XML Publisher

August 2011

Agenda ● Pre-Requisite ● Overview

● XML Publisher & Other Reporting Tools ● XML Publisher Report Generation – Configure XML Publisher – – – – –

Creating Data Source ing Data Source Creating Template Creating Report Definitions Viewing the Report

● XML Reports Using Application Engine ● XML Publisher Security ● Reference 2

Pre-Requisite – Adequate knowledge of ● PeopleCode ● Application Engine ● PS Query ● App Packages – Basic Formatting knowledge of ● MS Word ● MS Excel ● RTF documents

3

XML Publisher Overview ● XML Publisher is an Oracle tool that has been ported over to the PeopleSoft enterprise ERP suite ● It is a template based reporting mechanism which could be used for formatting pre-extracted data. ● As extraction of data and formatting the data are independent processes, XML Publisher allows us to reuse the same data for multiple report formats. ● Report templates can be created using Microsoft Word, Excel, Adobe Acrobat, etc.

● The data source itself could be a PeopleSoft Query, or a Rowset, or an XML files or an XML Doc object

4

XML Publisher Overview Separate data / layout / UI translation

Data Logic

XML Publisher Report output

Layout Flexibility Reduced maintenance 5

XML Publisher Overview SQL Query Row Set

EFT

Data Handler

DATA

XML

Banking EFT

Excel

Controller

HTML

XML Publisher

CEO

PDF

Template Manager

XML

Template

Government XML

B2B 6

XML Publisher Overview ● Following are some of the salient features of XML Publisher – Fast and scalable data retrieval – High fidelity formatting – Full range of charting capabilities – Multiple objects in one report – Multi table / forms layout – High degree of report interactivity (filter, sort, hide column etc.) – Conditional formatting – Broad range of formulas and functions

7

XML Publisher & Other Reporting Tools Tool

Pro

SQR

1. Flexible 1. May not be ed in Fusion 2. Can handle Complex Logic 2. The development can not be broken down into modular tasks. 3. Can run SQLs against a Database

Crystal

XML Publisher

8

1. What you see is what you get. 2. Easy to develop.

Con

1. Requires Crystal and driven through QUERY 2. Not capable of handling complex logic

1. What you see is what you get. 2. Can be driven via PeopleCode or Query. 1. Developer should have PeopleCode 3. Development Process can be skills. broken into logical sections – extraction of data and creation of template could be handled by two different individuals.

XML Publisher Report Generation Configure XML Publisher

Create Data Source

Data Source

Create and Templates

Define XML Publisher Reports

Run XML Publisher Reports View Published XMLP Reports 9

Configure XML Publisher ● Report Category: We can configure the XML Report Category using the following path. Navigation: Main Menu  Reporting Tools  XML Publisher  Setup  Report Category ● Report Category is a required attribute on all report definitions. By asg a report category, you are actually applying row level security to the data on those components

10

Configure XML Publisher ● Design Helper: This page enables s to a plug-in for Microsoft Word to facilitate offline RTF template design. Select the link to the tool ● Navigation: Main Menu  Reporting Tools  XML Publisher  Setup  Design Helper ● During template creation, a Design Helper facilitates the insertion of application data tag placeholders into your templates. A schema or sample data file is required for using a design helper

11

Configure XML Publisher ● Design Helper – Installation : – Install Java Runtime Environment (Ver 1.4 or higher) as XMLP requires Java (http://www.java.com/en//) – Before installing BIPublisherDesktop please close all open instances of Microsoft Office applications – Double click on the BIPublisherDesktop.exe from the ed files to install the plug-ins – After the installation is completed, we can see Add-Ins tab in the MS Word

12

Configure XML Publisher ● Permission Lists: – We can restrict the access to XML Publisher menu using PeopleSoft delivered Permission Lists and Roles – PeopleTools deliver permission list security and roles as shown in this table:

13

Permission List

Role

Intended for

PTPT2600

XMLP Report Developer

Report developers

PTPT2500

XMLP Power

Power s

Create Data Source ● Data Source is the file that feeds the merge process – merging the source data with the report template ● Each report must have a data source. ● XMLP provides the following data sources to choose from: Data Sources

XML File -SQR

Connected Query

XML File -PeopleCode

-PS Query

XML Data File 14

PS Query -PS Query

Create Data Source ● Create sample data to design your RTF template and map your PDF templates. ● However one could a Data source without sample data, as XML Publisher would access the Data file at runtime.

● One could generate the XML data using any means including PS/Query, SQR, Application Engine, PeopleCode, File Layout, and so forth.

15

Data Sources ● Navigation: Reporting Tools  XML Publisher  Data Source ● While using PS Query, click “Add a New Value”. Select PS Query as the Data Source type and click the Look Up Query and select the Query name. Click the “Add” button

16

Data Sources ● Enter the Data Source Description. Click Generate under the Generate File column for Sample Data File(.xml). Generate the schema file(.xsd). Save the XML file on the local Drive e.g. C:/Temp

17

Create Report Templates ● Sample File Generation: View and the XML file to be loaded into the report template using the following link and save into the local drive

18

Create Report Templates ● Template design involves the construction of a report‟s layout in a template file and is dependent upon what the core Oracle XML Publisher engine accept for processing ● From the Data menu select Load XML Data to load the *.xml document that contains the data fields to be inserted into the RTF layout template

● Data Should be loaded successful and the following screen should appear 19

Create Report Templates ● Insert Table/form using the Wizard

● Click on Next to continue and select the Table as report format. Specify the Grouping Field 20

Create Report Templates ● Select the fields to be shown on the Report and specify the field location using „^‟ and „v‟

● Click on next. Specify the group by criteria and sorting order. Click on next and specify the field names as shown below and then save the report in .rtf format 21

Create Report Templates ● Format the report as per the requirements using MS Word formatting tools

22

Report Definition ● Report definitions associate a data source with template files. Report definition access is based on permission list security and roles ● A report may include multiple templates. A template is used to associate different layout formats as required by different countries/regions or as required by different channels (web posting, printer, fax, and so on)

23

Report Definition ● Navigation: Main Menu  Reporting Tools  XML Publisher  Report Definition  Definition. Select Report Status, Report Category ID, Object Owner ID and Template Type

24

Report Definition ● Template: Navigation is Reporting Tools  XML Publisher  Report Definition  Template. Set the template Status to Active. Browse for the *.rtf template and click

25

Report Definition ● Output Format: Navigation is Reporting Tools  XML Publisher  Report Definition  Output. On the Output tab, select PDF as the default output. Click Save

26

Report Definition ● Security: Navigation is Reporting Tools  XML Publisher  Report Definition  Security ● The Security page captures attributes regarding who can view webposted output in the Report Manager repository and through the XML Publisher Report Repository Search page

27

Report Definition ● Bursting is available only when the reports are run through the Process Scheduler ● With bursting we can generate multiple reports based on bursting options ● s with the role assigned to permission list PTPT2600 can setup the Bursting options ● s with the role assigned to permission list PTPT2500 will have readonly access

28

Report Definition ● Translations: Navigation is Reporting Tools  XML Publisher  Translations ● Acts as an interface between report definition template and Content Library sub-templates ● The Template Translation feature is based upon standard Localization Interchange File Format (XLIFF) .xlf file processing ● The template should exist before translating

29

Report Definition ● Content Library: – Used for ing the reusable sub-template files – Sub-template names are not shown to the end- – Sub-templates are .rtf or .xsl templates used by primary .rtf or .xsl templates

30

Run XML Publisher Reports ● Query Report Viewer: The Query Report Viewer allows selection and online viewing of those reports that have a data source type of PeopleSoft Query. Existing Query security applies so that each has access to run only the reports to which he or she has qualified Query access to the data source ● Navigation: Reporting Tools  XML Publisher  Query Report Viewer. Select the format of report & click on View Report link

31

Run XML Publisher Reports ● Output

32

Run XML Publisher Reports ● Query Report Scheduler uses the Process Scheduler to: – Select runtime parameters for query-based reports – Monitor the report process request – Post and secure the results to either the Report Manager, a printer, or the Process Scheduler file directory ● Navigation: Reporting Tools  XML Publisher  Query Report Scheduler

33

Run XML Publisher Reports ● Limitations of PS Query: – If the number of rows goes beyond 3000, the report throws error – Complex s would be difficult to achieve – Output of PS Query is in flat structure

34

Locate and View XML Publisher Reports ● XMLP Report Search: XMLP Report Search can be used to locate and view the XMPL Reports based on the criteria like Report Definition ID, Folder Name, Created On etc ● Navigation: Reporting Tools  XML Publisher  XMLP Report Search

35

Locate and View XML Publisher Reports ● XMLP Report Manager: On the XMLP Report Search page, click on Report Manager link to view the current status of the report ● Navigation: Reporting Tools  XML Publisher  XMLP Report Search  Report Manager

36

Create Data Source – Application Engine ● Following are the steps to be followed to create Data Source: – Create a File Layout – Create an Application Engine Program and fetch all the rows by implementing the business logic – Generate an XML file – Invoke the Report Definition using the PeopleCode &oRptDefn = create PSXP_RPTDEFNMANAGER:ReportDefn(“Report Def name"); &oRptDefn.Get(); &oRptDefn.SetRuntimeDataXMLFile(&FilePath); &oRptDefn.OutDestination = %filepath &oRptDefn.ProcessReport(“TemplateID", &LanguageCd, %Date, &oRptDefn.GetOutDestFormatString(5)); 37

Create Data Source – Application Engine ● File Layout: Create one Temp record and insert this record in File Layout. Select XML as file layout Format

38

Create Data Source – Application Engine ● The App engine that‟s developed for XMLP would perform 2 jobs, – Create the XML file with source data – Call the App Package – PSXP_RPTDEFNMANAGER, and the method ReportDefn which has the inbuilt logic to merge the data with the report template and generate the report.

39

Create Data Source – Application Engine ● Following is a XML App engine generates the xml file to be used as a data source

40

Create Data Source – Application Engine ● Run the Application Engine Program. Enter the Run Control ID & Process Instance. Navigation: Edit  Run Program…

41

XML Publisher Security ● XML Publisher security can be separated into three categories: – Defining reports – Running reports – Viewing reports ● Data security – In case of Query-based report, the requester‟s row-level security to the underlying data source always applies. – However while using App Engines / SQR for generating XML files the program should handle row level security.

● Defining reports – Security for editing and viewing report definitions is controlled by the Report Category ID attribute, which is set on the Reporting Tools, XML Publisher, Setup, Report Category page

● Running reports – Application security and Process Scheduler security determine who can run reports. 42

XML Publisher Security ● Viewing reports – Security to Query-based reports viewed real time from the Query Report Viewer is controlled through query access groups. – For non-Query-based reports viewed online in real time, security has to be controlled by the code. – When you are viewing a report that was run through either the Query Report Scheduler or the Process Scheduler, security is controlled by both the Distribution ID field on the Report Definition, Security page.

43
