Motherboard

The main circuit board of a microcomputer. The motherboard contains the connectors for attaching additional boards. Typically, the motherboard contains the U, BIOS, memory, mass storage interfaces, serial and parallel ports, expansion slots, and all the controllers required to control standard peripheral devices, such as the display screen, keyboard, and disk drive. Collectively, all these chips that reside on the motherboard are known as the motherboard's chipset. On most PCs, it is possible to add memory chips directly to the motherboard. You may also be able to a faster PC by replacing the U chip. To add additional core features, you may need to replace the motherboard entirely.

Form Factor A motherboard by itself is useless, but a computer has to have one to operate. The motherboard's main job is to hold the computer's microprocessor chip and let everything else connect to it. Everything that runs the computer or enhances its performance is either part of the motherboard or plugs into it via a slot or port.


A modern motherboard..

The shape and layout of a motherboard is called the form factor. The form factor affects where individual components go and the shape of the computer's case. There are several specific form factors that most PC motherboards use so that they can all fit in standard cases. The form factor is just one of the many standards that apply to motherboards. Some of the other standards include: 







The socket for the microprocessor determines what kind of Central Processing Unit (U) the motherboard uses. The chipset is part of the motherboard's logic system and is usually made of two parts -- the northbridge and the southbridge. These two "bridges" connect the U to other parts of the computer. The Basic Input/Output System (BIOS) chip controls the most basic functions of the computer and performs a self-test every time you turn it on. The real time clock chip is a battery-operated chip that maintains basic settings and the system time.

The slots and ports found on a motherboard include: 





 

Peripheral Component Interconnect (PCI)connections for video, sound and video capture cards, as well as network cards Accelerated Graphics Port (AGP) - dedicated port for video cards. Integrated Drive Electronics (IDE) - interfaces the hard drives & CD-rom Universal Serial Bus or USB - external peripherals Memory slots

Some motherboards also incorporate newer technological advances:

PCI Express is a newer protocol that acts more like a network than a bus. It can eliminate the need for other ports, including the AGP port.  Rather than relying on plug-in cards, some motherboards have on-board sound, networking, video or other peripheral . (PCI) A standard for connecting peripherals to a personal computer, designed by intel and released around 1993. 

A Socket 754 motherboard

Many people think of the U as one of the most important parts of a computer. We'll look at how it affects the rest of the computer in the next section.

Sockets and Us The U is the first thing that comes to mind when many people think about a computer's speed and performance. The faster the processor, the faster the computer can think. In the early days of PC computers, all processors had the same set of pins that would connect the U to the motherboard, called the Pin Grid Array (PGA). These pins fit into a socket layout called Socket 7. This meant that any processor would fit into any motherboard.

U manufacturers Intel and AMD use a variety of PGAs, none of which fit into Socket 7. As microprocessors advance, they need more and more pins, both to handle new features and to provide more and more power to the chip.

Socket arrangements are often named for the number of pins in the PGA. Commonly used sockets are: •Socket 478 - for older Pentium and Celeron processors •Socket 754 - for AMD Sempron and some AMD Athlon processors •Socket 939 - for newer and faster AMD Athlon processors •Socket AM2 - for the newest AMD Athlon processors •Socket A - for older AMD Athlon processors

The newest Intel U does not have a PGA. It has an LGA, also known as Socket T. LGA stands for Land Grid Array. An LGA is different from a PGA in that the pins are actually part of the socket, not the U. Anyone who already has a specific U in mind should select a motherboard based on that U. For example, if you want to use one of the new multi-core chips made by Intel or AMD, you will need to select a motherboard with the correct socket for those chips. Us simply will not fit into sockets that don't match their PGA. The U communicates with other elements of the motherboard through a chipset.

Chipsets The chipset is the "glue" that connects the microprocessor to the rest of the motherboard and therefore to the rest of the computer. On a PC, it consists of two basic parts -- the Northbridge and the Southbridge. All of the various components of the computer communicate with the U through the chipset.

The Northbridge connects directly to the processor via the front side bus (FSB). A memory controller is located on the northbridge, which gives the U fast access to the memory. The northbridge also connects to the AGP or PCI Express bus and to the memory itself. The Southbridge is slower than the northbridge, and information from the U has to go through the Northbridge before reaching the Southbridge. Other busses connect the southbridge to the PCI bus, the USB ports and the IDE or SATA hard disk connections. Chipset selection and U selection go hand in hand, because manufacturers optimize chipsets to work with specific Us. The chipset is an integrated part of the motherboard, so it cannot be removed or upgraded. This means that not only must the motherboard's socket fit the U, the motherboard's chipset must work optimally with the U.

Bus Speed A bus is simply a circuit that connects one part of the motherboard to another. The more data a bus can handle at one time, the faster it allows information to travel. The speed of the bus, measured in megahertz (MHz), refers to how much data can move across the bus simultaneously. Busses connect different parts of the motherboard to one another
