Vilar IP Camera VS-IPC1002 ’s Manual

1

Index 1

INTRODUCTION............................................................................. - 1 1.1

WELCOME TO THE VILAR IP CAMERA ...................................................... - 1 -

1.2

PACKAGE CONTENTS ......................................................................... - 1 -

1.3

IDENTIFY VS-IPC1002 .................................................................... - 2 -

1.3.1 VS-IPC1002Views .................................................................... - 2 1.3.2 Indication and Operation .......................................................... - 4 2

FUNCTIONS AND FEATURES ........................................................ - 10 2.1

BASIC FUNCTIONS ......................................................................... - 10 -

2.2

ADVANCED FEATURES ..................................................................... - 10 -

3

SYSTEM REQUIREMENT ............................................................... - 11 -

4

SETUP PROCEDURE...................................................................... - 12 -

5

4.1

VS-IPC1002 POWER & NETWORK CONNECTION ..................................... - 12 -

4.2

ROUTER/SWITCH/HUB/XDSL MODEM CONNECTION ................................. - 13 -

4.3

USE IPCAMSEARCH TOOL TO SETUP VS-IPC1002................................... - 14 -

4.4

VIEW VIDEO ON WEB BROWSER ......................................................... - 16 -

4.5

SETUP VS-IPC1002 ON WEB ........................................................... - 22 -

4.6

MOUNTING THE VS-IPC1002 ........................................................... - 22 -

SYSTEM CONFIGURATION ........................................................... - 24 5.1

SYSTEM STATUS ............................................................................ - 24 -

5.2

MANAGEMENT ....................................................................... - 25 -

5.3

NETWORK ................................................................................... - 26 -

5.4

DATE AND TIME ............................................................................ - 27 -

5.5

VIDEO ....................................................................................... - 27 -

5.6

JPEG ENCRYPTION ........................................................................ - 28 -

5.7

E-MAIL ...................................................................................... - 29 -

5.8

FTP .......................................................................................... - 30 -

5.9

SENSORS AND MOTION DETECTION ..................................................... - 31 -

5.10 SCHEDULER TRIGGER...................................................................... - 31 5.11 SYSTEM MAINTENANCE .................................................................... - 32 5.12 SYSTEM LOG ................................................................................ - 32 5.13 GUEST ZONE ............................................................................... - 33 6

VISIT VS-IPC1002 OVER INTERNET ............................................ - 34 6.1

WAN IP ADDRESS ......................................................................... - 34 -

6.2

NETWORK ADDRESS TRANSLATION (NAT) ............................................. - 35 -

6.3

PORT FORWARDING ........................................................................ - 35 -

6.4

DEFAULT GATEWAY ......................................................................... - 36 -

6.5

ACCESSING MULTIPLE CAMERAS ON THE INTERNET ................................... - 36 -

6.6

DYNAMIC DOMAIN NAME SERVICE (DDNS) ........................................... - 37 -

6.7

CONFIGURATION EXAMPLE ................................................................ - 38 -

www.vipcam.cn

2

7

TECHNICAL PARAMETERS............................................................ - 40 -

www.vipcam.cn

3

Figures and Tables Index Figure 1 VS-IPC1002 View ......................................................... - 2 Figure 2 VS-IPC1002 Front View ................................................... - 2 Figure 3 VS-IPC1002 Back View.................................................... - 3 Figure 4 Front View Indication and Operation ................................. - 4 Figure 5 LCD Indications.............................................................. - 4 Figure 6 IP Address/Network Mask/Gateway................................... - 5 Figure 7 Back View Indication....................................................... - 7 Figure 8 Input & Output defines.................................................... - 7 Figure 9 Input & Output Pins Connection........................................ - 8 Figure 10 Insert a CF Card ........................................................... - 9 Figure 11 Connecting the Ethernet wire ....................................... - 12 Figure 12 connecting the power supply ........................................ - 12 Figure 13 LAN connection .......................................................... - 13 Figure 14 VS-IPC1002 Search Tool .............................................. - 14 Figure 15 Modify Vilar IP camera’s IP Address............................... - 15 Figure 16 Input ’s name and ................ - 15 Figure 17 VS-IPC1002 Home Page .............................................. - 16 Figure 18 Message box ..................................................... - 17 Figure 19 IE Security Warning .................................................... - 17 Figure 20 Security setting for ActiveX Controls.............................. - 18 Figure 21 Set VS-IPC1002 as a trusted site .................................. - 19 Figure 22 Video webpage........................................................... - 20 Figure 23 History Images View ................................................... - 21 Figure 24 The right-click menu of ActiveX Control ......................... - 21 Figure 25 The bottom menu of ActiveX Control ........................... - 22 Figure 26 System Status View .................................................... - 24 Figure 27 Management View ............................................... - 25 Figure 28 Network Setup View.................................................... - 26 Figure 29Date and Time Setup View ............................................ - 27 Figure 30 Video Setup View ....................................................... - 27 Figure 31JPEG Encryption Setup View.......................................... - 28 Figure32 Require Input in Client Web Browser................. - 28 Figure 33 Input in Web Browser (ActiveX) ...................... - 29 Figure 34 Input in Web Browser (Java) ........................ - 29 Figure35 E-mail Setup View ....................................................... - 29 Figure 36 FTP Setup View .......................................................... - 30 Figure 38 Scheduler Trigger Setup View ....................................... - 31 Figure 39 System Maintenance View.......................................... - 32 Figure 40 System Log View ........................................................ - 32 Figure 41 “Guest Zone” View...................................................... - 33 Figure 42 Vilar IP camera’s Application Environment ...................... - 34 Figure 43 Typical Network Environment ....................................... - 38 www.vipcam.cn

4

1 Introduction 1.1 Welcome to the Vilar IP Camera The Vilar IP Camera combines a high quality digital video camera with network connectivity and a powerful web server to bring clear video to your desktop from anywhere on your local network or over the Internet.

1.2 Package Contents Now the digital cameras are used more often in many public areas such as super markets, schools, factories and so on. Especially on some special areas such as banks and traffic cross road, its powerful image management can help you monitor those areas better.

Before starting, check that that all the following items have been included with your camera. If anything is missing, please your dealer.

The package includes. ü ü ü

Vilar IP Camera *1 Vilar IP Camera Utility CD *1 Quick Start Guide *1

ü ü ü ü

5V Power Adapter *1 Ethernet cable *1 Guarantee Card *1 Mounting bracket *1 -1-

1.3 Identify VS-IPC1002 1.3.1 VS-IPC1002Views

Figure 1 VS-IPC1002 View

Lens

Tilt

Night Vision LEDs

Pan Working Status LED

Privacy Indicate LED

Visiting LED

Privacy Status Button

IP Show LCD

Figure 2 VS-IPC1002 Front View

www.vipcam.cn

-2-

RJ45 Ethernet Socket

Input&Output Pins DC 5V Input Socket CF Card Socket RESET Button

Figure 3 VS-IPC1002 Back View

www.vipcam.cn

-3-

1.3.2 Indication and Operation

LED: Privacy

LED: Working

Button: Privacy LED: Visiting

LCD

Figure 4 Front View Indication and Operation

The privacy button toggles Privacy mode and Normal mode, In Privacy mode, all the remote s will not be allowed to see the video.

Figure 5 LCD Indications

LCD circulates display IP Address/Network Mask/Gateway, it shown as Figure 6.

www.vipcam.cn

-4-

IP Address=192.168.0.24

Subnet mask=255.255.255.0

Gateway IP=192.168.0.1

Figure 6 IP Address/Network Mask/Gateway

Status icon indications list: Icon

Meaning DDNS Server ed. Connected to the INTERNET successfully. Vilar Backbone server connected successfully. There is/are (s) visiting VS-IPC1002 video. Sensor triggered. detection)

(Digit

input

or

Motion

CF card detected. System in configuration status. E.g. Upgrading firmware.

www.vipcam.cn

-5-

Network mode indications： Icon

Meaning

Static IP

Use static (manually fixed) IP mode.

DH

IP Address is dynamic assigned by DH Server.

PPPoE

Vilar IP Camera’s internal PPPoE dial function enabled.(Used for xDSL)

There is a “ visiting” yellow LED on the . If this LED and the “ visiting” icon of LCD are open or close at the same time, that means the image can be viewed by remote audience. You can change the situation between the “privacy status” and “no privacy status” by switching the privacy status button. In the “privacy status”, the remote can not view image and the Privacy Indicate Lamp will light at the same time. Working status LED meaning: LED Status

Meaning

Normal Flashing: Turns on for 1/2 second every 3 seconds

Normal running

Always on or always off

System error

Fast Flashing: Turns on for 1/2 second every 1 second

System is starting, Please wait.

Slow Flashing: Turns on for 1/2 second every 6 second

Upgrading firmware, Please wait.

www.vipcam.cn

-6-

DC 5V Input Socket

RJ45 Ethernet Socket

Input & Output Pins

CF Card Socket Reset button Figure 7 Back View Indication

Output Pins Relay: Normally Open

Digit Input Pins

1

Output A

2

3

B

Input 1

4

5

Common Input 2

Figure 8 Input & Output defines

www.vipcam.cn

-7-

Input Pins: The input pins can be used for 2-way external sensor input. For example, you may connect a Person Infrared Sensor (PIR) to it for motion detection. When external sensor triggered, VS-IPC1002 can be programmed to send an email with picture or control the internal relay output. Connecting two sensors which send open and close signals to IO input pins. Pin3 and Pin4 connect two input lines of sensor 1 respectively. Pin4 and Pin5 connect two input lines of sensor 2 respectively. Output Pins: VS-IPC1002 has an internal relay. Relay’s two normally open s are represented by Pin 1 and Pin 2. You may use it to control one external load below AC/DC 36V & 2 Amp. The way of connecting IO input/output pins is that stripping off the rubber protect of cable to bare the 5mm brass wire first. And then plug the brass wire into the hole after press down the orange tab. After that release the screwdriver, the cable will be riveted.

Figure 9 Input & Output Pins Connection

External Power Socket：Connect to a 5V AC-DC adapter. CAUTION: Do not use any non-approved power adapter other than the ones which is accessory. This is to prevent any damage of VS-IPC1002. RJ-45 Ethernet Socket: Connects your VS-IPC1002 to LAN. CF Card Socket: As image storage CF Card could save the sensor trigger www.vipcam.cn

-8-

image on the real time or discontinuous time. Its maximum capacity is 2GByte. You have to format it as FAT16/FAT32 before use it. Both type1 and type2 CF card can be ed by this socket.

Figure 10 Insert a CF Card

Caution: Do not plug in / out CF Card with power supply. You have to cut off the power supply of VS-IPC1002 first before plugging in / out CF Card. This is to prevent any damage of CF Card. Note: Before purchasing CF Card, please test it first. Because not all brands and types CF Card can be ed by VS-IPC1002.

RESET button: Click the reset button shortly, will reboot the system. If you press the button and hold for 5 seconds or longer, the system will restore to factory default configuration, it will take about 30 seconds, then reboot automatically. Caution: DO NOT switch off VS-IPC1002’s power during the procedure of restoring factory default. It will take about 30 seconds.

www.vipcam.cn

-9-

2 Functions and Features 2.1 Basic Functions The basic function of VS-IPC1002 is transmitting remote video and audio on the IP network. The high quality video image can be transmitted with 30fps speed on the LAN/WAN by using MJPEG hardware compression technology. The VS-IPC1002 is basic on the T/IP standard. There is a WEB server inside which could Internet Explore. Because of that the management and maintenance of your device become more simply by using network to achieve the remote configuration, start-up and upgrade firmware. You can use this VS-IPC1002 to monitor some special places such as your home and your office. Also controlling the VS-IPC1002 and managing image are simple by clicking the website through the network.

2.2 Advanced Features

ü

Advanced Image Encryption Besides standard authentication, there is a powerful 128-bit AES encryption can be used to ensure the image transmission safe.

ü

Digital Video Recording and Transportation VS-IPC1002 can save the image in CF Card. sending the image to your mailbox automatic when the VS-IPC1002 is triggered.

ü

Motion Detection Your may use the internal Motion Detection function or external PIR sensor to trigger images recording and transportation.

ü

Alarm sensor input/output The detection sensor sends an alarm and records it by itself when there is a fire or accident. A message as an email is send to you by this sensor. (The input/output discreteness can be chosen)

ü

DDNS Using the VS-IPC1002 in the condition which including ADSL and IP change often is more convenient, because VS-IPC1002 provides dynamic DNS function.

www.vipcam.cn

- 10 -

3 System Requirement ü ü

LAN: 10Base-T Ethernet / 100BaseTX Fast Ethernet Web Browser can ActiveX ,such as Internet Explorer 5.0 or higher

ü ü ü ü ü ü

Web Browser can Java Applet, such as Firefox 1.5 PC – Intel Pentium III or equivalent, 1GHz or above 128MB RAM 800x600 resolution with 16-bit color or above Windows 2000, Windows XP, Linux Other device: read-only CD-ROM Note: Not only the fixed IP address can access cameras from the Internet, but also Dynamic IP can access cameras. If the IP address provided by your Internet Service Provider is dynamic (changing), then g up for a dynamic DNS service will make accessing from the Internet much more convenient. g up for a DDNS is free and easy; you can get it in some websites, such as our website www.vipcam.cn that can give you more information.

www.vipcam.cn

- 11 -

4 Setup Procedure Before use VS-IPC1002, please setup according to the following procedures.

4.1 VS-IPC1002 Power & Network Connection Step1: Connect the network cable to the RJ45 network connections port

Figure 11 Connecting the Ethernet wire

Step2: Connect the power adapter to the VS-IPC1002 power socket and then insert the plug into an available power outlet.

Figure 12 connecting the power supply

www.vipcam.cn

- 12 -

CAUTION: Do not use any non-approved power adapter other than the ones which are accessory. This is to prevent any damage of VS-IPC1002. In different country or region, the power supply might be different (110V/220, 50Hz/60Hz), please make sure it correspond to the tag marked on the power adapter.

4.2 Router/Switch/Hub/xDSL Modem Connection Plug the other end of the Ethernet cable into any available LAN port. A typical home router/gateway connection is shown below. The LED of LAN port will then turns ON.

Figure 13 LAN connection

Check these LED on the RJ45 socket of VS-IPC1002. If connection is successfully, the green light is on. If there’s any active data transportation, the orange LED will flash. The current IP address of VS-IPC1002, Network Mask and Gateway will be shown on the LCD after 1minute. VS-IPC1002 is available for visiting now. There are two methods for visiting its homepage: 1. Run Vilar IP camera management tool “VilarWizard_CN.exe” in the CD. This software will search for all VS-IPC1002 in your LAN. Select one and then click [visit] to continue.

www.vipcam.cn

- 13 -

2. Run an Internet Explorer, and input the IP address as shown on the LCD to IE’s address bar, for example: http://192.168.0.234. Note: VS-IPC1002 by default use fixed (static) IP address setting. The default IP address is :192.168.0.234, Network Mask is 255.255.255.0, Gateway is 192.168.0.1

4.3 Use Vilar IP camera mangement tool to setup VS-IPC1002 Insert the incidental CD into the CD-ROM drive. After run the Vilar IP camera management tool “VilarWizard_CN.exe”, the interface as follow will pup up.

Figure 14 VS-IPC1002 Search Tool

This tool shows all Vilar IP Cameras found on your LAN with its Serial Number/IP Address/Firmware Version. If your Vilar IP camera’s IP address is not as the same segment of your PC (defined by IP Address and Network Mask), you may not be able to visit your Vilar IP camera. For example, Your PC’s IP address is 192.168.100.33, network mask is 255.255.255.0, then your PC can visit the IP address from 192.168.100.1 to 192.168.100.255 only, If your Vilar IP camera’s IP Address is not within this range, you cannot access it. Therefore you can click [Setup IP] button to change Vilar IP camera’s IP address and adjust it adapting your PC setting. Click [Auto Set], let IPCamSearch tool find an available IP Address for you. www.vipcam.cn

- 14 -

Figure 15 Modify Vilar IP camera’s IP Address

Click [OK], and then input ’s name and to continue.

Figure 16 Input ’s name and

Note: By default, ’s name is: , is: 123456

Input the correct name and , and click [OK], then you can see a message box indicating Vilar IP camera’s IP Address has changed(VS-IPC1002 is in static IP mode now). Then you may click [Visit IPCam] to run an Internet Explorer, You can do more configuration by click [System Setup] on homepage of VS-IPC1002.

www.vipcam.cn

- 15 -

Note: If you don’t have Vilar IP camera management tool at hand, you may change your PC’s IP Address to the same segment, according to the IP shown on Vilar IP camera’s front LCD. Then you can input Vilar IP camera’s IP Address into IE’s address bar to access.

4.4 View the video of VS-IPC1002 on Web Browser You may visit Vilar IP camera’s homepage by IE or other compatible web browsers.

Figure 17 VS-IPC1002 Home Page

Note: Your web browser must Javascript function.

Click “ Visit” to view video. You will see a message box which requires your as shown below.

www.vipcam.cn

- 16 -

Figure 18 Message box

Note: By default, ’s name is: , is: 123456

Input correct name and , then you can view the video. The system will prompt you install the ActiveX control when you use it first time. The follow dialog box will be indicated after you setting the security option of Internet Explorer correctly.

Figure 19 IE Security Warning

Click [Install] to continue. If you cannot see the message above, you must modify IE’s security configuration.

www.vipcam.cn

- 17 -

Note: You can not the ActiveX Control without authorization until setup Internet Explorer security configuration properly. You can follow this procedure to setup IE security configuration: 1. Select [Internet Options] in [Tools] menu of IE; 2. Switch to [Security] option card; 3. Select [Custom Level]; 4. Setup as the following; a) Init and Run unmarked as safety ActiveX controls: [Alert]; b) ing unsigned ActiveX controls: Select [Alert]; c) Run ActiveX controls and plug-in: Select [Enable];

Select

Figure 20 Security setting for ActiveX Controls

5. Click [OK] to save it. In addition the IPCam also can be a “Trusted Sites”, the setting process as follow: 1. Select [Internet Options] in [Tools] menu of IE; 2. Switch to [Security] option card; www.vipcam.cn

- 18 -

3. Select [Trusted Sites]; 4. Uncheck “√“ before “……https:(S) ”; 5. Input Vilar IP camera’s IP address or http://192.168.0.250 or http://tom.vipcam.cn; 6. Click [Add], [OK] to save.

URL,

for

example,

Figure 21 Set VS-IPC1002 as a trusted site

Note: In order to operate new setting, you have to start up Internet Explorer again. After ActiveX Control is installed, you will see a picture as following.

www.vipcam.cn

- 19 -

Figure 22 Video webpage

There is a pan/tilt on the top-left of the website. You can click it to move the camera Up/Down/Left/Right; or choosing the right-left cruise, up-down cruise and centered. On the left, you can also select the Resolution, Quality, Brightness, Contrast and Zoom. Resolution can be 640x480, 320x240, and 160x120. The higher resolution, the higher clarity, while requiring more bandwidth. Quality can be “High”, “Standard” or “Low”. “High” consumes largest bandwidth, thus the frame per second will down. If you feel the frame per second (fps) is too slow, and want to increase it, you can select “Low” quality and lower resolution. If you hope to see clearer image, you may choose “High” quality and higher resolution. Brightness and Contrast can be changed according to different environment. “+” means add, “-” means reduce. “STD” means a standard (middle) value. Zoom will show the video in a scale of half or double. It won’t affect the transport fps or bandwidth. Click [Snapshot] will pop up a new page to snap a static JPEG image, you may www.vipcam.cn

- 20 -

click right key of mouse and select “save as…” to store it to your computer. Click [History], will pop up a History View Page (You must have inserted CF Card first).

Figure 23 History Images View

Under the ActiveX Control mode you can save the video on the local hard disk. Left –click the image display area of ActiveX Control, then select the corresponding function by right-click with your mouse.

Figure 1 The right-click menu of ActiveX Control

www.vipcam.cn

- 21 -

You can choose the function what you need from option at the bottom of the ActiveX Control as well.

Figure 2

The bottom menu of ActiveX Control

There are two kinds of video format such as IPEG and MPEG4. The video file size as JPEG format is bigger than MPEG4 format. The image can be saved in the preconcerted local address by click the [snapshot] button. The automatic name of image will be saved at once.

4.5 Setup VS-IPC1002 on Web You can click [System Setup] to modify all parameters. See the Chapter 5 for details .

4.6 Mounting the VS-IPC1002 The VS-IPC1002 can be placed on a flat surface, such as shelf and bookcase. It also can be installed on the wall with included pedestal or on the tripod by using the bottom standard tripod. Please make sure the network cable is settled before you use VS-IPC1002. This is to prevent the damage of VS-IPC1002 which caused by the VS-IPC1002 break away from the fixing surface.

CAUTION: The VS-IPC1002 should be mounted indoors or inside a weatherproof enclosure. Outdoor exposure may result in damage and will void your warranty. CAUTION: Don’t mount the VS-IPC1002 with the lens facing into direct sunlight. Prolonged exposure to direct sunlight will damage the sensor.

VS-IPC1002 can be installed on the vertical wall by using mounting pedestal. Choosing the observed areas becomes more convenient by adjusting the VS-IPC1002 platform at any point of view. Step 1. Find a suitable location to mount the camera.

www.vipcam.cn

- 22 -

Step 2. Using the mounting bracket as a guide, mark the location of the two mounting holes. Step 3. Drill a “¼” hole for each screw. Step 4. Use a hammer to tap the two plastic anchors into the holes. Step 5. Use the two screws to fasten the bracket to the wall. Step 6. Place the camera on the mounting bracket platform and rotate the camera to be facing in the desired direction. Step 7. Secure the camera to the mounting bracket using the thumbscrew located on the bottom of the platform. Step 8. Loosen the tilt adjust thumbscrew and tilt the camera toward the area to be observed.

www.vipcam.cn

- 23 -

5 System Configuration 5.1 System status This page shows status of the system for diagnose.

Figure 26 System Status View

www.vipcam.cn

- 24 -

5.2 Management

Figure 27 Management View

“ name”: Determine the name of visitor who can . The can set up to 16 case sensitive character names. “”: Set up a for the visitor . The must be between one and sixteen bytes which is English and number. “Authority”: Determine the permission lever for “”, “”, “Guest” or “Disabled”. :

This permission allows the have full authority including writing permission to all the sections.

:

This permission level allows the access VS-IPC1002 menus without the setup authority.

Guest:

This permission level allows the to access Vilar IP camera’s video only. The does not have any permission to change it.

disabled

Make the disable, no access.

to

”Allow Anybody Visit”: VS-IPC1002 provide a Guest Zone, if you checked www.vipcam.cn

- 25 -

this, any temporally visitors may enter Guest Zone to see the video without enter any name/. If you unchecked this (default), the visitors have to enter at least a “Guest” permission name/ to visit the “Guest Zone”. At any time, the “ Zone” only allows “” & “” permission to visit. ”Vilar Backbone” Service Setup: This service as a connection of central server is useful for customer. You can choose start “Vilar Backbone” function and enter the correct name, , IP address of server and port information. (Vilar Backbone service depends on the Vlilar Camera addition service provided by network carrier. Please connect your camera dealer to make sure the availability of this service in your area and the relative charge of this service.)

5.3 Network

Figure 28 Network Setup View

www.vipcam.cn

- 26 -

5.4 Date and Time

Figure 29Date and Time Setup View

5.5 Video

Figure 30 Video Setup View

www.vipcam.cn

- 27 -

5.6 JPEG Encryption

Figure 31JPEG Encryption Setup View

Figure32 Require Input in Client Web Browser

www.vipcam.cn

- 28 -

Figure 33 Input in Web Browser (ActiveX)

Figure 34 Input in Web Browser (Java)

5.7 E-mail

Figure35 E-mail Setup View

www.vipcam.cn

- 29 -

This section sets up the necessary Email server information. The will have to enter a valid Name and to the Email server. This information is necessary to allow email notification features. “SMTP Server”: The will have to enter the Email server address here. “Sender’s Email” This will determines Vilar IP camera’s Email address. “Email Requires Authentication”: If checked, the will have to provide the name and in order to access the Email server. “E-mail Sender name”: Enter the name or name to the Email server. “E-mail Sender ”: Enter the for the above name.

5.8 FTP

Figure 36 FTP Setup View

www.vipcam.cn

- 30 -

5.9 Sensors and Motion Detection

Figure 37 Sensors and Motion Detection Setup View

5.10

Scheduler Trigger

Figure 38 Scheduler Trigger Setup View

www.vipcam.cn

- 31 -

5.11

System Maintenance

Figure 39 System Maintenance View

5.12

System Log

Figure 40 System Log View

www.vipcam.cn

- 32 -

5.13

Guest Zone

Figure 41 “Guest Zone” View

www.vipcam.cn

- 33 -

6 Visit VS-IPC1002 over INTERNET The common environment for VS-IPC1002 using as follow: 1. In Local Area Network (LAN) only. 2. Direct connect to INTERNET via xDSL (PPPoE) Modem. 3. Share one INTERNET connection with other computer, and connect to INTERNET via a gateway or router.

Figure 42 Vilar IP camera’s Application Environment

If your LAN is connected to the Internet through a high speed (broadband) Internet connection, you can access your cameras by web browser from anywhere on the Internet. To do this you need to: 1. Know your WAN (Internet) IP address. This is the IP address that your Internet Service Provider gives you to access the Internet. It may be static (always the same) or dynamic (can change from time to time). 2. Make sure the router or gateway can visit the VS-IPC1002 through the port 80. 3. Make sure your camera’s default gateway is set as your LAN (local) IP address of your router/gateway.

6.1 WAN IP Address The WAN IP address is necessary when you want connect your home or business network to the internet. The WAN IP address is different from the LAN www.vipcam.cn

- 34 -

IP address. It can be seeing by outside network, and it is supplied by Internet Service Provider to grant you access the internet. Your WAN IP address is stored by your gateway router which uses it to connect the Internet. All the devices on your network connect to the Internet via your gateway router. You can find your current WAN IP address by checking your router’s status page. Also there are various websites such as www.whatismyip.com will help you find your current IP address. The term gateway is used generically to mean the device that connects a local network to the Internet. A gateway may be a router, a PC running software which allows it to act as a gateway such as a proxy server, or some other device. Most home networks use a NAT (Network Address Translation) router as a gateway. The term gateway router refers to such a device Static versus Dynamic IP address The IP address (or addresses) your ISP has provided will either be static (it means the IP address never change), or dynamic (it means the IP address change periodically). There are more challenges can be bring by dynamic address, because the IP address might has changed when you visiting. The change frequency of dynamic address depends on your Service Provider. Furthermore the new address will be produced when the DSL modem reconnecting or reboot. The IP address is not necessary when you using the DDNS via the domain name to find your network such as tom.vipcam.cm.

6.2 Network Address Translation (NAT) Most home routers and business firewalls have the network address translation (NAT) function. NAT can translate your external network or WAN IP address as your getaway router inside address. You can imagine the router includes two parts, one is LAN (inside part) another one is WAN (outside or internet part). A connection requirement can not reach your router from the internet until you have intercalated it. This process is known as port forwarding or port redirecting.

6.3 Port Forwarding All the T/IP (internet) networks are using software port to connect with each other. The port can be considered as channels of television. Default all the websites are through the channel 80 (port), the websites and the images can be sent via the port 80 to your browser by VS-IPC1002. Therefore this channel (port) can received the visiting application without the encumbrance from your router/firewall. You can visit VS-IPC1002 from the external network and those two ports have to transmitting or redirecting on the LAN IP address port by your gateway router. Thus the setting software of your router has to possessing transmission or redirecting function. www.vipcam.cn

- 35 -

Before setting up port forwarding, it’s best to configure your VS-IPC1002 to use a static LAN IP since your port forwarding setup will need to be updated if the camera’s LAN IP addresses changes. Note: Forwarding ports to your camera does not pose any additional security risk to your LAN.

6.4 Default Gateway Devices (PCs, cameras, etc.) on your network connect to the Internet via a gateway. For most home networks, a NAT router serves as the gateway. For business LANs, the gateway may be a PC running gateway software. In order to connect all devices on your network with Internet, gateway has to know the LAN IP address of itself. If your camera is set up to use DH, then it will retrieve this address automatically from your router. However, if you have configured your camera to use a static IP address, you must also be sure that you have set the correct gateway IP address in order to connect your camera to the Internet.

Note: It is impossible to test WAN (Internet) visit your cameras by a PC connected to the LAN. To be sure that your cameras are accessible by the Internet, you can ask some one who does not in your LAN to visit your VS-IPC1002 from internet by using your WAN IP address. You camera is now live on the Internet. Browsing your camera from the Internet is the same as browsing on your LAN except that you must enter your WAN IP address (or camera domain name if you’ve set up a DDNS service) instead of the LAN IP address.

6.5 Accessing Multiple Cameras on the Internet You have to assign different port to each VS-IPC1002 when accessing multiple cameras on the internet. Because of that your gateway can transmitting the correct request to correspond camera. All the websites requests will be sent to port 80 by browser if the default setting does not change. However the port 80 transmit the request to one LAN IP address only, therefore all the websites requests on the port 80 will send to that address. The solution of this problem is to set up the router, assign a different port number to each camera. For example, you may set up your second camera to use port 81. When you want to access this camera, you would tell your browser to use port 81, instead of port 80. In your router’s port forwarding setup, you would need to

www.vipcam.cn

- 36 -

forward port 81 to the LAN IP address of the second camera. Web page requests arriving at port 81 will automatically be directed to the second camera’s address.

To instruct your browser to use a different port, other than 80, to access a web page, you would add the port number at the end of the IP address or URL, separated by a colon. For example, to access a camera on port 81 if your WAN IP address is 210.82.13.21, you would enter http:// 210.82.13.21:81 into your browser’s address bar. You can do the same thing with a URL such as http://tom.vipcam.cn:81. The steps to set up remote access are as follows: 1. Go to your gateway router setup page and configure port forwarding to port 81 to LAN IP address of Camera_1(e.g. 192.168.0.151) and port 82 to the LAN IP address of Camera_2(e.g. 192.168.0.152). 2. From somewhere on the Internet, open up Internet Explorer and enter your WAN IP address followed by a colon and the port number such as: http://210.82.13.21:81 to access Camera_1.

Note: Some routers use port 80 for remote configuration and it’s possible to experience a conflict when using port 80 for camera access. Therefore, you prefer to use port 81 for your first camera, port 82 for the second, etc... This setup also makes it easier to which camera is using a particular port number.

6.6 Dynamic Domain Name Service (DDNS) Your Internet Service Provider (ISP) provides you at least one IP address which you use to connect to the Internet. The address you get may be static, meaning it never changes, or dynamic, meaning it’s likely to change periodically. Just how often it changes, depends on your ISP. A dynamic IP address complicates remote access since you may not know what your current WAN IP address is when you want to access your network over the Internet. The solution to the dynamic IP address problem comes in the form of a dynamic DNS service. The Internet uses DNS servers to lookup domain names and translates them into IP addresses. Domain names, such as www.vipcam.cn, are easy to as aliases of IP addresses. A dynamic DNS service is unique because it provides a means of updating your IP address so that your listing will remain current when your IP address changes. There are several excellent DDNS services available on the Internet and best of all most are free to use. Two such services you can use are www.3322.org and www.vipcam.cn. You’ll www.vipcam.cn

- 37 -

need to with the service and set up the domain name of your choice to begin using it. Please refer to the home page of the service for detailed instructions. A DDNS service works by ing your WAN IP address to its servers periodically. Your gateway-router may DDNS directly, in which case you can enter your DDNS information into your router and it will update the DDNS servers automatically when your IP address changes. Please consult your router’s documentation for more information. If your router does not DDNS, you can setup the Vilar IP camera’s DDNS client.

6.7 Configuration Example At home or business LAN, one or more computers and Vilar IP cameras are connected to the same IP Sharing Device(Gateway/Router), IP Sharing Device was assigned a public IP Address by ISP(e.g. 210.82.13.21), while each devices in LAN has assigned a different LAN IP(e.g. 192.168.0.151/192.168.0.10/192.168.0.11).

INTERNET Remote PC xDSL Modem

IP Sharing Device Public: 210.82.13.21 Privacy:192.168.0.1

IPCamera 192.168.0.151

PC1 192.168.0.10

PC2 192.168.0.11

Figure 43 Typical Network Environments

Now, every LAN devices connect to INTERNET via NAT function provided by IP Sharing Device. However, from the point of remote PC’s view, remote PC see only an IP Sharing Device, it doesn’t know how many PCs existed inside privacy LAN. This IP Sharing Device is also acted as a firewall. Thus, we have changed the setting of IP Sharing Device; let public PC has the www.vipcam.cn

- 38 -

opportunity to access LAN devices, e.g. VS-IPC1002. We can achieve this goal by enable Reversal NAT (RNAT) function of IP Sharing Device. 1. “Virtual Server”: Many routers have “Virtual Server” . You must forward the WAN 80 T port to LAN Vilar IP camera’s IP and Port. (If you visit 210.82.13.21’s 80 port outside, you will be forward to LAN 192.168.0.2’s 80 port). 2. Another method is the “DMZ Host”. If enabled to use a LAN device as the DMZ host, the outside PC will be able visit this LAN device directly, as if there is no IP Sharing Device exists. This method only one LAN device exposed to the WAN. Thus, if you have more Vilar IP cameras, you have to use the above method. Take D-Link (http://www.dlink.com) DI-604/DI-614+/DI-624 as an example: 1) to your router; 2) In WAN configuration, input the PPPoE name and provided by your ISP; 3) Click Advanced on Top of homepage; 4) Click Virtual Server (Note: If you use Virtual Server mode, you must turn DMZ host function off first. DMZ Host function will disable all Virtual Server function) 5) Input the following information on page: Enabled/Disabled: Enabled Name: VilarCamera Private IP: Input Vilar IP camera’s Address, e.g. 192.168.0.151 Protocol Type: T Private Port: 80 Public Port: 80 Schedule: Always 6) Click Apply to save. Vilar IP camera can be accessed in WAN.

www.vipcam.cn

- 39 -

7 Technical Parameters Items

Description

Video Video Input

Single high quality CMOS Sensor (300，000 pixels)

Compression

Motion-JPEG

FPS

30 frame per second (640x480) maximum.

Resolution

Typical Bandwidth

VGA (640x480) QVGA (320x240) QQVGA (160x120) Optional 160x120@10fps : 300 kilobits ～ 480 kilobits 320x240@10fps : 640 kilobits ～ 960 kilobits 640x480@10fps : 3.2 Megabits ～ 4.8 Megabits 160x120@30fps : 900 kilobits ～ 1.44 Megabits 320x240@30fps : 1.92 Megabits ～ 2.88 Megabits 640x480@30fps : 9.6 Megabits ～ 14.4 Megabits

Interface Digital Input

2-way Open/Close Input

Relay Output

1-way Relay Output（36V AC/DC, 2A）

Connection

5 Pins

Network Interface Protocol

Ethernet 10/100Base-T RJ-45 Transport: UDP/IP，T/IP，SMTP/HTTP/FTP Other: DNS and DH client, DDNS

Power Supply

5V DC

Consumption 5W Maximum Physical Cell

ABS plastic

Packing Size

27×24×12.4 cm

Temperature

0℃~45℃

Humidity

50℃ 95%

Management System Setup

Web Page

Upgrade

Firmware upgrade by Web

www.vipcam.cn

- 40 -

Other U

32bit ARM@66MHz frequency.

SDRAM

16MByte

FLASH

4MByte

www.vipcam.cn

- 41 -
