AGMS AUTOMATED GREENHOUSE MONITORING SYSTEM

BY K.MAHESH

INTRODUCTION

Benefits 



  

Automatically control environmental conditions within greenhouse allowing any type of plants to be grown all year round Eliminates risk of greenhouse not being maintained at specific environmental conditions due to human error Minimizes labor costs involved in maintaining a greenhouse Customer able to define specific greenhouse conditions “Plug-and play” product

Features  Detect

and maintain temperatures from -40°C to 125°C  Detect and maintain humidity levels between 5% RH and 95% RH  Detect sunlight and artificial light

Marketability / Business Proposal  





Presetting -defined environmental conditions will allow company to have constant business with consumer Consumer requires company to recalibrate monitoring system yearly, as well as change preset environmental conditions if necessary Services can be performed in relatively short period of time, and at reasonably low price, thus not interrupting the monitoring system In most cases, consumers rarely change environmental conditions in the greenhouse, and therefore prefer the environmental conditions be preset

Automated Greenhouse Monitoring System

OBJECTIVE





Build miniature greenhouse which is equipped with automatic monitoring system Constantly monitor environmental conditions in greenhouse to ensure it remains at preset temperature, light and humidity levels.

Functions  

 



Lower Temperature: 2 Cooling Fans Raise temperature: Heater (indicated by LED for demonstration purposes) Decrease humidity level: 2 Exhaust Fans Increase humidity level: Mister (indicated by LED for demonstration purposes) Increase lighting condition: Fluorescent Lightbulb

Miniature Greenhouse with Monitoring System

REVIEW ORIGINAL DESIGN

System Overview AC Source

Relay Photodiode

A to D Converter

Thermistor

A to D Converter

Humidity Sensor

A to D Converter

Fan Main Processing Unit

Heater

Mister

Exhaust Fan Counter

Temperature Display

 

Voltage output from sensors sent as inputs into PIC Based on input values, PIC outputs specific voltages to turn ON/OFF devices

Light Bulb

Hardware  Environmental

Sensors

 Microcontroller  Oscillator  Environment

Maintaining Devices  Transistors & Relay

Ambient Light Sensor    

Manufacturer: Perkin Elmer Optoelectronics VTP-1188SH Operating temperature: -20°C to 75°C Wavelength Measurement Range: 400nm to 1100nm Current limiting circuit used to control current input into PIC: Voltage Operating Range of PIC: -0.3V to +7.5V Max Current into PIC VDD Pin: 25mA VOUT of Sensor: 0V to 1V Current Limiting: Use 50Ω resistor at output of sensor Max IIN = 1V / 50Ω = 20mA

Temperature Sensor    





Manufacturer: Microchip Technology M9700A-E/TO Operating current: 6µA to 12µA Temperature Measurement Range: -40°C to 125°C Decoupling circuit to reduce noise from Power Supply: Connect +5V power supply to VDD pin using 200Ω resistor with 1µF decoupling capacitor Current limiting circuit to control current input into sensor: V = IR: 5V / 6µA = 833k Ω 5V / 12µA = 416.7kΩ Therefore use resistor between 416.7kΩ and 833kΩ Chose 680kΩ resistor Allowable input current into PIC so connect directly to PIC: IOUT = 100µA

Humidity Sensor    

Manufacturer: TDK Humidity Sensor Unit CHS-UGS Operating temperature: 5°C to 45°C Humidity Measurement Range: 5%RH to 95%RH Current limiting circuit used to control current input into PIC: Voltage Operating Range of PIC: -0.3V to +7.5V Max Current into PIC VDD pin: 25mA VOUT of Sensor: 0V to 1V Current Limiting: Use 50Ω resistor at output of sensor Max IIN = 1V / 50Ω = 20mA

Microcontroller           

Manufacturer: Microchip PIC16F877A Operating Frequency: 20 MHz Input: Analog/Digital Voltage Low voltage requirement: +5V Total Power Dissipation: 1.0W Voltage Operating Range: VDD = -0.3V to +7.5V Max Current into VDD pin: 250mA I/O Voltage Range: -0.3V to VDD + 0.3V Max Output Current by any I/O pin: 25mA Ambient temperature under bias: -55 to +125°C Analog to Digital conversion capability

Oscillator 

 

Manufacturer: Fox Electronics F1100E Frequency: 20MHz Voltage: VDD = 5V

Devices      

2 Cooling Fans Heater (LED) 2 Exhaust Fans Mister (LED) LAMP OFF indicator (LED) Fluorescent Light-bulb

Transistors to Power Cooling Fans, Exhaust Fans & Relay   





0 PIC OUTPUT

5Vdc

DEVICES

10 O hm

Z E N E R D IO D E (5 .6 V )

6



Power supply: 5V Recommended Collector Current: 500mA Recommended Base Current: 50mA Transistors used as switches to provide 5V to connected devices. To ensure circuit functions properly, followed recommended current flow through resistor. To obtain required current flows, applied Ohm’s law and obtained current limiting resistor for collector to be 10Ω and 100 Ω for the base. These specifications enable circuit to function properly

5

100 O hm

4



0

Relay to Turn ON/OFF Fluorescent Light-bulb   







DC voltage: 5V DC current: 500mA. Relay enabled AC current to flow by implementing a switch within the device which is controlled by DC current The relay supposed to allow AC current through when no dc current is flowing When DC current is es through, relay will flick switch to ground, therefore causing open circuit for AC current flow Applied Ohm’s law to limit current flow and obtained limiting resistor to be 10Ω

FLUORESCENT LAMP

U9 NC COM NO A

0

5Vdc

120VAC 0Vdc

10 O hm

TRANSISTOR

B R e la y _ S P D T _ p h y _ m s r d

0

Circuit Diagram Schematic

PROJECT BUILD & FUNCTIONAL TESTS

Flow Chart

Testing of PIC using Function Generator & LEDs Function generator used to simulate analog 









inputs of sensors LEDs used to display appropriate output from PIC Extreme cases such as voltage greater than or smaller than preset range tested Preset range of values for light, temperature and humidity tested, and function generator used to calibrate PIC input Counter tested by checking time duration to output signal after one input is read

Modifying Preset Values for Greenhouse Environmental Conditions 

Preset range can be modified by changing values of these variables: 1 ADC point equivalent to 4.883mV.



int16 photoTRIGGER = 635; // <310mV preset value for light switch int16 minTEMP = 1372; // 670mV preset min sample value for T (30C) int16 maxTEMP = 1597; // 780mV preset max sample value for T (38C) int16 minHUMID = 614; // 350mV preset min value for H (30%RH) int16 maxHUMID = 1065; // 520mV preset max value for H (52%RH)









Testing of Cooling Fans & Exhaust Fans    



Power supply: 5V Max current input: 800mA Current driven into fan: 500mA Reason: fan connected to transistor. For transistor, recommended collector current is 500mA. Therefore, use 500mA to power fans PIC will output 5V, thus use 100Ω resistor in order to limit current as recommended base current to be driven is 50mA. With this connection, fan functioned with sufficient power

Testing of Heater (LED), Mister (LED) & LAMP OFF Used LEDs to represent conditions in which heater and mister (LED) turned ON 

   





 

LED also used to signify situation where LAMP is OFF Voltage supply: 5V Max current input: 0.1A Voltage supply for LEDs supplied by output of PIC which will be 0V or 5 V To supply correct current into LEDs, used current limiting resistors From the Ohm’s law, V = IR, obtained current limiting resistor for LEDs: R = V / I = 5V / 0.1A = 50Ω This specifications allows LEDs to function correctly

Testing of Fluorescent Light-bulb    







Voltage supply: 120VAC To use lamp, had to use a relay Relay controls current flow from power supply to light bulb Relay needs 5VDC with 500mA current flow to function as a DC/AC switch. Transistor will be used as a DC/DC switch to allow sufficient power to relay The switching decision comes from PIC. When PIC outputs digital 0, lamp turns ON. When PIC outputs digital 1, lamp turns OFF Voltage equivalence of digital output 1 varies from 3.2V to 5V, and digital output 0 varies from 0V to 0.2V. When relay switch is flicked, 120V AC power for bulb will cut off since switch is thrown to connect with ground. Therefore, bulb turns OFF

SUCCESSES & CHALLENGES

Voltage & current inputs into PIC  Voltage

input to PIC must be less than 6V  Total current entering PIC must not exceed 300mA  Maximum current entering each pin must not exceed 25mA  Could damage PIC is not compliant

Noise  Thermal

sensor did not output values according to data sheet  Due primarily to noise from power supply and surrounding noise  Used decoupling capacitor circuit to minimize noise  Sensor output values as expected

Programming of PIC  





First 3 trial codes had issues with timer Timer problem fixed on fourth trial. Code was still not ready for multitasking (reading all 3 sensors at the same period and output desired signals from appropriate pins) Greenhouse monitoring system control successfully tested after sixth trial code. This code was implemented for demonstration Code for seven segment display fully programmed but not fully tested

7-Segment Display 



 



Insufficient time for testing and calibrating PIC has insufficient ROM when compiling. Attempted to simplify code but determined that second PIC required for this purpose. After several attempts, simplified version of code is completed Code and logic is functional 7-segment LED for double digits work as expected 7-segment LED for single digit does not work as expected. Problem may be caused by Pin C output

Output Current from PIC to Power Devices 





Output current from PIC insufficient to turn devices on Maximum output from one pin is 20mA. Devices such as cooling fans, exhaust fans and relay (used as AC switch) required more current Problem solved by using transistors

RECOMMENDATIONS 





Keep extra sensors in case (damaged humidity sensor – be careful with connections) Keep extra PIC when programming. Chances of damaging PIC when programming Modify code line by line and test constantly (will help in debugging process)

SUMMARY • Project successful; features described in Proposal functioned accordingly • Engineering knowledge acquired over the years fully applied and tested • Acquired many new skills and knowledge; improved researching and trouble-shooting techniques • Believe that product will be a success in the market as the “Push for Green” and environmental concerns intensifies in near future
