Software Upgrade Guideline
Secret
HUAWEI Y300-0100 V100R001C76B187 Software Upgrade Guideline
Prepared by
Y300-0100 Team
Date
2013-05-02
Reviewed by
Y300-0100 Team
Date
2013-05-02
Approved by
Y300-0100 Team
Date
2013-05-02
Huawei Technologies Co., Ltd. All rights reserved
2013-5-20
Huawei confidential, no spreading without permission
Page 1, Total7
Software Upgrade Guideline
Secret
Contents
1
2
VERSION INTRODUCTION ....................................................................................................... 3 1.1
THE FOLLOWING VERSIONS CAN BE UPGRADED. ....................................................................... 3
1.2
UPGRADE PREREQUISITE ........................................................................................................... 3
1.3
UPGRADE FILES ........................................................................................................................ 3
UPGRADE PREPARATION ........................................................................................................ 3 2.1
CHECK CURRENT UPGRADE ENVIRONMENT .............................................................................. 3
2.2
GET AND CHECK THE SOFTWARE PACKAGE............................................................................... 3
3
UPGRADE INTRODUCTION ..................................................................................................... 3
4
UPGRADE OPERATIONS ........................................................................................................... 4
5
6
4.1
NORMAL UPGRADE ................................................................................................................... 4
4.2
FORCE UPGRADE ....................................................................................................................... 5
UPGRADE VALIDATE ................................................................................................................ 6 5.1
CHECK THE VERSION ................................................................................................................ 6
5.2
BASIC FUNCTION CHECK ........................................................................................................... 7
NOTES ............................................................................................................................................ 7 6.1
NOTES 1.................................................................................................................................... 7
6.2
NOTES 2.................................................................................................................................... 7
2013-5-20
Huawei confidential, no spreading without permission
Page 2, Total7
Software Upgrade Guideline
Secret
1 Version introduction 1.1
The following versions can be upgraded. Versions can be upgraded
Y300-0100V100R001C00B175 1.2
Upgrade prerequisite The Y300-0100 handset software should be updated with the MICRO SD card.
1.3
Upgrade files File Name
Software: main package
Date
dload\UPDATE.APP
May 2,2013
Size 1,130,021 KB
MICRO SD card
Update tools
2 Upgrade preparation 2.1
Check current upgrade environment Make sure that the MICRO SD card is available and can be read and write.
2.2
Get and check the software package There are two software package: main package and vendor package.
3 Upgrade introduction There are two methods to upgrade: normal upgrade and force upgrade. Normal upgrade needs to start the handset and enter the Setting module. Force upgrade is often used when the handset can’t boot up or can’t enter the idle screen.
2013-5-20
Huawei confidential, no spreading without permission
Page 3, Total7
Software Upgrade Guideline
Secret
4 Upgrade operations 4.1
Normal upgrade
Step 1. A MICRO SD card of 2GB or more should be available. The MICRO SD card made by Sandisk, Kingstone, or Kingmax is recommended. Step 2. Format the MICRO SD card (This operation is optional). Step 3. Copy the Software: main package to a directory named dload. Step 4. Copy the entire dload folder (with UPDATE.APP in it) to the root directory of the MICRO SD card. Step 5. Insert the MICRO SD card into the handset and power on. After entering the home screen, find System Update application, press System Update->Update via SD card to start the upgrade. Reference to the following pictures
2013-5-20
Huawei confidential, no spreading without permission
Page 4, Total7
Software Upgrade Guideline
Secret
Step 6. When the progress bar stop, the phone will restart, if not you need to remove the battery manually.
Step 7. Copy the Software:vendor package to a directory named dload. Then Execute Step 4 – Step6 repeatedly.
4.2
Force upgrade Step 1. A MICRO SD card of 2G or more should be available. The MICRO SD card made by Sandisk, Kingstone, or Kingmax is recommended. 2013-5-20
Huawei confidential, no spreading without permission
Page 5, Total7
Software Upgrade Guideline
Secret
Step 2. Format the MICRO SD card (This operation is optional). Step 3. Copy the Software: main package to a directory named dload. Step 4. Copy the entire dload folder (with UPDATE.APP in it) to the root directory of the MICRO SD card. Step 5. Make sure your handset is power off. Insert the MICRO SD card into the handset. Press the VOLUME UP and VOLUME DOWN key, and then press the POWER key to power on the phone and enter the Software Upgrade Mode. Step 6. When the progress bar stop, the phone will restart, if not, you need to remove the battery manually.
Step 7. Copy the Software:vendor package to a directory named dload. Then Execute Step 4 – Step6 repeatedly.
5 Upgrade validate 5.1
Check the version
1. By Settings->About phone->Build number, to check the version. Just like
2013-5-20
Huawei confidential, no spreading without permission
Page 6, Total7
Software Upgrade Guideline
Secret
Y300-0100V100R001C76B187 5.2
Basic function check Switch on the handset, enter the idle screen, input a dial number and make a voice
call, then long press the power key to power off the handset.
6 Notes 6.1
Notes 1 To make sure that the power of the battery is enough to run the upgrade process.
Maybe you can connect the handset with the charger or the USB data cable to provide power. 6.2
Notes 2 Upgrade operations will erase the data, so if there is something very important,
recommend you to backup them. 2013-5-20
Huawei confidential, no spreading without permission
Page 7, Total7
