Addressing Modes Of 8051 1v5p59

Addressing mode:  Addressing mode is a way to address an

operand. Operand means the data we are operating upon (in most cases source data). It can be a direct address of memory, it can be names, it can be any numerical data etc.

Addressing mode: Eg: MOV A,#6AH  Here the data 6A is the operand, often known as

source data. When this instruction is executed, the data 6AH is moved to accumulator A.  There are 5 different ways to execute this instruction

and hence we say, we have got 5 addressing modes for 8051.

Addressing modes: They are :

1) Immediate addressing mode 2) Direct addressing mode 3) direct addressing mode 4) Indirect addressing mode 5) Indexed addressing mode

Immediate Addressing Mode Let’s begin with an example. Eg: MOV A, #6AH  In general we can write MOV A, #data  This addressing mode is named as “immediate” because it transfers an 8-bit data immediately to the accumulator (destination operand).  Note: The ‘#’ symbol before 6AH indicates that operand is a data (8 bit). If ‘#’ is not present then the hexadecimal number would be taken as address.

Immediate Addressing Mode

Immediate Addressing Mode

Immediate Addressing Mode

Direct Addressing Mode  This is another way of addressing an operand. Here the

address of the data (source data ) is given as operand. Lets take an example. Eg: MOV A, 04H  Here 04H is the address of 4 of

bank#0. When this instruction is executed, what ever data is stored in 04H is moved to accumulator.

Direct Addressing Mode

 In the picture above we can see, 04H holds the

data 1FH. So the data 1FH is moved to accumulator.

Direct Addressing Mode

Direct Addressing Mode

Direct Addressing Mode  In this addressing mode we use the name

directly (as source operand). An example is shown below. Eg: MOV A, R4  So in direct addressing mode, data

is transferred to accumulator from the (based on which bank is selected).

Direct Addressing Mode Take a look at the picture below.

Direct Addressing Mode

Indirect Addressing Mode  So in this addressing mode, address of the data (source

data to transfer) is given in the operand. Eg: MOV A, @R0  Here the value inside R0 is considered as an address,

which holds the data to be transferred to accumulator.  Note: Only R0 and R1 are allowed to form a

indirect addressing instruction. In other words programmer can must make any instruction either using @R0 or @R1. All banks are allowed.

Indirect Addressing Mode  If R0 holds the value 20H, and we have a data 2F H stored at

the address 20H, then the value 2FH will get transferred to accumulator after executing this instruction.

Indexed Addressing Mode  lets see two examples first.

Eg 1: MOVC A, @A+DPTR Eg2: MOVC A, @A+PC  Where DPTR is data pointer and PC is program

counter (both are 16 bit s).  The source operand is @A+DPTR and we know we will

get the source data (to transfer) from this location. It is nothing but adding contents of DPTR with present content of accumulator.

Indexed Addressing Mode  DPTR holds the value 01FE, where 01 is located in DPH and

FE is located in DPL . Accumulator now has the value 02H. A 16 bit addition is performed and now 01FE H+02 H results in 0200 H.

Arithmetic instructions:  ADD  ADDC  DA  L  SUBB  MUL  DIV

Addition(ADD):

Addition(ADDC):

Decimal adjust after addition(DA):

Decimal adjust after addition(DA):

Decimal adjust after addition(DA):

Decimal adjust after addition(DA):

Subtraction with barrow(SUBB):

Subtraction with barrow(SUBB):

Subtraction with barrow(SUBB):

Multiplication(MUL):

Division (DIV):
