Hp Compaq Nc6400 Laptop Specifications h3m3o

1 of 34

http://h18000.www1.hp.com/products/quickspecs/12446_ca/12446_ca.HTML

Overview

Standard Features

Options

Memory

Storage

HP Compaq nc6400 Notebook PC

Technical Specifications

HP recommends Windows Vista® Business

1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14.

Volume Mute Button with LED Volume Down Button Volume Up Button Integrated Microphone Biometric Fingerprint Sensor Pointstick Pointstick Buttons Stereo Speakers SD Media Slot Fast Infrared Port Touchpad with scroll zone Touchpad Buttons Hard Drive Activity LED Battery Charging LED

15. 16. 17. 18. 19. 20. 21. 22. 23. 24. 25. 26. 27. 28.

Power/Standby LED Wireless On/Off LED PC Card Eject Button PC Card Slot Headphone Jack Microphone Jack 2 USB 2.0 Ports Power Button with LED HP Info Centre Button Wireless On/Off Button with LED Presentation Mode Button Ambient Light Sensor Dual-band Wireless LAN Antennas 5-Band Wireless WAN Antennas (enabled with WWAN option)

5/13/2010 1:53 PM

2 of 34


1. 2. 3. 4. 5.

Integrated Smart Card Reader MultiBay II Drive with Easy Release Optical Drive Button USB 2.0 Port RJ-45 Port (NIC)

6. 7. 8. 9. 10.

RJ-11 Port (Modem) VGA/External Monitor Port S-Video TV Out Power Connector Kensington Lock Slot

At A Glance Genuine Windows Vista Business 32, Genuine Windows Vista Home Basic 32, Genuine Windows XP Professional, Genuine Windows XP Home Edition, or FreeDOS Sleek light-weight design starting at under 4.6 lb (2.1 kg) and 1.1 inch (29.2 mm) thin at front 14.1-inch wide screen display Intel® Core™ 2 Duo processors and Intel Core Duo processors Mobile Intel 945GM Express Chipset or Mobil Intel 945PM Express Chipset Up to 4GB* of 533- or 667-MHz DDR2 SDRAM, dual channel memory ATI Mobility Radeon X1300 or Intel Graphics Media Accelerator 950 Up to 100-GB 7200 rpm, -removable hard drive Optional integrated HP ev2200 1xEV-DO or HP hs2300 HSDPA Broadband Wireless module Optional integrated 802.11 a/b/g or 802.11 b/g wireless LAN module and Bluetooth® for optional Intel Centrino™ Duo mobile technology Protected by three-year standard parts and labour warranty – certain restrictions and exclusions apply * Above 3-GB, all memory may not be available due to system resource requirements. Overview

Processors

Standard Features

Options

Memory

Storage


Intel Core 2 Duo Processor T7600 (2.33-GHz, 667-FSB, 4-MB L2 cache)* Intel Core 2 Duo Processor T7400 (2.16-GHz, 667-FSB, 4-MB L2 cache)* Intel Core 2 Duo Processor T7200 (2.0-GHz, 667-FSB, 4-MB L2 cache)* Intel Core 2 Duo Processor T5600 (1.83-GHz, 667-FSB, 2-MB L2 cache)* Intel Core 2 Duo Processor T5500 (1.66-GHz, 667-FSB, 2-MB L2 cache)* Intel Core Duo Processor T2600* (2.16-GHz, 667-MHz FSB, 2-MB L2 cache) Intel Core Duo Processor T2500* (2.00-GHz, 667-MHz FSB, 2-MB L2 cache) Intel Core Duo Processor T2400* (1.83-GHz, 667-MHz FSB, 2-MB L2 cache)

5/13/2010 1:53 PM

3 of 34


* Intel's numbering is not a measurement of higher performance. NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds n battery optimization mode. Operating System

Preinstalled

Genuine Windows Vista Business 32* Genuine Windows Vista Home Basic 32* Genuine Windows XP Professional SP2 Genuine Windows XP Home Edition SP2 FreeDOS

ed (select drivers available on http://www.hp.com)

Genuine Windows Vista Business 64*† Genuine Windows Vista Enterprise*† Genuine Windows 2000 SUSE Linux Enterprise Desktop 10

Certified

* Certain Windows Vista product features require advanced or additional hardware. See http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade Advisor can help you determine which features of Windows Vista will run on your computer. To the tool, visit http://www.windowsvista.com/upgradeadvisor. † At initial boot, either 32- or 64-bit can be selected. This is a one time selection and the other version will be deleted. Chipset

Mobile Intel 945PM Express Chipset with 667-MHz front side bus (models with discrete graphics) or Mobile Intel 945GM Express Chipset with 667-MHz front side bus (models with integrated graphics)

Graphics

For discrete graphics models with 512MB of system memory: ATI Mobility Radeon X1300 256MB HyperMemory* Microsoft DirectX 9 capable For discrete graphics models with 1024MB or more of system memory: ATI Mobility Radeon X1300 512MB HyperMemory* Microsoft DirectX 9 capable For integrated graphics models: Intel Graphics Media Accelerator 950 with up to 224MB shared system memory, depending on model Microsoft DirectX 9 capable * Indicates dedicated video memory and shared system memory. Either 64MB or 128MB dedicated video memory, depending on model.

Display

Internal

External

14.1-inch WXGA (1280 x 800 resolution) 14.1-inch WXGA+ (1440 x 900 resolution) Ambient Light Sensor Up to 32-bit per pixel colour depth VGA port s resolutions up to 2048 x 1536 at 75 Hz, and lower resolutions at up to 100 Hz DVI port in optional HP Docking Station (sold separately) s resolutions up to 1600 x 1200 at both full and reduced blanking, and 1920 x 1200 at reduced blanking NOTE: Resolutions are dependent upon monitor capability, and resolution and colour depth settings.

5/13/2010 1:53 PM

4 of 34


Memory

Standard

512-MB, 1024-MB or 2048-MB 533-MHz or 667-MHz DDR2 SDRAM; two SODIMM slots ing dual channel memory Maximum Upgradeable to 4096-MB maximum (2048-MB SODIMM in slots 1 and 2) Dual-channel Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots. NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. Above 3-GB, all memory may not be available due to system resource requirements.

Communications

Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC)* 56K V.92 modem** with digital line guard * The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required. ** Designed for s from 56K modem compliant sources. Maximum achievable transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is subject to country regulatory approval.

Wireless Devices

for a broad range of secure, integrated wireless LAN options featuring for the latest industry standards. Integrated Bluetooth is also an option (factory configurable only) and can be combined with any of the ed wireless LAN options. All integrated wireless Wi-Fi certified Cisco Compatible Extensions (Version 3.0) LAN options Wired Equivalent Privacy (WEP) up to 128-bit keys Wi-Fi Protected Access (WPA) and WPA2 802.1x authentication , including EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, and LEAP Advanced Encryption Standard (AES) WiFi certified for WPA2, WMM Dual antennas integrated in the display enclosure Intel PRO/Wireless 3945ABG Network Connection

Intel Centrino mobile technology Integrated for 802.11a, b and g Up to 54-mbps data rate

Broadcom 4311AG WiFi Adapter

Integrated for 802.11a, b and g Up to 54-mbps data rate

Broadcom 4311BG WiFi Adapter

Integrated for 802.11 b and g Up to 54-mbps data rate

HP Integrated Module with Bluetooth 2.0 Wireless Technology

Bluetooth Specification v2.0 compliant Works with a wide range of Bluetooth devices

Keyboard

The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right control and alt keys, and 12 function keys. US and International key layouts are available. Other features include an integrated numeric keypad, hotkeys for instant access to power conservation, brightness, and other features, 19-mm x 19-mm key pitch (centreto-centre spacing), 2.5-mm stroke, comfort-dished keycaps, and bright key legends for improved visibility in low light conditions.

One-Touch Productivity Buttons

Provide one-touch access to the following features: HP Info Centre, Wireless On/Off, Presentation Mode, Volume Up, Volume Down, and Volume Mute

5/13/2010 1:53 PM

5 of 34


Pointing Device

Dual pointing devices: Touchpad with scroll zone, two soft-touch buttons and Pointstick, two soft-touch buttons

Expansion Card Slots

One Type I/II PC Card slot

s 32-bit CardBus and 16-bit PC Cards

Integrated Smart Card Compatible with ISO 7816 compliant Smart Cards PC/SC interface Reader Media Slots

Secure Digital slot

Storage

Hard Drives

Interfaces

PC Card Slot

One Type I/II

Smart Card Reader

One

External Monitor

One – VGA

External Microphone

One

Headphone/Line out

One

Power Connector

One

RJ-11 (Modem)

One

RJ-45 (NIC)

One

Fast Infrared Port

S-Video TV Out

One (4-Mb/s ) IrDA 4-MB compliant; IR performance will vary depending on performance of IR peripherals and application used. One ( for NTSC/PAL)

USB 2.0

Three

Docking Connector

One

Travel Battery Connector

One

LED Status Indicators

Eleven

Audio

s SD (Secure Digital), MMC (MultiMedia Card)

60-, 80-, 100-GB 7200 rpm SMART SATA 60-, 80-, 100-GB 5400 rpm SMART SATA NOTE: These hard drives are customer removable and will withstand multiple insertion/removal cycles. Up to 8 GB is reserved for the system recovery software. HP Mobile Data Hard drive is mounted directly to the notebook frame, reducing the Protection System 3D transmission of shock to the hard drive. Uses three-axis digital motion detection with intelligent sensitivity to help protect the hard drive during normal use from shock and vibration. Optical Drives MultiBay II (9.5-mm) DVD-ROM MultiBay II Drive DVD/CD-RW Combo MultiBay II Drive DVD+/-RW SuperMulti MultiBay II Drive with Double Layer

PremierSound audio/speaker subsystem ADI1981HD High Definition CODEC Integrated 16-bit Sound Blaster Pro compatible audio 24-bit DAC Integrated stereo speakers Integrated microphone External volume up, volume down, and mute buttons

5/13/2010 1:53 PM

6 of 34


Stereo headphone/line out Stereo microphone in Software

Preinstalled Software Adobe Acrobat Reader* with Windows Vista or HP Backup and Recovery Manager HP Help and Centre* Windows XP HP Mobile Print Driver* (Windows XP models) HP ProtectTools Security Manager*: BIOS Configuration for HP ProtectTools Embedded Security for HP ProtectTools Credential Manager for HP ProtectTools HP Quick Launch Buttons HP Wireless Assistant HP OpenView Radia Management Solutions* Sonic Digital Media Plus* (Windows XP models): RecordNow! (for optional DVD+/-RW and DVD/CDRW drives) MyDVD (DVD Authoring for optional DVD+/-RW drives) Roxio Creator 9 (Window Vista models with optional DVD+/-RW or DVD/CDRW drives) Synaptics Touchpad Driver Symantec Norton Internet Security* with complimentary 60-day live update Intervideo WinDVD* – DVD Player (for optional DVD+/-RW, DVD/CDRW and DVD drives) *NOTE: Software marked with an asterisk is loaded on the hard drive and can be installed by running the Software Setup utility. Additional software HP Client Manager Software available from the Web Smart Card Security for HP ProtectTools Device Access Manager for HP ProtectTools

HP Backup and Recovery Manager

Each unit is shipped with HP Backup and Recovery Manager. HP Backup and Recovery Manager can provide data and system file protection for HP business PCs to enable fast recovery if the system becomes corrupted or if important information is accidentally deleted. HP Backup and Recovery Manager can perform scheduled or manual backups of the entire drive or individual files and folders. Up to 8 GB of the hard drive is reserved for the system recovery software. HP Backup and Recovery Manager can also create software recovery CDs or DVDs (requires optional hardware).

HP OpenView Radia HP OpenView Radia Management Solutions automate the management of software such as Management Solutions operating systems, software, software updates, content, and configuration settings to ensure that each computer is maintained in the correct configuration. HP Client Management HP Client Management Interface is based on industry standards that include Microsoft Windows Management Interface (MS WMI), Web Based Enterprise Management (WBEM), System Interface Management BIOS (SMBIOS), and Advanced Configuration and Power Interface (AI). HP CMI is a foundation technology utilized in HP Client Management Solutions. SMBIOS Version 2.4

System Management BIOS, previously known as DMI BIOS, is used to store system management information.

HP ProtectTools Security Manager

HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP ProtectTools Security Manager is an extensible client security console that delivers enhanced security capabilities through add-on software modules. Modules currently available are:

5/13/2010 1:53 PM

7 of 34


Security

Smart Card Security for HP ProtectTools BIOS Configuration for HP ProtectTools Credential Manager for HP ProtectTools Embedded Security for HP ProtectTools Device Access Manager for HP ProtectTools

Standard Features

HP ProtectTools Security Manager HP Biometric Fingerprint Sensor Integrated Smart Card Reader TPM 1.2 Embedded Security Chip* Configuration Control Hardware Memory Change Alert Ownership Tag Setup Power-On DriveLock TPM Enhanced DriveLock* HP Disk Sanitizer Kensington Lock Slot for Computrace / LoJack for Laptops (must be purchased separately)

Optional Features

HP Privacy Filter

Narrows viewing area so that screen data is visible only to persons directly in front of the monitor *NOTE: TPM module disabled where use is restricted by law; for example, Russia. For more information on HP security solutions refer to http://www.hp.com/go/security. Power Supply

External Smart AC Adapter (65-watt standard with integrated graphics; 90-watt standard with discrete graphics), 6-foot (1.8-metre) power cord included. Total length including External AC adapter is 12 feet (3.66 metre). HP Fast Charge Technology* *Fast Charge Technology recharges your battery up to 90% within 90 minutes when the system is off. Fast Charge Technology does not apply to 12-cell Ultra Capacity batteries. Battery

Primary Battery

55Wh 6-cell Lithium-Ion

Optional HP 8-Cell Extended Life Battery

52Wh 8-cell high capacity Lithium-Ion

Optional HP 12-Cell 95Wh 12-cell high capacity Lithium-Ion Ultra-Capacity Battery Battery Life

6-cell Primary with integrated graphics

6-cell Primary with discrete graphics

Primary Battery

Up to 6 hours

Primary Battery and optional HP 8-Cell Extended Life Battery

Up to 12 hours and 15 minutes

Up to 4 hours and 30 minutes Up to 8 hours and 30 minutes

Primary Battery and Up to 16 hours and 15 minutes optional HP 12-Cell Ultra-Capacity Battery

Up to 13 hours

NOTE: Battery life will vary depending on the product configuration, product model, applications loaded on the product, power management settings of the product, and the product features used by the customer. As with all batteries, the maximum capacity of this battery will decrease

5/13/2010 1:53 PM

8 of 34


with time and usage. System Standby Time Up to 1 week Power Conservation

s enhanced Intel SpeedStep technology with Intel Core Duo and Intel Core Solo processors (allows Battery Optimized Mode, Maximum Performance Mode, or Automatic mode) Intel Display Power Saving technology (models with integrated graphics) ATI PowerPlay technology (models with discrete graphics) Hibernation Standby AI compliance

Docking

HP Docking Station HP Advanced Docking Station HP External MultiBay II HP Adjustable Notebook Stand HP's shared docking solutions provide simple and convenient port replication and cable management. Features include Gigabit NIC through, modem through, legacy parallel and serial ports, S-video TV out, USB 2.0 ports, integrated security mechanism*, integrated MultiBay II and ExpressCard** slots. These docking solutions are compatible across multiple Business Notebook platforms enabling a lower total cost of ownership. * HP/Kensington Cable Lock required (purchased separately) ** HP Advanced Docking Station only

Service and

HP Services includes a three-year standard parts and labour warranty, pick-up or carry-in, and toll-free 7 x 24 hardware technical phone . On-site service and warranty upgrades are also available. NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Centre for details. http://h20000.www2.hp.com/biz/Tech/ProductRoot.jsp.

Smart Buy Promotion Models*** Smart Buy Promotion Model*** nc6400 Processor EN362UT#ABA (English) Operating System EN362UT#ABC (Fr CAN) System Memory

Intel Core 2 Duo Processor T5500* Genuine Windows XP Professional 512 MB 667-MHz DDR2 (1 DIMM)

Hard Drive

60-GB 5400 rpm SATA

Display

14.1-inch WXGA

Graphics

Intel Graphics Media Accelerator 950

Audio

ADI High Definition CODEC line out/headphone and microphone jacks integrated microphone 56K V.92 modem Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC) Intel PRO/Wireless 3945ABG Network Connection, Bluetooth

Communications

Integrated Wireless Integrated Security

TPM 1.2 Embedded Security Chip HP Biometric Fingerprint Sensor Smart Card Reader

Pointing Device

Dual pointing devices (both Pointstick and Touchpad)

5/13/2010 1:53 PM

9 of 34


MultiBay II Drive

DVD/CD-RW Combo MultiBay II Drive

Battery

6-cell (55 WHr) Lithium-Ion

Power

External 65W adapter

Warranty

3/3/0

* Intel's numbering system is not a measurement of higher performance. *** Specially priced product, certain restrictions apply. Smart Buy Promotion Model*** nc6400 Processor RB516UT#ABA (English) Operating System RB516UT#ABC (Fr CAN) System Memory


Hard Drive

80-GB 5400 rpm SATA

Display

14.1-inch WXGA

Graphics


Audio


Communications


Pointing Device

TPM 1.2 Embedded Security Chip HP Biometric Fingerprint Sensor Smart Card Reader Dual pointing devices (both Pointstick and Touchpad)

MultiBay II Drive

DVD+RW DL MultiBay II Drive

Battery


Power


Warranty

3/3/0

* Intel's numbering system is not a measurement of higher performance. *** Specially priced product, certain restrictions apply. Smart Buy Promotion Model*** nc6400 Processor RB517UT#ABA (English) Operating System RB517UT#ABC (Fr CAN) System Memory


Hard Drive

60-GB 5400 rpm SATA

Display

14.1-inch WXGA

Graphics

ATI Mobility Radeon 512MB HyperMemory**

Audio


Communications


Pointing Device


5/13/2010 1:53 PM

10 of 34


MultiBay II Drive


Battery


Power


Warranty

3/3/0

* Intel's numbering system is not a measurement of higher performance. ** 512MB HyperMemory is a total of 64MB dedicated video memory and 448MB shared system memory. *** Specially priced product, certain restrictions apply. Smart Buy Promotion Model*** nc6400 Processor RB518UT#ABA (English) Operating System RB518UT#ABC (Fr CAN) System Memory


Hard Drive

80-GB 7200 rpm SATA

Display

14.1-inch WXGA

Graphics


Audio


Communications


Pointing Device


MultiBay II Drive


Battery


Power


Warranty

3/3/0

* Intel's numbering system is not a measurement of higher performance. ** 512MB HyperMemory is a total of 64MB dedicated video memory and 448MB shared system memory. *** Specially priced product, certain restrictions apply. Standard Models nc6400 RC454AW#ABA (English) RC454AW#ABC (Fr CAN)

Processor

Intel Core Duo Processor T2400*

Operating System

Genuine Windows XP Professional

System Memory

1024 MB 667-MHz DDR2 (1 DIMM)

Hard Drive

60-GB 5400 rpm SATA

Display

14.1-inch WXGA

Graphics


Audio

ADI High Definition CODEC line out/headphone and microphone jacks integrated microphone 56K V.92 modem Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC)

Communications

5/13/2010 1:53 PM

11 of 34


Integrated Wireless

Pointing Device

Intel PRO/Wireless 3945ABG Network Connection Bluetooth 2.0 TPM 1.2 Embedded Security Chip HP Biometric Fingerprint Sensor Smart Card Reader Dual pointing devices (both Pointstick and Touchpad)

MultiBay II Drive


Battery


Power


Warranty

3/3/0

Integrated Security

* Intel's numbering system is not a measurement of higher performance. ** 256MB HyperMemory is a total of 64MB dedicated video memory and 192MB shared system memory. nc6400 RA252AW#ABA (English) RA252AW#ABC (Fr CAN)

Processor


Operating System


System Memory


Hard Drive

60-GB 5400 rpm SATA

Display

14.1-inch WXGA

Graphics


Audio

ADI High Definition CODEC line out/headphone and microphone jacks integrated microphone 56K V.92 modem Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC)

Communications


Intel PRO/Wireless 3945ABG Network Connection Bluetooth 2.0 TPM 1.2 Embedded Security Chip HP Biometric Fingerprint Sensor Smart Card Reader

Pointing Device


MultiBay II Drive


Battery


Power


Warranty

3/3/0

* Intel's numbering system is not a measurement of higher performance. ** 256MB HyperMemory is a total of 64MB dedicated video memory and 192MB shared system memory. nc6400 RA253AW#ABA (English) RA253AW#ABC (Fr CAN)

Processor


Operating System


System Memory


Hard Drive

60-GB 5400 rpm SATA

Display

14.1-inch WXGA

Graphics


Audio

ADI High Definition CODEC line out/headphone and microphone jacks integrated microphone

5/13/2010 1:53 PM

12 of 34


Communications

Pointing Device

56K V.92 modem Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC) Intel PRO/Wireless 3945ABG Network Connection Bluetooth 2.0 TPM 1.2 Embedded Security Chip HP Biometric Fingerprint Sensor Smart Card Reader Dual pointing devices (both Pointstick and Touchpad)

MultiBay II Drive


Battery


Power


Warranty

3/3/0


* Intel's numbering system is not a measurement of higher performance. ** 256MB HyperMemory is a total of 64MB dedicated video memory and 192MB shared system memory. nc6400 Processor RB515UA#ABA (English) Operating System RB515UA#ABC (Fr CAN) System Memory


Hard Drive

80-GB 5400 rpm SATA

Display

14.1-inch WXGA

Graphics


Audio


Communications


TPM 1.2 Embedded Security Chip HP Biometric Fingerprint Sensor Smart Card Reader

Pointing Device


MultiBay II Drive


Battery


Power


Warranty

3/3/0

* Intel's numbering system is not a measurement of higher performance. nc6400 Processor RB519UA#ABA (English) Operating System RB519UA#ABC (Fr CAN) System Memory


Hard Drive

80-GB 7200 rpm SATA

Display

14.1-inch WXGA

Graphics


Audio


5/13/2010 1:53 PM

13 of 34


Communications


56K V.92 modem Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC) Intel PRO/Wireless 3945ABG Network Connection, Bluetooth

Pointing Device


MultiBay II Drive


Battery


Power


Warranty

3/3/0

* Intel's numbering system is not a measurement of higher performance. ** 512MB HyperMemory is a total of 128MB dedicated video memory and 384MB shared system memory. nc6400 RM100AW#ABA (English) RM100AW#ABC (Fr CAN) Global

Processor

Intel Core 2 Duo Processor T5600*

Operating System


System Memory


Hard Drive

80-GB 5400 rpm SATA

Display

14.1-inch WXGA

Graphics


Audio

Pointing Device

ADI High Definition CODEC line out/headphone and microphone jacks integrated microphone 56K V.92 modem Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC) Intel PRO/Wireless 3945ABG Network Connection Bluetooth 2.0 TPM 1.2 Embedded Security Chip HP Biometric Fingerprint Sensor Smart Card Reader Dual pointing devices (both Pointstick and Touchpad)

MultiBay II Drive


Battery


Power


Warranty

3/3/0

Communications


* Intel's numbering system is not a measurement of higher performance. nc6400 RM106AW#ABA (English) RM106AW#ABC (Fr CAN) Global

Processor

Intel Core 2 Duo Processor T7200*

Operating System


System Memory


Hard Drive

80-GB 5400 rpm SATA

Display

14.1-inch WXGA

Graphics


Audio


5/13/2010 1:53 PM

14 of 34


Communications

Pointing Device

56K V.92 modem Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC) Intel PRO/Wireless 3945ABG Network Connection Bluetooth 2.0 TPM 1.2 Embedded Security Chip HP Biometric Fingerprint Sensor Smart Card Reader Dual pointing devices (both Pointstick and Touchpad)

MultiBay II Drive


Battery


Power


Warranty

3/3/0


* Intel's numbering system is not a measurement of higher performance. ** 512MB HyperMemory is a total of 64MB dedicated video memory and 448MB shared system memory. Overview

Standard Features

Memory

Options

Memory

Storage


512-MB 533-MHz DDR2 SDRAM 1024-MB 533-MHz DDR2 SDRAM 512-MB 667-MHz DDR2 SDRAM

PE831A PE832A EM993AA

1024-MB 667-MHz DDR2 SDRAM 2048-MB 667-MHz DDR2 SDRAM

EM994AA EM995AA

MultiBay II Storage (9.5-mm)

DVD-ROM MultiBay II Drive Combo DVD/CD-RW MultiBay II Drive DVD+/-RW SuperMulti with Double Layer MultiBay II Drive 80-GB 5400 rpm MultiBay II Hard Drive

Other Storage

80-GB 5400 rpm Primary SATA Hard Drive HP USB Digital Drive + 256-MB Secure Digital Card HP USB Diskette Drive

Communications

Intel PRO/Wireless 3945ABG 802.11 a/b/g WLAN option kit

EX150AA#ABA

Expansion Solutions

HP Docking Station HP Advanced Docking Station HP 3-in-1 NAS Docking Station HP Monitor Stand HP Adjustable Notebook Stand

EN488AA#ABA EN489AA#ABA EM537AA#ABA PA507A PA508A

HP External MultiBay II (9.5-mm) HP 4-port USB 2.0 Hub

PA849A PA850A PA851A PH357A ET354AA DL702AA DC361B

PA509A#ABA DG954A

5/13/2010 1:53 PM

15 of 34


Power

HP 2-bay Battery Charging Station HP 10-bay Battery Charging Station Battery Adapter kit #1 65W Smart AC Adapter 90W Smart AC Adapter 90W Smart Auto Adapter 65W Air/Auto/AC Combo Adapter Primary 6-cell Battery Pack

DT533A#ABA DT534A#ABA PK402A ED494AA#ABA ED495AA#ABA ED493AA ED993AA#ABA PB994A

HP 8-cell Extended Life Battery HP 12-cell Ultra-Capacity Battery

PB993A EJ092AA

Carrying Cases

HP Entry Value Case HP Top Load Nylon HP Executive Leather case HP Sport Backpack

DL617A DC915A PA847A DG102A

Security

HP PCMCIA Smart Card Reader

DC350B

HP/Kensington Cable Lock

PC766A

Privacy Film for 6400 Series Input/Output Devices

ES216AA

USB/PS2 Keyboard

DC852A#ABA

USB/PS2 Keyboard (French) USB/PS2 Optical Mouse

DC852A#ABC DC369A

HP USB Optical Travel Mouse Overview

Standard Features

Options

Memory

F2100A

Storage


for up to 4096 MB* of 533- or 667-MHz DDR2 SDRAM Two DIMM slots DIMM sizes ed: 512 MB, 1024 MB, and 2048 MB Standard Memory

Optional Memory Upgrades

Up to 1024 MB 1024 MB 1280 MB 1536 MB 2048 MB

512 MB (512 MB x 1 or 256 MB x 2) 1024 MB (1024 MB x 1 or 512 MB x 2) 2048 MB (1024 MB x 2)

for up to 4096 MB* of memory is available (with the installation of optional DDR2 SDRAM memory kits). Both memory slots are accessible. Please refer to the Hardware and Software Guide for installation procedures. Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots. Slot 1 1024 MB 512 MB 1024 MB 1024 MB 1024 MB

Slot 2 Empty 512 MB 256 MB 512 MB 1024 MB

5/13/2010 1:53 PM

16 of 34


4096 MB*

2048 MB

2048 MB

NOTE: This chart does not represent all possible memory configurations. Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only HP branded memory modules to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. Memory Upgrades

512-MB 533-MHz DDR2 SDRAM

PE831A

1024-MB 533-MHz DDR2 SDRAM 512-MB 667-MHz DDR2 SDRAM 1024-MB 667-MHz DDR2 SDRAM 2048-MB 667-MHz DDR2 SDRAM

PE832A EM993AA EM994AA EM995AA

* Above 3-GB, all memory may not be available due to system resource requirements. Overview

Standard Features

Options

Memory

Storage


Removable Media Drive Quantity ed DVD+/-RW SuperMulti MultiBay One II Drive with Double Layer* DVD/CD-RW Combo MultiBay II One Drive* DVD-ROM MultiBay II Drive* One

Drive Bay MultiBay II MultiBay II MultiBay II

Hard Drive Quantity ed

Drive Bay

Primary Hard Drives 100-GB 7200 rpm SMART SATA One Dedicated hard drive bay Hard Drive 80-GB 7200 rpm SMART SATA One Dedicated hard drive bay Hard Drive 60-GB 7200 rpm SMART SATA One Dedicated hard drive bay Hard Drive 100-GB 5400 rpm SMART SATA One Dedicated hard drive bay Hard Drive 80-GB 5400 rpm SMART SATA Up to two Dedicated hard drive bay and/or MultiBay II Hard Drive 60-GB 5400 rpm SMART SATA One Dedicated hard drive bay Hard Drive * MultiBay II drives ed in the internal MultiBay II are also ed in the optional HP External MultiBay II and the HP Advanced Docking Station. Overview

Standard Features

Options

Memory

Storage


5/13/2010 1:53 PM

17 of 34


System Unit

Dimensions (HxWxD)

1.1 (at front) x 13.0 x 9.4 in (29.2 (at front) x 330 x 239 mm)

Weight

with MultiBay II weight saver and 6-cell battery

4.6 lb (2.1 kg)

5.0 lb (2.27 kg) with MultiBay II DVD/CDRW Combo Drive and 6-cell battery NOTE: Height varies depending upon where on the notebook the measurement is made. Weight includes integrated graphics, battery, 60-GB hard drive, 512-MB memory, 802.11 wireless communications module, and TPM Embedded Security Chip. Weight varies by configuration and components. Stand-Alone Power Normal Operating 18.5 V Voltage Requirements Average Operating 22 W (models with integrated graphics) Power 29 W (models with discrete graphics) Max Operating Power < 65 W (models with integrated graphics) < 90 W (models with discrete graphics) Temperature Operating 32° to 95° F (0° to 35° C) (not writing optical) 41° to 95° F (5° to 35° C) (writing optical) Non-operating -4° to 140° F (-20° to 60° C) Relative Humidity Operating 10% to 90%, non-condensing Non-operating Shock

Operating

5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature 125 G, 2 ms, half-sine

Random Vibration

Non-operating Operating

200 G, 2 ms, half-sine 0.75 grms

Altitude (unpressurized)

Non-operating Operating Non-operating

1.50 grms -50 to 10,000 ft (-15.24 to 3,048 m) -50 to 40,000 ft (-15.24 to 12,192 m)

UL CSA FCC Compliance Energy Star Compliant ICES GS

Yes Yes Yes Yes Yes Yes

Australia / NZ A-Tick Compliance CCC

Yes

Industry Standard Certifications

Japan VCCI Compliance MIC BSMI CE Marking Compliance BNCI or BELUS CIT GOST Saudi Arabian Compliance (IC)

Yes Yes Yes Yes Yes Yes Yes Yes Yes

5/13/2010 1:53 PM

18 of 34


SABS UKRSERTCOMPUTER HP 90W Smart AC Adapter (models with discrete graphics)

HP 65W Smart AC Adapter (models with integrated graphics)

Yes Yes

Dimensions

5.24 x 2.28 x 1.1 in (13.3 x 5.8 x 2.9 cm)

Weight

0.86 lb (390 g)

Input

100 to 240 VAC Input Efficiency Input frequency range Input AC current

83% min at 115 VAC 47 to 63 Hz 1.5 A at 90 VAC, 0.75 A at 180 VAC PFC Version 2.4 A at 90 VAC, 1.2 A at 180 VAC NON PFC Version 90W 18.5V 5 msec at 115 VAC input <11A, Over voltage protection- 29V max automatic shutdown

Output

Output power 65W DC output Hold-up time Output current limit

Connector

3 pin/grounded, mates with interchangeable cords

Environmental Design

Operating temperature Non-operating (storage) temperature Altitude Humidity Storage Humidity

32° to 104° F (0° to 40° C) -4° to 149° F (-20° to 65° C) 0 to 10,000 ft (0 to 3,048 m) 20% to 80% 10% to 90%

EMI and Safety Certifications

CE Mark – full compliance with LVD and EMC directives; Worldwide safety standards – IEC950, EN60950, UL1950, Class2, SELV; Agency approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCIB, NOM-1 NYCE; MTBF– over 200,000 hours at 25°C ambient condition.

Option Kit Contents

90W AC Adapter, power cable, warranty booklet

Dimensions

4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)

Weight

0.62 lb (280 g)

Input

100 to 240 VAC Input Efficiency Input frequency range Input AC current

Output

Connector

83% min at 115 VAC 47 to 63 Hz 1.7 A at 90 VAC, 0.85 A at 180 VAC

Output power 65W DC output Hold-up time Output current limit

65W 18.5V 5 msec at 115 VAC input <11A, Over voltage protection- 29V max automatic shutdown 3 pin/grounded, mates with interchangeable cords

Environmental Design Operating temperature Non-operating (storage) temperature Altitude Humidity Storage Humidity

32° to 104° F (0° to 40° C) -4° to 149° F (-20° to 65° C) 0 to 10,000 ft (0 to 3,048 m) 20% to 80% 10% to 90%

5/13/2010 1:53 PM

19 of 34


EMI and Safety Certifications

Option Kit Contents

CE Mark – full compliance with LVD and EMC directives; Worldwide safety standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF – over 200,000 hours at 25°C ambient condition. 65W AC Adapter, power cable, warranty booklet

Optional HP 12-Cell Dimensions (H x W x L) 1.3 x 6.0 x 10.6 in (3.33 x 15.25 x 26.88 cm) Ultra-Capacity Battery Weight 1.77 lb (0.803 kg) Cells/Type

12-cell Lithium-Ion

Energy

Voltage Watt-hour Capacity Amp-hour Capacity Operating (Charging) Operating (Discharging) Non-operating

Temperature

Battery Re-Charge Time Fuel Gauge

Optional HP 8-Cell Extended Life Battery

Smart Adapter System ON

3 to 4 hours 4 to 5 hours (depending on system power consumption) When pressed, LEDs light indicating level of charge remaining on battery

Dimensions (H x W x L) 1.0 x 3.9 x 8.7 in (2.5 x 10.0 x 22.0 cm) Weight

1.00 lb (0.455 kg)

Cells/Type

8-cell Lithium-Ion

Energy

Voltage Watt-hour Capacity

14.4V 52Wh

Amp-hour Capacity Operating (Charging) Operating (Discharging) Non-operating System in OFF mode or Standby System ON

3.6Ah 32° to 113° F (0° to 45° C) 14° to 140° F (–10° to 60° C) –4° to 140° F (–20° to 60° C) 3 hours

Temperature

Battery Re-Charge Time

Fuel Gauge

55Wh Primary 6-Cell Battery

14.8V 95Wh 6.45Ah 32° to 113° F (0° to 45° C) 14° to 140° F (–10° to 60° C) –4° to 140° F (–20° to 60° C)

3 to 5 hours (depending on system power consumption) HP Fast Charge Charges the battery up to 90% within 90 Technology minutes when system is OFF When pressed, LEDs light indicating level of charge remaining on battery

Dimensions (H x W x L) 0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm) Weight

0.737 lb (0.335 kg)

Cells/Type

6-cell Lithium-Ion

Energy

Voltage Watt-hour Capacity Amp-hour Capacity

Temperature

Operating (Charging) 32° to 113° F (0° to 45° C) Operating (Discharging) 14° to 140° F (–10° to 60° C) Non-operating –4° to 140° F (–20° to 60° C)

10.8V 55Wh 5.1Ah

5/13/2010 1:53 PM

20 of 34


Battery Re-Charge Time

System in OFF Mode or 2.5 hours Standby System ON HP Fast Charge Technology

14.1-Inch Colour TFT WXGA Display

14.1-Inch Colour TFT WXGA+ Display

3 to 5 hours (depending on system power consumption) Charges the battery up to 90% within 90 minutes when system is OFF

Active Area (W x H)

11.9 x 7.5 in (30.3 x 19.0 cm)

Diagonal Size

14.1 in (35.7 cm)

Surface Treatment

Anti-glare

Contrast Ratio

300:1 (typical)

Refresh Rate

60 Hz

Brightness

200 nit (typical)

Pixel Resolution

Pitch

0.237 mm

Format

1280x800

Configuration

RGB Stripe

Backlight

CCFL

PPI

107

Viewing Angle

±45° Horizontal, ±25° Vertical (typical)

Active Area (W x H)

11.9 x 7.5 in (30.3 x 19.0 cm)

Diagonal Size

14.1 in (35.7 cm)

Surface Treatment

Anti-glare

Contrast Ratio

300:1 (typical)

Refresh Rate

60 Hz

Brightness

200 nit (typical)

Pixel Resolution

Pitch

0.210 mm

Format

1440 x 900

Configuration

RGB Stripe

Backlight

CCFL

PPI

121

Viewing Angle

±45° Horizontal, ±25° Vertical (typical)

Drive Weight

0.25 lb (113 g)

Capacity

100 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-7 / SATA 1.0a

Transfer Rate

Synchronous (maximum) 100 MB/s (Drive Capability)

Seek Time (typical reads, including settling) Rotational Speed

Single Track Average Maximum 7200 rpm

Logical Blocks

195,371,568

Operating Temperature

41° to 140° F (5° to 60° C) [case temp]

Hard Drives 100-GB 7200 rpm SATA

1 ms 10 ms 18 ms

5/13/2010 1:53 PM

21 of 34


Features 80-GB 7200 rpm SATA Drive Weight

0.25 lb (113 g)

Capacity

80 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-7 / SATA 1.0a

Transfer Rate




Logical Blocks

156,301,488


41° to 140° F (5° to 60° C) [case temp]

Features

ATA Security

60-GB 7200 rpm SATA Drive Weight

100-GB 5400 rpm SATA

ATA Security

1 ms 10 ms 18 ms

0.25 lb (113 g)

Capacity

60 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-7 / SATA 1.0a

Transfer Rate


Seek Time (typical reads, including settling)

Single Track Average Maximum

Rotational Speed

7200 rpm

Logical Blocks

117,231,408


41° to 140° F (5° to 60° C) [case temp]

Features

ATA Security

Drive Weight

0.22 lb (101 g)

Capacity

100 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-7 / SATA 1.0a

Transfer Rate




Logical Blocks

195,371,568


41° to 140° F (5° to 60° C) [case temp]

Features

ATA Security

1 ms 10 ms 18 ms

3 ms 13 ms 24 ms

5/13/2010 1:53 PM

22 of 34



0.22 lb (101 g)

Capacity

80 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-7 / SATA 1.0a

Transfer Rate




Logical Blocks

156,301,488


41° to 140° F (5° to 60° C) [case temp]

Features

ATA Security


3 ms 13 ms 24 ms

0.22 lb (101 g)

Capacity

60 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-7 / SATA 1.0a

Transfer Rate




Logical Blocks

117,231,408


41° to 140° F (5° to 60° C) [case temp]

Features

ATA Security

3 ms 13 ms 24 ms

Removable Storage Drives – MultiBay II DVD-ROM MultiBay II Drive

Dimensions

0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)

Weight

0.45 lb (205 g)

Access Times

Random

Max Data Transfer Rate

<120 ms CD <200 ms DVD 3,600 KB/s 10,800 KB/s

Transfer Mode

24X-CD-ROM 8X-DVD Multiword DMA Mode 2

Interface

EIDE

ed Media (read)

CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW None

ed Media (write) Max Media Capacity (read)

8.5 GB

5/13/2010 1:53 PM

23 of 34



Transport

Tray Loading

Dimensions

0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)

Weight

0.45 lb (205 g)

Access Times

Random

Max Data Transfer Rate

Transfer Mode

24X CD-ROM 8X DVD 24X CD-R 24X CD-RW Multiword DMA Mode 2

Interface

EIDE

ed Media (read)

CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW CD-R, CD-RW

ed Media (write) Max Media Capacity (read) Max Media Capacity (write) Transport DVD+/-RW SuperMulti Dimensions MultiBay II Drive with Weight Double Layer Access Times Max Data Transfer Rate

<120 ms CD <155 ms DVD 3,600 KB/s 10,800 KB/s 3,600 KB/s 3,600 KB/s

8.5 GB 700 MB Tray loading 0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm) 0.45 lb (205 g) Random

<150 ms CD

24X CD-ROM 8X DVD 24X CD-R

<125 ms DVD 3,600 KB/s 10,800 KB/s 3,600 KB/s

10X CD-RW 4X DVD+R 2.4X DVD+RW 4X DVD-R

1,500 KB/s 5,400 KB/s 3,240 KB/s 5,400 KB/s

Transfer Mode

2X DVD-RW 2,700 KB/s 2X DVD-RAM 2,700 KB/s Multiword DMA Mode 2

Interface

EIDE

ed Media (read)

CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM

ed Media (write) Max Media Capacity (read)

8.5 GB

5/13/2010 1:53 PM

24 of 34


80-GB 5400 rpm MultiBay II Hard Drive

Max Media Capacity (write) Transport

8.5 GB

MultiBay II Drive Adapter Drive Weight

Dimensions (H x W x D) 0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm) Weight 0.16 lb (72 g) 0.22 lb (101 g)

Capacity

80 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-6

Transfer Rate




Logical Blocks

156,301,488


41° to 131° F (5° to 55° C)

Features

ATA Security

HP Fingerprint Sensor Mobile Voltage Operation

Tray Loading

3 ms 13 ms 24 ms

3.0V–3.6V Single Supply

Operating Temperature 32° – 158°F (0° – 70°C) Current Consumption @ 3.3V

Less than 70 mA peak imaging and scrolling Less than 25 mA hardware finger detection Advanced Power Management

High-Rate Image Capture

Up to 240 image frames /sec

ESD Resistance

IEC 61000-4-2 Level 4 (±15KV)

Detection Matrix

192 x 16 Pixels 9.7 mm x 0.81 mm 500 ppi High-Resolution Images

Implementation

ADI1981HD High Definition CODEC

Volume Controls

Up, down, and mute buttons

Full Duplex

Yes

Sound Blaster Pro compatible

Yes

Microphone Jack

Stereo or mono

Headphone/Line Out Jack

Stereo

PremierSound Audio Hardware

Integrated Microphone Yes Audio Output Quality

Frequency Response

20 Hz – 20 kHz

Signal to Noise Ratio

>85 dB

5/13/2010 1:53 PM

25 of 34


Internal Speakers

Total Harmonic Distortion

0.01%

Noise Floor

-110 dB

Play/Record Sampling Rate(s)

8 kHz – 48kHz

DAC

16, 20 or 24-bit

ADC

16 or 20-bit

Power Rating

2 Watts

Impedance

4 Ohms

Communications Integrated Broadcom Ethernet Features NetXtreme Gigabit Ethernet PCI Express Controller (BCM5753M)

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14) 100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30) 1000 Mbit/s operation (1000BASE-T; IEEE 802.3z and 802.3ab; IEEE 802.3 clauses 34-42) Auto-Negotiation (Automatic Speed Selection) Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s IEEE 802.1p QoS (Quality of Service) IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable) Power Management AI compliant -- multiple power modes Situation-sensitive features reduce power consumption NIC Battery Saving Mode (enabled by default) Performance Features T/IP/UDP Checksum Offload (configurable) T Segmentation Offload U Task Offload Adaptive Interrupts Manageability

Interface

V.92 56K Data/Fax Modem

Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only) PXE 2.1 Remote Boot Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30)) Comprehensive diagnostic and configuration software suite Cable Analyzer PCI Express x1

NIC Device Driver Name

Broadcom NetXtreme Gigabit Ethernet

Drivers Available

Microsoft Windows XP Microsoft Windows 2000

Form Factor

MDC 1.5 Daughtercard

Power Management

APM Revision 1.2, AI

Approvals/ Certifications

UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE Mark, Other Countries Data Mode Capabilities V.92 data V.8bis

5/13/2010 1:53 PM

26 of 34


Fax Mode Capabilities

Command Set

Broadcom 4311BG Wireless LAN 802.11b/g WiFi Adapter Standards

V.80 V44, V.42bis, MNP5 (Compression) V.42 (LAPM, MNP2-4) (Error Correction) Optional symbol rates: 2800, 3429 Asymmetric Symbol rates Synchronous primary channel data signaling rates: 3600, 31200 Automatic rate re-negotiation V.34 V.32bis V.32 V.23 V.22bis V.22 V.21 Bell 212A Bell 103J TIA/EIA-578-B (Class 1) T.30, T.4 (Group 3) V.17 V.29 V.27ter V.21 Channel 2 V.250 (Partial) TIA-602 Identification: +GMI, +GMM, +GMR Port control: +IPR, +ICF, +IFC, +ILRR Modulation: +MS, +MR, +MA Error control: +ES, +ER, +EB, +ESR, +ETBM Data compression: +DS, +DR V.251 IEEE 802.11b IEEE 802.11g

Interoperability

Wi-Fi certified Cisco Compatible Extensions Program compliant (details at www.hp.com/go/notebooks/WLAN)

Frequency Band

2.4 GHz

Data Rates

802.11b: 1, 2, 5.5, 11 Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps Direct Sequence Spread Spectrum DBPSK, DQPSK, CCK, OFDM

Modulation Security1

s 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.

for Cisco Security Features (proven compatibility with Cisco Aironet infrastructure products through the Cisco Compatible Extensions Program Version 4). Sub-channels Multinational with frequency bands and channels compliant to local regulations. Media Access Protocol CSMA/CA (Collision Avoidance) with ACK Network Architecture Models

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

5/13/2010 1:53 PM

27 of 34


Output Power (for 17.5 dBm 2 CKK) Output Power (for 15 dBm OFDM; power varies by data rate)2 Power Consumption

Power Management

Transmit: 2.0 W (max) Receive: 1.5 W (max) Idle mode3: 390 mW (nominal) Sleep mode: 20 mW (max) AI compliant power management 802.11 compliant power saving mode

Receiver Sensitivity4

54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm

Antenna type

Form Factor

High efficiency dual band antenna with spatial diversity, mounted in the display enclosure 802.11 b – Typical 1200 feet – Outdoor Open Area (@1 Mbps) 300 feet – Indoor, Office environment 802.11 g – Typical 1200 feet – Outdoor Open Area (@1 Mbps) 300 feet – Indoor, Office environment PCI-Express MiniCard

Weight

0.026 lb (12 g)

Dimensions

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

Operating Voltage

3.3v +/- 10%

Temperature

Operating Non-operating Operating Non-operating

32° to 176° F (0° to 80° C) -40° to 176° F (-40° to 80° C) 10% to 90% (non-condensing) 5% to 95% (non-condensing)

Altitude

Operating Non-operating

0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)

Configuration Utility5

Choice of Configuration Utility:

Range

Humidity

Microsoft Windows XP Wireless Network Connection Manager Broadcom Wireless Configuration Utility (required for Cisco Compatible Extensions ) LED Activity

LED Off – Radio OFF; Solid LED On – Radio ON

1. 2. 3. 4.

Check latest software/driver release for updates on ed security features. Maximum output power may vary by country according to local regulations. In Power Save Polling mode. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation). 5. WLAN supplier's client utility is required for Cisco Compatible Extensions . WLAN may also be compatible with certain third-party software supplicants.

Broadcom 4311AG 802.11a/b/g WiFi Adapter

Wireless LAN Standards Interoperability

IEEE 802.11a IEEE 802.11b IEEE 802.11g Wi-Fi certified Cisco Compatible Extensions Program compliant (details at www.hp.com/go/notebooks/WLAN)

Frequency Band

2.4 GHz and 5 GHz

Data Rates

802.11b: 1, 2, 5.5, 11 Mbps 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

5/13/2010 1:53 PM

28 of 34


Modulation

Direct Sequence Spread Spectrum DBPSK, DQPSK, CCK, OFDM

Security1




Roaming


Output Power (for CKK)2

17.5 dBm

15 dBm Output Power (for OFDM; power varies by data rate)2 Power Consumption Transmit: 2.0 W (max) Receive: 1.5 W (max) Idle mode3: 390 mW (nominal) Sleep mode: 20 mW (max) Power Management AI compliant power management 802.11 compliant power saving mode Receiver Sensitivity4


Antenna type

Form Factor

High efficiency dual band antenna with spatial diversity, mounted in the display enclosure 802.11 a – Typical 600 feet – Outdoor Open Area (@6 Mbps) 150 feet – Indoor, Office environment 802.11 b – Typical 1200 feet – Outdoor Open Area (@1 Mbps) 300 feet – Indoor, Office environment 802.11 g – Typical 1200 feet – Outdoor Open Area (@1 Mbps) 300 feet – Indoor, Office environment PCI-Express MiniCard

Weight

0.026 lb (12 g)

Dimensions

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

Operating Voltage

3.3v +/- 10%

Temperature

Operating Non-operating Operating Non-operating Operating Non-operating

Range

Humidity Altitude Configuration Utility5

32° to 176° F (0° to 80° C) -40° to 176° F (-40° to 80° C) 10% to 90% (non-condensing) 5% to 95% (non-condensing) 0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)

Choice of Configuration Utility: Microsoft Windows XP Wireless Network Connection Manager Broadcom Wireless Configuration Utility (required for Cisco Compatible Extensions )

LED Activity


5/13/2010 1:53 PM

29 of 34


1. 2. 3. 4.


Intel PRO/Wireless 3945ABG 802.11a/b/g Network Connection

Wireless LAN Standards

IEEE 802.11a IEEE 802.11b IEEE 802.11g

Interoperability

Wi-Fi certified Cisco Compatible Extensions Program compliant (details at www.hp.com/go/notebooks/WLAN)

Frequency Band

2.4 GHz and 5 GHz

Data Rates

802.11b: 1, 2, 5.5, 11 Mbps 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps Direct Sequence Spread Spectrum DBPSK, DQPSK, CCK, OFDM

Modulation Security1




Roaming


Output Power (for CKK)2

15 dBm

15 dBm Output Power (for OFDM; power varies by data rate)2 Power Consumption Transmit: 1.8 Watts (max) Receive: 1.4 Watts (max) Idle mode3: 150 mW (nominal) Sleep mode: 30 mW (max) Power Management AI compliant power management 802.11 compliant power saving mode Receiver Sensitivity4


Antenna type

High efficiency dual band antenna with spatial diversity, mounted in the display enclosure 802.11 a – Typical 600 feet – Outdoor Open Area (@6 Mbps) 150 feet – Indoor, Office environment 802.11 b – Typical 1200 feet – Outdoor Open Area (@1 Mbps) 300 feet – Indoor, Office environment 802.11 g – Typical 1200 feet – Outdoor Open Area (@1 Mbps) 300 feet – Indoor, Office environment PCI-Express MiniCard

Range

Form Factor

5/13/2010 1:53 PM

30 of 34


Weight

0.013 lb (6 g)

Dimensions

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

Operating Voltage

3.3v +/- 10%

Temperature

Operating Non-operating Operating Non-operating Operating Non-operating

Humidity Altitude Configuration Utility5

32° to 176° F (0° to 80° C) -40° to 176° F (-40° to 80° C) 10% to 90% (non-condensing) 5% to 95% (non-condensing) 0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)

Choice of Configuration Utility: Microsoft Windows XP Wireless Network Connection Manager Intel PROSet (required for Cisco Compatible Extensions )

LED Activity


1. 2. 3. 4.


HP Integrated Module with Bluetooth Wireless Technology

Bluetooth Specification 2.0 Compliant Dimensions

1.02 x 0.55 x 0.22 in (26 x 14 x 5.7 mm)

Frequency Band

2402 to 2480 MHz

Number of Available Channels

79 (1 MHz) available channels

Data Rates and Throughput

Transmit Power

3 Mbps data rate; throughput up to 2.17 Mbps Synchronous Connection Oriented links up to 3, 64 kbps, voice channels Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric or 1306.9 kbps symmetric -6 dBm to 4 dBm (Bluetooth Class II)

Receiver Sensitivity

Better than -80 dBM at 0.1 % raw bit error rate

Power Consumption

Peak (Tx) 264 mW Peak (Rx) 231 mW Sleep <1 mW

Antenna

Internally integrated within module

Range

Up 33 ft (10 m)

Electrical Interface

USB 2.0 compliant Microsoft Windows Plug and Play compliant

OS

Microsoft Windows XP Professional and Home Microsoft Windows 2000

Bluetooth Software ed Link Topology

Broadcom Bluetooth for Windows Microsoft Windows XP Bluetooth Software Point to Point, Multipoint Pico Nets up to 7 slaves

Security

Full of Bluetooth Security Provisions

Power Management

Microsoft Windows AI, and USB Bus

5/13/2010 1:53 PM

31 of 34


Certifications

Self configurable to optimize power conservation in all operating modes, including Standby, Hold, Park, and Sniff All necessary regulatory approvals for ed countries, including: FCC (47 CFR) Part 15C, Section 15.247 & 15.249 ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark

Temperature Humidity Altitude Bluetooth Profiles ed

Operating

-4° to 158° F (-20° to 70° C)

Non-operating

-40° to 176° F (-40° to 80° C)

Operating

10% to 90%

Non-operating

5% to 95%

Operating

15,000 ft (4,572 m)

Non-operating

40,000 ft (12,192 m)

(with Bluetooth for Windows 4.0 software) Serial Port Profile (SPP)* Dial-Up Networking (DUN)* Generic Object Exchange Profile (GOEP) Object Push Profile (OPP)* File Transfer Profile (FTP) Synchronization Profile (SYNC) Hard Copy Cable Replacement (HCRP)* Personal Area Networking Profile (PAN)* Human Interface Device Profile (HID)* FAX Profile (FAX) Basic Imaging Profile (BIP) Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)

*

Environmental Data

indicates the profile is also ed by Microsoft Windows XP SP2

Eco-Label Certifications

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks: US Energy Star US Federal Energy Management Program (FEMP) Taiwan Green Mark China Energy Conservation Program IT ECO declaration

System Configuration

The configuration used for the Energy Consumption and Declared Noise Emissions data is based on a "Typically Configured Notebook."

Energy Consumption

115 VAC

230 VAC

100 VAC

Normal Operation Sleep (Energy Star low power mode) Off Heat Dissipation*

25.6 W 2.1 W

25.6 W 2.6 W

25.6 W 2.1 W

2.0 W 115 VAC

2.4 W 230 VAC

2.0 W 100 VAC

87.3 BTU/hr 7.2 BTU/hr



Normal Operation Sleep

5/13/2010 1:53 PM

32 of 34


Off

6.8 BTU/hr 7.2 BTU/hr 6.8 BTU/hr *NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour. This product is in compliance with US executive order 13221, WOL (wake on LAN) disabled.

Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296) Idle Fixed Disk (random writes) Batteries

Sound Power (LWAd, bels)

Sound Pressure (LpAm, decibels)

3.40 3.43

25.1 34.1

This product complies with ISO standards: EU Directive 91/ 157/ EEC EU Directive 93/ 86/ EEC EU Directive 98/ 101/ EEC Batteries used in the product do not contain: Mercury greater than 5ppm by weight Cium greater than 10ppm by weight Lead greater than 4000 ppm by weight. Battery type and chemistry used in the product: Primary battery 6-cell high capacity Lithium-Ion battery pack Real Time Clock battery CR2032L/DBE (coin cell), Lithium

Additional Information

This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive – 2002/95/EC. This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive – 2002/96/EC. Keyboard complies with ISO standard: ISO 9995, EN 29241-4, and ISO/IEC 15412 Input devices of this product comply with ISO 9241, part 9. Plastics parts weighing over 0.055 pounds (25 grams) used in the product are marked per ISO 11469 and ISO1043. This product contains 0% recycled materials (by wt.) This product is greater than 94% recycle-able when properly disposed of at end of life.

Packaging

Packaging Materials External: Corrugated Paper – 0.89 lb (402 g) Internal: Corrugated – 0.10 lb (46 g) PET Bag– 0.03 lb (15 g) The plastic packaging material is made from at least 20% post-consumer recycled content. The corrugated paper packaging materials contains at least

5/13/2010 1:53 PM

33 of 34


80% recycled content. HP follows these guidelines to decrease the environmental impact of product packaging: Eliminate the use of heavy metals such as lead, chromium, mercury and cium in packaging materials. Eliminate the use of ozone-depleting substances (ODS) in packaging materials. Design packaging materials for ease of disassembly. Maximize the use of post-consumer recycled content materials in packaging materials. Use readily recyclable packaging materials such as paper and corrugated materials. Reduce size and weight of packages to improve transportation fuel efficiency. Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards. Material Usage

This product does not contain any of the following substances in excess of regulatory limits (for reference of these limits please refer to the HP General Specification of the Environment (http://www.hp.com/hpinfo/globalcitizenship/environment/ supplychain/gen_specifications.html): Asbestos Certain Azo Colorants Certain Brominated Flame Retardants – may not be used as flame retardants in plastics Cium Chlorinated Hydrocarbons Chlorinated Paraffins Formaldehyde Halogenated Diphenyl Methanes Lead carbonates and sulfates Lead and Lead compounds Mercuric Oxide Batteries Nickel – finishes must not be used on the external surface designed to be frequently handled or carried by the . Ozone Depleting Substances Polybrominated Biphenyls (PBBs) Polybrominated Biphenyl Ethers (PBBEs) Polybrominated Biphenyl Oxides (PBBOs) Polychlorinated Biphenyl (PCB) Polychlorinated Terphenyls (PCT) Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been voluntarily removed from most applications. Radioactive Substances Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

End-of-life Management HP offers our customers several other options for handling their aging computers while also minimizing the impact on the environmentand Recycling including product trade-in and leasing services-in addition to recycling services. Please go to: http://www.hp.com/recycle, or your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

5/13/2010 1:53 PM

34 of 34


Hewlett-Packard Corporate Environmental Information

For more information about HP's commitment to the environment: Global Citizenship Report http://www.hp.com/hpinfo/globalcitizenship/gcreport /index.html Environment website http://www.hp.com/environment Eco-label certifications http://www.hp.com/hpinfo/globalcitizenship/environment/ productdesign/ecolabels.html ISO 14001 certificates: http://www.hp.com/hpinfo/globalcitizenship/environment/ operations/envmanagement.html

Copyright © 2007 Hewlett-Packard Development Company, L.P. All rights reserved. Microsoft, Windows, Windows Vista, and Windows XP are ed trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. Core Duo, Centrino, and SpeedStep are ed trademarks or trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth is a ed trademark of Bluetooth SIG, Inc., in the U.S. and other countries. All other product names mentioned herein may be trademarks of their respective companies. The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. DA-12446 17 - Version 17 - August 10, 2007

5/13/2010 1:53 PM

Hp Compaq Nc6400 Laptop Specifications h3m3o

Overview 6h3y3j

More details h6z72

Related Documents 543cg

Hp Compaq Nc6400 Laptop Specifications h3m3o

Hp Compaq Nc6000 Specifications 1d1f19

Hp Compaq 6530b 6730b Free Laptop Schematic.pdf 645t22

Hp Compaq j2a6q

Hp Compaq j2a6q

Compaq Nc8000 Specifications y5l2g
