WS-C2960X-24PS-L Datasheet Overview (WS-C2960X-24PS-L) Cisco catalyst 2960X-24PS-L LAN Base stackable Layer 2 switch is comprised of 24 * 10/100/1000 Ethernet ports with POE+ and 4 * 1G SFP uplink interfaces. The industry standard IEEE802.3at PoE+ provides up to 30W per port. Quick Specs Table 1 shows the Quick Spec of the Cisco 2960X-24PS-L switch. Product Code

WS-C2960X-24PS-L

Enclosure Type

Rack-mountable - 1U

Feature Set

LAN Base

Uplink Interfaces

4 x 1G SFP

Ports

24 x Ethernet 10/100/1000 Gigabit ports

Available PoE Power

370W

Maximum stacking number

8

Stack bandwidth

80G

Forwarding Bandwidth

108Gbps

Switching Bandwidth

216Gbps

RAM

512MB

Flash Memory

128MB

Dimensions

44.5 cm x 36.8 cm x 4.5 cm

Package Weight

10.65 Kg

Product Details Figure 1 shows the front of the Cisco 2960X-24PS-L switch.

Figure 2 shows the back of the Cisco 2960X-24PS-L switch.

Note: ① FlexStack-Plus module slot and cover ② Fan Exhaust ③ RPS Connector ④ AC power connector Figure 3 shows the stackable capacity. This C2960X switch delivers stackable capacity that s up to 8 switches stacking with same 2960-X LAN base series. It also can stack up to 4 switches stacking when mixed with 2960-S LAN base series switches.

Figure 4 shows the WS-C2960X-24PS-L and cables.

The Accessories Table 2 shows some accessories of the WS-C2960X-24PS-L. Models

Description

C2960X-STACK

Catalyst 2960-X FlexStack Plus Stacking Module

CAB-STK-E-0.5M

Cisco FlexStack Stacking Cables

GLC-LH-SM

GE SFP, LC connector LX/LH transceiver

GLC-SX-MMD

1000BASE-SX SFP transceiver module, MMF, 850nm, DOM

CAB-CONSOLE-RJ45

Console Cable 6ft with RJ45 and DB9F

CAB-CONSOLE-USB

Console Cable 6 ft with USB Type A and mini-B
