Ge X400 Camera s Manual 1c2n3w

Manual imagination at work Getting Started

GE Digital Camera Power Pro Series : X400

Basic Operation Camera Function Controls Playback Using the Menus Camera Connectivity Appendix

EN

WARNING To prevent fire hazard or electrical shock, do not expose the camera battery pack or other accessories to water or humidity.

For Customers in the U.S.A. Tested to Comply with FCC Standards FOR HOME OR OFFICE USE FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

This symbol [crossed-out wheeled bin WEEE Annex IV] indicates separate collection of electrical waste and electronic equipment in the European countries. Please do not throw the equipment into domestic refuse. Please use the return and collection systems available in your country for proper safe disposal of this product.

Declaration of Conformity Model Name:

X400

Trade Name:

GE

Responsible Party: General Imaging Company

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Address:

For Customers in Europe

(Outside U.S. & Canada: +1-310-755-6857)

1411 W. 190th Street, Suite 550, Gardena, CA 90248, U.S.A.

Customer Service Telephone Number: +1-800-730-6597

"CE" mark indicates that this product complies with the European requirements for safety, health, environment and customer protection. "CE" marked cameras are intended for sales in Europe.



SAFETY PRECAUTIONS Camera Notes: Do not store or use the camera in the following types of locations: • In rain, very humid and dusty places. • In a place where the camera can be exposed directly to sunlight or subject to high temperature, e.g. Inside a closed car in summer. • In a place where the camera is subject to a high magnetic field, e.g. near motors, transformers or magnets. Do not place the camera on a wet surface or or in places where dripping water or sand may come in with the camera; doing so may cause irreparable damage. If the camera will not be used for a long period of time, we suggest you remove the batteries and the memory card from the camera and keep them in dry environment. Moisture may form inside the camera if the camera is suddenly brought from a cold location to a warm location. Allow moisture to completely dry prior to turning on camera. If water has penetrated the camera housing, turn off the camera and remove the battery and memory card. Allow the camera to air-dry for at least 24 hours before using again. If camera overheats, while in use or charging, disconnect thecharger and carefully remove batteries.

Battery Notes:

ii

Incorrect use of the batteries may cause them to leak, become hot, ignite or burst. Always observe the precautions given below: • Do not expose the batteries to water and take particular care to keep the terminals dry

• Do not heat the batteries or throw them into a fire • Do not attempt to deform, disassemble or modify the batteries Keep the batteries out of reach of babies and small children. In cold locations, battery performance will deteriorate and the life span of the battery may be compromised.

Memory Card Notes: When using a new or used SD memory card, or a SD memory card that has been initialized by a PC or a different model camera, be sure to reformat the card with your digital camera before using it. When editing image data, copy the image data to the PC’s hard disk first. Do not change or delete the folder or file names on the SD memory card from your PC. This may cause a memory card read error to occur when viewing photos on the memory card from the playback mode in your camera. The photos taken by this camera are stored in the auto-generated folder on the SD memory card. Do not store photos that are not taken by this model camera, as this may cause a read error to occur when the camera is in playback mode. Do not expose the camera to harsh environments such as moisture or extreme temperatures, which may shorten the life of your camera or damage the batteries. Do not remove the memory card without turning the camera off to avoid possible damage of your memory card. Do not switch off the digital camera when a writing process is in process to avoid incomplete data writing and damaged or loss of pictures. Align the SD memory card correctly before inserting it into the camera's SD memory card slot. Do not force the SD memory card into the camera's SD memory card slot.

BEFORE YOU START Preface Thank you for purchasing this GE digital camera. Please read this manual carefully and keep it in a safe place for future reference.

Copyright © Copyright 2012 General Imaging Company. All rights reserved. No part of this published manual may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form, by any means, without the prior written permission of General Imaging Company.

Trademarks All trademarks mentioned in this manual are used for identification purposes only and are properties of their respective owners.

Safety Information Please read the following important information carefully before using this product. • Do not take apart or attempt to service the camera yourself. • Do not drop or knock the camera. Improper handling may damage the product. • Turn the camera off before inserting or removing the battery and memory card. • Do not touch or scratch the camera lens. • Do not expose the camera to harsh environments such as moisture, chemicals or extreme temperatures, which may shorten the life of your camera or damage the batteries. • Do not use or store the camera in dusty, dirty or sandy areas, as the camera or components may be damaged. • Do not expose the lens to direct sunlight for extended periods of time. • all pictures and remove the batteries from the camera if you are going to store the camera for long periods of time.



• Do not use abrasive cleansers, alcohol-based or solventbased cleaners to clean the camera. To clean, wipe the camera with a slightly damp, soft cloth. • If water has penetrated the camera housing, turn the camera off and remove the battery and SD memory card. Allow camera to air-dry for at least 24 hours before using again. • Do not touch the lens. • Do not place the camera strap around a child or pet's neck. • When coming in from a cold environment to warm environment, avoid possible condensation by placing the camera in a cooler area and let it slowly adjust to room temperature.

About this Manual This manual provides you with instructions on how to use your new GE digital camera. Every effort has been made to ensure that the contents of this manual are accurate, however General Imaging Company reserves the right to make changes without notice.

Symbols used in this manual Throughout this manual, the following symbols are used to help you locate information quickly and easily: Indicates useful information.

• Always place the camera on a vibration-free surface. Indicates precautions to be taken while operating the camera.



CONTENTS WARNING.........................................................................i SAFETY PRECAUTIONS..................................................ii BEFORE YOU START...................................................... 1 Preface...........................................................................................1 Copyright..............................................................................1 Trademarks..........................................................................1 Safety Information......................................................................1 About this Manual.......................................................................2 Symbols used in this Manual............................................2

CONTENTS . ................................................................... 3

Set Display Language..................................................... 14 Set Date/Time................................................................... 15 Using the Mode Dial................................................................. 16 About the LCD Screen.............................................................. 17 Using Quick Record.................................................................. 18

BASIC OPERATION...................................................... 19 Shooting in Auto Mode............................................................ 19 Using the Zoom Function........................................................ 19 Open Flash................................................................................. 20 Self-timer................................................................................... 21 Macro Mode............................................................................... 22

GETTING READY............................................................ 7

EV (Exposure Value)..............................................................22

Unpacking.....................................................................................7

Face Detection.......................................................................... 23

Installing Shoulder Strap and Lens Cap.................................8

Smile Detection......................................................................... 24

Camera Views..............................................................................9

Blink Detection.......................................................................... 24

Inserting the Battery and SD/SDHC Card (Not included)................................................ 12

Stabilization............................................................................... 25

Turning On and Off................................................................... 14

Size...................................................................................... 27

Setting Language and Date/Time......................................... 14

Quality................................................................................ 27

Advanced Functions Menu..................................................... 26



WB (White Balance)......................................................... 28

Sport................................................................................... 37

Color.................................................................................... 28

Beach.................................................................................. 37

ISO....................................................................................... 29

Sunset................................................................................. 37

USING THE MODES..................................................... 30

Night Landscape.............................................................. 37

LCD Screen Display.................................................................. 30

Night Portrait .................................................................. 37

Still Picture Mode Display.............................................. 30

Party................................................................................... 38

Video Shooting Mode Display........................................ 32

Children.............................................................................. 38

Playback Mode Display................................................... 33

Indoor................................................................................. 38

Auto Scene Mode (ASCN)......................................................... 34 Landscape......................................................................... 34

Snow................................................................................... 38

Portrait............................................................................... 34 Night Portrait.................................................................... 35 Backlit Portrait................................................................. 35 Night Landscape.............................................................. 35 Macro.................................................................................. 35 Auto..................................................................................... 35 Panorama.................................................................................. 35 Scene Mode (SCN)..................................................................... 36



Fireworks........................................................................... 37

Landscape......................................................................... 37

ID......................................................................................... 38 Museum............................................................................. 38 Photo frame ..................................................................... 38 Panning Shot . .................................................................. 38 Text..................................................................................... 38 Leaf..................................................................................... 38 Glass................................................................................... 38 Fish eye ............................................................................. 38 Sketch................................................................................. 38 Portrait Mode............................................................................ 39

Auto Program Exposure.......................................................... 39

Date Imprint...................................................................... 51

Shutter Priority......................................................................... 40

Movie Menu............................................................................... 52

Aperture Priority....................................................................... 41

Expo Metering (Exposure Metering)............................. 53

Manual Mode............................................................................. 41

PLAYBACK.................................................................... 42

Continuous AF.................................................................. 53 Playback Menu.......................................................................... 54 Protect................................................................................ 54

Viewing Photos and Videos.................................................... 42

Delete................................................................................. 55

Thumbnail View........................................................................ 43

DPOF (Digital Print Order Format)............................... 56

Using Zoom in Playback (for still pictures only)................. 44

Resize.................................................................................. 57

Using the Delete Button.......................................................... 45

Rotate................................................................................. 57

USING THE MENUS..................................................... 46

Red-Eye Reduction.......................................................... 58 Trim..................................................................................... 58

Still Picture Menu..................................................................... 46

HDR-High Dynamic Range............................................. 59

AF Mode (Auto-Focus mode).......................................... 47

Display Setup.........................................................................59

AF-Assist Beam................................................................. 47

Slideshow........................................................................... 60

Expo Metering (Exposure Metering)............................. 48

Wallpaper Settings.......................................................... 60

Continuous Shot............................................................... 48

Setup Menu................................................................................ 63

Continuous AF.................................................................. 49

Beep.................................................................................... 64

Digital Zoom...................................................................... 50 Quick Review..................................................................... 50



LCD Brightness................................................................. 64

Video System............................................................................. 73

Power Saver...................................................................... 65

Using the PictBridge Menu..................................................... 74

Language........................................................................... 65

Print with Date................................................................. 74

Zone.................................................................................... 65

Print without Date........................................................... 75

Date/Time.......................................................................... 66

Print Index......................................................................... 76

File and Software...................................................................... 66

Print DPOF......................................................................... 77

Format Memory................................................................ 66

Exit...................................................................................... 77

Copy to Card (Copy internal memory to memory card)................................................................... 67 File Numbering................................................................. 67 Reset Settings................................................................... 68 FW Version (Firmware version)..................................... 68

CONNECTIONS............................................................ 69 Connecting to a PC................................................................... 69 Setting the USB Mode..................................................... 69 Transferring Files to your PC......................................... 69 Connecting to a PictBridge Compatible Printer................ 71 Setting the USB Mode..................................................... 71 Connecting the Camera and Printer............................ 72



APPENDICES................................................................ 78 Specifications............................................................................ 78 Error Messages......................................................................... 82 Troubleshooting....................................................................... 84

GETTING READY Unpacking Your camera box should contain the camera model you purchased along with the following items. If anything is missing or appears to be damaged, please your retailer.

AA-Size Alkaline Batteries

Warranty Card

CD-ROM

USB Cable

Lens Cap

Shoulder Strap



Installing Shoulder Strap and Lens Cap To Install Shoulder Strap

To Install Lens Cap

1 1

2 3

3

4



2

Camera Views Front View

Back View 6

2 1

3

disp

7 8 9

5

10 11 4

16 15

12 13 14



Left View

Right View

open

19

17

27-405mm

18

15x WIDE

optical zoom

20

Top View

Bottom View 26

22 21

10

ON/OFF

25 24 23

27

28 29

1

AF Assist/Timer Indicator

11

Menu Button

21

Zoom Wheel

2

Flash Lamp

12

Delete Button/Up Button

22

Shutter Button

3

Microphone

13

Macro Button/Right Button

23

Face Identification Button

4

Lens

14

Self-timer Button/Down Button

24

Stabilization Button

5

LCD Screen

15

Flash Button/Left Button

25

Shoulder Strap Mount

6

Status Indicator

16

OK Button

26

ON / OFF

7

Movie Button

17

USB/AV Port

27

Mode Dial

8

Playback Button

18

Handle

28

Card Slot/Battery Compartment

9

DISP

19

Flash On Button

29

Tripod Socket

10

Exposure Compensation Button

20

Speaker

11

Insert the Battery and SD/SDHC Card (Not included) 1. Open the battery compartment

2. Insert the enclosed AA batteries into the battery slot according to the correct polarity as shown below

2 1

4 3

12

3. Insert an SD/SDHC card (not included) into the SD memory card slot as shown

4. Close the battery compartment

Write protection buckle

Optional SD/SDHC cards are not included. The use of 64MB to16 GB memory cards from recognized manufacturers such as, Panasonic and Toshiba are recommended for reliable data storage. To remove the SD/SDHC card, open the battery compartment and gently push the card to release it. Remove the card out carefully.

13

Turning Camera On and Off Push ON/OFF to turn camera on/off

Setting Language and Date/Time When turning on the camera for the first time, the Display Language and Date/Time Setup menu will appear. Use the following procedures to set the camera Language, Date/Time to your preferences: 1. Push ON/OFF to turn the camera on. 2. Press Up/Down/Left/Right button to select the settings 3. Press the

button to confirm the settings

Set Display Language button and the Left/Right button and select 1. Press the the General Setup menu. After the camera is powered on, set the camera to Auto mode by turning the Mode Dial at the top of the camera (see page 16).

14

2. Use the Up/Down button and scroll down to desired language. Then press the Right button to access the language options 3. Use the Up/Down/Left/Right buttons to select the desired language 4. Press the button to confirm the setting

2. Use the Left/Right button to select date or time field, then press Up/Down buttons to adjust values. 3. Press the button to confirm the settings.

Set Date/Time button and use the Left/Right button to 1. Press the select the General Setup menu. Scroll down to Date/Time option and press the button to enter the Date/Time menu.

15

Using the Mode Dial This GE camera provides a convenient mode dial that allows you to manually switch between different modes with ease. All the available modes are listed below: Mode Name

Description

Auto Mode

Take still pictures in automatic mode

ASCN Mode

The camera automatically selects the best scene type for still pictures

Program AE Shutter Priority Aperture Priority

16

Icon

P S A

Setting allows you to choose the EV value and the camera will select both the shutter speed and aperture automatically Setting allows you to choose a specific shutter speed while the camera will adjust the aperture automatically to ensure correct exposure Allows you to choose a specific aperture and the camera will automatically adjust the shutter speed to match it

Manual Mode

Many of the camera settings can be configured manually in this mode

Portrait

Portrait pictures under normal conditions

Panorama Mode

Capture a sequence of shots and automatically stitch them together into a panoramic photo

Movie Mode

Record videos

Scene Mode

Choose from 20 different pre-set scene types and effects for your photos

About the LCD Screen When you turn the camera on, various icons are shown on the LCD screen to indicate the current camera settings and status. To learn more about the displayed icons, see “LCD Screen display” on page 30.

LCD Screen Notes: Extremely high-precision technology has been used to manufacture the LCD screen so that most of the pixels are operational. On occasion, there may be some minute points (black, white, red, blue or green) that constantly appear on the LCD screen. These points are normal in the manufacturing process and the recording is not affected in any way. Avoid exposing the LCD screen to water; remove any moisture on the LCD screen with a soft, dry cleaning cloth.

If the LCD monitor is damaged, take particular care with the liquid crystal in the monitor. If any of the following situations arise, take the recommended immediate action indicated below: • If liquid from inside the LCD screen comes in with your skin, wipe the area with a clean cloth and then wash thoroughly with soap and running water. • If liquid from inside the LCD screen gets into your eye, flush the affected eye with clean water for at least 15 minutes and then seek medical assistance immediately. • If the liquid crystal display or the liquid inside it are swallowed, flush your mouth thoroughly with water. Drink large quantities of water and induce vomiting. Then seek medical assistance immediately.

17

Using Quick Record In Shooting mode, press the Recording Shortcut button to enter the recording mode directly and begin video recording.

After recording, press the Recording shortcut button or Shutter button again and you can store the video and return to the shooting screen.

18

BASIC OPERATION Using the Zoom Function

Shooting in Auto Mode Auto mode is the easiest mode to take photos. While operating in this mode, the camera automatically optimizes camera settings to adjust your photos for best results.

Your camera is equipped with two types of zoom functions: optical zoom and digital zoom. Press the Zoom button of the camera to zoom in or out of the subject while taking pictures. Zoom Wheel

To start shooting, do the following: 1. Push ON/OFF to turn the camera on. 2. Switch the Mode dial to Auto Mode (

).

3. Compose your picture in the LCD screen and press the Shutter button halfway to focus on the subject. 4. The LCD screen will show a green focus frame after the subject is in focus. 5. Press the Shutter button down fully to capture the image. Zoom indicator (See “Digital Zoom“ on page 50)

When the optical zoom reaches its maximum value, release the Zoom button and then press it again for the digital zoom to begin. The zoom indicator is hidden after the Zoom button is released. The screen shows ( ) for the current zoom status.

19

Open Flash The flash is used to illuminate a subject in low light or for fillin lighting to achieve better illumination of a subject with pronounced shadows. 1. To turn on the flash, press the flash

button.

3. Press the Left/Right button to select from the following 6 modes: • •

Flash: Forced off Flash is turned off.

•

Flash: Red-Eye + Slow Synchro Using this mode for slow synchro shots with red-eye reduction.

•

Flash: Slow Synchro This allows for night scenery photos that include people in the foreground. The use of a tripod is recommended when shooting with this setting.

2. Press the left button to enter the flash Functions menu.

20

Flash: Forced Flash The flash will fire with each shot even if there is enough available light to take the photo without flash.

•



Flash: Red-eye reduction The camera emits a brief flash before the picture is taken to reduce red-eye effects.

•

Flash: Auto Camera flash goes off automatically based on existing light conditions.

4. Press the option.

button to confirm the settings and exit the

Self-Timer This setting allows you to set the camera for self portraits or group shots. The timer can be set to fire the shutter 2 seconds, or 10 seconds after the shutter button is pressed. 1. Press the Down button to enter the Self-Timer menu.

•

Self-timer: 2 sec A single picture is shot 2 seconds after the Shutter button is pressed.

•

Self-timer: 10 sec A single picture is shot 10 seconds after the Shutter button is pressed.

3. Press the menu.

button to confirm the settings and exit the

2. Press the Left/Right button to select the following three modes: •

Self-timer: Off Disables the self-timer.

21

Macro Mode The Macro setting is ideal for shooting small objects or closeup photos. This mode allows you to focus on subjects very close to the camera. 1. Press the Right button to enter the Macro menu.

EV (Exposure Value) The EV control allows for an override of the camera's auto exposure settings in order to provide more control in tricky lighting conditions. This will allow you to lighten or darken the exposure to your preference. 1. Press the

button to enter the exposure settings screen.

2. Press the Left/Right button to select the following two modes: •



Macro: Off

•



Macro: On

Select this option to disable Macro. Select this to focus on subjects 5cm from the lens. 3. Press the menu.

22

button to confirm the settings and exit the

2. Press the Up/Down button to adjust the exposure value of the image ranging between EV -2.0 to EV+2.0.

Face Detection The face detection mode detects people's faces and focuses on them resulting in clearer images. Face detection is engaged by default in most modes unless it is disabled by the . Face detection is disabled in Panorama Mode. 1. When the face detection feature is enabled it will display a frame around detected faces in the camera's field of view. 2. Press the Shutter button halfway to focus on the subject. 3. Press the Shutter button fully to capture the image. 4. Use the Face Detection button to disable this function.

23

Smile Detection The Smile Detection feature automatically detects and captures a person's smile. 1. In shooting mode, Press the Smile Detection button until the Icon appears on the LCD screen. 2. Point the camera at the subject, and press the Shutter button half way to focus. 3. Press the Shutter button all the way to capture the image, the camera will automatically release the shutter when it detects a smile.

4. Use the Smile Detection button to disable this function.

24

Blink Detection Blink Detection is enabled by default unless disabled by the . When shooting, if a subject is detected with its eyes closed, the Blink Detection icon will appear on the screen to show that a blink was detected.

Stabilization While in Shooting mode, press the button to reduce blurred images caused by inadvertent hand shake. The LCD will display either the Continuous or Single stabilization icon.

25

Advanced Functions Menu The Advanced Functions Menu of the camera include Image Size, Image Quality, White Balance, Image Color and ISO value. These functions allow advanced s better control for shooting under difficult lighting conditions. To set the Advanced Functions: 1. Pull up the Advanced Function Menus by pressing the button. 4. Use the Left/Right buttons to change the settings and then press to confirm the new settings and close this Advanced Function Menu.

2. Press Down button to enter the advanced function selection screen, press the Left/Right button to select the function that you want to set. 3. Press the Up button to enter the advanced function setting interface.

26

Size

Quality

The size setting refers to the image resolution in pixels. A higher image resolution allows you to print that image in larger sizes without degrading the image quality.

The camera's quality setting adjusts the compression ratio of the images. Higher quality settings produce better quality photos, but will take up more memory space.

There are three options for picture quality: The bigger the number of recorded pixels is, the better the image quality becomes. As the number of recorded pixels becomes smaller, you will be able to record more images on a memory card.

•

Quality: Best

•

Quality: Fine

•

Quality: Normal

27

WB (White Balance)

Color

The White Balance allows you to adjust the color temperature for different lighting sources to ensure accurate color reproduction.

The color setting allows you to add artistic color effects when taking pictures. You can try different color tones to alter the mood of your pictures.

The options for White Balance include:

28

•

WB: Auto

•

WB: Daylight

•

WB: Cloudy

•

The color options include: •

Color: Auto

•

Color: Vivid

WB: Fluorescent

•

Color: Black & White

•

WB: Fluorescent CWF (cool white fluorescent)

•

Color: Sepia

•

WB: Incandescent

•

WB: Manual (Press the Shutter button to detect WB)

ISO The ISO function allows you to set the sensitivity of the camera's light sensor based on the brightness of the scene. To improve the camera's sensor performance in darker environments, a higher ISO value is required. A lower ISO value is needed when shooting in bright conditions. Pictures at higher ISO will generally have more noise than those at lower ISO.

The camera's ISO settings include automatic, 80, 100, 200, 400, 800, 1600(4M) and 3200(4M). The available ISO values vary on different camera models.

29

USING THE MODES LCD Screen Display Still Picture Mode Display

1 Shooting Mode Icons

PSA

Mode: 1

2

3

4

5

6

7

8

4

19

9

18

10

17 16

11

15

20

14

21

13

22

23

4

24

12

Auto Mode

ASCN Mode



Program AE

Shutter Priority



Aperture Priority

Manual Mode

Portrait Scene Mode 2 AF Mode

Single-AF



Multi-AF

3 Expo Metering

Spot



Center



AiAE

4 Image Size 5 Image Quality

30

Panorama Mode

6 Remaining number of pictures 7 SD Memory card/built-in memory 8 Battery Status 9 WT Ratio (Displayed only when zoom is activated) 10 Zoom 11 ISO Value (Adjustable only in M, P, S, and A modes) 12 Histogram

23 Self-Timer 2-sec 10-sec 24 Flash Mode Flash: Forced off

13 Exposure Compensation (EV value) Flash: Forced flash

14 Shutter Speed 15 Aperture Value

Flash: Red-Eye + Slow Synchro

16 Focus Frame 17 Stabilization

Flash: Slow Synchro

18 Continuous Shot Flash: Red-eye reduction

19 Face Detection 20 Picture Color (Adjustable only in

M, P, S, and A modes)

21 White Balance (Adjustable only in

M, P, S, and A modes)

Flash: Auto

22 Macro Mode

31

Video Shooting Mode Display

4 Video Quality 5 Macro Mode

Mode :

6 Self-Timer 1

2

3

4

5

6

7

8

10-sec

9

7 Remaining time for video recording 13

10

12

11

8 SD Memory Card/Built-in Memory 9 Battery Status 10 Zoom 11 Zoom Value Scale (Displayed only when zoom is activated) 12 Image Stabilization 13 Recording Status Icon Recording standby

1 Video Mode Icon 2 Continuous AF 3 Metering

32



Spot



Center



AiAE

Recording For optimal video shooting, it is recommended that an SD memory card be used. If you shoot video using only the internal memory the results may have image jitter, noise and short recording times. While shooting, both optical zoom and up to 6x digital zoom are available.

Playback Mode Display

1 Playback Mode Icon 2 DPOF File

Mode:

3 File Protection 4 Picture Number 1

2

3

4

5

5 SD Memory Card/Built-in Memory

6

6 Battery Status 7 Image Zoom 8 Zoom Magnification Area

13

7

9 Current Display Area 10 Memory Space (this picture/total number of pictures) 11 Recording Date and Time 12 OK:PLAY

8

12

9

11

13 HDR

10

33

Auto Scene Mode (ASCN) In the "ASCN" mode, different recording conditions are detected intelligently and the most suitable settings will be automatically selected. Icon

Mode name

Icon

Mode name

Landscape Mode

Night Landscape Mode

Portrait Mode

Macro Mode

Night Portrait

Auto Mode

Backlit Portrait

2. Hold the camera steadily and aim at the subject. The optimum scene mode will be selected automatically. 3. Press the Shutter button halfway down to focus.

To use "ASCN":

4. Press the Shutter button all the way down to take the picture.

1. Turn the mode dial to "ASCN", The LCD screen will display the following icons.

Landscape Mode For landscapes, ASCN will automatically adjust the exposure and reproduce vivid green and blue colors. Portrait Mode For portraits, ASCN will automatically adjust the exposure and skin tones to produce natural looking photos.

34

Night Portrait When taking portraits at night, or in low light conditions, ASCN will automatically adjust the exposure for people and night scenes. Backlit Portrait When the sun or any other light source is behind you, ASCN will automatically adjust the foreground exposure to produce the best pictures possible. Night Landscape Mode For night scenes, ASCN will automatically increase the ISO value to compensate for low light. Macro Mode To produce more detailed close-ups, ASCN will automatically engage the camera's Macro mode and automatically focus the lens. Auto Mode The camera will automatically adjusts the exposure and focus to ensure the best possible pictures.

Panorama Panorama Mode allows you to create a panoramic picture. The camera will automatically compose a panoramic picture using the individual shots that you take. Follow these easy steps to create a panoramic picture: 1. Turn the mode dial to the Panorama Mode. 2. Use the Left/Right buttons to specify the direction of of the photo sequence. If nothing is chosen, in 2 seconds the panoramic sequence will commence at the default direction of left to right. 3. Compose the first view of the panoramic picture on the LCD screen and press the Shutter button to capture the image. 4. After the first shot is taken, two target icons will appear on the left and right side of the LCD screen. Pan the camera and the circle icon on the screen will move towards the square frame icon. When the circle icon and square frame overlap and turn green, the camera will automatically capture the next image. Repeat this step for the third picture in the series.

35

Manual Scene Mode (SCN) In Manual Scene mode, you can select from a total of 20 scene types to suit your needs. The camera will automatically adjust to the optimal settings based on the scene type that is chosen. To enter the Scene Mode, turn the mode dial to Manual Scene mode. The Scene Mode menu will appear. Flash Mode, Self-timer, Macro Mode, and Exposure Compensation are disabled in Panorama Mode. In the process of automatic panoramic shooting, "Improper alignment. Please try again." shown on the LCD screen means that the moving angle deviates from the green baseline during camera moving which leads to shooting failure, and you need to shoot again. Panorama Mode can stitch 2 or 3 pictures maximum.

36

Select a scene using the Up/Down/Left/Right button and press the button. Icon

Mode Name

Icon

Landscape For landscapes. Vivid reproduction of green and blue.

Mode Name

Sport

Landscape

Sport

Beach

Sunset

For fast-moving subjects. Capture sharp action shots without blur.

Fireworks

Night Landscape

Night Portrait

Party

Children

Indoor

Snow

ID

Museum

Photo frame

Panning Shot

Text

Leaf

Glass

Fish eye

Sketch

Beach For taking good pictures in the scenes with strong sunlight. Sunset For sunsets. Capture subjects in strong sunlight. Fireworks For fireworks at night. Slower shutter speed adjusted for brilliant images. Night Landscape For night scenes. use of tripod is recommended. Night Portrait For portraits against night time scenery.

37

Party

Panning Shot

For capturing more natural looking images of indoor gatherings.

Produces background image blur that emphasizes motion of the main subject.

Children

Text

For kids and pets. Flash is disabled for eye protection.

For text in print or on mhiteboards.

Indoor

Leaf

For indoors. Reduce blur and improve color accuracy.

For plants. Capture brilliant shots of greenery and blossoms.

Snow

Glass

For snow scenes. Reproduce natural and clear white scenes.

For objects behind transparent glass.

ID

Fish eye

For shooting certificates clearly. Museum For museum or flash-free area. Retain color and reduce blur. Photo frame For adding interesting frame effects to the photo.

38

For creating interesting fish eye effects that resemble photos taken with a fish eye lens. Sketch For taking photos with pencil sketch effect.

Auto Program Exposure

Portrait Mode In Portrait Mode, the camera is set to automatically adjust camera exposure for realistic portrayal of skin tones. 1. Turn the mode dial to select Portrait Mode (

).

2. Once in this mode, you can use other functions, such as image stabilization, face detection and smile detection.

P

When selecting P (Auto Program Exposure) mode, you can adjust the combined settings of EV value, shutter speed and aperture. The display on the LCD screen is as shown in the figure below:

1. Set the mode dial at the top of the camera to P and press the button to enter the Auto Program Exposure settings menu. 2. Press the Left/Right button to select the combination of EV, shutter speed and aperture for your scene.

39

Shutter Priority

S

When selecting S (Shutter Priority) mode, you can adjust the shutter speed and EV value. Selecting a higher shutter speed will capture fast moving objects clearly. Selecting a slower shutter speed will result in motion blur of moving objects. 1. Set the mode dial to S and press the Shutter Priority settings menu.

button to enter the

2. Press the Left/Right button to select EV/shutter speed. 3. Press the Up/Down button to select the parameter adjustment. 4. Press the button to engage the settings and enter the shooting screen. Shutter speed is adjustable between 30 and 1/2000; aperture size is adjustable between 3.0 and 7.9; EV value is adjustable between +2.0 and 2.0. When you press the shutter half way, the aperture size and shutter value of the current detection will display in the lower, left corner of the screen.

40

3. Press the Up/Down button to select the parameter adjustment. 4. Press the button to confirm the settings and enter the shooting screen.

Aperture Priority A

Manual Mode M

When selecting A (Aperture Priority) mode, you can adjust the aperture size and EV value. Selecting a large aperture opening will emphasize the point of focus and show a blurry background and foreground. A small aperture opening will keep both the background and main object in clear focus. 1. Set the mode dial to A and press the Aperture Priority setting's menu.

button to enter the

When selecting M (manual) mode, you can set the aperture and shutter speed manually. 1. Set the mode dial to M and press the the Manual Mode setting's menu.

button to enter

2. Press the Left/Right button to select the aperture/shutter speed.

2. Press the Left/Right button to select EV/aperture.

3. Press the Up/Down button to select the parameter adjustment. 3. Press the Up/Down button to select the parameter adjustment. 4. Press the button to confirm the settings and enter the shooting screen.

4. Press the button to confirm the settings and enter the shooting screen.

41

PLAYBACK Viewing Photos and Videos To view the captured photos and video clips on the LCD screen: 1. After pressing the button, the last photo or video clip taken will be displayed on the LCD screen. 2. Use the Left/Right navigation buttons to scroll through the photos or video clips stored in the internal memory or on the SD memory card. 3. To play a selected video clip, press the the movie playback mode.

button to enter

During video playback, the operating instructions will appear on the screen. Press the Left/Right button, and press the button to engage the following actions.

1 2 3 4 5

42

6

The operating instruction icons are as follows. 1

Return to the first frame and play

4

Return to the first frame

2

Play

5

Rewind

3

Fast Forward

6

Pause

When playing a movie, press the Up/Down arrow button to raise or lower the volume, to mute the volume press the down arrow until the mute icon appears.

Thumbnail View When in Playback mode, rotate the zoom wheel counter clockwise to the position to display thumbnail images of the photos and videos on the screen. W Zoom out T Zoom in

1. Use the Zoom button to switch between 3x3, 4x4 and Date Folder thumbnail display.

2. When displaying 3x3 and 4x4, use Up/Down/Left/Right button to select a picture or video clip for viewing; when displaying the Date Folder, use Up/Down button to select the Date Folder. button 3. When displaying a Date Folder, pressing the will enter the date information index.

43

Using Zoom Playback (for still pictures only) The zoom buttons can also be used during playback. This allows you to magnify photos between 2x to 8x. 1. Press the

button to switch to playback mode.

2. Use the Left/Right navigation buttons to select a photo to magnify.

4. Use Up/Down/Left/Right button to select a picture or video clip, press the button to return to the original size.

3. Rotate the zoom wheel clockwise to ( ) to zoom in. 4. Use the Zoom wheel to zoom in and out. The zoom magnification area frame and the frame of the whole photo will display on the screen.

The Date Folder is displayed in order based on the shooting date. If the indicator appears on the LCD, then a movie file is currently being displayed. Press the button to restore a preview icon to its original image size.

44

5. Use the navigation buttons to pan across the image. 6. Press the scale.

button to return the image to its original

Movie images cannot be magnified.

Using the Delete Button In Playback Mode, you can press the Up/Delete button to delete an unwanted photo or video. To delete pictures or videos: 1. Press the

button to switch to playback mode.

2. Select the picture or video clip you want to delete with the Left/Right button. 3. After pressing the Up/Delete button, the delete screen will display on the screen.

4. Select Yes or Back with the Up/Down button and press the button for confirmation. Erased photos/video clips cannot be recovered. Please refer to page 55 for instructions on the Delete Menu options.

45

USING THE MENUS Photo Setup Menu Mode:

PSA

In any of the above Photo Modes, press the the Photo Setup Menu.

button to go to

To adjust each setting: 1. In the Photo Setup Menu, use the Left/Right button to select the Tab (at the top of the screen) corresponding to the page containing the function you wish to change. 4. In the sub-menu press the Up/Down button to select a setting and press the function button to confirm that setting and exit the sub-menu. 5. Use the Up/Down Left/Right button to continue to navigate the Photo Menu for additional changes, or press the menu button to exit the Photo Menu.

2. Press the Up/Down buttons to select the function. 3. Press the Right button, or the function the sub-menu.

46

button to go to

After selecting a function, you can press the Up button to return to the Still Picture menu for other Photo Setup or Camera Setup pages. Or you can press the Down button several times to move to the next setup menu page. Refer to the following pages for more details about each setting.

AF Mode (Auto-Focus Mode)

AF-Assist Beam

Use this setting to control the Auto-Focus mechanism while taking pictures.

This option can turn on or turn off the AF assist lamp. The AF assist beam is useful for focusing in the dark or in low lighting conditions.

Two options are available: • Single-AF: The focus frame appears in the center of the LCD screen to focus on the subject. • Multi-AF: The camera automatically focuses the subject in a wide area to find the focus point.

47

Expo Metering (Exposure Metering) Use this setting to select the "target" size of the camera's field of view to be metered.

Use this setting to perform continuous shooting. After entering this mode, you can shoot multiple images by continuously holding the shutter button down.

Three metering "target" sizes are available to choose from:

There are five available options:

• Spot metering targets a small area in the center of the camera's field of view. • Center metering targets a slightly larger area in the center of the cameras field of view. • AiAE (Artificial Intelligence AE) targets the camera's entire field of view.

48

Continuous Shot

• Off: Turns off the Continuous Shot function. • Unlimited: Press and hold down the shutter button to shoot continuously until you release the shutter button or until the memory card has run out of space. • 3 Shots: Capture up to 3 consecutive pictures. • 3 Shots (Last): Capture pictures continuously until the Shutter button is released but only the last 3 shots are recorded. • Time Lapse: Automatically capture pictures at predefined intervals.

The flash is disabled in this mode in order to enable quick succession of shots.

Continuous AF With Continuous AF turned on, the camera will continually adjust focus automatically in response to any camera or subject movement.

49

Digital Zoom

Quick Review

Use this setting to enable or disable the Digital Zoom function. When Digital Zoom is turned off, only the optical zoom is functional.

This setting refers to the brief photo review immediately after taking a picture. The picture stays on the LCD screen for an adjustable period of time.

Four options are available: • Off • 1 sec • 2 sec • 3 sec

50

Date Imprint Include a Date/Time stamp in the photo image.

• Off • Date • Date / Time

51

Movie Mode Menu Mode: In the Movie Mode, press the sponding Movie menu.

button to go to the corre-

To configure each setting: 1. In the Movie menu, switch between the Movie Setup or different Camera Setup pages using the Left/Right button, select the tab with the function you want to adjust and press the Down button. 3. Press the Up/Down button to select an option or the Left or button to return to the menu. 4. Press the button to confirm the setting and return to the previous menu. Refer to the following pages for more details about each setting.

2. Press the Up/Down button to select the function and press the Right button to go to the sub-menu.

52

Expo Metering (Exposure Metering)

Continuous AF

Use this setting to select the "target" size of the camera's field of view to be metered.

After Continuous AF is turned on, the camera will adjust focus automatically in response to any camera or subject movement.

Three metering "target" sizes are available to choose from: • Spot metering targets a small area in the center of the camera's field of view. • Center metering targets a slightly larger area in the center of the cameras field of view. • AiAE (Artificial Intelligence AE) targets the camera's entire field of view.

53

Playback Menu Protect

Mode : In Playback mode, press the menu.

button to enter the Playback

The following section provides detailed instructions on the various menu options.

To prevent any pictures or videos from being accidentally erased, use this setting to lock one or all of the files.

To protect/unprotect a picture or video: 1. Use the Up/Down arrow button to select Protect, press the or Right button to enter the submenu. 2. Use the Up/Down button and select "one" to lock a single photo or movie; or select all to protect all photos and movies stored in in-built memory card. Press the button to confirm and enter the photo/movie protection interface.

54

3. Select Yes to lock displayed photos or videos, or select De-protection to unlock, then press and select "back" to return to the playback menu.

Delete There are three ways to delete files.

After selecting Reset, all previous protection settings will be cancelled.

• Delete One: 1. In the Delete Option, select One and then press the button. 2. Press the Left/Right button to locate the photo or video to be deleted. Press the Up/Down button and select Yes and press the button to delete the item or select "Back" to return to the previous menu.

55

DPOF (Digital Print Order Format)

• Delete All: 1. In the Delete option, select All and then press the button. 2. Use Up/Down button and select Yes to delete all files, or select Cancel to return to the menu. • Delete Date Folder: 1. In the Delete option, press Folder.

button after selecting Date

2. Use the Up/Down button to select Date Folder to be deleted, press to confirm, press the Up/Down button to select item (Yes: to delete the file, Cancel: to return to the menu) and then press to confirm. The “ ” indicator means a file is protected. File protection must be removed first before a file can be deleted. Deleting files will cause DPOF settings to be reset.

56

The DPOF feature allows you to compile a selection of pictures that you would like to have printed, and will save your selection in the memory card so that you can simply hand your SD memory card to a photo printing service without having to individually specify which photos you would like to print.

Resize

Rotate

This setting allows you to resize a picture to a specified resolution, and saves it as a new picture.

You can use this setting to change the orientation of the picture.

1. Select the Resize setting from the Playback menu as described previously.

1. Select the Rotate setting from the Playback menu as described previously. 2. Use the Left/Right navigation buttons to select a picture to rotate. 3. Use the Up/Down navigation buttons to select the direction of rotation or Back to cancel and return to the Playback menu.

2. Use the Left/Right navigation buttons to select a picture to resize. 3. Use the Up/Down navigation buttons to select a resolution (1024X768 or 640X480) to resize the image or Back to cancel and return to the Playback menu. 4. Press the

4. Press the

button to confirm the setting.

button to confirm the setting.

Resizing an image creates a new file that contains the image in the size you select. The file with the original image also remains in the memory.

Videos and panoramic pictures cannot be rotated. The rotated picture file will replace the original one.

57

Red-Eye Reduction Use this setting to remove red-eye effect in your photos. 1. Select the Red-Eye Reduction in the Playback menu as described previously. 2. Use the Left/Right button to select the picture that requires red eye removal. 3. Use the Up/Down navigation buttons and select Yes to fix the selected image or Back to cancel and return to the Playback menu.

4. Press the

58

button to confirm the setting.

For best results, the face of the subject should be relatively large in the LCD screen, the subject should be facing the camera and the red-eye effect should be clearly visible.

Trim

The Trim setting allows you to crop photos and save them as new pictures. To trim a picture: 1. With the camera in Playback mode press the menu button to access the Photo Menu. Then use the Left/Right button and select the "playback setup 2" tab. Use the Down button to select Trim and press the function button to enter the Trim sub-menu. 2. Using the Left/Right buttons, locate the photo that you want to crop. After the photo is displayed on the LCD screen press the Down button, select Yes and press the function button. 3. Use the zoom buttons and navigation buttons to compose the picture.

4. Press the button and a ‘Save Changes?’ prompt will appear. Select “O” to confirm the changes and save the new image, or select “X” to cancel the changes and return to the previous menu. The image can not be clipped/trimmed again once it has been clipped to 640X480.

HDR-High Dynamic Range With the HDR function, pictures that are overexposed may be corrected to optimize the highlights and lowlights captured to more accurately represent the actual scene. 1. Select HDR setting in the Playback menu as described previously. 2. Press the Left and Right button to find the picture you want to optimize and then select Confirm to perform HDR optimization or select Return to go back to Playback menu.

3. After using the HDR function, the image will be saved as a new file, and the original file is still stored in the memory.

Display Setup Mode: Press the button in Playback mode to enter the Display Setup menu.

Refer to the following sections for details of every setting.

59

Slideshow

Wallpaper Settings

This setting allows you to view all the stored pictures as a slideshow.

Use this setting to select your favorite picture to use as a background on the LCD screen.

1. Select Slideshow and press the Right button to enter the Slideshow options menu.

1. Press the Down button to select the Wallpaper Setting menu.

2. Press the Up/Down button to select effect, interval or repeat, and press the or Right button to enter and adjust settings. Press the button to confirm settings.

2. Press Right, and the camera will enter the Wallpaper Setting interface.

3. Use the Up/Down navigation buttons to select Start to run the slideshow or Cancel to return to the Playback menu. 4. Press the

60

button to confirm the setting.

Menu Wallpaper:

Startup Screen:

From the Display Setup tab use the Up/Down button to select the Wallpaper Settings option, press the button then press Right to enter the wallpaper sub-menu. Press Right and select either , Nature, or Sparkling. Press function to confirm the setting.

Use the UP/Down button to select the Welcome Wallpaper option, press the or Right button to select welcome wallpaper, press Left button to return to last page, and press to exit the menu.

• •

• GE Logo

• Nature • Sparkling

61

Back To Default: Use the Up/Down button to select the Back to Default option, press the or Right button to select whether to take the default settings, press the Left Button to return to last page, and press to exit the menu.

• Yes • No

62

Setup Menu Mode :

PSA

The Setup menu for the camera is available in all modes. Each menu page can be selected by pressing the button and switching between tabs with the Left/Right button.

2. Switch between different functions with the Up/Down button. 3. Press the Right button to enter the sub-menu. After selecting a function option, you can press the Up button to return to the menu for other Camera Setup pages. Or you can press the Down button to switch to the next menu page. Refer to the following pages for more details about each setting.

To adjust the settings: 1. Select the menu tab that corresponds with the function you want to adjust and press the Down button.

63

Beep

LCD Brightness

Use this setting to adjust the volume of the beep emitted when buttons are pressed and change the tones for the Shutter button, self-timer, and power-on/power-off.

Use this setting to adjust the brightness of your LCD screen.

To change this setting:

2. Select auto or adjust the brightness level using the Left/Right button, and press the button to confirm the setting.

1. Select the Beep setting from the Setup menu as described previously. 2. Use the Up/Down navigation buttons to switch between volume, shutter, key, self-timer, and power tone fields.

3. Press the Right button, then press the Up/Down button to adjust the volume or change the tone, and press the button to confirm the setting.

64

1. Select the LCD Brightness setting from the Setup menu as described previously.

Power Saver This setting allows you to save power and get the maximum possible running time for your batteries. Follow the steps below to turn off the LCD screen and camera automatically after a period of inactivity. 1. Select the Power Save setting from the Setup menu as described previously. 2. Press the Up/Down button to select the power items for the screen and camera and press the Right button.

• LCD off: On, 30 sec, 1 Min, 2 Min. • Camera off: On, 3 Min, 5 Min, 10 Min. 4. Press the

button to confirm.

Language See “Setting the Language“ section on page 14.

Zone The Zone setting is a useful function on your overseas trips. This feature enables you to display the local time on the LCD screen while you are overseas. 1. Select the Zone setting from the Setup menu as described previously. The world time screen will appear. 2. Use the Up/Down navigation buttons to switch between the hometown ( ) and travel destination ( ) fields.

3. Press the Up/Down button to adjust the selected item. Both items have the following options:

3. Use the Left/Right navigation buttons to select a city close to the desired time zone. Then press the button to confirm.

65

File / Software Format Memory Please note: formatting enables you to delete all contents in the memory card and built-in memory, including protected photo and movie files. To use this setting: 1. Select Format Memory in the File and Software menu. 2. Use the Up/Down navigation button to select Yes or No. Then press the button to confirm the setting.

Date/Time See “Setting the Date and Time“ section on page 15.

66

3. Select Yes, the camera will format the selected media. Note that when you perform the Format Memory function, it only formats the active memory. If an SD memory card is inserted, the SD memory card is active and will be formatted. If there is no SD memory card, the internal memory is active and the internal memory will be formatted. Formatting the SD memory card will not automatically format the internal memory.

Copy to Card (Copy internal memory to SD memory card) Use this setting to copy the files stored in the internal memory to an SD memory card. 1. Select Copy to Card in the File/Software menu, then press Right. 2. Use the Up/Down navigation buttons to select Yes or No. Then press the button to confirm the setting.

File Numbering After you take a picture or video clip, the camera will save it in a sequential number. You can use this to reset the file numbering to 1. (When there are more than 999 images on the SD memory card, the use of this feature will have no effect). 1. Select File Numbering in the File/Software menu, then press Right. 2. Select the option with the Up/Down button and press the button for confirmation.

67

Reset Settings

FW Version (Firmware Version)

Use this setting to restore the camera to its original factory default settings.

Use this setting to view the current camera firmware version.

1. Select Reset Settings in the File/Software menu, then press Right.

Select FW Version in the File/Software menu, then press Right.

2. Use the Up/Down navigation buttons to select Yes or No. Then press the button to confirm the setting.

To update to the latest firmware version, you can go to the following website: www.ge.com/digitalcameras and look under .

68

CONNECTIONS Connecting to a PC Use the included USB cable and ArcSoft software (CD-ROM) supplied with your camera to copy (transfer) pictures to a computer.

Setting the USB mode The camera’s USB port can be set to connect with either a PC or a Printer, the following steps will allow you to ensure that the camera is correctly configured to connect with a PC. 1. Go to the Transmission menu, then select USB connection with the Up/Down button, and press the Right button. 2. Use the Up/Down navigation buttons to select PC. 3. Press the

button to confirm the setting.

Transferring files to your PC The computer will automatically detect the camera as a removable drive. Double-click the My Computer icon on the desktop to locate the removable drive and to copy folders and files in the drive to a directory on your PC as you would copy any typical folder or file. By using the included USB cable, you can transfer the captured photos and videos to a PC. Follow the steps below to connect the camera to a PC. 1. Start a computer in which the included ArcSoft software has been installed. 2. Make sure both the camera and PC are turned on. 3. Connect one end of the supplied USB cable to the USB/AV OUT port on your camera. 4. Connect the other end of the cable to an available USB port on your PC.

69

Windows operating system (Windows 2000, Windows XP, Windows Vista, Windows 7). Click the [Safely remove the hardware] icon and remove the USB connector according to the appeared menu.

5. Disconnect the camera once transfer is completed.

If the USB option is set to [PC] : Turn the camera off and disconnect the USB cable.

If the USB option is set to [PC (PTP) ] : Remove the camera from the system as described below before turning the camera off and disconnecting the USB cable.

70

Macintosh Drag the untitled icon to the Trash. ("Untitled")

Connecting to a PictBridge Compatible Printer PictBridge allows printing images from an SD memory card in a digital camera directly to a printer, regardless of brand. To find out if a printer is PictBridge compatible, simply look for the PictBridge logo on the packaging or check the manual for specifications. With the PictBridge function on your camera, you can print the captured photos directly to a PictBridge compatible printer using the supplied USB cable, without the need for a PC.

3. Press the

button to confirm the setting.

Setting the USB mode The camera’s USB port can be set to connect with either a PC or a Printer, the following steps will ensure that the camera is correctly configured to connect with a Printer. 1. Go to the camera's Transmission menu and, select USB connection with the Up/Down button, then press the Right button.

After the camera is reset, it will switch to PC mode automatically from USB mode.

2. Use the Up/Down button and select Printer.

71

Connecting the camera and printer. 1. Make sure both the camera and printer are turned on.

If the camera is not connected to a PictBridge compatible printer, the following error message will appear on the LCD screen.

2. Connect one end of the supplied USB cable to the USB port on your camera. 3. Connect the other end of the cable to the USB port on the printer.

The above error message would also appear if the USB mode was set incorrectly, in which case you should disconnect the USB cable, check the USB mode settings, ensure that the Printer is turned on, and then try connecting the USB cable again.

72

Video System Use this feature to switch the video system from either NTSC or PAL. 1. Select Video System in the Transmission menu, then press Right. 2. Use the Up/Down navigation buttons to select NTSC or PAL. Then press the button to confirm.

The video output signal can be switched to NTSC or PAL to accommodate different regional TV standards. The appropriate setting will vary between regions. NTSC:

USA, Canada, Taiwan, Japan, etc.

PAL:

Europe, Asia (excluding Taiwan), Oceania, etc.

Note:

The TV output will not display properly if an incorrect video system is selected.

73

Using the PictBridge Menu After setting the USB mode to Printer, the PictBridge menu will appear.

Print with Date If you have set the date and time on your camera, the date and time will be recorded and saved with each photo you take. 1. Select Print with Date from the PictBridge menu. The following screen will appear.

Select a menu item with the Up/Down button and press the Right button or button to enter the item. Refer to the following sections for more detailed information on each setting.

74

2. Use the Left/Right navigation buttons to scroll through the photos.

3. Use the Up/Down navigation buttons to select the number of prints for the displayed photo.

Print without Date

4. Press the

1. Select Print without Date from the PictBridge menu. The following screen appears.

button and the following screen will appear.

5. Select Yes to print or exit, then press

Use this setting to print the photos without dates on them.

button again. 2. Use the Left/Right navigation buttons to scroll through the images. 3. Use the Up/Down navigation buttons to select the number of prints for the current displayed image. 4. Press the

button and the following screen will appear.

75

5. Select Yes to print or exit, then press the

button again.

Print Index You can use this setting to print an index of all the photos currently in your camera's memory. 1. Select Print index from the PictBridge menu. The following screen will appear.

76

2. Select Yes to print or exit, then press the

button again.

Print DPOF (Digital Print Order Format)

Exit

To use DPOF printing, you must make the selection of photos for printing using the DPOF settings beforehand. See “DPOF” section on page 56.

To exit the PictBridge menu, select Exit. The “Remove USB cable” message will be displayed.

1. Select Print DPOF from the PictBridge menu. The following screen will appear.

Disconnect the USB cable from the camera and printer.

2. Select Yes to print or exit, then press the

button again.

77

APPENDICES Specifications Design and specifications are subject to change without notice. Active Image Sensor Pixels

14.14 Megapixels

Total Image Sensor Pixels

14.48 Megapixels [1/2.33"CCD]

Lens

78

Focal Length

4.9mm (Wide) — 73.5mm (Tele)

[35mm film equivalent]

[27mm (Wide) — 405mm (Tele)]

F number

F3.0 (Wide) — F5.2 (Tele)

Lens Construction

11 groups 14 elements

Optical Zoom

15x

Focusing Range

Normal: (Wide) 23.6in. ~ ∞ / 60cm ~ ∞ (Tele) 47.2in. ~ ∞ / 120cm ~ ∞ Macro: 1.9in. ~ ∞ / 5cm ~ ∞ (Wide Only)

Viewfinder

No

Anti-Handshake

Optical Image Stabilization

Digital Zoom

6x Digital Zoom (Combined Zoom: 90x)

Number of Recording Pixels

Still Image

14MP: 4320×3240, (3:2)12MP: 4320×2880, 8MP: 3264×2448, 5MP: 2592×1944, 3MP: 2048×1536, (16:9)2MP: 1920×1080, 0.3MP: 640×480

Movie

VGA, QVGA

Image Compression

Best, Fine, Normal

DCF, DPOF (Ver1.1)

Yes

File Format

Still Image

Exif 2.2 (JPEG)

Movie

Movie Format: MOV (Motion JPEG), Audio: G.711 [Monaural]

Shooting Modes

Auto, ASCN, P, S, A, Manual, Panorama, Movie, Portrait, Scene (Landscape, Sport, Beach, Sunset, Fireworks, Night Landscape, Night Portrait, Party, Children, Indoor, Snow, ID, Museum, Photo frame, Panning Shot, Text, Leaf, Glass, Fish eye, Sketch)

Detection Features

Face, Smile, Blink

Red-Eye Removal

Yes

HDR

Yes (Post-Processing)

Panorama Capture LCD Display

Still Image

Yes (Horizontal)

View Angle

0° ~ 170° 2.7inch (230k Pixels)

79

ISO Sensitivity

Auto, ISO80/100/200/400/800/1600(4M)/3200(4M)

AF Method

Single AF, Multi-AF (TTL 13-point), Face-Detection, AF Assist Light (On/Off)

Exposure Metering Method

Artificial Intelligence AE (AiAE), Center-Weighted Average, Spot (Fixed to Center of Frame), Face AE

Exposure Control Method

Program AE (AE-Lock Available), Aperture prior AE, Shutter Prior AE

Exposure Compensation

±2EV in 1/3 Step Increments

Shutter Speed

1/2000 ~ 4 Seconds (Manual: 30 Seconds)

Continuous Shooting

Yes

Playback Modes

Single Photo, Index (9/16 Thumbnails), Slide Show, Movie, Date Zoom (Approx. 2x ~ 8x), Histogram Display

White Balance Control

Auto (AWB), Daylight, Cloudy, Fluorescent, Fluorescent CWF, Incandescent, Manual

Flash

80

Flash Method

Pop-up

Flash Modes

Auto, Red-Eye Reduction, Forced Flash, No Flash, Slow Synchro, Red-Eye Reduction + Slow Synchro

Shooting Range

(Wide) Approx. 11.8in. ~ 177.1in. / 0.3m ~ 4.5m (ISO800) (Tele) Approx. 19.6in. ~ 157.4in. / 0.5m ~ 4.0m (ISO800)

Recording Media

Internal Memory: Approx. 13MB SD/SDHC Card (Up to 16GB ) [Non MMC Card]

Other Features

PictBridge, ExifPrint , Multi-Language (26 Languages)

Jacks

AV-OUT/USB 2.0 (Mini 8 pin USB)

Power

AA Alkaline Battery(×4) AA NiMH Battery(×4) (Not Included)

Shooting Capability (Battery Performance)

Approx. 300 Shots of AA Alkaline Battery (Based on CIPA Standards) Approx. 500 Shots of AA NiMH Battery (Based on CIPA Standards) o

Operation Environment

Temperature: 32 ~ 104°F / 0 ~ 40 C, Humidity: 0 ~ 90%

Dimensions (W×H×D)

Approx. 4.0×2.9×2.6in. / 103.0×74.0×68.0mm (Based on CIPA Standards)

Weight

Approx. 12oz. / 350g (Body Only) AA Alkaline Battery(×4), USB Cable

Supplied Accessories (May Differ Depending On Country or Area)

Shoulder Strap, CD-ROM, Lens Cover Quick Start Guide, Feature Guide, Warranty Card

81

Error Messages Messages

Explanation

Card Error

• The SD memory card is not formatted.

Card Full

• The SD memory card is full and cannot store any new images.

Picture Error

• The picture was not captured correctly. • The picture is damaged.

82

No Picture

• There are no images on the SD memory card or in the internal memory.

Lens Error

• The lens is probably stuck and the camera will power off automatically.

System Error

• Unexpected error encountered.

Write Protect

• The write protection switch in the SD memory card is set to the “LOCKED” position.

Out of the Range

• When pictures were taken in Panorama mode, the direction of movement was incorrect or the angle was outside the range of the internal settings.

Messages

Explanation

Card is not formatted, format?

• Confirm whether the SD memory card should be formatted.

This image cannot be deleted

• The picture or video you are trying to delete is protected.

Warning!! Camera recording, please wait

• No other actions are allowed during video/audio recording.

Warning!! Battery exhausted

• The batteries are depleted.

This file cannot be played back

• The picture format is not recognized by the camera.

No connection

• The camera is not connected to the printer correctly.

Print error

• There is a problem with camera or printer.

Cannot print

• Check to see that the printer is not out of paper or out of ink. • Check to see if the printer has a paper jam.

83

Troubleshooting Problem Camera does not turn on

Camera turns off suddenly during operation The picture is blurred Images and video files cannot be saved No picture can be taken when pressing the Shutter button

84

Possible causes • The batteries have been depleted.

Solution • Replace the dead batteries with new ones.

• The batteries are not inserted correctly. • The batteries have been depleted.

• Replace the dead batteries with new ones.

• The lens is dirty.

• Use a soft cloth to clean the lens on your camera.

• appears when taking pictures. • The SD memory card is full.

• Use the Image Stabilization mode. • Replace the SD memory card with a new one. • Delete unwanted images.

• No available space to store the files.

• Unlock the memory card. • Replace the SD memory card with a new one or format the current SD memory card.

• The mode dial is in Playback mode.

• Delete unwanted images.

• The SD memory card is full.

• The SD memory card is locked.

Problem Images cannot print from the connected printer

Possible causes • The camera is not connected to the printer correctly.

Solution • Check the connection between the camera and printer.

• The printer is not PictBridge compatible.

• Use a PictBridge compatible printer.

• The printer is out of paper or out of ink.

• Replace the ink cartridge in the printer.

• The printer paper is jammed. Write to memory card is slow

Cannot write to the memory card

Too many movies to process

• Using a memory card below Class 4 may result in slower recording times. • The SD memory card has been locked. • The camera may experience trouble recording HD movies to SD cards with a rating lower than class 4. • The number of pictures or binders in the SD memory card exceed the specifications, so the playback of data folder can not be displayed.

• Reload more paper in the printer. • Remove the jammed paper. • Use an SDHC card and shoot after formatting the card. • Remove the SD memory card and unlock it. • Use an SDHC card and shoot after formatting the card.

• Delete unwanted files. • Transfer the files on the SD memory card to other area.

85

http://www.ge.com/digitalcameras

imagination at work

© 2012 General Imaging Company

Printed in China
