LPG-Series Pumps and Compressors For LPG and NH3 Stationary Applications
A Tradition of Excellence Corken, Inc. is recognized as a world leader in the manufacture of LPG pumps and compressors. Corken’s exceptional reputation in the LPG industry is built upon decades of maintaining the highest quality and customer service standards. This, combined with an absolute dedication to product performance, makes Corken a company recognized worldwide for its manufacturing leadership. Located in Oklahoma City, Oklahoma, USA, Corken was founded in 1924 and quickly gained a reputation for excellence in customer service. In the early 1950s, the company entered the liquid petroleum gas (LPG) industry, which proved to be a turning point. In the years to follow, Corken quickly gained market recognition for its quality line of compressors and pumps for the propane, butane and anhydrous ammonia industries. In 1991, Corken became part of the IDEX Corporation, a manufacturer of proprietary fluid handling and industrial products that are recognized as market leaders. Through the years, a total commitment to customer service, product integrity and strong dedication to technological innovation have made Corken a recognized world leader in the compressor and pump markets.
Corken designs and manufactures products meeting industry standards, including Underwriters’ Laboratories (UL), Canadian Standards Association (CSA), High Pressure Gas Safety Institute of Japan (KHK), Bureau Veritas of , European Union’s Pressure Equipment Directive (PED) and ATEX Directive for Machinery and many others. Corken is very proud to the elite group of companies that have achieved registration with the International Quality Standard ISO 9001 and the Environmental Management Standard ISO 14001. Today, Corken is a diversified company that serves a worldwide customer base. Corken truck pumps, stationary pumps, compressors and engineered packages are used by a wide range of companies throughout the world, including the Far East, Asia, Africa, Europe, the Middle East, South America and North America. Corken serves each of its customers through an extensive network of distributors—each sharing the same commitment to customer service that Corken has demonstrated for more than 80 years.
2
LPG Product Overview Coro-Flo® Pumps Regenerative Turbine Liquid Pump
Applications: • Propane cylinder filling
• Autogas pumping
• Bottle filling
• Agricultural ammonia
• Stand-by systems
• LP-Gas vaporizer feed
• Asphalt plants
Coro-Vane® Pumps Sliding Vane Positive Displacement Liquid Pump
Applications: • Propane/butane bulk transfer
• Tank/railcar unloading
• Truck/delivery applications
• Agricultural ammonia
• Barge unloading
Side Channel Pumps Multistage Regenerative Turbine Liquid Pump
Gas Compressors Single Stage, Lube/ Non-Lube Gas Compressor
Applications: • Propane/butane bulk transfer
• Barge unloading
• Carousel cylinder filling
• Tank/railcar unloading
• Multi-port butane bottle filling
• Agricultural ammonia
Applications: • Propane cylinder filling • Bulk transfer
• Tank evacuation for maintenance
• Truck/barge/railcar unloading
• LPG/butane/ammonia
• Liquid transfer/vapor recovery • Inert gas pad
3
Providing pumps Tanker Unloading and Vapor Recovery: Compressor
Cylinder Filling— Carousel: Side Channel Pump Coro-Vane® Pump
Vaporizer Feed Pumps: Coro-Flo® Pump Coro-Vane® Pump Side Channel Pump
Trailer Load/Unload: Coro-Vane® Pump Side Channel Pump Compressor 4
Terminal, Bulk Plant, Industrial & Automotive Applications and compressors to meet all your needs Rail Car Unload and Vapor Recovery: Compressor
Cylinder Evacuation: Compressor Coro-Flo® Pump Coro-Vane® Pump Side Channel Pump
Cylinder Filling— Scales: Coro-Flo® Pump Coro-Vane® Pump Side Channel Pump
Bulk Load/Unload: Coro-Vane® Pump Side Channel Pump Truck Pump Compressor
Automotive Filling: Coro-Flo® Pump Coro-Vane® Pump Side Channel Pump 5
Coro-Flo Turbine Pumps Stationary Applications ®
Designed specifically for LPG... The Corken Coro-Flo® pump was designed for LPG, NH3 and other light liquids. For low-capacity, medium-head pumping, the Coro-Flo pump is the pump of choice. Extremely quiet and free of vibration and pulsation, the Coro-Flo pump provides trouble-free service and long life for volatile liquids such as LPG. The exclusive turbine construction provides smooth continuous flow through the pump case, resulting in higher efficiency and greater capacity and pressure for the same size motor. The one moving part, the impeller, floats on the shaft without ing adjacent surfaces, thus extending pump life.
Heavy-duty, permanently lubricated ball bearings: Ensure precision operation and long service life. Balanced mechanical seal assembly: Easily replaced by removing the cover. High flow inlet and discharge: Provides higher efficiency and greater capacity.
3/4" NPT Connection: For easy installation of by valve system.
Simple to service... The Coro-Flo® pump has been designed for simplicity of inspection and service. The cover can be removed and the impeller and seal serviced without disturbing the piping. The balanced mechanical seal is furnished with its own sleeve, providing extremely reliable service.
Applications... Although the Corken Coro-Flo® pump was originally developed to fill propane cylinders, it has found its way into many other applications, especially where volatile liquid transfer is involved. It is commonly used to feed industrial vaporizing and aerosol filling systems, and to transfer liquefied gases like NH3, CO2, SO2 and refrigerant gases. In process plants, the Coro-Flo pump is used as a boiler feed pump and for handling condensate. Every Corken Coro-Flo® pump is thoroughly inspected and tested to assure its quality and performance. The Coro-Flo pump is listed by Underwriters’ Laboratories, Inc. for use in LP-Gas and anhydrous ammonia service.
F-Model 101 Direct Drive
Free-floating impeller design: No metal-to-metal for longer pump life.
Ductile-iron case and cover: For extra strength and durability.
C-Model w/Close-Coupled Motor
FF-Model w/ANSI Flange Connections DS/DL-Model Direct Mounted
6
Vaporizer Feed, Cylinder & Automotive Filling Specifications & Performance Specifications
Model 9
Inlet
12
13
14
1-1/4" NPT 1-1/4" NPT 1-1/2" NPT 1-1/2" NPT 1-1/2" NPT
Outlet
1" NPT
1" NPT
1" NPT
1" NPT
1" NPT
(a) 3,450
2,880 3,450
2,880 3,450
2,880 3,450
2,880 3,450
70 (4.8)
60 (4.1) 70 (4.8)
75 (5.2) 100 (6.9)
75 (5.2) 125 (8.6)
75 (5.2) 125 (8.6)
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Direct mounted frame (DS/DL)
Yes
Yes
Yes
Yes
Yes
Double seal option (except C-model)
Yes
Yes
Yes
Yes
Yes
Flange option 1-1/2" x 1" – 300# (except C-model)
Yes
Yes
Yes
Yes
Yes
RPM—50 Hz RPM—60 Hz Max. differential press. 50 Hz (bar) 60 Hz (bar) Mounting options Close coupled Direct driven (101) V-belt (103)
Continuous-duty motors: Fan-cooled motors with permanently lubricated ball bearings ensure years of trouble-free service.
10
Impeller material options
Bronze (standard), ductile iron, stainless steel
O-ring material options
Buna N (standard), Neoprene®, PTFE, Viton®, ethylene-propylene1
Seal seat material opt.
Cast Iron (standard), Ni-Resist, stainless steel, tungsten carbide, ceramic
Temperature -25/2 25°F (minimum/maximum) -32/107°C
-25/225°F -32/107°C
5 hp 3.7 kW
Maximum driver
-25/225°F -25/225°F -25/225°F -32/107°C -32/107°C -32/107°C
5 hp 3.7 kW
10 hp 7.5 kW
10 hp 7.5 kW
20 hp 15 kW
(a) Not suitable for 2880 RPM 1 ed trademark of the DuPont company.
m3/hr 1
2
3
m3/hr 4
5
100
6
2880 RPM
1
2
3
4
5
6
125
6.9
7
8
3450 RPM
3.4
50
10
12
13
psid
5.1
6.9
75
5.1
50
14
bar
75
bar
psid
100
8.6
3.4
9
10
12
13
14
25
1.7
1.7
25
5
10
15
20
gpm
25
5
10
15
20
25
30
35
gpm
Note: Performance curves are based on propane and similar products.
7
Coro-Flo Turbine Pumps Autogas Series ®
High strength metric fasteners.
ANSI and DIN 300# flanges provide optimal leak control and enhances structural integrity.
Case and cover of ASTM A536 ductile iron, providing maximum thermal shock protection.
Pressure gauge connections help simplify analysis of system performance.
Heavy-duty ball bearings are rated for continuous duty service and provide maximum life.
Self-aligning, free-floating, precision machined impeller, incorporating proprietary design, optimizes flow and provides quiet non-pulsating transfer of LPG.
Maximum sealing provided by a single balanced, precision lapped, mechanical seal.
Designed for ease of service. Seal can be replaced in minutes by simply removing the cover.
Three mounting options available: direct drive with coupling, belt drive, and direct mounted with C-face electric motor.
All Coro-Flo® 150 Models
Specification Inlet
1-1/2" – ANSI 300# R.F. Flange (DIN optional)
Outlet
1" – ANSI 300# R.F. Flange (DIN optional)
RPM
3,450 @ 60 Hz or 2,880 @ 50 Hz
Maximum working pressure
27.6 Bar (400 psig)
Maximum differential pressure
17.2 Bar (250 psi)
Maximum/minimum temperature
Bronze (standard)
O-ring material
Buna-N (standard)
Seal materials
Silicon Carbide
Maximum driver Type of electric motor*
• Autogas dispensing • Cylinder filling • Vaporizer feed
107°C (225°F) / -32°C (-25°F)
Impeller material
Applications:
• Bulk transfer • Direct burner feed
15 kW (20 hp) Rigid-Base (frame mount) and C-face (direct mount)
* Consult factory regarding other types of motors.
Frame Mount
8
Direct Mount
Autogas Series Performance 15.0
15.0
20.0
Performance Curve 2,880 RPM
15.0
Example @ 2,880 RPM
Curves based on LPG*
200
Capacity
12.5
12.5
10.0
10.0
7.5
7.5
hp
psi
bar
150
kW
Differential Pressure
Power required
10.0
100
Flow 85 L/min 22.5 gpm
7.5 5.0
5.0 5.0
50 2.5
Power Required 5.1 kW 6.8 hp
2.5 3.0
0
0
0
0
50
10
100
20
L/min 30
150
40
0 250
200
50
Differential Pressure 10.0 bar 145.0 psi
0
60
gpm Capacity
Performance Curve 3,450 RPM
17.5
17.5 250
Curves based on LPG* Capacity
15.0
20.0
15.0
Power required
Example @ 3,450 RPM
200 12.5
Differential Pressure 10.0 bar 145.0 psi
15.0 150
10.0
7.5
7.5
5.0
5.0
hp
psi
bar
10.0
kW
Differential Pressure
12.5
10.0
100 7.5
5.0
50 2.5
Flow 128 L/min 33.8 gpm Power Required 6.3 kW 8.4 hp
2.5 3.0
0
0 0
0
50
10
100
20
L/min 30
150
40
0 250
200
50
0
60
gpm Capacity
* The performance curves are based on aboveground LPG installations. Performance curves for underground LPG tanks will vary based on the specific installation. Consult factory.
9
Side Channel Pumps Stationary Applications For those LPG applications where high-differential pressure is necessary or low NPSH conditions exist, such as pumping from underground tanks, the SC-Series multistage side channel is the pump of choice. The integral centrifugal and side channel design which characterizes this line provides a new dimension in liquid transfer applications. The SC-Series exceeds expectations in the handling of liquids involving high-differential pressures, low NPSH conditions, and aerated liquids up to 50% gas. Six different sizes, each ranging from one to eight stages, provide solutions for a wide range of pressures, capacities, and liquid transfer requirements. Multiple material and sealing options, enabling it to handle many different liquids, enhance the versatility of the SC-Series. Typical installations where this pump might be found are LPG cylinder filling, vaporizer feeding, pumping from underground storage and bulk filling operations.
Multiple material options for impellers and casing: Ductile iron casing, brass impellers, and Viton® are standard for LPG applications.
Proprietary centrifugal impeller design: Ensures efficient transfer even at low NPSH conditions.
Multistage side channel design delivers higher differential pressures... The Corken SC pump line utilizes an integral centrifugal and side-channel design to create the flow characteristics that make this pump special. The high-differential pressure and self-priming capabilities are results of the multistage side channel design. This feature incorporates one to eight stages of open radial-vane impellers and special modular side channel casings.
Quiet, smooth transfer even at low NPSH... The SC pump’s ability to handle low NPSH applications is attributed to the proprietary centrifugal impeller design near the pump inlet. The SC pump is cylindrical in shape, with liquid flow entering the pump horizontally (parallel with the pump shaft) and exiting vertically through the discharge flange on the top of the pump.
Many sealing options to choose from, including magnetic drive...
Modular construction: Minimizes spare parts requirements.
In a time when leakage control is becoming more and more prevalent, Corken offers a complete range of seal options. The side channel magnetic drive (SCM) sealless multistage pump meets the most stringent environmental regulations. The SCM line retains all of the advantages of the standard SC design along with two additional advantages; there are no seals to maintain and no potential leak paths.
Sealless (SCM Model) Magnetic Drive
10
Side Channel (SC Model) w/Direct-Coupled Drive
Bulk Filling, Carousel Filling & Vaporizor Feeding Specifications & Performance
DIN and ANSI flanges: For leakage control and greater structural integrity.
Specification
Model 10
40 50 Number of stages 1 to 8 Inlet flange 1-1/2 (40) 2-1/2 (65) 2-1/2 (65) 3 (80) 4 (100) inches (mm) Outlet flange 3/4 (20) 1-1/4 (32) 1-1/4 (32) 1-1/2 (40) 2 (50) inches (mm) RPM-50 Hz 1,450 1,450 1,450 1,450 1,450 RPM-60 Hz 1,750 1,750 1,750 1,750 1,750 Max. working pressure 580 (40) 580 (40) 580 (40) 580 (40) 580 (40) psig (bar) Differential press. range 10 (.7)15 (1)10 (.7)10 (.7)10 (.7)psi (bar) 150 (10.3) 230 (15.9) 180 (12.4) 175 (12.1) 210 (14.5) Mininimum temperature -40° (-40°) -40° (-40°) -40° (-40°) -40° (-40°) -40° (-40°) °F (°C) Maximum temperature 428° (220°) 428° (220°) 428° (220°) 428° (220°) 428° (220°) °F (°C) NPSH range ft (m) 1.6 (.5)2 (.6)1.6 (.5)1.3 (.4)1.3 (.4)13 (4) 3.3 (1) 6.6 (2) 8.2 (2.5) 12 (3.5) Maximum viscosity 1,050 (230) 1,050 (230) 1,050 (230) 1,050 (230) 1,050 (230) SSU (cSt) Maximum proportion 50% 50% 50% 50% 50% of gas allowable DIN flange option Yes Yes Yes Yes Yes ANSI flange option No Yes Yes Yes Yes Casing material option Ductile iron (standard), cast iron, stainless steel Impeller material option Bronze (standard), steel, stainless steel1 O-ring material option Viton® (standard), PTFE, ethylene-propylene2 Double seal option Yes Yes Yes Yes Yes Magnetic drive option Yes Yes Yes Yes Yes High temp. option Yes Yes Yes Yes Yes Internal relief option No No No No No
Heavy-duty bearings standard: Other bearing configurations available for high-temperature service.
Highly reliable mechanical seals: Standard with numerous seal options for special applications.
Multiple side channel stages: Provide self-priming, high-differential pressure, nonpulsating, trouble-free operation.
1
20
2
Stainless steel impeller not available on Model 60.
30
2
3
4
5
4 (100) 2-1/2 (65) 1,450 1,750 580 (40) 10 (.7)250 (17.2) -40° (-40°) 428° (220°) 4.6 (1.4)8.2 (2.5) 1,050 (230) 50% Yes Yes Ductile iron
Yes No Yes No
ed trademark of the DuPont company. gpm
gpm 1
60
10
20
30
40 50
75
1
100 125 150 200
2
3
4
5
10
20
30
40 50
75
100 125 150 200 18
18 250
250
1450 RPM
1750 RPM
16
14
200
16
14
200
12
(psi)
10
150
10
(bar)
150
(bar)
(psi)
12
8
8 100
100
6
6
4
4 50
50
10
20
30
40
50
10
60
20
30
40
50 60 2
2
0.1
.2
.3
.4
.5 .6 .7 .8 .9 1.0
2
3
m3/hr
4
5
6 7 8 9 10
20
30
40 50 60 70
0.1
.2
.3
.4
.5 .6 .7 .8 .9 1.0
2
3
4
5
6 7 8 9 10
20
30
40 50 60 70
m3/hr
11
Coro-Vane Pumps Stationary Applications ®
Pump design delivers high pumping efficiencies. The sliding-vane design of the Coro-Vane® pump is commonly found in the LPG industry because its pumping efficiencies remain high throughout the life of the pump. The CoroVane pump is unique because it can handle small amounts of vapor formed at the pump suction, and the vanes are self-adjusting for wear. With these design characteristics, pumping efficiencies remain high throughout the life of the pump.
Built-in relief valve: Preset, no-adjust internal relief valve always assures proper setting.
Pressure gauge connections: Available for both suction and discharge.
Long life & ease of maintenance... The pump housing and rotors are constructed of ductile iron for high strength. The pump design includes removable pump casing liners in all models. Worn liners and vanes can be replaced in minutes. Some models incorporate reversible sideplates which double their service life. Seal maintenance is easy. Simply remove four bolts to remove bearings and seals.
Applications... Typical applications include cylinder filling, loading and unloading of bulk trucks and transport trailers. Some Coro-Vane® pump models come with an internal relief valve for added pump protection, relieving the pressure from the pump discharge back to the suction. All pumps must have an external by valve to comply with NFPA & UL code requirements.
Positive displacement... Coro-Vane® pumps are positive displacement pumps. They produce up to a maximum differential pressure of 125 psig (8.6 bar g). Corken manufactures five sizes of Coro-Vane pumps, ranging from 1 gpm to 350 gpm (0.2 to 79.5 m3/hr) with v-belt and direct-drive mounting options.
Precision-machined sideplates and liners (cam): Maximize pumping capacity and are easily replaced.
Direct-Coupled Mounting
Direct-Coupled 101 Mounting
12
Belt-Drive 103 Mounting
Bulk Filling, Carousel Filling & Cylinder Filling Specifications & Performance Specifications
Case and heads are made of ductile iron: For extra strength and long life.
Suction flange Low-impact, high-strength vane design: Extends pump life.
Discharge flange Minimum RPM Maximum RPM
Highly reliable mechanical seals: Easily replaced by simply removing the bearing cap.
521
1021
F1021
1"
2-1/2"
3"
3" 300# ASA
3/4"
2"
3"
2-1/2" 300# ASA
1,450 1,750
420 950
420 950
420 950
Minimum temperature
-25 °F (-32 °C)
Maximum temperature
225 °F (107 °C)
Max. working pressure psig (bar)
350 (25.2)
400 (28.6)
400 (28.6)
400 (28.6)
Max. differential pressure psid (bar)
125 (8.6)
125 (8.6)
125 (8.6)
125 (8.6)
No
2"
4"
No
Discharge flange option
No
2-1/2"
4"
No
Internal relief
Yes
Yes
Yes
Suction flange option
No ®
®1
O-ring material options:
Buna N (standard), PTFE, Viton , Neoprene
Seal seat material options:
Cast iron (standard), stainless steel, Ni-Resist
Steel slip-on flange option (suction & discharge)
No
Yes
Yes
No
Discharge flange option elbow (2" or 1-1/2")
No
Yes
No
No
Cast steel case option Maximum driver Heavy-duty roller-type bearings: Provides longer life.
Model C51/F51
1
No
Yes
No
No
2 hp 1.5 kW
10 hp 7.5 kW
20 hp 15 kW
20 hp 15 kW
ed trademark of the DuPont company.
L/min 5
10
15
20
120
C51/ F51
110
8 7
100 90
6 5
70 60
4
50
1450 RPM
40
1750 RPM
bar
psi
80
3
30
2
20 10
1
2
3
4
5
6
gpm
13
Vertical LPG Compressors Stationary Applications Why select a compressor to transfer LPG and NH3? Compressors are extremely versatile for they can be used to transfer liquids between tanks, off-load/load-out liquids, recover residual vapor, and evacuate vapors for maintenance purposes. Many LPG piping systems do not provide ideal NPSH conditions for liquid pumps which causes excessive pump maintenance. Since compressors are only exposed to vapors, they are not affected by poor NPSH conditions. Many LPG pressurized tanks such as railcars and buried tanks have top unloading connections. A compressor can be the perfect solution for transferring liquids to and from such tanks.
Why select a Corken compressor? Corken has over 60 years of experience in providing state-of-theart designs to the LPG and NH3 markets. Corken designs meet the most stringent global quality standards, including those of Japan, and the United States. Environmental impact and safety are always considered very seriously at Corken. It is Corken’s commitment to provide its customers with products of the greatest integrity, providing years of trouble-free service.
Compressors matched to your needs... Corken provides oil-free and non-lubricated vertical and horizontal compressor designs. Compressors are available in both threaded and ANSI flanged connections. Depending on the application, single- and two-stage compressors are available.
For applications of all types... Corken gas compressors are designed for use in liquid transfer, vapor recovery, scavenger and portable applications. Whether it is gas recovery from cylinders or barge unloading, Corken has a compressor for your application.
14
Threaded and ANSI flanges: Compressors are available in either threaded NPT, ANSI, or DIN flanged connections. High-efficiency valves: Corken valves offer quiet operation and high durability in oil-free gas applications. Specially designed suction valves which tolerate small amounts of condensate are available. O-ring head gaskets: Easy to install O-ring head gaskets providing highly reliable seals. Ductile- iron construction: All cylinders and heads are ductile iron for maximum thermal shock endurance.
Self-lubricating PTFE piston rings: Corken provides a variety of state-of-the-art piston ring designs to provide the most cost-effective operation of compressors for non-lube service. The step-cut design provides higher efficiencies during the entire life of the piston ring. Positively locked piston: Simple piston design allows end clearance to be precisely set to provide maximum efficiency and long life.
Self-lubricating piston rod seals: Seals constructed of PTFE incorporating special fillers to ensure no oil carry over and maximize leakage control. Spring loaded seal design self adjusts to compensate for normal wear. Nitride-coated piston rods: Impregnated nitride coating provides superior corrosion and wear resistance. Cast-iron crosshead: Durable cast-iron crossheads provide superior resistance to corrosion and galling. Pressure-lubricated crankcase with filter: Self-reversing oil pump ensures proper lubrication regardless of directional rotation to main and connecting rod bearings. Standard 10-micron filter ensures long-lasting bearing life (not available on Model 91).
Cylinder Evacuation, Bulk Transfer and Recovery Custom-engineered packages... Corken supplies custom-engineered packages to meet the most demanding customer specifications. Skid-mounted units can be supplied with control s, safety controls, pulsation dampeners, specialized traps, valving and other special accessories as required. Corken offers standard mountings designed specifically for liquid transfer, vapor recovery, and gas scavenging applications.
Serviceability... Corken compressors are designed to minimize required maintenance and make such maintenance extremely simple. Maintenance operations such as valve replacement may be accomplished without disturbing the piping, while ring replacement may be accomplished simply by removing the head.
Versatility... Corken compressors are designed for use with maximum versatility. The same compressor installed for one application can easily be piped to be utilized for other plant applications. For example, a rail carunloading compressor can also be utilized to load and unload trucks. Model 491
Sized for your capacity needs... Corken offers four sizes of vertical, oil-free, single-stage compressors (Models 91, 291, 491 & 691). These compressors cover a full range of capacities from 24 to 361 gpm (5.5 to 82 m3/hr) in liquid transfer.
For even greater capacity... Corken Model D891 is a double-acting single-stage vertical gas compressor capable of capacities from 337 to 757 gpm (76.5 to 171.9 m 3/hr).
Model F291
Model D891
15
Horizontal LPG Compressors Stationary Applications For high-volume transfer...
Self-lubricating piston and rider rings: Made of PTFE to ensure extended service life.
Corken’s horizontal single-stage compressor is perfect for the terminal requiring transfer of large volumes of LPG (i.e., barge, multiple rail car, etc.). This heavy-duty, balanced-opposed gas compressor offers smooth, quiet operation. The compressor is offered with various sizes of cylinders. Corken currently offers 8" (203.2 mm), 6" (152.4 mm), 5" (127.0 mm), 4" (101.6 mm), 3-1/4" (82.6 mm), and 2-3/4" (69.9 mm) cylinders. These cylinders may be arranged in various combinations of single-, two-, three-, or four-stages. The horizontal compressors are offered in lubricated and non-lubricated designs. Although these compressors are not classified as oil-free, the potential for oil carry-over is minimized.
For stringent environmental requirements... In response to increasingly stringent environmental requirements to reduce emissions of volatile organic compounds and other hazardous gases, Corken offers a purge-pak piston-rod-sealing system for the HG601 series horizontal compressors. While precise leakage rates cannot be guaranteed due to the many complex factors which affect leakage, the purge-pak and rodsealing system substantially reduces potential leakage compared to conventional segmented piston-rod seal configurations. Tests have shown that in many cases, leakage can be reduced below 1 scfh (0.027 m3/hr).
Water-cooled cylinders... To increase the versatility of the horizontal compressor, Corken offers water-cooled cylinders in the 8" (203.2 mm), 6" 152.4 mm), 4" (101.6 mm) and 3-1/4" (82.6 mm) bore sizes. Water-cooled cylinders greatly reduce the operating temperature which increases the valve, piston ring, and seal life in the most difficult applications.
Model 601
16
Crankshaft journal, connecting-rod bearings, wrist pins and crossheads: Pressure lubricated by an oil pump with oil filtered by a 10-micron spin-on filter. Thermostatically-controlledcrankcase heater (optional): Assures proper oil viscosity in all weather conditions. Heavy-duty crankcase: A rugged, internally ribbed design, incorporating heavy-duty main bearings and four-bolt connecting rods. Force-feed lubricator (optional): Assures proper lubrication of cylinders and packing when required.
Tanker and Multiple Railcar Unloading and Recovery Available Options Blank valve... Heavy-duty cylinder design: Each cylinder is hydrostatically tested to 1-1/2 times the rated working pressure for maximum strength. MC1002 coating is available on all cylinders, providing longer piston-ring life.
In addition to the flexibility of reconfiguring the stages and number of cylinders, the capacity may be controlled through the blank valve option, which changes the cylinder to single acting.
Variable clearance heads... This option on all cylinder sizes allows for pressure and capacity adjustment while the compressor is operating.
External crankcase oil cooler... Corken compressors can be equipped with a force-feed lubrication system and external oil filter. An optional external oil cooler is available when required to ensure optimal service life.
Materials... The horizontal compressor line offers many optional materials for parts such as gaskets, piston rings, o-rings, pistons and more. This allows the compressor to be used with a variety of gases. The MC1002 corrosion-resistant coating is also available for all parts that come in with the gas.
Engineered packages... Custom-engineered skid-mounted units can be supplied with control s, wiring, pulsation dampeners, receiver tanks and other special accessories as required.
Placement of valves: Makes inspection and maintenance simple.
17
Liquid Gas Transfer Compressor Applications Bulk application... The “107” bulk plant gas compressor unit is complete with pressure gauges, steel baseplate, mechanical liquid trap, four-way valve, strainer, interconnecting piping, adjustable driver-slide-base, v-belt drive and beltguard ready to receive an electric motor. This standard unit is typically used for liquid transfer and vapor recovery in applications including rail car and truck loading and unloading. Many options such as ASME liquid traps with Class 1, Group D switches and total engineered packages can be provided.
Large terminal and barge applications... The D891 and HG601 series compressors are for high-volume transfer applications with flow capacities from 337 to 1552 gpm (76.5 to 352.5 m3/hr). These compressors are available in standard mounting configurations and also in special-engineered packages which include safety shutdowns and controls as required.
Scavenger applications... Corken has a variety of standard scavenger packages available, depending on the customer’s requirements. For maintenance purposes, scavengers can be sized for small-cylinder to large-tank evacuation systems. Corken will assist in custom engineering your scavenger systems for your specific application.
Truck compressor applications... The “102” compressor comes complete with extended crankshaft for utilization on trucks with PTO and hydraulic drive systems. The compressor can be used for loading/unloading as well as vapor recovery on trucks.
18
Compressor Specifications & Performance Specifications
Model 91
291
491
691
891 (a)
HG601BB (b)(e)
HG601AA (b)(e)
Bore of cylinder inches (mm)
3.0 (76.2)
3.0 (76.2)
4.0 (101.6)
4.5 (114.3)
4.5 (113)
6 (152)
8 (203)
Stroke: inches (mm)
2.5 (63.5)
2.5 (63.5)
3.0 (76.2)
4.0 (101.6)
4.0 (101.6)
3 (76.2)
3 (76.2)
Piston displacement CFM (m3/hr) minimum @ 400 RPM maximum @ 825 RPM maximum @ 1,200 RPM
4.0 (6.8) 8.3 (14.1) -
8.0 (13.6) 16.5 (28.0) -
17.2 (29.2) 35.5 (60.3) -
29.2 (49.6) 60.2 (102.3) -
350 (24.1)
350 (24.1)
350 (24.1)
350 (24.1)
465 (32.1)
365 (25.2)
315 (21.7)
7.5 (5.6)
15 (11)
15 (11)
35 (26.1)
45 (34)
75 (55.9)
75 (55.9)
Maximum working pressure: psig (bar) Maximum brake horsepower (kW) Maximum rod load lb (kg)
56.6 (96.2) 76.8 (130.5) 138 (234.5) 113.2 (192.0) 230.5 (391.9) 413.8 (703.5)
3,600 (1,632.9) 3,600 (1,632.9) 4,000 (1,814.4) 5,500 (2,494.8) 7,000 (3,175.2) 7,000 (3,175.2) 7,000 (3,175.2)
Maximum outlet temperature °F (°C)
350 (177)
Bare unit weight lb (kg)
115 (52.2)
160 (72.6)
260 (117.9)
625 (283.5)
855 (387.8)
Maximum flow-propane gpm (m3/hr)
50 (11.4) (c)
101 (22.9) (c)
215 (48.8) (c)
361 (82.0) (c)
694 (157.6) (c)
ANSI/DIN flange option
F91
F291
F491
F691
(d)
(a) Double-acting vertical compressor (b) Double-acting horizontal compressor (c) Maximum flow is based on 825 RPM or maximum hp, 30 psid. Capacities shown are based on 100 °F (37.8 °C) and will vary depending upon piping, fittings, product being transferred, and temperature. The factory will supply a detailed compressor analysis if required. 1,000 Gallon (3,785 Liter) Tank1
50
491 691
Vapor Pressure (psig)
Vapor Pressure (psig)
Vapor Pressure (psig)
100
150
480 gal recovered @ 110¡F
100
50
18 gal re covered @ 70¡F 5
150
1615 gal recovered @ 110¡F
100
50
640 gal recovered @ 70¡F
190 gal recove red @ 70¡F
10
15
(d)
291 491
45 gal rec overed @ 110¡F
0
(d)
200
91 291
0
1,305 (296.4) 1,725 (391.8) (e) (f)
33,000 Gallon (124,918 Liter) Tank1
200
150
20
25
0
30
868 (393.7)
(d) Not available (e) Maximum rating at 1,200 RPM (f) Maximum is based on hp limit and 845 RPM
10,000 Gallon (37,854 Liter) Tank1
200
828 (375.6)
0
20
40
Time (min)
60
Time (min)
80
100
120
0
0
30
60
90
120
150
180
Time (min)
Performance—Propane1
RPM
800 700 600 500 91 291
491
691
891
HG601BB
HG601AA*
400 50
100
150
200
250
300
350
400
500
750 1000 1250 1500 1750
gpm 10
20
30
40
50
60
70
m3/hr
80
100 150 200 250 300 350 400
(Liquid)
1 Capacities shown are based on 100 °F (37.8 °C) and will vary depending upon piping, fittings, product being transferred, and temperature. The factory will supply a detailed compressor analysis if required. * Maximum 75 hp is reached at 845 RPM
19
Propane Compressor Selection Table Capacity Service gpm(1) 23 Small 29 bulk 34 plants 40 39 45 44 50 56 Unloading 61 single tank 66 car or 71 transport 79 84 84 89 89 95 101 106 108 114 Unloading 119 two or 125 more tank 130 cars at 136 one time 141 or large 147 transport 152 with excess 158 flow valves 163 of adequate 163 capacity 168 171 179 178 186 193 200 208 215 223 230 Unloading 237 large 245 tank cars, 252 multiple 260 vessels, 275 barges or 297 terminals 319 334 452 623
Displacement cfm 4 5 6 7 7 8 8 9 10 11 12 13 14 15 15 16 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 30 31 31 32 32 34 35 36 38 39 41 42 43 45 46 47 48 54 58 60 82 113
Compressor Model RPM 91 400 91 505 91 590 91 695 290,291 345 91 795 290,291 390 290,291 435 290,291 490 290,291 535 290,291 580 290,291 625 290,291 695 290,291 735 490,491 345 290,291 780 490,491 370 490,491 390 490,491 415 490,491 435 490,491 445 490,491 470 490,491 490 490,491 515 490,491 535 490,491 560 490,491 580 490,491 605 490,491 625 490,491 650 490,491 670 690,691 400 490,491 695 690,691 420 490,491 740 690,691 440 690,691 455 690,691 475 690,691 495 690,691 510 690,691 530 690,691 550 690,691 565 690,691 585 690,691 605 690,691 620 690,691 640 690,691 675 690,691 730 690,691 785 690,691 820 D891 580 D891 800
Driver Sheave Size P.D."(2) 1,750 RPM 1,450 RPM A 3.0 A 3.6 A 3.8 B 4.6 B 4.6 B 5.6 B 5.4 B 6.6 A 3.0 A 3.6 B 6.2 B 7.4 A 3.4 B 4.0 A 3.8 B 4.6 B 4.4 B 5.2 B 4.8 B 5.8 B 5.2 B 6.2 B 5.6 B 6.6 B 6.2 B 7.4 B 6.6 B 8.0 A 3.0 A 3.6 B 7.0 B 8.6 A 3.2 A 3.8 A 3.4 B 4.0 A 3.6 B 4.4 A 3.8 B 4.6 B 4.0 B 4.8 B 4.2 B 5.0 B 4.4 B 5.2 B 4.6 B 5.6 B 4.8 B 5.8 B 5.0 B 6.0 B 5.2 B 6.2 B 5.4 B 6.4 B 5.6 B 6.6 B 5.8 B 7.0 B 6.0 B 4.4 B 5.2 B 6.2 B 7.4 B 4.6 B 5.6 B 6.6 B 8.0 B 4.8 B 5.8 B 5.0 B 6.0 B 5.2 B 6.2 B 5.4 B 6.4 B 5.6 B 6.8 B 5.8 B 7.0 B 6.0 A 7.0 B 6.2 B 7.4 B 6.4 A 7.4 B 6.6 B 8.0 B 6.8 B 7.0 A 8.2 B 7.4 B 8.6 B 8.0 B 9.4 B 8.6 TB 9.0 A 10.6 5V 7.1 5V 8.5 5V 9.75 5V 11.8
Notes: (1) The capacities shown are based on 70°F, but will vary depending upon piping, fittings used, product being transferred and temperature. The factory can supply a detailed computer analysis if required. (2) Driver sheaves: 91 - 2 belts; 290,291,490,491 - 3 belts; 690,691 - 4 belts.
20
Driver Horsepower Liquid Liquid Transfer Transfer and without Residual Residual Vapor Vapor Recovery Recovery 100°F 80°F 100°F 80°F 5 3 3 3 5 5 5 5 5 5 5 5 5 5 5 5 3 3 3 3 7-1/2 7-1/2 7-1/2 7-1/2 5 3 3 3 5 5 3 3 5 5 5 5 5 5 5 5 7-1/2 5 5 5 7-1/2 5 7-1/2 5 7-1/2 7-1/2 7-1/2 7-1/2 10 7-1/2 10 7-1/2 7-1/2 7-1/2 5 5 10 10 10 10 7-1/2 7-1/2 7-1/2 5 7-1/2 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 10 10 7-1/2 7-1/2 10 10 10 7-1/2 15 10 10 10 15 10 10 10 15 10 10 10 15 10 15 10 15 15 15 15 15 15 15 15 15 15 15 15 15 15 10 10 15 15 15 15 15 15 10 10 15 15 15 15 15 15 10 10 15 15 15 10 15 15 15 10 15 15 15 15 20 15 15 15 20 15 15 15 20 15 15 15 20 15 15 15 20 15 15 15 20 15 15 15 20 20 15 15 20 20 20 15 25 20 20 20 25 20 20 20 25 20 25 20 30 25 25 20 30 30 30 30 40 40 30
Piping Size (3) Vapor Liquid 3/4 1-1/4 3/4 1-1/4 1 1-1/4 1 1-1/2 1 1-1/2 1 1-1/2 1 1-1/2 1 1-1/2 1 2 1 2 1 2 1-1/4 2 1-1/4 2 1-1/4 2-1/2 1-1/4 2-1/2 1-1/4 2-1/2 1-1/4 2-1/2 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 4 1-1/2 4 1-1/2 4 2 4 2 4 2 4 2 4 2 4 2 4 2 4 2 4 2 4 3 6 3 6
(3) The piping sizes shown are considered minimum. If the length exceeds 100 ft, use the next larger size. Consult factory for compressors with higher flows.
Ammonia Compressor Selection Table Capacity Service gpm(1) 23 Small 29 bulk 34 plants 40 43 46 45 50 56 Unloading 62 single tank 67 car or 72 transport 80 85 85 90 90 96 102 107 110 115 Unloading 120 two or 126 more tank 131 cars at 138 one time 142 or large 148 transport 153 with excess 160 flow valves 165 of adequate 165 capacity 170 173 181 180 188 195 203 211 218 226 233 Unloading 240 large 248 tank cars, 255 multiple 263 vessels, 278 barges or 301 terminals 323 338 459 633
Displacement cfm 4 5 6 7 7 8 8 9 10 11 12 13 14 15 15 16 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 30 31 31 32 32 34 35 36 38 39 41 42 43 45 45 47 48 54 58 60 82 113
Compressor Model RPM 91 400 91 505 91 590 91 695 290,291 345 91 795 290,291 390 290,291 435 290,291 490 290,291 535 290,291 580 290,291 625 290,291 695 290,291 735 490,491 345 290,291 780 490,491 370 490,491 390 490,491 415 490,491 435 490,491 445 490,491 470 490,491 490 490,491 515 490,491 535 490,491 560 490,491 580 490,491 605 490,491 625 490,491 650 490,491 670 690,691 400 490,491 695 690,691 420 490,491 740 690,691 440 690,691 455 690,691 475 690,691 495 690,691 510 690,691 530 690,691 550 690,691 565 690,691 585 690,691 605 690,691 620 690,691 640 690,691 675 690,691 730 690,691 785 690,691 820 D891 580 D891 800
Driver Sheave Size P.D."(2) 1,750 RPM 1,450 RPM A 3.0 A 3.6 A 3.8 B 4.6 B 4.6 B 5.6 B 5.4 B 6.6 A 3.0 A 3.6 B 6.2 B 7.4 A 3.4 B 4.0 A 3.8 B 4.6 B 4.4 B 5.2 B 4.8 B 5.8 B 5.2 B 6.2 B 5.6 B 6.6 B 6.2 B 7.4 B 6.6 B 8.0 A 3.0 A 3.6 B 7.0 B 8.6 A 3.2 A 3.8 A 3.4 B 4.0 A 3.6 B 4.4 A 3.8 B 4.6 B 4.0 B 4.8 B 4.2 B 5.0 B 4.4 B 5.2 B 4.6 B 5.6 B 4.8 B 5.8 B 5.0 B 6.0 B 5.2 B 6.2 B 5.4 B 6.4 B 5.6 B 6.6 B 5.8 B 7.0 B 6.0 B 4.4 B 5.2 B 6.2 B 7.4 B 4.6 B 5.6 B 6.6 B 8.0 B 4.8 B 5.8 B 5.0 B 6.0 B 5.2 B 6.2 B 5.4 B 6.4 B 5.6 B 6.8 B 5.8 B 7.0 B 6.0 A 7.0 B 6.2 B 7.4 B 6.4 A 7.4 B 6.6 B 8.0 B 6.8 B 7.0 A 8.2 B 7.4 B 8.6 B 8.0 B 9.4 B 8.6 TB 9.0 A 10.6 5V 7.1 5V 8.5 5V 9.75 5V 11.8
Notes: (1) The capacities shown are based on 70°F, but will vary depending upon piping, fittings used, product being transferred and temperature. The factory can supply a detailed computer analysis if required. (2) Driver sheaves: 91 - 2 belts; 290,291,490,491 - 3 belts; 690,691 - 4 belts.
Driver Horsepower Liquid Liquid Transfer Transfer and Without Residual Residual Vapor Vapor Recovery Recovery 100°F 80°F 100°F 80°F 5 3 3 3 5 5 5 3 5 5 5 5 5 5 5 5 5 3 3 3 7-1/2 5 5 5 5 3 3 3 5 5 3 3 5 5 5 3 7-1/2 5 5 5 7-1/2 5 5 5 7-1/2 5 5 5 7-1/2 7-1/2 7-1/2 5 10 7-1/2 7-1/2 7-1/2 7-1/2 7-1/2 5 5 10 7-1/2 7-1/2 7-1/2 10 7-1/2 5 5 10 7-1/2 5 5 10 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 15 10 7-1/2 7-1/2 15 10 7-1/2 7-1/2 15 10 10 7-1/2 15 10 10 7-1/2 15 10 10 7-1/2 15 10 10 10 15 10 10 10 15 15 10 10 15 15 15 10 15 15 10 10 15 15 15 10 15 15 10 10 15 15 15 15 15 15 10 10 20 15 10 10 20 15 10 10 20 15 15 10 20 15 15 10 20 15 15 15 20 15 15 15 20 15 15 15 20 20 15 15 20 20 15 15 25 20 15 15 25 20 15 15 25 20 15 15 25 20 20 15 30 25 20 20 30 25 20 20 40 30 30 30 40 40 30
Piping Size (3) Vapor Liquid 3/4 1-1/4 3/4 1-1/4 1 1-1/4 1 1-1/2 1 1-1/2 1 1-1/2 1 1-1/2 1 1-1/2 1 2 1 2 1 2 1-1/4 2 1-1/4 2 1-1/4 2-1/2 1-1/4 2-1/2 1-1/4 2-1/2 1-1/4 2-1/2 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 4 1-1/2 4 1-1/2 4 2 4 2 4 2 4 2 4 2 4 2 4 2 4 2 4 2 4 3 6 3 6
(3) The piping sizes shown are considered minimum. If the length exceeds 100 ft, use the next larger size. Consult factory for compressors with higher flows.
21
LPG Accessories By Valves B166B (3/4", 1") Automatic Dual-Purpose, By Valve Typical Application: On all cylinder filling pumps as well as aerosol propellant feed pumps.
Specification
B166B
ZV200
B177
Inlet
3/4", 1"
2" (standard)
2", 2-1/2"
Outlet
3/4", 1"
2" (standard)
2", 2-1/2"
Slip-on flange option
No
Yes
2", 2-1/2"
Differential pressure range psi (bar)
25–225 (1.7–15.5)
41–150 (2.8–10.3)
10–125 (0.7–8.6)
Buna N (standard), Neoprene®, PTFE, Viton®, ethylene-propylene1
O-ring material options 1
ed trademark of the DuPont company. Ethylene-propylene not availble for B177.
A combination by and priming valve specifically designed for small cylinder-fillingtype pumps, especially of the regenerative turbine type, such as the Corken Coro-Flo® pump series. The patented vapor elimination system keeps liquefied gas pumps primed to increase system reliability and decrease pump and seal wear. The B166B is a smooth operating by with moderate pressure build-up.
ZV200 By Valve Typical Applications: Used for both truck and stationary applications for loading and unloading. A low-pressure build-up by valve designed for applications requiring protection for positive displacement pumps. Specifically designed for protecting pumps with capacities up to 250 gpm (56.8 m3/hr). The continuous internal bleed will assist in the operation of systems with “air” or “electric” operated internal valves.
B177 (2", 2-1/2") Differential By Valve
B177 Performance
Typical Application: In liquefied gas bulk-plant installations for loading and unloading pumps.
22
20
30
40
50
60
70
80
8.6
psid
125
bar
A low-pressure build-up by valve specifically designed for applications requiring protection for positive displacement pumps in the 50 to 350 gpm (11.4 to 79.5 m3/hr) range. It can also be used as a differential back-pressure valve to assure adequate pressure on meters, etc. To properly function, this valve requires a pressure sensing line from the storage tank.
m3/hr 10
21/2"
2" 20
1.4
10
0.7
50
100
150
200
gpm
250
300
350
Flo-Chek, 4-Way Valve, Ell Strainer & Liquid Traps, etc... Flo-Chek valve... The Flo-Chek enables you to detect flow in the gas or liquid lines and prevents release of product from storage tank in the event of a hose failure. Flow-indicating and back-check valves feature all ductile iron construction and are available in 1-1/4" through 4", NPT or welded flanges with a 400 psig (27.6 bar) rating. Standard O-rings are Buna N. PTFE, Viton®, and Neoprene® are optional.1
4-way non-lubricated valve... A convenient and simple means of reversing flow direction to a compressor. Made of ductile iron body, complete with handle and flow direction indicator (1" or 1-1/4" NPT and 2" — 300# ANSI flange, 500 psig rating [34.5 bar g]).
Low-oil-pressure switch... NEMA 7 pressure switch allows you to shut down the compressor if the oil pressure drops below 10 psi (0.69 bar), which protects the compressor from lack of lubrication. Available in 120 or 230 volt and can be used with magnetic starters up to NEMA Size 3.
Strainer... The right-angle design will minimize pressure drop and comes complete with ductile iron body with monel screen and steel plug. Available for liquid or vapor service (1-1/4" NPT 250 psig [17.2 bar] rating).
Pressure gauges... Stainless steel case-glycerine filled pressure gauges will mount on the compressor head or in the piping system and come with the following features: • 0 to 400 psi (0 to 28 bar) range, 5 psi (0.34 bar) increment • 2-1/2" dial with 1/4" NPT center back connection
Automatic liquid trap, with one NEMA 7 liquid-level switch for compressor shutdown and drain valve.
ASME code-stamped automatic liquid trap with two NEMA 7 liquid-level switches for compressor shutdown and alarm. Equipped with relief valve, pressure gauge, demister pad, and drain valve.
1-1/4" x 1-1/4" NPT or
1-1/2" x 1-1/2" NPT or
1-1/4" x 1-1/2" NPT
2" x 2" 300# ANSI flange.
Liquid traps... Standard liquid trap with mechanical float assembly and drain valve. 1-1/4" x 1-1/4" NPT or 1-1/4" x 1-1/2" NPT
1
ed trademark of the DuPont company.
23
CORKEN, INC. • A Unit of IDEX Corporation 3805 N.W. 36th St., Oklahoma City, OK 73112 U.S.A. (405) 946-5576 FAX (405) 948-7343 Visit our website at http://www.corken.com E-mail us at [email protected] LPG100E
PRINTED IN THE USA SEPTEMBER 2009
A Tradition of Excellence Corken, Inc. is recognized as a world leader in the manufacture of LPG pumps and compressors. Corken’s exceptional reputation in the LPG industry is built upon decades of maintaining the highest quality and customer service standards. This, combined with an absolute dedication to product performance, makes Corken a company recognized worldwide for its manufacturing leadership. Located in Oklahoma City, Oklahoma, USA, Corken was founded in 1924 and quickly gained a reputation for excellence in customer service. In the early 1950s, the company entered the liquid petroleum gas (LPG) industry, which proved to be a turning point. In the years to follow, Corken quickly gained market recognition for its quality line of compressors and pumps for the propane, butane and anhydrous ammonia industries. In 1991, Corken became part of the IDEX Corporation, a manufacturer of proprietary fluid handling and industrial products that are recognized as market leaders. Through the years, a total commitment to customer service, product integrity and strong dedication to technological innovation have made Corken a recognized world leader in the compressor and pump markets.
Corken designs and manufactures products meeting industry standards, including Underwriters’ Laboratories (UL), Canadian Standards Association (CSA), High Pressure Gas Safety Institute of Japan (KHK), Bureau Veritas of , European Union’s Pressure Equipment Directive (PED) and ATEX Directive for Machinery and many others. Corken is very proud to the elite group of companies that have achieved registration with the International Quality Standard ISO 9001 and the Environmental Management Standard ISO 14001. Today, Corken is a diversified company that serves a worldwide customer base. Corken truck pumps, stationary pumps, compressors and engineered packages are used by a wide range of companies throughout the world, including the Far East, Asia, Africa, Europe, the Middle East, South America and North America. Corken serves each of its customers through an extensive network of distributors—each sharing the same commitment to customer service that Corken has demonstrated for more than 80 years.
2
LPG Product Overview Coro-Flo® Pumps Regenerative Turbine Liquid Pump
Applications: • Propane cylinder filling
• Autogas pumping
• Bottle filling
• Agricultural ammonia
• Stand-by systems
• LP-Gas vaporizer feed
• Asphalt plants
Coro-Vane® Pumps Sliding Vane Positive Displacement Liquid Pump
Applications: • Propane/butane bulk transfer
• Tank/railcar unloading
• Truck/delivery applications
• Agricultural ammonia
• Barge unloading
Side Channel Pumps Multistage Regenerative Turbine Liquid Pump
Gas Compressors Single Stage, Lube/ Non-Lube Gas Compressor
Applications: • Propane/butane bulk transfer
• Barge unloading
• Carousel cylinder filling
• Tank/railcar unloading
• Multi-port butane bottle filling
• Agricultural ammonia
Applications: • Propane cylinder filling • Bulk transfer
• Tank evacuation for maintenance
• Truck/barge/railcar unloading
• LPG/butane/ammonia
• Liquid transfer/vapor recovery • Inert gas pad
3
Providing pumps Tanker Unloading and Vapor Recovery: Compressor
Cylinder Filling— Carousel: Side Channel Pump Coro-Vane® Pump
Vaporizer Feed Pumps: Coro-Flo® Pump Coro-Vane® Pump Side Channel Pump
Trailer Load/Unload: Coro-Vane® Pump Side Channel Pump Compressor 4
Terminal, Bulk Plant, Industrial & Automotive Applications and compressors to meet all your needs Rail Car Unload and Vapor Recovery: Compressor
Cylinder Evacuation: Compressor Coro-Flo® Pump Coro-Vane® Pump Side Channel Pump
Cylinder Filling— Scales: Coro-Flo® Pump Coro-Vane® Pump Side Channel Pump
Bulk Load/Unload: Coro-Vane® Pump Side Channel Pump Truck Pump Compressor
Automotive Filling: Coro-Flo® Pump Coro-Vane® Pump Side Channel Pump 5
Coro-Flo Turbine Pumps Stationary Applications ®
Designed specifically for LPG... The Corken Coro-Flo® pump was designed for LPG, NH3 and other light liquids. For low-capacity, medium-head pumping, the Coro-Flo pump is the pump of choice. Extremely quiet and free of vibration and pulsation, the Coro-Flo pump provides trouble-free service and long life for volatile liquids such as LPG. The exclusive turbine construction provides smooth continuous flow through the pump case, resulting in higher efficiency and greater capacity and pressure for the same size motor. The one moving part, the impeller, floats on the shaft without ing adjacent surfaces, thus extending pump life.
Heavy-duty, permanently lubricated ball bearings: Ensure precision operation and long service life. Balanced mechanical seal assembly: Easily replaced by removing the cover. High flow inlet and discharge: Provides higher efficiency and greater capacity.
3/4" NPT Connection: For easy installation of by valve system.
Simple to service... The Coro-Flo® pump has been designed for simplicity of inspection and service. The cover can be removed and the impeller and seal serviced without disturbing the piping. The balanced mechanical seal is furnished with its own sleeve, providing extremely reliable service.
Applications... Although the Corken Coro-Flo® pump was originally developed to fill propane cylinders, it has found its way into many other applications, especially where volatile liquid transfer is involved. It is commonly used to feed industrial vaporizing and aerosol filling systems, and to transfer liquefied gases like NH3, CO2, SO2 and refrigerant gases. In process plants, the Coro-Flo pump is used as a boiler feed pump and for handling condensate. Every Corken Coro-Flo® pump is thoroughly inspected and tested to assure its quality and performance. The Coro-Flo pump is listed by Underwriters’ Laboratories, Inc. for use in LP-Gas and anhydrous ammonia service.
F-Model 101 Direct Drive
Free-floating impeller design: No metal-to-metal for longer pump life.
Ductile-iron case and cover: For extra strength and durability.
C-Model w/Close-Coupled Motor
FF-Model w/ANSI Flange Connections DS/DL-Model Direct Mounted
6
Vaporizer Feed, Cylinder & Automotive Filling Specifications & Performance Specifications
Model 9
Inlet
12
13
14
1-1/4" NPT 1-1/4" NPT 1-1/2" NPT 1-1/2" NPT 1-1/2" NPT
Outlet
1" NPT
1" NPT
1" NPT
1" NPT
1" NPT
(a) 3,450
2,880 3,450
2,880 3,450
2,880 3,450
2,880 3,450
70 (4.8)
60 (4.1) 70 (4.8)
75 (5.2) 100 (6.9)
75 (5.2) 125 (8.6)
75 (5.2) 125 (8.6)
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Direct mounted frame (DS/DL)
Yes
Yes
Yes
Yes
Yes
Double seal option (except C-model)
Yes
Yes
Yes
Yes
Yes
Flange option 1-1/2" x 1" – 300# (except C-model)
Yes
Yes
Yes
Yes
Yes
RPM—50 Hz RPM—60 Hz Max. differential press. 50 Hz (bar) 60 Hz (bar) Mounting options Close coupled Direct driven (101) V-belt (103)
Continuous-duty motors: Fan-cooled motors with permanently lubricated ball bearings ensure years of trouble-free service.
10
Impeller material options
Bronze (standard), ductile iron, stainless steel
O-ring material options
Buna N (standard), Neoprene®, PTFE, Viton®, ethylene-propylene1
Seal seat material opt.
Cast Iron (standard), Ni-Resist, stainless steel, tungsten carbide, ceramic
Temperature -25/2 25°F (minimum/maximum) -32/107°C
-25/225°F -32/107°C
5 hp 3.7 kW
Maximum driver
-25/225°F -25/225°F -25/225°F -32/107°C -32/107°C -32/107°C
5 hp 3.7 kW
10 hp 7.5 kW
10 hp 7.5 kW
20 hp 15 kW
(a) Not suitable for 2880 RPM 1 ed trademark of the DuPont company.
m3/hr 1
2
3
m3/hr 4
5
100
6
2880 RPM
1
2
3
4
5
6
125
6.9
7
8
3450 RPM
3.4
50
10
12
13
psid
5.1
6.9
75
5.1
50
14
bar
75
bar
psid
100
8.6
3.4
9
10
12
13
14
25
1.7
1.7
25
5
10
15
20
gpm
25
5
10
15
20
25
30
35
gpm
Note: Performance curves are based on propane and similar products.
7
Coro-Flo Turbine Pumps Autogas Series ®
High strength metric fasteners.
ANSI and DIN 300# flanges provide optimal leak control and enhances structural integrity.
Case and cover of ASTM A536 ductile iron, providing maximum thermal shock protection.
Pressure gauge connections help simplify analysis of system performance.
Heavy-duty ball bearings are rated for continuous duty service and provide maximum life.
Self-aligning, free-floating, precision machined impeller, incorporating proprietary design, optimizes flow and provides quiet non-pulsating transfer of LPG.
Maximum sealing provided by a single balanced, precision lapped, mechanical seal.
Designed for ease of service. Seal can be replaced in minutes by simply removing the cover.
Three mounting options available: direct drive with coupling, belt drive, and direct mounted with C-face electric motor.
All Coro-Flo® 150 Models
Specification Inlet
1-1/2" – ANSI 300# R.F. Flange (DIN optional)
Outlet
1" – ANSI 300# R.F. Flange (DIN optional)
RPM
3,450 @ 60 Hz or 2,880 @ 50 Hz
Maximum working pressure
27.6 Bar (400 psig)
Maximum differential pressure
17.2 Bar (250 psi)
Maximum/minimum temperature
Bronze (standard)
O-ring material
Buna-N (standard)
Seal materials
Silicon Carbide
Maximum driver Type of electric motor*
• Autogas dispensing • Cylinder filling • Vaporizer feed
107°C (225°F) / -32°C (-25°F)
Impeller material
Applications:
• Bulk transfer • Direct burner feed
15 kW (20 hp) Rigid-Base (frame mount) and C-face (direct mount)
* Consult factory regarding other types of motors.
Frame Mount
8
Direct Mount
Autogas Series Performance 15.0
15.0
20.0
Performance Curve 2,880 RPM
15.0
Example @ 2,880 RPM
Curves based on LPG*
200
Capacity
12.5
12.5
10.0
10.0
7.5
7.5
hp
psi
bar
150
kW
Differential Pressure
Power required
10.0
100
Flow 85 L/min 22.5 gpm
7.5 5.0
5.0 5.0
50 2.5
Power Required 5.1 kW 6.8 hp
2.5 3.0
0
0
0
0
50
10
100
20
L/min 30
150
40
0 250
200
50
Differential Pressure 10.0 bar 145.0 psi
0
60
gpm Capacity
Performance Curve 3,450 RPM
17.5
17.5 250
Curves based on LPG* Capacity
15.0
20.0
15.0
Power required
Example @ 3,450 RPM
200 12.5
Differential Pressure 10.0 bar 145.0 psi
15.0 150
10.0
7.5
7.5
5.0
5.0
hp
psi
bar
10.0
kW
Differential Pressure
12.5
10.0
100 7.5
5.0
50 2.5
Flow 128 L/min 33.8 gpm Power Required 6.3 kW 8.4 hp
2.5 3.0
0
0 0
0
50
10
100
20
L/min 30
150
40
0 250
200
50
0
60
gpm Capacity
* The performance curves are based on aboveground LPG installations. Performance curves for underground LPG tanks will vary based on the specific installation. Consult factory.
9
Side Channel Pumps Stationary Applications For those LPG applications where high-differential pressure is necessary or low NPSH conditions exist, such as pumping from underground tanks, the SC-Series multistage side channel is the pump of choice. The integral centrifugal and side channel design which characterizes this line provides a new dimension in liquid transfer applications. The SC-Series exceeds expectations in the handling of liquids involving high-differential pressures, low NPSH conditions, and aerated liquids up to 50% gas. Six different sizes, each ranging from one to eight stages, provide solutions for a wide range of pressures, capacities, and liquid transfer requirements. Multiple material and sealing options, enabling it to handle many different liquids, enhance the versatility of the SC-Series. Typical installations where this pump might be found are LPG cylinder filling, vaporizer feeding, pumping from underground storage and bulk filling operations.
Multiple material options for impellers and casing: Ductile iron casing, brass impellers, and Viton® are standard for LPG applications.
Proprietary centrifugal impeller design: Ensures efficient transfer even at low NPSH conditions.
Multistage side channel design delivers higher differential pressures... The Corken SC pump line utilizes an integral centrifugal and side-channel design to create the flow characteristics that make this pump special. The high-differential pressure and self-priming capabilities are results of the multistage side channel design. This feature incorporates one to eight stages of open radial-vane impellers and special modular side channel casings.
Quiet, smooth transfer even at low NPSH... The SC pump’s ability to handle low NPSH applications is attributed to the proprietary centrifugal impeller design near the pump inlet. The SC pump is cylindrical in shape, with liquid flow entering the pump horizontally (parallel with the pump shaft) and exiting vertically through the discharge flange on the top of the pump.
Many sealing options to choose from, including magnetic drive...
Modular construction: Minimizes spare parts requirements.
In a time when leakage control is becoming more and more prevalent, Corken offers a complete range of seal options. The side channel magnetic drive (SCM) sealless multistage pump meets the most stringent environmental regulations. The SCM line retains all of the advantages of the standard SC design along with two additional advantages; there are no seals to maintain and no potential leak paths.
Sealless (SCM Model) Magnetic Drive
10
Side Channel (SC Model) w/Direct-Coupled Drive
Bulk Filling, Carousel Filling & Vaporizor Feeding Specifications & Performance
DIN and ANSI flanges: For leakage control and greater structural integrity.
Specification
Model 10
40 50 Number of stages 1 to 8 Inlet flange 1-1/2 (40) 2-1/2 (65) 2-1/2 (65) 3 (80) 4 (100) inches (mm) Outlet flange 3/4 (20) 1-1/4 (32) 1-1/4 (32) 1-1/2 (40) 2 (50) inches (mm) RPM-50 Hz 1,450 1,450 1,450 1,450 1,450 RPM-60 Hz 1,750 1,750 1,750 1,750 1,750 Max. working pressure 580 (40) 580 (40) 580 (40) 580 (40) 580 (40) psig (bar) Differential press. range 10 (.7)15 (1)10 (.7)10 (.7)10 (.7)psi (bar) 150 (10.3) 230 (15.9) 180 (12.4) 175 (12.1) 210 (14.5) Mininimum temperature -40° (-40°) -40° (-40°) -40° (-40°) -40° (-40°) -40° (-40°) °F (°C) Maximum temperature 428° (220°) 428° (220°) 428° (220°) 428° (220°) 428° (220°) °F (°C) NPSH range ft (m) 1.6 (.5)2 (.6)1.6 (.5)1.3 (.4)1.3 (.4)13 (4) 3.3 (1) 6.6 (2) 8.2 (2.5) 12 (3.5) Maximum viscosity 1,050 (230) 1,050 (230) 1,050 (230) 1,050 (230) 1,050 (230) SSU (cSt) Maximum proportion 50% 50% 50% 50% 50% of gas allowable DIN flange option Yes Yes Yes Yes Yes ANSI flange option No Yes Yes Yes Yes Casing material option Ductile iron (standard), cast iron, stainless steel Impeller material option Bronze (standard), steel, stainless steel1 O-ring material option Viton® (standard), PTFE, ethylene-propylene2 Double seal option Yes Yes Yes Yes Yes Magnetic drive option Yes Yes Yes Yes Yes High temp. option Yes Yes Yes Yes Yes Internal relief option No No No No No
Heavy-duty bearings standard: Other bearing configurations available for high-temperature service.
Highly reliable mechanical seals: Standard with numerous seal options for special applications.
Multiple side channel stages: Provide self-priming, high-differential pressure, nonpulsating, trouble-free operation.
1
20
2
Stainless steel impeller not available on Model 60.
30
2
3
4
5
4 (100) 2-1/2 (65) 1,450 1,750 580 (40) 10 (.7)250 (17.2) -40° (-40°) 428° (220°) 4.6 (1.4)8.2 (2.5) 1,050 (230) 50% Yes Yes Ductile iron
Yes No Yes No
ed trademark of the DuPont company. gpm
gpm 1
60
10
20
30
40 50
75
1
100 125 150 200
2
3
4
5
10
20
30
40 50
75
100 125 150 200 18
18 250
250
1450 RPM
1750 RPM
16
14
200
16
14
200
12
(psi)
10
150
10
(bar)
150
(bar)
(psi)
12
8
8 100
100
6
6
4
4 50
50
10
20
30
40
50
10
60
20
30
40
50 60 2
2
0.1
.2
.3
.4
.5 .6 .7 .8 .9 1.0
2
3
m3/hr
4
5
6 7 8 9 10
20
30
40 50 60 70
0.1
.2
.3
.4
.5 .6 .7 .8 .9 1.0
2
3
4
5
6 7 8 9 10
20
30
40 50 60 70
m3/hr
11
Coro-Vane Pumps Stationary Applications ®
Pump design delivers high pumping efficiencies. The sliding-vane design of the Coro-Vane® pump is commonly found in the LPG industry because its pumping efficiencies remain high throughout the life of the pump. The CoroVane pump is unique because it can handle small amounts of vapor formed at the pump suction, and the vanes are self-adjusting for wear. With these design characteristics, pumping efficiencies remain high throughout the life of the pump.
Built-in relief valve: Preset, no-adjust internal relief valve always assures proper setting.
Pressure gauge connections: Available for both suction and discharge.
Long life & ease of maintenance... The pump housing and rotors are constructed of ductile iron for high strength. The pump design includes removable pump casing liners in all models. Worn liners and vanes can be replaced in minutes. Some models incorporate reversible sideplates which double their service life. Seal maintenance is easy. Simply remove four bolts to remove bearings and seals.
Applications... Typical applications include cylinder filling, loading and unloading of bulk trucks and transport trailers. Some Coro-Vane® pump models come with an internal relief valve for added pump protection, relieving the pressure from the pump discharge back to the suction. All pumps must have an external by valve to comply with NFPA & UL code requirements.
Positive displacement... Coro-Vane® pumps are positive displacement pumps. They produce up to a maximum differential pressure of 125 psig (8.6 bar g). Corken manufactures five sizes of Coro-Vane pumps, ranging from 1 gpm to 350 gpm (0.2 to 79.5 m3/hr) with v-belt and direct-drive mounting options.
Precision-machined sideplates and liners (cam): Maximize pumping capacity and are easily replaced.
Direct-Coupled Mounting
Direct-Coupled 101 Mounting
12
Belt-Drive 103 Mounting
Bulk Filling, Carousel Filling & Cylinder Filling Specifications & Performance Specifications
Case and heads are made of ductile iron: For extra strength and long life.
Suction flange Low-impact, high-strength vane design: Extends pump life.
Discharge flange Minimum RPM Maximum RPM
Highly reliable mechanical seals: Easily replaced by simply removing the bearing cap.
521
1021
F1021
1"
2-1/2"
3"
3" 300# ASA
3/4"
2"
3"
2-1/2" 300# ASA
1,450 1,750
420 950
420 950
420 950
Minimum temperature
-25 °F (-32 °C)
Maximum temperature
225 °F (107 °C)
Max. working pressure psig (bar)
350 (25.2)
400 (28.6)
400 (28.6)
400 (28.6)
Max. differential pressure psid (bar)
125 (8.6)
125 (8.6)
125 (8.6)
125 (8.6)
No
2"
4"
No
Discharge flange option
No
2-1/2"
4"
No
Internal relief
Yes
Yes
Yes
Suction flange option
No ®
®1
O-ring material options:
Buna N (standard), PTFE, Viton , Neoprene
Seal seat material options:
Cast iron (standard), stainless steel, Ni-Resist
Steel slip-on flange option (suction & discharge)
No
Yes
Yes
No
Discharge flange option elbow (2" or 1-1/2")
No
Yes
No
No
Cast steel case option Maximum driver Heavy-duty roller-type bearings: Provides longer life.
Model C51/F51
1
No
Yes
No
No
2 hp 1.5 kW
10 hp 7.5 kW
20 hp 15 kW
20 hp 15 kW
ed trademark of the DuPont company.
L/min 5
10
15
20
120
C51/ F51
110
8 7
100 90
6 5
70 60
4
50
1450 RPM
40
1750 RPM
bar
psi
80
3
30
2
20 10
1
2
3
4
5
6
gpm
13
Vertical LPG Compressors Stationary Applications Why select a compressor to transfer LPG and NH3? Compressors are extremely versatile for they can be used to transfer liquids between tanks, off-load/load-out liquids, recover residual vapor, and evacuate vapors for maintenance purposes. Many LPG piping systems do not provide ideal NPSH conditions for liquid pumps which causes excessive pump maintenance. Since compressors are only exposed to vapors, they are not affected by poor NPSH conditions. Many LPG pressurized tanks such as railcars and buried tanks have top unloading connections. A compressor can be the perfect solution for transferring liquids to and from such tanks.
Why select a Corken compressor? Corken has over 60 years of experience in providing state-of-theart designs to the LPG and NH3 markets. Corken designs meet the most stringent global quality standards, including those of Japan, and the United States. Environmental impact and safety are always considered very seriously at Corken. It is Corken’s commitment to provide its customers with products of the greatest integrity, providing years of trouble-free service.
Compressors matched to your needs... Corken provides oil-free and non-lubricated vertical and horizontal compressor designs. Compressors are available in both threaded and ANSI flanged connections. Depending on the application, single- and two-stage compressors are available.
For applications of all types... Corken gas compressors are designed for use in liquid transfer, vapor recovery, scavenger and portable applications. Whether it is gas recovery from cylinders or barge unloading, Corken has a compressor for your application.
14
Threaded and ANSI flanges: Compressors are available in either threaded NPT, ANSI, or DIN flanged connections. High-efficiency valves: Corken valves offer quiet operation and high durability in oil-free gas applications. Specially designed suction valves which tolerate small amounts of condensate are available. O-ring head gaskets: Easy to install O-ring head gaskets providing highly reliable seals. Ductile- iron construction: All cylinders and heads are ductile iron for maximum thermal shock endurance.
Self-lubricating PTFE piston rings: Corken provides a variety of state-of-the-art piston ring designs to provide the most cost-effective operation of compressors for non-lube service. The step-cut design provides higher efficiencies during the entire life of the piston ring. Positively locked piston: Simple piston design allows end clearance to be precisely set to provide maximum efficiency and long life.
Self-lubricating piston rod seals: Seals constructed of PTFE incorporating special fillers to ensure no oil carry over and maximize leakage control. Spring loaded seal design self adjusts to compensate for normal wear. Nitride-coated piston rods: Impregnated nitride coating provides superior corrosion and wear resistance. Cast-iron crosshead: Durable cast-iron crossheads provide superior resistance to corrosion and galling. Pressure-lubricated crankcase with filter: Self-reversing oil pump ensures proper lubrication regardless of directional rotation to main and connecting rod bearings. Standard 10-micron filter ensures long-lasting bearing life (not available on Model 91).
Cylinder Evacuation, Bulk Transfer and Recovery Custom-engineered packages... Corken supplies custom-engineered packages to meet the most demanding customer specifications. Skid-mounted units can be supplied with control s, safety controls, pulsation dampeners, specialized traps, valving and other special accessories as required. Corken offers standard mountings designed specifically for liquid transfer, vapor recovery, and gas scavenging applications.
Serviceability... Corken compressors are designed to minimize required maintenance and make such maintenance extremely simple. Maintenance operations such as valve replacement may be accomplished without disturbing the piping, while ring replacement may be accomplished simply by removing the head.
Versatility... Corken compressors are designed for use with maximum versatility. The same compressor installed for one application can easily be piped to be utilized for other plant applications. For example, a rail carunloading compressor can also be utilized to load and unload trucks. Model 491
Sized for your capacity needs... Corken offers four sizes of vertical, oil-free, single-stage compressors (Models 91, 291, 491 & 691). These compressors cover a full range of capacities from 24 to 361 gpm (5.5 to 82 m3/hr) in liquid transfer.
For even greater capacity... Corken Model D891 is a double-acting single-stage vertical gas compressor capable of capacities from 337 to 757 gpm (76.5 to 171.9 m 3/hr).
Model F291
Model D891
15
Horizontal LPG Compressors Stationary Applications For high-volume transfer...
Self-lubricating piston and rider rings: Made of PTFE to ensure extended service life.
Corken’s horizontal single-stage compressor is perfect for the terminal requiring transfer of large volumes of LPG (i.e., barge, multiple rail car, etc.). This heavy-duty, balanced-opposed gas compressor offers smooth, quiet operation. The compressor is offered with various sizes of cylinders. Corken currently offers 8" (203.2 mm), 6" (152.4 mm), 5" (127.0 mm), 4" (101.6 mm), 3-1/4" (82.6 mm), and 2-3/4" (69.9 mm) cylinders. These cylinders may be arranged in various combinations of single-, two-, three-, or four-stages. The horizontal compressors are offered in lubricated and non-lubricated designs. Although these compressors are not classified as oil-free, the potential for oil carry-over is minimized.
For stringent environmental requirements... In response to increasingly stringent environmental requirements to reduce emissions of volatile organic compounds and other hazardous gases, Corken offers a purge-pak piston-rod-sealing system for the HG601 series horizontal compressors. While precise leakage rates cannot be guaranteed due to the many complex factors which affect leakage, the purge-pak and rodsealing system substantially reduces potential leakage compared to conventional segmented piston-rod seal configurations. Tests have shown that in many cases, leakage can be reduced below 1 scfh (0.027 m3/hr).
Water-cooled cylinders... To increase the versatility of the horizontal compressor, Corken offers water-cooled cylinders in the 8" (203.2 mm), 6" 152.4 mm), 4" (101.6 mm) and 3-1/4" (82.6 mm) bore sizes. Water-cooled cylinders greatly reduce the operating temperature which increases the valve, piston ring, and seal life in the most difficult applications.
Model 601
16
Crankshaft journal, connecting-rod bearings, wrist pins and crossheads: Pressure lubricated by an oil pump with oil filtered by a 10-micron spin-on filter. Thermostatically-controlledcrankcase heater (optional): Assures proper oil viscosity in all weather conditions. Heavy-duty crankcase: A rugged, internally ribbed design, incorporating heavy-duty main bearings and four-bolt connecting rods. Force-feed lubricator (optional): Assures proper lubrication of cylinders and packing when required.
Tanker and Multiple Railcar Unloading and Recovery Available Options Blank valve... Heavy-duty cylinder design: Each cylinder is hydrostatically tested to 1-1/2 times the rated working pressure for maximum strength. MC1002 coating is available on all cylinders, providing longer piston-ring life.
In addition to the flexibility of reconfiguring the stages and number of cylinders, the capacity may be controlled through the blank valve option, which changes the cylinder to single acting.
Variable clearance heads... This option on all cylinder sizes allows for pressure and capacity adjustment while the compressor is operating.
External crankcase oil cooler... Corken compressors can be equipped with a force-feed lubrication system and external oil filter. An optional external oil cooler is available when required to ensure optimal service life.
Materials... The horizontal compressor line offers many optional materials for parts such as gaskets, piston rings, o-rings, pistons and more. This allows the compressor to be used with a variety of gases. The MC1002 corrosion-resistant coating is also available for all parts that come in with the gas.
Engineered packages... Custom-engineered skid-mounted units can be supplied with control s, wiring, pulsation dampeners, receiver tanks and other special accessories as required.
Placement of valves: Makes inspection and maintenance simple.
17
Liquid Gas Transfer Compressor Applications Bulk application... The “107” bulk plant gas compressor unit is complete with pressure gauges, steel baseplate, mechanical liquid trap, four-way valve, strainer, interconnecting piping, adjustable driver-slide-base, v-belt drive and beltguard ready to receive an electric motor. This standard unit is typically used for liquid transfer and vapor recovery in applications including rail car and truck loading and unloading. Many options such as ASME liquid traps with Class 1, Group D switches and total engineered packages can be provided.
Large terminal and barge applications... The D891 and HG601 series compressors are for high-volume transfer applications with flow capacities from 337 to 1552 gpm (76.5 to 352.5 m3/hr). These compressors are available in standard mounting configurations and also in special-engineered packages which include safety shutdowns and controls as required.
Scavenger applications... Corken has a variety of standard scavenger packages available, depending on the customer’s requirements. For maintenance purposes, scavengers can be sized for small-cylinder to large-tank evacuation systems. Corken will assist in custom engineering your scavenger systems for your specific application.
Truck compressor applications... The “102” compressor comes complete with extended crankshaft for utilization on trucks with PTO and hydraulic drive systems. The compressor can be used for loading/unloading as well as vapor recovery on trucks.
18
Compressor Specifications & Performance Specifications
Model 91
291
491
691
891 (a)
HG601BB (b)(e)
HG601AA (b)(e)
Bore of cylinder inches (mm)
3.0 (76.2)
3.0 (76.2)
4.0 (101.6)
4.5 (114.3)
4.5 (113)
6 (152)
8 (203)
Stroke: inches (mm)
2.5 (63.5)
2.5 (63.5)
3.0 (76.2)
4.0 (101.6)
4.0 (101.6)
3 (76.2)
3 (76.2)
Piston displacement CFM (m3/hr) minimum @ 400 RPM maximum @ 825 RPM maximum @ 1,200 RPM
4.0 (6.8) 8.3 (14.1) -
8.0 (13.6) 16.5 (28.0) -
17.2 (29.2) 35.5 (60.3) -
29.2 (49.6) 60.2 (102.3) -
350 (24.1)
350 (24.1)
350 (24.1)
350 (24.1)
465 (32.1)
365 (25.2)
315 (21.7)
7.5 (5.6)
15 (11)
15 (11)
35 (26.1)
45 (34)
75 (55.9)
75 (55.9)
Maximum working pressure: psig (bar) Maximum brake horsepower (kW) Maximum rod load lb (kg)
56.6 (96.2) 76.8 (130.5) 138 (234.5) 113.2 (192.0) 230.5 (391.9) 413.8 (703.5)
3,600 (1,632.9) 3,600 (1,632.9) 4,000 (1,814.4) 5,500 (2,494.8) 7,000 (3,175.2) 7,000 (3,175.2) 7,000 (3,175.2)
Maximum outlet temperature °F (°C)
350 (177)
Bare unit weight lb (kg)
115 (52.2)
160 (72.6)
260 (117.9)
625 (283.5)
855 (387.8)
Maximum flow-propane gpm (m3/hr)
50 (11.4) (c)
101 (22.9) (c)
215 (48.8) (c)
361 (82.0) (c)
694 (157.6) (c)
ANSI/DIN flange option
F91
F291
F491
F691
(d)
(a) Double-acting vertical compressor (b) Double-acting horizontal compressor (c) Maximum flow is based on 825 RPM or maximum hp, 30 psid. Capacities shown are based on 100 °F (37.8 °C) and will vary depending upon piping, fittings, product being transferred, and temperature. The factory will supply a detailed compressor analysis if required. 1,000 Gallon (3,785 Liter) Tank1
50
491 691
Vapor Pressure (psig)
Vapor Pressure (psig)
Vapor Pressure (psig)
100
150
480 gal recovered @ 110¡F
100
50
18 gal re covered @ 70¡F 5
150
1615 gal recovered @ 110¡F
100
50
640 gal recovered @ 70¡F
190 gal recove red @ 70¡F
10
15
(d)
291 491
45 gal rec overed @ 110¡F
0
(d)
200
91 291
0
1,305 (296.4) 1,725 (391.8) (e) (f)
33,000 Gallon (124,918 Liter) Tank1
200
150
20
25
0
30
868 (393.7)
(d) Not available (e) Maximum rating at 1,200 RPM (f) Maximum is based on hp limit and 845 RPM
10,000 Gallon (37,854 Liter) Tank1
200
828 (375.6)
0
20
40
Time (min)
60
Time (min)
80
100
120
0
0
30
60
90
120
150
180
Time (min)
Performance—Propane1
RPM
800 700 600 500 91 291
491
691
891
HG601BB
HG601AA*
400 50
100
150
200
250
300
350
400
500
750 1000 1250 1500 1750
gpm 10
20
30
40
50
60
70
m3/hr
80
100 150 200 250 300 350 400
(Liquid)
1 Capacities shown are based on 100 °F (37.8 °C) and will vary depending upon piping, fittings, product being transferred, and temperature. The factory will supply a detailed compressor analysis if required. * Maximum 75 hp is reached at 845 RPM
19
Propane Compressor Selection Table Capacity Service gpm(1) 23 Small 29 bulk 34 plants 40 39 45 44 50 56 Unloading 61 single tank 66 car or 71 transport 79 84 84 89 89 95 101 106 108 114 Unloading 119 two or 125 more tank 130 cars at 136 one time 141 or large 147 transport 152 with excess 158 flow valves 163 of adequate 163 capacity 168 171 179 178 186 193 200 208 215 223 230 Unloading 237 large 245 tank cars, 252 multiple 260 vessels, 275 barges or 297 terminals 319 334 452 623
Displacement cfm 4 5 6 7 7 8 8 9 10 11 12 13 14 15 15 16 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 30 31 31 32 32 34 35 36 38 39 41 42 43 45 46 47 48 54 58 60 82 113
Compressor Model RPM 91 400 91 505 91 590 91 695 290,291 345 91 795 290,291 390 290,291 435 290,291 490 290,291 535 290,291 580 290,291 625 290,291 695 290,291 735 490,491 345 290,291 780 490,491 370 490,491 390 490,491 415 490,491 435 490,491 445 490,491 470 490,491 490 490,491 515 490,491 535 490,491 560 490,491 580 490,491 605 490,491 625 490,491 650 490,491 670 690,691 400 490,491 695 690,691 420 490,491 740 690,691 440 690,691 455 690,691 475 690,691 495 690,691 510 690,691 530 690,691 550 690,691 565 690,691 585 690,691 605 690,691 620 690,691 640 690,691 675 690,691 730 690,691 785 690,691 820 D891 580 D891 800
Driver Sheave Size P.D."(2) 1,750 RPM 1,450 RPM A 3.0 A 3.6 A 3.8 B 4.6 B 4.6 B 5.6 B 5.4 B 6.6 A 3.0 A 3.6 B 6.2 B 7.4 A 3.4 B 4.0 A 3.8 B 4.6 B 4.4 B 5.2 B 4.8 B 5.8 B 5.2 B 6.2 B 5.6 B 6.6 B 6.2 B 7.4 B 6.6 B 8.0 A 3.0 A 3.6 B 7.0 B 8.6 A 3.2 A 3.8 A 3.4 B 4.0 A 3.6 B 4.4 A 3.8 B 4.6 B 4.0 B 4.8 B 4.2 B 5.0 B 4.4 B 5.2 B 4.6 B 5.6 B 4.8 B 5.8 B 5.0 B 6.0 B 5.2 B 6.2 B 5.4 B 6.4 B 5.6 B 6.6 B 5.8 B 7.0 B 6.0 B 4.4 B 5.2 B 6.2 B 7.4 B 4.6 B 5.6 B 6.6 B 8.0 B 4.8 B 5.8 B 5.0 B 6.0 B 5.2 B 6.2 B 5.4 B 6.4 B 5.6 B 6.8 B 5.8 B 7.0 B 6.0 A 7.0 B 6.2 B 7.4 B 6.4 A 7.4 B 6.6 B 8.0 B 6.8 B 7.0 A 8.2 B 7.4 B 8.6 B 8.0 B 9.4 B 8.6 TB 9.0 A 10.6 5V 7.1 5V 8.5 5V 9.75 5V 11.8
Notes: (1) The capacities shown are based on 70°F, but will vary depending upon piping, fittings used, product being transferred and temperature. The factory can supply a detailed computer analysis if required. (2) Driver sheaves: 91 - 2 belts; 290,291,490,491 - 3 belts; 690,691 - 4 belts.
20
Driver Horsepower Liquid Liquid Transfer Transfer and without Residual Residual Vapor Vapor Recovery Recovery 100°F 80°F 100°F 80°F 5 3 3 3 5 5 5 5 5 5 5 5 5 5 5 5 3 3 3 3 7-1/2 7-1/2 7-1/2 7-1/2 5 3 3 3 5 5 3 3 5 5 5 5 5 5 5 5 7-1/2 5 5 5 7-1/2 5 7-1/2 5 7-1/2 7-1/2 7-1/2 7-1/2 10 7-1/2 10 7-1/2 7-1/2 7-1/2 5 5 10 10 10 10 7-1/2 7-1/2 7-1/2 5 7-1/2 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 10 10 7-1/2 7-1/2 10 10 10 7-1/2 15 10 10 10 15 10 10 10 15 10 10 10 15 10 15 10 15 15 15 15 15 15 15 15 15 15 15 15 15 15 10 10 15 15 15 15 15 15 10 10 15 15 15 15 15 15 10 10 15 15 15 10 15 15 15 10 15 15 15 15 20 15 15 15 20 15 15 15 20 15 15 15 20 15 15 15 20 15 15 15 20 15 15 15 20 20 15 15 20 20 20 15 25 20 20 20 25 20 20 20 25 20 25 20 30 25 25 20 30 30 30 30 40 40 30
Piping Size (3) Vapor Liquid 3/4 1-1/4 3/4 1-1/4 1 1-1/4 1 1-1/2 1 1-1/2 1 1-1/2 1 1-1/2 1 1-1/2 1 2 1 2 1 2 1-1/4 2 1-1/4 2 1-1/4 2-1/2 1-1/4 2-1/2 1-1/4 2-1/2 1-1/4 2-1/2 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 4 1-1/2 4 1-1/2 4 2 4 2 4 2 4 2 4 2 4 2 4 2 4 2 4 2 4 3 6 3 6
(3) The piping sizes shown are considered minimum. If the length exceeds 100 ft, use the next larger size. Consult factory for compressors with higher flows.
Ammonia Compressor Selection Table Capacity Service gpm(1) 23 Small 29 bulk 34 plants 40 43 46 45 50 56 Unloading 62 single tank 67 car or 72 transport 80 85 85 90 90 96 102 107 110 115 Unloading 120 two or 126 more tank 131 cars at 138 one time 142 or large 148 transport 153 with excess 160 flow valves 165 of adequate 165 capacity 170 173 181 180 188 195 203 211 218 226 233 Unloading 240 large 248 tank cars, 255 multiple 263 vessels, 278 barges or 301 terminals 323 338 459 633
Displacement cfm 4 5 6 7 7 8 8 9 10 11 12 13 14 15 15 16 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 30 31 31 32 32 34 35 36 38 39 41 42 43 45 45 47 48 54 58 60 82 113
Compressor Model RPM 91 400 91 505 91 590 91 695 290,291 345 91 795 290,291 390 290,291 435 290,291 490 290,291 535 290,291 580 290,291 625 290,291 695 290,291 735 490,491 345 290,291 780 490,491 370 490,491 390 490,491 415 490,491 435 490,491 445 490,491 470 490,491 490 490,491 515 490,491 535 490,491 560 490,491 580 490,491 605 490,491 625 490,491 650 490,491 670 690,691 400 490,491 695 690,691 420 490,491 740 690,691 440 690,691 455 690,691 475 690,691 495 690,691 510 690,691 530 690,691 550 690,691 565 690,691 585 690,691 605 690,691 620 690,691 640 690,691 675 690,691 730 690,691 785 690,691 820 D891 580 D891 800
Driver Sheave Size P.D."(2) 1,750 RPM 1,450 RPM A 3.0 A 3.6 A 3.8 B 4.6 B 4.6 B 5.6 B 5.4 B 6.6 A 3.0 A 3.6 B 6.2 B 7.4 A 3.4 B 4.0 A 3.8 B 4.6 B 4.4 B 5.2 B 4.8 B 5.8 B 5.2 B 6.2 B 5.6 B 6.6 B 6.2 B 7.4 B 6.6 B 8.0 A 3.0 A 3.6 B 7.0 B 8.6 A 3.2 A 3.8 A 3.4 B 4.0 A 3.6 B 4.4 A 3.8 B 4.6 B 4.0 B 4.8 B 4.2 B 5.0 B 4.4 B 5.2 B 4.6 B 5.6 B 4.8 B 5.8 B 5.0 B 6.0 B 5.2 B 6.2 B 5.4 B 6.4 B 5.6 B 6.6 B 5.8 B 7.0 B 6.0 B 4.4 B 5.2 B 6.2 B 7.4 B 4.6 B 5.6 B 6.6 B 8.0 B 4.8 B 5.8 B 5.0 B 6.0 B 5.2 B 6.2 B 5.4 B 6.4 B 5.6 B 6.8 B 5.8 B 7.0 B 6.0 A 7.0 B 6.2 B 7.4 B 6.4 A 7.4 B 6.6 B 8.0 B 6.8 B 7.0 A 8.2 B 7.4 B 8.6 B 8.0 B 9.4 B 8.6 TB 9.0 A 10.6 5V 7.1 5V 8.5 5V 9.75 5V 11.8
Notes: (1) The capacities shown are based on 70°F, but will vary depending upon piping, fittings used, product being transferred and temperature. The factory can supply a detailed computer analysis if required. (2) Driver sheaves: 91 - 2 belts; 290,291,490,491 - 3 belts; 690,691 - 4 belts.
Driver Horsepower Liquid Liquid Transfer Transfer and Without Residual Residual Vapor Vapor Recovery Recovery 100°F 80°F 100°F 80°F 5 3 3 3 5 5 5 3 5 5 5 5 5 5 5 5 5 3 3 3 7-1/2 5 5 5 5 3 3 3 5 5 3 3 5 5 5 3 7-1/2 5 5 5 7-1/2 5 5 5 7-1/2 5 5 5 7-1/2 7-1/2 7-1/2 5 10 7-1/2 7-1/2 7-1/2 7-1/2 7-1/2 5 5 10 7-1/2 7-1/2 7-1/2 10 7-1/2 5 5 10 7-1/2 5 5 10 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 10 7-1/2 7-1/2 7-1/2 15 10 7-1/2 7-1/2 15 10 7-1/2 7-1/2 15 10 10 7-1/2 15 10 10 7-1/2 15 10 10 7-1/2 15 10 10 10 15 10 10 10 15 15 10 10 15 15 15 10 15 15 10 10 15 15 15 10 15 15 10 10 15 15 15 15 15 15 10 10 20 15 10 10 20 15 10 10 20 15 15 10 20 15 15 10 20 15 15 15 20 15 15 15 20 15 15 15 20 20 15 15 20 20 15 15 25 20 15 15 25 20 15 15 25 20 15 15 25 20 20 15 30 25 20 20 30 25 20 20 40 30 30 30 40 40 30
Piping Size (3) Vapor Liquid 3/4 1-1/4 3/4 1-1/4 1 1-1/4 1 1-1/2 1 1-1/2 1 1-1/2 1 1-1/2 1 1-1/2 1 2 1 2 1 2 1-1/4 2 1-1/4 2 1-1/4 2-1/2 1-1/4 2-1/2 1-1/4 2-1/2 1-1/4 2-1/2 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/4 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 3 1-1/2 4 1-1/2 4 1-1/2 4 2 4 2 4 2 4 2 4 2 4 2 4 2 4 2 4 2 4 3 6 3 6
(3) The piping sizes shown are considered minimum. If the length exceeds 100 ft, use the next larger size. Consult factory for compressors with higher flows.
21
LPG Accessories By Valves B166B (3/4", 1") Automatic Dual-Purpose, By Valve Typical Application: On all cylinder filling pumps as well as aerosol propellant feed pumps.
Specification
B166B
ZV200
B177
Inlet
3/4", 1"
2" (standard)
2", 2-1/2"
Outlet
3/4", 1"
2" (standard)
2", 2-1/2"
Slip-on flange option
No
Yes
2", 2-1/2"
Differential pressure range psi (bar)
25–225 (1.7–15.5)
41–150 (2.8–10.3)
10–125 (0.7–8.6)
Buna N (standard), Neoprene®, PTFE, Viton®, ethylene-propylene1
O-ring material options 1
ed trademark of the DuPont company. Ethylene-propylene not availble for B177.
A combination by and priming valve specifically designed for small cylinder-fillingtype pumps, especially of the regenerative turbine type, such as the Corken Coro-Flo® pump series. The patented vapor elimination system keeps liquefied gas pumps primed to increase system reliability and decrease pump and seal wear. The B166B is a smooth operating by with moderate pressure build-up.
ZV200 By Valve Typical Applications: Used for both truck and stationary applications for loading and unloading. A low-pressure build-up by valve designed for applications requiring protection for positive displacement pumps. Specifically designed for protecting pumps with capacities up to 250 gpm (56.8 m3/hr). The continuous internal bleed will assist in the operation of systems with “air” or “electric” operated internal valves.
B177 (2", 2-1/2") Differential By Valve
B177 Performance
Typical Application: In liquefied gas bulk-plant installations for loading and unloading pumps.
22
20
30
40
50
60
70
80
8.6
psid
125
bar
A low-pressure build-up by valve specifically designed for applications requiring protection for positive displacement pumps in the 50 to 350 gpm (11.4 to 79.5 m3/hr) range. It can also be used as a differential back-pressure valve to assure adequate pressure on meters, etc. To properly function, this valve requires a pressure sensing line from the storage tank.
m3/hr 10
21/2"
2" 20
1.4
10
0.7
50
100
150
200
gpm
250
300
350
Flo-Chek, 4-Way Valve, Ell Strainer & Liquid Traps, etc... Flo-Chek valve... The Flo-Chek enables you to detect flow in the gas or liquid lines and prevents release of product from storage tank in the event of a hose failure. Flow-indicating and back-check valves feature all ductile iron construction and are available in 1-1/4" through 4", NPT or welded flanges with a 400 psig (27.6 bar) rating. Standard O-rings are Buna N. PTFE, Viton®, and Neoprene® are optional.1
4-way non-lubricated valve... A convenient and simple means of reversing flow direction to a compressor. Made of ductile iron body, complete with handle and flow direction indicator (1" or 1-1/4" NPT and 2" — 300# ANSI flange, 500 psig rating [34.5 bar g]).
Low-oil-pressure switch... NEMA 7 pressure switch allows you to shut down the compressor if the oil pressure drops below 10 psi (0.69 bar), which protects the compressor from lack of lubrication. Available in 120 or 230 volt and can be used with magnetic starters up to NEMA Size 3.
Strainer... The right-angle design will minimize pressure drop and comes complete with ductile iron body with monel screen and steel plug. Available for liquid or vapor service (1-1/4" NPT 250 psig [17.2 bar] rating).
Pressure gauges... Stainless steel case-glycerine filled pressure gauges will mount on the compressor head or in the piping system and come with the following features: • 0 to 400 psi (0 to 28 bar) range, 5 psi (0.34 bar) increment • 2-1/2" dial with 1/4" NPT center back connection
Automatic liquid trap, with one NEMA 7 liquid-level switch for compressor shutdown and drain valve.
ASME code-stamped automatic liquid trap with two NEMA 7 liquid-level switches for compressor shutdown and alarm. Equipped with relief valve, pressure gauge, demister pad, and drain valve.
1-1/4" x 1-1/4" NPT or
1-1/2" x 1-1/2" NPT or
1-1/4" x 1-1/2" NPT
2" x 2" 300# ANSI flange.
Liquid traps... Standard liquid trap with mechanical float assembly and drain valve. 1-1/4" x 1-1/4" NPT or 1-1/4" x 1-1/2" NPT
1
ed trademark of the DuPont company.
23
CORKEN, INC. • A Unit of IDEX Corporation 3805 N.W. 36th St., Oklahoma City, OK 73112 U.S.A. (405) 946-5576 FAX (405) 948-7343 Visit our website at http://www.corken.com E-mail us at [email protected] LPG100E
