EXPERIMENT 8 FIELD MEASUREMENT OF DRY UNIT WEIGHT AND MOISTURE CONTENT I.

INTRODUCTION: Applicable ASTM Standards ASTM D1556: Standard Test Method for Density and Unit Weight of Soil in Place by the Sand-Cone Method ASTM D2167: Standard Test Method for Density and Unit Weight of Soil in Place by Rubber Balloon Method Purpose of Measurement The sand-cone and rubber balloon tests are destructive in situ field tests used to measure the total unit weight (γ) of compacted earth materials. When accompanied with moisture content (ω) measurements of the same material, the sand cone and rubber balloon tests can be used to measure both w and dry unit weight (γd) to confirm that the earth materials are compacted in accordance with construction specifications. Definitions and Theory Overview When soil is used to construct highway subgrades and base courses, waste containment liners, earth dams, embankments, and other purposes, the soil must be compacted in accordance with construction specifications. Specifications for compacted soil are typically given in of an acceptable range of moisture content (w) and/or dry unit weight (γd) based on results of laboratory compaction tests (ASTM D698 and D1557). To confirm that soil is compacted in accordance with construction specifications, γ and w of representative samples of compacted soil are measured as part of a Construction Quality Assurance (CQA) plan. A CQA plan specifies the type and frequency of laboratory or field tests to be performed on the soil, as well as acceptance criteria. Moisture content and dry unit weight are often specified. Given γ and w, γd is expressed as:

where w is expressed as a decimal. To measure γ and ω in situ, a small hole (on the order of 0.1 ft3) is excavated at the surface of a compacted layer of soil. The soil is removed, and its moisture content is measured using a standard method such as ASTM D2216. The mass of the soil, Mwet, is also recorded. Equation 9.1 can be rewritten in of ω and Mwet:

where g is the gravitational constant (i.e. 9.81 m/s2), and V is the volume of the hole. Therefore, any method that provides a means to measure V will be useful in deriving γd for CQA purposes when accompanied with moisture content measurements of the material removed from the hole. There are two such methods commonly used today: the sand cone method (ASTM D1556) and the rubber balloon method (ASTM D2167). Each method is described in the following sections. Sand Cone Method The sand cone method employs the use of poorly graded sand that, when poured out of a container through funnel into a hole, fills the hole at a known, precalibrated value for γd. By weighing the container before and after the hole is filled, the volume of the hole can be calculated based on the calibrated value for γd. The sand cone device is illustrated below. The device consists of a sand container, funnel, and sand. The sand must be a clean, dry, poorly graded sand with a coefficient of uniformity (Cu = D60/D10) less than 2.0, a maximum particle size (D100) less than 2.0 mm, and less than 3% by weight ing the #60 (250 μm) sieve. The sand should consist of rounded or subrounded particles rather than angular particles. The sand should be stored in an airtight container between tests so that it remains dry.

Sand cone device. Parts include A) base plate, B) funnel, and C) sand container Equipment and Materials for Sand Cone Test The following equipment and materials are required for performing the sand cone test:      

II.

Small digging tools (e.g. shovels, trowels, chisels, etc.); large sealable plastic bag or airtight container; poorly graded subrounded to rounded sand; sand cone device, including container and funnel; scale capable of measuring to the nearest 1.0 g; and base plate. PROCEDURE:

Sand Cone Test Calibration of the Sand Cone Device Since the results of sand cone testing are highly dependent upon the particular sand cone device and type of sand used, it is very important to calibrate the device. The procedure for calibrating the device is as follows: 1) Fill the sand cone container with dry sand and place the funnel on the container. Record the mass of the filled sand cone device, M6. 2) Place the base plate on a clean, flat surface and place the inverted sand cone device over the base plate. Open the valve in the funnel and allow the sand to fill the base plate and funnel. Close the valve after the base plate and funnel are filled. Remove the sand cone device from the base plate and record the mass of the device with the remaining sand, M7.

3) Calculate the mass of the sand in the base plate and funnel, M2: M2 = M6 – M7 4) Refill the container and obtain the mass of the refilled device (M 8). Place the base plate over a calibration container of known volume. Many base plates are machined to snugly fit over a proctor mold with a known volume, V 1, of either 1/13.33 or 1/30 ft3, so a proctor mold may be used to facilitate the calibration. 5) Place the inverted sand cone device over the base plate, open the valve, and fill the base plate, funnel, and calibration chamber with sand. After the calibration chamber, base plate, and funnel are filled, close the valve. Remove the sand cone device from the base plate and weigh the sand cone device with the remaining sand, M9. 6) Calculate the mass of the sand in the calibration chamber, M5: M5 = M8 – M9 – M2 7) Calculate the total unit weight of the sand, γ1:

where g is the gravitational constant. Performing a Sand Cone Measurement Once the sand and sand cone device have been calibrated using the procedure described in the previous section, sand cone measurements can be performed using the following procedure: 1) Fill the sand cone device with the same type of sand used for the calibration. Obtain the mass of the filled sand cone, M10. 2) Locate a flat, level spot on the surface of the material to be tested. Place the base plate on the surface. 3) Excavate a test hole through the center of the base plate. The minimum test hole volume is dependent upon the maximum particle size as described in Table 1. The shape of the test hole should approximate the shape of the calibration chamber. The base plate should not overhang the test hole, and the bottom of the test hole should be flat or concave upward. Place the excavated soil in a sealed plastic bag to use for measurement of moisture content later as shown in Figure 1.

Figure 1. Excavation of a Test Hole

Table 1. Minimum test hole volume based on maximum particle size

4) Position the filled sand cone device over the excavated test hole. Open the valve and fill the test hole, base plate, and funnel with sand. Do not perform the test if there are significant ambient vibrations (e.g. heavy equipment operation), and take care not to move or shake the device during filling. After filling, close the valve and measure the mass of the sand cone with the remaining sand, M11. 5) Calculate the mass of the sand used to fill the test hole, funnel, and base plate, M1: M1 = M10 – M11 6) Calculate volume of the test hole, V:

7) Record the moist mass of the material excavated from the test hole, M3. 8) Dry the soil in an oven using the methods described in ASTM D2216 to obtain the dry mass of the soil, M4. Calculate the moisture content of the material, ω:

9) Calculate the dry unit weight, γd, of the soil:

Expected Results Dry unit weight can range from 12.20 to 21.65 kN/m3 for compacted soils. For projects that involve soil compaction, specifications typically state that soil should be compacted to within 90% of maximum dry unit weight for standard or modified proctor compaction effort. Maximum dry unit weight is typically around 18-20.5 kN/m3 for standard and modified proctor compaction effort, respectively. Shown in Table 2 are the soil dry unit weights according to its type of soil.

Table 2. Typical values of soil dry unit weights Soil Type γ (lb/ft3) γsat (lb/ft3) Sand, loose and uniform 90 118 Sand, dense and uniform 109 130 sand, loose and well graded 99 124 Sand, dense and well graded 116 135 glacial clay, soft 76 110 glacial clay, stiff 106 125

III.

DATA AND RESULTS

Calibration

Measurement

Weight of the cylindrical mold (kg)

Mass of filled device

Weight of the mold w/ Ottawa sand (kg)

Mass of device after filling base plate funnel and test hole

Weight of Ottawa sand (kg)

Mass of sand in the base pate, funnel and test hole

Height of the mold (mm)

Volume of test hole

Diameter of the mold (mm)

Mass of moist material excavated from the test hole

Volume of the mold (mm3)

Dry mass of material excavated from the test hole

Dry unit (KN/m3)

weight

Moisture Content

of

Ottawa

sand

Dry unit Weight

IV.

EQUATIONS AND CALCULATION SPACE

V.

ILLUSTRATIONS

Figure. 8.1 Borrowed the materials needed for the experiment.

Figure. 8.2 Measuring the inner diameter of the cylindrical mold.

Figure. 8.3 Measuring the height of the cylindrical mold.

Figure. 8.4 Weighing the mass of the cylindrical mold.

Figure. 8.5 Weighing the weight of the cone.

Figure. 8.6 Weighing the mass of the container with Ottawa sand.

Figure. 8.7 Measuring the mass of the empty can (1).

Figure. 8.8 Measuring the mass of the empty can (2).

Figure. 8.9 Measuring the mass of the empty can (3).

Figure. 8.10 Pouring the Ottawa sand in the cylindrical mold.

Figure. 8.11 Cylindrical mold filled with Ottawa sand.

Figure. 8.12 Weighing the mass of cylindrical mold filled with Ottawa sand.

Figure. 8.13 Excavating the soil inside the steel plate.

Figure. 8.14 Filling the excavated soil with the Ottawa sand.

Figure. 8.15 Excavated soil filled with Ottawa sand.

Figure. 8.16 Measuring the mass of the Ottawa sand that filled the excavated soil.

Figure. 8.17 Measuring the mass of the cone with the Ottawa sand.

Figure. 8.18 Getting three 50g of soil collected from the excavation.

Figure. 8.20 Drying the soil using the stove

Figure. 8.23 Weighing the mass of container 3 w/ dry soil.

Figure. 8.21 Weighing the mass of container 1 w/ dry soil.

Figure. 8.22 Weighing the mass of container 2 w/ dry soil.

Figure. 8.24 Group picture after performing experiment.

VI.

OBSERVATION

_______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ ______________________________________________________________________

VII.

CONCLUSION

_______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________

VIII. RECOMMENDATION _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________
