MAUVE 1 7

2 3 4

8 9 10

5 6

11 12

13

SL. NO. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

PART NO. K31504104H K31504004H K31204004H K3120580CA K31205704H K3120620C K31226504H K3121060C K31209704H K31209604H K3120820CF K3120810CF K31211404H K3211730 K3211720

DESCRIPTION MIRROR ASSY RH MAUVE MIRROR ASSY LH MAUVE HOUSING HEADLAMP FRONT MAUVE FRONT TOP LOGO TVS FRONT MAUVE FRONT BOTTOM PILLION HANDLE MAUVE SIDE BOTTOM CENTER SIDE TOP RH MAUVE SIDE TOP LH MAUVE SIDE BOTTOM RH SIDE BOTTOM LH COVER SPARK PLUG MAUVE EMBLEM FASHION SERIES TAPE SET MAUVE

SCOOTY PEP+ COLOUR ME COLLECTION FRESH GREEN S.No.

PART NO.

DESCRIPTION

1

K3150410AL

MIRROR ASSY. RH

2

K3150400AL

MIRROR ASSY. LH

3

K3120400AL

HOUSING HEADLAMP FRONT

4

K3120580CA

FRONT TOP LOGO TVS

5

K3120570AL

FRONT

6

K3120620C

FRONT BOTTOM

7

K3122650AL

PILLION HANDLE

8

K3121060C

SIDE BOTTOM CENTER

9

K3120970AL

SIDE TOP RH

10

K3120960AL

SIDE TOP LH

11

K3120820CF

SIDE BOTTOM RH

12

K3120810CF

SIDE BOTTOM LH

13

K3121140AL

COVER SPARK PLUG

AQUA BLUE S.No.

PART NO.

DESCRIPTION

1

K3150410BB

MIRROR ASSY. RH

2

K3150400BB

MIRROR ASSY. LH

3

K3120400BB

HOUSING HEADLAMP FRONT

4

K3120580CA

FRONT TOP LOGO TVS

5

K3120570BB

FRONT

6

K3120620C

7

K3122650BB

8

K3121060C

FRONT BOTTOM PILLION HANDLE SIDE BOTTOM CENTER

9

K3120970BB

SIDE TOP RH

10

K3120960BB

SIDE TOP LH

11

K3120820CF

SIDE BOTTOM RH

12

K3120810CF

SIDE BOTTOM LH

13

K3121140BB

COVER SPARK PLUG

S.No.

PART NO.

1

K3150410BL

MIRROR ASSY. RH

2

K3150400BL

MIRROR ASSY. LH

3

K3120400BL

HOUSING HEADLAMP FRONT

4

K3120580CA

FRONT TOP LOGO TVS

5

K3120570BL

FRONT

TOP FROST DESCRIPTION

6

K3120620C

FRONT BOTTOM

7

K3122650BL

PILLION HANDLE

8

K3121060C

SIDE BOTTOM CENTER

9

K3120970BL

SIDE TOP RH

10

K3120960BL

SIDE TOP LH

11

K3120820CF

SIDE BOTTOM RH

12

K3120810CF

SIDE BOTTOM LH

13

K3121140BL

COVER SPARK PLUG

SCOOTY PEP+ COLOUR ME COLLECTION LUSTROUS PINK S.No.

PART NO.

DESCRIPTION

1

K31504106H

MIRROR ASSY. RH

2

K31504006H

MIRROR ASSY. LH

3

K31204006H

HOUSING HEADLAMP FRONT

4

K3120580CA

FRONT TOP LOGO TVS

5

K31205706H

FRONT

6

K3120620C

FRONT BOTTOM

7

K31226506H

PILLION HANDLE

8

K3121060C

SIDE BOTTOM CENTER

9

K31209706H

SIDE TOP RH

10

K31209606H

SIDE TOP LH

11

K3120820CF

SIDE BOTTOM RH

12

K3120810CF

SIDE BOTTOM LH

13

K31211406H

COVER SPARK PLUG

NAUGHTY BROWN S.No.

PART NO.

1 2 3 4 5 6 7 8 9 10 11 12 13

K31504107H K31504007H K31204007H K3120580CA K31205707H K3120620C K31226507H K3121060C K31209707H K31209607H K3120820CF K3120810CF K31211407H

DESCRIPTION MIRROR ASSY. RH MIRROR ASSY. LH HOUSING HEADLAMP FRONT FRONT TOP LOGO TVS FRONT FRONT BOTTOM PILLION HANDLE SIDE BOTTOM CENTER SIDE TOP RH SIDE TOP LH SIDE BOTTOM RH SIDE BOTTOM LH COVER SPARK PLUG

WIMBLEDON WHITE S.No.

PART NO.

DESCRIPTION

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

K3150410F K3150400F K3120400F K3120580F K3120570F K3120620F K3122650F K3121060C K3120970F K3120960F K3120820F K3120810F K3121140F K3212200 K3212110

S.No.

PART NO.

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

K31504108H K31504008H K31204008H K31205808HA K31205708H K31206208H K31226508H K31210608H K31209708H K31209608H K31208208H K31208108H K31211408H K3212190 K3212110

MIRROR ASSY. RH MIRROR ASSY. LH HOUSING HEADLAMP FRONT FRONT TOP LOGO TVS FRONT FRONT BOTTOM PILLION HANDLE SIDE BOTTOM CENTER SIDE TOP RH SIDE TOP LH SIDE BOTTOM RH SIDE BOTTOM LH COVER SPARK PLUG TAPE SET TAPE SET WIMBLEDON

WIMBLEDON RED DESCRIPTION MIRROR ASSY. RH MIRROR ASSY. LH HOUSING HEADLAMP FRONT FRONT TOP LOGO TVS FRONT FRONT BOTTOM PILLION HANDLE SIDE BOTTOM CENTER SIDE TOP RH SIDE TOP LH SIDE BOTTOM RH SIDE BOTTOM LH COVER SPARK PLUG TAPE SET TAPE SET WIMBLEDON

CLASSIC PINK 1

7

2 3 4

8 5 6

9 10

11

12 13

S.No.

PART NO.

DESCRIPTION

1

K31504103H

MIRROR ASSY RH CLASSIC PINK

2

K31504003H

MIRROR ASSY LH CLASSIC PINK

3

K31204003H

HOUSING HEADLAMP FRONT CLAS.

4

K3120580CA

FRONT TOP LOGO TVS

5

K31205703H

FRONT CLASSIC PINK

6

K3120620C

FRONT BOTTOM

7

K31226503H

PILLION HANDLE CLASSIC PINK

8

K3121060C

SIDE BOTTOM CENTER

9

K31209703H

SIDE TOP RH CLASSIC PINK

10

K31209603H

SIDE TOP LH CLASSIC PINK

11

K3120820CF

SIDE BOTTOM RH

12

K3120810CF

SIDE BOTTOM LH

13

K31211403H

COVER SPARK PLUG CLASSIC

14

K3211630

TAPE SET CLASSIC PINK

ROCK CANDY PINK 1

2 3

7 4 8 9 10

5 6

11 12 13

S.No.

PART NO.

1 2 3 4 5 6 7 8 9 10 11 12 13 14

K31504109H K31504009H K31204009H K3120580CA K31205709H K3120620C K31226509H K3121060C K31209709H K31209609H K3120829C K3120819C K31211409H K3221240

DESCRIPTION MIRROR ASSY RH MIRROR ASSY LH HOUSING HEADLAMP FRONT FRONT TOP LOGO TVS FRONT FRONT BOTTOM PILLION HANDLE SIDE BOTTOM CENTER SIDE TOP RH SIDE TOP LH SIDE BOTTOM RH SIDE BOTTOM LH COVER SPARK PLUG TAPESET

BABY BLUE 1

2 3

7 4 8 9 10

5 6

11 12 13

S.No.

PART NO.

1 2 3 4 5 6 7 8 9 10 11 12 13 14

K3150410CE K3150400CE K3120400CE K3120580CA K3120570CE K3120620C K3122650CE K3121060C K3120970CE K3120960CE K3120829C K3120819C K3121140CE K3221240

DESCRIPTION MIRROR ASSY RH MIRROR ASSY LH HOUSING HEADLAMP FRONT FRONT TOP LOGO TVS FRONT FRONT BOTTOM PILLION HANDLE SIDE BOTTOM CENTER SIDE TOP RH SIDE TOP LH SIDE BOTTOM RH SIDE BOTTOM LH COVER SPARK PLUG TAPESET

DEEP ORANGE 1

2 3

7 4 8 9 10

5 6

11 12 13

S.No.

PART NO.

1 2 3 4 5 6 7 8 9 10 11 12 13 14

K3150410BG K3150400BG K3120400BG K3120580CA K3120570BG K3120620C K3122650BG K3121060C K3120970BG K3120960BG K3120829C K3120819C K3121140BG K3221250

S.No.

PART NO.

1 2 3 4 5 6 7 8 9 10 11 12 13 14

K3150410DL K3150400DL K3120400DL K3120580CA K3120570DL K3120620C K3122650DL K3121060C K3120970DL K3120960DL K3120829C K3120819C K3121140DL K3221250

DESCRIPTION MIRROR ASSY RH MIRROR ASSY LH HOUSING HEADLAMP FRONT FRONT TOP LOGO TVS FRONT FRONT BOTTOM PILLION HANDLE SIDE BOTTOM CENTER SIDE TOP RH SIDE TOP LH SIDE BOTTOM RH SIDE BOTTOM LH COVER SPARK PLUG TAPESET

SPRING BUD GREEN 1

2 3

7 4 8 9

5

10

6

11 12 13

DESCRIPTION MIRROR ASSY RH MIRROR ASSY LH HOUSING HEADLAMP FRONT FRONT TOP LOGO TVS FRONT FRONT BOTTOM PILLION HANDLE SIDE BOTTOM CENTER SIDE TOP RH SIDE TOP LH SIDE BOTTOM RH SIDE BOTTOM LH COVER SPARK PLUG TAPESET

AUREOLIN YELLOW 1

2 3

7 4 8 9 10

5 6

11 12 13

S.No.

PART NO.

1 2 3 4 5 6 7 8 9 10 11 12 13 14

K31504109R K31504009R K31204009R K3120580CA K31205709R K3120620C K31226509R K3121060C K31209709R K31209609R K3120829C K3120819C K31211409R K3221250

DESCRIPTION MIRROR ASSY RH MIRROR ASSY LH HOUSING HEADLAMP FRONT FRONT TOP LOGO TVS FRONT FRONT BOTTOM PILLION HANDLE SIDE BOTTOM CENTER SIDE TOP RH SIDE TOP LH SIDE BOTTOM RH SIDE BOTTOM LH COVER SPARK PLUG TAPESET

CAMELLIN GREEN LIGHT + WHITE S.No. 12

13 6

7

11

1 2 3 10 5

8

4

9

PART NO.

DESCRIPTION

1

K31204001F

2

K31205800CB

HOUSING HEADLAMP FRONT WHITE

3

K31205701FA

4

K3120620EL

BOTTOM FRONT CAM GREEN+T SET

5

K31233701F

COVER SPARK PLUG WHITE

6

K31209601FA

SIDE TOP L + LOGO L CAM GREEN

7

K31209701FA

SIDE TOP R+LOGO R CAM GREEN

8

K31208100CI

SIDE , BOTTOM L + LOGO CAM GREEN

FRONT TOP LOGO TVS SAF BLUE FRONT +TAPESET CAM GREEN

9

K31208200CI

10

K3121060C

SIDE BTM CNTR SIL MET GREY

SIDE , BOTTOM R + LOGO CAM GREEN

11

K31206501F

PILLION HANDLE PAINTED REF PEP+

12

K31504101F

MIRROR ASSY R WHITE REF PEP+

13

K31504001F

MIRROR ASSY L WHITE REF PEP+

14

K3222270

S.No.

PART NO.

1

K31204001F

2

K31205800CB

FRONT TOP LOGO TVS SAF BLUE

3

K31205701FB

FRONT +TAPESET CLASSIC PINK

4

K31206203H

BOTTOM FRONT CLASSIC PINK+T

5

K31233701F

COVER SPARK PLUG WHITE

6

K31209601FB

SIDE TOP L + LOGO L CLASSIC PINK

7

K31209701FB

SIDE TOP R+LOGO R CLASSIC PINK

8

K31208100CJ

SIDE , BOTTOM L + LOGO CLASSIC

9

SIDE , BOTTOM R + LOGO CLASSIC P

10

K31208200CJ K3121060C

11

K31206501F

PILLION HANDLE PAINTED REF PEP+

12

K31504101F

MIRROR ASSY R WHITE REF PEP+

13

K31504001F

MIRROR ASSY L WHITE REF PEP+

14

K3222080

TAPESET EL

CLASSIC PINK + WHITE 12

13 6

7

11

1 2 3 10 5

8

4

9

DESCRIPTION HOUSING HEADLAMP FRONT WHITE

SIDE BTM CNTR SIL MET GREY

TAPESET PINK .

DEEP PURPLE + WHITE 12

S.No.

13 6

7

11

1 2

3 10 5

4

8

9

PART NO.

DESCRIPTION

1

K31204001F

HOUSING HEADLAMP FRONT WHITE

2

K31205800CB

FRONT TOP LOGO TVS SAF BLUE

3

K31205701F

FRONT +TAPESET DEEP PURPLE

4

K31206204B

BOTTOM FRONT DEEP PURPLE+T

5

K31233701F

COVER SPARK PLUG WHITE

6

K31209601F

SIDE TOP L + LOGO L DP PURPLE

7

K31209701F

SIDE TOP R+LOGO R DP PURPLE

8

K31208100CH

SIDE , BOTTOM L + LOGO DEEP P

9

SIDE , BOTTOM R + LOGO DP PURPLE

10

K31208200CH K3121060C

11

K31206501F

PILLION HANDLE PAINTED REF PEP+

12

K31504101F

MIRROR ASSY R WHITE REF PEP+

13

K31504001F

MIRROR ASSY L WHITE REF PEP+

14

K3222280

TAPESET PURPLE

SIDE BTM CNTR SIL MET GREY

FLAME RED + WHITE S.No. 12

13 6

7

11

1 2 3 10 5

8

4

9

PART NO.

DESCRIPTION

1

K31204001F

HOUSING HEADLAMP FRONT WHITE

2

K31205800CB

FRONT TOP LOGO TVS SAF BLUE

3

K31205701FC

FRONT +TAPESET FLAME RED

4

K31206206G

BOTTOM FRONT FLAME RED+TAPE

5

K31233701F

COVER SPARK PLUG WHITE

6

K31209601FC

SIDE TOP L + LOGO L FLAME RED

7

K31209701FC

SIDE TOP R+LOGO R FLAME RED

8

K31208100CK

SIDE , BOTTOM L+LOGO FLAME RED

9

K31208200CK K3121060C

SIDE , BOTTOM R+LOGO DP PURPLE

10 11

K31206501F

PILLION HANDLE PAINTED REF PEP+

12

K31504101F

MIRROR ASSY R WHITE REF PEP+

13

K31504001F

MIRROR ASSY L WHITE REF PEP+

14

K3222070

TAPESET FLAME RED .

SIDE BTM CNTR SIL MET GREY

METALIC BLUE + WHITE S.No. 12

13 6

7

11

1 2 3 10 5

9

8

4

PART NO.

DESCRIPTION

1

K31204001F

HOUSING HEADLAMP FRONT WHITE

2

K31205800CB

FRONT TOP LOGO TVS SAF BLUE

3

K31205701FD

FRONT +TAPESET METALIC BLUE

4

K31206201B

BOTTOM FRONT MET BLUE+TAPE

5

K31233701F

COVER SPARK PLUG WHITE

6

K31209601FD

SIDE TOP L + LOGO L MET BLUE

7

K31209701FD

SIDE TOP R+ LOGO R MET BLUE

8

K31208100CL

SIDE , BOTTOM L + LOGO MET BLUE

9

SIDE , BOTTOM R + LOGO MET BLUE

10

K31208200CL K3121060C

11

K31206501F

PILLION HANDLE PAINTED REF PEP+

12

K31504101F

MIRROR ASSY R WHITE REF PEP+

13

K31504001F

MIRROR ASSY L WHITE REF PEP+

14

K3222380

TAPESET BLUE

SIDE BTM CNTR SIL MET GREY

MAUVE S.No. 12

13 6

7

11

PART NO.

DESCRIPTION

1

K31204004H

HOUSING HEADLAMP FR MAUVE -PEP

2

K31205800CB

FRONT TOP LOGO TVS SAF BLUE

1

3

K31205704HA

FR+LOGO MAUVE

2

4

K31206204B

BOTTOM FRONT DEEP PURPLE+T

5

K31233704H

COVER SPARK PLUG BLK MAUVE

6

K31209604HA

SIDE TOP L+LOGO MAUVE

7

K31209704HA

SIDE TOP R+LOGO MAUVE

8

K31208100CH

SIDE , BOTTOM L + LOGO

9

K31208200CH

SIDE , BOTTOM R + LOGO

10

K3121060C

SIDE BTM CNTR SIL MET GREY

11

k31226504H

PILLION HANDLE MAUVE - PEP

12

K31504104H

MIRROR ASSY R

13

K31504004H

MIRROR ASSY L

14

K3222720

TAPESET 4B

3 10 5

4

8

9

TOP FROST S.No.

12

PART NO.

DESCRIPTION

13 6

7

11

1 2 3 10 5

4

8

9

1

K3120400BL

HOUSING HEADLAMP FR TOP FROST

2

K31205800CB

FRONT TOP LOGO TVS SAF BLUE

3

K3120570BLA

FR+LOGO TOP FROST

4

K31206200DA

BOTTOM FRONT+TAPESET BLACK

5

K3123370BL

COVER SPARK PLUG TOP FROST

6

K3120960BLA

SIDE TOP L+LOGO TOP FROST

7

K3120970BLA

SIDE TOP R+LOGO TOP FROST

8

K31208100CN

SIDE , BOTTOM L + LOGO SIL MET

9

K31208200CN

SIDE , BOTTOM R + LOGO SIL MET

10

K3121060C

SIDE BTM CNTR SIL MET GREY

11

k3122650BL

PILLION HANDLE TOP FROST

12

K3150400BL

MIRROR ASSY L TOP FROST

13

K3150410BL

MIRROR ASSY R TOP FROST

14

K3222730

TAPESET HBLK
