’s Guide 219/224 Type A
This houshold sewing machine is designed to comply with IEC/EN 60335-2-28 and UL1594
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic safety precautions should always be followed, including the following: Read all instructions before using this household sewing machine.
DANGER - To reduce the risk of electric shock: • •
A sewing machine should never be left unattended when plugged in. Always unplug this sewing machine from the electric outlet immediately after using and before cleaning. Always unplug before relamping. Replace bulb with same type rated 15 Watt.
WARNING - To reduce the risk of burns, fire, electric shock, or injury to persons: •
• • •
• • • • • • • • • • • •
This sewing machine is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the sewing machine by a person responsible for their safety. Children should be supervised to ensure that they do not play with the sewing machine. Use this sewing machine only for its intended use as described in this manual. Use only attachments recommended by the manufacturer as contained in this manual. Never operate this sewing machine if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Return the sewing machine to the nearest authorized dealer or service center for examination, repair, electrical or mechanical adjustment. Never operate the sewing machine with any air openings blocked. Keep ventilation openings of the sewing machine and foot controller free from the accumulation of lint, dust, and loose cloth. Keep fingers away from all moving parts. Special care is required around the sewing machine needle. Always use the proper needle plate. The wrong plate can cause the needle to break. Do not use bent needles. Do not pull or push fabric while stitching. It may deflect the needle causing it to break. Switch the sewing machine off (“0”) when making any adjustment in the needle area, such as threading needle, changing needle, threading bobbin, or changing presser foot, etc. Always unplug sewing machine from the electrical outlet when removing covers, lubricating, or when making any other servicing adjustments mentioned in the instruction manual. Never drop or insert any object into any opening. Do not use outdoors. Do not operate where aerosol (spray) products are being used or where oxygen is being istrated. To disconnect, turn all controls to the off (“0”) position, then remove plug from outlet. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
SAVE THESE INSTRUCTIONS For the USA and Canada
This sewing machine has a polarized plug (one blade wider than the other). To reduce the risk of electric shock, this plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, a qualified electrician to install the proper outlet. Do not modify the plug in any way.
TABLE OF CONTENTS Name of Parts Extension Table To Store Foot Control Standard Accessories
Finishing Sewing 22 Straight Stitching on Heavy Fabrics 23 Seam Allowance Lines 23
2-3 4 4 5
UTILITY STITCHING
GETTING READY TO SEW Connecting the Machine to the Power Supply Controlling Sewing Speed Up/Down Needle Position Button Reverse Stitch Button Pressure Adjusting Dial Dropping the Feed Teeth Sewing Light Presser Foot Lifter To Remove and Attach the Presser Foot To Remove and Attach Presser Foot Ankle Changing the Needle Needle and Thread chart Winding the Bobbin Setting the Spool Removing the Bobbin Winding the Bobbin Inserting the Bobbin Threading the Machine To Use Needle Threader Drawing Up Bobbin Thread Pattern Selector Dial Stitch Length Dial Zigzag Width Control Infinite Needle Position Balancing Needle Thread Tension Straight Stitching Starting to Sew Changing Sewing Direction
Zigzag Stitching Overcasting Seam/Overcast stitch Multiple ZigZag Reinforced Straight Stitch Lightening Stitch Sewing Buttons Automatic Buttonhole Corded Buttonhole Manual Buttonhole Zipper Sewing Blind Stitch Hemming Decorative Satin Stitch Patterns Stretch Stitch Patterns Adjusting Stretch Stitch Balance Smocking Quilting Pin Tucking Shell Tuck Fagoting Patch Work Applique
6 7 8 8 8 9 9 10 10 10 11 11 12 12 13 14 15 16 17 18 18 19 19 20 21 21 21
24 24 25 25 26 26 27 28-31 32 33-34 35-38 39 40 40 41 42 43 44 44 45 45 46
CARE OF YOUR MACHINE Cleaning the Hook Assembly Area and Feed Teeth 47 Replacing the Bobbin Holder 48 Troubleshooting 49-50
1
Name of parts (Model 224) 06
04
05
03 02
01 22
07
21 08
20 19
09 10 11
18
12 13
14
15
16
17
25 26 24 23 27 28
29
36 35
34 30
33
31 32
2
01. 02. 03. 04. 05. 06. 07. 08. 09. 10. 11. 12. 13. 14. 15. 16. 17. 18. 19. 20. 21. 22. 23. 24. 25. 26. 27. 28. 29. 30. 31. 32. 33. 34. 35. 36.
Bobbin winder stopper Bobbin winder spindle Extra spool pin mounting hole Spool holder Spool pin Thread tension dial Thread take-up lever Pressure adjusting dial Face plate Thread cutter Needle threader Needle plate Extension table Hook cover plate Hook cover plate release button Up/down needle position button Reverse stitch button Speed setting lever Pattern selector dial Stitch length dial Pattern indicating window Zigzag width control lever Presser foot Needle Needle clamp screw Foot holder Thumb screw Carrying handle Handwheel Feed balance dial Power switch Machine sockets Drop feed lever Free arm Buttonhole lever Presser foot lifter
Name of parts (Model 219) 06
05
04
03 02
01 19
07
18 08
17 16
09 10
15
11 12
13
14
22 23 21 20 24 25
26
33 32
31 27
30
28 29
3
01. 02. 03. 04. 05. 06. 07. 08. 09. 10. 11. 12. 13. 14. 15. 16. 17. 18. 19. 20. 21. 22. 23. 24. 25. 26. 27. 28. 29. 30. 31. 32. 33.
Bobbin winder stopper Bobbin winder spindle Extra spool pin mounting hole Spool holder Spool pin Thread tension dial Thread take-up lever Pressure adjusting dial Face plate Thread cutter Needle plate Extension table Hook cover plate Hook cover plate release button Reverse stitch button Pattern selector dial Stitch length dial Pattern indicating window Zigzag width control lever Presser foot Needle Needle clamp screw Foot holder Thumb screw Carrying handle Handwheel Feed balance dial Power switch Machine socket Drop feed lever Free arm Buttonhole lever Presser foot lifter
Extension Table The extension table provides added sewing surface and can be easily removed for free arm sewing.
For free arm sewing Remove the extension table by pulling it away from the machine, as illustrated.
(2)
(1)
(1) Pin (2) Hole
To Store Foot Control 1. Insert the foot control in the extension table. 2. Plug the cord into the holes on the table. (1) Plug (2) Holes 3. Fold the cord as illustrated and store in the table. (3) Cord
(2) (3) (1)
4
Standard Accessories
02
01
03
01. 02. 03. 04.
04
05. 06. 07. 08. 09. 10. 11. 12. 13. 14. 15.
05 06
07
08
09
C: Overcast foot E: Zipper foot G: Blind hem foot B: Transparent buttonsewing/ button hole foot R: Automatic buttonhole foot Set of needles Bobbins Screwdriver Lint brush Seam ripper Quilter´s guide Large spool holder Small spool holder Additional spool pin Spool pin felt
10 11
12
14
13
15
16 16.
5
Storage place (Open the extension table and store the standard accessories.)
GETTING READY TO SEW Connecting the Machine to the Power Supply (for Model 224)
7 1
After switching off the power 1 , connect the plugs in the order of 2, 4 and 6.
2 1. 2. 3. 4. 5. 6. 7.
6
3
4 5
1
3
4
Power switch Foot control plug Foot control socket Machine power plug Machine power socket Power supply plug Wall outlet
Connecting the Machine to the Power Supply (for Model 219)
5
Before connecting the power, make sure the voltage and frequency of the machine conform to your electrical power supply. Switch off the power, fit the nonreversible plug into the machine socket and connect the power supply plug. Switch on the power.
2
1. 2. 3. 4. 5.
6
Power switch Machine power plug Machine power socket Power supply plug Wall outlet
Controlling Sewing Speed Speed Setting Lever (for Model 224) The maximum sewing speed can be controlled by the speed setting lever.
Foot Controller (Model 224) Sewing speed can be varied by the foot control. Foot controller type C-21365 for use with sewing machine Model 224
Foot Controller (Model 219) Sewing speed can be varied by the foot control. Foot controller type YC-482J (for USA and Canada only) or YC-190 for use with sewing machine Model 219
Note: Some fabrics have a lot of excess dye which can cause discoloration on other fabric but also on your sewing machine. This discoloring may be very difficult or impossible to remove. Fleece and denim fabric in especially red and blue often contain a lot of excess dye. If you suspect that your fabric/ready-to-wear garment contains a lot of excess dye, always pre-wash it before sewing/ embroidering to avoid the discoloring.
7
Needle Up/Down Position Button (for Model 224) When you press this button, the needle will go up or down. If the needle is up and you press this button, the needle will go down to its lowest position. If the needle is down and you press this button, the needle will go up to its highest position.
Reverse Stitch Button As long as you keep the reverse stitch button depressed, the machine sews backwards.
Presser foot Pressure Adjusting Dial The presser foot pressure adjusting dial should be set at 3 for regular sewing. Reduce the pressure to 2 for applique, cutwork, drawnwork, basting and embroidery for better maneuverability of fabric. Velours and knits with a lot of stretch may require a 1 setting.
8
Dropping the Feed Teeth * For button sewing and free motion sewing, drop the feed teeth. * When finished sewing, raise the feed teeth. Drop feed lever is located to the back and underneath the free arm bed. 1. To raise the feed teeth. 2. To drop the feed teeth.
1
Note: The feed teeth must always be up for normal sewing.
2
Sewing Light The sewing light is located behind the face plate. To change the bulb, take the face plate off the sewing machine by removing the set screw. Caution: Unplug the power supply before changing the bulb and wait until the bulb has cooled down before touching it. (1)
(1) Model 224 (12V, 5W) To remove ........ Draw out slowly To replace ........ Push in
(2)
(2) Model 219 (15W) To remove ......... Push and twist to the left. To replace ......... Push and twist to the right.
9
Presser Foot Lifter The presser foot lifter raises and lowers your presser foot. (3)
You can raise it about 0.6 cm (1/4˝) higher than the normal raised position for easy removal of the presser foot or to help you place heavy fabric under it.
(3) (2)
(2)
(1) Presser foot lifter (2) Normal raised position (3) Extra lift position
(1)
1
To Remove and Attach the Presser Foot
2
Unplug the power supply before changing the presser foot. 1. Press the red button on the back of the presser foot ankle. The presser foot will drop off. 2. Place the selected presser foot so the pin on the foot lies just under the groove of the foot ankle. Lower the ankle to lock the foot in place.
(3) (1)
(2)
(1) Red button (2) Groove (3) Pin
1
To Remove and Attach the Presser Foot Ankle
(1)
1. To Remove Remove the thumb screw by turn ing the screw counterclockwise with the screwdriver.
2
(1) Thumb screw 2. To Attach Match the hole in foot ankle with the threaded hole in the presser bar. Fit the thumb screw into the hole Tighten the screw by turning it clockwise.
10
1
Changing the Needle
2 (2)
(1) (1)
1. Raise the needle by pressing the up/down needle position button and lower the presser foot. Turn off the power switch.
(3)
Loosen the needle clamp screw by turning it counterclockwise. Remove the needle from the clamp. 2. Insert the new needle into the needle clamp with the flat side to the rear. When inserting the needle into the clamp push it up as far as it will go and tighten the clamp screw firmly. (1) Needle clamp screw (2) Pin (3) Flat side of the needle
Needle and Thread Chart Needle size
Fabric
Cotton thread size
Silk thread size
No. 60 (#7) No. 70 (#10)
Fine silk Crepe de chine
70 - 80
100 - 140
No. 75 (#11) No. 80 (#12)
Poplin Pure Silk
50 - 60
80 - 100
No. 80 (#12)
Broad cloth Cotton Wool
40 - 50
60 - 70
30 - 40
50 - 60
No. 100 (#16)
Denim
30
45 - 50
Stretch needle No. 70 (#10)
Tricot
70 - 80
100 - 140
No. 90 (#14)
11
Winding the Bobbin Settting the Spool Lift up the spool pin and place the spool of thread on it with the thread coming off the spool as shown. (1)
Press the large spool holder firmly against the spool of thread with the flat side of the spool holder against the spool of the thread. (1) Large spool holder (2) Small spool holder
(2)
Removing the Bobbin Gently slide the bobbin cover plate release button to the right and remove the cover plate.
(1)
Lift out the bobbin. (1) Bobbin cover plate release button (2) Bobbin cover plate (2)
12
B (2) (1) (3) A
Winding the Bobbin
1
1. Guide the thread around the thread guide. 2. Thread through the hole in the bobbin from the inside to the outside. Put the bobbin on the bobbin winder spindle. 3. Slide it to the right.
2
Caution: Never move the bobbin winder spindle when the machine is running. 4. With the free end of the thread held in your hand, depress the foot control. Stop the machine when it has made a few turns, and cut the thread close to the hole in the bobbin. 5. Depress the foot control again. When the bobbin is fully wound, it will stop automatically. Return the bobbin winder to its original position by moving the spindle to the left, and cut the thread as shown.
3
4
To use the additional spool pin, set the felt and the spool as shown above.
5
(1) Additional spool pin (2) Felt (3) Additional spool pin hole
13
Inserting the Bobbin
1
1. Place the bobbin in the bobbin holder with the thread running counterclockwise.
2. Guide the thread into the notch A on the front side of the bobbin holder. Draw the thread to the left, sliding it between the tension spring blades.
2
A 3. Continue to draw the thread lightly until the thread slips into notch B.
3
Note: Check the threading by referring to the chart shown on the bobbin cover plate.
B
4
4. Pull out about 15 cm (6 inches) of thread and attach the bobbin cover plate.
14
Threading the Machine 1 3
4
Raise the thread take-up lever to its highest position by turning the handwheel toward you.
2
Raise the presser foot with the presser foot lifter and the thread in the order from 1 to 5 .
5
1
1. Bring the thread from the spool and it through the thread guide. Then draw it down along the right slot.
2
2. Guide the thread around the bottom of the thread guide plate from right to left, then draw it upward.
3. Firmly draw the thread from right to left over the take-up lever and down into the take-up lever eye. Then guide it down along the left slot.
3
4. Slide the thread from the left behind the needle bar thread guide.
4, 5
5. Thread the needle from front to back.
15
To Use Needle Threader (for Model 224)
1
1. Raise the needle to its highestposition. Lower the needle threader as far as it will go.
2. Push the knob in the direction of the arrow in the illustration, and insert the hook into the needle eye. Bring the thread around the guide and under the hook.
2
(1) Guide (2) Hook (1)
3
(2) 3. Push the knob in the direction of the arrow in the illustration, and draw the thread loop to the back of the needle.
4. Raise the needle threader knob slowly to draw the thread loop up. the end of the thread through the needle eye by pulling the thread loop to the back.
4
16
Drawing Up Bobbin Thread
1
1. Raise the presser foot and hold the needle thread lightly with your left hand.
2. Press the up/down needle position button twice to pick up the bobbin thread. Draw up the needle thread forming a loop of bobbin thread.
2 (2)
(1)
(1) Needle thread (2) Bobbin thread
3
3. Pull 15 cm (6 inches) of both threads back and under the presser foot.
17
Pattern Selector Dial
C
B
A
A. Recommended stitch length (Model 224) B. Set any stitch length C. Reset indication for buttonhole (Model 219)
Turn the pattern selector dial to indicate a selected pattern on the pattern indicating window.
(2)
1
(1) Pattern selector dial (2) Pattern indication window (1)
Note: Always raise the needle above the fabric and presser foot before you turn the pattern selector dial.
Stitch Length Dial The higher the number, the longer the stitch length. You can select the suitable stitch length for fabrics that you plan to sew.
(2)
(1) Stitch length dial (2) Setting mark
(1) 2
Note: Always raise the needle above the fabric and presser foot before you turn the stitch length dial.
18
Zigzag Width Control The higher the number, the wider the stitch width becomes. Note: Always raise the needle above the fabric and presser foot before you turn the zigzag width control.
Infinite Needle Position When pattern number 14 is selected and the stitch width control is activated, you can move the needle between center and left needle positions.
19
Balancing Needle Thread Tension (1)
(4)
The needle thread and the bobbin thread should interlock in the center of two layers of fabric in straight seams.
(3)
To obtain better zigzag stitches, the needle thread tension should be slightly weaker than in the case of straight sewing. The needle thread should appear slightly on the reverse side of the fabric.
(2)
(1) (2) (3) (4)
Needle thread Bobbin thread Right side Wrong side
To loosen needle thread tension Loosen the needle thread tension by moving the dial to a lower number.
To tighten needle thread tension Tighten the needle thread tension by moving the dial to a higher number.
20
(2)
(1)
Straight Stitching
(3)
(1) (2) (3) (4) (5)
14 0123456
(4) (5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
14 0 or 6 1.5 - 4 2-6 A: Zigzag foot
Starting to Sew Raise the presser foot and position the fabric next to a seam guide line on the needle plate (see page 23). Lower the needle to the point where you want to start. Lower the presser foot and pull the threads toward the back. Depress the foot control. Gently guide the fabric along the seam guide line letting the fabric feed naturally.
Changing Sewing Direction Stop the machine and bring the needle down into the fabric by pressing the up/down needle position button (or by turning the handwheel for Model 219). Raise the presser foot. Pivot the fabric around the needle to change sewing direction as desired. Lower the presser foot.
21
Finishing Sewing
1
1. To fasten the ends of seams, press the reverse button and sew several reverse stitches.
2
2. Raise the presser foot. Remove the fabric, and draw the threads to the back.
3
3. Cut the thread using the thread cutter. The threads are cut the proper length for starting the next seam.
22
Straight Stitching on Heavy Fabrics 1. Lower the needle into the fabric at the point where you wish to start sewing. Press the small black button on the zigzag foot with your left hand to lock the presser foot to the fabric. 2. Lower the presser foot with your right hand, keeping pressure on the black button with your left hand.
(1)
3. Release the black button and start sewing. (1) Black button
Seam Allowance Lines The seam guides on the needle plate and bobbin cover plate help you measure the seam width. (1) Seam allowance lines Number
15
20 1/2 5/8 3/4
Distance (cm) 1.5 2.0 1.3 1.6 1.9 (1)
Note: The numbers indicate the distance between the middle needle position and the seam allowance lines.
Turning a Square Corner Stop stitching and lower the needle when the fabric edge facing you lines up with the cornering guides as shown. Raise the presser foot and turn the fabric to line up to the edge with the 1.6 cm (5/8 inch) seam guide. Lower the presser foot and begin stitching in the new direction.
(2)
(2) Cornering guides
23
UTILITY STITCHING (1)
(2)
Zigzag Stitching
(3)
13
(1) (2) (3) (4) (5)
(4)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
13 0-6 0.5 - 3 3-5 A: Zigzag foot
(5)
Simple zigzag stitching is widely used for overcasting, applique and sewing on buttons.
(1)
(2)
(3)
Overcasting
13
(1) (2) (3) (4) (5)
(4) (5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
13 5 or 6 1-2 4-7 C: Overcast foot
This type of stitch is used on the seam allowance to prevent fabrics from fraying at raw edges. It can be used to finish a hem edge. Place the edge of the fabric next to the black guide of foot C . (6)
(6) Black guide
24
(1)
Seam/Overcast Stitch
(2)
(1) (2) (3) (4)
19
(3)
(4)
Stitch selector: Stitch width: Top thread tension: Presser foot:
* Stitch length:
19 5 or 6 4-7 C: Overcast foot Set any length
Place the edge of the fabric next to the black guide on the foot and brush guide. The wires on this foot prevent light weight fabric from rolling and creating a ridge. As you sew the needle falls off the fabric wrapping the threads around the raw edge to prevent raveling. (5) Black guide
(5)
(1)
Multiple ZigZag
(3)
(2)
12
(1) (2) (3) (4) (5)
(4)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
12 3-6 0.5 - 1.5 4-6 A: Zigzag foot
(5)
This stitch is used to finish the seam allowance on synthetics and other fabrics that tend to pucker. Place your fabric to allow a 1.6 cm (5/8 inch) seam. Trim the extra seam allowance edge after sewing as illustrated. Note: Be careful not to cut the stitches.
25
(1)
Reinforced Straight Stitch
(2)
(1) Stitch selector: (2) Stitch width: (3) Top thread tension: (4) Presser foot: * Stitch length:
16 0123456
(3)
(4)
16 0 or 6 3-6 A: Zigzag foot Set any length
This strong, durable stitch is recommended where both elasticity and strength are needed to ensure comfort and durability. Use it to reinforce areas such as crotch and armhole seams. Also use it when constructing items such as backpacks for extra reinforcement. The stitch is sewn with two stitches forward and one stitch backward, forming a seam that does not rip easily. Garments should be basted for fitting before seaming. (1)
Lightening Stitch
(2)
15
(3)
(1) Stitch selector: (2) Stitch width: (3) Top thread tension: (4) Presser foot: * Stitch length:
(4)
15 4-5 3-6 A: Zigzag foot Set any length
This stitch is used for seaming tricot and light weight knit fabrics, it permits the seam to be pressed completely flat and prevent thread breaking with stretch fabric seams. For a 1.5 cm (5/8 inch) seam, use the 2 cm (6/8 inch) marking on the needle plate. When sewing light weight knit fabrics, set the pressure dial at 1 or 2.
26
(1)
(2)
Sewing Buttons
(4)
13
(1) (2) (3) (4)
0123456
(3)
(5)
Stitch selector: Stitch width: Top thread tension: Presser foot:
(5) Feed teeth lowered * Stitch length:
13 3 - 3.5 4-7 B: Transparent buttonsewing foot Set any length
Tape the button over the placement mark. A pin can be placed on top the foot to form a shank. Before lowering the foot, test the needle swing, making sure the needle drops in each hole. Adjust the stitch width if necessary and lower the foot. Align both holes of the button with the needle swing, lower the foot and depress the foot control. Sew about 10 stitches, then pull out approximately 20 cm (8 inches) of both the needle and bobbin thread and cut. Pull the needle thread down through the hole in the button (so it is between the hole and fabric). Now, pull the needle thread firmly to draw the bobbin thread up through the fabric. Wind one thread clockwise around the shank, the other counterclockwise. Finally, tie the 2 threads together. Note: When sewing on the button is completed, raise the feed teeth.
27
(1)
(2)
Automatic Buttonhole
(3)
1
(1) (2) (3) (4) (5)
0 1
(4)
1.
(5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
1 4-6 0.5 - 1 2-5 R: Automatic buttonhole foot
* The size of buttonhole is automatically set by placing the button in the automatic buttonhole foot R. * The button holder of the foot takes a button size up to 2.5 cm (1 inch) in diameter. * Make a test buttonhole on a fabric sample duplicating the interfacing and seams of the actual garment. * Place the button on the fabric sample and mark the top and bottom to determine the position of the buttonhole. * Use interfacing on stretch fabrics. * Use stabilizer under all fabrics
(1)
(2)
2.
1. Attach the automatic buttonhole foot R. Make sure the groove on the holder catches the pin on the foot when lowering the presser foot. (1) Groove (2) Pin 2. Pull the button holder to the back, and place the button in it. Push it together tightly on the button.
(3)
(3) Button holder If the button is extremely thick, make a test buttonhole. If it is difficult to fit the button through the test buttonhole, lengthen the size by pulling back the button holder which will increase the buttonhole length. (4) Gap
(4)
28
3. Pull the buttonhole lever downward as far as it will go.
3
(5) Buttonhole lever (5)
4. Draw both threads to the left under the foot. Insert the garment under the foot, and lower the needle at the starting point.
4
Then lower the automatic buttonhole foot.
(8)
(6) (7) (8) (9)
(6) (9)
Needle thread Bobbin thread Hole Starting point
Note: Make sure there is no gap between the slider and the spring holder.
(7)
If there is a gap, the length of the rows will be different, as shown.
(10) (13)
(10) (11) (12) (13)
(12) (11)
29
Slider Spring holder Difference There should be no gap.
5. Sew slowly and stop the machine at the starting point when the buttonhole is completed.
5
Step 1: First the front bartack and left row is sewn. Step 2: Next the back bartack, a locking stitch and the right row is sewn.
6
6. Cut both needle and bobbin threads leaving about 10 cm (4 inches) of thread ends loose. Draw the needle thread to the wrong side of the fabric by pulling the bobbin thread. Then, knot the threads. Place a pin on the rear side of the bartack position so that you do not need to worry about cutting the end of the buttonhole stitch. Then cut the opening with a seam ripper.
(To sew a series of same-size buttonholes) To reset the buttonhole sewing function, select a different stitch pattern with the pattern selector dial 2, then return it to the buttonhole.
1
2
30
7. When finished, push the button hole lever up as far as it will go.
7
To adjust buttonhole stitch density. Set the stitch length dial between 0.5 and 1.0 to adjust the buttonhole stitch density.
0 1
31
(1)
(2)
Corded Buttonhole
(3)
1
(1) (2) (3) (4) (5)
1 4-6 0.5 - 1 2-5 R: Automatic buttonhole foot 1. Use the same procedure as described in automatic buttonhole sewing steps.
0 1
(4)
(5)
1
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
Note: Set the stitch width to match the thickness of the cord used. (1) With the buttonhole foot raised, hook the filler cord on the spur at the back of the buttonhole foot. (1)
Bring the ends toward you under the buttonhole foot, clearing the front end. Hook the filler cord into the forks on the front of automatic buttonhole foot R to hold them tight. Lower the needle into the garment where the buttonhole will start and lower the foot. 2. Depress the foot control gently and sew the buttonhole. Each side of the buttonhole and the bartacks will be sewn over the cord. Remove the fabric from the machine and cut the sewing threads only.
2
(2) (4) (3)
(2) Needle thread (3) Bobbin thread (4) Starting point
3
3. Pull the left end of the filler cord to tighten it. Thread the end of the cord through a darning needle, draw to the wrong side of the fabric and cut. Note: To cut the buttonhole opening, refer to the instructions on page 30.
32
(2)
(1)
Manual Buttonhole
(3)
1
(1) (2) (3) (4) (5)
0 1
(4)
(5)
1.
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
1 4-6 0.5 - 1 2-5 B: Transparent buttonhole foot
Note: If the diameter of the button is more than 2.5 cm (1 inch), a buttonhole must be made manually as follows. 1. Attach the buttonhole foot B.
2, 3
2. Pull the buttonhole lever downward as far as it will go. 3. Lower the needle into the garment where the buttonhole is to start, and lower the foot. (1) Needle thread (2) Bobbin thread (3) Starting point
(1)
(3) (2)
33
4
4. Sew the front bartack and left row, then stop the machine after sewing the desired total length of buttonhole.
5
5. Pull the buttonhole lever toward you.
6
6. Sew the back bartack and right row, then stop the machine at the starting point.
7
7. When finished, push the buttonhole lever up as far as it will go.
34
(1)
(2)
Zipper Sewing
(3)
(1) (2) (3) (4) (5)
14 0123456
(4)
(5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
14 0 1.5 - 4 3-6 E: Zipper foot
To Snap On the Zipper Foot Fit the pin on the zipper foot into the groove on the ankle. (2)
(1)
To sew the left side of the zipper Attach the zipper foot on the right-hand side. To sew the right side of the zipper Attach the zipper foot on the left-hand side.
(4)
(3)
(1) (2) (3) (4)
1
Groove Pin When the left side is sewn When the right side is sewn
Fabric Preparation (9)
(7)
1. Add 1 cm (3/8 inch) to the zipper size. This is the overall opening size. (1) (2) (3) (4) (5) (6) (7) (8) (9)
(8) (6) (3)
(4)
(2) (1)
(5)
35
Right side of fabric 1 cm (3/8 inch) Opening size Zipper size Slider Zipper teeth Zipper tape Wrong side End of opening
2. Place right sides of fabric together and sew to the end of the zipper opening. Reverse stitch to lock the stitches. Manually increase the stitch length to 4 and sew the zipper opening.
2
(10) (11) (12) (13) (14)
2 cm (3/4 inch) 11.3 cm (Stitch length) Reverse stitch End of opening Straight stitch
To Sew
1
(1)
1. Fold back the left seam allowance. Turn under the right seam allowance to form a 0.2 to 0.3 cm (1/8 inch) fold. Place the zipper teeth next to this fold and pin in place.
(3)
(2)
(4)
2. Attach the zipper foot with the pin on the right hand side. Lower the zipper foot on the top side at the bottom of the zipper so that the needle pierces the fabric next to the fold and the zipper tape. (1) Lower fabric (2) End of opening (3) Stitch line (4) 0.3 cm (1/8 inch) (5) Wrong side of fabric (6) Opening size (7) Fold (8) Basting stitch line
(6) (5)
(8)
(7)
2
(3)
(5)
36
3. Sew through all layers next to the fold. Stop just before the zipper foot reaches the slider on the zipper tape. Lower the needle slightly into the fabric. Raise the zipper foot and open the zipper. Lower the foot and stitch the remainder of the seam.
3
(9)
(9) Slider (10) 5 cm (2 inches) (10)
4
4. Close the zipper and spread the fabric flat with the right side facing up. Baste the opened fabric and zipper tape together. (11) Basting stitch (12) Zipper tape (9)
(11)
(12)
37
5. Remove the zipper foot and reattach it on its left side. Guide the edge of the foot along the zipper teeth and stitch through the garment and zipper tape. Stop about 5 cm (2 inches) from the top of the zipper.
5
(13) Remove the basting stitches (14) Reverse stitches (0.7 - 1cm) (14) (13)
6. Lower the needle slightly into the fabric, raise the foot, remove the basting stitches and open the zipper. Lower the foot and stitch the remainder of the seam, making sure the fold is even.
6
38
(1)
(2)
Blind Stitch Hemming
(3)
(1) (2) (3) (4) (5)
0123456
(4)
(5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
9 3-4 2 2-5 G: Blind hem foot
1. How to fold the fabric
1
(1) (2) (3) (4)
(2) (2)
(1) (1) (3)
Wrong side of fabric 0.4 - 0.7 cm (5/32 - 1/4 inch) Heavy weight fabric Light/Medium weight fabric
2. How to sew
(4)
When the needle comes to the left hand side, position the fabric so that the folded edge comes to the left side of the guide. Lower the presser foot.
2
3. Adjust the position of the needle swing with the stitch width button so that the needle just pierces the folded edge of the fabric when the needle comes to the left side. Sew, guiding the folded edge along the guide. (5) Guide dial (6) Guide (7) Folded edge
3 (5)
4. Open the fabric after sewing, and press flat. (8) Right side of fabric
(6) (7)
Note: For a professional looking hem, try not to let the needle pierce more than 0.2 cm (1/8 inch) into the fold. If the folded edge is pierced too far to the left side, you can not expect a good seam on the right side of the fabric.
4 (8)
39
2
3
Decorative Satin Stitch Patterns
(2)
(1) 4
5
6
(1) (2) (3) (4) (5)
(3) (4)
0
(5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
1
2-6 3-6 0.5 2-5 A: Zigzag foot
Satin stitches are used for decorative stitches on blankets, linens, tableclothes and napkins. It is also especially attractive in applique. Note: Use tear-away stabilizer under fabric. Sew a row of stitches and adjust the thread tension so the upper thread appears on the reverse side of the fabric. Test the stitch on a sample of the actual fabric first.
Stretch Stitch Patterns 15 16 17 18 19 20 21 22 23 24
(1) Stitch selector:
15 - 24 (Model 224) 15 - 19 (Model 219) (2) Stitch width: 3-6 (3) Top thread tension: 2-4 (4) Presser foot: A: Zigzag foot *Stitch length: Set any length
(1) (2)
(3) (4)
The stretch stitch does not actually stretch as it is being sewn, but is stitched in a forward and backward motion (sometimes called a reverse action stitch), so that it will expand when the fabric stretches instead of breaking. This stitch can also be used for topstitching on all fabrics Note: We recommend a stretch needle for stretch, knit or organdy fabric to prevent skipped stitches.
40
Adjusting Stretch Stitch Balance If stretch stitch patterns are uneven when sewn on a particular fabric, adjust them with the feed balance dial. (1) (2) (3) (4)
(3)
(1)
(A)
Feed balance dial Standard mark Setting mark Example: Pattern 18
(2) (4)
(B)
To Adjust distorted patterns (A) If patterns are compressed, correct by turning the dial in the direction of ( + ). (B) If patterns are drawn out, correct by turning the dial in the direction of ( - )
41
(1) 18
Smocking
(2)
(1) Stitch selector:
24
(2) Stitch width: (3) Top thread tension: (4) Presser foot: *Stitch length:
(4)
(3)
18 or 24 (Model 224) 3-6 3-5 A: Zigzag foot Set any length
With the manual stitch length at 11.3 cm (4.5 inch), sew straight lines 1 cm (3/8 inch) apart, across the area to be smocked. (1)
A looser needle thread tension will make gathering easier. Knot the threads along one edge. Pull the bobbin threads and distribute the gathers evenly. Secure the threads at the other end. Reduce the tension and pressure if necessary and sew pattern stitches between the straight seams. Pull out the gathering stitches. (1) 1 cm (3/8 inch) (1)
42
(1)
(2)
Quilting
(3)
14
(1) (2) (3) (4) (5)
0123456
(4) (5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
14 0 or 6 1.5 - 4 3-6 A: Zigzag foot
(6) Quilter (6)
(1) The quilting guide will help to keep the stitching lines straight.
(2)
Loosen the quilt guide holding screw.
(3)
Slide the quilt guide in the opening to the desired width and tighten the screw. Sew, guiding the quilt guideover the previous row of stitching. (4)
(1) (2) (3) (4)
t
43
Quilt Guide holding screw Hole Quilt Guide Distance
(1)
(2)
Pin Tucking
(3)
(1) (2) (3) (4) (5)
14 0123456
(4)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
(5)
11 5-6 2-3 6-8 G:Blind stitch hem foot
Fold the fabric with wrong sides together on the foldline. Position the fabric so that the needle pierces 0.1 to 0.2 cm (1/16 inch) inside from the folded edge and lower the presser foot. Turn the guide screw and move the sliding guide next to the folded edge. Sew guiding the folded edge along the sliding guide. Press the pin tucks to one side.
(1) (2)
(1) Guide screw (2) Sliding guide
Shell Tuck (1)
(2)
(1) Stitch selector: (2) Stitch width: (3) Stitch length: (4) Top thread tension: (5)Presser foot:
11 5-6 2 6-8 B:Transparent buttonhole foot Note: Use a lightweight fabric such as tricot. Fold and stitch on the bias.
(3)
11
(4) (5)
Set the stitch width and length as you desire. You may need to tighten the top thread slightly. Allow the needle to just clear the folded edge of the fabric when it zigzags. If you sew rows of shell stitches, space the rows 1.5 cm (5/8 inch) apart. You can sew shell stitches on knits or soft silky wovens in any direction.
44
(1)
(2)
Fagoting
(3)
(1) Stitch selector:
8, 10 20 (Model 224) (2) Stitch width: 3-6 (3) Stitch length: 1 *Set any length for pattern 20 (4) Top thread tension: 2-5 (5) Presser foot: A: Zigzag foot
10 20
(5)
(4)
Fold under each fabric edge 1.5 cm (1/2 inch) and press. Pin the two edges a tear-away stabilizer backing 0.3 cm (1/8 inch) apart. Sew slowly, guiding the fabric so the needle catches the folded edge on each side. Remove the backing when finished.
(1)
(2)
Patch Work
(3)
(1) (2) (3) (4) (5)
12
(4)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
8, 12 5-6 1 2-5 A: Zigzag foot
(5)
Sew seam and press seam allowance open. Sew pattern stitch on right side of garment centering over the seam line. (1)
(1)
(1) Right side of fabric
45
(1)
(2)
Applique
(3)
(1) (2) (3) (4) (5)
13 0123456
(4) (5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
(6) (6) Presser Dial:
13 3-5 0.5 - 1 3-5 B:Transparent buttonhole foot 2
Baste (or fuse with iron-on fusible web) applique pieces on the fabric. Stitch around the applique making sure the needle falls along the outer edge of the applique. When sewing corners, lower the needle down into the fabric. Raise the presser foot and pivot the fabric to the right or left.
(1)
Note: When applique sewing is finished, return the pressure dial to 3.
46
CARE OF YOUR MACHINE Caution Before performing any of the following,make sure that the sewing machine is unplugged from the power source. Do not dismantle the machine other than explained on this page.
1
Cleaning the Hook Assembly Area and Feed Teeth
(1)
1. Remove the presser foot and needle. Remove the screw on the left side of the needle plate with the screwdriver supplied with the machine.
2
2. Remove the needle plate and take out the bobbin. Lift up the bobbin holder and remove it.
3
3. Brush out dust and lint.
4
4. Clean the feed teeth and hook assembly area with the lint brush.
5
5. Wipe out gently with a soft, dry cloth. Note: You may also use a vacuum cleaner.
47
Replacing the Bobbin Holder
1
1-2. Insert the bobbin holder so that the knob fits next to the stopper in the hook assembly area. (1) Knob (2) Stopper
2
(2) (1)
3
3. Insert the bobbin. Replace the needle plate, inserting the two needle plate guide pins into the holes in the needle plate. Replace the screw.
(3)
(3) Guide hole (4) Screw
(4) (3)
After cleaning, be sure to replace the needle and presser foot.
48
Troubleshooting Condition
Cause
The needle thread breaks.
1. 2. 3. 4. 5.
6. 7. 8.
The bobbin thread breaks.
1. 2. 3.
The needle breaks.
1. 2. 3. 4. 5.
Skipped stitches
1. 2. 3. 4. 5. 6.
Seam puckering
1. 2. 3. 4. 5.
Reference The needle thread is not threaded properly. The needle thread tension is too tight. The needle is bent or blunt. The needle is incorrectly inserted. The needle thread and the bobbin thread are not set properly under (drawn to the rear of ) the presser foot when sewing is starting. The fabric is not drawn to the rear when sewing is finished. The thread is too heavy or too fine for the needle. The thread is old and brittle.
Refer to page 15
The bobbin thread is not threaded properly in the bobbin holder. Lint has collected in the bobbin holder. The bobbin is damaged and doesn´t turn smoothly.
Refer to page 14
The needle is incorrectly inserted. The needle is bent or blunt. The needle clamp screw is loose. The fabric is not drawn to the rear when sewing is finished. The needle is too fine for the fabric being sewn.
Refer Refer Refer Refer
The needle is incorrectly inserted. The needle is bent or blunt. The needle and/or threads are not suitable for the work being sewn. A blue tipped needle is not being used for sewing stretch, very fine fabrics or synthetics. The needle thread is not threaded properly. The wrong needle is used.
Refer to page 11 Refer to page 11 Refer to page 11
The needle thread tension is not tight. The needle thread is not threaded properly. The needle is too heavy for the fabric being sewn. The stitch length is too long for the fabric. The presser foot pressure is not correctly adjusted.
Refer to page 20 Refer to pages 14, 15
49
Refer Refer Refer Refer
to to to to
page page page page
20 11 11 21
Refer to page 22 Refer to page 11
Refer to page 47 Change the bobbin.
to to to to
page page page page
11 11 11 22
Refer to page 11
Refer to page 11 Refer to page 15 Change the needle.
Refer to page 11 Make stitch denser. Refer to page 8
Troubleshooting, continued Condition
Cause
The fabric is not feeding smoothly.
1. 2. 3.
The feed teeth are packed with lint. The stitches are too fine. The feed teeth were not raised after being lowered.
Refer to page 47 Make stitch coarser Refer to page 9
Gathering
1. 2.
The needle thread tension is too loose. The needle is too heavy or light for the fabrics being sewn.
Refer to page 20 Refer to page 11
The machine does not work.
1. 2.
The machine is not plugged in. A thread is caught in the hook assembly area. The bobbin winder spindle is still in the winding position.
Refer to page 6 Refer to page 47 Refer to page 13
3.
Reference
Patterns are distorted.
1. 2.
The stitch is not balanced. The stitch lenght is too long or too short
Refer to page 42
The automatic buttonhole stitches are not working.
1.
The stitch density is not suitable for the fabric being sewn. Interfacing is not being used with stretch fabrics.
Refer to pages 28, 31
Noisy operation
1.
There is thread caught in the hook assembly area. Lint has built up in the bobbin holder or hook assembly are.
Refer to page 47 Refer to page 47
2.
2.
50
Refer to page 28
We reserve the right to change the machine equipment and the assortment of accessories without prior notice, or make modifications to the performance or design. Such modifications, however, will always be to the benefit of the and the product.
Please note that on disposal, this product must be safely recycled in accordance with relevant National legislation relating to electrical/electronic products. If in doubt please your retailer for guidance.
412 68 03-26D • InHouse • ©2001-2004 VSM Group AB • All rights reserved • Printed in Sweden on environmentally-friendly paper
This houshold sewing machine is designed to comply with IEC/EN 60335-2-28 and UL1594
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic safety precautions should always be followed, including the following: Read all instructions before using this household sewing machine.
DANGER - To reduce the risk of electric shock: • •
A sewing machine should never be left unattended when plugged in. Always unplug this sewing machine from the electric outlet immediately after using and before cleaning. Always unplug before relamping. Replace bulb with same type rated 15 Watt.
WARNING - To reduce the risk of burns, fire, electric shock, or injury to persons: •
• • •
• • • • • • • • • • • •
This sewing machine is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the sewing machine by a person responsible for their safety. Children should be supervised to ensure that they do not play with the sewing machine. Use this sewing machine only for its intended use as described in this manual. Use only attachments recommended by the manufacturer as contained in this manual. Never operate this sewing machine if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Return the sewing machine to the nearest authorized dealer or service center for examination, repair, electrical or mechanical adjustment. Never operate the sewing machine with any air openings blocked. Keep ventilation openings of the sewing machine and foot controller free from the accumulation of lint, dust, and loose cloth. Keep fingers away from all moving parts. Special care is required around the sewing machine needle. Always use the proper needle plate. The wrong plate can cause the needle to break. Do not use bent needles. Do not pull or push fabric while stitching. It may deflect the needle causing it to break. Switch the sewing machine off (“0”) when making any adjustment in the needle area, such as threading needle, changing needle, threading bobbin, or changing presser foot, etc. Always unplug sewing machine from the electrical outlet when removing covers, lubricating, or when making any other servicing adjustments mentioned in the instruction manual. Never drop or insert any object into any opening. Do not use outdoors. Do not operate where aerosol (spray) products are being used or where oxygen is being istrated. To disconnect, turn all controls to the off (“0”) position, then remove plug from outlet. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
SAVE THESE INSTRUCTIONS For the USA and Canada
This sewing machine has a polarized plug (one blade wider than the other). To reduce the risk of electric shock, this plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, a qualified electrician to install the proper outlet. Do not modify the plug in any way.
TABLE OF CONTENTS Name of Parts Extension Table To Store Foot Control Standard Accessories
Finishing Sewing 22 Straight Stitching on Heavy Fabrics 23 Seam Allowance Lines 23
2-3 4 4 5
UTILITY STITCHING
GETTING READY TO SEW Connecting the Machine to the Power Supply Controlling Sewing Speed Up/Down Needle Position Button Reverse Stitch Button Pressure Adjusting Dial Dropping the Feed Teeth Sewing Light Presser Foot Lifter To Remove and Attach the Presser Foot To Remove and Attach Presser Foot Ankle Changing the Needle Needle and Thread chart Winding the Bobbin Setting the Spool Removing the Bobbin Winding the Bobbin Inserting the Bobbin Threading the Machine To Use Needle Threader Drawing Up Bobbin Thread Pattern Selector Dial Stitch Length Dial Zigzag Width Control Infinite Needle Position Balancing Needle Thread Tension Straight Stitching Starting to Sew Changing Sewing Direction
Zigzag Stitching Overcasting Seam/Overcast stitch Multiple ZigZag Reinforced Straight Stitch Lightening Stitch Sewing Buttons Automatic Buttonhole Corded Buttonhole Manual Buttonhole Zipper Sewing Blind Stitch Hemming Decorative Satin Stitch Patterns Stretch Stitch Patterns Adjusting Stretch Stitch Balance Smocking Quilting Pin Tucking Shell Tuck Fagoting Patch Work Applique
6 7 8 8 8 9 9 10 10 10 11 11 12 12 13 14 15 16 17 18 18 19 19 20 21 21 21
24 24 25 25 26 26 27 28-31 32 33-34 35-38 39 40 40 41 42 43 44 44 45 45 46
CARE OF YOUR MACHINE Cleaning the Hook Assembly Area and Feed Teeth 47 Replacing the Bobbin Holder 48 Troubleshooting 49-50
1
Name of parts (Model 224) 06
04
05
03 02
01 22
07
21 08
20 19
09 10 11
18
12 13
14
15
16
17
25 26 24 23 27 28
29
36 35
34 30
33
31 32
2
01. 02. 03. 04. 05. 06. 07. 08. 09. 10. 11. 12. 13. 14. 15. 16. 17. 18. 19. 20. 21. 22. 23. 24. 25. 26. 27. 28. 29. 30. 31. 32. 33. 34. 35. 36.
Bobbin winder stopper Bobbin winder spindle Extra spool pin mounting hole Spool holder Spool pin Thread tension dial Thread take-up lever Pressure adjusting dial Face plate Thread cutter Needle threader Needle plate Extension table Hook cover plate Hook cover plate release button Up/down needle position button Reverse stitch button Speed setting lever Pattern selector dial Stitch length dial Pattern indicating window Zigzag width control lever Presser foot Needle Needle clamp screw Foot holder Thumb screw Carrying handle Handwheel Feed balance dial Power switch Machine sockets Drop feed lever Free arm Buttonhole lever Presser foot lifter
Name of parts (Model 219) 06
05
04
03 02
01 19
07
18 08
17 16
09 10
15
11 12
13
14
22 23 21 20 24 25
26
33 32
31 27
30
28 29
3
01. 02. 03. 04. 05. 06. 07. 08. 09. 10. 11. 12. 13. 14. 15. 16. 17. 18. 19. 20. 21. 22. 23. 24. 25. 26. 27. 28. 29. 30. 31. 32. 33.
Bobbin winder stopper Bobbin winder spindle Extra spool pin mounting hole Spool holder Spool pin Thread tension dial Thread take-up lever Pressure adjusting dial Face plate Thread cutter Needle plate Extension table Hook cover plate Hook cover plate release button Reverse stitch button Pattern selector dial Stitch length dial Pattern indicating window Zigzag width control lever Presser foot Needle Needle clamp screw Foot holder Thumb screw Carrying handle Handwheel Feed balance dial Power switch Machine socket Drop feed lever Free arm Buttonhole lever Presser foot lifter
Extension Table The extension table provides added sewing surface and can be easily removed for free arm sewing.
For free arm sewing Remove the extension table by pulling it away from the machine, as illustrated.
(2)
(1)
(1) Pin (2) Hole
To Store Foot Control 1. Insert the foot control in the extension table. 2. Plug the cord into the holes on the table. (1) Plug (2) Holes 3. Fold the cord as illustrated and store in the table. (3) Cord
(2) (3) (1)
4
Standard Accessories
02
01
03
01. 02. 03. 04.
04
05. 06. 07. 08. 09. 10. 11. 12. 13. 14. 15.
05 06
07
08
09
C: Overcast foot E: Zipper foot G: Blind hem foot B: Transparent buttonsewing/ button hole foot R: Automatic buttonhole foot Set of needles Bobbins Screwdriver Lint brush Seam ripper Quilter´s guide Large spool holder Small spool holder Additional spool pin Spool pin felt
10 11
12
14
13
15
16 16.
5
Storage place (Open the extension table and store the standard accessories.)
GETTING READY TO SEW Connecting the Machine to the Power Supply (for Model 224)
7 1
After switching off the power 1 , connect the plugs in the order of 2, 4 and 6.
2 1. 2. 3. 4. 5. 6. 7.
6
3
4 5
1
3
4
Power switch Foot control plug Foot control socket Machine power plug Machine power socket Power supply plug Wall outlet
Connecting the Machine to the Power Supply (for Model 219)
5
Before connecting the power, make sure the voltage and frequency of the machine conform to your electrical power supply. Switch off the power, fit the nonreversible plug into the machine socket and connect the power supply plug. Switch on the power.
2
1. 2. 3. 4. 5.
6
Power switch Machine power plug Machine power socket Power supply plug Wall outlet
Controlling Sewing Speed Speed Setting Lever (for Model 224) The maximum sewing speed can be controlled by the speed setting lever.
Foot Controller (Model 224) Sewing speed can be varied by the foot control. Foot controller type C-21365 for use with sewing machine Model 224
Foot Controller (Model 219) Sewing speed can be varied by the foot control. Foot controller type YC-482J (for USA and Canada only) or YC-190 for use with sewing machine Model 219
Note: Some fabrics have a lot of excess dye which can cause discoloration on other fabric but also on your sewing machine. This discoloring may be very difficult or impossible to remove. Fleece and denim fabric in especially red and blue often contain a lot of excess dye. If you suspect that your fabric/ready-to-wear garment contains a lot of excess dye, always pre-wash it before sewing/ embroidering to avoid the discoloring.
7
Needle Up/Down Position Button (for Model 224) When you press this button, the needle will go up or down. If the needle is up and you press this button, the needle will go down to its lowest position. If the needle is down and you press this button, the needle will go up to its highest position.
Reverse Stitch Button As long as you keep the reverse stitch button depressed, the machine sews backwards.
Presser foot Pressure Adjusting Dial The presser foot pressure adjusting dial should be set at 3 for regular sewing. Reduce the pressure to 2 for applique, cutwork, drawnwork, basting and embroidery for better maneuverability of fabric. Velours and knits with a lot of stretch may require a 1 setting.
8
Dropping the Feed Teeth * For button sewing and free motion sewing, drop the feed teeth. * When finished sewing, raise the feed teeth. Drop feed lever is located to the back and underneath the free arm bed. 1. To raise the feed teeth. 2. To drop the feed teeth.
1
Note: The feed teeth must always be up for normal sewing.
2
Sewing Light The sewing light is located behind the face plate. To change the bulb, take the face plate off the sewing machine by removing the set screw. Caution: Unplug the power supply before changing the bulb and wait until the bulb has cooled down before touching it. (1)
(1) Model 224 (12V, 5W) To remove ........ Draw out slowly To replace ........ Push in
(2)
(2) Model 219 (15W) To remove ......... Push and twist to the left. To replace ......... Push and twist to the right.
9
Presser Foot Lifter The presser foot lifter raises and lowers your presser foot. (3)
You can raise it about 0.6 cm (1/4˝) higher than the normal raised position for easy removal of the presser foot or to help you place heavy fabric under it.
(3) (2)
(2)
(1) Presser foot lifter (2) Normal raised position (3) Extra lift position
(1)
1
To Remove and Attach the Presser Foot
2
Unplug the power supply before changing the presser foot. 1. Press the red button on the back of the presser foot ankle. The presser foot will drop off. 2. Place the selected presser foot so the pin on the foot lies just under the groove of the foot ankle. Lower the ankle to lock the foot in place.
(3) (1)
(2)
(1) Red button (2) Groove (3) Pin
1
To Remove and Attach the Presser Foot Ankle
(1)
1. To Remove Remove the thumb screw by turn ing the screw counterclockwise with the screwdriver.
2
(1) Thumb screw 2. To Attach Match the hole in foot ankle with the threaded hole in the presser bar. Fit the thumb screw into the hole Tighten the screw by turning it clockwise.
10
1
Changing the Needle
2 (2)
(1) (1)
1. Raise the needle by pressing the up/down needle position button and lower the presser foot. Turn off the power switch.
(3)
Loosen the needle clamp screw by turning it counterclockwise. Remove the needle from the clamp. 2. Insert the new needle into the needle clamp with the flat side to the rear. When inserting the needle into the clamp push it up as far as it will go and tighten the clamp screw firmly. (1) Needle clamp screw (2) Pin (3) Flat side of the needle
Needle and Thread Chart Needle size
Fabric
Cotton thread size
Silk thread size
No. 60 (#7) No. 70 (#10)
Fine silk Crepe de chine
70 - 80
100 - 140
No. 75 (#11) No. 80 (#12)
Poplin Pure Silk
50 - 60
80 - 100
No. 80 (#12)
Broad cloth Cotton Wool
40 - 50
60 - 70
30 - 40
50 - 60
No. 100 (#16)
Denim
30
45 - 50
Stretch needle No. 70 (#10)
Tricot
70 - 80
100 - 140
No. 90 (#14)
11
Winding the Bobbin Settting the Spool Lift up the spool pin and place the spool of thread on it with the thread coming off the spool as shown. (1)
Press the large spool holder firmly against the spool of thread with the flat side of the spool holder against the spool of the thread. (1) Large spool holder (2) Small spool holder
(2)
Removing the Bobbin Gently slide the bobbin cover plate release button to the right and remove the cover plate.
(1)
Lift out the bobbin. (1) Bobbin cover plate release button (2) Bobbin cover plate (2)
12
B (2) (1) (3) A
Winding the Bobbin
1
1. Guide the thread around the thread guide. 2. Thread through the hole in the bobbin from the inside to the outside. Put the bobbin on the bobbin winder spindle. 3. Slide it to the right.
2
Caution: Never move the bobbin winder spindle when the machine is running. 4. With the free end of the thread held in your hand, depress the foot control. Stop the machine when it has made a few turns, and cut the thread close to the hole in the bobbin. 5. Depress the foot control again. When the bobbin is fully wound, it will stop automatically. Return the bobbin winder to its original position by moving the spindle to the left, and cut the thread as shown.
3
4
To use the additional spool pin, set the felt and the spool as shown above.
5
(1) Additional spool pin (2) Felt (3) Additional spool pin hole
13
Inserting the Bobbin
1
1. Place the bobbin in the bobbin holder with the thread running counterclockwise.
2. Guide the thread into the notch A on the front side of the bobbin holder. Draw the thread to the left, sliding it between the tension spring blades.
2
A 3. Continue to draw the thread lightly until the thread slips into notch B.
3
Note: Check the threading by referring to the chart shown on the bobbin cover plate.
B
4
4. Pull out about 15 cm (6 inches) of thread and attach the bobbin cover plate.
14
Threading the Machine 1 3
4
Raise the thread take-up lever to its highest position by turning the handwheel toward you.
2
Raise the presser foot with the presser foot lifter and the thread in the order from 1 to 5 .
5
1
1. Bring the thread from the spool and it through the thread guide. Then draw it down along the right slot.
2
2. Guide the thread around the bottom of the thread guide plate from right to left, then draw it upward.
3. Firmly draw the thread from right to left over the take-up lever and down into the take-up lever eye. Then guide it down along the left slot.
3
4. Slide the thread from the left behind the needle bar thread guide.
4, 5
5. Thread the needle from front to back.
15
To Use Needle Threader (for Model 224)
1
1. Raise the needle to its highestposition. Lower the needle threader as far as it will go.
2. Push the knob in the direction of the arrow in the illustration, and insert the hook into the needle eye. Bring the thread around the guide and under the hook.
2
(1) Guide (2) Hook (1)
3
(2) 3. Push the knob in the direction of the arrow in the illustration, and draw the thread loop to the back of the needle.
4. Raise the needle threader knob slowly to draw the thread loop up. the end of the thread through the needle eye by pulling the thread loop to the back.
4
16
Drawing Up Bobbin Thread
1
1. Raise the presser foot and hold the needle thread lightly with your left hand.
2. Press the up/down needle position button twice to pick up the bobbin thread. Draw up the needle thread forming a loop of bobbin thread.
2 (2)
(1)
(1) Needle thread (2) Bobbin thread
3
3. Pull 15 cm (6 inches) of both threads back and under the presser foot.
17
Pattern Selector Dial
C
B
A
A. Recommended stitch length (Model 224) B. Set any stitch length C. Reset indication for buttonhole (Model 219)
Turn the pattern selector dial to indicate a selected pattern on the pattern indicating window.
(2)
1
(1) Pattern selector dial (2) Pattern indication window (1)
Note: Always raise the needle above the fabric and presser foot before you turn the pattern selector dial.
Stitch Length Dial The higher the number, the longer the stitch length. You can select the suitable stitch length for fabrics that you plan to sew.
(2)
(1) Stitch length dial (2) Setting mark
(1) 2
Note: Always raise the needle above the fabric and presser foot before you turn the stitch length dial.
18
Zigzag Width Control The higher the number, the wider the stitch width becomes. Note: Always raise the needle above the fabric and presser foot before you turn the zigzag width control.
Infinite Needle Position When pattern number 14 is selected and the stitch width control is activated, you can move the needle between center and left needle positions.
19
Balancing Needle Thread Tension (1)
(4)
The needle thread and the bobbin thread should interlock in the center of two layers of fabric in straight seams.
(3)
To obtain better zigzag stitches, the needle thread tension should be slightly weaker than in the case of straight sewing. The needle thread should appear slightly on the reverse side of the fabric.
(2)
(1) (2) (3) (4)
Needle thread Bobbin thread Right side Wrong side
To loosen needle thread tension Loosen the needle thread tension by moving the dial to a lower number.
To tighten needle thread tension Tighten the needle thread tension by moving the dial to a higher number.
20
(2)
(1)
Straight Stitching
(3)
(1) (2) (3) (4) (5)
14 0123456
(4) (5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
14 0 or 6 1.5 - 4 2-6 A: Zigzag foot
Starting to Sew Raise the presser foot and position the fabric next to a seam guide line on the needle plate (see page 23). Lower the needle to the point where you want to start. Lower the presser foot and pull the threads toward the back. Depress the foot control. Gently guide the fabric along the seam guide line letting the fabric feed naturally.
Changing Sewing Direction Stop the machine and bring the needle down into the fabric by pressing the up/down needle position button (or by turning the handwheel for Model 219). Raise the presser foot. Pivot the fabric around the needle to change sewing direction as desired. Lower the presser foot.
21
Finishing Sewing
1
1. To fasten the ends of seams, press the reverse button and sew several reverse stitches.
2
2. Raise the presser foot. Remove the fabric, and draw the threads to the back.
3
3. Cut the thread using the thread cutter. The threads are cut the proper length for starting the next seam.
22
Straight Stitching on Heavy Fabrics 1. Lower the needle into the fabric at the point where you wish to start sewing. Press the small black button on the zigzag foot with your left hand to lock the presser foot to the fabric. 2. Lower the presser foot with your right hand, keeping pressure on the black button with your left hand.
(1)
3. Release the black button and start sewing. (1) Black button
Seam Allowance Lines The seam guides on the needle plate and bobbin cover plate help you measure the seam width. (1) Seam allowance lines Number
15
20 1/2 5/8 3/4
Distance (cm) 1.5 2.0 1.3 1.6 1.9 (1)
Note: The numbers indicate the distance between the middle needle position and the seam allowance lines.
Turning a Square Corner Stop stitching and lower the needle when the fabric edge facing you lines up with the cornering guides as shown. Raise the presser foot and turn the fabric to line up to the edge with the 1.6 cm (5/8 inch) seam guide. Lower the presser foot and begin stitching in the new direction.
(2)
(2) Cornering guides
23
UTILITY STITCHING (1)
(2)
Zigzag Stitching
(3)
13
(1) (2) (3) (4) (5)
(4)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
13 0-6 0.5 - 3 3-5 A: Zigzag foot
(5)
Simple zigzag stitching is widely used for overcasting, applique and sewing on buttons.
(1)
(2)
(3)
Overcasting
13
(1) (2) (3) (4) (5)
(4) (5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
13 5 or 6 1-2 4-7 C: Overcast foot
This type of stitch is used on the seam allowance to prevent fabrics from fraying at raw edges. It can be used to finish a hem edge. Place the edge of the fabric next to the black guide of foot C . (6)
(6) Black guide
24
(1)
Seam/Overcast Stitch
(2)
(1) (2) (3) (4)
19
(3)
(4)
Stitch selector: Stitch width: Top thread tension: Presser foot:
* Stitch length:
19 5 or 6 4-7 C: Overcast foot Set any length
Place the edge of the fabric next to the black guide on the foot and brush guide. The wires on this foot prevent light weight fabric from rolling and creating a ridge. As you sew the needle falls off the fabric wrapping the threads around the raw edge to prevent raveling. (5) Black guide
(5)
(1)
Multiple ZigZag
(3)
(2)
12
(1) (2) (3) (4) (5)
(4)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
12 3-6 0.5 - 1.5 4-6 A: Zigzag foot
(5)
This stitch is used to finish the seam allowance on synthetics and other fabrics that tend to pucker. Place your fabric to allow a 1.6 cm (5/8 inch) seam. Trim the extra seam allowance edge after sewing as illustrated. Note: Be careful not to cut the stitches.
25
(1)
Reinforced Straight Stitch
(2)
(1) Stitch selector: (2) Stitch width: (3) Top thread tension: (4) Presser foot: * Stitch length:
16 0123456
(3)
(4)
16 0 or 6 3-6 A: Zigzag foot Set any length
This strong, durable stitch is recommended where both elasticity and strength are needed to ensure comfort and durability. Use it to reinforce areas such as crotch and armhole seams. Also use it when constructing items such as backpacks for extra reinforcement. The stitch is sewn with two stitches forward and one stitch backward, forming a seam that does not rip easily. Garments should be basted for fitting before seaming. (1)
Lightening Stitch
(2)
15
(3)
(1) Stitch selector: (2) Stitch width: (3) Top thread tension: (4) Presser foot: * Stitch length:
(4)
15 4-5 3-6 A: Zigzag foot Set any length
This stitch is used for seaming tricot and light weight knit fabrics, it permits the seam to be pressed completely flat and prevent thread breaking with stretch fabric seams. For a 1.5 cm (5/8 inch) seam, use the 2 cm (6/8 inch) marking on the needle plate. When sewing light weight knit fabrics, set the pressure dial at 1 or 2.
26
(1)
(2)
Sewing Buttons
(4)
13
(1) (2) (3) (4)
0123456
(3)
(5)
Stitch selector: Stitch width: Top thread tension: Presser foot:
(5) Feed teeth lowered * Stitch length:
13 3 - 3.5 4-7 B: Transparent buttonsewing foot Set any length
Tape the button over the placement mark. A pin can be placed on top the foot to form a shank. Before lowering the foot, test the needle swing, making sure the needle drops in each hole. Adjust the stitch width if necessary and lower the foot. Align both holes of the button with the needle swing, lower the foot and depress the foot control. Sew about 10 stitches, then pull out approximately 20 cm (8 inches) of both the needle and bobbin thread and cut. Pull the needle thread down through the hole in the button (so it is between the hole and fabric). Now, pull the needle thread firmly to draw the bobbin thread up through the fabric. Wind one thread clockwise around the shank, the other counterclockwise. Finally, tie the 2 threads together. Note: When sewing on the button is completed, raise the feed teeth.
27
(1)
(2)
Automatic Buttonhole
(3)
1
(1) (2) (3) (4) (5)
0 1
(4)
1.
(5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
1 4-6 0.5 - 1 2-5 R: Automatic buttonhole foot
* The size of buttonhole is automatically set by placing the button in the automatic buttonhole foot R. * The button holder of the foot takes a button size up to 2.5 cm (1 inch) in diameter. * Make a test buttonhole on a fabric sample duplicating the interfacing and seams of the actual garment. * Place the button on the fabric sample and mark the top and bottom to determine the position of the buttonhole. * Use interfacing on stretch fabrics. * Use stabilizer under all fabrics
(1)
(2)
2.
1. Attach the automatic buttonhole foot R. Make sure the groove on the holder catches the pin on the foot when lowering the presser foot. (1) Groove (2) Pin 2. Pull the button holder to the back, and place the button in it. Push it together tightly on the button.
(3)
(3) Button holder If the button is extremely thick, make a test buttonhole. If it is difficult to fit the button through the test buttonhole, lengthen the size by pulling back the button holder which will increase the buttonhole length. (4) Gap
(4)
28
3. Pull the buttonhole lever downward as far as it will go.
3
(5) Buttonhole lever (5)
4. Draw both threads to the left under the foot. Insert the garment under the foot, and lower the needle at the starting point.
4
Then lower the automatic buttonhole foot.
(8)
(6) (7) (8) (9)
(6) (9)
Needle thread Bobbin thread Hole Starting point
Note: Make sure there is no gap between the slider and the spring holder.
(7)
If there is a gap, the length of the rows will be different, as shown.
(10) (13)
(10) (11) (12) (13)
(12) (11)
29
Slider Spring holder Difference There should be no gap.
5. Sew slowly and stop the machine at the starting point when the buttonhole is completed.
5
Step 1: First the front bartack and left row is sewn. Step 2: Next the back bartack, a locking stitch and the right row is sewn.
6
6. Cut both needle and bobbin threads leaving about 10 cm (4 inches) of thread ends loose. Draw the needle thread to the wrong side of the fabric by pulling the bobbin thread. Then, knot the threads. Place a pin on the rear side of the bartack position so that you do not need to worry about cutting the end of the buttonhole stitch. Then cut the opening with a seam ripper.
(To sew a series of same-size buttonholes) To reset the buttonhole sewing function, select a different stitch pattern with the pattern selector dial 2, then return it to the buttonhole.
1
2
30
7. When finished, push the button hole lever up as far as it will go.
7
To adjust buttonhole stitch density. Set the stitch length dial between 0.5 and 1.0 to adjust the buttonhole stitch density.
0 1
31
(1)
(2)
Corded Buttonhole
(3)
1
(1) (2) (3) (4) (5)
1 4-6 0.5 - 1 2-5 R: Automatic buttonhole foot 1. Use the same procedure as described in automatic buttonhole sewing steps.
0 1
(4)
(5)
1
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
Note: Set the stitch width to match the thickness of the cord used. (1) With the buttonhole foot raised, hook the filler cord on the spur at the back of the buttonhole foot. (1)
Bring the ends toward you under the buttonhole foot, clearing the front end. Hook the filler cord into the forks on the front of automatic buttonhole foot R to hold them tight. Lower the needle into the garment where the buttonhole will start and lower the foot. 2. Depress the foot control gently and sew the buttonhole. Each side of the buttonhole and the bartacks will be sewn over the cord. Remove the fabric from the machine and cut the sewing threads only.
2
(2) (4) (3)
(2) Needle thread (3) Bobbin thread (4) Starting point
3
3. Pull the left end of the filler cord to tighten it. Thread the end of the cord through a darning needle, draw to the wrong side of the fabric and cut. Note: To cut the buttonhole opening, refer to the instructions on page 30.
32
(2)
(1)
Manual Buttonhole
(3)
1
(1) (2) (3) (4) (5)
0 1
(4)
(5)
1.
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
1 4-6 0.5 - 1 2-5 B: Transparent buttonhole foot
Note: If the diameter of the button is more than 2.5 cm (1 inch), a buttonhole must be made manually as follows. 1. Attach the buttonhole foot B.
2, 3
2. Pull the buttonhole lever downward as far as it will go. 3. Lower the needle into the garment where the buttonhole is to start, and lower the foot. (1) Needle thread (2) Bobbin thread (3) Starting point
(1)
(3) (2)
33
4
4. Sew the front bartack and left row, then stop the machine after sewing the desired total length of buttonhole.
5
5. Pull the buttonhole lever toward you.
6
6. Sew the back bartack and right row, then stop the machine at the starting point.
7
7. When finished, push the buttonhole lever up as far as it will go.
34
(1)
(2)
Zipper Sewing
(3)
(1) (2) (3) (4) (5)
14 0123456
(4)
(5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
14 0 1.5 - 4 3-6 E: Zipper foot
To Snap On the Zipper Foot Fit the pin on the zipper foot into the groove on the ankle. (2)
(1)
To sew the left side of the zipper Attach the zipper foot on the right-hand side. To sew the right side of the zipper Attach the zipper foot on the left-hand side.
(4)
(3)
(1) (2) (3) (4)
1
Groove Pin When the left side is sewn When the right side is sewn
Fabric Preparation (9)
(7)
1. Add 1 cm (3/8 inch) to the zipper size. This is the overall opening size. (1) (2) (3) (4) (5) (6) (7) (8) (9)
(8) (6) (3)
(4)
(2) (1)
(5)
35
Right side of fabric 1 cm (3/8 inch) Opening size Zipper size Slider Zipper teeth Zipper tape Wrong side End of opening
2. Place right sides of fabric together and sew to the end of the zipper opening. Reverse stitch to lock the stitches. Manually increase the stitch length to 4 and sew the zipper opening.
2
(10) (11) (12) (13) (14)
2 cm (3/4 inch) 11.3 cm (Stitch length) Reverse stitch End of opening Straight stitch
To Sew
1
(1)
1. Fold back the left seam allowance. Turn under the right seam allowance to form a 0.2 to 0.3 cm (1/8 inch) fold. Place the zipper teeth next to this fold and pin in place.
(3)
(2)
(4)
2. Attach the zipper foot with the pin on the right hand side. Lower the zipper foot on the top side at the bottom of the zipper so that the needle pierces the fabric next to the fold and the zipper tape. (1) Lower fabric (2) End of opening (3) Stitch line (4) 0.3 cm (1/8 inch) (5) Wrong side of fabric (6) Opening size (7) Fold (8) Basting stitch line
(6) (5)
(8)
(7)
2
(3)
(5)
36
3. Sew through all layers next to the fold. Stop just before the zipper foot reaches the slider on the zipper tape. Lower the needle slightly into the fabric. Raise the zipper foot and open the zipper. Lower the foot and stitch the remainder of the seam.
3
(9)
(9) Slider (10) 5 cm (2 inches) (10)
4
4. Close the zipper and spread the fabric flat with the right side facing up. Baste the opened fabric and zipper tape together. (11) Basting stitch (12) Zipper tape (9)
(11)
(12)
37
5. Remove the zipper foot and reattach it on its left side. Guide the edge of the foot along the zipper teeth and stitch through the garment and zipper tape. Stop about 5 cm (2 inches) from the top of the zipper.
5
(13) Remove the basting stitches (14) Reverse stitches (0.7 - 1cm) (14) (13)
6. Lower the needle slightly into the fabric, raise the foot, remove the basting stitches and open the zipper. Lower the foot and stitch the remainder of the seam, making sure the fold is even.
6
38
(1)
(2)
Blind Stitch Hemming
(3)
(1) (2) (3) (4) (5)
0123456
(4)
(5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
9 3-4 2 2-5 G: Blind hem foot
1. How to fold the fabric
1
(1) (2) (3) (4)
(2) (2)
(1) (1) (3)
Wrong side of fabric 0.4 - 0.7 cm (5/32 - 1/4 inch) Heavy weight fabric Light/Medium weight fabric
2. How to sew
(4)
When the needle comes to the left hand side, position the fabric so that the folded edge comes to the left side of the guide. Lower the presser foot.
2
3. Adjust the position of the needle swing with the stitch width button so that the needle just pierces the folded edge of the fabric when the needle comes to the left side. Sew, guiding the folded edge along the guide. (5) Guide dial (6) Guide (7) Folded edge
3 (5)
4. Open the fabric after sewing, and press flat. (8) Right side of fabric
(6) (7)
Note: For a professional looking hem, try not to let the needle pierce more than 0.2 cm (1/8 inch) into the fold. If the folded edge is pierced too far to the left side, you can not expect a good seam on the right side of the fabric.
4 (8)
39
2
3
Decorative Satin Stitch Patterns
(2)
(1) 4
5
6
(1) (2) (3) (4) (5)
(3) (4)
0
(5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
1
2-6 3-6 0.5 2-5 A: Zigzag foot
Satin stitches are used for decorative stitches on blankets, linens, tableclothes and napkins. It is also especially attractive in applique. Note: Use tear-away stabilizer under fabric. Sew a row of stitches and adjust the thread tension so the upper thread appears on the reverse side of the fabric. Test the stitch on a sample of the actual fabric first.
Stretch Stitch Patterns 15 16 17 18 19 20 21 22 23 24
(1) Stitch selector:
15 - 24 (Model 224) 15 - 19 (Model 219) (2) Stitch width: 3-6 (3) Top thread tension: 2-4 (4) Presser foot: A: Zigzag foot *Stitch length: Set any length
(1) (2)
(3) (4)
The stretch stitch does not actually stretch as it is being sewn, but is stitched in a forward and backward motion (sometimes called a reverse action stitch), so that it will expand when the fabric stretches instead of breaking. This stitch can also be used for topstitching on all fabrics Note: We recommend a stretch needle for stretch, knit or organdy fabric to prevent skipped stitches.
40
Adjusting Stretch Stitch Balance If stretch stitch patterns are uneven when sewn on a particular fabric, adjust them with the feed balance dial. (1) (2) (3) (4)
(3)
(1)
(A)
Feed balance dial Standard mark Setting mark Example: Pattern 18
(2) (4)
(B)
To Adjust distorted patterns (A) If patterns are compressed, correct by turning the dial in the direction of ( + ). (B) If patterns are drawn out, correct by turning the dial in the direction of ( - )
41
(1) 18
Smocking
(2)
(1) Stitch selector:
24
(2) Stitch width: (3) Top thread tension: (4) Presser foot: *Stitch length:
(4)
(3)
18 or 24 (Model 224) 3-6 3-5 A: Zigzag foot Set any length
With the manual stitch length at 11.3 cm (4.5 inch), sew straight lines 1 cm (3/8 inch) apart, across the area to be smocked. (1)
A looser needle thread tension will make gathering easier. Knot the threads along one edge. Pull the bobbin threads and distribute the gathers evenly. Secure the threads at the other end. Reduce the tension and pressure if necessary and sew pattern stitches between the straight seams. Pull out the gathering stitches. (1) 1 cm (3/8 inch) (1)
42
(1)
(2)
Quilting
(3)
14
(1) (2) (3) (4) (5)
0123456
(4) (5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
14 0 or 6 1.5 - 4 3-6 A: Zigzag foot
(6) Quilter (6)
(1) The quilting guide will help to keep the stitching lines straight.
(2)
Loosen the quilt guide holding screw.
(3)
Slide the quilt guide in the opening to the desired width and tighten the screw. Sew, guiding the quilt guideover the previous row of stitching. (4)
(1) (2) (3) (4)
t
43
Quilt Guide holding screw Hole Quilt Guide Distance
(1)
(2)
Pin Tucking
(3)
(1) (2) (3) (4) (5)
14 0123456
(4)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
(5)
11 5-6 2-3 6-8 G:Blind stitch hem foot
Fold the fabric with wrong sides together on the foldline. Position the fabric so that the needle pierces 0.1 to 0.2 cm (1/16 inch) inside from the folded edge and lower the presser foot. Turn the guide screw and move the sliding guide next to the folded edge. Sew guiding the folded edge along the sliding guide. Press the pin tucks to one side.
(1) (2)
(1) Guide screw (2) Sliding guide
Shell Tuck (1)
(2)
(1) Stitch selector: (2) Stitch width: (3) Stitch length: (4) Top thread tension: (5)Presser foot:
11 5-6 2 6-8 B:Transparent buttonhole foot Note: Use a lightweight fabric such as tricot. Fold and stitch on the bias.
(3)
11
(4) (5)
Set the stitch width and length as you desire. You may need to tighten the top thread slightly. Allow the needle to just clear the folded edge of the fabric when it zigzags. If you sew rows of shell stitches, space the rows 1.5 cm (5/8 inch) apart. You can sew shell stitches on knits or soft silky wovens in any direction.
44
(1)
(2)
Fagoting
(3)
(1) Stitch selector:
8, 10 20 (Model 224) (2) Stitch width: 3-6 (3) Stitch length: 1 *Set any length for pattern 20 (4) Top thread tension: 2-5 (5) Presser foot: A: Zigzag foot
10 20
(5)
(4)
Fold under each fabric edge 1.5 cm (1/2 inch) and press. Pin the two edges a tear-away stabilizer backing 0.3 cm (1/8 inch) apart. Sew slowly, guiding the fabric so the needle catches the folded edge on each side. Remove the backing when finished.
(1)
(2)
Patch Work
(3)
(1) (2) (3) (4) (5)
12
(4)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
8, 12 5-6 1 2-5 A: Zigzag foot
(5)
Sew seam and press seam allowance open. Sew pattern stitch on right side of garment centering over the seam line. (1)
(1)
(1) Right side of fabric
45
(1)
(2)
Applique
(3)
(1) (2) (3) (4) (5)
13 0123456
(4) (5)
Stitch selector: Stitch width: Stitch length: Top thread tension: Presser foot:
(6) (6) Presser Dial:
13 3-5 0.5 - 1 3-5 B:Transparent buttonhole foot 2
Baste (or fuse with iron-on fusible web) applique pieces on the fabric. Stitch around the applique making sure the needle falls along the outer edge of the applique. When sewing corners, lower the needle down into the fabric. Raise the presser foot and pivot the fabric to the right or left.
(1)
Note: When applique sewing is finished, return the pressure dial to 3.
46
CARE OF YOUR MACHINE Caution Before performing any of the following,make sure that the sewing machine is unplugged from the power source. Do not dismantle the machine other than explained on this page.
1
Cleaning the Hook Assembly Area and Feed Teeth
(1)
1. Remove the presser foot and needle. Remove the screw on the left side of the needle plate with the screwdriver supplied with the machine.
2
2. Remove the needle plate and take out the bobbin. Lift up the bobbin holder and remove it.
3
3. Brush out dust and lint.
4
4. Clean the feed teeth and hook assembly area with the lint brush.
5
5. Wipe out gently with a soft, dry cloth. Note: You may also use a vacuum cleaner.
47
Replacing the Bobbin Holder
1
1-2. Insert the bobbin holder so that the knob fits next to the stopper in the hook assembly area. (1) Knob (2) Stopper
2
(2) (1)
3
3. Insert the bobbin. Replace the needle plate, inserting the two needle plate guide pins into the holes in the needle plate. Replace the screw.
(3)
(3) Guide hole (4) Screw
(4) (3)
After cleaning, be sure to replace the needle and presser foot.
48
Troubleshooting Condition
Cause
The needle thread breaks.
1. 2. 3. 4. 5.
6. 7. 8.
The bobbin thread breaks.
1. 2. 3.
The needle breaks.
1. 2. 3. 4. 5.
Skipped stitches
1. 2. 3. 4. 5. 6.
Seam puckering
1. 2. 3. 4. 5.
Reference The needle thread is not threaded properly. The needle thread tension is too tight. The needle is bent or blunt. The needle is incorrectly inserted. The needle thread and the bobbin thread are not set properly under (drawn to the rear of ) the presser foot when sewing is starting. The fabric is not drawn to the rear when sewing is finished. The thread is too heavy or too fine for the needle. The thread is old and brittle.
Refer to page 15
The bobbin thread is not threaded properly in the bobbin holder. Lint has collected in the bobbin holder. The bobbin is damaged and doesn´t turn smoothly.
Refer to page 14
The needle is incorrectly inserted. The needle is bent or blunt. The needle clamp screw is loose. The fabric is not drawn to the rear when sewing is finished. The needle is too fine for the fabric being sewn.
Refer Refer Refer Refer
The needle is incorrectly inserted. The needle is bent or blunt. The needle and/or threads are not suitable for the work being sewn. A blue tipped needle is not being used for sewing stretch, very fine fabrics or synthetics. The needle thread is not threaded properly. The wrong needle is used.
Refer to page 11 Refer to page 11 Refer to page 11
The needle thread tension is not tight. The needle thread is not threaded properly. The needle is too heavy for the fabric being sewn. The stitch length is too long for the fabric. The presser foot pressure is not correctly adjusted.
Refer to page 20 Refer to pages 14, 15
49
Refer Refer Refer Refer
to to to to
page page page page
20 11 11 21
Refer to page 22 Refer to page 11
Refer to page 47 Change the bobbin.
to to to to
page page page page
11 11 11 22
Refer to page 11
Refer to page 11 Refer to page 15 Change the needle.
Refer to page 11 Make stitch denser. Refer to page 8
Troubleshooting, continued Condition
Cause
The fabric is not feeding smoothly.
1. 2. 3.
The feed teeth are packed with lint. The stitches are too fine. The feed teeth were not raised after being lowered.
Refer to page 47 Make stitch coarser Refer to page 9
Gathering
1. 2.
The needle thread tension is too loose. The needle is too heavy or light for the fabrics being sewn.
Refer to page 20 Refer to page 11
The machine does not work.
1. 2.
The machine is not plugged in. A thread is caught in the hook assembly area. The bobbin winder spindle is still in the winding position.
Refer to page 6 Refer to page 47 Refer to page 13
3.
Reference
Patterns are distorted.
1. 2.
The stitch is not balanced. The stitch lenght is too long or too short
Refer to page 42
The automatic buttonhole stitches are not working.
1.
The stitch density is not suitable for the fabric being sewn. Interfacing is not being used with stretch fabrics.
Refer to pages 28, 31
Noisy operation
1.
There is thread caught in the hook assembly area. Lint has built up in the bobbin holder or hook assembly are.
Refer to page 47 Refer to page 47
2.
2.
50
Refer to page 28
We reserve the right to change the machine equipment and the assortment of accessories without prior notice, or make modifications to the performance or design. Such modifications, however, will always be to the benefit of the and the product.
Please note that on disposal, this product must be safely recycled in accordance with relevant National legislation relating to electrical/electronic products. If in doubt please your retailer for guidance.
412 68 03-26D • InHouse • ©2001-2004 VSM Group AB • All rights reserved • Printed in Sweden on environmentally-friendly paper
Related Documents 543cg
Huskystar 219 224 Manual En 6b316w
December 2019 42
Huskystar 219 224 Manual En 6b316w
November 2019 50
Huskystar 219 Manual 3c535l
October 2019 49
Huskystar 207 215 Manual En 494yd
December 2019 38
224 563m6e
June 2022 0
219 4j2h57
July 2020 4More Documents from "ljubica" 613433
Huskystar 219 224 Manual En 6b316w
December 2019 42
Skdd 2b4f3k
August 2021 0
Table Of Upper Limb Muscles 1c731c
November 2019 129
