Guide to ‘O’ rings

Contents Introduction ‘O’ ring stocks Quality Trademark acknowledgements How to use this guide Selecting an ‘O’ ring Selecting a back-up ring Selecting a material Coloured materials How to order

2 2 2 2 3-5 3 3 4 4 5

Introduction

Quality

The ‘O’ ring, or toroidal seal, is an exceptionally versatile sealing device. Applications ranging from garden hose couplings to critical aerospace or refinery duties make it the world’s most popular volume-produced seal.

Quality standards Our quality systems are third-party ed to BS EN ISO 9001:2000. We are also regularly assessed and quality approved by a wide range of industry bodies and individual customers including multinational corporations, utilities and government organisations.

‘O’ rings offer many benefits to design engineers and plant operators, they: G G

Materials & properties General materials Commercial ‘O’ rings High performance materials Guide to material use Lubricants Surface texture Explosive decompression FEP encapsulated ‘O’ rings Back-up rings James Walker ‘O’ rings Chart 50: Inch and metric sizes ‘O’ rings for pipe fittings Chart 72: Metric sizes Chart 17000: Inch sizes Non-standard sizes

6-10 6 6 7 8 8 8 9 10 10 11-23 11-17 17 18-20 21-22 23

Design notes 24-28 Design notes: General 24-25 Design notes: Housings 26-28 (fold out page 28 for easy reference) ‘O’ ring cord & kits ‘O’ ring cord ‘O’ ring kits Special packaging and kits

29 29 29 29

Distribution network

30

G G G

G

Suit many static and dynamic duties. Occupy little space. Seal efficiently in both directions. Are compatible with most fluid media. Can work between –65°C and +315°C when made of elastomer – according to material type. Can function at temperatures down to –200°C when made of PTFE.

Today, the design engineer is faced with a bewildering array of ‘O’ ring statistics and advice. In this guide we simplify design data, give concise information on materials and facilitate part selection for specification and ordering purposes. The result is a document that contains valuable information for use by buyers, designers and maintenance staff.

‘O’ ring stocks We now stock over seven million ‘O’ rings ready for same-day despatch. If the rings you want are not available off-the-shelf, we can supply them within days from our extensive manufacturing facility. With our flexible production schedules, we can meet the most urgent requests from industry.

Trademark acknowledgements James Walker acknowledges the following trademarks as mentioned in this guide. All other names bearing the ® symbol are ed trademarks of James Walker. Trademark Company

Trademark

Company

Aflas® Dyneon™ Hypalon® Kalrez®

PEEK™ Tecnoflon® Viton®

Victrex plc Ausimont Spa DuPont Performance Elastomers

2

In addition, we hold test equipment for all relevant BS, ISO, ASA, API, ANSI, DIN, DTD and NATO standards. Certificates of conformity are supplied on request. Packaging and labelling is available to individual specifications.

Asahi Glass 3M Dyneon DuPont Performance Elastomers DuPont Performance Elastomers

Quality production and inspection Our Materials Technology Centre houses one of Europe’s most advanced facilities for elastomer batch production. At its heart is a computer-controlled internal mixer that holds formulae for over 300 of our elastomeric compounds. Together with on-line rheometer testing, this gives us complete batch traceability, regardless of any release certificate requirements. The post-curing of silicone and fluorocarbon elastomers is also under microprocessor control for temperature level and time. Each cure cycle is tracerecorded as a vital link in our quality chain. Every ‘O’ ring we manufacture is visually inspected. This is backed by batch inspection of physical dimensions with an even closer study of mismatch, flash and other specific parameters. Material Safety Data Sheets (MSDS) are available on request.

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

How to use this guide

Selecting an ‘O’ ring This guide contains three chart sizes: G Chart 50 – including BS1806 and SAE AS568A. G Chart 72 – metric sizes to BS4518. G Chart 17000 – James Walker inch sizes.

If your ‘O’ ring is a non-standard size our Technical Services Team. We have in excess of 8000 ‘O’ ring moulding tools in our library and are sure we can help.

To match an existing ‘O’ ring If your existing ‘O’ ring has a BS1806, SAE AS568A or BS4518 reference:

Selecting a back-up ring One or more back-up rings are used to prevent extrusion of an elastomeric ‘O’ ring under arduous operating conditions. Our standard back-up rings are machined in PTFE and normally supplied in single turn or spiral form. See page 10 for more details of back-up rings.

1. Refer to Chart 50 for BS1806 and SAE AS568A, or Chart 72 for BS4518. 2. Quote appropriate James Walker number. Table 1: Diameter sections used in JW charts Chart 50 (BS1806 & SAE AS568A) 0.070"/1.78mm 0.103"/2.62mm 0.139"/3.53mm 0.210"/5.33mm 0.275"/6.99mm

Chart 72 (BS4518)

Chart 17000

1.6mm 2.4mm 3.0mm 5.7mm 8.4mm

0.063" 0.094" 0.125" 0.188" 0.250"

For an existing housing 1. Refer to diagrams on page 28. 2. Select the one that matches your housing. 3. Obtain from existing housing the critical dimensions shown on selected diagram. 4. Refer to Housing Tables 7 & 8 on page 26. These show BS1806/SAE AS 568A in both inch and metric units, and BS4518 (metric) with more data on pages 18-20.

If only the size is known 1. Obtain diameter section A of ‘O’ ring .

5. Cross reference dimensions on housing tables.

2. Consult Table 1 (above) to find the JW chart that covers rings of the appropriate diameter section A.

6. Read off diameter section A, and consult appropriate JW chart under that specific diameter section.

3. Consult appropriate JW chart, under specific diameter section A.

7. Refer to column that shows housing diameter (coded as selected diagram on page 28) and identify the one that matches yours.

4. Obtain inside diameter B of ‘O’ ring. 5. Refer to column on JW chart that lists inside diameters B and identify your existing ‘O’ ring. 6. Quote appropriate James Walker number.

B A

Figure 1: ‘O’ ring diameter section A and inside diameter B

8. Quote appropriate James Walker number. For a new application 1. Refer to Design notes section, pages 24-28, for guidance with regard to applications. 2. For metric equipment, select ‘O’ ring from Chart 72, pages 18-20.

Back-up ring for use with James Walker ‘O’ ring number Refer to How to order section on page 5 for precise specification details relating to back-up rings for Chart 50, Chart 72 and Chart 17000 applications. Back-up ring for use with existing ‘O’ ring 1. Identify appropriate JW chart and James Walker number for existing ‘O’ ring. If necessary, use method outlined on this page in To match an existing ‘O’ ring. (Note: If a standard ‘O’ ring has been used on a non-standard shaft or cylinder – ie, compressed or stretched into place – the equivalent standard back-up ring must not be used as it cannot be stretched or squeezed in the same way.) 2. Refer to How to order section on page 5 for precise specification details. Back-up ring for use with non-standard size ‘O’ ring our Technical Service Team who will recommend the correct back-up ring.

3. If the metric size you require is not available from Chart 72, then select from metric columns in Chart 50, pages 11-17.

Back-up ring for new application 1. Select the ‘O’ ring you require from JW charts, using method outlined on this page.

4. For inch sizes use Chart 50, or Chart 17000 on pages 21-22.

2. Refer to How to order section on page 5 for precise specification details.

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

3

How to use this guide

Selecting a material Table 2: Stocked material details Standard compound reference

Rubber type

Specifications

PB80

Medium nitrile (NBR)

*BS6996 Grade BO80

EP18/H/75

Ethylene-propylene (EPM)

*DTD 5612A Grade 80

Stocked

Colour

ASTM D2000 reference



Black

ASTM D2000 M2BG 810, B14, EF11, EF21, EO14, EO34 BS5176 2MBG 810, B14, E14, E34, E51, E61



Black

ASTM D2000 M3BA 810, A14, B13, Z1, Z2 Z1: Hardness 75±5 IRHD Z2: Water resistance (70 hours at 200°C); hardness change ±6 IRHD, volume change ±5%



Black

ASTM D2000 M6HK 810, A1-10, B36

Black

ASTM D2000 M7 HK 914, B38, Z1**

Black

ASTM D2000 M3HK 910, A1-10, B38, Z1**

FR10/80

Fluorocarbon (FPM)

FR25/90

Fluorocarbon (FPM)

FR58/90

Fluorocarbon (FPM)

Elast-O-Lion® 101

Hydrogenate nitrile (HNBR)

Elast-O-Lion® 180

Hydrogenated nitrile (HNBR)



Black

Elast-O-Lion® 985

Hydrogenated nitrile (HNBR)



Black

SIL 80/2

Silicone (VMQ)

*DTD 5582A Grade 80 (as amended)



Black

White

ASTM D2000 7GE 805, A19, B37, EO36, Z1 Z1: colour white BS5176 2MGE 805 A19, B17, Z1 Z1: colour white

* All DTD specifications have been declared OBSOLETE. ** Suitable for explosive decompression, consult our Technical Services Team. * Note: Please specify on your enquiry or order if you want ‘O’ rings to meet these specifications.

Table 2 gives details of our nine most widely demanded stocked materials. We recommend that you specify one of these wherever possible for your ‘O’ rings. Full details of all readily available materials and their chemical compatibility are given on pages 6-8. We generally stock compounds of 80 IRHD (International Rubber Hardness Degrees) as these: G G

Frequently give extrusion resistance approaching that of 90 IRHD. Give sealability comparable to materials of 70 IRHD.

‘O’ ring sizes shown on Chart 50, Chart 72 and Chart 17000 are supplied from standard low or high shrinkage tooling without mould charges. Our high shrinkage tooling allows fluorocarbon and silicone ‘O’ rings to be manufactured within the tolerances shown on page 23. If you have any doubt about material selection, please consult our Technical Services Team for specific recommendations. 4

Coloured materials Quality management systems, product liability and health and safety issues have created a growing need to identify elastomers by their colour. With stocks of black components held in several materials, it is possible for the end to select the wrong item and cause an equipment malfunction. Common mistakes include using nitrile NBR seals in phosphate-ester hydraulic fluid systems or ethylene-propylene EPM rubber with mineral oil. To help overcome this, we offer the following non-black compounds: G G G

Fluorocarbon (FPM, FKM) – green. Silicone (VMQ) – white or red. Ethylene-propylene (EPM) – red.

It should be noted that physical properties may vary from standard materials, also that other colours may be available. Please consult our Technical Services Team for specific recommendations.

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

How to use this guide

How to order The following information and examples will enable you to order the correct ‘O’ ring and back-up ring to meet specific requirements.

Back-up rings – Chart 50, metric sizes When ordering Chart 50 back-up rings to match our suggested metric shaft and cylinder sizes, please use:

EXAMPLE: PTFE spiral back-up ring to use with a 49.4mm ID x 4.1mm DS ‘O’ ring on a 50mm diameter shaft. Housing width 7.1mm, depth 3.5mm.

Prefix 150 for shaft applications. Prefix 250 for cylinder applications.

Subsequent orders When re-ordering from James Walker, please state the Re-Order Part Number (eg, OB-03400X) shown on our documentation that acknowledges your previous order. Our computerised re-order system will ensure swift service.

G G

For particularly critical applications – including those requiring FEP encapsulated ‘O’ rings – we recommend that you state the following details to enable us to ensure suitability: G G G G G G G

Pressures. Pressure media. Operating temperatures. Static or dynamic operation (with speeds, if appropriate). Housing type. Tolerances. Any other important factors.

‘O’ rings Standard sizes For a standard size ‘O’ ring, listed on our charts, please state appropriate James Walker number followed by materials reference. If no material or application conditions are specified we will supply our medium nitrile grade PB80. EXAMPLE: JW 50-001 PB80 Other sizes For other sizes, please state inside diameter, diameter section and material reference. EXAMPLE: ID 49.4mm, DS 4.1mm. SIL 80/2 Back-up rings Back-up rings are supplied in spiral form unless single turn is stated. Also, they are supplied in PTFE as standard, unless otherwise stated. Back-up rings – Chart 50, inch sizes When ordering Chart 50 back-up rings for inch size shafts and cylinders, please state the same JW50 number as for the ‘O’ ring. Also indicate spiral or single turn, and material. EXAMPLE: For a JW 50-433 (0.275 inch diameter section) ‘O’ ring on a 5⁄÷™ inch diameter shaft or 6 inch diameter cylinder, order JW 50-433 PTFE spiral back-up ring.

The reason is that ‘O’ rings can be stretched or squeezed by a small percentage – see Design notes pages 2428 – but the back-up ring must be manufactured exactly to suit the shaft or cylinder. Also indicate spiral or single turn, and material. EXAMPLE 1: For a 140mm diameter shaft, order JW 150-433 PTFE spiral back-up ring. EXAMPLE 2: For a 155mm diameter cylinder, order JW 250-433 PTFE spiral back-up ring. Back-up rings – Chart 72 When ordering Chart 72 back-up rings (which cover those to BS5106), please state the same JW 72 number as the ‘O’ ring. Also indicate spiral or single turn, and material. EXAMPLE: JW 72-1393-57 PTFE spiral back-up ring. Back-up rings – Chart 17000 When ordering Chart 17000 back-up rings, please state the same JW 17000 number as the ‘O’ ring. Also indicate spiral or single turn, and material. EXAMPLE: JW 17029 PTFE spiral back-up ring. Back-up rings – other sizes When ordering back-up rings to fit ‘O’ rings that are not listed in our charts, please state the following: 1. Spiral or single turn, and material. 2. Back-up ring size, if known, or 3. ‘O’ ring inside diameter B; ‘O’ ring diameter section A; shaft or cylinder diameter (C or D); housing width and depth (E and F). See page 28.

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

5

Materials & properties

General materials Note: Materials for stocked ‘O’ rings are printed in red. For specific details see Selecting a material on page 4. Nitrile – acrylonitrile-butadiene (NBR) Stocked grade PB80 We have a wide range of compounds based on various acrylonitrile/butadiene ratios. Higher acrylonitrile content generally gives better hydrocarbon resistance, whereas low acrylonitrile content gives better low temperature flexibility. Our PB range is suitable for use with mineral oils – particularly hydraulic types – as well as water and some solvents. Our Proteus range is generally suitable for food applications, but please consult our Technical Services Team on specific applications before ordering. Chloroprene (CR) – eg, Neoprene These general purpose rubbers are largely unaffected by sunlight and atmospheric aging. They will give satisfactory service in many media, such as mineral lubricating oils and greases, dilute acids/alkalis and some solvents. Natural rubber (NR) Materials based on natural rubber have high strength and high resilience with good abrasion resistance. They are suitable for use in hot and cold water, ammonia, ethylene glycol, dilute acids and alkalis. Limited resistance to heat, weathering and oils has reduced the use of natural rubbers in favour of synthetic elastomers.

Ethylene-propylene (EPM/EPDM) Stocked grade EP18/H/75 These compounds have excellent resistance to weathering, ozone, hot and cold water and steam. EPM grades are available for use with water up to +180°C, making them ideal for steam raising plant. These materials also display resistance to aliphatic phosphate-ester hydraulic fluids, acids, alkalis, salt solutions, alcohols, glycols and silicone oils. Our EP62 range of rubbers for potable water applications is WRAS approved. Butyl – isobutylene-isoprene (IIR) Butyl rubber has similar chemical resistance to ethylene-propylene. Very low gas permeability makes butyl popular for vacuum and high pressure gas applications. It must not be used with mineral oils. Epichlorhydrin (ECO) Compounds based on this elastomer have good resistance to mineral oils, fuels and ozone. Corrosive properties and poor compression set resistance limit the use of these materials for sealing applications. Chlorosulphonated polyethylene (CSM) – eg, Hypalon® These elastomers show excellent resistance to weathering and give good service in many media. They are not recommended for dynamic seal applications as compression set resistance is limited.

Commercial ‘O’ rings

Polyurethane (AU/EU) Stress relaxation at above +50°C often precludes these elastomers from ‘O’ ring sealing applications. However, many polyurethane ‘O’ rings are used in drive transmissions where their tensile strength, elongation characteristics and wear resistance prove invaluable. These materials also have excellent resistance to weathering and oxygen, and good resistance to hydrocarbon fuels and mineral oils. Resistance to acids is low, and some grades are affected by water and humidity. Fluorosilicone (FVMQ) Fluorosilicone grades are available for applications involving hydrocarbon oils, petroleum fuels and mineral-based hydraulic fluids. This material is primarily used for static seals in aerospace fuel systems. It has similar mechanical limitations to silicone. Silicone (VMQ) Stocked grade SIL 80/2 Many grades of silicone rubber are available. They offer good resistance to weathering and compression set at high temperatures, plus excellent electrical properties. Use is limited by high gas permeability, low tensile strength, and poor resistance to tear and abrasion. Some grades are suitable for food applications.

G G

To complement our products, we supply general purpose ‘commercial quality’ ‘O’ rings for less critical applications. These are available with: G Competitive prices. G Full traceability – on request. G Quantities from one to millions. G Wide range of material and sizes. Materials – a comprehensive range including: G Ethylene-propylene (EPM/EPDM) G Neoprene (CR) G Nitrile (NBR) G Polyurethane (AU/EU) 6

Silicone (VMQ) Fluoroelastomer (FKM)

Commercial ‘O’ rings are supplied to James Walker Charts: G JW46: covering BS1806 & SAE AS568A. G JW47: European metric range. G JW48: metric sizes to BS4518. G JW49: Japanese industry sizes. Non-standard sizes are also available in commercial materials to suit specific customer requirements. Please our Technical Services Team to determine product suitability.

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

Materials & properties

High performance materials Fluoroelastomers (FPM, FKM) – eg, Viton®, Tecnoflon®, Dyneon™ Stocked grades FR10/80, FR25/90, FR58/90 Fluoroelastomers operate efficiently under severe chemical conditions and at higher temperatures where many other seal materials cannot survive. According to grade they are well suited to arduous applications involving: G

Temperatures from –30°C to +250°C. Petroleum fuels and mineral-based hydraulic fluids. Many solvents.

FR64/70 & 80: Dipolymer-based compounds developed to offer enhanced performance in steam, hot water and mineral acids. LR5853: Tetrapolymer-based range with hardnesses of 80, 90 and 98 IRHD. It has enhanced fluid resistance, especially with methanol and gasoline-alcohol blends that adversely affect other fluoroelastomers. These grades stiffen below –5°C, thus LR6316 and FR25 are recommended for low temperature use.

We have developed numerous grades of fluoroelastomer, including the following:

LR6316: Available in hardnesses of 75 and 90 IRHD, these compounds are based on a special tetrapolymer with a similar fluid resistance to LR5853, plus improved low temperature characteristics for service down to –28°C.

General purpose fluoroelastomers FR10: Dipolymer-based range with hardnesses of 50 to 90 IRHD. These grades are ideal for general applications and are approved to UK Ministry of Defence low compression set specifications.

FR25: Tetrapolymer-based range with hardnesses of 70 to 90 IRHD. Offers fluid resistance approaching that of the FR10 range plus improved low temperature characteristics for service down to –33°C. FR25/90 is compounded for explosive decompression (ED) resistance.

FR17: Terpolymer-based range with hardnesses of 65 to 95 IRHD. It has enhanced chemical resistance and better high temperature flexibility characteristics than FR10, although these properties are – to some extent – at the expense of compression set resistance.

Aflas® (TFE/P) These compounds have resistance to oils, lubricants and some fuels approaching that of fluorocarbon dipolymers but, in addition, are suitable for sour gas duties or where amines and high temperature water or steam are used.

FR44: Dipolymer-based range with hardnesses of 50 to 90 IRHD. It comes in a distinctive shade of green for easy identification. These low compression set grades meet many regularly used specifications.

AF85: Available in hardnesses of 70, 80 and 90 IRHD. Typical maximum service temperature is +200°C although higher temperatures can be sustained in some media: eg, up to +260°C in steam. Other specialised grades are available, such as AF69/90 that is compounded for explosive decompression (ED) resistance.

G G

Special fluoroelastomer grades Many grades are available for specific duties. The following are of particular value: FR58/90 & 98: These terpolymer-based grades resist explosive decompression (ED) as described on page 9, and have good all round elastomeric properties. We are market leader in seals for ED environments.

Kalrez® – perfluoroelastomer (FFPM) These perfluoroelastomers offer almost universal chemical resistance. Grades are available for continuous operation at up to +315°C. James Walker is authorised UK distributor for Kalrez® products used for fluid sealing and handling duties. Please ask for technical details and separate literature.

Fluolion® (PTFE) Fluolion® is the ed trademark of James Walker products manufactured from polytetrafluoroethylene. PTFE is an extremely inert material, unaffected by virtually every known chemical including most acids, alkalis and solvents. These exceptional properties make PTFE the ideal material for ‘O’ ring back-up rings. The flow characteristics of PTFE under stress are usually a disadvantage in ‘O’ rings. Elast-O-Lion® – hydrogenated nitrile (HNBR) Stocked grades Elast-O-Lion® 101, 180, 985 Elast-O-Lion® is the ed trademark of James Walker for its range of high performance hydrogenated nitrile compounds. These materials have the excellent oil/fuel resistance of traditional nitrile (NBR) elastomers. They also have superior mechanical properties and can sustain higher service temperatures: eg, up to +180°C in oil. In addition, they display superior resistance to aggressive fluids such as sour (H2S) crude oil, lubricating oil additives and amine corrosion inhibitors. Fully saturated grades of HNBR have excellent resistance to ozone. Five ranges are available with various acrylonitrile contents from low to ultra high, and hardnesses of 50 to 90 IRHD. In addition, four grades – Elast-O-Lion 101, 201, 301 and 985 – have been specially developed for oilfield duties where a combination of high mechanical strength, resistance to explosive decompression (ED) and chemical resistance is required. Temperature capability is between –46°C and +180°C depending on material grade and application. Further information on elastomers For additional information on our extensive range of high performance elastomers, please refer to our High Performance Elastomers guide.

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

7

Materials and properties

Guide to material use Hydraulic fluids fire resistent

Temperature range (°C)

MA T TY ERI PE AL

Air o W r ox at y W er – gen at u Di er – p to lu a 8 Di te ac bove 0°C lu id 80 Lo te al s °C w ka Ald er a lis l eh co Am yd ho e ls i Ch nes s lo Et rina he te Ke rs d s olv to en Hy nes ts d Hy roca dr br Le oca on ad rb s – Ke ed ons alip ro p h An sen etro – aro atic im e l (g m as ati Fu al o oli c e i ne Lu l oils ls an ) b a d Lu ricat nd fats br ing die Sil icat oi sel ic in ls o Ve one g oi – m ils ge oi ls i ne – l t s Hy ab s ra d le an yn l Ch rau oils d gr thet ea ic lor lic f se Oi ina lui li te ds –m W n wa d at te ine W er in r em ra at lb o as Ph er – il em ulsio ed os gly u ns Ph pha co lsio os te l ba ns ph es se ate te d Lo es rs – w ter ali s – ph ar atic Hi om gh ati –c c on tin Hi uo gh us –i nte rm Ha itte rd nt ne ss ra ng eI Av RH a D the ilabl fol e to low th ing e la sp test ec is ific su ati e o on f s

Table 3

Acrylic ACM 2 4 Aflas® TFE/P 1 1 Butyl IIR 1 1 Elast-O-Lion® HNBR 1 1 Epichlorohydrin ECO 2 2 Ethylene-propylene EPM/EPDM 1 1 Fluolion® PTFE 1 1 Fluoroelastomers FKM 1 1

4 1F 2 1 3 1 1 3

4 1 1 1 3 2 1 1

4 2 1 2 2 1 1 2

4 1 1 1 2 1 1 4C

4 4 1 1 1 2 2 1 4 4 1 2 1 1 4C 4C

3 1 4 2 4 4 1 1

3 4 4 4 4 1 4 4 4 4 3 1 1 1 3C 4C

1 1 4 1 3 4 1 1

3 3 4 3 4 4 1 1

1 2 4 2 1 4 1 1

1 1 4 1 1 4 1 1

1 1 2 1 1 2 1 1

1 1 4 2 1 4 1 1

1 1 4 1 1 4 1 1

2 2 4 1 4 4 1 2

1 1 1 1 1 1 1 1

1 1 3 1 1 3 1 1

1 1 4 1 1 4 1 1

4 2 4 4 4 4 1 2

4 1 4 2 2 4 1 1

4 1 4 2 2 4 1 1

4 1 1 2 2 1 1 2

4 1 2 1 4 1 1 3

4 2 2 4 4 2 1 1

–20 0 –35 –25A –30 –45 –200 –15D

150 200 120 160 150 120 250 200

Fluorosilicone Hypalon® Kalrez® Natural rubber

2 3 1 4

3 4 1 3

2 1 1 2

1 1 1 2

4 3 1 3

1 4 1 4

3 4 1 4

1 2 1 4

1 4 1 4

2 4 1 4

1 4 1 4

1 3 1 4

2 3 1 4

1 4 1 4

2 4 1 4

3 1 1 1

1 2 1 4

2 2 1 4

4 4 1 4

2 4 1 4

2 3 1 4

2 1 1 3

3 4 1 4

3 4 1 4

–60 –30 –25 –50

180 120 315 100

Neoprene Nitrile

FVMQ CSM FFKM NR

1 2 1 3

1 1 1 2

4 4 1 2

4 4 1 4

CR 1 2 3 3 2 1 3 2 4 4 4 2 4 3 2 2 3 2 3 1 3 3 4 4 4 3 4 4 –40 120 NBR 2 1 3 3 2 1 3 4 3 4 4 1 3 2 1 1 2 1 2 1 1 1 4 3 3 1 4 4 –30A 120

Polyurethane Silicone

AU/EU 1 4 4 4 4 4 4 4 3 2 4 2 4 2 2 2 3 2 4 1 2 1 4 4 4 4 4 4 –15 85 VMQ 1 1 1 3 2 1 2 2 4 4 3 3 4 4 4 2 4 3 3 4 1 4 3 3 4 2 3 3 –60 200

175 230F 150 200 175 150B

80 70 - 90 60 - 70 BS 3227 50 - 90 70 - 90 50 - 90 *DTD 5597, 5608

230D 50 - 98 DEF STAN 02-337, *DTD 5543, 5603, 5612, 5613. 200 60 - 80 *DTD 5583 150 65 - 80 350 65 - 95 AS 568A, SAE AMS 7257A 120 40 - 85 BS 1154, DEF STAN 02-820 & *DEF STAN 22-005 150 40 - 90 BS 2752 150 40 - 90 BS 2751, 6996, 6997, DEF STAN 02-337, *DEF STAN 22-005,*DTD 5509, 5594, 5595, 5606, 5607. 100 55 - 95E 250 40 - 80 *DTD 818, 5531, 5582, 5605

Key 1 Very Good 2 Good 3 Fair 4 Not Recommended

*These specifications have been declared OBSOLETE. A Low acrylonitrile content grades are available for temperatures down to –46°C B EPM grades are available for hot water service up to +180°C C Fluoroelastomer grades are available which offer resistance to these chemicals D Fluoroelastomer grades are available for temperatures from –33°C to +250°C E Polyurethane grades are also available from 60 to 74 hardness Shore D F Aflas® grades suitable for temperatures up to +260°C in hot water and steam Note: These figures are provided as a guide only. Actual service life will depend on type of application, whether static or dynamic, specific pressure medium, temperature cycle, time of exposure, etc. The low temperatures quoted are values at atmospheric pressure and may change at elevated pressures.

Surface texture

Lubricants We recommend the following lubricants be specified and applied lightly to ‘O’ rings before assembly (but please note the important exceptions): G

G

James Walker’s Molyon Grease, containing MoS2, for operating temperatures from –20°C to +150°C. James Walker’s Silicone Grease, for operating temperatures from –50°C to +200°C. 8

G

James Walker’s Copper Anti-Seize Compound or Nickel Anti-Seize Compound for operating temperatures above +200°C.

Exceptions: DO NOT use mineral-based oil or grease, such as our Molyon and Anti-Seize Compounds, on seals made from natural rubber (NR), butyl (IIR) or ethylene-propylene (EPM/EPDM). Likewise, DO NOT use silicone oil or grease on seals made from silicone (VMQ) compounds.

All ‘O’ rings precision-moulded by James Walker are supplied with surface texture to Grade N of BS6442/ISO 3601-3 Limits of surface imperfections on elastomeric toroidal sealing rings (‘O’ rings), with the higher Grade S provided if required. Our Commercial ‘O’ rings (page 6) and items in our ‘O’ Ring Kits (page 29) do not necessarily comply with Grade N surface texture. Please consult our Technical Services Team if surface texture is important for your specific application.

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

Materials and properties

Explosive decompression Although explosive decompression (ED) is a phenomenon generally found in the oil and gas industry, it can be experienced in any application where there is a rapid drop in gas pressure. ED damage has been noted in sealing applications ranging from paint guns and fire extinguishers to marine stern gland seals and systems containing refrigerants.

Explosive decompression damage is structural failure in the forms of blistering, internal cracking and splits caused when the gas pressure, to which the seal is exposed, is rapidly reduced from high to low. The elastomeric components of a system are, to a greater or lesser extent, susceptible to the permeation and diffusion of gases dissolving in their surface. With time, these components will become saturated with whatever gases are in the system. Under these conditions – as long as the internal gas pressure of the elastomer remains at equilibrium with the ambient pressure – there is minimal damage, if any, and no deterioration in performance of the elastomeric component occurs (unless caused by other factors such as chemical or thermal degradation or by extrusion damage). When the external gas pressure is removed or pressure fluctuations occur, large pressure gradients are created between the interior and the surface of the elastomeric component. This pressure differential may be balanced by the gas simply diffusing/ permeating out of the elastomer, especially if any external constraints are not removed. However, if the physical properties of the elastomeric compound cannot resist crack and blister growth during the permeation process, then structural failure is the inevitable result.

‘O’ rings after explosive decompression.

Explosive decompression damage can manifest itself in various ways – anything from internal splits that are not visible on the surface of the seal to surface blisters, fractures and complete fragmentation.

In order to overcome many of the problems associated with high pressure gas systems, we have conducted intensive materials development programmes over the last 20 years. Much of this work was carried out in collaboration with equipment manufacturers, major oil and gas operators, and research bodies. We offer five standard grades of ED resistant elastomer, all of which have been extensively validated in-house.They are tested, approved and specified by oilfield operators and equipment manufacturers alike. The formulation, mixing, quality control and processing of these compounds is rigorously controlled and today they are rated by many as the benchmarks by which all others are judged. Although each of these compounds has a broad range of application capability, their particular features are as follows: G

FR58/90 – A fluoroelastomer (FKM) with excellent chemical and thermal properties, plus ED resistance in hydrocarbon applications. It is approved and specified by many oil producers and equipment manufacturers.

G

FR25/90 – This fluoroelastomer (FKM) combines an improved low temperature capability with excellent thermal and chemical properties. It is ED resistant in hydrocarbon applications.

G

Elast-O-Lion 101 – An hydrogenated nitrile (HNBR) grade with high mechanical strength and wear resistant properties. It has good resistance to many oilfield chemicals including H2S and amine corrosion inhibitors. It is resistant to explosive decompression and is approved to many ED specifications.

G

Elast-O-Lion 985 – This hydrogenated nitrile (HNBR) grade offers improved low temperature capacity, but with reduced mechanical properties and ED resistance compared to Elast-O-Lion 101.

G

AF69/90 – An Aflas® (TFE/P) based ED resistant grade with excellent resistance to oilfield media and steam.

James Walker’s eight-flange explosive decompression test rigs.

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

9

Materials and properties

FEP encapsulated ‘O’ rings

levels of chemical resistance and/or hygiene are required.

FEP encapsulated ‘O’ rings have a core of elastomer that is completely covered with a seamless sheath of FEP fluoropolymer. The elastomeric core is normally either fluorocarbon or silicone.

Although FEP encapsulated ‘O’ rings are most suited to static duties, they may be used with slow, short movements on rotary applications such as valve stem sealing.

An encapsulated ‘O’ ring is generally used when: G

G

A standard elastomer ‘O’ ring has inadequate chemical resistance for a particular application, and A solid PTFE ‘O’ ring does not offer sufficient elasticity for reliable, longterm fluid sealing.

Their advantages are manifold, including: G

G

G

They are typically used in the chemical, petrochemical, food and pharmaceutical industries and other sectors where high

G G

Excellent chemical resistance to a wide range of media – please consult our Technical Services Team for further advice. Operational temperature ranges of –60°C to +200°C with silicone core, –20°C to +200°C with fluorocarbon core. Low friction and low ‘stick-slip’ effect. Can be used with food, pharmaceutical and medical products. Far better elasticity than solid PTFE.

Our FEP encapsulated ‘O’ rings are fully interchangeable with standard elastomeric ‘O’ rings. However, due to the FEP sheath, they are less flexible than normal elastomeric ‘O’ rings and have limited stretch with higher permanent deformation. Auxiliary tools may be needed to facilitate efficient fitting.

Back-up rings Back-up rings are installed to prevent extrusion of the ‘O’ ring. These are manufactured from PTFE, PEEK™, and filled PTFE.

Groove length 1 back-up

Groove length 2 back-ups

They are normally recommended for applications where: G G G

Pressure of the fluid medium exceeds 100bar, or ‘O’ rings of low strength elastomer are used, or Adverse mechanical conditions prevail.

Please consult our Technical Services Team if fluid pressure is likely to exceed 420bar.

Direction of pressure

Pressure from either direction

Figure 2: Typical back-up ring installations

Figure 3: Spiral back-up ring

Two back-up rings – one either side of the ‘O’ ring in its housing – are needed when the application is double acting. Back-up rings are normally supplied as a spiral of two turns. This enables the back-up ring to be opened with ease for fitting over a shaft, and ensures the ‘O’ ring is ed around its entire diameter. Single turn back-up rings can also be supplied and these are usually endless to 10

Figure 4: Typical housings (see pages 24-28)

ensure good . However, they can be scarf split if required, although we do not recommend this because extrusion can occur at the split.

Smaller sizes of back-up ring are available only as a single turn. This is because spiral back-up rings need an inside diameter greater than 3mm for machining purposes.

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

Chart 50: Inch and metric sizes

To order your Chart 50 ‘O’ ring or back-up ring, see page 5. For housing details refer to pages 24-28. Our Chart 50 reflects the standards in many countries, particularly those of the UK and USA. Despite UK metrification, inch sizes to BS1806 are still very popular. Reference numbers highlighted in red indicate those sizes covered by: G

BS1806: Dimensions of toroidal sealing rings (‘O’ rings) and their housings (inch sizes), and SAE AS568A: American National Standard Aerospace size standard for ‘O’ rings.

James Walker Number

INCH DIAMETERS METRIC DIAMETERS (mm) Inside Inside Shaft Cyl. Dia. B C, P, T D, Q Dia. B C D

0.070 ±0.003” (1.78 ±0.08mm) Diameter Section A 50-008* " 802* " 009* " 010* " 803*

0.176 ±0.005 0.188 " 0.208 " 0.239 " 0.250 "

3/ 16

5/16

13/64

21/64

7/32

11/32

1/4

3/8

17/64

25/64

9/32

13/32

5/16

7/16

21/64

29/64

11/32

15/32

3/8

1/2

" " " " "

610* 011* 804* 611* 012*

0.266 0.301 0.313 0.344 0.364

Although the basic range is in inches, the ‘O’ rings can of course be used for sealing metric dimensioned components. The tables below include suggested metric shaft and cylinder sizes for which each individual ‘O’ ring is suitable. (Note: These figures are NOT merely direct metric conversions of inch sizes. Separate ranges of back-up rings are available for metric shafts and cylinders – see page 5 for ordering references.)

" " " " "

013 806 014 015 016

0.426 " 0.438 " 0.489 " 0.551 ±0.007 0.614 ±0.009

7/16

9/16

29/64

37/64

1/2

5/8

9/16

11/16

5/8

3/4

" " " " "

017 018 019 020 021

0.676 0.739 0.801 0.864 0.926

11/16

13/16

* An asterisk symbol denotes that the ring is suitable for both dynamic and static applications. Other sizes are not recommended for dynamic duties.

3/4

7/8

" " " " "

022 023 024 025 026

" " " " "

G

8 8.5 9 9.5 9.8

6.75 7.65 7.94 8.73 9.25

7 7.5 8 9 9.5

10 11 11.5 12 12.5

10.82 " 11.11 " 12.42 " 14.00 ±0.18 15.60 ±0.23

11 11.5 12.5 14 15.5

14.2 14.5 16 17.5 19

17 19 20 22 23

20.5 22.5 24 25.5 27

" " " " "

13/16

15/16

7/8

1 11/16

0.989 ±0.010 1 1.051 " 11/16 1.114 " 11/8 1.176 ±0.011 13/16 1.239 " 11/4

11/8 13/16 11/4 15/16 13/8

25.12 ±0.25 26.70 " 28.30 " 29.87 ±0.28 31.47 "

25 27 28 30 31

29 30 32 34 35

027 028 517 029 519

1.301 " 15/16 1.364 ±0.013 13/8 1.428 " 17/16 1.489 " 11/2 1.553 " 19/16

17/16 11/2 19/16 15/8 111/16

33.05 " 34.65 ±0.33 36.27 " 37.82 " 39.45 "

32 35 36 38 39

37 38 40 42 43

" " " " "

030 031 032 033 034

1.614 " 15/8 1.739 ±0.015 13/4 1.864 " 17/8 1.989 ±0.018 2 2.114 " 21/8

13/4 17/8 2 21/8 21/4

41.00 " 44.17 ±0.38 47.35 " 50.52 ±0.46 53.70 "

40 44 47 50 53

45 48 51 55 58

4.1

" " " " "

035 036 037 038 039

2.239 " 21/4 2.364 " 23/8 2.489 " 21/2 2.614 ±0.020 25/8 2.739 " 23/4

23/8 21/2 25/8 23/4 27/8

56.87 " 60.05 " 63.22 " 66.40 ±0.51 69.57 "

56 60 63 65 69

61 65 67 70 75

5 6 6.2 6.5 7

" " " "

040 041 532 042

2.864 " 27/8 2.989 ±0.024 3 3.110 " 31/8 3.239 " 31/4

3 31/8 31/4 33/8

72.75 " 75.92 ±0.61 78.99 " 82.27 "

70 75 78 80

77 80 85 88

A

INCH DIAMETERS METRIC DIAMETERS (mm) Inside Inside Shaft Cyl. Dia. B C, P, T D, Q Dia. B C D

" " " " "

4.5 5 5.5 6 6.5

17.17 18.77 20.35 21.95 23.52

B

James Walker Number

" " " " "

4.47 ±0.13 4.76 " 5.28 " 6.07 " 6.35 "

15/16

" " " " "

0.040 ±0.003” (1.02 ±0.08mm) Diameter Section A 50-001 " 606 " 607

0.029 ±0.004 0.070 ±0.005 0.100 "

1/32

3/32

5/64

9/64

7/64

11/64

0.74 ±0.10 1.78 ±0.13 2.54 "

0.8 2 2.8

2.5 3.6 4.5

0.050 ±0.003” (1.27 ±0.08mm) Diameter Section A 50-002

0.042 ±0.004

3/64

0.130

1.70 ±0.10

1.2

3.3

0.060 ±0.003” (1.52 ±0.08mm) Diameter Section A 50-003

0.056 ±0.004

1/16

11/64

1.42 ±0.10

1.5

0.070 ±0.003” (1.78 ±0.08mm) Diameter Section A 50-004* " 005* " 006* " 801* " 007*

0.070 ±0.005 0.101 " 0.114 " 0.125 " 0.145 "

5/64

13/64

7/64

15/64

1/8

1/4

9/64

17/64

5/32

9/32

1.78 ±0.13 2.57 " 2.90 " 3.18 " 3.68 "

2 2.8 3 3.5 4

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

11

Chart 50: Inch and metric sizes

James Walker Number

INCH DIAMETERS METRIC DIAMETERS (mm) Inside Inside Shaft Cyl. Dia. B C, P, T D, Q Dia. B C D

0.070 ±0.003” (1.78 ±0.08mm) Diameter Section A 50-534 " 043 " 536 " 044 " 538

James Walker Number

INCH DIAMETERS METRIC DIAMETERS (mm) Inside Inside Shaft Cyl. Dia. B C, P, T D, Q Dia. B C D

0.103 ±0.003” (2.62 ±0.08mm) Diameter Section A

3.360 ±0.024 33/8 3.489 " 31/2 3.610 ±0.027 35/8 3.739 " 33/4 3.860 " 37/8

31/2 35/8 33/4 37/8 4

85.34 ±0.61 88.62 " 91.69 ±0.69 94.97 " 98.04 "

85 88 90 95 98

90 95 98 100 102

50-615* " 113* " 616* " 114* " 809*

0.516 ±0.007 0.549 " 0.594 " 0.612 ±0.009 0.625 "

33/64

45/64

9/16

3/4

19/32

25/32

5/8

13/16

41/64

53/64

" " " " "

045 540 046 542 047

3.989 " 4 4.110 " 41/8 4.239 ±0.030 41/4 4.360 " 43/8 4.489 " 41/2

41/8 41/4 43/8 41/2 45/8

101.32 " 104.39 " 107.67 ±0.76 110.74 " 114.02 "

100 104 107 110 114

105 110 112 115 120

" " " " "

115* 810* 617* 116* 117

0.674 " 0.688 " 0.703 " 0.737 " 0.799 ±0.010

11/16

7/8

45/64

57/64

23/32

29/32

" " " " "

544 048 546 049 548

4.610 " 45/8 4.739 " 43/4 4.860 ±0.037 47/8 4.989 " 5 5.095 " 51/8

43/4 47/8 5 51/8 51/4

117.09 " 120.37 " 123.44 ±0.94 126.72 " 129.41 "

116 120 123 125 130

122 125 130 132 135

" " " " "

812 118 813 119 814

0.813 0.862 0.875 0.924 0.938

" " " " "

050 550 551 552 553

5.239 5.345 5.470 5.595 5.720

51/4 53/8 51/2 55/8 53/4

53/8 51/2 55/8 53/4 57/8

133.07 135.76 138.94 142.11 145.29

132 135 138 140 145

138 140 145 148 150

" " " " "

120 121 122 123 124

0.987 " 1 1.049 " 11/16 1.112 " 11/8 1.174 ±0.012 13/16 1.237 " 11/4

" " " " "

554 555 556 557 558

5.845 " 57/8 5.970 " 6 6.095 ±0.040 61/8 6.220 " 61/4 6.345 " 63/8

6 61/8 61/4 63/8 61/2

148.46 " 151.64 " 154.81 ±1.02 157.99 " 161.16 "

148 150 155 158 160

155 158 160 162 165

" " " " "

125 126 127 128 129

1.299 " 1.362 " 1.424 " 1.487 " 1.549 ±0.015

" " " "

559 560 561 562

6.470 6.595 6.720 6.845

61/2 65/8 63/4 67/8

65/8 63/4 67/8 7

164.34 167.51 170.69 173.86

165 167 170 174

170 172 175 180

" " " " "

130 131 132 133 134

1.5 2.3 3 4 4.5

6 7 7.5 8.5 9.5

" " " " "

5.5 6 7.5 9.5 10

10 11 12.5 14 15

11 11.5 12 12.5

16 17 17.5 17.8

" " " " "

" " " "

" " " " "

" " " "

13.10 ±0.18 13.94 " 15.08 " 15.54 ±0.23 15.88 "

13 14 15 15.5 16

18 19 20 20.5 21

17 17.5 18 19 20

22 22.5 23 24 25.5

20.5 21 22 23 23.5

26 27 27.5 28.5 29

3/4

15/16

13/16

1

17.12 " 17.46 " 17.86 " 18.72 " 20.29 ±0.25

53/64

11/64 11/16 15/64 11/8 19/64

20.64 21.89 22.23 23.47 23.81

13/16 11/4 15/16 13/8 17/16

25.07 " 26.64 " 28.24 " 29.82 ±0.30 31.42 "

25 27 28 30 31

30 32 34 35 37

15/16 13/8 17/16 11/2 19/16

11/2 19/16 15/8 111/16 13/4

32.99 " 34.59 " 36.17 " 37.77 " 39.34 ±0.38

32 35 36 38 39

38 40 42 43 45

1.612 " 1.674 " 1.737 " 1.799 " 1.862 ±0.017

15/8 111/16 13/4 113/16 17/8

113/16 17/8 115/16 2 21/16

40.94 " 42.52 " 44.12 " 45.69 " 47.29 ±0.43

40 42 44 45 47

47 48 50 51 53

135 136 137 138 139

1.925 1.987 2.050 2.112 2.175

115/16 2 21/16 21/8 23/16

21/8 23/16 21/4 25/16 23/8

48.90 50.47 52.07 53.64 55.25

48 50 52 53 55

55 56 58 60 61

" " " " "

140 141 142 143 144

2.237 " 21/4 2.300 ±0.020 25/16 2.362 " 23/8 2.425 " 27/16 2.487 " 21/2

27/16 21/2 29/16 25/8 211/16

56.82 " 58.42 ±0.51 59.99 " 61.60 " 63.17 "

56 58 60 61 63

62 65 66 67 69

" " " "

145 146 147 148

2.550 " 29/16 2.612 " 25/8 2.675 ±0.022 211/16 2.737 " 23/4

23/4 213/16 27/8 215/16

64.77 " 66.34 " 67.95 ±0.56 69.52 "

65 66 68 69

70 72 74 75

" " " " "

7/8 57/64 15/16 61/64

" " " " "

0.103 ±0.003” (2.62 ±0.08mm) Diameter Section A 50-102* " 103* " 104* " 105* " 106*

0.049 ±0.005 0.081 " 0.112 " 0.143 " 0.174 "

1/16

1/4

3/32

9/32

1/8

5/16

5/32

11/32

3/16

3/8

7/32

13/32

1/4

7/16

5/16

1/2

3/8

9/16

13/32

19/32

" " " " "

107* 108* 109* 110* 613*

0.206 0.237 0.299 0.362 0.391

" " " "

111* 614* 112* 807*

7/16 0.424 " 15/32 0.469 " 1/2 0.487 " 0.500 ±0.007 -

12

" " " " "

5/8 21/32 11/16

-

1.24 ±0.13 2.06 " 2.84 " 3.63 " 4.42 " 5.23 6.02 7.59 9.19 9.92

" " " " "

10.77 " 11.91 " 12.37 " 12.70 ±0.18

" " " " "

" " " " "

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

Chart 50: Inch and metric sizes

James Walker Number

INCH DIAMETERS METRIC DIAMETERS (mm) Inside Inside Shaft Cyl. Dia. B C, P, T D, Q Dia. B C D

0.103 ±0.003” (2.62 ±0.08mm) Diameter Section A 50-149 " 150 " 640 " 151 " 641

2.800 ±0.022 213/16 2.862 " 27/8 2.924 ±0.024 215/16 2.987 " 3 3.049 " 31/16 33/16 31/4 35/16 31/2 33/4

James Walker Number

INCH DIAMETERS METRIC DIAMETERS (mm) Inside Inside Shaft Cyl. Dia. B C, P, T D, Q Dia. B C D

0.139 ±0.004” (3.53 ±0.10mm) Diameter Section A

3 31/16 31/8 33/16 31/4

71.12 ±0.56 72.69 " 74.27 ±0.61 75.87 " 77.44 "

70 72 74 75 77

77 78 80 82 85

33/8 37/16 31/2 311/16 315/16

80.62 " 82.22 " 83.79 " 88.57 " 94.92 ±0.71

80 82 84 88 95

87 88 90 95 100

" " " " "

0.171 ±0.005 0.234 " 0.296 " 0.359 " 0.421 "

3/16

7/16

1/4

1/2

5/16

9/16

3/8

5/8

7/16

11/16

206* 207* 208* 209* 210*

0.484 " 0.546 ±0.007 0.609 ±0.009 0.671 " 0.734 ±0.010

1/2

3/4

9/16

13/16

5/8

7/8

11/16

15/16

3/4

13/16

50-201* " 202* " 203* " 204* " 205*

4.34 ±0.13 5.94 " 7.52 " 9.12 " 10.69 "

4.5 6 7.5 9.5 11

11 12.5 14 16 17.5

1

12.29 " 13.87 ±0.18 15.47 ±0.23 17.04 " 18.64 ±0.25

12.5 14 15.5 17 19

19 20.5 22 24 25

20.22 21.82 23.39 24.99 25.80

20 22 23 25 26

28 29 30 32 33

" " " " "

642 152 643 153 154

3.174 " 3.237 " 3.299 " 3.487 " 3.737 ±0.028

" " " " "

155 156 157 158 159

3.987 " 4 4.237 ±0.030 41/4 4.487 " 41/2 4.737 " 43/4 4.987 ±0.035 5

43/16 47/16 411/16 415/16 53/16

101.27 " 107.62 ±0.76 113.97 " 120.32 " 126.67 ±0.89

100 107 114 120 125

110 115 120 130 135

" " " " "

211* 212* 213* 214* 618*

0.796 0.859 0.921 0.984 1.016

1 11/32

11/16 11/8 13/16 11/4 19/32

" " " " "

160 161 162 163 164

5.237 " 5.487 " 5.737 " 5.987 " 6.237 ±0.040

51/4 51/2 53/4 6 61/4

57/16 511/16 515/16 63/16 67/16

133.02 " 139.37 " 145.72 " 152.07 " 158.42 ±1.02

132 138 145 150 158

140 145 155 160 165

" " " " "

215* 216* 217* 218* 219*

1.046 " 11/16 1.019 ±0.012 11/8 1.171 " 13/16 1.234 " 11/4 1.296 " 15/16

15/16 13/8 17/16 11/2 19/16

26.57 " 28.17 ±0.30 29.74 " 31.34 " 32.92 "

27 28 30 31 32

34 35 36 38 40

" " " " "

165 166 167 168 169

6.487 " 61/2 6.737 " 63/4 6.987 " 7 7.237 ±0.045 71/4 7.487 " 71/2

611/16 615/16 73/16 77/16 711/16

164.77 " 171.12 " 177.47 " 183.82 ±1.14 190.17 "

165 170 177 183 190

170 180 185 190 200

" " " " "

220* 221* 222* 824 223

1.359 " 13/8 1.421 " 17/16 1.484 ±0.015 11/2 1.563 " 19/16 1.609 " 15/8

15/8 111/16 13/4 113/16 17/8

34.52 " 36.09 " 37.69 ±0.38 39.69 " 40.87 "

35 36 38 39 40

42 43 45 47 48

" " " " "

170 171 172 173 174

7.737 " 73/4 7.987 " 8 8.237 ±0.050 81/4 8.487 " 81/2 8.737 " 83/4

715/16 83/16 87/16 811/16 815/16

196.52 " 202.87 " 209.22 ±1.27 215.57 " 221.92 "

195 200 208 215 220

205 210 215 225 230

" " " " "

825 826 224 827 828

1.625 1.688 1.734 1.750 1.813

115/16 2 21/16

41.28 42.86 44.04 44.45 46.04

41 42 43 44 45

49 50 51 52 53

" " " "

175 176 177 178

8.987 " 9 9.237 ±0.055 91/4 9.487 " 91/2 9.737 " 93/4

93/16 97/16 911/16 915/16

228.27 " 234.62 ±1.40 240.97 " 247.32 "

225 235 240 245

235 240 250 255

" " " " "

225 829 830 226 831

1.859 ±0.018 17/8 1.875 " 1.938 " 115/16 1.984 " 2 2.000 " -

21/8 23/16 21/4 -

47.22 ±0.46 47.63 " 49.21 " 50.39 " 50.80 "

46 47 48 49 50

54 55 56 58 59

" " " " "

832 227 833 834 228

2.063 " 2.109 " 2.125 " 2.188 " 2.234 ±0.020

21/16 21/8 23/16 21/4

25/16 23/8 27/16 21/2

52.39 " 53.57 " 53.98 " 55.56 " 56.74 ±0.51

52 53 54 55 56

60 61 62 63 64

" " " "

835 836 229 837

2.250 2.313 2.359 2.375

25/16 23/8 -

29/16 25/8 -

57.15 58.74 59.92 60.33

57 58 59 60

65 66 67 68

" " " " "

" " " " "

" " " "

7/8 15/16

111/16 13/4 113/16

" " " " "

" " " " "

" " " "

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

13

Chart 50: Inch and metric sizes

James Walker Number

INCH DIAMETERS METRIC DIAMETERS (mm) Inside Inside Shaft Cyl. Dia. B C, P, T D, Q Dia. B C D

0.139 ±0.004” (3.53 ±0.10mm) Diameter Section A 50-838 " 230 " 839 " 840 " 231

James Walker Number

INCH DIAMETERS METRIC DIAMETERS (mm) Inside Inside Shaft Cyl. Dia. B C, P, T D, Q Dia. B C D

0.139 ±0.004” (3.53 ±0.10mm) Diameter Section A

2.438 ±0.020 27/16 2.484 " 21/2 2.500 " 2.563 " 29/16 2.609 " 25/8

211/16 23/4 213/16 27/8

61.91 ±0.51 " 63.09 63.50 " 65.09 " 66.27 "

61 62 63 64 65

69 70 71 72 73

5.109 ±0.035 5.234 " 5.359 " 5.484 " 5.609 "

51/8 51/4 53/8 51/2 55/8

53/8 51/2 55/8 53/4 57/8

129.77 ±0.89 " 132.94 136.12 " 139.29 " 142.47 "

130 132 135 138 140

138 140 145 148 150

215/16 3 31/16

66.68 " 68.26 " 69.44 ±0.61 69.85 " 71.44 "

66 67 68 69 70

74 75 76 77 79

" " " " "

256 257 258 259 260

5.734 " 5.859 " 5.984 " 6.234 ±0.040 6.484 "

53/4 57/8 6 61/4 61/2

6 61/8 61/4 61/2 63/4

145.64 " 148.82 " 151.99 " 158.34 ±1.02 164.69 "

145 148 150 158 165

155 158 160 170 175

31/8 33/16 31/4 33/8

72.62 73.03 74.61 75.79 78.97

71 72 74 75 78

80 81 82 85 88

" " " " "

261 262 263 264 265

6.734 " 6.984 " 7.234 ±0.045 7.484 " 7.734 "

63/4 7 71/4 71/2 73/4

7 71/4 71/2 73/4 8

171.04 " 177.39 " 183.74 ±1.14 190.09 " 196.44 "

170 177 183 190 195

180 185 195 200 205

7.984 " 8.234 ±0.050 8.484 " 8.734 " 8.984 "

8 81/4 81/2 83/4 9

81/4 81/2 83/4 9 91/4

202.79 " 209.14 ±1.27 215.49 " 221.84 " 228.19 "

200 208 215 220 225

210 220 225 230 235

50-251 " 252 " 253 " 254 " 255

" " " " "

841 842 232 843 844

2.625 " 2.688 " 211/16 2.734 ±0.024 23/4 2.750 " 2.813 " 213/16

" " " " "

233 845 846 234 235

2.859 2.875 2.938 2.984 3.109

" " " " "

236 237 238 239 240

3.234 " 31/4 3.359 " 33/8 3.484 " 31/2 3.609 ±0.028 35/8 3.734 " 33/4

31/2 35/8 33/4 37/8 4

82.14 " 85.32 " 88.49 " 91.67 ±0.71 94.84 "

80 85 88 90 95

90 95 98 100 102

" " " " "

266 267 268 269 270

" " " " "

241 242 243 244 245

3.859 " 37/8 3.984 " 4 4.109 " 41/8 4.234 ±0.030 41/4 4.359 " 43/8

41/8 41/4 43/8 41/2 45/8

98.02 " 101.19 " 104.37 " 107.54 ±0.76 110.72 "

98 100 104 107 110

105 110 112 115 120

" " " " "

271 272 273 274 275

9.234 ±0.055 91/4 9.484 " 91/2 9.734 " 93/4 9.984 " 10 10.484 " 101/2

91/2 93/4 10 101/4 103/4

234.54 ±1.40 240.89 " 247.24 " 253.59 " 266.29 "

235 240 245 250 265

245 250 255 265 275

" " " " "

246 247 248 249 250

4.484 " 41/2 4.609 " 45/8 4.734 " 43/4 4.859 ±0.035 47/8 4.984 " 5

43/4 47/8 5 51/8 51/4

113.89 " 117.07 " 120.24 " 123.42 ±0.89 126.59 "

114 116 120 123 125

122 125 130 132 135

" " " " "

276 277 278 279 280

10.984 ±0.065 11 11.484 " 111/2 11.984 " 12 12.984 " 13 13.984 " 14

111/4 113/4 121/4 131/4 141/4

278.99 ±1.65 291.69 " 304.39 " 329.79 " 355.19 "

275 290 300 330 350

290 300 315 340 365

" " " "

281 282 283 284

14.984 " 15 15.955 ±0.075 16 16.955 ±0.080 17 17.955 ±0.085 18

151/4 161/4 171/4 181/4

380.59 " 405.26 ±1.91 430.66 ±2.03 456.06 ±2.16

380 400 430 455

390 415 440 465

" " " " "

27/8 215/16 3 31/8

" " " " "

0.210 ±0.005” (5.33 ±0.13mm) Diameter Section A

14

50-309* " 310* " 311* " 312* " 313*

0.412 ±0.005 0.475 " 0.537 ±0.007 0.600 ±0.009 0.662 "

7/16

13/16

1/2

7/8

" 314* " 315*

0.725 ±0.010 0.787 "

3/4

9/16

15/16

5/8

1 11/16

10.46 ±0.13 12.07 " 13.64 ±0.18 15.24 ±0.23 16.81 "

13/8 13/16

18.42 ±0.25 19.99 "

11/16

13/16

11 12.5 14 15.5 17

20.5 22 23.5 25 27

19 20

28.5 30

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

Chart 50: Inch and metric sizes

James Walker Number

INCH DIAMETERS METRIC DIAMETERS (mm) Inside Inside Shaft Cyl. Dia. B C, P, T D, Q Dia. B C D

0.210 ±0.005” (5.33 ±0.13mm) Diameter Section A 50-338* " 620* " 339* " 340* " 341*

Coloured ‘O’ rings on a cartridge mechanical seal.

James Walker Number

INCH DIAMETERS METRIC DIAMETERS (mm) Inside Inside Shaft Cyl. Dia. B C, P, T D, Q Dia. B C D

0.210 ±0.005” (5.33 ±0.13mm) Diameter Section A 50-316* " 317* " 318* " 319* " 320*

0.850 ±0.010 7/8 15/16 0.912 " 0.975 " 1 1.037 " 11/16 1.100 ±0.012 11/8 13/16 11/4 15/16 13/8 11/2

11/4 15/16 13/8 17/16 11/2

21.59 ±0.25 23.16 " 24.77 " 26.34 " 27.94 ±0.30

22 23 25 27 28

31.5 33 35 36.5 38

19/16 15/8 111/16 13/4 17/8

29.51 " 31.12 " 32.69 " 34.29 " 37.47 ±0.38

30 31 32 35 38

40 42 43 45 48

" " " " "

321* 322* 323* 324* 325*

1.162 " 1.225 " 1.287 " 1.350 " 1.475 ±0.015

" " " " "

326* 327* 328* 329* 330*

1.600 " 15/8 1.725 " 13/4 1.850 " 17/8 1.975 ±0.018 2 2.100 " 21/8

2 21/8 21/4 23/4 21/2

40.64 " 43.82 " 46.99 " 50.17 ±0.46 53.34 "

40 42 45 50 52

52 55 58 62 65

" " " " "

331* 332* 333* 334* 335*

2.225 " 21/4 2.350 " 23/8 2.475 ±0.020 21/2 2.600 " 25/8 2.725 " 23/4

25/8 23/4 27/8 3 31/8

56.52 " 59.69 " 62.87 ±0.51 66.04 " 69.22 "

56 60 63 65 68

68 70 75 78 80

2.850 " 27/8 2.938 ±0.024 215/16 2.975 " 3

31/4 35/16 33/8

72.39 " 74.61 ±0.61 75.57 "

70 72 75

83 85 88

" 336* " 619* " 337*

3.100 ±0.024 31/8 3.141 " 3.225 " 31/4 3.350 " 33/8 3.475 " 31/2

31/2 35/8 33/4 37/8

78.74 ±0.61 79.78 " 81.92 " 85.09 " 88.27 "

78 80 82 85 88

90 92 95 98 100

" " " " "

621* 342* 343* 344* 622*

3.531 ±0.028 39/16 3.600 " 35/8 3.725 " 33/4 3.850 " 37/8 3.938 " 315/16

315/16 89.69 ±0.71 91.44 " 4 41/8 94.62 " 41/4 97.79 " 45/16 100.01 "

90 92 95 98 100

101 102 105 108 110

" " " " "

345* 346* 347* 623* 348*

3.975 " 4 4.100 " 41/8 4.225 ±0.030 41/4 4.313 " 45/16 4.350 " 43/8

43/8 41/2 45/8 411/16 43/4

100.97 " 104.14 " 107.32 ±0.76 109.54 " 110.49 "

101 104 107 109 110

112 115 118 120 121

" " " " "

349* 350 860 351 861

4.475 4.600 4.625 4.725 4.750

41/2 45/8 43/4 -

47/8 5 51/8 -

113.67 116.84 117.48 120.02 120.65

114 116 117 120 121

125 128 130 131 132

" " " " "

352 862 353 863 354

4.850 " 47/8 4.875 ±0.037 4.975 " 5 5.000 " 5.100 " 51/8

51/4 53/8 51/2

123.19 " 123.82 ±0.94 126.37 " 127.00 " 129.54 "

123 124 125 127 129

134 135 137 138 140

" " " " "

864 355 865 356 866

5.125 5.225 5.250 5.350 5.375

" " " " "

51/4 53/8 -

55/8 53/4 -

130.18 132.72 133.35 135.89 136.53

" " " " "

130 132 133 135 136

141 143 145 146 148

" " " " "

357 867 358 868 359

5.475 5.500 5.600 5.625 5.725

" " " " "

51/2 55/8 53/4

57/8 6 61/8

139.07 139.70 142.24 142.88 145.42

" " " " "

138 140 142 143 145

150 151 153 155 156

" " " " "

869 360 870 361 644

5.750 " 5.850 " 5.875 " 5.975 " 6.100 ±0.040

57/8 6 61/8

61/4 63/8 61/2

146.05 " 148.59 " 149.23 " 151.77 " 154.94 ±1.02

146 148 149 150 155

158 160 162 165 168

6.225 6.350

61/4 63/8

65/8 63/4

158.12 161.29

158 160

170 172

" 362 " 645

" " " " "

" "

" " " " "

" "

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

15

Chart 50: Inch and metric sizes

James Walker Number

B

INCH DIAMETERS METRIC DIAMETERS (mm) Inside Inside Shaft Cyl. Dia. B C, P, T D, Q Dia. B C D

A 0.275 ±0.006” (6.99 ±0.15mm) Diameter Section A

James Walker Number

INCH DIAMETERS METRIC DIAMETERS (mm) Inside Inside Shaft Cyl. Dia. B C, P, T D, Q Dia. B C D

0.210 ±0.005” (5.33 ±0.13mm) Diameter Section A 50-363 " 646 " 364 " 647 " 365 " " " " "

366 367 368 369 370

" " " " "

371 372 373 374 375

" " " " "

376 377 378 379 380

6.475 ±0.040 6.600 " 6.725 " 6.850 " 6.975 "

1/2

6 65/8 63/4 67/8 7

7/8

6 7 71/8 71/4 73/8

164.47 ±1.02 167.64 " 170.82 " 173.99 " 177.17 "

165 167 170 174 177

175 180 182 185 190

7.225 ±0.045 7.475 " 7.275 " 7.975 " 8.225 ±0.050

71/4 71/2 73/4 8 81/4

75/8 77/8 81/8 83/8 85/8

183.52 ±1.14 189.87 " 196.22 " 202.57 " 208.92 ±1.27

183 190 195 200 208

195 200 210 215 220

8.475 " 8.725 " 8.975 " 9.225 ±0.055 9.475 "

1/2

8 83/4 9 91/4 91/2

7/8

8 91/8 93/8 95/8 97/8

215.27 " 221.62 " 227.97 " 234.32 ±1.40 240.67 "

215 220 225 235 240

230 235 240 245 255

9.725 " 93/4 9.975 " 10 10.475 ±0.060 101/2 10.975 " 11 11.475 ±0.065 111/2

101/8 103/8 107/8 113/8 117/8

247.02 " 253.37 " 266.07 ±1.52 278.77 " 291.47 ±1.65

245 250 265 275 290

260 265 280 290 305

3/8

" " " " "

381 382 383 384 385

11.975 " 12 12.975 " 13 13.975 ±0.070 14 14.975 " 15 15.955 ±0.075 16

12 133/8 143/8 153/8 163/8

304.17 " 329.57 " 354.97 ±1.78 380.37 " 405.26 ±1.91

300 330 350 380 400

315 340 370 395 420

" " " " "

386 387 388 389 390

16.955 17.955 18.955 19.955 20.955

17 18 19 20 21

173/8 183/8 193/8 203/8 213/8

430.66 456.06 481.46 506.86 532.26

430 455 480 505 530

445 470 500 525 550

22 23 24 25 26

3/8

" " " " "

391 392 393 394 395

21.955 22.940 23.940 24.940 25.940

±0.080 ±0.085 ±0.090 ±0.095 " ±0.100 ±0.105 ±0.110 ±0.115 ±0.120

22 233/8 243/8 253/8 263/8

557.66 582.68 608.08 633.48 658.88

±2.03 ±2.16 ±2.29 ±2.41 " ±2.54 ±2.67 ±2.79 ±2.92 ±3.05

555 580 605 630 655

575 600 625 650 675

0.275 ±0.006” (6.99 ±0.15mm) Diameter Section A 41/2 49/16

5 113.67 ±0.84 51/16 114.70 "

114 115

127 128

50-426* " 427* " 428* " 625* " 429*

4.600 ±0.033 4.725 " 4.850 " 4.906 ±0.037 4.975 "

45/8 43/4 47/8 415/16 5

51/8 51/4 53/8 57/16 51/2

51/8 51/4 55/16 53/8 51/2

55/8 129.54 53/4 132.72 513/16 134.54 57/8 135.89 6 139.07

" " " " "

116.84 ±0.84 " 120.02 123.19 " 124.62 ±0.94 126.37 "

130 135 137 138 140

130 132 135 136 140

145 147 148 150 155

142 145 148 150 155

158 160 162 165 170

158 160 162 165 166

172 175 178 180 181

" " " " "

430* 431* 626* 432* 433*

5.100 5.225 5.297 5.350 5.475

" " " " "

434* 435* 436* 437* 872*

5.600 " 5.725 " 5.850 " 5.975 " 6.125 ±0.040

55/8 53/4 57/8 6 61/8

61/8 61/4 63/8 61/2 65/8

" " " " "

438* 627* 874* 439* 628*

6.225 6.281 6.375 6.475 6.563

61/4 65/16 63/8 61/2 69/16

63/4 158.12 613/16 159.54 67/8 161.93 7 164.47 71/16 166.69

" " " " "

876* 440* 878* 441* 880*

6.625 " 6.725 " 6.875 " 6.975 " 7.125 ±0.045

65/8 63/4 67/8 7 71/8

71/8 71/4 73/8 71/2 75/8

168.28 " 170.82 " 174.63 " 177.17 " 180.98 ±1.14

168 170 175 177 180

182 185 190 192 195

" " " " "

442* 882* 443* 884* 444*

7.225 7.375 7.475 7.625 7.725

71/4 73/8 71/2 75/8 73/4

73/4 77/8 8 81/8 81/4

183.52 187.33 189.87 193.68 196.22

183 187 190 193 195

200 202 205 208 210

" " " " "

886* 445* 445A 446 446A

7.875 " 7.975 " 8.225 ±0.055 8.475 " 8.725 "

77/8 8 81/4 81/2 83/4

83/8 81/2 83/4 9 91/4

200.03 " 202.57 " 208.92 ±1.40 215.27 " 221.62 "

200 202 208 215 220

215 220 225 230 240

" " " " "

447 447A 448 448A 449

8.975 9.225 9.475 9.725 9.975

9 91/4 91/2 93/4 10

91/2 93/4 10 101/4 101/2

227.97 234.32 240.67 247.02 253.37

225 235 240 245 250

245 250 260 265 270

" " " "

449A 450 450A 451

10.225 ±0.060 101/4 10.475 " 101/2 10.725 " 103/4 10.975 " 11

103/4 11 111/4 111/2

259.72 ±1.52 266.07 " 272.42 " 278.77 "

260 265 270 275

275 280 290 295

" " " " "

" " " " "

" " " " "

" " " " "

116 120 123 125 126

142.24 " 145.42 " 148.59 " 151.77 " 155.58 ±1.02 " " " " "

" " " " "

" " " " "

50-425* " 624*

4.475 ±0.033 4.516 "

16

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

Chart 50: Inch and metric sizes

James Walker Number

INCH DIAMETERS METRIC DIAMETERS (mm) Inside Inside Shaft Cyl. Dia. B C, P, T D, Q Dia. B C D

0.275 ±0.006” (6.99 ±0.15mm) Diameter Section A 50-451A " 452 " 452A " 453 " 648

11.225 ±0.060 111/4 11.475 " 111/2 11.725 " 113/4 11.975 " 12 12.225 " 121/4

113/4 12 121/4 121/2 123/4

285.12 ±1.52 291.47 " 297.82 " 304.17 " 310.52 "

285 290 295 300 310

300 310 315 320 325

" " " " "

454 649 455 650 456

12.475 " 121/2 12.725 " 123/4 12.975 " 13 13.225 ±0.070 131/4 13.475 " 131/2

13 131/4 131/2 133/4 14

316.87 " 323.22 " 329.57 " 335.92 ±1.78 342.27 "

315 320 330 335 340

330 340 345 350 360

" " " " "

457 458 459 460 461

13.975 " 14.475 " 14.975 " 15.475 " 15.955 ±0.075

14 141/2 15 151/2 16

141/2 15 151/2 16 161/2

354.97 " 367.67 " 380.37 " 393.07 " 405.26 ±1.91

350 365 380 390 400

370 385 400 410 420

" " " " "

462 463 464 465 466

16.455 " 161/2 16.955 ±0.080 17 17.455 ±0.085 171/2 17.955 " 18 18.455 " 181/2

17 171/2 18 181/2 19

417.96 " 430.66 ±2.03 443.36 ±2.16 456.06 " 468.76 "

415 430 440 455 465

435 450 460 470 485

" " " " "

467 468 469 470 471

18.955 ±0.090 19 19.455 " 191/2 19.955 ±0.095 20 20.955 " 21 21.955 ±0.100 22

191/2 20 201/2 211/2 221/2

481.46 ±2.29 494.16 " 506.86 ±2.41 532.26 " 557.66 ±2.54

480 495 505 530 555

500 510 525 550 575

" " " "

472 473 474 475

22.940 23.940 24.940 25.940

231/2 241/2 251/2 261/2

582.68 608.08 633.48 658.88

580 605 630 655

600 625 650 675

±0.105 ±0.110 ±0.115 ±0.120

23 24 25 26

±2.67 ±2.79 ±2.92 ±3.05

‘O’ rings for pipe fittings The chart below gives details of ‘O’ rings for use with inch Unified Standard threads. The sizes are specified in SAE AS 568 A: American National Standard Aerospace size standard for ‘O’ rings. James INCH SIZES METRIC CONVERSIONS (mm) Walker Diameter Inside Diameter Inside Number Section A Diameter B Section A Diameter B

50-901 " 902 " 903 " 904 " 905

0.056±0.033 0.064 " 0.064 " 0.072 " 0.072 "

0.185±0.005 0.239 " 0.301 " 0.351 " 0.414 "

1.42 ±0.08 4.70 ±0.13 1.63 " 6.07 " 1.63 " 7.65 " 1.83 " 8.92 " 1.83 " 10.52 "

0.468 " 0.530±0.007 0.644±0.009 0.706 " 0.755 "

1.98 2.08 2.21 2.46 2.46

" " " " "

906 907 908 909 910

0.078 0.082 0.087 0.097 0.097

" " " " "

" " " " "

911 912 913 914 916

0.116±0.004 0.116 " 0.116 " 0.116 " 0.116 "

0.863 " 0.924 " 0.986±0.010 1.047 " 1.171 "

2.95 ±0.10 21.92 " 2.95 " 23.47 " 2.95 " 25.04 ±0.25 2.95 " 26.59 " 2.95 " 29.74 "

" " " " "

918 920 924 928 932

0.116 0.118 0.118 0.118 0.118

1.355±0.012 1.475±0.014 1.720 " 2.090±0.018 2.337 "

2.95 3.00 3.00 3.00 3.00

" " " " "

" " " " "

" " " " "

11.89 " 13.46 ±0.18 16.36 ±0.23 17.93 " 19.18 "

34.42 ±0.30 37.47 ±0.36 43.69 " 53.09 ±0.46 59.36 "

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

17

Chart 72: Metric sizes

To order your Chart 72 ‘O’ ring or back-up ring, see page 5. For housing details refer to pages 24-28. Our Chart 72 covers G BS4518: Metric dimensions of toroidal sealing rings (‘O’ rings) and their housings. This range is based on a Swedish standard often quoted against NATO requirements. It is now used extensively throughout the UK and other European countries. If the size you want is not listed, please use the metric columns in Chart 50 (pages 11-17). Tolerances on Chart 72 apply to our standard NBR medium nitrile material PB80. See page 23 for tolerances applying to other materials. Chart 72 back-up rings cover sizes including those in G BS5106: Dimensions of spiral anti-extrusion back-up rings and their housings. Table 4: Pneumatic and static plug housing details to BS4518 For applications requiring back-up rings, use dynamic housing sizes on pages 26-27. PNEUMATIC

STATIC PLUG

Diameter Section A

Radial Depth F

Groove Width E ‘O’ Ring Only

Radial Depth F

2.4 3.0 4.1 5.7 8.4

2.13/2.20 2.70/2.77 3.73/3.82 5.22/5.38 7.75/7.96

3.1/3.3 3.7/3.9 5.0/5.2 6.4/6.6 9.0/9.2

1.84/1.97 2.35/2.50 3.30/3.45 4.70/4.95 7.20/7.50

All dimensions in millimetres For flange applications, the value of groove inside and outside diameters (V and W – see Figure 15, page 28) are shown on Chart 72. BS4500 tolerances H11 and h11 are given on page 27. All Chart 72 dimensions are in millimetres. * An asterisk symbol denotes that the ring is suitable for both dynamic and static applications. Other sizes are not recommended for dynamic duties.

B A

18

James Walker Number

DIAMETERS FLANGE GROOVE DIAMETERS Inside Cyl. Internal Pressure External Pressure Dia. B C, T D V max W (H11) V (h11) W min

1.6 ±0.08mm Diameter Section A 72-0031-16 " 0041-16 " 0051-16 " 0061-16 " 0071-16

3.1 ±0.15 4.1 " 5.1 " 6.1 " 7.1 "

3.5 4.5 5.5 6.5 7.5

6 7 8 9 10

1.0 2.3 3.3 4.3 5.8

6.3 7.3 8.3 9.3 10.3

3.5 4.5 5.5 6.5 7.5

7.5 8.5 9.5 10.5 11.5

" " " " "

0081-16 8.1 " 0091-16 9.1 " 0101-16 10.1 ±0.20 0111-16 11.1 " 0121-16 12.1 "

8.5 9.5 10.5 11.5 12.5

11 12 13 14 15

6.8 7.8 8.8 9.8 10.8

11.3 12.3 13.3 14.3 15.3

8.5 9.5 10.5 11.5 12.5

12.5 13.5 14.5 15.5 16.5

" " " " "

0131-16 0141-16 0151-16 0161-16 0171-16

13.1 14.1 15.1 16.1 17.1

13.5 14.5 15.5 16.5 17.5

16 17 18 19 20

11.8 12.8 14.0 15.0 16.0

16.3 17.3 18.3 19.3 20.3

13.5 14.5 15.5 16.5 17.5

17.5 18.5 19.5 20.5 21.5

" " " " "

0181-16 0191-16 0221-16 0251-16 0271-16

18.1 ±0.25 19.1 " 22.1 " 25.1 " 27.1 "

18.5 19.5 22.5 25.5 27.5

21 22 25 28 30

17.0 18.0 21.0 24.0 26.0

21.3 22.3 25.3 28.3 30.3

18.5 19.5 22.5 25.5 27.5

22.5 23.5 26.5 29.5 31.5

" " " "

0291-16 0321-16 0351-16 0371-16

29.1 " 32.1 ±0.30 35.1 " 37.1 "

29.5 32.5 35.5 37.5

32 35 38 40

28.0 31.0 34.0 36.0

32.3 35.3 38.3 40.3

29.5 32.5 35.5 37.5

33.5 36.5 39.5 41.5

" " " " "

2.4 ±0.08mm Diameter Section A 72-0036-24* " 0046-24* " 0056-24* " 0066-24* " 0076-24*

3.6 ±0.15 4.6 " 5.6 " 6.6 " 7.6 "

4 5 6 7 8

8 9 10 11 12

1.0 2.5 4.0 5.0

8.4 9.4 10.4 11.4 12.4

4 5 6 7 8

10 11 12 13 14

" " " " "

0086-24* 8.6 " 0096-24* 9.6 " 0106-24* 10.6 ±0.20 0116-24* 11.6 " 0126-24* 12.6 "

9 10 11 12 13

13 14 15 16 17

6.4 7.4 8.4 9.5 10.5

13.4 14.4 15.4 16.4 17.4

9 10 11 12 13

15 16 17 18 19

" " " " "

0136-24* 13.6 0146-24* 14.6 0156-24* 15.6 0166-24* 16.6 0176-24* 17.6

14 15 16 17 18

18 19 20 21 22

11.5 12.5 13.5 14.5 15.5

18.4 19.4 20.4 21.4 22.4

14 15 16 17 18

20 21 22 23 24

" " " "

0186-24 0196-24 0206-24 0216-24

19 20 21 22

23 24 25 26

16.5 17.5 18.5 19.5

23.4 24.4 25.4 26.4

19 20 21 22

25 26 27 28

" " " " "

18.6 ±0.25 19.6 " 20.6 " 21.6 "

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

Chart 72: Metric sizes

James Walker Number

DIAMETERS FLANGE GROOVE DIAMETERS Inside Cyl. Internal Pressure External Pressure Dia. B C, T D V max W (H11) V (h11) W min

2.4 ±0.08mm Diameter Section A 72-0246-24 " 0276-24 " 0296-24 " 0316-24 " 0346-24

James Walker Number

3.0 ±0.10mm Diameter Section A

24.6 ±0.25 27.6 " 29.6 " 31.6 ±0.30 34.6 "

25 28 30 32 35

29 32 34 36 39

22.5 25.5 27.5 29.5 32.5

29.4 32.4 34.4 36.4 39.4

25 28 30 32 35

31 34 36 38 41

36 38 40 42 45

40 42 44 46 49

33.5 35.5 37.5 39.5 42.5

40.4 42.4 44.4 46.4 49.4

36 38 40 42 45

42 44 46 48 51

" " " " "

0645-30 0695-30 0745-30 0795-30 0845-30

" " " " "

DIAMETERS FLANGE GROOVE DIAMETERS Inside Cyl. Internal Pressure External Pressure Dia. B C, T D V max W (H11) V (h11) W min

72-0545-30 " 0555-30 " 0575-30 " 0595-30 " 0625-30

54.5 ±0.40 55.5 " 57.5 " 59.5 " 62.5 "

55 56 58 60 63

60 61 63 65 68

52 53 55 57 60

60 61 63 65 68

55 56 58 60 63

63 64 66 68 71

64.5 " 69.5 " 74.5 " 79.5 " 84.5 ±0.50

65 70 75 80 85

70 75 80 85 90

62 67 72 77 82

70 75 80 85 90

65 70 75 80 85

73 78 83 88 93

90 95 100 105 110

95 100 105 110 115

87 92 97 102 107

95 100 105 110 115

90 95 100 105 110

98 103 108 113 118

" " " " "

0356-24 0376-24 0396-24 0416-24 0446-24

35.6 37.6 39.6 41.6 44.6

" " " " "

0456-24 0476-24 0496-24 0516-24 0546-24

45.6 " 47.6 " 49.6 " 51.6 ±0.40 54.6 "

46 48 50 52 55

50 52 54 56 59

43.5 45.5 47.5 49.5 52.5

50.4 52.4 54.4 56.4 59.4

46 48 50 52 55

52 54 56 58 61

" " " " "

0895-30 89.5 0945-30 94.5 0995-30 99.5 1045-30 104.5 1095-30 109.5

" " " " "

0556-24 0576-24 0586-24 0596-24 0616-24

55.6 57.6 58.6 59.6 61.6

" " " " "

56 58 59 60 62

60 62 63 64 66

53.5 55.5 56.5 57.5 59.5

60.4 62.4 63.4 64.4 66.4

56 58 59 60 62

62 64 65 66 68

" " " " "

1145-30 114.5 " 1195-30 119.5 " 1245-30 124.5 ±0.60 1295-30 129.5 " 1345-30 134.5 "

115 120 125 130 135

120 125 130 135 140

112 117 122 127 132

120 125 130 135 140

115 120 125 130 135

123 128 133 138 143

" " " "

0626-24 0646-24 0676-24 0696-24

62.6 64.6 67.6 69.6

" " " "

63 65 68 70

67 69 72 74

60.5 62.5 65.5 67.5

67.4 69.4 72.4 74.4

63 65 68 70

69 71 74 76

" " " " "

1395-30 139.5 1445-30 144.5 1495-30 149.5 1545-30 154.5 1595-30 159.5

140 145 150 155 160

145 150 155 160 165

137 142 147 152 157

145 150 155 160 165

140 145 150 155 160

148 153 158 163 168

" " " " "

" " " " "

3.0 ±0.10mm Diameter Section A 72-0195-30* 19.5 ±0.25 " 0215-30* 21.5 " " 0225-30* 22.5 " " 0245-30* 24.5 " " 0255-30* 25.5 "

20 22 23 25 26

25 27 28 30 31

17 19 20 22 23

25 27 28 30 31

20 22 23 25 26

28 30 31 33 34

" " " " "

1645-30 164.5 " 1695-30 169.5 " 1745-30 174.5 " 1795-30 179.5 " 1845-30 184.5 ±0.80

165 170 175 180 185

170 175 180 185 190

162 167 172 177 182

170 175 180 185 190

165 170 175 180 185

173 178 183 188 193

" " " " "

0265-30* 26.5 " 0275-30* 27.5 " 0295-30* 29.5 " 0315-30* 31.5 ±0.30 0325-30* 32.5 "

27 28 30 32 33

32 33 35 37 38

24 25 27 29 30

32 33 35 37 38

27 28 30 32 33

35 36 38 40 41

" " " " "

1895-30 189.5 1945-30 194.5 1995-30 199.5 2095-30 209.5 2195-30 219.5

" " " " "

190 195 200 210 220

195 200 205 215 225

187 192 197 207 217

195 200 205 215 225

190 195 200 210 220

198 203 208 218 228

" " " " "

0345-30* 34.5 0355-30* 35.5 0365-30* 36.5 0375-30* 37.5 0395-30* 39.5

" " " " "

35 36 37 38 40

40 41 42 43 45

32 33 34 35 37

40 41 42 43 45

35 36 37 38 40

43 44 45 46 48

" " " "

2295-30 229.5 2395-30 239.5 2445-30 244.5 2495-30 249.5

" " " "

230 240 245 250

235 245 250 255

227 237 242 247

235 245 250 255

230 240 245 250

238 248 253 258

" " " "

0415-30* 41.5 0425-30* 42.5 0445-30* 44.5 0495-30* 49.5

" " " "

42 43 45 50

47 48 50 55

39 40 42 47

47 48 50 55

42 43 45 50

50 51 53 58

41 42 46 49

55 56 60 63

45 46 50 53

59 60 64 67

5.7 ±0.12mm Diameter Section A 72-0443-57* 44.3 ±0.30 " 0453-57* 45.3 " " 0493-57* 49.3 " " 0523-57* 52.3 ±0.40

45 46 50 53

55 56 60 63

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

19

Chart 72: Metric sizes

James Walker Number

DIAMETERS FLANGE GROOVE DIAMETERS Inside Cyl. Internal Pressure External Pressure Dia. B C, T D V max W (H11) V (h11) W min

5.7 ±0.12mm Diameter Section A 72-0543-57* " 0553-57* " 0593-57* " 0623-57* " 0643-57*

James Walker Number

DIAMETERS FLANGE GROOVE DIAMETERS Inside Cyl. Internal Pressure External Pressure Dia. B C, T D V max W (H11) V (h11) W min

5.7 ±0.12mm Diameter Section A

54.3 ±0.40 55.3 " 59.3 " 62.3 " 64.3 "

55 56 60 63 65

65 66 70 73 75

51 52 56 59 61

65 66 70 73 75

55 56 60 63 65

69 70 74 77 79

69.3 " 74.3 " 79.3 " 84.3 ±0.50 89.3 "

70 80 75 85 80 90 85 95 90 100

66 71 76 81 86

80 85 90 95 100

70 75 80 85 90

84 89 94 99 104

" " " " "

" 4993-57 499.3

" " " " "

0693-57* 0743-57* 0793-57* 0843-57* 0893-57*

" " " " "

0943-57* 94.3 0993-57* 99.3 1043-57*104.3 1093-57*109.3 1143-57*114.3

" " " " "

" " " " "

95 100 105 110 115

105 110 115 120 125

91 96 101 106 111

105 110 115 120 125

95 100 105 110 115

109 114 119 124 129

1193-57*119.3 " 1243-57*124.3±0.60 1293-57*129.3 " 1343-57*134.3 " 1393-57*139.3 "

120 125 130 135 140

130 135 140 145 150

116 121 126 131 136

130 135 140 145 150

120 125 130 135 140

134 139 144 149 154

" " " " "

1443-57*144.3 1493-57 149.3 1543-57 154.3 1593-57 159.3 1643-57 164.3

145 150 155 160 165

155 160 165 170 175

141 146 151 156 161

155 160 165 170 175

145 150 155 160 165

159 164 169 174 179

" " " " "

1693-57 1743-57 1793-57 1843-57 1893-57

169.3 " 174.3 " 179.3 ±0.80 184.3 " 189.3 "

170 175 180 185 190

180 185 190 195 200

166 171 176 181 185

180 185 190 195 199

170 175 180 185 190

184 189 194 199 204

" " " " "

1943-57 1993-57 2093-57 2193-57 2293-57

194.3 199.3 209.3 219.3 229.3

195 200 210 220 230

205 210 220 230 240

190 195 205 215 225

204 209 219 229 239

195 200 210 220 230

209 214 224 234 244

" " " " "

2393-57 2493-57 2593-57 2693-57 2793-57

239.3 " 249.3 " 259.3 ±1.00 269.3 " 279.3 "

240 250 260 270 280

250 260 270 280 290

235 245 255 265 275

249 259 269 279 289

240 250 261 271 281

254 264 274 285 295

" " " "

2893-57 2993-57 3093-57 3193-57

289.3 " 299.3 " 309.3 ±1.50 319.3 "

290 300 310 320

300 310 320 330

285 295 305 315

299 309 319 329

291 301 311 321

305 315 325 335

" " " " "

" " " " "

72-3393-57 339.3 ±1.50 " 3593-57 359.3 " " 3793-57 379.3 " " 3893-57 389.3 " " 3993-57 399.3 " 4193-57 4393-57 4593-57 4793-57 4893-57

419.3 ±2.00 439.3 " 459.3 " 479.3 " 489.3 " "

340 360 380 390 400

350 370 390 400 410

335 355 375 385 395

349 369 389 399 409

341 361 381 391 401

355 375 395 405 415

420 440 460 480 490

430 450 470 490 500

415 435 455 475 485

429 449 469 489 499

422 442 462 482 492

436 456 476 496 506

500 510

495

509

502

516

8.4 ±0.15mm Diameter Section A 72-1441-84*144.1 ±0.60 " 1491-84*149.1 " " 1541-84*154.1 " " 1591-84*159.1 " " 1641-84*164.1 "

145 150 155 160 165

160 165 170 175 180

140 145 150 155 160

160 165 170 175 180

145 150 155 160 165

165 170 175 180 185

" " " " "

1691-84*169.1 " 1741-84*174.1 " 1791-84*179.1 " 1841-84*184.1±0.80 1891-84*189.1 "

170 175 180 185 190

185 190 195 200 205

165 170 175 180 185

185 190 195 200 205

170 175 180 185 190

190 195 200 205 210

" " " " "

1941-84*194.1 1991-84*199.1 2041-84*204.1 2091-84*209.1 2191-84*219.1

" " " " "

195 200 205 210 220

210 215 220 225 235

190 195 200 205 215

210 215 220 225 235

195 200 205 210 220

215 220 225 230 240

" " " "

2291-84*229.1 2341-84*234.1 2391-84*239.1 2491-84*249.1

" " " "

230 235 240 250

245 250 255 265

225 230 235 245

245 250 255 265

230 235 240 250

250 255 260 270

Coloured ‘O’ rings on a hydraulic cylinder.

20

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

Chart 17000: Inch sizes

To order your Chart 17000 ‘O’ ring or back-up ring, see page 5. For housing details refer to pages 24-28. We originally developed this inch range of ‘O’ rings for the Royal Navy. However, its popularity has led to its use in many industries. This is reflected in it being stocked in our four most popular materials. If the size you want is not listed, please refer to the inch columns on Chart 50 (pages 11-17). Tolerances on Chart 17000 apply to our standard NBR medium nitrile material PB80. See page 23 for tolerances applying to other materials. * An asterisk symbol denotes that the ring is suitable for both dynamic and static applications. Other sizes are not recommended for dynamic duties.

B

James Walker Number

Dias. B,C,P,T

INCH SIZES Tol. on B

Dias. D, Q

0.094 ±0.003" Diameter Section A

James Walker Number

Dias. B,C,P,T

INCH SIZES Tol. on B

Dias. D, Q

±0.011 " " " "

1.938 2.000 2.063 2.125 2.188

0.125 ±0.004" Diameter Section A

A

James Walker Number

Dias. B,C,P,T

INCH SIZES Tol. on B

Dias. D, Q

0.063 ±0.003" Diameter Section A 17001 17002 17003 17004 17005

0.125 0.156 0.188 0.219 0.250

±0.004 " ±0.005 " "

0.250 0.281 0.313 0.344 0.375

17006 17007 17008 17009 17010

0.281 0.313 0.344 0.375 0.406

" " " " ±0.006

0.406 0.438 0.469 0.500 0.531

17011 17012 17013

0.438 0.469 0.500

" " "

0.563 0.594 0.625

0.094 ±0.003" Diameter Section A 17014* 17015* 17016*

0.469 0.500 0.531

±0.006 " "

0.656 0.688 0.719

17017* 17018* 17019*

0.563 0.594 0.625

17020* 17021* 17022* 17023* 17024*

0.656 0.688 0.719 0.750 0.781

17025* 17026* 17027* 17028*

0.813 0.875 0.938 1.000

±0.006 " " " " " " "

0.750 0.781 0.813 0.844 0.875 0.906 0.938 0.969

±0.008 " " "

1.000 1.063 1.125 1.188

0.125 ±0.004" Diameter Section A 17029* 17030* 17031* 17032* 17033*

1.000 1.063 1.125 1.188 1.250

±0.008 " " " "

1.250 1.313 1.375 1.438 1.500

17034* 17035* 17036* 17037* 17038*

1.313 1.375 1.438 1.500 1.563

" " " ±0.011 "

1.563 1.625 1.688 1.750 1.813

17039*

1.625

"

17040* 17041* 17042* 17043* 17044*

1.688 1.750 1.813 1.875 1.938

17045* 17046* 17047* 17048* 17049*

2.000 2.125 2.250 2.375 2.500

17050* 17051* 17052* 17053*

2.625 2.750 2.875 3.000

" " " " " " " ±0.016 "

2.250 2.375 2.500 2.625 2.750 2.875 3.000 3.125 3.250

1.875

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

21

Chart 17000: Inch sizes

James Walker Number

Dias. B,C,P,T

INCH SIZES Tol. on B

Dias. D, Q

0.188 ±0.005" Diameter Section A 17054* 17055* 17056* 17057* 17058*

3.000 3.125 3.250 3.375 3.500

17059* 17060* 17061* 17062* 17063*

3.625 3.750 3.875 4.000 4.125

17064* 17065* 17066* 17067* 17068*

4.250 4.375 4.500 4.625 4.750

17069* 17070* 17071* 17072* 17073*

4.875 5.000 5.125 5.250 5.375

17074* 17075* 17076* 17077* 17078*

5.500 5.625 5.750 5.875 6.000

22

James Walker Number

Dias. B,C,P,T

INCH SIZES Tol. on B

Dias. D, Q

0.250 ±0.006" Diameter Section A ±0.016 " " " "

3.375 3.500 3.625 3.750 3.875

17079* 17080* 17081* 17082* 17083*

6.000 6.250 6.500 6.750 7.000

±0.021 " " " "

6.500 6.750 7.000 7.250 7.500

" " " " "

4.000 4.125 4.250 4.375 4.500

17084* 17085* 17086* 17087* 17088

7.250 7.500 7.750 8.000 8.250

±0.030 " " " "

7.750 8.000 8.250 8.500 8.750

" " " " "

4.625 4.750 4.875 5.000 5.125

17089 17090 17091 17092 17093

8.500 8.750 9.000 9.250 9.500

5.250 5.375 5.500 5.625 5.750

17094 17095 17096 17097 17098

9.750 10.000 10.250 10.500 10.750

5.875 6.000 6.125 6.250 6.375

17099 17100 17101 17102 17103

11.000 11.250 11.500 11.750 12.000

" " ±0.021 " " " " " " "

" " " " " " " ±0.040 " " " " " "

9.000 9.250 9.500 9.750 10.000 10.250 10.500 10.750 11.000 11.250 11.500 11.750 12.000 12.250 12.500

James Walker Number

Dias. B,C,P,T

INCH SIZES Tol. on B

Dias. D, Q

0.250 ±0.006" Diameter Section A 17104 17105 17106 17107 17108

12.500 13.000 13.500 14.000 14.500

±0.040 " " " "

13.000 13.500 14.000 14.500 15.000

17109 17110 17111 17112 17113

15.000 15.500 16.000 16.500 17.000

" " ±0.055 " "

15.500 16.000 16.500 17.000 17.500

17114 17115 17116 17117 17118

17.500 18.000 18.500 19.000 19.500

17119 17120 17121 17122 17123

20.000 20.500 21.000 21.500 22.000

17124 17125 17126 17127

22.500 23.000 23.500 24.000

" " " " " ±0.075 " " " " " " " "

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

18.000 18.500 19.000 19.500 20.000 20.500 21.000 21.500 22.000 22.500 23.000 23.500 24.000 24.500

Non-standard sizes

Methods of production

Tolerances

Using one of the following techniques, we are able to produce any size of ‘O’ ring you require.

Tables 5 and 6 below show the tolerances, on diameter section A and inside diameter B, that can be achieved using various production methods.

Moulded For this, our main method of manufacture, we hold a growing inventory approaching 10,000 moulding tools. We also have one of the largest presses of its type in the world for moulding endless rings up to 2.2 metres diameter. This press is used to produce highintegrity seals, including those for nuclear fuel transportation flasks. The nature of such an application demands stringent quality procedures. James Walker design technologists worked closely with our customer on this successful project. Extruded and mould-ed This approach is particularly economical when a high degree of precision is unnecessary: eg, for large diameter nonstandard ‘O’ rings in static duties. The ring is made from a length of extruded cord by vulcanising the ends together in a moulding tool. Rings must have a minimum section diameter of 3mm and a minimum inside diameter of 200mm. Maximum inside diameter is unlimited. NOTE: This method must not be confused with rings ed by adhesive. Generally, the use of such adhesives results in a less secure with operational temperature limitations below that of the cord material. Moulded and mould-ed This method is used when the nonstandard ‘O’ ring must have a diameter section to very close tolerances and a mould- is acceptable. It is often applied to sizes above 2.2 metres diameter, when two or more smaller rings are manufactured, then cut and moulded.

B A

For standard materials G PB80 – Low shrinkage. G EP18/H/75, FR10/80, FR58/90, SIL 80/2, Elast-O-Lion® 101, 180 and 985 – High shrinkage.

Table 5: Tolerances on Diameter Section A Diameter Moulded Section A including Up to and mould Above Including ed

Table 6: Tolerances on Inside Diameter B

Extruded and mould ed

Inside Diameter B

Above 2.7

2.7 3

±0.08 ±0.10

– +0.38 –0.10

3

3.5

±0.10

+0.40 –0.10

4 10

3.5

4

±0.10

+0.42 –0.11

4

5

±0.12

5

6

6

±0.10 ±0.10

±0.13 ±0.15

10 20

±0.13 ±0.15

±0.18 ±0.22

20 38

38 70

±0.20 ±0.28

±0.28 ±0.40

+0.46 –0.12

70 127

127 180

±0.40 ±0.55

±0.60 ±0.75

±0.13

+0.50 –0.14

180 260

260 400

±0.75 ±1.00

±1.10 ±1.60

7

±0.15

+0.54 –0.16

400 500

500 700

±1.40 ±1.90

±1.90 ±2.60

7

8

±0.18

+0.58 –0.18

700 900

900 1100

±2.40 ±2.90

±3.30 ±4.00

8

10

±0.21

+0.66 –0.21

1100 1400

1400 1700

±3.60 ±4.30

±5.00 ±6.00

12.7

±0.25

+0.75 –0.25

1700

-

±5.00

±7.00

10

All dimensions in millimetres

2.6

Low High Shrinkage Shrinkage and Up to and mould Including ed 2.6 4

All dimensions in millimetres

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

23

Design notes: General

How ‘O’ rings work Rubber has a very high bulk modulus and is therefore virtually incompressible. This means that an ‘O’ ring must be deformed on the diameter section to give it an initial sealing force within a housing (see Figure 5).

72 and Chart 17000. The amount of allowable deformation varies according to the application, as follows: G

G

Figure 5 When system pressure is applied, the ‘O’ ring deforms further (see Figure 6). But because of the initial squeeze, the sealing force always exceeds the force exerted on the ‘O’ ring by the system pressure.

G

Figure 6 At higher pressures, back-up rings may be required to prevent ‘O’ ring extrusion (see page 10). Leakage problems often arise due to lack of initial squeeze, or the ‘O’ ring diameter section being too large for its housing. Reciprocating applications ‘O’ rings marked (*) on our charts are recommended for both static and light/medium reciprocating duties. Other sizes are not recommended for dynamic applications.

‘O’ ring tolerances Tolerances quoted on Charts 50, 72 and 17000 apply to our standard NBR medium nitrile material PB80. For tolerances applying to other materials, see page 23. Non-standard housing diameters Individual ‘O’ rings can be stretched or squeezed very slightly to fit housing diameters that do not match the dimensions specified in Chart 50, Chart 24

Groove in piston applications: A maximum of 4 per cent stretch is acceptable on an ‘O’ ring inside diameter to fit a cylinder diameter D that is not covered by JW chart sizes. See page 28. Flange and triangular groove applications: A maximum of 2 per cent stretch is acceptable on an ‘O’ ring inside diameter when the seal is used on an external pressure flange, or housed in a triangular groove. Likewise, a maximum of 1 per cent squeeze is acceptable on an ‘O’ ring outside diameter when the seal is used on an internal pressure flange.

Cylinder and piston housing tolerances It is important that tolerances on housing diameters for cylinders and pistons meet the requirements of the formulae given on page 28 (ie, dimensions C and D as shown on Figures 9-12). Surface finish of metal parts For maximum seal life the surface finish of metal parts in with an ‘O’ ring should not exceed: G

Rotary applications ‘O’ rings may be used for rotating applications where peripheral speeds are low. For recommendations, please consult our Technical Services Team.

Groove in cylinder application: A maximum of 3 per cent squeeze is acceptable on an ‘O’ ring outside diameter to fit a shaft diameter C that is not covered by JW chart sizes. See page 28.

G

0.8µm (32µin) CLA or Ra in the case of static parts, or 0.4µm (16µin) for moving parts.

A finish finer than 0.15µm (6µin) should be avoided in dynamic applications as a lubricating film may not be retained. For details of these finishes, please refer to BS1134: Assessment of surface texture. Diametral clearance G Under no circumstances should the maximum total diametral clearance (G max) indicated on our housing tables (pages 26-27) be exceeded. This is to ensure that, if complete shaft offset occurs, the maximum extrusion gap at any point of the ‘O’ ring does not exceed G.

Pressure restrictions ‘O’ rings are generally suitable for pressures up to 100bar. Where higher pressures are involved, we recommend the use of back-up rings, as described on page 10. For stuffing box applications we recommend piston-type grooves, although triangular grooves are generally acceptable for pressures below 100bar (see Figures 7 and 8). G

2

Pressure

G

Figure 7 2 G

2

Pressure

G

2

Figure 8

For flange applications, ‘O’ rings will normally be suitable for sealing pressures above 100bar where metal-to-metal prevents extrusion. Complex dynamic, high vacuum or high temperature duties Groove dimensions quoted allow for expansion, swell and retention of interference over the longest possible seal life. However, these dimensions may not suit complex dynamic applications, static duties with high vacuum, or high temperature duties. If in doubt, please consult our Technical Services Team.

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

Design notes: General

Six useful hints G

Select the largest diameter section ‘O’ ring to fit the nominal groove size. This will absorb adverse tolerances in metal parts and aid durability, particularly in high temperature applications. Explosive decompression (ED) environments are an exception – see page 9. To minimise gas permeation, the smallest possible diameter section, that does not compromise mechanical sealing efficiency, should be used. Please ask for separate literature on our high performance elastomers and ED resistant materials.

G

Consider how the ‘O’ ring will over other parts during assembly. Provide the lead-ins as recommended on page 28 (Figures 9 and 11), remove all burrs, and use thin fitting sleeves where appropriate.

G

Smear seals lightly with a suitable lubricant before assembly (see page 8 for recommendations).

G

On reciprocating applications always check whether a standard ‘O’ ring is suitable. Those that are suitable are indicated (*) on Chart 50, Chart 72 and Chart 17000.

G

With a cylinder or piston groove, where the ‘O’ ring inside diameter is less than three times the diameter section, a two part recess – with component split at the ‘O’ ring housing – may be required to facilitate assembly. This is because it is impractical to stretch or squeeze the seal into position without causing damage.

G

Always store ‘O’ rings under conditions that meet the requirements of BS ISO 2230:2002 Rubber products – guidelines for storage, or BS 4F68 (2002): Controlled storage of rubbers for use in aerospace applications. To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

25

Design notes: Housings

Table 7: Metric Groove Dimensions Diameter Groove Width E Section A ‘O’ring only +1 back-up +2 back-up

All dimensions in millimetres. Radial Diametrical Flange Groove Depth Clearance F G max Depth H K min

Triangular Groove

Groove Radii

L min Chamfer M R max R1 max

Depth X

Width Y

1.0/1.02 1.27 1.5/1.52 1.6 1.78

1.5/1.6 1.8/1.9 2.1/2.2 2.3/2.5 2.3/2.5

# # # 3.7/3.9 3.8/3.9

# # # 5.0/5.2 5.3/5.4

0.81/0.86 1.06/1.11 1.26/1.32 1.18/1.25 1.52/1.57

0.11 0.11 0.12 0.12 0.13

0.7/0.8 0.9/1.0 1.1/1.2 1.2/1.3 1.3/1.5

1.8 2.1 2.4 2.4 2.4

# # 3.0 4.0 4.8

# # 2.08/2.20 2.20/2.32 2.41/2.54

# # 0.8 0.8 0.8

0.2 0.3 0.3 0.2 0.8

0.11/0.22 0.11/0.22 0.12/0.24 0.20/0.40 0.13/0.25

# # # 1.37/1.43 1.50/1.56

# # # 1.34/1.40 1.50/1.56

2.0 2.4 2.5 2.62 3.0

2.6/2.7 3.2/3.4 3.2/3.3 3.5/3.7 4.0/4.2

4.1/4.2 4.6/4.8 4.7/4.8 5.0/5.1 5.4/5.6

5.6/5.7 6.0/6.2 6.2/6.3 6.5/6.6 6.8/7.0

1.72/1.79 1.97/2.09 2.17/2.25 2.31/2.39 2.50/2.65

0.12 0.14 0.13 0.13 0.15

1.6/1.7 1.7/1.8 2.0/2.1 2.1/2.3 2.2/2.3

2.8 3.7 3.4 3.6 4.5

4.0 5.0 5.0 6.4 6.0

2.71/2.83 3.30/3.42 3.46/3.59 3.68/3.81 4.20/4.32†

1.0 1.3 1.3 1.0 2.0

0.4 0.5 0.5 0.8 1.0

0.12/0.24 0.20/0.40 0.13/0.26 0.13/0.25 0.20/0.40

1.65/1.72 1.96/2.04 2.05/2.13 2.16/2.24 2.46/2.55†

1.70/1.77 2.05/2.13 2.15/2.23 2.26/2.34 2.58/2.67

3.5/3.53 4.0 4.1 4.5 5.0

4.7/4.9 5.1/5.3 5.5/5.7 5.8/6.0 6.4/6.6

6.2/6.4 6.6/6.8 7.1/7.3 7.6/7.8 8.2/8.4

7.7/7.9 8.1/8.3 8.7/8.9 9.4/9.6 10.0/10.2

3.10/3.18 3.52/3.62 3.50/3.67 3.96/4.07 4.42/4.54

0.15 0.15 0.16 0.16 0.16

2.8/3.0 3.2/3.4 3.1/3.2 3.7/3.9 4.1/4.3

4.8 5.5 6.0 6.0 6.7

7.9 8.0 8.0 9.0 10.0

4.95/5.08† 5.75/5.90 5.60/5.72† 6.45/6.61 7.18/7.34

1.5 2.0 2.5 2.3 2.5

0.8 0.8 1.0 0.9 1.0

0.13/0.25 0.15/0.30 0.20/0.40 0.16/0.32 0.16/0.32

2.89/2.99† 3.32/3.42† 3.39/3.50† 3.74/3.85† 4.23/4.35

3.03/3.13 3.48/3.58 3.59/3.70 3.92/4.03 4.37/4.49

5.33 5.7 6.0 6.99/7.0 8.0

7.0/7.2 7.5/7.7 7.8/8.0 9.4/9.6 10.7/10.9

8.8/9.0 9.3/9.5 9.6/9.8 12.0/12.2 13.3/13.5

10.6/10.8 11.1/11.3 11.4/11.6 14.6/14.8 15.9/16.1

4.67/4.78 4.95/5.18 5.31/5.45 6.22/6.35 7.09/7.27

0.18 0.18 0.18 0.20 0.20

4.3/4.5 4.4/4.5 5.0/5.2 5.9/6.1 6.7/6.9

7.1 8.1 7.9 9.4 10.6

11.1 7.49/7.62 10.0 7.80/7.92† 12.0 8.64/8.82 14.3 10.03/10.16 16.0 11.61/11.81

2.3 3.0 3.0 2.5 4.0

0.8 1.0 1.2 0.8 1.6

0.13/0.25 0.20/0.40 0.18/0.36 0.13/0.25 0.20/0.40

4.54/4.67 4.80/4.94 5.02/5.16 5.85/6.01 6.70/6.88

4.64/4.77 4.98/5.12 5.25/5.39 6.12/6.28 7.01/7.19

8.4 9.0 9.5/9.53 10.0 12.5/12.7

11.0/11.2 12.3/12.5 13.1/13.3 13.8/14.0 18.5/18.8

13.6/13.8 15.6/15.8 16.4/16.6 17.1/17.3 21.8/22.1

16.2/16.4 7.50/7.75 18.9/19.1 7.97/8.17 19.7/19.9 8.43/8.64 20.4/20.6 8.89/9.10 25.1/25.4 11.13/11.39

12.0 12.1 12.7 13.3 17.4

14.0 18.0 19.0 20.0 25.0

4.0 4.5 4.8 5.0 6.3

1.0 1.8 1.9 2.0 2.5

0.20/0.40 7.02/7.21 0.21/0.42 7.54/7.74 0.22/0.44 7.97/8.18 0.23/0.46 8.41/8.62 0.26/0.52 10.52/10.78

0.20 6.6/6.7 0.21 7.5/7.7 0.22 8.0/8.2 0.23 8.4/8.6 0.26 10.5/10.8

11.50/11.62† 13.08/13.29 13.83/14.05 14.58/14.81 18.30/18.56

Table 8: Inch Groove Dimensions Diameter Groove Width E Section A ‘O’ring only +1 back-up +2 back-up

7.34/7.53 7.89/8.09 8.34/8.55 8.80/9.01 11.01/11.27

All dimensions in inches. Radial Diametrical Flange Groove Depth Clearance F G max Depth H K min

Triangular Groove

Groove Radii

L min Chamfer M R max R1 max

R2

Dovetail Groove Depth X

Width Y

0.040 0.050 0.060 0.063 0.070

.059/.063 .069/.073 .080/.085 .084/.089 .089/.099

# # # .142/.147 .147/.152

# # # .200/.205 .205/.210

.032/.034 .042/.044 .051/.053 .053/.055 .060/.062

.004 .004 .005 .005 .005

.028/.032 .037/.041 .045/.050 .047/.052 .051/.061

.068 .078 .091 .094 .095

# # .120 .125 .188

# # .082/.087 .086/.091 .095/.100

# # .030 .031 .030

.008 .010 .012 .013 .030

.004/.008 .004/.008 .005/.010 .005/.010 .005/.010

# # # .054/.056 .059/.062

# # # .053/.055 .059/.062

0.094 0.103 0.125 0.139 0.188

.121/.126 .136/.146 .159/.164 .183/.193 .240/.246

.179/.184 .194/.199 .217/.222 .241/.247 .312/.318

.237/.242 .252/.257 .275/.280 .299/.305 .384/.390

.081/.084 .091/.094 .110/.114 .122/.125 .166/.171

.005 .005 .005 .006 .006

.075/.080 .081/.091 .102/.107 .110/.120 .155/.161

.129 .140 .168 .190 .248

.188 .250 .250 .313 .375

.129/.134 .145/.150 .183/.188 .195/.200† .269/.275

.047 .040 .063 .060 .094

.019 .030 .025 .030 .038

.005/.010 .005/.010 .005/.010 .005/.010 .006/.012

.077/.080 .085/.088 .103/.107† .115/.119† .156/.161†

.080/.083 .089/.092 .107/.111 .120/.124 .163/.168

0.210 0.250 0.275 0.375 0.500

.276/.286 .328/335 .370/.380 .514/.523 .718/.728

.348/.355 .430/.437 .472/.480 .644/.653 .848/.858

.420/.427 .532/.539 .574/.582 .774/.783 .978/.988

.184/.188 .221/.227 .245/.250 .333/.341 .446/.456

.007 .007 .008 .009 .010

.170/.180 .207/.214 .231/.241 .314/.323 .421/.431

.280 .333 .370 .501 .674

.438 .500 .563 .750 1.000

.295/.300 .360/.367 .395/.400 .545/.554 .733/.743

.090 .125 .100 .188 .250

.030 .050 .030 .075 .100

.005/.010 .007/.014 .005/.010 .009/.018 .010/.020

.179/.184 .208/.214 .230/.236 .315/.323 .421/.431

.183/.188 .218/.224 .241/.247 .329/.337 .441/.451

Key: Chart 50 Chart 72 Chart 17000 # †

R2

Dovetail Groove

BS1806, BS4518 and BS5106 figures are given in red.

Diameter Section A indicated is too small for this groove type These dimensions can only be used with moulded ‘O’ rings. Use Tables 10 and 11, page 27 for ‘O’ rings manufactured by other methods.

26

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

Design notes: Housings

For ‘O’ rings manufactured by extrusion Table 9: BS 4500 ISO Limits and Fits Extract (See Figures 13 - 15, page 28) Nom.

Diameter up to and including

H11

h11

3 6 10 18

3 6 10 18 30

+0/+0.060 +0/+0.075 +0/+0.090 +0/+0.110 +0/+0.130

30 50 80 120 180

50 80 120 180 250

+0/+0.160 +0/+0.190 +0/+0.220 +0/+0.250 +0/+0.290

Above

Tolerance

Table 9 continued Nom. Above

Diameter up to and including

Tolerance H11

h11

–0/–0.060 –0/–0.075 –0/–0.090 –0/–0.110 –0/–0.130

250 315 400 500 630

315 400 500 630 800

+0/+0.320 +0/+0.360 +0/+0.400 +0/+0.440 +0/+0.500

–0/–0.320 –0/–0.360 –0/–0.400 –0/–0.440 –0/–0.500

–0/–0.160 –0/–0.190 –0/–0.220 –0/–0.250 –0/–0.290

800 1000 1250 1600 2000

1000 1250 1600 2000 2500

+0/+0.560 +0/+0.660 +0/+0.780 +0/+0.920 +0/+1.100

–0/–0.560 –0/–0.660 –0/–0.780 –0/–0.920 –0/–1.100

All dimensions in millimetres

Table 10: Triangular Groove Sizes

Table 11: Dovetail Groove Sizes

Diameter Section A

Diameter Section A

Triangular Chamfer M

Metric (mm) 3.0 4.48/4.63 3.5/3.53 5.10/5.25 4.1 6.00/6.16 5.7 8.18/8.36 8.4 12.18/12.38

Metric (mm) 3.0 3.5/3.53 4.0 4.1 4.5

Inch 0.139

.201/.207

Dovetail Depth X

¥ ¥ 3.48/3.58 3.59/3.70 3.88/3.99

Inch 0.125 0.139 0.188

¥ ¥ .159/.164

¥ ’O’ rings not suitable for dovetail grooves.

General Information Health warning: If PTFE products are heated to elevated temperatures, fumes will be produced which may give unpleasant effects, if inhaled. Whilst some fumes are emitted below 300°C, the affect at these temperatures is negligible. Care should be taken to avoid contaminating tobacco with PTFE particles or dispersion which may remain on hands or clothing. Material Safety Data Sheets (MSDS) are available on request. Information in this publication and otherwise supplied to s is based on our general experience and is given in good faith, but because of factors which are outside our knowledge and control and affect the use of products, no warranty is given or is to be implied with respect to such information. Specifications are subject to change without notice. Statements of operating limits quoted in this publication are not an indication that these values can be applied simultaneously.

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

27

Design notes: Housings

Housing arrangements Figure 9: Groove in cylinder Max. lead in dia.

Min. = - 2A max. - G groove dia.

P h11 H

Direction of pressure

Shaft diameter

15 - 20°

Figure 18: Groove radii and taper for figures 9 - 15

Figure 13: Groove in flange, external pressure

Radius R2

Radius R1 max.

K C E F

Figure 14: Groove in flange, internal pressure

0 - 5°

Q H11 Groove diameter

B

G total diametral clearance

H

A Max. groove dia. = C min. + 2F max. Min. groove dia. = C max. + 2F min.

K Direction of pressure

Figure 10: Plug groove, terminology as figures 9 and 18

List of symbols The following symbols are used throughout this guide:

Figure 15: Groove in flange, Chart 72 W

A

‘O’ ring diameter section

B

‘O’ ring inside diameter

C

Shaft diameter

D

Cylinder diameter

V H

Figure 11: Groove in piston Min. lead in dia.

=

Max. + 2A max. + G groove dia.

Figure 16: Triangular groove 15 - 20°

M

E

L

T D cylinder diameter

G total diametral clearance

G total diametral clearance

Max. groove dia. = D min. - 2F min. Min. groove dia. = D max. - 2F max.

Figure 12: Plug groove, terminology as figures 11 and 18

Groove radial depth

G

Maximum diametral clearance

H

Flange groove depth

H11 BS4500 tolerance (holes)

45°

Groove diameter

Groove width

F

h11 BS4500 tolerance (shafts)

Maximum radius R

F

E

K

Minimum flange groove width

L

Minimum spigot length

M

Triangular groove chamfer

P

Flange groove inside diameter

Q

Flange groove outside diameter

R

Triangular groove radius

R1 Corner radius (maximum) at groove base Figure 17: Dovetail groove

R2 Corner radius at groove entrance

Maximum radius 2G

20 - 25°

A+B

X

Radius min. G max. 2G

Y

T

Triangular groove inside diameter

V

BS4518 flange groove inside diameter

W

BS4518 flange groove outside diameter

X

Dovetail groove depth

Y

Dovetail groove width

28 To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz

‘O’ ring cords & kits

‘O’ ring cord

‘O’ ring kits These three boxed kits represent excellent value for money in of quantity, quality and convenience.

We manufacture a large selection of ‘O’ ring cord in metric and inch cross sections in the following elastomers: FR10/80 Fluorocarbon (80 IRHD) PB70 Nitrile (70 IRHD) EP21/E/80 Ethylene-propylene (80 IRHD) GN/W/70 Neoprene (70 IRHD) SIL/60/6 Silicone (60 IRHD) Standard cross sections: 1.6mm ⁄÷¡§ inch 1.78mm 0.070 inch 2.0mm 2.4mm ‹÷#™ inch 2.62mm 0.103 inch 3.0mm 3.18mm ⁄÷• inch 3.53mm 0.139 inch 4.0mm fi÷#™ inch 4.5mm 4.76mm ‹÷¡§ inch 5.0mm 5.33mm 0.210 inch 5.7mm 6.0mm 6.35mm ⁄÷¢ inch 6.99mm 0.275 inch 8.0mm fi÷¡§ inch 8.73mm ⁄⁄÷#™ inch 9.5mm ‹÷• inch 10mm 10.32mm ⁄‹÷#™ inch 11.11mm ‡÷¡§ inch 11.91mm ⁄fi÷#™ inch 12.7mm ⁄÷™ inch How supplied: by the metre to any length. Most of the above elastomers and cord sizes are available from stock or on short lead times. Other sizes and elastomers can be supplied on request. All these cords are manufactured to BS3734-1:1997 and ISO3302-1:1996.

Each kit has been carefully assembled for maintenance engineers and equipment refurbishers who need a good selection of rings constantly available to suit many industrial applications. The boxes are designed to withstand industrial maintenance activities, and have partitions to hold all items separately and securely. From the kit layouts, s can readily see when they are running low on a particular size of ring or cord. ‘O’ ring sealing kit – metric sizes (JW order code ZL000186) Box containing nitrile (NBR) elastomer rings of 70 IRHD: G 404 ‘O’ rings in total. G In 30 sizes ranging from 3mm ID x 2mm section up to 45mm ID x 4mm section.

‘O’ ring sealing kit – inch sizes (JW order code ZL000097) Box containing nitrile (NBR) elastomer rings of 70 IRHD: G 382 ‘O’ rings in total. G In 30 sizes ranging from ⁄÷• inch ID x ⁄÷¡§ inch section up to 1‹÷¢ inch ID x ‹÷¡§ inch section. Service kit – ‘O’ ring cord (JW order code ZL000275) Box containing tools and nitrile (NBR) elastomer ‘O’ ring cord of 70 IRHD: G 14 off 2m lengths: 1.78mm diameter (0.070 inch), 2.0mm, 2.4mm, 2.62mm (0.103 inch), 3.0mm, 3.5mm (0.138 inch), 4.0mm, 4.5mm, 5.0mm, 5.33mm (0.210 inch), 5.7mm, 6.0mm, 6.99mm (0.275 inch), 8.0mm. G Tape measure, retractable blade knife, splicing aid and adhesive for forming rings. G Full instructions.

Special packaging and kits Special packaging and bagging can be provided for all of our ‘O’ rings – from individually bagged rings to complete sealing kits

containing a variety of sizes and materials. These can be custom-branded and over printed with dedicated part numbers to simplify ordering, stocking and issuing routines. Your own company name and logo can be printed on the bag or label to provide a custom packaged kit with your own references to save additional repackaging if you are re-selling.

To order or get further details, call your local shown on rear cover or listed at www.jameswalker.biz 29

James Walker Group companies James Walker Australia Pty Ltd Tel: +61 2 9644 9755 Fax: +61 2 9644 6395 Email: [email protected]

James Walker Ibeica SA +34 94 4470099 Tel: Fax: +34 94 4471077 Email: [email protected]

James Walker Norge AS Tel: +47 22 706800 Fax: +47 22 706801 Email: [email protected]

James Walker Ireland Ltd Tel: +353 (0)1 454 2500 Fax: +353 (0)1 454 4561 Email: [email protected]

James Walker Singapore Pte Ltd Tel: +65 6777 9896 Fax: +65 6777 6102 Email: [email protected]

James Walker Italiana srl Tel: +39 02 257 8308 Fax: +39 02 263 00487 Email: [email protected]

James Walker South Africa (PTY) Ltd Tel: +27 (0)31 205 6251/2/3 Fax: +27 (0)31 205 6266 Email: [email protected]

James Walker Mfg Co (USA) Tel: +1 708 754 4020 Fax: +1 708 754 4058 Email: [email protected]

James Walker Deutschland Gmbh Tel: +49 (0)40 386 0810 Fax: +49 (0)40 389 3230 Eamil: [email protected]

James Walker New Zealand Limited Tel: +64 (0)9 377 0329 Fax: +64 (0)9 307 6619 Email: [email protected]

James Walker SAS Tel: +33 (0)437 497482 Fax: +33 (0)437 497483 Email: [email protected]

Ask for these free guides to James Walker’s products and services.

Compression packings

Gaskets & tings

Hydraulic sealing products

James Walker & Co Ltd Customer Centre 1 Millennium Gate, Westmere Drive Crewe, Cheshire CW1 6AY, UK Tel: +44 (0)1270 536000 Fax: +44 (0)1270 536100 Email: [email protected] www.jameswalker.co.uk BP4179 305/10m ML-011653

ed Office: Lion House, Oriental Road, Woking, Surrey GU22 8AP, UK. Reg. No. 2432592 England © James Walker 2005
