N68S3B Setup Manual

FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. There is no guarantee that interference will not occur in a particular installation.

The vendor makes no representations or warranties with respect to the contents here and specially disclaims any implied warranties of merchantability or fitness for any purpose. Further the vendor reserves the right to revise this publication and to make changes to the contents here without obligation to notify any party beforehand. Duplication of this publication, in part or in whole, is not allowed without first obtaining the vendor’s approval in writing.

The content of this ’s manual is subject to be changed without notice and we will not be responsible for any mistakes found in this ’s manual. All the brand and product names are trademarks of their respective companies.

Dichiarazione di conformità sintetica Ai sensi dell’art. 2 comma 3 del D.M. 275 del 30/10/2002 Si dichiara che questo prodotto è conforme alle normative vigenti e soddisfa i requisiti essenziali richiesti dalle direttive 2004/108/CE, 2006/95/CE e 1999/05/CE quando ad esso applicabili

Short Declaration of conformity We declare this product is complying with the laws in force and meeting all the essential requirements as specified by the directives 2004/108/CE, 2006/95/CE and 1999/05/CE whenever these laws may be applied

Table of Contents Chapter 1: Introduction ........................................ 1 1.1 1.2 1.3 1.4 1.5

Before You Start ................................................................................ 1 Package Checklist ............................................................................. 1 Motherboard Features...................................................................... 2 Rear Connectors ..................................................................... 3 Motherboard Layout......................................................................... 4

Chapter 2: Hardware Installation .......................... 5 2.1 2.2 2.3 2.4

Installing Central Processing Unit (U)....................................... 5 FAN Headers...................................................................................... 7 Installing System Memory ................................................................ 8 Connectors and Slots ....................................................................... 10

Chapter 3: Headers & Jumpers Setup .................. 13 3.1 3.2

How to Setup Jumpers .................................................................... 13 Detail Settings.................................................................................. 13

Chapter 4: RAID Functions .................................. 18 4.1 4.2 4.3

Operating System............................................................................ 18 Raid Arrays ...................................................................................... 18 How RAID Works............................................................................. 18

Chapter 5: Useful Help ........................................ 20 5.1 5.2 5.3 5.4 5.5

Driver Installation Note.................................................................. 20 Software............................................................................................ 21 Extra Information............................................................................ 24 AMI BIOS Beep Code....................................................................... 25 Troubleshooting............................................................................... 26

Appendix: SPEC In Other Languages ................... 28 German.................................................................................................................. 28 French .................................................................................................................... 30 Italian..................................................................................................................... 32 Spanish ................................................................................................................... 34 Portuguese ............................................................................................................ 36 Polish...................................................................................................................... 38 Russian ................................................................................................................... 40 Arabic..................................................................................................................... 42 Japanese ................................................................................................................ 44

N68S3B

CHAPTER 1: INTRODUCTION 1.1

BEFORE YOU START

Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: „ „ „

„

„

„

1.2

Prepare a dry and stable working environment with sufficient lighting. Always disconnect the computer from power outlet before operation. Before you take the motherboard out from anti-static bag, ground yourself properly by touching any safely grounded appliance, or use grounded wrist strap to remove the static charge. Avoid touching the components on motherboard or the rear side of the board unless necessary. Hold the board on the edge, do not try to bend or flex the board. Do not leave any unfastened small parts inside the case after installation. Loose parts will cause short circuits which may damage the equipment. Keep the computer from dangerous area, such as heat source, humid air and water.

PACKAGE CHECKLIST IDE Cable X 1 (optional) Serial ATA Cable X 2 Rear I/O for ATX Case X 1 Installation Guide X 1 Fully Setup Driver CD X 1 (full version manual files inside) USB 2.0 Cable X1 (optional) Serial ATA Power Cable X 1 (optional)

Note: The package contents may be differed by area or your motherboard version.

1

Motherboard Manual

1.3

MOTHERBOARD FEATURES SPEC

U

FSB Chipset

Socket AM3

AMD 64 Architecture enables 32 and 64 bit

AMD Phenom II/ Athlon II processors

computing

(Maximum Watt: 95W)

s Hyper Transport 2.0

HyperTransport 2.0 s up to 2.0 GT/s Bandwidth GeForce 7025/nForce 630a Low Pin Count Interface

ITE 8728 Super I/O

Provides the most commonly used legacy Super I/O functionality

Max Memory Capacity 8GB

Memory

Each DIMM s 512MB/

Dual Channel Mode DDR3 memory module s DDR3 800 / 1066 / 1333 ed DIMM and ECC DIMM is not ed

1GB/2GB/4GB DDR3 Graphics

Integrated in GeForce 7025 Chipset

IDE

Integrated IDE Controller

SATA II

Integrated Serial ATA Controller

LAN

Realtek RTL 8201CL

Sound

VT1708B

Max Shared Video Memory is 512MB Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode s PIO Mode 0~4, Data transfer rates up to 3 Gb/s SATA Version 2.0 specification compliant 10 / 100 Mb/s auto negotiation Half / Full duplex capability 5.1 channels audio out High Definition Audio

PCI Express x16 slot

x1

s PCI-E x16 expansion cards

PCI slot

x1

s PCI expansion cards

On Board

IDE Connector

x1

Each connector s 2 IDE device

Connector

SATA Connector

x2

Each connector s 1 SATA devices

Front Connector

x1

s front facilities

Front Audio Connector

x1

s front audio function

U Fan header

x1

U Fan power supply (with Smart Fan function)

System Fan header

x1

System Fan Power supply

Slots

2

H/W Monitor ITE's "Smart Guardian" function

DDR3 DIMM Slots x 2 Main

Environment Control initiatives

N68S3B SPEC CMOS clear header

x1

Restore CMOS data to factory default

USB connector

x2

Each connector s 2 front USB ports

Power Connector (24pin)

x1

Connects to Power supply

Power Connector (4pin)

x1

Connects to Power supply

Printer Port Connector

x1

Each connector s 1 Printer port

PS/2 Keyboard

x1

Connects to PS/2 Keyboard

PS/2 Mouse

x1

Connects to PS/2 Mouse

Back VGA port

x1

Connect to D-SUB monitor

I/O

LAN port

x1

Connect to RJ-45 ethernet cable

USB Port

x4

Connect to USB devices

Audio Jack

x3

Provide Audio-In/Out and microphone connection

Board Size Special Features

170 mm(W) x 235 mm(L)

uATX

RAID 0 / 1 Biostar reserves the right to add or remove

OS Windows XP / Vista / 7

1.4

for any OS With or without notice.

REAR CONNECTORS

PS/2 Mouse

LAN

Line In/ Sur round Line Out Mic I n 1/ Bass/ Cent er

PS/ 2 Keyboard

VGA

USBX2

USBX2

3

Motherboard Manual

1.5

MOTHERBOARD LAYOUT JKB MS

JKB_PWR

JATXP WR4

DDR3_B1

DDR3_A1

JVGA

So ck et A M 3

JATXPWR1

JCFAN JUSB1

IDE

JUSBPWR1 JUSBLA N1

GeForce 7025/ nForce 630a

JA UDIO1

BAT1

JUSB PWR2 JUSB2

JUSB3

JCMOS1

PEX16_1

LAN

BIOS

Super I/O JPRNT JAUDIOF

Codec

PCI1

SATA2 JSFAN

Note: ■ represents the 1st pin.

4

SATA1 J1

N68S3B

CHAPTER 2: HARDWARE INSTALLATION 2.1

INSTALLING CENTRAL PROCESSING UNIT (U)

Step 1: Pull the lever toward direction A from the socket and then raise the lever up to a 90-degree angle.

Step 2: Look for the white triangle on socket, and the gold triangle on U should point towards this white triangle. The U will fit only in the correct orientation.

5

Motherboard Manual Step 3: Hold the U down firmly, and then close the lever toward direct B to complete the installation.

Step 4: Put the U Fan on the U and buckle it. Connect the U FAN power cable to the JCFAN. This completes the installation.

6

N68S3B

2.2

FAN HEADERS

These fan headers cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.

JCFAN: U Fan Header

Pin 1 2 3

4 1

4

Assignment Ground +12V FAN RPM rate sense Smart Fan Control (By Fan)

JSFAN: System Fan Header

Pin 1 2 3

1

Assignment Ground +12V FAN RPM rate sense

3

Note: The JCFAN s 4-pin head connector; the JSFAN, 3-pin head connector. When connecting with wires onto connectors, please note that the red wire is the positive and should be connected to pin#2, and the black wire is Ground and should be connected to GND.

7

Motherboard Manual

2.3

INSTALLING SYSTEM MEMORY

D DR 3 _A1 D DR 3 _ B1

A. Memory Modules

8

1.

Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot so that the notch on the DIMM matches the break on the Slot.

2.

Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated.

N68S3B

B. Memory Capacity DIMM Socket Location

DDR3 Module

Total Memory Size

DDR3_A1

512MB/1GB/2GB/4GB

DDR3_B1

512MB/1GB/2GB/4GB

Max is 8GB.

C. Dual Channel Memory installation Please refer to the following requirements to activate Dual Channel function: Install memory module of the same density in pairs, shown in the table. Dual Channel Status DDR3_A1 DDR3_B1 Disabled

O

X

Disabled

X

O

Enabled

O

O

(O means memory installed, X means memory not installed.) The DRAM bus width of the memory module must be the same (x8 or x16)

9

Motherboard Manual

2.4

CONNECTORS AND SLOTS

IDE: IDE/ATAPI Connector The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA 33/66/100/133 functionality. The IDE connector can connect a master and a slave drive, so you can connect up to two drives.

40

39

2

1

JATXPWR4: ATX Power Source Connector This connect provides +12V to U power circuit.

10

4

3

1

2

Pin 1 2 3 4

Assignment +12V +12V Ground Ground

N68S3B

JATXPWR1: ATX Power Source Connector This connector allows to connect 24-pin power connector on the ATX power supply.

Pin 13 14 15 16 17 18 19 20 21 22 23 24

Assignment +3.3V -12V Ground PS_ON Ground Ground Ground NC +5V +5V +5V Ground

Pin 1 2 3 4 5 6 7 8 9 10 11 12

12

24

1

13

Assignment +3.3V +3.3V Ground +5V Ground +5V Ground PW_OK Standby Voltage+5V +12V +12V +3.3V

Note: Before you power on the system, please make sure that both JATXPWR1 and JATXPWR4 connectors have been plugged-in.

11

Motherboard Manual

PEX16_1: PCI-Express Gen2 x16 Slot -

PCI-Express 1.0a compliant. Maximum theoretical realized bandwidth of 4GB/s simultaneously per direction, for an aggregate of 8GB/s totally. PCI-Express s a raw bit-rate of 2.5Gb/s on the data pins. 2X bandwidth over the traditional PCI architecture.

PEX16_1

PCI1: Peripheral Component Interconnect Slot This motherboard is equipped with 1 standard PCI slot. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards. This PCI slot is designated as 32 bits.

PCI1

12

N68S3B

CHAPTER 3: HEADERS & JUMPERS SETUP 3.1

HOW TO SETUP JUMPERS

The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”.

Pin opened

3.2

Pin closed

Pin1-2 closed

DETAIL SETTINGS

J1: Front Header This 16-pin connector includes Power-on, Reset, HDD LED, Power LED, Sleep, and speaker connection. It allows to connect the PC case’s front switch functions. PWR_LED On/Off + + -

9 1

16 8

+ RST

SPK

HLED

Pin 1 2 3 4 5 6 7 8

Assignment +5V N/A N/A Speaker HDD LED (+) HDD LED (-) Ground Reset control

Function Speaker Connector Hard drive LED Reset button

Pin 9 10 11 12 13 14 15 16

Assignment N/A N/A N/A Power LED (+) Power LED (+) Power LED (-) Power button Ground

Function N/A N/A Power LED Power-on button

13

Motherboard Manual

JUSB2/JUSB3: Headers for USB 2.0 Ports at Front These headers allow to connect additional USB cable on the PC front , and also can be connected with internal USB devices, like USB card reader.

JUSB 2 JUSB 3 10

9

2

1

Pin 1 2 3 4 5 6 7 8 9 10

Assignment +5V (fused) +5V (fused) USBUSBUSB+ USB+ Ground Ground NC Key

SATA1/SATA2: Serial ATA Connectors The motherboard has a PCI to SATA Controller with 2 channels SATA interface, it satisfies the SATA 2.0 spec and with transfer rate of 3.0Gb/s.

S ATA2 SATA1

1

14

4

7

Pin 1 2 3 4 5 6 7

Assignment Ground TX+ TXGround RXRX+ Ground

N68S3B

JAUDIOF: Front Audio Header This header allows to connect the front audio output cable with the PC front . This header allows only HD audio front connector; AC’97 connector is not acceptable.

2

10

1

9

Pin 1 2 3 4 5 6 7 8 9 10

Assignment Mic Left in Ground Mic Right in GPIO Right line in Jack Sense Front Sense Key Left line in Jack Sense

JCMOS1: Clear CMOS Header By placing the jumper on pin2-3, it allows to restore the BIOS safe setting and the CMOS data, please carefully follow the procedures to avoid damaging the motherboard. 3

1

Pin 1-2 Close: Normal Operation (default).

3

3

1

1

Pin 2-3 Close: Clear CMOS data.

※ Clear CMOS Procedures: 1. 2. 3. 4. 5. 6.

Remove AC power line. Set the jumper to “Pin 2-3 close”. Wait for five seconds. Set the jumper to “Pin 1-2 close”. Power on the AC. Reset your desired or clear the CMOS data. 15

Motherboard Manual

JPRNT: Printer Port Connector This header allows you to connect printer port on the PC.

Pin 1 2 3 4 5 6 7 8 9 10 11 12 13

2

26

1

25

Assignment -Strobe -ALF Data 0 -Error Data 1 -Init Data 2 -Scltin Data 3 Ground Data 4 Ground Data 5

Pin 14 15 16 17 18 19 20 21 22 23 24 25 26

Assignment Ground Data 6 Ground Data 7 Ground -ACK Ground Busy Ground PE Ground SCLT Key

JKB_PWR: Power Source Header for PS/2 Keyboard and Mouse 1

1

3

3

Pin 1-2 close +5V for PS/2 keyboard and mouse.

1

3

Pin 2-3 close +5V STB for PS/2 keyboard and mouse.

16

N68S3B

JUSBPWR1/JUSBPWR2: Power Source Headers for USB Ports Pin 1-2 Close: JUSBPWR1: +5V for USB ports at JUSB1/JUSBLAN1. JUSBPWR2: +5V for USB ports at front (JUSB2/JUSB3). Pin 2-3 Close: JUSBPWR1: +5V STB for USB ports at JUSB1/JUSBLAN1. JUSBPWR2: +5V STB for USB ports at front (JUSB2/JUSB3).

1

JUSBPWR1 1

3 Pin 1-2 close

3 3 1

JUSBPWR2

1 3 Pin 2-3 close

17

Motherboard Manual

CHAPTER 4: RAID FUNCTIONS 4.1

OPERATING SYSTEM

s Windows XP, Windows Vista, and Windows 7.

4.2

RAID ARRAYS

RAID s the following types of RAID arrays: RAID 0: RAID 0 defines a disk striping scheme that improves disk read and write times for many applications. RAID 1: RAID 1 defines techniques for mirroring data.

4.3

HOW RAID WORKS

RAID 0: The controller “stripes” data across multiple drives in a RAID 0 array system. It breaks up a large file into smaller blocks and performs disk reads and writes across multiple drives in parallel. The size of each block is determined by the stripe size parameter, which you set during the creation of the RAID set based on the system environment. This technique reduces overall disk access time and offers high bandwidth.

Features and Benefits ­ ­ ­ ­ ­

Drives: Minimum 2, and maximum is up to 6 or 8. Depending on the platform. Uses: Intended for non-critical data requiring high data throughput, or any environment that does not require fault tolerance. Benefits: provides increased data throughput, especially for large files. No capacity loss penalty for parity. Drawbacks: Does not deliver any fault tolerance. If any drive in the array fails, all data is lost. Fault Tolerance: No.

Block 1 Block 3 Block 5

18

Block 2 Block 4 Block 6

N68S3B

RAID 1: Every read and write is actually carried out in parallel across 2 disk drives in a RAID 1 array system. The mirrored (backup) copy of the data can reside on the same disk or on a second redundant drive in the array. RAID 1 provides a hot-standby copy of data if the active volume or drive is corrupted or becomes unavailable because of a hardware failure. RAID techniques can be applied for high-availability solutions, or as a form of automatic backup that eliminates tedious manual backups to more expensive and less reliable media.

Features and Benefits ­ ­ ­ ­ ­

Drives: Minimum 2, and maximum is 2. Uses: RAID 1 is ideal for small databases or any other application that requires fault tolerance and minimal capacity. Benefits: Provides 100% data redundancy. Should one drive fail, the controller switches to the other drive. Drawbacks: Requires 2 drives for the storage space of one drive. Performance is impaired during drive rebuilds. Fault Tolerance: Yes.

Block 1 Block 2 Block 3

Block 1 Block 2 Block 3

19

Motherboard Manual

CHAPTER 5: USEFUL HELP 5.1

DRIVER INSTALLATION NOTE After you installed your operating system, please insert the Fully Setup Driver CD into your optical drive and install the driver for better system performance. You will see the following window after you insert the CD

The setup guide will auto detect your motherboard and operating system. Note: If this window didn’t show up after you insert the Driver CD, please use file browser to locate and execute the file SETUP.EXE under your optical drive.

A. Driver Installation To install the driver, please click on the Driver icon. The setup guide will list the compatible driver for your motherboard and operating system. Click on each device driver to launch the installation program.

B. Software Installation To install the software, please click on the Software icon. The setup guide will list the software available for your system, click on each software title to launch the installation program.

C. Manual Aside from the paperback manual, we also provide manual in the Driver CD. Click on the Manual icon to browse for available manual. Note: You will need Acrobat Reader to open the manual file. Please the latest version of Acrobat Reader software from http://www.adobe.com/products/acrobat/readstep2.html 20

N68S3B

5.2

SOFTWARE

Installing Software 1. Insert the Setup CD to the optical drive. The drivers installation program would appear if the Autorun function has been enabled. 2. Select Software Installation, and then click on the respective software title. 3. Follow the on-screen instructions to complete the installation.

BIOScreen Utility This utility allows you to personalize your boot logo easily. You can choose JPG or BMP as your boot logo so as to customize your computer.

Please follow the following instructions to update boo logo: 1. Load Image：Choose the picture as the boot logo. 2. Transform：Transform the picture for BIOS and preview the result. 3.

Update Bios：Write the picture to BIOS Memory to complete the update. 21

Motherboard Manual

BIOS Update BIOS Update is a convenient utility which allows you to update your motherboard BIOS under Windows system. AWARD BIOS

Show current BIOS information

Clear CMOS function (Only for AWARD BIOS)

Save current BIOS to a .bin file

Update BIOS with a BIOS file

Once click on this button, the saving dialog will show. Choose the position to save file and enter file name. (We recommend that the file name should be English/number and no longer than 7 characters.) Then click Save.

22

AMI BIOS

N68S3B Before doing this, please the proper BIOS file from the website. For AWARD BIOS, update BIOS procedure should be run with Clear CMOS function, so please check on Clear CMOS first. Then click Update BIOS button, a dialog will show for asking you backup current BIOS. Click Yes for BIOS backup and refer to the Backup BIOS procedure; or click No to skip this procedure.

After the BIOS Backup procedure, the open dialog will show for requesting the BIOS file which is going to be updated. Please choose the proper BIOS file for updating, then click on Open.

The utility will update BIOS with the proper BIOS file, and this process may take minutes. Please do not open any other applications during this process.

After the BIOS Update process, click on OK to restart the system.

While the system boots up and the full screen logo shows, press key to enter BIOS setup.



In the BIOS setup, use the Load Optimized Defaults function and then Save and Exit Setup to exit BIOS setup. BIOS Update is completed.

All the information and content above about the software are subject to be changed without notice. For better performance, the software is being continuously updated. The information and pictures described above are for your reference only. The actual information and settings on board may be slightly different from this manual. 23

Motherboard Manual

5.3

EXTRA INFORMATION

U Overheated If the system shutdown automatically after power on system for seconds, that means the U protection function has been activated. When the U is over heated, the motherboard will shutdown automatically to avoid a damage of the U, and the system may not power on again. In this case, please double check: 1. The U cooler surface is placed evenly with the U surface. 2. U fan is rotated normally. 3. U fan speed is fulfilling with the U speed. After confirmed, please follow steps below to relief the U protection function. 1. Remove the power cord from power supply for seconds. 2. Wait for seconds. 3. Plug in the power cord and boot up the system. Or you can: 1. Clear the CMOS data. (See “Close CMOS Header: JCMOS1” section) 2. Wait for seconds. 3. Power on the system again.

24

N68S3B

5.4

AMI BIOS BEEP CODE

Boot Block Beep Codes Number of Beeps 1 2 3 4 5 7 10 11 12 13

Description No media present. (Insert diskette in floppy drive A:) “AMIBOOT.ROM” file not found in root directory of diskette in A: Insert next diskette if multiple diskettes are used for recovery Flash Programming successful File read error No Flash EPROM detected Flash Erase error Flash Program error “AMIBOOT.ROM” file size error BIOS ROM image mismatch (file layout does not match image present in flash device)

POST BIOS Beep Codes Number of Beeps 1 3 6 7 8

Description Memory refresh timer error Base memory read/write test error Keyboard controller BAT command failed General exception error (processor exception interrupt error) Display memory error (system video adapter)

Troubleshooting POST BIOS Beep Codes Number of Beeps 1, 3

6, 7

8

Troubleshooting Action Reseat the memory, or replace with known good modules. Fatal error indicating a serious problem with the system. Consult your system manufacturer. Before declaring the motherboard beyond all hope, eliminate the possibility of interference by a malfunctioning add-in card. Remove all expansion cards except the video adapter. z If beep codes are generated when all other expansion cards are absent, consult your system manufacturer’s technical . z If beep codes are not generated when all other expansion cards are absent, one of the add-in cards is causing the malfunction. Insert the cards back into the system one at a time until the problem happens again. This will reveal the malfunctioning card. If the system video adapter is an add-in card, replace or reseat the video adapter. If the video adapter is an integrated part of the system board, the board may be faulty. 25

Motherboard Manual

5.5

TROUBLESHOOTING Probable

1.

There is no power in the system. Power LED does not shine; the fan of the power supply does not work 2. Indicator light on keyboard does not shine. System is inoperative. Keyboard lights are on, power indicator lights are lit, and hard drives are running. System does not boot from a hard disk drive, but can be booted from optical drive.

Solution 1. 2. 3.

Make sure power cable is securely plugged in. Replace cable. technical .

Using even pressure on both ends of the DIMM, press down firmly until the module snaps into place. 1. Check cable running from disk to disk controller board. Make sure both ends are securely plugged in; check the drive type in the standard CMOS setup. 2. Backing up the hard drive is extremely important. All hard disks are capable of breaking down at any time. System only boots from an optical 1. Back up data and applications drive. Hard disks can be read, files. applications can be used, but system 2. Reformat the hard drive. fails to boot from a hard disk. Re-install applications and data using backup disks. Screen message shows “Invalid Review system’s equipment. Make sure Configuration” or “CMOS Failure.” correct information is in setup. System cannot boot after installs a 1. Set master/slave jumpers second hard drive. correctly. 2. Run SETUP program and select correct drive types. Call the drive manufacturers for compatibility with other drives.

26

N68S3B

This page is intentionally left blank.

27

Motherboard Manual

APPENDIX: SPEC IN OTHER LANGUAGES GERMAN Spezifikationen

U

Sockel AM3

Die AMD 64-Architektur unterstützt eine 32-Bit- und

AMD Phenom II/ Athlon II Prozessoren

64-Bit-Datenverarbeitung

(Maximales Watt: 95W)

Unterstützt Hyper Transport 2.0

Unterstützt HyperTransport 2.0 mit einer FSB Chipsatz

Bandbreite von bis zu 2.0 GT/s GeForce 7025/nForce 630a Low Pin Count-Schnittstelle

ITE8716F Super E/A

Bietet die häufig verwendeten alten Super E/A-Funktionen.

Umgebungskontrolle, Hardware-Überwachung "Smart Guardian"-Funktion von ITE

DDR3 DIMM-Steckplätze x 2

Dual-Kanal DDR3 Speichermodul

Arbeitsspeich Max. 8GB Arbeitsspeicher

Unterstützt DDR3 800 / 1066 / 1333

Jeder DIMM unterstützt 512MB/

registrierte DIMMs. ECC DIMMs werden nicht

1GB/2GB/4GB DDR3.

unterstützt.

Grafik

Integrierter GeForce 7025-Chipsatz

Max. 512 MB gemeinsam benutzter Videospeicher

IDE

Integrierter IDE-Controller

SATA

Integrierter Serial ATA-Controller

LAN

Realtek RTL 8201CL

er

Ultra DMA 33 / 66 / 100 / 133 Bus Master-Modus Unterstützt PIO-Modus 0~4, Datentransferrate bis zu 3 Gb/s Konform mit der SATA-Spezifikation Version 2.0. 10 / 100 Mb/s Auto-Negotiation Halb-/ Vollduplex-Funktion

HD 5.1-Kanal-Audioausgabe

Audio-Unters VT1708B

Unterstützt High-Definition Audio

tützung PCI Express x16 Steckplatz

x1

PCI-Steckplatz

x1

Onboard-Ans IDE-Anschluss

x1

Jeder Anschluss unterstützt 2 IDE-Laufwerke

SATA-Anschluss

x2

Jeder Anschluss unterstützt 1 SATA-Laufwerk

Fronttafelanschluss

x1

Unterstützt die Fronttafelfunktionen

Front-Audioanschluss

x1

Unterstützt die Fronttafel-Audioanschlussfunktion

Steckplätze

chluss

28

N68S3B Spezifikationen U-Lüfter-Sockel

x1

System-Lüfter-Sockel

x1

"CMOS löschen"-Sockel

x1

USB-Anschluss

x2

Stromanschluss (24-polig)

x1

Stromanschluss (4-polig)

x1

Druckeranschluss Anschluss

x1

PS/2-Tastatur

x1

PS/2-Maus

x1

Rückseiten-E VGA-Anschluss

x1

LAN-Anschluss

x1

/A

Platinengröß

USB-Anschluss

x4

Audioanschluss

x3

U-Lüfterstromversorgungsanschluss (mit Smart Fan-Funktion) System-Lüfter-Stromversorgungsanschluss

Jeder Anschluss unterstützt 2 Fronttafel-USB-Anschlüsse

Jeder Anschluss unterstützt 1 Druckeranschluss

170 mm (B) X 235 mm (L)

e Sonderfunkti

Unterstützt RAID 0 / 1

onen OS-Unterstü tzung

Biostar behält sich das Recht vor, ohne Ankündigung Windows XP / Vista / 7

die Unterstützung für ein Betriebssystem hinzuzufügen oder zu entfernen.

29

Motherboard Manual

FRENCH SPEC Socket AM3 UC

Processeurs AMD Phenom II/ Athlon II (Watt maximum : 95W)

Bus frontal Chipset

Prend en charge Hyper Transport 2.0

Prend en charge Hyper Transport 2.0 jusqu'à une bande ante de 2.0 GT/s GeForce 7025/nForce 630a Interface à faible compte de broches

ITE 8728 Super E/S

L'architecture AMD 64 permet le calcul 32 et 64 bits

Fournit la fonctionnalité de Super E/S patrimoniales la plus utilisée.

Initiatives de contrôle environnementales, Moniteur de matériel Fonction "Gardien intelligent" de l'ITE

Fentes DDR3 DIMM x 2

Module de mémoire DDR3 à mode à double voie

Mémoire

Capacité mémoire maximale de 8 Go

Prend en charge la DDR3 800 / 1066 / 1333

principale

Chaque DIMM prend en charge des DDR3 Les DIMM à registres et DIMM avec code correcteurs de 512Mo/1Go/2Go/4Go

d'erreurs ne sont pas prises en charge

Graphiques Integré dans la chipset GeForce 7025

IDE

Contrôleur IDE intégré

SATA

Contrôleur Serial ATA intégré

LAN

Realtek RTL 8201CL

Mode principale de Bus Ultra DMA 33 / 66 / 100 / 133 Prend en charge le mode PIO 0~4, Taux de transfert jusqu'à 3 Go/s. Conforme à la spécification SATA Version 2.0 10 / 100 Mb/s négociation automatique Half / Full duplex capability

Prise en charge

Sortie audio à 5.1 voies

VT1708B

Prise en charge de l'audio haute définition

audio HD Fentes Connecteur embarqué

Fente PCI Express x16

x1

Fente PCI

x1

Connecteur IDE

x1

Connecteur SATA

x2

Connecteur du panneau avant

x1

Connecteur Audio du panneau avant x1

30

Mémoire vidéo partagée maximale de 512 Mo

Chaque connecteur prend en charge 2 périphériques IDE Chaque connecteur prend en charge 1 périphérique SATA Prend en charge les équipements du panneau avant Prend en charge la fonction audio du panneau avant

N68S3B SPEC Embase de ventilateur UC

x1

Embase de ventilateur système

x1

Embase d'effacement CMOS

x1

Connecteur USB

x2

Connecteur d'alimentation

x1

Alimentation électrique du ventilateur UC (avec fonction de ventilateur intelligent) Alimentation électrique du ventilateur système

Chaque connecteur prend en charge 2 ports USB de panneau avant

(24 broches) Connecteur d'alimentation

x1

(4 broches)

E/S du panneau arrière

Connecteur de Port d'imprimante

x1

Clavier PS/2

x1

Souris PS/2

x1

Port VGA

x1

Port LAN

x1

Port USB

x4

Fiche audio

x3

Chaque connector prend en charge 1 Port d'imprimante

Dimension s de la

170 mm (l) X 235 mm (H)

carte Fonctionnal ités

Prise en charge RAID 0 / 1

spéciales SE Windows XP / Vista / 7

Biostar se réserve le droit d'ajouter ou de supprimer le de SE avec ou sans préavis.

31

Motherboard Manual

ITALIAN SPECIFICA

U

FSB

Socket AM3

L’architettura AMD 64 abilita la co mputazione 32

Processori AMD Phenom II/ Athlon II

e 64 bit

(Watt massimo: 95W)

o di Hyper Transport 2.0

o di HyperTransport 2.0 fino a 2.0 GT/s di larghezza di banda

Chipset

GeForce 7025/nForce 630a Interfaccia LPC (Low Pin Count)

ITE 8728 Super I/O Fornisce le funzionalità legacy Super I/O usate più comunemente.

Monitoraggio hardware Funzione "Smart Guardian" di ITE

Alloggi DIMM DDR3 x 2 Memoria

Capacità massima della memoria 8GB

principale

Ciascun DIMM a DDR3

Modulo di memoria DDR3 a canale doppio o di DDR3 800 / 1066 / 1333 DIMM registrati e DIMM ECC non sono ati

512MB/1GB/2GB/4GB Grafica

Funzioni di controllo dell’ambiente:

Integrata nel Chipset GeForce 7025

La memoria video condivisa massima è di 512 MB Modalità Bus Master Ultra DMA 33 / 66 / 100 /

IDE

Controller IDE integrato

133 o modalità PIO Mode 0-4

SATA

LAN

Velocità di trasferimento dei dati fino a 3 Gb/s.

Controller Serial ATA integrato

Compatibile specifiche SATA Versione 2.0. Negoziazione automatica 10 / 100 Mb/s

Realtek RTL 8201CL

Capacità Half / Full Duplex

o audio HD Alloggi

Uscita audio 5.1 canali

VT1708B

o audio High-Definit ion (HD)

Alloggio PCI Express x16

x1

Alloggio PCI

x1

Connettori Connettore IDE

x1

Ciascun connettore a 2 unità IDE

su scheda Connettore SATA

x2

Ciascun connettore a 1 unità SATA

Connettore pannello frontale

x1

a i servizi del pannello frontale

Connettore audio frontale

x1

a la funzione audio pannello frontale

32

N68S3B SPECIFICA Collettore ventolina U

x1

Collettore ventolina sistema

x1

Collettore cancellaz ione CMOS

x1

Connettore USB

x2

Connettore alimentazione

x1

Alimentazione ventolina U (con funzione Smart Fan) Alimentazione ventolina di sistema

Ciascun connettore a 2 porte USB pannello frontale

(24 pin) Connettore alimentazione

x1

(4 pin)

I/O pannello posteriore

Dimension i scheda

Connettore Porta stampante

x1

Tastiera PS/2

x1

Mouse PS/2

x1

Porta VGA

x1

Porta LAN

x1

Porta USB

x4

Connettore audio

x3

Ciascun connettore a 1 Porta stampante

170 mm (larghezza) x 235 mm (altezza)

Caratterist iche

o RAID 0 / 1

speciali Sistemi operativi ati

Biostar si riserva il diritto di aggiungere o Windows XP / Vista / 7

rimuovere il o di qualsiasi sistema operativo senza preavviso.

33

Motherboard Manual

SPANISH Especificación

U

FSB

Conector AM3

La arquitectura AMD 64 permite el procesado de 32 y

Procesadores AMD Phenom II/ Athlon II

64 bits

(Vatio máximo: 95W)

Soporta las tecnologías Hyper Transport 2.0

ite HyperTransport 2.0 con un ancho de banda de hasta 2.0 GT/s

Conjunto de chips

GeForce 7025/nForce 630a Interfaz de cuenta Low Pin

ITE 8728 Súper E/S

Le ofrece las funcionalidades heredadas de uso más común Súper E/S.

Iniciativas de control de entorno, Monitor hardware Función "Guardia inteligente" de ITE

Ranuras DIMM DDR3 x 2

Módulo de memoria DDR3 de canal Doble

Memoria

Capacidad máxima de memoria de 8GB

ite DDR3 de 800 / 1066 / 1333

principal

Cada DIMM ite DDR de

No ite DIMM registrados o DIMM compatibles con

512MB/1GB/2GB/4GB

ECC

Gráficos

Integrados en el conjunto de chips

Memoria máxima de vídeo compartida de 512 MB

GeForce 7025 IDE

SATA

Red Local

Modo bus maestro Ultra DMA 33 / 66 / 100 / 133

Controlador IDE integrado

Soporte los Modos PIO 0~4, Tasas de transferencia de hasta 3 Gb/s.

Controlador ATA Serie Integrado

Compatible con la versión SATA 2.0. Negociación de 10 / 100 Mb/s

Realtek RTL 8201CL

Funciones Half / Full dúplex

Soporte de sonido HD Ranuras

34

Soporte de sonido Alta Definición

Ranura PCI Express x16

X1

Ranura PCI

X1

Conectores Conector IDE en placa

Salida de sonido de 5.1 canales

VT1708B

X1

Cada conector soporta 2 dispositivos IDE

Conector SATA

X2

Cada conector soporta 1 dispositivos SATA

Conector de frontal

X1

Soporta instalaciones en el frontal

N68S3B Especificación Conector de sonido frontal

X1

Soporta funciones de sonido en el frontal

Cabecera de ventilador de U

X1

Fuente de alimentación de ventilador de U (con función Smart Fan)

Cabecera de ventilador de sistema X1 Cabecera de borrado de CMOS

X1

Conector USB

X2

Conector de alimentación

X1

Fuente de alimentación de ventilador de sistema

Cada conector soporta 2 puertos USB frontales

(24 patillas) Conector de alimentación

X1

(4 patillas)

trasero de E/S

Tamaño de la placa Funciones especiales

Conector Puerto de impresora

X1

Teclado PS/2

X1

Ratón PS/2

X1

Puerto VGA

X1

Puerto de red local

X1

Puerto USB

X4

Conector de sonido

X3

170 mm. (A) X 235 Mm. (H)

ite RAID 0 / 1

Soporte de sistema operativo

Cada conector soporta 1 Puerto de impresora

Windows XP / Vista / 7

Biostar se reserva el derecho de añadir o retirar el soporte de cualquier SO con o sin aviso previo.

35

Motherboard Manual

PORTUGUESE ESPECIFICAÇÕES Socket AM3 U

A arquitectura AMD 64 permite uma computação de

Processadores AMD Phenom II/ Athlon II 32 e 64 bits (Watt máximo: 95W)

FSB Chipset Especificaç ão Super I/O

a as tecnologias Hyper Transport 2.0

a a tecnologia HyperTransport 2.0 com uma largura de banda até 2.0 GT/s GeForce 7025/nForce 630a ITE 8728

Interface LPC (Low Pin Count).

Proporciona as funcionalidades mais

Iniciativas para controlo do ambiente

utilizadas em termos da especificação

Monitorização do hardware

Super I/O.

Função "Smart Guardian" da ITE

Ranhuras DIMM DDR3 x 2 Memória principal

Capacidade máxima de memória: 8 GB Cada módulo DIMM a uma

gráfica

ados

Integrada no chipset GeForce 7025

IDE

Controlador IDE integrado

SATA

Controlador Serial ATA integrado

LAN

Realtek RTL 8201CL

a módulos DDR3 800 / 1066 / 1333 Os módulos DIMM registados e os DIMM ECC não são

memória DDR3 de 512MB/ 1GB/2GB/4GB

Placa

Módulo de memória DDR3 de canal duplo

Memória de vídeo máxima partilhada: 512 MB Modo Bus master Ultra DMA 33 / 66 / 100 / 133 a o modo PIO 0~4, Velocidades de transmissão de dados até 3 Gb/s. Compatibilidade com a especificação SATA versão 2.0. Auto negociação de 10 / 100 Mb/s Capacidade semi/full-duplex

e para áudio de alta

Saída de áudio de 5.1 canais

VT1708B

a a especificação High-Definition Audio

definição Ranhuras

Ranhura PCI Express x16

x1

Ranhura PCI

x1

Conectores Conector IDE

x1

Cada conector a 2 dispositivos IDE

na placa

Conector SATA

x2

Cada conector a 1 dispositivo SATA

Conector do frontal

x1

Para e de várias funções no frontal

36

N68S3B ESPECIFICAÇÕES Conector de áudio frontal

x1

Conector da ventoinha da U

x1

Conector da ventoinha do sistema x1 Conector para limpeza do CMOS

x1

Conector USB

x2

Conector de alimentação

x1

a a função de áudio no frontal Alimentação da ventoinha da U (com a função Smart Fan) Alimentação da ventoinha do sistema

Cada conector a 2 portas USB no frontal

(24 pinos) Conector de alimentação

x1

(4 pinos) Conector da para impressora

x1

Teclado PS/2

x1

Entradas/S Rato PS/2

x1

aídas no

Porta VGA

x1



Porta LAN

x1

traseiro

Porta USB

x4

Tomada de áudio

x3

Tamanho da placa

Cada conector a 1 Porta para impressora

170 mm (L) X 235 mm (A)

Característi cas

a as funções RAID 0 / 1

especiais A Biostar reserva-se o direito de adicionar ou remover

Sistemas operativos ados

Windows XP / Vista / 7

e para qualquer sistema operativo com ou sem aviso prévio.

37

Motherboard Manual

POLISH SPEC

Procesor

FSB Chipset

Socket AM3

Architektura AMD 64 umożliwia przetwarzanie 32 i 64

AMD Phenom II/ Athlon II Procesory

bitowe

(Maksymalny Watt: 95W)

Obsługa Hyper Transport 2.0

Obsługa HyperTransport 2.0 o szerokości pasma do 2.0 GT/s GeForce 7025/nForce 630a Gniazda DDR3 DIMM x 2

Moduł pamięci DDR3 z trybem podwójnego kanału

Pamięć

Maks. wielkość pamięci 8GB

główna

Każde gniazdo DIMM obsługuje moduły

Obsługa DDR3 800 / 1066 / 1333 Brak obsługi ed DIMM oraz ECC DIMM

512MB/1GB/2GB/4GB DDR3 Interfejs Low Pin Count

ITE 8728 Super I/O

Funkcje kontroli warunków pracy,

Zapewnia najbardziej powszechne

Monitor H/W

funkcje Super I/O.

Funkcja ITE "Smart Guardian"

Grafika

Zintegrowana w chipsecie GeForce 7025

IDE

Zintegrowany kontroler IDE

SATA

Zintegrowany kontroler Serial ATA

LAN

Realtek RTL 8201CL

Obsługa audio HD

Maks. wielkość współdzielonej pamięci video wynosi 512 MB Ultra DMA 33 / 66 / 100 / 133 Tryb Bus Master obsługa PIO tryb 0~4, Transfer danych do 3 Gb/s. Zgodność ze specyfikacją SATA w wersji 2.0. 10 / 100 Mb/s z automatyczną negocjacją szybkości Działanie w trybie połowicznego / pełnego dupleksu 5.1 kanałowe wyjście audio

VT1708B

Obsługa High-Definition Audio

Gniazdo PCI Express x16

x1

Gniazdo PCI

x1

Złącza

Złącze IDE

x1

Każde złącze obsługuje 2 urządzenia IDE

wbudowan

Złącze SATA

x2

Każde złącze obsługuje 1 urządzenie SATA

e

Złącze a przedniego

x1

Obsługa elementów a przedniego

Przednie złącze audio

x1

Obsługa funkcji audio na u przednim

Gniazda

38

N68S3B SPEC Złącze główkowe wentylatora procesora

Zasilanie wentylatora procesora (z funkcją Smart Fan)

x1 Złącze główkowe wentylatora

Zasilanie wentylatora systemowego

systemowego x1 Złącze główkowe kasowania CMOS x1 Złącze USB

x2

Każde złącze obsługuje 2 porty USB na u przednim

Złącze zasilania (24 pinowe)

x1

Złącze zasilania (4 pinowe)

x1

Złącze Port drukarki

x1

Klawiatura PS/2

x1

Mysz PS/2

x1

Back Port VGA

x1

I/O

Port LAN

x1

Port USB

x4

Gniazdo audio

x3

Wymiary płyty Funkcje

Każde złącze obsługuje 1 Port drukarki

170 mm (S) X 235 mm (W)

Obsługa RAID 0 / 1

specjalne Obsluga systemu operacyjne

Biostar zastrzega sobie prawo dodawania lub Windows XP / Vista / 7

odwoływania obsługi dowolnego systemu operacyjnego bez powiadomienia.

go

39

Motherboard Manual

RUSSIAN СПЕЦ U Архитектура AMD 64 разрешать обработка данных

(централь

Гнездо AM3

ный

Процессоры AMD Phenom II/ Athlon II

процессор (Максимальный ватт: 95W)

на 32 и 64 бит Поддержка Hyper Transport 2.0

) FSB Набор микросхем

Поддержка HyperTransport 2.0 с пропускной способностью до 2.0 GT/s GeForce 7025/nForce 630a Слоты DDR3 DIMM x 2

Модуль памяти с двухканальным режимом DDR3

Основная

Максимальная ёмкость памяти 8 ГБ

Поддержка DDR3 800 / 1066 / 1333

память

Каждый модуль DIMM поддерживает

Не поддерживает зарегистрированные модули

512МБ/1ГБ/2ГБ/4ГБ DDR3

DIMM and ECC DIMM Интерфейс с низким количеством выводов

ITE 8728 Super I/O

Обеспечивает наиболее используемые действующие функциональные

IDE

SATA Локальная сеть

Аппаратный монитор Функция ITE "Smart Guardian" (Интеллектуальная

возможности Super I/O.

Графика

Инициативы по охране окружающей среды,

защита)

Встроенная в набор микросхем GeForce Максимальная совместно используемая видео 7025

память составляет 512 МБ

Встроенное устройство управления

Режим "хозяина" шины Ultra DMA 33 / 66 / 100 / 133

встроенными интерфейсами устройств Поддержка режима PIO 0~4, Встроенное последовательное

скорость передачи данных до 3 гигабит/с.

устройство управления ATA

Соответствие спецификации SATA версия 2.0. Автоматическое согласование 10 / 100 Мб/с

Realtek RTL 8201CL

Частичная / полная дуплексная способность

Звуковая поддержка жесткого

Звуковая поддержка High-Definition

VT1708B

5.1канальный звуковой выход

диска Слоты Встроенны й разъём

40

Слот PCI Express x16

x1

Слот PCI

x1

Разъём IDE

x1

Каждый разъём поддерживает 2 встроенных интерфейса накопителей

Разъём SATA

x2

Каждый разъём поддерживает 1 устройство SATA

Разъём на лицевой панели

x1

Поддержка устройств на лицевой панели

Входной звуковой разъём

x1

Поддержка звуковых функций на лицевой панели

N68S3B СПЕЦ Контактирующее приспособление

Источник питания для вентилятора центрального

вентилятора центрального

процессора (с функцией интеллектуального

процессора

x1

Контактирующее приспособление вентилятора системы

x1

вентилятора) Источник питания для вентилятора системы

Открытое контактирующее приспособление CMOS

x1

USB-разъём

x2

Разъем питания (24 вывод)

x1

Разъем питания (4 вывод)

x1

Разъём Порт подключения x1

Клавиатура PS/2

x1

Мышь PS/2

x1

панель

Порт VGA

x1

средств

Порт LAN

x1

ввода-выв USB-порт

x4

панели

принтера

Гнездо для подключения наушников

Размер

лицевой панели

Каждый разъём поддерживает 1 Порт подключения

принтера

Задняя

ода

Каждый разъём поддерживает 2 USB-порта на

x3

170 мм (Ш) X 235 мм (В)

Специальн ые техническ ие

Поддержка RAID 0 / 1

характери стики Поддержк а OS

Biostar сохраняет за собой право добавлять или Windows XP / Vista / 7

удалять средства обеспечения для OS с или без предварительного уведомления.

41

‫‪Motherboard Manual‬‬

‫‪ARABIC‬‬ ‫اﻟﻤﻮاﺻﻔﺎت‬ ‫‪AM3‬ﻡﻘﺒﺲ‬

‫إﺟﺮاء اﻟﻌﻤﻠﻴﺎت اﻟﺤﺎﺳﻮﺑﻴﺔ ﺑﺴﺮﻋﺔ ‪ 32‬و‪ 64‬ﺑﺖ‪AMD 64‬ﺗﻤﻜﻦ ﺗﻘﻨﻴﺔ‬

‫وﺡﺪة اﻟﻤﻌﺎﻟﺠﺔ‬ ‫اﻟﻤﺮآﺰیﺔ‬

‫‪AMD Phenom II/ Athlon II‬ﻡﻌﺎﻟﺠﺎت‬

‫و ‪Hyper Transport2.0‬ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔ‬

‫)و‪: 95‬ﻗﺼ ﻮى واط(‬ ‫اﻟﻨﺎﻗﻞ اﻷﻡﺎﻡﻲ اﻟﺠﺎﻥﺒﻲ ‪ 2.0 GT/s‬ﺑﺘﺮدد یﺼﻞ إﻟﻰ ‪HyperTransport 2.0‬ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔ‬ ‫ﻡﺠﻤﻮﻋﺔ اﻟﺸﺮاﺋﺢ‬

‫‪GeForce 7025/nForce 630a‬‬ ‫‪Low Pin Count Interface‬ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔ‬

‫‪Super I/O‬‬

‫‪ITE 8728‬‬

‫وﺳﺎﺋﻞ اﻟﺘﺤﻜﻢ ﻓﻲ اﻟﺒﻴﺌﺔ‪:‬‬

‫اﻷآﺜﺮ اﺳﺘﺨﺪاﻡًﺎ‪Super I/O .‬ﺗﻮﻓﺮ وﻇﻴﻔﺔ‬

‫ﻡﺮاﻗﺐ ﻟﻤﻌﺮﻓﺔ ﺡﺎﻟﺔ اﻷﺟﻬﺰة‬ ‫‪ ITE‬ﻡﻦ "‪"Smart Guardian‬وﻇﻴﻔﺔ‬

‫ﻓﺘﺤﺔ ‪DDR3 DIMM‬‬ ‫اﻟﺬاآﺮة اﻟﺮﺋﻴﺴﻴﺔ‬

‫ﻋﺪد‪2‬‬

‫ﺳﻌﺔ ذاآﺮة ﻗﺼﻮى ‪ 8‬ﺟﻴﺠﺎ ﺑﺎیﺖ‬

‫ﻡﺰدوﺟﺔ اﻟﻘﻨﺎة‪DDR3‬وﺡﺪة ذاآﺮة‬ ‫ﺳﻌﺎت ‪ 1333 / 1066 / 800‬ﻡﻴﺠﺎ ﺑﺎیﺖ‪DDR3‬ﺗﺪﻋﻢ اﻟﺬاآﺮة ﻡﻦ ﻥﻮع‬

‫ﻡﻴﺠﺎ ﺑﺎیﺖ ‪ /512‬ﺳﻌﺔ ‪ DDR3‬ﺗﺪﻋﻢ ذاآﺮة ﻡﻦ ﻥﻮع ‪DIMM‬ﺗﺪﻋﻢ آﻞ ﻓﺘﺤﺔ‬

‫‪ ECC‬وﺗﻠﻚ اﻟﺘﻲ ﻻ ﺗﺘﻮاﻓﻖ ﻡﻊ ‪DIMM‬ﻻ ﺗﺪﻋﻢ رﻗﺎﺋﻖ اﻟﺬاآﺮة‬

‫و‪ /1‬و‪ /2‬و‪ 4‬ﺟﻴﺠﺎ ﺑﺎیﺖ‬ ‫ﺑﻄﺎﻗﺔ اﻟﺮﺳﻮﻡﺎت‬

‫‪ GeForce 7025‬ﻡﺪﻡﺠﺔ ﻓﻲ رﻗﺎﺋﻖ‬

‫ﻡﻨﻔﺬ ‪IDE‬‬

‫ﻡﺘﻜﺎﻡﻞ‪IDE‬ﻡﺘﺤﻜﻢ‬

‫‪SATA‬‬

‫ﻡﺘﻜﺎﻡﻞ‪Serial ATA‬ﻡﺘﺤﻜﻢ‬

‫ﺵﺒﻜﺔ داﺥﻠﻴﺔ‬

‫یﺠﺎ ﺑﺎیﺖ‪512‬أﻗﺼﻰ ﺳﻌﺔ ﻟﺬاآﺮة اﻟﻔﻴﺪیﻮ اﻟﻤﺸﺘﺮآﺔ‬ ‫وﺿﻊ رﺋﻴﺴﻲ‪Ultra DMA 33 / 66 / 100 / 133‬ﻥﺎﻗﻞ ﺑﺘﻘﻨﻴﺔ‬ ‫‪PIO Mode 0~4‬دﻋﻢ وﺿﻊ‬ ‫ﺟﻴﺠﺎﺑﺖ‪/‬ﺙﺎﻥﻴﺔ‪3.‬ﻥﻘﻞ اﻟﺒﻴﺎﻥﺎت ﺑﺴﺮﻋﺎت ﺗﺼﻞ إﻟﻰ‬ ‫‪ 2.0.‬اﻹﺹﺪار ‪SATA‬ﻡﻄﺎﺑﻘﺔ ﻟﻤﻮاﺹﻔﺎت‬ ‫ﺗﻔﺎوض ﺗﻠﻘﺎﺋﻲ ‪ 100/10‬ﻡﻴﺠﺎ ﺑﺎیﺖ ‪ /‬ﺙﺎﻥﻴﺔ‬

‫‪Realtek RTL 8201CL‬‬

‫إﻡﻜﺎﻥﻴﺔ اﻟﻨﻘﻞ اﻟﻤﺰدوج اﻟﻜﺎﻡﻞ‪/‬اﻟﻨﺼﻔﻲ‬ ‫ﻗﻨﻮات ﻟﺨﺮج اﻟﺼﻮت‪5.1‬‬

‫دﻋﻢ اﻟﺼﻮت ﻋﺎﻟﻲ‬ ‫اﻟﺘﻌﺮیﻒ‬

‫‪VT1708B‬‬

‫ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔ اﻟﺼﻮت ﻋﺎﻟﻲ اﻟﺘﻌﺮیﻒ ﻡﻦ‬

‫ﻓﺘﺤﺔ ‪PCI Express x16‬‬

‫ﻋﺪد ‪1‬‬

‫ﻓﺘﺤﺔ ‪PCI‬‬

‫ﻋﺪد‪1‬‬

‫اﻟﻤﻨﺎﻓﺬ ﻋﻠﻰ ﺳﻄﺢ‬

‫ﻡﻨﻔﺬ ‪IDE‬‬

‫ﻋﺪد ‪1‬‬

‫‪IDE‬یﺪﻋﻢ آﻞ ﻡﻨﻔﺬ اﺙﻨﻴﻦ ﻡﻦ أﺟﻬﺰة‬

‫اﻟﻠﻮﺡﺔ‬

‫ﻡﻨﻔﺬ ‪SATA‬‬

‫ﻋﺪد‪2‬‬

‫‪SATA‬یﺪﻋﻢ آﻞ ﻡﻨﻔﺬ واﺡﺪ ﻡﻦ أﺟﻬﺰة‬

‫ﻡﻨﻔﺬ اﻟﻠﻮﺡﺔ اﻷﻡﺎﻡﻴﺔ‬

‫ﻋﺪد ‪1‬‬

‫یﺪﻋﻢ ﺗﺠﻬﻴﺰات اﻟﻠﻮﺡﺔ اﻷﻡﺎﻡﻴﺔ‬

‫ﻡﻨﻔﺬ اﻟﺼﻮت اﻷﻡﺎﻡﻲ‬

‫ﻋﺪد ‪1‬‬

‫یﺪﻋﻢ وﻇﻴﻔﺔ اﻟﺼﻮت ﺑﺎﻟﻠﻮﺡﺔ اﻷﻡﺎﻡﻴﺔ‬

‫اﻟﻔﺘﺤﺎت‬

‫‪42‬‬

‫‪N68S3B‬‬ ‫اﻟﻤﻮاﺻﻔﺎت‬

‫وﺹﻠﺔ ﻡﺮوﺡﺔ وﺡﺪة اﻟﻤﻌﺎﻟﺠﺔ اﻟﻤﺮآﺰیﺔ‬

‫ﻋﺪد ‪1‬‬

‫‪Smart Fan‬ﻟﺘﻮﺹﻴﻞ اﻟﻄﺎﻗﺔ ﻟﻤﺮوﺡﺔ وﺡﺪة اﻟﻤﻌﺎﻟﺠﺔ ﻡﻊ وﻇﻴﻔﺔ‬

‫وﺹﻠﺔ ﻡﺮوﺡﺔ اﻟﻨﻈﺎم‬

‫ﻋﺪد ‪1‬‬

‫ﻟﺘﻮﺹﻴﻞ اﻟﻄﺎﻗﺔ ﻟﻤﺮوﺡﺔ اﻟﻨﻈﺎم‬

‫وﺹﻠﺔ ﻡﺴﺢ ‪CMOS‬‬

‫ﻋﺪد ‪1‬‬

‫ﻡﻨﻔﺬ ‪USB‬‬

‫ﻋﺪد ‪2‬‬

‫ﻡﻨﻔﺬ ﺗﻮﺹﻴﻞ اﻟﻄﺎﻗﺔ )‪24‬دﺑﻮس(‬

‫ﻋﺪد ‪1‬‬

‫ﻡﻨﻔﺬ ﺗﻮﺹﻴﻞ اﻟﻄﺎﻗﺔ )‪4‬دﺑﻮس(‬

‫ﻋﺪد ‪1‬‬

‫ﻡﻨﻔﺬ ﻃﺎﺑﻌﺔ‬

‫ﻋﺪد ‪1‬‬

‫ﻟﻮﺡﺔ ﻡﻔﺎﺗﻴﺢ ‪PS/2‬‬

‫ﻋﺪد ‪1‬‬

‫ﻡﺎوس ‪PS/2‬‬

‫ﻋﺪد ‪1‬‬

‫ﻡﻨﺎﻓﺬ دﺥﻞ‪/‬ﺥﺮج‬

‫ﻡﻨﻔﺬ ‪VGA‬‬

‫ﻋﺪد ‪1‬‬

‫اﻟﻠﻮﺡﺔ اﻟﺨﻠﻔﻴﺔ‬

‫ﻡﻨﻔﺬ ﺵﺒﻜﺔ اﺗﺼﺎل ﻡﺤﻠﻴﺔ‬

‫ﻋﺪد ‪1‬‬

‫ﻡﻨﺎﻓﺬ ‪USB‬‬

‫ﻋﺪد‪4‬‬

‫ﻡﻘﺒﺲ ﺹﻮت‬

‫ﻋﺪ‪3‬‬

‫ﺡﺠﻢ اﻟﻠﻮﺡﺔ‬

‫‪ 170‬ﻡﻢ )ﻋﺮض( ‪ 235 X‬ﻡﻢ )ارﺗﻔﺎع(‬

‫ﻡﺰایﺎ ﺥﺎﺹﺔ‬

‫‪RAID 0 / 1‬ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔ‬

‫دﻋﻢ أﻥﻈﻤﺔ اﻟﺘﺸﻐﻴﻞ‬

‫‪Windows XP / Vista / 7‬‬

‫ﺑﺎﻟﻠﻮﺡﺔ اﻷﻡﺎﻡﻴﺔ‪USB‬یﺪﻋﻢ آﻞ ﻡﻨﻔﺬ ﻓﺘﺤﺘﻲ‬

‫ﺑﺤﻘﻬﺎ ﻓﻲ إﺿﺎﻓﺔ أو إزاﻟﺔ اﻟﺪﻋﻢ ﻷي ﻥﻈﺎم ﺗﺸﻐﻴﻞ ﺑﺈﺥﻄﺎر أو ‪Biostar‬ﺗﺤﺘﻔﻆ‬ ‫ﺑﺪون إﺥﻄﺎر‪.‬‬

‫‪43‬‬

Motherboard Manual

JAPANESE 仕様

U

FSB

Socket AM3

AMD 64アーキテクチャでは、32ビットと64ビット計算が可

AMD Phenom II/ Athlon II プロセッサ

能です

(最高のワット: 95W)

ハイパートランスポート2.0サポートします

2.0 GT/sのバンド幅までハイパートランスポ ート2.0をサポートします

チップセッ

GeForce 7025/nForce 630a

ト DDR3 DIMMスロット x 2 デュアル チャンネルモードDDR3メモリモジュール メインメモ

最大メモリ容量8GB

リ

各DIMMは 512MB/1GB/2GB/4GB DDR3

DDR3 800 / 1066 / 1333 をサポート 登録済みDIMMとECC DIMMはサポートされません をサポート 低ピンカウントインターフェイス

ITE 8728 Super I/O

もっとも一般に使用されるレガシーSuper I/O 機能を採用しています。

グラフィッ

環境コントロールイニシアチブ、 H/Wモニター ITEの「スマートガーディアン」機能

GeForce 7025チップセットに統合

最大の共有ビデオメモリは512 Bです

クス IDE

統合IDEコントローラ

SATA

統合シリアルATAコントローラ

LAN

Realtek RTL 8201CL

Ultra DMA 33 / 66 / 100 / 133バスマスタモード PIO Mode 0~4のサポート、 最高3Gb/秒のデータ転送速度 SATAバージョン2.0仕様に準拠。 10 / 100 Mb/秒のオートネゴシエーション 半/全二重機能

HDオーディ オのサポー

5.1チャンネルオーディオアウト

VT1708B

ハイデフィニションオーディオのサポート ト スロット

オンボード コネクタ

44

PCI Express x16スロット

x1

PCIスロット

x1

IDEコネクタ

x1

SATAコネクタ

x2

各コネクタは1つのSATAデバイスをサポートします

フロントパネルコネクタ

x1

フロントパネル機能をサポートします

各コネクタは2つのIDEデバイスをサポートします

N68S3B 仕様 フロントオーディオコネクタ

x1

フロントパネルオーディオ機能をサポートします

Uファンヘッダ

x1

Uファン電源装置(スマートファン機能を搭載)

システムファンヘッダ

x1

システムファン電源装置

CMOSクリアヘッダ

x1

USBコネクタ

x2

各コネクタは2つのフロントパネルUSBポートをサポートし ます

電源コネクタ(24ピン)

x1

電源コネクタ(4ピン)

x1

プリンタポートコネクタ

x1

PS/2キーボード

x1

PS/2マウス

x1

背面パネル

VGAポート

x1

I/O

LANポート

x1

USBポート

x4

オーディオジャック

x3

ボードサイ

各コネクタは1つのプリンタポートをサポートします

170 mm (幅) X 235 mm (高さ)

ズ 特殊機能

RAID 0 / 1 のサポート

OSサポート Windows XP / Vista / 7

Biostarは事前のサポートなしにOSサポートを追加または削 除する権利を留保します。

2010/11/12

45
