BAUER FILTER CARTRIDGES OUTSTANDING PURIFICATION OF BREATHING AIR, INDUSTRIAL AIR AND GASES

››Removal of water vapour H2O using molecular filter sieve ››Removal of oil vapour and odours CxHy with activated carbon ››Safe conversion of carbon monoxide CO into non-toxic carbon dioxide CO2

B R E ATH I NG AIR

IN DU ST RY

2 | FILTER CARTRIDGES

BAUER KOMPRESSOREN

CARTRIDGES FOR AIR PROCESSING P 21 Application: for compressors with P 21 TRIPLEX Filter (e.g. JUNIOR II) Spare part number

Processing capacity

057679

130 Nm3 *

–

–

059183

110 Nm3 *

Industry

–

–

Industry with SECURUS

–

–

Standard With SECURUS With CO-Converter

P 31 Application: for compressors with P 31 TRIPLEX Filter (e.g. MARINER 250) Spare part number

Processing capacity

80100

620 Nm3 *

–

–

80114

460 Nm3 *

Industry

–

–

Industry with SECURUS

–

–

Standard With SECURUS With CO-Converter

P 41 Application: for compressors with P 41 (e.g. MARINER 320) Spare part number

Processing capacity

Standard

062565

1600 Nm3 *

With SECURUS

061686

1590 Nm3 *

With CO-Converter

061687

1350 Nm3 *

Industry

–

–

Industry with SECURUS

–

–

* Processing capacity at 20 °C / 300 bar. Cartridge life time applicable to drying only. ** Cartridge life time only applies for oil separation. Processing capacity for water separation might be lower than for oil separation.

BAUER KOMPRESSOREN

FILTER CARTRIDGES | 3

P 61/P 60 Application: for compressors with P 61 Spare part number

Processing capacity

Standard

058826

2480 Nm³ *

With SECURUS

060036

2420 Nm³ *

With CO-Converter

060037

2240 Nm³ *

Industry

068622

5180 Nm³ **

Industry with SECURUS

090984

6220 Nm³ **

P 81/P 80 Application: for compressors with P 81 Spare part number

Processing capacity

Standard

1x 058825/1x 058826

5330 Nm³ *

With SECURUS

1x 058825/1x 060036

5270 Nm³ *

With CO-Converter

1x 058825/1x 060036/ 1x 063282

5270 Nm³ *

Industry

1x 058823/1x 068622

12200 Nm³ **

Industry with SECURUS

1x 058823/1x 090984

13200 Nm³ **

P 101/P 100 Application: for compressors with P 100 Spare part number

Processing capacity

Standard

2x 058825/1x 058826

8180 Nm³ *

With SECURUS

2x 058825/1x 060036

8120 Nm³ *

With CO-Converter

2x 058825/1x 060036/ 1x 063283

8120 Nm³ *

Industry

2x 058823/1x 068622

19100 Nm³ **

Industry with SECURUS

2x 058823/1x 090984

20200 Nm³ **

* Processing capacity at 20 °C / 300 bar. Cartridge life time applicable to drying only. ** Cartridge life time only applies for oil separation. Processing capacity for water separation might be lower than for oil separation.

BAUER KOMPRESSOREN

FILTER CARTRIDGES | 4

HEADLINE P 120 Application: for compressors with P 120 Spare part number

Processing capacity

Standard

1x 067099/1x 067867

10000 Nm³ *

With SECURUS

1x 067099/1x 067097

16000 Nm³ *

With CO-Converter

1x 067099/1x 067097/ 1x 065562

16000 Nm³ *

Industry

1x 067812/1x 067867

41000 Nm³ **

Industry with SECURUS

1x 067812/1x 068067

21500 Nm³ **

P 140 Application: for compressors with P 140 Spare part number

Processing capacity

Standard

2x 067099/1x 067867

18660 Nm³ *

With SECURUS

2x 067099/1x 067097

24600 Nm³ *

With CO-Converter

2x 067099/1x 067097/ 1x 065562

24600 Nm³ *

Industry

2x 067812/1x 067867

62500 Nm³ **

Industry with SECURUS

2x 067812/1x 067097

44700 Nm³ **

THE ADVANTAGES OF OUR CARTRIDGES ››Air and gases which are purified by BAUER cartridges are within the limit values of DIN EN 12021 *** › Oil: < 0.1 mg/m3 (DIN EN 12021 max. 0.5 mg/m3) › Carbon monoxide (CO): < 5 ml/m³ (ppm) › Humidity: ≤ 10 mg/m3 ››Above-average service life of all cartridges ››Vacuum-packed for long shelf life without loss of cartridge service life ››Optional: B-SECURUS activates safe shutdown when the filter is saturated with moisture ››Our B-TIMER can monitor the service life of many cartridge types ››All cartridges are in stock for immediate delivery

* Processing capacity at 20 °C / 300 bar. Cartridge life time applicable to drying only. ** Cartridge life time only applies for oil separation. Processing capacity for water separation might be lower than for oil separation. *** Assuming proper maintenance and installation of the BAUER compressor systems in accordance with operating instructions/operating manuals, in cases where intake air CO2 concentration does not exceed the levels required by the applicable breathing air standard

5 | FILTER CARTRIDGES

BAUER KOMPRESSOREN

CALCULATION OF LIFE TIME

HEADLINE HEADLINE HEADLINE

Processing capacity depending on temperature at 300 bar

Nm³ 3000

2500

2000

1500

1000

500

0 18

20

22

24

26

28

30

32

34

36

38

40

42

44

°C

– – – –

P 21 P 31 P 41 P 61
