F1 (20A)

Anti-lock brake system (ABS)

F2 (30A)

Anti-lock brake system (ABS)

F3 (30A)

Heater/air conditioning (AC)

F4 (30A)

Heater/air conditioning (AC)

F5 (30A/40A)

Engine coolant blower motor 1

F6 (20A/30A/40A)

Engine coolant blower motor 2

F7 (10A)

Windscreen wipers

F8 (15A)

Horn

F9 (25A)

Headlamp washers

F10

-

F11

-

F12 (5A)

Engine coolant pump relay - if fitted

F13 (15A)

Front fog lamps

F14 (30A)

Windscreen wipers - high speed

F15 (30A)

Windscreen wipers - low speed

F16 (5A)

Anti-lock brake system (ABS), stop lamps

F17 (25A)

Fuel filter heater

F18 (25A)

Starter motor

F19 (30A)

Automatic transmission (AT)

F20 (10A)

Air conditioning (AC)

F21 (20A)

Engine management

F22 (7,5)

Engine management

F23 (10A)

Headlamp adjustment

F24 (15A)

Fuel pump (FP)

F25 (15A)

Automatic transmission (AT)

F26 (10A)

Engine management

F27 (5A)

Power steering

F28 (5A)

Automatic transmission (AT)

F29 (7,5A)

Automatic transmission (AT)

F30 (10A)

Engine management

F31 (10A)

Headlamp adjustment

F32 (5A)

Air conditioning (AC), anti-lock brake system (ABS)

F33 (5A)

Headlamp adjustment

F34 (7,5A)

Steering column function control module

F35 (20A)

Audio system, navigation system

F36 (7,5A)

Audio system, telephone

Location

Component

1

Multifunction control module

2

Engine coolant blower motor relay 1

3

Engine coolant blower motor relay 2

4

Headlamp washer pump relay

Opel/Vauxhall 2005

Manufacturer: Opel/Vauxhall Engine code: Z19DTH

Model: Astra-H 1,9D CDTi Output: 110 (150) 4000

© Autodata Limited 2010 Valid forever. 16.05.2015

Tuned for:

Year: 2004-11

V8.500-

5

Fog lamp relay - front

6

Windscreen wiper motor relay 1 (low/high wiper speed)

7

Windscreen wiper motor relay 2 (ON/OFF)

8

Heater/AC blower motor

9

Fuel heater relay

10

Starter motor relay

11

Engine coolant blower motor relay 3

12

AC compressor clutch relay

13

Engine control (EC) relay

14

Fuel lift pump relay - Diesel

14

Fuel pump (FP) relay - petrol

15

Ignition main circuits relay 1
