Introduction & Parts Ordering E.S. Ritchie & Sons, Inc. has a tradition of excellence in servicing its products. Our customers expect timely, accurate, and complete repair of all Ritchie® products, and we are committed to continuing this tradition. As a qualified repair technician, your contribution is vital. Your work directly affects customer satisfaction. This manual is your key resource to help you repair and service Ritchie® navigational instruments.

Parts ordering Information 1. Parts are available from the factory at 50% off list price to Ritchie Authorized Service Stations who meet all requirements. 2. There is a net $20.00 minimum order. 3. Proper part numbers from the most recent Service Manual must be used. If you are unsure of a part number please because there will be a 15% re-stocking fee for improperly ordered parts returned to the factory. Parts can be ordered by: Phone 781-826-5131 781-709-3202 Fax 781-826-7336

e-mail [email protected] Mail

E.S. Ritchie & Sons, Inc. P.O. Box 548 Pembroke, MA 02359

The following are ed Trademarks and Trade Names of E.S. Ritchie & Sons. CombiDamp™ Explorer™ Globemaster® Helmsman™ Kayaker™ Navigator™ PowerDamp Plus® PowerDamp®

Com Dial Magnetic Com Magnetic Com Magnetic Com Magnetic Com Magnetic Com Com Dial Com Dial

Ritchie® RitchieAngler® RitchieSport® SportAbout™ SuperSport™ Tactician™ Trek™ Voyager®

Navigation Instruments Magnetic Com Magnetic Com Hand Held Com Magnetic Com Magnetic Com Magnetic Com Magnetic Com

This manual is arranged by com families. If you do not know what family the com is in, see the index at the back of this manual.

Isopar® is a ed Trademark of Exxon Mobil Corporation. Mossy Oak® is a ed Trademark of Haas Outdoors, Inc. Break Up® is a ed Trademark of Haas Outdoors, Inc. Shadow Grass® is a ed Trademark of Haas Outdoors, Inc.

January 1, 2007

0-1

Service Manual Information Model and Serial Number Information Most Ritchie comes built after 1974 were supplied with a model & serial number sticker which can be found on the com bowl or the bottom of the housing. The serial number is key to determining what year a com was built, which in turn helps you determine what parts to order in this manual. The serial number will take one of three forms. 1. A code number stamped in the bezel designated the model # and year of manufacture. Ritchie with this number for model and year information. 2. A code that consists of a letter (A, B, C, or D) and a slash /, followed by a 2 digit number. 3. A 10-digit number in which the first 2 numbers represent the year of manufacture and the second two indicate any mid year model changes. These changes are referred to as Rev numbers. (00 indicates no changes) (01 would indicate Rev 1) Note: Some comes have a –R in the serial number. This indicates that a Globemaster has been upgraded to a bladder style diaphragm and bowl. Examples of serial numbers A/87 A/87-R 94.000123 94.010124

Built in 1987; any parts ordered will be for a 1987 model com. Built in 1987 but upgraded to a bladder style diaphragm and bowl, order accordingly. Built in 1994; consider it a 1994 in this manual Built in 1994: consider it a 1994 Rev 1 in this manual.

Zone Sticker & Dial Balance For the ultimate in accuracy Ritchie Com Dials are balanced to accommodate for magnetic inclination in the Northern Hemisphere. By special request Southern Hemisphere dials are available. To determine if a dial has been balanced for Zones 2 through 7 check the bottom of the dial for a scribed number. (Models made after 1997 will also have a zone label on the bowl. Please indicate zone when ordering a dial for the Southern Hemisphere. Note: Dials in the Explorer models will function properly in all zones except 7. Fluid Labels (Isopar L) All Ritchie comes (except sealed capsule models) will have an ID label indicating that the com is filled with Isopar. Older models containing odorless Mineral Spirits will have no ID label. Using This Manual This manual is divided into seven sections arranged by com family. An Index is provided at the back of the manual for model number reference. Most even number pages have diagrams showing com breakdown. Each part is assigned a key number, which is used in conjunction with the parts list found on the next page. If there is more than one key number assigned to part, different colors or types are available. N/A indicates that the part is no longer available. In some cases a replacement part may be available and the part number is given.

January 1, 2007

0-2

Repair Tips Opening comments 1. Be careful not to disturb the compensators when performing a repair. If you do, re-compensation will be necessary. 2. Before beginning any service work, check the dial’s sensitivity. 3. Replace O-rings on all repairs. 4. Make sure you do not disturb the factory bend in the balance tab, unless re-balancing the gimbal ring & pan assembly is necessary. 5. When reassembling fully gimbaled units, make sure to install the gimbal with the correct side up. The flat surface should be on top and the gimbal pins and springs should not be visible. General Repair Tips Sticking dial 1. Before disassembly, follow these steps to test for a sticking dial. a) Allow dial to settle, and then take note of the reading. b) Deflect the dial 5o to port with a ferrous screwdriver or similar device. c) Check to see that the dial returns to the original reading. d) Repeat steps b and c, this time deflect the dial to starboard. 2. If the dial fails to return accurately the cause is usually a worn or defective pivot or jewel. The complete dial assembly must be replaced. The pivot and jewel are not field repairable. 3. Drain the com of fluid and remove the dome. 4. Do not disturb the factory bend in the balance tab, unless the gimbal system is off balance. If it is off balance, refer to the next section. 5. Replace the dial assembly and re-assemble the com with new O-ring seals. Gimbal system off balance 1. Drain the com of fluid and remove the dome. 2. Allow the dial/pan/gimbal assembly to dry thoroughly before attempting to balance them. 3. Check the pan to gimbal ring spacing. The pan should have just enough clearance to swing freely within the ring. Excess spacing will cause the pan to slide side to side and make accurate gimbal balance virtually impossible. 4. Set the bowl on the bench and using a small bubble level shim it until the top is level. 5. Place the dial/pan/gimbal assembly in the bowl and observe the relationship between the gimbal ring and the top of the bowl. If necessary, bend the balance tab to level the gimbal ring with the top of the bowl. 6. Observe the relationship of the pan to the gimbal ring. If necessary, bend the balance tab to level the pan with the gimbal ring. 7. Re-assemble the com with new O-ring seals.

January 1, 2007

0-3

Repair Tips & Fluid Requirements

Bubble in the fluid A bubble in the fluid usually indicates a leak or incomplete vacuuming of the fluid. The problem may be caused by inadequately bottomed bezel or diaphragm retaining screws, improperly installed fill plug screw, failed o-ring, diaphragm, bowl, or crazed dome. 1. Check to see if there is an O-ring or diaphragm leak by pressing on the diaphragm. 2. Replace the failed part. 3. Make sure the diaphragm retainer is completely bottomed out. 4. Re-assemble the com with new O-ring seals. Dome Replacement 1. Always replace the dome if any cracks or de-lamination is visible. 2. When re-assembling a flare type dome, the dome must be centered inside the bezel and the bezel screws must be tightened evenly in a torque pattern. There should be a space left between the bezel and clamping ring that is even all the way around. 3. When re-assembling a compression type dome, the dome and bezel will self-center. the bezel screws must be tightened evenly in a torque pattern. The bezel will bottom against the bowl (or clamping ring) when the screws are tight. Dampening Fluid Always use Ritchie com fluid. (Be sure to subject the fluid to a vacuum equivalent of 28 inches of mercury for a minimum of 15 minutes before sealing it in the com. This step prevents the formation of a bubble in the fluid due to temperature changes.) Ritchie began using Isopar L as dampening fluid during 2001. This fluid is a high-purity isoparaffinic solvent very similar to Odorless Mineral spirits. Ritchie changed to this fluid because it has a higher flash point and conforms to most of the world's shipping regulations. It is important to note that some other manufacturers use Isopar M as their dampening fluid. PLEASE NOTE: ISOPAR M CANNOT BE USED IN RITCHIE COMES. Replacing Odorless Mineral spirits with Isopar L Ritchie will no longer be providing Odorless Mineral Spirits. If you have a com that has odorless mineral spirits, you can replace it with Isopar L. It is recommended that you completely replace the old fluid with Isopar L. There is no harm to the com if a small amount of Odorless Mineral Sprits is mixed with the Isopar L.

Quantity Ritchie Part # Pint (16 fl oz) SH-0154 Quart (32 fl oz) SH-0155 1 Gallon (128 fl oz) SH-0156 4 Gallons (512 fl oz) SH-0157

January 1, 2007

Fluid Capacity Voyager 9.4 fl oz Helmsman 17.0 fl oz Navigator 24.4 fl oz 5" Globemaster 40.0 fl oz 6" Globemaster 66.1 fl oz

0-4

Options for Alternate Lighting Voltages Type 1 Lighting (1 LED) These Compases have one light wire B-80's (all) & B-81's (1981 to 1997) D-84's (all) & D-85 (1981 to 1997) F-82's (all) & F-83's (1981 to 1997) HB-70 (All) & HB-71 (1981 to 1995) HB-85 (All) HD-74 (All) & HD-75 (1981 to 1995) HD-75 (1981 to 1995) HF-72's (all) & HF-73's (1981 to 1995) HF-742's (all) HV-76 & 77 (all) SS-1000's (all) & SS-1002's (all) Type 2 Lighting (2 LED's) These Compases have two light wires (2 LED's Total) B-81's & D-85 (1998 to 2005) F-83's (1998 to 2005) HB-71 & HD-75 (1996 to 2005) HF-73's & HF-743's (1996 to 2005) HF-79's (all) S-87's (2000 to 2005) Type 3 Lighting (2 LED's) These Compases have one light wire DNB-200, DNP-200 & DNW-200 (all) FN-201's & FNW-201's (all) Globemasters (1996 to present) SS-2000's (all)

Resistor selection by LED Part Number 24 volt 32 volt GM-0087 ASY SH-0126-200 SH-0126-330 NV-0044 ASY w/ NV-0045 ASY SH-0028 ASY SH-0029 ASY SH-0102 ASY SH-0102 ASY (2) SH-0111 ASY SH-0174 ASY SH-0174 ASY w/ NV-0128 ASY SH-0176 ASY SH-0194 ASY* SH-0194 ASY w/ SH-0195* ASY SH-0195 ASY* SH-0195 ASY* (2) SH-0202 ASY* * ultra-bright LED

January 1, 2007

SH-0126-200 SH-0126-330 SH-0126-200 SH-0126-330 SH-0126-330 SH-0126-200 SH-0126-200 SH-0126-200

SH-0126-330 SH-0126-500 SH-0126-500 SH-0126-330 SH-0126-330 SH-0126-330

Type 1a Lighting (1 ultra bright LED) These Compases have one light wire B-80's (2005 rev 1 to present) D-84's (2005 rev 1 to present) F-82's (2005 rev 1 to present) HB-70 (2005 rev 1 to present) HB-740 & HB-845 (all) HB-85 & HD-74 (2005 rev 1 to present) HD-744 (all) HF-72's & HF-742's (2005 rev 1 to present) SS-1000's & SS-1002's (2005 rev 1 to present) Type 2a Lighting (2 ultra bright LED's) These Compases have two light wires B-81's (2005 rev 1 to present) F-83's (2005 rev 1 to present) HB-71 (2005 rev 1 to present) HB-741 & HD-745 (all) HD-75 (2005 rev 1 to present) HF-743's (2005 rev 1 to present) S-87's (2005 rev 1 to present) Type 4 Lighting (4 LED's) These Compases have two light wires DNB-203, DNP-203 & DNW-203 (all) FN-203's & FNW-203's (all) Type 5 Lighting (3 LED's) These Compases have two light wires BN-202 (all)

Resistor selection by Lighting Type 24 volt 32 volt Type 1 SH-0126-330 SH-0126-500 Type 1a SH-0126-820 SH-0126-1.1 Type 2 SH-0126-200 SH-0126-330 Type 2a SH-0126-390 SH-0126-560 Type 3 SH-0126-200 SH-0126-330 Type 4 NV-0160-150 NV-0162-250 Type 5 SH-0126-200 SH-0126-330

NV-0160-150 NV-0162-250 SH-0126-200 SH-0126-330 SH-0126-820 SH-0126-1.1 SH-0126-390 SH-0126-560 SH-0126-820 SH-0126-1.1 SH-0126-390 SH-0126-560 SH-0126-820 SH-0126-1.1

0-5

Protective Covers Protective Covers Comments Family Ritchie Part # Explorer B-51's, D-55's F-50's, RA-91's, RA-93's, S-53's & All E-50-C S-0FF90 Voyager B-80, D-84, D-85, F-82, All F-82W V-80-C* Use V-80-C when you have a RU-90 or RU-90W 82 to 2000 B-81, F-83, F-83W with the optional Light Kit installed. 2000 rev 1 B-81, B-81W, F-83, V-83-C* to present F-83W S-87, S-87W All RU-90 & RU-90W V-81-C* Helmsman All

All

HB-740, HB-741, HD-744, HD-745, HF-742's, HF-743's SS-1002's HF-72's, HF-73's, HB-70, HB-71, HD-74, HD-75, HB-85, SS-1000's, HF-79, HF-79G, HF-79G HV-76 & HV-77

All

Navigator ALL Models (except BN-202) BN-202

HF-741-C*

H-71-C*

Some OEM's and older style Helmsman's use the HL-0087 sunshade (see page 5-12). Use Protective cover # H-70-C*

H-79-C** HV-C* HC-80

Back Cover

N-203-C*

replaces N-200-C

BN-C* NC-20

Back Cover

Globemaster LL-C** FB-500 & SF-500 LL-C** SS-5000 & SS-5000W All GM-5C SP-5C & SP-5B GM-5C SS-5100P & SS-5100B * For replacment rubber bumpers order Part # SH-0012 **For replacment rubber bumpers order Part # 5G-0139

Leveling Blocks HV-76 & HV-77 HL-B BN-202 N-LB

January 1, 2007

Weather Shields Binnacle WS-P mount

0-6

Accessories & Screwdrivers

Sport Trek Explorer Voyager

Compensator Screwdrivers EX-0066 Helmsman (except HV-76 & 77) EX-0066 Navigator (except BN-202) EX-0066 HV-76 & 77, BN-202 SH-0069 Globemaster

Kayak Tie downs X-TD Bungee Cord 3' RS-0117 Snap Clip RS-0118 Mounting Plate RS-0115 Foam Spacer RS-0119 X-11-H Holder

CS-06P1T1 CS-08J1D1 CS-08E1G1 CS-08E3G1

January 1, 2007

SH-0069 SH-0069 SH-0058 SH-0058

KTD.2 RS-0117 RS-0118 EX-0193 EX-0150 N/A

Navy Standard Jewel, Navy Std. Pivot, Navy Std. O-ring, Navy Std. (old) O-ring, Navy Std.

0-7

The Ritchie Com Repairable Capsule Design Sunshade Bezel

Escutcheon

Types of Dials

Open Face

PowerDamp

Dome Bezel

O-Ring (dome) Dial

skirt

Open Face

non PowerDamp

Gimbal Pan Balance Tab Fill Plug

CombiDamp

Bowl

O-Ring (plug) Diaphragm Diaphragm Retainer

Direct Read RITCHIE

Compensator Rods Comp Cover

Binnacle Housing

Base assembly

Sealed Capsule Design

Upper Housing

Types of Dials Direct Read Tactical CombiDamp RITCHIE

Capsule

Lower Housing

January 1, 2007
