mm Width at bottom, inches or mm Depth at top, inches or mm Depth at bottom, inches or mm Area at top, sq. inches or sq. mm Area at bottom, sq. inches or sq. mm Moment of inertia at top, in.4 or mm4 Moment of inertia at bottom, in.4 or mm4

173

Properties of elastic circular sections 3.11.3.2.1 Section property 3.11.3.2.2 Section dimension 3.11.3.2.3 Section dimension 3.11.3.2.4 Section dimension 3.11.3.2.5 Section dimension 3.11.3.2.6 Section property 3.11.3.2.7 Section property

Lines 3.11.3.2 Young’s modulus, psi or kPa Width at top, inches or mm Width at bottom, inches or mm Area at top, sq. inches or sq. mm Area at bottom, sq. inches or sq. mm Moment of inertia at top, in.4 or mm4 Moment of inertia at bottom, in.4 or mm4

Properties of elastic pipe sections 3.11.3.3.1 Section property 3.11.3.3.2 Section dimension 3.11.3.3.3 Section dimension 3.11.3.3.4 Section dimension 3.11.3.3.5 Section dimension 3.11.3.3.6 Section dimension 3.11.3.3.7 Section dimension 3.11.3.3.8 Section property 3.11.3.3.9 Section property

Lines 3.11.3.3 Young’s modulus, psi or kPa Width at top, inches or mm Width at bottom, inches or mm Wall thickness at top, inches or mm Wall thickness at bottom, inches or mm Area at top, sq. inches or sq. mm Area at bottom, sq. inches or sq. mm Moment of inertia at top, in.4 or mm4 Moment of inertia at bottom, in.4 or mm4

Properties of strong H-pile sections 3.11.3.4.1 Section property 3.11.3.4.2 Section dimension 3.11.3.4.3 Section dimension 3.11.3.4.4 Section dimension 3.11.3.4.5 Section dimension 3.11.3.4.6 Section dimension 3.11.3.4.7 Section dimension

Lines 3.11.3.4 Young’s modulus, psi or kPa H section flange width, inches or mm H section depth, inches or mm H section flange thickness, inches or mm H section web thickness, inches or mm H section area, sq. inches or sq. mm H section moment of inertia, in.4 or mm4

Properties of weak H-pile sections 3.11.3.5.1 Section property 3.11.3.5.2 Section dimension 3.11.3.5.3 Section dimension 3.11.3.5.4 Section dimension 3.11.3.5.5 Section dimension 3.11.3.5.6 Section dimension 3.11.3.5.7 Section property

Lines 3.11.3.5 Young’s modulus, psi or kPa H section flange width, inches or mm H section depth, inches or mm H section flange thickness, inches or mm H section web thickness, inches or mm H section area, sq. inches or sq. mm H section moment of inertia, in.4 or mm4

Properties of elastic embedded pole 3.11.3.6.1 Section property 3.11.3.6.2 Section dimension 3.11.3.6.3 Section dimension 3.11.3.6.4 Section dimension

Lines 3.11.3.6 Young’s modulus, psi or kPa Pole width at top, inches or mm Pole width at bottom, inches or mm Pole area at top, sq. inches or sq. mm 174

Properties of elastic embedded pole 3.11.3.6.5 Section dimension 3.11.3.6.6 Section property 3.11.3.6.7 Section property 3.11.3.6.8 Section dimension

Lines 3.11.3.6 Pole area at bottom, sq. inches or sq. mm Pole moment of inertia at top, in.4 or mm4 Pole moment of inertia at bottom, in.4 or mm4 Drilled hole diameter, inches or mm

Table 8-16 Properties for Elastic Piles with Specified Moment Capacity Properties for Elastic Piles with Specified Moment Capacity 3.11.1 Section dimension 3.11.2 Shear capacity at top of section 3.11.3 Shear capacity at bottom of section

3.11.4 Geometric shape code

Lines 3.11 Length of section, ft or m Shear capacity of section, lbs or kN Shear capacity of section, lbs or kN Enter: 1 = rectangular, follow by Lines 3.11.3.1 2 = circular solid, follow by Lines 3.11.3.2 3 = pipe , follow by Lines 3.11.3.3 4 = strong H-pile, follow by Lines 3.11.3.4 5 = weak H-pile, follow by Lines 3.11.3.5 6 = embedded pole, follow by Lines 3.11.3.6

Properties of elastic rectangular sections with Lines 3.11.4.1 specified moment capacity 3.11.4.1.1 Section property Young’s modulus, psi or kPa 3.11.4.1.2 Section dimension Width at top, inches or mm 3.11.4.1.3 Section dimension Width at bottom, inches or mm 3.11.4.1.4 Section dimension Depth at top, inches or mm 3.11.4.1.5 Section dimension Depth at bottom, inches or mm 3.11.4.1.6 Section dimension Area at top, sq. inches or sq. mm 3.11.4.1.7 Section dimension Area at bottom, sq. inches or sq. mm 3.11.4.1.8 Section property Moment of inertia at top, in.4 or mm4 3.11.4.1.9 Section property Moment of inertia at bottom, in.4 or mm4 Properties of elastic circular sections with Lines 3.11.4.2 specified moment capacity 3.11.4.2.1 Section property Young’s modulus, psi or kPa 3.11.4.2.2 Section dimension Width at top, inches or mm 3.11.4.2.3 Section dimension Width at bottom, inches or mm 3.11.4.2.4 Section dimension Area at top, sq. inches or sq. mm 3.11.4.2.5 Section dimension Area at bottom, sq. inches or sq. mm 3.11.4.2.6 Section property Moment of inertia at top, in.4 or mm4 3.11.4.2.7 Section property Moment of inertia at bottom, in.4 or mm4

175

Properties of elastic pipe sections with Lines 3.11.4.3 specified moment capacity 3.11.4.3.1 Section property Young’s modulus, psi or kPa 3.11.4.3.2 Section dimension Width at top, inches or mm 3.11.4.3.3 Section dimension Width at bottom, inches or mm 3.11.4.3.4 Section dimension Wall thickness at top, inches or mm 3.11.4.3.5 Section dimension Wall thickness at bottom, inches or mm 3.11.4.3.6 Section dimension Area at top, sq. inches or sq. mm 3.11.4.3.7 Section dimension Area at bottom, sq. inches or sq. mm 3.11.4.3.8 Section property Moment of inertia at top, in.4 or mm4 3.11.4.3.9 Section property Moment of inertia at bottom, in.4 or mm4 Properties of strong H-pile sections with Lines 3.11.4.4 specified moment capacity 3.11.4.4.1 Section property Young’s modulus, psi or kPa 3.11.4.4.2 Section dimension H section flange width, inches or mm 3.11.4.4.3 Section dimension H section depth, inches or mm 3.11.4.4.4 Section dimension H section flange thickness, inches or mm 3.11.4.4.5 Section dimension H section web thickness, inches or mm 3.11.4.4.6 Section dimension H section area, sq. inches or sq. mm 3.11.4.4.7 Section property H section moment of inertia, in.4 or mm4 Properties of weak H-pile sections with Lines 3.11.4.5 specified moment capacity 3.11.4.5.1 Section property Young’s modulus, psi or kPa 3.11.4.5.2 Section dimension H section flange width, inches or mm 3.11.4.5.3 Section dimension H section depth, inches or mm 3.11.4.5.4 Section dimension H section flange thickness, inches or mm 3.11.4.5.5 Section dimension H section web thickness, inches or mm 3.11.4.5.6 Section dimension H section area, sq. inches or sq. mm 3.11.4.5.7 Section property H section moment of inertia, in.4 or mm4 Properties of elastic embedded pole with Lines 3.11.4.6 specified moment capacity 3.11.4.6.1 Section property Young’s modulus, psi or kPa 3.11.4.6.2 Section dimension Pole width at top, inches or mm 3.11.4.6.3 Section dimension Pole width at bottom, inches or mm 3.11.4.6.4 Section dimension Pole area at top, sq. inches or sq. mm 3.11.4.6.5 Section dimension Pole area at bottom, sq. inches or sq. mm 3.11.4.6.6 Section property Pole moment of inertia at top, in.4 or mm4 3.11.4.6.7 Section property Pole moment of inertia at bottom, in.4 or mm4 3.11.4.6.8 Section dimension Drilled hole diameter, inches or mm

176

Table 8-17 Properties for Piles with Nonlinear Bending Properties Properties for Piles with Nonlinear Bending Lines 3.13 Properties 3.13.1 Section dimension Length of section, ft or m 3.13.2 Shear capacity Shear capacity of section, lbs or kN 3.13.3 Section dimension Section diameter, inches or mm 3.13.4.1 Number of axial thrusts Minimum = 1, maximum = 100 Repeat Lines 3.13.4.1.1 through 3.13.4.1.2.2 for every axial thrust value 3.13.4.1.1 Axial thrust force Axial thrust force in lbs or kN 3.13.4.1.2 Number of input M-EI values for Section or Number of input moment and Minimum = 2, maximum = 150 curvature values for Section Repeat the following two lines for each input point 3.13.4.1.2.1 Moment Bending moment in in-lbs or kN-m 3.13.4.1.2.2 Bending Stiffness EI or Bending Bending stiffness in lb-in2 or kN-m2, or Curvature bending curvature in rad/in or rad/m Table 8-18 Concrete Properties Concrete Properties 1 Compressive strength of concrete 2 Maximum coarse aggregate size 3 Concrete tensile strength option

4 Concrete stress-strain curve option

Lines psi or kPa in. or mm “Use default concrete tensile strength” (provided for future program option to utilize non-default value) “Use internal stress-strain curve for concrete” (provided for future program option to utilize -defined stress-strain curve for concrete)

Table 8-19 Reinforcing Steel Properties Reinforcing Steel Properties

1 Rebar option

2 Rebar pattern option

Lines Rebar number options: For no rebar enter: “No rebar” If not Section 1 and rebar data same as above section, enter: “Rebar Arrangement Same As Section Above” If Section 1 or rebar not same as above section enter: “Rebar Arrangement Same As Section Above” If rebar in circular pattern, enter: “Rebar in circle”, and follow by Lines 3.1 through 3.7. If rebar in noncircular pattern, enter: “Rebar in noncircular pattern”, and follow by 177

Reinforcing Steel Properties 3.1 Circular pattern data 3.2 Circular pattern data 3.2 Circular pattern data 3.3 Circular pattern data 3.4 Circular pattern data 3.5 Circular pattern data 3.6 Circular pattern data 3.7 Circular pattern data 4.1 Non-circular pattern data 4.2 Non-circular pattern data 4.3 Non-circular pattern data 4.4.1 Non-circular pattern bar data 4.4.2 Non-circular pattern bar data 4.4.3 Non-circular pattern bar data 4.4.4 Non-circular pattern bar data 4.4.5 Non-circular pattern bar data 4.4.6 Non-circular pattern bar data

Lines Lines 4.1 through 4.4.6 Yield stress of bars, psi or kPa Young’s modulus of bars, psi or kPa Number of bars or bundles; Maximum = 300 for single bars, Maximum = 150 for 2-bar bundles, or Maximum = 100 for 3-bar bundles Number of bars in bundle, 1 to 3 Bar diameter, inches or mm Bar area, sq. in. or sq. mm Rebar clear cover, inches or mm Rebar circle offset from centroid of section, inches or mm Yield stress of bars, psi or kPa Young’s modulus of bars, psi or kPa Number of bars, Repeat line 5.4.4.1 through 5.4.4.6 for all bars in noncircular arrangement Bar identification number Bar size index number Bar diameter, inches or mm Bar area, sq. in. or sq. mm Bar X-coordinate Bar Y-coordinate

Table 8-20 Prestressing Strand Properties Prestressing Strand Properties

1 Strand arrangement option

2.1 Auto-arranged strand property

2.2 Auto-arranged strand property 2.3 Auto-arranged strand property 2.4 Auto-arranged strand property 2.5 Auto-arranged strand property 2.6 Auto-arranged strand property

Lines If strands in arranged pattern, enter: “Autoposition strands”, and follow by Lines 2.1 through 2.7. If strands in non-arranged pattern, enter: “Manually-positioned strands”, and follow by Lines 3.1 through 3.6.4. Strand family type, enter 1 for Grade 250 Lolax strands, 2 for Grade 270 Lo-lax strands, 3 for Grade 300 strands, 4 for Grade 145 smooth bars, 5 for Grade 160 smooth bars, 6 for deformed bars Stand size index number Number of strands Prestressing force, lbs or kN Fraction of prestress loss, decimal Strand clear cover, inches or mm 178

Prestressing Strand Properties 2.7 Auto-arranged strand property

3.1 Manually-arranged strand property

3.2 Manually-arranged strand property 3.3 Manually-arranged strand property 3.4 Manually-arranged strand property 3.5 Manually-arranged strand property Repeat Lines 3.6.1 through 3.6.4 for all strands 3.6.1 Individual strand property 3.6.2 Individual strand property 3.6.3 Individual strand property 3.6.4 Individual strand property

Lines Strand pattern type, enter 0 for circle, 1 for square, 2 for weak square Strand family type, enter 1 for Grade 250 Lolax strands, 2 for Grade 270 Lo-lax strands, 3 for Grade 300 strands, 4 for Grade 145 smooth bars, 5 for Grade 160 smooth bars, 6 for deformed bars Stand size index number Number of strands, Prestressing force, lbs or kN Fraction of prestress loss, decimal Strand identification number Strand size index Strand X-coordinate Strand Y-coordinate

8-5 SOIL LAYERS Command Table 8-21 Soil Layer Properties Soil Layer Properties 1 Number of soil Layers Repeat following lines for each soil layer

Lines Minimum = 1, maximum = 40

179

Soil Layer Properties

2(1) Soil type index.

2(2) Depth of top of soil layer 2(3) Depth of bottom of soil layer

Lines Enter 1 = soft clay, follow by lines 3.1 2 = API soft clay with J, follow by lines 3.2 3 = stiff clay with free water, follow by lines 3.3 4 = stiff clay without free water, follow by lines 3.4 5 = stiff clay without free, with k , follow by lines 3.5 6 = Reese sand, follow by lines 3.6 7 = API sand, follow by lines 3.7 8 = Liquefied sand, follow by lines 3.8 9 = Liquefied sand hybrid model, follow by line 3.9 10 = Reese weak rock, follow by lines 3.10 11 = vuggy limestone (strong rock) , follow by lines 3.11 12 = Piedmont residual soil, follow by lines 3.12 13 = massive rock, follow by lines 3.13 14 = loess, follow by lines 3.14 15 = silt (cemented c- soil) , follow by lines 3.15 16 = elastic subgrade, follow by lines 3.16 17 = -input p-y curves, follow by lines 3.17 Depth of top of soil layer below pile head, ft or m Depth of bottom of soil layer below pile head, ft or m

Table 8-22 Properties for Soft Clay 3.1 Properties for soft clay (3 values per line) 3.1.1(1) Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 3.1.1(2) Undrained shear strength at top of Shear strength in psf or kPa layer Strain factor 50 (dimensionless), enter 0 for 3.1.1(3) Strain factor E50 at top of layer internal default value 3.1.2(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer 3.1.2(2) Undrained shear strength at bottom Shear strength in psf or kPa of layer Strain factor 50 (dimensionless), enter 0 for 3.1.2(3) Strain factor E50 at bottom of layer internal default value

180

Table 8-23 Properties for API Soft Clay 3.2 Properties for API soft clay with J 3.2.1(1) Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 3.2.1(2) Undrained shear strength at top of Shear strength in psf or kPa layer Strain factor 50 (dimensionless), 3.2.1(3) Strain factor E50 at top of layer enter 0 for internal default value 3.2.1(4) Parameter J at top of layer dimensionless 3.2.2(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer 3.2.2(2) Undrained shear strength at bottom Shear strength in psf or kPa of layer Strain factor 50 (dimensionless), 3.2.2(3) Strain factor E50 at bottom of layer enter 0 for internal default value 3.2.1(4) Parameter J at bottom of layer dimensionless Table 8-24 Properties for Stiff Clay with Free Water 3.3 Properties for stiff clay with free water (4 values per line) 3.3.1(1) Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 3.3.1(2) Undrained shear strength at top of Shear strength in psf or kPa layer Strain factor 50 (dimensionless), enter 0 for 3.3.1(3) Strain factor E50 at top of layer internal default value k in lbs/in3 or kN/m3, enter 0 for internal 3.3.1(4) p-y modulus k at top of layer default value 3.3.2(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer 3.3.2(2) Undrained shear strength at bottom Shear strength in psf or kPa of layer Strain factor 50 (dimensionless), enter 0 for 3.3.2(3) Strain factor E50 at bottom of layer internal default value k in lbs/in3 or kN/m3, enter 0 for internal 3.3.1(4) p-y modulus k at bottom of layer default value Table 8-25 Properties for Stiff Clay without Free Water 3.4 Properties for stiff clay without free water (3 values per line) 3.4.1(1) Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 3.4.1(2) Undrained shear strength at top of Shear strength in psf or kPa layer Strain factor 50 (dimensionless), 3.4.1(3) Strain factor E50 at top of layer enter 0 for internal default value 3.4.2(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer 3.4.2(2) Undrained shear strength at bottom Shear strength in psf or kPa 181

3.4 Properties for stiff clay without free water (3 values per line) of layer Strain factor 50 (dimensionless), 3.4.2(3) Strain factor E50 at bottom of layer enter 0 for internal default value Table 8-26 Properties for Stiff Clay with Free Water Using k 3.5 Properties for stiff clay without free water using k (4 values per line) 3.5.1(1) Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 3.5.1(2) Undrained shear strength at top of Shear strength in psf or kPa layer Strain factor 50 (dimensionless), enter 0 for 3.5.1(3) Strain factor E50 at top of layer internal default value k in lbs/in3 or kN/m3, enter 0 for internal 3.5.1(4) p-y modulus k at top of layer default value 3.5.2(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer 3.5.2(2) Undrained shear strength at bottom Shear strength in psf or kPa of layer Strain factor 50 (dimensionless), 3.5.2(3) Strain factor E50 at bottom of layer enter 0 for internal default value k in lbs/in3 or kN/m3, enter 0 for internal 3.5.2(4) p-y modulus k at bottom of layer default value Table 8-27 Properties for Sand 3.6 Properties for Reese sand (3 values per line) 3.6.1(1) Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 3.6.1(2) Friction angle at top of layer Friction angle in degrees k in lbs/in3 or kN/m3, enter 0 for internal 3.6.1(3) p-y modulus k at top of layer default value 3.6.2(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer 3.6.2(2) Friction angle at bottom of layer Friction angle in degrees k in lbs/in3 or kN/m3, enter 0 for internal 3.6.2(3) p-y modulus k at bottom of layer default value Table 8-28 Properties for API Sand 3.7 Properties for API sand (3 values per line) 3.7.1(1) Effective unit weight at top of layer 3.7.1(2) Friction angle at top of layer 3.7.1(3) p-y modulus k at top of layer 3.7.2(1) Effective unit weight at top of layer 3.7.2(2) Friction angle at bottom of layer 3.7.2(3) p-y modulus k at bottom of layer

Effective unit weight in pcf or kN/m3 Friction angle in degrees k in lbs/in3 or kN/m3, enter 0 for internal default value Effective unit weight in pcf or kN/m3 Friction angle in degrees k in lbs/in3 or kN/m3, enter 0 for internal

182

3.7 Properties for API sand (3 values per line) default value Table 8-29 Properties for Liquefied Sand 3.8 Properties for liquefied sand (1 value per line) 3.8.1 Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 3.8.2 Effective unit weight at bottom of layer Effective unit weight in pcf or kN/m3 Table 8-30 Properties for Liquefied Sand Hybrid Model 3.9 Properties for liquefied sand hybrid model (4 values per line) Option 1 is to enter values for effective unit weight and SPT blowcount and zeros for residual strength and 50. Option 2 is to enter non-zero values for effective unit weight and for residual strength and 50. 3.9.1(1) Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 3.9.1(2) SPT blowcount at top of layer SPT (N1)60-cs blows/ft or blows/0.3 m 3.9.1(3) Residual strength at top of layer Sr in psf or kPa 3.9.1(4) 50 at top of layer 50 3.9.2(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer 3.9.2(2) SPT blowcount at bottom of layer SPT (N1)60-cs blows/ft or blows/0.3 m 3.9.2(3) Residual strength at bottom of layer Sr in psf or kPa 3.9.2(4) 50 at bottom of layer 50 Table 8-31 Properties for Weak Rock 3.10 Properties for weak rock (5 values per line) 3.10.1(1) Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 3.10.1(2) Uniaxial compressive strength qu at Uniaxial compressive strength in psi or kPa top of layer 3.10.1(3) Initial rock mass modulus at top of Emass in psi or kPa layer 3.10.1(4) RQD at top of layer RQD in percent k in lbs/in3 or kN/m3, 3.10.1(5) Parameter krm at top of layer enter 0 for internal default value 3.10.2(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer 3.10.2(2) Uniaxial compressive strength qu at Uniaxial compressive strength in psi or kPa bottom of layer 3.10.2(3) Initial rock mass modulus at bottom Emass in psi or kPa of layer 3.10.2(4) RQD at bottom of layer RQD in percent k in lbs/in3 or kN/m3, 3.10.2(5) Parameter krm at bottom of layer enter 0 for internal default value

183

Table 8-32 Properties for Vuggy Limestone 3.11 Properties for vuggy limestone (2 values per line) 3.11.1(1) Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 3.11.1(2) Uniaxial compressive strength qu at Uniaxial compressive strength in psi or kPa top of layer 3.11.2(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer 3.11.2(2) Uniaxial compressive strength qu at Uniaxial compressive strength in psi or kPa bottom of layer Table 8-33 Properties for Piedmont Residual Soil 3.12 Properties for Piedmont residual soil (6 values per line) 3.12.1(1) Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 Enter 1 for SPT, 2 for cone penetrometer, 3.12.1(2) Test type index 3 for dilatometer, or 4 for pressuremeter modulus 3.12.1(3) SPT blowcount at top of layer Blows/foot or blows/ 0.3 m 3.12.1(4) Cone tip resistance at top of layer qtip in psi or kPa 3.12.1(5) Dilatometer modulus at top of layer psi or kPa 3.12.1(6) Pressuremeter modulus at top of psi or kPa layer 3.12.2(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer Enter 1 for SPT, 3.12.2(2) Test type index 2 for cone penetrometer, (a value must be entered but is ignored for 3 for dilatometer, or bottom of layer) 4 for pressuremeter modulus 3.12.2(3) SPT blowcount at bottom of layer Blows/foot or blows/ 0.3 m 3.12.2(4) Cone tip resistance at bottom of qtip in psi or kPa layer 3.12.2(5) Dilatometer modulus at bottom of psi or kPa layer 3.12.2(6) Pressuremeter modulus at bottom of psi or kPa layer Table 8-34 Properties for Massive Rock 3.13 Properties for massive rock 3.13.1(1) Effective unit weight at top of layer 3.13.1(2) Uniaxial compressive strength of intact rock at top of layer 3.13.1(3) Material index for layer 3.13.1(4) Poisson’s ratio for layer 3.13.1(5) GSI for layer

Effective unit weight in pcf or kN/m3 Uniaxial compressive strength of intact rock in psi or kPa Hoek-Brown material index mi Poisson’s ratio  Geologic Strength Index

184

Option 1 is to input a non-zero value for modulus of intact rock and a value of zero for modulus of rock mass to have LPile compute the modulus for rock mass internally. Option 2 is to input a non-zero value for the modulus of rock mass. 3.13.1(6) Modulus of intact rock for layer Modulus of intact rock in psi or kPa 3.13.1(7) Modulus of rock mass for layer Modulus of rock mass in psi or kPa 3.13.2(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer 3.13.2(2) Uniaxial compressive strength of Uniaxial compressive strength of intact rock intact rock at bottom of layer in psi or kPa 3.13.2(3) Material index for layer Hoek-Brown material index mi 3.13.2(4) Poisson’s ratio for layer Poisson’s ratio  3.13.2(5) GSI for layer Geologic Strength Index 3.13.2(6) Modulus of intact rock for layer Modulus of intact rock in psi or kPa 3.13.2(7) Modulus of rock mass for layer Modulus of rock mass in psi or kPa Table 8-35 Properties for Loess 3.14 Properties for loess, (2 values per line) 3.14.1(1) Effective unit weight at top of layer 3.14.1(2) Cone tip resistance at top of layer 3.14.2(1) Effective unit weight at bottom of layer 3.14.2(2) Cone tip resistance at bottom of layer

Effective unit weight in pcf or kN/m3 qtip in psi or kPa Effective unit weight in pcf or kN/m3 qtip in psi or kPa

Table 8-36 Properties for Cemented Silt 3.15 Properties for cemented silt c- soil (5 values per line) 3.15.1(1) Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 3.15.1(2) Undrained shear strength at top of Shear strength in psf or kPa layer 3.15.1(3) Friction angle at top of layer Friction angle in degrees Strain factor 50 (dimensionless), 3.15.1(4) Strain factor E50 at top of layer enter 0 for internal default value k in lbs/in3 or kN/m3, 3.15.1(5) p-y modulus k at top of layer enter 0 for internal default value 3.15.2(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer 3.15.2(2) Undrained shear strength at bottom Shear strength in psf or kPa of layer 3.15.2(3) Friction angle at bottom of layer Friction angle in degrees Strain factor 50 (dimensionless), 3.15.2(4) Strain factor E50 at bottom of layer enter 0 for internal default value k in lbs/in3 or kN/m3, enter 0 for internal 3.15.2(5) p-y modulus k at bottom of layer default value

185

Table 8-37 Properties for Elastic Subgrade 3.16 Properties for elastic subgrade (2 values per line) 3.16.1(1) Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 3.16.1(2) Elastic subgrade modulus at top of pci or kN/m3 layer 3.16.2(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer 3.16.2(2) Elastic subgrade modulus at bottom pci or kN/m3 of layer Table 8-38 Properties for -Input p-y Curves 3.17 Properties for -Input p-y Curves (2 values per line) 3.17.1(1) Effective unit weight at top of layer Effective unit weight in pcf or kN/m3 3.17.1(2) Number of input p-y points for Number of points curve at top of layer Repeat Line 3.17.2 for each point on curve 3.17.2(1) y value for curve at top of layer inches or meters 3.17.2(2) p value for curve at top of layer lbs/inch or kN/m 3.17.3(1) Effective unit weight at bottom of Effective unit weight in pcf or kN/m3 layer 3.17.3(2) Number of input p-y points for Number of points curve at bottom of layer Repeat Line 3.17.4 for each point on curve 3.17.4(1) y value for curve at bottom of layer inches or meters 3.17.4(2) p value for curve at bottom of layer lbs/inch or kN/m

8-6 PILE BATTER AND SLOPE Command Table 8-39 Pile Batter and Ground Slope Properties Pile Batter and Slope Properties 1 Ground slope 2 Pile batter

Lines degrees degrees

8-7 TIP SHEAR Command Table 8-40 Tip Shear Curve Properties Tip Shear Properties 1 Number of points Repeat Line 2 for all tip shear points 2(1) Point number 2(2) y value 2(3) tip shear value

Lines integer Maximum coarse aggregate size, in. or mm Inches or meters lbs or kN

186

8-8 GROUP EFFECT FACTORS Command Table 8-41 Group Effect Properties Group Effect Properties 1 Number of points Repeat Line 2 for all points 2(1) Point number 2(2) Depth below pile head 2(3) p-multiplier 2(4) y-multiplier

Lines integer integer ft or meters Dimensionless Dimensionless

8-9 LRFD LOADS Command Table 8-42 LRFD Load Properties LRFD Load Properties 1 Number of LRFD unfactored loads Repeat line 2 and .3 for every load 2(1)

Lines integer

Load number (starting with 1) Enter: 1 for dead load 2 for live load 3 for earthquake load 4 for impact load 5 for wind load 6 for water load 2(2) Load type index 7 for ice load 8 for horizontal soil pressure 9 for live roof load 10 for rain load 11 for snow load 12 for temperature load 13 for special load 2(3) Horizontal shear force lbs or kN 2(4) Moment in-lbs or kN-m 2(5) Vertical load force lbs or kN 2(6) Number of distributed lateral load points integer Repeat line 12.3 for each distributed lateral load point for this unfactored load 3.(1) Point number integer 3(2) Depth below pile head in or meters 3(3) Lateral load intensity lbs/in or kN/m

187

8-10 LRFD FACTORS AND CASES Command Table 8-43 LRFD Load Factors and Loading Case Properties Concrete Properties 1 Number of load combinations Repeat line 2 for every load combination 2(1) dead load factor 2(2) live load factor 2(3) earthquake load factor 2(4) impact load factor 2(5) wind load factor 2(6) water load factor 2(7) ice load factor 2(8) horizontal soil pressure load factor 2(9) live roof load factor 2(10) rain load factor 2(11) snow load factor 2(12) temperature load factor 2(13) special load factor 2(14) resistance factor for moment 2(15) resistance factor for shear 2(16) Name of load combination

Lines Minimum = 1, maximum = 100 Dimensionless Dimensionless Dimensionless Dimensionless Dimensionless Dimensionless Dimensionless Dimensionless Dimensionless Dimensionless Dimensionless Dimensionless Dimensionless Dimensionless Dimensionless Text

8-11 LOADING Command Table 8-44 Conventional Loading Properties Conventional Loading Properties 1 Number of load cases Repeat Line 2 for all load cases 2(1) Load number

2(2) Pile-head condition

2(3) Pile-head condition 1

2(4) Pile-head condition 2

Lines Integer Integer Enter: 1 for shear and moment, 2 for shear and slope, 3 for shear and rotational stiffness, 4 for displacement and moment, 5 for displacement and slope Enter shear force for conditions 1, 2, or 3 in lbs or kN Enter displacement for conditions 4 or 5 in inches or meters Enter moment for condition 1 or 4 in in-lbs or kN-m Enter slope for condition 2 in radians Enter rotational stiffness for condition 3 in in188

Conventional Loading Properties

Lines lbs/rad. or kN-m/rad. Enter slope for condition 4 in radians Lbs or kN

2(5) Axial thrust load 2(6) Toggle for computation of top deflection Enter 0 for no, 1 for yes versus pile length for this load condition If UseDistributedLoading NO has been input under OPTIONS, omit lines 3 and 4. If UseDistributedLoading ONE has been input under OPTIONS, enter lines 3 and 4once. If UseDistributedLoading ALL has been input under OPTIONS, enter lines 3 and 4 for every load case Enter 0 for no distributed lateral loading, 3 Number of distributed lateral loading points Enter number of loading points to enter distributed lateral loading data Repeat Line 4 for all distributed lateral loading points 4(1) Load point number dimensionless 4(2) Depth below pile head Feet or meters 4(3) Distributed lateral loading intensity lbs/inch or kN/m

8-12 P-Y OUTPUT DEPTHS Command Table 8-45 p-y Output Depth Properties p-y Output Depth Properties 1 Number of output depths Repeat Line 2 for all depths 2 Depth of output p-y curve

Lines integer ft or meters

8-13 SOIL MOVEMENTS Command Table 8-46 Soil Movement Properties Soil Movement Properties 1 Number of soil movement points Repeat Line 2 for all depths 3 Depth below pile head 4 Lateral soil movement

Lines integer ft or meters inches or millimeters

8-14 AXIAL THRUST LOADS Command Table 8-47 Axial Thrust Loads for EI Computations Only Axial Thrust Properties 1 Number of axial thrust values Repeat Line 2 for all axial thrust values 2 Thrust load number, axial thrust

Lines Compressive strength of concrete, psi or kPa Two values per line (thrust number, thrust value) 189

8-15 FOUNDATION STIFFNESS Command Table 8-48 Foundation Stiffness Computations Controls for Computation of Foundation Stiffness Computations

Lines

Integer 1 = Use force and moment from Load Case 1 2 = Use pile-head deflection and rotation from 1 Computation method Load Case 1 3 = Use specified values of pile-head deflection and rotation 2 Number of points to compute Integer Integer, 3 Point distribution method 0 = logarithmic distribution, 1 = arithmetic distribution If computation method = 2, enter values for pile-head deflection and rotation 4 Pile-head deflection Inches or meters 5 Pile-head rotation Radians

8-16 PILE PUSHOVER ANALYSIS DATA Command Table 8-49 Pushover Analysis Computations Controls for Pile Pushover Analysis Computations

Lines

Integer 0 = pinned head 1 Computation method 1 = fixed head 2 = pinned and fixed head Integer, 0 = logarithmic distribution, 2 Point distribution method 1 = arithmetic distribution 2 = -specified displacements If point distribution method = 0 or 1, enter Lines 3, 4, and 5 3 Number of points to compute Integer 4 Maximum pile-head deflection Inches or meters 5 Minimum pile-head deflection Inches or meters If point distribution method = 2, enter Lines 6 and 7 6 Number of -specified displacements Integer Repeat Line 7 for every -specified pushover displacement 7 -specified pushover displacement Inches or meters 8 Axial thrust force Lbs or kN

190

8-17 PILE BUCKLING ANALYSIS DATA Command Table 8-50 Pile Buckling Analysis Data Pile Buckling Analysis Data 1 Pile-head fixity condition 2 Number of loading steps 3 Pile-head shear 4 Pile-head moment 5 Pile-head rotational stiffness 6 Maximum axial compression load

Lines 0 = shear and moment 1 = shear and slope 2 = shear and rotational stiffness Integer, maximum 50 Lbs or kN In-lbs or kN-m In-lbs/radians or kN-m/radians Lbs or kN

8-18 LRFD Data File The LRFD data file is used to store load and resistance factors in a format that also defines load case combinations and load case names. The purpose of this data file is to eliminate the need to input data that may be common to many analyses. The LRFD data file is a plain text (ASCII) file. The LRFD data file is read from the Program Options and Settings dialog (see Section 3-4 on page 23 for more information about the Program Options and Settings dialog). Any edited set of LRFD load and resistance factors and load combinations may be saved as an LRFD file from the File Menu. It is suggested that the use the editing features of LPile to create any LRFD data file. The file extension for the LRFD data file is lrfd.

191

(This page was deliberately left blank)

192

References American Petroleum Institute, 1987. Recommended Practice for Planning, Deg, and Constructing Fixed, Offshore Platforms, API Recommended Practice 2A (RP 2A), 17th Edition, April 1, 1987. Brown, D. A., 2002. Personal Communication about “Specifying Initial k for Stiff Clay with No Free Water.” Georgiadis, M., 1983. “Development of p-y Curves for Layered Soils,” Proceedings, Geotechnical Practice in Offshore Engineering, ASCE, April, pp. 536-545. Horne, M., 1978. Plastic Theory of Structures, Permagon Press, New York. Liang, R.; Yang, K.; and Nusairat, J., 2009. “ p-y Criterion for Rock Mass,” Journal of Geotechnical and Geoenvironmental Engineering, Vol. 135, No. 1, pp. 26-36. Matlock, H., and Reese, L. C., 1962. “Generalized Solution for Laterally Loaded Piles,” Transactions, ASCE, Vol. 127, Part I, pp. 1220-1251. O’Neill, M. W., and Reese, L. C., 1999. “Drilled Shafts: Construction Procedures and Design Methods,” Report No. FHWA-IF-99-025, US Department of Transportation, Federal Highway istration.. Reese, L. C., 1984. “Handbook on Design of Piles and Drilled Shafts Under Lateral Load,: Report No. FHWA-IP-84-11, US Department of Transportation, Federal Highway istration. Reese, L. C., and Van Impe, W., 2011. Single Piles and Pile Groups Under Lateral Loading, 2nd Edition, CRC Press (Balkema), 507 p. Rollins, K. M.; Gerber, T. M.; Lane, J. D.; and Ashford, S. A., 2005a. “Lateral Resistance of a Full-Scale Pile Group in Liquefied Sand”, Journal of the Geotechnical and Geoenvironmental Engineering Division, ASCE, Vol. 131, pp. 115-125. Rollins, K. M.; Hales, L. J.; and Ashford, S. A., 2005b. “p-y Curves for Large Diameter Shafts in Liquefied Sands from Blast Liquefaction Tests,” Seismic Performance and Simulation of Pile Foundations in Liquefied and Laterally Spreading Ground, Geotechnical Special Publication No. 145, ASCE, p. 11-23. Timoshenko, S. P., 1941. Strength of Materials, Part II, Advanced Theory and Problems, 10th Printing, Van Nostrand, New York.

193

(This page was deliberately left blank)

194

Appendix 1 Input Error Messages Un-numbered: Version mismatch between main program and dynamic link library for computation files. Input Data Error No. 1: An error was detected in the input data for computing a p-y curve using the API sand criteria. A value of zero was input for the friction angle of the sand. Input Data Error No. 2: An error was detected in the input data when computing a p-y curve using the API criteria for sand. The angle of the ground slope cannot be greater than the internal friction angle of the sand at the ground surface. Input Data Error No. 3: The pile tip is below the deepest extent of the input data for soil shear strength versus depth. Input Data Error No. 4: The pile extends below the deepest extent of the input data for soil shear strength versus depth. Input Data Error No. 5: The pile tip is below the deepest extent of the input curve for soil shear strength versus depth. Input Data Error No. 6: Use of p-y multipliers cannot be specified for use with -specified p-y curves. Input Data Error No. 7: The number of points defining effective unit weight versus depth is zero and number of input p-y curves is also zero. Input Data Error No. 8: A value of zero was input for the friction angle for a sand when computing a p-y curve using the Reese et al. criteria. Input Data Error No. 9: The angle of the slope cannot be greater than the friction angle of the sand at the ground surface. Input Data Error No. 10: A negative or zero value was input for the friction angle for silt. Input Data Error No. 11: The angle of the ground surface slope cannot be greater than the angle of internal friction angle of the silt (c-phi) soil at the ground surface. Input Data Error No. 12: An error was detected that is related to an incompatibility between the input data defining soil layering and soil shear strength values when computing a p-y curve using the Matlock soft clay criteria. Input Data Error No. 13: A cohesion of zero was input for a stiff clay without free water. Input Data Error No. 14: An error was detected in the input data used to compute p-y curves in stiff clay with free water. A value of zero was input for the cohesion of a stiff clay. Input Data Error No. 15: The pile extends below the deepest extent of the input curve for effective unit weight versus depth. Input Data Error No. 16: The input value for the compressive strength of a weak rock was input as negative or zero.

195

Appendix 1 – Input Error Messages Input Data Error No. 17: The value number of points to define the pile properties is 2 to 40. Either too few or too many points were input for the definition of pile properties. Input Data Error No. 18: The depth at the bottom of the last layer is higher than the tip of the pile. Input Data Error No. 19: The depth of the first point of the data for effective unit is not located at the ground surface. Input Data Error No. 20: The depth of the first point of the soil strength profile is not located at the ground surface. Input Data Error No. 21: The depth for the first data point for p-multipliers is not located at the ground surface. Input Data Error No. 22: Loading was specified to be cyclic, but the number of cycles of loading was specified outside the range of 2 to 5000. Input Data Error No. 23: Deleted. Input Data Error No. 24: Deleted. Input Data Error No. 25: The input file is empty. No analysis can be performed. Input Data Error No. 26: The number of rebar cannot exceed 300 in this version of LPile. Input Data Error No. 27: Zero values were entered for one of pile diameter, pile area, or moment of inertia. Input Data Error No. 28: Cyclic loading type was specified and the number of cycles of loading are outside the valid range of 2 to 5,000. Input Data Error No. 29: A depth above the ground surface was specified for the printing of a p-y curve. Input Data Error No. 30: A depth below the pile tip was specified for the printing of a p-y curve. Input Data Error No. 31: The pile extends below the deepest extent of the input data for RQD versus depth. Input Data Error No. 32: Type of reinforcement is unrecognized by LPile. Input Data Error No. 33: Tapered rebar option type is unrecognized. Input Data Error No. 34: Specified rebar cover is greater than one-half of pile diameter. Input Data Error No. 35: Too many pile sections specified for analysis. Input Data Error No. 36: Deleted. Input Data Error No. 37: Deleted. Input Data Error No. 38: Deleted. Input Data Error No. 39: Deleted. Input Data Error No. 40: Deleted. Input Data Error No. 41: Deleted. Input Data Error No. 42: Deleted. 196

Appendix 1 – Input Error Messages Input Data Error No. 43: Pile section type unrecognized. Input Data Error No. 44: Units of computation option unrecognized by program. Input Data Error No. 45: Input data for pile properties specifies a negative pile station coordinate. Input Data Error No. 46: Input data for pile properties specified a pile station below the pile tip. Input Data Error No. 47: The depth of the top of a layering is greater than or equal to the depth of the bottom of the layer. Input Data Error No. 48: A negative or zero value was input for the cohesion for silt. Input Data Error No. 49: The interpolated value of RQD used for p-y curves in weak rock was found to be invalid because it was either less than zero or more than 100 percent. Input Data Error No. 50: The pile-tip movement data for shear resistance at the pile tip is in error. Either the first point is not zero or one of the other points is less than or equal to the previous point. Input Data Error No. 51: The nonlinear bending stiffness input by the varies by more than a factor of 100 for a given axial thrust force. This indicates that either unrealistic or erroneous data was input. Input Data Error No. 52: The nonlinear bending stiffness input by the exhibits strain hardening behavior. LPile can handle nonlinear bending cases only with strain softening behavior. Input Data Error No. 53: The number of lines of soil movement data is outside the range of 2 to 50. Input Data Error No. 54: The top and bottom elevations for weak rock layer are equal. Input Data Error No. 55: The specified number of pile increments is less than 40. Input Data Error No. 56: The specified number of pile increments is more than 500. Input Data Error No. 57: The input value for pile length is zero. Input Data Error No. 58: The pile tip is below the deepest extent of the input curve for weak rock parameter krm versus depth. Input Data Error No. 59: The number of input pile diameters is more than 40. Input Data Error No. 60: An error was detected in the shear strength of soil input data when interpolating to obtain values of cohesion or uniaxial compressive strength. The depth increment between the upper and lower soil depths in a layer is zero. Input Data Error No. 61: The depth of the bottom of the top soil layer is less than or equal to zero. This will cause the algorithm for layering correction to p-y curves to generate incorrect p-y curves for layers below the top layer. Input Data Error No. 62: An error was detected for input values for uniaxial compressive strength. Values cannot be less than zero. Input Data Error No. 63: The input value of krm is less than or equal to zero for weak rock.

197

Appendix 1 – Input Error Messages Input Data Error No. 64: The input value for the number of iterations is less than 40 or more than 1000. Input Data Error No. 65: The input value for the convergence tolerance cannot be smaller than 1×10−10 inches. Input Data Error No. 66: The input value for the convergence tolerance cannot be larger than 0.001 inches. Input Data Error No. 67: The input value for the convergence tolerance cannot be smaller than 2.54×10−12 meters. Input Data Error No. 68: The input value for the convergence tolerance cannot be larger than 2.54×10−5 meters. Input Data Error No. 69: The input value for the excessive deflection limit is smaller than 10 percent of the pile diameter. Input Data Error No. 70: The input value for the number of cycles of loading is greater than 10 and one of the soil layers is loess. The soil model for loess is valid only for 1 to 10 cycles of loading. Input Data Error No. 71: An error was detected in the soil shear strength values to be used for computing a p-y curve using the Matlock soft clay with -defined J criteria. A negative or zero value of cohesion was input for a soft clay soil. Input Data Errors 72-94 are reserved for future use. Input Data Error No. 95: An input line was unrecognized. See the output report for further details. Input Data Error No. 99: An input line was unrecognized. See the output report for further details.

198

Appendix 2 Runtime Error Messages Runtime Error No. 1: Internal error occurred in the LPile computation dynamic link library. This error is reported when the dynamic link library fails to load into memory. Runtime Error No. 2: Contents of file NAMES.DAT is corrupted. This file contains the path and name of all data and output files used by LPile. Runtime Error No. 3: The name of the input data file is corrupted. Runtime Error No. 4: The name of the output report file is corrupted. Runtime Error No. 5: The name of the plot output file is corrupted. Runtime Error No. 6: The name of the runtime message file is corrupted. Runtime Error No. 7: The name is corrupted. Runtime Error No. 8: company name is corrupted. Runtime Error No. 9: The computed deflection of the pile head is larger than the allowable deflection. This error may be due to overloading the pile or bad input data. Runtime Error No. 10: LPile was unable to obtain an answer within the specified convergence tolerance within the specified limit on iterations. Runtime Error No. 11: The numerical solution failed due to a small pivot number. Runtime Error No. 12: An error occurred because the computed value of compressive strain in concrete is larger than 0.001. This indicates that that the drilled shaft has failed due to crushing of concrete. Runtime Error No. 13: Deleted. Runtime Error No. 14: An internal error occurred in computing area of concrete for prestressing computations. Runtime Error No. 15: An error occurred in computing area of steel for prestressing computations. Runtime Error No. 16: The location of neutral axis was not found within 1,000 iterations during computation of non-linear moment-curvature behavior. Runtime Error No. 17: Filename information corrupted. No analysis can be performed. Runtime Error Nos. 18-21: Deleted. Runtime Error No. 22: A runtime error was caused by the input value krm being less than or equal to 0. Runtime Error No. 23: A runtime error was caused by the input value for combined ground slope and pile batter being greater than the angle of friction of a silt layer. Runtime Error No. 24: The input value for axial thrust force is greater than the structural capacity in compression. 199

Appendix 2 – Runtime Error Messages Runtime Error No. 25: The input value for axial thrust force is greater than the structural capacity in tension. Runtime Error No. 26: An LRFD load case value for axial thrust force is greater than the structural capacity in compression. Runtime Error No. 27: An LRFD load case value for axial thrust force is greater than the structural capacity in tension. Runtime Error No. 28: An unrecoverable numerical error has occurred. Either pile-top deflection or computed maximum change in deflection is not a number and further computations are impossible. Runtime Error No. 29: A layer thickness was too thin to contain a nodal point. This prevents the correct computation of the layer’s p-y curve. Runtime Error No. 30: An error occurred in the computation of the undrained shear strength value for a soil layer. Runtime Error No. 31: The computed value of soil modulus computed in Reese sand is not-anumber. This is due to one or more of the required soil properties being equal to zero. See the output report for more information. Runtime Error No. 32: The default value of soil modulus computed in Reese sand is not-anumber. This is due to one or more of the required soil properties being equal to zero. See the output report for more information. Runtime Error No. 33: The default value of soil modulus computed in soft clay is not-a-number. This is due to one or more of the required soil properties being equal to zero. See the output report for more information. Runtime Error No. 34: The computed value of soil modulus computed in soft clay is not-anumber. This is due to one or more of the required soil properties being equal to zero. See the output report for more information. Runtime Error No. 35: The default value of soil modulus computed in API soft clay is not-anumber. This is due to one or more of the required soil properties being equal to zero. See the output report for more information. Runtime Error No. 36: The computed value of soil modulus computed in API soft clay is not-anumber. This is due to one or more of the required soil properties being equal to zero. See the output report for more information.

200

Appendix 3 Warning Messages1 Warning Message No. 300: Multiple warning messages have been generated. See the output report file for more details. Warning Message No. 301: An unreasonable input value for k has been specified See the output report file for more details. Warning Message No. 302: An unreasonable input value for friction angle has been specified for a soil layer defined using the sand criteria. See the output report file for more details. Warning Message No. 303: An unreasonable input value for friction angle has been specified for a soil layer defined using the API sand criteria. See the output report file for more details. Warning Message No. 304: An unreasonable input value for shear strength has been specified for a soil layer defined using the soft clay criteria. See the output report file for more details. Warning Message No. 3041: An unreasonable input value for shear strength has been specified for a layer defined using the soft clay criteria. The input value is greater than 1,250 psf (8.68 psi). Warning Message No. 3042: An unreasonable input value for shear strength has been specified for a layer defined using the soft clay criteria. The input value is greater than 59.85 kPa. See the output report file for more details. Warning Message No. 305: Too many values were calculated for moment-curvature. This may indicate that the pile is too weak or is under-reinforced. You should examine your input data and increase the amount of steel reinforcement if necessary. Warning Message No. 3051: An unreasonable input value for shear strength has been specified for a layer defined using the stiff clay with free water criteria. The input value is less than 500 psf (3.47 psi). Warning Message No. 3052: An unreasonable input value for shear strength has been specified for a layer defined using the stiff clay with free water criteria. The input value is greater than 8,000 psf (55.55 psi). Warning Message No. 3053: An unreasonable input value for shear strength has been specified for a layer defined using the stiff clay with free water criteria. The input value is less than 23.94 kPa. Warning Message No. 3054: An unreasonable input value for shear strength has been specified for a layer defined using the stiff clay with free water criteria. The input value is greater than 383.04 kPa. See the output report file for more details. Warning Message No. 306: Negative values of bending moment were computed in nonlinear EI computations. This may indicate that the pile is too weak or is under-reinforced and that all reinforcing steel has yielded.

1

Note, the warning message number is not displayed by LPile

201

Appendix 3 – Warning Messages Warning Message No. 3061: An unreasonable input value for shear strength has been specified for a layer defined using the stiff clay without free water criteria. The input value is less than 500 psf (3.47 psi). Warning Message No. 3062: An unreasonable input value for shear strength has been specified for a layer defined using the stiff clay without free water criteria. The input value is greater than 8,000 psf (55.55 psi). Warning Message No. 3063: An unreasonable input value for shear strength has been specified for a layer defined using the stiff clay without free water criteria. The input value is less than 23.94 kPa. Warning Message No. 3064: An unreasonable input value for shear strength has been specified for a layer defined using the stiff clay without free water criteria. The input value is greater than 383.04 kPa. Warning Message No. 307: The input data for nonlinear bending appears to be have been input incorrectly. Negative values of bending moment should not be input. Warning Message No. 3071: An unreasonable input value for the uniaxial compressive strength has been specified for a layer defined using the weak rock criteria. The input value is less than 100 psi. Warning Message No. 3072: An unreasonable input value for unconfined compressive strength has been specified for a soil defined using the weak rock criteria. The input value is greater than 1,000 psi. Warning Message No. 3073: An unreasonable input value for unconfined compressive strength has been specified for a soil defined using the weak rock criteria. The input value is less than 689.5 kPa. Warning Message No. 3074: An unreasonable input value for unconfined compressive strength has been specified for a soil defined using the weak rock criteria. The input value is greater than 6895 kPa. Warning Message No. 308: An unreasonable input value for uniaxial compressive strength has been specified for a layer defined using the vuggy limestone (strong rock) criteria. Warning Message No. 309: An unreasonable input value for compressive strength of concrete has been specified. Warning Message No. 3091: An unreasonable input value for compressive strength of concrete has been specified. The input value is either smaller than 2,000 psi or larger than 8,000 psi. Warning Message No. 3092: An unreasonable input value for compressive strength of concrete has been specified. The input value is either smaller than 13,790 kPa or larger than 55,160 kPa. Warning Message No. 310: An unreasonable input value for modulus of elasticity for steel has been specified. Warning Message No. 311: An unreasonable input value for yield strength of reinforcement has been specified.

202

Appendix 3 – Warning Messages Warning Message No. 3101: An unreasonable input value for modulus of elasticity has been specified for the reinforcing steel. The input value is either smaller than 27,500,000 psi or larger than 30,500,000 psi. Warning Message No. 3102: An unreasonable input value for modulus of elasticity has been specified for the reinforcing steel. The input value is either smaller than 189,600,000 kPa or larger than 210,300,000 kPa. Warning Message No. 3111: An unreasonable input value for yield strength of reinforcing steel has been specified. The input value is either smaller than 38,000 psi or larger than 80,000 psi. Warning Message No. 3112: An unreasonable input value for yield strength of reinforcing steel has been specified. The input value is either smaller than 262,000 kPa or larger than 551,600 kPa. Warning Message No. 312: An input value for cover of reinforcement has been specified that may be unreasonable. Warning Message No. 3121: An unreasonable input value for concrete cover thickness has been specified. The input value is either smaller than 0.8 inches or larger than 6 inches. Warning Message No. 3122: An unreasonable input value for concrete cover thickness has been specified. The input value is either smaller than 0.02 meters or larger than 0.16 meters. You should check your input for accuracy. Warning Message No. 313: An unreasonable input value for loss of prestress has been specified. Warning Message No. 314: An unreasonable input value for prestressing force has been specified. Warning Message No. 315: Pile deflection has exceeded the failure deflection for the vuggy limestone criteria for one or more of the loading cases analyzed. You should check the computed output for both deflection and bending moment. Warning Message No. 316: The input value for krm used by the weak rock criteria is smaller than 0.00005. This value is outside the recommended range of 0.00005 to 0.0005. Warning Message No. 317: The input value for krm used by the weak rock criteria is larger than 0.0005. This value is outside the recommended range of 0.00005 to 0.0005. You should check your input data for accuracy. Warning Message No. 318: The pile deflection is less than 1×10−14. LPile used the limiting value of soil modulus when computing the p-y curve for soft clay. Warning Message No. 3261: An unreasonable input value for shear strength has been specified for a layer defined using the stiff clay without free water criteria with -defined k. The input value is less than 500 psf (3.47 psi). Warning Message No. 3262: An unreasonable input value for shear strength has been specified for a layer defined using the stiff clay without free water criteria with -defined k. The input value is greater than 8,000 psf (55.55 psi). Warning Message No. 3263: An unreasonable input value for shear strength has been specified for a layer defined using the stiff clay without free water criteria with -defined k. The input value is less than 23.94 kPa. 203

Appendix 3 – Warning Messages Warning Message No. 3264: An unreasonable input value for shear strength has been specified for a layer defined using the stiff clay without free water criteria with -defined k. The input value is greater than 383.04 kPa. Warning Message No. 351: Values entered for effective unit weights of soil were outside the limits of 0.011574 pci (20 pcf) or 0.0810019 pci (140 pcf). This data may be erroneous. Warning Message No. 352: Values entered for effective unit weights of soil were outside the limits of 3.15 kN/m3 or 22 kN/m3. This data may be erroneous. Warning Message No. 353: Values of effective unit weight cannot be checked because general units have been selected. Warning Message No. 354: The maximum depth of a soil layer defined as liquefiable sand is greater than meters or 236.22 inches. This is greater than the maximum depth recommended for this p-y curve criteria. Warning Message No. 355: Computation of nonlinear bending stiffness found that moment capacity was developed at compressive strains smaller than 0.003. This usually indicates that a section is under-reinforced or the level of prestressing is too small. Warning Message No. 400: One or more of the LRFD load cases have overloaded the structural capacity of the pile. See the LRFD Performance by Load Case Combination section of the output report file for more details.

204
