Welcome to HUAWEI B970b Wireless Gateway

HUAWEI B970b Wireless Gateway Guide

Notice Copyright © Huawei Technologies Co., Ltd. 2010. All rights reserved.

1 2

No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders under licenses.

3

8 9

NO WARRANTY

10

11

Trademarks and Permissions

4

HUAWEI, and

are trademarks or ed

trademarks of Huawei Technologies Co., Ltd.

5

Other trademarks, product, service and company names mentioned are the property of their respective owners.

6 Notice

7

Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers, thus the descriptions herein

may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation.

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.

Import and Export Regulations

12

Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary governmental permits and licenses in order to export, reexport or import the product mentioned in this manual including the software and technical data therein.

Safety Precautions Read the safety precautions carefully to ensure the correct and safe use of your wireless device. Do not switch on your device when the device use is prohibited or when the device use may cause interference or danger. Do not use your device while driving.

Follow the rules or regulations in hospitals and health care facilities. Switch off your device near medical apparatus. Switch off your device in an aircraft. The device may cause interference to control signals of the aircraft. Switch off your device near high-precision electronic devices. The device may affect the performance of these devices. Do not attempt to disassemble your device or its accessories. Only qualified personnel are allowed to service or repair the device.

Do not place your device or its accessories in containers with strong electromagnetic field. Do not place magnetic storage media near your device. Radiation from the device may erase the information stored on them. Do not put your device in a hightemperature place or use it in a place with flammable gas such as a gas station. Keep your device and its accessories away from children. Do not allow children to use your device without guidance. Use approved accessories only to avoid explosion. Observe the laws or regulations on device use. Respect others’ privacy and legal rights when using your device.

Table of Contents Table of Contents 1 Quick Start 1 Appearance ................................................1 PC Configuration Requirements.................2 Installation ..................................................2 Making a Call..............................................4 Dial-up Access ...........................................4 Restoring the Factory Defaults...................5

Using the Management Page 6

Management Page Overview .....................6 Viewing Configuration Info .........................6 Quick Setup................................................7

Configuring Your Computer 10

Wireless Configuration .............................10 Configuring the PC Network.....................11

Advanced Settings 12

Overview ..................................................12 System Management ...............................12 SIM Settings .............................................13 Mobile Network Settings...........................14 Dial-up Settings ........................................15 DH Settings ........................................16 Clip Settings .............................................17 WLAN Settings .........................................17

Security Settings 21 Firewall Switch .........................................21 LAN MAC Filter ........................................21

LAN IP Filter............................................. 21 Virtual Server ........................................... 22 DMZ Settings ........................................... 23 UPnP Settings.......................................... 23 Remote Management .............................. 23

Troubleshooting 25 Abbreviations 28

1 Quick Start ed functions and actual Note The appearance are subject to your product purchased. The following pictures are displayed for illustration purpose only. For details of your product selection, consult your service provider.

Indicator

• Steady on and in yellow: The WLAN is enabled • Blinking: Data is being transmitted

Signal

• Steady on and in green: Signal strength is strong • Steady on and in yellow: Signal strength is medium • Steady on and in red: Signal strength is weak • Fast blinking in red: The SIM card does not exist or the PIN code is not verified

Mode

• Double blinking in green: Searching for the network • Blinking in green: ing with the 2G network • Steady on and in green: 2G data service connected • Blinking in blue: ing with the 3G network • Steady on and in blue: WCDMA data service connected • Steady on and in cyan: HSPA data service connected

Appearance

Power indicator

Phone

WLAN indicator

Ethernet

ON/OFF key Signal strength indicator Network mode indicator

Internal/External Antenna Charger Pedestal

Indicator Power

Status

Status

WLAN

• Steady on and in yellow: The device is switched on successfully

1

PC Configuration Requirements

PC Configuration Requirements The recommended PC configurations for using the device are as follows: • • • •

U: Pentium 500 MHz or above Memory: 128 MB RAM or above Hard disk: 100 MB or above available space Operating System: Windows 2000, Windows XP, or Windows Vista • LCD resolution: 800*600 pixel or above, recommended 1024*768 pixel • Interface: standard USB interface • Internet Browser: Internet Explorer 6.0 or Internet Explorer 7.0, Firefox 1.5 or Firefox 2.0, Safari 3.0

◆ Step 2: Connect to the power adapter Use a power adapter that is compatible with the device; otherwise, the device may be damaged.

Installation ◆ Step 1: Insert the SIM card Before inserting or removing the SIM card, you must disconnect the device from the power Warning adapter.

!

Remove the card slot out of the device. Slide the SIM card into the card slot with the golden facing upward. Insert the card slot into the device.

2

◆ Step 3: Connect to a PC If the indicator of the Ethernet interface connecting with a network cable is on, the connection is successful. The Ethernet cable cannot be longer than

Installation 100 meters (328 feet). To achieve better effect, use the shielded cable.

◆ Step 5: Place the device The device can be placed horizontally on a table, hanging against the wall, or leaning against the pedestal. Place the device on a higher place or near the window, so it can receive stronger signals. Press the bayonet of the pedestal, and place the device into the pedestal as shown in the figure. Thus, the device can lean against the pedestal.

◆ Step 4: Connect to a telephone set The communication quality of the telephone set can be interfered by the wireless signal. Place the telephone set one meter away from the device. To avoid electrical devices from interfering by the wireless signal, place electrical devices one Warning meter away from the device.

!

◆ Step 6: Connect the external antenna (optional) Connect the external antenna cable with the antenna jack on the main unit. Screw the cable to make sure that the antenna is tightly connected with the antenna jack.

3

Making a Call

Internal/External Aerial switch

Dial-up Access By default, the device dials up to access the Internet as required. You can directly use the network services such as web browsing, and receiving or sending emails.

Logging In to the Management Page

Note You can choose whether to use the external

antenna. In the area covered with strong signal, you can switch to the antenna internal and uninstall the external antenna. In the area covered with weak signal, you can install the external antenna and switch to the antenna external. For details of antenna selection, consult your local dealer.

◆ Step 7: Power On/Off Press and hold the On/ Off button to power on or off the device.

1

Start the Internet browser and enter the address http://192.168.1.1 in the address bar.

2

Select a type, enter the , and then click . • : This type is authorized to view and change configurations. The default is . • : This type is authorized to view only the basic status information. The default is .

Note To avoid the configuration conflict, only one

Making a Call When you hear the dial tone after picking up the handset, you can make a call.

4

is allowed to to the management page at a time.

Restoring the Factory Defaults

Accessing the Internet 1

Note If PPP Connection is Auto or On

Demand, refresh the page to view the current network connection status.

Click Connection.

3

Note • If you are required to enter the PIN code, enter the correct one. If you fail to enter the correct PIN or PUK code, the network-related functions are unavailable. • The SIM card is supplied by the service provider. For details, your service provider. • When the Save PIN Code check box is selected, the Auto validation is enabled. • If Auto validation is enabled, the PIN code is recorded and automatically validated after each restart.

2

If PPP Connection is Manual, click Connect / Disconnect to connect to or disconnect from the network.

Wait for several minutes. If you are notified that the connection is successful, you can start the browser and enter the website address to access the Internet.

Restoring the Factory Defaults If you need to reconstruct the network or you forget the changes of some parameters, you can choose to restore factory defaults and reconfigure the device. Reset

Reset: Press and hold it to restore the factory defaults.

Note After this operation, all configurations are restored to the defaults.

5

2 Using the Management Page Management Page Overview

Item

Green icon

Red icon

Operation Functions

SIM

The card is valid. The card is not inserted or is invalid.

The following table shows the main operations in the management page.

WAN

The PPP dial-up connection is established.

Item

Description

Basic Status Displays the parameter configuration status of the device. Quick Setup Quickly configures the device. Connection

Displays the network connection status and connects to the network.

Advanced Settings

Configures the advanced settings.

Security

Configures the security settings.



Log out of the management page.

WCDMA The WCDMA network is available.

The PPP dial-up connection is not established. The WCDMA network is unavailable.

Note If the device is ed with

other network modes, the corresponding network connection status is displayed.

SIG

The signal strength from weak to strong is shown as follows:

Device Status The following table shows the status information of the device.

6

Viewing Configuration Info On the configuration page, you can view the current parameter configuration information and the network connection status.

Quick Setup 1

Click Basic Status.

2

Click Advanced on the right part of the page to view the advanced status.

3

Click Refresh to view the current status on the advanced status page.

Quick Setup You can use the quick setup wizard to configure and maintain the basic parameters of the device. Click Quick Setup to access the welcome page. Click Next to configure the PPP profile settings.

provider provides the relevant parameters, select Static and enter their values. Otherwise, select Dynamic and the device automatically obtains them.

Configuring PPP Dial-up Settings PPP Connection: Select the dial-up access mode. • Auto: The device automatically connects to the Internet and does not disconnect when no data is transmitted. • On Demand: The device automatically connects to the Internet when data transmission exists. When the duration of no data transmission exceeds the maximum idle time, the device disconnects the Internet connection. • Manual: The device connects to the Internet after you click Connect on the connection page. For details, see "Accessing the Internet".

Configuring PPP Profile Settings

PPP Authentication: This service is provided by your ISP. For details, consult your ISP.

• Profile Name: Enter a profile name when the text box is empty. • Dial-up Number/PPP Name/PPP : Enter these three parameters provided by the internet service provider (ISP). The dial-up number is used to initiate the network call; the PPP name and PPP is used to obtain the service authorization provided by the ISP. • APN/IP Address: Select the mode for obtaining the access point name (APN) and IP address. If the service

Configuring WLAN Settings (Name) SSID: Enter a name for your wireless local area network (WLAN). • The service set identifier (SSID) is used to identify a WLAN. A PC and the wireless device can perform normal data communication only when they have the same SSIDs. To ensure the WLAN security, do not use the default SSID. You can enter a character string as the SSID, such as MyHome.

7

Quick Setup SSID Broadcast: Enable or disable the SSID broadcast. • Enabled: The device broadcasts the SSID of the WLAN and s can easily access the WLAN. In this case, unauthorized s can also access the WLAN because the SSID is broadcasted. • Disabled: The device does not broadcast the SSID of the WLAN. Before accessing the WLAN, a must obtain the SSID of the WLAN. In this case, the WLAN security is improved.

Note For the convenience of s accessing the WLAN, you can select Enabled for SSID Broadcast when you configure the WLAN setting. After the setting, you can select Disabled to improve the WLAN security.

• WPA-PSK: It is a 256-bit data encryption method that can automatically change the key. • WPA2-PSK: It is a more secure version of WPA-PSK and it s the IEEE 802.11i standard. • WPA Encryption Algorithm: TKIP, AES, TKIP+AES. • WPA Pre-Shared Key: You can enter a 64-character hexadecimal value or 8-63-character ASCII value as the key. The ASCII value contains all characters that can be entered through the PC keyboard, and the hexadecimal value contains numbers of 0-9 and characters of A-F. For example, you can enter the ASCII value of 1234abcde as the key. • Network Key Rotation Interval: It is used to set how long a network key is dynamically changed. By default, it is 0. To disable this function, you can set the value to 0 or null.

Configuring WLAN Encryption

WEP

To access the WLAN, you must set the wireless security key on your PC to be the same as that of the wireless device. No Encryption

• Wireless Equivalent Privacy (WEP) is a 64-bit or 128-bit data encryption method. The 128-bit WEP encryption provides higher security level. • Network Key 1: You can enter 5 ASCII characters or 10-character hexadecimal numeral to form a 64-bit key. You can also enter 13 ASCII characters or 26-character hexadecimal numeral to form a 128-bit key.

• For the convenience of s accessing the WLAN, you can select NO ENCRYPTION for the Encryption Mode when you set up a WLAN. It is not recommended to select this option in daily use.

8

WPA-PSK/WPA2-PSK

Quick Setup

Validating Quick Setup The last page of the wizard displays all the settings you have configured. • To accept the settings, click Finish. • To change the settings, click Back. • To quit the settings, click Cancel.

9

3 Configuring Your Computer This takes the Windows XP operating system (OS) as an example to describe how to configure your computer. For other OSs, the configurations may be different and you need to configure them as required.

Wireless Configuration The wireless configuration allows your PC to connect to the device through the wireless network. If you need only the Ethernet to connect your PC, you can skip this part.

Configuring the Wireless Network 1

Choose Start > Control > Network Connections > Wireless Network Connection.

2

Click Show Wireless Networks to display the wireless network connection list.

3

Select the network connection that the SSID is the same as that of the device, and then click Connect.

4

If the encryption parameter is set for the device, the Wireless Network Connection dialog box is displayed and requires the network key and confirmation. The value you entered must be the same as the WPA Pre-Shared Key or Network Key of the device.

5

Wait for a while after you enter the correct network key. The wireless connection icon displays in the status area in the lower right corner of the screen. Then, your PC can automatically connect to the device.

Configuration Requirements • To set up wireless network connection, your PC must be configured with the WLAN adapter that s the IEEE 802.11 b/g protocol. • If the encryption function is enabled, you need to ensure that all PCs connecting to the device use the same key as that of the device. • For the use of WLAN adapter, refer to the WLAN adapter guide provided by the manufacturer. • For the encryption configurations, see "Configuring WLAN Encryption". • For SSID parameters configuration, see "Configuring WLAN Settings".

10

Configuring the PC Network

Configuring the PC Network The recommended configurations of the PC are as follows: • Obtain an IP address automatically. • Deselect Use a proxy server for your LAN.

Configuring the Network Connection 1

Choose My Network Places > Properties > Local Area Connection.

2

Right-click the Local Area Connection icon and select Properties.

3

In the Local Area Connection Properties dialog box, select Internet Protocol (T/IP) in the This connection uses the following items list box, and then click Properties.

4

In the Internet Protocol (T/IP) Properties dialog box, select Obtain an IP address automatically and Obtain DNS server address automatically, and then click OK.

Disabling Proxy Settings 1

Start the Internet browser, and then choose Tools > Internet Options.

2

Select the Connections tab, and then click LAN Settings.

3

In the LAN Settings dialog box, deselect Use a proxy server for your LAN.

11

4 Advanced Settings Overview Click Advanced Settings, you can configure both the basic attributes and advanced parameters of the device, and also perform routine maintenance and management to the device. The following table shows the functions of the shortcut icons. Icon

Description Click to access the System page. Click to access the SIM Settings page.

Icon

Click to access the WLAN Settings page.

System Management Click

to access the System page.

Changing the You can change the to prevent unauthorized s from logging in to the management page.

Click to access the Mobile Network Settings page.

1

Click

Click to access the Dial-up Settings page.

2

Enter the current , and then enter the new and confirm it.

Click to access the DH Settings page.

3

Click Modify.

Click to access the Clip Settings page.

.

Upgrading the device 1

12

Description

Click

.

SIM Settings 2

Enter the path or click Browse to select the software image file to be updated.

3

Click Upgrade.

• After the system is upgraded, the system automatically restarts. Warning • The software programs for upgrading must come from the official website of Huawei or the official website of the service provider. • Upgrading the software does not change the configuration of the client.

!

Restoring the Factory Defaults If you need to reconstruct the network or you forget the changes of some parameters, you can choose to restore factory defaults and reconfigure the device. Click to access the Restore Defaults page, and then click Restore. this operation, all configurations are Note After restored to the defaults.

Restarting the Device 1

Click

2

Click Reboot.

to access the Reboot page.

Viewing the Version Information Click

to access the Version page.

SIM Settings Click

to access the SIM Settings page.

Enabling or Disabling the PIN Code 1

Click

2

Select Enable/Disable in the PIN Code Operation list box.

3

Enter the correct PIN code.

.

13

Mobile Network Settings 4

Click Apply.

2

Select Enable/Disable in the Auto Validate option button.

3

Enter the current PIN code.

4

Click Apply.

Changing the PIN Code When the PIN code protection is enabled, you can reset the PIN code.

1

Click

2

Select Modify in the PIN Code Operation list box.

3

Enter the current PIN code.

4

Enter the new PIN code and confirm it.

5

Click Apply.

.

Auto Validating PIN Code You can enable or disable the auto validate PIN code function.

1

14

Click

.

Mobile Network Settings Click page.

to access the Mobile Network Settings

Setting the Preferred Mode and Band 1

Click

2

Select the preference of connection mode in the Preferred Mode list box.

.

service provider provides only the Note • If2Gtheservice and the preferred mode is configured as 3G only, you cannot access the Internet.

Dial-up Settings • If the service provider provides only the 3G service and the preferred mode is configured as 2G only, you cannot access the Internet. • If the service provider provides neither the 3G nor 2G service, you cannot access the Internet regardless of the preferred mode.

4

In Manual mode, select the searched network and click Log on.

Dial-up Settings Click

3

Select the band to search the network in the Band list box.

4

Click Apply.

Configuring the Mode for Searching Network 1

Click

2

Select the mode for searching the network.

.

• Auto: The device automatically searches the network and s with it. • Manual: You need to manually search the network and with it.

3

to access the Dial-up Settings page.

Configuring the PPP Settings 1

Click

2

Enter the correct parameters.

to access the PPP Settings page.

• Profile List: Select a profile from the established dial-up connection list. If the drop-down list is empty, you need to create a profile list. • PPP Connection: Select the dial-up connection mode. • PPP Authentication: The service is provided by your ISP. For details, consult your ISP. • PPP Max Idle Time: The duration of the PPP connection is in idle. In On Demand mode, if no data is transmitted in this duration, the PPP connection automatically disconnects.

Click Apply.

15

DH Settings • PPP MTU: It is the maximum transmission unit (MTU) of the PPP connection. It is used to set the maximum number of bytes encapsulated in a single data frame. • PPP Max Dial Time: Set the maximum waiting time when connecting to the Internet.

3

◆ Deleting a Profile

1

Select a profile to be deleted in the Profile List drop-down list.

2

Click Delete.

Managing the Profile List Click

to access the Profile Settings page.

◆ Creating a Profile

1

Enter the profile information in the text box according to the prompts.

2

Click Save.

◆ Changing a Profile

16

1

Select a profile to be changed in the Profile List drop-down list. Relevant information is displayed in the corresponding text box.

2

Enter the profile information.

Click Save.

DH Settings Click to access the DH Settings page, you can set the mode for asg IP addresses in a LAN. DH automatically assigns IP addresses to the network devices. If you are using the DH server, you need to do the configurations on the PC connecting with the device. For details, see "Configuring the Network Connection". • IP Address: The default IP address of the device is 192.168.1.1. • Subnet Mask: The combination of the subnet mask and IP address enables the flexible sub netting. By default, the subnet mask is 255.255.255.0.

Clip Settings • DH Server: It is used to assign IP addresses dynamically. If the DH server is Enabled, it can automatically assign IP addresses for PCs. It is recommended to select Enabled for the DH server. • Start IP Address/End IP Address: It is used to define the IP address range that the host can use during the IP address assignment. For example, in the network segment 192.168.1.0/24, the default IP address of the device is 192.168.1.1. The host IP address can range from 192.168.1.2 to 192.168.1.254. The minimum range is a single IP address. • DH Lease Time: The DH server automatically assigns an IP address to each device connected to the network. When the leased time expires, the DH server checks whether the device is connected to the network. If the device is disconnected from the network, the server assigns the IP address to another device. Thus, the IP address is not wasted. Start IP Address must be smaller than Note • The or equal to the End IP Address. • If the DH Server is Enabled, the configurations of Start IP Address, End IP address, and DH Lease Time are valid; otherwise, you cannot configure them.

Clip Settings 1

Click

2

Select Clip Mode.

3

Click Apply.

to access the Clip Settings page.

WLAN Settings Click

to access the WLAN Settings page.

Enabling or Disabling the WLAN 1

Click

2

Select Enabled/Disabled to enable or disable the WLAN.

3

Click Apply.

to access the WLAN Enable page.

17

WLAN Settings

WLAN Basic Settings Click page.

to access the WLAN Basic Settings

◆ Wireless Interface

Auto and the device can automatically search for the channel.

◆ Configuring the 802.11 Mode Mode

Description

54g Auto

The WLAN has the best compatibility in this mode.

• It refers to the SSID and MAC address, and is used to identify the wireless device.

54g The WLAN has the best performance Performance in this mode.

◆ SSID

54g LRS

If the device has difficulties in communicating with devices conforming to the IEEE 802.11b standards, select this mode.

54g Only

The device can only work in the low performance 802.11g standard network mode.

• Entering a name (SSID) for your WLAN. • Enabling or Disabling the SSID Broadcast.

◆ Enabling or Disabling the AP Isolation • On: The terminals (PCs) connecting to the device through the WLAN cannot communicate with each other. • Off: The terminals (PCs) connecting to the device through the WLAN can communicate with each other.

◆ Selecting a Country

802.11b Only The device can only work in the low performance 802.11b standard network mode.

• Country: It is used to identify the country. Different countries have different standards on channel usage.

◆ Configuring the Transmission Rate

◆ Selecting a WLAN Channel • Channel: It refers to the channel that the device works with. If you do not know which channel to select, select

18

1

Select Auto, the device automatically searches the transmission rate.

WLAN Settings 2

Click Apply to submit the setting.

WLAN Advance Settings Click page.

to access the WLAN Advance Settings

A security key can protect your WLAN from illegal data attacking. The security key of your wireless device must be consistent with that of the PC. ◆ Configuring the 802.11 Authentication • Open: Open system authentication. A accessing the WLAN can choose WEP, WPA-PSK, WPA2-PSK or WPA-PSK|WPA2-PSK key to the authentication or choose No ENCRYPTION to skip the authentication. • Shared: Shared key authentication. It can use only WEP. The accessing the WLAN must use the WEP to authenticate.

◆ Configuring the Encryption Mode • Encryption modes: No ENCRYPTION, WPA-PSK, WPA2-PSK, WPA-PSK|WPA2-PSK and WEP. • For details, refer to "Configuring WLAN Encryption".

Configuring the MAC Filter Click to access the WLAN MAC Filter page.You can control and manage the clients accessing the WLAN, and improve the WLAN security performance. ◆ MAC Restrict Mode The following table shows the MAC address filter modes: Parameter Description Disabled

The MAC address filter function is disabled.

Allow

The clients with addresses in the MAC Addresses list are allowed to connect with the device through the WLAN.

Deny

The clients with addresses in the MAC Addresses list are not allowed to connect with the device through the WLAN.

19

WLAN Settings ◆ MAC Addresses • Enter MAC addresses in the list. The device can perform the access control over the clients whose MAC addresses are in the list.

WLAN Bridge Click

to access the WLAN Bridge page.

• Preamble Type: It has two options: Long and Short. In the case that the client (PC) s the Short type, the WLAN can have a better performance if it is Short. • MAX Associations Limit: It refers to the maximum number of connections. It is used to set the maximum number of concurrent WLAN s on the device. • Mode: It refers to the WLAN accessing mode. The device can work in two modes, as shown in the following table. The default value is Access Point.

Mode

Description

Wireless It is used to connect two or more access Bridge points. Access Point

20

The access points meeting the IEEE 802.11b/g standard or the wireless terminals can connect the wireless device.

• Bridge Restriction: It refers to the limitation to the peer MAC addresses. When it is Disabled, the device can access all the remote bridges; when it is Enabled, the device can only access the remote bridges that the addresses are in the address list. • Bridges: It refers to the physical address of the remote peer bridge. The device s the point-to-multipoint (PTM) bridge mode. • Peer MAC Address: It refers to the physical address list of the remote peer bridges. • Link Status: Up shows the successful connection and Down shows the failed connection.

5 Security Settings Click Security. You can configure the advanced security settings.

Firewall Switch Your device has a true firewall that controls the incoming and outgoing data flow and protects your computer from illegal intrusion.

1

Click

2

Select the Enable the firewall (main switch of the firewall) check box to enable the firewall.

.

Note • Only when the Enable the firewall

check box is selected, the other functions such as the IP address filter function, the MAC address filter function, and the WAN port ping function are available. • When the Enable LAN MAC address filter check box is selected, the default filter rules are available.

3

Select other options as required, and then click Apply.

LAN MAC Filter Your device s MAC filtering based on a list of either denied or allowed computers. A common method to restrict network access is to specify the Media Access Control (MAC) address. To locate the MAC address in the Windows OS, choose Start > Run, and then enter cmd. The command window is displayed, enter ipconfig/ all, and then press Enter. The MAC address is displayed as the Physical Address.

1

Click

2

Select LAN MAC Filter Mode.

3

Enter the MAC addresses of the clients and click Apply.

.

LAN IP Filter You can configure the device to block specific IP addresses so that they cannot be accessed from

21

Virtual Server computers in the local network.

1

Click

2

Select Protocol and Status.

3

Enter the IP addresses and corresponding ports to be blocked from accessing the LAN.

4

Click Ok.

3

• Name: Enter a name to the service provided by the LAN. • WAN Port: Enter the WAN port of the LAN in which the computer provides services. • IP Address: Specify a computer in the LAN to provide services. • LAN Port: Enter the LAN port of the computer that provides services.

.

• Validate: Click Apply. • Edit: Click • Delete: Click

following way: select a port from the Common Port list. The Protocol, Status, Name, WAN Port, and LAN Port will be set as the default values. If required, you can change them.

in the Modification column.

Your device s the virtual server to enable external computers to access WWW, FTP, or other services provided by the LAN.

22

Note You can also add a virtual server in the

in the Modification column.

Virtual Server

1

Click

2

Select Protocol and Status.

.

Enter values in the following text boxes:

4

Click Ok. • Validate: Click Apply. • Edit: Click • Delete: Click

in the Modification column. in the Modification column.

DMZ Settings

DMZ Settings If your PC cannot run network applications through the device, you can set the computer to access the Internet unlimitedly by configuring the IP address of the computer in the demilitarized zone (DMZ). However, the DMZ computer is not protected by the firewall. It is vulnerable to attack and may also put other computers in the home network at risk.

UPnP Settings The Universal Plug and Play (UPnP) service allows other network s to control your device’s network features to realize the intelligent interconnection.

1

Click

2

Select Enabled/Disabled for UPnP Status to enable or disable the UPnP service

3

Click Apply.

.

1

Click

2

Select Enabled/Disabled for DMZ Status to enable or disable the DMZ service.

3

Enter the local IP address of the computer that is specified as a DMZ host.

The remote web management allows the access and control of the device either from the home network or from the Internet.

4

Click Apply.

When you are on a trip, you can maintain your device through the remote web management service. It also allows your ISP to help you solve the device problems from a remote location.

.

Note Only one computer can be specified as a DMZ host at a time.

Remote Management

1

Click

.

23

Remote Management

24

2

Select Enabled/Disabled for Remote Status to enable or disable the service.

3

Enter the IP address that can access and control your device.

4

Click Apply.

6 Troubleshooting What to do if a PC in the LAN cannot access the Internet?

1

If the power indicator is off, you need to check whether the power adapter is normally connected.

2

If the signal strength indicator is off, you need to check whether the area is covered by the network.

3

4

5

If the area is covered by the network, you need to check whether the network mode is correct. For information about network mode, see "Mobile Network Settings". If the indicator of the Ethernet interfaces blinks, the corresponding Ethernet interface is normally connected. If the indicator is off, you need to check and ensure that the related Ethernet connection is normal.

are correct, and see "Configuring PPP Profile Settings" for details.

6

If the DH service is disabled and the PC obtains the IP address dynamically, the PC also cannot access the Internet. You can change the mode to manually assign an IP address. See "Configuring the Network Connection".

7

Check whether the driver of the network adapter is correctly installed.

8

If the preceding methods cannot solve the problem, please consult your service provider.

What to do if a PC in the WLAN cannot access the WLAN?

1

If interferences or shields near the device exist, you can adjust the position of the device. When the signal strength is strong, you can move to the next step.

You must configure the correct PPP name and PPP when you access the Internet through the device. Check whether they

25

2

Check and record the following data on the network adapter of your PC: SSID, WEP type, and key.

3

Check and record the following data on the device: SSID, WEP type, and key.

4

Compare the recorded data, the SSID on the network adapter should be ANY or be the same as that on the device. The WEP type and key on the network adapter and device should be the same. Otherwise, you need to change the data on the network adapter.

What to do if I forgot the IP address of the LAN interface? If you forgot the IP address of the LAN interface, you can enter http://e.home and to the management page when the PC obtains the IP address automatically.

26

What to do if bridging between two devices is unsuccessful?

1

Make sure that the two devices work on the same channel. For details, see "Selecting a WLAN Channel".

2

Make sure that the MAC address of one device is in the peer MAC address list of the other device. For details, see "WLAN Bridge".

When the signal strength is normal, what to do if the ing rate is low? In this case, you need to set the value in the registry as follows:

1

Choose Start > Run.

2

Enter regedit in the Open text box and then click OK.

3

Select parameters in the following directory: \HKEY_LOCAL_MACHINE\SYSTEM\CurrentC ontrolSet\Services\Tip.

4

Choose Edit > New > DWORD Value.

5

Rename New Value #1 to TWindowSize.

6

Right-click TWindowSize and then select Modify.

7

Select Decimal and enter 65535 in the Value data text box, and then click OK.

8

For the DWORD Value of DefaultRcvWindow, do the same operations as that of TWindowSize.

27

7 Abbreviations

28

3G

The Third Generation

WLAN

Wireless Local Area Network

AP

Access Point

WCDMA

Wideband CDMA

APN

Access Point Name

WI-FI

Wireless Fidelity

CDMA

Code Division Multiple Access

DH

Dynamic Host Configuration Protocol

DNS

Domain Name Server

EDGE

Enhanced Data rates for GSM Evolution

GSM

Global System for Mobile communications

GPRS

General Packet Radio Service

HSPA

High Speed Packet Access

HSDPA

High Speed Downlink Packet Access

HSUPA

High Speed Uplink Packet Access

IP

Internet Protocol

LAN

Local Area Network

LED

Light Emitting Diode

NAT

Network Address Translation

POTS

Plain Old Telephone Service

UMTS

Universal Mobile Telecommunications System

WAN

Wide Area Network

Version:V100R002_03 Part Number: 31010APJ
