Aviation Six Pack – Instrument 6 Pack Before the days of Glass s, this was a typical General Aviation Instrument . Even with the trend towards only Glass Cockpits, the basic Flight Instruments remain the same. Six Pack? The Six Pack is not a half-dozen beers, and it’s not a well toned and muscled belly. Instead, Pilots know the 6-Pak refers to the six Primary Flight Instruments. 3+3=6 The 6 basic flight instruments are divided into two categories. Three instruments are connected to the aircraft’s Pitot Static Pressure System, and the other three are Gyro Instruments typically driven by the aircraft’s Vacuum system pump. It’s important for student pilots to recognize this difference. In the event of a partial system failure, the pilot will be better prepared when they recognize the specific instruments that may be affected. The SIX PACK: 1. Airspeed Indicator (Pitot Static) 2. Attitude Indicator (Gyro) 3. Altimeter (Pitot Static) 4. Vertical Speed Indicator (Pitot Static) 5. Heading Indicator (Gyro) 6. Turn Coordinator (Gyro) These six instruments are denoted by number on the Cessna 172 Instrument above. Every pilot must have a thorough understanding of these six flight instruments – the Aviation Six Pack – and the way they work. Pilots should have knowledge of each instrument’s characteristics and limitations. During flight, a pilot must interpret the information displayed on these six flight

instruments to fly safely and within the limitations of the aircraft’s safe operating envelope.

Let’s take a closer look at each of these six flight instruments and how they work. Six Pack – 6 Pack – Cockpit Instruments Pitot Static Instruments The Pitot Static System relies on a Pitot Tube to measure the dynamic pressure due to the forward motion of the airplane through the air, and Static Vents to measure the static, outside barometric pressure as the airplane gains or loses altitude. The three flight instruments connected to the Pitot Static System include the Airspeed Indicator, Altimeter, and Vertical Speed Indicator. Gyroscopic Instruments A Gyroscope is a rotor or spinning wheel, rotating at a high speed. Usually, this is powered by the Vacuum System Pump. Gyroscopic Inertia is the tendency of a rotating body to maintain its plane of rotation, known as Rigidity in Space. Gyroscopic Precession is the tendency of a rotating body to consistently react to a force being applied by turning in the direction of its rotation exactly 90 degrees to its axis. These principles of physics are used to make very precise Flight Instruments including the Attitude Indicator, Heading Indicator, and Turn Coordinator.

#1) Airspeed Indicator The Airspeed Indicator measures the speed of the aircraft through the air, but really this is the speed at which the air is flowing over the airplane. And , this is not a measurement of ground speed. The dial is usually calibrated in Nautical miles known as KNOTS. KNOTS vs. Miles KNOTS are a measure of speed based on nautical, or sea miles. Aviation uses both nautical and statute miles for measuring distance and speed, but the Airspeed Indicator typically shows KNOTS. Nautical Mile = 6,076 feet Statute Mile = 5,280 feet Therefore, 1 Nautical Mile distance = 1.15 Statute Mile distance

The airspeed indicator is connected to the Pitot Static System. To give a reading of speed through the air, the flight instrument measures the difference between the dynamic pressure in the Pitot Tube and the atmospheric pressure from the Static vent. When the airplane is standing still on the ground, the pressure in the two systems will be the same resulting in a reading of zero. However, when the airplane is travelling through the air, the dynamic pressure in the Pitot system will increase and a reading is ed. Indicated Airspeed The Indicated airspeed (IAS) is the reading displayed on the face of the instrument. The small windows at the top and bottom of the Airspeed Indicator are used for determining True Airspeed (TAS). , the Airspeed Indicator displays the Indicated Air Speed (IAS), and adjustments are needed to calculate the Calibrated Airspeed (CAS) and True Airspeed (TAS). Speed Ranges and limitations are marked on the Airspeed Indicator and are specific to the make and model of the aircraft. Different makes and models of airplanes will have the markings at different speeds based on limitations of each aircraft. Typically Green markings on instruments reflect normal operations, and Red markings reflect abnormal operations or limitations. The Red Line The speed marked by the Red Line is the Never Exceed Speed (Vne). This speed should never be exceeded in the Aircraft or structural damage may occur. The Yellow Arc The speed range marked by the Yellow Arc is the Caution Speed Range. Speed range indicated by the Yellow Arc is for Smooth Air Only. The Green Arc The Green Arc denotes the Normal Operating Airspeed Range. The White Arc The Flaps Operating Range is denoted by the White Arc. Flaps may only be used within this range of speeds.

#2) Attitude Indicator

The Attitude Indicator is also called the artificial horizon or the gyro horizon. This flight instrument depicts the position of the airplane in relation to the horizon. It shows whether the wings are level, and if the plane is climbing or descending, or flying straight and level. A pair of wings represents the attitude of the aircraft. Behind the aircraft is a ball. The top is blue, representing the sky, and the bottom half is usually brown, representing the ground. As the airplane manoeuvres in the air, the pair of wings will show the degree of bank and pitch attitude. The Attitude Indicator is a Gyroscopic Instrument, and it uses a Gyroscope to stabilize a horizon bar which stays parallel to the natural horizon. The miniature airplane in the centre of the Attitude Indicator will pitch and bank around the horizon bar to indicate the airplanes current attitude relative to the horizon.

#3) Altimeter The Altimeter measures the Altitude or height of the aircraft above Sea Level. , ground elevation varies widely, so the Altimeter reading does not measure height about the Ground, but instead above Sea Level. The Pilot must be aware of the Ground elevation, to then calculate the height of the airplane above the Ground. Similar to a clock, an Altimeter has three hands. The fastest moving hand reads in Hundreds of Feet. The shortest hand reads in Thousands of feet. The Longest hand, which moves the slowest, reads in Tens of Thousands of feet. (On some altimeters, the Tens of Thousands of feet is represented with the shortest hand, instead of the Longest Hand) The Altimeter pictured here has a reading of 1,410 feet above sea level. The fastest moving hand (Hundreds) is between the 4 and 5, and the small hash marks represent 20 feet each. Therefore, this hand has a reading of 410 feet. The shortest hand (Thousands) is between the 1 and 2. Therefore, the current altitude would be 1,410. The Altimeter reading is based on barometric pressure, and barometric pressure is constantly changing. This requires the altimeter to be set prior to every flight, and during flight as barometric pressure in your flying area changes.

#4) Vertical Speed Indicator (VSI) The Rate of Climb and Rate of Descent are indicated on the Vertical Speed Indicator (VSI). This is measured in Feet Per Minute, and displayed in Hundreds of FPM. The VSI flight instrument measures the vertical speed (vertical velocity, or rate of climb). This instrument is connected to the static air pressure system. There is a standard barometric pressure change with altitude changes, and this standard rate of change is calibrated to measure the aircraft’s change in altitude and rate of change. The pilot relies on both the Altimeter and the Vertical Speed Indicator to monitor altitude and altitude changes. At a glance, the VSI shows the pilot if they are flying at a steady altitude, or if they are ascending or descending, and the rate at which their altitude is changing in feet per minute.

#5) Heading Indicator The Heading Indicator is another Gyroscopic flight instrument. Sometimes known as the Directional Gyro or Heading Gyro, this instrument is the principal direction instrument used in flight. The Heading Indicator is gyroscopically stabilized. Unlike the magnetic com, the Directional Gyro is not as affected by banks, turns, and speed changes. However, the Heading Indicator is NOT a magnetic com.

The Heading Indicator must be set according to the Magnetic Com indication before takeoff, and occasionally adjusted to the Magnetic com while the aircraft is in steady, level flight. Precession error must be corrected for at regular intervals of about 15 minutes by re-calibrating the Heading Indicator (HI) to the Magnetic Com. The outline of an aircraft is positioned over a 360 degree scale with markings for North, East, South and West. The larger markings indicate 10 degrees each, and the smaller markings denote 5 degree variations.

#6) Turn Coordinator This is another Gyroscopic instrument. This instrument gives information about the direction and rate of a turn. Additionally, it indicates if the turn is being flown in coordinated flight. If the aircraft is slipping or skidding during a turn, the ball (or inclinometer) in the bottom portion of the Turn Coordinator will not be centred. During a coordinated turn, the ball will remain centered. If the ball is not centered, the pilot must adjust the turn by using more or less rudder to correct for adverse yaw. Standard Rate Turn The white lines indicate the bank amount for a Standard Rate Turn. The turn indicator indicates the rate of turn, and not the amount of turn. A Standard Rate Turn, or Rate One Turn, will give a standard rate of turn of 3 degrees per second. Therefore, a 360 degree turn will be exactly 2 minutes. This allows the pilot to determine by time, the degrees of turn. For instance, a pilot could use a standard rate of turn for 60 seconds, and confidently know they have changed their course by 180 degrees based on 3 degrees per second. This becomes particularly important when pilots begin Instrument flying. Six Pack – Primary Flight Instruments – Cockpit Instrument Every Pilot needs to have a complete and proper understanding of the Six Pack – The Primary Flight
