COJINETES, BUJES Y ARANDELAS PARA MOTOR

CATÁLOGO DE APLICACIONES Y REFERENCIAS TÉCNICAS 2008-2009

ÍNDICE

CONTENIDO PAG. DESCRIPCIÓN DE COJINETE

2

AUDI

6

CHRYSLER - DODGE - JEEP - PLYMOUTH

8

FORD - LINCOLN - MERCURY

42

GM CHEVROLET - BUICK - OLDSMOBILE - PONTIAC

84

HONDA

132

HYUNDAI

136

ISUZU

138

MAZDA

142

MITSUBISHI

148

NISSAN

156

RENAULT

174

SUZUKI

182

TOYOTA

184

VAM (RAMBLER)

192

VOLKSWAGEN

198

NÚMERO BIELA

211

NÚMERO BANCADA

233

NÚMERO BUJE DE ÁRBOL

257

NÚMERO ARANDELAS

269

INTERCAMBIOS CLEMEX A MORESA

273

INTERCAMBIOS FEDERAL MOGUL A MORESA

276

INTERCAMBIOS DURABOND A MORESA

279

DAÑOS EN COJINETES

281

COJINETE

EL COJINETE Es un elemento conformado por dos o más materiales (capas de material antifricción), el cual soporta cargas y velocidades; protege y permite el giro libre y silencioso del cigüeñal ó árbol de levas, además es una pieza reemplazable que compensa el rectificado en estos componentes.

COJINETES PARA BIELA Y BANCADA Moresa ofrece una línea completa de Cojinetes de Biela y Bancada (Metales), bajo requerimientos de Equipo Original, utilizando las últimas tecnologías metalúrgicas para la formulación de sus aleaciones de aluminio (Según SAE J460). Casquillo Soporte de Acero Capa de Aleación de Aluminio

Muesca de Ubicación

Espesor de Ceja Diám Diám

Muesca de Ubicación

Chaflán

etro E

etro I

xter ior

nter ior

Ranura de Lubricación

Barreno de Lubricación Ancho Interior entre caras Ranura de Cara Área Antifricción

2

Ancho del Cojinete

COJINETE

Los cojinetes por diseño cuentan con un diseño de tipo excéntrico lo que significa, que el espesor va disminuyendo desde el centro hacia sus extremos, esto ayudará al efecto de fijación de la pieza, y permitirá que la capa de aceite se forme bajo el área de carga. Cuando realice las mediciones del cojinete, se deberá de hacer en el centro de la pieza, ya que al realizar la medición en alguna otra parte del cojinete se incurrirá en un error. Corona (Pared en la Línea Central)

Excentricidad

Muñón

3/8

1/4 Cojinetes Rectos

Línea de Partición Holgura

BUJES Los Bujes Moresa ofrecen un perfecto ajuste al ser instalados en su alojamiento, brindan mayor capacidad de amoldamiento en su área de trabajo y protegen los muñones del árbol de levas ya que están especialmente diseñados para el mercado de repuesto, por las características de sus materiales y su fabricación de una sola pieza, brindan los siguientes beneficios: Ajuste suave y preciso Seguridad y rapidez en su instalación Evita perdidas de presión de aceite No se abre ni deforma, haciendo más sencilla su instalación

3

COJINETE

Producidos bajo las más estrictas normas que requiere el mercado automotriz de equipo original, los bujes Moresa son rectificados en su diámetro exterior e interior por medio de un maquinado concéntrico, lo que le brinda una superficie perfectamente uniforme a lo largo de su circunferencia, ofreciendo una mayor área de o, tanto en el alojamiento como en la superficie de trabajo. Ancho d el Buje

Buje de una sola Pieza

Diámetro Exterior

Casquillo soporte de acero Espesor

Área de trabajo (aleación suave Babbit)

Barreno de lubricación Diámetro Interior

IMPORTANCIA DE UN TORQUE (APRIETE) ADECUADO Para obtener el claro de lubricación adecuado, necesitamos aplicar el torque indicado por el fabricante. Actualmente diversas especificaciones contienen fracciones de giro ó ángulo en grados, que se debe aplicar al apriete final.

Torquímetro 4

Angulómetro

COJINETE

CLARO DE LUBRICACION Verifique el claro de lubricación con “Platigage”. El plastigage es una fibra compresible calibrada la cual nos indica el claro de lubricación y la uniformidad de asentamiento del muñón sobre el cojinete.

5

AUDI

4 CILINDROS /

4 CYLINDER

MOTOR / ENGINE

CIL.

CYL.

AÑO / YEAR

LINEA / LINE

1500 (1.5L)

1972-

1

1588 cc (1.6L)

1972-

1

1600 (1.6L) ABB,ABM,ADA,ADP- AEH,DT,JU,PP,RN

1985 -

1

AÑO

YEAR

MOTOR / APLICACIÓN

Diámetro del Cilindro Nominal Bore

Carrera Stroke

ENGINE / APPLICATION

Línea Line

mm Pulgadas

mm Pulgadas

1500 (1.5L) (1470 cc) Audi 80

76.50 3.012

80.00 3.149

1972-

1588 cc (1.6L) (1600) Audi 80/100

79.50 3.130

80.00 3.150

1985 -

1600 (1.6L) ABB,ABM,ADA,ADPAEH,DT,JU,PP,RN (1595 cc) Audi 80, A3, A4, A4 Avant

81.00 3.189

77.40 3.047

COJINETE, BUJE No. de Parte O ARANDELA BEARING, BUSHING OR THURST WASHER

L4

1

1972-

Ubicación Location

Part Number

COJINETE DE BIELA

4B1017 STD 010 020 030 040 050 060

COJINETE DE BANCADA

5C1157 STD 010 020 030

TODOS

1-2-4-5 ( A, B )

3 ( C, D )

1 BUJE DE ARBOL

MO1726M STD

2 L4

2

1982-

1986-

6

1800 (1.8L) ADR/AEB/AGN/ AGU- DR/DS/DZ JN/JV/JW/ - NE/NP/PH/PM/PV RS/RU/SH/4B (1781 cc) A4,A4 Quatro/Avant/Cabrio Turb, Audi 80/100, A3/A3 Turbo

81.00 3.189

86.40 3.402

2000 (2.0L) AAD,AAE,ABK,ABTADW,3A,6A (1984 cc) Audi 80/80E Quatro, Audi Avant/Cabrio, A6 Quatro

82.50 3.248

92.80 3.654

COJINETE DE BIELA

4B1426 STD 010 020 030 040

COJINETE DE BANCADA

5C1157 STD 010 020 030

TODOS

1-2-4-5 ( A, B )

3 (C, D )

AUDI

4 CILINDROS /

4 CYLINDER

MOTOR / ENGINE

AÑO / YEAR

LINEA / LINE

1982-

2

1986-

2

1800 (1.8L) ADR/AEB/AGN/AGU- DR/DS/DZ JN/JV/JW/ - NE/NP/PH/PM/PV - RS/RU/SH/4B 2000 (1.8L) AAD,AAE,ABK,ABT- ADW,3A,6A Diámetro Estándar del Diámetro Total Muñón del Alojamiento Standard Shaft Diameter

mm Pulgadas

45.938/45.959 1.808/1.809

Housing Bore

mm Pulgadas

48.999/49.014 1.929/1.930

Ancho del Cojinete Width Bearing

mm Pulgadas

19.00 0.748

Espesor Máximo de Pared Max Wall Thickness

mm Pulgadas

1.506 0.0593

Claro de Lubricación

Torque

Imagen del Cojinete / Arandela

Oil Clearance

Torque

Image of the Bearing and Thurst Washer

mm Pulgadas

N.m Lbs.Ft

0.0406/0.1016 0.0016/0.0040

45 N.m 33 Lbs.Ft

8 Piezas A

B

C

D

4 Piezas

4 Piezas

1 Pieza

1 Pieza

53.957/53.978 2.124/2.125

58.999/59.017 2.323/2.324

18.49 0.728

2.502 0.0985

0.0406/0.1041 0.0016/0.0041

53.957/53.978 2.124/2.125

58.999/59.017 2.323/2.324

24.94 0.982

2.502 0.0985

0.0406/0.1041 0.0016/0.0041

42.959/42.972 1.691/1.692

45.999/46.025 1.811/1.812

14.99 0.590

1.499 0.0590

0.0279/0.0990 0.0011/0.0039

1 Pieza

41.958/41.974 1.652/1.653

44.999/45.024 1.772/1.773

14.99 0.590

1.499 0.0590

0.0279/0.0990 0.0011/0.0039

1 Pieza

47.757/47.777 1.880/1.881

50.599/50.620 1.992/1.993

19.00 0.748

1.405 0.0553

0.0228/0.0812 0.0009/0.0032

64 a 68 N.m 47 a 50 Lbs.Ft

30 N.m + 90° 22 Lbs.Ft + 90° 8 Piezas

53.957/53.978 2.124/2.125

53.957/53.978 2.124/2.125

58.999/59.017 2.323/2.324

58.999/59.017 2.323/2.324

18.49 0.728

24.94 0.982

2.502 0.0985

2.502 0.0985

0.0406/0.1041 0.0016/0.0041

0.0406/0.1041 0.0016/0.0041

64 a 68 N.m

A

B

C

D

4 Piezas

4 Piezas

1 Pieza

1 Pieza

47 a 50 Lbs.Ft
