PIC32 ETHERNET STARTER KIT ’S GUIDE Preface NOTICE TO CUSTOMERS All documentation becomes dated, and this manual is no exception. Microchip tools and documentation are constantly evolving to meet customer needs, so some actual dialogs and/or tool descriptions may differ from those in this document. Please refer to our web site (www.microchip.com) to obtain the latest documentation available. Documents are identified with a “DS” number. This number is located on the bottom of each page, in front of the page number. The numbering convention for the DS number is “DSXXXXXA”, where “XXXXX” is the document number and “A” is the revision level of the document. For the most up-to-date information on development tools, see the MPLAB® IDE online help. Select the Help menu, and then Topics to open a list of available online help files.

INTRODUCTION This chapter contains general information that will be useful to know before using the PIC32 Ethernet Starter Kit. Items discussed in this chapter include: • • • • • • •

Document Layout Conventions Used in this Guide Recommended Reading The Microchip Web Site Development Systems Customer Change Notification Service Customer Document Revision History

DOCUMENT LAYOUT This document describes how to use the PIC32 Ethernet Starter Kit (all also referred to as “starter kit”) as a development tool to emulate and debug firmware on a target board. This ’s guide is composed of the following chapters: • Chapter 1. “Introduction” provides a brief overview of the starter kit, highlighting its features and uses. • Chapter 2. “Hardware” provides the hardware descriptions of the starter kit. • Appendix A. “Board Layout and Schematics” provides a block diagram, board layouts, and detailed schematics of the starter kit.

© 2010 Microchip Technology Inc.

DS61166A-page 5

PIC32 Ethernet Starter Kit ’s Guide CONVENTIONS USED IN THIS GUIDE This manual uses the following documentation conventions: DOCUMENTATION CONVENTIONS Description

Represents

Examples

Arial font: Italic characters Initial caps

Referenced books

MPLAB® IDE ’s Guide

Emphasized text

...is the only compiler...

A window

the Output window

A dialog

the Settings dialog

A menu selection

select Enable Programmer

Quotes

A field name in a window or dialog “Save project before build”

Underlined, italic text with right angle bracket

A menu path

File>Save

Bold characters

A dialog button

Click OK

A tab

Click the Power tab

A key on the keyboard

Press <Enter>,

Sample source code

#define START

Filenames

autoexec.bat

File paths

C:\mcc18\h

Keywords

_asm, _endasm, static

Command-line options

-Opa+, -Opa-

Bit values

0, 1

Constants (in source code)

0xFF, ‘A’

Italic Courier New

A variable argument

file.o, where file can be any valid filename

Square brackets [ ]

Optional arguments

mcc18 [options] file [options]

Curly brackets and pipe character: { | }

Choice of mutually exclusive arguments; an OR selection

errorlevel {0|1}

Ellipses...

Replaces repeated text

var_name [, var_name...]

Text in angle brackets < > Courier New font: Plain Courier New

Represents code supplied by void main (void) { ... }

DS61166A-page 6

© 2010 Microchip Technology Inc.

Preface RECOMMENDED READING This ’s guide describes how to use the starter kit. The following Microchip documents are available and recommended as supplemental reference resources.

PIC32MX5XX/6XX/7XX Family Data Sheet (DS61156) Refer to this document for detailed information on PIC32 devices. Reference information found in this data sheet includes: • • • •

Device memory maps Device pinout and packaging details Device electrical specifications List of peripherals included on the devices

MPLAB® C Compiler for PIC32 ’s Guide (DS51686) This document, formerly the “MPLAB C32 C Compiler for PIC32 ’s Guide”, details the use of Microchip’s MPLAB C Compiler for PIC32 to develop an application.

MPLAB® IDE ’s Guide (DS51519) Refer to this document for more information pertaining to the installation and implementation of the MPLAB IDE software, as well as the MPLAB Editor and MPLAB SIM Simulator software that are included with it.

Universal Serial Bus Specification and Associated Documents The Universal Serial Bus is defined by the USB 2.0 specification and its associated supplements and class-specific documents. These documents are available from the USB Implementers Forum. See their web site at: http://www.usb.org

THE MICROCHIP WEB SITE Microchip provides online via our web site at http://www.microchip.com. This web site makes files and information easily available to customers. Accessible by most Internet browsers, the web site contains the following information: • Product – Data sheets and errata, application notes and sample programs, design resources, ’s guides and hardware documents, latest software releases and archived software • General Technical – Frequently Asked Questions (FAQs), technical requests, online discussion groups, Microchip consultant program member listings • Business of Microchip – Product selector and ordering guides, latest Microchip press releases, listings of seminars and events; and listings of Microchip sales offices, distributors and factory representatives

© 2010 Microchip Technology Inc.

DS61166A-page 7

PIC32 Ethernet Starter Kit ’s Guide DEVELOPMENT SYSTEMS CUSTOMER CHANGE NOTIFICATION SERVICE Microchip’s customer notification service helps keep customers current on Microchip products. Subscribers will receive e-mail notification whenever there are changes, updates, revisions or errata related to a specified product family or development tool of interest. To , access the Microchip web site at http://www.microchip.com, click Customer Change Notification and follow the registration instructions. The Development Systems product group categories are: • Compilers – The latest information on Microchip C compilers and other language tools. These include the MPLAB® C compiler; MPASM™ and MPLAB 16-bit assemblers; MPLINK™ and MPLAB 16-bit object linkers; and MPLIB™ and MPLAB 16-bit object librarians. • Emulators – The latest information on the Microchip MPLAB REAL ICE™ in-circuit emulator. • In-Circuit Debuggers – The latest information on the Microchip in-circuit debugger, MPLAB ICD 3. • MPLAB IDE – The latest information on Microchip MPLAB IDE, the Windows® Integrated Development Environment for development systems tools. This list is focused on the MPLAB IDE, MPLAB SIM simulator, MPLAB IDE Project Manager and general editing and debugging features. • Programmers – The latest information on Microchip programmers. These include the MPLAB PM3 device programmer and the PICkit™ 3 development programmers.

CUSTOMER s of Microchip products can receive assistance through several channels: • • • •

Distributor or Representative Local Sales Office Field Application Engineer (FAE) Technical

Customers should their distributor, representative or field application engineer (FAE) for . Local sales offices are also available to help customers. A listing of sales offices and locations is included in the back of this document. Technical is available through the web site at: http://.microchip.com

DS61166A-page 8

© 2010 Microchip Technology Inc.

Preface DOCUMENT REVISION HISTORY Revision A (December 2010) This is the initial release of the PIC32 Ethernet Starter Kit ’s Guide.

© 2010 Microchip Technology Inc.

DS61166A-page 9

PIC32 Ethernet Starter Kit ’s Guide NOTES:

DS61166A-page 10

© 2010 Microchip Technology Inc.

PIC32 ETHERNET STARTER KIT ’S GUIDE Chapter 1. Introduction Thank you for purchasing a Microchip Technology PIC32 Ethernet Starter Kit. This board provides a low-cost, modular development system for Microchip’s line of 32-bit microcontrollers. The starter kit comes preloaded with demonstration software for the to explore the new features of the PIC32. It is also expandable through a modular expansion interface, which allows the to extend its functionality. The starter kit also supplies on-board circuitry for full debug and programming capabilities. This chapter covers the following topics: • Kit Contents • PIC32 Functionality and Features The preprogrammed example code on the PIC32 MCU is available via from the Microchip web site at http://www.microchip.com. All project files have been included so that the code may be used directly to restore the PIC32 MCU on the starter kit to its original state (i.e., if the sample device has been reprogrammed with another program) or so you can use the tutorial code as a platform for further experimentation.

1.1

KIT CONTENTS The PIC32 Ethernet Starter Kit contains the following items: • PIC32 Ethernet Starter Kit development board • USB mini-B to full-sized A cable – USB debug cable to debug and power the board • USB micro-B to full-sized A cable – PIC32 USB cable to communicate with the PIC32 USB port • RJ-45 CAT5 Ethernet patch cable – Ethernet CAT5 cable to communicate with the PIC32 Ethernet port Note:

© 2010 Microchip Technology Inc.

If you are missing any part of a kit, a Microchip sales office for assistance. A list of Microchip offices for sales and service is provided on the back page of this document.

DS61166A-page 11

PIC32 Ethernet Starter Kit ’s Guide 1.2

PIC32 FUNCTIONALITY AND FEATURES Representations of the layout of the PIC32 Ethernet Starter Kit are shown in Figure 1-1 and Figure 1-2. The top assembly of the board includes these key features, as indicated in Figure 1-1: 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15.

PIC32MX795F512L 32-bit microcontroller. PIC32MX440F512H USB microcontroller for on-board debugging. Green power indicator LED. On-board crystal for precision microcontroller clocking (8 MHz). USB connectivity for on-board debugger communications. Orange debug indicator LED. Three push button switches for -defined inputs. Three -defined indicator LEDs. USB Type A receptacle connectivity for PIC32 host-based applications. HOST mode power jumper. RJ-45 Ethernet port. Ethernet 10/100 bus speed indicator LED. 50 MHz Ethernet PHY oscillator. 32 kHz oscillator (optional). USB Host and OTG power supply for powering PIC32 USB applications.

Note:

When running self-powered USB device applications, open the jumper JP2 to prevent possibly back-feeding voltage onto the VBUS from one port on the host to another (or from one host to another).

For details on these features, refer to Chapter 2. “Hardware”. FIGURE 1-1:

PIC32 ETHERNET STARTER KIT LAYOUT (TOP SIDE)

12 11

8

13 7

6

8 7

1

5

8

14

2

7 4 9

15 10

DS61166A-page 12

3

© 2010 Microchip Technology Inc.

Introduction The bottom assembly of the board includes these key features, as indicated in Figure 1-2: 1. Regulated +3.3V power supply for powering the starter kit via USB or expansion board. 2. Connector for various expansion boards. 3. USB Type micro-AB receptacle for OTG and USB device connectivity for PIC32 OTG/device-based applications. 4. External Ethernet PHY. FIGURE 1-2:

PIC32 ETHERNET STARTER KIT LAYOUT (UNDERSIDE)

4

2

3 1

© 2010 Microchip Technology Inc.

DS61166A-page 13

PIC32 Ethernet Starter Kit ’s Guide NOTES:

DS61166A-page 14

© 2010 Microchip Technology Inc.

PIC32 ETHERNET STARTER KIT ’S GUIDE Chapter 2. Hardware This chapter describes the hardware features of the PIC32 Ethernet Starter Kit.

2.1

HARDWARE FEATURES The key features of the PIC32 Ethernet Starter Kit are listed below. They are presented in the order given in Section 1.2 “PIC32 Functionality and Features”. You can refer to Figure 1-1 for their locations on the board.

2.1.1

Processor

The PIC32 Ethernet Starter Kit is designed with a permanently mounted (i.e., soldered) PIC32MX795F512L processor.

2.1.2

Power Supply

There are two ways to supply power to the PIC32 Ethernet Starter Kit: • USB bus power connected to USB debug connector J1. • An external application board with a regulated DC power supply that provides +5V can be connected to the J2 application board connector that is provided on the bottom side of the board. One green LED (D3) is provided to show that the PIC32 microcontroller is powered up.

2.1.3

Debug USB Connectivity

The PIC32 Ethernet Starter Kit includes a PIC32MX440F512H USB microcontroller that provides debugger connectivity over USB. The PIC32MX440F512H is hard-wired to the PIC32 device to provide two types of protocol translation: • I/O pins of PIC32MX440F512H to the ICSP™ pins of the PIC32 • I/O pins of PIC32MX440F512H to the JTAG pins of the PIC32 The PIC32 Ethernet Starter Kit currently uses the JTAG pins of the PIC32 device for programming and debugging.

2.1.4

PIC32 USB Connectivity

There are three possible ways to connect to the PIC32 USB microcontroller: • HOST Mode Connect the device to the Type A connector J4, located on the top side of the starter kit. If using the Debug USB port to power the Host port, install jumper JP2 to short the back-power prevention diode. Note that a maximum of ~400 mA can be supplied from the Debug USB port to the Host port using this method. If the full 500 mA supply is needed, an external supply must be connected to the application board and jumper JP2 must be removed to prevent back-powering the Debug USB port.

© 2010 Microchip Technology Inc.

DS61166A-page 15

PIC32 Ethernet Starter Kit ’s Guide • DEVICE Mode First, connect the debug mini-B USB cable to port J1. Next, connect the starter kit to the host using a cable with a Type-B micro-plug to the starter kit’s micro-A/B port J5, located on the bottom side of the starter kit. The other end of the cable must have a Type-A plug. Connect it to a USB host. Jumper JP2 should be removed. • OTG Mode Connect the starter kit to the OTG device using an OTG micro-A/B cable to the micro-A/B port J5, located on the bottom side of the starter kit. The starter kit provides an on-board power supply capable of providing 120 mA Max. This supply is controlled by the PIC32MX795F512L microcontroller. Jumper JP2 should be removed.

2.1.5

Switches

Push button switches provide the following functionality: • SW1: Active-low switch connected to RD6 • SW2: Active-low switch connected to RD7 • SW3: Active-low switch connected to RD13 The switches do not have any debounce circuitry and require the use of internal pull-up resistors; this allows you to investigate software debounce techniques. When Idle, the switches are pulled high (+3.3V). When pressed, they are grounded.

2.1.6

LEDs

The RD0 through RD2 LEDs are connected to PORTD of the processor. The PORTD pins are set high to light the LEDs.

2.1.7

Oscillator Options

The installed microcontroller has an oscillator circuit connected to it. The main oscillator uses an 8 MHz crystal (Y2) and functions as the controller’s primary oscillator. Use of an external crystal is required to develop USB applications. The USB specification dictates a frequency tolerance of ±0.25% for full speed. Non-USB applications can use the internal oscillators. The starter kit also has provisions for an external secondary 32 kHz oscillator (Y3); however, this is not populated. A suitable oscillator, the ECS-3X8, can be obtained from Digi-Key: Part no. X801-ND CMR200TB32.768KDZFTR. The PIC32MX440F512H is independently clocked and has its own 8 MHz crystal (Y1).

2.1.8

120-Pin Modular Expansion Connector

The PIC32 Ethernet Starter Kit has been designed with a 120-pin modular expansion interface, which allows the board to provide basic generic functionality now, and easy extendability to new technologies as they become available. TABLE 2-1:

STARTER KIT CONNECTOR PART NUMBERS Connector

DS61166A-page 16

HIROSE Electric PN

Starter Kit Connector

FX10A-120P/12-SV1(71)

Application Board Connector

FX10A-120S/12-SV(71)

© 2010 Microchip Technology Inc.

Hardware 2.1.9

Ethernet PHY

The PIC32 Ethernet Starter Kit has been designed with a National DP83848 PHY for connecting the starter kit using an RJ-45 cable to a network. The interface between the PHY and the PIC32 has been configured for the industry standard RMII interface and has been isolated from the Modular Expansion Connector. LED D8 indicates the Ethernet bus speed. When lit, the bus speed is 100 Mbps; when off, the bus speed is 10 Mbps.

© 2010 Microchip Technology Inc.

DS61166A-page 17

PIC32 Ethernet Starter Kit ’s Guide NOTES:

DS61166A-page 18

© 2010 Microchip Technology Inc.

PIC32 ETHERNET STARTER KIT ’S GUIDE Appendix A. Board Layout and Schematics A.1

PIC32 ETHERNET STARTER KIT BLOCK DIAGRAM

FIGURE A-1:

HIGH-LEVEL BLOCK DIAGRAM OF THE PIC32 ETHERNET STARTER KIT

Power Circuit USB OTG

Device/OTG (Type micro-A/B)

+3.3V Power Supply

VUSB(1) or +5V_EXT

Host (Type A)

Debug USB

Debugger Circuit

ICSP™ JTAG

+5V EXT

(PIC32MX440F512H) PIC32MX795F512L

Application Board Connector

USB Host

Switches LEDs

Ethernet PHY 10/100 Jack

Note 1:

From Debugger USB Port.

© 2010 Microchip Technology Inc.

DS61166A-page 19

PIC32 Ethernet Starter Kit ’s Guide A.2

PIC32 ETHERNET STARTER KIT BOARD LAYOUT

FIGURE A-2:

DS61166A-page 20

PIC32 ETHERNET STARTER KIT LAYOUT (TOP ASSEMBLY)

© 2010 Microchip Technology Inc.

Board Layout and Schematics FIGURE A-3:

PIC32 ETHERNET STARTER KIT LAYOUT (BOTTOM ASSEMBLY)

© 2010 Microchip Technology Inc.

DS61166A-page 21

PIC32 Ethernet Starter Kit ’s Guide A.3

PIC32 ETHERNET STARTER KIT BOARD SCHEMATICS

FIGURE A-4:

PIC32 ETHERNET STARTER KIT (ETHERNET)

J1 J2 J3 J4 J5 J6 J7 J8

DS61166A-page 22

© 2010 Microchip Technology Inc.

PIC32 ETHERNET STARTER KIT (PIC32 DEVICE) © 2010 Microchip Technology Inc.

FIGURE A-5:

Board Layout and Schematics

DS61166A-page 23

PIC32 Ethernet Starter Kit ’s Guide

PIC32 ETHERNET STARTER KIT (USB HOST AND OTG POWER SUPPLIES) DS61166A-page 24

FIGURE A-6:

© 2010 Microchip Technology Inc.

PIC32 ETHERNET STARTER KIT (DEBUGGER) © 2010 Microchip Technology Inc.

FIGURE A-7:

Board Layout and Schematics

DS61166A-page 25

PIC32 Ethernet Starter Kit ’s Guide

PIC32 ETHERNET STARTER KIT (3.3V POWER SUPPLY) DS61166A-page 26

FIGURE A-8:

© 2010 Microchip Technology Inc.

Board Layout and Schematics FIGURE A-9:

PIC32 ETHERNET STARTER KIT (APPLICATION BOARD CONNECTOR)

© 2010 Microchip Technology Inc.

DS61166A-page 27

PIC32 Ethernet Starter Kit ’s Guide NOTES:

DS61166A-page 28

© 2010 Microchip Technology Inc.

PIC32 ETHERNET STARTER KIT ’S GUIDE Appendix B. Bill of Materials TABLE B-1:

PIC32 ETHERNET STARTER KIT BILL OF MATERIALS

Reference

Description

Manufacturer

Part No.

U4

IC SMT, M1253, DC/DC Converter 3.3V 8L MSOP

Microchip

M1253-33X50I/MS

U1

IC SMT, PIC32MX440F512H-80I/MR 64P QFN

Microchip

PIC32MX440F512H-80I/MR

U2

IC SMT, PIC32MX795F512L 100L TQFP

Microchip

PIC32MX795F512L-80I/PT

U5

IC SMT, TC1262-3.3VDB, SOT-223

Microchip

TC1262-3.3VDBTR

C1, C9-C14, CAP SMT, 0.1 µF 0603 CER 16V 10% X7R C27, C28, C30-C33, C35-C39

Panasonic

ECJ-1VB1C104K

C17

CAP SMT, 1.0 µF 0805 CER 16V 10% X7R

Kemet

C0805C105K4RACTU

C2, C29, C34

CAP SMT, 10 µF 0805 CER 6.3V 20% , X5R

Panasonic

ECJ-2FB0J106M

C7, C8, C18 CAP SMT, 4.7 µF 0805 CER 16V +80-20% Y5V

Panasonic

ECJ-2FB0J475K

C3-C6

CAP SMT, 20 pF 0603 CER 50V, 5% C0G

Rohm

MCH185A200JK

C25

CAP SMT, 6.8 µF 0805 CER 6.3V 10% X5R

Kemet

C0805C685K9PACTU

C26

CAP SMT, 100 µF 1812 CER 6.3V -20%,+80% Y5V Panasonic

ECJ-5YF0J107Z

JP2

CONN, HDR, 1x2 Breakaway, 0.100" Pitch, 0.025 SQ Post (0.100"/0.230")

TSW-102-07-G-S

Samtec

CONN, Shunt, 2-pin Shorting Shunt (.100" Spacing) Sullins

SSC02SYAN

J1

CONN SMT, RET, USB Mini-B 5POS RA

Delphi

15430262-110

J2

CONN, SMT, HDR, 120P, w/Post

Hirose Electronics

J4

CONN, RET, USB Type-A w/Board Lock

FCI

J5

CONN, RET, USB Micro-B SMD TH SHLL

Hirose Electronics ZX62D-AB-5P8

D2, D7

Diode SMT, Schottky 30V 0.5A SOD-123

On Semiconductor MBR0530T1G

U6

IC SMT, TPS20X1 .75A Power DIST Switch 5-SOT23

Texas Instruments TPS2051BDBVR

U3

IC SMT, TPS2041 1A PWR DIST Switch SNGL SOT23-5

Texas Instruments TPS2041BDBVR

LED1

LED SMT, 0805 Red DIFF 2x1.25 mm Thin

Lumex

SML-LXT0805IW-TR

D1, LED2

LED SMT, 0805 Yellow DIFF 2x1.25 mm Thin

Lumex

SML-LXT0805YW-TR

D3, D8, LED3

LED SMT, 0805 Green DIFF 2x1.25 mm

Lumex

SML-LXT0805GW-TR

Y1, Y2

OSC SMT, Crystal 8.000 MHz 18 pF SMD

Abracon Corp.

ABM3B-8.000MHZ-B2-T

R4, R9, R11, R12

RES SMT, 1.0 KΩ 1/10W 5% 0603

Panasonic

ERJ-3GEYJ102V

R10, R13, R14, R16, R18

RES SMT, 4.7 KΩ 1/10W 5% 0603

Panasonic

ERJ-3GEYJ472V

© 2010 Microchip Technology Inc.

87520-0010BLF

DS61166A-page 29

PIC32 Ethernet Starter Kit ’s Guide TABLE B-1:

PIC32 ETHERNET STARTER KIT BILL OF MATERIALS (CONTINUED)

Reference

Description

Manufacturer

Part No.

R5, R19, R20, R22, R23

RES SMT, 330Ω 1/10W 5% 0603

Panasonic

ERJ-3GEYJ331V

R17

RES SMT, 100 KΩ 1/10W 1% 0603

Panasonic

PANASONIC ERJ-3EKF1003V

S1-S3

Switch, Light Touch 160 gF

Panasonic

EVQ-PPBA25

J6

CONN, MAGJACK 1PORT SHLD 10/100BT and LEDs

Bel Stewart

SI-60062-F

U8

IC SMT, TXRX Ethernet PHYTER 48-LQFP

National

DP83848CVV/NOPB

Y4

OSC SMT, Oscillator 50.0000 MHz 3.3V

AVX

ECS-80-20-5PVX

R55, R56

RES SMT, 1.5 KΩ 1/10W 1% 0603

Panasonic

ERJ-3EKF1501V

R15, R21, R25, R33, R51, R57

RES SMT, 2.2 KΩ 1/16W 1% 0603

SPC Technology

MC0603WGF2201T5E-TC

R29, R59-R63

RES SMT, 33Ω 1/10W 5% 0603

Panasonic

ERJ-3GEYJ330V

R37, R39-R41

RES SMT, 49.9Ω 1/10W 1% 0603

Rohm

MCR03EZPFX49R9

R28, R44

RES SMT, 249Ω 1/10W 1% 0603

Yageo

RC0603FR-07249RL

R26

RES SMT, 510Ω 1/16W 1% 100 PPM 0603

Yageo/Phyco

9C06031A5100FKHFT

R50

RES SMT, 4.87 KΩ 1/10W 1% 0603

Yageo

RC0603FR-074K87L

Spare Location, Do Not Install C18, C15, C16, GND1, J3, R24, R27, TP9, TP10, TP11, Y3

DS61166A-page 30

—

—

© 2010 Microchip Technology Inc.

PIC32 ETHERNET STARTER KIT ’S GUIDE Index C

S

Customer Change Notification Service ...................... 8 Customer ...................................................... 8

Starter Kit Board Block Diagram................................................... 19 Starter Kit Layout Bottom Assembly ........................................ 13, 21 Top Assembly ............................................. 12, 20 Starter Kit Schematics 3.3V Power Supply ........................................... 26 Application board connector ............................. 27 Debugger .......................................................... 25 Ethernet ............................................................ 22 PIC32 device..................................................... 23 USB Host and OTG power supplies ................. 24

D Documentation Conventions ........................................................ 6

H Hardware Features LEDs ............................................................15, 16 Oscillator Options ............................................. 16 PICtail Plus Card Edge Connectors.................. 16 Power Supply.................................................... 15 Processor ............................................ 15 Switches ........................................................... 16 USB Connectivity .............................................. 15

U USB Connectivity ...................................................... 15

I

W

Internet Address......................................................... 7

WWW Address........................................................... 7

M Microchip Internet Web Site ....................................... 7 MPLAB IDE Simulator, Editor ’s Guide............... 7

P PIC32 Layout 32-bit microcontroller ................................. 12 Debug indicator LED ................................. 12 Ethernet 10/100 Bus Speed LED .............. 12 Ethernet PHY oscillator ............................. 12 Expansion board connector ....................... 13 External Ethernet PHY .............................. 13 HOST mode power jumper ........................ 12 On-board crystal ........................................ 12 Optional 32 kHz oscillator .......................... 12 Power supply ............................................. 13 Power-indicator LED.................................. 12 RJ-45 Ethernet port ................................... 12 Switches .................................................... 12 USB connectivity ....................................... 12 USB Host and OTG power supply ............. 12 USB microcontroller................................... 12 USB Type A receptacle ............................. 12 USB Type micro-AB receptacle ................. 13 -defined LEDs .................................... 12

© 2010 Microchip Technology Inc.

DS61166A-page 31

Worldwide Sales and Service AMERICAS

ASIA/PACIFIC

ASIA/PACIFIC

EUROPE

Corporate Office 2355 West Chandler Blvd. Chandler, AZ 85224-6199 Tel: 480-792-7200 Fax: 480-792-7277 Technical : http://.microchip.com Web Address: www.microchip.com

Asia Pacific Office Suites 3707-14, 37th Floor Tower 6, The Gateway Harbour City, Kowloon Hong Kong Tel: 852-2401-1200 Fax: 852-2401-3431

India - Bangalore Tel: 91-80-3090-4444 Fax: 91-80-3090-4123 India - New Delhi Tel: 91-11-4160-8631 Fax: 91-11-4160-8632

Austria - Wels Tel: 43-7242-2244-39 Fax: 43-7242-2244-393 Denmark - Copenhagen Tel: 45-4450-2828 Fax: 45-4485-2829

India - Pune Tel: 91-20-2566-1512 Fax: 91-20-2566-1513

- Paris Tel: 33-1-69-53-63-20 Fax: 33-1-69-30-90-79

Japan - Yokohama Tel: 81-45-471- 6166 Fax: 81-45-471-6122

- Munich Tel: 49-89-627-144-0 Fax: 49-89-627-144-44

Atlanta Duluth, GA Tel: 678-957-9614 Fax: 678-957-1455 Boston Westborough, MA Tel: 774-760-0087 Fax: 774-760-0088 Chicago Itasca, IL Tel: 630-285-0071 Fax: 630-285-0075 Cleveland Independence, OH Tel: 216-447-0464 Fax: 216-447-0643 Dallas Addison, TX Tel: 972-818-7423 Fax: 972-818-2924 Detroit Farmington Hills, MI Tel: 248-538-2250 Fax: 248-538-2260 Kokomo Kokomo, IN Tel: 765-864-8360 Fax: 765-864-8387 Los Angeles Mission Viejo, CA Tel: 949-462-9523 Fax: 949-462-9608 Santa Clara Santa Clara, CA Tel: 408-961-6444 Fax: 408-961-6445 Toronto Mississauga, Ontario, Canada Tel: 905-673-0699 Fax: 905-673-6509

Australia - Sydney Tel: 61-2-9868-6733 Fax: 61-2-9868-6755 China - Beijing Tel: 86-10-8528-2100 Fax: 86-10-8528-2104 China - Chengdu Tel: 86-28-8665-5511 Fax: 86-28-8665-7889

Korea - Daegu Tel: 82-53-744-4301 Fax: 82-53-744-4302

China - Chongqing Tel: 86-23-8980-9588 Fax: 86-23-8980-9500

Korea - Seoul Tel: 82-2-554-7200 Fax: 82-2-558-5932 or 82-2-558-5934

China - Hong Kong SAR Tel: 852-2401-1200 Fax: 852-2401-3431

Malaysia - Kuala Lumpur Tel: 60-3-6201-9857 Fax: 60-3-6201-9859

China - Nanjing Tel: 86-25-8473-2460 Fax: 86-25-8473-2470

Malaysia - Penang Tel: 60-4-227-8870 Fax: 60-4-227-4068

China - Qingdao Tel: 86-532-8502-7355 Fax: 86-532-8502-7205

Philippines - Manila Tel: 63-2-634-9065 Fax: 63-2-634-9069

China - Shanghai Tel: 86-21-5407-5533 Fax: 86-21-5407-5066

Singapore Tel: 65-6334-8870 Fax: 65-6334-8850

China - Shenyang Tel: 86-24-2334-2829 Fax: 86-24-2334-2393

Taiwan - Hsin Chu Tel: 886-3-6578-300 Fax: 886-3-6578-370

China - Shenzhen Tel: 86-755-8203-2660 Fax: 86-755-8203-1760

Taiwan - Kaohsiung Tel: 886-7-213-7830 Fax: 886-7-330-9305

China - Wuhan Tel: 86-27-5980-5300 Fax: 86-27-5980-5118

Taiwan - Taipei Tel: 886-2-2500-6610 Fax: 886-2-2508-0102

China - Xian Tel: 86-29-8833-7252 Fax: 86-29-8833-7256

Thailand - Bangkok Tel: 66-2-694-1351 Fax: 66-2-694-1350

Italy - Milan Tel: 39-0331-742611 Fax: 39-0331-466781 Netherlands - Drunen Tel: 31-416-690399 Fax: 31-416-690340 Spain - Madrid Tel: 34-91-708-08-90 Fax: 34-91-708-08-91 UK - Wokingham Tel: 44-118-921-5869 Fax: 44-118-921-5820

China - Xiamen Tel: 86-592-2388138 Fax: 86-592-2388130 China - Zhuhai Tel: 86-756-3210040 Fax: 86-756-3210049

08/04/10

DS61166A-page 32

© 2010 Microchip Technology Inc.
