Harmonics on the Double Bass Eric Daino String harmonics have occupied an important place in orchestral, chamber, and solo repertoire for well over a century now. And since the early twentieth century composers as renowned as Schoenberg, Stravinsky, and Ravel have found increasingly complex and innovative applications of string harmonics. The double bass in particular has benefited from the increased experimentation and progressive use of harmonics present in contemporary works. The largest instrument of the violin family has one primary advantage over the smaller and higher string instruments: the lower range and greater length of the double bass’ open strings allows more headroom to explore an extreme upper . A greater number of partials are accessible on a double bass string before the length between nodes becomes miniscule and impossible to navigate. With the use of harmonics the range of the double bass can extend well into the upper of the violin (and even down below the lower limit of the piano, with the application of subharmonics). Many sources exist detailing the physical phenomenon of string harmonics, therefore it is not the aim of this paper to describe the application of harmonics on the double bass in of physical production, but rather as technical and aural components of performance and composition.1 A certain knowledge of the physical processes regarding string harmonics and the overtone series are assumed of the reader. The term partial will henceforth refer to each level of the overtone series, with the first partial as the fundamental. Nodes refer to the points on a string where waveforms begin and end and where by touching, all lower partials are eliminated. These points occur at all whole number divisions of the fundamental length. The distances between nodes increases or decreases in direct proportion to the length of the string, so upper partials on a double bass string have more length to vibrate than those on a violin string. The average fundamental length of a violin string is about 13” and that of a bass string is about 41-42”.2 Therefore the eighth partial for example, is somewhat impractical on a violin as it leaves just over an inch and a half of the string to vibrate. On the double bass however, the eighth partial is still fairly accessible with over five inches of the string left to vibrate between nodes. Examples of partials as high as the 21st are studied by modern players, and while challenging to perform, produce clear and definite audible effects.3























































 1

For a classic analysis of the physical acoustics of music, see Hermann von Helmholtz, On the Sensations of Tone as a Physiological Basis for the Theory of Music, translated by Alexander J. Ellis (Bristol: Thoemmes Press / Maruzen Co., LTD, 1998). Chapter 1 deals with the harmonic series on pp. 33-35. 2 Norman Lamb and Susan Lamb Cook, Guide to Teaching Strings (New York: McGrawHill, 2002), 12, 15. 3
Dennis Lane Woodrich, “Multi-Nodal Performance Technique for Contrabass Harmonics,” M.A. thesis, University of California, San Diego, 1980, appendix B.

Natural and Artificial Harmonics One of the most distinguishable characteristics of harmonics on the double bass is indeed the clarity of tone afforded by the technique. The tone of a traditionally stopped or open string is rather complex, as it possesses not only the fundamental pitch but also all overtones above the fundamental. As upper partials are isolated by interfering with the vibrations of the fundamental or lower partials, the harmonic tone becomes less complex and more pure in nature. The clear, glassy timbre of harmonics blends well with other sounds and instruments, as the distinct body of the tone associated with the timbre of the double bass becomes cut away and a simpler more generic tone remains. In the very high partials the harmonic tone begins to thin out, which can possibly be undesirable. Available dynamic range also decreases as of harmonics increases. Practical use of partials above the tenth or eleventh is generally limited to subtle or quiet ages due to these effects.4 Also, as the harmonic tone becomes less defined in upper partials, bow noise becomes more apparent. This extraneous noise takes the form of a dull scratching sound as the bow moves across the string at a normal speed or pressure, but much less pitched output remains intact. When articulating with pizzicato, a percussive snap of the fingers on the string becomes more prominent over the harmonic tone with upper partials as well. Harmonics can be produced with the bow or pizzicato, however articulating with the bow makes upper partials speak more easily. The left hand must lightly touch a node of the string, but not depress the string fully to the fingerboard so as to change the fundamental. When placed on a node, all upper partials still sound as they are in series with the selected partial; their waveforms fit inside the selected partial. Lower partials are eliminated in this manner because the node selected on the string rests at a point in the middle of larger waveforms, stopping their vibrations. Bow registration is an important factor in producing harmonics. The placement of the bow may interfere with some partials if care is not taken to adjust registration for new harmonics in a age.5 Generally higher partials will speak most easily when bow registration is closer to the bridge, but true sul ponticello bowing may produce unpredictable overtones. There is no single correct area of bow registration for each partial, as it may vary from instrument to instrument, and there may be several alternative positions available that work better for some performers than others. Bowing directly on one of the nodes of a desired partial however will interfere with the vibration of that harmonic. For this reason, higher partials with multiple nodes become more difficult to locate successful bow registrations. As the number of nodes available increases with the higher partials, more options present themselves to left hand placement. Therefore the produced pitch does not relate to the position used to activate the harmonic. This discrepancy creates some confusion as to which node is optimal in generating a desired harmonic, especially with upper partials. The notation used to depict harmonics is often not as helpful as either composer or























































 4

Bertram Turetzky, The Contemporary Contrabass (Berkeley: University of California Press), 124. 5 Ibid., 124.

performer would prefer, but two general methods have been in practice since the early twentieth century. In either method, if the resulting pitch is given, it should be written an octave lower than sounding, consistent with normal double bass notation. Cecil Forsyth suggested otherwise in his text on orchestration,6 but bassists now agree that the practice of notating harmonics sons reale is archaic and unnecessary.7 The first method employs a symbol “o” above a pitch to indicate it is to be produced as a harmonic, but which node is to be used is left unspecified and remains the responsibility of the performer to determine which positioning is best. In ages where the use of harmonics is sparing and the partials are low, this system works well, as any “guesswork” is usually logically revealed to the performer in the context of the music. This system is also common when the harmonic node that is to be played is located at the same position of the stopped note of that pitch. At the upper end of the fingerboard many pitches are available as both harmonic and stopped tones, and this notational system was commonly used in solo repertoire by composers such as Bottesini who made extensive use of this tessitura.

Figure 1: Gran Duo Concertante by Giovanni Bottesini (version for Clarinet, String Bass, and Piano) - m. 25 The second method indicates the positioning of the harmonic with a diamondshaped notehead in tablature style. Tablature style notation does not concern itself with the designation of the sounding pitch. Composers such as Stravinsky and Ravel used this system when extended agework of harmonics were used, especially in conjunction with higher partials. In some cases this notational system seems to be an outgrowth of artificial harmonic notation (to be discussed later). While tablature style may seem at first to aid the individual performer, in orchestral pieces confusion almost always arises within a section of double basses or from the conductor as to what the desired pitch should actually be.

Figure 2: Ma Mere l’Oye by Marice Ravel - I. Pavane de la Belle au bois dormant, mm. 7-8























































 6

Cecil Forsyth, Orchestration (New York: Macmillan Company), 443. Barry Green, Advanced Techniques of Double Bass Playing (Cincinnati: Piper Company, 1976), 160. 7

Various styles of notation have been employed combining the two methods, but rarely with a great deal of success. Ravel actually changed his preferred method of notating harmonics throughout his compositional career, creating a great deal of discrepancies from piece to piece. Lucas Drew has managed to assemble a guide to interpreting Ravel’s notation, which demands a careful read before performing works by the composer.8 The performance of harmonics requires a large amount of information, which the performer must usually become reacquainted with for each piece that is encountered. Unfortunately, standard notation usually becomes too cluttered to adequately display what is necessary. Schoenberg often notated harmonics rather redundantly.9 In this example for violin and cello, he uses the “o” symbol, diamond shaped noteheads, writes an abbreviation for flageolet tone (harmonic), and gives the sounding pitch as well.

Figure 3: Pierrot Lunaire by Arnold Schoenberg - 10. Raub m. 16 Another method of notating extended ages of harmonics, especially those utilizing more difficult upper partials, uses two separate staves. A primary staff should indicate positioning in tablature style, and a smaller ossia staff should indicate resulting pitches.10

Figure 4: Double staff notation of harmonics























































 8

Lucas Drew, The Notation of Harmonics for Double Bass: A Guide to the Orchestral Works of Maurice Ravel (New York: University of Miami Music Publications, 1972). 9 Norman Del Mar, Anatomy of the Orchestra (Berkeley: University of California Press, 1981), 119. 10 This notation is used by the author in the cello part of Sand Walk (2009), a setting of text by Aja Beech for baritone and cello.

Harmonics sounded on any of the open strings are referred to as natural or open harmonics. While a great variety of pitches are available in harmonics from the overtone series of just four (or five, depending on the instrument) fundamentals, the chromatic spectrum may be filled in completely with the use of artificial or stopped harmonics. Artificial harmonics are identical in timbre and tone quality to natural harmonics, but are produced by stopping an open string and then touching a new node that is created by the shortened fundamental. If the left hand is used both to stop the string and touch a node, artificial harmonics are limited to the reach of the performer, typically within the middle to high of a string where the distance between fundamental and partials is smaller. Higher partials that lie closer to the fundamental are also easier to reach. The right hand may also be used to touch a node and attack the string as pizzicato simultaneously. This technique makes reaching lower partials with fundamentals in all s more practical. While it may be safely assumed that some notes marked as a harmonic that are not located within the natural harmonic series of any open string must be played as an artificial harmonic, common practice dictates that they are always notated in tablature form. The stopped note is notated normally, and the position of the harmonic is notated above with a diamond notehead.11 As this method is the only accepted notational system for the use of artificial harmonics, it is curious to observe so much confusion over the notation of natural harmonics. If two staves are used as the system of harmonic notation however, artificial harmonics fit in seamlessly with natural harmonics, and the ease of reading artificial harmonic positioning is combined with simple representation of sounding pitch. The timbre and practical application of natural and artificial harmonics is familiar to most composers and performers, as the use of such techniques has been honed over the better part of the twentieth century. More recent developments in the performance of harmonics have found their way into modern repertoire, many of which require closer examination. Pulled Harmonics The sounding pitch of any harmonic may be raised slightly by touching the node on the side of the string and then pulling the string sideways towards the edge of the fingerboard. This technique will increase the tension of the string and can be used to raise the pitch of the harmonic more than a semitone in some applications.12 Nodes located closer to the middle of the string are more useful when pulling, as their pitches can be raised higher and with greater ease than those of nodes closer to the nut or bridge. Aside from intentional bending of harmonic pitches, harmonics, which normally are of























































 11

Kurt Stone, Music Notation in the Twentieth Century: A Practical Guidebook (New York: W. W. Norton & Company, 1980), 312. See also David Cope, New Music Notation (Dubuque: Kendall/Hunt Publishing Company, 1976), 99. 12 Gardner Read, Contemporary Instrumental Techniques (New York: Schirmer Books, 1976), 58.

fixed intonation, may be adjusted in this manner to tune to other instruments in an ensemble,13 or to compensate for upper partials in the harmonic series being flatter than equal temperament intonation. The timbre of the harmonic generally remains the same, but if pulled to an extreme the tone begins to dampen. If the string is pulled taut enough, the left hand finger acts as a suspended bridge and a stopped pitch about a semitone higher than its placement over the fingerboard is heard. With proper control, rapid alternation between the pulled harmonic and “stopped” tone can be achieved. In the extreme upper off of the end of the fingerboard, pulling a harmonic to the side becomes the alternative to stopping a pitch on the fingerboard. This tone is not actually a harmonic, but has been classified as so in the old Italian school because the string is not stopped against the fingerboard, just as normal harmonics are produced.14 Harmonic Glissandi Two categories of harmonic glissandi are used in contemporary literature. The more common category involves techniques that glissando over a harmonic series, so that the resulting pitch sequence breaks cleanly and pitches do not slide smoothly into the next. The most simple example of this technique calls for the left hand to lightly touch any node on an open string and then glissando upwards or downwards, still maintaining a light touch so as only to isolate partials and not stop the string. When the finger es over a node, that partial is excited and will remain sounding until the finger es through the node to another. This technique is most useful with the bow, drawing a continuous sound. Pizzicato attacks will die out too quickly as the left hand finger es through a node, thereby muting the string, and when the left hand finger finds a new node, the string will have stopped vibrating. Pizzicato tremolo will achieve a rearticulation once a new node is found, but dead space will still exist in between nodes. The continuous excitement of a string when attacked with the bow can sustain a harmonic even after the left hand finger has left the node, but if the glissando is too slow, dead space will occur in between nodes. With careful registration of the bow, it is possible to make very high partials speak better so that dead space between more familiar nodes is lessened. In any case, all pitches present as a result of any partial will sound cleanly and definitely, intonation remaining fixed as a component of the harmonic series. Natural harmonic glissandi using open strings have been used routinely throughout the twentieth century for effect. One of the first notated examples occurs in the viola and cello parts near the beginning of the fourth movement of Ravels’s Rapsodie Espagnole (1908). The instructions read “Slide the finger lightly over the string near the bridge.”15























































 13

Green, 160. Knut Guettler, A Guide to Advanced Modern Double Bass Technique (London: Yorke Edition, 1992), 112. 15 Maurice Ravel, Four Orchestral Works in Full Score (New York: Dover Publications, Inc., 1989) . 14

Figure 5: Rapsodie Espagnol by Maurice Ravel - IV. Feria, mm. 5-6 The same type of glissando may be used in conjunction with artificial harmonics, albeit with limited physical range. An artificial harmonic stopped anywhere on the string can be used to initiate a glissando by either of two methods. The first entails keeping the fundamental fixed (usually stopped by the left thumb) and sliding the finger touching the node either towards or away from the stopped note. The second, which is more difficult to maintain an even glissando with, requires the finger touching the node to remain fixed as the thumb stopping the fundamental slides towards or away from the node. Both methods result in similar effects as a natural harmonic glissando, but using artificial harmonics makes available a wider range of chromaticism in regards to the pitched output of the glissandi. The second category of harmonic glissandi involves the even sliding of a pitch, much like traditional stopped glissando, but applied to the timbre of a harmonic. This sound can be achieved only with the use of artificial harmonics. To evenly slide an artificial harmonic up or down the fingerboard, the distance between fingers touching the string must change according to the distance between the fundamental and desired node. As the glissando moves up the distance between the stopped note and harmonic decreases, and as the glissando moves down the distance increases. This technique requires a great deal of precision from the performer in order to control the rate of change in distance between points as well as an even glissando simultaneously. Perhaps the most popular technique of harmonic glissandi is a combination of both main categories. The “seagull” glissando involves an evenly slid pitch that then breaks and resets to slide again, all stemming from a continuous motion of the left hand sliding down the fingerboard. This effect is achieved by fixing the distance between points of in an artificial harmonic, and initiating an even downwards glissando. As the even downwards slide of a pitch becomes unfocused due to the placement of the left hand finger no longer lying on a node, a higher partial of a lower fundamental will “catch” the slide, and the glissando will restart. The technique takes its name from the call of seagulls, which is quite accurately imitated in certain contexts.

Multi-nodal harmonics Theoretically, any two or more nodes on a string may be isolated simultaneously, and the multiple of their partials will sound. For instance, if the nodes corresponding to the third and fourth partials are activated together, the pitch of the twelfth partial will be heard.16 This technique is particularly useful to reach upper partials in positions on the fingerboard that do not approach the extremes near the bridge or nut. And while the tone of sounding harmonic is identical to one produced normally, the left hand may be able to locate positioning quickly so that that higher partials speak more clearly with this technique. Multi-nodal harmonics extend the upper range of the bass more consistently than any other performance technique. Previously only theoretical partials such as the twentyfirst, nearly impossible to locate with the left hand, become within reach and more exact for the hand to pinpoint. While the left hand benefits greatly from the use of multi-nodal harmonics, the right hand must still take care in proper bow placement when attempting to articulate the extreme upper partials. Consistent with the traditional tendencies of harmonics, dynamic expression decreases greatly with the extreme upper partials, and these harmonics are still only useful in more subtle and soft contexts. Multi-nodal techniques are most useful and practical around the upper limit that most composers adhere to in compositions utilizing harmonics (up to about the twelfth partial). Partials above this general area will still take a considerable amount of practice to produce consistently but are ittedly more certain in their execution than single node natural harmonics. Harmonic Flautando Traditional flautando bowing calls for the bow to be placed sul tasto and drawn lightly, imitating the timbre of a flute. Harmonic flautando operates with the same principles, but activates a partial above the fundamental, enhancing the flutelike qualities of the technique to a much more accurate imitation of an actual flute. The left hand does not affect the production of harmonic flautando. Instead, partials are activated by the bow when placed on a node. Using a quick and light bowstroke appropriate for traditional flautando, a pitch an octave lower than that of the selected partial will sound. For example, to sound a harmonic flautando pitch an octave above the fundamental, the bow should be placed on a node of the fourth partial, normally two octaves above the fundamental. To sound a pitch an octave and a fifth above the fundamental, the bow should be placed on a node of the sixth partial, normally two octaves and a fifth above the fundamental, etc. The technique presents its most useful opportunities at the two intervals described, but higher partials can also be produced with increased bow control.























































 16

Dennis Lane Woodrich, Multi-Nodal Performance Technique for Contrabass Harmonics, M.A. thesis, University of California, San Diego, 1980, 16.

Harmonic flautando enables a performer to “pop” harmonics out of a texture without altering the left hand. Bassist Mark Dresser has used the technique to achieve a drastically gentle quality in performance, and recommends the use of vibrato to further proliferate the pure flutelike expressiveness.17 While harmonic flautando has not been used prominently in current repertoire, it may be used as a substitute for ages marked with traditional flautando. One must simply use left hand positioning an octave lower than written and bow at the fourth partial to produce the correct pitch. Subharmonics The use of subharmonics enables the performer to play notes that are actually lower in pitch than the fundamental. The curious physical phenomenon of subharmonics has commanded the attention of several acoustical studies over recent years, with sometimes mystifying results.18 Subharmonics exist as part of the undertone series, which is the logical inverse of the overtone series, and are produced by locating the normal harmonic nodes of the string with the bow and applying overpressure.19 The scratching and groaning normally associated with an overpressured bow stroke can be controlled and will “catch” a lower pitch depending on the amount of pressure used and the exact location of the bow. To present a considerable amount of confusion over the acoustical production of the technique, what limited use of subharmonics that has found its way into string repertoire does not actually correctly utilize the undertone series. The tones commonly referred to as subharmonics in the context of most musical applications are pitched between the fundamental and its lower octave. Since the second partial of the undertone series is the lower octave, these pitches are not located on true partials of the fundamental, and occur as part of the undertone series for a modified fundamental. As of a June 2009 feature on subharmonics in Strings magazine, the exact reasoning why these pitches occur is still unknown.20 These pitches that are produced without satisfying physical explanation are referred to by Allen Strange and Patricia Strange as “Anomalous Low Frequencies” or ALFs.21























































 17

Mark Dresser, “Discover, Develop, Integrate: Techniques Unveiled” (presentation at the 2009 International Society of Bassists Convention, State College, Pennsylvania, June 8-13, 2009). 18 See R. J. Hanson, Andrew Scheider, and Frederick Halgedahl, “Anomalous Lowpitched Tones from a Bowed Violin String,” Catgut Acoustical Society Journal 2, no. 6 (1994): 1, and Knut Guettler, “Wave Analysis of a String Bowed to Anomalous Low Frequencies,” Catgut Acoustical Society Journal 2, no. 6 (1994): 4. 19 Carleen M. Hutchins, Alvin S. Hopping, and Frederick A. Saunders, “Subharmonics and Plate Tap Tones in Violin Acoustics,” The Journal of the Acoustical Society of America 32 (Nov. 1960): 1444. See also Read, 59. 20 James Reel, “Mari Kimura on Subharmonics,” Strings 170 (June 2009): http://www.stringsmagazine.com/article/default.aspx?articleid=24421 21 Allen Strange and Patricia Strange, The Contemporary Violin: Extended Performance Technique (Berkeley: University of California Press, 2001), 25.

Regardless of their confusing acoustical origins, ALFs have been used with success in contemporary compositions, and modern performers are refining a highly specialized technique to produce them consistently. Most examples in printed music occur for violins, an instrument with considerably greater room to explore downwards in range. The first notated instance of subharmonics or ALFs appeared in Black Angels by George Crumb, and were referred to as “pedal tones.”22

Figure 6: Black Angels by George Crumb, 4. Devil-music, pg. 3 Since 1994 Japanese violinist Mari Kimura has been at the forefront of performing ALFs, and has demonstrated virtuosic control of the technique in compositions written for and by her. She has written articles on subharmonics and developed a system to control ALF pitches, in which she demonstrates in chart form where to place the bow in relation to the fundamental and how much pressure to apply in order to produce the desired interval below the fundamental.23 However, many of her own compositions and those written for her do not include information as specific as required bow pressure and placement, and leaves it up to the violinist to figure out how to produce the notated pitch. This omission is partly due to inconsistencies from player to player but more importantly from instrument to instrument that unfortunately present the impossibility of a truly standardized technique in ALF production. Variables of string























































 22

The notational system of indicating finger positioning with block noteheads remains in practice today by the few composers incorporating subharmonics in string repertoire. Composers also still couple this notational designation with an additional staff to indicate sounding pitch. See James Reel, “Mari Kimura on Subharmonics.” 23 For chart demonstration, see Mari Kimura, “How to Produce Subharmonics on the Violin,” Journal of New Music Research 28 (June 1999): 180-182. Kimura consistently (and erroneously) refers to any pitch below the fundamental as a subharmonic. She upholds this designation by reasoning that “Anomalous Low Frequency” is not a musical term and will not persist as vocabulary in describing the technique, even though her chart clearly indicates she does not use the traditional undertone series to produce the given intervals below the fundamental. She has made these assertions in “How to Produce Subharmonics on the Violin,” 183, and in Mari Kimura, “The World Below G,” Strings 16 (Aug. 2001): 29.

composition and twisting also produce issues with consistency.24 Given the lack of flexibility in altering or manipulating double bass strings most performers are faced with in comparison to the violin, the application of subharmonics or ALFs in double bass performance therefore is decidedly more limited. It can be recommended at this time that only the subharmonic octave be applied in musical contexts for the double bass.25 While other intervals are certainly possible, the technique of performing them remains relatively unexplored, and performers seeking to use varied ALF intervals below the fundamental must currently specialize their own personal method of bow placement, pressure, and speed. The subharmonic or ALF octave however can be and is produced reliably and regularly, enough so that Mark Dresser has prescribed a standardized technique since 1988.26 To produce a pitch an octave lower than the note that is stopped, the bow should be placed on the node of the sixth partial (two octaves and a fifth above the fundamental) and a great deal pressure should be applied as the bow is drawn. The scratching and groaning sound of overpressure can be controlled with a very even bow stroke to “catch” the lower octave. Due to the increased girth of double bass strings, contrary to the violin it is desirable to stop the string with a left hand pressure that is less than normal. For this reason, producing ALFs on the bass is most difficult (but still possible) on open strings. The tone of subharmonic octaves is much more gritty and nasal than a normally drawn bowed note. While first attempts to produce ALFs may still contain a good deal of overpressure “noise,” it is possible to completely eliminate the extraneous scratching sounds and draw a consistent and even tone. The dynamic range is difficult to control, mostly resulting in at least forte because of the extreme amount of bow pressure required. It is possible however, with a great deal of control to produce a useful piano dynamic, especially with fundamentals in the lower part of the double bass’ range. Using subharmonic octaves, it is theoretically possible to extend the range of the bass below the lower limit of the piano, and as far down as almost to the lower limit of human hearing. The lower the fundamental used, the harder it is to hear the complete pitch. The lowest pitches available begin to sound similar to an analog synthesizer producing square waveforms in the extreme low . The clicking or beating that is observed in very low synthesized sounds is somewhat reproduced as the overpressured bow vibrates the string so slowly that individual catching and slipping of bow hairs is heard. While subharmonic octaves from fundamentals on the low E string do have audible effects, they would be heard more easily and fully in a musical context that utilizes these ultra-low pitches as the foundation for other pitches, even if just a doubled























































 24

Kimura, “How to Produce Subharmonics on the Violin,” 181-182. Kimura has concluded that older strings produce more consistent results than new strings, and also that twisting a string counterclockwise from the tailpiece end replicates the properties of an older string on a new one. Twisting a string is impractical however on a double bass. 25 The octave lower than the fundamental is the only true subharmonic that can be used practically on the double bass. This interval may also fall under the umbrella term of ALF; the use of either term when describing this interval is current. 26 Mark Dresser, “A Personal Pedagogy,” in Arcana: Musicians on Music, ed. by John Zorn, 250-261 (New York: Granary Books, Inc., 2000) 256.

octave at the normal fundamental. As with any tone, the presence of natural overtones will strengthen and give character to the fundamental. Therefore if the subharmonic pitch is treated as a fundamental and other pitches above it within its own harmonic series are provided in addition, the subharmonic will appear louder. These ultra-low pitches are best utilized in musical contexts that require a deep foundation upon which to build other musical events. This particular tessitura (E0 to B1, below the normal C extension range) is not practical at all for agework. Using subharmonics as a substitute for a C extension below the normal E string generally will not produce smooth results, as even in contexts without active agework, the timbre of a subharmonic C1 is not identical to the rich and deep tone of an open C extenstion on another bass, and within a double bass section or mixed ensemble the subharmonic pitch may not blend properly. Multiphonics As with other extended applications of string harmonics, multiphonics have long been deemed too imprecise and unpredictable to develop a standardized performance technique or to be demanded in any sort of fixed (non-aleatoric or -improvisational) musical context. Indeed, the production of multiphonics on the double bass is decidedly more delicate than the blaring and abrasive qualities normally associated with multiphonics on woodwind instruments like the clarinet and saxophones.27 The general physical properties occur similarly: the vibrating column of air in a woodwind instrument and the vibrating string of a double bass is split between two or more pitches. Just as variables such as fingering and embouchure affect the production of certain multiphonic chords and clusters, left hand positioning, bow location, speed, and pressure will affect those on double bass. Multiphonics occur on a string by producing any combination of partials in the harmonic series and/or the fundamental simultaneously. A finger position must be located that will activate two or more partials together, usually at some point between closely positioned nodes.28 When multiple partials sound together, the string vibrates in such a manner that the “dead” spot associated with a single node is no longer present. This property affects the sensation under the left hand that will thus be of the entire string still vibrating; there is no defined point on the string where waveforms begin and end that the finger rests. These points in between partials may be discovered by gently sliding the left hand back and forth between adjacent nodes with a light bow stroke until both partials are heard at once. This process may be used to find and sound multiple partials together, but the more partials that are used simultaneously, the less chordal qualities the multiphonic will contain. Higher partials that are closer together in pitch also lie closer























































 27

Phillip Rehfeldt, New Directions for Clarinet (Berkeley: University of California Press, 1994), 41. 28 Håkon Thelin, “A New World of Sounds: Recent Advancements in Contemporary Double Bass Techniques: Harmonics and Multiphonics,” (presentation at the 2009 International Society of Bassists Convention, State College, Pennsylvania, June 8-13, 2009).

together on the string, therefore when maximizing the amount of partials sounding simultaneously using nodes that are near to each other, dense upper partial content is sure to be present. To sound a harmonic partial at the same time as the fundamental, the left hand must simply apply a lighter than usual pressure at the desired node. Using either method, possibilities of diads, triads, multi-voice chords, and clusters exist with mixes of different partials and/or the fundamental. While many of the available multiphonics are unpredictable, there are some chords and combinations that are more dependable than others, and which possess opportunities for definite musical events.29 Generally, multiphonics using combinations that utilize lower partials produce more consistent chords, and also more tonally recognizable chords. The third, fourth, and fifth, partials in particular result in strong components to build multiphonics off of using surrounding nodes, and many multiphonics containing these partials offer potential for inclusion by composers as fixed musical elements. To produce a major chord with the pitch of the fundamental as the root, some practicing and familiarity with an individual instrument will yield consistent results for the performer. To produce a G major chord on the G string, the left hand finger should be placed approximately at the D#3; the precise placement may vary by as much as a quartertone in either direction depending on the instrument or player. This location is close to the third, fifth, and eighth partials, which can all sound simultaneously.30 When exploring a specific multiphonic for the first time, it is best to start by isolating the lowest partial involved alone, and then slowly oscillate between that partial and the others, with a light bow stroke. Soon, the point in the oscillation at which all partials still sound can be identified and secured. If the open string fundamental is desired in the chord, the left hand must slightly lessen its pressure on the string. These techniques can be applied to finding multiphonics at any point on the bass string, as long as the performer is certain of the desired partials to be involved in the multiphonic. Multiphonics should be notated with an additional staff to indicate sounding pitches. It may also be helpful to indicate in a musical context which partials are desired in addition to their sounding pitches. In order to avoid confusion and create a fixed musical purpose with an element that has long been as non-specific as multiphonics, composers must include more detail than is normally afforded for the notation of harmonics.

























































 29

Strange, 134. Allen Strange and Patricia Strange quote Tracy Silverman romanticizing the unpredictability of violin harmonics, but it there are more certain applications available on the cello and double bass. 30 Dresser, “A Personal Pedagogy,” 258.

Figure 7: Notation of multiphonics Dynamics of multiphonics can be controlled with bow speed. As dynamic intensity rises however, it does become more difficult to sustain a controlled multiphonic. Most triadic multiphonics respond best at softer dynamic levels, but complex cluster multiphonics may achieve a very high volume. Drawing the bow diagonally may also aid in projection.31 The tone of multiphonics falls in between that of a normally stopped note and a traditional harmonic. The pure and glassy harmonic tone is somewhat muddied by the string’s indecision of pitch, which gives the tone a mildly grating or gritty quality. This characteristic split-tone has contributed to the perception of multiphonics as wild and uncontrollable, and has similar properties to multiphonics on wind instruments. Indeed, multiphonics may be employed in raucous contexts without definable pitch content, to extent of noticing beating from the conflict of very close partials. More importantly though, multiphonics are now capable of being tamed to a serene and more delicate role in double bass music. Double Stops Some problems arise when performing harmonic techniques on two strings simultaneously. As many of these techniques depend on a great deal of finesse and control with the bow hand, the elements of bow placement, speed, or pressure used to initiate an event on one string may not correlate to a different event on a neighboring string. For this reason, some combinations of harmonic techniques are more difficult than others, and some are impossible. The one timbre that may be combined successfully with any previously described harmonic technique remains a traditionally stopped or open string. A normally bowed note can sound under a high variance of conditions that may be required for another technique. When using double stops of natural harmonics, most combinations are available without problems. As the specificity required of the bow hand increases with higher partials, pairings of natural harmonics that utilize extreme partials on both strings become more difficult to attain, and in some cases impossible. In general, combinations of partials above the eighth are not recommended.32 For the same reason, even rapid























































 31

Dresser, “Discover, Develop, Integrate: Techniques Unveiled.” Lawrence E. Czoka and Dennis L. Woodrich, Foundation Studies in Natural Harmonics for the Contrabassist (San Diego: Christopher Publications, 1978), 32-38. 32

alternation of single harmonics on different strings in agework may not speak due to bowing issues, even though the left hand positioning is perfectly logical. Double stops involving subharmonic octaves and traditionally bowed notes or open strings work particularly well, especially with open strings at unison with or stopped fifths above the fundamental. Other intervals are possible but may sound muddy depending on the . Double subharmonics are only possible in fourths so that the required bow placement for each string remains the same, and even so, eliciting a clear tone from double subharmonics invites a challenge. A better alternative would be to use a normally bowed note a fifth below the fundamental of the lower stop.

Figure 8: Subharmonic double stops Multiphonics can be combined with many other techniques, but as the density of bowing requirements increases, the predictability of multiphonic specificity decreases. If pitched content of a multiphonic is not a defined concern, such as with indeterminate clusters, multiphonic double stops can be useful in musical contexts. Combinations of multiphonics with other techniques or double multiphonics can create some of the most complex timbres available from the double bass. A wide range is available from ethereal and clear chords and clusters to wild and grating indeterminate beating. *** Harmonics on the double bass have existed simultaneously as one of the most common, and also one of the most confusing techniques of the twentieth century. The twenty-first century presents many more options and variations for use by the performer and composer, and hopefully, in newly clear and concise contexts. In particular, there still remains a great deal of room for exploration and perfection of extended harmonics techniques on the double bass.

Bibliography Bottesini, Giovanni. Duetto for Clarinet, String Bass, and Piano. New York: International Music Company, 1999. Cope, David. New Music Notation. Dubuque: Kendall/Hunt Publishing Company, 1976. Crumb, George. Black Angels (Images 1). New York: C. F. Peters, 1971. Czoka, Lawrence E. and Dennis L. Woodrich. Foundation Studies in Natural Harmonics for the Contrabassist. San Diego: Christopher Publications, 1978. Del Mar, Norman. Anatomy of the Orchestra. Berkeley: University of California Press, 1981. Dresser, Mark. “Discover, Develop, Integrate: Techniques Unveiled.” Presentation at the 2009 International Society of Bassists Convention, State College, Pennsylvania, June 8-13, 2009. ________. “A Personal Pedagogy.” In Arcana: Musicians on Music, edited by John Zorn, 250-261. New York: Granary Books, Inc., 2000. Drew, Lucas. The Notation of Harmonics for Double Bass: A Guide to the Orchestral Bass Parts of Maurice Ravel in Simplified Chart Form. New York: University of Miami Music Publications, 1972. Forsyth, Cecil. Orchestration. New York: Macmillan Company, 1949. Green, Barry. Advanced Techniques of Double Bass Playing. Cincinnati: Piper Company, 1976. Guettler, Knut. A Guide to Advanced Modern Double Bass Technique. London: Yorke Edition, 1992. ________. “Wave Analysis of a String Bowed to Anomalous Low Frequencies.” Catgut Acoustical Society Journal 2, no. 6 (1994): 4. Hanson, R. J., Andrew Scheider, and Frederick Halgedahl. “Anomalous Low-pitched Tones from a Bowed Violin String.” Catgut Acoustical Society Journal 2, no. 6 (1994): 1. Helmholtz, Hermann von. On the Sensations of Tone as a Physiological Basis for the Theory of Music. Translated by Alexander J. Ellis. Bristol: Thoemmes Press / Maruzen Co., LTD, 1998.

Hutchins, Carleen M., Alvin S. Hopping, and Frederick A. Saunders. “Subharmonics and Plate Tap Tones in Violin Acoustics.” The Journal of the Acoustical Society of America 32 (Nov. 1960): 1443-1449. Kimura, Mari. “How to Produce Subharmonics on the Violin.” Journal of New Music Research 28 (June 1999): 178-184. ________. “The World Below G.” Strings 16 (Aug. 2001): 24-29. Lamb, Norman and Susan Lamb Cook. Guide to Teaching Strings. New York: McGraw-Hill, 2002. Ravel, Maurice. Four Ochestral Works in Full Score. New York: Dover Publications, Inc., 1989. Read, Gardner. Contemporary Instrumental Techniques. New York: Schirmer Books, 1976. Reel, James. “Mari Kimura on Subharmonics.” Strings 107 (June 2009): http://www.stringsmagazine.com/article/default.aspx?articleid=24421 Rehfeldt, Phillip. New Directions for Clarinet. Berkeley: University of California Press, 1994. Schoenberg, Arnold. Pierrot Lunaire. Universal Edition, 1914. Stone, Kurt. Music Notation in the Twentieth Century: A Practical Guidebook. New York: W.W. Norton & Company, 1980. Strange, Patricia and Allen Strange. The Contemporary Violin: Extended Performance Technique. Berkeley: University of California Press, 2001. Stravinsky, Igor. The Firebird. London: Ernst Eulenburg Ltd., 1910. Thelin, Håkon. “A New World of Sounds: Recent Advancements in Contemporary Double Bass Techniques: Harmonics and Multiphonics.” Presentation at 2009 International Society of Bassists Convention, State College, Pennsylvania, June 813, 2009. Turetzky, Bertram. The Contemporary Contrabass. Berkeley: University of California Press, 1988. Woodrich, Dennis Lane. “Multi-Nodal Performance Technique for Contrabass Harmonics.” M.A. thesis, University of California, San Diego, 1980.
