A58MD / A58MG / A58ML Setup Manual

FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. There is no guarantee that interference will not occur in a particular installation.

The vendor makes no representations or warranties with respect to the contents here and specially disclaims any implied warranties of merchantability or fitness for any purpose. Further the vendor reserves the right to revise this publication and to make changes to the contents here without obligation to notify any party beforehand. Duplication of this publication, in part or in whole, is not allowed without first obtaining the vendor’s approval in writing.

The content of this ’s manual is subject to be changed without notice and we will not be responsible for any mistakes found in this ’s manual. All the brand and product names are trademarks of their respective companies.

Dichiarazione di conformità sintetica Ai sensi dell’art. 2 comma 3 del D.M. 275 del 30/10/2002 Si dichiara che questo prodotto è conforme alle normative vigenti e soddisfa i requisiti essenziali richiesti dalle direttive 2004/108/CE, 2006/95/CE e 1999/05/CE quando ad esso applicabili

Short Declaration of conformity We declare this product is complying with the laws in force and meeting all the essential requirements as specified by the directives 2004/108/CE, 2006/95/CE and 1999/05/CE whenever these laws may be applied

Table of Contents Chapter 1: Introduction ...............................................................1 1.1 1.2 1.3 1.4 1.5

Before You Start......................................................................... 1 Package Checklist ..................................................................... 1 Motherboard Specifications ....................................................... 2 Rear Connectors ............................................................. 3 Motherboard Layout .................................................................. 4

Chapter 2: Hardware Installation ................................................5 2.1 2.2 2.3 2.4 2.5 2.6 2.7

Install Central Processing Unit (U) ....................................... 5 Install a Heatsink ....................................................................... 5 Connect Cooling Fans ............................................................... 7 Install System Memory .............................................................. 8 Expansion Slots ....................................................................... 10 Jumper Setting .........................................................................11 Headers & Connectors ............................................................ 12

Chapter 3: UEFI BIOS & Software.............................................16 3.1 3.2 3.3

UEFI BIOS Setup .................................................................... 16 BIOS Update ........................................................................... 16 Software................................................................................... 21

Chapter 4: Useful Help ..............................................................24 4.1 4.2 4.3 4.4 4.5

Driver Installation..................................................................... 24 AMI BIOS Beep Code.............................................................. 25 Troubleshooting ....................................................................... 25 RAID Functions ....................................................................... 26 AMD DUAL Graphics Technology ........................................... 28

Appendix: Specifications In Other Languages .......................30 Arabic ......................................................................................................... 30 French ........................................................................................................ 32 German....................................................................................................... 34 Italian .......................................................................................................... 36 Japanese .................................................................................................... 38 Polish.......................................................................................................... 40 Portuguese ................................................................................................. 42 Russian....................................................................................................... 44 Spanish....................................................................................................... 46

A58MD/A58MG/A58ML

CHAPTER 1: INTRODUCTION 1.1

Before You Start

Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: „ Prepare a dry and stable working environment with sufficient lighting. „ Always disconnect the computer from power outlet before operation. „ Before you take the motherboard out from anti-static bag, ground yourself properly by touching any safely grounded appliance, or use grounded wrist strap to remove the static charge. „ Avoid touching the components on motherboard or the rear side of the board unless necessary. Hold the board on the edge, do not try to bend or flex the board. „ Do not leave any unfastened small parts inside the case after installation. Loose parts will cause short circuits which may damage the equipment. „ Keep the computer from dangerous area, such as heat source, humid air and water. „ The operating temperatures of the computer should be 0 to 45 degrees Celsius. „ To avoid injury, be careful of: Sharp pins on headers and connectors Rough edges and sharp corners on the chassis Damage to wires that could cause a short circuit

1.2

Package Checklist ; ; ; ;

Serial ATA Cable x2 Rear I/O for ATX Case x1 Installation Guide x1 Fully Setup Driver DVD x1

Note: The package contents may be different due to the sales region or models in which it was sold. For more information about the standard package in your region, please your dealer or sales representative.

1

Motherboard Manual

1.3

Motherboard Specifications Specifications Socket FM2+/FM2 for AMD A-series processor

U

Maximum U TDP (Thermal Design Power): 100Watt

Chipset

AMD A55 FCH

* Please refer to www.biostar.com.tw for U list. s Dual Channel DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/ 2400(OC)/ 2600(OC) Memory

2 x DDR3 DIMM Memory Slot, Max. s up to 32 GB Memory Each DIMM s non-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB DDR3 module * Please refer to www.biostar.com.tw for Memory list. AMD A55 FCH

Storage

4x SATA 3Gb/s Connector s RAID 0,1,10 & AHCI Realtek RTL 8111G (A58MD, A58MG)

LAN

10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability Realtek RTL 8106E (A58ML) 10/ 100 Mb/s auto negotiation, Half / Full duplex capability

Audio Codec USB Expansion Slots

ALC662 5.1 Channels, High Definition Audio AMD A55 FCH 8x USB 2.0 port (4 on rear I/Os and 4 via internal headers) 1x PCIe x1 Slot 1x PCIe 3.0 x16 Slot (Only FM2+ processors can PCIe 3.0.) 1x PS/2 Mouse 1x PS/2 Keyboard 1x VGA Port

Rear I/Os

1x DVI Port (A58MD) 1x LAN port 4x USB 2.0 Port 3x Audio Jack 4x SATA 3.0Gb/s Connector 2x USB 2.0 Header (each header s 2 USB 2.0 ports) 1x 4-Pin Power Connector 1x 24-Pin Power Connector 1x U Fan Connector

Internal I/Os

1x System Fan Connector 1x Front Header 1x Front Audio Header 1x Clear CMOS Header 1x Serial Port Header 1x Chassis Speaker Header

Form Factor

microATX Form Factor, 218 mm x 174 mm Windows XP / 7 / 8

OS

Biostar reserves the right to add or remove for any OS with or without notice.

2

A58MD/A58MG/A58ML

1.4

Rear Connectors A58MD

A58MG/ A58ML

Note 1: Note 2: Note 3:

Note 4:

DVI-D / VGA Output require an AMD family processor with intedrated graphics. The mainboard s two independent display outputs. (A58MD) Since the audio chip s High Definition Audio Specification, the function of each audio jack can be defined by software. The input / output function of each audio jack listed above represents the default setting. However, when connecting external microphone to the audio port, please use the Line In (Blue) and Mic In (Pink) audio jack. Maximum resolution: Outputs DVI-D VGA

Maximum resolution 1920 x 1200 @60Hz 2560 x 1600 @60Hz 1920 x 1600 @60Hz

Bit Depth 30 bpp 24 bpp --

3

Motherboard Manual

1.5

Motherboard Layout

Note: ■ represents the 1st pin.

4

A58MD/A58MG/A58ML

CHAPTER 2: HARDWARE INSTALLATION 2.1

Install Central Processing Unit (U)

Step 1: Locate the U socket on the motherboard

Step 2: Pull the socket locking out from the socket and then raise the lever up to a 90-degree angel.

Step 3: Look for the white triangle on socket, and the gold triangle on U should point towards this white triangle. The U will fit only in the correct orientation.

5

Motherboard Manual Step 4: Hold the U down firmly, and then close the lever to locked the position

2.2

Install a Heatsink

Step 1: Place the heatsink and fan assembly onto the retention frame. Match the heatsink clip with the socket mounting-lug. Hook the spring clip to the mounting-lug.

Step 2: On the other side, push the retention clip straight down to lock into the plastic lug on the retention frame, and then press down the locker until it stops.

Note1: Do not forget to connect the U fan connector. Note2: For proper installation, please kindly refer to the installation manual of your U heatsink. 6

A58MD/A58MG/A58ML

2.3

Connect Cooling Fans

These fan headers cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.

U_FAN1: U Fan Header

Pin 1 2 3 4

Assignment Ground +12V FAN RPM rate sense Smart Fan Control(By Fan)

SYS_FAN1: System Fan Header

Pin 1 2 3

Assignment Ground +12V FAN RPM rate sense

Note: U_FAN1, SYS_FAN1 4-pin and 3-pin head connectors. When connecting with wires onto connectors, please note that the red wire is the positive and should be connected to pin#2, and the black wire is Ground and should be connected to GND.

7

Motherboard Manual

2.4

Install System Memory

A. DDR3 Modules

Step 1: Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot.

Step 2: Insert the DIMM vertically and firmly into the slot until the retaining clips snap back in place and the DIMM is properly seated.

Note: If the DIMM does not go in smoothly, do not force it. Pull it all the way out and try again.

8

A58MD/A58MG/A58ML

B. Memory Capacity DIMM Socket Location

DDR3 Module

DDR3_A1

512MB/1GB/2GB/4GB/8GB/16GB

DDR3_B1

512MB/1GB/2GB/4GB/8GB/16GB

Total Memory Size Max is 32GB.

C. Dual Channel Memory Installation Please refer to the following requirements to activate Dual Channel function: Install memory module of the same density in pairs, shown in the table. Dual Channel Status

DDR3_A1

DDR3_B1

Disabled

O

X

Disabled

X

O

Enabled

O

O

(O means memory installed, X means memory not installed.) Note: The DRAM bus width of the memory module must be the same (x8 or x16)

9

Motherboard Manual

2.5

Expansion Slots

PEX16_1: PCI-Express Gen3 x16 Slot -

PCI-Express 3.0 compliant. Maximum theoretical realized bandwidth of 16GB/s simultaneously per direction, for an aggregate of 32GB/s totally. Only FM2+ processors can PCIe 3.0.

PEX1_1: PCI-Express Gen2 x1 Slot -

PCI-Express 2.0 compliant. Data transfer bandwidth up to 500MB/s per direction; 1GB/s in total

Install an Expansion Card You can install your expansion card by following steps: 1. Read the related expansion card's instruction document before install the expansion card into the computer. 2. Remove your computer's chassis cover, screws and slot bracket from the computer. 3. Place a card in the expansion slot and press down on the card until it is completely seated in the slot. 4. Secure the card’s metal bracket to the chassis back with a screw. 5. Replace your computer's chassis cover. 6. Power on the computer, if necessary, change BIOS settings for the expansion card. 7. Install related driver for the expansion card.

10

A58MD/A58MG/A58ML

2.6

Jumper Setting

The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”.

Pin opened

Pin closed

Pin1-2 closed

JCMOS1: Clear CMOS Header Placing the jumper on pin2-3, it allows to restore the BIOS safe setting and the CMOS data. Please carefully follow the procedures to avoid damaging the motherboard.

1

3

Pin 1-2 Close: Normal Operation (default).

1

3

Pin 2-3 Close: Clear CMOS data.

※ Clear CMOS Procedures: 1. 2. 3. 4.

5. 6.

Remove AC power line. Set the jumper to “Pin 2-3 close”. Wait for five seconds. Set the jumper to “Pin 1-2 close”. Power on the AC. Load Optimal Defaults and save settings in CMOS.

11

Motherboard Manual

2.7

Headers & Connectors

ATXPWR1: ATX Power Source Connector For better compatibility, we recommend to use a standard ATX 24-pin power supply for this connector. Make sure to find the correct orientation before plugging the connector.

Pin 13 14 15 16 17 18 19 20 21 22 23 24

Assignment +3.3V -12V Ground PS_ON Ground Ground Ground NC +5V +5V +5V Ground

Pin 1 2 3 4 5 6 7 8 9 10 11 12

Assignment +3.3V +3.3V Ground +5V Ground +5V Ground PW_OK Standby Voltage+5V +12V +12V +3.3V

ATXPWR2: ATX Power Source Connector This connector will provide +12V to U power circuit. Pin 1 2 3 4

Assignment +12V +12V Ground Ground

Note1: Before you power on the system, please make sure that both ATXPWR1 and ATXPWR2 connectors have been plugged-in. Note2: Insufficient power supplied to the system may result in instability or the peripherals not functioning properly. Use of a PSU with a higher power output is recommended when configuring a system with more power-consuming devices.

12

A58MD/A58MG/A58ML

J1: Front Header This connector includes Power-on, Reset, HDD LED and Power LED connections. It allows to connect the PC case’s front switch functions.

Pin

Assignment

1

N/A

3

HDD LED(+)

5

HDD LED(-)

7

Ground

9

Reset Control

Function N/A HDD LED

Reset Button

Pin

Assignment

2

Power LED (+)

4

Power LED (+)

6

Power LED (-)

8

Power Button

10

Ground

Function

Power LED

Power-On Button

JSPKR1: Chassis Speaker Header Please connect the chassis speaker to this header.

Pin

Assignment

1

+5V

2

N/A

3

N/A

4

Speaker

13

Motherboard Manual

SATA1~SATA4: Serial ATA 3.0 Gb/s Connectors These connectors connect to SATA hard disk drives via SATA cables.

Pin 1 2 3 4 5 6 7

Assignment Ground TX+ TXGround RXRX+ Ground

F_USB1/F_USB2: Headers for USB 2.0 Ports at Front This header allows to connect additional USB cable on the PC front , and also can be connected with a wide range of simultaneously accessible external Plug and Play peripherals. Pin 1 2 3 4 5 6 7 8 9 10

14

Assignment +5V (fused) +5V (fused) USBUSBUSB+ USB+ Ground Ground NC Key

A58MD/A58MG/A58ML

F_AUDIO1: Front Audio Header This header allows to connect the front audio output cable with the PC front . This header s HD and AC’97 audio front connector.

Pin 1 2 3 4 5 6 7 8 9 10

HD Audio Assignment Mic Left in Ground Mic Right in GPIO Right line in Jack Sense Front Sense Key Left line in Jack Sense

Pin 1 2 3 4 5 6 7 8 9 10

AC’97 Assignment Mic In Ground Mic Power Audio Power RT Line Out RT Line Out Reserved Key LFT Line Out LFT Line Out

Note1: It is recommended that you connect a high-definition front audio module to this connector to avail of the motherboard's high definition audio capability. Note2: Please try to disable the "Front Jack Detection" if you want to use an AC'97 front audio output cable. The function can be found via O.S. Audio Utility.

J_COM1: Serial Port Connector The motherboard has a Serial Port Connector for connecting RS-232 Port. Pin

Assignment

1 2 3 4 5 6 7 8 9 10

Carrier detect Received data Transmitted data Data terminal ready Signal ground Data set ready Request to send Clear to send Ring indicator NC

15

Motherboard Manual

CHAPTER 3: UEFI BIOS & SOFTWARE 3.1 „

„

3.2

UEFI BIOS Setup For better system performance, the UEFI BIOS firmware is being continuously updated. The UEFI BIOS information described below in this manual is for your reference only and the actual UEFI BIOS information and settings on board may be different from this manual For further information of setting up the UEFI BIOS, please refer to the UEFI BIOS Manual in the Setup DVD.

BIOS Update There are three ways to update the BIOS: BIOS Update Utility, BIOS Online Update Utility and BIOS Flasher.

1. BIOS Update Utility 1. Installing BIOS Update Utility from the DVD Driver. 2. the proper BIOS from www.biostar.com.tw .

3. Open BIOS Update Utility and click the Update BIOS button on the main screen.

4. A warning message will show up to request your agreement to start the BIOS update. Click OK to start the update procedure.

5. Choose the location for your BIOS file in the system. Please select the proper BIOS file, and then click on Open. It will take several minutes, please be patient.

16

A58MD/A58MG/A58ML 6. After the BIOS Update process is finished, click on OK to reboot the system.

7. While the system boots up and the full screen logo shows up, please press the

key to enter BIOS setup.

After entering the BIOS setup, please go to the Save & Exit, using the Restore Defaults function to load Optimized Defaults, and select Save Changes and Reset to restart the computer. Then, the BIOS Update is completed.

Backup BIOS Click the Backup BIOS button on the main screen for the backup of BIOS, and select a proper location for your backup BIOS file in the system, and click Save.

17

Motherboard Manual

2. Online Update Utility 1. Installing BIOS Update Utility from the DVD Driver. 2. Please make sure the system is connected to the internet before using this function.

3. Open BIOS Update Utility and click the Online Update button on the main screen.

4. An open dialog will show up to request your agreement to start the BIOS update. Click Yes to start the online update procedure.

5. If there is a new BIOS version, the utility will ask you to it. Click Yes to proceed.

6. After the is completed, you will be asked to program (update) the BIOS or not. Click Yes to proceed.

7. After the updating process is finished, you will be asked you to reboot the system. Click OK to reboot.

18

A58MD/A58MG/A58ML 8. While the system boots up and the full screen logo shows up, press key to enter BIOS setup. After entering the BIOS setup, please go to the Save & Exit, using the Restore Defaults function to load Optimized Defaults, and select Save Changes and Reset to restart the computer. Then, the BIOS Update is completed.

3. BIOSTAR BIOS Flasher BIOSTAR BIOS Flasher is a BIOS flashing utility providing you an easy and simple way to update your BIOS via USB pen drive. Note1: This utility only allows storage device with FAT32/16 format and single partition. Note2: Shutting down or resetting the system while updating the BIOS will lead to system boot failure.

The BIOSTAR BIOS Flasher is built in the BIOS ROM. To enter the utility, press during the Power-On Self Tests (POST) procedure while booting up. Updating BIOS with BIOSTAR BIOS Flasher 1. Go to the website to the latest BIOS file for the motherboard. 2. Then, copy and save the BIOS file into a USB flash (pen) drive. 3. Insert the USB pen drive that contains the BIOS file to the USB port. 4. Power on or reset the computer and then press during the POST process.

5. After entering the POST screen, the BIOS-FLASHER utility pops out. Choose [fs0] to search for the BIOS file.

19

Motherboard Manual

6. Select the proper BIOS file, and a message asking if you are sure to flash the BIOS file. Click Yes to start updating BIOS.

7. A dialog pops out after BIOS flash is completed, asking you to restart the system. Press the [Y] key to restart system.

8. While the system boots up and the full screen logo shows up, press key to enter BIOS setup. After entering the BIOS setup, please go to the Save & Exit, using the Restore Defaults function to load Optimized Defaults, and select Save Changes and Reset to restart the computer. Then, the BIOS Update is completed.

20

A58MD/A58MG/A58ML

3.3

Software

Installing Software 1. Insert the Setup DVD to the optical drive. The driver installation program would appear if the Autorun function has been enabled. 2. Select Software Installation, and then click on the respective software title. 3. Follow the on-screen instructions to complete the installation. Note1: All the information and content about following software are subject to be changed without notice. For better performance, the software is being continuously updated. Note2: The information and pictures described below are for your reference only. The actual information and settings on board may be slightly different from this manual.

Launching Software After the installation process is completed, you will see the software icon showing on the desktop. Double-click the icon to launch it.

eHot-Line eHot-Line is a convenient utility that helps you to with our Tech- system. This utility will collect the system information which is useful for analyzing the problem you may have encountered, and then send these information to our tech- department to help you fix the problem. Note: Before you use this utility, please set Outlook Express as your default e-mail client application program. represents important information that you must provide. Without this information, you may not be able to send out the mail.

*

This block will show the information which would be collected in the mail.

condition *Describe of your system.

your area or *Select the area close to you. Provide the e-mail address that you would like to send the copy to. the name of *Provide the memory module manufacturer.

Provide the name of the power supply manufacturer and the model no. Send the mail out.

Exit this dialog.

Save these information to a .txt file

21

Motherboard Manual

After filling up this information, click “Send” to send the mail out. A warning dialog would appear asking for your confirmation; click “Send” to confirm or “Do Not Send” to cancel.

If you want to save this information to a .txt file, click “Save As…” and then you will see a saving dialog appears asking you to enter file name.

Enter the file name and then click “Save”. Your system information will be saved to a .txt file.

Open the saved .txt file, you will see your system information including motherboard/BIOS/U/video/ device/OS information. This information is also concluded in the sent mail.

Note1: We will not share customer’s data with any other third parties, so please feel free to provide your system information while using eHot-Line service. Note2: If you are not using Outlook Express as your default e-mail client application, you may need to save the system information to a .txt file and send the file to our tech with other e-mail application. Go to the following web http://www.biostar.com.tw/app/en/about/.php for getting our information.

22

A58MD/A58MG/A58ML

BIOScreen Utility This utility allows you to personalize your boot logo easily. You can choose BMP as your boot logo so as to customize your computer.

Please follow the step-by-step instructions below to update boot logo: z

Load Image：Choose the picture as the boot logo.

z

Transform：Transform the picture for BIOS and preview the result.

z

Update Bios：Write the picture to BIOS Memory to complete the update

23

Motherboard Manual

CHAPTER 4: USEFUL HELP 4.1

Driver Installation

After you installed your operating system, please insert the Fully Setup Driver DVD into your optical drive and install the driver for better system performance. You will see the following window after you insert the DVD

The setup guide will auto detect your motherboard and operating system. Note: If this window didn’t show up after you insert the Driver DVD, please use file browser to locate and execute the file SETUP.EXE under your optical drive.

A. Driver Installation To install the driver, please click on the Driver icon. The setup guide will list the compatible driver for your motherboard and operating system. Click on each device driver to launch the installation program.

B. Software Installation To install the software, please click on the Software icon. The setup guide will list the software available for your system, click on each software title to launch the installation program.

C. Manual Aside from the paperback manual, we also provide manual in the Driver DVD. Click on the Manual icon to browse for available manual. Note: You will need Acrobat Reader to open the manual file. Please the latest version of Acrobat Reader software from http://get.adobe.com/reader/

24

A58MD/A58MG/A58ML

4.2

AMI BIOS Beep Code

Boot Block Beep Codes Number of Beeps Continuing

Description Memory sizing error or Memory module not found

POST BIOS Beep Codes Number of Beeps 1 8

4.3

Description Success booting. Display memory error (system video adapter)

Troubleshooting Probable

1. 2.

Solution

There is no power in the system. 1. Power LED does not shine; the fan of the power supply does not work 2. Indicator light on keyboard does 3. not shine.

Make sure power cable is securely plugged in. Replace cable. technical .

System is inoperative. Keyboard lights Using even pressure on both ends of the are on, power indicator lights are lit, DIMM, press down firmly until the module and hard drives are running. snaps into place. System does not boot from a hard disk 1. drive, but can be booted from optical drive. 2.

Check cable running from disk to disk controller board. Make sure both ends are securely plugged in; check the drive type in the standard CMOS setup. Backing up the hard drive is extremely important. All hard disks are capable of breaking down at any time.

System only boots from an optical drive. Hard disks can be read, applications can be used, but system fails to boot from a hard disk.

1. 2.

Screen message shows “Invalid Configuration” or “CMOS Failure.”

Review system’s equipment. Make sure correct information is in setup.

System cannot boot after installs 1. a second hard drive. 2.

Back up data and applications files. Reformat the hard drive. Re-install applications and data using backup disks.

Set master/slave jumpers correctly. Run SETUP program and select correct drive types. Call the drive manufacturers for compatibility with other drives.

25

Motherboard Manual

U Overheated If the system shutdown automatically after power on system for seconds, that means the U protection function has been activated. When the U is over heated, the motherboard will shutdown automatically to avoid a damage of the U, and the system may not power on again. In this case, please double check: 1. The U cooler surface is placed evenly with the U surface. 2. U fan is rotated normally. 3. U fan speed is fulfilling with the U speed. After confirmed, please follow steps below to relief the U protection function. 1. Remove the power cord from power supply for seconds. 2. Wait for seconds. 3. Plug in the power cord and boot up the system. Or you can: 1. Clear the CMOS data. (See “Close CMOS Header: JCMOS1” section) 2. Wait for seconds. 3. Power on the system again.

4.4

RAID Functions

RAID Definitions RAID 0:

In a RAID 0 system data are split up in blocks that get written across all the drives in the array. By using multiple disks (at least 2) at the same time, this offers superior I/O performance. This performance can be enhanced further by using multiple controllers, ideally one controller per disk.

Features and Benefits ­ Drives: Minimum 2, and maximum is up to 6 or 8. Depending on the platform. ­ Uses: Intended for non-critical data requiring high data throughput, or any environment that does not require fault tolerance. ­ Benefits: provides increased data throughput, especially for large files. No capacity loss penalty for parity. ­ Drawbacks: Does not deliver any fault tolerance. If any drive in the array fails, all data is lost. ­ Fault Tolerance: No. ­ Total Capacity: (Minimal. HDD Capacity) x (Connected HDDs Amount) 26

A58MD/A58MG/A58ML RAID 1:

Data are stored twice by writing them to both the data disk (or set of data disks) and a mirror disk (or set of disks). If a disk fails, the controller uses either the data drive or the mirror drive for data recovery and continues operation. You need at least 2 disks for a RAID 1 array.

Features and Benefits ­ Drives: Minimum 2, and maximum is 2. ­ Uses: RAID 1 is ideal for small databases or any other application that requires fault tolerance and minimal capacity. ­ Benefits: Provides 100% data redundancy. Should one drive fail, the controller switches to the other drive. ­ Drawbacks: Requires 2 drives for the storage space of one drive. Performance is impaired during drive rebuilds. ­ Fault Tolerance: Yes.

RAID 10: RAID 10 combines the advantages (and disadvantages) of RAID 0 and RAID 1 in one single system. It provides security by mirroring all data on a secondary set of disks (disk 3 and 4 in the drawing below) while using striping across each set of disks to speed up data transfers. Features and Benefits ­ Drives: Minimum 4, and maximum is 6 or 8, depending on the platform. ­ Benefits: Optimizes for both fault tolerance and performance, allowing for automatic redundancy. May be simultaneously used with other RAID levels in an array, and allows for spare disks. ­ Drawbacks: Requires twice the available disk space for data redundancy, the same as RAID level 1. ­ Fault Tolerance: Yes.

27

Motherboard Manual

4.5

AMD DUAL Graphics Technology

AMD Dual Graphics Technology Introduction When adds a PCIE display adapter, it can be integrated with IGD to show better performance. To make the two video devices work simultaneously and normally, please refer to the following setting.

AMD Dual Graphics Requirement „

Operating System: Windows 7 / Windows 8

„

ed Dual Graphics Combinations: Richland APUs

AMD Radeon™ Graphics Card

A10-Series HD 8670D

A8-Series HD8570D

A6-Series HD 8470D

“Oland” XT, HD 8870

●

●

●(Note2)

“Oland” Pro, HD 8850

●

●

●

“Turks” XT, HD 6670

●

●

●

“Turks” Pro, HD 6570

●

●

●

“Caicos” Pro, HD 6450

●

●

●

AMD Radeon™ Graphics Card

A10-Series HD 7660D

A8-Series HD7560D

A6-Series HD 7540D

“Turks” XT, HD 6670

●

●

--

“Turks” Pro, HD 6570

●

●

●

--

●

Trinity APUs

“Caicos” Pro, HD 6450 -● Recommended graphics cards for AMD dual-graphics

Note 1: A4-Series Us do not Dual Graphics. Note 2: Only available for DDR3 graphics memory Note 3: The information described above in this manual is for your reference only and the actual information and settings on board may be different from this manual. For further AMD Dual Graphics information, please visit the following website: http://www.amd.com

28

A58MD/A58MG/A58ML

AMD Dual Graphics Setup Step 1: Insert Dual Graphics-Ready graphics card into PEX16_1 slot. Step 2: Set the BIOS setting as follows: [Chipset]→[North Bridge]→[GFX Configuration] →[Surround View]→[Enabled]

Step 3: Install Driver DVD Chipset Driver, and reboot the system. Activate AMD VISION Engine Control Center to make sure CrossFire has been enabled.

29

‫‪Motherboard Manual‬‬

‫‪APPENDIX: Specifications In Other Languages‬‬ ‫‪Arabic‬‬ ‫اﻟﻤﻮاﺻﻔﺎت‬ ‫اﻟﻤﺄﺧﺬ ‪ FM2+/FM2‬ﻟﻤﻌﺎﻟﺞ اﻳﻪ إم دى ‪ AMD‬ﺗﺴﻠﺴﻞ ‪A‬‬ ‫ﻗﺎﻋﺪة وﺣﺪة اﻟﻤﻌﺎﻟﺠﺔ‬ ‫اﻟﻤﺮآﺰﻳﺔ‬ ‫ﻣﺠﻤﻮﻋﺔ اﻟﺸﺮاﺋﺢ‬

‫اﻟﺤﺪ اﻷﻗﺼﻰ ﻟﻠﻄﺎﻗﺔ اﻟﺤﺮارﻳﺔ ﻓﻲ ﺗﺼﻤﻴﻢ اﻟﻤﻌﺎﻟﺞ ) ‪ 100 :( thermal design power – TDP‬واط‪.‬‬ ‫* ﻳﺮﺟﻰ اﻟﺮﺟﻮع إﻟﻰ اﻟﻤﻮﻗﻊ‪ www.biostar.com.tw‬ﻟﻘﺎﺋﻤﺔ دﻋﻢ اﻟﻤﻌﺎﻟﺞ ‪.U‬‬ ‫اﻳﻪ إم دى ‪AMD A55 FCH‬‬ ‫ﺗﺪﻋﻢ ﻗﻨﺎة ﻣﺰدوﺟﺔ دي‪ .‬دي‪ .‬ار‪2400(OC)/ /2133 /1866 / 1600 / 1333 / 1066 / 800 DDR3 .‬‬ ‫)‪2600(OC‬‬

‫اﻟﺬاآﺮة‬

‫‪ x2‬دي‪ .‬دي‪ .‬ار‪ DDR3 .‬ﻓﺘﺤﺎت اﻟﺬاآﺮة اﻟﻤﺰدوﺟﺔ ‪ ،DIMM‬ﺗﺘﺤﻤﻞ آﺤﺪ أﻗﺼﻰ ‪ 32‬ﺟﻴﺠﺎﺑﺎﻳﺖ ذاآﺮة‬ ‫آﻞ ﻓﺘﺤﺔ ﻣﺰدوﺟﺔ ‪ DIMM‬ﺗﺘﺤﻤﻞ دون ‪ 512 ECC‬ﻣﻴﺠﺎ ﺑﺎﻳﺖ ‪ 16/8/4/2/1/‬ﺟﻴﺠﺎﺑﺎﻳﺖ دي‪ .‬دي‪ .‬ار ‪DDR3‬‬ ‫* ﻳﺮﺟﻰ اﻟﺮﺟﻮع إﻟﻰ اﻟﻤﻮﻗﻊ‪ www.biostar.com.tw‬ﻟﻘﺎﺋﻤﺔ دﻋﻢ اﻟﺬاآﺮة‪.‬‬ ‫اﻳﻪ إم دى ‪: FCH A55 AMD‬‬

‫اﻟﺘﺨﺰﻳﻦ‬

‫وﺻﻠﺔ ‪ x4‬ﺳﺎﺗﺎ ‪ 3 SATA‬ﺟﻴﺠﺎ ﺑﺎﻳﺖ ‪ /‬اﻟﺜﺎﻧﻴﺔ‬ ‫ﺗﺘﺤﻤﻞ راﻳﺪ ‪AHCI / 10 / 1 / 0 RAID‬‬ ‫رﻳﻴﺎﻟﺘﻴﻚ رت ل ‪(A58MD, A58MG), REALTEK RTL 8111G‬‬

‫ﺷﺒﻜﺔ ﻣﺤﻠﻴﺔ ‪LAN‬‬

‫‪ 1000 / 100 / 10‬ﻣﻴﺠﺎﺑﺎﻳﺖ ‪ /‬اﻟﺜﺎﻧﻴﺔ ‪ ،‬ﺗﺤﺪﻳﺪ ﺗﻠﻘﺎﺋﻲ ‪ ،‬اﻟﻨﺼﻒ ‪ /‬اﻟﻘﺪرة اﻟﻘﺼﻮى اﻟﻤﺰدوﺟﺔ‬ ‫رﻳﻴﺎﻟﺘﻴﻚ رت ل ‪(A58ML), REALTEK RTL 8106E‬‬ ‫‪ 100 / 10‬ﻣﻴﺠﺎﺑﺎﻳﺖ ‪ /‬اﻟﺜﺎﻧﻴﺔ ‪ ،‬ﺗﺤﺪﻳﺪ ﺗﻠﻘﺎﺋﻲ ‪ ،‬اﻟﻨﺼﻒ ‪ /‬اﻟﻘﺪرة اﻟﻘﺼﻮى اﻟﻤﺰدوﺟﺔ‬

‫اﻟﺘﺮﻣﻴﺰ اﻟﺼﻮﺗﻲ‬

‫‪ALC662‬‬ ‫‪ 5.1‬ﻗﻨﻮات ﻋﺎﻟﻴﺔ اﻟﺪﻗﺔ‬

‫ﻧﺎﻗﻞ ﻣﺘﺴﻠﺴﻞ ﻋﺎم‬

‫ﻳﻪ إم دى ‪A55‬‬

‫‪USB‬‬

‫ﻣﻨﺎﻓﺬ ‪ 8 x‬ﻧﺎﻗﻞ ﻣﺘﺴﻠﺴﻞ ﻋﺎم ‪ 4 ) 2.0 USB‬ﻓﻲ اﻟﻤﺪاﺧﻞ واﻟﻤﺨﺎرج اﻟﺨﻠﻔﻴﺔ و ‪ 4‬ﻣﻦ ﺧﻼل اﻟﻤﻮزع اﻟﺪاﺧﻠﻲ (‬

‫ﻓﺘﺤﺎت اﻟﺘﻮﺳﻊ‬

‫‪FCH AMD‬‬

‫‪ x1‬ﻓﺘﺤﺔ ﻣﻨﻔﺬ اﻟﻤﻠﺤﻘﺎت اﻹﺿﺎﻓﻴﺔ ‪PCIe x1‬‬ ‫‪ x 1‬ﻓﺘﺤﺔ ﻣﻨﻔﺬ اﻟﻤﻠﺤﻘﺎت اﻹﺿﺎﻓﻴﺔ ‪16 x3.0 PCIe‬‬ ‫‪ PS/2 x 1‬اﻟﻔﺎرة‬ ‫‪ PS/2 x 1‬ﻟﻮﺣﺔ اﻟﻤﻔﺎﺗﻴﺢ ﻟﻠﻜﻤﺒﻴﻮت‬

‫اﻟﻤﺪاﺧﻞ واﻟﻤﺨﺎرج‬ ‫اﻟﺨﻠﻔﻴﺔ‬

‫ﻓﺘﺤﺔ ﺗﻮﺻﻴﻞ ﻋﺪد ‪ x 1‬ﻣﻨﻈﻮﻣﺔ اﻟﻌﺮض اﻟﻤﺮﺋﻲ ‪VGA‬‬ ‫ﻓﺘﺤﺔ ﺗﻮﺻﻴﻞ ﻋﺪد ‪ x 1‬واﺟﻬﺔ ﻣﺮﺋﻴﺔ رﻗﻤﻴﺔ ‪(A58MD) DVI‬‬ ‫ﻓﺘﺤﺔ ﻟﺘﻮﺻﻴﻞ ﻋﺪد ‪ x 1‬اﻟﺸﺒﻜﺔ اﻟﻤﺤﻠﻴﺔ ‪LAN‬‬ ‫ﻓﺘﺤﺔ ﺗﻮﺻﻴﻞ ﻋﺪد ‪ x 4‬ﻧﺎﻗﻞ ﻣﺘﺴﻠﺴﻞ ﻋﺎم ‪2.0 USB‬‬ ‫ﻓﺘﺤﺔ ﺗﻮﺻﻴﻞ ﻋﺪد ‪ x 3‬ﺟﺎك ﻟﻠﺼﻮت‬

‫‪30‬‬

‫‪A58MD/A58MG/A58ML‬‬ ‫اﻟﻤﻮاﺻﻔﺎت‬ ‫وﺻﻠﺔ ‪ 3 x SATA 4‬ﺟﻴﺠﺎﺑﺎﻳﺖ ‪ /‬اﻟﺜﺎﻧﻴﺔ‬ ‫ﻣﻮزع ‪ x2‬ﻧﺎﻗﻞ ﻣﺘﺴﻠﺴﻞ ﻋﺎم ‪ ) 2.0 USB‬آﻞ ﻣﻮزع ﻳﺘﺤﻤﻞ ﻓﺘﺤﺘﻴﻦ ﻧﺎﻗﻞ ﻣﺘﺴﻠﺴﻞ ﻋﺎم ‪( 2.0 USB‬‬ ‫ﻣﻮﺻﻠﺔ ﻟﻠﻄﺎﻗﺔ ‪ 4 x 1‬دﺑﺎﺑﻴﺲ‬ ‫وﺻﻠﺔ ﻟﻠﻄﺎﻗﺔ ‪ 24 x1‬دﺑﻮس‬ ‫اﻟﻤﺪاﺧﻞ واﻟﻤﺨﺎرج‬ ‫اﻟﺪاﺧﻠﻴﺔ‬

‫وﺻﻠﺔ ‪ x 1‬ﻣﺮوﺣﺔ ﺗﺒﺮﻳﺪ وﺣﺪة اﻟﻤﻌﺎﻟﺠﺔ اﻟﻤﺮآﺰﻳﺔ‬ ‫وﺻﻠﺔ ‪ x1‬ﻣﺮاوح ﺗﺒﺮﻳﺪ اﻟﻤﻨﻈﻮﻣﺔ‬ ‫ﻣﻮزع ‪ x 1‬اﻟﻠﻮﺣﺔ اﻷﻣﺎﻣﻴﺔ‬ ‫ﻣﻮزع ‪ x1‬اﻟﺼﻮت اﻷﻣﺎﻣﻲ‬ ‫ﻣﻮزع ‪ x1‬ﺳﻴﻤﻮس ﻣﺒﺎﺷﺮ‬ ‫ﻣﻮزع ‪ x1‬ﻓﺘﺤﺔ ﺗﺴﻠﺴﻠﻴﺔ‬ ‫ﻣﻮزع ‪ x 1‬اﻟﻬﻴﻜﻞ رﺋﻴﺲ ﻣﻮﺻﻞ‬

‫ﻋﺎﻣﻞ اﻟﺸﻜﻞ‬ ‫أﻧﻈﻤﺔ اﻟﺘﺸﻐﻴﻞ اﻟﻤﺪﻋﻮﻣﺔ‬

‫‪31‬‬

‫ﻋﺎﻣﻞ ﺷﻜﻞ ﻣﺪد اﻟﺘﻜﻨﻮﻟﻮﺟﻴﺎ اﻟﻤﺘﻘﺪﻣﺔ ‪ 218 ، microATX‬ﻣﻢ ‪ 174 x‬ﻣﻢ‬ ‫وﻳﻨﺪوز إآﺲ ﺑﻲ ‪ / windows xp‬وﻳﻨﺪوز ‪ / 7‬وﻳﻨﺪوز ‪8‬‬ ‫ﺑﻴﻮﺳﺘﺎر ‪ BIOSTAR‬ﺗﺤﺘﻔﻆ ﺑﺤﻖ إﺿﺎﻓﺔ أو أزﻟﺔ اﻟﺪﻋﻢ ﻷي ﻧﻈﺎم ﺗﺸﻐﻴﻞ ﻣﻊ أو ﺑﺪون أﻧﻈﺎر‪.‬‬

Motherboard Manual

French Spécifications Interface de connexion FM2+/FM2 pour série A AMD Unité

Enveloppe thermique Unité Centrale maximum : 100Watt

Centrale

* Veuillez vous reporter à www.biostar.com.tw pour la liste des s modèles d'Unité Centrale.

Jeu de puces

AMD A55 FCH e mémoire DDR3 double canal 800/ 1066/ 1333/ 1600/ 1866/ 2133/ 2400(OC)/ 2600(OC)

Mémoire

Banc de mémoire 2 x DDR3 DIMM, e max. jusqu’à une mémoire de 32 GB Chaque module DIMM e module DDR3 non-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB * Veuillez vous reporter à www.biostar.com.tw pour la liste des soutien de la mémoire. AMD A55 FCH

Stockage

Connecteur 4 x SATA 3Gb/s e système RAID 0,1,10 & AHCI Realtek RTL 8111G (A58MD, A58MG) 10/ 100/ 1000 Mb/s auto négociation, capacité bidirectionnelle à l'alternat /

Réseau local

bidirectionnelle simultanée Realtek RTL 8106E (A58ML) 10/ 100 Mb/s auto négociation, capacité bidirectionnelle à l'alternat / bidirectionnelle simultanée

Codec audio

USB

ALC662 Canaux 5.1, écoute audio de haute définition AMD A55 FCH Port 8x USB 2.0 (4 sur les I/O arrières et 4 en interne)

Connecteur

1x PCIe x1 Fente

d’extension

1x PCIe 3.0 x16 Fente 1x PS/2 Clavier 1x PS/2 Souris 1x Port VGA

I/O arrirèes

1x Port DVI (A58MD) 1x port LAN 4x Port USB 2.0 3x entrées audio

32

A58MD/A58MG/A58ML Spécifications 4x Connecteur SATA 3.0Gb/s 2x embases USB 2.0 (chaque embase e 2 Ports USB 2.0) 1x 4-Broche de carte 1x 24-Broche de carte 1x Connecteur ventilateur unité centrale I/O en interne

1x Connecteur ventilateur système 1x Fiche panneau avant 1x Fiche audio avant 1x Fiche mémoire CMOS vide 1x Embase port série 1x Connecteur Audio du panneau avant

Facteur d'encombrement

Facteur d'encombrement microATX, 218 mm x 174 mm Windows XP / 7 / 8

SE

Biostar se réserve le droit d’ajouter ou d'enlever le pour toute SE avec ou sans préavis.

33

Motherboard Manual

German Spezifikationen Anschluss-FM2+/FM2 für AMD A-Serie U-Unterstützung

Maximale U TDP (Thermal Design Power): 100 Watt

Chipset

AMD A55 FCH

* Bitte konsultieren Sie www.biostar.com.tw für U-Unterstützungsliste

Unterstützt zweikanaliges DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/ 2400(OC)/ 2600(OC) Festplattenspeicher

2 x DDR3 DIMM-SpeicherSlot, Max. Uterstützung bis zu 32 GB-Speicher Jedes DIMM unterstützt nicht-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB DDR3-Module * Bitte konsultieren Sie www.biostar.com.tw für für Speicherunterstützung Liste. AMD A55 FCH:

Arbeitsspeicher

4x SATA 3Gb-Verbindung Unterstützt RAID 0,1,10 & AHCI Realtek RTL 8111G (A58MD, A58MG)

LAN

10/ 100/ 1000 Mb Auto-Negotiation, Halb- / Voll-Duplex-fähig Realtek RTL 8106E (A58ML) 10/ 100/ 1000 Mb Auto-Negotiation, Halb- / Voll-Duplex-fähig

Audio-Codec

USB

ALC662 5.1 Kanäle, HD-Audio AMD A55 FCH: 8x USB 2.0-Port (4 hintere I/Os und 4 via interne Header)

Erweiterungsanschl

1x PCIe x1-Slot

üsse

1x PCIe 3.0 x16-Slot 1x PS/2-Maus 1x PS/2-Keyboard 1x VGA-Port

Hintere I/Os

1x DVI-Port (A58MD) 1x LAN-Port 4x USB 2.0-Port 3x Audio Jack

34

A58MD/A58MG/A58ML Spezifikationen 4x SATA 3.0Gb/s-Verbinung 2x USB 2.0-Header (jeder Header unterstützt 2 USB 2.0-Ports) 1x 4-Pin-Stromverbindung 1x 24-Pin-Stromverbindung 1x U-Ventilatorverbindung Interne I/Os

1x System-Ventilatorverbindung 1x Header für Front 1x Header für Frontaudio 1x Header für klares CMOS 1x Serieller Port-Header 1x Chassis Lautsprecher-Header

Formfaktor OS-Unterstützung

microATX Formfaktor, 218 mm x 174 mm Windows XP / 7 / 8 Biostar reserves the right to add or remove for any OS with or without notice.

35

Motherboard Manual

Italian Specificazioni Slot FM2+/FM2 per processore AMD serie-A

o processore

Alimentazione di Proiezione Termico (TDP – Thermal Design Power): 100Watt * Si prega di consultare www.biostar.com.tw per la lista di o del processore.

Tipo scheda

AMD A55 FCH a DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/ 2400(OC)/ 2600(OC) Doppio Canale

Memoria

2 x DDR3 DIMM Slot di Memoria a fino a 32 GB Memoria Ogni DIMM a non-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB DDR3 moduli * Si prega di consultare www.biostar.com.tw per la lista di o del memoria. AMD A55 FCH:

Memorizzazione

Connettore 4x SATA 3Gb/s a RAID 0,1,10 & AHCI Realtek RTL 8111G (A58MD, A58MG)

Catena

10/ 100/ 1000 Mb auto negoziazione, capacita di duplex Meta / Completo Realtek RTL 8106E (A58ML) 10/ 100 Mb auto negoziazione, capacita di duplex Meta / Completo

Codec Audio

USB

Slot di espansione

ALC662 Canali Audio di Alta Definizione 5.1 Piattaforma AMD A55 FCH: Slot 8x USB 2.0 (4 nei ingressi/ uscite posteriore e 4 da distributori interni) Slot 1x PCIe x1 Slot 1x PCIe 3.0 x16 Mouse 1x PS/2 Tastiera 1x PS/2 Slot 1x VGA

Ingressi/ Uscite Posteriore

Slot 1x DVI (A58MD) Slot 1x LAN Slot 4x USB 2.0 Jack audio 3x

36

A58MD/A58MG/A58ML Specificazioni Connettore 4x SATA 3.0Gb/s Distributore 2x USB 2.0(ogni distributore a 2 slot USB 2.0) Connettore con 4 pin x1 Connettore con 24 pin x1 Connettore Ventilatore processore x1 Ingressi/ Uscite Interni

Connettore Ventilatore Sistema x1 Distributore Pannello Frontale x1 Distributore Audio Frontale x1 Distributore CMOS Diretto x1 Distributore Slot Serie x1 Distributore casse telaio x1

Fattore di Forma

Fattore di Forma microATX, 218 mm x 174 mm Windows XP / 7 / 8

o SO

Biostar si riserva il diritto di aggiungere o ritirare il o per qualsiasi SO con o senza preavviso.

37

Motherboard Manual

Japanese 仕様 AMD A-シリーズ プロセッサの Socket FM2+/FM2 U サポート

最大 U TDP （Thermal Design Power 最大放熱量）:100 W *U サポート リストについては、www.biostar.com.twを参照してください。

チップセット

AMD A55 FCH デュアルチャンネル DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/ 2400(OC)/ 2600(OC) をサポート 2 x DDR3 DIMM メモリ スロット、 最大 32 GB メモリまでサポート

メモリ

各 DIMM は、 非-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB DDR3 モジュールをサポートしてい ます *サポートされているメモリのリストについては、www.biostar.com.twを参照してく ださい。 AMD A55 FCH:

保存スペース

4x SATA 3Gb/s コネクタ RAID 0,1,10 & AHCI のサポート Realtek RTL 8111G (A58MD, A58MG)

LAN

10/ 100/ 1000 Mb/s オートネゴーシエーション、半/全 二重通信 Realtek RTL 8106E (A58ML) 10/ 100 Mb/s オートネゴーシエーション、半/全 二重通信

オーディオ コーデ

ALC662

ック

5.1 チャンネル, ハイ デフィニション オーディオ

USB

拡張スロット

AMD A55 FCH: 8x USB 2.0 ポート (後部 I/O に4つ 及び 内蔵ヘッダー経由に4つ) 1x PCIe x1 スロット 1x PCIe 3.0 x16 スロット 1x PS/2 キーボード 1x PS/2 マウス 1x VGA ポート

後部 I/O

1x DVI ポート (A58MD) 1x LAN ポート 4x USB 2.0 ポート 3x オーディオ ジャック

38

A58MD/A58MG/A58ML 仕様 4x SATA 3.0Gb/s コネクタ 2x USB 2.0 ヘッダー (各ヘッダーは、2つの USB 2.0 ポートをサポートしています) 1x 4-Pin パワー コネクタ 1x 24-Pin パワー コネクタ 1x U ファン コネクタ 内蔵 I/O

1x システム ファン コネクタ 1x フロント パネル ヘッダー 1x フロント オーディオ ヘッダー 1x クリア CMOS ヘッダー 1x シリアル ポート ヘッダー 1x シャーシスピーカーヘッダー

フォーム ファクタ サポート OS

microATX フォーム ファクタ、218 mm x 174 mm Windows XP / 7 / 8 Biostar には、通知なしでサポート OS を変更する権限があります。

39

Motherboard Manual

Polish Specyfikacje techniczne Gniazdo procesora (Socket) FM2+/FM2 dla procesorów AMD seria-A Obsługa procesora

Moc Wydzielanego Ciepła (TDP - Thermal Design Power): 100Watt * Proszę sprawdzić listę obsługiwanych procesorów na stronie internetowej

www.biostar.com.tw Rodzaj płyty

AMD A55 FCH Obsługa pamięci DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/ 2400(OC)/ 2600(OC) Dwukanałowa 2 x DDR3 DIMM Pamięć Gniazda procesora (Slot), Maksymalna wielkość pamięci 32

Pamięć

GB Każdy DIMM obsługuje jeden moduł non-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB DDR3 * Proszę sprawdzić listę obsługiwanych pamięć na stronie internetowej

www.biostar.com.tw AMD A55 FCH: Przechowywanie

Złącze 4x SATA 3Gb/s Obsługa RAID 0,1,10 & AHCI Układ RTL 8111G (A58MD, A58MG)

LAN

10/ 100/ 1000 Mb auto negocjacja, pojemność dupleks Połowe / Pełny Układ RTL 8106E (A58ML) 10/ 100 Mb auto negocjacja, pojemność dupleks Połowe / Pełny

Codec Audio

ALC662 Kanały Audio wysokiej Definicji 5.1 Płyta AMD A55 FCH:

USB

8 x złącza USB 2.0 (4 przez tylne porty wejścia/ wyjścia oraz 4 przez wewnętrzne porty)

Złącza rozszerzeń

złącza 1x PCIe x1 (Slot) złącza 1x PCIe 3.0 x16 (Slot) Myszka 1x PS/2 Klawiatura 1x PS/2 Port 1x VGA

Tylne porty wejścia/ wyjścia

Port 1x DVI (A58MD) Port 1x LAN Porty 4x USB 2.0 Porty audio 3x

40

A58MD/A58MG/A58ML Specyfikacje techniczne Złącza 4x SATA 3.0Gb/s Złącza 2x USB 2.0 (każde złącze obsługuje dodatkowe 2 porty USB 2.0) Złącza 4 pionowe x 1 Złącza 24 pionowe x 1 Wewnętrzne porty wejścia/ wyjścia

Złącze wentylatora U x 1 Złącze wentylatora obudowy x 1 Złącze przedniego u x1 Złącze audio przedniego u x1 Złącze bezpośrednie CMOS x1 Port szeregowy x1 złącze głośników Podwozie x1

Obudowa

Obudowa microATX, 218 mm x 174 mm Windows XP / 7 / 8

Obsługa OS

Biostar zastrzega sobie prawo do dodania lub wycofania obsługi dla OS, z wypowiedzeniem lub bez wypowiedzenia.

41

Motherboard Manual

Portuguese Especificações Porta FM2+/FM2 para processador AMD série-A e Processador

Alimentação de Design Térmico (TDP – Thermal Design Power): 100Watt * Por favor consulte www.biostar.com.tw para obter uma lista de e do processador.

Tipo Placa Mãe

AMD A55 FCH a DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/ 2400(OC)/ 2600(OC) Canal Duplo 2 x DDR3 DIMM Slot de memória a até 32 GB Memória

Memória

Cada DIMM a non-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB DDR3 módulo * Por favor consulte www.biostar.com.tw para obter uma lista de e do memória. AMD A55 FCH:

Armazenamento

Conector 4x SATA 3Gb/s a RAID 0,1,10 & AHCI Realtek RTL 8111G (A58MD, A58MG)

LAN

10/ 100/ 1000 Mb auto negociação, capacidade duplex Metade / Cheio Realtek RTL 8106E (A58ML) 10/ 100 Mb auto negociação, capacidade duplex Metade / Cheio

Codec de Audio

USB

Slots de expansão

ALC662 Canais de Áudio de Alta Definição 5.1 Plataforma AMD A55 FCH: Porta 8x USB 2.0 (4 nas entradas/saídas traseiras e 4 pelos Dispositivos internos) Porta 1x PCIe x1 Porta 1x PCIe 3.0 x16 Mouse 1x PS/2 Teclado 1x PS/2 Porta 1x VGA

Entradas/Saídas no traseiro

Porta 1x DVI (A58MD) Porta 1x LAN Porta 4x USB 2.0 Soquete audio 3x

42

A58MD/A58MG/A58ML Especificações Conector 4x SATA 3.0Gb/s Dispositivo 2x USB 2.0 (cada Dispositivo a 2 portas USB 2.0) Conector de 4 pinos x1 Conector de 24 pinos x1 Conector de Ventoinha processador x1 Conectores na placa

Conector de Ventoinha Sistema x1 Dispositivo Frontal x1 Dispositivo de Audio Frontal x1 Dispositivo CMOS Direct x1 Dispositivo Porta Série x1 Chassis Speaker Header x1

Fator de Fôrma

Fator de Fôrma microATX, 218 mm x 174 mm Windows XP / 7 / 8

e OS

Biostar reserva seu direito de adicionar ou retirar o e para qualquer OS com ou sem notificação.

43

Motherboard Manual

Russian Спецификации Сокет FM2+/FM2 для процессоров AMD серии A Поддержка центрального процессора Набор микросхем

Максимальный термопакет центрального процессора (TDP): 100 ватт * Перечень поддержки центрального процессора смотрите на

www.biostar.com.tw. AMD A55 FCH Поддерживает двухканальный DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/ 2400(OC)/ 2600(OC)

Память

2 гнезда платы памяти DDR3 DIMM, максимальная память до 32 Гб Каждый модуль DIMM поддерживает модуль не-ECC 512 Мб/ 1/ 2/ 4/ 8/ 16 Гб DDR3 * Перечень поддержки памяти смотрите на www.biostar.com.tw. AMD A55 FCH:

Накопитель

Соединитель 4x SATA 3 Гб/с Поддерживает RAID 0,1,10 & AHCI Realtek RTL 8111G (A58MD, A58MG)

Локальная сеть

Автосогласование 10/ 100/ 1000 Мб/с, работает в полно/полудуплексном режиме Realtek RTL 8106E (A58ML) Автосогласование 10/ 100 Мб/с, работает в полно/полудуплексном режиме

Аудиокодек

USB

Гнезда расшир.

ALC662 Каналы 5.1, высококачественное аудио AMD A55 FCH: 8 портов USB 2.0 (4 сзади ввода-вывода и 4 через внутренние контакты) 1x гнезда PCIe x1 1x PCIe 3.0 x16 гнездо 1 мышь PS/2 1 клавиатура PS/2 1 порт VGA

Задняя плата ввода-вывода

1 порт DVI (A58MD) 1 порт локальной сети 4 порта USB 2.0 3 гнезд для подключения наушников

44

A58MD/A58MG/A58ML Спецификации Соединитель 4x SATA 3 Гб/с 2 контакта USB 2.0 (каждый контакт поддерживает 2 порта USB 2.0) 1 4-выводный разъем питания 1 24-выводный разъем питания 1 разъем вентилятора ЦП Внутр. Плата ввода-вывода

1 разъема вентилятора системы 1 контакт передней панели 1 контакт передней аудиопанели 1 контакт микросхемы Clear CMOS 1 контакт последовательного порта 1 Шасси спикер заголовка

Конструктив

Форм-фактор microATX, 218 мм x 174 мм Windows XP / 7 / 8

Поддержка ОС

Biostar оставляет за собой право добавлять или удалять поддержку любой ОС, с уведомлением или без.

45

Motherboard Manual

Spanish Especificaciones Ranura FM2+/FM2 para procesador AMD serie - A Compatibilidad con el procesador

Alimentación de Proyección Térmica (TDP – Thermal Design Power): 100Watt *Por favor consultar con www.biostar.com.tw para la lista de compatibilidad con el procesador.

Tipo de Placa

AMD A55 FCH Soporta DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/ 2400(OC)/ 2600(OC) Doble Canal 2x DDR3 DIMM Ranura de memoria Soporta hasta 32 GB Memoria

Memoria

Cada DIMM soporta un modulo non-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB DDR3 *Por favor consultar con www.biostar.com.tw para la lista de compatibilidad con el memoria. AMD A55 FCH:

Almacenamiento de información

Conector 4x SATA 3Gb/s Soporta RAID 0,1,10 & AHCI Realtek RTL 8111G (A58MD, A58MG)

LAN

10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo Realtek RTL 8106E (A58ML) 10/ 100 Mb/s auto negociación, capacidad dúplex Mitad/Completo

Códec Audio

ALC662 Canales Audio de Alta Definición 5.1 Plataforma AMD A55 FCH:

USB

Ranura 8x USB 2.0 (4 en las entradas/salidas posteriores y 4 por los distribuidores internos)

Ranuras de

Ranura 1x PCIe x1

Extinción

Ranura 1x PCIe 3.0 x16 Ratón 1x PS/2 Teclado 1x PS/2 Ranura 1x VGA

trasero de E/S

Ranura 1x DVI (A58MD) Ranura 1x LAN Ranura 4x USB 2.0 Socket audio 3x

46

A58MD/A58MG/A58ML Especificaciones Conector 4x SATA 3Gb’s Distribuidor 2x USB 2.0 (cada distribuidor soporta 2 ranuras USB 2.0) Conector con 4 patillas x1 Conector con 24 patillas x1 Conector Ventilador procesador x1 Conectores en placa

Conector Ventilador Sistema x1 Distribuidor Frontal x1 Distribuidor Audio Frontal x1 Distribuidor CMOS Directo x1 Distribuidor Ranura Serie x1 Cabezal del altavoz del chasis x1

Factor de Forma

Factor de Forma microATX, 218 mm x 174 mm Windows XP / 7 / 8

Soporte OS

Biostar reserva su derecho de añadir o retirar el soporte para cada OS con o sin notificación.

2013/08/27

47
