Volvo Ingersoll Rand Dd14s Dd16 k5x14

Volvo double drum Compactors

DD14s, dd16

Leading the industry in performance, safety, and durability Volvo Construction Equipment offers vibratory compactors with stellar performance and unsured value. The DD14S and DD16 feature drums with 66,7 Hz frequency—the same high frequency found in much larger machines—to give you better speed and higher productivity. Built for comfort and safety as well, these double-drum compactors offer a competitive advantage in hot mix asphalt, soil sub-base, aggregate-base, and numerous other applications. Performance Features • Drum performance - 66,7 Hz frequency provides optimal impact spacing at higher rolling speeds - DD16 front-drum vibration only, double-drum vibration, or static mode - DD14S front drum vibration / static only - Machined drum surface has chamfered edges to produce a professional quality finish on each job - Durable carbon steel and thick shells prolong drum life • Industry-leading water system - 197 l water tank - Water flows only when the compactor is moving (in automatic mode) - Standard pressurized spray system distributes water coverage evenly across each drum • Operations - Full-day fuel capacity extend operating intervals - High curb and minimal side clearances allow efficient maneuvering around obstacles - Isolation of the vibratory drum and operator platform enhances operator comfort and safety - Propulsion and vibration controls are conveniently designed for comfort, simplicity, and ease of use

2

• Serviceability - Unobstructed daily checkpoints - Easy-to-lift engine enclosure - Ground-level access to engine, radiator, battery, and filters - Color-coded service charts with detailed checkpoints, service intervals, and lubricant info • Comfort and safety - Continuous alarm until seat belt is fastened - Easy access to primary controls - Vibration-isolated and molded skid-resistant platform with kick plates for added safety - Standard safety features include: Roll Over Protective Structure (ROPS), convenient grab handle on both sides of compactor, springapplied, hydraulically released parking brake (SAHR), emergency stop switch, seat shut down switch, and propulsion control with neutral start Available Options - Audible alarm - CE Certification - Foldable ROPS - Hazard and turn signals - Hydraulic test ports - Inside wipers - Low fuel alarm

- Series traction control - Special paint - Strobe light - Urethane wipers - Water strainer - Work lights

Specifications Model Machine Weights (w/ ROPS) Operating Weight Static Weight @ Front Drum Static Weight @ Rear Drum Shipping Weight Static Linear Load @ Front Drum Static Linear Load @ Rear Drum Machine Dimensions Length Width Height — Top Of Steering Wheel Height — Top Of ROPS Drum Base Drum Width Diameter Shell Thickness Finish Vibration Frequency Centrifugal Force Nominal Amplitude Type System Vibrating Drums Propulsion Type System Drum Drive Speed Gradeability (theoretical) Brakes Service Parking / Secondary Engine Make & Model Rated Power @ Installed Speed Type Steering Design Type System Articulation Angle Outside Turning Radius Water System Type Pump Tank Capacity Filters Drum Wipers Type Miscellaneous Fuel Capacity Hydraulic Oil Capacity Oscillation Curb Clearance — Vibration / Traction Side Clearance

DD14S

DD16

kg kg kg kg kg/cm kg/cm

1 519 712 807 1 342 7,91 8,97

1 619 739 880 1 442 7,39 8,80

mm mm mm mm mm

2 035 1 018 1 534 2 240 1 400

2 035 1 085 1 534 2 240 1 400

mm mm mm

900 560 12

1 000 560 12 Machined, chamfered edge

Hz kN mm

66,7 15,6 0,37

66,7 17,8 0,40 Open-loop, series circuit

Front drum only

km/h

Both or front only

Closed-loop, hydrostatic, parallel circuit Pump: axial piston; Motor: radial piston, low speed, high torque 0 – 6,3 0 – 6,3 33,5% 32,5% Dynamic hydrostatic through propulsion system Spring-applied, hydraulically released (SAHR) on each drum drive

kW

Kubota D722-B Tier 4 12,4 3-cylinder diesel

Kubota D722-B Tier 4 12,4 3-cylinder diesel

Centerpoint articulation Double-acting, hydraulic, 1-cylinder mm

+ / - 34º 2 740

+ / - 34º 2 790 Pressurized Electric, diaphragm

l

197

197 100 mesh screen @ nozzles, 80 mesh in-line Spring-loaded, self-adjusting, neoprene wipers

l l mm mm

29,5 34,1 + / - 10º 337 / 440 49

29,5 34,1 + / - 10º 440 / 440 42

Product improvement is a continuing goal at Volvo. Designs and specifications are subject to change without notice or obligation.

3
