HCD-RG490/RG590 SERVICE MANUAL

AEP Model E Model

Ver. 1.2 2006.06

HCD-RG490/RG590

UK Model HCD-RG590

Australian Model HCD-RG490

• HCD-RG490 is the amplifier, CD player, tape deck and tuner section in MHC-RG490S. • HCD-RG590 is the amplifier, CD player, tape deck and tuner section in MHC-RG590S. Photo: HCD-RG590 (Except AEP, UK, Russian models)

Model Name Using Similar Mechanism CD Mechanism Type CD Section

Base Unit Name Optical Pick-up Block Name

TAPE Section

Model Name Using Similar Mechanism Tape Transport Mechanism Type

HCD-RG270 CDM74KF-K6BD83S (Except Mexican model)/ CDM74KF-F1BD84 (Mexican model) BU-K6BD83S-WOD (Except Mexican model)/ BU-F1BD84 (Mexican model) KSM-213D (Except Mexican model)/ KSM-215D (Mexican model) NEW CWN42FF609

SPECIFICATIONS

Amplifier section European and Russian models: HCD-RG590 Front speaker DIN power output (rated): 110 + 110 watts (6 ohms at 1 kHz, DIN) Continuous RMS power output (reference): 145 + 145 watts (6 ohms at 1 kHz, 10% THD) Music power output (reference): 290 + 290 watts (6 ohms at 1 kHz, 10% THD) Subwoofer DIN power output (rated): 130 watts (6 ohms at 80 Hz, DIN) Continuous RMS power output (reference): 170 watts (6 ohms at 80 Hz, 10% THD) Music power output (reference): 340 watts (6 ohms at 80 Hz, 10% THD) HCD-RG490 Front speaker DIN power output (rated): 95 + 95 watts (6 ohms at 1 kHz, DIN) Continuous RMS power output (reference): 125 + 125 watts (6 ohms at 1 kHz, 10% THD) Music power output (reference): 250 + 250 watts (6 ohms at 1 kHz, 10% THD)

Subwoofer DIN power output (rated): 120 watts (6 ohms at 80 Hz, DIN) Continuous RMS power output (reference): 150 watts (6 ohms at 80 Hz, 10% THD) Music power output (reference): 300 watts (6 ohms at 80 Hz, 10% THD) Other models: HCD-RG590 The following are measured at AC 220 V, 50 Hz (Argentine model), AC 120 or 127 V, 60 Hz (Mexican model), AC 127 or 220 V, 60 Hz (Saudi Arabian model), AC 120, 220 or 240 V, 50/60 Hz (other models) Front speaker: DIN power output (rated): 110 + 110 W (6 ohms at 1 kHz, DIN) Continuous RMS power output (reference): 145 + 145 W (6 ohms at 1 kHz, 10% THD)

Subwoofer: DIN power output (rated): 130 W (6 ohms at 80 Hz, DIN) Continuous RMS power output (reference): 170 W (6 ohms at 80 Hz, 10% THD) HCD-RG490 Front speaker The following are measured at AC 120, 127, 220, 240 V 50/60 Hz DIN power output (rated): 95 + 95 watts (6 ohms at 1 kHz, DIN) Continuous RMS power output (reference): 125 + 125 watts (6 ohms at 1 kHz, 10% THD) Subwoofer DIN power output (rated): 120 watts (6 ohms at 80 Hz, DIN) Continuous RMS power output (reference): 150 watts (6 ohms at 80 Hz, 10% THD)

– Continued on next page –

COMPACT DISC DECK RECEIVER 9-887-053-03 2006F05-1 © 2006.06

Sony Corporation Home Audio Division Published by Sony Techno Create Corporation

HCD-RG490/RG590 Ver. 1.1

Inputs: AUDIO IN (stereo mini jack): voltage 250 mV, impedance 47 kilohms MIC (phone jack) (Latin American model only): sensitivity 1 mV, impedance 10 kilohms Outputs: PHONES (stereo mini jack): accepts headphones of 8 ohms or more VIDEO OUT (phono jack) (Mexican model only): max. output level 1Vpp, unbalanced, Sync negative, load impedance 75 ohms SPEAKER: accepts impedance of 6 to 16 ohms SUBWOOFER OUT: accepts impedance of 6 to 16 ohms

CD player section System: Compact disc and digital audio system Laser Diode Properties Emission duration: continuous Laser Output*: Less than 44.6µW *This output is the value measurement at a distance of 200mm from the objective lens surface on the Optical Pick-up Block with 7mm aperture.

Frequency response: 20 Hz − 20 kHz Signal-to-noise ratio: More than 90 dB Dynamic range: More than 90 dB

Tape deck section Recording system: 4-track 2-channel, stereo Frequency response: 50 − 13,000 Hz (±3 dB), using Sony TYPE I cassettes

Tuner section FM stereo, FM/AM superheterodyne tuner FM tuner section: Tuning range 87.5 − 108.0 MHz (50 kHz step) Antenna: FM lead antenna Antenna terminals: 75 ohms unbalanced Intermediate frequency: 10.7 MHz AM tuner section: Tuning range Pan-American model: 530 − 1,710 kHz (with 10 kHz tuning interval) 531 − 1,710 kHz (with 9 kHz tuning interval) European, Russian and Saudi Arabian models: 531 − 1,602 kHz (with 9 kHz tuning interval) Other models: 530 − 1,710 kHz (with 10 kHz tuning interval) 531 − 1,602 kHz (with 9 kHz tuning interval) Antenna: AM loop antenna, external antenna terminal Intermediate frequency: 450 kHz

Power consumption Mexican model: HCD-RG590: 205 watts HCD-RG490: 240 watts Other models: HCD-RG590: 205 watts HCD-RG490: 245 watts Dimensions (w/h/d) (excl. speakers): Approx. 280 × 328 × 412.3 mm Mass (excl. speakers) European and Russian models: HCD-RG590: Approx. 9.5 kg HCD-RG490: Approx. 9.5 kg Other models: HCD-RG590: Approx. 9.7 kg HCD-RG490: Approx. 9.5 kg Design and specifications are subject to change without notice.

General Power requirements European and Russian models: AC 230 V, 50/60 Hz Australian model: AC 230 − 240 V, 50/60 Hz Mexican model: AC 127 V, 60 Hz Argentine model: AC 220 V, 50/60 Hz Saudi Arabian model: AC 120 − 127, 220 or 230 − 240 V, 50/60 Hz, Adjustable with voltage selector Other models: AC 120, 220 or 230 − 240 V, 50/60 Hz, Adjustable with voltage selector

Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be damaged by heat. Flexible Circuit Board Repairing • Keep the temperature of the soldering iron around 270 ˚C during repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. SAFETY-RELATED COMPONENT WARNING!!

This appliance is classified as a CLASS 1 LASER product. This marking is located on the rear exterior.

2

COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.

HCD-RG490/RG590

TABLE OF CONTENTS 1.

SERVICING NOTES ............................................... 4

2.

GENERAL ................................................................... 5

3.

DISASSEMBLY

3-1. 3-2. 3-3. 3-4. 3-5

3-13. 3-14. 3-15.

Disassembly Flow ........................................................... Case (Side-L), Case (Side-R) .......................................... Case (Top) ....................................................................... LID (CD) ......................................................................... CD Mechanism Deck (CDM74KF-K6BD83S: Except Mexican model) (CDM74KF-F1BD84: Mexican model) .......................... Front Block ............................................................ Mecha Deck (CWN42FF609) ......................................... Back Section .......................................................... MAIN Board .................................................................... BD Board (Mexican model), CD Board (Except Mexican model) ................................ DRIVE Board, SW Board ............................................... Optical Pick-up Block (KSM-213D: Except Mexican model) (KSM-215D: Mexican model) ................................... SENSOR Board ............................................................... MOTOR (TB) Board ....................................................... MOTOR (LD) Board .......................................................

4.

TEST MODE .............................................................. 16

5.

MECHANICAL ADJUSTMENTS ....................... 19

6.

ELECTRICAL ADJUSTMENTS ......................... 20

7.

DIAGRAMS

7-1. 7-2. 7-3. 7-4.

Block Diagram – CD SERVO Section – ......................... Block Diagram – MAIN Section – .................................. Block Diagram – AMP/VIDEO Section – ...................... Block Diagram – /POWER SUPPLY Section – ........................... Printed Wiring Board – CD Board (Except RG490: MX/RG590: MX models) – ................. Schematic Diagram – CD Board (Except RG490: MX/RG590: MX models) – ................. Printed Wiring Board – BD Board (RG490: MX/RG590: MX models) – ............................. Schematic Diagram – BD Board (RG490: MX/RG590: MX models) – ............................. Printed Wiring Boards – CHANGER Section – .............. Schematic Diagram – CHANGER Section – .................. Printed Wiring Board – DECK Board – .......................... Schematic Diagram – DECK Board – ............................. Printed Wiring Board – MAIN Board (Except RG490: MX/RG590: MX models) – ................. Schematic Diagram – MAIN Board (1/3) (Except RG490: MX/RG590: MX models) – ................. Schematic Diagram – MAIN Board (2/3) (Except RG490: MX/RG590: MX models) – ................. Schematic Diagram – MAIN Board (3/3) (Except RG490: MX/RG590: MX models) – ................. Printed Wiring Board – MAIN Board (RG490: MX/RG590: MX models) – ............................. Schematic Diagram – MAIN Board (1/3) (RG490: MX/RG590: MX models) – ............................. Schematic Diagram – MAIN Board (2/3) (RG490: MX/RG590: MX models) – .............................

3-6. 3-7. 3-8. 3-9. 3-10. 3-11. 3-12.

7-5. 7-6. 7-7. 7-8. 7-9. 7-10. 7-11. 7-12. 7-13. 7-14. 7-15. 7-16. 7-17. 7-18. 7-19.

8 9 9 10

10 11 11 12 12 13 13

14 14 15 15

23 24 25 26

7-20. Schematic Diagram – MAIN Board (3/3) (RG490: MX/RG590: MX models) – ............................. 7-21. Printed Wiring Board – MIC. AUX. HP Board – ............ 7-22. Schematic Diagram – MIC. AUX. HP Board – ............... 7-23. Printed Wiring Board – POWER Board (RG490) – ........ 7-24. Schematic Diagram – POWER Board (RG490) – .......... 7-25. Printed Wiring Board – POWER Board (RG590) – ........ 7-26. Schematic Diagram – POWER Board (RG590) – .......... 7-27. Printed Wiring Boards – SUB WOOFER Section – ........ 7-28. Schematic Diagram – SUB WOOFER Section – ............ 7-29. Printed Wiring Boards – CD-G Section (RG490: MX/RG590: MX models) – ............................. 7-30. Schematic Diagram – CD-G Section (RG490: MX/RG590: MX models) – ............................. 7-31. Printed Wiring Board – Board – ........................ 7-32. Printed Wiring Boards – KEY Section – ......................... 7-33. Schematic Diagram – /KEY Section – ............... 7-34. Printed Wiring Board – TRANSFORMER Board (RG490) – ........................... 7-35. Schematic Diagram – TRANSFORMER Board (RG490) – ........................... 7-36. Printed Wiring Board – TRANSFORMER Board (RG590) – ........................... 7-37. Schematic Diagram – TRANSFORMER Board (RG590) – ...........................

8.

43 44 45 46 47 48 49 50 51 52 53 54 55 56 58 59 60 61

EXPLODED VIEWS

8-1. 8-2. 8-3. 8-4. 8-5. 8-6. 8-7. 8-8.

Case Section .................................................................... Board Section ..................................................... LID (Top) Section ............................................................ Front Section ......................................................... MAIN Board Section ....................................................... POWER Board, SUB WOOFER Board Section ............. Chassis Section ................................................................ CD Mechanism Deck Section-1 (CDM74KF-K6BD83S) (Except Mexican model)/ (CDM74KF-F1BD84) (Mexican model) ........................ 8-9. CD Mechanism Deck Section-2 (CDM74KF-K6BD83S) (Except Mexican model)/ (CDM74KF-F1BD84) (Mexican model) ........................

78 79 80 81 82 83 84

85

86

28

9.

ELECTRICAL PARTS LIST ................................ 87

29 30

• Abbreviation MX: Mexican model

31 32 33 34 35 36 37 38 39 40 41 42

3

HCD-RG490/RG590 Ver. 1.1

SECTION 1 SERVICING NOTES

NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electrostatic break-down because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic break-down and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pickup block. Therefore, when checking the laser diode emission, observe from more than 30 cm away from the objective lens. UNLEADED SOLDER Boards requiring use of unleaded solder are printed with the leadfree mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size) : LEAD FREE MARK Unleaded solder has the following characteristics. • Unleaded solder melts at a temperature about 40 °C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder t for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350 °C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! • Strong viscosity Unleaded solder is more viscou-s (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. • Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. RELEASING THE ANTITHEFT LOCK The disc table lock function for the antitheft of an demonstration disc in the store is equipped. Releasing Procedure : 1. Press the I/1 button to turn the power on. 2. While pressing the s button, press the A button until “UNLOCKED” displayed on the fluorescent indicator tube (around 5 seconds). Note: When “LOCKED” is displayed, the antitheft lock is not released by turning power on/off with the I/1 button.

NOTES ON REPLACEMENT OF IC901 ON THE MAIN BOARD IC901 on the MAIN board cannot exchange with single. When IC901 is damaged, exchange the entire mounted board.

4

MODEL IDENTIFICATION – Back – Model number label

Label indication 2-664-523-0[] CED 2-664-524-0[] E3 2-664-526-0[] EA3 2-664-527-0[] E51 2-664-528-0[] AR 2-664-529-0[] MX4 2-664-534-0[] CED

Model RG590: AEP, UK RG590: E3 RG590: EA RG590: E51 RG590: AR RG590: MX RG490: AEP

2-664-535-0[] E3 2-664-536-0[] AU 2-664-537-0[] EA3 2-664-538-0[] E51 2-664-539-0[] AR 2-664-540-0[] MX4 2-664-577-0[] RU 2-680-569-0[] E2 2-680-570-0[] E2 2-683-086-0[] RU

RG490: E3 RG490: AUS RG490: EA RG490: E51 RG490: AR RG490: MX RG490: RU RG590: E2 RG490: E2 RG590: RU

• Abbreviation AR : Argentina model AUS : Australian model E2 : 120V AC area in E model E3 : 240V AC area in E model E51 : Chilean and Peruvian models EA : Saudi Arabia model MX : Mexican model RU : Russian model

HCD-RG490/RG590 SECTION 2 GENERAL

This section is extracted from instruction manual.

HCD-RG490/RG590: UK model

Guide to parts and controls

4 SUBWOOFER indicator

Unit

5 SUBWOOFER button

Lights up when the subwoofer is turned on.

Press to turn on and off the subwoofer.

6 Mexican model: Unit: KARAOKE button Press to activate the karaoke mode.

qd Latin American model only: MIC jack Connect the microphone. Mexican model comes with 2 microphone jacks.

MIC LEVEL Turn to adjust the microphone volume.

Mexican model only: ECHO LEVEL Turn to adjust the echo level.

Remote: DISPLAY button Press to change the information on the display.

Other models: DISPLAY button Press to change the information on the display.

7 ILLUMINATION button Press to change the illumination pattern around the VOLUME control qf.

Remote

8 Buttons for synchro recording or manual recording REC PAUSE/START button, CD SYNC button Press to record on a tape.

9 PUSH Z Press to insert or eject a tape.

q; Playback buttons Unit: NX (play/pause) button Remote: N (play) button, X (pause) button

qf Unit: VOLUME control Turn to adjust the volume.

Remote: VOLUME +/– button Press to adjust the volume.

qg EQ BAND button Press to select the frequency band.

qh ENTER button Press to enter the settings.

qj Sound buttons Unit: GROOVE button, SURROUND button Remote: EQ button Press to select the sound.

qk A (open/close) button Press to insert and eject a disc.

ql DISC 1 – 3 button Press to select a disc. Press to switch to the CD function from other function.

Press to start or pause playback.

Unit: DISC SKIP/EX-CHANGE button

x (stop) button

Press to select a disc. Press to exchange a disc while playing.

Press to stop playback.

./> (go back/go forward)

Remote: DISC SKIP button Press to select a disc.

Press to select a track or file.

w; Remote sensor This manul mainly explains operations using the remote, but the same operations can also be performed using the buttons on the unit having the same or similar names.

1 ?/1 (power) button Press to turn on the system.

2 STANDBY indicator Lights up when the system is turned off.

Unit: TUNING +/– button Remote: +/– (tuning) button Press to tune in the desired station.

+/– (select folder) button Press to select a folder on an MP3 disc.

m/M (rewind/fast forward) button

wa CLOCK/TIMER SELECT button CLOCK/TIMER SET button Press to set the clock and the timers.

ws REPEAT/FM MODE button Press to listen to a disc, a single track or file repeatedly. Press to select the FM reception mode (monaural or stereo).

Press to find a point in a track or file.

wd Battery compartment lid

Press to select the CD function.

MULTI JOG dial (./> (go back/go forward), +/– (tuning))

wf CLEAR button

TUNER/BAND button

Turn to select a track or file. Turn to tune in the desired station. (Same as the ./>, +/– buttons on the remote)

3 CD button

Press to select the TUNER function. Press to select FM or AM reception mode.

Unit: TAPE A/B button Remote: TAPE button Press to select the TAPE function. Press to select TAPE A or TAPE B.

qa PHONES jack Connect the headphones.

qs AUDIO IN jack Connect to an audio component.

Press to delete a pre-programmed track.

wg TUNER MEMORY button Press to preset the radio station.

wh PLAY MODE/TUNING MODE button Press to select the play mode of a CD, MP3 or tape. Press to select the tuning mode.

AUDIO IN button Press to select the AUDIO IN function.

wj SLEEP button Press to set the Sleep Timer.

FUNCTION button Press to select the function.

5

HCD-RG490/RG590

EXCEPT HCD-RG490/RG590: UK model

Basic Operations Adjusting the sound To adjust the volume Press VOLUME +/− on the remote (or turn the VOLUME control on the unit) qs.

To add a sound effect To

Press

Reinforce the bass and create a more powerful sound

GROOVE wd on the unit repeatedly until “GROOVE” appears.

Set the surround effect

SURROUND wd on the unit repeatedly until “SURR” appears. EQ on the remote (or PRESET EQ on the unit) wd repeatedly. To cancel, press EQ on the remote (or PRESET EQ on the unit) wd repeatedly until “EQ OFF” appears.

Select the preset sound effect * Mexican model: KARAOKE button Other models: DISPLAY button

• The maximum number of: − folders is 150 (including the root folder). − MP3 files is 255. − MP3 files and folders that can be contained on a single disc is 300. − folder levels (the tree structure of files) is 8. • Compatibility with all MP3 encoding/writing software, recording device, and recording media cannot be guaranteed. Incompatible MP3 discs may produce noise or interrupted audio or may not play at all.

Notes on playing multisession discs • If the disc begins with a CD-DA (or MP3) session, it is recognized as a CD-DA (or MP3) disc, and playback continues until another session is encountered. • A disc with a mixed CD format is recognized as a CD-DA (audio) disc.

Notes on the Mexican model • You cannot select the graphic channels of CD-Gs or display CD-G images with fading effects. • Some functions of the unit, when used during CD-G disc playback, may cause image distortion in the video output.

Listening to the radio 1 Select “FM” or “AM.” Press TUNER/BAND

To turn on the subwoofer Press SUBWOOFER wh on the unit repeatedly until “SUB ON” appears. The SUBWOOFER indicator wg on the unit lights up. If you later disconnect the subwoofer, repeat the procedure until “SUB OFF” appears. The volume of the subwoofer is linked to the front speakers.

repeatedly.

2 Select the tuning mode. Press TUNING MODE 3 repeatedly until “AUTO” appears.

3 Tune in the desired station. Press +/− on the remote (or TUNING +/− on the unit) 8. Scanning stops automatically when a station is tuned in, and then “TUNED” and “STEREO” (for stereo programs) appear.

Playing a CD/CD-G/MP3 disc

The system offers the following display modes. Display mode

When the system is off1),

Demonstration

The clock display is replaced by lighting and flashing of the display window. The clock is displayed. The display is turned off to conserve power. The timer and clock continue to operate.

Clock Power Saving Mode2) 1)

2)

The STANDBY indicator 2 on the unit lights up when the system is off. When the system is in Power Saving Mode, the following functions are unavailable: − setting the clock. − changing the AM tuning interval (except for Saudi Arabian model). − turning on the system by pressing the function buttons (for example, CD 3). − changing the CD power manage function. − resetting the system to factory settings.

Notes on the display information • The following are not displayed; − total playing time for a CD-DA disc depending on the play mode. − total playing time for an MP3 disc. − Remaining playing time for an MP3 file. • The following are not displayed correctly; − elapsed playing time of an MP3 file encoded using a VBR (variable bit rate). − folder and file names that do not follow either the ISO9660 Level 1, Level 2 or Joliet in the expansion format. • The following are displayed; − ID3 tag information for MP3 files when ID3 version 1 and version 2 tags are used. − up to 30 characters of ID3 tag information upercase letters (A to Z), numbers (0 to 9), and symbols (˝ $ % ’ ( ) * , – . / < = > @ [ \ ] _ ` { | } ! ? ^).

CD-G discs are ed only on the Mexican model.

1 Select the CD function. Press CD 3.

2 Place a disc.

To stop automatic scanning

Press A (open/close) qj on the unit, and place a disc with the label side up on the disc tray.

Press x (stop) 8.

To connect an optional headphones

To tune in a station with a weak signal If “TUNED” does not appear and the scanning does not stop, press TUNING MODE qh repeatedly until “AUTO” and “PRESET” disappear, and then press +/− on the remote (or TUNING +/− on the unit) 8 repeatedly to tune in the desired station.

Before using the system To use the remote Slide and remove the battery compartment lid wk, and insert the two supplied R6 (size AA) batteries, E side first, matching the polarities shown below.

To insert additional discs, press DISC SKIP qk to rotate the disc tray. To close the disc tray, press A (open/close) qj on the unit again. Do not force the disc tray closed with your finger, as this may damage the unit.

3 Start playback. Press N (play) on the remote (or NX (play/pause) on the unit) 8.

Notes on using the remote • With normal use, the batteries should last for about six months. • Do not mix an old battery with a new one or mix different types of batteries. • If you do not use the remote for a long period of time, remove the batteries to avoid damage from battery leakage and corrosion.

To

Press

Pause playback

X (pause) on the remote (or NX (play/pause) on the unit) 8. To resume play, press the button again.

Stop playback

x (stop) 8.

Select a folder on an MP3 disc Select a track or file

To set the clock

1 Turn on the system. Press ?/1 (power) 1.

2 Select the clock set mode. Press CLOCK/TIMER SET wj on the remote. If the current mode appears on the display, press ./> 8 repeatedly to select “CLOCK SET” and then press ENTER qf.

3 Set the time. Press ./> 8 repeatedly to set the hour, and then press ENTER qf. Use the same procedure to set the minutes. When you turn off the system after setting the clock, the clock display appears instead of the demonstration display. The clock settings are lost when you disconnect the power cord or if a power failure occurs.

on

To select

Press

CD

CD 3.

Tuner Tape (deck A or B)

TUNER/BAND 3. TAPE on the remote (or TAPE A/B on the unit) 3.

Component (connected using an audio cord)

AUDIO IN 3 on the unit.

Playing a tape 1 Select a tape deck. Press TAPE (or TAPE A/B on the unit) 3 repeatedly.

2 Insert a tape. Press PUSH Z 7 on the unit, and insert the TYPE I (normal) tape into the cassette holder with the side you want to play facing forward. Make sure there is no slack in the tape to avoid damaging the tape or the tape deck. Press PUSH Z 7 on the unit again to close the cassette holder.

3 Start playback. Press N (play) on the remote (or NX (play/pause) on the unit) 8. Do not eject the tape during playback or recording, as this may cause irreparable damage to the tape and the cassette holder.

Hold down m/M (rewind/fast forward) 8 during playback, and release the button at the desired point.

To

Press

Pause playback

Select Repeat Play

REPEAT qg repeatedly until “REP” or “REP1” appears. DISC SKIP (or DISC 1 − 3 on the unit) qk in stop mode.

X (pause) on the remote (or NX (play/pause) on the unit) 8. To resume play, press the button again.

Stop playback

x (stop) 8.

DISC 1 − 3 qk on the unit (Automatic Source Selection).

Rewind or fast forward Select Relay Play*

PLAY MODE qh repeatedly until “RELAY” appears.

EX-CHANGE qk on the unit.

* After the playback of the front side of deck A, deck B plays the front side, and then stops.

Select a disc Switch to CD function from other function Exchange other discs while playing

Press PLAY MODE qh repeatedly while the player is stopped. You can select normal play (“ALL DISCS” for all discs or “1 DISC” for a disc or “ *” for all MP3 files in the folder on the disc), shuffle play (“ALL SHUF*”), or DISCS SHUF” or “1 DISC SHUF” or “ program play (“PGM”). * When playing a CD-DA disc, (SHUF) Play performs the same operation as 1 DISC (SHUF) Play.

Notes on Repeat Play • All tracks or files on a disc are played repeatedly up to five times. • You cannot select “REP” and “ALL DISCS SHUF” at the same time. • “REP1” indicates that a single track or file is repeated until you stop it.

Notes on playing MP3 discs • Do not save other types of files or unnecessary folders on a disc that has MP3 files. • Folders that have no MP3 files are skipped. • MP3 files are played back in the order that they are recorded onto the disc. • The system can only play MP3 files that have a file extension of “.MP3.” • If there are files on the disc that have the “.MP3” file extension, but that are not MP3 files, the unit may produce noise or may malfunction.

6

Press FM MODE qg on the remote repeatedly until “MONO” appears to turn off stereo reception.

Find a point in a track or file (except for CD-G discs)

To change the play mode

Selecting a music source Press the following buttons (or press FUNCTION the remote repeatedly).

+/− (select folder) 8.

To reduce static noise on a weak FM stereo station

./> (go back/go forward) (or turn the MULTI JOG dial on the unit) 8.

m/M (rewind/fast forward) 8.

Changing the display To

Press

Change the ILLUMINATION 4 on the unit illumination repeatedly. pattern around the VOLUME control qs

Change information on the display* Change Display mode (See below.)

Using optional audio components

DISPLAY 5 repeatedly when the system is turned on. DISPLAY 5 repeatedly when the system is turned off.

* For example, you can view CD/CD-G/MP3 disc information, such as the track or file number or folder name during normal play, or the total playing time while the player is stopped.

Connect headphones to the PHONES jack 9 on the unit.

To connect an optional component Connect additional audio component to the AUDIO IN jack 0 on the unit using an audio analog cord (not supplied). Turn down the volume on the system, and then select the AUDIO IN function.

HCD-RG490/RG590

Other Operations Creating your own CD program (Program Play) Use buttons on the remote to create your own program.

1 Press CD 3 to select the CD function. 2 Press PLAY MODE qh repeatedly until “PGM” appears while the player is stopped.

3 Press DISC SKIP qk repeatedly to select a disc. 4 Press ./> 8 repeatedly until the desired track number appears. +/− (select When programming MP3 files, press folder) 8 repeatedly to select the desired folder, and then select the desired file. Disc tray number Selected track or file number

When recording a folder from an MP3 disc, press PLAY MODE qh repeatedly to select “ ” and then +/− (select folder) 8 repeatedly to select press the desired folder. To record only your favorite CD tracks or MP3 files in your desired order, perform steps 2 to 6 of “Creating your own CD program.” For Manual Recording and Sound Mixing: Select the desired source to record or mix. To record only sound from a microphone, press CD 3, and do not start playing any other source in step 4. For CD Synchro Recording: Press CD SYNC 6.

4 Start recording.

Press ENTER qf to add the track or file to the program. “– –.– –” appears when the total program time exceeds 100 minutes for a CD, or when you select an MP3 file.

6 Repeat steps 3 through 5 to program additional tracks or files, up to a total of 25 tracks or files.

7 To play your program of tracks or files, press N (play) 8. The program remains available until you open the disc tray. To play the same program again, press N (play) 8.

To cancel Program Play

For Manual Recording: Press REC PAUSE/START 6, and then start playing the desired recording source. If there is noise while recording from the tuner, reposition the appropriate antenna to reduce the noise. For Sound Mixing: Press REC PAUSE/START 6, and then start playing the desired source and start singing or speaking into the microphone. If acoustic (howling) occurs, reduce the volume, move the microphone away from the speakers, or change the direction of the microphone. Press x (stop) 8. • Recording stops if you change to a different function. • When loud sound signals are input, the system automatically adjusts the recording level to prevent distortion of the recorded sound signal (Auto Level Control function). • You cannot eject the disc during CD Synchro Recording.

Creating your own sound effect You can preset your favorite radio stations and tune them in instantly by selecting the corresponding preset number. Use buttons on the remote to preset stations.

1 Tune in the desired station (see “Listening to the radio”).

2 Press TUNER MEMORY wl. Preset number

You can raise or lower the levels of specific frequency ranges, and then store the setting as “” in the memory. Use buttons on the unit to create your own sound effect.

1 Press BASS, VOCAL or GUITAR wf to select a frequency band.

2 Press SELECT B/b w; repeatedly to select a frequency, and then press SELECT +/– repeatedly to adjust the frequency level. Repeat this for each band you want to adjust. Frequency

Press +/– 8 repeatedly to select your desired preset number. If another station is already assigned to the selected preset number, the station is replaced by the new stations.

4 Press ENTER qf. 5 Repeat steps 1 through 4 to store other stations. You can preset up to 20 FM and 10 AM stations. The preset stations are retained for about half a day even if you disconnect the power cord or if a power failure occurs.

6 To call up a preset radio station, press TUNING MODE qh repeatedly until “PRESET” appears, and then press +/– 8 repeatedly to select the desired preset number.

Frequency level

Frequency band

3 Hold down PRESET EQ wd until “COMPLETE” appears The setting is stored in the memory.

4 To call up the personal sound effect, press PRESET EQ wd repeatedly until “” appears.

To cancel the sound effect

1 Turn MIC LEVEL qa to MIN to turn down the 2 Connect an optional microphone to the MIC jack

Use buttons on the unit to control tape recording.

1 Load a recordable tape into deck B with the side you want to record facing forward, and then press TAPE A/B 3 repeatedly to select TAPE B.

2 Prepare the recording source. For CD Synchro Recording: Press CD 3 to select the CD function. Load the disc you want to record, and press DISC SKIP qk repeatedly to select the disc.

Use buttons on the remote to control the Play Timer and the Rec Timer. Make sure you have set the clock.

1 Prepare the sound source. For Play Timer: Prepare the sound source, and then press VOLUME +/− qs to adjust the volume. To start from a specific CD track or MP3 file, create your own program. For Rec Timer: Tune in the preset radio station.

2 Press CLOCK/TIMER SET wj. 3 Press ./> 8 repeatedly to select “PLAY SET” or “REC SET,” and then press ENTER qf. “ON” appears, and the hour indication flashes.

4 Set the time to start playing or recording. Press ./> 8 repeatedly to set the hour, and then press ENTER qf. The minute indication flashes. Use the procedure above to set the minutes.

5 Use the same procedure as in step 4 to set the time to stop playing or recording.

6 Select the sound source or prepare the tape. For Play Timer: Press ./> 8 repeatedly until the desired sound source appears, and then press ENTER qf. The display shows the timer settings.

7 Press ?/1 (power) 1 to turn off the system. The system turns on 15 seconds before the preset time. If the system is on at the preset time, the Play Timer and the Rec Timer will not play or record.

To activate or check the timer again Press CLOCK/TIMER SELECT wj, press ./> 8 repeatedly until “PLAY SELECT” or “REC SELECT” appears, and then press ENTER qf.

To change the setting

You can record an entire CD onto a tape. The recording level is adjusted automatically.

You can “mix” sounds by playing one of the components and singing or speaking into a microphone (not supplied). The mixed sound can be recorded onto a tape.

You can record a preset radio station at a specified time.

Enjoying karaoke

CD Synchro Recording:

Sound Mixing (Latin American model only):

Rec Timer:

To cancel the timer

You can record on a TYPE I (normal) tape in three ways:

You can record just the portions you like from a sound source, including connected audio components.

You can wake up to CD, tape or tuner at a preset time.

Press PRESET EQ wd repeatedly until “EQ OFF” appears.

You can sing along by connecting an optional microphone. Use buttons on the unit for karaoke.

Manual Recording:

Play Timer:

For Rec Timer: Load a recordable tape into deck B. The display shows the timer settings.

(Latin American model only)

Recording onto a tape

The system offers three timer functions. You cannot activate both the Play Timer and the Rec Timer at the same time. If you use either with the Sleep Timer, the Sleep Timer has priority. You can fall asleep to music. This function works even if the clock is not set. Press SLEEP qd repeatedly. If you select “AUTO,” the system automatically turns off after the current disc or tape stops or in 100 minutes. Do not select “AUTO” during Synchro Recording of a tape.

Notes

Presetting radio stations

Using the Timers

Sleep Timer:

To delete the last track or file of the program

Press DISPLAY 5 repeatedly while the player is stopped.

You cannot set the SURROUND effect when “KARAOKE PON” has been selected.

For CD Synchro Recording: Press REC PAUSE/START 6. When the recording is completed, the CD player and the tape deck stop automatically.

To stop recording

To view program information, such as total playing time and the number of tracks

Note on the Mexican model

While recording, you cannot listen to other sources.

Press PLAY MODE qh repeatedly until “PGM” disappears while the player is stopped. Press CLEAR ws while the player is stopped.

To cancel karaoke mode, in addition to the above procedure, press KARAOKE 5 repeatedly until “m” disappears. To adjust the microphone reverb, turn ECHO LEVEL qa to adjust the reverb effect. To cancel, turn ECHO LEVEL qa to MIN. To use CD-Gs, turn on your TV, and select the appropriate video input.

3 Set deck B to stand by for recording.

For Manual Recording and Sound Mixing: Press REC PAUSE/START 6.

Total playing time of program (including selected track or file)

For the Mexican model only:

Repeat the same procedure as above until “TIMER OFF” appears, and then press ENTER qf.

Start over from step 1. Tips

• The Play Timer setting remains as long as the setting is not canceled manually. • The volume is reduced to minimum during the Rec Timer. • The Rec Timer is canceled automatically after the Rec Timer has been activated.

microphone volume level. qa.

The Mexican model has 2 microphone jacks.

3 For the Mexican model only: Press KARAOKE 5 repeatedly to select “KARAOKE PON” for stereo-recorded CD, or “MPX L” or “MPX R” for multiplex CD.

4 Start playing the music. 5 Turn MIC LEVEL qa to adjust the microphone volume. If acoustic (howling) occurs, reduce the volume, move the microphone away from the speakers, or change the direction of the microphone. After you have finished, disconnect the microphone from the MIC jack qa.

7

HCD-RG490/RG590 SECTION 3 DISASSEMBLY • This set can be disassembled in the order shown below.

3-1. DISASSEMBLY FLOW

SET

3-2. CASE (SIDE-L), CASE (SIDE-R) (Page 9)

3-3. CASE (TOP) (Page 9)

3-4. LID (CD) (Page 9)

3-5. CD MECHANISM DECK (CDM74KF-K6BD83S: Except Mexican model) (CDM74KF-F1BD84: Mexican model) (Page 11)

3-6. FRONT BLOCK (Page 10)

3-10. BD BOARD (Mexican model), CD BOARD (Except Mexican model) (Page 12)

3-12. OPTICAL PICK-UP BLOCK (KSM-213D: Except Mexican model) (KSM-215D: Mexican model) (Page 13)

3-7. MECHANICAL DECK (CWM42FF609) (Page 10) 3-11. DRIVER BOARD, SW BOARD (Page 13)

3-13. SENSOR BOARD (Page 14)

3-8. BACK SECTION (Page 11) 3-14. MOTOR (TB) BOARD (Page 14) 3-9. MAIN BOARD (Page 12) 3-15. MOTOR (LD) BOARD (Page 15)

8

HCD-RG490/RG590

Note: Follow the disassembly procedure in the numerical order given.

3-2. CASE (SIDE-L), CASE (SIDE-R)

3 case (side-L) 2 two screws (BVTP3 × 8)

1 three screws (case 3 TP2)

6 case (side-R)

5 two screws (BVTP3 × 8)

4 three screws (case 3 TP2)

3-3. CASE (TOP)

2 Open the case (top). 4 four claws 3

1 two screws (B3)

5 case (top) 2 Open the case (top).

2 Open the case (top).

9

HCD-RG490/RG590

3-4. LID (CD)

3 four claws

4 lid (CD)

2

1 Turn the gear (loading A) to the direction of the arrow.

3-5. CD MECHANISM DECK (CDM74KF-K6BD83S: EXCEPT MEXICAN MODEL) (CDM74KF-F1BD84: MEXICAN MODEL)

3 flexible flat (13 core) cable (Mexican model) (CN331) 2 flexible flat (23 core) cable (except Mexican model) (CN301) flexible flat (31 core) cable (Mexican model) (CN302)

6 CD mechanism deck (CDM74KF-K6BD83S: except Mexican model) (CDM74KF-F1BD84: Mexican model)

4 connector (Mexican model) (CN1004) 1 flexible flat (13 core) cable (CN701)

5 three screws (BVTP3 × 8)

5 screw (BVTP3 × 8)

5 screw (BVTP3 × 8)

10

HCD-RG490/RG590 Ver. 1.1

3-6. FRONT BLOCK • Abbreviation AR : Argentina model AUS : Australian model E2 : 120V AC area in E model E3 : 240V AC area in E model E51 : Chilean and Peruvian models EA : Saudi Arabia model MX : Mexican model RU : Russian model

1 flexible flat (19 core) cable (CN991)

5 front block

3 two connectors (CN301, CN302)

4 four screws (BVTP3 × 8)

2 flexible flat (9 core) cable (AEP, UK, RU, E3, EA, AUS models) flexible flat (13 core) cable (E2, E51, MX, AR models) (CN061)

3-7. MECHA DECK (CWN42FF609)

2 mecha deck (CWN42FF609)

2 cover (TCM) (Mexican model)

1 four screws (BVTP2.6 × 8)

1 two screws (BVTP2.6 × 8)

11

HCD-RG490/RG590 Ver. 1.1

3-8. BACK SECTION

4 back section

1 flexible flat (11 core) cable (AEP, UK models) flexible flat (9 core) cable (except AEP, UK models) (tuner (FM/AM)) 2 connector (CN041)

3 four screws (B3)

3 two screws (B3)

3-9. MAIN BOARD

2 connector (CN501)

5 two screws (BVTT4 × 8) 9 POWER board, SUB WOOFER board block

2 connector (RG490: CN903) (RG590: CN905)

4 screw (BV3) 8 MAIN board

2 connector (CN907)

7 connector (CN031)

6

3 screw (BVTP3 × 8)

1 flexible flat (11 core) cable (CN008)

12

3 screw (BVTP3 × 8)

HCD-RG490/RG590

3-10. BD BOARD (MEXICAN MODEL), CD BOARD (EXCEPT MEXICAN MODEL) 1 screw (BVTP2.6 × 8) 2 screw (BVTP3 × 8)

3 cover (CDM)

5 screw (BVTP2.6) (Mexican model)

6 gap tube (Mexican model)

8 BD board (Mexican model), CD board (except Mexican model) 7 Remove soldering from the four points.

4 flexible flat (16 core) cable (CN101)

3-11. DRIVE BOARD, SW BOARD 1 two screws (BTTP (M2.6)) 3 connector (CN703) 4 DRIVER board

5 screw (BTTP (M2.6))

6 SW board

2 wire (flat type) (5 core) (CN702)

13

HCD-RG490/RG590

3-12. OPTICAL PICK-UP BLOCK (KSM-213D: EXCEPT MEXICAN MODEL) (KSM-215D: MEXICAN MODEL)

1 floating screw (PTPWH M2.6)

2 holder (213) assy

9

5 two insulators

qg optical pick-up block (KSM-213D: except Mexican model) (KSM-215D: Mexican model) 8 two insulators

4 two coil springs (insulator)

7 two coil springs (insulator)

3 two floating screws (PTPWH M2.6)

6 two floating screws (PTPWH M2.6)

qd flexible flat (16 core) cable (CN101) qf BD board (Mexican model), CD board (except Mexican model) qa gap tube (Mexican model)

qs Remove the four solders of motor.

0 screw (BVTP2.6 × 8) (Mexican model)

3-13. SENSOR BOARD 1 floating screw (PTPWH M2.6) 2 tray

8 screw (BTTP (M2.6)) 3 belt (table) 0 SENSOR board 4 floating screw (PTPWH M2.6) 5 pulley (table)

6 floating screw (PTPWH M2.6) 7 gear (geneva)

14

9 connector (CN731)

HCD-RG490/RG590

3-14. MOTOR (TB) BOARD

2 stopper

4

1 stopper 7 table motor assy (M741)

3 wire (flat type) (5 core) (CN742) 8 MOTOR (TB) board 6 Remove the two solderings of motor. 5 two screws (BTTP (M2.6))

3-15. MOTOR (LD) BOARD

2 two screws (BTTP (M2.6)) 3 Remove the two solderings of motor. 4 MOTOR (LD) board

5 loading motor assy (M751)

1 belt (loading)

15

HCD-RG490/RG590 Ver. 1.1

SECTION 4 TEST MODE

COLD RESET

AMP TEST MODE

The cold reset clears all data including preset data stored in the RAM to initial conditions. Execute this mode when returning the set to the customer. Procedure: 1. Press three buttons of s , 7 and [DISC 1] simultaneously. 2. The message “COLD RESET” is displayed on the fluorescent indicator tube momentarily, then becomes standby states.

This mode is used to display the parameter of amplifier IC and display the VACS status. Procedure: 1. Press the I/1 button to turn the power on. 2. Press three buttons of s , 7 and A simultaneously. 3. When the AMP test mode is activated, the message “AMP TEST IN” is displayed on the fluorescent indicator tube momentarily, then amplifier adjustment mode is displayed on the fluorescent indicator tube. 4. Press the [REC PAUSE/START] button to changed over between VACS status display mode and the amplifier IC parameter display mode. 5. In this mode, press the [ENTER] button to changed over DBFB on/off, and “DBFB ON” or “DBFB OFF” is displayed on the fluorescent indicator tube. 6. In this mode, press the [SURROUND] button to changed over surround on/off, and “SURROUND ON” or “SURROUND OFF” is displayed on the fluorescent indicator tube. − HCD-RG490/RG590: UK models − 7. In this mode, press the [EQ BAND] button to enter the equalizer adjustment mode. In the equalizer adjustment mode, press the [EQ BAND] button to change over the adjustment band as LOW/MID/HIGH. And turn the multi jog knob to adjust the equalizer level of each bands. − Except HCD-RG490/RG590: UK models − 7. In this mode, press the [BASS], [VOCAL] or [GUITER] buttons to enter the parametric equalizer adjustment mode. In the parametric equalizer adjustment mode, press the [BASS], [VOCAL] and [GUITER] buttons to change over the adjustment band. And press the B and b buttons to adjust the equalizer frequency of each bands, or press the [+] and [--] buttons to adjust the equalizer level of each bands. 8. To release the amplifier IC parameter display mode or equalizer adjustment mode, press the I/1 button to the power off.

TUNING STEP CHANGE-OVER (Except RG490: AEP, Russian, Saudi Arabia/ RG590: AEP, UK, Russian, Saudi Arabia models) A step of AM tuning interval can be changed over between 9 kHz and 10 kHz. Procedure: 1. Press the I/1 button to turn the power on. 2. Press the [TUNER/BAND] button to select “AM”. 3. Press the I/1 button to turn the power off. 4. Press two buttons of [TUNING --] and I/1 simultaneously. 5. The message “AM 9K STEP” or “AM 10K STEP” is displayed on the fluorescent indicator tube, and thus the tuning interval is changed over.

CD SHIP (LOCK) MODE This mode moves the optical pick-up to the position durable to vibration. Use this mode when returning the set to the customer after repair. Procedure: 1. Press the I/1 button to turn the power on. 2. Press the [CD] button to select “CD”. 3. Press two buttons of 7 and [POWER] simultaneously. 4. The message “LOCK” is displayed on the fluorescent indicator tube, and the CD ship mode is set.

CD SHIP (LOCK) MODE & COLD RESET This mode is used to perform CD ship (lock) mode and cold reset simultaneously. Procedure: 1. Press the I/1 button to turn the power on. 2. Press the [CD] button to select “CD”. 3. Press three buttons of s , [CD] and A simultaneously. 4. The message “COLD RESET” is displayed on the fluorescent indicator tube momentarily, then becomes standby states.

ANTITHEFT LOCK MODE This mode is used to unable to take sample disc out of disc table in the shop. Procedure: 1. Press the I/1 button to turn the power on. 2. Press the [CD] button to select “CD”. 3. Press two buttons of s and A for 5 seconds. 4. The message “LOCKED” is displayed on the fluorescent indicator tube and the disc table is locked. (Even if pressing the A button, the message “LOCKED” is displayed on the fluorescent indicator tube and the disc table is locked) 5. To release this mode, press two buttons of s and A for 5 seconds. 6. The message “UNLOCKED” is displayed on the fluorescent indicator tube and the disc table is unlocked.

16

MC TEST MODE This mode is used to check operations of microprocessor. Procedure: 1. Press the I/1 button to turn the power on. 2. Press three buttons of s , 7 and [DISC 3] simultaneously. 3. When the MC test mode is activated, VACS level is displayed on the fluorescent indicator tube momentarily. 4. Turn the multi jog knob clockwise, the message “ALL EQ MAX” is displayed on the fluorescent indicator tube momentarily and turn the multi jog knob counterclockwise, the message “ALL EQ MIN” is displayed on the fluorescent indicator tube momentarily. 5. Press the [ENTER] button, the message “ALL EQ FLAT” is displayed on the fluorescent indicator tube momentarily. 6. Turn the [VOLUME] knob clockwise, the message “VOLUME MAX” is displayed on the fluorescent indicator tube momentarily and turn the [VOLUME] knob counterclockwise, the message “VOLUME MIN” is displayed on the fluorescent indicator tube momentarily. 7. Press the [REC PAUSE/START] button to changed over VACS on/off. 8. Press the I/1 button to release from this mode, then cold reset is performed.

HCD-RG490/RG590

VERSION DISPLAY MODE This mode is used to check the model, destination and software version. Procedure: 1. Press the I/1 button to turn the power on. 2. Press three buttons of s , 7 and [DISC 2] simultaneously. 3. Fluorescent indicator tube, and LEDs are all turned on. 4. Press the [REC PAUSE/START] button to display the software version and year, month, day of the software creation. 5. Press the [CD SYNC] button to display the model and destination. 6. To release this mode, press three buttons of s , 7 and [DISC 2] simultaneously.

CD ERROR CODE DISPLAY MODE This mode can be used for error code display of CD section. Procedure: 1. Press the I/1 button to turn the power on. 2. Press the [CD] button to select “CD”. 3. Press three buttons of s , [CD] and [DISC 1] simultaneously. 4. When this mode is activated, mechanism deck error code is displayed on the fluorescent indicator tube. 5. Press the [REC PAUSE/START] button to changed over between optical pick-up error code display mode and mechanism deck error code mode. 6. Turn the multi jog knob to change over display of error history. 7. To release this mode, press the I/1 button to turn the power off. 1. Mechanism Deck Error Code Mode When this mode is entered, mechanism deck error code is displayed with the 10-character format on the fluorescent indicator tube. The first digit from the left indicates: The first digit from the left indicates which mode the error history is. In the mechanism deck error code mode, “M” is displayed on the fluorescent indicator tube. The second digit from the left indicates: (Error history number display) The second digit from the left indicates which order the error history is. “1” indicates the latest error history, and each time the number increases by one, the error history goes back to one-previous error. The third and 4th digit from the left indicates: (Error status display) The third and 4th digit from the left indicates which error status is indicated. Display 0 0 0 8 1 6

1 7

1 8

2 0 2 2

The 5th and 6th digit from the left indicates: (Present status display) The 5th and 6th digit from the left indicates which operating status when an error occurred is indicated. Display 0 1 0 2 0 3 0 1 1 1 1 1 1

4 0 1 2 3 4 8

Status Open completion status From open status, the movement to chucking down position is under way From chucking down position, the open operation is under way Chucking down completion status The chucking down operation is under way The chucking up operation is under way Close completion status From close status, the ex-open operation is under way From ex-open status, the close operation is under way Ex-pen completion status

The 7th and 8th digit from the left indicates: (Motor status display) The 7th and 8th digit from the left indicates which motor output status when an error occurred is indicated. Display × 0 × 1 × 2 × 3 0 × 1 × 2 × 3 ×

Status No table motor output Table motor forward output Table motor backward output Table motor break output No loading motor output Loading motor forward output Loading motor backward output Loading motor break output

The 9th and 10 th digit from the left indicates: (Tray status display) The 9th and 10th digit from the left indicates which target processing when an error occurred is indicated. Display 0 1 1 2 1 8

Status Open operation Close operation Ex-open operation

Status No error Table operation time-out (Table does not move to the target position within the specified time) In the chucking down operation, the operation was retried by the maximum number of times but the operation could not be completed In the chucking up and down operation, the reverse recovery processing was attempted but it could not be recovered In the chucking up operation, the operation was retried by the maximum number of times but the operation could not be completed Loading operation time-out (Table does not move to the target position within the specified time) As the chuck was in the ex-open status at the initialization, the closing was attempted but could not be completed

17

HCD-RG490/RG590

2. Optical Pick-up Error Code Mode When this mode is entered, optical pick-up error code is displayed with the 8-character format on the fluorescent indicator tube. The first digit from the left indicates: The first digit from the left indicates which mode the error history is. In the optical pick-up error code mode, “D” is displayed on the fluorescent indicator tube. The second digit from the left indicates: (Error history No. display) The second digit from the left indicates which order the error history is. “1” indicates the latest error history, and each time the number increases by one, the error history goes back to one-previous error. The third and 4th digit from the left indicates: (Error status display) The third and 4th digit from the left indicates which error status is indicated. Display 0 1 0 2 0 0 0 0 0

3 4 5 6 7

Status Not focused (TOC read without a disc) GFS NG (TOC read with a disc chucked) Start operation time-over Defocused continuously (Defocused during TOC reading) Q code not entered for specified time Tracking not turned ON Blank disc (Blank disc TOC read)

The 5th and 6th digit from the left indicates: (Error step display) The 5th and 6th digit from the left indicates which processing when a trouble occurred Display 0 1 0 2 0 3 0 4 0 5 0 6 0 7 0 8 0 9 0 A 0 B 0 C 0 D 0 E

Contents Power OFF in progress Initialize in progress Oscillation stopping From oscillation stop, oscillation starting Stopping Stop operation is under way Start operation in progress TOC read in progress Search operation is under way Playback operation is under way Pause operation is under way Playback manual search operation is under way Pause manual search operation is under way —

The 7th and 8th digit from the left indicates: The 7th and 8th digit from the left indicates which operation in progress when a trouble occurred. (Step of each processing of the 5th and 6th digits is indicated)

18

5 REPEAT LIMIT CANCEL MODE Number of repeat for CD playback is 5 times when the repeat mode is “REPEAT”. This mode is used to enables CD to repeat playback for limitless times. Procedure: 1. Press the I/1 button to turn the power on. 2. Press the [CD] button to select “CD”. 3. Press three buttons of s , [CD] and 7 simultaneously. 4. The message “LIMIT OFF” is displayed on the fluorescent indicator tube momentarily, CD repeat 5 limit is cancelled.

CD POWER MANAGE This mode is used to changed over CD power on/off for decreasing of reception noise in the tuner mode. Procedure: 1. Press the I/1 button to turn the power on. 2. Press the [CD] button to select “CD”. 3. Press the I/1 button to turn the power off. 4. Press two buttons of s and I/1 simultaneously. 5. The message “CD POWER ON” or “CD POWER OFF” is displayed on the fluorescent indicator tube, and CD power on/off changed over in the tuner mode.

HCD-RG490/RG590 SECTION 5 MECHANICAL ADJUSTMENTS PRECAUTION 1. Clean the following parts with a denatured-alcohol-moistened swab : record/playback head pinch roller erase head rubber belts capstan idlers 2. Demagnetize the record/playback head with a head demagnetizer. (Do not bring the head magnetizer close to the erase head.) 3. Do not use a magnetized screwdriver for the adjustments. 4. After the adjustments, appiy suitable locking compound to the parts adjusted. 5. The adjustments should be performed with the rated power supply voltage unless otherwise noted.

TORQUE MEASUREMENT Mode

Torque Meter

FWD

CQ-102C

FWD Back Tension

CQ-102C

FF/REW

CQ-201B

Meter Reading 2.6 – 6.9 mN⋅m (30 – 70 g⋅cm) (0.41 – 0.97 oz⋅inch) 0.15 – 0.59 mN⋅m (1.5 – 6.0 g⋅cm) (0.021 – 0.083 oz⋅inch) 5.4 – 16.7 mN⋅m 55 – 170 g⋅cm) 0.76 – 2.35 oz⋅inch)

TAPE TENSION MEASUREMENT Mode

Tension Meter

FWD

CQ-403A

Meter Reading more than 100 g (more than 3.53 oz)

19

HCD-RG490/RG590 SECTION 6 ELECTRICAL ADJUSTMENTS DECK SECTION

4. After the adjustments, apply suitable locking compound to the pats adjusted.

0 dB=0.775 V

1. Demagnetize the record/playback head with a head demagnetizer. 2. Do not use a magnetized screwdriver for the adjustments. 3. After the adjustments, apply suitable locking compound to the parts adjust.

TEST TAPE Tape P-4-A063

Signal 6.3 kHz, -10 dB

Used for Azimuth Adjustment

RECORD/PLAYBACK HEAD AZIMUTH ADJUSTMENT Note 1: Remove the mecha deck before this adjustment. (Refer to Section 3. DISASSEMBLY (See page 8)) Note 2: Perform this adjustment for both decks.

Procedure: 1. Mode: Playback test tape P-4-A063 (6.3 kHz, –10 dB)

MIC. AUX. HP board PHONES jack (J701) level meter set

+ –

2. Turn the adjustment screw and check output peaks. If the peaks do not match for L-CH and R-CH, turn the adjustment screw so that outputs match within 1dB of peak.

within 1dB

L-CH peak

within 1dB

Output level

Screw position

R-CH peak L-CH peak

Screw position

R-CH peak

3. Mode: Playback test tape MIC. AUX. HP board P-4-A063 PHONES jack oscilloscope (6.3 kHz, –10 dB) (J701) V set

waveform of oscilloscope

in phase 45° good

20

90° 135° 180° wrong

H

Adjustment Location: Playback Head (DECK-A) Record/Playback/Erase Head (DECK-A)

HCD-RG490/RG590

CD SECTION Note: 1. CD Block is basically constructed to operate without adjustment. 2. Use YEDS-18 disc (3-702-101-01) unless otherwise indicated. 3. Use an oscilloscope with more than 10 MΩ impedance. 4. Clean the object lens by an applicator with neutral detergent when the signal level is low than specified value with the following checks. 5. Check the focus bias check when optical pick-up block is replaced. • Abbreviation MX: Mexican model

Connecting Location: – CD Board (Conductor Side) (Except RG490: MX/RG590: MX) –

FOCUS BIAS CHECK oscilloscope (DC range) CD board (Except RG490: MX/RG590: MX) BD board (RG490: MX/RG590: MX) TP (RFACI) TP (VC)

+ –

Procedure : 1. Connect oscilloscope to TP (RFACI) and TP (VC) on the CD board (Except RG490: MX/RG590: MX) or BD board (RG490: MX/RG590: MX). 2. Press the I/1 button to turn the power on, and press the A button to open the CD disc table. 3. Set disc (YEDS-18) on the tray and press the 7 button to playback. 4. Confirm that oscilloscope waveform is as shown in the figure below. (eye pattern) A good eye pattern means that the diamond shape (◊) in the center of the waveform can be clearly distinguished.

IC201

TP (VC)

TP (RFACI)

– BD Board (Conductor Side) (RG490: MX/RG590: MX) – VOLT/DIV: 200 mV TIME/DIV: 500 ns

level: 0.9 ± 0.4 Vp-p

TP (VC)

IC201

TP (RFACI)

21

HCD-RG490/RG590

MEMO

22

HCD-RG490/RG590 SECTION 7 DIAGRAMS 7-1. BLOCK DIAGRAM – CD SERVO Section – DETECTOR

+3.3V A

A 57 A

B B

BCK 5

6 BCKI

LRCK 1

2 LRCKI

AOUT2 117

R-CH A

FEO 55

E F 51 F

26 A

B

50 E

F

27 B

C

TEO 53

28 C

D LASER DIODE CD DSP IC201

AUTOMATIC POWER CONTROL Q321 LD

LD

SSTP

XTAO

39

109

108

67 PD

OPTICAL PICK-UP BLOCK (KSM-213D) (EXCEPT RG490: MX/RG590: MX) (KSM-215D) (RG490: MX/RG590: MX)

+3.3V

AUTOMATIC POWER CONTROL Q10

PD

27 OPOUT

OPIN+ 2

X201 16.9344MHz

MDP

6 9 10 11 12 13 14

MDP SFDR SRDR TFDR TRDR FFDR FRDR

38 MDP

CH3FIN 23

18 CH3OUTR

CH3RIN 22

SFDR

TEI 21

FEI 23

SSTP 7

78

77

102 105 104 107 115 95 110

98 99 110

65 66 63 60 65 61

S101 (LIMIT)

15 CH4OUTR 17 CH3OUTF

X171 16.9344MHz

41 SFDR

SBSO, WFCK, SCOR, EXCK

M

(FOCUS)

14 CH1OUTF

CH1FIN 4

13 CH1OUTR

CH1RIN 5

12 CH2OUTF

CH2FIN 6

11 CH2OUTR

CH2RIN 7

SRDR

TFDR TRDR

FFDR FRDR

MUTE 20

42 SRDR 15 54 28 18 19 71

TEI 52

43 TFDR

C-11 C-12 C-9 C-13 C-14 C-10 MP3-RST C-15

FEI 54

44 TRDR

45 FFDR

SYSTEM CONTROLLER IC901 (1/4) (EXCEPT RG490: MX/RG590: MX) IC901 (1/4) (RG490: MX/RG590: MX) O-LM-F 34 O-LM-R 33

C-3 C-5 C-15 C-6 C-7 C-11 C-12 C-9 C-10 C-14 C-13 C-1 C-8

C-8

C-4

MIDIO MICK MICS MIACK PO11/BUCK/AD14 MILP RESET STANDBY

: CD PLAY EXCEPT RG490: MX /RG590: MX

MP3 DECODR IC301

(RG490: MX/RG590: MX)

46 FRDR

89 11 16 20 26 12 90 13 14 10 15 7 8

Abbrivation MX : Mexican model R-ch is omitted due to same as L-ch. SIGNAL PATH

6 7 4 8 36 5 2 3

RG490: MX RG590: MX

C-3 C-5 C-15 C-4 C-6 C-7 C-11 C-12 C-9 C-10 C-14 C-13 C-1 C-8 MP3-RST

LOADING MOTOR DRIVE IC701 7 FIN 9 RIN

OUT1 4 OUT2 2

O-CD-DATA O-TM-F 36 O-CD-CLK O-TM-R 35 O-XLAT/O-MP3-STB O-D-MUTE/O-XLT I-CD-SENS I-SCOR I-CD-NUMBER-SENS 37 I-MP3-DATA O-MP3-DATA O-MP3-CLK I-CD-ENCODER 66 O-MP3-XLAT/O-MP3-CS O-MP3-CS/O-MP3-LP I-MP3-REQ I-OPEN-SW 38 I-MP3-ACK O-XTCN O-XRST O-MP3-RESST

7 FIN 9 RIN

OUT1 4 OUT2 2

LEVEL SHIFT Q731 ROTARY ENCODER S711

OPEN CLOSE

HCD-RG490/RG590

23

23

M

M751 (LOADING)

M

M741 (TABLE)

TABLE MOTOR DRIVE IC712 52 54 28 31 53 40 71 72 70 26 30 29 27 24 32 25

B

(Page 25)

SDIO BCKA LRCKA SBSY/BCKIB SFSY/LRCKIB SDO0

(TRACKING)

2-AXIS DEVICE

: VIDEO

R-CH

37 PD MDP SFDR SRDR TFDR TRDR FFDR FRDR

DATA CLOK XLAT SENS SCOR DATA2 CLK2 XLAT-MP3 REQ-MP3 IREQ-MP3 ACK-MP3 XTACN XRST

M402 (EXCEPT RG490: MX/RG590: MX) M102 (RG490: MX/RG590: MX) (SLED)

CH4IN 24

AOUT2 86

CD DSP IC101

36 LD

16 CH4OUTF

M

42 RFACI

TEO 22

FOCUS/TRACKING COIL DRIVE, SPINDLE/SLED MOTOR DRIVE IC402 (EXCEPT RG490: MX/RG590: MX) IC251 (RG490: MX/RG590: MX) M401 (EXCEPT RG490: MX/RG590: MX) M101 (RG490: MX/RG590: MX) (SPINDLE)

RFACO 41

20 F

S201 (LIMIT) (EXCEPT RG490: MX/RG590: MX)

AOUT1 81

EG_ IN

FEO 24

F

PD

35

19 E

66 LD

XTAI

PD

AC_ 34 SUM

29 D

E LD

A

(Page 24)

PCMD BCK LRCK BCKI LRCKI PCMDI

60 D

E

4 PCMDI

SBSO EXCK WFCK

71 RFACI PCMD 3

SCOR SBSO EXCK WFCK

59 C

D

CD-L

AOUT1 112 RFACO 70

DATA CLOK XLAT SENS SCOR XTACN XRST

D

EG_ IN

C-3 C-5 C-4 C-6 C-7 C-1 C-8

I-V AMP

C

65

XTAO

AC_ 64 SUM

XTAI

58 B

C

DISC TABLE ADDRESS SENSOR IC731 DISC TABLE ADDRESS DETECT S751 DISC TABLE OPEN/CLOSE DETECT

HCD-RG490/RG590 Ver. 1.1 7-2. BLOCK DIAGRAM – MAIN Section – (RG490: MX/RG590: MX) DIGITAL ECHO IC802

Abbrivation AR : Argentina model E2 : 120V AC area in E model E3 : 240V AC area in E model E51 : Chilean and Peruvian models EA : Saudi Arabia model MX : Mexican model R-ch is omitted due to same as L-ch. SIGNAL PATH

VR851 ECHO LEVEL (RG490: MX/RG590: MX)

JK801 MIC 1

MIC AMP IC801 (1/2) MUTING Q801

JK802 MIC 2

VR801 MIC LEVEL

: TUER (FM/AM) : CD PLAY

RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR

+9V

: TAPE PLAY (DECK-A)

JK802 MIC

: TAPE PLAY (DECK-B)

RG490: E2, E51, AR/ RG590: E2, E51, AR

RG490: E2, E51, AR/ RG590: E2, E51, AR

: REC INPUT SELECTOR, TONE CONTROL, ELECTRICAL VOLUME IC101 (EXCEPT RG490: MX/RG590: MX) IC101 (RG490: MX/RG590: MX)

RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR

: AUDIO IN

36 37

HP IN

(Page 25)

(RG490/RG590: AEP, UK, RU) J702 AUDIO IN

2 AUXL

R-CH

TONEOUTL 10

11 VINL

OUT

OUTL 14

(RG590: E2, E3, E51, EA, MX, AR)

CD-L

40 CDL

(Page 23)

PB SWITCH (DECK-A) Q301

L-CH HP1 (PB) (DECK-A) R-CH

PB AMP IC301

+

R-CH

R-CH

BB12 12

PARAMETRIC EQUALIZER IC102 (RG590: E2, E3, E51, EA, AR) IC102 (RG590: MX)

SW OUT

+

LOUT 9 BB22 13

RECOUTL 3

D031

BASS AGC Q113

BASS AGC

R-CH

R-CH

R-CH

R-CH

REC SWITCH Q403 HRPE1 (REC/PB/ERASE) (DECK-B)

MUTING Q307 Q401

MUTING MUTING CONTROL CONTROL SWITCH SWITCH Q400, Q305, 407 306

REC BIAS SWITCH Q451, 452

ERASE

+9V

REC CONTROL SWITCH Q409, 410

TAPE MECHANISM DECK CONTROLLER IC701 (1/2)

D923

TAPE MECHANISM DECK BLOCK

O-MOTOR 33

CAPSTAN/REEL MOTOR DRIVE Q701, 704

CAMP+

O-SOL-A 34

TRIGGER PLUNGER DRIVE (DECK-A) Q703, 706

A-SOL

2

3

61 55

58 57

56

68 63

O-REC-MUTE

I-HP/AUDIO IN I-MIC-DET

O-R2S15207FP-DATA O-AUDIO-CLK

O-R2S15208SP-DATA

I-STREAM I-VACS

45 43 44 42

4

O-REC/PB

AM ANT

O-SOL-B 35

TRIGGER PLUNGER DRIVE (DECK-B) Q702, 705

B-SOL

D921

O-BIAS

R-CH

I-LC23003-DI O-LC23003-DO O-LC23003-CLK O-LC23003-CE

SYSTEM CONTROLLER IC901 (2/4) (EXCEPT RG490: MX/RG590: MX) IC901 (2/4) (RG490: MX/RG590: MX)

RDS-DATA RDS-CLK

RDS DATA RDS CLK

D

BAND- FILTER Q111, 112

TUNER-L

PLL DO PLL DI PLL CLK PLL CE

(Page 25)

REC AMP IC401

M

TUNER (FM/AM) FM ANT

TUNER-R AM

4

DECK-A/B SELECT SWITCH, REC/PB SELECT SWITCH Q405, 406, 408

BIAS OSC Q453

FM75Ω COAXIAL

16 15

R-CH R-CH

L451 BIAS OSC

ANTENNA

SAOUT

MUTING Q305

DATA CLK

3 6

L-CH

(Page 25)

F

(Page 25)

G

(Page 25)

R-CH 2 LIN

1 TUNERL

PB SWITCH (DECK-B) Q303

E

R-CH

39 TAPEL

DATA CLK

A

: MIC

MIC1 MIC2

C

MIC AMP IC801 (2/2)

RDS-DATA, RDS-CLK (RG490: AEP/RG590: AEP, UK)

HCD-RG490/RG590

24

24

I-TCM-SYNC 73

36 O-TCM-SYNC I-HALF-A I-HALF-B I-RELL-A I-RELL-B I-REC-SW

30 27 31 28 29

A-HALF B-HALF A-PHOTO B-PHOTO B-REC-F

HCD-RG490/RG590 Ver. 1.1 7-3. BLOCK DIAGRAM – AMP/VIDEO Section – HP IN

G

BASS AGC

+

R-CH

(Page 24)

R-CH IC251 (EXCEPT RG490: MX/RG590: MX) IC251 (RG490: MX/RG590: MX)

E

OUT

IC441 (RG490) IC441 (RG590) JK441

–1 BUFFER

POWER AMP

+ – – +

(Page 24) –2

STANDBY SWITCH Q489 (RG490) Q489 – 491 (RG590)

MUTING Q251

C

(Page 24)

J701 PHONES

R-CH

L SPEAKER R

RY441 R-CH TH441 RELAY B+ OVER LOAD DETECT Q441

TEMPERATURE DETECT Q483, 484

DC DETECT Q481, 482

FAN MOTOR DRIVE Q043 – 045

R-CH

M

M001 (FAN)

D035

+

R-CH

TEMPERATURE DETECT Q503, 507

F

SW OUT

BUFFER Q276

LINE AMP Q277

BUFFER Q271

PROTECTOR Q485

+

+

+

+

OVER LOAD DETECT Q501

DC DETECT Q505, 506

FAN MOTOR DETECT Q046

RELAY DRIVE Q486, 488 PROTECT DETECT Q487

+

JK501

POWER AMP IC501

+ –

(Page 24) MUTING Q272

SUB WOOFER OUT

RY501 RELAY DRIVE Q502

MUTING CONTROL SWITCH Q261

SUB WOOFER SWITCH Q274 PROTECT

(RG490: MX/RG590: MX)

O-SWR

41

I-PROTECTOR

49

22

H

(Page 26)

J803 3 DATA 5 SFSY 4 SBSY

SCHMITT TRIGGER IC1005

EXCK

1, 2, 24, 25

(Page 24)

VD0 – VD3

RDS-DATA, RDS-CLK

RDS-CLK

VA0 – VA7

3 22 4 23

13 28 14 26

XWE XOE XRAS XCAS

MUTE 6

LEVEL SHIFT Q1005, 1009

XRESET 54

LEVEL SHIFT Q1002, 1006

DEN 52

59

60

NTSC/PAL SELECT SWITCH Q1001

D

(RG490: AEP/RG590: AEP, UK)

GDET 37

15 – 22

WE OE RAS CAS

VIDEO OUT

RDS-DATA

9 – 12, 14 – 17

A0 – A7

VIDEO AMP IC1006

VIDEO MUTING Q1010

2 CLCK

DQ1 – DQ4

D-RAM IC1002

VOUT 44

XO1

SBSO WFCK SCOR

XI1

(Page 23)

46 48

64

CD GRAPHICS DECODER IC1001

25, 27, 29, 30

B

SBSO, WFCK, SCOR, EXCK

O-CDG-RST /I-RDS-CLK

O-STK-MUTE

SYSTEM CONTROLLER IC901 (3/4) (EXCEPT RG490: MX/RG590: MX) IC901 (3/4) (RG490: MX/RG590: MX)

O-CDG-MUTE-DATA /I-RDS-DATA

5

O-VMUTE I-CDG-DET

21 O-SYS-XMUTE

RG490: AEP, MX/ RG590: AEP, UK, MX

Abbrivation MX : Mexican model R-ch is omitted due to same as L-ch. SIGNAL PATH : TUNER (FM/AM)

+3.3V

: VIDEO

X102 14.31818MHz

HCD-RG490/RG590

25

25

HCD-RG490/RG590 Ver. 1.1

7-4. BLOCK DIAGRAM – /POWER SUPPLY Section –

68 – 80

FL701 FLUORESCENT INDICATOR TUBE

45 – 58, 61 – 67

FLUORESCENT INDICATOR TUBE /LED DRIVER IC701 (2/2) SO1 SI1 SCK1 CE XRESET

S1 – S21

9 8 7 16 6

PT901 MAIN POWER TRANSFORMER

SYSTEM CONTROLLER IC901 (4/4) (EXCEPT RG490: MX/RG590: MX) IC901 (4/4) (RG490: MX/RG590: MX) 77 76 78 75 74

VF VF

I-VFD-DATA O-VFD-DATA O-VFD-CLK O-VFD-CE O-VFD-RESET

B+ SWITCH Q041, 042

RELAY B+

G1 – G13

F904 RECT D402

39 – 43

(RG490: MX/RG590: MX) LED DRIVE Q601 – 605

D908

(RG590)

O-FRONT-SP-RELAY 23

D601 – 605 (STREAM)

–27V REGULATOR Q902

–VFL

STREAM LED1 – STREAM LED5

CDG +5V

+5V REGULATOR IC1003

F905 AMP SECTION B+

B+ SWITCH Q1007, 1008

(RG490) F908

O-CDG-POWER 47 D622 (RG490/RG590: AEP, UK, RU) D623 (RG590: E2, E3, E51, EA, MX, AR)

LED DRIVE Q621

SUBWOOFER S611 – 613, S614 – 618 (RG590: E2, E3, E51, EA, MX, AR), S621 – 627, S628 (RG490/RG590: AEP, UK, RU), S631 – 638, S641 – 648 (RG590: E2, E3, E51, EA, MX, AR)

RECT D401

37 SW LED

F909

D301, 302

(RG590)

M+7V +9V REGULATOR

19 – 22

M+9V D001

IC021 (EXCEPT RG490: MX/RG590: MX) IC021 (RG490: MX/RG590: MX)

KEY1 – KEY4

+9V REGULATOR

+9V S671 VOLUME

ROTARY ENCODER

10 I-VOL-A 11 I-VOL-B

IC011 (EXCEPT RG490: MX/RG590: MX) IC011 (RG490: MX/RG590: MX)

ROTARY ENCODER

F907

12 I-JOG-A 13 I-JOG-B

F906 +3.3V REGULATOR

X1

X2

+3.3V 3

4 CD DSP +1.8V

+1.8V REGULATOR IC203

IC006 (EXCEPT RG490: MX/RG590: MX) IC006 (RG490: MX/RG590: MX)

(EXCEPT RG490: MX/RG590: MX)

RECT D001 – 004

RG490: E2, E3, E51, EA/ RG590: E2, E3, E51, EA VOLTAGE SELECTOR S901

D006

MP3 +1.5V

69 O-STBY-LED

EVER +10V

RECT D902 – 905 RG490: AEP, RU, MX, AR, AUS/ RG590: AEP, UK, RU, MX, AR PT902 SUB POWER TRANSFORMER POWER ON/OFF RELAY DRIVE Q002

+1.5V REGULATOR IC303 (RG490: MX/RG590: MX)

D008 D007

REMOTE CONTROL RECEIVER IC610

RY901

(AC IN)

X701 4.19MHz

D611 STANDBY

RG490: AEP, RU, MX, AR, AUS/ RG590: AEP, UK, RU, MX, AR

RECT D011 – 014

UNREG +16V S672 (MULTI JOG)

RECT D021 – 024

80 I-XSIRCS-IN

PROTECT DETECT Q011

PROTECT

(Page 25)

D902 I-XRESET 10 S601 – 606

65 I-KEY0

VDD (+3.3V)

RESET SWITCH Q901

REGULATOR Q903, 904

RESET SIGNAL GENERATOR

I-AC-CUT 9 79 I-WAKEUP

IC902 (EXCEPT RG490: MX/RG590: MX) IC902 (RG490: MX/RG590: MX) AC DETECT Q902

I-AC-PULSE 1

RECT D910

X1 (16MHZ)

X2 (16MHZ)

XT1 (32.768KHZ)

XT2 (32.768KHZ)

O-POWER-RELAY 7

15

14

12

11

X902 16MHz

Abbrivation AR : Argentina model AUS : Australian model E2 : 120V AC area in E model E3 : 240V AC area in E model E51 : Chilean and Peruvian models EA : Saudi Arabia model MX : Mexican model RU : Russian model

X901 32.768kHz

HCD-RG490/RG590

26

26

H

HCD-RG490/RG590 Ver. 1.1

• Note For Printed Wiring Boards and Schematic Diagrams Note on Printed Wiring Board: • X : parts extracted from the component side. • Y : parts extracted from the conductor side. • f : internal component. : Pattern from the side which enables seeing. • (The other layers' patterns are not indicated.) Caution: Pattern face side: (Conductor Side) Parts face side: (Component Side)

Parts on the pattern face side seen from the pattern face are indicated. Parts on the parts face side seen from the parts face are indicated.

Caution: Pattern face side: (Side B) Parts face side: (Side A)

Parts on the pattern face side seen from the pattern face are indicated. Parts on the parts face side seen from the parts face are indicated.

• Indication of transistor

C Q

These are omitted.

B E

Q B

C

E These are omitted.

• Circuit Boards Location Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. (p: pF) 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • f : internal component. • 2 : nonflammable resistor. • 5 : fusible resistor. • C : designation.

CD-G board (MX model) BD board (MX model)/ CD board (EXCEPT MX model)

SW board MOTOR (LD) board KEY TOP board (RG590: E2, E3, E51, EA, MX, AR models)

SENSOR board

Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. • A : B+ Line. • B : B– Line. • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. – CD/BD Boards – no mark :CD PLAY – CD-G Board – no mark : CD-G PLAY – Other Boards – no mark : TUNER (FM/AM) ( ) : CD PLAY ⟨⟨ ⟩⟩ : TAPE PLAY { } : REC ∗ : Impossible to measure • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal production tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal production tolerances. • Circled numbers refer to waveforms. • Signal path. F : TUNER (FM/AM) J : CD PLAY E : TAPE PLAY (DECK-A) d : TAPE PLAY (DECK-B) G : REC N : MIC f : AUDIO IN L : VIDEO • Abbreviation AR : Argentina model AUS : Australian model E2 : 120 V AC area in E model E3 : 240 V AC area in E model E51 : Chilean and Peruvian models EA : Saudi Arabia model MX : Mexican model RU : Russian model

KEY LEFT board

DRIVER board

TUNER (FM/AM) MOTOR (TB) board

board

MIC. AUX. HP board KEY RIGHT board

VIDEO-OUT board (MX model)

TRANSFORMER board

SUB WOOFER board

SW-SP board MAIN board

POWER board

DECK board • Abbreviation AR : Argentina model E2 : 120 V AC area in E model E3 : 240 V AC area in E model E51 : Chilean and Peruvian models EA : Saudi Arabia model MX : Mexican model

HCD-RG490/RG590

27

27

HCD-RG490/RG590

7-5. PRINTED WIRING BOARD – CD Board (Except RG490: MX/RG590: MX models) –

1

2

3

• See page 27 for Circuit Boards Location.

4

5

: Uses unleaded solder.

6

7

8

9

10

A CD BOARD (COMPONENT SIDE) CD BOARD

M

M401 (SPINDLE)

(CONDUCTOR SIDE)

S201 (LIMIT)

C401

B C403

R280 C405

C406

R421

C

C104

22

21

15

IC402

R451 R104 R105

M

R109

R102

C272

28

C451

R107

R452

R110

R423

C109

R101

1

R277 R275

R108

7

8

14 M402 (SLED)

C219 31

D

C220

C101 C102

C232

C215

C268

120

C224

TP (VC)

R291

C217

IC201

C205 C207

C206

C251

C223 C210

C203

C202

E

61

C254

R256 R207

MAIN BOARD CN301

C221

(Page 36)

C208

C261

R260 C256

C258 C230

R268

R267 R265

12

R322 R321

Q321

E

C273

R324 R323

C321

C303

C264

C227

1-868-067-

(12)

C322

F

A

C222

90 TP (RFACI)

C323

C274

C204

91

R254

C257

R201

60

CN301

C265 R266

R202

CN102

C213

R255 C253

R258

C266 R271

R252 R253

C260 R250

C110 C201

C252

R203

R257

X201

C275

C267

C108

R270

C276

C214

R401

C292

R292 C218

1

30

C277

C424

R278

C105

C291

C103

C107

C271

R276

R103

C404

C301 C304

C112

R112

C113

R113 R111

C111

C226 4

3

5

1

IC203

OPTICAL PICK-UP BLOCK (KSM-213D)

12 1-868-067-

HCD-RG490/RG590

28

28

(12)

HCD-RG490/RG590

• See page 57 for Waveforms.

7-6. SCHEMATIC DIAGRAM – CD Board (Except RG490: MX/RG590: MX models) –

• See page 62 for IC Block Diagrams.

• See page 66 for IC Pin Function Description.

C260 0.47

C261 0.01

R260 0

C273 470p

C264 1000p

C210 0.1 C208 0.1

TP (RFACI)

R256 22k

C230 100p

C257 0.1

R265 4.7k

R250 1M R258 220k

C265 0.1

R268 10k

C274 0.1

CN301 16P

C301 0.1

VC

R267 4.7k

C258 220p

VCC R266 1k

R257 100k

R324 100k C256 0.1

C221 0.1

C323 100 10V

R321 2.2

C322 1

C304 1

C303 10

E D

R322 2.2

A B

Q321 2SA2119K

R323 0

C

AUTOMATIC F

POWER C321 1000p

GND

CONTROL

LD VR PD F+

TP (VC)

T+

AVDD4

RFDCO

PDSENS

LD

AC_SUM

PD

EG_IN

RFC

RFACI

AVSS4

RFACO

AVDD3

BIAS

ASYI

ASYO

VPCO

VCTL

AVSS3

FILI

CLTV

PCO

FILO

SVSS

VDD

SVDD

VSS

SVDD

SSTB-MP3

C222 0.1

DATA

SVSS

TEST1

TCLK2

F-

M401

D

(SPINDLE) SP+

C SP-

JTAGTCK

B SL+

JTAGTDI

A C207 100 10V

JTAGTDO

C254 4700p

R255 1k JTAGTMS TRST VSS

TEO

VDD

TEI

C213 0.1 F

DOUT

E

TEST

C267 5p

C266 10p R270 1k

X201 16.9344MHz

C215 0.1

R271 1M

AVDD0

IOVSS2

CD DSP

IOVDD1

PLLVDD

IC201 CXD3014A-201R

FRDR

PLLVSS

FFDR

XVSS

TRDR

XTAO

TFDR

XTAI R203

C218 0.1

R112 100

C202 0.1 C217 0.1

C291 470p

SFDR

AVDD1

IOVSS1

AOUT1

SSTP

VREFL

MDP

AVSS1

LOCK

AVSS2

VDD

AOUT2

VSS

C424 0.1

SVSS

COUT

VDD

SCOR

C2PO

GFS

XPCK

XUGF

SVDD

WFCK

SENS

SVSS

VDD

DFCT XLAT

ACK-MP3

R423 10k

C404 0.1

FOK REQ-MP3

XLAT-MP3

DATA2

CLOK

VSS

XRST

IREQ-MP3

XTACN

BCK

BCKI

PCMDI

PCMD

LRCKI

LRCK

IOVSS0

C219 0.1

VOUT

STBY

NC

C451 0.047 R451 22k

R292 100

IOVDD0

GND

R452 10k

VSS

VREFR

AVDD2

VIN

C232 0.1

C277 1

C292 470p

CN102 23P

C205 0.1

C276 1

R291 100

C201 100 10V

R111 100

0.1

SRDR

XVDD

R113 100

C251 470p

AVSS0 C206

C268 10p

(SLED)

C252 4700p R252 10k

IOVDD2

TES1

C275 5p

C253 470p

FEI R253 1k

C223 0.1

M402

FEO R254 10k

C214 0.1

SL-

VC

R421 0

MIRR SVDD

+1.8V REGULATOR

DATA

IC203 BH18LB1WG-TR

CLK-MP3

C224 0.1

D-MUTE

OPIN+

OPINPREVCC

CH1FIN

GAIN-SW

CH4CAPA

OPOUT

CH2FIN

CH1RIN CH4IN

CH2RIN

CH3FIN

GND

CH3RIN

CNF4

POWVCC

MOTOR DRIVE IC402 BA5947FM

R277 100 R110 100

VREF

SPINDLE/SLED C272 0.1

XRST

(Page 39)

GND

XATCN

C271 0.1

MUTE

AVDD(3.3V)

R276 47k

CH2OUTF

COIL DRIVE,

R275 100

CH2OUTR

FOCUS/TRUCKING

R201 0

R278 100

R-CH

POWVCC

C204 0.1

A-GND

CH3OUTR

C203 100 10V

R202 0

L-CH

CH1OUTF

D-GND

CH1OUTR

C220 0.1

CH3OUTF

C227 1

C226 1

CH4OUTF

R207 0

D-OUT

CH4OUTR

DVDD(3.3V)

IREQ-MP3 R103 100 CLK R105 100 DATA-MP3 R104 100 XLAT-MP3 R109 100 REQ-MP3 R108 100 ACK-MP3

R280 0

R107 100 XLAT R102 100 SENS R101 100 SCOR

C405 0.1

C406 0.1

HCD-RG490/RG590

29

29

SL-

SP-

C401 220 10V

SL+

R401 0

SP+

C107 220p

C109 220p

C104 220p

C105 22p

C103 22p

C101 22p

C102 22p

C108 220p

C110 220p

C112 22p

C113 22p

M+7V

C111 220p

M-GND

S201 (LIMIT)

HCD-RG490/RG590

7-7. PRINTED WIRING BOARD – BD Board (RG490: MX/RG590: MX models) –

1

2

3

• See page 27 for Circuit Boards Location.

4

5

: Uses unleaded solder.

6

7

8

9

10

11

A BD BOARD (COMPONENT SIDE) M

M101 (SPINDLE)

BD BOARD

IC303

S101 (LIMIT)

(CONDUCTOR SIDE)

C302

B

3

1

4

5

C305

C303

C255 R313

R351

C260

R419

C306

C316 28

22

21

15

R403

R353

C257

C313

R354

C

R405

R404

C252

C315

R302

16

1

R352

IC251

C314

17

64

IC301

R307 C312

C317 1

C259

7

8

14

C320

R305 32

C308

C309

49 33

R402 R410

48

R401

R409 R303

R191

R165

R201

R411

R408 C194

CN201

90

C181 C112

C15

C11

R121

C162

R181

R112 32

R161

1-864-566-

61

30

11

C16

Q10

C185

C161

R13 C151

C111

C17

R12

C18

R171

R11

C10

C125

IC101

R111

C195

(11)

31

CN101

E

R151 R423

C132 R141

C134

C133 TP (RFACI)

R203 R142

R132

R133

OPTICAL PICK-UP BLOCK (KSM-215D)

30

30

C141

C131

R143 C142

R131

HCD-RG490/RG590

31 R421 R422

C143

C122

C123

R204

60

C124

R10

11 1-864-566-

(11)

B MAIN BOARD CN302

C186

C115

C171 C209

91

R182

C172 R172

X171

F

120

C196

E C203

R406

1

C14

C182

C163

R412

R173 C174

C201

TP (VC)

R114

C183

R162

C251

R113

C210

1

R407

C113

R251

C184

R205

C212

R163

R252

C114

D

C213

C310

C116

C211

C318

FB301

M102 (SLED)

C311

C307

R253

C258

M

R301

R306

(Page 40)

HCD-RG490/RG590

7-8. SCHEMATIC DIAGRAM – BD Board (RG490: MX/RG590: MX models) –

• See page 57 for Waveforms. • See page 62 for IC Block Diagrams.

• See page 66 for IC Pin Function Description.

C131 100p

C10 10

C142 1500p

R141 4.7k

C17 220 4V

R12 100k

C16 1

R132 10k

VC

C123 0.1

C122 0.1

VCC C11 10

R10 3.3

(RFACI)

R133 180k

C15 0.1

R13 1

R121 15k

TP

C133 0.01

C141 0.1

R151 0

R131 1M

C124 330p

C143 0.1

R142 1k

R307 10k

R143 3.3k

C125 0.1

C132 0.47

C151 100 10V

R203 0 C307 0.1

C134 0.1

Q10 2SB1690KT146

R11 0

AUTOMATIC

E

E

D

D

A

A

B

B

C

C

F

AGND

SBSY/BCKIB

R351 100

BCKO

AVDD4

RFDCO

PDSENS

LD

EG_IN

PD

NC

RFC

AVSS4

RFACI

RFACO

ASYI

BIAS

ASYO

VCTL

VPCO

AVSS3

FILI

FILO

PCO

AC_SUM

LRCKI

AVDD3

R352 100

LRCKO

CLTV

PCMDI

AVDD5

SDI0

AVSS5

BCKI

DDVRSEN

BCKIA

PD

NC D C B

VSS

B

C306 0.1

MICK MIDIO

MIDIO MILP

R403 100

MICS

R401 100

MP3STB MP3RST

R173 0

C172 27p

C174 0.1

C113 3300p

F

TEST

E

F

R172 1M

C115 0.1

NC AVSS0 AVDD0 IOVDD1

XVSS

CD DSP

XTAO

IC101 CXD3059AR

FRDR FRDR FFDR

XTAI

FFDR

XVDD

TRDR TFDR

AVDD1

TFDR

AOUT1

SRDR

SRDR SFDR

C183 R181 22 100 6.3V

C316 0.0022 C186 470p

AOUT2

VREFL

SFDR

AVSS1

IOVSS1

AVSS2

SSTP

VREFR

MDP

AOUT2

LOCK

AVDD2

VSS

C195 0.1

S101

MDP

R182 C184 22 100 6.3V

FOK

MIRR NC

COUT

WDCK

C4M

VDD

SCOR

C2PO

GFS

XUGF

XPCK

WFCK

ATSK

SCLK

SENS

DFCT VDD

CLOCK

XLAT

VSS

DATA

SYSM

XRST

EXCK

SBSO

LMUT

SQCK

RMUT

SQSO

IOVDD0

IOVSS0

NC

C203 100 10V

(LIMIT)

+1.5V REGULATOR VIN

GND

R113 1k

AOUT1

C162 0.1 STBY

C111 3300p

TRDR

C185 470p

C308 47 4V

NC

TEI

DOUT

NC

C201 100 10V

VOUT

IOVDD2

XTACN

VCOI

VSSP

MIMD

TEST

VSSX

XI

XO

X171 C171 R171 22p 16.9344MHz 470

C181 0.1

C182 0.1

C309 0.1

TEO

IOVSS2 C318 0.01

R313 220

C312 0.1

EMPHI

TEST1

C317 0.01

C311 0.1

R111 1k R112 15k

E

R161 100

VDDP

C315 0.1

FEI

C114 470p

RESET

R306 0

FEO

EMPH

R114 15k

R305 100k

C313 0.1

F-

TP (VC)

R402 100

VDD

DOUT

R301 100k

C314 47 4V

T-

CN101 16P

C112 470p C161 0.1

STANBY

VDDX

VDD

VSS

AD0/PO00

AD1/PO01

AD3/PO03

AD2/PO02

R419 100

VC

XTSL

MICS CKO/PO13/AD16

MILP

AD8 PO07/AD7

C116 100 10V

A

BCK

NC

IC301 TC94A34FG-002

AD4/PO04

MIACK

R404 100 MICK

AD9

PO06 /AD6 PO05 /AD5

R405 100 MIACK MP3 DECODER

R302 10k

SRMSTB

C310 0.1

R353 100

VDDT

AD10

T+

F-

A PCMD

VSS PO10/CCE/AD13

VDDM

VDDT

F+

T+ T-

C

PO11/BUCK/AD14 PO08/AD11

R303 100k

C14 0.1

F+

D

LRCK

SDO0

PO9/AD12

VR

C18 1000p R354 100

LRCKIA

NC

TXO

VDD

SFSY/LRCKIB

VSS

CKI/CLOCK/ IRQ/FIO

PIO0/SDI2/IO0

PIO3/IO3

PIO2/IO2

DATA

DDVROUT

MP3REQ

SDI1/

DDCR

SDO3/OE

PIO1/SDI3/IO1

AD15/CAS/

LD PIO4/FI1/BUS0/IO4

PO12

PIO7/BUS3/IO7

CS/RAS/

PIO6/FI3/BUS2/IO7

SDO2

PIO5/FI2/BUS1/IO5

CONTROL WE/SDO1

F

POWER

IC303 BH15FB1WG

R162 47k

C210 0.1 C196 0.1

C194 0.1 R165 0

C303 0.1

SCOR

SENS

R252 22k

WFCK

CLOCK

R251 10k

XLT

DATA

SBSO

EXCK

XRST

R191 0 R163 C163 100 0.1

XTACN

C302 0.1

FB301

C305 220 4V

CN201 31P M+7V M-GND M-GND

MIACK

MILP

MP3-CS

MICS

MP3-GND

R253 10k

C259 0.1

C213 22p

MP3(3.3V) MP3-RST

C251 6800p

FRDR

MDP

MP3-LP

FFDR

MIDIO

TFDR

MP3-DIO

TRDR

MICK

MP3-CLK

T-

MP3-ACK

F+

MP3REQ

F-

MP3STB

MP3-REQ

T+

MP3-STB

C258 0.1

MP3RST

C320 1000p

R205 0

C209 0.01 C257 0.1

AOUT2

R-CH

CH1OUTF

CH1OUTR

CH2OUTF

POWVCC

GND

CNF4

CH2OUTR

CH4OUTR

CH4OUTF

CH3OUTF

CH3OUTR

POWVCC

AVDD(3.3V)

OPOUT

IC251 BA5947FM-E2

XTACN

OUTVREF

SPINDLE/SLED MOTOR DRIVE

MUTE

R412 100

C211 220p

GND

XTCN

CH2RIN

XRST

COIL DRIVE,

CH3RIN

DATA

R406 100

CH1FIN

R407 100

XRST

CH2FIN

CD-DATA

FOCUS/TRACKING

CH1RIN

XLT

CH3FIN

CLOCK

R408 100

CH4IN

R409 100

XLT

CH4CAPA

CD-CLK

C212 22p

SW

SENS

OPIN+

SCOR

R410 100

PREVCC

(Page 43)

R411 100

CD-SENS

OPIN-

R201 SCOR

C252 0.1

C255 0.1

C260 220 10V

A-GND

DOUT

D-OUT DVDD(3.3V)

SFDR

D-GND

R204 0

D-GND

SRDR

AOUT1

L-CH

M101 (SPINDLE)

M102

WFCK

R423 100

WFCK

SBSO

R421 100

SBSO

EXCK

R422 100

EXCK

(SLED)

HCD-RG490/RG590

31

31

HCD-RG490/RG590 7-9. PRINTED WIRING BOARDS – CHANGER Section – • Semiconductor Location

1

Ref. No. Location D701 D711

E-7 E-7

IC701 IC712 IC731

F-7 F-8 F-5

Q731

C-9

2

• See page 27 for Circuit Boards Location.

3

4

5

: Uses unleaded solder.

6

7

8

9

10

MOTOR (LD) BOARD

A

M751 (LOADING)

B

DRIVER BOARD

M

CN705

1

CN702

C751

2

CN704

1

2

R733 2

C

1

C737

Q731

12 1-687-133-

R734

C736 C735

(12)

JW710

CN703 R723

SENSOR BOARD

S711 ROTARY ENCODER DISC TABLE ADDRESS DETECT

D

E

R732

CN721

JW711

C741

4

R751 C752

R722 R721

JW712

1

CN741

JW707

R736

JW708

JW709

MOTOR (TB) BOARD

JW706 C715

R713

R701

D711

D701

R702

JW705 1

CN731 3

E

EXCEPT RG490: MX/ RG590: MX

R711

IC701

R712

M741 (TABLE)

E C

IC731

A K

1-687-132-

1

M

IC712 1

C1 MAIN BOARD

JW713

(Page 36)

12

JW704

(12)

JW714 JW703

SW BOARD

F

C2

CN701

MAIN BOARD

JW702

(Page 40)

R731

RG490: MX/ RG590: MX 9 S751 DISC TABLE OPEN/CLOSE DETECT OPEN

G

9

C731

JW701

CN742

1-687-134-

CLOSE

12 1-866-201-

12 (12)

CN751 2 1

H 12 1-687-669-

HCD-RG490/RG590

32

32

(12)

(12)

HCD-RG490/RG590

FIN

GND

RIN

FIN

GND

RIN

VM

VCC VCC

OUT1

VM

RNF

OUT1

DRIVE

RNF

VREF

LOADING MOTOR

OUT2

• See page 62 for IC Block Diagrams.

7-10. SCHEMATIC DIAGRAM – CHANGER Section –

IC701 BA6956AN

CN721 2P

M751

R702 100

CN704 2P

LM-2

LM-2

LM-1

LM-1

C751 0.01

(LOADING)

R701 470

D701 MTZJ-T-77 5.1A

S711 ROTARY ENCODER

CN703 4P E-3

E2

E-2

E1

E-1

VREF

E3

TABLE MOTOR DRIVE

OUT2

DISC TABLE ADDRESS DETECT

IC712 BA6956AN

R721 4.7k

R723 4.7k

R722 4.7k

C737 0.1

0.1

0.1

C735

C736

GND

R712 4.7k

D711 MTZJ-T-77 3.6B

M741 (TABLE)

CN731 3P SENS-IN IC731 RPI-576

SENS-OUT GND

CN742 5P

CN741 3P SENS-IN SENS-OUT

TM-2

TM-1

TM-1

SENS-OUT

GND

GND

C715 100 16V

R713 22k

CN702 5P

TM-2

SENS-IN

R711 1k CN701 13P M+9V

RG490:MX/

M-GND

RG590:MX

LM-R

C741 0.01

LM-F

SENS-IN

TM-R

SENS-OUT

TM-F

GND

EXCEPT

M-GND

R736 390

(Page 37)

E-1 E-2 E-3 TBL ADDRESS SENS D+3.3V R734 12k

DISC TABLE

R732 10k

OPEN SW

R731 100

ADDRESS SENSOR R733 1k

S751 DISC TABLE OPEN/CLOSE DETECT OPEN

CN751 2P OPEN SW GND

Q731 DTC114ESA

CN705 2P

LEVEL

OPEN SW

SHIFT

GND

C731 10 50V C752 0.1

CLOSE

HCD-RG490/RG590

33

33

R751 4.7k

(Page 41) RG490:MX/ RG590:MX

HCD-RG490/RG590

EXCEPT RG490: MX/ RG590: MX

DECK BOARD

MAIN BOARD CN201

D1

MAIN BOARD CN201

D2

6

E

E

E

Q409

Q410

Q406

C401

R301

R305

S

JR311

S

R316

JW310 JW319

3

E

C414

C418 S

R307

8

1

CN302

JR402

C403 R403

R423

R406 R412

R414

R413

R458

R433

R431 G

C355

C354

CN301 1

R303

R456

D

C306

JW308 D

JW309

C301

Q301

G C305

D C302

S

C454

R429

Q403

C462

C452

E

R435

D

L451 BIAS OSC

R461 R462

C456

R465

R463 R464 JR307

6

1

4

3

Q453

G

D

R450

R457

JR302

G JR303

C303

D

R302

R443

K

JW318

R315

Q302

E

G

Q402

A A

E

C415

S

Q303

C356 R437

R430

R309

D

Q404

Q401

C317

C318

JW312 C461

C315

JR306

E

R432

R436 R438 S

Q407

R439

C458

R427

JW315

R444 R308

R449

C413

C411

C431

R428

R446

S

JW311

R311

R304

Q451

R445 R434

G

G

C304

5

1

IC401

C416

Q305

R317 4

C417 8

Q400

R466

C316

R313

JW314

R310

R407

4 R411

C412

D

Q306

C326

8

R312

R314

IC301

C307

R441

C325

C324

C406

R410 R320

C353

C323 1

R424

R453

E

C405 R404 5

R408

JW313

R318

R416 C410

JR310

R323 R319

R324

C433 R402

Q304

C

C328

C327

JR301

C352

R490

JW305

C351

JW303

R485

E

R454

R415

R409

C402

JW320

R326 R325

C404

D301

R401

R351

JW304

R482

JW301

C330

JW306

R488

R405

FB301 C329

R455

JW316

C350

R440

E

JW307

E

R442

R483

R452

C409

JW302

Q452

R451 R349

JW317

B

7

RG490: MX/ RG590: MX

CN008 R481

5

(Page 40)

(Page 36)

A

4

C430

D-2 D-2 D-3 D-3 D-3 D-3 C-4 D-5 D-5 D-5 D-5 B-1 B-1 D-4 B-2 B-3 B-4 C-7 B-7 D-7

3

R350

Q301 Q302 Q303 Q304 Q305 Q306 Q400 Q401 Q402 Q403 Q404 Q405 Q406 Q407 Q408 Q409 Q410 Q451 Q452 Q453

Q408

C-2 C-5

2

R489

IC301 IC401

1

R484

B-3 C-6

: Uses unleaded solder.

D401

Ref. No. Location D301 D401

• See page 27 for Circuit Boards Location.

7-11. PRINTED WIRING BOARD – DECK Board –

Q405

• Semiconductor Location

R460 R459

C453

R306 1-868-914-

E HP1 (PB HEAD) (DECK-A)

HRPE1 REC/PB/ERASE HEAD (DECK-B)

HCD-RG490/RG590

34

34

11 (11)

HCD-RG490/RG590

• See page 57 for Waveforms.

7-12. SCHEMATIC DIAGRAM – DECK Board –

Q405,406,408

Q301 2SJ460 PB SWITCH (DECK-A) S

DECK-A/B SELECT SWITCH, REC/PB SELECT SWITCH

R350 0

8

R489 22k

Q406 2SA1235 Q408 2SA1235

C327 220p

2

C350 220 16V

R484 22k

R323 4.7k

R317 470k

R319 22k

C323 0.0047

C352 0.1

R490 4.7k

R325 100

C329 0.047

R326 100

C330 0.047

C351 220 10V

C328 220p

Q405 2SC3052

C324 0.0047

C326 0.0022

C317 10 50V

R318 470k

(DECK-A)

L-CH

R-CH C302 1000p

R302 47k

PB SWITCH (DECK-A) S

6

R315 100

S

IC301(2/2) R312 NJM14558M-TE2 220 R314 47

R324 4.7k

C301 1000p

Q302 2SJ460

R311 220

C318 10 50V R320 22k

CN301 3P

C305 220k

C325 0.0022 PB AMP

R485 2.2k

(PB) R301 47k

R313 47

R351 1k

R488 22k

R482 47k

HP1

R305 220k

R306 220k

IC301(1/2) NJM14558M-TE2

R483 22k

R481 4.7k

R309 470

1

C353 0.1

R349 100

3

C315 47p

Q303 2SJ460 R303 PB SWITCH 47k (DECK-B)

C303 1000p

R304 47k

C304 1000p

C306 220k

R310 470

7 5

R316 100

4 D301 UDZW-TE17-4.3B

C433 0.01 C401 0.1 50V

EXCEPT RG490:MX/ RG590:MX

R401 47k

R403 22k

3

CN008 11P

Q400,407

1

PB-R

C411 10p

FB301 0

C405 220p C403 47p

REC-R

R413 220k

R409 100k

R431 1k

R445 0

SWITCH

C356 10 50V R429 10k

REC AMP

REC-L

R407 4.7k

C430 0.1

R415 2.2k

Q407 2SA1235

R435 10k

R411 470k

R405 47k

REC/PB SW +9V

C413 220p

IC401(1/2) BA4558

A-GND

R423 47k

C417 0.01

C431 0.1

R433 47k

R440 10k

C415 0.0047

R416 2.2k

O-BIAS

MUTING

R307 4.7k

NC

C404 47p

R406 47k

RG490:MX/

C406 220p

RG590:MX

JR310 0

R402 47k

6

R404 22k

7

C412 10p

C307 0.01

C410 10 50V

R434 47k C418 0.01

R424 47k

R412 470k

R410 100k

R438 0

C416 0.0047

S Q400 2SK2158

S Q402 2SK2158 R432 1k

R428 0

R436 10k

C462 470p

REC SWITCH Q409,410

Q451,452

R466 0 R449 22

REC BIAS SWITCH

R450 22

R464 1k

R456 22

R462 2.2k

R455 10

R442 47k

R453 4.7k

1

R454 4.7k

Q452 2SC3052

Q409 RT1N431C

C453 0.001

Q451 KTA1271Y-AT

R452 47k

OSC

C458 0.0022

R458 4.7

HCD-RG490/RG590

35

R463 1k

R465 0

R459 0

R460 0

4 L451 BIAS

R457 22k

BIAS JR402 0

5

3

C454 0.0047 Q453 2SC2001

R451 10k

R461 2.2k 6

2

Q410 RT1N431C

35

OSC C452 47 16V

R441 0

C461 470p

MUTING

Q404 2SA1235

4

(DECK-B)

ERASE

MUTING R-CH

L-CH D401 MC2838

R414 220k

R446 0

C414 220p

HRPE1 (REC/PB/ERASE) CN302 8P

Q306 2SC3052 R308 4.7k

R430 10k

5

REC CONTROL SWITCH

C355 0.01

R439 4.7k

IC401(2/2) BA4558 C402 0.1 50V

MUTING

R444 100k

R437 0

S

C409 10 50V

DECK-D-GND R408 4.7k

Q305 2SC3052

Q401 2SK2158

REC-MUTE

(Page 42)

C354 0.1

MUTING CONTROL R443 10k

2

PB-L

(Page 38)

REC SWITCH

R427 0

8

S Q304 2SJ460 PB SWITCH (DECK-B)

C316 47p

Q403 2SA1235

C456 0.01

HCD-RG490/RG590 Ver. 1.1 • See page 27 for Circuit Boards Location.

7-13. PRINTED WIRING BOARD – MAIN Board (Except RG490: MX/RG590: MX models) – 1

• Semiconductor Location

2

7

8

9

R382

R365

R325 JW325 JW321

JW203 JW210

C066 C063

C064 C065

R283

JW294 JW112

JW300

JW301

D012

JW297

C012

JW221

JW220

R033

R290

R286 R285 JW276

C265

R263

JW277 R035

R036

JW273

Q277

R287

R271

E

JW274 JW275 A

R037 R034

EP031

A

JR114

K D035 12 1-869-003-

K

(CHASSIS)

RG490: AEP, RU/ RG590: AEP, UK, RU

RG490: AEP, RU, E3, EA, AUS /RG590: AEP, UK, RU, E3, EA

RG490: E2, E51, AR/ RG590: E2, E51, AR

F1

MIC. AUX. HP BOARD CN801

J1

(Page 44) (RG490)

HCD-RG490/RG590

36

R043

R281 R042

JR115

C276

R274

E

R251 C259

R276

Q271 C274

Q261

JW272

C255

R253

R257

Q251

R261

D031

R063

R279 R289 R268

E R267

C264

C273

E R264

C266

R262

E

R272 C278

E

R280

Q272

C271

R277

Q252

R291

R060

JW222

E

36

POWER BOARD CN441

J2

(CHASSIS)

POWER BOARD CN441

(Page 46) (Page 48)

(RG590)

R049 Q043 R050

R038

TRANSFORMER BOARD CN907

(Page 58) K2 TRANSFORMER BOARD CN907

(Page 60) (RG590)

JW223

Q042

JW271

JW270

R254

JW269

R252

C263

IC251

R059

R064

A

R057

Q041

D013

D014

D024 JW302

R250

C254 C256

JW268

JW315 Q011

A

1

R052 C260

R104

R167 R165

E

D009

JW303 JW305 JW267

JW266

JW264

JW256

JW254

JW255

JW310

JW253

R145

JW265

JW252

JW251

R068 R265

JW309

R141

R162 JW249

JW250 JW311

R169

JW298

R155

R164 R156

JW248

JW247

R157

K

C032

R292

R269

D007

11

C026

R039

K1 E R041

JW106

JW288 D023

D021

D022

R160

JW308

JW246

R103

13

C257

R047 R061

JW322

JW214

JW283

JW282

JW226

JW236 R128 JR105

EP061 RG590: E2, E3, E51, EA, AR

RG490: AEP/ RG590: AEP, UK

JW319

JW320

JW102 JW103

JW184

JW185

JW110

JW183

JW182 JW181

JW180

JW179

JW178

JW177

JW176

JW167 JW225

JW235

JW261 JW263

JW299

CN031

R032

R106

R166

R168

C386

C385 JW331

JW196

JW197

C388 C387

JW332

JW192

JW195

JW202

JW187

JW186

JR109

JW339 JW101

JW171

JW105

R319

JW170

JW169

JR110

R322

R321

JW162 JW175

JW174

JW173 JW239

JW224

JW232 C068 JW234

R170 CN061

R016 C010 JW296

E

C258

RG590: E2, E3, E51, EA, AR

R054

R001 JW295

C031

C253

JR122

C167

R143

R147

JW323

JW314 JW206

C116

J

C153

R135

C133 JW245

C141

JW281

JW242 R144

R152

C148 R148

C177

5

Q002

(RG490)

R045

E R053 C035

E

D011

C011

Q045 E

Q044

CN001

C013

E

R153 1

C171

R137

(RG490/RG590: AEP, UK, RU)

C168

JW260

R131

R139

C170

A K

C027

Q276

C169

C173 C165

C164

C143

R120 C157 C160

IC1026 10

A

R006

R005

RG490: AEP, RU, E3, EA, AUS /RG590: AEP, UK, RU, E3, EA

R142

G D

1

C281

C172

R140 RG590: E2, E3, E51, EA, AR

R178

C176

C151

C139

R014

JW286

RG490: E2, E51, AR/ RG590: E2, E51, AR

R046 S

Q046

D036 1

(Page 50)

R048 JW293

R013

JW287

R163

JR121

IC101

R136

C147

R171

11

R161

R138 C178

C155

10

C135 C125 C129

20

C152

C166 C156 C174

1

JR123

C154

R177

R134

R123 C137 R125 R175

C159

C134

JR101 R133

21

40

R158

R056

JW292 R051 R055

Q274 E JW207

JW289

C023

R154

Q114

C142

C163 C175

C123

E

1 C275

JW291

D003

IC021

JW238

JW257

C112

C150

C146

C120 (RG490/RG590: AEP, UK, RU) C114 30 31

C145 C149

RG490: AEP, RU, E3, EA, AUS /RG590: AEP, UK, RU, E3, EA

R132 R159 E

R151

C110

JW262

R121

JW316

JW240

JR102

C109

D001

SUB WOOFER BOARD CN501

C034 CN271

C008

3

JW285

C140 Q113 C130 C144

R122

C138

3

JW241

R130

R172

C121

R101 C122

D004

C025

JW278 JW279

JW307

R126

JW258

JW208

C002

D002

(NC)

JW284

C136

C124

JW243

R105

C001 JW313

R010 R011

CN091

JW237

C126

JR107

C267

R202

R201

RG490: AEP, RU/ RG590: AEP, UK, RU

R176

C115

JR104

JW259

JW231

JW230 JW233

JW228 CN201

(Page 34)

R904 JW172

R999 R997

R996

JW227

RG490: AEP, RU/ RG590: AEP, UK, RU C069

R110

R102

DECK BOARD CN008

I

R113 R111

R109

H1

D006

R124

R941

E

D1

RG490: E2, E51, AR/ RG590: E2, E51, AR

R114

R112

Q111

IC006 IC011

C015

D943 A

Q112 E R108 C117

H

K

A C111

C158

R949 R951

JW341

JW280

JW229

A R943 C119

G

JW218

R950

R942 R946 C118

JW217

JW219

R944

D921

K

A/K C921

JW329

1

JW216

R947 D947

JW330

JW215

JW164

A

D923

A/K

CN991

R355

K

R948 R945

R914

C922

R351

RG490: RU, E2, E51, EA, AR/ RG590: RU, E2, E51, EA, AR

R363 R366

R326

3

R353

R119

R352

JR119 C923

1 C006

JW312

R354

JW244

R349 R350

F

R902

R901

R912

JW152

R116

(RG490/RG590: AEP, UK, RU) RG490: AEP, EA/ /RG590: AEP, UK, EA

JR103

R356

JW151

JW150

JW148

K

3

JW146

JW147

D008

A

A C902

JR111 JR112

E1 BOARD CN601

A

C007

JW290

K D902

JR118

JW324

C901 D901 E Q904

R364

JW158

JW108

K

JW144

JW168

JW143

E

JW159

JW165

R910

2

IC902

D905

JW157

R903

1

JW163

JW161

JW160

E

D910 4 3 C904

Q903

C908

C906

JW145

C927

C913

Q901 C909

JW149

R935

JW141

R905 R909

E C919 R932

JW166

C920

Q902

R982

(Page 54)

R908

C910

R911

JW137

D302

R907

C911

R913

E

C914

JW140

R973

C305 JW156

C926 X901

R936

R922

D

2

RG490: AEP, RU, E3, EA, AUS /RG590: AEP, UK, RU, E3, EA

C916

R918

1

11

1

22

JW189

X902

JW213

R919 R974 80 R972

CN301

D301

JW139

JW190

23

R070

1 3 CN041

C033

JW188

20

R381

1

1

JW212

61

C903

13 C391

JW117

21

C917

60

C918

JW032

JR108

JR106

JW193

JR120

C317 R963

JW118

IC901

R967

R969

JW135

JW134

R965

C912

SUPPLIED WITH THE ASSEMBLED BLOCK

R383

JW122

40

JW133

41

R981

C

R315 R317 R953

JW153

R956

JW132

TUNER(FM/AM)

M

(Page 32)

R316

JW129 R920

R955 JW131

JW119

JW127 R980

C1

(Page 28)

CD BOARD CN102

A

JW306

JW154

R971

M001 (FAN) DRIVER BOARD CN701

R318

R925

JW130

JW121

JW136

JR117

R348

R324 R323

JW126

AM

R344 JW205

R342

R129

Note: IC901 on the MAIN board cannot exchange with single. When IC901 is damaged, exchange the entire mounted board.

10

ANTENNA FM75Ω COAXIAL

R976

R961

JW125

JW155

R979

R923 R924

R957 R959

R921

B

R345

R346 R347 R341 R343 JW124

JW123

R970 R975

JW128

JW340

JW116

C924

C268

G-9 H-9 H-9 H-9 G-9 G-9 G-9 F-9 G-2 G-2 H-4 H-4 J-7 I-7 J-9 I-8 I-9 F-9 I-5 J-9 D-3 D-2 E-3 E-3

JW115

R952

C925

R127

Q002 Q011 Q041 Q042 Q043 Q044 Q045 Q046 Q111 Q112 Q113 Q114 Q251 Q252 Q261 Q271 Q272 Q274 Q276 Q277 Q901 Q902 Q903 Q904

E-7 F-7 G-7 I-3 I-4 I-7 C-2 E-3

6

JW120

RG490: AEP/ RG590: AEP, UK

JW142

IC006 IC011 IC021 IC101 IC102 IC251 IC901 IC902

5

A

RG490: AEP/ RG590: AEP, UK

F-8 F-8 F-8 F-8 G-9 H-9 E-7 H-9 G-7 H-7 G-7 G-7 G-6 G-6 G-6 G-7 J-7 J-8 G-9 D-3 D-4 E-3 E-3 E-3 D-3 F-2 F-2 G-2 F-2

4

MAIN BOARD

Ref. No. Location D001 D002 D003 D004 D006 D007 D008 D009 D011 D012 D013 D014 D021 D022 D023 D024 D031 D035 D036 D301 D302 D901 D902 D905 D910 D921 D923 D943 D947

3

: Uses unleaded solder.

(12)

HCD-RG490/RG590 Ver. 1.1 • See page 57 for Waveforms. • See page 66 for IC Pin Function Description.

7-14. SCHEMATIC DIAGRAM – MAIN Board (1/3) (Except RG490: MX/RG590: MX models) –

(1/3) G-5

T-DI

R980 100 I-MIC-DET

TCM-SYNC

RG590:AEP,UK

C-LR

LM-R

C-LF

LM-F

C-TR

TM-R

C-TF

TM-F

C-E1

E-1

C-E2

E-2

TBL ADDRESS SENS

C-SE

D+3.3V R920 470k

OPEN SW

C-OS

1

R952 47k

VDD(EVER)

(Page 33)

E-3

C-E3

R925 1k

R961 1k

D-GND

RG490:AEP/

C924 100p

-VFL

TCM-SNYC

T-CE

T-CL

T-DO

G-3

G-6

C-3

C-6

C-5

100k(RG490:EA/RG590:EA)

C925 100p

R955 1k

22k(RG490)

VF

RG490:AEP/

10k(RG490:E2,E51,AR/RG590:E2,E51,AR)

R971 100

4.7k(RG590:AEP,UK,RU)

R979 100

2.2k(RG490:RU/RG590:RU)

R921 100

∗R351

2.2k(RG590:E2,E3,E51,EA,AR)

R924 100

VF

C912 0.1

∗R355

CN991 19P

P-DA

1k(RG490:RU/RG590:RU) 10k(RG490:E2,E51,EA,AR/RG590:E2,E51,EA,AR)

R923 100

1k(RG490:AEP/RG590:AEP,UK)

13

M-GND

∗R350

470k(RG490:EA/RG590:EA)

M+9V M-GND

RG590:AEP,UK

∗R352

PM-CL

M-DA

C391 0.1

VDD(SWITCHED) ∗R354

VACS LED-GND

R346 1k

M-GND M-GND C-E1

R347 22k

R345 10k

R922 220k I-PROTECTOR

O-CDG-RST/ I-RDS-CLK

O-LC23003-CE

I-SUFFIX C918 0.001 I-VACS

PROTECT

O-LC23003-DO

I-HP/ AUDIO IN R349 10k

O-VMUTE

R350 ∗

R354 ∗

O-LC23003-CLK

M+9V

I-HP-AUX

R341 10k

I-LC23003-DI

R342 1k

VCE

R352 ∗

I-CDG-DET

R997 100

R351 ∗

R355 ∗ R356 1M

O-CDG-POWER

C-E2

R344 22k

R348 22k

I-XM-RXD

R343 22k

VCL

VFD-CLK VFD-CE

C-E3 VDI

O-CDG-MUTE-DATA/ I-RDS-DATA

VDO

O-XM-TXD

R999 100

VFD-DO

O-CD-DATA

VFD-DI

RG590:RU,E2,E51,EA,AR

I-CD-SENS

VRE

I-MIC-DET

R996 100

RG490:RU,E2,E51,EA,AR/ RG490:AEP,EA/ RG590:AEP,UK,EA

O-CD-CLK

VFD-RESET

(RG490/RG590:AEP,UK,RU)

O-R2S15208SP-DATA

(Page 56)

22k(RG490)

RMS

O-AUDIO-CLK

KEY0

SIRCS

O-R2S15207FP-DATA

KEY0

1k(RG590)

AVSS

STBY

AVREF

STBY-LED

R956 100 R957 100

IXTUNED

I-KEY0

O-TM-F

I-CD-ENCODER

O-TM-R

R353 10k I-MODEL

C-OS C-SE

R975 100

C-TF

R976 100

C-TR

R969 100

C-LF

R967 100

C-LR

O-LM-F

STREAM I-STREAM

O-LM-R SYSTEM CONTROLLER

STBY O-STBY-LED C-12

C-8 O-XRST

IC901 µPD7BF0547GGC (S) -UBT-A

R981 100 O-MP3-CLK R974 100

C-11 CN091 9P

TCM-SYNC

RESET

VRE

VDD

VCE

O-MP3-DATA

I-MP3-REQ

I-TAPE-SYNC

O-XLAT/ O-MP3-STB

R972 100

FLMD

O-VFD-CE

O-MP3-XLAT/ O-MP3-CS

O-VFD-DATA

O-MP3-RESET

C923 220p

VDO VDI

R973 100

VCL

R982 470

C-15 R963 100

C-13 C-9 MP3-RST

FSP O-FRONT-SP-RELAY

XT1(32.768KHZ)

O-SWR

R953 10k

EVDD

VDD

EVSS

VSS

X1(16MHZ)

SYS-M O-SYS-XMUTE

REGC

X2(16MHZ)

O-SWR

FLMDO

XT2(32.768KHZ)

I-XRESET

I-AC-CUT

I-AC -PULSE

SO

O-SW_GAIN

I-XSIRCS -IN

O-REC/PB

220p

O-REC-MUTE

I-WAKEUP C926

O-STK-MUTE

RMS

SI

O-BIAS

SCK

R911 1k

O-XM-POWER3.3

O-POWER-RELAY

O-VFD-CLK KEY0

C-14

C-1

(NC) VSS

R965 100

O-XTCN

I-VFD-DATA VSS

C-10

I-MP3-ACK

O-VFD-RESET AVREF

C-4

O-D-MUTE O-XLT O-MP3-CS/ O-MP3-LP

I-MP3-DATA

FLMD

R959 100 R970 100

I-OPEN-SW I-CD-NUMBER-SENS

R913 1k

KEY0

C-7

I-SCOR

Q903 KTA1271Y-AT

Q901 2SC3052

Q903,904 REGULATOR

RESET SWITCH

R918 220k

D910 1SS355TE-17

A1 A2 A3

Q902 2SC3052

A4

AC DETECT A5

C913 1p C920 1p

FLMD

C914 22p

C927 22p

C910 0.1

C919 0.1

P-RELAY

R932 2.2k

STK-M

C904 0.1

A

JW339

C911 0.001

O-BIAS

R935 10k

IC902 PST3429UL

REC-MUTE

GENERATOR

A6

C901 100 16V

C916 47000 5.5V

R902 0 D901 UDZW-TE17-4.7B

D923 MC2840

R948 2.2k

R944 220k

R901 100k D902 MC2836

R914 10k C917 0.1

R950 4.7k

D943 MC2838

R904 2.2k

X902 16MHz

RESET SIGNAL

O-R/P

(Page 39)

C902 10 50V

R949 10k

R912 1k

C903 0.47 50V

R936 22k

D921 MC2840

R946 0 B3

R951 220

R947 220k C922 4.7 50V

B4 R945 220

VACS

D905 1SS355TE-17

X901 32.768KHz

C909 0.1

R919 0

Q904 2SC3052 R908 47k

D947 1SS355TE-17

R903 10k

C906 10 50V

R909 22k

STREAM

R905 10k

C908 0.1

PROTECT

R907 47k

C921 2.2 50V

R942 10k

R941 2.2k

(Page 38)

R943 4.7k

A7

B1

A8 R910 10k B2

(Page 39)

(Page 38)

Note: IC901 on the MAIN board cannot exchange with single. When IC901 is damaged, exchange the entire mounted board.

HCD-RG490/RG590

37

37

HCD-RG490/RG590 Ver. 1.1

7-15. SCHEMATIC DIAGRAM – MAIN Board (2/3) (Except RG490: MX/RG590: MX models) –

• See page 62 for IC Block Diagrams.

(2/3)

RG490:AEP,RU/

RG490:AEP,RU/

RG590:AEP,UK,RU

RG590:AEP,UK,RU

R172 0

R176 2.2k

C136 220p

(Page 39)

R136 10k

C130 1 50V

C152 0.022

C150 0.022

C4

C176 1

C144 0.047 (RG490/RG590:AEP,UK,RU)

C154 1 50V

CN201 11P

RG490:AEP,RU/

GND

O-R/P

R133 0

REC-L C115 100 16V

A-GND

JR101 0

JR102 0

C109

4700p

10 50V

MIX2

OUTL

VCC

BB22

C110 10 50V

470k(RG490:AEP,RU,E3,EA,AUS/RG590:AEP,UK,RU,E3,EA)

C123 47p

RG590:AEP,UK,RU

D-GND AUX-IN-Rch

R131 100

C139 0.1

C151 0.022

C149 0.022

R127 ∗

I-HP-AUX R168 R166 R104 1k 4.7k 10k

R-OUT

C153 1 50V

R141 22k

R139 1k

R161 22k

R163 47k

R162 22k C175 1

C163 1

R156 220k

R164 47k

R155 220k Q114 2SC3052

Q113 2SC3052 R157 220k

R137 2.2k

R102 1k

R108 2.2k

R159 47k

R109 4.7k

R160 47k

R167 R165 R103 1k 4.7k 10k

R147 C147 47k 470p

RG490:AEP,RU/

RG490:AEP,RU/

RG590:AEP,UK,RU

RG590:AEP,UK,RU

C135 220p

R135 10k

C117 0.001

C069 1000p

R116 100

(Page 37) C119 2.2 50V

R111 100k

C112 47 16V

B3

R154 1M

B4 Q112 2SC3052 Q111 2SC3052

Q113,114 C134 0.1

C111 22 50V

R113 4.7k

ELECTRICAL VOLUME

R145 47k

Q111,112 BAND- FILTER

TONE CONTROL,

C141 10 50V

R148 C148 47k 470p

AUX-IN-Lch

(Page 45)

∗

INPUT SELECTOR,

A-GND

HP-GND

C155

R177 0

E51,EA,AR

C145 4700p

R129 ∗

C143 0.047

R171 0

D-GND O-HP/AUX

PM-CL

R158 220k

C116 1 50V

R106 1k

∗

RG590:E2,E3,

C129 1 50V

C137 1 50V

MIC SIG

0.15(RG490)

(RG490/RG590:AEP,UK,RU)

I-MIC-DET R068 10

∗C155-158 0.18(RG590)

13P(RG490:E2,E51,AR/RG590:E2,E51,AR)

MIC +9V

C157

C173 47p

VOLINL

TONE OUTL

MID22

MID12

TRE2

BASS22

47k(RG490:E2,E51,AR/RG590:E2,E51,AR)

R175 2.2k

BASS12

∗R129,130

M-DA

R143 220

BB12

SAOUT

R105 100

CDL

R144 220

R119 470

C159 220p

RG490:AEP,RU/

O-MIC-DET

R120 470

C160 220p CLK

(RG490:E2,E51,AR/RG590:E2,E51,AR) CN061

R140 R178 0 1k

DATA

MIX1

C125 1 50V R125 4.7k

C281 0.01

C158 ∗

TAPEL

9P(RG490:AEP,RU,E3,EA,AUS/RG590:AEP,UK,RU,E3,EA)

P-DA

OUTR IC101 R2S15207FP

C114 0.1 R121 100

R142 22k

C174 47p

C267 4700p C268

R152 100

R153 100

C177 1

BB11

SURROUNDR

RECOUTL

R201 2.2k

R134 0

C165 1

VOLINR

C122 0.047 R101 10k

AUXL

PB-L

R202 2.2k

R151 100

BB21

TUNERL

PB-R

C169 0.01

C156 ∗

SURROUNDL

(Page 35)

CLK

(/RG590:E2,E3,E51,EA,AR)

C121 100 16V REFIN

REC-R

PM-CL

DATA

TONE OUTR

MID21

MID11

TRE1

BASS21

BASS11

TAPER C120 0.1

R123 2.2k

AUXR

R122 100

O-BIAS

RECOUTR

CDR

C124 47p

DECK-D-GND

REC/PB SW

C171 100p

GND

C166 1

RG590:AEP,UK,RU

RG590:AEP,UK,RU,E3,EA)

TUNERR

RG490:AEP,RU,E3,EA,AUS/

REC-MUTE

C170 100 16V

VCC

RG590:E2,E51,AR

NC

+9V

C164 1

C178 1

RG490:E2,E51,AR/

REC-MUTE

C172 100p

ROUT

1k(RG490:E2,E51,AR/RG590:E2,E51,AR)

O-BIAS

REF OUT

RIN

2.2k(RG490:AEP,RU,E3,EA,AUS/RG590:AEP,UK,RU,E3,EA)

(Page 37)

REF IN LIN

LOUT

B2 R070 10k

(Page 39)

IC102 R2S15208SP

C167 100 10V

∗R127,128 B1

D3

PARAMETRIC EQUALIZER

C140 0.1

C3

R128 ∗

D2 C168 100 10V

R138 2.2k

C146 4700p

R132 C126 100 1 50V

R130 ∗

C142 10 50V

R126 R124 4.7k 2.2k

C2

C138 1 50V

C1

D1

C133 0.1

BASS AGC

R110 47k

R114 2.2k

C118 2.2 50V

(Page 39)

R112 470 D4

C068 1000p

C066 1000p D5 C065 1000p

HP-GND

RG490:AEP,RU,E3,EA,AUS /RG590:AEP,UK,RU,E3,EA

L-OUT EP061

C063 0.1

C064 0.001

D7 D8 D9

(CHASSIS)

D10

(Page 39)

HCD-RG490/RG590

38

38

HCD-RG490/RG590 Ver. 1.1

7-16. SCHEMATIC DIAGRAM – MAIN Board (3/3) (Except RG490: MX/RG590: MX models) –

(3/3)

R265 100

Q261 RT1P141C-TP-1 C259 10 50V

∗R250,253 4.7k(RG490) C263 470 16V

10k(RG590) A1 ∗R254,257 A2 R292 2.2k

A3

R263 2.2k

C264 1000p

R261 10k

BUFFER

2.7k(RG490)

Q251 2SC3052

IC251 BA4558F-E2

4.7k(RG590)

MUTING

A4

C256 22p

A5

(Page 37)

R251 470

R253 ∗

A6

C255 22p R291 R257 2.2k ∗

D2

R274 4.7k Q276 2SC3052

R276 10k

BUFFER

Q271 2SC3052 BUFFER

C271 0.047

R286 22k

SW-SIG

C273 0.22 C266 4.7 50V

R277 2.2k

Q277 2SC3052 C276 0.22

C274 10 25V

R279 2.2k

R280 4.7k

SW-SIG GND SW-ON/OFF

Q272 2SC3052

R287 470k

MUTING R272 4.7k

C278 0.1

MUTING

LINE AMP

(Page 51)

CN271 3P

C275 470p

R281 2.2k

R250 R254 C258 ∗ ∗ 47 16V

C253 47p

R285 10k

MUTING CONTROL SWITCH R268 4.7k

R267 47k

Q252 2SC3052

C254 47p

C265 4.7 50V

C260 10 R252 25V 470

D1

R262 10k R264 2.2k

R052 470k

R271 0

R269 2.2k

R289 100k

R290 1k

SYS-M

C257 47 16V D3

(Page 38)

Q274 RT1N431C-TP-1 SUB WOOFER SWITCH O-SWR

R283 10k FSP

Q043-045

R056 10k

FAN MOTOR DRIVE STBY R D002 10EDB40

R006 4.7k

P-RELAY

D004 10EDB40

Q002 2SC3052

Q042 KTA1271Y-AT

R042 10k

R043 4.7k

D001 10EDB40

+9V REGULATOR IC011 TA7809S D011 10EDB40

+3.3V REGULATOR R010 22k

IC006 TA78033LS

O G I

C015 100 16V

R011 10k

O

D007 UDZW-TE17-4.7B

PROTECT DETECT

(Page 38)

R016 100k

G

Q045 2SC3052

R050 2.2k

I

R055 2.2k

C007 22 50V

C006 10 50V

R001 22

+9V REGULATOR

R047 2.2

R046 4.7

R048 22

R061 10

C033 100 16V

R051 2.2k

Q046 2SK2158

R049 220k

FAN MOTOR DETECT

C013 2200 25V

S

C034 4.7 50V

EP031

(CHASSIS)

D022 10EDB40 C023 2200 25V

O G I

C025 100 16V

(FAN) FAN+

D021 10EDB40

IC021 TA7809S

R014 C010 10k 0.1

M001

FAN-

R045 1k

Q041 2SC3052

D014 10EDB40

CN041 3P FAN+

R053 22k

R054 22k

D013 10EDB40

R013 22k

D5

C035 47 25

D035 MC2838

D008 MC2838

Q011 RT1N141C-TP-1

Q041,042 B+ SWITCH

R057 1k

D012 10EDB40

D006 1SS355TE-17 PROTECT

C001 0.1 C011 0.1

C012 0.1

D009 MC2838

R041 0

Q044 2SC3052

D036 MC2836

D003 10EDB40

C008 2200 25V

RELAY DRIVE

R039 22 1/2W

Q043 KTA1266GR

POWER ON/OFF

R005 4.7k

R038

C002 0.1

R036 4.7k

D023 10EDB40

R035 4.7k

SP L-OUT (RG490)

D024 10EDB40

SP-GND

R033 22k

SP R-OUT

T-DI

D

A

B

R034 22k

SP RELAY B+ PROTECT

PROTECT

(Page 47)

R-OUT

T-CE

T-CL

G-6

G-5

D302 10EDB40

T-DO

C-7

C-6

C-15

C-13

C-10

C-5

C-9

C-11

C-8

C-14

C-1

C-4

C-3

(Page 37)

A7

C-12

C

D4

R059 1k 2W

R060 1k 2W

AMP-A-GND L-OUT

A8

/RG590:AEP,UK,RU,E3, EA

-VFL GND (RG590)

R064 100

CN031 13P

100p

100p

100p

C388

C385

R366 0

R326 22k

R037 4.7k

R363 0

R365 0

R325 22k

D031 R032 1k 1SS355TE-17 D10

D8

C1

C4

C3

D9

1

C2

TUNER-L

+9V

TUNER-R

GND

N/C

PLL CE

PLL DI

PLL CLK

11

RDS CLK

RG590:AEP,UK

RDS DATA

RG490:AEP/

PLL DO

M+7V

M-GND

SCOR

SENS

XLAT

REQ-MP3

R364 0

D7

ACK-MP3

XLAT-MP3

DATA-MP3

CLK

IREQ-MP3

XRST

XTACN

AVDD(3.3V)

R CH

A-GND

D-OUT

L-CH

D-GND

CN301 23P

DVDD(3.3V)

(RG590)

D-MUTE

A

-VFL

CLK-MP3

A

DATA

(Page 61)

STBY R

470p

C317 1000 10V

EVER +10V

C386

D-GND

C387

R324 100

VF

R323 100

VF

TUNER (FM/AM)

(Page 29)

(Page 49)

STK MUTE

R063 100

R321 100

D

PWR-GND

C032 1000p C031 0

RG490:AEP,RU,E3,EA,AUS

R322 100

AC4

STK-M JW032

C305 1000p

R318 100

C

R319 100

AC4

R317 100

B

R383 1k

D301 10EDB40

/RG590:AEP,UK,RU,E3, EA A

AC3

STBY RELAY

R382 1k

RG490:AEP,RU,E3,EA,AUS C027 0.01

R315 100

(Page 59)

AC3

R316 100

CN001 11P (RG490)

R381 1k

UNREG +16V

C026 0.01

SUPPLIED WITH

(Page 38)

THE ASSEMBLED BLOCK

FM75Ω AM

COAXIAL ANTENNA

HCD-RG490/RG590

39

39

(Page 38)

HCD-RG490/RG590 • See page 27 for Circuit Boards Location.

7-17. PRINTED WIRING BOARD – MAIN Board (RG490: MX/RG590: MX models) – 1

• Semiconductor Location

6

7

8

9

R340

R339

R316

JW193

JW197

JW331

JW196

JW332

R325

JW195

JW202 JW319

JW325

JW320

JW321

D008

JW214

JW203

C147 R147

C064

R006

JW294 JW112

JW300 D031 R033

R060

R290

JW273

R274

Q041

C276

C265

E Q277

R287

JW277 R271

E

Q261

R286 R285 JW276

Q251 E

R281 R042

R280

C278

R272

C273

JW271

JW270

R279 R289 R268

R276

C274

C266

R263

JW274

R032

R037

JW275

R034

A

A

JR114 EP031

K D035

11 1-868-901-

K

F2

(CHASSIS)

MIC. AUX. HP BOARD CN801

J3

(Page 44) (RG490)

HCD-RG490/RG590

40

40

R043

D012 JW297

JW298 R064

R103

JW269 R251

R059 JW268

R167 R165

C259

E Q271

R267

JW264

JW256

R254

R291

E

R264

Q252

IC251 C264

R269

R104

JW301

D013

D014

JW303 JW305

JW255

JW254

JW310

JW253

JW267

C257

E

R036

R166

R252

C254 C256 C263

POWER BOARD CN441

(Page 46)

J4

(CHASSIS)

POWER BOARD CN441

(Page 48)

(RG590)

R045

JW106 JW302

D024

D023

D021

D022

R068 R265

JW309

R141

JW252 R142

JW251 C169

R118

R292

R145

(RG590)

C260

R047 R061

JW322

JW290

JW283

JW282

D006

R050

JW210

JW103 JW184

JW185

JW110

JW183

JW182 JW181

R160 R155

R156 JW249

JW248 JW247

JW250

C171

JW220

Q272

JR115

K3

E

R039

R041

TRANSFORMER BOARD CN907

(Page 58) K4 TRANSFORMER BOARD CN907

(Page 60) (RG590)

JW223 JW222

R277 C271

(RG490)

Q043

JW213 JW108

JW212

JW324

JW105

JW102

JW339 JW101

JR109

JR110

R315

R318

R321

JW170

JW171

JW179

JW167 JW225

JW239

JW224

JW226

R153

R063 C063

C388 C387 C386

C385

JW032

R323

JR108 R317

JW169

JW335 JW174

JW173

JW172 JW236

IC102 R168

CN061

R106

JW263

EP061

JW192

JW191 JW186

JW187

JW188

R324

JW163

JW165

JW161 JW235

5

R250

R035

JW281

JW314

1

A A R057

JW221

1

R052

C258

R152

R143

JW261

JW206

JW323

(RG590)

C167

C026

CN031

JW272 R261 R262

C153

R135

R139

JW315 Q011

E

C255 R253

C116 R144

C160 JR121 C157

C170

D007 E K D009

E

E R053

R038 JW296

11

13

JW266

C165 C177

6

R054

C010

JW299

C031

C253 R257

JR122

10

R117

R131 (RG490)

C035 E

C027

Q045

Q044

R005

E

E

JW265

C141

R048 A A D036

Q042

Q276

R148

C129

C172

C168

R120

C148

JW242

R140 R178 C155

R163

JW260

R129

C143

C174

C012

R046

D

JW295 R016

C281

R162

JW311

C139

JW245

R127

C125 R171

11

R137 JW244

C145 C149 C151

10

C159

20

C158

(RG590) C166 21 C156

JR123 1

R134

R133 R123 R125 C137 R175

R138 C178

30

31

R157

IC101

C152

C154

C176

C114 40

C173

JW262

R121

(RG490)

R055 JW207

CN001

C013

C011 JW287

R164

C146

C120

C109

C150

R158 R161

Q046

K

D011

R154

Q114

JR105 C144

R058 JW292 S G

1

R014

JW286

C164

R122 JW240

1

C023

JW257

E

Q113

C142

R101 C122

C110

E

C140

R174

C121

JW293

R013

R049

R056

R051

E

JW289

3

JW238

Q274

JW291

D003

1

C275

R011

IC021

JW285 C112

R132 R159

JW307

JR104

JW259

JR107

JW243

R202

C267

C268

JW237 C130

D002 C008

(Page 50)

CN271

R283

D001

SUB WOOFER BOARD CN501

C034 3

D004

R010

JW278

JW284

JW308

R201

R126

C002

R001 Q002

R130

R105 C126

C138

J

D301 JW162

R176

JW208

C001 JW313

JW241

R136

C115

JW228 CN201

JW258

(NC)

JW216 JW233

R110

R102

C015

1

R128

C069

JW329

H2

IC006 IC011

JW279

C175

R109

R114

JW234 C068

JW229

E

R124

E

R113 R111

Q111

JW227

Q112

K

C025

CN091

JW232

A

R116

G

JW341

JW288

K

JW330

1 C006

D943

A C111

R364

R363 R366

JW215

R151

R951

JW231

R949

R943 R946 R941 C119 C118

A

JW280

JW230

JW219

R944

D921

A

R942

R108

Q903

JW217

JW246

R947

D947 A/K R950 C921

R365

R326

3

JW164

A

D923 K

R914

CN991

C922

C033

3

JW152

JR103 R353

R119 R177 C163

K

R945

JR119

JW218

F

C007

A

JW312

R356

R349 R352

JW151

JW150

JW148

R996 R999 R997

JW146

JW147 (RG490)

C923 JW334

C902

E2

I

R903 R912

9

3 CN041

JR118

R336

Q904

JR117

JW145

R953

JW180

JR112

E

R910

JW178

D902 R901 A

E

JW177

K

1 1

JW166 D303

R320

JW176

K

R381

JW159

C333

R322

JW175

JW144

JW160

IC902

C906

JW143

H

R333 R338

R967 JW136

C920 C913 C927

C914

C909 E D910 R907 4 3 C904 C901 D905 1 2

C908

D901

R935

Q901

JW142

E

1

CN302

R904 R902 JW168

E R932

R982 JW141

R905 R909

C910 C919

Q902

SUPPLIED WITH THE ASSEMBLED BLOCK

JW158

JW333

R908

C911

R911

(Page 34)

JW156

X902

JW149

R972 R973

DECK BOARD CN008

JW154

C916

X901

C926

R913

C117

13 C391

1

JW140

TUNER(FM/AM)

M

JW155

C903

R918 80

R936

R922

A/K

JW153

JW189

R974

D

BOARD CN601

R319

JW157

C918

C2

(Page 32)

R382

20 R919

JW139

DRIVER BOARD CN701

JW190

C917

21

(Page 30)

R383

C317

61

R070

R963

JW138

JR106 60

D2

R969

C912

IC901

(Page 54)

R965

40

JW135

R920

JW134

41

R981

C

R956 JW133

R925

JW132

BD BOARD CN201

B

JW129

R955

R968

R980

R334 JR111

JW120 R372 R337

R332

M001 (FAN)

R335

JW130 JW131

AM

CN331

JW128

R977

R971

JW127

(Page 52)

C336

JW137

R348

CD-G BOARD CN1001

G

FM75Ω COAXIAL

R330

D302

JW125 JW126

R948

Note: IC901 on the MAIN board cannot exchange with single. When IC901 is damaged, exchange the entire mounted board.

10

ANTENNA

JR113

R970 R975 R976

R342

R329

JW124

R957 R959

R347

R979

R924

R346

R341

JW123

R331

JW122

R345

R343

R921 R923

B

JW121

JW119

JW118

JW117

JW116

JW115

JW340 R344

JW336 JW337

JW316

G-9 H-9 H-9 H-8 G-9 G-9 G-9 F-9 G-2 G-2 H-3 H-4 I-7 I-7 J-9 I-8 I-8 F-9 I-5 J-9 D-3 D-2 E-3 E-3

JR116

R952

R355

Q002 Q011 Q041 Q042 Q043 Q044 Q045 Q046 Q111 Q112 Q113 Q114 Q251 Q252 Q261 Q271 Q272 Q274 Q276 Q277 Q901 Q902 Q903 Q904

JW107 JW109

R354

E-6 F-6 G-6 I-3 I-4 I-6 C-2 E-3

5

JW104

R112

IC006 IC011 IC021 IC101 IC102 IC251 IC901 IC902

4

A

JW338

F-8 F-8 F-8 F-8 G-9 H-9 E-6 H-8 G-7 H-7 G-7 G-7 G-6 G-6 G-6 G-6 J-6 J-7 G-9 C-3 C-3 D-4 E-3 E-2 E-3 D-3 F-1 F-2 G-2 F-2

3

MAIN BOARD

Ref. No. Location D001 D002 D003 D004 D006 D007 D008 D009 D011 D012 D013 D014 D021 D022 D023 D024 D031 D035 D036 D301 D302 D303 D901 D902 D905 D910 D921 D923 D943 D947

2

: Uses unleaded solder.

(11)

HCD-RG490/RG590 7-18. SCHEMATIC DIAGRAM – MAIN Board (1/3) (RG490: MX/RG590: MX models) –

• See page 57 for Waveforms. • See page 66 for IC Pin Function Description.

(1/3) G-5

T-DI

T-CE

T-CL

G-1

R971 100

R925 100

R980 100

D-GND TCM-SYNC

I-MIC-DET

LM-R

C-LF

LM-F

C-TR

TM-R

C-TF

TM-F

C-E1

E-1

C-E2

E-2

C-E3

E-3

C-SE

TBL ADDRESS SENS

13

(Page 33)

D+3.3V C-OS

OPEN SW 1

R920 470k

R952 47k

VDD(EVER)

C-LR

R955 1k

-VFL

R968 100

R977 100

R961 100

VF

TCM-SNYC

T-DO

G-3

G-2

G-6

C-6

C-3

C-5

P-DA R921 100

R979 100

R924 100

VF

M+9V M-GND M-GND

R923 100

C912 0.1

CN991 19P

PM-CL

M-DA

C391 0.1

VDD(SWITCHED) STBY-LED

STBY

KEY0

KEY0

∗R355

22k(RG490)

R346 1k

M-GND M-GND C-E1

R347 22k

R345 10k

C918 0.001 I-VACS

PROTECT

R922 220k I-PROTECTOR

KEY0

O-CDG-RST/ I-RDS-CLK

O-LC23003-CE

O-VMUTE

I-CDG-DET

O-LC23003-DO

I-SUFFIX

O-LC23003-CLK

VACS LED-GND

I-HP/ AUDIO IN R349 10k

I-XM-RXD

I-HP-AUX

R341 10k

I-LC23003-DI

R344 22k

O-CDG-POWER

C-E2

O-CDG-MUTE-DATA/ I-RDS-DATA

VCE

R352 10k R354 ∗

O-XM-TXD

R342 1k

O-CD-DATA

R997 100

M+9V

R355 ∗

R356 1M

I-CD-SENS

VCL

(RG490)

R348 22k

O-CD-CLK

VFD-CLK

R343 22k

I-MIC-DET

C-E3 VDI

O-R2S15208SP-DATA

VDO

VFD-DO

O-AUDIO-CLK

R999 100

O-R2S15207FP-DATA

VRE

VFD-DI

AVSS

R996 100

AVREF

VFD-RESET

VFD-CE

1k(RG590)

22k(RG490) RMS

SIRCS

(Page 56)

∗R354

2.2k(RG590)

R956 100 R957 100

IXTUNED

R959 100

C-OS

R970 100

C-SE

I-OPEN-SW I-CD-NUMBER-SENS

R913 1k I-KEY0

O-TM-F

I-CD-ENCODER

O-TM-R

I-MODEL

O-LM-F

I-STREAM

O-LM-R

R353 10k STREAM

R975 100

C-TF

R976 100

C-TR

R969 100

C-LF

R967 100

C-LR

SYSTEM CONTROLLER

STBY O-STBY-LED C-12

C-8 O-XRST

IC901 mPD7BF0547GC (S) -UBT-A

R981 100 O-MP3-CLK R974 100

C-11 CN091 9P

TCM-SYNC

RESET

VRE

VDD

VCE

AVREF

VDO

O-MP3-DATA

I-MP3-REQ

I-TAPE-SYNC

O-XLAT/ O-MP3-STB

R972 100

FLMD

O-VFD-CE

O-MP3-XLAT/ O-MP3-CS

O-VFD-DATA

O-MP3-RESET

C923 220p

VDI

R973 100

VCL

R982 470

C-15 R963 100

C-13 C-9 MP3-RST

FSP O-FRONT-SP-RELAY

XT1(32.768KHZ)

O-SWR SYS-M R953 10k

EVDD

VDD

VSS

EVSS

O-SYS-XMUTE

REGC

X1(16MHZ)

X2(16MHZ)

O-SWR

FLMDO

XT2(32.768KHZ)

I-XRESET

I-AC-CUT

O-XM-POWER3.3

O-POWER-RELAY

O-SW_GAIN

I-AC -PULSE

SO

O-BIAS

I-XSIRCS -IN

O-REC-MUTE

220p

O-REC/PB

C926

RMS

SI

O-STK-MUTE

R911 1k I-WAKEUP

SCK

C-14

C-1 O-VFD-CLK

KEY0

R965 100

O-XTCN

I-VFD-DATA (NC) VSS

C-10

I-MP3-ACK

O-VFD-RESET

VSS

C-4

O-D-MUTE O-XLT O-MP3-CS/ O-MP3-LP

I-MP3-DATA

FLMD

C-7

I-SCOR

Q903 KTA1271Y-AT

Q901 2SC3052

Q903,904 REGULATOR

RESET SWITCH

R918 220k

D910 1SS355TE-17

A1 A2 A3

Q902 2SC3052

A4

AC DETECT A5

C913 1p C920 1p

FLMD

C927 22p

C910 0.1

C914 22p

C919 0.1

P-RELAY

R932 2.2k

STK-M

C904 0.1

A

JW339

C911 0.001

O-BIAS

R935 10k

IC902 PST3429UL

REC-MUTE

GENERATOR

A6

C901 100 16V

C916 47000 5.5V

R902 0 D901 UDZW-TE17-4.7B

D923 MC2840

R948 2.2k

R944 220k

R901 100k D902 MC2836

R914 10k C917 0.1

R950 4.7k

D943 MC2838

R904 2.2k

X902 16MHz

RESET SIGNAL

O-R/P

(Page 43)

C902 10 50V

R949 10k

R912 1k

C903 0.47 50V

R936 22k

D921 MC2840

R946 0 B3

R951 220

R947 220k C922 4.7 50V

B4 R945 220

VACS

D905 1SS355TE-17

X901 32.768KHz

C909 0.1

R919 0

Q904 2SC3052 R908 47k

D947 1SS355TE-17

R903 10k

C906 10 50V

R909 22k

STREAM

R905 10k

C908 0.1

PROTECT

R907 47k

C921 2.2 50V

R942 10k

R941 2.2k

(Page 42)

R943 4.7k

A7

B1

A8 R910 10k B2

(Page 43)

(Page 42)

Note: IC901 on the MAIN board cannot exchange with single. When IC901 is damaged, exchange the entire mounted board.

HCD-RG490/RG590

41

41

HCD-RG490/RG590

• See page 62 for IC Block Diagrams.

7-19. SCHEMATIC DIAGRAM – MAIN Board (2/3) (RG490: MX/RG590: MX models) –

(2/3) D1

R172 0

R176 2.2k

D2

(Page 43)

R136 10k

C4

C152 0.022

C3

R128 1k

C176 1

B1 B2

(RG490)

C164 1

GND

PM-CL

CLK C169 0.01

+9V

C165 1

O-R/P

R133 0

A-GND

C158 ∗

C122 0.047 SURROUNDR IC101 R2S15207FP

10 50V

C160 220p CLK

MIX2

OUTL

VCC

BB22

C110 10 50V

C157

∗

C155

∗

R177 0

C173 47p

VOLINL

TONE OUTL

MID22

MID12

TRE2

R125 4.7k

PM-CL

BB12

BASS22

CDL

BASS12

C125 1 50V

SAOUT

R105 100

TAPEL R121 100

RECOUTL

C114 0.1

4700p

M-DA

R143 220 R119 470

C159 220p

C267 4700p C268

R144 220 DATA

MIX1

AUXL

R201 2.2k

R120 470

OUTR

R101 10k C109

R140 R178 1k 0

C156 ∗

TUNERL

R202 2.2k

R134 0

C281 0.01

BB21

SURROUNDL C115 100 16V

R142 22k

C174 47p BB11

C121 100 16V

REC-L REC-R

P-DA

R153 100

C177 1

VOLINR

REFIN REC/PB SW

R152 100

(RG590)

TONE OUTR

MID21

MID11

TRE1

BASS21

AUXR

GND

BASS11

TAPER

RECOUTR

CDR

R122 100 C120 0.1

R123 2.2k

TUNERR

O-BIAS REC-MUTE

R151 100

ELECTRICAL VOLUME

DECK-D-GND

REC-MUTE

C171 100p

DATA C178 1

C166 1

O-BIAS

C170 100 16V

VCC

TONE CONTROL,

CN201 11P

PB-L

C172 100p

ROUT C154 1 50V

PB-R

REF OUT

RIN

NC

(Page 35)

REF IN LIN

C144 0.047

INPUT SELECTOR,

(Page 41)

(Page 43)

IC102 R2S15208SP

C167 100 10V

LOUT

C130 1 50V

R070 10k

D3

PARAMETRIC EQUALIZER

C140 0.1

C150 0.022

R132 C126 100 1 50V

R138 2.2k

C146 4700p

R130 47k

C142 10 50V

R126 R124 4.7k 2.2k

C2

C138 1 50V

C1

C168 100 10V

∗C155-158 0.15(RG490)

C153 1 50V

0.18(RG590)

R175 2.2k

R141 22k

R139 1k

R161 22k

R163 47k

R162 22k C175 1

R164 47k

(RG490) C163 1

R156 220k

R155 220k R158 220k

D-GND O-HP/AUX D-GND AUX-IN-Rch

I-HP-AUX R168 R166 R104 1k 4.7k 10k

R131 100

C139 0.1

R148 C148 47k 470p

C141 10 50V R137 2.2k

R102 1k

R108 2.2k

R109 4.7k

R159 47k

R160 47k C112 47 16V

(Page 45)

HP-GND R-OUT

C068 1000p R167 R165 R103 1k 4.7k 10k

R135 10k

R147 C147 47k 470p

C069 1000p

(Page 41) C119 2.2 50V

R111 100k

B3 B4 Q112 2SC3052

Q111 2SC3052 C117 0.001

R116 100

R154 1M

A-GND AUX-IN-Lch

C111 22 50V

R113 4.7k

Q113,114 BASS AGC

R145 47k

BAND- FILTER

R157 220k

C151 0.022

R106 1k

C149 0.022

MIC SIG

R127 1k

C145 4700p

R068 10

Q111,112

Q114 2SC3052

Q113 2SC3052

C143 0.047

I-MIC-DET

MIC +9V

R129 47k

C116 1 50V

O-MIC-DET

R171 0

(RG590)

C129 1 50V

C137 1 50V

CN061 11P

R110 47k

R114 2.2k

C118 2.2 50V

(Page 43)

R112 470 D4 D5

HP-GND L-OUT EP061

C063 0.1

C064 0.001

D7 D8 D9

(CHASSIS)

D10

(Page 43)

HCD-RG490/RG590

42

42

HCD-RG490/RG590

7-20. SCHEMATIC DIAGRAM – MAIN Board (3/3) (RG490: MX/RG590: MX models) –

(3/3)

Q261 RT1P141C-TP-1

R265 100 C259 10 50V

∗R250,253 4.7k(RG490) 10k(RG590)

C263 470 16V

A1 ∗R254,257 R292 2.2k

R261 10k

2.7k(RG490)

Q251 2SC3052

IC251 BA4558F-E2

4.7k(RG590)

MUTING

A4

C256 22p

A5

(Page 41)

R263 2.2k

BUFFER

A2 A3

C264 1000p

R251 470

R253 ∗

A6

R291 R257 2.2k ∗

D2

R274 4.7k Q276 2SC3052

R276 10k

R286 22k

BUFFER

Q271 2SC3052 BUFFER

C271 0.047

SW-SIG

C273 0.22 C266 4.7 50V

R277 2.2k

R287 470k

C276 0.22

C274 10 25V

R279 2.2k

R280 4.7k

SW-SIG GND SW-ON/OFF

Q272 2SC3052 Q277 2SC3052

MUTING C278 0.1

R272 4.7k

MUTING

LINE AMP

(Page 51)

CN271 3P

C275 470p

R281 2.2k

R250 R254 C258 ∗ ∗ 47 16V

C253 47p

R268 4.7k

R267 47k

Q252 2SC3052

C254 47p C255 22p

R285 10k

MUTING CONTROL SWITCH

C265 4.7 50V

R262 C260 10k 10 R252 25V 470

D1

R264 2.2k

R052 470k

R271 0

R269 2.2k

R289 100k

R290 1k

SYS-M

C257 47 16V D3

(Page 42)

Q274 RT1N431C-TP-1 SUB WOOFER SWITCH O-SWR

R283 10k FSP

Q043-045

R056 10k

FAN MOTOR DRIVE STBY RELAY D002 10EDB40

R006 4.7k

P-RELAY

D004 10EDB40

Q002 2SC3052

RELAY DRIVE

Q042 KTA1271Y-AT

R042 10k

R043 4.7k

D001 10EDB40

Q041,042

+9V REGULATOR C001 0.1 C011 0.1

IC011 TA7809S +3.3V REGULATOR

D011 10EDB40

D009 MC2838

IC006 TA78033LS

R010 22k

R011 10k

C015 100 16V

G

O PROTECT

PROTECT

D007 UDZW-TE17-4.7B

DETECT

D013 10EDB40 D014 10EDB40

I

C006 10 50V

C007 22 50V

+9V REGULATOR

R001 22

O

(Page 42)

C010 0.1

D5

C025 100 16V

R014 10k

G

R047 2.2

R046 4.7

R048 22

R061 10

C033 100 16V

R051 2.2k Q046 2SK2158

C013 2200 25V

(FAN) FAN+

R049 220k

FAN MOTOR DETECT

S

C034 4.7 50V

EP031

D021 10EDB40

IC021 TA7809S

R013 22k

R016 100k

R050 2.2k R055 2.2k

D035 MC2838

D008 MC2838

Q011 RT1N141C-TP-1

G

Q045 2SC3052

M001

FAN-

R045 1k

R054 22k

D012 10EDB40

CN041 3P FAN+

R053 22k

Q041 2SC3052

I

D006 1SS355TE-17

C035 47 25

B+ SWITCH

R057 1k

C012 0.1

O

R041 0

Q044 2SC3052

D036 MC2836

D003 10EDB40

C008 2200 25V

R039 22 1/2W

Q043 KTA1266GR

POWER ON/OFF

R005 4.7k

R038

C002 0.1

(CHASSIS)

D022 10EDB40 C023 2200 25V

I

R036 4.7k

D023 10EDB40

R035 4.7k

SP L-OUT (RG490)

D024 10EDB40

SP-GND

R033 22k

SP R-OUT

AC3-2

C-7

SBSO

WFCK

EXCK

G-5

G-6

G-3

R335 100

G-2

G-1

AC4-2

AC4-1 T-CE

T-DI

T-CL

T-DO

C-15

C-14

C-13

C-12

C-9

C-10

C-11

R383 1k

PWR-GND

C031 0

(Page 49)

STK MUTE

C4

FM75Ω COAXIAL ANTENNA

HCD-RG490/RG590

43

43

R339 1k

R330 1k SCOR

WFCK

SBSO

EXCK

CDG-BGC

CDG-DET

(Page 53)

BLOCK

AM

R340 1k

MUTE-DATA

R338 100

R334 100

R337 100

CDG-RST

R333 10k

R331 100

R332 100

R372 100

CDG-POWER

+9V

GND

GND

TUNER-L

+9V

TUNER-R

GND

N/C

PLL CE

PLL DI

PLL DO

PLL CLK

TUNER(FM/AM)

THE ASSEMBLED

D10

D8

C2

C1

CN331 13P

D031 R032 1k 1SS355TE-17

D7

SUPPLIED WITH

(Page 42)

R037 4.7k

JW032

1

CN031 13P

R063 100

C385 100p

C388 100p

(RG590) R064 100 R363 0

C336 0.01

C3

L-OUT

GND

R364 0

M+7V

M-GND

M-GND

MP3-STB

MP3-REQ

MP3-ACK

MP3-CLK

MP3-LP

MP3-DIO

AMP-A-GND

R060 1k 2W

UNREG +16V

V-MUTE

R381 1k

R382 1k C386 100p

C387 470p

R325 22k

R326 22k

R324 100

R316 100

R336 10k

R322 100

R323 100

R366 0

9

(Page 31)

(Page 47)

R-OUT

R329 100

C317 1000 10V

MP3-CS

D303 UDZW-TE17-4.7B

R320 100 MP3-RST

SCOR

CD-SENS

CD-CLK

XLT

CD-DATA

AVDD(3.3V)

XTCN

XRST

R-CH

D-GND

A-GND

L-CH

D-GND

WFCK

CN302 31P

SBSO

(RG590)

EXCK

A

-VFL

D-OUT

STBY RELAY

DVDD(3.3V)

EVER +10V

A

MP3-RST

C-7

C-6

C-5

C-3

C-4

C-8

C-1 R318 100

D-GND

MP3(3.3V)

AC4-2

VF

C333 0.1

AC4

R365 0

MP3-GND

AC4-1

R321 100

AC4

PROTECT

R059 1k 2W

-VFL

D301 10EDB40

R317 100

AC3-2

VF

(Page 61)

SP RELAY B+ PROTECT

STK-M

AC3-1

AC3

STBY RELAY

D302 10EDB40

R034 22k

C027 0.01

R319 100

(Page 59)

CN001 11P C026 0.01 AC3

R315 100

(RG490)

SBSO

A8

WFCK

EXCK

(Page 41)

A7

AC3-1

D4

D9

(Page 42)

HCD-RG490/RG590 Ver. 1.2

• See page 27 for Circuit Boards Location.

7-21. PRINTED WIRING BOARD – MIC. AUX. HP Board –

1

2

3

: Uses unleaded solder.

4

5

6

7 (Page 36)

EXCEPT RG490: MX/ RG590: MX

RG490: MX/ RG590: MX

MIC. AUX. HP BOARD

R859

C867

R858 R857

C868

C865

R815

C819

R856

R813

C816

C815

JW811 JW804

C801

R809

C807

R808

C808

C810

R811

C784

C802

R810

R812 R803

R860

C803

C809

C811

R819

R862

JW807

C869

C805

1

R804

RG490: MX/ RG590: MX

R802

R807

R801

Q801

JW809

R820

E

C863

C

JW813

JW802

C859

JW808

R854

R861

C864

R806 R855

JW810 JW801

R821 C782 JW812

R805

VR851 ECHO LEVEL C862

RG490: MX/ RG590: MX

EP701 13

IC801

D851

IC802

C856

C861

C813

R817

C870

R818

C818

JW805

B

MAIN BOARD CN061

C817

C852

JW806

C853

R814

C814

C851

C854

F2

(RG490: E2, E51, MX, AR/RG590: E2, E51, MX, AR)

R851

C857

R852

R853

(RG490: MX/RG590: MX)

C858

F1

(Page 40)

MAIN BOARD CN061

(CHASSIS)

R816

A

8

R823 VR801 MIC LEVEL

R825 C821

JW803

C820

C781

RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA

C783

R831 R826 JR801

R832

R827

R824

JR802

EP801

RG490: E2, E51, AR/ RG590: E2, E51, AR

C833

EXCEPT RG490: MX/ RG590: MX

D (CHASSIS)

12, 13 (12, 13)

1-868-902-

1-869-004-

RG490: MX/ RG590: MX JK802

RG490: E2, E51, AR/ RG590: E2, E51, AR

11, 12 (11, 12)

MIC

JK801 MIC 1

MIC 2

(RG490: MX/RG590: MX)

HCD-RG490/RG590

44

44

J702 AUDIO IN

J701 PHONES

HCD-RG490/RG590 Ver. 1.1

7-22. SCHEMATIC DIAGRAM – MIC. AUX. HP Board –

• See page 62 for IC Block Diagrams.

RG490:E2,E51,AR/ RG590:E2,E51,AR

(RG490:MX/RG590:MX)

R862 470

JR801 0 JK801 R801 4.7k

JR802 0

MIC 1 RG490:MX/

R802 0

RG590:MX RG490:E2,E51,MX,AR/ RG590:E2,E51,MX,AR

R805 100k

RG590:MX

C803 0.022

R804 0

R861 470

RG490:MX/

C805 0.022

IC801(1/2) BA4558F-E2

C808 220p

3 1

MIC AMP

2 4

R803 4.7k JK802 R807 10k

R806 100k

MIC RG490:E2,E51,AR/ RG590:E2,E51,AR

C801 10 16V

Q801 C802 2SC3052 1000p

C807 1000p

R819 470k

R808 10k

IC802 M65850FP

C811 0.1 50V

R809 100k R810 1k

R817 4.7k

C813 100 16V

C851 R851 1 50V 22k

R812 100 C818 10 16V

C854 0.022

8 7

R815 100

IC801(2/2) BA4558F-E2 EP801

C814 2.2 50V

R814 220k

C833 0.1

C816 220p

(CHASSIS)

REF

C863 R856 2.2 10k 50V

R813 10k

C870 47 16V

C868 0.022 C867 0.047

OP2IN

R859 22k

CC1 C864 1000p

CC2 C858 0.47 50V

R820 22k

R827 10k

C869 47 16V

OP1OUT

OP2OUT

R816 100k

6

R860 100k

LPF1OUT CLOCK

OP1IN

C857 0.47 50V

C819 0.1

5

VCC

C853 0.047

C817 2.2 50V

NC LPF1IN

R853 22k

MIC LEVEL

R818 4.7k

C815 47p

D851 UDZW-TE17-5.1B

NC R852 C852 22k 1000p

VR801 50KA

C809 10 16V

MIC 2

RG590:MX

DIGITAL ECHO

C810 470p

MUTING

RG490:MX/

R811 47k

R858 22k

VR851 50K

LPF2IN R857 22k

GND LPF2OUT C856 4700p

ECHO LEVEL

C859 0.1

R854 47k

C861 1 50V

R855 22k

C865 4700p C862 0.047

R821 10k

R823 2.2k

13 O-MIC-DET

EXCEPT RG490:MX/

MIC +9V

RG590:MX

MIC SIG D-GND R825 1k

J702 AUDIO IN C820 1000p

C821 1000p

R832 R831 470k 470k

R826 1k

O-HP/AUX D-GND

R824 22k

(Page 38)

AUX-IN-RCH

RG490:AEP,RU,E3,EA,AUS

A-GND

/RG590:AEP,UK,RU,E3,EA

AUX-IN-LCH HP-GND

(Page 42)

R-OUT

J701 PHONES

HP-GND C783 C784 0.1 0.1

C781 ∗

L-OUT

C782 ∗

RG590:MX 1

∗C781,782 EP701 (CHASSIS)

RG490:MX/

1000p(RG490:E2,E51,AR/RG590:E2,E51,AR) 2200p(RG490:AEP,RU,E3,EA,AUS/RG590:AEP,UK,RU,E3,EA)

HCD-RG490/RG590

45

45

HCD-RG490/RG590 Ver. 1.1

• See page 27 for Circuit Boards Location.

7-23. PRINTED WIRING BOARD – POWER Board (RG490) – 1

A

2

3

4

5

: Uses unleaded solder.

6

7

8

9

10

11

12

• Semiconductor Location

M1

TRANSFORMER BOARD CN903

13

(Page 58)

Ref. No. Location

1

C403

F-7 F-6 D-4 D-4 D-3 E-2 E-3 E-2 E-3 F-2 G-3

C405

JW431

D401

J1

C406

(Page 50)

JW427

L1

D

(EXCEPT MX)

C404

Q441 Q442 Q481 Q482 Q483 Q484 Q485 Q486 Q487 Q488 Q489

R401

G-5

JW428

SUB WOOFER BOARD CN502

POWER BOARD

(Page 36)

4 CN441

J3 MAIN BOARD CN031

JW422

E

E

E

Q482

Q481

Q483

(Page 40)

CN443

R486

E

MAIN BOARD CN031

JW426

C481

Q484 R485

6

R465

(MX)

1

JW411

R458

Q442

R452

R451 JW467

R491

TH441

E

JW459

RY441

JW443

C441

R441 R447

R445

C451

C454

-1

JW417

C447

JW442

R425

R421

C448

R453

R423 C442

C411

R420

R422

C453

R461 L441

R443

R448

C443 R434

C445

C446

R446 R435

EP401

R444

R413 R411

R414

R462

R442 R412 R415

C493 (AEP, RU)

-2

R424

R454

JW416

JW405

R495

JW402

JW423

JW424

JW401

JW425

A

C494

Q489

K D441

JW433 JW403

C488

G

D481

R449 R493

D483

JW461

JW444

C489 R460 K

R492

C452

JW451

R459

Q488

JW462

JW452 JW445

R457

JW418

C490

Q441

R455

E

JW448

JW404

R496

JW463

JW449

R456

E

JW450

E

Q485

R440

JW406

R490

JW456

JW460

JW408 R487

JW464

JW453

JW409

E

R499

JW455

JW454

JW421

JW420

JW419 JW415

R498

R482

R488

Q487

JW407

JW410

R481

E

Q486

JW414

E

JW412

R497

C486

JW413

R484

E

R480

R466 R483

F

3

R402

IC441

CN442 1

JW430

C

C-10 F-7 G-12 F-7 F-2

JW434

B

D401 D441 D443 D481 D483

JW447

R416 L442

(AEP, RU)

IC441

C460

(CHASSIS)

D443

C459

R418

R419

JW457

R417

R407

12 1-869-308-

H –

+

R

SPEAKER JK441

HCD-RG490/RG590

46

46

–

+

L

(12)

HCD-RG490/RG590 Ver. 1.1

7-24. SCHEMATIC DIAGRAM – POWER Board (RG490) –

R447 47k

C441 10 50V

JW401

R441 2.2k

L441 4 IC441(1/2) STK403-130 R434 0

C445 100p 10

C448 22 35V

R443 47k

C447 22 35V

C453 0.1

C489 47 63V

R493 47k

C488 22 35V

Q481 2SC3052

Q482 2SC3052

R414 10

R416 10

R480 100k

R484 100k

R485 100k

Q483 2SC3052

R415 10

RY441

D443 1SS355

R483 22

R457 22k

R459 47k

D481 1SS355

R425 10

R453 10

R424 10

R420 10

SP GND Q484 2SC3052

C481 100 10V

R417 100

R418 100

R407 100

R419 100

L

TH441 R486 100k

R460 47k D441 MC2836

Q442 2SC5625

R423 10

R421 10

R422 10

R454 10

C411 0.01

R444 47k R446 1k

R462 10

SP(L) JK441 C459 1000p 100V

C490 100 63V

(AEP,RU)

R412 10

Q483,484

R492 1k Q441 2SC5625

C491 0.1

R465 47k

TEMPERATURE DETECT

C451 0.1 R455 1k

D483 1SS355

R466 100k

DC DETECT

R491 10k

Q489 2SC5625 STANDBY SWITCH

R497 100k

Q481,482

R451 0.22 5W POWER AMP

C443 0.001

R411 10

R413 10 L442

-2

R445 1k

R461 10 -1

R495 1

Q485 2SA1235 PROTECTOR

R458 22k

R482 10k

C460 1000p 100V

SPEAKER SP GND (AEP,RU)

R SP(R)

C486 2.2 50V

(CHASSIS) EP401

R448 47k

C444 0.001

R456 1k

C454 0.1

Q441,442

R481 4.7k

CN441 13P

OVER LOAD

9

DETECT

C452 0.1

14

SP L-OUT

R487 47k

6 2

15 R442 2.2k

Q486,488

3

R452 0.22 5W

1 8

RELAY DRIVE

R440 22k

R499 1k

C493 2200p

C494 2200p

C442 10 50V

R488 Q486 22k 2SC3052EF

R496 100

4

C405 2200 63V

R401 100k

3

C403 0.1 100V

Q488 2SC2411K

SP-GND SP R-OUT SP RELAY B+

D401 D10XB20

(Page 39)

PROTECT

R490 4.7k

JW402 (AEP,RU)

1

DETECT

R498 1k

7

IC441(2/2) STK403-130

R435 0

(EXCEPT MX)

2

Q487 2SC3052 PROTECT

C446 100p

R-OUT

C406 2200 63V

R402 100k

C404 0.1 100V

AMP-A-GND L-OUT UNREG +16V PWR-GND

R449 47 1/2W

(Page 43)

STK-MUTE -VFL GND

CN443 6P

CN442 3P AC1

+VCC NC

NC

GND

GND

-VCC

AC1

(Page 59)

OVERLOAD/DC DETECT

(Page 51)

(MX)

RELAY+ RELAY-

HCD-RG490/RG590

47

47

HCD-RG490/RG590 Ver. 1.1 • See page 27 for Circuit Boards Location.

7-25. PRINTED WIRING BOARD – POWER Board (RG590) – 1

A

2

3

4

5

: Uses unleaded solder.

6

7

8

9

10

11

12

• Semiconductor Location

M2

TRANSFORMER BOARD CN905

13

(Page 60)

Ref. No. Location

C

D

I-5

Q441 Q442 Q481 Q482 Q483 Q484 Q485 Q486 Q487 Q488 Q489 Q490 Q491

G-7 G-6 F-2 F-3 G-1 H-1 G-5 F-6 F-5 F-7 G-2 G-1 G-2

5

(CHASSIS)

JW402

JW401

C413

C414

C403

C404

JW408

R404

IC441

CN442 1

R406

C-8 C-11 G-7 I-12 F-3 H-4 I-4 G-7

R402

B

D401 D402 D441 D443 D444 D445 D446 D481

1 1

R401

4

4

D401

R409

D402 R410

JW410 JW409

R403 R405

C406

C405

EP402

C402

(Page 50)

L2

JW443

JW444

JW416

JW446

JW447

JW452 C481 E

JW458

R479

D446

C442

JW424

JW426

JW428

JW429 JW435

JW436

JW460

JW461

R491

JW437

-1

C451

R422

R454

JW432 C411

C491

-2

C453

R421

R448

R413 L441

R425

R420

R453 JW434

R446

18

R461

R412

R424

EP401

(AEP, UK, RU) R494

R411

R423

R476

C444

1

C448

R436

R439

C445

C441

JW441

R445 R447

C446

IC441

D445

C454

JW440

C447

C452 RY441

A

R414

R442

R444

JW467

C443

JW421 JW423

JW431

JW433

JW465

D441

R493

TH441

JW459

JW464 R460

JW422

JW430

JW439

R459

K

JW419 JW420

JW438

R443 R468

JW425

D481 K

E

R441

JW468

H

1

R492

JW404

R450

JW403

R449

R495

JW482

R467

E

JW463

JW484 JW485

JW406

JW481

R483

6

Q441 R458

Q442

JW483

E

R474

R496

E

JW405

R482

R456

R473 R484

E

R463

R480 Q484

R455

R478

Q483

CN443

Q488 E

R457

JW470 R481

C461

Q485

R490

Q486

JW462

Q489 Q490

C486

R487

JW469

R477 E

E

JW466

E

E

R485

Q487

R488

JW477

JW479

JW474

JW476

R464

R471

R472

R470

Q491

(MX)

R440

R499 R498

JW478

R469

D444

C462

(Page 40)

JW418 JW456

JW457

JW473 C463

G

JW417

JW453

JW472

JW480

R486

JW450

JW454

JW471 R497

R475

MAIN BOARD CN031

C409

JW451

R466

Q482

Q481

J4

JW445

JW455

JW475

E

F

R465

(Page 36)

CN441

JW448

JW449

POWER BOARD

J2 MAIN BOARD CN031

JW442

JW414

E

(EXCEPT MX)

JW415

SUB WOOFER BOARD CN502

C410

R462

JW486 R415

(AEP, UK, RU)

L442

C460

C459

R416 R417

R407

R418

R419

D443

I

11 1-868-911(CHASSIS)

J

–

+

R

SPEAKER JK441

HCD-RG490/RG590

48

48

–

+

L

(11)

HCD-RG490/RG590 Ver. 1.1 7-26. SCHEMATIC DIAGRAM – POWER Board (RG590) –

C461 47 100V

R467 2.2k 1W

R496 100

D445 UDZW-TE17-16B

R441 2.2k

+PRE +

+VH

NF/CH1

+REF +VL -REF/CH1

+RE/CH1 L441

R493 C445 100p 0

IN/CH1 -1

-

JW403

-PRE

R449 0.22 5W

IC441(1/2) STK412-240

R497 100k

Q481,482

R464 100k

R445 1k

R491 47k

Q491 2SA2026

R455 1k

R470 47k

C453 0.1

R462 10

R414 10

R416 10

R415 10

Q483,484

Q481 2SC3052

Q482 2SC3052

R412 10

R480 100k

R484 100k

Q483 2SC3052

R485 100k

RY441 D443 1SS355

Q489 2SC5625 D444 1SS355

(AEP,UK,RU) R443 47k

R469 47k

Q489-491

R473 47k

Q441 2SC5625

R459 100k

R463 47k

C462 47 100V

R495 1

R436 22k

R476 22k

R439 10k

R479 10k

D481 1SS355

R453 10

SP GND Q484 2SC3052

C481 100 10V

R420 10

R424 10

R417 100

R418 100

R407 100

R419 100

L

TH441 R486 100k

SP(L) JK441 C459 1000p 100V

R460 100k

R475 10k R468 2.2k 1W

∗C411 Q442 2SC5625

R423 10

R421 10

R492 47k

R422 10

R454 10

0.01 (AEP,UK,RU) Q485 2SA1235 PROTECTOR

R458 22k

R482 10k

C460 1000p 100V

C411 ∗

1000p (E2,E3,E51,EA,MX,AR)

Q490 2SC3052

D446 UDZW-TE17-16B

R477 100

R425 10

D441 MC2836

STANDBY SWITCH

R444 47k

R483 22

R457 22k

R471 100k

C463 470 6.3V

C491 0.1

C448 47 50V

R446 1k

R472 100k R474 2.2k

C447 47 50V C443 0.001

R465 47k

TEMPERATURE DETECT

C451 0.1 C441 10 50V

R466 100k

DC DETECT

R447 47k

R411 10

R413 10 L442

-2

POWER AMP

R461 10

SPEAKER SP GND (AEP,UK,RU)

R SP(R)

C486 2.2 50V

(CHASSIS) EP401

R448 47k C454 0.1

Q441,442

R481 4.7k

CN441 13P

OVER LOAD R478 10k

SUB R494 0

-VH -REF -VL

C444 0.001

C446 100p

C452 0.1

SP L-OUT

R487 47k

Q487 2SC3052

R456 1k

BIAS

NF/CH2

DETECT

R440 22k

R405 100k

R499 1k

-RE/CH2

R442 2.2k

Q486,488 IC441(2/2) STK412-240

R450 0.22 5W

RELAY DRIVE

R488 22k

R490 4.7k

Q486 2SC3052

C405 2200 71V

R401 100k

3

SP-GND

C403 0.1 100V

4

DETECT

R498 1k

IN/CH2 +

1

PROTECT JW404

+RE/CH2

(EXCEPT MX)

2

R403 100k

SP R-OUT SP RELAY B+

D401 D10XB20

(Page 39)

PROTECT R-OUT

Q488 2SC2411K

C406 2200 71V

C442 10 50V

AMP-A-GND

C404 0.1 100V

R402 100k

L-OUT UNREG +16V

(Page 43)

PWR-GND R406 100k

STK MUTE

R404 100k

-VFL GND

CN442 5P

CN443 6P +VCC

C410 3300 50V

NC

AC-VH

R410 100k

AC-VL

GND

2

-VCC

1

OVERLOAD/DC DETECT

(Page 51)

(MX)

C409 3300 50V

RELAY+

4

D402 D10XB20

C414 0.1

GND

C413 0.1

AC-VL AC-VH

R409 100k

(Page 61)

3

RELAYC402 0.01

HCD-RG490/RG590

49

49

EP402

(CHASSIS)

HCD-RG490/RG590

• See page 27 for Circuit Boards Location.

7-27. PRINTED WIRING BOARDS – SUB WOOFER Section –

1

2

3

4

(RG490)

L1

SUB WOOFER BOARD

5

6

7

8

9

(Page 48)

POWER BOARD CN443

L2

SW-SP BOARD

POWER BOARD CN443

CN504

EXCEPT RG490: MX/ RG590: MX

4

CN502

(Page 36)

CN501 1

R523

R521

JW514

R505

Q502

R508

JW522

RY501 R525 R526

C509

C506

JW506

JW505

C507

R527

Q506 E

R511

D503

R514

R507

R502

C505

C503

R501

1

CN503

4

(12) 12 1-868-920-

(12)

E R503

JR501

C512

12

R513 D501

R524 R529

JW504

C504

-2

1-868-919-

D502

C514

R510

C516

JW503

E

-1

JW509

R504

Q505

–

C513

JW501

D507

JK501 SUB WOOFER OUT

R512

JW521

R531

D

+

3

R506

C

R509

JW516 JW507

JR502

(Page 40) RG490: MX/ RG590: MX

1 D504

E

E

H2 MAIN BOARD CN271

R534

R516

C517

R517

C510

Q503

R532

R533

JW502

MAIN BOARD CN271

R518

C511

R520

R522

H1

B

10

(RG590)

(Page 46)

A

: Uses unleaded solder.

Q501

R515

C508

C502

E Q507

R530

IC501

• Semiconductor Location Ref. No. Location

HCD-RG490/RG590

50

50

D501 D502 D503 D504 D507

C-4 C-6 C-6 B-7 C-2

IC501

D-4

Q501 Q502 Q503 Q505 Q506 Q507

D-6 B-6 B-3 C-2 C-3 D-3

HCD-RG490/RG590

7-28. SCHEMATIC DIAGRAM – SUB WOOFER Section –

POWER AMP IC501 STK404-130

1

2

3

4

5

6

7

8

9

10

11

12

13

Q507 2SC3052

TEMPERATURE DETECT

R506 1

R530 22k

R507 4.7k 1W

R511 0.22 5W

C508 220p

JW521

C516 10 50V

JR501 0

C505 10p

C502 220p

EXCEPT RG490:MX/

R510 0.22 5W

R508 4.7k 1W

C507 47 50V

R513 1k

R509 100

RG590:MX

Q501 2SC5625

C513 0.1

R531 4.7k

RG490:MX/

D507 1SS355

1SS355

100V 10

R517 10k

R527 10 R526 10

R515 47k

D503 1SS355

D502

C511

100V

R525 10

R518 10k

DETECT

C512 0.1

R512 10

10

25V

UDZW-TE17-12B

100 C506

SW-ON/OFF

(Page 43)

R505 ∗

D501

C509

SW-SIG GND

100V

C504 22 25V

100

R502 47k

SW-SIG

R514 22k

C510

47k

0.0047

R501

2.2k CN501 3P

R529

(Page 39)

C503

OVER LOAD R504 47k R503 1k

Q502 2SA1235

R534 1

RELAY DRIVE

RG590:MX

(RG490)

4.7k 2W(RG590)

GND -VCC OVERLOAD/DC DETECT

(Page 47)

RELAY+

R523 100

R522 100

R521 100

R516 100

RELAY-

Q505,506

(Page 49)

Q506 2SC3052

Q505 2SC3052

R524 47k

R532 22k

R520 100k

DC DETECT

Q503 2SC3052

TEMPERATURE

(RG590)

DETECT

C514 100 35V

-1 RY501

CN503 4P

CN504 4P

SUB WOOFER OUT

4.7k 1W(RG490)

+VCC

-2

JK501

∗R505 CN502 6P

D504 1SS355

C517 10 50V

R533 22k

HCD-RG490/RG590

51

51

HCD-RG490/RG590

• See page 27 for Circuit Boards Location.

7-29. PRINTED WIRING BOARDS – CD-G Section (RG490: MX/RG590: MX models) –

1

2

3

4

5

: Uses unleaded solder.

6

7

8

9

10

11

CD-G BOARD (SIDE B)

CD-G BOARD (SIDE A)

A IC1003 L1001

3

C1010

Q1008 2

C1008 E 1

R1033 R1032

L1002

R1034 R1035

C1012

B

13

E

Q1007

C1028

5

1

22

26

IC1002 14

C1002

E

R1022

MAIN BOARD CN331

E

E

(Page 40)

E

E

C1015 C1016

C1022

R1037

R1017

R1020

R1011

C1003

R1012

R1003

R1015

C1005

C1006

C1019

7

Q1005

C1018

D

1

60

R1036

46

R1023

1

Q1009

45

R1016 R1004

X1002

C1007

C1004

R1029

8

R1013

IC1005

R1005

Q1001

14

CN1001

Q1006

C1001

R1006

G

Q1002

IC1001

R1021

15

R1051

R1038

31

C1013

18

16

C1011

30

C

9

C1014

VIDEO OUT BOARD CN803

R1031

FB1001

C1030

C1023

IC1006 1

C803 C1027 C1029 R1030

C1031

CN1004

E

JR1001

Q1010

C1024

3

6

VIDEO OUT

1

C1026

C1025

E

4

J803

2

(RG590)

11

11 1-865-725-

(11)

1-865-725-

(11)

(RG490)

11

12

(11)

(12)

1-868-912- 1-869-309-

• Semiconductor Location Ref. No. Location

HCD-RG490/RG590

52

52

IC1001 IC1002 IC1003 IC1005 IC1006

C-2 B-7 A-3 C-4 E-2

Q1001 Q1002 Q1005 Q1006 Q1007 Q1008 Q1009 Q1010

C-7 C-6 D-6 C-6 B-3 A-4 D-6 E-7

HCD-RG490/RG590

• See page 57 for Waveforms.

7-30. SCHEMATIC DIAGRAM – CD-G Section (RG490: MX/RG590: MX models) –

• See page 62 for IC Block Diagrams.

• See page 66 for IC Pin Function Description.

SCOR

3A

GND 4Y

2Y 5A

3Y

2A 6Y

4A

1Y 6A

5Y

1A VCC

R1036 0.0047

R1037 0.0022

WFCK

SCHMITT TRIGGER IC1005 SN74AHCT04NSR

R1038 470P SBSO

EXCK

C1011 0.01

CN1001 13P

D-RAM

LEVEL SHIFT

IC1002 MSM514400E-60TS

L1002 10

A4

VCC A4

A5

A5

A6

A3 A2

MUTE-DATA

CDG/_BGC CDG/BGC

A6

Q1005 RT1N441C-TP-1

_RST CDG-RST

(Page 43)

R1023 220

Q1005,1009

EXCK EXCK

R1022 220

SBSO SBSO

R1020 10k

R1021 220

R1003 4.7k

R1004 2.2k

Q1009 RT1P141C-TP-1

WFCK WFCK

C1001 0.01

SCOR SCOR

A7

A1 A7

Q1002 RT1N441C-TP-1

A0 A8

CDG-DET CDG-DET CDG-POWER CDG-POWER VMUTE

C1012 47 6.3V

_RST

V-MUTE

C1014 0.01

OE

A9

GND

C1019 22p Q1002,1006

R1015 100

RAS

VA0

XWE

XRAS

MCDI

MCCK

MCDO

MCE

VSS1

VDD1

SFSY

SBSY

MUTE

X1002 14.31818MHz

DATA

+9V

CLCK

SESUB

OE

GND

CAS DQ3 VA1

XI1

VA2

XO2

VA3

XI2

VA4

PDOWN

VA5

SENTSC

VA6

DQ4

DQ2 DQ4

C1018 22p

LEVEL SHIFT

DQ3

WE

XO1

DQ1 VSS

C1016 0

A4 A5 A6 CD GRAPHICS DECODER XRESET

R1017 10k Q1006 RT1P141C-TP-1

A7 VA7

IC1001 TC9411AFG

C1015 0.01 FSC

VSS2

DEN

Q1001 RT1N441C-TP-1

CDG/_BGC

R1016 10k

VDD2

PNG

VD0

QNG

XCAS

Q1001 NTSC/PAL

VDD3

VD1

VSS3

XOE

BIAS2

VD2

C1003 0.01

OE

SELECT SWITCH C1005 0.01

DQ3

C1006 0.01

Q1010 RT1N441C-TP-1

BLNKIN

BIN

GIN

RIN

XHSYNC

XVSYNC

GDET

VON

TEST1

TEST2

LINESW

VREF

VD3

C1002 0.01 C1028 100 6.3V

VIDEO AMP IC1006 NJM2561F

VOUT SAVE _PWR

C1026 1000 6.3V

C1023 1 50V

VIN GND C1004 0.01

VCC

C1031 1 50V

C1022 22p

C1025 0.01

R1032 10k

R1035 2.2k

R1034 2.2k

R1029 1k

R1030 22k

R1031 75

L1001 0

R1013 R1012 2.2k 10k C1013 100 6.3V

Q1007,1008

C1007 0.01

VSAG

C1030 22 6.3V

R1011 4.7k

VIDEO MUTING

FB1001 0

AVDD

AVSS

VMUTE

VDOUT

DQ4 BIAS1

R1033 2.2k

R1005 2.2k

B+ SWITCH

+5V REGULATOR C1010 100 6.3V

IC1003 µPC2905 O

R1006 4.7k

G

Q1008 2SB1122 Q1007 RT1N441C-TP-1

I C1008 1 50V

JR1001 0

J803 C1029 0.001 C1024 100 6.3V

CDG-DET

R1051 10

C1027 220p

CN1004 3P GND

CN803 2P VIDEO OUT

VIDEO GND

CDG-POWER GND

HCD-RG490/RG590

53

53

C803 0.1

VIDEO OUT

HCD-RG490/RG590 Ver. 1.2

• See page 27 for Circuit Boards Location.

7-31. PRINTED WIRING BOARD – Board –

1

• Semiconductor Location

2

Ref. No. Location

7

8

9

BOARD C622 CN604 1

1

2

41

5

44

45

R744

Q

R743

JW635 JW633

JW628

JW681

JW679

JW678

JW677

JW674

JW675

JW676

C710

60

JW663

R607

JW629

JW632

C703 R703

R628

JW661

R705 R706

R613

R707

Q603

JW619

X701

R701

C701 80

41

1

40

JR610

R704

JW662

R603 E

JW631

1

JW630

R633

S613

61

IC701

JW625

N

JW624

JW621

R618

JW623

R617

5

JW665

C702

R608

JW627

1 C631

(Page 55) KEY TOP BOARD CN607

C711 JW664

CN606

C705 JR614

R610 C704

R708 R702

Q604 D601 – 605 (STREAM)

JW615 R647

D604

JW657

D602

S623 s

R766

R711 JW658

E

R718

JW659

R719

R670

C708

R765

JW616

R713

R764

E

R671

R717

R663

21

C709

R712

R690

R691

20

C707

R710

(RG590: E2, E3, E51, EA, MX, AR)

JR609

R716

R634 JW617

JR613

R715

R661

JW618

R763

D603

R762

R681

R709

(RG590: E2, E3, E51, EA, MX, AR)

R680

7

R660

D

JW673

JW671

JW670

C 3 RG590: E2, E3, E51, EA, MX, AR

R746

C712 JW672

R627

JW669

JW666

5

JW668

JW634

4

IC610

C621

JR612

JW680

5

(Page 55)

JW667

B

R745

FL701 FLUORESCENT INDICATOR TUBE

KEY RIGHT BOARD CN605

B-1 D-8 G-6 F-7 D-4 E-3 H-5 F-3 F-3 H-5 H-6 G-3 H-7 G-8

6

A

JW626

Q601 Q602 Q603 Q604 Q605 Q621 Q701 Q702 Q703 Q704 Q705 Q706

5

JW622

IC610 IC701

H-6 F-7 D-5 F-4 H-4 H-6

4

JW620

D601 D602 D603 D604 D605 D711

3

: Uses unleaded solder.

JW614

JW654

JR608

JW660

JR605

E

R672 JW651

JW652 R632

C641

JW602

Q601

R631

D601

E K

Q702

CN601

Q703

R742

R741

JW611

K

D711

R775

R774

E

Q705

–

JW637

TAPE MECHANISM DECK BLOCK S611 – 613, 621 – 623

EXCEPT RG490: MX/ RG590: MX

MAIN BOARD CN991

(Page 36)

E2

MAIN BOARD CN991

(Page 40)

RG490: MX/ RG590: MX

HCD-RG490/RG590

54

JW650

JW648

JW649

JW647

S621 j

A

H E1

KEY LEFT BOARD CN609 (RG590: E2, E3, E51, EA, MX, AR) CN603 (RG490/RG590: AEP, UK, RU)

(Page 55)

1

JW636

R773 E

11

E

JR603 R635

JW644

JW638 R776

E

Q605

P CN602 6

JW612

JW601

JR611

(RG490/RG590: AEP, UK, RU)

R601

E

Q704 D605

R629

R611

JW613

R605

R615

JW610

JW609

+

JW685

R772

S611 J

JW642

JW603 C625

JW641

JW639

JR602

JW646

1

JW643

3

JW608

JW604

JW606 JW605

JW645

R602

JW607

R673

(RG590: E2, E3, E51, EA, MX, AR) CN608 1

Q706

C642 R771

R612

R609 R650

S622 l TUNING –

R674

Q701

R651

G

JR606

JW653

Q602 E

JW640

F

R604

Q621 S612 L TUNING +

R614

E

R662

JW655 JR604

JR607

JW656

S671 ROTARY ENCODER VOLUME

54

SUPPLIED WITH THE ASSEMBLED BLOCK

11, 12

12, 13

(11, 12)

(12, 13)

1-868-903RG490: MX/ RG590: MX

1-869-005EXCEPT RG490: MX/ RG590: MX

HCD-RG490/RG590

1

2

3

Ver. 1.2

• See page 27 for Circuit Boards Location.

7-32. PRINTED WIRING BOARDS – KEY Section – 4

5

6

: Uses unleaded solder.

7

8

9

10

(RG590: E2, E3, E51, EA, MX, AR)

A

BOARD CN606

N

(Page 54)

KEY TOP BOARD CN607

R692

S641

5 R693

R664

VOCAL

BASS

1

GUITAR

S643

S642 JW684

S618

R694 S648

B R668

R659

R658

D623, S618

R667

R665

R666

–

R695

S617

S616

S615

S614

S644

EQ BAND

SURROUND

GROOVE

CLEAR

ENTER

SUB WOOFER

<

D623

R698

S645

S647

,

R697

R696

S646

C +

(MX)

(EXCEPT MX) 11

12

(11)

(12)

1-868-906- 1-869-008-

KEY LEFT BOARD

KEY RIGHT BOARD

D

S601 – 606, S614 – 618, S624 – 628, S631 – 638, S641 – 648

D611 STANDBY

1

S638

S601

R626

R652

R688

S637

E

S606

CD

JW682

F

R656

S636

TUNER/BAND

DISC 3

RG590: E2, E3, E51, EA, MX, AR S605

CN609 1

DISC 2

R687

JW683

R686

R675

P R655

BOARD CN608 6 CN603 (RG490/RG590: AEP, UK, RU)

S635

RG590: E2, E3, E51, EA, MX, AR CN602 (RG490/RG590: AEP, UK, RU)

TAPE A/B

S604

G

DISC 1

(Page 54)

DISC SKIP/ EX-CHANGE

R685

CN605

R654

H

1

R639

R653

Q

A

R640

S603

S634

AUDIO IN

(RG490/RG590: AEP, UK, RU)

D622

BOARD CN604

5

(Page 54)

R684 SURROUND

(RG490/RG590: AEP, UK, RU)

PLAY MODE/ TUNING MODE

D622, S628

I

SUB WOOFER

S633

R683

S632

S628

RG590: E2, E3, E51, EA, MX, AR

C643 (RG490/RG590: AEP, UK, RU)

1

3

GROOVE

EXCEPT RG490: MX/ RG590: MX

C644 REPEAT

DISPLAY

J

RG590: E2, E3, E51, EA, MX, AR

KARAOKE (RG490: MX/RG590: MX)

EQ BAND

S602

S625

R676

(RG490/RG590: AEP, UK, RU)

SLEEP RG590: E2, E3, E51, EA, MX, AR

S672 ROTARY ENCODER (MULTI JOG)

ILLUMINATION

ENTER

CD SYNC

R677 S626

S631

R682

K

R678

S624

(RG490/RG590: AEP, UK, RU) REC/PAUSE START

S627

11, 12

12, 13

11

12

(11, 12)

(12, 13)

(11)

(12)

1-868-904 RG490: MX/ RG590: MX

1-868-905- 1-869-007-

1-869-006EXCEPT RG490: MX/ RG590: MX

RG490: MX/ RG590: MX

HCD-RG490/RG590

55

55

EXCEPT RG490: MX/ RG590: MX

HCD-RG490/RG590 Ver. 1.2 7-33. SCHEMATIC DIAGRAM – /KEY Section –

• See page 57 for Waveforms. • See page 66 for IC Pin Function Description.

R664 4.7k

R666 10k

R667 22k

R668 47k

S614

S615

S616

S617

S618

CLEAR

GROOVE

SURROUND

EQ BAND

SUBWOOFER

R692 2.2k

R693 2.2k

R694 4.7k

R695 4.7k

R696 10k

R697 22k

R698 47k

S641

S642

S643

S644

S645

S646

S647

BASS

VOCAL

GUITER

ENTER

R665 4.7k

FL701

SUBWOOFER

GND

SW LED

KEY4

LED+9V

G12

S648

R659 1k

G13

G10

G11

G9

G8

G7

G6

G4

G5

G3

G2

G1

S1

S2

S3

S4

S5

S6

S7

S8

S9

S10

S12

S11

S13

S14

S15

S16

S17

S18

S19

S20

S21

R658 1k

KEY1 OUT

NX

D623 SLR325MC

F2

NP

NP

G13

G12

G11

G10

G9

G7

G8

G6

G5

G4

G3

G2

NC

NC

G1

S1

S2

S3

S4

S5

S6

S8

S7

S9

S10

S11

S12

S13

S14

S16

S15

S17

S18

S19

NC

S20

S21

NX

NP

F1

NP

FLUORESCENT INDICATOR TUBE

+

-

CN607 5P

GND

KEY4

SW LED

LED+9V

CN606 5P

(RG590:E2,E3,E51,EA,MX,AR)

ST2

ST1

ST5

S1

S2

S3

S4

S5

S6

S7

S8

S9

S10

RECEIVER

S11

REMOTE CONTROL

S12

C631 47 10V

R744 22k

S13

R628 47

R743 22k

C622 2.2 50V

C621 2.2 50V

S14

R627 100

RMS

R746 4.7k

IC610 RPM7240-H18

KEY1 OUT

R745 4.7k

C712 22 50V

C710 0.1

C711 0.1

S15 S16

VF

R741 22

-VFL

ST1

ST2

ST3

R632 10k

R609 100

TCM-SYNC

S18

SW LED

S19

O-TCM-SYNC

∗D601-605

S20

Q601-605

SOL-A FLUORESCENT INDICATOR TUBE

S21 G13

G11

STBY-LED

STBY

G10

KEY0

KEY0

G9

RMS

DECK CONTROLLER

VDI

VFD-DI

VOLUME

VFD-CE

G10

I-HALF-A

G9

I-REC-SW

G4

VCE

G3

M+9V

R766 2.2k

R718 100

R765 47k

G8

I-REEL-B

G7

I-HALF-B NC

G5

VDD0

M-GND

R715 100

R763 2.2k

D-GND

C708 0.1

G4

AVDD

G3

VSS0

G2

KEY4

G1

KEY3

C709 47 10V

B-SOL

KEY2

KEY1

AVSS

I-MODEL

CE

NC

NC

I-JOG B

I-JOG A

SO1

SI1

SCK1

XRESET

IC

X2

R607 10k

X1

C641 0.01

11

R680 22k

R681 47k

Q701,704 CAPSTAN/REEL MOTOR DRIVE

R608 10k

∗R713

R713 ∗

0(RG490/RG590:AEP,UK,RU) 1k(RG590:E2,E3,E51,EA,MX,AR)

R771 1k

R690 ∗

∗R690

R772 10k Q704 KTA1273-Y-AT

10k(RG490/RG590:AEP,UK,RU)

Q701 RT1N431C-TP-1 R773 1k

(RG590:E2,E3,E51,EA,MX,AR)

R710 1k

R711 1k

C707 4700p

R709 2.2k

R708 100

Q705 KTA1271Y-AT

Q702 RT1N431C-TP-1

KEY3

KEY4

VCE

K1-OUT

SOL-A D711 MC2836

Q702,705

KEY3

JOG-B

JOG-A

KEY0

STBY

SW OUT

R651 47k

R674 4.7k

R671 47k

R663 2.2k

R662 2.2k

R673 2.2k

R670 22k R672 2.2k

S623

S622

S621

S613

S612

R660 22k

R661 47k

S611

JOG-A

JOG-B

KEY3

KEY2

GND

JOG-B

KEY3

KEY2

GND

RG590:E2,E3,

CN604 5P

JOG-A

R617 10k

GND

KEY2 OUT

KEY0

STBY

SW LED

CN602 6P

LED+9V

GND

KEY2 OUT

KEY0

STBY

R618 10k

CN608 4P

TUNING

TUNING

+

-

+

-

(RG490/RG590:AEP,UK,RU)

CN605 5P

GND

KEY0

KEY2 OUT

STBY

SW LED

CN603 6P

LED+9V

GND

KEY2 OUT

KEY0

STBY

E51,EA,MX,AR

CN609 4P

S624

(RG490/RG590:AEP,UK,RU)

D622 SLR-325MCT31 SUBWOOFER

R640 1k

D611 SLR-325VCT31P STANDBY

R639 1k

C643 0.01

C644 0.01

R626 1k

R682 2.2k

R683 2.2k

R684 4.7k

R685 4.7k

R686 10k

R687 22k

R688 47k

S631

S632

S633

S634

S635

S636

S637

S638

SURROUND

GROOVE

DISC 3

DISC 2

DISC 1

PLAY MODE/

REPEAT

R675 4.7k

(RG490/RG590:AEP,UK,RU)

R678 47k

ENTER

R677 22k

R656 10k

R676 10k

R655 4.7k

R654 4.7k

R653 2.2k

R652 2.2k

(RG490/RG590:AEP,UK,RU)

EQ BAND

DISC SKIP/ EX-CHANGE

S672 S628

S627

S626

S625

S606

S605

S604

S603

SUBWOOFER

CD SYNC

REC/PAUSE

ILLUMINATION

CD

TUNER/BAND

TAPE A/B

AUDIO IN

S602

S601

ROTARY ENCODER

RG590:E2,E3, E51,EA,MX,AR

SLEEP

TUNING MODE

(MULTI JOG)

START

EXCEPT RG490:MX

DISPLAY

/RG590:MX (RG490:MX/RG590:MX)

KARAOKE

HCD-RG490/RG590

56

56

R776 10k

Q703 RT1N431C-TP-1

C702 47 10V R650 22k

R774 10k

Q706 KTA1271Y-AT

SOL-B

R775 1k

JOG-B

R707 100 JOG-A

R705 100

R704 0

R706 100 VOL-B

VDO

VOL-A

R703 100

R702 220 VCL

VDI

RST

VOL-A

VOL-B

R701 0

X701 4.19MHz

MOTOR R691 47k

C705 470p

C704 470p

C703 0.1

22k(RG590:E2,E3,E51,EA,MX,AR)

C701 0.1

BLOCK

B-HALF NC

R712 1k

VDD1

JR602 0

M-GND

C642 0.01

THE ASSEMBLED

B-PHOTO

R762 47k

R610 100k

G1

M-GND

TAPE MECHANISM DECK BLOCK

R764 47k

SUPPLIED WITH

G6

VSS1

C625 22 50V

CAPM+ B-REC-F

R716 100

G2

LED-GND

A-HALF

R717 100

G5

VCL

R719 100 I-REEL-A

G6

ROTARY ENCODER

VDO

R629 100

VFD-CLK

1

A-PHOTO NC

IC701 mPD780232GC -509-8BT-A

G7

S671

A-SOL

MOTOR O-MOTOR

G8

RST

VFD-RESET

O-SOL-A

/LED DRIVER,TAPE MECHANISM

G13 G12

KEY4

O-SOL-B

S21

VDD(SWITCHED)

LED DRIVE

SOL-B S20

LED DRIVE

(STREAM)

K1-OUT

Q621 2SC3052 TCM-SYNC

1L4345V22DOTDT02(RG490/RG590:AEP,UK,RU) TCM-SYNC

SIRCS

(Page 41)

ST4 R647 10k

NC

G11

(RG490:MX/RG590:MX)

SW OUT

S17

VDD(EVER)

VFD-DO

ST3

STREAM LED4

S18

G12

(Page 37)

STREAM LED3

S17

S19

R742 22

1L4344B22C0CDT02(RG590:E2,E3,E51,EA,MX,AR)

D-GND

S16

R631 10k

I-VOL B

/RG590:MX

R633 10k

I-VOL A

EXCEPT RG490:MX

R634 10k

ST4

ST5

VF

R635 10k

STREAM LED2

S15

CN601 19P

STREAM LED1

NC

STREAM LED5

S1

S2

S3

S4

S5

S6

S8

D601 ∗ Q601 2SC3052

Q602 2SC3052

S9

D602 ∗ Q603 2SC3052

S7

R611 1k

S10

D603 ∗ Q604 2SC3052

R601 1k

S11

R612 1k

S12

D604 ∗ Q605 2SC3052

R602 1k

S13

D605 ∗

R613 1k

S14

R603 1k

R614 1k

VDD2

R604 1k

R615 1k

VLOD

R605 1k

Q703,706

TRIGGER PLUNGER DRIVE

TRIGGER PLUNGER DRIVE

(DECK-A)

(DECK-B)

HCD-RG490/RG590

• Waveforms – BD Board –

– CD Board –

1

IC201 1 (LRCK), 2 (LRCKI) (CD play mode)

qa

– DECK Board –

IC101 ra (RFACO) (CD play mode)

wa

Q453 (Base) (REC mode)

3.3 Vp-p 1 V/DIV, 10 µs/DIV

2

IC201 5 (BCK), 6 (BCKI) (CD play mode)

qs

IC101 ys (LRCKI), yd (LRCK) (CD play mode)

22.8 µs

IC201 u; (RFACO) (CD play mode)

qd

Q453 (Collector) (REC mode)

es

4

IC201
2 V/DIV, 5 µs/DIV

1 V/DIV, 20 ns/DIV

IC101 y; (BCKI), yh (BCK) (CD play mode)

1 V/DIV, 200 ns/DIV

IC101 uj (XTAO) (CD play mode)

2.3 Vp-p 59 ns 1 V/DIV, 20 ns/DIV

4.5Vp-p 59 ns 2 V/DIV, 20 ns/DIV

HCD-RG490/RG590

57

57

ta

IC701 4 (X2)

3.5 Vp-p

6.7 Vp-p 239 ns

2 V/DIV, 50 ns/DIV

rs

IC1001 4 (SBSY) (CD-G play mode)

2.5 Vp-p 62.5 ns

472 ns

qf

IC1001 y; (XO1) (CD-G play mode)

70 ns

IC901 qf (X2 (16MHZ))

6.1 Vp-p

4.5 Vp-p Approx. 900 mVp-p 200 mV/DIV, 500 ns/DIV

ra

1 V/DIV, 10 µs/DIV

17 µs

1 V/DIV, 10 µs/DIV

1 V/DIV, 200 ns/DIV

3

ws

IC901 qa (XT2 (32.768KHZ))

3 Vp-p

500 mV/DIV, 5 µs/DIV

– Board –

– CD-G Board –

30.6 µs

17 µs

4.5 Vp-p

3.3 Vp-p 472 ns

ea

1.3 Vp-p

Approx. 900 mVp-p 200 mV/DIV, 500 ns/DIV

22.8 µs

– MAIN Board –

5.1 Vp-p 13.4 ms 2 V/DIV, 5 ms/DIV

1 V/DIV, 100 ns/DIV

HCD-RG490/RG590 Ver. 1.1

7-34. PRINTED WIRING BOARD – TRANSFORMER Board (RG490) – 1

2

3

• See page 27 for Circuit Boards Location.

4

5

6

: Uses unleaded solder.

7

8

9

10

11

12

13

TRANSFORMER BOARD

A (AC IN)

Q902 D901 2

CN901

1

R910

R911

RY901

R908

R904 R903

C908

B

C910

C909

D906

D908

JW929

F904 FH907

FH908

CN903 1

JW901

M1

JW937

C

POWER BOARD CN442

JW921 F905 8

JW922

(AEP, RU, MX, AR, AUS)

JW924

3

FH909

(Page 46)

FH910

PT901 MAIN POWER TRANSFORMER

JW926

F906

JW920

JW902

JW912

D

FH911

FH912 CN907 1

7

(E2, E3, E51, EA)

JW934

S901

(EXCEPT MX)

JW923

VOLTAGE SELECTOR 230 – 240V T 220V t120V

K1 F907

(AUS) (AEP, RU, AR, AUS)

(E2, E3, E51, EA, MX)

E

MAIN BOARD CN001

JW907

FH913

FH914

(Page 36)

(AEP, RU, AR)

JW931 JW903

(E2, E3, E51, EA, MX)

(Page 40)

JW909

JW930

JW906

JW933

F

(MX)

JW932 C911

4

JW917

1

(AEP, RU, MX, AR, AUS)

∗

JW910

JW925

(MX)

11

(AEP, RU, AR, AUS)

PT902

JW928

BUILT IN TRANSFORMER

D905

∗ NOT REPLACEABLE:

D903

1

D902

C907

SUB POWER TRANSFORMER

D904

G

K3 MAIN BOARD CN001

JW904

JW905

JW908

R914 K 12

D910 A 9

5

A

1-869-310-

(12)

18

H

• Semiconductor Location Ref. No. Location

HCD-RG490/RG590

58

58

D901 D902 D903 D904 D905 D906 D908 D910

A-8 G-11 G-11 G-11 G-12 B-9 B-8 H-10

Q902

B-9

HCD-RG490/RG590 Ver. 1.1

7-35. SCHEMATIC DIAGRAM – TRANSFORMER Board (RG490) –

F904 T8AL 250V

CN903 3P AC1

(AUS)

GND AC1

(Page 47)

F905 T8AL 250V C907 0.1

C908 220 63V

W901

JW907

240V

(E2,E3,E51,EA)

JW901

(AEP,RU,AR) 220V

F906 T3.15AL 250V

JW908 JW902

120V

(CHASSIS)

(E2,E3,E51,EA)

CN907 11P

(E2,E3,E51,EA,MX)

AC3 (EXCEPT MX)

JW909

S901

D910 MC2838

AC4

SELECTOR

R914 10k

VF

R908 1

VF

STBY-RELAY

120V RY901 220V

D903 10EDB40-TB3

-27V

230-240V

JW903

D902 10EDB40-TB3

JW917

REGULATOR

A

JW925

TRANSFORMER

Q902 2SB1238PQR -TV2

EVER +10V

PT902 SUB POWER

D908 10EDB40-TB3

D-GND

(MX)

MX,AR,AUS

VOLTAGE

AC4

(Page 43)

AEP,RU,

F907 T3.15AL 250V

AC3

(Page 39)

JW910

JW912

∗NOT REPLACEABLE:

-VFL

JW904

D904 10EDB40-TB3

BUILT IN TRANSFORMER

(MX)

JW905

PT901

CN901 2P

MAIN POWER C910 100 50V

R904 1k D906 UDZW-TE17 -27B

R903 10k

TRANSFORMER C911 1000 25V

C909 10 50V

∗R910

59

59

22(EXCEPT MX)

D905 10EDB40-TB3 R910 ∗

HCD-RG490/RG590

JW906 (AC IN)

0(MX)

R911 0

D901 1SS355TE-17

(E2,E3,E51,EA,MX) (AEP,RU,AR,AUS)

HCD-RG490/RG590 Ver. 1.1

7-36. PRINTED WIRING BOARD – TRANSFORMER Board (RG590) – 2

1

A

3

• See page 27 for Circuit Boards Location.

4

5

6

: Uses unleaded solder.

7

8

9

10

11

12

13

• Semiconductor Location Ref. No. Location C-8 H-11 H-12 H-11 H-12 B-8 C-8 H-10

Q902

B-9

JW911

D906

F909 C910

R904

FH910

FH909

C909

Q902

R903

R910 RY901

D901

D908 R911

CN901 2

C908

R908

TRANSFORMER BOARD

F905

JW927

B

D901 D902 D903 D904 D905 D906 D908 D910

CN905

FH911

FH912

5

1

C JW901

M2 POWER BOARD CN442

F904

(AC IN)

FH907 JW921

PT901 MAIN POWER TRANSFORMER 8

JW922

D

(Page 48)

1

FH908

(AEP, UK, RU, MX, AR)

JW924 F908 FH916

FH915

JW929

JW902

JW926

JW920

JW912

CN907

F906

E

1

7

JW934

(E2, E3, E51, EA)

S901 VOLTAGE SELECTOR

FH918

FH917 (EXCEPT MX)

JW923

K2

230 – 240V T 220V t120V (E2, E3, E51, EA, MX)

MAIN BOARD CN001

(AEP, UK, RU, AR)

(Page 36)

F907

(AEP, UK, RU, AR) JW908

FH913

FH914

K4

JW903

(E2, E3, E51, EA, MX) JW909

(Page 40)

JW930

(MX)

MAIN BOARD CN001

JW904

JW906

JW905

F

(MX)

11 (AEP, UK, RU, AR)

C911

4

JW917

1

G (AEP, UK, RU, MX, AR)

∗

JW910

C914

D905

∗ NOT REPLACEABLE:

D903

1

D902

PT902 SUB POWER TRANSFORMER

D904

JW928

JW925 C907

BUILT IN TRANSFORMER R914

H

K 11

D910 A 9

5

19

I

HCD-RG490/RG590

60

60

A

1-868-913-

(11)

HCD-RG490/RG590 Ver. 1.1

7-37. SCHEMATIC DIAGRAM – TRANSFORMER Board (RG590) –

PT901 MAIN POWER F908 T8AL 250V

TRANSFORMER

F904 T6.3AL 250V

CN905 5P AC-VH AC-VL GND

F905 T6.3AL 250V

AC-VL AC-VH

(Page 49)

F909 T8AL 250V C907 0.1 F906 T3.15AL 250V

W901

240V (E2,E3,E51,EA)

220V

JW902 120V

(CHASSIS)

CN907 11P

JW909 (E2,E3,E51,EA)

C908 220 63V

AC3 (EXCEPT MX)

(E2,E3,E51,EA,MX)

AEP,UK,RU,

F907 T3.15AL 250V

AC3

S901

MX,AR

VOLTAGE D910 MC2838

AC4

SELECTOR

R914 10k

VF

R908 1

VF

STBY-RELAY

C914 1000p

JW917

D906 UDZW-TE17 -27B

R903 10k

C911 1000 25V

C909 10 50V

HCD-RG490/RG590

61

(MX)

∗R910

JW905

D905 10EDB40-TB3 R911 0

22(EXCEPT MX)

D901 1SS355TE-17

CN901 2P

JW906 (AC IN)

0(MX)

R910 ∗

61

JW903 JW904

D904 10EDB40-TB3

BUILT IN TRANSFORMER

R904 1k

230-240V

D902 10EDB40-TB3

∗NOT REPLACEABLE:

-VFL (MX)

C910 100 50V

220V

D903 10EDB40-TB3

REGULATOR

120V RY901

TRANSFORMER

-27V

A

JW925

SUB POWER

Q902 2SB1238PQR -TV2

EVER +10V

PT902

D908 10EDB40-TB3

D-GND

(Page 43)

JW910

JW912

AC4

(Page 39)

JW901

(AEP,UK,RU,AR) JW908

(E2,E3,E51,EA,MX) (AEP,UK,RU,AR)

HCD-RG490/RG590

CH3FIN

CH3RIN

GND

MUTE

POWVCC

CH3OUTF

CH3OUTR

CH4OUTF

CH4OUTR

THERMAL PROTECTION

CH4IN

VIN 1

CH4CAPA

IC251 BA5947FM-E2 OUTVREF

IC203 BH18LB1WG-TR

OPOUT

– BD Board –

PREVCC

• IC Block Diagrams – CD Board –

28

27

26

25

24

23

22

21

20

19

18

17

16

15

OVER CURRENT PROTECTION

GND 2

VOLTAGE REFERENCE

STBY 3

CONTROL BLOCK

MUTING

D

D

D

D

– + 5 VOUT

+ – INTERFACE

4 NC

LEVEL SHIFT

INTERFACE INTERFACE

15

MUTING

D

D

D

D

1 2

3

4

5

6

7

8

9

10

11

12

13

14

CH1OUTF

CH4OUTR

16

CH1OUTR

CH4OUTF

17

CH2OUTF

CH3OUTR

18

+ – INTERFACE

IC303 BH15FB1WG

LEVEL SHIFT

INTERFACE VIN 1 THERMAL PROTECTION

INTERFACE

OVER CURRENT PROTECTION

+ – D

VREF

D

D

D GND 2

VOLTAGE REFERENCE

STBY 3

CONTROL BLOCK

– + 5 VOUT

14 CH1OUTF

13 CH1OUTR

12 CH2OUTF

11 CH2OUTR

10 POWVCC

9 VREFIN

8 GND

7 CH2RIN

6 CH2FIN

5 CH1RIN

4 CH1FIN

3 SW

OPIN– OPIN+

1 2

HCD-RG490/RG590

62

62

D

CH2OUTR

CH3OUTF

19

D

POWVCC

POWVCC

20

D

VREFIN

MUTE

21

D

GND

GND

22

CH2RIN

CH3RIN

23

CH2FIN

CH3FIN

24

CH1RIN

CH4IN

25

CH1FIN

CH4CAPA

26

SW

OUTVREF

27

VREF

OPIN– OPIN+

OPOUT

28

+ –

PREVCC

IC402 BA5947FM-E2

4 NC

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

SBSY/ BCKIB

SFSY/ LRCKIB

TXO

VDD

CKI/CLCK/ IRQ/FI0

VSS

PIO0/ SDI2/IO0

PIO1/ SDI3/IO1

PIO2/ IO2

PIO3/ IO3

BUS3/FI1/ PIO4/IO4

BUS2/FI2/ PIO5/IO5

BUS1/FI3/ PIO6/IO6

BUS0/ PIO7/IO7

SDO1//WE

LRCKO 13 BCKO 12

BCKIA 15 SDI0 14 AX

Interrupt Control CRAM 4k word

/MICK 7 ERAM 4k word x1 2k word x1

MX

A0

YRAM 4k word

MIDIO 6

Timer

DIT JTAG I/F

CROM 4k word x9

MY

MAC

XO/X1/X2 Y0/Y1/Y2

A1

MZ

VDDT 9

X-Pointer

AY

ALU

A2

XRAM 4k word

X-Bus

Y-Bus

Program Control

SRAM I/F

1k bit SRAM

/RESET 2

SRAM/DRAM I/F

PROM 4k word x5

PRAM 4k word

40 bit

Timing Generator

CDP Control I/F

SDO0 11 A3

/MIACK/ 8 AD16 round & limit

STANDBY 3 Instruction Decoder

1

Address Calc. 2sets

Y-Pointer

VSS 10

round & limit

MCU I/F

/MILP 5

C-Pointer

Audio I/F

VDDP

DATA/ SDI1

VCOI

VSSP MIMD TEST VSSX XI XO VDDX CKO/ PO13/ AD16 VDD VSS PO0/ AD0 PO1/ AD1 PO2/ AD2 PO3/ AD3 PO4/ AD4

HCD-RG490/RG590

IC301 TC94A34FG-002

64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49

VCO 48 PO5/AD5

/MICS 4

Bus Switch

Flag

General Input/ Output Port

LRCKIA 16 47 PO6/AD6

46 PO7AD7

45 AD8

44 AD9

43 AD10

42 VDDT

41 SRMSTB

40 VDDM

39 PO8/AD11

38 PO9/AD12

/CCE/ 37 PO10/ AD13

BUCK/ 36 PO11/ AD14

SDO3/ 35 /OE

PO12/ 34 AD15/ /CAS

SDO2/ 33 /CS/ /RAS

Sub Code I/F

63

HCD-RG490/RG590

– DRIVER Board – IC701, 712 BA6956AN

TSD

4

5

6

7

8

9

VM

VCC

FIN

GND

RIN

OUT2

3

OUT1

2

RNF

1 VREF

CONTROL LOGIC

– MAIN Board –

INB1 INC1 IND1

REC1

BASS1

BASS21

TRE1

MID11

MID21

TONEOUT1

IC101 R2S15207FP

30 29 28

27

26

25

24

23

22

21

TONE CONTROL (BASS, TREBLE, MID) RECOUT

TONE ON/OFF

VOCALCUT ON/OFF

20 VOLIN1

INA1 31 VOLUME INPUT SELECTOR GND 32

+

19 BB11 18 BB21

TONE ATT

BASSBOOST ON/OFF REFIN 33 17 OUT1

REF SURROUND VOCAL CUT

SUR1 34 SUR2 35

+

MCU INTERFACE

MONO/STEREO

16 DATA 15 CLOCK 14 OUT2

MIX1 36 MIX2 37

BASSBOOST ON/OFF

TONE ATT

+

13 BB22 12 BB12

VCC 38 INPUT SELECTOR VOLUME

INA2 39 INB2 40 RECOUT

11 VOLIN2

VOCALCUT ON/OFF

64

1 2

3

4

5

6

7

8

9

10

INC2 IND2

REC2

SAOUT

BASS12

BASS22

TRE2

MID12

MID22

TONEOUT2

TONE CONTROL (BASS, TREBLE, MID)

TONE ON/OFF

HCD-RG490/RG590

IC102 R2S15208SP

REFIN 1

REF AMP

LIN 2

10 REFOUT

9 LOUT

3BAND PARAMETRIC EQUALIZER

RIN 3

8 ROUT 7 GND

VCC 4 MCU INTERFACE

DATA 5

6 CLOCK

– MIC. AUX. HP Board –

NC

VCC

CLOCK

REF

OP2IN

OP2OUT

LPF2IN

LPF2OUT

IC802 M65850FP-E1

16

15

14

13

12

11 10

9

OSCILLATOR

D/A

LPF2

1/2 VCC DO1

CLOCK AUTO RESET

RESET

MAIN CONTROL D1 DO0

MO

20KBIT SRAM

MI

A/D

1

2

3

4

5

6

7

8

NC

LPF1IN

LPF1OUT

OP1OUT

OP1IN

CC1

CC2

GND

LPF1

– CD-G Board – IC1005 SN74AHCT04NSR

IC1006 NJM2561F1-TE2

VCC 14

1

13

2

12

3

11

4

10

5

9

6

8

POWER SAVE

1

VOUT

2

VSAG

3

75 OHM DRIVER

LOW- FILTER

6

VCC

5

GND

4

VIN

CLAMP

7 GND

65

HCD-RG490/RG590

• IC Pin Function Description CD BOARD IC201 CXD3014A-201R (CD DSP)

Pin No.

Pin Name

I/O

1

LRCK

O

L/R sampling clock signal output terminal

2

LRCKI

I

L/R sampling clock signal input terminal

3

PCMD

O

Serial data output terminal

4

PCMDI

I

Serial data input terminal

5

BCK

O

Bit clock signal output terminal

6

BCKI

I

Bit clock signal input terminal

7

XTACN

I

Oscillation circuit on/off control signal input from the system controller "L": oscillation stop, "H": self-oscillation

8

XRST

I

System reset signal input from the system controller "L": reset

9

VSS

-

Ground terminal

10

IREQ-MP3

O

MP3 data request signal output to the system controller

11

CD serial data transfer clock signal input from the system controller

66

Description

CLOK

I

12

DATA2

I

MP3 serial data input from the system controller

13

XLAT-MP3

I

MP3 serial data latch pulse signal input from the system controller

14

REQ-MP3

I

MP3 data request signal input from the system controller

15

ACK-MP3

O

MP3 acknowledge signal output to the system controller

16

XLAT

I

CD serial data latch pulse signal input from the system controller

17

VDD

-

Power supply terminal (+1.8V)

18

SVSS

-

Ground terminal

19

SVDD

-

Power supply terminal (+1.8V)

20

SENS

O

Internal status (SENSE) signal output to the system controller

21

WFCK

O

Write frame clock signal output terminal Not used

22

XUGF

O

XUGF signal output terminal Not used

23

XPCK

O

XPCK signal output terminal Not used

24

GFS

O

Guard frame sync signal output terminal Not used

25

C2PO

O

C2 pointer signal output terminal Not used

26

SCOR

O

Subcode sync (S0+S1) detection signal output to the system controller

27

VDD

-

Power supply terminal (+1.8V)

28

COUT

O

Numbers of track counted signal output terminal Not used

29

SVSS

-

Ground terminal

30

SVDD

-

Power supply terminal (+1.8V)

31

MIRR

O

Mirror signal output terminal Not used

32

DFCT

O

Defect signal output terminal Not used

33

FOK

O

Focus OK signal output terminal Not used

34

VSS

-

Ground terminal

35

VDD

-

Power supply terminal (+1.8V)

36

Ground terminal

VSS

-

37

LOCK

O

GFS is sampled by 460 Hz "H" output when GFS is "H" Not used

38

MDP

O

Spindle motor servo control signal output terminal

39

SSTP

I

Disc inner position detection signal input terminal

40

IOVSS1

-

Ground terminal

41

SFDR

O

Sled servo drive signal (+) output terminal

42

SRDR

O

Sled servo drive signal (-) output terminal

43

TFDR

O

Tracking servo drive signal (+) output terminal

44

TRDR

O

Tracking servo drive signal (-) output terminal

45

FFDR

O

Focus servo drive signal (+) output terminal

HCD-RG490/RG590

Pin No.

Pin Name

I/O

46

FRDR

O

47

IOVDD1

-

Power supply terminal (+3.3V)

48

AVDD0

-

Power supply terminal (+3.3V)

49

AVSS0

-

Ground terminal

50

E

I

E signal input from the optical pick-up block

51

F

I

F signal input from the optical pick-up block

52

TEI

I

Tracking error signal input terminal

53

TEO

O

Tracking error signal output terminal

54

FEI

I

Focus error signal input terminal

55

FEO

O

Focus error signal output terminal

56

VC

O

Middle point voltage output terminal

Description Focus servo drive signal (-) output terminal

57

A

I

A signal input from the optical pick-up block

58

B

I

B signal input from the optical pick-up block

59

C

I

C signal input from the optical pick-up block

I

D signal input from the optical pick-up block

60

D

61

AVDD4

-

Power supply terminal (+3.3V)

62

RFDCO

O

RFDC signal output terminal Not used

63

PDSENS

I

Reference voltage input terminal for PD

64

AC_SUM

O

RFAC summing amplifier signal output terminal

65

EQ_IN

I

RF equalizer circuit input terminal

66

LD

O

Laser diode on/off control signal output to the automatic power control circuit "H": laser diode on

67

PD

I

Light amount monitor input from the laser diode of optical pick-up block

68

RFC

I

Equalizer cut off frequency adjustment terminal

69

AVSS4

-

Ground terminal

70

RFACO

O

EFM signal output terminal

71

RFACI

I

EFM signal input terminal

72

AVDD3

-

Power supply terminal (+3.3V)

73

BIAS

I

Asymmetry circuit constant current input terminal

74

ASYI

I

Playback EFM asymmetry comparator voltage input terminal

75

ASYO

O

Playback EFM full-swing output terminal

76

VPCO

O

Charge pump output terminal for broad-band EFM PLL

77

VCTL

I

VCO2 control voltage input terminal for broad-band EFM PLL

78

AVSS3

-

Ground terminal

79

CLTV

I

VCO1 control voltage input terminal for multiplier

80

FILO

O

Filter output terminal for master PLL

81

FILI

I

Filter input terminal for master PLL

82

PCO

O

Charge pump output terminal for master PLL

83

SVSS

-

Ground terminal

84

SVDD

-

Power supply terminal (+1.8V)

85

SSTB-MP3

I

MP3 standby on/off control signal input terminal "L": standby Not used

86

VDD

-

Power supply terminal (+1.8V)

87

VSS

-

Ground terminal

88

TEST1

I

Input terminal for the test Normally: fixed at "L"

89

DATA

I

CD serial data input from the system controller

90

CLK2

I

MP3 serial data transfer clock signal input from the system controller

91

SVSS

-

Ground terminal

67

HCD-RG490/RG590

Pin No.

Pin Name

I/O

92

SVDD

-

Power supply terminal (+2.5V)

93

JTAGTCK

I

Clock signal input terminal (for JTAG) Not used

94

JTAGTDI

I

Data input terminal (for JTAG) Not used

95

JTAGTDO

O

Data output terminal (for JTAG) Not used

96

JTAGTMS

I

Mode select signal input terminal (for JTAG) Not used

97

TRST

I

Reset signal input terminal (for JTAG) Not used

98

VSS

-

Ground terminal

99

VDD

-

Power supply terminal (+1.8V)

100

IOVDD2

-

Power supply terminal (+3.3V)

101

DOUT

O

Digital audio signal output terminal Not used

102

TEST

I

Input terminal for the test Normally: fixed at "L"

103

TES1

I

Input terminal for the test Normally: fixed at "L"

68

Description

104

IOVSS2

-

Ground terminal

105

PLLVDD

-

Power supply terminal (+1.8V)

106

PLLVSS

-

Ground terminal

107

XVSS

-

Ground terminal

108

XTAO

O

System clock output terminal (16.9344 MHz)

109

XTAI

I

System clock input terminal (16.9344 MHz)

110

XVDD

-

Power supply terminal (+1.8V)

111

AVDD1

-

Power supply terminal (+3.3V)

112

AOUT1

O

L-ch analog audio signal output terminal

113

VREFL

O

L-ch reference voltage output terminal

114

AVSS1

-

Ground terminal

115

AVSS2

-

Ground terminal

116

VREFR

O

R-ch reference voltage output terminal

117

AOUT2

O

R-ch analog audio signal output terminal

118

AVDD2

-

Power supply terminal (+3.3V)

119

IOVDD0

-

Power supply terminal (+3.3V)

120

IOVSS0

-

Ground terminal

HCD-RG490/RG590

BD BOARD IC101 CXD3059AR (CD DSP) Pin No.

Pin Name

I/O

1

MIRR

O

Mirror signal output terminal Not used

Description

2

DFCT

O

Defect signal output terminal Not used

3

FOK

O

Focus OK signal output terminal Not used

4

VSS

-

Ground terminal

5

LOCK

O

GFS is sampled by 460 Hz "H" output when GFS is "H" Not used

6

MDP

O

Spindle motor servo control signal output terminal

7

SSTP

I

Disc inner position detection signal input terminal

8

IOVSS0

-

Ground terminal

9

SFDR

O

Sled servo drive signal (+) output terminal

10

SRDR

O

Sled servo drive signal (-) output terminal

11

TFDR

O

Tracking servo drive signal (+) output terminal

12

TRDR

O

Tracking servo drive signal (-) output terminal

13

FFDR

O

Focus servo drive signal (+) output terminal

14

FRDR

O

Focus servo drive signal (-) output terminal

15

IOVDD1

-

Power supply terminal (+3.3V)

16

AVDD0

-

Power supply terminal (+3.3V)

17

AVSS0

-

Ground terminal

18

NC

-

Not used

19

E

I

E signal input from the optical pick-up block

20

F

I

F signal input from the optical pick-up block

21

TEI

I

Tracking error signal input terminal

22

TEO

O

Tracking error signal output terminal

23

FEI

I

Focus error signal input terminal

24

FEO

O

Focus error signal output terminal

25

VC

O

Middle point voltage output terminal

26

A

I

A signal input from the optical pick-up block

27

B

I

B signal input from the optical pick-up block

28

C

I

C signal input from the optical pick-up block

29

D

I

D signal input from the optical pick-up block

30

NC

-

Not used

31

AVDD4

-

Power supply terminal (+3.3V)

32

RFDCO

O

RFDC signal output terminal Not used

33

PDSENS

I

Reference voltage input terminal for PD

34

AC_SUM

O

RFAC summing amplifier signal output terminal

35

EQ_IN

I

RF equalizer circuit input terminal

36

LD

O

Laser diode on/off control signal output to the automatic power control circuit "H": laser diode on

37

PD

I

Light amount monitor input from the laser diode of optical pick-up block

38

NC

-

Not used

39

RFC

I

Equalizer cut off frequency adjustment terminal

40

AVSS4

-

Ground terminal

41

RFACO

O

EFM signal output terminal

42

RFACI

I

EFM signal input terminal

43

AVDD3

-

Power supply terminal (+3.3V)

44

BIAS

I

Asymmetry circuit constant current input terminal

45

ASYI

I

Playback EFM asymmetry comparator voltage input terminal

69

HCD-RG490/RG590

Pin No.

Pin Name

I/O

46

ASYO

O

Playback EFM full-swing output terminal

47

VPCO

O

Charge pump output terminal for broad-band EFM PLL

48

VCTL

I

VCO2 control voltage input terminal for broad-band EFM PLL

49

AVSS3

-

Ground terminal

50

CLTV

I

VCO1 control voltage input terminal for multiplier

51

FILO

O

Filter output terminal for master PLL

52

FILI

I

Filter input terminal for master PLL

53

PCO

O

Charge pump output terminal for master PLL

70

Description

54

AVDD5

-

Power supply terminal (+3.3V)

55

DDVROUT

O

DC/DC converter output terminal

56

DDVRSEN

O

DC/DC converter output voltage monitor input terminal

57

AVSS5

-

Ground terminal

58

DDCR

I

Input terminal for the test

59

NC

-

B signal input from the optical pick-up block

60

BCKI

I

Bit clock signal input terminal

61

PCMDI

I

Serial data input from the MP3 decoder

62

LRCKI

I

L/R sampling clock signal input terminal

63

LRCK

O

L/R sampling clock signal output terminal

64

VSS

-

Ground terminal

65

PCMD

O

Serial data output to the MP3 decoder

66

BCK

O

Bit clock signal output terminal

67

VDD

-

Power supply terminal (+3.3V)

68

EMPH

O

"L" is output when playback disc is emphasis off "H" is output when playback disc is emphasis on Not used

69

EMPHI

O

"L" is input when de-emphasis is off

70

IOVDD2

-

Power supply terminal (+3.3V)

71

DOUT

O

Digital audio signal output terminal

72

TEST

I

Input terminal for the test

Normally: fixed at "L" Normally: fixed at "L"

Normally: fixed at "L"

"H" is output when de-emphasis is on Not used

73

TEST1

I

Input terminal for the test

74

IOVSS2

-

Ground terminal

75

NC

-

Not used

76

XVSS

-

Ground terminal

77

XTAO

O

System clock output terminal (16.9344 MHz)

78

XTAI

I

System clock input terminal (16.9344 MHz)

79

XVDD

-

Power supply terminal (+1.8V)

80

AVDD1

-

Power supply terminal (+3.3V)

81

AOUT1

O

L-ch analog audio signal output terminal

82

VREFL

O

L-ch reference voltage output terminal

83

AVSS1

-

Ground terminal

84

AVSS2

-

Ground terminal

85

VREFR

O

R-ch reference voltage output terminal

86

AOUT2

O

R-ch analog audio signal output terminal

87

AVDD2

-

Power supply terminal (+3.3V)

88

NC

-

B signal input from the optical pick-up block

89

IOVDD0

-

Power supply terminal (+3.3V)

90

RMUT

O

Muting control signal (for R-ch) output terminal

Not used

91

LMUT

O

Muting control signal (for L-ch) output terminal

Not used

92

NC

-

B signal input from the optical pick-up block

Not used

HCD-RG490/RG590

Pin No.

Pin Name

I/O

Description

93

XTSL

I

Input terminal for the system clock frequency setting "L": 16.9344 MHz, "H": 33.8688MHz Fixed at "L" in this set

94

IOVSS0

-

Ground terminal

95

XTACN

I

Oscillation circuit on/off control signal input from the system controller "L": oscillation stop, "H": self-oscillation

96

SQSO

O

Subcode Q data output terminal Not used

97

SQCK

I

Subcode Q data reading clock signal input terminal Not used

98

SBSO

O

Subcode serial data output to the CD graphic decoder

99

EXCK

I

Subcode serial data reading clock signal input from the CD graphic decoder

100

XRST

I

System reset signal input from the system controller "L": reset

101

SYSM

I

System muting on/off control signal input terminal "H": muting on Fixed at "L" in this set

102

DATA

O

CD serial data input from the system controller

103

VSS

-

Ground terminal

104

XLAT

I

CD serial data latch pulse signal input from the system controller

105

CLOCK

I

CD serial data transfer clock signal input from the system controller

106

VDD

-

Power supply terminal (+3.3V)

107

SENS

O

Internal status (SENSE) signal output to the system controller

108

SCLK

I

SENSE serial data reading clock signal input terminal Not used

109

ATSK

O

Output terminal for anti-shock Not used

110

WFCK

O

Write frame clock signal output to the CD graphic decoder

111

XUGF

O

XUGF signal output terminal Not used

112

XPCK

O

XPCK signal output terminal Not used

113

GFS

O

Guard frame sync signal output terminal Not used

114

C2PO

O

C2 pointer signal output terminal Not used

115

SCOR

O

Subcode sync (S0+S1) detection signal output to the system controller and CD graphic decoder

116

VDD

-

Power supply terminal (+3.3V)

117

C4M

O

4.2336 MHz clock signal output terminal Not used

118

WDCK

O

Guard subcode sync (S0+S1) detection signal output terminal Not used

119

COUT

O

Numbers of track counted signal output to terminal Not used

120

NC

-

Not used

71

HCD-RG490/RG590

MAIN BOARD IC901 uPD78F0547GC (S)-UBT-A (SYSTEM CONTROLLER) Pin No.

Pin Name

1

I-AC-PULSE

I

AC power detection signal input terminal

2

O-REC/PB

O

Recording/playback selection signal output terminal "L": playback, "H": recording

3

O-REC-MUTE

O

Recording muting on/off control signal output terminal "L": muting on

72

I/O

Description

4

O-BIAS

O

Recording bias on/off control signal output terminal "H": bias on

5

O-STK-MUTE

O

Standby signal output to the power amplifier (for front speaker)

6

O-SW_GAIN

O

Sub woofer gain control signal output terminal Not used

7

O-POWER-RELAY

O

Power on/off relay drive signal output terminal "H": power on

8

O-XM-POWER3.3

O

Power on/off control signal output terminal for XM section Not used

9

I-AC-CUT

I

AC power off detection signal input terminal

10

I-XRESET

I

System reset signal input from the reset signal generator "L": reset For several hundreds msec. after the power supply rises, "L" is input, then it changes to "H"

11

XT2 (32.768KHZ)

O

Sub system clock output terminal (32.768 kHz)

12

XT1 (32.768KHZ)

I

Sub system clock input terminal (32.768 kHz)

13

FLMDO

I

Internal flash memory data writing mode control signal input terminal

14

X2 (16MHZ)

O

Main system clock output terminal (16 MHz)

15

X1 (16MHZ)

I

Main system clock input terminal (16 MHz)

16

REGC

-

External capacitor connection terminal for regulator

17

VSS

-

Ground terminal

18

EVSS

-

Ground terminal

19

VDD

-

Power supply terminal (+3.3V)

20

EVDD

-

Power supply terminal (+3.3V)

21

O-SYS-MUTE

O

Muting on/off control signal output terminal "L": muting on

22

O-SWR

O

Sub woofer speaker on/off relay drive signal output terminal "L": sub woofer speaker on

23

O-FRONT-SPRELAY

O

Front speaker on/off relay drive signal output terminal "H": front speaker on

24

O-XTCN

O

Oscillation circuit on/off control signal output to the CD DSP "L": oscillation stop, "H": self-oscillation

25

O-MP3-RST

O

System reset signal output to the MP3 decoder "L": reset (RG490: Mexican/RG590: Mexican models)

26

O-MP3-XLAT/ O-MP3-CS

O

MP3 serial data latch pulse signal output to the CD DSP (Except RG490: Mexican/RG590: Mexican models) MP3 chip select signal output to the MP3 decoder (RG490: Mexican/RG590: Mexican models)

27

I-MP3-ACK

I

MP3 acknowledge signal input from the CD DSP (Except RG490: Mexican/RG590: Mexican models) MP3 acknowledge signal input from the MP3 decoder (RG490: Mexican/RG590: Mexican models)

28

O-XLAT/ O-MP3-STB

O

CD serial data latch pulse signal output to the CD DSP (Except RG490: Mexican/RG590: Mexican models) Standby signal output to the MP3 decoder (RG490: Mexican/RG590: Mexican models)

I

MP3 data request signal input from the CD DSP (Except RG490: Mexican/RG590: Mexican models) MP3 data request signal input from the MP3 decoder (RG490: Mexican/RG590: Mexican models)

O

MP3 data request signal output to the CD DSP (Except RG490: Mexican/RG590: Mexican models) MP3 serial data latch pulse signal output to the MP3 decoder (RG490: Mexican/RG590: Mexican models)

29

I-MP3-REQ

30

O-MP3-CS/ O-MP3-LP

HCD-RG490/RG590 Ver. 1.1

Pin No.

Pin Name

31

O-D-MUTE/ O-XLT

I/O

Description

O

System reset signal output to the motor/coil driver "L": reset (Except RG490: Mexican/RG590: Mexican models) CD serial data latch pulse signal output to the CD DSP (RG490: Mexican/RG590: Mexican models)

32

O-XRST

O

System reset signal output to the CD DSP "L": reset (Except RG490: Mexican/RG590: Mexican models) System reset signal output to the CD DSP and motor/coil driver "L": reset (RG490: Mexican/RG590: Mexican models)

33

O-LM-R

O

Loading motor control signal output terminal (reverse direction)

34

O-LM-F

O

Loading motor control signal output terminal (forward direction)

35

O-TM-R

O

Table motor control signal output terminal (reverse direction)

36

O-TM-F

O

Table motor control signal output terminal (forward direction)

37

I-CD-NUMBERSENS

I

Disc table address sensor input terminal

38

I-OPEN-SW

I

Disc table open/close detection switch input terminal "L": open, "H": close

39

I-XTUNED

I

Tuning detection signal input terminal Not used

40

I-SCOR

I

Subcode sync (S0+S1) detection signal input from the CD DSP

41

O-CDG-RST/ I-RDS-CLK

I/O

System reset signal output to the CD graphics decoder "L": reset (RG490: Mexican/RG590: Mexican models) RDS data transfer clock signal input from the tuner (FM/AM) (RG490: AEP/RG590: AEP, UK models)

42

O-LC23003-CE

O

Chip enable signal output to the tuner (FM/AM)

43

O-LC23003-DO

O

Serial data output to the tuner (FM/AM)

44

O-LC23003-CLK

O

Serial data transfer clock signal output to the tuner (FM/AM)

45

I-LC23003-DI

I

Serial data input from the tuner (FM/AM)

46

O-VMUTE

O

Video muting on/off control signal output terminal "H": muting on (RG490: Mexican/RG590: Mexican models)

47

O-CDG -POWER

O

Power on/off control signal output terminal for CD-G section "H": power on (RG490: Mexican/RG590: Mexican models)

48

I-CDG-DET

I

CD-G detection signal input from the CD graphics decoder

49

O-CDG-MUTEDATA/ I-RDS-DATA

I/O

Muting control signal output to the CD graphics decoder (RG490: Mexican/RG590: Mexican models) RDS data input from the tuner (FM/AM) (RG490: AEP/RG590: AEP, UK models)

50

I-XM-RXD

I

Receive data input terminal Not used

51

O-XM-TXD

O

Transmit data output terminal Not used

52

O-CD-DATA

O

CD serial data output to the CD DSP

53

I-CD-SENS

I

Internal status (SENSE) signal input from the CD DSP

54

O-CD-CLK

O

CD serial data transfer clock signal output to the CD DSP

55

I-MIC-DET

I

Microphone plug insert detection signal input terminal "L": microphone plug insert ( RG490: 120V AC area in E, Chilean, Peruvian, Mexican, Argentina/RG590: 120V AC area in E, Chilean, Peruvian, Mexican, Argentina models)

56

O-R2S15208SPDATA

O

Serial data output to the parametric equalizer (RG590: 120V AC area in E, 240V AC area in E, Chilean, Peruvian, Saudi Arabia, Mexican, Argentina models)

57

O-AUDIO-CLK

O

Serial data transfer clock signal output to the electrical volume and parametric equalizer (RG590: 120V AC area in E, 240V AC area in E, Chilean, Peruvian, Saudi Arabia, Mexican, Argentina models) Serial data transfer clock signal output to the electrical volume (RG490/RG590: AEP, UK Russian models)

58

O-R2S15207FPDATA

O

Serial data output to the electrical volume

73

HCD-RG490/RG590

Pin No.

Pin Name

I/O

59

AVREF

I

60

AVSS

-

Ground terminal

74

Description Reference voltage (+3.3V) input terminal

61

I-HP/AUDIO IN

I

Headphone plug and audio in plug insert detection signal input terminal "L": headphone plug or audio in plug insert

62

I-SUFFIX

I

Setting terminal for the model and destination

63

I-VACS

I

VACS signal input terminal (A/D input)

64

I-PROTECTOR

I

Protector detection signal input terminal

65

I-KEY0

I

Front key input terminal (A/D input)

66

I-CD-ENCODER

I

Disc table address sensor (rotary encoder) input terminal

67

I-MODEL

I

Setting terminal for the model and destination

68

I-STREAM

I

Audio signal input for stream LED (A/D input)

69

O-STBY-LED

O

LED drive signal output terminal for STANDBY indicator "H": LED on

70

O-MP3-CLK

O

MP3 serial data transfer clock signal output to the CD DSP (Except RG490: Mexican/RG590: Mexican models) MP3 serial data transfer clock signal output to the MP3 decoder (RG490: Mexican/RG590: Mexican models)

71

I-MP3-DATA

I

MP3 serial data input terminal (Except RG490: Mexican/RG590: Mexican models) MP3 serial data input from the MP3 decoder (RG490: Mexican/RG590: Mexican models)

72

O-MP3-DATA

O

MP3 serial data output to the CD DSP (Except RG490: Mexican/RG590: Mexican models) MP3 serial data input from the MP3 decoder (RG490: Mexican/RG590: Mexican models)

73

I-TCM-SYNC

I

Sync signal input from the tape mechanism deck controller

74

O-VFD-RESET

O

System reset signal output to the fluorescent indicator tube/LED driver "L": reset

75

O-VFD-CE

O

Chip enable signal output to the fluorescent indicator tube/LED driver

76

O-VFD-DATA

O

Serial data output to the fluorescent indicator tube/LED driver

77

I-VFD-DATA

I

Serial data input from the fluorescent indicator tube/LED driver

78

O-VFD-CLK

O

Serial data transfer clock signal output to the fluorescent indicator tube/LED driver

79

I-WAKEUP

I

Wake up signal input terminal

80

I-XSIRCS-IN

I

SIRCS signal input from the remote control receiver

HCD-RG490/RG590

CD-G BOARD IC1001 TC9411AFG (BS, K) (CD GRAPHICS DECODER) Pin No.

Pin Name

I/O

1

SESUB

I

Not used

2

CLCK

O

Subcode serial data reading clock signal output to the CD DSP

3

DATA

I

Subcode serial data input from the CD DSP

4

SBSY

I

Subcode sync (S0+S1) detection signal input from the CD DSP

5

SFSY

I

Write frame clock signal input from the CD DSP

6

MUTE

I

Muting control signal input from the system controller

7

VDD1

-

Power supply terminal (+5V)

8

VSS1

-

Ground terminal

9

MCE

I

Chip enable signal input terminal

10

Description

Not used

MCDO

O

Serial data output terminal

11

Not used

MCDI

I

Serial data input terminal

12

MCCK

I

Serial data transfer clock signal input terminal

13

XWE

O

Write enable signal output to the D-RAM

Not used

14

XRAS

O

Row address strobe signal output to the D-RAM

15 to 22

VA0 to VA7

O

Address signal output to the D-RAM

23

VSS2

-

Ground terminal

24

Power supply terminal (+5V)

Not used

VDD2

-

25

VD0

I/O

Two-way data bus with the D-RAM

26

XCAS

O

Column address strobe signal output to the D-RAM

27

VD1

I/O

Two-way data bus with the D-RAM

28

XOE

O

Output enable signal output to the D-RAM

29, 30

VD2, VD3

I/O

Two-way data bus with the D-RAM

31

BLANKIN

I

Blanking signal input terminal

Not used

32

BIN

I

RGB (B) signal input terminal

Not used

33

GIN

I

RGB (G) signal input terminal

Not used

34

RIN

I

RGB (R) signal input terminal

Not used

35

XHSYNC

O

Horizontal synchronize signal output terminal

36

XVSYNC

O

Vertical synchronize signal output terminal

37

GDET

O

CD-G detection signal output to the systerm controller

38

VON

I

Video on control signal input terminal

39, 40

TEST1, TEST2

I

Test mode setting terminal

41

LINESW

I

Line switch input terminal

42

VREF

I

Reference voltage input terminal

43

AVDD

-

Power supply terminal (+5V)

44

VDOUT

O

Video signal output terminal

Not used

Not used

Not used

Not used

45

AVSS

-

Ground terminal

46, 47

BIAS1, BIAS2

I

Bias setting terminal

48

VSS3

-

Ground terminal

49

VDD3

-

Power supply terminal (+5V)

50

QNG

O

Not used

51

PNG

O

Not used

52

NTSC/PAL selection signal input terminal

DEN

I

53

FSC

O

Not used

54

XRESET

I

System reset signal input from the system controller

55

SENTSC

I

Not used

56

PDOWN

I

Power down signal input terminal

"L": reset

Not used

75

HCD-RG490/RG590

Pin No.

Pin Name

I/O

57

XI2

I

System clock input terminal (17.734475 MHz) (for PAL) Not used

58

XO2

O

System clock output terminal (17.734475 MHz) (for PAL) Not used

59

XI1

I

System clock input terminal (14.31818 MHz) (for NTSC)

60

XO1

O

System clock output terminal (14.31818 MHz) (for NTSC)

76

Description

HCD-RG490/RG590

BOARD IC701 uPD780232GC-509-8BT-A (FLUORESCENT INDICATOR TUBE/LED DRIVER, TAPE MECHANISM DECK CONTROLLER) Pin No.

Pin Name

I/O

1

VDD1

-

Description Power supply terminal (+3.3V)

2

VSS1

-

Ground terminal

3

X1

I

System clock input terminal (4.19 MHz)

4

X2

O

System clock output terminal (4.19 MHz)

5

IC

I

Input terminal for the IC test Normally: fixed at "L"

6

XRESET

I

System reset signal input from the system controller "L": reset

7

SCK1

I

Serial data transfer clock signal input from the system controller

8

SI1

I

Serial data input from the system controller

9

SO1

O

Serial data output to the system controller

10

I-VOL A

I

Jog dial pulse input from the rotary encoder (VOLUME) (A phase input)

11

I-VOL B

I

Jog dial pulse input from the rotary encoder (VOLUME) (B phase input)

12

I-JOG A

I

Jog dial pulse input from the rotary encoder (multi jog) (A phase input)

13

I-JOG A

I

Jog dial pulse input from the rotary encoder (multi jog) (B phase input)

14, 15

NC

I

Not used

16

CE

I

Chip select signal input from the system controller

17

I-MODEL

I

Destination setting terminal

18

AVSS

-

Ground terminal

19 to 22

KEY1 to KEY4

I

Front key input terminal (A/D input)

23

VSS0

-

Ground terminal

24

AVDD

-

Power supply terminal (+5V)

25

VDD0

-

Power supply terminal (+5V)

26

NC

I

Not used

27

I-HALF-B

I

Deck-B cassette detection signal input from the tape mechanism deck block "L": cassette in

28

I-REEL-B

I

Deck-B tape reel rotating detection signal input from the tape mechanism deck block

29

I-REC-SW

I

Recording-proof detection signal input from the tape mechanism deck block "L": recording possible

30

I-HALF-A

I

Deck-A cassette detection signal input from the tape mechanism deck block "L": cassette in

31

I-REEL-A

I

Deck-A tape reel rotating detection signal input from the tape mechanism deck block

32

NC

I

Not used

33

O-MOTOR

O

Capstan/reel motor drive signal output terminal "H": motor on

34

O-SOL-A

O

Deck-A side trigger plunger drive signal output terminal "H": plunger on

35

O-SOL-B

O

Deck-B side trigger plunger drive signal output terminal "H": plunger on

36

O-TCM-SYNC

O

Sync signal output to the system controller

37

SW LED

O

LED rive signal output of the SUBWOOFER indicator "H": LED on

38

NC

I

Not used

39 to 43

STREAM LED1 to STREAM LED5

O

LED rive signal output of the stream indicator "H": LED on

44

NC

I

Not used

45 to 58

S1 to S14

O

Segment drive signal output to the fluorescent indicator tube

59

VDD2

-

Power supply terminal (+5V)

60

VLOD

-

Power supply terminal (-27V)

61 to 67

S15 to S21

O

Segment drive signal output to the fluorescent indicator tube

68 to 80

G13 to G11

O

Grid drive signal output to the fluorescent indicator tube

77

HCD-RG490/RG590 Ver. 1.1

SECTION 8 EXPLODED VIEWS

NOTE: • Items marked “*” are not stocked since they • -XX and -X mean standardized parts, so they are seldom required for routine service. Some may have some difference from the original delay should be anticipated when ordering one. these items. • Color Indication of Appearance Parts • The mechanical parts with no reference Example: number in the exploded views are not supplied. KNOB, BALANCE (WHITE) . . . (RED) • Accessories are given in the last of the ↑ ↑ electrical parts list. Parts Color Cabinet's Color • Abbreviation AR : Argentina model E3 : 240V AC area in E model MX : Mexican model AUS : Australian model E51 : Chilean and Peruvian models RU : Russian model E2 : 120V AC area in E model EA : Saudi Arabia model

8-1.

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified.

CASE SECTION

8

(RG490: MX/RG590: MX)

4 7 CD mechanism deck section-1

5

6

3

4 10

2

#1

#1

6

MAIN board section #1

2

1 2 4 #1 board section

9 2 #1

Ref. No. 1 1 1 1

Part No.

Description

Remark

1

LID (CD) (RG590: E2, E51, AR) LID (CD) (RG590: E3, EA) LID (CD) (RG490: E2, E51, AR) LID (CD) (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU) 2-658-299-41 LID (CD) (RG490: MX)

1 2 3 4

2-658-299-51 3-363-099-32 2-599-855-11 3-254-143-11

78

2-658-299-01 2-658-299-11 2-658-299-21 2-658-299-31

LID (CD) (RG590: MX) SCREW (CASE 3 TP2) CASE (SIDE-L) SCREW (B3), (+) BV TAPPING

Ref. No.

Part No.

Description

Remark

5

1-832-838-21 CABLE, FLEXIBLE FLAT (13 CORE) (RG490: MX/RG590: MX)

6 7 8 9 10

4-951-620-01 SCREW (2.6X8), +BVTP A-1159-964-A CD-G BOARD, COMPLETE (RG490: MX/RG590: MX) 2-599-854-11 CASE (TOP) 2-599-856-11 CASE (SIDE-R) 2-675-793-01 COVER (OP)

#1

7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S

HCD-RG490/RG590 Ver. 1.1

8-2.

BOARD SECTION 55 54 55 63 53

55 56

(RG490/RG590: AEP, UK, RU)

66

55

65

57

55

61 62

58 53 (RG490/RG590: AEP, UK, RU) lid (top) section

60 59

52

51

64 Ref. No. 51 51 52 53 54

54 54 54 55 56

57 58 59 59

Part No.

Description

2-658-294-01 2-658-294-11 2-658-292-01 2-658-279-01 A-1159-677-A

KNOB (JOG) (RG590: E2, E3, E51, EA, MX, AR) KNOB (JOG) (RG490/RG590: AEP, UK, RU) KNOB (VOL A) INDICATOR (POWER) KEY LEFT BOARD, COMPLETE (RG490: AEP, RU, E2, E3, E51, EA, AR, AUS/ RG590: AEP, UK, RU)

Remark

A-1159-678-A KEY LEFT BOARD, COMPLETE (RG590: E2, E3, E51, EA, AR) A-1159-679-A KEY LEFT BOARD, COMPLETE (RG590: MX) A-1163-183-A KEY LEFT BOARD, COMPLETE (RG490: MX) 4-951-620-01 SCREW (2.6X8), +BVTP 2-658-275-01 KEY (POWER) (I/1, CD, TUNER/BAND, TAPE A/B, AUDIO IN) 2-658-274-01 KEY (REC) 2-658-276-01 KEY (CD) (DISC 1, DISC 2, DISC 3, DISC SKIP/EX-CHANGE, A) 2-658-281-01 KEY (JOG) (GROOVE, SURROUND, ENTER, EQ BAND) (RG490/RG590: AEP, UK, RU) 2-658-281-11 KEY (JOG) (REPEAT, ENTER, SLEEP, PLAY MODE/TUNING MODE) (RG590: E2, E3, E51, EA, MX, AR)

Ref. No.

Part No.

Description

Remark

60

A-1159-681-A KEY RIGHT BOARD, COMPLETE (EXCEPT RG490: MX/RG590: MX)

60

A-1159-682-A KEY RIGHT BOARD, COMPLETE (RG490: MX/RG590: MX) 1-831-952-21 CABLE, FLEXIBLE FLAT (19 CORE) 1-831-779-21 CABLE, FLEXIBLE FLAT (11 CORE) A-1159-666-A BOARD, COMPLETE (RG490: AEP, RU, E2, E3, E51, EA, AR, AUS/ RG590: AEP, UK, RU) A-1159-667-A BOARD, COMPLETE (RG590: E2, E3, E51, EA, AR)

61 62 63

63

63 63 64 65 66

A-1159-668-A A-1163-174-A 4-225-252-01 2-658-277-01

BOARD, COMPLETE (RG590: MX) BOARD, COMPLETE (RG490: MX) CUSHION (FOOT) RING (SUB WOOFER) (RG490/RG590: AEP, UK, RU) 2-658-278-01 KEY (SUB WOOFER) (RG490/RG590: AEP, UK, RU)

79

HCD-RG490/RG590 Ver. 1.1

8-3.

LID (TOP) SECTION

(RG490/RG590: AEP, UK, RU)

(RG590: E2, E3, E51, EA, MX, AR)

110

108

108

not supplied

108

107 112 111

109

108

108 not supplied

108 #1

not supplied

106

104

front section

101

Ref. No. 101 102 102 103 104

105 106 106 106 106

80

Part No.

103

105

102

Description

Remark

2-658-285-03 REFLECTOR (VOL) X-2109-226-1 RING (VOL) ASSY (SERVICE) (RG590: E2, E3, E51, EA, MX, AR) X-2109-227-1 RING (VOL) ASSY (SERVICE) (RG490/RG590: AEP, UK, RU) 2-658-284-01 GUIDE (VOL LED) 2-658-286-01 KEY (CENTER L) (7, l TUNING –, j –) 2-658-287-01 KEY (CENTER R) (s, L TUNING +, J +) 2-658-283-61 WINDOW (DISPLAY) (RG490: AEP) 2-658-283-71 WINDOW (DISPLAY) (RG490: RU, E2, E3, E51, EA, MX, AR, AUS) 2-658-283-81 WINDOW (DISPLAY) (RG590: AEP, UK) 2-658-283-91 WINDOW (DISPLAY) (RG590: RU, E2, E3, E51, EA, MX, AR)

Ref. No. 107 108 109 110 111

112 112 #1

Part No.

Description

Remark

X-2109-229-1 LID (TOP B) ASSY (SERVICE) (RG490/RG590: AEP, UK, RU) 4-951-620-01 SCREW (2.6X8), +BVTP 2-658-302-01 KEY (SELECT) (+ < , –) (RG590: E2, E3, E51, EA, MX, AR) X-2109-228-1 LID (TOP A) ASSY (SERVICE) (RG590: E2, E3, E51, EA, MX, AR) X-2109-231-1 KEY (P-EQ) ASSY (SERVICE) (PRESET EQ, BASS, VOCAL, GUITAR) (RG590: E2, E3, E51, EA, MX, AR) A-1159-684-A KEY TOP BOARD, COMPLETE (RG590: E2, E3, E51, EA, AR) A-1159-685-A KEY TOP BOARD, COMPLETE (RG590: MX) 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S

HCD-RG490/RG590 Ver. 1.1

8-4.

FRONT SECTION

158

(RG490: MX/ RG590: MX) not supplied

not supplied not supplied

170 171

169 169

not supplied

155

156

159

not supplied

156

159

159

157

not supplied

159

160

(RG490: MX/ RG590: MX)

172 161 not supplied 162 154

167

168

163

153

164

159 165

152

166 (RG490: MX/ RG590: MX)

162 (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) (RG490: MX/RG590: MX)

Ref. No. 151 152 153 154 155

155 156 157 157 157

Part No.

Description

151

(RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR)

151

Remark

2-638-220-01 KNOB (MIC) (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 2-658-304-01 SPRING (CASS R) 2-658-271-01 BOX, CASSETTE (R) 2-658-303-01 SPRING (CASS L) 2-658-270-01 BOX, CASSETTE (L) (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 2-658-270-11 BOX, CASSETTE (L) (RG490: AEP, RU, E3, EA, AUS/RG590: AEP, UK, RU, E3, EA) 4-238-631-11 TAPE SPRING X-2109-217-1 (SERVICE) ASSY, FRONT (RG490: AEP, RU, E3, EA, AUS/RG590: AEP, UK, RU) X-2109-218-1 (SERVICE) ASSY, FRONT (RG490: E2, E51, AR) X-2109-219-1 (SERVICE) ASSY, FRONT (RG490: MX)

Ref. No.

Part No.

Description

161 162 163 164

4-231-841-01 4-224-104-41 4-231-836-01 4-231-824-01

SPRING (HEART CAM-B) DAMPER SPRING (HEART CAM-A) CAM (A), HEART

165

2-658-272-01 HOLDER (MIC 1) (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 2-658-273-01 HOLDER (MIC 2) (RG490: MX/RG590: MX) A-1159-739-A MIC. AUX. HP BOARD, COMPLETE (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) A-1159-740-A MIC. AUX. HP BOARD, COMPLETE (RG490: E2, E51, AR/RG590: E2, E51, AR) A-1159-741-A MIC. AUX. HP BOARD, COMPLETE (RG490: MX/RG590: MX)

166 167

167 167

168 157

157 158 159

X-2109-220-1 (SERVICE) ASSY, FRONT (RG590: E3, EA) X-2109-221-1 (SERVICE) ASSY, FRONT (RG590: E2, E51, AR) X-2109-222-1 (SERVICE) ASSY, FRONT (RG590: MX) 1-417-656-21 MECHA DECK (CWN42FF609) 4-951-620-01 SCREW (2.6X8), +BVTP

160

4-231-825-01 CAM (B), HEART

157

159

168 169 170 171 172

Remark

1-831-772-21 CABLE, FLEXIBLE FLAT (9 CORE) (RG490: AEP, RU, E3, EA, AUS/RG590: AEP, UK, RU, E3, EA) 1-831-789-21 CABLE, FLEXIBLE FLAT (13 CORE) (RG490: E2, E51, MX, AR/RG590: E2, E51, MX, AR) 4-235-777-01 BELT (FR) 2-683-559-01 BELT (AF) 4-683-560-01 BELT (BF) 4-951-620-11 SCREW (2.6X10), +BVTP (RG490: MX/RG590:MX)

81

HCD-RG490/RG590 Ver. 1.1

201 8-5.

MAIN BOARD SECTION

#2

202

202

(RG490: MX/RG590: MX) not supplied not supplied (VIDEO-OUT board)

203

202 M001

202

POWER board, SUB WOOFER board section

202

204

not supplied (SW-SP board)

202

(RG490: AEP, RU/ RG590: AEP, UK, RU)

209

210

205

208 206 #1 chassis section #1

207 Ref. No. 201

Part No.

Description

Remark

Ref. No.

Part No.

Description

Remark

MAIN BOARD, COMPLETE (RG590: MX) MAIN BOARD, COMPLETE (RG490: AEP) MAIN BOARD, COMPLETE (RG490: RU) MAIN BOARD, COMPLETE (RG490: E3, AUS)

2-658-298-51 , BACK (RG490: AEP, RU, AR, AUS/ RG590: AEP, UK, RU, AR) 2-658-298-61 , BACK (RG490: E2, E3, E51/RG590: E2, E3, E51) 2-658-298-71 , BACK (RG490: MX/RG590: MX) 2-664-764-51 , BACK (RG490: EA/RG590: EA) 3-254-143-11 SCREW (B3), (+) BV TAPPING

207 207 207 207

A-1159-747-A A-1163-191-A A-1163-192-A A-1163-193-A

207 207

3-252-829-01 SCREW (B3), (+) BV TAPPING 1-693-710-11 TUNER (FM/AM) (RG490: RU/RG590: RU) 1-693-711-11 TUNER (FM/AM) (RG490: E2, E3, E51, EA, MX, AR, AUS/RG590: E2, E3, E51, EA, MX, AR) 1-693-712-11 TUNER (FM/AM) (RG490: AEP/RG590: AEP, UK) 1-831-619-21 CABLE, FLEXIBLE FLAT (11 CORE) (RG490: AEP/RG590: AEP, UK)

207 207 208

A-1163-194-A MAIN BOARD, COMPLETE (RG490: EA) A-1163-195-A MAIN BOARD, COMPLETE (RG490: E2, E51, AR) A-1163-196-A MAIN BOARD, COMPLETE (RG490: MX) A-1184-870-A MAIN BOARD, COMPLETE (RG590: RU) 1-831-771-21 CABLE, FLEXIBLE FLAT (23 CORE) (RG490: AEP, RU, E2, E3, E51, EA, AR, AUS/ RG590: AEP, UK, RU, E2, E3, E51, EA, AR)

209 210

206 207 207 207

1-831-769-21 CABLE, FLEXIBLE FLAT (9 CORE) (RG490: RU, E2, E3, E51, EA, MX, AR, AUS/ RG590: RU, E2, E3, E51, EA, MX, AR) 1-831-786-21 CABLE, FLEXIBLE FLAT (13 CORE) A-1159-743-A MAIN BOARD, COMPLETE (RG590: AEP, UK) A-1159-744-A MAIN BOARD, COMPLETE (RG590: E3) A-1159-745-A MAIN BOARD, COMPLETE (RG590: EA)

207

A-1159-746-A MAIN BOARD, COMPLETE

201 201 201 202 203 204 204 204 205

205

(RG590: E2, E51, AR)

82

208

M001 #1

1-832-043-21 CABLE, FLEXIBLE FLAT (31 CORE) (RG490: MX/RG590: MX) 3-077-331-01 +BV3 (3-CR) 2-666-281-01 SHEET (GROUND REAR) (RG490: AEP, RU/RG590: AEP, UK, RU) 1-787-344-11 FAN, DC 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S

#2

7-685-881-09 SCREW +BVTT 4X8 (S)

HCD-RG490/RG590 Ver. 1.1

8-6.

POWER BOARD, SUB WOOFER BOARD SECTION

#1 #1 not supplied

254

252 not supplied

not supplied

#1

253

#1

253

251

252

#1

not supplied #1

not supplied

Ref. No. 251 251 251 251 251

Part No.

Description

Remark

A-1159-779-A POWER BOARD, COMPLETE (RG590: AEP, UK, RU) A-1159-780-A POWER BOARD, COMPLETE (RG590: E3, EA) A-1159-781-A POWER BOARD, COMPLETE (RG590: E2, E51, MX, AR) A-1163-224-A POWER BOARD, COMPLETE (RG490: AEP, RU) A-1163-225-A POWER BOARD, COMPLETE (RG490: E3, EA, AUS)

Ref. No. 251

Part No.

Description

Remark

252 253 254 254

A-1163-226-A POWER BOARD, COMPLETE (RG490: E2, E51, MX, AR) 3-905-609-31 SCREW (TRANSISTOR) 3-254-143-11 SCREW (B3), (+) BV TAPPING A-1159-815-A SUB WOOFER BOARD, COMPLETE (RG590) A-1178-854-A SUB WOOFER BOARD, COMPLETE (RG490)

#1

7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S

83

HCD-RG490/RG590 Ver. 1.1

8-7.

CHASSIS SECTION (RG490)

(MX)

308

not supplied

307 304

309

PT901

306

F907

F904 F905

F906

(RG590)

(MX)

308

F909

not supplied

305

not supplied

not supplied

F905

302

#1

307 309

302 303 F907 Ref. No. 301 302 303 304 305

* 305 0 306 0 306 0 306 0 306 0 306 307 307 307 307

307 307 307 307

84

not supplied

F904 F906

F908

301

Part No.

Description

Remark

A-1171-482-A 3-077-331-01 1-831-928-21 4-900-386-01 3-703-244-00

DECK BOARD, COMPLETE +BV3 (3-CR) CABLE, FLEXIBLE FLAT (11 CORE) SCREW BUSHING (2104), CORD (RG490: AEP, RU, E51, EA, AR, AUS/RG590: AEP, UK, RU, E51, EA, AR)

3-703-571-12 BUSHING (S) (4516), CORD (RG490: E2, E3, MX/RG590: E2, E3, MX) 1-769-744-81 CORD, POWER (RG490: EA/RG590: UK, EA) 1-775-790-71 CORD, POWER (RG490: AUS) 1-827-226-31 CORD, POWER (RG490: E2, E3, MX/RG590: E2, E3, MX) 1-829-387-11 CORD, POWER (RG490: AR/RG590: AR) 1-830-188-11 CORD, POWER (RG490: AEP, RU, E51/ RG590: AEP, RU, E51) A-1159-798-A TRANSFORMER BOARD, COMPLETE (RG590: AEP, UK, RU) A-1159-799-A TRANSFORMER BOARD, COMPLETE (RG590: E2, E3, E51) A-1159-801-A TRANSFORMER BOARD, COMPLETE (RG590: EA) A-1159-802-A TRANSFORMER BOARD, COMPLETE (RG590: AR) A-1159-803-A TRANSFORMER BOARD, COMPLETE (RG590: MX) A-1163-242-A TRANSFORMER BOARD, COMPLETE (RG490: AEP, RU) A-1163-243-A TRANSFORMER BOARD, COMPLETE (RG490: E2, E3, E51) A-1163-244-A TRANSFORMER BOARD, COMPLETE (RG490: AUS)

Ref. No.

Part No.

Description

Remark

307

A-1163-245-A TRANSFORMER BOARD, COMPLETE (RG490: EA)

307

A-1163-246-A TRANSFORMER BOARD, COMPLETE (RG490: AR) A-1163-247-A TRANSFORMER BOARD, COMPLETE (RG490: MX) 3-701-748-00 CLAMP 1-500-868-11 CORE, FERRITE (RG490: MX/RG590: MX) 1-532-506-33 FUSE (T6.3AL/250V) (RG590)

307 308 309 0 F904 0 F904 0 F905 0 F905 0 F906 0 F907 0 F908

1-533-949-33 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V) (RG490) 1-532-506-33 FUSE (T6.3AL/250V) (RG590) 1-533-949-33 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V) (RG490) 1-532-465-33 FUSE (T3.15AL/250V) 1-532-465-33 FUSE (T3.15AL/250V)

0 PT901 0 PT901 0 PT901

1-533-949-33 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V) (RG590) 1-533-949-33 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V) (RG590) 1-443-921-11 TRANSFORMER, POWER (RG490: AEP, RU) 1-443-922-11 TRANSFORMER, POWER (RG590: AEP, UK, RU) 1-443-930-11 TRANSFORMER, POWER (RG490: EA)

0 PT901 0 PT901 0 PT901 0 PT901

1-443-931-11 1-443-932-11 1-443-933-11 1-443-935-11

0 F909

0 PT901

TRANSFORMER, POWER (RG590: EA) TRANSFORMER, POWER (RG490: MX) TRANSFORMER, POWER (RG590: MX) TRANSFORMER, POWER (RG590: E2, E3, E51, AR) 1-443-937-11 TRANSFORMER, POWER (RG490: E2, E3, E51, AR, AUS)

HCD-RG490/RG590

8-8.

CD MECHANISM DECK SECTION-1 (CDM74KF-K6BD83S) (EXCEPT Mexican model)/ (CDM74KF-F1BD84) (Mexican model)

506 512

508

501 506

507 506

507

513

509

508 511

514 514 515

510

505 505

M741

502 504 503 516 CD mechanism deck section-2

501

Ref. No.

Part No.

Description

501 502 503 504 505

4-218-253-62 1-828-938-51 1-687-134-12 4-243-815-11 4-245-571-02

SCREW (M2.6), +BTTP WIRE (FLAT TYPE) (5 CORE) MOTOR (TB) BOARD TABLE (LOADING) GEAR (STOPPER)

506 507 508 509

4-218-252-61 4-245-570-01 4-245-572-01 1-687-132-12

SCREW (+PTPWH M2.6), FLOATING GEAR (T) BUSHING (GEAR) SENSOR BOARD

Remark

Ref. No.

Part No.

Description

510

4-243-820-01 GEAR (TABLE)

511 512 513 514 515

4-243-819-01 4-243-816-11 4-243-823-11 4-985-672-01 4-243-821-01

516 M741

3-231-598-01 SHEET (BA) A-1108-965-A MOTOR ASSY, TABLE

Remark

GEAR (GENEVA) TRAY BELT (TABLE) SCREW (+PTPWH M2.6), FLOATING PULLEY (TABLE)

85

HCD-RG490/RG590

8-9.

CD MECHANISM DECK SECTION-2 (CDM74KF-K6BD83S) (EXCEPT Mexican model)/ (CDM74KF-F1BD84) (Mexican model) 555

562

563

555 566 564

561

567

555 565

560

581

569 570

S711

552 558 572 579

555 572

572

M751

580

573

557

573

572 553 556

573

568

552

551 555

555

552

576

578 S101

554

(MX) not supplied

Ref. No.

Part No.

Description

551 552 553 554 555

A-1103-756-B 4-218-253-52 1-687-669-12 4-244-034-11 4-985-672-01

DRIVER BOARD, COMPLETE SCREW (M2.6), +BTTP SW BOARD BELT (LOADING) SCREW (+PTPWH M2.6), FLOATING

556 557 558 559 560

4-225-844-01 4-224-613-11 1-687-133-12 3-087-053-01 4-244-108-01

GEAR (LOADING A) GEAR (SHAFT) MOTOR (LD) BOARD +BVTP2.6 (3CR) (MX) GEAR, SWING

561 562 563 564 565

4-224-609-01 4-224-608-01 3-016-533-11 4-224-611-01 4-224-606-01

GEAR (LOADING C) COLLAR, SWING WASHER (FR), STOPPER GEAR (LOADING B) GEAR (RV)

566 567 568

4-243-818-01 GEAR (U/D) 4-243-822-02 LEVER (LIFTER) X-2102-809-2 PULLEY (KH) ASSY

Remark

Ref. No.

Part No.

4-231-189-01 PULLEY (B), CHUCKING X-2055-190-1 HOLDER (213) ASSY

572 573 576 578 578

4-227-549-11 4-227-045-31 1-832-404-21 A-1095-982-A A-1134-279-A

0 579

580 581 M751 S101 S711

559

Description

569 570

0 579

86

555

573

Remark

INSULATOR SPRING (INSULATOR), COIL CABLE, FLEXIBLE FLAT (16 CORE) BD BOARD, COMPLETE (MX) CD BOARD, COMPLETE (EXCEPT MX)

8-820-244-01 OPTICAL PICK-UP BLOCK (KSM-215D/C2NP) (MX) A-4735-357-A OPTICAL PICK-UP BLOCK (KSM-213D) (EXCEPT MX) 1-471-035-21 MAGNET ASSY 4-243-817-22 CHASSIS A-1108-966-A MOTOR ASSY, LOADING 1-771-853-11 SWITCH, DETECTION (LIMIT) 1-477-680-12 ENCODER, ROTARY (DISC TABLE ADDRESS DETECT)

HCD-RG490/RG590 Ver. 1.1 BD

SECTION 9 ELECTRICAL PARTS LIST NOTE: • Items marked “*” are not stocked since they • Due to standardization, replacements in the are seldom required for routine service. parts list may be different from the parts Some delay should be anticipated when specified in the diagrams or the components ordering these items. used on the set. • SEMICONDUCTORS • -XX and -X mean standardized parts, so they In each case, u: µ, for example: may have some difference from the original uA... : µA... uPA... : µPA... one. uPB... : µPB... uPC... : µPC... • RESISTORS uPD... : µPD... All resistors are in ohms. • CAPACITORS METAL: Metal-film resistor. uF: µF METAL OXIDE: Metal oxide-film resistor. • COILS F: nonflammable uH: µH • Abbreviation AR : Argentina model E3 : 240V AC area in E model MX : Mexican model AUS : Australian model E51 : Chilean and Peruvian models RU : Russian model E2 : 120V AC area in E model EA : Saudi Arabia model Ref. No.

Part No.

Description

Remark

A-1095-982-A BD BOARD, COMPLETE (RG490: MX/RG590: MX) ******************* < CAPACITOR > C10 C11 C14 C15 C16

1-165-989-11 1-165-989-11 1-164-360-11 1-164-360-11 1-115-156-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

10uF 10uF 0.1uF 0.1uF 1uF

10% 10%

C17 C18 C111 C112 C113

1-126-246-11 1-162-964-11 1-162-967-11 1-162-962-11 1-162-967-11

ELECT CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

220uF 0.001uF 0.0033uF 470PF 0.0033uF

20% 10% 10% 10% 10%

4V 50V 50V 50V 50V

C114 C115 C116 C122 C123

1-162-962-11 1-164-360-11 1-128-995-21 1-107-826-11 1-107-826-11

CERAMIC CHIP CERAMIC CHIP ELECT CHIP CERAMIC CHIP CERAMIC CHIP

470PF 0.1uF 100uF 0.1uF 0.1uF

10%

50V 16V 10V 16V 16V

C124 C125 C131 C132 C133

1-162-959-11 1-164-360-11 1-162-927-11 1-117-863-11 1-162-970-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

330PF 0.1uF 100PF 0.47uF 0.01uF

5% 5% 10% 10%

50V 16V 50V 6.3V 25V

C134 C141 C142 C143 C151

1-164-360-11 1-107-826-11 1-162-965-11 1-164-360-11 1-128-995-21

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT CHIP

0.1uF 0.1uF 10% 0.0015uF 10% 0.1uF 100uF 20%

16V 16V 50V 16V 10V

C161 C162 C163 C171 C172

1-164-360-11 1-164-360-11 1-164-360-11 1-162-919-11 1-162-920-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.1uF 0.1uF 0.1uF 22PF 27PF

5% 5%

16V 16V 16V 50V 50V

C174 C181 C182 C183 C184

1-164-360-11 1-164-360-11 1-164-360-11 1-124-778-00 1-124-778-00

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT CHIP ELECT CHIP

0.1uF 0.1uF 0.1uF 22uF 22uF

20% 20%

16V 16V 16V 6.3V 6.3V

C185 C186 C194 C195

1-162-962-11 1-162-962-11 1-164-360-11 1-164-360-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

470PF 470PF 0.1uF 0.1uF

20% 10% 10%

6.3V 6.3V 16V 16V 10V

Ref. No.

50V 50V 16V 16V

When indicating parts by reference number, please include the board.

Description

Remark

C196

1-164-360-11 CERAMIC CHIP

0.1uF

C201 C203 C209 C210 C211

1-128-995-21 1-128-995-21 1-162-970-11 1-107-826-11 1-164-230-11

ELECT CHIP ELECT CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

100uF 100uF 0.01uF 0.1uF 220PF

20% 20% 10% 10% 5%

10V 10V 25V 16V 50V

C212 C213 C251 C252 C255

1-162-919-11 1-162-919-11 1-162-969-11 1-164-360-11 1-164-360-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

22PF 5% 22PF 5% 0.0068uF 10% 0.1uF 0.1uF

50V 50V 25V 16V 16V

C257 C258 C259 C260 C302

1-164-360-11 1-164-360-11 1-164-360-11 1-128-394-11 1-164-360-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT CHIP CERAMIC CHIP

0.1uF 0.1uF 0.1uF 220uF 0.1uF

16V 16V 16V 10V 16V

C303 C305 C306 C307 C308

1-164-360-11 1-126-246-11 1-164-360-11 1-164-360-11 1-126-208-21

CERAMIC CHIP ELECT CHIP CERAMIC CHIP CERAMIC CHIP ELECT CHIP

0.1uF 220uF 0.1uF 0.1uF 47uF

C309 C310 C311 C312 C313

1-164-360-11 1-164-360-11 1-164-360-11 1-164-360-11 1-164-360-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.1uF 0.1uF 0.1uF 0.1uF 0.1uF

C314 C315 C316 C317 C318

1-126-208-21 1-107-826-11 1-162-966-11 1-162-970-11 1-162-970-11

ELECT CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

47uF 0.1uF 0.0022uF 0.01uF 0.01uF

20% 10% 10% 10% 10%

4V 16V 50V 25V 25V

C320

1-162-964-11 CERAMIC CHIP

0.001uF

10%

50V

16V

20%

20%

20%

16V 4V 16V 16V 4V 16V 16V 16V 16V 16V

< CONNECTOR > CN101 CN201

1-770-425-51 CONNECTOR, FFC/FPC 16P 1-784-879-51 CONNECTOR, FFC (LIF (NON-ZIF)) 31P < FERRITE BEAD >

FB301 10% 10%

Part No.

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified.

1-500-445-21 FERRITE, EMI (SMD) (2012) < IC >

IC101

8-752-425-12 IC CXD3059AR

87

HCD-RG490/RG590 BD Ref. No. IC251 IC301 IC303

CD Part No.

Description

Remark

6-705-808-01 IC BA5947FM-E2 6-705-365-01 IC TC94A34FG-002 6-705-807-01 IC BH15FB1WG < TRANSISTOR >

Q10

6-551-120-01 TRANSISTOR

Part No.

Description

Remark

R407 R408 R409 R410 R411

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R412 R419 R421 R422 R423

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

2SA2119K

< RESISTOR/FERRITE BEAD > R10 R11 R12 R13 R111

1-216-791-11 1-216-864-11 1-216-845-11 1-218-446-11 1-216-821-11

METAL CHIP SHORT CHIP METAL CHIP METAL CHIP METAL CHIP

3.3 0 100K 1 1K

5%

1/10W

5% 5% 5%

1/10W 1/10W 1/10W

R112 R113 R114 R121 R131

1-216-835-11 1-216-821-11 1-216-835-11 1-216-835-11 1-216-857-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

15K 1K 15K 15K 1M

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R132 R133 R141 R142 R143

1-216-833-11 1-216-848-11 1-216-829-11 1-216-821-11 1-216-827-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10K 180K 4.7K 1K 3.3K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R151 R161 R162 R163 R165

1-216-864-11 1-216-809-11 1-216-841-11 1-216-809-11 1-216-864-11

SHORT CHIP METAL CHIP METAL CHIP METAL CHIP SHORT CHIP

0 100 47K 100 0

5% 5% 5%

1/10W 1/10W 1/10W

R171 R172 R173 R181 R182

1-216-817-11 1-216-857-11 1-216-295-00 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP SHORT CHIP METAL CHIP METAL CHIP

470 1M 0 100 100

5% 5%

1/10W 1/10W

5% 5%

1/10W 1/10W

R191 R201 R203 R204 R205

1-216-864-11 1-500-445-21 1-216-864-11 1-216-864-11 1-216-864-11

SHORT CHIP 0 FERRITE, EMI (SMD) (2012) SHORT CHIP 0 SHORT CHIP 0 SHORT CHIP 0

R251 R252 R253 R301 R302

1-216-833-11 1-216-837-11 1-216-833-11 1-216-845-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10K 22K 10K 100K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R303 R305 R306 R307 R313

1-216-845-11 1-216-845-11 1-216-864-11 1-216-833-11 1-216-813-11

METAL CHIP METAL CHIP SHORT CHIP METAL CHIP METAL CHIP

100K 100K 0 10K 220

5% 5%

1/10W 1/10W

5% 5%

1/10W 1/10W

R351 R352 R353 R354 R401

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R402 R403 R404 R405 R406

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

88

Ref. No.

< VIBRATOR > X171 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz) ************************************************************ A-1134-279-A CD BOARD, COMPLETE (EXCEPT RG490: MX/RG590: MX) ******************* < CAPACITOR > C101 C102 C103 C104 C105

1-162-919-11 1-162-919-11 1-162-919-11 1-164-230-11 1-162-919-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

22PF 22PF 22PF 220PF 22PF

5% 5% 5% 5% 5%

50V 50V 50V 50V 50V

C107 C108 C109 C110 C111

1-164-230-11 1-164-230-11 1-164-230-11 1-164-230-11 1-164-230-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

220PF 220PF 220PF 220PF 220PF

5% 5% 5% 5% 5%

50V 50V 50V 50V 50V

C112 C113 C201 C202 C203

1-162-919-11 1-162-919-11 1-128-995-21 1-164-360-11 1-128-995-21

CERAMIC CHIP CERAMIC CHIP ELECT CHIP CERAMIC CHIP ELECT CHIP

22PF 22PF 100uF 0.1uF 100uF

5% 5% 20%

50V 50V 10V 16V 10V

C204 C205 C206 C207 C208

1-164-360-11 1-164-360-11 1-164-360-11 1-128-995-21 1-164-360-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT CHIP CERAMIC CHIP

0.1uF 0.1uF 0.1uF 100uF 0.1uF

C210 C213 C214 C215 C217

1-164-360-11 1-164-360-11 1-164-360-11 1-164-360-11 1-164-360-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.1uF 0.1uF 0.1uF 0.1uF 0.1uF

16V 16V 16V 16V 16V

C218 C219 C220 C221 C222

1-164-360-11 1-164-360-11 1-164-360-11 1-164-360-11 1-164-360-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.1uF 0.1uF 0.1uF 0.1uF 0.1uF

16V 16V 16V 16V 16V

C223 C224 C226 C227 C230

1-164-360-11 1-164-360-11 1-165-908-11 1-165-908-11 1-162-927-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.1uF 0.1uF 1uF 1uF 100PF

10% 10% 5%

16V 16V 10V 10V 50V

C232 C251 C252

1-164-360-11 CERAMIC CHIP 1-164-315-11 CERAMIC CHIP 1-162-968-11 CERAMIC CHIP

0.1uF 470PF 5% 0.0047uF 10%

16V 50V 50V

20%

20%

16V 16V 16V 10V 16V

HCD-RG490/RG590 CD Ref. No.

Part No.

Description

Remark

C253 C254

1-164-315-11 CERAMIC CHIP 1-162-968-11 CERAMIC CHIP

470PF 5% 0.0047uF 10%

50V 50V

C256 C257 C258 C260 C261

1-107-826-11 1-107-826-11 1-164-230-11 1-117-863-11 1-162-970-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.1uF 0.1uF 220PF 0.47uF 0.01uF

10% 10% 5% 10% 10%

16V 16V 50V 6.3V 25V

C264 C265 C266 C267 C268

1-162-964-11 1-107-826-11 1-162-915-11 1-162-910-11 1-162-915-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.001uF 0.1uF 10PF 5PF 10PF

10% 10% 0.5PF 0.25PF 0.5PF

50V 16V 50V 50V 50V

C271 C272 C273 C274 C275

1-107-826-11 1-164-360-11 1-164-315-11 1-107-826-11 1-162-910-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.1uF 0.1uF 470PF 0.1uF 5PF

10%

C276 C277 C291 C292 C301

1-165-908-11 1-165-908-11 1-164-315-11 1-164-315-11 1-164-360-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

1uF 1uF 470PF 470PF 0.1uF

10% 10% 5% 5%

C303 C304 C321 C322 C323

1-137-710-11 1-165-908-11 1-162-964-11 1-165-908-11 1-128-995-21

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT CHIP

10uF 1uF 0.001uF 1uF 100uF

20% 10% 10% 10% 20%

6.3V 10V 50V 10V 10V

C401 C404 C405 C406 C424

1-128-394-11 1-164-360-11 1-164-360-11 1-164-360-11 1-164-360-11

ELECT CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

220uF 0.1uF 0.1uF 0.1uF 0.1uF

20%

10V 16V 16V 16V 16V

C451

1-165-176-11 CERAMIC CHIP

0.047uF

10%

16V 16V 5% 50V 10% 16V 0.25PF 50V 10V 10V 50V 50V 16V

16V

< CONNECTOR > CN102 CN301

1-770-706-21 CONNECTOR, FFC/FPC 23P 1-770-425-51 CONNECTOR, FFC/FPC 16P

Ref. No.

Part No.

Description

Remark

R112 R113 R201 R202 R203

1-216-809-11 1-216-809-11 1-216-295-00 1-216-295-00 1-500-445-21

METAL CHIP 100 5% METAL CHIP 100 5% SHORT CHIP 0 SHORT CHIP 0 FERRITE, EMI (SMD) (2012)

1/10W 1/10W

R207 R250 R252 R253 R254

1-216-295-00 1-216-857-11 1-216-833-11 1-216-821-11 1-216-833-11

SHORT CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

0 1M 10K 1K 10K

R255 R256 R257 R258 R260

1-216-821-11 1-216-837-11 1-216-845-11 1-216-849-11 1-216-864-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP SHORT CHIP

R265 R266 R267 R268 R270

1-216-829-11 1-216-821-11 1-216-829-11 1-216-833-11 1-216-821-11

R271 R275 R276 R277 R278

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

1K 22K 100K 220K 0

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 1K 4.7K 10K 1K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

1-216-857-11 1-216-809-11 1-216-841-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

1M 100 47K 100 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R280 R291 R292 R321 R322

1-216-864-11 1-216-809-11 1-216-809-11 1-216-789-11 1-216-789-11

SHORT CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

0 100 100 2.2 2.2

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

R323 R324 R401 R421 R423

1-216-864-11 1-216-845-11 1-216-295-00 1-216-864-11 1-216-833-11

SHORT CHIP METAL CHIP SHORT CHIP SHORT CHIP METAL CHIP

0 100K 0 0 10K

5%

1/10W

5%

1/10W

R451 R452

1-216-837-11 METAL CHIP 1-216-833-11 METAL CHIP

22K 10K

5% 5%

1/10W 1/10W

< VIBRATOR >

< IC > IC201 IC203 IC402

X201 1-795-101-21 VIBRATOR, CERAMIC (16.9344MHz) ************************************************************

8-753-246-30 IC CXD3014A-201R 6-709-050-01 IC BH18LB1WG-TR 6-705-808-01 IC BA5947FM-E2

A-1159-964-A CD-G BOARD, COMPLETE (RG490: MX/RG590: MX) *********************

< TRANSISTOR > Q321

6-551-120-01 TRANSISTOR

CD-G

2SA2119K < CAPACITOR >

< RESISTOR/FERRITE BEAD > R101 R102 R103 R104 R105

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R107 R108 R109 R110 R111

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

C1001 C1002 C1003 C1004 C1005

1-162-970-11 1-162-970-11 1-162-970-11 1-162-970-11 1-162-970-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.01uF 0.01uF 0.01uF 0.01uF 0.01uF

10% 10% 10% 10% 10%

25V 25V 25V 25V 25V

C1006 C1007 C1008 C1010 C1011

1-162-970-11 1-162-970-11 1-126-193-11 1-126-206-11 1-162-970-11

CERAMIC CHIP CERAMIC CHIP ELECT CHIP ELECT CHIP CERAMIC CHIP

0.01uF 0.01uF 1uF 100uF 0.01uF

10% 10% 20% 20% 10%

25V 25V 50V 6.3V 25V

89

HCD-RG490/RG590 CD-G Ref. No.

DECK Part No.

Description

C1012 C1013 C1014 C1015 C1016

1-126-205-11 1-126-206-11 1-162-970-11 1-162-970-11 1-216-864-11

ELECT CHIP ELECT CHIP CERAMIC CHIP CERAMIC CHIP SHORT CHIP

47uF 100uF 0.01uF 0.01uF 0

20% 20% 10% 10%

Remark 6.3V 6.3V 25V 25V

C1018 C1019 C1022 C1023 C1024

1-162-919-11 1-162-919-11 1-162-919-11 1-126-193-11 1-126-206-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT CHIP ELECT CHIP

22PF 22PF 22PF 1uF 100uF

5% 5% 5% 20% 20%

50V 50V 50V 50V 6.3V

C1025 C1026 C1027 C1028 C1029

1-162-970-11 1-110-530-11 1-162-957-11 1-126-206-11 1-164-357-11

CERAMIC CHIP ELECT CHIP CERAMIC CHIP ELECT CHIP CERAMIC CHIP

0.01uF 1000uF 220PF 100uF 0.001uF

10% 20% 5% 20% 5%

25V 6.3V 50V 6.3V 50V

C1030 C1031

1-124-778-00 ELECT CHIP 1-126-193-11 ELECT CHIP

22uF 1uF

20% 20%

6.3V 50V

Ref. No.

Part No.

Description

Remark

R1020 R1021 R1022 R1023 R1029

1-216-833-11 1-216-813-11 1-216-813-11 1-216-813-11 1-216-821-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10K 220 220 220 1K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R1030 R1031 R1032 R1033 R1034

1-216-837-11 1-218-285-11 1-216-833-11 1-216-825-11 1-216-825-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 75 10K 2.2K 2.2K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R1035 R1036 R1037 R1038 R1051

1-216-825-11 1-162-968-11 1-162-966-11 1-162-962-11 1-216-797-11

METAL CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP METAL CHIP

2.2K 0.0047uF 0.0022uF 470PF 10

5% 10% 10% 10% 5%

1/10W 50V 50V 50V 1/10W

< VIBRATOR > X1002 1-813-555-11 VIBRATOR, CRYSTAL (14.31818MHz) ************************************************************

< CONNECTOR > CN1001 1-779-416-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P CN1004 1-794-509-41 PIN, CONNECTOR (PC BOARD) (3P)

A-1171-482-A DECK BOARD, COMPLETE *********************

< JUMPER RESISTOR > < CAPACITOR/RESISTOR > FB1001 1-216-864-11 SHORT CHIP

0

< IC > IC1001 IC1002 IC1003 IC1005 IC1006

6-707-420-01 6-704-474-01 6-705-469-01 8-759-584-98 6-706-369-01

IC IC IC IC IC

TC9411AFG (BS, K) MSM514400E-60TS-K BA50BC0FP-E2 SN74AHCT04NSR NJM2561F1-TE2

< RESISTOR > JR1001 1-216-864-11 SHORT CHIP L1001 1-216-864-11 SHORT CHIP L1002 1-216-797-11 METAL CHIP

0 0 10

5%

1/10W

< TRANSISTOR > Q1001 Q1002 Q1005 Q1006 Q1007

8-729-027-59 8-729-027-59 8-729-027-59 8-729-027-23 8-729-027-59

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

DTC144EKA-T146 DTC144EKA-T146 DTC144EKA-T146 DTA114EKA-T146 DTC144EKA-T146

Q1008 Q1009 Q1010

8-729-804-41 TRANSISTOR 8-729-027-23 TRANSISTOR 8-729-027-59 TRANSISTOR

2SB1122-S DTA114EKA-T146 DTC144EKA-T146

< RESISTOR > R1003 R1004 R1005 R1006 R1011

1-216-829-11 1-216-825-11 1-216-825-11 1-216-829-11 1-216-829-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 2.2K 2.2K 4.7K 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R1012 R1013 R1015 R1016 R1017

1-216-833-11 1-216-825-11 1-216-809-11 1-216-833-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10K 2.2K 100 10K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

90

C301 C302 C303 C304 C305

1-162-964-11 1-162-964-11 1-162-964-11 1-162-964-11 1-216-849-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP METAL CHIP

0.001uF 0.001uF 0.001uF 0.001uF 220K

10% 10% 10% 10% 5%

50V 50V 50V 50V 1/10W

C306 C307 C315 C316 C317

1-216-849-11 1-162-970-11 1-162-923-11 1-162-923-11 1-126-964-11

METAL CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT

220K 0.01uF 47PF 47PF 10uF

5% 10% 5% 5% 20%

1/10W 25V 50V 50V 50V

C318 C323 C324 C325 C326

1-126-964-11 1-162-968-11 1-162-968-11 1-162-966-11 1-162-966-11

ELECT CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

10uF 0.0047uF 0.0047uF 0.0022uF 0.0022uF

20% 10% 10% 10% 10%

50V 50V 50V 50V 50V

C327 C328 C329 C330 C350

1-162-960-11 1-162-960-11 1-136-161-00 1-136-161-00 1-126-934-11

CERAMIC CHIP CERAMIC CHIP MYLAR MYLAR ELECT

220PF 220PF 0.047uF 0.047uF 220uF

10% 10% 5% 5% 20%

50V 50V 50V 50V 16V

C351 C352 C353 C354 C355

1-126-934-11 1-107-826-11 1-107-826-11 1-107-826-11 1-162-970-11

ELECT CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

220uF 0.1uF 0.1uF 0.1uF 0.01uF

20% 10% 10% 10% 10%

16V 16V 16V 16V 25V

C356 C401 C402 C403 C404

1-126-964-11 1-126-956-11 1-126-956-11 1-162-923-11 1-162-923-11

ELECT ELECT ELECT CERAMIC CHIP CERAMIC CHIP

10uF 0.1uF 0.1uF 47PF 47PF

20% 20% 20% 5% 5%

50V 50V 50V 50V 50V

C405 C406 C409 C410

1-162-960-11 1-162-960-11 1-126-964-11 1-126-964-11

CERAMIC CHIP CERAMIC CHIP ELECT ELECT

220PF 220PF 10uF 10uF

10% 10% 20% 20%

50V 50V 50V 50V

HCD-RG490/RG590 DECK Ref. No.

Part No.

Description

Remark

C411

1-162-915-11 CERAMIC CHIP

10PF

0.5PF

50V

C412 C413 C414 C415 C416

1-162-915-11 1-162-960-11 1-162-960-11 1-162-968-11 1-162-968-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

10PF 220PF 220PF 0.0047uF 0.0047uF

0.5PF 10% 10% 10% 10%

50V 50V 50V 50V 50V

C417 C418 C430 C431 C433

1-107-726-91 1-107-726-91 1-164-156-11 1-164-156-11 1-162-970-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.01uF 0.01uF 0.1uF 0.1uF 0.01uF

10% 10%

10%

16V 16V 25V 25V 25V

C452 C453 C454 C456 C458

1-126-947-11 1-130-471-00 1-130-479-00 1-130-483-00 1-130-475-00

ELECT MYLAR MYLAR MYLAR MYLAR

47uF 0.001uF 0.0047uF 0.01uF 0.0022uF

20% 5% 5% 5% 5%

35V 50V 50V 50V 50V

C461 C462

1-162-962-11 CERAMIC CHIP 1-162-962-11 CERAMIC CHIP

470PF 470PF

10% 10%

50V 50V

< CONNECTOR > CN008 CN301 CN302

1-568-830-11 CONNECTOR, FFC 11P 1-815-444-11 PIN, CONNECTOR (PWB) 3P 1-815-449-11 PIN, CONNECTOR (PWB) 8P < DIODE >

D301 D401

6-501-165-01 DIODE UDZW-TE17-4.3B 6-500-335-01 DIODE MC2838-T112-1

Ref. No.

Part No.

Description

Remark

Q402 Q403

8-729-045-62 FET 8-729-600-22 TRANSISTOR

2SK2158-T2B 2SA1235-F

Q404 Q405 Q406 Q407 Q408

8-729-600-22 8-729-120-28 8-729-600-22 8-729-600-22 8-729-600-22

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SA1235-F 2SC1623-L5L6 2SA1235-F 2SA1235-F 2SA1235-F

Q409 Q410 Q451 Q452 Q453

6-551-276-01 6-551-276-01 8-729-037-13 8-729-120-28 8-729-011-92

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

RT1N431C-TP-1 RT1N431C-TP-1 KTA1271Y 2SC1623-L5L6 2SC2001TP-K1K2

< RESISTOR > R301 R302 R303 R304 R305

1-216-841-11 1-216-841-11 1-216-841-11 1-216-841-11 1-216-849-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

47K 47K 47K 47K 220K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R306 R307 R308 R309 R310

1-216-849-11 1-216-829-11 1-216-829-11 1-216-817-11 1-216-817-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

220K 4.7K 4.7K 470 470

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R311 R312 R313 R314 R315

1-216-813-11 1-216-813-11 1-216-805-11 1-216-805-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

220 220 47 47 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R316 R317 R318 R319 R320

1-216-809-11 1-216-853-11 1-216-853-11 1-216-837-11 1-216-837-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 470K 470K 22K 22K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R323 R324 R325 R326 R349

1-216-829-11 1-216-829-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 4.7K 100 100 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R350 R351 R401 R402 R403

1-216-864-11 1-216-821-11 1-216-841-11 1-216-841-11 1-216-837-11

SHORT CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

0 1K 47K 47K 22K

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

R404 R405 R406 R407 R408

1-216-837-11 1-216-841-11 1-216-841-11 1-216-829-11 1-216-829-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 47K 47K 4.7K 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R409 R410 R411 R412 R413

1-216-845-11 1-216-845-11 1-216-853-11 1-216-853-11 1-216-849-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100K 100K 470K 470K 220K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R414 R415 R416 R423

1-216-849-11 1-216-825-11 1-216-825-11 1-216-841-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

220K 2.2K 2.2K 47K

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

< JUMPER RESISTOR > FB301

1-216-864-11 SHORT CHIP

0

< IC > IC301 IC401

6-702-457-01 IC NJM14558M-TE2 8-759-909-71 IC BA4558F < JUMPER RESISTOR >

JR301 JR302 JR306 JR307 JR310

1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11

SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP

0 0 0 0 0

JR311 JR402

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP

0 0

< TRANSFORMER > L451

1-443-760-11 TRANSFORMER, BIAS OSCILLATION < TRANSISTOR >

Q301 Q302 Q303 Q304 Q305

6-550-290-01 6-550-290-01 6-550-290-01 6-550-290-01 8-729-120-28

FET FET FET FET TRANSISTOR

2SJ460-T 2SJ460-T 2SJ460-T 2SJ460-T 2SC1623-L5L6

Q306 Q400 Q401

8-729-120-28 TRANSISTOR 8-729-045-62 FET 8-729-045-62 FET

2SC1623-L5L6 2SK2158-T2B 2SK2158-T2B

91

HCD-RG490/RG590 Ver. 1.2 DECK DRIVER

KEY LEFT

Ref. No.

Description

Part No.

Remark

R424

1-216-841-11 METAL CHIP

47K

5%

R427 R428 R429 R430 R431

1-216-864-11 1-216-864-11 1-216-833-11 1-216-833-11 1-216-821-11

SHORT CHIP SHORT CHIP METAL CHIP METAL CHIP METAL CHIP

0 0 10K 10K 1K

5% 5% 5%

1/10W 1/10W 1/10W

R432 R433 R434 R435 R436

1-216-821-11 1-216-841-11 1-216-841-11 1-216-833-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

1K 47K 47K 10K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R437 R438 R439 R440 R441

1-216-864-11 1-216-864-11 1-216-829-11 1-216-833-11 1-216-864-11

SHORT CHIP SHORT CHIP METAL CHIP METAL CHIP SHORT CHIP

0 0 4.7K 10K 0

R442 R443 R444 R445 R446

1-216-841-11 1-216-833-11 1-216-845-11 1-216-864-11 1-216-864-11

METAL CHIP METAL CHIP METAL CHIP SHORT CHIP SHORT CHIP

R449 R450 R451 R452 R453

1-216-801-11 1-216-801-11 1-216-833-11 1-216-841-11 1-216-829-11

R454 R455 R456 R457 R458

Ref. No. C741 C751 C752

1/10W 1/10W

47K 10K 100K 0 0

5% 5% 5%

1/10W 1/10W 1/10W

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22 22 10K 47K 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

1-216-829-11 1-216-797-11 1-216-801-11 1-216-837-11 1-216-793-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 10 22 22K 4.7

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R459 R460 R461 R462 R463

1-216-864-11 1-216-864-11 1-216-825-11 1-216-825-11 1-216-821-11

SHORT CHIP SHORT CHIP METAL CHIP METAL CHIP METAL CHIP

0 0 2.2K 2.2K 1K

5% 5% 5%

1/10W 1/10W 1/10W

R464 R465 R466 R481 R482

1-216-821-11 1-216-864-11 1-216-864-11 1-216-829-11 1-216-841-11

METAL CHIP SHORT CHIP SHORT CHIP METAL CHIP METAL CHIP

1K 0 0 4.7K 47K

5%

1/10W

5% 5%

1/10W 1/10W

R483 R484 R485 R488 R489

1-216-837-11 1-216-837-11 1-216-825-11 1-216-837-11 1-216-837-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 22K 2.2K 22K 22K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

CN701 CN702 * CN703 CN704

92

0.01uF 0.01uF 0.1uF

20% 20%

16V 16V 50V

1-784-735-11 1-784-766-11 1-564-720-11 1-785-328-11

CONNECTOR, FFC 13P CONNECTOR, FFC 5P PIN, CONNECTOR (SMALL TYPE) 4P PIN, CONNECTOR (LIGHT ANGRE) 2P

8-719-921-42 DIODE MTZJ-5.1A 8-719-109-69 DIODE RD3.6ESB2

IC701 IC712

8-759-598-69 IC BA6956AN 8-759-598-69 IC BA6956AN < TRANSISTOR > 8-729-029-66 TRANSISTOR

DTC114ESA

< RESISTOR > R701 R702 R711 R712 R713

1-249-413-11 1-247-807-31 1-249-417-11 1-249-425-11 1-249-433-11

CARBON CARBON CARBON CARBON CARBON

470 100 1K 4.7K 22K

5% 5% 5% 5% 5%

1/4W 1/4W 1/4W 1/4W 1/4W

R721 R722 R723 R731 R732

1-249-425-11 1-249-425-11 1-249-425-11 1-247-807-31 1-249-429-11

CARBON CARBON CARBON CARBON CARBON

4.7K 4.7K 4.7K 100 10K

5% 5% 5% 5% 5%

1/4W 1/4W 1/4W 1/4W 1/4W

R733 1-249-417-11 CARBON 1K 5% 1/4W R734 1-249-430-11 CARBON 12K 5% 1/4W R736 1-249-412-11 CARBON 390 5% 1/4W R751 1-249-425-11 CARBON 4.7K 5% 1/4W ************************************************************ A-1159-677-A KEY LEFT BOARD, COMPLETE(RG490: AEP, RU, E2, E3, E51, EA, AR, AUS/RG590: AEP, UK, RU) A-1159-678-A KEY LEFT BOARD, COMPLETE (RG590: E2, E3, E51, EA, AR) A-1159-679-A KEY LEFT BOARD, COMPLETE (RG590: MX) A-1163-183-A KEY LEFT BOARD, COMPLETE (RG490: MX) ************************ < LED > D611 D622

6-501-483-01 LED SLR-325VCT31P (STANDBY) 8-719-060-27 LED SLR-325MCT31 (SUBWOOFER) (RG490/RG590: AEP, UK, RU) < RESISTOR >

< CAPACITOR > 100uF 10uF 0.1uF 0.1uF 0.1uF

1-162-306-11 CERAMIC 1-162-306-11 CERAMIC 1-164-159-21 CERAMIC

< IC >

A-1103-756-B DRIVER BOARD, COMPLETE ***********************

ELECT ELECT CERAMIC CERAMIC CERAMIC

Remark

< DIODE >

Q731

R490 1-216-829-11 METAL CHIP 4.7K 5% 1/10W ************************************************************

1-126-933-11 1-126-964-11 1-164-159-21 1-164-159-21 1-164-159-21

Description

< CONNECTOR >

D701 D711 5% 5%

C715 C731 C735 C736 C737

Part No.

1/10W

20% 20%

16V 50V 50V 50V 50V

R626 R639

1-216-821-11 METAL CHIP 1-216-821-11 METAL CHIP

R640

1-216-821-11 METAL CHIP

R652 R653

1-216-825-11 METAL CHIP 1-216-825-11 METAL CHIP

1K 5% 1/10W 1K 5% 1/10W (RG490/RG590: AEP, UK, RU) 1K 5% 1/10W (RG490/RG590: AEP, UK, RU) 2.2K 5% 1/10W 2.2K 5% 1/10W

HCD-RG490/RG590 KEY LEFT Ref. No.

Part No.

Description

R654 R655 R656 R675 R676

1-216-829-11 1-216-829-11 1-216-833-11 1-216-829-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

R677 R678

1-216-837-11 METAL CHIP 1-216-841-11 METAL CHIP

Remark 4.7K 4.7K 10K 4.7K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

22K 5% 1/10W 47K 5% 1/10W (RG490/RG590: AEP, UK, RU)

Ref. No. S634 S635 S636

S603 S604

1-762-875-21 SWITCH, KEYBOARD (I/1) 1-762-875-21 SWITCH, KEYBOARD (DISPLAY) (EXCEPT RG490: MX/RG590: MX) 1-762-875-21 SWITCH, KEYBOARD (KARAOKE) (RG490: MX/RG590: MX) 1-762-875-21 SWITCH, KEYBOARD (AUDIO IN) 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)

S605 S606 S625 S626 S627

1-762-875-21 1-762-875-21 1-762-875-21 1-762-875-21 1-762-875-21

S602

SWITCH, KEYBOARD (TUNER/BAND) SWITCH, KEYBOARD (CD) SWITCH, KEYBOARD (ILLUMINATION) SWITCH, KEYBOARD (REC PAUSE/START) SWITCH, KEYBOARD (CD SYNC)

S628

1-762-875-21 SWITCH, KEYBOARD (SUBWOOFER) (RG490/RG590: AEP, UK, RU) ************************************************************ A-1159-681-A KEY RIGHT BOARD, COMPLETE (EXCEPT RG490: MX/RG590: MX) A-1159-682-A KEY RIGHT BOARD, COMPLETE (RG490: MX/RG590: MX) *************************

1-162-970-11 CERAMIC CHIP 1-162-970-11 CERAMIC CHIP

< LED > D623

8-719-063-92 LED SLR325MC-M-T31-NP (SUBWOOFER) < RESISTOR >

R658 R659 R664 R665 R666

1-216-821-11 1-216-821-11 1-216-829-11 1-216-829-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

1K 1K 4.7K 4.7K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R667 R668 R692 R693 R694

1-216-837-11 1-216-841-11 1-216-825-11 1-216-825-11 1-216-829-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 47K 2.2K 2.2K 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R695 R696 R697 R698

1-216-829-11 1-216-833-11 1-216-837-11 1-216-841-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 10K 22K 47K

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

< SWITCH > 0.01uF 0.01uF

10% 10%

25V 25V

< RESISTOR > R682 R683 R684 R685 R686

1-216-825-11 1-216-825-11 1-216-829-11 1-216-829-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

2.2K 2.2K 4.7K 4.7K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R687 R688

1-216-837-11 METAL CHIP 1-216-841-11 METAL CHIP

22K 47K

5% 5%

1/10W 1/10W

< SWITCH > S624 S631 S631 S632 S632

S633 S633

Remark

A-1159-684-A KEY TOP BOARD, COMPLETE (RG590: E2, E3, E51, EA, AR) A-1159-685-A KEY TOP BOARD, COMPLETE (RG590: MX) ***********************

< CAPACITOR > C643 C644

Description

1-762-875-21 SWITCH, KEYBOARD (A) 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE) 1-762-875-21 SWITCH, KEYBOARD (DISC 3)

S637 1-762-875-21 SWITCH, KEYBOARD (DISC 2) S638 1-762-875-21 SWITCH, KEYBOARD (DISC 1) S672 1-786-418-11 SWITCH, ROTARY (ENCODER) (MULTI JOG) ************************************************************

< SWITCH > S601 S602

Part No.

Ver. 1.1 KEY TOP

KEY RIGHT

S614 S615 S616 S617 S618

1-762-875-21 1-762-875-21 1-762-875-21 1-762-875-21 1-762-875-21

SWITCH, KEYBOARD (CLEAR) SWITCH, KEYBOARD (GROOVE) SWITCH, KEYBOARD (SURROUND) SWITCH, KEYBOARD (EQ BAND) SWITCH, KEYBOARD (SUBWOOFER)

S641 S642 S643 S644 S645

1-762-875-21 1-762-875-21 1-762-875-21 1-762-875-21 1-762-875-21

SWITCH, KEYBOARD (BASS) SWITCH, KEYBOARD (VOCAL) SWITCH, KEYBOARD (GUITAR) SWITCH, KEYBOARD (ENTER) SWITCH, KEYBOARD (B)

S646 1-762-875-21 SWITCH, KEYBOARD (+) S647 1-762-875-21 SWITCH, KEYBOARD (b) S648 1-762-875-21 SWITCH, KEYBOARD (–) ************************************************************

1-762-875-21 SWITCH, KEYBOARD (ENTER) 1-762-875-21 SWITCH, KEYBOARD (EQ BAND) (RG490/RG590: AEP, UK, RU) 1-762-875-21 SWITCH, KEYBOARD (SLEEP) (RG590: E2, E3, E51, EA, MX, AR) 1-762-875-21 SWITCH, KEYBOARD (SURRROUND) (RG490/RG590: AEP, UK, RU) 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE/TUNING MODE) (RG590: E2, E3, E51, EA, MX, AR) 1-762-875-21 SWITCH, KEYBOARD (GROOVE) (RG490/RG590: AEP, UK, RU) 1-762-875-21 SWITCH, KEYBOARD (REPEAT) (RG590: E2, E3, E51, EA, MX, AR)

93

HCD-RG490/RG590 Ver. 1.1 MAIN Ref. No.

Part No.

Description

A-1159-743-A A-1159-744-A A-1159-745-A A-1159-746-A A-1159-747-A

MAIN BOARD, COMPLETE (RG590: AEP, UK) MAIN BOARD, COMPLETE (RG590: E3) MAIN BOARD, COMPLETE (RG590: EA) MAIN BOARD, COMPLETE(RG590: E2, E51, AR) MAIN BOARD, COMPLETE (RG590: MX)

Remark

A-1163-191-A A-1163-192-A A-1163-193-A A-1163-194-A A-1163-195-A

MAIN BOARD, COMPLETE (RG490: AEP) MAIN BOARD, COMPLETE (RG490: RU) MAIN BOARD, COMPLETE (RG490: E3, AUS) MAIN BOARD, COMPLETE (RG490: EA) MAIN BOARD, COMPLETE(RG490: E2, E51, AR)

C124

Part No.

Description

Remark

1-126-933-11 ELECT 100uF 20% 16V 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V 1-162-923-11 CERAMIC CHIP 47PF 5% 50V (RG490: AEP, RU/RG590: AEP, UK, RU) 1-162-923-11 CERAMIC CHIP 47PF 5% 50V (RG490: AEP, RU/RG590: AEP, UK, RU) 1-126-960-11 1-126-960-11 1-126-960-11 1-126-960-11 1-164-156-11

A-1163-196-A MAIN BOARD, COMPLETE (RG490: MX) A-1184-870-A MAIN BOARD, COMPLETE (RG490: RU) *********************

C134

7-685-872-01 SCREW +BVTT 3X8 (S)

C135

C137 C138

1-164-156-11 CERAMIC CHIP 0.1uF 25V (RG490: AEP, RU/RG590: AEP, UK, RU) 1-162-960-11 CERAMIC CHIP 220PF 10% 50V (RG490: AEP, RU/RG590: AEP, UK, RU) 1-162-960-11 CERAMIC CHIP 220PF 10% 50V (RG490: AEP, RU/RG590: AEP, UK, RU) 1-126-960-11 ELECT 1uF 20% 50V 1-126-960-11 ELECT 1uF 20% 50V

C139 C140 C141 C142 C143

1-107-826-11 1-107-826-11 1-126-964-11 1-126-964-11 1-137-374-11

CERAMIC CHIP CERAMIC CHIP ELECT ELECT MYLAR

0.1uF 0.1uF 10uF 10uF 0.047uF

10% 10% 20% 20% 5%

16V 16V 50V 50V 50V

C144 C145 C146 C147 C148

1-137-374-11 1-162-968-11 1-162-968-11 1-164-362-11 1-164-362-11

MYLAR CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.047uF 0.0047uF 0.0047uF 470PF 470PF

5% 10% 10% 5% 5%

50V 50V 50V 50V 50V

C149 C150 C151 C152 C153

1-164-227-11 1-164-227-11 1-164-227-11 1-164-227-11 1-126-960-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT

0.022uF 10% 25V 0.022uF 10% 25V 0.022uF 10% 25V 0.022uF 10% 25V 1uF 20% 50V (RG490/RG590: AEP, UK, RU)

C154

1-126-960-11 ELECT

C155

1-136-167-00 MYLAR

C155

1-136-168-00 MYLAR

C156

1-136-167-00 MYLAR

C156

1-136-168-00 MYLAR

C157

1-136-167-00 MYLAR

0.15uF

5%

C157

1-136-168-00 MYLAR

0.18uF

5%

C158

1-136-167-00 MYLAR

0.15uF

5%

C158

1-136-168-00 MYLAR

0.18uF

5%

C159

1-162-960-11 CERAMIC CHIP

220PF

10%

C160 C163

1-162-960-11 CERAMIC CHIP 1-125-837-11 CERAMIC CHIP

C136

C001 C002 C006 C007 C008

1-136-497-81 1-136-497-81 1-126-964-11 1-126-965-11 1-126-943-11

FILM FILM ELECT ELECT ELECT

0.1uF 0.1uF 10uF 22uF 2200uF

5% 5% 20% 20% 20%

50V 50V 50V 50V 25V

C010 C011 C012 C013 C015

1-165-621-11 1-136-497-81 1-136-497-81 1-126-943-11 1-126-933-11

CERAMIC CHIP FILM FILM ELECT ELECT

0.1uF 0.1uF 0.1uF 2200uF 100uF

5% 5% 20% 20%

50V 50V 50V 25V 16V

C023 C025 C026 C027 C031

1-126-943-11 1-126-933-11 1-162-974-11 1-162-974-11 1-216-864-11

ELECT ELECT CERAMIC CHIP CERAMIC CHIP SHORT CHIP

2200uF 100uF 0.01uF 0.01uF 0

C032

1-162-964-11 CERAMIC CHIP

C033 C034 C035 C063

1-126-933-11 1-126-963-11 1-126-947-11 1-164-156-11

C064 C065

1-162-964-11 CERAMIC CHIP 1-162-964-11 CERAMIC CHIP

20% 20%

25V 16V 50V 50V

0.001uF 10% 50V (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) ELECT 100uF 20% 16V ELECT 4.7uF 20% 50V ELECT 47uF 20% 35V CERAMIC CHIP 0.1uF 25V

C068 C069

0.001uF 10% 50V 0.001uF 10% 50V (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V

C109 C110 C111 C112 C114

1-126-964-11 1-126-964-11 1-126-965-11 1-126-947-11 1-164-360-11

ELECT ELECT ELECT ELECT CERAMIC CHIP

10uF 10uF 22uF 47uF 0.1uF

20% 20% 20% 20%

50V 50V 50V 35V 16V

C115 C116 C117 C118 C119

1-126-933-11 1-126-960-11 1-162-964-11 1-126-961-11 1-126-961-11

ELECT ELECT CERAMIC CHIP ELECT ELECT

100uF 1uF 0.001uF 2.2uF 2.2uF

20% 20% 10% 20% 20%

16V 50V 50V 50V 50V

C120

1-164-360-11 CERAMIC CHIP

94

C121 C122 C123

C125 C126 C129 C130 C133

< CAPACITOR >

C066

Ref. No.

0.1uF

16V

C164

ELECT 1uF 20% 50V ELECT 1uF 20% 50V ELECT 1uF 20% 50V ELECT 1uF 20% 50V CERAMIC CHIP 0.1uF 25V (RG490: AEP, RU/RG590: AEP, UK, RU)

1uF 20% 50V (RG490/RG590: AEP, UK, RU) 0.15uF 5% 50V (RG490) 0.18uF 5% 50V (RG590) 0.15uF 5% 50V (RG490) 0.18uF 5% 50V (RG590) 50V (RG490) 50V (RG590) 50V (RG490) 50V (RG590) 50V

220PF 10% 50V 1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR) 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR)

HCD-RG490/RG590 Ver. 1.1 MAIN Ref. No. C165 C166

Part No.

Description

Remark

1-125-837-11 CERAMIC CHIP

1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR) 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR)

C167

1-104-665-11 ELECT

100uF 20% 25V (RG590: E2, E3, 51, EA, MX, AR) ELECT 100uF 20% 25V (RG590: E2, E3, 51, EA, MX, AR) CERAMIC CHIP 0.01uF 50V (RG590: E2, E3, 51, EA, MX, AR) ELECT 100uF 20% 16V (RG590: E2, E3, 51, EA, MX, AR) CERAMIC CHIP 100PF 5% 50V (RG590: E2, E3, 51, EA, MX, AR)

C168

1-104-665-11

C169

1-162-974-11

C170

1-126-933-11

C171

1-162-927-11

C172

1-162-927-11 CERAMIC CHIP

100PF 5% 50V (RG590: E2, E3, 51, EA, MX, AR) CERAMIC CHIP 47PF 5% 50V CERAMIC CHIP 47PF 5% 50V CERAMIC CHIP 1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR) CERAMIC CHIP 1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR)

C173 C174 C175

1-162-949-11 1-162-949-11 1-125-837-11

C176

1-125-837-11

C177

1-125-837-11 CERAMIC CHIP

C178

1-125-837-11

C253 C254 C255

1-162-923-11 1-162-923-11 1-162-919-11

1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR) CERAMIC CHIP 1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR) CERAMIC CHIP 47PF 5% 50V CERAMIC CHIP 47PF 5% 50V CERAMIC CHIP 22PF 5% 50V

C256 C257 C258 C259 C260

1-162-919-11 1-126-947-11 1-126-947-11 1-126-964-11 1-124-261-00

CERAMIC CHIP ELECT ELECT ELECT ELECT

22PF 47uF 47uF 10uF 10uF

5% 20% 20% 20% 20%

50V 35V 35V 50V 25V

C263 C264 C265 C266 C267

1-126-935-11 1-162-964-11 1-126-963-11 1-126-963-11 1-162-968-11

ELECT CERAMIC CHIP ELECT ELECT CERAMIC CHIP

470uF 0.001uF 4.7uF 4.7uF 0.0047uF

20% 10% 20% 20% 10%

16V 50V 50V 50V 50V

C268 C271 C273 C274 C275

1-162-968-11 1-165-176-11 1-115-467-11 1-124-261-00 1-164-362-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT CERAMIC CHIP

0.0047uF 0.047uF 0.22uF 10uF 470PF

10% 10% 10% 20% 5%

50V 16V 10V 25V 50V

C276 C278 C281 C305

1-115-467-11 1-107-826-11 1-162-974-11 1-162-964-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

C317

1-126-926-11 ELECT

C333

1-164-156-11 CERAMIC CHIP

C336

1-162-970-11 CERAMIC CHIP

C385 C386 C387

1-162-927-11 CERAMIC CHIP 1-162-927-11 CERAMIC CHIP 1-162-962-11 CERAMIC CHIP

0.1uF 25V (RG490: MX/RG590: MX) 0.01uF 10% 25V (RG490: MX/RG590: MX) 100PF 5% 50V 100PF 5% 50V 470PF 10% 50V

C388 C391

1-162-927-11 CERAMIC CHIP 1-164-156-11 CERAMIC CHIP

100PF 0.1uF

Ref. No.

Part No.

Description

Remark

C901 C902 C903

1-126-933-11 ELECT 1-126-964-11 ELECT 1-126-959-11 ELECT

100uF 10uF 0.47uF

C904 C906 C908 C909 C910

1-164-156-11 1-126-964-11 1-164-156-11 1-164-156-11 1-164-156-11

CERAMIC CHIP ELECT CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.1uF 10uF 0.1uF 0.1uF 0.1uF

C911 C912 C913 C914 C916

1-162-964-11 1-164-156-11 1-162-905-11 1-162-919-11 1-114-154-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP DOUBLE LAYER

0.001uF 0.1uF 1PF 22PF 47000uF

C917 C918 C919 C920 C921

1-164-156-11 1-162-964-11 1-164-156-11 1-162-905-11 1-126-961-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT

0.1uF 0.001uF 0.1uF 1PF 2.2uF

C922 C923 C924

1-126-963-11 ELECT 1-162-960-11 CERAMIC CHIP 1-162-927-11 CERAMIC CHIP

20% 20% 20%

20%

16V 50V 50V 25V 50V 25V 25V 25V

10%

50V 25V 0.25PF 50V 5% 50V 5.5V 25V 50V 25V 0.25PF 50V 20% 50V

10%

C926

4.7uF 20% 50V 220PF 10% 50V 100PF 5% 50V (RG490: AEP/RG590: AEP, UK) 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (RG490: AEP/RG590: AEP, UK) 1-162-960-11 CERAMIC CHIP 220PF 10% 50V

C927

1-162-919-11 CERAMIC CHIP

C925

22PF

5%

50V

< CONNECTOR > * CN031 CN041 CN061 CN061

0.22uF 10% 10V 0.1uF 10% 16V 0.01uF 50V 0.001uF 10% 50V (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 1000uF 20% 10V

5%

50V 25V

CN091 CN201 CN301 CN302 CN331 CN991

1-573-094-11 SOCKET, CONNECTOR 13P 1-819-131-11 PIN, CONNECTOR 3P 1-568-828-11 CONNECTOR, FFC 9P (RG490: AEP, RU, E3, EA, AUS/RG590: AEP, UK, RU, E3, EA) 1-784-774-11 CONNECTOR, FFC 13P (RG490: E2, E51, MX, AR/RG590: E2, E51, MX, AR) 1-568-828-11 CONNECTOR FFC 9P, 1-568-830-11 CONNECTOR, FFC11P 1-779-291-11 CONNECTOR, FFC (LIF (NON-ZIF)) 23P (EXCEPT RG490: MX/RG590: MX) 1-779-299-11 CONNECTOR, FFC (LIF (NON-ZIF)) 31P (RG490: MX/RG590: MX) 1-784-774-11 CONNECTOR, FFC 13P (RG490: MX/RG590: MX) 1-784-780-11 CONNECTOR, FFC 19P < DIODE >

D001 D002 D003 D004 D006

6-500-522-21 6-500-522-21 6-500-522-21 6-500-522-21 8-719-988-61

DIODE DIODE DIODE DIODE DIODE

10EDB40-TB3 10EDB40-TB3 10EDB40-TB3 10EDB40-TB3 1SS355TE-17

D007 D008 D009 D011 D012

6-501-166-01 8-719-000-08 6-500-335-01 6-500-522-21 6-500-522-21

DIODE DIODE DIODE DIODE DIODE

UDZW-TE17-4.7B MC2838 MC2838-T112-1 10EDB40-TB3 10EDB40-TB3

D013 D014 D021 D022

6-500-522-21 6-500-522-21 6-500-522-21 6-500-522-21

DIODE DIODE DIODE DIODE

10EDB40-TB3 10EDB40-TB3 10EDB40-TB3 10EDB40-TB3

95

HCD-RG490/RG590 Ver. 1.1 MAIN Ref. No.

Part No.

Description

Remark

Ref. No.

Part No.

Description

Remark

< TRANSISTOR >

D023

6-500-522-21 DIODE 10EDB40-TB3

D024 D031 D035 D036 D301

6-500-522-21 8-719-988-61 8-719-000-08 8-719-000-07 6-500-522-21

10EDB40-TB3 1SS355TE-17 MC2838 MC2836 10EDB40-TB3

Q002 Q011 Q041 Q042 Q043

8-729-120-28 8-729-027-43 8-729-120-28 8-729-037-13 8-729-037-03

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SC1623-L5L6 DTC114EKA-T146 2SC1623-L5L6 KTA1271Y KTA1266GR-AT

D302 D303 D901 D902 D905

6-500-522-21 DIODE 10EDB40-TB3 6-501-166-01 DIODE UDZW-TE17-4.7B (RG490: MX/RG590: MX) 6-501-166-01 DIODE UDZW-TE17-4.7B 8-719-000-07 DIODE MC2836 8-719-988-61 DIODE 1SS355TE-17

Q044 Q045 Q046 Q111 Q112

8-729-120-28 8-729-120-28 8-729-045-62 8-729-120-28 8-729-120-28

TRANSISTOR TRANSISTOR FET TRANSISTOR TRANSISTOR

2SC1623-L5L6 2SC1623-L5L6 2SK2158-T2B 2SC1623-L5L6 2SC1623-L5L6

D910 D921 D923 D943 D947

8-719-988-61 6-500-848-01 6-500-848-01 8-719-000-08 8-719-988-61

Q113 Q114 Q251 Q252 Q261

8-729-120-28 8-729-120-28 8-729-120-28 8-729-120-28 8-729-027-23

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SC1623-L5L6 2SC1623-L5L6 2SC1623-L5L6 2SC1623-L5L6 DTA114EKA-T146

Q271 Q272 Q274 Q276 Q277

8-729-120-28 8-729-120-28 6-551-276-01 8-729-120-28 8-729-120-28

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SC1623-L5L6 2SC1623-L5L6 RT1N431C-TP-1 2SC1623-L5L6 2SC1623-L5L6

Q901 Q902 Q903 Q904

8-729-120-28 8-729-120-28 8-729-037-13 8-729-120-28

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SC1623-L5L6 2SC1623-L5L6 KTA1271Y 2SC1623-L5L6

DIODE DIODE DIODE DIODE DIODE

DIODE DIODE DIODE DIODE DIODE

1SS355TE-17 MC2840-T112-1 MC2840-T112-1 MC2838 1SS355TE-17

< IC > IC006 IC011 IC021 IC101 IC102

6-702-771-01 8-759-701-59 8-759-701-59 6-709-331-01 6-709-330-01

IC IC IC IC IC

TA78033LS NJM78M09FA NJM78M09FA R2S15207FP R2S15208SP (RG590: E2, E3, E51, EA, MX, AR)

IC251 IC901 IC902

8-759-909-71 IC BA4558F (Not supplied) IC uPD78F0547GC (S)-UBT-A 8-759-713-61 IC PST3429UL < JUMPER RESISTOR >

JR101

1-216-864-11 SHORT CHIP

JR102

1-216-864-11 SHORT CHIP

JR103 JR104 JR105

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP

JR106 JR107 JR108 JR109 JR110

1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11

SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP

0 0 0 0 0

JR111 JR112 JR113 JR114 JR115

1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11

SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP

0 0 0 (RG490: MX/RG590: MX) 0 0

JR116 JR117 JR118 JR119 JR120

1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11

SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP

JR121 JR122 JR123

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP

96

0 (RG490: AEP, RU, E3, EA, AUS/RG590: AEP, UK, RU, E3, EA) 0 (RG490: AEP, RU, E3, EA, AUS/RG590: AEP, UK, RU, E3, EA) 0 0 0

0 (RG490: MX/RG590: MX) 0 0 0 0 (EXCEPT RG490: MX/RG590: MX) 0 0 0

Note: IC901 on the MAIN board cannot exchange with single. When IC901 is damaged, exchange the entire mounted board.

< RESISTOR > R001 R005 R006 R010 R011

1-216-801-11 1-216-829-11 1-216-829-11 1-216-837-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22 4.7K 4.7K 22K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R013 R014 R016 R032 R033

1-216-837-11 1-216-833-11 1-216-845-11 1-216-821-11 1-216-837-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 10K 100K 1K 22K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R034 R035 R036 R037 R039

1-216-837-11 1-216-829-11 1-216-829-11 1-216-829-11 1-260-308-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP CARBON

22K 4.7K 4.7K 4.7K 22

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/2W

R041 R042 R043 R045 R046

1-216-864-11 1-216-833-11 1-216-829-11 1-216-821-11 1-216-793-11

SHORT CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

0 10K 4.7K 1K 4.7

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

R047 R048 R049 R050 R051

1-216-789-11 1-216-801-11 1-216-849-11 1-216-825-11 1-216-825-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

2.2 22 220K 2.2K 2.2K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R052 R053 R054 R055 R056

1-216-853-11 1-216-837-11 1-216-837-11 1-216-825-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

470K 22K 22K 2.2K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

HCD-RG490/RG590 Ver. 1.1 MAIN Ref. No.

Part No.

Description

R057 0 R059 0 R060 R061 R063

1-216-821-11 1-215-892-11 1-215-892-11 1-216-797-11 1-216-809-11

METAL CHIP METAL OXIDE METAL OXIDE METAL CHIP METAL CHIP

R064 R068

1-216-809-11 METAL CHIP 1-216-797-11 METAL CHIP

1K 1K 1K 10 100

5% 5% 5% 5% 5%

Remark

Ref. No.

1/10W 2W F 2W F 1/10W 1/10W

R133

1-216-864-11 SHORT CHIP

R134

1-216-864-11 SHORT CHIP

R135 R136 R137

1-216-833-11 METAL CHIP 1-216-833-11 METAL CHIP 1-216-825-11 METAL CHIP

0 (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 0 (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 10K 5% 1/10W 10K 5% 1/10W 2.2K 5% 1/10W

R138 R139 R140 R141 R142

1-216-825-11 1-216-821-11 1-216-821-11 1-216-837-11 1-216-837-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

2.2K 1K 1K 22K 22K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R143 R144 R145 R147 R148

1-216-813-11 1-216-813-11 1-216-841-11 1-216-841-11 1-216-841-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

220 220 47K 47K 47K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R151

1-216-809-11 METAL CHIP

R152

1-216-809-11 METAL CHIP

R153

1-216-809-11 METAL CHIP

R154 R155

1-216-857-11 METAL CHIP 1-216-849-11 METAL CHIP

R156 R157 R158 R159 R160

1-216-849-11 1-216-849-11 1-216-849-11 1-216-841-11 1-216-841-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

220K 220K 220K 47K 47K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R161 R162 R163 R164 R165

1-216-837-11 1-216-837-11 1-216-841-11 1-216-841-11 1-216-829-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 22K 47K 47K 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R166 R167 R168 R171 R172

1-216-829-11 1-216-821-11 1-216-821-11 1-216-864-11 1-216-864-11

METAL CHIP METAL CHIP METAL CHIP SHORT CHIP SHORT CHIP

4.7K 1K 1K 0 0

5% 5% 5%

1/10W 1/10W 1/10W

R175 R176 R177 R178 R201

1-216-825-11 1-216-825-11 1-216-864-11 1-216-864-11 1-216-825-11

METAL CHIP METAL CHIP SHORT CHIP SHORT CHIP METAL CHIP

2.2K 2.2K 0 0 2.2K

5% 5%

1/10W 1/10W

5%

1/10W

R202 R250

1-216-825-11 METAL CHIP 1-216-829-11 METAL CHIP

2.2K 4.7K

5% 5%

R250

1-216-833-11 METAL CHIP

10K

5%

R251 R252

1-216-817-11 METAL CHIP 1-216-817-11 METAL CHIP

470 470

5% 5%

1/10W 1/10W (RG490) 1/10W (RG590) 1/10W 1/10W

R253

1-216-829-11 METAL CHIP

4.7K

5%

R253

1-216-833-11 METAL CHIP

10K

5%

R254

1-216-826-11 METAL CHIP

2.7K

5%

R254

1-216-829-11 METAL CHIP

4.7K

5%

100 5% 1/10W 10 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 10K 5% 1/10W 10K 5% 1/10W 1K 5% 1/10W

R070 R101 R102

1-216-833-11 METAL CHIP 1-216-833-11 METAL CHIP 1-216-821-11 METAL CHIP

R103 R104 R105 R106

1-216-833-11 1-216-833-11 1-216-809-11 1-216-821-11

R108

1-216-825-11 METAL CHIP

10K 5% 1/10W 10K 5% 1/10W 100 5% 1/10W 1K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 2.2K 5% 1/10W

R109 R110 R111 R112 R113

1-216-829-11 1-216-841-11 1-216-845-11 1-216-817-11 1-216-829-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 47K 100K 470 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R114 R116 R119 R120 R121

1-216-825-11 1-216-809-11 1-216-817-11 1-216-817-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

2.2K 100 470 470 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R122 R123 R124 R125 R126

1-216-809-11 1-216-825-11 1-216-825-11 1-216-829-11 1-216-829-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 2.2K 2.2K 4.7K 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R127

1-216-821-11 METAL CHIP

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

R127

1-216-825-11 METAL CHIP

R128

1-216-821-11 METAL CHIP

R128

1-216-825-11 METAL CHIP

R129

1-216-841-11 METAL CHIP

R129

1-216-853-11 METAL CHIP

R130

1-216-841-11 METAL CHIP

R130

1-216-853-11 METAL CHIP

R131 R132

1-216-809-11 METAL CHIP 1-216-809-11 METAL CHIP

5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 2.2K 5% 1/10W (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 1K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 2.2K 5% 1/10W (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 47K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR)

Part No.

Description

Remark

100 5% 1/10W (RG590: E2, E3, E51, EA, MX, AR) 100 5% 1/10W (RG590: E2, E3, E51, EA, MX, AR) 100 5% 1/10W (RG590: E2, E3, E51, EA, MX, AR) 1M 5% 1/10W 220K 5% 1/10W

1K

470K 5% 1/10W (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 47K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 470K 5% 1/10W (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 100 5% 1/10W 100 5% 1/10W

1/10W (RG490) 1/10W (RG590) 1/10W (RG490) 1/10W (RG590)

97

HCD-RG490/RG590 Ver. 1.1 MAIN Ref. No.

Part No.

Description

Remark

1-216-821-11 METAL CHIP

R340

1-216-821-11 METAL CHIP

R341

1-216-833-11 METAL CHIP

R342 R343 R344 R345 R346

1-216-821-11 1-216-837-11 1-216-837-11 1-216-833-11 1-216-821-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

1K 22K 22K 10K 1K

R347 R348 R349 R350

1-216-837-11 1-216-837-11 1-216-833-11 1-216-821-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 22K 10K 1K

R351

1-216-825-11 METAL CHIP

2.2K

R351

1-216-833-11

R351

1-216-845-11

R352

1-216-821-11

R352

1-216-833-11

R352

1-216-853-11 METAL CHIP

R353 R354

1-216-833-11 METAL CHIP 1-216-821-11 METAL CHIP

R354

1-216-837-11 METAL CHIP

5% 1/10W (RG490: MX/RG590: MX) 100 5% 1/10W 100 5% 1/10W 100 5% 1/10W 100 5% 1/10W

R355

1-216-825-11 METAL CHIP

R355

1-216-829-11 METAL CHIP

R355

1-216-837-11 METAL CHIP

22K 22K 100

5% 1/10W 5% 1/10W 5% 1/10W (RG490: MX/RG590: MX) 1K 5% 1/10W (RG490: MX/RG590: MX) 100 5% 1/10W (RG490: MX/RG590: MX)

R356

1-216-857-11 METAL CHIP

R363 R364

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP

5% 1/10W (RG590: AEP, UK, RU) 22K 5% 1/10W (RG490) 1M 5% 1/10W (RG490/RG590: AEP, UK, RU) 0 0

R365 R366 R372

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP 1-216-809-11 METAL CHIP

0 0 100

100

R381 R382

1-216-821-11 METAL CHIP 1-216-821-11 METAL CHIP

5% 1/10W (RG490: MX/RG590: MX) 1K 5% 1/10W 1K 5% 1/10W

R383 R901 R902 R903 R904

1-216-821-11 1-216-845-11 1-216-864-11 1-216-833-11 1-216-825-11

METAL CHIP METAL CHIP SHORT CHIP METAL CHIP METAL CHIP

1K 100K 0 10K 2.2K

5% 5%

1/10W 1/10W

5% 5%

1/10W 1/10W

R905 R907 R908 R909

1-216-833-11 1-216-841-11 1-216-841-11 1-216-837-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10K 47K 47K 22K

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

1/10W (RG490)

R257

1-216-829-11 METAL CHIP

4.7K

5%

R261 R262 R263 R264

1-216-833-11 1-216-833-11 1-216-825-11 1-216-825-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10K 10K 2.2K 2.2K

5% 5% 5% 5%

1/10W (RG590) 1/10W 1/10W 1/10W 1/10W

R265 R267 R268 R269 R271

1-216-809-11 1-216-841-11 1-216-829-11 1-216-825-11 1-216-864-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP SHORT CHIP

100 47K 4.7K 2.2K 0

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

R272 R274 R276 R277 R279

1-216-829-11 1-216-829-11 1-216-833-11 1-216-825-11 1-216-825-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 4.7K 10K 2.2K 2.2K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R280 R281 R283 R285 R286

1-216-829-11 1-216-825-11 1-216-833-11 1-216-833-11 1-216-837-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 2.2K 10K 10K 22K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R287 R289 R290 R291 R292

1-216-853-11 1-216-845-11 1-216-821-11 1-216-825-11 1-216-825-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

470K 100K 1K 2.2K 2.2K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R315 R316 R317 R318 R319

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R320

1-216-809-11 METAL CHIP

100

R321 R322 R323 R324

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

R325 R326 R329

1-216-837-11 METAL CHIP 1-216-837-11 METAL CHIP 1-216-809-11 METAL CHIP

R330

1-216-821-11 METAL CHIP

R331

1-216-809-11 METAL CHIP

R333

1-216-833-11 METAL CHIP

R334

1-216-809-11 METAL CHIP

R335

1-216-809-11 METAL CHIP

R336

1-216-833-11 METAL CHIP

R337

98

1-216-809-11 METAL CHIP

Remark

R339

5%

1-216-809-11 METAL CHIP

Description

5% 1/10W (RG490: MX/RG590: MX) 1K 5% 1/10W (RG490: MX/RG590: MX) 1K 5% 1/10W (RG490: MX/RG590: MX) 10K 5% 1/10W

2.7K

R332

Part No.

1-216-809-11 METAL CHIP

1-216-826-11 METAL CHIP

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

Ref. No. R338

R257

5% 1/10W (RG490: MX/RG590: MX) 10K 5% 1/10W (RG490: MX/RG590: MX) 100 5% 1/10W (RG490: MX/RG590: MX) 100 5% 1/10W (RG490: MX/RG590: MX) 10K 5% 1/10W (RG490: MX/RG590: MX) 100

5% 1/10W (RG490: MX/RG590: MX)

R350

100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

5% 1/10W 5% 1/10W 5% 1/10W 5% 1/10W (RG490: RU/RG590: RU) 1-216-833-11 METAL CHIP 10K 5% 1/10W (RG490: E2, E51, EA, AR/RG590: E2, E51, EA, AR) 5% 1/10W (RG490: RU/RG590: RU) METAL CHIP 10K 5% 1/10W (RG490: E2, E51, AR/RG590: E2, E51, AR) METAL CHIP 100K 5% 1/10W (RG490: EA/RG590: EA) METAL CHIP 1K 5% 1/10W (RG490: AEP/RG590: AEP, UK) METAL CHIP 10K 5% 1/10W (RG490: MX/RG590: MX) 470K

5% 1/10W (RG490: EA/RG590: EA) 10K 5% 1/10W 1K 5% 1/10W (RG590) 22K 5% 1/10W (RG490) 2.2K 5% 1/10W (RG590: E2, E3, E51, EA, MX, AR) 4.7K

HCD-RG490/RG590 MAIN Ref. No.

Part No.

Description

Remark

Ref. No. R981 R982 R996 R997 R999

Part No.

Description

1-216-809-11 1-216-817-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

R910

1-216-833-11 METAL CHIP

10K

5%

1/10W

R911 R912 R913 R914 R918

1-216-821-11 1-216-821-11 1-216-821-11 1-216-833-11 1-216-849-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

1K 1K 1K 10K 220K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R919 R920 R921 R922 R923

1-216-864-11 1-216-853-11 1-216-809-11 1-216-849-11 1-216-809-11

SHORT CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

0 470K 100 220K 100

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

R924 R925

1-216-809-11 METAL CHIP 1-216-809-11 METAL CHIP

R925

1-216-821-11 METAL CHIP

R932 R935

1-216-825-11 METAL CHIP 1-216-833-11 METAL CHIP

R936 R941 R942 R943 R944

1-216-837-11 1-216-825-11 1-216-833-11 1-216-829-11 1-216-849-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 2.2K 10K 4.7K 220K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

C781

1-162-964-11 CERAMIC CHIP

C781

1-162-966-11 CERAMIC CHIP

R945 R946 R947 R948 R949

1-216-813-11 1-216-864-11 1-216-849-11 1-216-825-11 1-216-833-11

METAL CHIP SHORT CHIP METAL CHIP METAL CHIP METAL CHIP

220 0 220K 2.2K 10K

5%

1/10W

C782

1-162-964-11 CERAMIC CHIP

5% 5% 5%

1/10W 1/10W 1/10W

C782

1-162-966-11 CERAMIC CHIP

R950 R951 R952 R953 R955

1-216-829-11 1-216-813-11 1-216-841-11 1-216-833-11 1-216-821-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 220 47K 10K 1K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

C783

1-165-621-11 CERAMIC CHIP

C784 C801

1-165-621-11 CERAMIC CHIP 1-126-157-11 ELECT

R956 R957 R959 R961

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100

C802

1-115-416-11 CERAMIC CHIP

C803

1-136-157-00 FILM

R961

1-216-821-11 METAL CHIP

C805

1-136-157-00 FILM

C807

1-115-416-11 CERAMIC CHIP

C808

1-164-230-11 CERAMIC CHIP

C809

1-126-157-11 ELECT

C810

1-164-315-11 CERAMIC CHIP

C811

1-124-463-00 ELECT

C813

1-125-972-11 ELECT

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100

R969

1-216-809-11 METAL CHIP

5% 1/10W 5% 1/10W 5% 1/10W 5% 1/10W (RG490: MX/RG590: MX) 100 5% 1/10W

R970 R971 R972 R973 R974

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100 100

R975 R976 R977

1-216-809-11 METAL CHIP 1-216-809-11 METAL CHIP 1-216-809-11 METAL CHIP

100 100 100

R979 R980

1-216-809-11 METAL CHIP 1-216-809-11 METAL CHIP

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

5% 1/10W 5% 1/10W 5% 1/10W (RG490: MX/RG590: MX) 100 5% 1/10W 100 5% 1/10W

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

X901 1-579-463-11 VIBRATOR, CRYSTAL (32.768kHz) X902 1-795-482-11 VIBRATOR, CERAMIC (16MHz) ************************************************************ A-1159-739-A MIC. AUX. HP BOARD, COMPLETE(RG490: AEP, RU, E3, EA, AUS/RG590: AEP, UK, RU, E3, EA) A-1159-740-A MIC. AUX. HP BOARD, COMPLETE (RG490: E2, E51, AR/RG590: E2, E51, AR) A-1159-741-A MIC. AUX. HP BOARD, COMPLETE (RG490: MX/RG590: MX) ***************************

5% 1/10W 5% 1/10W (RG490: MX/RG590: MX) 1K 5% 1/10W (RG490: AEP/RG590: AEP, UK) 2.2K 5% 1/10W 10K 5% 1/10W

R963 R965 R967 R968

Remark 100 470 100 100 100

< VIBRATOR >

100 100

5% 1/10W 5% 1/10W 5% 1/10W 5% 1/10W (RG490: MX/RG590: MX) 1K 5% 1/10W (RG490: AEP/RG590: AEP, UK)

Ver. 1.1 MIC. AUX. HP

< CAPACITOR > 0.001uF 10% 50V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 0.0022uF 10% 50V (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 0.001uF 10% 50V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 0.0022uF 10% 50V (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 0.1uF 50V 0.1uF 50V 10uF 20% 16V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 0.001uF 5% 25V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 0.022uF 5% 50V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 0.022uF 5% 50V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 0.001uF 5% 25V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 220PF 5% 50V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 10uF 20% 16V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 470PF 5% 50V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 0.1uF 20% 50V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 100uF 20% 16V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR)

99

HCD-RG490/RG590 Ver. 1.1 MIC. AUX. HP Ref. No.

Part No.

Description

C814

1-124-257-00 ELECT

C815

1-162-923-11 CERAMIC CHIP

C816

1-164-816-11 CERAMIC CHIP

C817

1-124-257-00 ELECT

C818

1-126-157-11 ELECT

C819

1-164-156-11 CERAMIC CHIP

C820

1-162-964-11 CERAMIC CHIP

C821

1-162-964-11 CERAMIC CHIP

C833

1-164-156-11 CERAMIC CHIP

Remark 2.2uF 20% 50V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 47PF 5% 50V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 220PF 2% 50V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 2.2uF 20% 50V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 10uF 20% 16V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 0.1uF 25V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 0.001uF 10% 50V (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 0.001uF 10% 50V (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 0.1uF 25V (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR)

Ref. No.

1-126-160-11 ELECT

C852

1-162-964-11 CERAMIC CHIP

C853

1-165-176-11 CERAMIC CHIP

C854

1-164-227-11 CERAMIC CHIP

C856

1-162-968-11 CERAMIC CHIP

C857

1-124-465-00 ELECT

C858

1-124-465-00 ELECT

C859

1-107-826-11 CERAMIC CHIP

C861

1-126-160-11 ELECT

C862

1-165-176-11 CERAMIC CHIP

C863

1-124-257-00 ELECT

C864

1-162-964-11 CERAMIC CHIP

C865

1-162-968-11 CERAMIC CHIP

C867

1-165-176-11 CERAMIC CHIP

C868

1-164-227-11 CERAMIC CHIP

C869

1-124-589-11 ELECT

C870

1-124-589-11 ELECT

100

20% 50V (RG490: MX/RG590: MX) 0.001uF 10% 50V (RG490: MX/RG590: MX) 0.047uF 10% 16V (RG490: MX/RG590: MX) 0.022uF 10% 25V (RG490: MX/RG590: MX) 0.0047uF 10% 50V (RG490: MX/RG590: MX)

D851

2.2uF 20% 50V (RG490: MX/RG590: MX) 0.001uF 10% 50V (RG490: MX/RG590: MX) 0.0047uF 10% 50V (RG490: MX/RG590: MX) 0.047uF 10% 16V (RG490: MX/RG590: MX) 0.022uF 10% 25V (RG490: MX/RG590: MX) 47uF 20% 16V (RG490: MX/RG590: MX) 47uF 20% 16V (RG490: MX/RG590: MX)

Remark

6-501-167-01 DIODE UDZW-TE17-5.1B (RG490: MX/RG590: MX) < EARTH TERMINAL >

* EP701 * EP801

1-537-738-21 TERMINAL, EARTH 1-537-738-21 TERMINAL, EARTH(RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) < IC >

IC801 IC802

8-759-909-71 IC BA4558F (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 8-759-496-41 IC M65850FP-E1 (RG490: MX/RG590: MX) < JACK >

J701 J702 JK801 JK802 JK802

1-794-702-11 1-794-702-11 1-816-573-11 1-816-573-11

JACK, HEADPHONE (PHONES) JACK, HEADPHONE AUDIO IN) JACK (MIC 1) (RG490: MX/RG590: MX) JACK (MIC) (RG490: E2, E51, AR/RG590: E2, E51, AR) 1-816-573-11 JACK (MIC 2) (RG490: MX/RG590: MX) < JUMPER RESISTOR >

1uF

0.47uF 20% 50V (RG490: MX/RG590: MX) 0.47uF 20% 50V (RG490: MX/RG590: MX) 0.1uF 10% 16V (RG490: MX/RG590: MX) 1uF 20% 50V (RG490: MX/RG590: MX) 0.047uF 10% 16V (RG490: MX/RG590: MX)

Description < DIODE >

JR801 C851

Part No.

JR802

1-216-864-11 SHORT CHIP 0 (RG490: E2, E51, AR/RG590: E2, E51, AR) 1-216-864-11 SHORT CHIP 0 (RG490: E2, E51, AR/RG590: E2, E51, AR) < TRANSISTOR >

Q801

8-729-120-28 TRANSISTOR 2SC1623-L5L6 (RG490: E2, E51, MX, AR/RG590: E2, E51, MX, AR) < RESISTOR >

R801

1-216-829-11 METAL CHIP

R802 R803

1-216-864-11 SHORT CHIP 1-216-829-11 METAL CHIP

R804

1-216-864-11 SHORT CHIP

R805

1-216-845-11 METAL CHIP

R806

1-216-845-11 METAL CHIP

R807

1-216-833-11 METAL CHIP

R808

1-216-833-11 METAL CHIP

R809

1-216-845-11 METAL CHIP

R810

1-216-821-11 METAL CHIP

4.7K 5% 1/10W (RG490: MX/RG590: MX) 0 (RG490: MX/RG590: MX) 4.7K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 0 (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 100K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 100K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 10K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 10K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 100K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 1K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR)

HCD-RG490/RG590 MIC. AUX. HP Ref. No. R811

Part No.

Description

1-216-841-11 METAL CHIP

R812

1-216-809-11 METAL CHIP

R813

1-216-833-11 METAL CHIP

R814

1-216-849-11 METAL CHIP

R815

1-216-809-11 METAL CHIP

R816

1-216-845-11 METAL CHIP

R817

1-216-829-11 METAL CHIP

R818

1-216-829-11 METAL CHIP

R819

1-216-853-11 METAL CHIP

R820

1-216-837-11 METAL CHIP

R821

1-216-833-11 METAL CHIP

R823 R824 R825 R826

1-216-825-11 1-216-837-11 1-216-821-11 1-216-821-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

R827 R831 R832 R851

1-216-833-11 1-216-853-11 1-216-853-11 1-216-837-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

R852

1-216-837-11 METAL CHIP

R853

1-216-837-11 METAL CHIP

R854

1-216-841-11 METAL CHIP

R855

1-216-837-11 METAL CHIP

R856

1-216-833-11 METAL CHIP

R857

1-216-837-11 METAL CHIP

R858

1-216-837-11 METAL CHIP

R859

1-216-837-11 METAL CHIP

R860

1-216-845-11 METAL CHIP

R861

1-216-817-11 METAL CHIP

R862

1-216-817-11 METAL CHIP

Remark 47K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 100 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 10K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 220K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 100 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 100K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 4.7K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 4.7K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 470K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 22K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 10K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 2.2K 5% 1/10W 22K 5% 1/10W 1K 5% 1/10W 1K 5% 1/10W 10K 5% 1/10W 470K 5% 1/10W 470K 5% 1/10W 22K 5% 1/10W (RG490: MX/RG590: MX) 22K 5% 1/10W (RG490: MX/RG590: MX) 22K

5% 1/10W (RG490: MX/RG590: MX) 47K 5% 1/10W (RG490: MX/RG590: MX) 22K 5% 1/10W (RG490: MX/RG590: MX) 10K 5% 1/10W (RG490: MX/RG590: MX) 22K 5% 1/10W (RG490: MX/RG590: MX) 5% 1/10W (RG490: MX/RG590: MX) 22K 5% 1/10W (RG490: MX/RG590: MX) 100K 5% 1/10W (RG490: MX/RG590: MX) 470 5% 1/10W (RG490: MX/RG590: MX) 470 5% 1/10W (RG490: MX/RG590: MX)

Ref. No.

MOTOR (LD)

Part No.

MOTOR (TB)

Description

Ver. 1.1 Remark

< VARIABLE RESISTOR > VR801

1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL) (RG490: E2, E51, MX, AR/RG590: E2, E51, MX, AR) VR851 1-223-983-11 RES, VAR, CARBON 50K (ECHO LEVEL) (RG490: MX/RG590: MX) ************************************************************ 1-687-133-12 MOTOR (LD) BOARD ***************** ************************************************************ 1-687-134-12 MOTOR (TB) BOARD ***************** < CONNECTOR > CN742 1-784-727-11 CONNECTOR, FFC 5P ************************************************************ A-1159-666-A BOARD, COMPLETE(RG490: AEP, RU, E2, E3, E51, EA, AR, AUS/RG590: AEP, UK, RU) A-1159-667-A BOARD, COMPLETE (RG590: E2, E3, E51, EA, AR) A-1159-668-A BOARD, COMPLETE (RG590: MX) A-1163-174-A BOARD, COMPLETE (RG490: MX) ********************** 2-658-282-01 FL GUIDE < CAPACITOR > C621 C622 C625 C631 C641

1-126-961-11 1-126-961-11 1-128-131-11 1-126-947-11 1-162-970-11

ELECT ELECT ELECT ELECT CERAMIC CHIP

2.2uF 2.2uF 22uF 47uF 0.01uF

20% 20% 20% 20% 10%

50V 50V 50V 35V 25V

C642 C701 C702 C703 C704

1-162-970-11 1-164-156-11 1-126-947-11 1-164-156-11 1-162-962-11

CERAMIC CHIP CERAMIC CHIP ELECT CERAMIC CHIP CERAMIC CHIP

0.01uF 0.1uF 47uF 0.1uF 470PF

10%

10%

25V 25V 35V 25V 50V

C705 C707 C708 C709 C710

1-162-962-11 1-162-968-11 1-164-156-11 1-126-947-11 1-164-156-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT CERAMIC CHIP

470PF 10% 0.0047uF 10% 0.1uF 47uF 20% 0.1uF

50V 50V 25V 35V 25V

C711 C712

1-165-621-11 CERAMIC CHIP 1-126-965-11 ELECT

0.1uF 22uF

50V 50V

20%

20%

< CONNECTOR > CN601 * CN606

22K

1-784-780-11 CONNECTOR, FFC 19P 1-815-553-11 PIN, CONNECTOR (PWB) 5P (RG590: E2, E3, E51, EA, MX, AR) < DIODE >

D601 D601 D602

6-501-451-01 LED 1L4344B22COCDT02 (STREAM) (RG590: E2, E3, E51, EA, MX, AR) 6-501-452-01 LED 1L4345V22DOTDT02 (STREAM) (RG490/RG590: AEP, UK, RU) 6-501-451-01 LED 1L4344B22COCDT02 (STREAM) (RG590: E2, E3, E51, EA, MX, AR)

101

HCD-RG490/RG590 Ver. 1.1 Ref. No. D602 D603

D603 D604 D604 D605 D605

D711

Part No.

Description

Remark

6-501-452-01 LED 1L4345V22DOTDT02 (STREAM) (RG490/RG590: AEP, UK, RU) 6-501-451-01 LED 1L4344B22COCDT02 (STREAM) (RG590: E2, E3, E51, EA, MX, AR) 6-501-452-01 LED 1L4345V22DOTDT02 (STREAM) (RG490/RG590: AEP, UK, RU) 6-501-451-01 LED 1L4344B22COCDT02 (STREAM) (RG590: E2, E3, E51, EA, MX, AR) 6-501-452-01 LED 1L4345V22DOTDT02 (STREAM) (RG490/RG590: AEP, UK, RU) 6-501-451-01 LED 1L4344B22COCDT02 (STREAM) (RG590: E2, E3, E51, EA, MX, AR) 6-501-452-01 LED 1L4345V22DOTDT02 (STREAM) (RG490/RG590: AEP, UK, RU) 8-719-000-07 DIODE MC2836 < FLUORESCENT INDICATOR >

FL701 FL701

1-519-871-11 INDICATOR TUBE, FLUORESCENT (RG490/RG590: AEP, UK, RU) 1-519-872-11 INDICATOR TUBE, FLUORESCENT (RG590: E2, E3, E51, EA, MX, AR) < IC >

IC610 IC701

6-600-446-01 IC RPM7240-H18 6-806-287-01 IC uPD780232GC-509-8BT-A < JUMPER RESISTOR >

JR602 JR603 JR604 JR605 JR606

1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11

SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP

0 0 0 0 0

JR607 JR608 JR609 JR610 JR611

1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11

SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP

0 0 0 0 0

JR612 JR613 JR614

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP

0 0 0

Ref. No.

Q601 Q602 Q603 Q604 Q605

8-729-120-28 8-729-120-28 8-729-120-28 8-729-120-28 8-729-120-28

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SC1623-L5L6 2SC1623-L5L6 2SC1623-L5L6 2SC1623-L5L6 2SC1623-L5L6

Q621 Q701 Q702 Q703 Q704

8-729-120-28 6-551-276-01 6-551-276-01 6-551-276-01 8-729-040-76

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SC1623-L5L6 RT1N431C-TP-1 RT1N431C-TP-1 RT1N431C-TP-1 KTA1273-Y-AT

Q705 Q706

8-729-037-13 TRANSISTOR 8-729-037-13 TRANSISTOR

KTA1271Y KTA1271Y

5% 5% 5%

1/10W 1/10W 1/10W

R607 R608 R609 R610 R611

1-216-833-11 1-216-833-11 1-216-809-11 1-216-845-11 1-216-821-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10K 10K 100 100K 1K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R612 R613 R614 R615 R617

1-216-821-11 1-216-821-11 1-216-821-11 1-216-821-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

1K 1K 1K 1K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R618 R627 R628 R629 R631

1-216-833-11 1-216-809-11 1-216-805-11 1-216-809-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10K 100 47 100 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R632 R633 R634 R635 R647

1-216-833-11 1-216-833-11 1-216-833-11 1-216-833-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10K 10K 10K 10K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R650 R651 R660 R661 R662

1-216-837-11 1-216-841-11 1-216-837-11 1-216-841-11 1-216-825-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 47K 22K 47K 2.2K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R663 R670 R671 R672 R673

1-216-825-11 1-216-837-11 1-216-841-11 1-216-825-11 1-216-825-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

2.2K 22K 47K 2.2K 2.2K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R674 R680 R681 R690

1-216-829-11 1-216-837-11 1-216-841-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

102

1K 1K

5% 5%

1/10W 1/10W

4.7K 5% 1/10W 22K 5% 1/10W 47K 5% 1/10W 10K 5% 1/10W (RG490/RG590: AEP, UK, RU) 1-216-837-11 METAL CHIP 22K 5% 1/10W (RG590: E2, E3, E51, EA, MX, AR)

R691

1-216-841-11 METAL CHIP

R701 R702 R703 R704

1-216-864-11 1-216-813-11 1-216-809-11 1-216-864-11

SHORT CHIP METAL CHIP METAL CHIP SHORT CHIP

R705 R706 R707 R708 R709

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11 1-216-825-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

R710 R711 R712 R713

1-216-821-11 1-216-821-11 1-216-821-11 1-216-821-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

R713 1-216-821-11 METAL CHIP 1-216-821-11 METAL CHIP

Remark 1K 1K 1K

< RESISTOR > R601 R602

Description

1-216-821-11 METAL CHIP 1-216-821-11 METAL CHIP 1-216-821-11 METAL CHIP

R690

< TRANSISTOR >

Part No.

R603 R604 R605

47K 5% 1/10W (RG590: E2, E3, E51, EA, MX, AR) 0 220 5% 1/10W 100 5% 1/10W 0 100 100 100 100 2.2K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

1K 5% 1/10W 1K 5% 1/10W 1K 5% 1/10W 1K 5% 1/10W (RG590: E2, E3, E51, EA, MX, AR) 1-216-864-11 SHORT CHIP 0 (RG490/RG590: AEP, UK, RU)

HCD-RG490/RG590 Ref. No.

Remark

Ref. No.

Part No.

Description

R715 R716 R717 R718 R719

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

C405

1-137-841-11 ELECT

C405

1-137-847-21 ELECT

C406

1-135-928-21 ELECT

R741 R742 R743 R744 R745

1-216-801-11 1-216-801-11 1-216-837-11 1-216-837-11 1-216-829-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22 22 22K 22K 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

C406

1-137-840-11 ELECT

C406

1-137-841-11 ELECT

C406

1-137-847-21 ELECT

R746 R762 R763 R764 R765

1-216-829-11 1-216-841-11 1-216-825-11 1-216-841-11 1-216-841-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 47K 2.2K 47K 47K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

C409

1-127-811-11 ELECT

C409

1-135-515-21 ELECT

C410

1-127-811-11 ELECT

R766 R771 R772 R773 R774

1-216-825-11 1-216-821-11 1-216-833-11 1-216-821-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

2.2K 1K 10K 1K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

C410

1-135-515-21 ELECT

C411

R775 R776

1-216-821-11 METAL CHIP 1-216-833-11 METAL CHIP

1K 10K

5% 5%

1/10W 1/10W

C441

1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V (RG590: E2, E3, E51, EA, MX, AR) 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (RG490/RG590: AEP, UK, RU) 1-130-495-00 MYLAR 0.1uF 5% 50V (RG590) 1-130-495-00 MYLAR 0.1uF 5% 50V (RG590) 1-126-964-11 ELECT 10uF 20% 50V 1-126-964-11 1-162-964-11 1-162-964-11 1-162-927-11 1-162-927-11

C411 C413

< SWITCH > C414 S611 S612 S613 S621 S622

1-762-875-21 1-762-875-21 1-762-875-21 1-762-875-21 1-762-875-21

SWITCH, KEYBOARD (J, SELECT FOLDER +) SWITCH, KEYBOARD (L, TUNING +) SWITCH, KEYBOARD (7) SWITCH, KEYBOARD (j, SELECT FOLDER –) SWITCH, KEYBOARD (l, TUNING –)

S623 S671

1-762-875-21 SWITCH, KEYBOARD (s) 1-479-670-11 ENCODER, ROTARY (VOLUME)

C442 C443 C444 C445 C446

< VIBRATOR >

C447

X701 1-795-054-21 VIBRATOR, CERAMIC (4.19MHz) ************************************************************ A-1159-779-A POWER BOARD, COMPLETE (RG590: AEP, UK, RU) A-1159-780-A POWER BOARD, COMPLETE (RG590: E3, EA) A-1159-781-A POWER BOARD, COMPLETE (RG590: E2, E51, MX, AR) A-1163-224-A POWER BOARD, COMPLETE (RG490: AEP, RU) A-1163-225-A POWER BOARD, COMPLETE (RG490: E3, EA, AUS) A-1163-226-A POWER BOARD, COMPLETE (RG490: E2, E51, MX, AR) ***********************

Part No.

Description

Ver. 1.1 POWER

ELECT CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

Remark 2200uF 20% 71V (RG590: E2, E51, MX, AR) 2200uF 20% 71V (RG590: AEP, UK, RU, E3, EA) 2200uF 20% 63V (RG490: AEP, RU, E3, EA, AUS) 2200uF 20% 63V (RG490: E2, E51, MX, AR) 2200uF 20% 71V (RG590: E2, E51, MX, AR) 2200uF 20% 71V (RG590: AEP, UK, RU, E3, EA) 3300uF 20% 50V (RG590: E2, E51, MX, AR) 3300uF 20% 50V (RG590: AEP, UK, RU, E3, EA) 3300uF 20% 50V (RG590: E2, E51, MX, AR) 3300uF 20% 50V (RG590: AEP, UK, RU, E3, EA)

10uF 0.001uF 0.001uF 100PF 100PF

20% 10% 10% 5% 5%

50V 50V 50V 50V 50V

1-126-965-11 ELECT

22uF

20%

C447

1-126-967-11 ELECT

47uF

20%

C448

1-126-965-11 ELECT

22uF

20%

C448

1-126-967-11 ELECT

47uF

20%

C451

1-136-497-81 FILM

0.1uF

5%

50V (RG490) 50V (RG590) 50V (RG490) 50V (RG590) 50V (RG490)

C451

1-130-495-00 MYLAR

0.1uF

5%

C452

1-136-497-81 FILM

0.1uF

5%

C452

1-130-495-00 MYLAR

0.1uF

5%

C453

1-136-497-81 FILM

0.1uF

5%

C453

1-130-495-00 MYLAR

0.1uF

5%

C454

1-136-497-81 FILM

0.1uF

5%

7-685-872-01 SCREW +BVTT 3X8 (S) < CAPACITOR > C402

1-107-726-91 CERAMIC CHIP

C403 C404 C405

1-137-749-11 MYLAR 1-137-749-11 MYLAR 1-135-928-21 ELECT

C405

1-137-840-11 ELECT

0.01uF

10%

16V (RG590) 0.1uF 100V 0.1uF 100V 2200uF 20% 63V (RG490: AEP, RU, E3, EA, AUS) 2200uF 20% 63V (RG490: E2, E51, MX, AR)

C454 C459 C460

50V (RG590) 50V (RG490) 50V (RG590) 50V (RG490) 50V (RG590)

50V (RG490) 1-130-495-00 MYLAR 0.1uF 5% 50V (RG590) 1-104-987-11 MYLAR 0.001uF 5% 200V (RG490: AEP, RU/RG590: AEP, UK, RU) 1-104-987-11 MYLAR 0.001uF 5% 200V (RG490: AEP, RU/RG590: AEP, UK, RU)

103

HCD-RG490/RG590 Ver. 1.1 POWER Ref. No. C461

Part No.

Description

1-128-562-11 ELECT

Remark 47uF

20%

C462

1-128-562-11 ELECT

47uF

20%

C463

1-104-655-91 ELECT

470uF

20%

C481 C486 C488

1-104-665-11 ELECT 1-126-961-11 ELECT 1-126-965-11 ELECT

100uF 2.2uF 22uF

20% 20% 20%

C489

1-128-552-51 ELECT

47uF

20%

C490

1-128-576-11 ELECT

C491

1-165-621-11 CERAMIC CHIP

C491

1-162-964-11 CERAMIC CHIP

C493

1-162-966-11 CERAMIC CHIP

C494

1-162-966-11 CERAMIC CHIP

100V (RG590) 6.3V (RG590) 25V 50V 50V (RG490)

Ref. No. Q489 Q490 Q491

Part No.

Description

6-551-268-01 TRANSISTOR 8-729-120-28 TRANSISTOR 6-551-270-01 TRANSISTOR

Remark 2SC5625 2SC1623-L5L6 (RG590) 2SA2026 (RG590)

< RESISTOR > R401 R402 R403

1-216-845-11 METAL CHIP 1-216-845-11 METAL CHIP 1-216-845-11 METAL CHIP

100K 100K 100K

5% 5% 5%

R404

1-216-845-11 METAL CHIP

100K

5%

R405

1-216-845-11 METAL CHIP

100K

5%

R406

1-216-845-11 METAL CHIP

100K

5%

R407 R409

1-216-809-11 METAL CHIP 1-216-845-11 METAL CHIP

100 100K

5% 5%

R410

1-216-845-11 METAL CHIP

100K

5%

R411

1-216-797-11 METAL CHIP

10

5%

1/10W (RG590) 1/10W 1/10W (RG590) 1/10W (RG590) 1/10W

< DIODE >

R412 R413 R414 R415 R416

1-216-797-11 1-216-797-11 1-216-797-11 1-216-797-11 1-216-797-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10 10 10 10 10

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

63V (RG490) 100uF 20% 63V (RG490) 0.1uF 50V (RG590: AEP, UK, RU) 0.001uF 10% 50V (RG490: AEP, RU) 0.0022uF 10% 50V (RG490: AEP, RU) 0.0022uF 10% 50V (RG490: AEP, RU)

< CONNECTOR > * CN441

100V (RG590)

1-573-087-11 PIN, CONNECTOR 13P

1/10W 1/10W 1/10W (RG590) 1/10W (RG590) 1/10W (RG590)

D401 D402 D441 D443 D444

6-500-360-01 6-500-360-01 8-719-000-07 8-719-988-61 8-719-988-61

DIODE DIODE DIODE DIODE DIODE

D10XB20 D10XB20 (RG590) MC2836 1SS355TE-17 1SS355TE-17 (RG590)

R417 R418 R419 R420 R421

1-216-809-11 1-216-809-11 1-216-809-11 1-216-797-11 1-216-797-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 10 10

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

D445 D446 D481 D483

6-501-179-01 6-501-179-01 8-719-988-61 8-719-988-61

DIODE DIODE DIODE DIODE

UDZW-TE17-16B (RG590) UDZW-TE17-16B (RG590) 1SS355TE-17 1SS355TE-17 (RG490)

R422 R423 R424 R425 R434

1-216-797-11 1-216-797-11 1-216-797-11 1-216-797-11 1-216-864-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP SHORT CHIP

10 10 10 10 0 (RG490)

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

R435 R436

1-216-864-11 SHORT CHIP 1-216-837-11 METAL CHIP

0 (RG490) 22K 5%

R439

1-216-833-11 METAL CHIP

10K

5%

R440 R441

1-216-837-11 METAL CHIP 1-216-825-11 METAL CHIP

22K 2.2K

5% 5%

1/10W (RG590) 1/10W (RG590) 1/10W 1/10W

R442 R443 R444 R445 R446

1-216-825-11 1-216-841-11 1-216-841-11 1-216-821-11 1-216-821-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

2.2K 47K 47K 1K 1K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R447 R448 0 R449

1-216-841-11 METAL CHIP 1-216-841-11 METAL CHIP 1-212-974-00 FUSIBLE

47K 47K 47

5% 5% 5%

0 R449

1-220-893-11 METAL

0.22

10%

0 R450

1-220-893-11 METAL

0.22

10%

1/10W 1/10W 1/2W F (RG490) 5W F (RG590) 5W F (RG590)

0 R451

1-220-893-11 METAL

0.22

10%

< IC > IC441 IC441

6-600-169-01 IC STK412-240M-E (RG590) 6-600-221-01 IC STK403-130-E (RG490) < TERMINAL BOARD>

JK441

1-694-785-11 TERMINAL BOARD (SPEAKER) < COIL >

L441 L442

1-422-009-13 COIL, AIR-CORE 1-422-009-13 COIL, AIR-CORE < TRANSISTOR >

Q441 Q442 Q481 Q482 Q483

6-551-268-01 6-551-268-01 8-729-120-28 8-729-120-28 8-729-120-28

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SC5625 2SC5625 2SC1623-L5L6 2SC1623-L5L6 2SC1623-L5L6

Q484 Q485 Q486 Q487 Q488

8-729-120-28 8-729-600-22 8-729-120-28 8-729-120-28 8-729-901-87

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SC1623-L5L6 2SA1235-F 2SC1623-L5L6 2SC1623-L5L6 2SC2411K-CQ

104

5W F (RG490)

HCD-RG490/RG590 POWER Ref. No.

Part No.

0 R452

1-220-893-11 METAL

Description

Remark 0.22

10%

R453 R454 R455

1-216-797-11 METAL CHIP 1-216-797-11 METAL CHIP 1-216-821-11 METAL CHIP

10 10 1K

5% 5% 5%

R456 R457 R458 R459

1-216-821-11 1-216-837-11 1-216-837-11 1-216-841-11

1K 22K 22K 47K

5% 5% 5% 5%

R459

1-216-845-11 METAL CHIP

100K

5%

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

R460

1-216-841-11 METAL CHIP

47K

5%

R460

1-216-845-11 METAL CHIP

100K

5%

R461 R462 R463

1-216-797-11 METAL CHIP 1-216-797-11 METAL CHIP 1-216-841-11 METAL CHIP

10 10 47K

5% 5% 5%

R464

1-216-845-11 METAL CHIP

100K

5%

R465 R466 0 R467

1-216-841-11 METAL CHIP 1-216-845-11 METAL CHIP 1-215-871-11 METAL OXIDE

47K 100K 2.2K

5% 5% 5%

0 R468

1-215-871-11 METAL OXIDE

2.2K

5%

R469

1-216-841-11 METAL CHIP

47K

5%

R470

1-216-841-11 METAL CHIP

47K

5%

R471

1-216-845-11 METAL CHIP

100K

5%

R472

1-216-845-11 METAL CHIP

100K

5%

R473

1-216-841-11 METAL CHIP

47K

5%

5W F (RG490) 1/10W 1/10W 1/10W 1/10W 1/10W 1/10W 1/10W (RG490) 1/10W (RG590) 1/10W (RG490) 1/10W (RG590) 1/10W 1/10W 1/10W (RG590) 1/10W (RG590) 1/10W 1/10W 1W F (RG590) 1W F (RG590) 1/10W (RG590) 1/10W (RG590) 1/10W (RG590) 1/10W (RG590) 1/10W (RG590)

R474

1-216-825-11 METAL CHIP

2.2K

5%

R475

1-216-833-11 METAL CHIP

10K

5%

R476

1-216-837-11 METAL CHIP

22K

5%

1-212-881-11 FUSIBLE

100

5%

R478

1-216-833-11 METAL CHIP

10K

5%

R479

1-216-833-11 METAL CHIP

10K

5%

R480 R481 R482 R483

1-216-845-11 1-216-829-11 1-216-833-11 1-216-801-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100K 4.7K 10K 22

5% 5% 5% 5%

1/10W (RG590) 1/10W 1/10W 1/10W 1/10W

R484 R485 R486 R487 R488

1-216-845-11 1-216-845-11 1-216-845-11 1-216-841-11 1-216-837-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100K 100K 100K 47K 22K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R490 R491

1-216-829-11 METAL CHIP 1-216-833-11 METAL CHIP

4.7K 10K

5% 5%

1/10W 1/10W

0 R477

1/10W (RG590) 1/10W (RG590) 1/10W (RG590) 1/4W F (RG590) 1/10W (RG590)

Ref. No.

Part No.

SENSOR

SUB WOOFER

Description

Remark (RG490) 1/10W (RG590) 1/10W (RG490) 1/10W (RG590)

R491

1-216-841-11 METAL CHIP

47K

5%

R492

1-216-821-11 METAL CHIP

1K

5%

R492

1-216-841-11 METAL CHIP

47K

5%

R493

1-216-841-11 METAL CHIP

47K

5%

1-216-864-11 1-216-864-11 1-202-972-61 1-212-881-11

0 (RG590) 0 (RG590) 1 5% 100 5%

1/4W F 1/4W F

100K 1K 1K

1/10W 1/10W 1/10W

R493 R494 0 R495 0 R496 R497 R498 R499

SHORT CHIP SHORT CHIP FUSIBLE FUSIBLE

1-216-845-11 METAL CHIP 1-216-821-11 METAL CHIP 1-216-821-11 METAL CHIP

5% 5% 5%

1/10W (RG490)

< RELAY > RY441 RY441

1-755-307-11 RELAY (RG490) 1-755-308-11 RELAY (RG590) < THERMISTOR >

TH441 1-807-796-11 THERMISTOR ************************************************************ 1-687-132-12 SENSOR BOARD ************* < CONNECTOR > CN731

1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE) 3P < IC >

IC731 6-600-022-01 IC RPI-576 ************************************************************ A-1159-815-A SUB WOOFER BOARD, COMPLETE (RG590) A-1178-854-A SUB WOOFER BOARD, COMPLETE (RG490) **************************** < CAPACITOR > C502 C503 C504 C505 C506

1-162-960-11 1-162-968-11 1-104-662-91 1-162-915-11 1-104-665-11

CERAMIC CHIP CERAMIC CHIP ELECT CERAMIC CHIP ELECT

220PF 0.0047uF 22uF 10PF 100uF

10% 10% 20% 0.5PF 20%

50V 50V 25V 50V 25V

C507 C508 C509 C510 C511

1-126-967-11 1-164-230-11 1-128-563-11 1-128-582-11 1-128-582-11

ELECT CERAMIC CHIP ELECT ELECT ELECT

47uF 220PF 100uF 10uF 10uF

20% 5% 20% 20% 20%

50V 50V 100V 100V 100V

C512 C513 C514 C516 C517

1-136-497-81 1-136-497-81 1-126-948-11 1-126-964-11 1-126-964-11

FILM FILM ELECT ELECT ELECT

0.1uF 0.1uF 100uF 10uF 10uF

5% 5% 20% 20% 20%

50V 50V 35V 50V 50V

< CONNECTOR > CN501 CN502

1-815-444-11 PIN, CONNECTOR (PWB) 3P 1-819-134-11 PIN, CONNECTOR 6P

105

HCD-RG490/RG590 Ver. 1.1 SUB WOOFER Ref. No. CN503

SW

Part No.

SW-SP

TRANSFORMER

Description

Remark

1-819-132-11 PIN, CONNECTOR 4P < DIODE >

D501 D502 D503 D504 D507

6-501-176-01 8-719-988-61 8-719-988-61 8-719-988-61 8-719-988-61

DIODE DIODE DIODE DIODE DIODE

Ref. No.

Part No.

R532 R533 0 R534

1-216-837-11 METAL CHIP 1-216-837-11 METAL CHIP 1-202-972-61 FUSIBLE

< SWITCH > S751

1-786-514-11 SWITCH, LEVER (SLIDE) (DISC TABLE OPEN/CLOSE DETECT) ************************************************************

0 0

SW-SP BOARD ************

< TRANSISTOR > Q501 Q502 Q503 Q505 Q506

6-551-268-01 8-729-600-22 8-729-120-28 8-729-120-28 8-729-120-28

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SC5625 2SA1235-F 2SC1623-L5L6 2SC1623-L5L6 2SC1623-L5L6

Q507

8-729-120-28 TRANSISTOR

2SC1623-L5L6

< TERMINAL BOARD> JK501

1-780-242-11 TERMINAL BOARD, PUSH (ANTENNA) 2P (SUB WOOFER OUT) ************************************************************ A-1159-798-A TRANSFORMER BOARD, COMPLETE (RG590: AEP, UK, RU) A-1159-799-A TRANSFORMER BOARD, COMPLETE (RG590: E2, E3, E51) A-1159-801-A TRANSFORMER BOARD, COMPLETE (RG590: EA) A-1159-802-A TRANSFORMER BOARD, COMPLETE (RG590: AR) A-1159-803-A TRANSFORMER BOARD, COMPLETE (RG590: MX)

< RESISTOR > R501 R502 R503 R504 0 R505

1-216-841-11 1-216-841-11 1-216-821-11 1-216-841-11 1-215-873-00

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL OXIDE

47K 47K 1K 47K 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1W F (RG490)

0 R505

1-215-896-00 METAL OXIDE

4.7K

5%

0 R506 0 R507 0 R508 0 R509

1-202-972-61 1-215-873-00 1-215-873-00 1-212-881-11

FUSIBLE METAL OXIDE METAL OXIDE FUSIBLE

1 4.7K 4.7K 100

5% 5% 5% 5%

2W F (RG590) 1/4W F 1W F 1W F 1/4W F

0 R510 0 R511 R512 R513 R514

1-220-893-11 1-220-893-11 1-216-797-11 1-216-821-11 1-216-837-11

METAL METAL METAL CHIP METAL CHIP METAL CHIP

0.22 0.22 10 1K 22K

10% 10% 5% 5% 5%

5W F 5W F 1/10W 1/10W 1/10W

R515 R516 R517 R518 R520

1-216-841-11 1-216-809-11 1-216-833-11 1-216-833-11 1-216-845-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

47K 100 10K 10K 100K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R521 R522 R523 R524 R525

1-216-809-11 1-216-809-11 1-216-809-11 1-216-841-11 1-216-797-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 47K 10

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R526 R527 R529 R530 R531

1-216-797-11 1-216-797-11 1-216-825-11 1-216-837-11 1-216-829-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10 10 2.2K 22K 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

106

1/10W 1/10W 1/4W F

1-687-669-12 SW BOARD *********

6-600-091-01 IC STK404-130S

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP

5% 5% 5%

RY501 1-755-307-11 RELAY ************************************************************

< JUMPER RESISTOR > JR501 JR502

Remark 22K 22K 1

< RELAY >

UDZW-TE17-12B 1SS355TE-17 1SS355TE-17 1SS355TE-17 1SS355TE-17

< IC > IC501

Description

A-1163-242-A TRANSFORMER BOARD, COMPLETE (RG490: AEP, RU) A-1163-243-A TRANSFORMER BOARD, COMPLETE (RG490: E2, E3, E51) A-1163-244-A TRANSFORMER BOARD, COMPLETE (RG490: AUS) A-1163-245-A TRANSFORMER BOARD, COMPLETE (RG490: EA) A-1163-246-A TRANSFORMER BOARD, COMPLETE (RG490: AR) A-1163-247-A TRANSFORMER BOARD, COMPLETE (RG490: MX) ***************************** 1-533-233-31 FUSE HOLDER < CAPACITOR > C907

1-136-497-81 FILM

0.1uF

5%

C907

1-130-495-00 MYLAR

0.1uF

5%

C908 C909 C910

1-128-553-11 ELECT 1-126-964-11 ELECT 1-126-968-11 ELECT

220uF 10uF 100uF

20% 20% 20%

C911 C914

1-126-942-61 ELECT 1-162-964-11 CERAMIC CHIP

1000uF 0.001uF

20% 10%

50V (RG490) 50V (RG590) 63V 50V 50V 25V 50V (RG590)

HCD-RG490/RG590 TRANSFORMER Ref. No.

Part No.

Description

Remark

Ref. No.

Part No.

1-793-660-11 1-819-131-11 1-819-133-11 1-819-139-11

Remark

< JACK >

< CONNECTOR > * CN901 CN903 CN905 CN907

Description

Ver. 1.1 VIDEO OUT

J803 1-774-227-11 JACK, PIN 1P (VIDEO OUT) ************************************************************

PIN, CONNECTOR (PC BOARD) 3P PIN, CONNECTOR 3P (RG490) PIN, CONNECTOR 5P (RG590) PIN, CONNECTOR 11P

MISCELLANEOUS **************

< DIODE > 5 D901 D902 D903 D904 D905

8-719-988-61 6-500-522-21 6-500-522-21 6-500-522-21 6-500-522-21

D906 D908 D910

6-501-184-01 DIODE UDZW-TE17-27B 6-500-522-21 DIODE 10EDB40-TB3 6-500-335-01 DIODE MC2838-T112-1 (RG490: EA, AR, AUS/RG590: EA, AR) 8-719-000-08 DIODE MC2838 (RG490: AEP, RU, E2, E3, E51, MX/RG590: AEP, UK, RU, E2, E3, E51, MX)

D910

DIODE DIODE DIODE DIODE DIODE

1SS355TE-17 10EDB40-TB3 10EDB40-TB3 10EDB40-TB3 10EDB40-TB3

61 62 158 168

0 PT902 0 PT902

204 204 204 205

< TRANSFORMER > 0 PT902

168

1-443-927-11 TRANSFORMER, POWER (RG490: EA, MX/RG590: EA, MX) 1-443-928-11 TRANSFORMER, POWER (RG490: E2, E3, E51, AR, AUS/RG590: E2, E3, E51, AR) 1-443-929-11 TRANSFORMER, POWER (RG490: AEP, RU/RG590: AEP, UK, RU)

205

206 208

< TRANSISTOR > 208 Q902

8-729-048-66 TRANSISTOR

2SB1238-PQR-TV2 303

1-832-838-21 WIRE (FLAT TYPE) (13 CORE) (RG490: MX/RG590: MX) 1-831-952-21 CABLE, FLEXIBLE FLAT (19 CORE) 1-831-779-21 CABLE, FLEXIBLE FLAT (11 CORE) 1-417-656-21 MECHA DECK (CWN42FF609) 1-831-772-21 CABLE, FLEXIBLE FLAT (9 CORE) (RG490: AEP, RU, E3, EA, AUS/RG590: AEP, UK, RU, E3, EA) 1-831-789-21 CABLE, FLEXIBLE FLAT (13 CORE) (RG490: E2, E51, MX, AR/RG590: E2, E51, MX, AR) 1-693-710-11 TUNER (FM/AM) (RG490: RU/RG590: RU) 1-693-711-11 TUNER (FM/AM) (RG490: E2, E3, E51, EA, MX, AR, AUS/RG590: E2, E3, E51, EA, MX, AR) 1-693-712-11 TUNER (FM/AM) (RG490: AEP/RG590: AEP, UK) 1-831-619-21 CABLE, FLEXIBLE FLAT (11 CORE) (RG490: AEP/RG590: AEP, UK) 1-831-769-21 CABLE, FLEXIBLE FLAT (9 CORE) (RG490: RU, E2, E3, E51, EA, MX, AR, AUS/ RG590: RU, E2, E3, E51, EA, MX, AR) 1-831-786-21 CABLE, FLEXIBLE FLAT (13 CORE) 1-831-771-21 CABLE, FLEXIBLE FLAT (23 CORE) (RG490: AEP, RU, E2, E3, E51, EA, AR, AUS/ RG590: AEP, UK, RU, E2, E3, E51, EA, AR) 1-832-043-21 CABLE, FLEXIBLE FLAT (31 CORE) (RG490: MX/RG590: MX) 1-831-928-21 CABLE, FLEXIBLE FLAT (11 CORE)

< RESISTOR > R903 R904 0 R908 R910

1-216-833-11 1-216-821-11 1-202-972-61 1-216-801-11

METAL CHIP METAL CHIP FUSIBLE METAL CHIP

R910

10K 5% 1/10W 1K 5% 1/10W 1 5% 1/4W F 22 5% 1/10W (EXCEPT RG490: MX/RG590: MX) 1-216-864-11 SHORT CHIP 0 (RG490: MX/RG590: MX)

R911 R914

1-216-864-11 SHORT CHIP 1-216-833-11 METAL CHIP

0 10K

5%

1/10W

< RELAY > 0 RY901 0 RY901

1-755-276-11 RELAY, POWER (RG490: MX/RG590: MX) 1-755-334-11 RELAY, AC POWER (EXCEPT RG490: MX/RG590: MX)

0 306 0 306 0 306 0 306 0 306

309 502 576 0 579 0 579

580 0 F904 0 F904

< SWITCH > 0 S901

1-786-055-31 SELECTOR, VOLTAGE (VOLTAGE SELECTOR) (RG490: E2, E3, E51, EA/RG590: E2, E3, E51, EA) ************************************************************ VIDEO OUT BOARD (RG490: MX/RG590: MX) **************** < CAPACITOR > C803

1-100-566-91 CERAMIC CHIP

0.1uF

10%

25V

0 F905 0 F905

0 F906 0 F907 0 F908

1-769-744-81 CORD, POWER (RG490: EA/RG590: UK, EA) 1-775-790-71 CORD, POWER (RG490: AUS) 1-827-226-31 CORD, POWER (RG490: E2, E3, MX/ RG590: E2, E3, MX) 1-829-387-11 CORD, POWER (RG490: AR/RG590: AR) 1-830-188-11 CORD, POWER (RG490: AEP, RU, E51/RG590: AEP, RU, E51) 1-500-868-11 1-828-938-51 1-832-404-21 8-820-244-01

CORE, FERRITE (RG490: MX/RG590: MX) WIRE (FLAT TYPE) (5 CORE) CABLE, FLEXIBLE FLAT (16 CORE) OPTICAL PICK-UP BLOCK (KSM-215D/C2NP) (MX) A-4735-357-A OPTICAL PICK-UP BLOCK (KSM-213D) (EXCEPT MX)

1-471-035-21 MAGNET ASSY 1-532-506-33 FUSE (T6.3AL/250V) (RG590) 1-533-949-33 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V) (RG490) 1-532-506-33 FUSE (T6.3AL/250V) (RG590) 1-533-949-33 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V) (RG490)

M001

1-532-465-33 FUSE (T3.15AL/250V) 1-532-465-33 FUSE (T3.15AL/250V) 1-533-949-33 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V) (RG590) 1-533-949-33 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V) (RG590) 1-787-344-11 FAN, DC

M741

A-1108-965-A MOTOR ASSY, TABLE

0 F909

107

HCD-RG490/RG590 Ver. 1.1

Ref. No.

Part No.

Description

M741 M751 0 PT901 0 PT901 0 PT901

A-1108-965-A A-1108-966-A 1-443-921-11 1-443-922-11 1-443-930-11

MOTOR ASSY, TABLE MOTOR ASSY, LOADING TRANSFORMER, POWER (RG490: AEP, RU) TRANSFORMER, POWER (RG590: AEP, UK, RU) TRANSFORMER, POWER (RG490: EA)

0 PT901 0 PT901 0 PT901 0 PT901

1-443-931-11 1-443-932-11 1-443-933-11 1-443-935-11

0 PT901

Remark

TRANSFORMER, POWER (RG590: EA) TRANSFORMER, POWER (RG490: MX) TRANSFORMER, POWER (RG590: MX) TRANSFORMER, POWER (RG590: E2, E3, E51, AR) 1-443-937-11 TRANSFORMER, POWER (RG490: E2, E3, E51, AR, AUS)

S101 S711

1-771-853-11 SWITCH, DETECTION (LIMIT) 1-477-680-12 ENCODER, ROTARY (DISC TABLE ADDRESS DETECT) ************************************************************ ACCESSORIES ************ 0 0 0

108

1-569-007-12 ADAPTOR, CONVERSION 2P (RG490: E3/RG590: E3) 1-569-008-32 ADAPTOR, CONVERSION 2P (RG490: E51/RG590: E51) 1-770-019-61 ADAPTOR, CONVERSION PLUG (RG490: EA/RG590: UK, EA)

Ref. No.

Part No.

Description

Remark

HCD-RG490/RG590 AEP Model E Model HCD-RG490/RG590

SERVICE MANUAL

UK Model HCD-RG590

Australian Model

Ver. 1.1 2006.04

HCD-RG490

SUPPLEMENT-1 File this supplement with the service manual.

Subject: Change of DECK board (Suffix-12)

In this set, DECK board has been changed in the midway of production. Printed wiring board and schematic diagram of new type, and changed parts list are described in this supplement-1. Refer to original service manual and supplement-2 for other information.

1.

NEW/FORMER DESCRIPTION

– DECK Board (Component Side) –

Former : 1-868-914-11 New : 1-868-914-12

9-887-053-81

HCD-RG490/RG590 2.

DIAGRAMS

• Note for Printed Wiring Boards and Schematic Diagrams Note on Printed Wiring Board: • X : parts extracted from the component side. • Y : parts extracted from the conductor side. • : Pattern from the side which enables seeing. (The other layers' patterns are not indicated.) • Indication of transistor C Q B E

2

These are omitted.

Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. (p: pF) 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. • A : B+ Line. • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. ⟨⟨ ⟩⟩ : TAPE PLAY { } : REC • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal production tolerances. • Signal path. E : TAPE PLAY (DECK-A) d : TAPE PLAY (DECK-B) G : REC • Abbreviation MX : Mexican model

HCD-RG490/RG590

2-1. PRINTED WIRING BOARD – DECK Board –

1

• Semiconductor Location

: Uses unleaded solder.

2

3

4

5

6

Ref. No. Location

7

(Refer to page 36 (Refer to page 40 on service manual) on service manual) EXCEPT RG490: MX/ RG590: MX

DECK BOARD

MAIN BOARD CN201

D1

MAIN BOARD CN201

D2

RG490: MX/ RG590: MX

CN008 E

R489

E

E

Q409

Q410

Q406

R301

R305

S

JR311

S

R316

JW310 JW319

3

E

R423

R403

1

CN302

JR402

C403 C414

C418

R412

R413

C404 R414

S

R307

8

R405

JW316

R458

R433

C415

R456 R431

G

C355

C354

CN301 1

R303

C454

R429

Q403

D

C306

JW308 D

JW309

C301

Q301

G C305

D C302

S

R450

C462

C452

E

R435

D

L451 BIAS OSC

R461 R462

C456

R465 6

1

4

3

Q453

G

D

Q401

JR302

G JR303

C303

D

R302

R443

K

R457

R315

Q302

E

Q402

A A

E

G

R430

S

Q303

JR404 S C356 C460

Q404

R466

R309

D

JW312 C461

C317

C318

JW311

C315

JR306

E

R432

R436

Q407

R439

C458

R427

JW315

R447 R308

R449

C413

C411

C431

R428

R446

S

JW320

R311

R304

Q451

R445 R434

G

G

C304

5

1

IC401

C416

Q305

R317 4

C417 8

Q400

Q306

C316

R313

JW314

R310

R407

4 R411

C412

D

JW306

C326

8

R312

R314

IC301

C307

R441

C325

C324

C406

R410 R320

C353

C323 1

R424

R453

E

C405 R404 5

R408

JW313

R318

R416 C410

JR310

R323 R319

R324

C433 R402

Q304

C

C328

C327

JR301

C352

R490

JW305

C351

JW303

R485

E

R454

R415

R409

C402

JW307

R326 R325

R406

D301

R401

R351

JW304

R482

JW301

C330

C430

R488 C329

R455

C401

FB301

R350

E

R440

C350

Q405

B

R442

E

Q408

R483

R452

C409

JW302

Q452

R451 R349

JW317

JW318

R484

R481

D401

A

R460

R463

R459

R464

C453

JR307

R306 1-868-914-

E HP1 (PB HEAD) (DECK-A)

HRPE1 REC/PB/ERASE HEAD (DECK-B)

HCD-RG490/RG590

3

3

12 (12)

D301 D401

B-3 C-6

IC301 IC401

C-2 C-5

Q301 Q302 Q303 Q304 Q305 Q306 Q400 Q401 Q402 Q403 Q404 Q405 Q406 Q407 Q408 Q409 Q410 Q451 Q452 Q453

D-2 D-2 D-3 D-3 D-3 D-3 C-4 D-5 D-5 D-5 D-5 B-1 B-1 D-4 B-2 B-3 B-4 C-7 B-7 D-7

HCD-RG490/RG590

2-2. SCHEMATIC DIAGRAM – DECK Board –

Q405,406,408

Q301 2SJ460 PB SWITCH (DECK-A) S

DECK-A/B SELECT SWITCH, REC/PB SELECT SWITCH

R350 0

8

R489 22k

C353 0.1

Q408 2SA1235

C327 220p

2

Q406 2SA1235

R484 22k

R317 470k

R323 4.7k

R319 22k

C323 0.0047

C352 0.1

R490 4.7k

R325 100

C329 0.047

R326 100

C330 0.047

C351 220 10V

C328 220p

Q405 2SC3052

C324 0.0047

C326 0.0022

C317 10 50V

R318 470k

(DECK-A)

L-CH

R-CH R302 47k

PB SWITCH (DECK-A)

C302 1000p

S

6

R315 100

S

R312 IC301(2/2) NJM14558M-TE2 220 R314 47

R324 4.7k

C301 1000p

Q302 2SJ460

R311 220

C318 10 50V R320 22k

CN301 3P

C305 220k

C325 0.0022 PB AMP

R485 2.2k

(PB) R301 47k

R313 47

R351 1k

R488 22k

R482 47k

HP1

R305 220k

R306 220k

IC301(1/2) NJM14558M-TE2

R483 22k

R481 4.7k

R309 470

1

C350 220 16V

R349 100

3

C315 47p

Q303 2SJ460 R303 PB SWITCH 47k (DECK-B)

C303 1000p

R304 47k

C304 1000p

C306 220k

R310 470

7 5

R316 100

4 D301 UDZW-TE17-4.3B

C433 0.01 C401 0.1 50V EXCEPT RG490:MX/ RG590:MX

R401 47k

R403 22k

3

CN008 11P

Q400,407

1 PB-L

C411 10p

FB301 0

C405 220p C403 47p

REC-R

R413 220k

R445 0

R431 1k

SWITCH

R407 4.7k

REC AMP

C430 0.1

R415 2.2k

Q407 2SA1235 C356 10 50V

R429 10k

REC-L

R435 10k

R411 470k

R409 100k

R405 47k

REC/PB SW +9V

C413 220p

IC401(1/2) BA4558

A-GND

C431 0.1

C417 0.01

R423 47k

R433 47k

R440 10k

C415 0.0047

MUTING

R416 2.2k

O-BIAS

JR310 0

R439 4.7k

R447 1M

RG490:MX/

C410 10 50V

R434 47k

NC

C404 47p

RG590:MX

R408 4.7k

R406 47k

C406 220p

C418 0.01

R424 47k

R412 470k

R410 100k

R402 47k

6

R404 22k

7

C412 10p

C460 470p

C416 0.0047

S S

Q400 2SK2158

R432 1k

R428 0

R436 10k

C462 470p

Q404 2SA1235 R466 0

REC SWITCH Q409,410

R449 22

Q451,452 REC BIAS SWITCH

R450 22

R456 22

R464 1k R462 2.2k

R455 10

R453 4.7k

R442 47k

1

R454 4.7k

Q452 2SC3052 R451 10k Q409 RT1N431C

R461 2.2k 6

2

Q410 RT1N431C

C453 0.001

Q451 KTA1271Y-AT

R452 47k

OSC

R458 4.7

C458 0.0022

HCD-RG490/RG590

4

R463 1k

R465 0

R459 0

R460 0

4 L451 BIAS

R457 22k

BIAS JR402 0

5

3

C454 0.0047 Q453 2SC2001

4

OSC C452 47 16V

R441 0

C461 470p

MUTING

5

REC CONTROL SWITCH

(DECK-B)

ERASE

MUTING R-CH

L-CH D401 MC2838

R414 220k

4

HRPE1 (REC/PB/ERASE) CN302 8P

Q306 2SC3052 R308 4.7k

R430 10k

R446 0

C414 220p

C355 0.01

C307 0.01

Q402 2SK2158

IC401(2/2) BA4558 C402 0.1 50V

MUTING

S

C409 10 50V

DECK-D-GND

Q305 2SC3052 R307 4.7k

Q401 2SK2158

REC-MUTE

(Refer to page 42 on service manual)

C354 0.1

MUTING CONTROL R443 10k

2

PB-R

(Refer to page 38 on service manual)

REC SWITCH

R427 0

8

S Q304 2SJ460 PB SWITCH (DECK-B)

C316 47p

Q403 2SA1235

C456 0.01

HCD-RG490/RG590 3.

DECK

ELECTRICAL PARTS LIST

NOTE: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable

Ref. No.

Part No.

• Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • SEMICONDUCTORS In each case, u: µ, for example: uA... : µA... uPA... : µPA... uPB... : µPB... uPC... : µPC... uPD... : µPD... • CAPACITORS uF: µF • COILS uH: µH

Description

Remark

A-1171-482-A DECK BOARD, COMPLETE ********************* < CAPACITOR/RESISTOR > C301 C302 C303 C304 C305

1-162-964-11 1-162-964-11 1-162-964-11 1-162-964-11 1-216-849-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP METAL CHIP

0.001uF 0.001uF 0.001uF 0.001uF 220K

10% 10% 10% 10% 5%

50V 50V 50V 50V 1/10W

C306 C307 C315 C316 C317

1-216-849-11 1-162-970-11 1-162-923-11 1-162-923-11 1-126-964-11

METAL CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT

220K 0.01uF 47PF 47PF 10uF

5% 10% 5% 5% 20%

1/10W 25V 50V 50V 50V

C318 C323 C324 C325 C326

1-126-964-11 1-162-968-11 1-162-968-11 1-162-966-11 1-162-966-11

ELECT CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

10uF 0.0047uF 0.0047uF 0.0022uF 0.0022uF

20% 10% 10% 10% 10%

50V 50V 50V 50V 50V

C327 C328 C329 C330 C350

1-162-960-11 1-162-960-11 1-136-161-00 1-136-161-00 1-126-934-11

CERAMIC CHIP CERAMIC CHIP MYLAR MYLAR ELECT

220PF 220PF 0.047uF 0.047uF 220uF

10% 10% 5% 5% 20%

50V 50V 50V 50V 16V

C351 C352 C353 C354 C355

1-126-934-11 1-107-826-11 1-107-826-11 1-107-826-11 1-162-970-11

ELECT CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

220uF 0.1uF 0.1uF 0.1uF 0.01uF

20% 10% 10% 10% 10%

16V 16V 16V 16V 25V

C356 C401 C402 C403 C404

1-126-964-11 1-126-956-11 1-126-956-11 1-162-923-11 1-162-923-11

ELECT ELECT ELECT CERAMIC CHIP CERAMIC CHIP

10uF 0.1uF 0.1uF 47PF 47PF

20% 20% 20% 5% 5%

50V 50V 50V 50V 50V

C405 C406 C409 C410 C411

1-162-960-11 1-162-960-11 1-126-964-11 1-126-964-11 1-162-915-11

CERAMIC CHIP CERAMIC CHIP ELECT ELECT CERAMIC CHIP

220PF 220PF 10uF 10uF 10PF

10% 10% 20% 20% 0.5PF

50V 50V 50V 50V 50V

C412 C413 C414 C415 C416

1-162-915-11 1-162-960-11 1-162-960-11 1-162-968-11 1-162-968-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

10PF 220PF 220PF 0.0047uF 0.0047uF

0.5PF 10% 10% 10% 10%

50V 50V 50V 50V 50V

Ref. No.

When indicating parts by reference number, please include the board.

Part No.

Description

Remark

C417 C418 C430 C431 C433

1-107-726-91 1-107-726-91 1-164-156-11 1-164-156-11 1-162-970-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.01uF 0.01uF 0.1uF 0.1uF 0.01uF

10% 10%

10%

16V 16V 25V 25V 25V

C452 C453 C454 C456 C458

1-126-947-11 1-130-471-00 1-130-479-00 1-130-483-00 1-130-475-00

ELECT MYLAR MYLAR MYLAR MYLAR

47uF 0.001uF 0.0047uF 0.01uF 0.0022uF

20% 5% 5% 5% 5%

35V 50V 50V 50V 50V

C460 C461 C462

1-162-962-11 CERAMIC CHIP 1-162-962-11 CERAMIC CHIP 1-162-962-11 CERAMIC CHIP

470PF 470PF 470PF

10% 10% 10%

50V 50V 50V

< CONNECTOR > CN008 CN301 CN302

1-568-830-11 CONNECTOR, FFC 11P 1-815-444-11 PIN, CONNECTOR (PWB) 3P 1-815-449-11 PIN, CONNECTOR (PWB) 8P < DIODE >

D301 D401

6-501-165-01 DIODE UDZW-TE17-4.3B 6-500-335-01 DIODE MC2838-T112-1 < JUMPER RESISTOR >

FB301

1-216-864-11 SHORT CHIP

0

< IC > IC301 IC401

6-702-457-01 IC NJM14558M-TE2 8-759-909-71 IC BA4558F < JUMPER RESISTOR >

JR301 JR302 JR306 JR307 JR310

1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11

SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP

0 0 0 0 0

JR311 JR402 JR404

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP

0 0 0

< TRANSFORMER > L451

1-443-760-11 TRANSFORMER, BIAS OSCILLATION

5

HCD-RG490/RG590 DECK Ref. No.

Part No.

Description

Remark

< TRANSISTOR >

Part No.

Description

Remark

R407 R408

1-216-829-11 METAL CHIP 1-216-829-11 METAL CHIP

4.7K 4.7K

5% 5%

1/10W 1/10W

Q301 Q302 Q303 Q304 Q305

6-550-290-01 6-550-290-01 6-550-290-01 6-550-290-01 8-729-120-28

FET FET FET FET TRANSISTOR

2SJ460-T 2SJ460-T 2SJ460-T 2SJ460-T 2SC1623-L5L6

R409 R410 R411 R412 R413

1-216-845-11 1-216-845-11 1-216-853-11 1-216-853-11 1-216-849-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100K 100K 470K 470K 220K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

Q306 Q400 Q401 Q402 Q403

8-729-120-28 8-729-045-62 8-729-045-62 8-729-045-62 8-729-600-22

TRANSISTOR FET FET FET TRANSISTOR

2SC1623-L5L6 2SK2158-T2B 2SK2158-T2B 2SK2158-T2B 2SA1235-F

R414 R415 R416 R423 R424

1-216-849-11 1-216-825-11 1-216-825-11 1-216-841-11 1-216-841-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

220K 2.2K 2.2K 47K 47K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

Q404 Q405 Q406 Q407 Q408

8-729-600-22 8-729-120-28 8-729-600-22 8-729-600-22 8-729-600-22

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SA1235-F 2SC1623-L5L6 2SA1235-F 2SA1235-F 2SA1235-F

R427 R428 R429 R430 R431

1-216-864-11 1-216-864-11 1-216-833-11 1-216-833-11 1-216-821-11

SHORT CHIP SHORT CHIP METAL CHIP METAL CHIP METAL CHIP

0 0 10K 10K 1K

5% 5% 5%

1/10W 1/10W 1/10W

Q409 Q410 Q451 Q452 Q453

6-551-276-01 6-551-276-01 8-729-037-13 8-729-120-28 8-729-011-92

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

RT1N431C-TP-1 RT1N431C-TP-1 KTA1271Y 2SC1623-L5L6 2SC2001TP-K1K2

R432 R433 R434 R435 R436

1-216-821-11 1-216-841-11 1-216-841-11 1-216-833-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

1K 47K 47K 10K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R439 R440 R441 R442 R443

1-216-829-11 1-216-833-11 1-216-864-11 1-216-841-11 1-216-833-11

METAL CHIP METAL CHIP SHORT CHIP METAL CHIP METAL CHIP

4.7K 10K 0 47K 10K

5% 5%

1/10W 1/10W

5% 5%

1/10W 1/10W

R445 R446 R447 R449 R450

1-216-864-11 1-216-864-11 1-216-857-11 1-216-801-11 1-216-801-11

SHORT CHIP SHORT CHIP METAL CHIP METAL CHIP METAL CHIP

0 0 1M 22 22

5% 5% 5%

1/10W 1/10W 1/10W

R451 R452 R453 R454 R455

1-216-833-11 1-216-841-11 1-216-829-11 1-216-829-11 1-216-797-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10K 47K 4.7K 4.7K 10

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R456 R457 R458 R459 R460

1-216-801-11 1-216-837-11 1-216-793-11 1-216-864-11 1-216-864-11

METAL CHIP METAL CHIP METAL CHIP SHORT CHIP SHORT CHIP

22 22K 4.7 0 0

5% 5% 5%

1/10W 1/10W 1/10W

R461 R462 R463 R464 R465

1-216-825-11 1-216-825-11 1-216-821-11 1-216-821-11 1-216-864-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP SHORT CHIP

2.2K 2.2K 1K 1K 0

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

R466 R481 R482 R483 R484

1-216-864-11 1-216-829-11 1-216-841-11 1-216-837-11 1-216-837-11

SHORT CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

0 4.7K 47K 22K 22K

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

R485 R488 R489 R490

1-216-825-11 1-216-837-11 1-216-837-11 1-216-829-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

2.2K 22K 22K 4.7K

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

< RESISTOR >

6

Ref. No.

R301 R302 R303 R304 R305

1-216-841-11 1-216-841-11 1-216-841-11 1-216-841-11 1-216-849-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

47K 47K 47K 47K 220K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R306 R307 R308 R309 R310

1-216-849-11 1-216-829-11 1-216-829-11 1-216-817-11 1-216-817-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

220K 4.7K 4.7K 470 470

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R311 R312 R313 R314 R315

1-216-813-11 1-216-813-11 1-216-805-11 1-216-805-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

220 220 47 47 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R316 R317 R318 R319 R320

1-216-809-11 1-216-853-11 1-216-853-11 1-216-837-11 1-216-837-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 470K 470K 22K 22K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R323 R324 R325 R326 R349

1-216-829-11 1-216-829-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 4.7K 100 100 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R350 R351 R401 R402 R403

1-216-864-11 1-216-821-11 1-216-841-11 1-216-841-11 1-216-837-11

SHORT CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

0 1K 47K 47K 22K

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

R404 R405 R406

1-216-837-11 METAL CHIP 1-216-841-11 METAL CHIP 1-216-841-11 METAL CHIP

22K 47K 47K

5% 5% 5%

1/10W 1/10W 1/10W

HCD-RG490/RG590 AEP Model E Model

HCD-RG490/RG590

1.

NEW/FORMER DESCRIPTION – KEY RIGHT Board (Component Side) –

– MAIN Board (Component Side) –

SERVICE MANUAL

UK Model

( RG490: Mexican/ RG590: Mexican models) Former : 1-868-901-11 New : 1-868-901-12

HCD-RG590

Australian Model

Ver. 1.2 2006.06

HCD-RG490 (Except RG490: Mexican/ RG590: Mexican models) Former : 1-869-003-12 New : 1-869-003-13

SUPPLEMENT-2 Subject: Change of MAIN, KEY RIGHT and KEY TOP boards (Suffix-12 (RG490: Mexican/RG590: Mexican models) or Suffix-13 (Except RG490: Mexican/RG590: Mexican models))

– KEY TOP Board (Component Side) –

(Except RG490: Mexican/ RG590: Mexican models) Former : 1-869-008-12 New : 1-869-008-13

In this set, MAIN, KEY RIGHT and KEY TOP boards have been changed in the midway of production. Printed wiring board and schematic diagram of new type, and changed parts list are described in this supplement-2. Refer to original service manual and supplement-1 for other information.

TABLE OF CONTENTS 1.

NEW/FORMER DESCRIPTION ......................... 1

2.

DIAGRAMS

3.

( RG490: Mexican/ RG590: Mexican models) Former : 1-868-905-11 New : 1-868-905-12

( RG490: Mexican/ RG590: Mexican models) Former : 1-868-906-11 New : 1-868-906-12

File this supplement with the service manual.

2-1. Printed Wiring Board – MAIN Board (Except RG490: Mexican/RG590 Mexican models) – ... 2-2. Schematic Diagram – MAIN Board (1/3) (Except RG490: Mexican/RG590 Mexican models) – ... 2-3. Schematic Diagram – MAIN Board (2/3) (Except RG490: Mexican/RG590 Mexican models) – ... 2-4. Schematic Diagram – MAIN Board (3/3) (Except RG490: Mexican/RG590 Mexican models) – ... 2-5. Printed Wiring Board – MAIN Board (RG490: Mexican/RG590 Mexican models) – ................ 2-6. Schematic Diagram – MAIN Board (1/3) (RG490: Mexican/RG590 Mexican models) – ................ 2-7. Schematic Diagram – MAIN Board (2/3) (RG490: Mexican/RG590 Mexican models) – ................ 2-8. Schematic Diagram – MAIN Board (3/3) (RG490: Mexican/RG590 Mexican models) – ................ 2-9. Printed Wiring Boards – KEY Section (Except RG490: Mexican/RG590 Mexican models) – ... 2-10. Schematic Diagram – KEY Section (Except RG490: Mexican/RG590 Mexican models) – ... 2-11. Printed Wiring Boards – KEY Section (RG490: Mexican/RG590 Mexican models) – ................ 2-12. Schematic Diagram – KEY Section (RG490: Mexican/RG590 Mexican models) – ................

(Except RG490: Mexican/ RG590: Mexican models) Former : 1-869-007-12 New : 1-869-007-13

HCD-RG490/RG590

3 4 5 6 7 8 9 10 11 12 13 14

ELECTRICAL PARTS LIST ................................ 15

9-887-053-82

HCD-RG490/RG590

1

HCD-RG490/RG590 2.

DIAGRAMS

• Note for Printed Wiring Boards and Schematic Diagrams Note on Printed Wiring Board: • X : parts extracted from the component side. • Y : parts extracted from the conductor side. • f : internal component. : Pattern from the side which enables seeing. • (The other layers' patterns are not indicated.) • Indication of transistor

C Q

These are omitted.

B E

Q B

C

E These are omitted.

Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. (p: pF) 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • f : internal component. • 2 : nonflammable resistor. • C : designation. Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. • A : B+ Line. • B : B– Line. • Voltages are dc with respect to ground under no-signal (detuned) conditions. no mark : TUNER (FM/AM) ( ) : CD PLAY ⟨⟨ ⟩⟩ : TAPE PLAY { } : REC • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal production tolerances. • Signal path. F : TUNER (FM/AM) J : CD PLAY E : TAPE PLAY G : REC N : MIC f : AUDIO IN L : VIDEO • Abbreviation AR : Argentina model AUS : Australian model E2 : 120 V AC area in E model E3 : 240 V AC area in E model E51 : Chilean and Peruvian models EA : Saudi Arabia model RU : Russian model

HCD-RG490/RG590

2

2

HCD-RG490/RG590 2-1. PRINTED WIRING BOARD – MAIN Board (Except RG490: Mexican/RG590 Mexican models) – 1

2

3

4

5

6

: Uses unleaded solder.

7

8

9

10

MAIN BOARD

Ref. No. Location

RG490: AEP/ RG590: AEP, UK

JW115

R952

C925

JW136

R382

JW202

R365

JW319

JW325

JW320

C066 C063

C064 C065

R103

JW321

JW324

JW203 JW210

R283

JW294 JW112

JW300

IC251

R033

R290

(CHASSIS)

RG490: AEP, RU/ RG590: AEP, UK, RU

RG490: AEP, RU, E3, EA, AUS /RG590: AEP, UK, RU, E3, EA

R049

E-7 F-7 G-7 I-3 I-4 I-7 C-2 E-3

Q002 Q011 Q041 Q042 Q043 Q044 Q045 Q046 Q111 Q112 Q113 Q114 Q251 Q252 Q261 Q271 Q272 Q274 Q276 Q277 Q901 Q902 Q903 Q904

G-9 H-9 H-9 H-9 G-9 G-9 G-9 F-9 G-2 G-2 H-4 H-4 J-7 I-7 J-9 I-8 I-9 F-9 I-5 J-9 D-3 D-2 E-3 E-3

Q043 R050

R038

K2 TRANSFORMER BOARD CN907

C276

C274 R286 R285 JW276

C265

R263

R274

E

Q277

R287

JW277

R035

R036

JW273

R271

E

JW274 JW275 A

R037 R034

EP031

A

JR114

K D035 13 1-869-003-

K

R043

R281 R042

JR115 C273

R276

Q271

IC006 IC011 IC021 IC101 IC102 IC251 IC901 IC902

Q261

JW272

C255

R253

R257

Q251

R261

C259

R279 R289 R268

F-8 F-8 F-8 F-8 G-9 H-9 E-7 H-9 G-7 H-7 G-7 G-7 G-6 G-6 G-6 G-7 J-7 J-8 G-9 D-3 D-4 E-3 E-3 E-3 D-3 F-2 F-2 G-2 F-2

E

D031

R063

E

C271 E

R251

R060

JW220

R280

Q272

R264

R267

C264

R059

R064

Q041

JW221

C266

R262

R291

JW268

JW222

R272 C278

E Q252

R039

(RG590)

JW223

E

JW271

JW270

R254

JW269 R252

C263

R104

R167 R165

A

R057

Q042

R277

TRANSFORMER BOARD CN907

JW315 Q011

A

C026

JW303 JW305 JW267

JW266

JW264

JW256 JW253

R145

JW252

R068 R265 JW254

JW255

JW310

R052 C260

R250

C254 C256

R269

E

D009

JW301

D012

C012

JW297

K

1

R292

C257

D007

11

D001 D002 D003 D004 D006 D007 D008 D009 D011 D012 D013 D014 D021 D022 D023 D024 D031 D035 D036 D301 D302 D901 D902 D905 D910 D921 D923 D943 D947

R047 R061

JW322 D013

D014

D024

D023

D021

D022

JW302

JW299

C032

R032

JW311

R169

EP061

R147

JW263

RG590: E2, E3, E51, EA, AR

R166

R168

R016 C010 JW296

CN031

13

C253

R170 CN061

JW295

E

JW265

C167

JW261

RG590: E2, E3, E51, EA, AR

JW251

JW250

R152

R143

JW309

R141

R162 5

R054

K1 E

R001

E

Q276

R153 1

Q002

(RG490)

R045

E R053 C035

E

D011

C011

Q045 E

Q044

CN001

C013

C031

C258

A K

R005

JW298

R155

R164 R156 C164

C168

JW249

R157 JW247

JW248

JR105 R139

C170

A

R006

C027

R160

JW308

JW246

JW307

JR121

IC1026 10

D

R041

JW106

JW288

JW283

JW282

JW226

JW236 R128

R120 C157 C160

R106

C172

R140 RG590: E2, E3, E51, EA, AR

R178

RG490: AEP/ RG590: AEP, UK

C385 JW331

JW196

JW197

C388 C387

JW332 R325

JW195

JW190

JW214

JW103 JW185

JW110

JW183 JW184

JW182 JW180

JW181

JW179

JW178

JW177

JW176

JW167 JW225

1

RG490: AEP, RU, E3, EA, AUS /RG590: AEP, UK, RU, E3, EA

R142

G

D036

JW235

C068

R138 C178

C386

JW193

JW192

JW032 JW187

JW186 JW102

JW105

JR109

JW339 JW101

JW171

JW170

JW169

JR110

R319

R322

R321

JW165 JW175

JW174

JW173

JW224

JW239

JW232 C174

R136

R163

C148 R148

JR122

R161

C147

JW323

JW314 JW206

C116

J

C153

R135

C152

C166 C156

C133

JW245

C141

JW281

JW242

C154

R046 S

Q046

1

C281

JW260

C177 R144

C275

JW293

R014

JW286

C171

R137

(RG490/RG590: AEP, UK, RU)

JW289

C023

RG490: E2, E51, AR/ RG590: E2, E51, AR

R056

JW292 R051 R055

Q274 E JW207

JW291

R013

JW287

C169

R131

R158

1

R048

IC021

JW238

R154

C176

C173 C165

C142

C155

C151 C143

E Q114

R177

IC101

C139

D001

D003

SUB WOOFER BOARD CN501

C034 CN271

D002

3

JW257

C112

C150

C146

11

R132 R159 E

C163 C175

R171

R129

20 10

C135 C125 C129

JW234

R172

C124

1

C159

C134 JR123 R175

21

40

R134

3

C025

JW278

JW285

R151

R127

JW316 C123

JR101 R133 R123 C137 R125

C120 (RG490/RG590: AEP, UK, RU) C114 30 31

R119

RG490: AEP, RU, E3, EA, AUS /RG590: AEP, UK, RU, E3, EA

D004

JW241

C140 Q113 C130 C144

R122

JW262

JR102

C110

JW208

C002

C008

(NC)

JW279

R130

JW240

R121

R124

JW233 R126

R101 C122

C001 JW313

R010 R011

JW284

C136

JR107

C121

C138

C109

JW231

JW230

JW227 JW243

R202

C267

R105

IC006 IC011

C015

H1

1

CN091

JW237

C126

C145 C149

RG490: AEP, RU/ RG590: AEP, UK, RU

JW258

JR104

JW259

R176

C115

R201 C268

H

I

RG490: AEP, RU/ RG590: AEP, UK, RU C069

JW228 CN201

JW329

D006

R110

R102

DECK BOARD CN008

RG490: E2, E51, AR/ RG590: E2, E51, AR

R114

R113 R111

R109

R999 R997

A

R116

R941

E

JW341

D943

A C111

R112

Q111

K

1 C006

JW280

JW229

R943 C119

K

C158

R949 R951

Q112 E

D1

R902

JW172

R950

A

G R108 C117

R996

JW217

JW218

A/K C921

D008

A

JW215

JW216

R947 D947

R942 R946 C118

R914

JW219

K

R944

D921

A/K

JW152

JW164

A

D923

JW330

3

CN991

R355 K

R948 R945

JR119 C923

R353

C922

R351

RG490: RU, E2, E51, EA, AR/ RG590: RU, E2, E51, EA, AR

A

C007

JW312

R354

JW244

R349 R352

R350

F

RG490: AEP, EA/ /RG590: AEP, UK, EA

JR103

R356

JW151

JW150

JW148 (RG490/RG590: AEP, UK, RU)

R904

R901

R912

R363 R366

R326

JW158

3

JW146

JW147

JR118

A C902

JR111 JR112

E1 BOARD CN601

R903

C901 D901 E Q904

JW159

R364

JW290

K D902

E

JW157

JW108

K

JW144

JW163 R910

2

IC902

Q903

1

JW162

JW166 JW161

JW160

E

D910 4 3 C904

D905

JW143

JW145

C927

C913

C920

C908

C906

JW142

Q901 C909

JW168

R935

JW141

R905 R909

E C919 R932

R982

E

R908

C910 Q902

R907

C911

R911

JW137

D302

JW149

R973

C914

JW140

R913

C305 JW156

C926 X901

R936

R922

D

2

RG490: AEP, RU, E3, EA, AUS /RG590: AEP, UK, RU, E3, EA

C916

R918

1

11

1

22

JW213

X902

JW188

R919 R974 80 R972

CN301

D301

JW139

3 CN041

C033

JW189

23

R070

1 1

1

JW212

20

C903

JW117

C917

61

C918

JW122

JR108 21

13 C391

JW118

JR120

C317 R963

JR106 60

R381

R383

JW119

IC901

R967

R969

JW135

R965

C912

JW154

40

JW133

41

R981

C

R315 R317 R953

JW153

R956

JW132

SUPPLIED WITH THE ASSEMBLED BLOCK

R316

JW129 R920

R955 JW131

TUNER(FM/AM)

M

DRIVER BOARD CN701

R318

JW127 R980

JW155

R971 JW130

C1

CD BOARD CN102

A

JW306

JR117

R925

M001 (FAN)

R324 R323

R348

JW205

JW126

AM

R344

R976

R342

JW134

RG490: AEP/ RG590: AEP, UK

R961

JW125

R957 R959

R979

ANTENNA FM75Ω COAXIAL

JW121

R346 R347 R341 R343 JW124

R921 R923 R924

R345

R970 R975

JW128

JW340

JW116

C924 JW123

JW120

A

B

• Semiconductor Location

RG490: E2, E51, AR/ RG590: E2, E51, AR

F1

MIC. AUX. HP BOARD CN801

J1

POWER BOARD CN441

J2

(CHASSIS)

POWER BOARD CN441

Note: IC901 on the MAIN board cannot exchange with single. When IC901 is damaged, exchange the entire mounted board.

(RG590)

(RG490)

HCD-RG490/RG590

3

(13)

3

HCD-RG490/RG590

2-2. SCHEMATIC DIAGRAM – MAIN Board (1/3) (Except RG490: Mexican/RG590 Mexican models) –

(1/3) G-5

T-DI

R980 100 I-MIC-DET

TCM-SYNC

RG590:AEP,UK

C-LR

LM-R

C-LF

LM-F

C-TR

TM-R

C-TF

TM-F

C-E1

E-1

C-E2

E-2 E-3

C-E3

R925 1k

R961 1k

D-GND

RG490:AEP/

C924 100p

-VFL

TCM-SNYC

T-CE

T-CL

T-DO

G-3

G-6

C-6

C-3

C-5

100k(RG490:EA/RG590:EA)

C925 100p

R955 1k

22k(RG490)

VF

RG490:AEP/

10k(RG490:E2,E51,AR/RG590:E2,E51,AR)

R971 100

4.7k(RG590:AEP,UK,RU)

R979 100

2.2k(RG490:RU/RG590:RU)

R921 100

∗R351

2.2k(RG590:E2,E3,E51,EA,AR)

R924 100

VF

C912 0.1

∗R355

CN991 19P

P-DA

1k(RG490:RU/RG590:RU) 10k(RG490:E2,E51,EA,AR/RG590:E2,E51,EA,AR)

R923 100

1k(RG490:AEP/RG590:AEP,UK)

13

M-GND

∗R350

470k(RG490:EA/RG590:EA)

M+9V M-GND

RG590:AEP,UK

∗R352

PM-CL

M-DA

C391 0.1

TBL ADDRESS SENS

C-SE

D+3.3V R920 470k

OPEN SW

C-OS

1

R952 47k

VDD(EVER) VDD(SWITCHED) ∗R354

VACS LED-GND

R346 1k

M-GND M-GND C-E1

R347 22k

R345 10k

I-SUFFIX C918 0.001 I-VACS

PROTECT

R922 220k I-PROTECTOR

O-CDG-RST/ I-RDS-CLK

O-LC23003-CE

I-HP/ AUDIO IN R349 10k

O-VMUTE

R350 ∗

R354 ∗

O-LC23003-DO

M+9V

I-HP-AUX

R341 10k

O-LC23003-CLK

VCE

I-LC23003-DI

R997 100

R352 ∗

O-CDG-POWER

R342 1k

VCL

VFD-CLK

R351 ∗

R355 ∗ R356 1M

I-CDG-DET

C-E2

R344 22k

R348 22k

I-XM-RXD

R343 22k

O-CDG-MUTE-DATA/ I-RDS-DATA

C-E3 VDI

O-XM-TXD

VDO

O-CD-DATA

R999 100

VFD-DO

I-CD-SENS

VFD-DI

RG590:RU,E2,E51,EA,AR

I-MIC-DET

VRE

RG490:RU,E2,E51,EA,AR/ RG490:AEP,EA/ RG590:AEP,UK,EA

O-CD-CLK

R996 100

(RG490/RG590:AEP,UK,RU)

O-R2S15208SP-DATA

VFD-RESET

VFD-CE

22k(RG490)

RMS

O-AUDIO-CLK

KEY0

SIRCS

O-R2S15207FP-DATA

KEY0

1k(RG590)

AVSS

STBY

AVREF

STBY-LED

R956 100 R957 100

I-KEY0

O-TM-F

I-CD-ENCODER

O-TM-R

R353 10k

C-OS C-SE

R975 100

C-TF

R976 100

C-TR

R969 100

C-LF

R967 100

C-LR

O-LM-F

I-MODEL STREAM

O-LM-R

I-STREAM SYSTEM CONTROLLER

STBY O-STBY-LED C-12

C-8 O-XRST

IC901 µPD7BF0547GGC (S) -UBT-A

R981 100 O-MP3-CLK R974 100

C-11 CN091 9P

TCM-SYNC

O-MP3-DATA

I-MP3-REQ

I-TAPE-SYNC

O-XLAT/ O-MP3-STB

O-VFD-RESET

I-MP3-ACK

R972 100

VRE

RESET VDD

VCE

FLMD

O-VFD-CE

O-MP3-XLAT/ O-MP3-CS

O-VFD-DATA

O-MP3-RESET

C923 220p

VDO

AVREF

VDI

R973 100

VCL

R982 470

C-14 C-15

R963 100

C-13 C-9 MP3-RST

FSP

XT1(32.768KHZ)

O-FRONT-SP-RELAY O-SWR

R953 10k

EVDD

VDD

EVSS

VSS

X1(16MHZ)

SYS-M O-SYS-XMUTE

REGC

X2(16MHZ)

O-SWR

FLMDO

XT2(32.768KHZ)

I-XRESET

I-AC-CUT

I-AC -PULSE

SO

O-SW_GAIN

I-XSIRCS -IN

O-REC/PB

220p

O-REC-MUTE

I-WAKEUP C926

O-STK-MUTE

RMS

SI

O-BIAS

SCK

R911 1k

O-XM-POWER3.3

O-POWER-RELAY

O-VFD-CLK KEY0

R965 100

C-1

(NC) VSS

C-10

O-XTCN

I-VFD-DATA VSS

C-4

O-D-MUTE O-XLT O-MP3-CS/ O-MP3-LP

I-MP3-DATA

FLMD

R959 100 R970 100

I-OPEN-SW I-CD-NUMBER-SENS

R913 1k

KEY0

C-7

I-SCOR IXTUNED

Q903 KTA1271Y-AT

Q901 2SC3052

Q903,904 REGULATOR

RESET SWITCH

R918 220k

D910 1SS355TE-17

A1 A2 A3

Q902 2SC3052

A4

AC DETECT A5

C913 1p C920 1p

FLMD

C927 22p

C910 0.1

C914 22p

C919 0.1

P-RELAY

R932 2.2k

STK-M

C904 0.1

A

JW339

C911 0.001

O-BIAS

R935 10k

IC902 PST3429UL

REC-MUTE

GENERATOR

A6

C901 100 16V

C916 47000 5.5V

R902 0 D901 UDZW-TE17-4.7B

D923 MC2840

R948 2.2k

R944 220k

R901 100k D902 MC2836

R914 10k C917 0.1

R950 4.7k

D943 MC2838

R904 2.2k

X902 16MHz

RESET SIGNAL

O-R/P

(Page 6)

C902 10 50V

R949 10k

R912 1k

C903 0.47 50V

R936 22k

D921 MC2840

R946 0 B3

R951 220

R947 220k C922 4.7 50V

B4 R945 220

VACS

D905 1SS355TE-17

X901 32.768KHz

C909 0.1

R919 0

Q904 2SC3052 R908 47k

D947 1SS355TE-17

R903 10k

C906 10 50V

R909 22k

STREAM

R905 10k

C908 0.1

PROTECT

R907 47k

C921 2.2 50V

R942 10k

R941 2.2k

(Page 5)

R943 4.7k

A7

B1

A8 R910 10k B2

(Page 6)

(Page 5)

HCD-RG490/RG590

4

4

Note: IC901 on the MAIN board cannot exchange with single. When IC901 is damaged, exchange the entire mounted board.

HCD-RG490/RG590

2-3. SCHEMATIC DIAGRAM – MAIN Board (2/3) (Except RG490: Mexican/RG590 Mexican models) –

(2/3) R176 2.2k

RG490:AEP,RU/

RG490:AEP,RU/

RG590:AEP,UK,RU

RG590:AEP,UK,RU

R172 0

C136 220p

(Page 6)

R136 10k

C152 0.022

C150 0.022

C4

C176 1

C144 0.047 (RG490/RG590:AEP,UK,RU)

C154 1 50V

CN201 11P

RG490:AEP,RU/

GND

O-R/P

R133 0

JR101 0

C115 100 16V

JR102 0

4700p

10 50V

MIX2

OUTL

VCC

BB22

C110 10 50V

0.18(RG590)

I-HP-AUX

D-GND AUX-IN-Rch

R168 R166 R104 1k 4.7k 10k

R131 100

C139 0.1

C151 0.022

R127 ∗

D-GND O-HP/AUX

R141 22k

R139 1k

R161 22k

R163 47k

R162 22k C175 1

C163 1

R156 220k

R164 47k

R155 220k Q111,112

Q114 2SC3052

Q113 2SC3052 R157 220k

R137 2.2k

R102 1k

R108 2.2k

R159 47k

R109 4.7k

R160 47k

R167 R165 R103 1k 4.7k 10k

R147 C147 47k 470p

RG490:AEP,RU/

RG490:AEP,RU/

RG590:AEP,UK,RU

RG590:AEP,UK,RU

C135 220p

R135 10k

C117 0.001

C069 1000p

R116 100

(Page 4) C119 2.2 50V

R111 100k

C112 47 16V

B3

R154 1M

B4 Q112 2SC3052 Q111 2SC3052

Q113,114 C134 0.1

C111 22 50V

R113 4.7k

ELECTRICAL VOLUME

R145 47k

BAND- FILTER

TONE CONTROL,

C141 10 50V

R148 C148 47k 470p

AUX-IN-Lch

R-OUT

C153 1 50V

INPUT SELECTOR,

A-GND

HP-GND

∗

E51,EA,AR

C149 0.022

R106 1k

R129 ∗

C145 4700p

R171 0

C143 0.047

MIC SIG

C155

R177 0

RG590:E2,E3,

C129 1 50V

C116 1 50V

R068 10

PM-CL

R158 220k

I-MIC-DET

MIC +9V

∗

RG590:AEP,UK,RU

13P(RG490:E2,E51,AR/RG590:E2,E51,AR) O-MIC-DET

0.15(RG490)

(RG490/RG590:AEP,UK,RU)

C137 1 50V

9P(RG490:AEP,RU,E3,EA,AUS/RG590:AEP,UK,RU,E3,EA)

∗C155-158

470k(RG490:AEP,RU,E3,EA,AUS/RG590:AEP,UK,RU,E3,EA)

RG490:AEP,RU/ C123 47p

C157

C173 47p

VOLINL

TONE OUTL

MID22

MID12

TRE2

BASS22

BASS12

47k(RG490:E2,E51,AR/RG590:E2,E51,AR)

M-DA

R143 220

BB12

SAOUT

∗R129,130

RECOUTL

R105 100

CDL

R144 220

R119 2.2k

C159 220p

(RG490:E2,E51,AR/RG590:E2,E51,AR) CN061

R120 2.2k

C160 220p CLK

TAPEL

R175 2.2k

R140 R178 1k 0

DATA

MIX1

C125 1 50V R125 4.7k

C281 0.01

C158 ∗ IC101 R2S15207FP

C114 0.1 R121 100

P-DA

OUTR

SURROUNDR C109

R142 22k

C174 47p

C267 4700p C268

R152 100

R153 100

C177 1

BB11

C122 0.047 R101 10k

AUXL

R201 2.2k

R134 0

C165 1

C156 ∗

TUNERL

PB-L

R151 100

BB21

SURROUNDL

R202 2.2k

C169 0.01

(/RG590:E2,E3,E51,EA,AR)

C121 100 16V

REC-L

PB-R

PM-CL

CLK

VOLINR

REFIN

A-GND

GND

TONE OUTR

MID21

MID11

TRE1

BASS21

BASS11

TAPER C120 0.1

R123 2.2k

AUXR

C124 47p R122 100

O-BIAS

RECOUTR

CDR

DECK-D-GND

REC-R

C171 100p

DATA

C166 1

RG590:AEP,UK,RU

RG590:AEP,UK,RU,E3,EA)

TUNERR

RG490:AEP,RU,E3,EA,AUS/

REC/PB SW

C170 100 16V

VCC

RG590:E2,E51,AR

NC

+9V

C164 1

C178 1

RG490:E2,E51,AR/ R070 10k

REC-MUTE

C172 100p

ROUT

1k(RG490:E2,E51,AR/RG590:E2,E51,AR)

REC-MUTE

REF OUT

RIN

2.2k(RG490:AEP,RU,E3,EA,AUS/RG590:AEP,UK,RU,E3,EA)

O-BIAS

REF IN LIN

LOUT

C130 1 50V

B2

(Page 4)

(Page 6)

IC102 R2S15208SP

C167 100 10V

∗R127,128 B1

D3

PARAMETRIC EQUALIZER

C140 0.1

C3

R128 ∗

D2 C168 100 10V

R138 2.2k

C146 4700p

R132 C126 100 1 50V

R130 ∗

C142 10 50V

R126 R124 4.7k 2.2k

C2

C138 1 50V

C1

D1

C133 0.1

BASS AGC

R110 47k

R114 2.2k

C118 2.2 50V

(Page 6)

R112 470 D4

C068 1000p

C066 1000p D5 C065 1000p

HP-GND

RG490:AEP,RU,E3,EA,AUS /RG590:AEP,UK,RU,E3,EA

L-OUT EP061

C063 0.1

C064 0.001

D7 D8 D9

(CHASSIS)

D10

(Page 6)

HCD-RG490/RG590

5

5

HCD-RG490/RG590

2-4. SCHEMATIC DIAGRAM – MAIN Board (3/3) (Except RG490: Mexican/RG590 Mexican models) –

(3/3)

Q261 RT1P141C-TP-1

R265 100 C259 10 50V

∗R250,253 4.7k(RG490) 10k(RG590)

C263 470 16V

A1 ∗R254,257 A2 R292 470

A3

R263 2.2k

C264 1000p

R261 10k

BUFFER

2.7k(RG490)

Q251 2SC3052

IC251 BA4558F-E2

4.7k(RG590)

MUTING

A4

C256 22p

A5

(Page 4)

R251 470

R253 ∗

A6

C255 22p R291 R257 470 ∗

D2

R268 4.7k

R274 4.7k Q276 2SC3052

R276 10k

BUFFER

Q271 2SC3052 BUFFER

C271 0.047

R286 22k

SW-SIG

C273 0.22 C266 4.7 50V

R277 2.2k

Q277 2SC3052 C276 0.22

C274 10 25V

R279 2.2k

R280 4.7k

SW-SIG GND SW-ON/OFF

Q272 2SC3052

R287 470k

MUTING R272 4.7k

C278 0.1

MUTING

CN271 3P

C275 470p

LINE AMP R281 2.2k

R250 R254 C258 ∗ ∗ 47 16V

C253 47p

R285 10k

MUTING CONTROL SWITCH

R267 47k

Q252 2SC3052

C254 47p

C265 4.7 50V

C260 10 R252 25V 470

D1

R262 10k R264 2.2k

R052 470k

R271 0

R269 2.2k

R289 100k

R290 1k

SYS-M

C257 47 16V D3

(Page 5)

Q274 RT1N431C-TP-1 SUB WOOFER SWITCH O-SWR

R283 10k FSP

Q043-045

R056 10k

FAN MOTOR DRIVE STBY R D002 10EDB40

R006 4.7k

P-RELAY

D004 10EDB40

Q002 2SC3052 RELAY DRIVE

Q042 KTA1271Y-AT

R042 10k

R043 4.7k

D001 10EDB40

+9V REGULATOR IC011 TA7809S +3.3V REGULATOR R010 22k

IC006 TA78033LS

O G I

C015 100 16V

R011 10k

O

D007 UDZW-TE17-4.7B

PROTECT DETECT

I

C007 22 50V

C006 10 50V

R001 22

+9V REGULATOR

R046 4.7

R048 22

R061 10

C033 100 16V

R051 2.2k

Q046 2SK2158

R049 220k

FAN MOTOR DETECT

C013 2200 25V

S

C034 4.7 50V

EP031

R036 4.7k

D023 10EDB40

R035 4.7k

SP L-OUT (RG490)

D024 10EDB40

SP-GND

R033 22k

SP R-OUT

T-DI

T-CL

B

D

R034 22k

SP RELAY B+ PROTECT

PROTECT R-OUT

T-CE

T-DO

G-6

G-5

C-7

C-6

C-15

C-9

C-13

C-10

C-5

C-11

C-8

C-1

C-14

C-4

C-3 A7

D302 10EDB40

A

D4

R059 1k 2W

R060 1k 2W

AMP-A-GND L-OUT

A8

B

R383 1k

-VFL GND (RG590)

R064 100

CN031 13P

100p

100p

100p

C388

C385

R366 0

R326 22k

R037 4.7k

R365 0

R325 22k

R032 D031 1k 1SS355TE-17 D10

D8 D9

C2

C4

C1

(Page 5) 1

C3

TUNER-L

+9V

TUNER-R

N/C

GND

PLL CE

PLL DI

PLL CLK

11

PLL DO

RG590:AEP,UK

RDS CLK

RG490:AEP/

RDS DATA

M+7V

M-GND

SCOR

SENS

XLAT

REQ-MP3

R364 0

R363 0

D7 ACK-MP3

XLAT-MP3

DATA-MP3

CLK

IREQ-MP3

XRST

XTACN

AVDD(3.3V)

R CH

A-GND

L-CH

D-GND

DVDD(3.3V)

D-MUTE

CN301 23P

D-OUT

(RG590)

DATA

A

-VFL

CLK-MP3

STBY R

470p

C317 1000 10V

EVER +10V

C386

D-GND

C387

R324 100

VF

R322 100

VF

A

STK MUTE

R063 100

R323 100

D

C032 1000p C031 0

/RG590:AEP,UK,RU,E3, EA

R321 100

AC4

PWR-GND

RG490:AEP,RU,E3,EA,AUS

R318 100

C

STK-M JW032

C305 1000p

R319 100

AC4

STBY RELAY

R382 1k

D301 10EDB40

/RG590:AEP,UK,RU,E3, EA A

R317 100

AC3

RG490:AEP,RU,E3,EA,AUS C027 0.01

R315 100

AC3

R316 100

CN001 11P

R381 1k

UNREG +16V

C026 0.01

(RG490)

R055 2.2k

R047 2.2

(CHASSIS)

D022 10EDB40 C023 2200 25V

O G I

C025 100 16V

R014 C010 10k 0.1

C-12

(Page 4)

R050 2.2k

(FAN) FAN+

D021 10EDB40

IC021 TA7809S

R013 22k

D5

Q045 2SC3052

M001

FAN-

R045 1k

Q041 2SC3052

D014 10EDB40

CN041 3P FAN+

R053 22k

R054 22k

D013 10EDB40

C

(Page 5)

R016 100k

C035 47 25

D035 MC2838

D008 MC2838

Q011 RT1N141C-TP-1

G

Q041,042 B+ SWITCH

R057 1k

D012 10EDB40

D006 1SS355TE-17 PROTECT

C001 0.1 C011 0.1

C012 0.1

D009 MC2838

D011 10EDB40

R041 0

Q044 2SC3052

D036 MC2836

D003 10EDB40

C008 2200 25V

R039 22 1/2W

Q043 KTA1266GR

POWER ON/OFF

R005 4.7k

R038

C002 0.1

TUNER (FM/AM) SUPPLIED WITH

(Page 5)

THE ASSEMBLED BLOCK

FM75Ω AM

COAXIAL ANTENNA

HCD-RG490/RG590

6

6

HCD-RG490/RG590 2-5. PRINTED WIRING BOARD – MAIN Board (RG490: Mexican/RG590 Mexican models) – 1

2

3

4

5

: Uses unleaded solder.

6

7

8

9

10

• Semiconductor Location

MAIN BOARD

Ref. No. Location

A

R332

R333 R338

R340

JW193

C063

C388 C387 C386

C385 JW197

JW331

JW196

JW332

R325

JW195

JW189

JW202

JW187

JW319

JW325 JW324

JW321

JW214

JW203

C147 R147

C064

R006

JW294 JW112

Q041

JW298

JW300 JW273

C265

R290

R274

R281 R042

R280

E

(CHASSIS)

R037

MIC. AUX. HP BOARD CN801

JW275

Q277

JW277 R271

A

A

R047 R061

Q002 Q011 Q041 Q042 Q043 Q044 Q045 Q046 Q111 Q112 Q113 Q114 Q251 Q252 Q261 Q271 Q272 Q274 Q276 Q277 Q901 Q902 Q903 Q904

G-9 H-9 H-9 H-8 G-9 G-9 G-9 F-9 G-2 G-2 H-3 H-4 I-7 I-7 J-9 I-8 I-8 F-9 I-5 J-9 D-3 D-2 E-3 E-3

R039

K4 TRANSFORMER BOARD CN907

E

JR114 EP031

K D035

J3

E-6 F-6 G-6 I-3 I-4 I-6 C-2 E-3

JW274

R032

R034

F2

IC006 IC011 IC021 IC101 IC102 IC251 IC901 IC902

R287

12 1-868-901-

K

F-8 F-8 F-8 F-8 G-9 H-9 E-6 H-8 G-7 H-7 G-7 G-7 G-6 G-6 G-6 G-6 J-6 J-7 G-9 C-3 C-3 D-4 E-3 E-2 E-3 D-3 F-1 F-2 G-2 F-2

Q261

R286 R285 JW276

Q251 E

R272

C273

JW271

JW270

C278

C276

R267

R254

R279 R289 R268

R276

C274

C266

R036

JW264

JW256

JW253

JW269

JW255

JW254

JW310

E

R264

R263

R043

D012 JW297

JW303 JW305

D031 R033

R060

JW301

D013

D014

JW302

D024

D023

D021

D022

R068 R265

JW309

R141

JW251

JW252 R142

R064

R103

C259

R251

JW268

R167 R165

E Q271

R045

JW106

JW288

JW290

JW283

JW282

D006

R050

JW210

JW322

JW185

JW184

JW103

JW183

JW181

JW110

JW182 R155

R156

JW250

C169

R118

R291

R059

E Q252

IC251 C264

R269

R104

JW220

Q272

JR115

Q043

JW213 JW212

JW108

D008

JW320

JW102

JW105

JR110

JW101

JR109

JW339

R315

R318

JW170

JW171 JW180

JW179

JW178

JW167 JW225

R160

C257

R063 JW263

EP061

JW192

JW191 JW032

R323

JR108 R317 R321

JW169

JW163

JW188

JW186

R324

JW174

JW172

JW173

JW224

JW226

R166

R252

C254 C256 C263

R035

JW281

JW314

CN061

R106 JW261

JW206

JW323

(RG590)

R168

R143

R292

R145

(RG590)

C260

JW272 R261 R262

C153

R135

C171

R152

R250

C255 R253

C116 R144

IC102

R153

JW267

C165 C177

5

JW222

R277 C271

R041

TRANSFORMER BOARD CN907

(RG590) JW223

JW221

1

R052

K3

E

JW315 Q011

A A R057

E

C253 R257

JR122

1

C026

(RG490)

E R053

E K D009

CN031

C031

C258

R117

R131 (RG490)

C167

C170

D007

11

13

JW266

C141

6

C160 JR121 C157 R139

JW299

E

R038

C010

E

E

JW265

C129

10

R054

JW296

Q042

Q276

R148

JW242

C172

C168

C148

R129

C143

R140 R178 C155 R120

JW260

C139

C174

R163

JW311

R127

C125 R171

11

R137 JW244

C145 C149 C151

10

C159

20

C158

(RG590) C166 21 C156

JR123 1

R134

R138 C178

30

31

R162

JW247

IC101

C152

C154

C035 E

JW295 R016

C281

R164

C176

(RG490)

C114

C150

R158 R161

R157

C120

C173

JW262

JW316

R121

JW335

C144

R154

Q114

C146

40 R133 R123 R125 C137 R175

Q113

JW287

Q045

Q044

R005

C027

C011

D001 D002 D003 D004 D006 D007 D008 D009 D011 D012 D013 D014 D021 D022 D023 D024 D031 D035 D036 D301 D302 D303 D901 D902 D905 D910 D921 D923 D943 D947

R048

K

D011

R046

D

A A D036

CN001

C013

C012

JW286

JW249

R122

JW257

E

JR105 C142

JW240

C109

E

JW248

C121

R101 C122

C138

C140

R174

JR107

JW243

R202 JR104

C110

JW239

JW237 C130

C112

R132 R159

C164

R201 C267

C268

JW258

JW285

Q046

R055 JW207

1

R014

C023

JW284

R130

R126 R105 C126

R058 JW292 S G

R001 Q002

JW308

CN201

R176

JW293

R013

R049

R056

R051

E

JW241

R136

C115

JW228

JW259

JW165

JW162

JW233

R110

R102

H

JW161

C069

JW307

R114

R128

R109

C923 JW334

JW229

E

R113 R111

E

R112

Q111 R108

JW227

Q112

G

JW238

Q274

JW291

D003

JW289

3

1

C275

R011

IC021

JW278

JW236

A

R116

C008 R010

1 CN271

R283

D001

SUB WOOFER BOARD CN501

C034 3

D004 D002

C025

(NC)

D943

A C111

C002

1

JW279

JW232

R951

JW208

C001 JW313

JW235

R943 R946 R941 C119 C118

JW329

H2

IC006 IC011

C015

JW280

JW234 C068

R942

K

JW230

R949

K

JW215

JW216

R950

A

JW330

1 C006

JW341

CN091

C175

A/K C921

JW231

D947

R124

R944

D921

K

JW217

JW246

R947

A

3

JW164

D923

R945

R914

R119 R177 C163

R948

C922

A

R364

R363 R366

3

JW152 CN991

JW218

K

JR119

JR103 R353

JW219

R355

R354

F

C007

A

JW312

R356

R349

JW151

JW150

JW148

R996 R999 R997

JW146

JW147 (RG490)

R352

J

R965

D901

C902

E2

I

R903 R912

R365

R326

JR118

R336

Q904

JR117

JW145

R953

JW177

JR112

E

R910

JW176

D902 R901 A

E

JW175

JW144

K

C033

JW166 D303

R320

R151

E

K

R904 R902 JW168

IC902

C906

Q903

C909 E D910 R907 4 3 C904 C901 D905 1 2

C908

JW142 JW143

JW160

C913 C927

C914

Q901

C333

R322

9

3 CN041

JW159

JW333

JW149

R935

R905 R909

C910 C919

E R932

R982 JW141

R908

C911 Q902

1 1

JW158

CN302

X902

C920

R972 R973

R913

DECK BOARD CN008

JW156

C916

X901

C926

R911

1

1

JW140

R381

JW155

C903

R918 80

R936

R922

C117

13 C391

JW154

JW190

R974

D

A/K

JW153

JW157

C918

BOARD CN601

R319

20 R919

JW139

SUPPLIED WITH THE ASSEMBLED BLOCK

R382

D301

61

C917

21

C2

R383

C317

JR106 60

R070

R963

JW138

IC901

D2

R969

JW135

40

C912

JW245

C

R920

JW134

41

R981

R956 JW133

R925

JW132

R955

R968

R980

R339

R967 JW136

JW129

JW130 JW131

AM

TUNER(FM/AM)

M

DRIVER BOARD CN701

R316

JW128

R977

R971

JW127

BD BOARD CN201

B JW137

JW126

M001 (FAN)

R335

D302

R348

R970 R975 R976

JW125

CD-G BOARD CN1001

G R330

C336

R329

R342

R957 R959

JW124

FM75Ω COAXIAL

CN331

R343

R979

R924

R346

R341

JW123

R331

JW122

R345

R347

JW338 R921 R923

B

ANTENNA

JR113

R372 R337

R344

JW336

R334 JR111

JW120 JR116

R952

JW337

JW121

JW119

JW118

JW116

JW107 JW109

JW117

JW340

JW115

JW104

POWER BOARD CN441

J4

(12)

(CHASSIS)

POWER BOARD CN441

Note: IC901 on the MAIN board cannot exchange with single. When IC901 is damaged, exchange the entire mounted board.

(RG590)

(RG490)

HCD-RG490/RG590

7

7

HCD-RG490/RG590

2-6. SCHEMATIC DIAGRAM – MAIN Board (1/3) (RG490: Mexican/RG590 Mexican models) –

(1/3) G-5

T-DI

T-CE

T-CL

G-1

R971 100

R925 100

R980 100

D-GND TCM-SYNC

I-MIC-DET

LM-R

C-LF

LM-F

C-TR

TM-R

C-TF

TM-F

C-E1

E-1

C-E2

E-2

C-E3

E-3

C-SE

TBL ADDRESS SENS

13

D+3.3V C-OS

R952 47k

VDD(EVER)

C-LR

R955 1k

-VFL

R968 100

R977 100

R961 100

VF

TCM-SNYC

T-DO

G-3

G-2

G-6

C-6

C-3

C-5

P-DA R921 100

R979 100

R924 100

VF

M+9V M-GND M-GND

R923 100

C912 0.1

CN991 19P

PM-CL

M-DA

C391 0.1

OPEN SW 1

R920 470k

VDD(SWITCHED) STBY-LED

STBY

KEY0

KEY0

SIRCS

∗R354 1k(RG590)

22k(RG490)

22k(RG490)

R346 1k

M-GND M-GND C-E1

R347 22k

R345 10k

C918 0.001 I-VACS

PROTECT

R922 220k I-PROTECTOR

KEY0

O-CDG-RST/ I-RDS-CLK

O-LC23003-CE

O-VMUTE

O-LC23003-DO

I-SUFFIX

O-LC23003-CLK

VACS LED-GND

I-HP/ AUDIO IN R349 10k

I-XM-RXD

I-HP-AUX

R341 10k

I-LC23003-DI

R344 22k

O-CDG-POWER

C-E2

I-CDG-DET

VCE

R352 10k R354 ∗

O-CDG-MUTE-DATA/ I-RDS-DATA

R342 1k

O-XM-TXD

R997 100

M+9V

R355 ∗

R356 1M

O-CD-DATA

VCL

(RG490)

R348 22k

I-CD-SENS

VFD-CLK

R343 22k

I-MIC-DET

C-E3 VDI

O-CD-CLK

VDO

O-R2S15208SP-DATA

R999 100

VFD-DO

O-AUDIO-CLK

VFD-DI

AVSS

VRE AVREF

R996 100

O-R2S15207FP-DATA

RMS

VFD-RESET

VFD-CE

∗R355 2.2k(RG590)

R957 100

IXTUNED

R959 100

C-OS

R970 100

C-SE

I-OPEN-SW I-CD-NUMBER-SENS

R913 1k

R975 100

C-TF

R976 100

C-TR

O-TM-F

I-KEY0 I-CD-ENCODER

O-TM-R

I-MODEL

O-LM-F

I-STREAM

O-LM-R

R353 10k STREAM

R969 100

C-LF

R967 100

C-LR C-8

SYSTEM CONTROLLER

STBY O-STBY-LED C-12

O-XRST

IC901 mPD7BF0547GC (S) -UBT-A

R981 100 O-MP3-CLK R974 100

C-11 CN091 9P

TCM-SYNC

RESET

O-MP3-DATA

I-MP3-REQ

I-TAPE-SYNC

O-XLAT/ O-MP3-STB

O-VFD-RESET

I-MP3-ACK

R972 100

VRE VCE

VDD

VDO

AVREF

VDI

R973 100

VCL

R982 470

VSS

KEY0

R911 1k

FLMD

O-VFD-CE

O-MP3-XLAT/ O-MP3-CS

O-VFD-DATA

O-MP3-RESET

C923 220p

VSS

C-15 C-13

R963 100

C-9 MP3-RST

FSP O-FRONT-SP-RELAY

XT1(32.768KHZ)

O-SWR

R953 10k

EVDD

VDD

EVSS

VSS

X1(16MHZ)

SYS-M O-SYS-XMUTE REGC

X2(16MHZ)

O-SWR

FLMDO

XT2(32.768KHZ)

I-XRESET

I-AC-CUT

O-XM-POWER3.3

O-POWER-RELAY

O-SW_GAIN

O-STK-MUTE

I-AC -PULSE

SO

O-BIAS

I-XSIRCS -IN

O-REC/PB

220p

SI

O-REC-MUTE

I-WAKEUP C926

C-14

R965 100

O-XTCN

O-VFD-CLK

(NC)

RMS

C-10

C-1 I-VFD-DATA

SCK

C-4

O-D-MUTE O-XLT O-MP3-CS/ O-MP3-LP

I-MP3-DATA

FLMD

C-7

R956 100 I-SCOR

Q901 2SC3052

Q903,904

Q903 KTA1271Y-AT

REGULATOR

RESET SWITCH R903 10k

C906 10 50V

R909 22k R919 0

Q904 2SC3052 D905 1SS355TE-17

R918 220k

D910 1SS355TE-17

A1 A2 A3

Q902 2SC3052

A4

AC DETECT RESET SIGNAL

A5

C920 1p

B1

C927 22p

FLMD

C910 0.1

C919 0.1

C914 22p

R932 2.2k

P-RELAY

C911 0.001

STK-M

C904 0.1

A

JW339

R935 10k

O-BIAS

IC902 PST3429UL

REC-MUTE

GENERATOR

A6

O-R/P

(Page 10)

C901 100 16V

C916 47000 5.5V

R902 0 D901 UDZW-TE17-4.7B

D923 MC2840

R948 2.2k

R944 220k

R901 100k D902 MC2836

R914 10k C917 0.1

R950 4.7k

D943 MC2838

R904 2.2k

X902 16MHz C913 1p

R949 10k

R912 1k

C903 0.47 50V C902 10 50V

X901 32.768KHz

C909 0.1

R908 47k

D947 1SS355TE-17

R936 22k

D921 MC2840

R946 0 B3

R951 220

R947 220k C922 4.7 50V

B4 R945 220 VACS

R905 10k

STREAM

C908 0.1

PROTECT

R907 47k

C921 2.2 50V

R942 10k

R941 2.2k

(Page 9)

R943 4.7k

A7 A8 R910 10k

B2

(Page 10)

(Page 9)

HCD-RG490/RG590

8

8

Note: IC901 on the MAIN board cannot exchange with single. When IC901 is damaged, exchange the entire mounted board.

HCD-RG490/RG590

2-7. SCHEMATIC DIAGRAM – MAIN Board (2/3) (RG490: Mexican/RG590 Mexican models) –

(2/3) D1

R172 0

R176 2.2k

D2

(Page 10)

R136 10k

C4 C130 1 50V

C152 0.022

C3

R128 1k

(Page 10)

IC102 R2S15208SP

C167 100 10V

REF IN LIN

C176 1

REF OUT LOUT

C144 0.047

RIN

C172 100p

ROUT

B1

C154 1 50V

B2

(RG490) INPUT SELECTOR,

C164 1

GND

PM-CL

DATA CLK C178 1

C169 0.01

+9V

GND

O-R/P

R133 0

A-GND PB-R

R202 2.2k

C267 4700p

PB-L

R201 2.2k

C268

R134 0

C158 ∗

C122 0.047 IC101 R2S15207FP

10 50V

C160 220p

MIX1

CLK

MIX2

OUTL

C110 10 50V

RECOUTL

PM-CL

∗

C155

∗

R177 0

C173 47p

VOLINL

TONE OUTL

MID22

MID12

TRE2

BASS22

BASS12

BB12

SAOUT

R125 4.7k

AUXL

CDL

TUNERL

R105 100

C157 BB22

TAPEL

M-DA

R143 220 R119 2.2k

C159 220p

C125 1 50V

R144 220 DATA

VCC

R121 100

R120 2.2k

OUTR

SURROUNDR

C114 0.1

4700p

R140 R178 1k 0

C156 ∗

R101 10k C109

C281 0.01

BB21

SURROUNDL C115 100 16V

R142 22k

C174 47p BB11

C121 100 16V

REC-L REC-R

P-DA

R153 100

C177 1

VOLINR

REFIN REC/PB SW

R152 100

(RG590)

TONE OUTR

MID21

MID11

TRE1

BASS21

BASS11

TAPER

AUXR

R122 100 C120 0.1

R123 2.2k

RECOUTR

CDR

O-BIAS

TUNERR

DECK-D-GND

REC-MUTE

R151 100

C165 1

C166 1

NC

REC-MUTE

C171 100p

VCC

ELECTRICAL VOLUME

CN201 11P

O-BIAS

C170 100 16V

TONE CONTROL,

R070 10k

(Page 8)

D3

PARAMETRIC EQUALIZER

C140 0.1

C150 0.022

R132 C126 100 1 50V

R138 2.2k

C146 4700p

C2

R130 47k

C142 10 50V

R126 R124 4.7k 2.2k

C138 1 50V

C1

C168 100 10V

∗C155-158 0.15(RG490)

C153 1 50V

0.18(RG590)

R175 2.2k

R141 22k

R139 1k

R161 22k

R163 47k

R162 22k C175 1

R164 47k

(RG490) C163 1

R156 220k

R155 220k R158 220k

D-GND O-HP/AUX D-GND AUX-IN-Rch

I-HP-AUX R168 R166 R104 1k 4.7k 10k

R131 100

C139 0.1

R148 C148 47k 470p

C141 10 50V R137 2.2k

R102 1k

R108 2.2k

R109 4.7k

R159 47k

R160 47k C112 47 16V

HP-GND R-OUT

C068 1000p R167 R165 R103 1k 4.7k 10k

R135 10k

R147 C147 47k 470p

C117 0.001

C069 1000p

R116 100

(Page 8) C119 2.2 50V

R111 100k

B3

R154 1M

B4 Q112 2SC3052 Q111 2SC3052

A-GND AUX-IN-Lch

C111 22 50V

R113 4.7k

Q113,114 BASS AGC

R145 47k

BAND- FILTER

R157 220k

C151 0.022

R106 1k

C149 0.022

MIC SIG

R127 1k

C145 4700p

R068 10

Q111,112

Q114 2SC3052

Q113 2SC3052

C143 0.047

I-MIC-DET

MIC +9V

R129 47k

C116 1 50V

O-MIC-DET

R171 0

(RG590)

C129 1 50V

C137 1 50V

CN061 11P

R110 47k

R114 2.2k

C118 2.2 50V

(Page 10)

R112 470 D4 D5

HP-GND L-OUT EP061

C063 0.1

C064 0.001

D7 D8 D9

(CHASSIS)

D10

(Page 10)

HCD-RG490/RG590

9

9

HCD-RG490/RG590

2-8. SCHEMATIC DIAGRAM – MAIN Board (3/3) (RG490: Mexican/RG590 Mexican models) –

(3/3)

R265 100

4.7k(RG490) 10k(RG590)

C263 470 16V

A1 ∗R254,257 R292 470

R263 2.2k R261 10k

2.7k(RG490)

Q251 2SC3052

IC251 BA4558F-E2

4.7k(RG590)

MUTING

A4

C256 22p

A5

(Page 8)

C264 1000p

R251 470

BUFFER

A2 A3

R253 ∗

A6

R291 R257 470 ∗

R268 4.7k

Q276 2SC3052

R276 10k

R286 22k

BUFFER

Q271 2SC3052 BUFFER

C271 0.047

SW-SIG

C273 0.22 C266 4.7 50V

R277 2.2k

R287 470k Q277 2SC3052 C276 0.22

C274 10 25V

R279 2.2k

R280 4.7k

SW-SIG GND SW-ON/OFF

Q272 2SC3052

MUTING C278 0.1

R272 4.7k

MUTING

CN271 3P

C275 470p

LINE AMP R281 2.2k

R250 R254 C258 ∗ ∗ 47 16V

C253 47p

R274 4.7k

MUTING CONTROL SWITCH

C265 4.7 50V

R267 47k

Q252 2SC3052

C254 47p C255 22p

D2

R285 10k

Q261 RT1P141C-TP-1 C259 10 50V

∗R250,253

R262 10k C260 10 R252 25V 470

D1

R264 2.2k

R052 470k

R271 0

R269 2.2k

R289 100k

R290 1k

SYS-M

C257 47 16V D3

(Page 9)

Q274 RT1N431C-TP-1 SUB WOOFER SWITCH O-SWR

R283 10k FSP

Q043-045

R056 10k

FAN MOTOR DRIVE STBY RELAY D002 10EDB40

R006 4.7k

P-RELAY

D004 10EDB40

Q002 2SC3052

RELAY DRIVE

R043 4.7k

D001 10EDB40

Q041,042

+9V REGULATOR

+3.3V REGULATOR

D011 10EDB40

D009 MC2838

IC006 TA78033LS

R010 22k

R011 10k

C015 100 16V

G

O PROTECT

PROTECT

D007 UDZW-TE17-4.7B

DETECT

D013 10EDB40 D014 10EDB40

I

C006 10 50V

C007 22 50V

+9V REGULATOR

R001 22

O

G

I

R061 10

R049 220k

S

C034 4.7 50V

EP031

(CHASSIS) R036 4.7k

D023 10EDB40

R035 4.7k

SP L-OUT (RG490)

D024 10EDB40

SP-GND

R033 22k

SP R-OUT

R059 1k 2W

C-7

SBSO

WFCK

EXCK

G-5

G-6

G-3

R335 100

G-2

AC4-2

AC3-1

AC3-2

G-1

T-CE

T-DI

T-CL

T-DO

C-15

C-14

C-13

C-12

C-9

C-10

R-OUT

R329 100

C031 0

STK MUTE

(RG590)

C4

TUNER(FM/AM) SUPPLIED WITH

BLOCK

FM75Ω AM

COAXIAL ANTENNA

HCD-RG490/RG590

10

10

R330 1k

R339 1k

R340 1k

MUTE-DATA

R338 100

R334 100

R337 100

CDG-RST

R333 10k

R331 100

R332 100 CDG-POWER

R372 100

V-MUTE

R032 D031 1k 1SS355TE-17 D10

D7 SCOR

WFCK

SBSO

D8 EXCK

CDG-BGC

CDG-DET

GND

GND

CN331 13P

+9V

TUNER-L

+9V

TUNER-R

GND

N/C

PLL CE

PLL DI

PLL DO

PLL CLK

1

THE ASSEMBLED

(Page 9)

R037 4.7k

JW032

C2

C1

9

CN031 13P

R063 100

C336 0.01

C3

L-OUT

PWR-GND

GND

R364 0

M+7V

M-GND

M-GND

MP3-STB

MP3-REQ

MP3-ACK

MP3-CLK

AMP-A-GND

R064 100 R363 0

C385 100p

C388 100p

R383 1k

R381 1k

R382 1k C386 100p

C387 470p

R366 0

R325 22k

R326 22k

R324 100

R316 100

R336 10k

R322 100

R323 100 MP3-LP

MP3-DIO

R060 1k 2W

UNREG +16V

C317 1000 10V

MP3-CS

D303 UDZW-TE17-4.7B

R320 100 SCOR

CD-SENS

CD-CLK

XLT

CD-DATA

AVDD(3.3V)

XTCN

XRST

R-CH

D-GND

A-GND

D-OUT

D-GND

WFCK

SBSO

CN302 31P

EXCK

A

-VFL

L-CH

STBY RELAY

DVDD(3.3V)

EVER +10V

MP3-RST

D-GND

(RG590)

C-11

C-7

C-6

C-5

C-3

C-4

C-8

C-1 R318 100

VF

MP3(3.3V)

AC4-2

C333 0.1

AC4 VF

MP3-GND

AC4-1

R365 0

R321 100

AC4

PROTECT

-VFL

D301 10EDB40

R317 100

AC3-2

A

SP RELAY B+ PROTECT

STK-M

AC3-1

AC3

STBY RELAY

D302 10EDB40

R034 22k

C027 0.01

R319 100

CN001 11P C026 0.01 AC3

MP3-RST

A8

SBSO

EXCK

A7

R315 100

(RG490)

R048 22

D4

WFCK

(Page 8)

R046 4.7

FAN MOTOR DETECT

D022 10EDB40 C023 2200 25V

AC4-1

(Page 9)

C025 100 16V

R014 10k

C010 0.1

D5

R047 2.2

C033 100 16V

R051 2.2k Q046 2SK2158

C013 2200 25V

(FAN) FAN+

D021 10EDB40

IC021 TA7809S

R013 22k

R016 100k

R055 2.2k

D035 MC2838

D008 MC2838

Q011 RT1N141C-TP-1

G

R050 2.2k

R054 22k

D012 10EDB40

D006 1SS355TE-17

Q045 2SC3052

M001

FAN-

R045 1k

Q041 2SC3052

I

C012 0.1

O

C035 47 25

CN041 3P FAN+

R053 22k

B+ SWITCH

R057 1k

C001 0.1 C011 0.1

IC011 TA7809S

R041 0

Q044 2SC3052

D036 MC2836

D003 10EDB40

C008 2200 25V

R039 22 1/2W

Q043 KTA1266GR

Q042 KTA1271Y-AT

R042 10k

POWER ON/OFF

R005 4.7k

R038

C002 0.1

D9

(Page 9)

HCD-RG490/RG590 2-9. PRINTED WIRING BOARDS – KEY Section (Except RG490: Mexican/RG590 Mexican models) – 1

2

3

4

5

6

: Uses unleaded solder.

7

8

9

10

(RG590: E2, E3, E51, EA, AR)

A

N

BOARD CN606

KEY TOP BOARD CN607

R692

S641

5 R693

R664

VOCAL

BASS

1

GUITAR

S643

S642 JW684

S618

R694 S648

B R668

R659

R658

D623, S618

R667

SUB WOOFER

R665

R666 S616

S615

S614

S644

EQ BAND

SURROUND

GROOVE

CLEAR

ENTER

<

D623

–

R695

S617

R698

S645

S647

,

R697

R696

S646

C +

13 1-869-008-

KEY RIGHT BOARD

D

S638

S614 – 618, S624, S631 – 638, S641 – 648

DISC 1

R688

S637

E

DISC 2

R687

S636

F DISC 3

R686

S635

G DISC SKIP/ EX-CHANGE

R685

CN605 1

S634

H Q

A

(RG490/RG590: AEP, UK, RU)

BOARD CN604

5

R684 SURROUND PLAY MODE/ TUNING MODE

I

RG590: E2, E3, E51, EA, AR

S633

S632

R683

C643 (RG490/RG590: AEP, UK, RU)

1

3

GROOVE

C644 REPEAT

J

RG590: E2, E3, E51, EA, AR (RG490/RG590: AEP, UK, RU) EQ BAND SLEEP RG590: E2, E3, E51, EA, AR

S624

S672 ROTARY ENCODER (MULTI JOG)

S631 R682

K

ENTER

13 1-869-007-

(13)

HCD-RG490/RG590

11

11

(13)

HCD-RG490/RG590 2-10. SCHEMATIC DIAGRAM – KEY Section (Except RG490: Mexican/RG590 Mexican models) –

R664 4.7k

R667 22k

R668 47k

S614

S615

S616

S617

S618

CLEAR

GROOVE

SURROUND

EQ BAND

SUBWOOFER

R692 2.2k

R693 2.2k

R694 4.7k

R695 4.7k

R696 10k

R697 22k

R698 47k

S641

S642

S643

S644

S645

S646

S647

BASS

VOCAL

GUITER

ENTER

R665 4.7k

D623 SLR-325MCT31 SUBWOOFER

S648

GND

KEY4

KEY1 OUT

SW LED

R659 1k

LED+9V

R658 1k

R666 10k

+

-

CN607 5P

(RG590: E2, E3, E51, EA, AR) TO BOARD CN606

GND

KEY2

KEY3

JOG-B

CN605 5P

JOG-A

TO BOARD CN604

S624 C643 0.01

ENTER C644 0.01

(RG490/RG590: AEP, UK, RU)

R682 2.2k

R683 2.2k

R684 4.7k

R685 4.7k

R686 10k

R687 22k

R688 47k

S631

S632

S633

S634

S635

S636

S637

S638

EQ BAND

SURROUND

GROOVE

DISC 3

DISC 2

DISC 1

DISC SKIP/ EX-CHANGE

RG590: E2, E3,

S672

E51, EA, AR

ROTARY ENCODER (MULTI JOG)

HCD-RG490/RG590

12

12

SLEEP

PLAY MODE/ TUNING MODE

REPEAT

HCD-RG490/RG590 2-11. PRINTED WIRING BOARDS – KEY Section (RG490: Mexican/RG590 Mexican models) – 1

2

3

4

5

6

: Uses unleaded solder.

7

8

9

10

(RG590)

A

N

BOARD CN606

KEY TOP BOARD CN607

R692

S641

5 R693

R664

S642 VOCAL

BASS

1

GUITAR

S643

JW684

S618

R694 S648

B R668

R659

R658

D623, S618

R667

SUB WOOFER

R665

R666 S616

S615

S614

S644

EQ BAND

SURROUND

GROOVE

CLEAR

ENTER

<

D623

–

R695

S617

R698

S645

S647

,

R697

R696

S646

C +

12 1-868-906-

KEY RIGHT BOARD

D

S638

S614 – 618, S624, S631 – 638, S641 – 648

DISC 1

R688

S637

E

DISC 2

R687

S636

F DISC 3

R686

S635

G DISC SKIP/ EX-CHANGE

R685

CN605 1

S634

H Q

A

(RG490)

BOARD CN604

5

R684 SURROUND PLAY MODE/ TUNING MODE

I

(RG590)

S633

S632

R683

C643 (RG490)

1

3

GROOVE

C644 REPEAT

J

(RG590) (RG490) EQ BAND SLEEP

S672 ROTARY ENCODER (MULTI JOG)

S624

(RG590)

S631 R682

K

ENTER

12 1-868-905-

(12)

HCD-RG490/RG590

13

13

(12)

HCD-RG490/RG590 2-12. SCHEMATIC DIAGRAM – KEY Section (RG490: Mexican/RG590 Mexican models) –

R664 4.7k

R667 22k

R668 47k

S614

S615

S616

S617

S618

CLEAR

GROOVE

SURROUND

EQ BAND

SUBWOOFER

R692 2.2k

R693 2.2k

R694 4.7k

R695 4.7k

R696 10k

R697 22k

R698 47k

S641

S642

S643

S644

S645

S646

S647

BASS

VOCAL

GUITER

ENTER

R665 4.7k

D623 SLR-325MCT31 SUBWOOFER

S648

GND

KEY4

KEY1 OUT

SW LED

R659 1k

LED+9V

R658 1k

R666 10k

+

-

CN607 5P

(RG590) TO BOARD CN606

GND

KEY2

KEY3

JOG-B

CN605 5P

JOG-A

TO BOARD CN604

S624 C643 0.01

ENTER C644 0.01

(RG490)

R682 2.2k

R683 2.2k

R684 4.7k

R685 4.7k

R686 10k

R687 22k

R688 47k

S631

S632

S633

S634

S635

S636

S637

S638

EQ BAND

SURROUND

GROOVE

DISC 3

DISC 2

DISC 1

DISC SKIP/ EX-CHANGE

(RG590)

S672

SLEEP

PLAY MODE/ TUNING MODE

ROTARY ENCODER (MULTI JOG)

HCD-RG490/RG590

14

14

REPEAT

HCD-RG490/RG590 3.

KEY RIGHT

ELECTRICAL PARTS LIST

NOTE: • Items marked “*” are not stocked since they • Due to standardization, replacements in the are seldom required for routine service. parts list may be different from the parts Some delay should be anticipated when specified in the diagrams or the components ordering these items. used on the set. • SEMICONDUCTORS • -XX and -X mean standardized parts, so they In each case, u: µ, for example: may have some difference from the original uA... : µA... uPA... : µPA... one. uPB... : µPB... uPC... : µPC... • RESISTORS uPD... : µPD... All resistors are in ohms. • CAPACITORS METAL: Metal-film resistor. uF: µF METAL OXIDE: Metal oxide-film resistor. • COILS F: nonflammable uH: µH • Abbreviation AR : Argentina model E3 : 240V AC area in E model MX : Mexican model AUS : Australian model E51 : Chilean and Peruvian models RU : Russian model E2 : 120V AC area in E model EA : Saudi Arabia model Ref. No.

Part No.

Description

Remark

Ref. No.

Part No.

KEY TOP

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. When indicating parts by reference number, please include the board.

Description

Remark

A-1159-684-A KEY TOP BOARD, COMPLETE (RG590: E2, E3, E51, EA, AR) A-1159-685-A KEY TOP BOARD, COMPLETE (RG590: MX) ***********************

A-1159-681-A KEY RIGHT BOARD, COMPLETE (EXCEPT RG490: MX/RG590: MX) A-1159-682-A KEY RIGHT BOARD, COMPLETE (RG490: MX/RG590: MX) *************************

< LED > < CAPACITOR > D623 C643 C644

1-162-970-11 CERAMIC CHIP 1-162-970-11 CERAMIC CHIP

0.01uF 0.01uF

10% 10%

8-719-060-27 LED SLR-325MCT31 (SUBWOOFER)

25V 25V

< RESISTOR > R682 R683 R684 R685 R686

1-216-825-11 1-216-825-11 1-216-829-11 1-216-829-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

2.2K 2.2K 4.7K 4.7K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R687 R688

1-216-837-11 METAL CHIP 1-216-841-11 METAL CHIP

22K 47K

5% 5%

1/10W 1/10W

< RESISTOR > R658 R659 R664 R665 R666

1-216-821-11 1-216-821-11 1-216-829-11 1-216-829-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

1K 1K 4.7K 4.7K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R667 R668 R692 R693 R694

1-216-837-11 1-216-841-11 1-216-825-11 1-216-825-11 1-216-829-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 47K 2.2K 2.2K 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R695 R696 R697 R698

1-216-829-11 1-216-833-11 1-216-837-11 1-216-841-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 10K 22K 47K

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

< SWITCH > S624 S631 S631 S632 S632

S633 S633 S634 S635 S636

1-762-875-21 SWITCH, KEYBOARD (ENTER) 1-762-875-21 SWITCH, KEYBOARD (EQ BAND) (RG490/RG590: AEP, UK, RU) 1-762-875-21 SWITCH, KEYBOARD (SLEEP) (RG590: E2, E3, E51, EA, MX, AR) 1-762-875-21 SWITCH, KEYBOARD (SURRROUND) (RG490/RG590: AEP, UK, RU) 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE/TUNING MODE) (RG590: E2, E3, E51, EA, MX, AR) 1-762-875-21 SWITCH, KEYBOARD (GROOVE) (RG490/RG590: AEP, UK, RU) 1-762-875-21 SWITCH, KEYBOARD (REPEAT) (RG590: E2, E3, E51, EA, MX, AR) 1-762-875-21 SWITCH, KEYBOARD (A) 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE) 1-762-875-21 SWITCH, KEYBOARD (DISC 3)

S637 1-762-875-21 SWITCH, KEYBOARD (DISC 2) S638 1-762-875-21 SWITCH, KEYBOARD (DISC 1) S672 1-786-418-11 SWITCH, ROTARY (ENCODER) (MULTI JOG) ************************************************************

< SWITCH > S614 S615 S616 S617 S618

1-762-875-21 1-762-875-21 1-762-875-21 1-762-875-21 1-762-875-21

SWITCH, KEYBOARD (CLEAR) SWITCH, KEYBOARD (GROOVE) SWITCH, KEYBOARD (SURROUND) SWITCH, KEYBOARD (EQ BAND) SWITCH, KEYBOARD (SUBWOOFER)

S641 S642 S643 S644 S645

1-762-875-21 1-762-875-21 1-762-875-21 1-762-875-21 1-762-875-21

SWITCH, KEYBOARD (BASS) SWITCH, KEYBOARD (VOCAL) SWITCH, KEYBOARD (GUITAR) SWITCH, KEYBOARD (ENTER) SWITCH, KEYBOARD (B)

S646 1-762-875-21 SWITCH, KEYBOARD (+) S647 1-762-875-21 SWITCH, KEYBOARD (b) S648 1-762-875-21 SWITCH, KEYBOARD (–) ************************************************************

15

HCD-RG490/RG590 MAIN Ref. No.

Part No.

Description

A-1159-743-A A-1159-744-A A-1159-745-A A-1159-746-A A-1159-747-A

MAIN BOARD, COMPLETE (RG590: AEP, UK) MAIN BOARD, COMPLETE (RG590: E3) MAIN BOARD, COMPLETE (RG590: EA) MAIN BOARD, COMPLETE(RG590: E2, E51, AR) MAIN BOARD, COMPLETE (RG590: MX)

Remark

A-1163-191-A A-1163-192-A A-1163-193-A A-1163-194-A A-1163-195-A

MAIN BOARD, COMPLETE (RG490: AEP) MAIN BOARD, COMPLETE (RG490: RU) MAIN BOARD, COMPLETE (RG490: E3, AUS) MAIN BOARD, COMPLETE (RG490: EA) MAIN BOARD, COMPLETE(RG490: E2, E51, AR)

C124

Part No.

Description

Remark

1-126-933-11 ELECT 100uF 20% 16V 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V 1-162-923-11 CERAMIC CHIP 47PF 5% 50V (RG490: AEP, RU/RG590: AEP, UK, RU) 1-162-923-11 CERAMIC CHIP 47PF 5% 50V (RG490: AEP, RU/RG590: AEP, UK, RU) 1-126-960-11 1-126-960-11 1-126-960-11 1-126-960-11 1-164-156-11

A-1163-196-A MAIN BOARD, COMPLETE (RG490: MX) A-1184-870-A MAIN BOARD, COMPLETE (RG490: RU) *********************

C134

7-685-872-01 SCREW +BVTT 3X8 (S)

C135

C137 C138

1-164-156-11 CERAMIC CHIP 0.1uF 25V (RG490: AEP, RU/RG590: AEP, UK, RU) 1-162-960-11 CERAMIC CHIP 220PF 10% 50V (RG490: AEP, RU/RG590: AEP, UK, RU) 1-162-960-11 CERAMIC CHIP 220PF 10% 50V (RG490: AEP, RU/RG590: AEP, UK, RU) 1-126-960-11 ELECT 1uF 20% 50V 1-126-960-11 ELECT 1uF 20% 50V

C139 C140 C141 C142 C143

1-107-826-11 1-107-826-11 1-126-964-11 1-126-964-11 1-137-374-11

CERAMIC CHIP CERAMIC CHIP ELECT ELECT MYLAR

0.1uF 0.1uF 10uF 10uF 0.047uF

10% 10% 20% 20% 5%

16V 16V 50V 50V 50V

C144 C145 C146 C147 C148

1-137-374-11 1-162-968-11 1-162-968-11 1-164-362-11 1-164-362-11

MYLAR CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.047uF 0.0047uF 0.0047uF 470PF 470PF

5% 10% 10% 5% 5%

50V 50V 50V 50V 50V

C149 C150 C151 C152 C153

1-164-227-11 1-164-227-11 1-164-227-11 1-164-227-11 1-126-960-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT

0.022uF 10% 25V 0.022uF 10% 25V 0.022uF 10% 25V 0.022uF 10% 25V 1uF 20% 50V (RG490/RG590: AEP, UK, RU)

C154

1-126-960-11 ELECT

C155

1-136-167-00 MYLAR

C155

1-136-168-00 MYLAR

C156

1-136-167-00 MYLAR

C156

1-136-168-00 MYLAR

C157

1-136-167-00 MYLAR

0.15uF

5%

C157

1-136-168-00 MYLAR

0.18uF

5%

C158

1-136-167-00 MYLAR

0.15uF

5%

C158

1-136-168-00 MYLAR

0.18uF

5%

C159

1-162-960-11 CERAMIC CHIP

220PF

10%

C160 C163

1-162-960-11 CERAMIC CHIP 1-125-837-11 CERAMIC CHIP

C136

C001 C002 C006 C007 C008

1-136-497-81 1-136-497-81 1-126-964-11 1-126-965-11 1-126-943-11

FILM FILM ELECT ELECT ELECT

0.1uF 0.1uF 10uF 22uF 2200uF

5% 5% 20% 20% 20%

50V 50V 50V 50V 25V

C010 C011 C012 C013 C015

1-165-621-11 1-136-497-81 1-136-497-81 1-126-943-11 1-126-933-11

CERAMIC CHIP FILM FILM ELECT ELECT

0.1uF 0.1uF 0.1uF 2200uF 100uF

5% 5% 20% 20%

50V 50V 50V 25V 16V

C023 C025 C026 C027 C031

1-126-943-11 1-126-933-11 1-162-974-11 1-162-974-11 1-216-864-11

ELECT ELECT CERAMIC CHIP CERAMIC CHIP SHORT CHIP

2200uF 100uF 0.01uF 0.01uF 0

C032

1-162-964-11 CERAMIC CHIP

C033 C034 C035 C063

1-126-933-11 1-126-963-11 1-126-947-11 1-164-156-11

C064 C065

1-162-964-11 CERAMIC CHIP 1-162-964-11 CERAMIC CHIP

20% 20%

25V 16V 50V 50V

0.001uF 10% 50V (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) ELECT 100uF 20% 16V ELECT 4.7uF 20% 50V ELECT 47uF 20% 35V CERAMIC CHIP 0.1uF 25V

C068 C069

0.001uF 10% 50V 0.001uF 10% 50V (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V

C109 C110 C111 C112 C114

1-126-964-11 1-126-964-11 1-126-965-11 1-126-947-11 1-164-360-11

ELECT ELECT ELECT ELECT CERAMIC CHIP

10uF 10uF 22uF 47uF 0.1uF

20% 20% 20% 20%

50V 50V 50V 35V 16V

C115 C116 C117 C118 C119

1-126-933-11 1-126-960-11 1-162-964-11 1-126-961-11 1-126-961-11

ELECT ELECT CERAMIC CHIP ELECT ELECT

100uF 1uF 0.001uF 2.2uF 2.2uF

20% 20% 10% 20% 20%

16V 50V 50V 50V 50V

C120

1-164-360-11 CERAMIC CHIP

16

C121 C122 C123

C125 C126 C129 C130 C133

< CAPACITOR >

C066

Ref. No.

0.1uF

16V

C164

ELECT 1uF 20% 50V ELECT 1uF 20% 50V ELECT 1uF 20% 50V ELECT 1uF 20% 50V CERAMIC CHIP 0.1uF 25V (RG490: AEP, RU/RG590: AEP, UK, RU)

1uF 20% 50V (RG490/RG590: AEP, UK, RU) 0.15uF 5% 50V (RG490) 0.18uF 5% 50V (RG590) 0.15uF 5% 50V (RG490) 0.18uF 5% 50V (RG590) 50V (RG490) 50V (RG590) 50V (RG490) 50V (RG590) 50V

220PF 10% 50V 1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR) 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR)

HCD-RG490/RG590 MAIN Ref. No. C165 C166

Part No.

Description

Remark

1-125-837-11 CERAMIC CHIP

1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR) 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR)

C167

1-104-665-11 ELECT

100uF 20% 25V (RG590: E2, E3, 51, EA, MX, AR) ELECT 100uF 20% 25V (RG590: E2, E3, 51, EA, MX, AR) CERAMIC CHIP 0.01uF 50V (RG590: E2, E3, 51, EA, MX, AR) ELECT 100uF 20% 16V (RG590: E2, E3, 51, EA, MX, AR) CERAMIC CHIP 100PF 5% 50V (RG590: E2, E3, 51, EA, MX, AR)

C168

1-104-665-11

C169

1-162-974-11

C170

1-126-933-11

C171

1-162-927-11

C172

1-162-927-11 CERAMIC CHIP

100PF 5% 50V (RG590: E2, E3, 51, EA, MX, AR) CERAMIC CHIP 47PF 5% 50V CERAMIC CHIP 47PF 5% 50V CERAMIC CHIP 1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR) CERAMIC CHIP 1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR)

C173 C174 C175

1-162-949-11 1-162-949-11 1-125-837-11

C176

1-125-837-11

C177

1-125-837-11 CERAMIC CHIP

C178

1-125-837-11

C253 C254 C255

1-162-923-11 1-162-923-11 1-162-919-11

1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR) CERAMIC CHIP 1uF 10% 6.3V (RG590: E2, E3, 51, EA, MX, AR) CERAMIC CHIP 47PF 5% 50V CERAMIC CHIP 47PF 5% 50V CERAMIC CHIP 22PF 5% 50V

C256 C257 C258 C259 C260

1-162-919-11 1-126-947-11 1-126-947-11 1-126-964-11 1-124-261-00

CERAMIC CHIP ELECT ELECT ELECT ELECT

22PF 47uF 47uF 10uF 10uF

5% 20% 20% 20% 20%

50V 35V 35V 50V 25V

C263 C264 C265 C266 C267

1-126-935-11 1-162-964-11 1-126-963-11 1-126-963-11 1-162-968-11

ELECT CERAMIC CHIP ELECT ELECT CERAMIC CHIP

470uF 0.001uF 4.7uF 4.7uF 0.0047uF

20% 10% 20% 20% 10%

16V 50V 50V 50V 50V

C268 C271 C273 C274 C275

1-162-968-11 1-165-176-11 1-115-467-11 1-124-261-00 1-164-362-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT CERAMIC CHIP

0.0047uF 0.047uF 0.22uF 10uF 470PF

10% 10% 10% 20% 5%

50V 16V 10V 25V 50V

C276 C278 C281 C305

1-115-467-11 1-107-826-11 1-162-974-11 1-162-964-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

C317

1-126-926-11 ELECT

C333

1-164-156-11 CERAMIC CHIP

C336

1-162-970-11 CERAMIC CHIP

C385 C386 C387

1-162-927-11 CERAMIC CHIP 1-162-927-11 CERAMIC CHIP 1-162-962-11 CERAMIC CHIP

0.1uF 25V (RG490: MX/RG590: MX) 0.01uF 10% 25V (RG490: MX/RG590: MX) 100PF 5% 50V 100PF 5% 50V 470PF 10% 50V

C388 C391

1-162-927-11 CERAMIC CHIP 1-164-156-11 CERAMIC CHIP

100PF 0.1uF

Ref. No.

Part No.

Description

Remark

C901 C902 C903

1-126-933-11 ELECT 1-126-964-11 ELECT 1-126-959-11 ELECT

100uF 10uF 0.47uF

20% 20% 20%

C904 C906 C908 C909 C910

1-164-156-11 1-126-964-11 1-164-156-11 1-164-156-11 1-164-156-11

CERAMIC CHIP ELECT CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP

0.1uF 10uF 0.1uF 0.1uF 0.1uF

C911 C912 C913 C914 C916

1-162-964-11 1-164-156-11 1-162-905-11 1-162-919-11 1-114-154-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP DOUBLE LAYER

0.001uF 0.1uF 1PF 22PF 47000uF

50V 25V 0.25PF 50V 5% 50V 5.5V

C917 C918 C919 C920 C921

1-164-156-11 1-162-964-11 1-164-156-11 1-162-905-11 1-126-961-11

CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP CERAMIC CHIP ELECT

0.1uF 0.001uF 0.1uF 1PF 2.2uF

25V 50V 25V 0.25PF 50V 20% 50V

C922 C923 C924

1-126-963-11 ELECT 1-162-960-11 CERAMIC CHIP 1-162-927-11 CERAMIC CHIP

20%

16V 50V 50V 25V 50V 25V 25V 25V

10%

10%

C926

4.7uF 20% 50V 220PF 10% 50V 100PF 5% 50V (RG490: AEP/RG590: AEP, UK) 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (RG490: AEP/RG590: AEP, UK) 1-162-960-11 CERAMIC CHIP 220PF 10% 50V

C927

1-162-919-11 CERAMIC CHIP

C925

22PF

5%

50V

< CONNECTOR > * CN031 CN041 CN061 CN061

0.22uF 10% 10V 0.1uF 10% 16V 0.01uF 50V 0.001uF 10% 50V (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 1000uF 20% 10V

5%

50V 25V

CN091 CN201 CN301 CN302 CN331 CN991

1-573-094-11 SOCKET, CONNECTOR 13P 1-819-131-11 PIN, CONNECTOR 3P 1-568-828-11 CONNECTOR, FFC 9P (RG490: AEP, RU, E3, EA, AUS/RG590: AEP, UK, RU, E3, EA) 1-784-774-11 CONNECTOR, FFC 13P (RG490: E2, E51, MX, AR/RG590: E2, E51, MX, AR) 1-568-828-11 CONNECTOR FFC 9P, 1-568-830-11 CONNECTOR, FFC11P 1-779-291-11 CONNECTOR, FFC (LIF (NON-ZIF)) 23P (EXCEPT RG490: MX/RG590: MX) 1-779-299-11 CONNECTOR, FFC (LIF (NON-ZIF)) 31P (RG490: MX/RG590: MX) 1-784-774-11 CONNECTOR, FFC 13P (RG490: MX/RG590: MX) 1-784-780-11 CONNECTOR, FFC 19P < DIODE >

D001 D002 D003 D004 D006

6-500-522-21 6-500-522-21 6-500-522-21 6-500-522-21 8-719-988-61

DIODE DIODE DIODE DIODE DIODE

10EDB40-TB3 10EDB40-TB3 10EDB40-TB3 10EDB40-TB3 1SS355TE-17

D007 D008 D009 D011 D012

6-501-166-01 8-719-000-08 6-500-335-01 6-500-522-21 6-500-522-21

DIODE DIODE DIODE DIODE DIODE

UDZW-TE17-4.7B MC2838 MC2838-T112-1 10EDB40-TB3 10EDB40-TB3

D013 D014 D021 D022

6-500-522-21 6-500-522-21 6-500-522-21 6-500-522-21

DIODE DIODE DIODE DIODE

10EDB40-TB3 10EDB40-TB3 10EDB40-TB3 10EDB40-TB3

17

HCD-RG490/RG590 MAIN Ref. No.

Part No.

Description

Remark

D023

6-500-522-21 DIODE 10EDB40-TB3

D024 D031 D035 D036 D301

6-500-522-21 8-719-988-61 8-719-000-08 8-719-000-07 6-500-522-21

D302 D303 D901 D902 D905

6-500-522-21 DIODE 10EDB40-TB3 6-501-166-01 DIODE UDZW-TE17-4.7B (RG490: MX/RG590: MX) 6-501-166-01 DIODE UDZW-TE17-4.7B 8-719-000-07 DIODE MC2836 8-719-988-61 DIODE 1SS355TE-17

D910 D921 D923 D943 D947

8-719-988-61 6-500-848-01 6-500-848-01 8-719-000-08 8-719-988-61

DIODE DIODE DIODE DIODE DIODE

10EDB40-TB3 1SS355TE-17 MC2838 MC2836 10EDB40-TB3

Ref. No.

Part No.

Description

JR114 JR115

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP

JR116 JR117 JR118 JR119 JR120

1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11

JR121 JR122 JR123

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP

SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP

Remark 0 0 0 (RG490: MX/RG590: MX) 0 0 0 0 (EXCEPT RG490: MX/RG590: MX) 0 0 0

< TRANSISTOR > DIODE DIODE DIODE DIODE DIODE

1SS355TE-17 MC2840-T112-1 MC2840-T112-1 MC2838 1SS355TE-17

Q002 Q011 Q041 Q042 Q043

8-729-120-28 8-729-027-43 8-729-120-28 8-729-037-13 8-729-037-03

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SC1623-L5L6 DTC114EKA-T146 2SC1623-L5L6 KTA1271Y KTA1266GR-AT

Q044 Q045 Q046 Q111 Q112

8-729-120-28 8-729-120-28 8-729-045-62 8-729-120-28 8-729-120-28

TRANSISTOR TRANSISTOR FET TRANSISTOR TRANSISTOR

2SC1623-L5L6 2SC1623-L5L6 2SK2158-T2B 2SC1623-L5L6 2SC1623-L5L6

Q113 Q114 Q251 Q252 Q261

8-729-120-28 8-729-120-28 8-729-120-28 8-729-120-28 8-729-027-23

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SC1623-L5L6 2SC1623-L5L6 2SC1623-L5L6 2SC1623-L5L6 DTA114EKA-T146

Q271 Q272 Q274 Q276 Q277

8-729-120-28 8-729-120-28 6-551-276-01 8-729-120-28 8-729-120-28

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SC1623-L5L6 2SC1623-L5L6 RT1N431C-TP-1 2SC1623-L5L6 2SC1623-L5L6

Q901 Q902 Q903 Q904

8-729-120-28 8-729-120-28 8-729-037-13 8-729-120-28

TRANSISTOR TRANSISTOR TRANSISTOR TRANSISTOR

2SC1623-L5L6 2SC1623-L5L6 KTA1271Y 2SC1623-L5L6

< IC > IC006 IC006 IC011 IC011 IC021

IC021 IC101 IC101 IC102 IC102 IC251 IC251 IC901 IC901 IC902

IC902

6-702-771-01 IC TA78033LS (EXCEPT RG490: MX/RG590: MX) 6-702-771-01 IC TA78033LS (RG490: MX/RG590: MX) 8-759-701-59 IC NJM78M09FA (EXCEPT RG490: MX/RG590: MX) 8-759-701-59 IC NJM78M09FA (RG490: MX/RG590: MX) 8-759-701-59 IC NJM78M09FA (EXCEPT RG490: MX/RG590: MX) 8-759-701-59 IC NJM78M09FA (RG490: MX/RG590: MX) 6-709-331-01 IC R2S15207FP (EXCEPT RG490: MX/RG590: MX) 6-709-331-01 IC R2S15207FP (RG490: MX/RG590: MX) 6-709-330-01 IC R2S15208SP (RG590: E2, E3, E51, EA, AR) 6-709-330-01 IC R2S15208SP (RG590: MX) 8-759-909-71 IC BA4558F (EXCEPT RG490: MX/RG590: MX) 8-759-909-71 IC BA4558F (RG490: MX/RG590: MX) (Not supplied) IC uPD78F0547GC (S)-UBT-A (EXCEPT RG490: MX/RG590: MX) (Not supplied) IC uPD78F0547GC (S)-UBT-A (RG490: MX/RG590: MX) 8-759-713-61 IC PST3429UL (EXCEPT RG490: MX/RG590: MX) 8-759-713-61 IC PST3429UL (RG490: MX/RG590: MX) < JUMPER RESISTOR >

JR101

1-216-864-11 SHORT CHIP

JR102

1-216-864-11 SHORT CHIP

JR103 JR104 JR105

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP

JR106 JR107 JR108 JR109 JR110

1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11 1-216-864-11

JR111 JR112 JR113

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP

18

SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP SHORT CHIP

0 (RG490: AEP, RU, E3, EA, AUS/RG590: AEP, UK, RU, E3, EA) 0 (RG490: AEP, RU, E3, EA, AUS/RG590: AEP, UK, RU, E3, EA) 0 0 0 0 0 0 0 0 0 0 0 (RG490: MX/RG590: MX)

Note: IC901 on the MAIN board cannot exchange with single. When IC901 is damaged, exchange the entire mounted board.

< RESISTOR > R001 R005 R006 R010 R011

1-216-801-11 1-216-829-11 1-216-829-11 1-216-837-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22 4.7K 4.7K 22K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R013 R014 R016 R032 R033

1-216-837-11 1-216-833-11 1-216-845-11 1-216-821-11 1-216-837-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 10K 100K 1K 22K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R034 R035 R036 R037 R039

1-216-837-11 1-216-829-11 1-216-829-11 1-216-829-11 1-260-308-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP CARBON

22K 4.7K 4.7K 4.7K 22

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/2W

R041 R042 R043 R045

1-216-864-11 1-216-833-11 1-216-829-11 1-216-821-11

SHORT CHIP METAL CHIP METAL CHIP METAL CHIP

0 10K 4.7K 1K

5% 5% 5%

1/10W 1/10W 1/10W

HCD-RG490/RG590 MAIN Ref. No.

Part No.

Description

Remark

R046

1-216-793-11 METAL CHIP

4.7

5%

1/10W

R047 R048 R049 R050 R051

1-216-789-11 1-216-801-11 1-216-849-11 1-216-825-11 1-216-825-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

2.2 22 220K 2.2K 2.2K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R052 R053 R054 R055 R056

1-216-853-11 1-216-837-11 1-216-837-11 1-216-825-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

470K 22K 22K 2.2K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R057 0 R059 0 R060 R061 R063

1-216-821-11 1-215-892-11 1-215-892-11 1-216-797-11 1-216-809-11

METAL CHIP METAL OXIDE METAL OXIDE METAL CHIP METAL CHIP

1K 1K 1K 10 100

5% 5% 5% 5% 5%

1/10W 2W F 2W F 1/10W 1/10W

Part No.

Description

Remark

R129

1-216-853-11 METAL CHIP

470K 5% 1/10W (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 47K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 470K 5% 1/10W (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 100 5% 1/10W 100 5% 1/10W

R130

1-216-841-11 METAL CHIP

R130

1-216-853-11 METAL CHIP

R131 R132

1-216-809-11 METAL CHIP 1-216-809-11 METAL CHIP

R133

1-216-864-11 SHORT CHIP

R134

1-216-864-11 SHORT CHIP

R135 R136 R137

1-216-833-11 METAL CHIP 1-216-833-11 METAL CHIP 1-216-825-11 METAL CHIP

0 (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 0 (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 10K 5% 1/10W 10K 5% 1/10W 2.2K 5% 1/10W

R138 R139 R140 R141 R142

1-216-825-11 1-216-821-11 1-216-821-11 1-216-837-11 1-216-837-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

2.2K 1K 1K 22K 22K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R143 R144 R145 R147 R148

1-216-813-11 1-216-813-11 1-216-841-11 1-216-841-11 1-216-841-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

220 220 47K 47K 47K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R151

1-216-809-11 METAL CHIP

R152

1-216-809-11 METAL CHIP

R153

1-216-809-11 METAL CHIP

R154 R155

1-216-857-11 METAL CHIP 1-216-849-11 METAL CHIP

R064 R068

1-216-809-11 METAL CHIP 1-216-797-11 METAL CHIP

R070 R101 R102

1-216-833-11 METAL CHIP 1-216-833-11 METAL CHIP 1-216-821-11 METAL CHIP

R103 R104 R105 R106

1-216-833-11 1-216-833-11 1-216-809-11 1-216-821-11

R108

1-216-825-11 METAL CHIP

10K 5% 1/10W 10K 5% 1/10W 100 5% 1/10W 1K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 2.2K 5% 1/10W

R109 R110 R111 R112 R113

1-216-829-11 1-216-841-11 1-216-845-11 1-216-817-11 1-216-829-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 47K 100K 470 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R114 R116 R119 R120 R121

1-216-825-11 1-216-809-11 1-216-825-11 1-216-825-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

2.2K 100 2.2K 2.2K 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R156 R157 R158 R159 R160

1-216-849-11 1-216-849-11 1-216-849-11 1-216-841-11 1-216-841-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

220K 220K 220K 47K 47K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R122 R123 R124 R125 R126

1-216-809-11 1-216-825-11 1-216-825-11 1-216-829-11 1-216-829-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 2.2K 2.2K 4.7K 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R161 R162 R163 R164 R165

1-216-837-11 1-216-837-11 1-216-841-11 1-216-841-11 1-216-829-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 22K 47K 47K 4.7K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R127

1-216-821-11 METAL CHIP

METAL CHIP METAL CHIP METAL CHIP SHORT CHIP SHORT CHIP

4.7K 1K 1K 0 0

1/10W 1/10W 1/10W

1-216-825-11 METAL CHIP

1-216-829-11 1-216-821-11 1-216-821-11 1-216-864-11 1-216-864-11

5% 5% 5%

R127

R166 R167 R168 R171 R172

R128

1-216-821-11 METAL CHIP

METAL CHIP METAL CHIP SHORT CHIP SHORT CHIP METAL CHIP

2.2K 2.2K 0 0 2.2K

1/10W 1/10W

1-216-825-11 METAL CHIP

1-216-825-11 1-216-825-11 1-216-864-11 1-216-864-11 1-216-825-11

5% 5%

R128

R175 R176 R177 R178 R201

5%

1/10W

R202 R250

1-216-825-11 METAL CHIP 1-216-829-11 METAL CHIP

2.2K 4.7K

5% 5%

1/10W 1/10W (RG490)

R129

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

1-216-841-11 METAL CHIP

100 5% 1/10W 10 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 10K 5% 1/10W 10K 5% 1/10W 1K 5% 1/10W

Ref. No.

1K

5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 2.2K 5% 1/10W (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 1K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR) 2.2K 5% 1/10W (RG490: AEP, RU, E3, EA, AUS/ RG590: AEP, UK, RU, E3, EA) 47K 5% 1/10W (RG490: E2, E51, MX, AR/ RG590: E2, E51, MX, AR)

100 5% 1/10W (RG590: E2, E3, E51, EA, MX, AR) 100 5% 1/10W (RG590: E2, E3, E51, EA, MX, AR) 100 5% 1/10W (RG590: E2, E3, E51, EA, MX, AR) 1M 5% 1/10W 220K 5% 1/10W

19

HCD-RG490/RG590 MAIN Ref. No.

Part No.

Description

Remark

Description

Remark

R333

1-216-833-11 METAL CHIP

R334

1-216-809-11 METAL CHIP

R335

1-216-809-11 METAL CHIP

R336

1-216-833-11 METAL CHIP

R337

1-216-809-11 METAL CHIP

R338

1-216-809-11 METAL CHIP

R339

1-216-821-11 METAL CHIP

R340

1-216-821-11 METAL CHIP

R341

1-216-833-11 METAL CHIP

5% 1/10W (RG490: MX/RG590: MX) 100 5% 1/10W (RG490: MX/RG590: MX) 1K 5% 1/10W (RG490: MX/RG590: MX) 1K 5% 1/10W (RG490: MX/RG590: MX) 10K 5% 1/10W

R342 R343 R344 R345 R346

1-216-821-11 1-216-837-11 1-216-837-11 1-216-833-11 1-216-821-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

1K 22K 22K 10K 1K

R347 R348 R349 R350

1-216-837-11 1-216-837-11 1-216-833-11 1-216-821-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 22K 10K 1K

R351

1-216-825-11 METAL CHIP

2.2K

R351

1-216-833-11

R351

1-216-845-11

R352

1-216-821-11

R352

1-216-833-11

R352

1-216-853-11 METAL CHIP

R353 R354

1-216-833-11 METAL CHIP 1-216-821-11 METAL CHIP

R354

1-216-837-11 METAL CHIP

5% 1/10W (RG490: MX/RG590: MX) 100 5% 1/10W 100 5% 1/10W 100 5% 1/10W 100 5% 1/10W

R355

1-216-825-11 METAL CHIP

R355

1-216-829-11 METAL CHIP

R355

1-216-837-11 METAL CHIP

22K 22K 100

R356

1-216-857-11 METAL CHIP

R363 R364

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP

5% 1/10W (RG590: AEP, UK, RU) 22K 5% 1/10W (RG490) 1M 5% 1/10W (RG490/RG590: AEP, UK, RU) 0 0

R365 R366 R372

1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP 1-216-809-11 METAL CHIP

0 0 100

10K

5%

R251 R252

1-216-817-11 METAL CHIP 1-216-817-11 METAL CHIP

470 470

5% 5%

R253

1-216-829-11 METAL CHIP

4.7K

5%

R253

1-216-833-11 METAL CHIP

10K

5%

R254

1-216-826-11 METAL CHIP

2.7K

5%

R254

1-216-829-11 METAL CHIP

4.7K

5%

R257

1-216-826-11 METAL CHIP

2.7K

5%

R257

1-216-829-11 METAL CHIP

4.7K

5%

R261 R262 R263 R264

1-216-833-11 1-216-833-11 1-216-825-11 1-216-825-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10K 10K 2.2K 2.2K

5% 5% 5% 5%

1/10W (RG590) 1/10W 1/10W 1/10W 1/10W

R265 R267 R268 R269 R271

1-216-809-11 1-216-841-11 1-216-829-11 1-216-825-11 1-216-864-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP SHORT CHIP

100 47K 4.7K 2.2K 0

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

R272 R274 R276 R277 R279

1-216-829-11 1-216-829-11 1-216-833-11 1-216-825-11 1-216-825-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 4.7K 10K 2.2K 2.2K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R280 R281 R283 R285 R286

1-216-829-11 1-216-825-11 1-216-833-11 1-216-833-11 1-216-837-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 2.2K 10K 10K 22K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R287 R289 R290 R291 R292

1-216-853-11 1-216-845-11 1-216-821-11 1-216-817-11 1-216-817-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

470K 100K 1K 470 470

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R315 R316 R317 R318 R319

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R320

1-216-809-11 METAL CHIP

100

R321 R322 R323 R324

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

R325 R326 R329

1-216-837-11 METAL CHIP 1-216-837-11 METAL CHIP 1-216-809-11 METAL CHIP

R330

1-216-821-11 METAL CHIP

R331

1-216-809-11 METAL CHIP

20

Part No.

1-216-809-11 METAL CHIP

1-216-833-11 METAL CHIP

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

Ref. No. R332

R250

1/10W (RG590) 1/10W 1/10W 1/10W (RG490) 1/10W (RG590) 1/10W (RG490) 1/10W (RG590) 1/10W (RG490)

5% 1/10W 5% 1/10W 5% 1/10W (RG490: MX/RG590: MX) 1K 5% 1/10W (RG490: MX/RG590: MX) 100 5% 1/10W (RG490: MX/RG590: MX)

R350

100

5% 1/10W (RG490: MX/RG590: MX) 10K 5% 1/10W (RG490: MX/RG590: MX) 100 5% 1/10W (RG490: MX/RG590: MX) 100 5% 1/10W (RG490: MX/RG590: MX) 10K 5% 1/10W (RG490: MX/RG590: MX) 100

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

5% 1/10W 5% 1/10W 5% 1/10W 5% 1/10W (RG490: RU/RG590: RU) 1-216-833-11 METAL CHIP 10K 5% 1/10W (RG490: E2, E51, EA, AR/RG590: E2, E51, EA, AR) 5% 1/10W (RG490: RU/RG590: RU) METAL CHIP 10K 5% 1/10W (RG490: E2, E51, AR/RG590: E2, E51, AR) METAL CHIP 100K 5% 1/10W (RG490: EA/RG590: EA) METAL CHIP 1K 5% 1/10W (RG490: AEP/RG590: AEP, UK) METAL CHIP 10K 5% 1/10W (RG490: MX/RG590: MX) 470K

5% 1/10W (RG490: EA/RG590: EA) 10K 5% 1/10W 1K 5% 1/10W (RG590) 22K 5% 1/10W (RG490) 2.2K 5% 1/10W (RG590: E2, E3, E51, EA, MX, AR) 4.7K

5% 1/10W (RG490: MX/RG590: MX)

HCD-RG490/RG590 MAIN Ref. No.

Part No.

Description

Remark

R381 R382

1-216-821-11 METAL CHIP 1-216-821-11 METAL CHIP

1K 1K

5% 5%

1/10W 1/10W

R383 R901 R902 R903 R904

1-216-821-11 1-216-845-11 1-216-864-11 1-216-833-11 1-216-825-11

METAL CHIP METAL CHIP SHORT CHIP METAL CHIP METAL CHIP

1K 100K 0 10K 2.2K

5% 5%

1/10W 1/10W

5% 5%

1/10W 1/10W

R905 R907 R908 R909 R910

1-216-833-11 1-216-841-11 1-216-841-11 1-216-837-11 1-216-833-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

10K 47K 47K 22K 10K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R911 R912 R913 R914 R918

1-216-821-11 1-216-821-11 1-216-821-11 1-216-833-11 1-216-849-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

1K 1K 1K 10K 220K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R919 R920 R921 R922 R923

1-216-864-11 1-216-853-11 1-216-809-11 1-216-849-11 1-216-809-11

SHORT CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

0 470K 100 220K 100

5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

R924 R925

1-216-809-11 METAL CHIP 1-216-809-11 METAL CHIP

R925

1-216-821-11 METAL CHIP

R932 R935

1-216-825-11 METAL CHIP 1-216-833-11 METAL CHIP

R936 R941 R942 R943 R944

1-216-837-11 1-216-825-11 1-216-833-11 1-216-829-11 1-216-849-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

22K 2.2K 10K 4.7K 220K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R945 R946 R947 R948 R949

1-216-813-11 1-216-864-11 1-216-849-11 1-216-825-11 1-216-833-11

METAL CHIP SHORT CHIP METAL CHIP METAL CHIP METAL CHIP

220 0 220K 2.2K 10K

5%

1/10W

5% 5% 5%

1/10W 1/10W 1/10W

R950 R951 R952 R953 R955

1-216-829-11 1-216-813-11 1-216-841-11 1-216-833-11 1-216-821-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

4.7K 220 47K 10K 1K

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W 1/10W

R956 R957 R959 R961

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100

R961

1-216-821-11 METAL CHIP

R963 R965 R967 R968

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

R969

1-216-809-11 METAL CHIP

5% 1/10W 5% 1/10W 5% 1/10W 5% 1/10W (RG490: MX/RG590: MX) 100 5% 1/10W

R970

1-216-809-11 METAL CHIP

100

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

Ref. No.

Part No.

Description

R971 R972 R973 R974

1-216-809-11 1-216-809-11 1-216-809-11 1-216-809-11

METAL CHIP METAL CHIP METAL CHIP METAL CHIP

100 100 100 100

R975 R976 R977

1-216-809-11 METAL CHIP 1-216-809-11 METAL CHIP 1-216-809-11 METAL CHIP

100 100 100

R979 R980

1-216-809-11 METAL CHIP 1-216-809-11 METAL CHIP

5% 1/10W 5% 1/10W 5% 1/10W (RG490: MX/RG590: MX) 100 5% 1/10W 100 5% 1/10W

R981 R982 R996 R997 R999

1-216-809-11 1-216-817-11 1-216-809-11 1-216-809-11 1-216-809-11

100 470 100 100 100

METAL CHIP METAL CHIP METAL CHIP METAL CHIP METAL CHIP

Remark 5% 5% 5% 5%

5% 5% 5% 5% 5%

1/10W 1/10W 1/10W 1/10W

1/10W 1/10W 1/10W 1/10W 1/10W

< VIBRATOR > X901 X902

1-579-463-11 VIBRATOR, CRYSTAL (32.768kHz) 1-795-482-11 VIBRATOR, CERAMIC (16MHz)

100 100

5% 1/10W 5% 1/10W (RG490: MX/RG590: MX) 1K 5% 1/10W (RG490: AEP/RG590: AEP, UK) 2.2K 5% 1/10W 10K 5% 1/10W

5% 1/10W 5% 1/10W 5% 1/10W 5% 1/10W (RG490: MX/RG590: MX) 1K 5% 1/10W (RG490: AEP/RG590: AEP, UK) 100 100 100 100

5%

1/10W

21

HCD-RG490/RG590

REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver.

Date

Description of Revision

1.0

2006.02

New

1.1

2006.04

Addition of AEP, Russian, Saudi Arabia, Argentina and Australian models to HCD-RG490 Addition of AEP, Russian, Saudi Arabia models to HCD-RG590 Change of DECK board (Suffix-12) (SUPPLEMENT-1)

1.2

2006.06

(ECN-ECB57489)

Change of KEY LEFT, MIC. AUX. HP and boards (Suffix-12 (RG490: Mexican/RG590: Mexican models) or Suffix-13 (Except RG490: Mexican/RG590: Mexican models)) Change of MAIN, KEY RIGHT and KEY TOP boards (Suffix-12 (RG490: Mexican/RG590: Mexican models) or Suffix-13 (Except RG490: Mexican/RG590: Mexican models)) (SUPPLEMENT-2) (ECN-ECB62070)

2
