HT Mastic 500NF® DESCRIPTION HT Mastic 500NF is an asphalt based material formulated for spray, trowel or brush applications. HT Mastic 500NF is water soluble before setting. This product is asbestos free. USES HT Mastic 500NF is an asphalt based water emulsion coating formulated for application on internal steel casing surfaces of boilers, process furnaces, stacks, flues, behind mineral wool, brick, castable or ceramic fiber linings. HT Mastic 500NF protects the internal vessel casing from deterioration from corrosive chemicals. This material may be sued to seal bolted casing ts from gas leakage or heat loss. HT Mastic 500NF can be used at elevated temperatures up to 400 degrees F with intermittent surges to 500 degrees F. Do not apply HT Mastic 500NF to surfaces above 200 degrees F. APPLICATION Steel surface shall be free of dust, loose dirt or other deleterious material (Minimum SP2/Prefered SP6). Recommended application thickness is approximately 1/8” wet film. Material may be applied by air gun – 45:1 ratio. (See attached Spray Equipment Recommendations). HT Mastic 500NF typically dries for refractory application within 4-8 hours, depending on thickness and humidity. HT Mastic 500NF cleans with water. STORAGE If material is stored below application temperature, do not heat by any means. Move materials to storage area where application temperature can be achieved. DO NOT STORE HT Mastic 500NF AT OR BELOW FREEZING TEMPERATURES. Freezing will cause product to separate. FLAMABILITY HT Mastic 500NF is Class IIIB. HT Mastic 500NF can be transported as a non-hazardous material including air freight. There is low risk of flammability when HT Mastic 500NF is applied near a welding area. LIST OF MAJOR INGREDIENTS Asphalt Water

HT Mastic 500NF® TYPICAL PROPERTIES AND PERFORMANCE Flash Point, degrees F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >450 Lbs./gal. , approximately . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9.5 Solids, by volume % . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Volatiles by volume % . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Application Temp . . . . . . . . . . . . . . . . . . . . . . . . . . . 40°. F to 120° F Coverage Approx. 1/8” Wet Film Thickness . . . . 13 SF/Gallon Dry to Touch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 hours Dry firm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8 hours Film Shrinkage, % loss thickness . . . . . . . . . . . . . . . . . . . . . . 49% HT MASTIC 500NF, being water based, has many features that include: • good corrosion protection at an attractive price point • environmentally and worker friendly • easy application • extremely low VOC’s • no flash hazard from open flame or welding • less expensive transportation due to non-hazardous classification HT MASTIC 500NF is a blend of traditionally immiscible materials, such as oil and water, dispersed into a thick fibered paste using a proprietary clay suspension process. It is important to properly handle and store any water based products. Please pay close attention to the following restrictions when considering purchasing HT Mastic 500NF: • 9 Month Shelf Life from date of manufacture* • Dry time to resist surface moisture - 24-48 hours • Never expose material to freezing temperatures • Store out of direct sunlight • When warehousing, store in temperatures between 45° to 110° F. • Do not break seal on drums until ready for application • Do not apply in direct sunlight

MASTIC SPRAY EQUIPMENT HT Mastic 500NF can be applied with a roller, brush, or spray gun. One spray gun option is the Graco 45:1 pump www. graco.com/us/en/products/coatings-and-foam/premier34-1-45-1-and-74-1.html with a ram & platen for pumping out of drums. • This pump and lower assembly are stainless steel and has a “tuff stack” seal package for durability • This pump and assembly will produce 4.6 gpm flow • There are several part numbers that comprise this assemble, and can be ordered as a package (Package # GDD159) • You may want to order an external runaway valve (Part # 224040) to protect this equipment when a drum runs empty • Approximate cost for this setup is $15,000 READ MSDS SHEET BEFORE USE MANUFACTURED FOR Refractory Anchors, Inc. 9836 S. 219th E. Ave. • Broken Arrow, OK 74014 1-800-331-3270 • 918-455-8485 • FAX 918-455-9321 www.rai-1.com • [email protected] LIMITED WARRANTY Refractory Anchors, Inc. makes no warranty, either express or implied, as to the quality, merchantability or fitness for any particular purpose of any products referred to and except as hereafter stated, makes no guarantee of results or of satisfaction from reliance upon the information of recommendations set forth. The buyer’s or ’s exclusive remedy and Refractory Anchors, Inc. sole limit of liability from any losses resulting from the use of said product shall be for the purchase price of the product causing the loss.

*Mixing is always recommended prior to all mastic application. For HT Mastic 500NF stored longer than 6 months, thorough mixing is required. Mix thoroughly to a creamy consistency. 55 gallon drum mixer: http://www.indco.com/shop/print/DLG-4A 5 gallon mixer: http://www.lowes.com/pd_176765-51872-50616_0__?productId=3369308
