Veritas Netbackup Bmr Installation 3z6v6a

NBU651 BMR Avi Weinberger

Bare Metal Restore Overview BMR automates system recovery by restoring the operating system, the system configuration, and all system and data files with two steps: Run one command from the NetBackup master server. Reboot the client. Separate system backups or reinstallations are not required. Point in Time recovery.

2

Bare Metal Restore Overview

Industry’s Broadest Platform Recover Linux Servers (Red Hat & SUSE) Single Solution for: Windows, Linux, and UNIX Recover Windows servers to dissimilar hardware

Step 9. Reboot

8.

Server Recovery Time

A simplified and automated restore process Custom Application Restore Integration into NetBackup console

Bare Metal Restore™

7.

Load tape(s) and restore

6. 5. 4. 3.

Reload backup software Reboot

Step Patches Install OS

3.

Reboot

2.

Collect all media & Lic.

2.

Click “Prepare to Restore”

1.

Repair hardware

1.

Repair hardware

Traditional Recovery

3

Faster Restores

Reboot

Bare Metal Restore

Bare Metal Restore Overview Master server. The NetBackup master server manages backups and restores of the protected client systems. BMR server

Media servers. NetBackup media servers control storage devices on which the client files are stored.

4

Bare Metal Restore Overview Boot servers. Boot servers provide the environment that is required to rebuild a protected client, including resources such as shared resource trees (SRT). For UNIX and Linux systems, a boot server also provides the resources used to boot the client system when it performs a network boot prior to restore.

Shared resource trees contain the operating system software, NetBackup client and additional software that are used to rebuild the protected system so that NetBackup can restore the original files.

5

Bare Metal Restore Overview Each client type and operating system version requires its own SRT. For example: Solaris 9 requires a Solaris 9 SRT, Windows Server 2003 requires a Windows Server 2003 SRT, and so on. Windows SRTs require the appropriate service packs. If you have some Windows XP protected clients at Service Pack 1 and others at Service Pack 2, you need two SRTs

Clients. Clients are the systems backed up by NetBackup and protected by BMR. A client may also be a server for other applications or data, a NetBackup media server, or a BMR boot server.

6

Bare Metal Restore Topology

7

NetBackup 6.5.1 BMR How To Install BMR server product. BMR on Windows Install and configure windows boot server. Shared Resource Tree Management. Client Restoration.

BMR on Unix Install and configure Solaris boot server. Shared Resource Tree Management. Client Restoration.

8

Installing BMR Server ./install NetBackup Add-On Product Installation Choose the Add-On Products you wish to install one at a time or select Install All Add-On Products. 1) NetBackup Bare Metal Restore 2) NetBackup Bare Metal Restore Boot Server 3) Install All Add-On Products q) Done Selecting Products x) Exit from this Script Choose an option: 1 Choose an option: q Installing NetBackup Bare Metal Restore Starting the NetBackup Bare Metal Restore daemon. [Info] V-127-41 Setting up BMR Database ... [Info] V-127-38 Initializing BMR database ... [Info] V-127-39 Loading BMR database ...

9

Installing BMR Server [Info] V-127-68 Loading data from dos.uncooked into BMR database ... [Info] V-127-68 Loading data from unattend.txt into BMR database ... [Info] V-127-68 Loading data from BMRDB.install.sql into BMR database ... [Info] V-127-68 Loading data from PnpDB_2000.xml into BMR database ... [Info] V-127-68 Loading data from PnpDB_2000SP1.xml into BMR database ... [Info] V-127-68 Loading data from PnpDB_2000SP2.xml into BMR database ... [Info] V-127-68 Loading data from PnpDB_2000SP3.xml into BMR database ... [Info] V-127-68 Loading data from PnpDB_2000SP4.xml into BMR database ... [Info] V-127-68 Loading data from PnpDB_2003SP1.xml into BMR database ... [Info] V-127-68 Loading data from PnpDB_WinPE_2003SP1.xml into BMR database ... [Info] V-127-68 Loading data from PnpDB_XP.xml into BMR database ... [Info] V-127-68 Loading data from PnpDB_XPSP1.xml into BMR database ... [Info] V-127-68 Loading data from PnpDB_XPSP2.xml into BMR database ... [Info] V-127-68 Loading data from PnPDB_2003.xml into BMR database ... [Info] V-127-68 Loading data from PnpDB_2003SP2.xml into BMR database ... ing the running version of BMRDB ... BMRDB version 6.5.0.0 verified. bmrsetupmaster Nothing to upgrade. Version unchanged. Database validation successful. [Info] V-127-66 Setting up BMR master server completed successfully. 10

Installing BMR Boot Server

11

Installing BMR Boot Server

12

Installing BMR Boot Server

13

Installing BMR Boot Server

14

Installing BMR Boot Server

15

Installing BMR Boot Server

16

Installing BMR Boot Server

17

Installing BMR Boot Server

18

Boot Server Assistant

19

Setting Network Boot

20

Setting Network Boot

21

Setting Network Boot

22

Setting Network Boot

23

Setting Network Boot

24

Shared Resource Tree

25

Create Shared Resource Tree

26

Create Shared Resource Tree

27

Create Shared Resource Tree

28

Create Shared Resource Tree

29

Create Shared Resource Tree

30

Create Shared Resource Tree

31

Create Shared Resource Tree

32

Create Shared Resource Tree

33

Update Shared Resource Tree

34

Update Shared Resource Tree

35

Update Shared Resource Tree

36

Update Shared Resource Tree

37

BMR Boot Servers

38

List Shared Resource Tree

39

BMR Policy  Collect disaster recovery information for Bare Metal Restore

40

BMR Policy

41

BMR Policy  ALL_LOCAL_DRIVES  C:\  Shadow Copy Components:\

42

Client Backup

43

BMR Client Configuration File

44

Client Restoration

45

Client Restoration Task

46

Client Restoration

47

Client Restoration

48

Client Restoration

49

Client Restoration

50

Client Restoration

51

Client Restoration

52

Client Restoration

53

Client First Boot

54

Client First Boot

55

Client Restoration Task

56

Driver Package Wizard

57

Driver Package Wizard

58

Driver Package Wizard

59

Restoring to a Dissimilar System

60

Restoring to a Dissimilar System

61

Restoring to a Dissimilar System

62

Restoring to a Dissimilar System

63

Restoring to a Dissimilar System

64

Installing BMR Boot Server ./install NetBackup Add-On Product Installation Choose the Add-On Products you wish to install one at a time or select Install All Add-On Products. ( 1 NetBackup Bare Metal Restore ( 2 NetBackup Bare Metal Restore Boot Server ( 3 Install All Add-On Products q) Done Selecting Products x) Exit from this Script Choose an option: 2 Choose an option: q Installing NetBackup Bare Metal Restore Boot Server

65

Installing BMR Boot Server Starting the NetBackup Bare Metal Restore Boot Server daemon. LiveUpdate is not installed, skipping registration step... Please refer to the NetBackup Bare Metal Restore 's Guide for complete details on use and configuration of NetBackup Bare Metal Restore Boot Server. NetBackup Bare Metal Restore Boot Server installation completed. ********** Execution of ./install is complete. bmrsetupboot

66

Create Shared Resource Tree root@t2000 # bmrsrt Select one of the following options: 1. 2. 3. 4. 5. 6. 7. 8.

Create a new Shared Resource Tree. Create a new CD image based Shared Resource Tree. Copy an existing Shared Resource Tree to a new location. Import a Shared Resource Tree. Modify an existing Shared Resource Tree. Delete an existing Shared Resource Tree. List Shared Resource Trees available on this server. Quit.

Enter your selection (1-8) [1] : 1 Enter the name of the SRT to create : Solaris10 Enter the description of the new SRT : Solaris10U4 SFHA50MP1 NBU651 Enter desired level of Solaris/SunOS (8/5.8, 9/5.9 or 10/5.10) [5.10] : Enter the directory in which to place the new SRT [/export/srt] : Enter a [hostname:/]pathname containing a suitable Solaris 5.10 Boot CDROM or SRT image [/cdrom/cdrom0/s0] : This step may take considerable time. Please wait... Preparing boot files - please stand by... 67

Create Shared Resource Tree Enter a [hostname:]/pathname containing Veritas NetBackup Client software : / export/netbackup65/NB_65_Unix_Clients/NB_65_CLIENTS3_20070723 Symantec Installation Script Copyright 1993 - 2007 Symantec Corporation, All Rights Reserved. Installing NetBackup Client Software NOTE: To install NetBackup Server software, insert the appropriate NetBackup Server cdrom. Do you wish to continue? [y,n] (y) Do you want to install the NetBackup client software for this client? [y,n] (y) This package will install Solaris/Solaris10 client. This package will install NetBackup client 6.5. Enter the name of the NetBackup server : t2000

68

List Shared Resource Tree root@t2000 # bmrsrt Select one of the following options: 1. 2. 3. 4. 5. 6. 7. 8.

Create a new Shared Resource Tree. Create a new CD image based Shared Resource Tree. Copy an existing Shared Resource Tree to a new location. Import a Shared Resource Tree. Modify an existing Shared Resource Tree. Delete an existing Shared Resource Tree. List Shared Resource Trees available on this server. Quit.

Enter your selection (1-8) [1] : 7 Name State Type Path Description --------- ----- ---- --------------------- ---------------------------Solaris10 READY NFS /export/srt/Solaris10 Solaris10U4 SFHA50MP1 NBU651 69

Modify Shared Resource Tree Select one of the following options: 1. 2. 3. 4. 5. 6. 7. 8.

Create a new Shared Resource Tree. Create a new CD image based Shared Resource Tree. Copy an existing Shared Resource Tree to a new location. Import a Shared Resource Tree. Modify an existing Shared Resource Tree. Delete an existing Shared Resource Tree. List Shared Resource Trees available on this server. Quit.

Enter your selection (1-8) [1] : 5 Enter the name of an existing SRT : Solaris10 -----------------------------------------------------------------------------SRT name: Solaris10 Location: /export/srt/Solaris10 Description: Solaris10U4 SFHA50MP1 NBU651 Exclusive use: (none) -----------------------------------------------------------------------------70

Modify Shared Resource Tree You may make modifications to this SRT. Select one of the following options: 1. 2. 3. 4. 5. 6. 7. 8.

Install Veritas NetBackup Maintenance Pack. Install Veritas Volume Manager and Veritas File System. Update Veritas Volume Manager and Veritas File System. Install Veritas Security Services. Install additional packages or patches. Change SRT description. Change client exclusive use of this SRT. Quit.

Enter your selection (1-8) [8] : 2

71

Modify Shared Resource Tree Ready to add Veritas Volume Manager/File System to SRT. Select one of the following options: 1. 2. 3. 4.

72

Install Veritas License Software. (prerequisite to below) Install Veritas Volume Manager. Install Veritas File System. Return to the previous menu.

List Shared Resource Tree

73

Client Backup

74

BMR Client Configuration File

75

Client Restoration

76

Client Restoration

77

Client Restoration

78

Client Restoration

79

Client Restoration

80

Client Restoration

81

Thanks [email protected]
