List of SAP PM Main Tables classified by PM Object (Plant Maintenance) SAP Plant Maintenance Tables or SAP PM Tables in this article are classified by SAP PM Business Topics. You will find the SAP PM tables for:

        

Equipment Tables Functional Locations Tables for Serial Numbers Measurement Document Tables for Maintenance Notification Tables for Service Notification Tables for Maintenance and Service Orders Task Lists Tables Maintenance Plans tables

SAP PM Equipment Tables

The business object “Equipment” is an individual, physical object that is to be maintained independently. It can be installed in a technical system or part of a technical system. The main SAP Plant Maintenance Tables for Equipment are:

      

EQUI: Equipment master data EQKT: Multilingual equipment short texts, long texts, and internal remarks EQUZ: Equipment time segments ILOA: Location and assignment data for the maintenance object IHSG: Table of permits for Plant Maintenance with long texts IHPA: Partners FLEET: Fleet object-specific data for technical objects

SAP PM Functional Locations Tables The business object functional location is an organizational unit within Logistics, that structures the maintenance objects of a company according to functional, process-related or spatial criteria. A functional location represents the place at which a maintenance task is to be performed. The most used SAP Plant Maintenance Tables for Functional Locations.

     

IFLOT: Functional location master data IFLOS: Functional location labelling IFLOTX: Multilingual short texts and long texts for the functional location ILOA: Location and assignment data for the maintenance object IHPA: Partner IHSG: Table of permits for Plant Maintenance with long texts.

SAP PM Tables for Serial Numbers Serial Number SAP PM Tables manage how the ID for different objects in SAP PM are generated. The main SAP Plant Maintenance Tables for Serial Numbers are:

       

OBJK: Object list for Plant Maintenance SER01: Document header for serial numbers for delivery SER02: Document header for serial numbers for maintenance contract (SD order) SER03: Document header for serial numbers for delivery SER04: Document header for serial numbers for inspection lot SER05: Document header for serial numbers for PP order SER06: Document number for serial numbers for handling unit – contents SER07: Document header for serial numbers in physical inventory

SAP PM Measurement Document

   

The data transferred to the system after a measurement has been taken at a measuring point or a counter is described in the R/3 System as a measurement document. This transfer can be performed automatically or manually. The measurement document is therefore the result of a measurement or counter reading being entered in the system. CDHDR: Change document header CDPOS: Change document item IMRG: Measurement document THEAD: Long text

SAP PM Tables for Maintenance Notification   

         

Check more data about in this post SAP Maintenance Notification Overview. You use this application component in maintenance processing in the event of a malfunction or exceptional situation to: Describe the exceptional technical condition at an object Request the maintenance department to perform a necessary task Document work that has been performed Maintenance notifications document maintenance tasks completely, and make them available for analysis in the long term. You can use them for preliminary planning and execution of tasks. QMEL: Notification header data QMFE: Items QMMA: Activities QMSM: Tasks QMUR: Causes QMIH: Maintenance data ILOA: Location data IHPA: Partners PMLP: Print log KSSK: Classification

JEST, JESTO: Status SWW_CONTOB: Workflow, work item THEAD: Long text

  

SAP Plant Maintenance Tables for Service Notification The common SAP PM tables for Service Notification are:

QMEL: Notification header data QMFE: Items QMMA: Activities QMSM: Tasks QMUR: Causes QMIH: Maintenance data ILOA: Location data IHPA: Partner PMLP: Print log

        

SAP PM Tables for Maintenance and Service Orders For Service Orders data, check these SAP PM Tables:

AFIH: Order header AFAB: Network – Relationships AFPO: Order Item AFFH: PRT assignment data for the work order AFFL: Work order sequence AFFT: Order – Process Instructions AFFV: Order – Process Instruction Values AFKO: Order header data PP orders IHPA: Partners PMCO: Cost structure and overview of the order MCIPMIS: Order data for PMIS PMCOQT: Quantity structure for the maintenance order PMPL: Print data for the order PMSDO: PM organizational data for SD documents

             

SAP PM Task Lists Tables SAP Plant Maintenance Tables for Task Lists are:

PLKO: Task list header PLKZ: Time-independent header data (for example, istrative

  data)    

MAPL: Material-task list assignments KALC: Formulas for material quantity calculation KALT: Texts for the formulas EAPL: Equipment assignments

                  

TAPL: Assignments of functional locations PLFL: Task list sequences PLPO: Operations PLAS: Assignments of operations to sequences PLMZ: Material component assignments PLWP: Maintenance package assignments PLFH: Production resources/tool assignments PLMK: Inspection plan characteristics PLMW: Inspection plan characteristic values PLAB: Task list relationships PLTX: PMS texts PLPH: Phases and partial operations for CAP PLFT: Process instructions PLFV: Process instruction characteristics and partial operation parameters MLST: Milestones EINA: Purchasing info record (general data) EINE: Purchasing info record (data for purchasing organization) ESLL: Lines for service package ESLH: Service package header data Here an example for SAP PM Tables Data Model for SAP PM Routine. It explains How to Link Between PLKO and PLPO for Routine in SAP.

SAP Maintenance Plans tables And finally, the SAP Maintenance Plans Master data Tables for Plans are, mainly:

MPLA: Maintenance plan MMPT: Cycle definitions and measuring points for the maintenance

  plan      

MHIS: Maintenance plan calls MHIO: Call objects, call object history ONR00: Object number MPOS: Maintenance item ILOA: Location and assignment for maintenance object (PM object) OBJK: Object list for Plant Maintenance
