7 Liver - Spleen Trauma 623w36

Management of Spleen/Liver Trauma George W. Holcomb, III, M.D., MBA Surgeon-in-Chief Children’s Mercy Hospital Kansas City, MO

Mechanisms for Intra-abdominal Trauma 1. Motor vehicle collisions 2. Automobile vs pedestrian accidents 3. Falls

4. ATV 5. Handlebar injury from bicycle 6. Sports 7. Non-accidental trauma

Frequency of Pediatric Blunt Abdominal Injuries • Spleen 27% • Kidney 27% • Liver 15%

• Pancreas 2%

Splenic Trauma • Diagnosis: • Plain abdominal film • Unreliable and nonspecific • Triad of radiographic findings in acute splenic rupture • Left diaphragmatic elevation • Left lower lobe atelectasis • Left pleural effusion

Radiograph demonstrates a left pleural effusion, left basilar atelectasis, and inferomedial displacement of the splenic flexure (arrow)

Splenic Trauma • Diagnosis: • FAST • Focused Abdominal Sonography for Trauma • Bedside study for unstable patient • 15% false-negative • May miss up to 25% of liver and spleen injuries • Compared to CT only 63% sensitive for detecting free fluid

Fluid in the subphrenic space and splenorenal recess can be detected. The image shown demonstrates blood (arrow) between the spleen (S) and diaphragm (D).

Splenic Trauma • Diagnosis: • CT with IV contrast • Noninvasive, highly

accurate, easily identifies and quantifies extent of injury, for stable patient only A: Hemoperitoneum with a liver laceration (arrow) and a shattered spleen is seen.

AAST Splenic Injury Scale

*Advance one grade for multiple injuries, up to grade III Moore EE, Cogbill TH, Jurkovich GJ, et al

AAST Splenic Injury Scale

17-yo boy injured on an ATV. Grade I injury with subcapsular fluid occupying less than 10% of spleen’s surface area.

AAST Splenic Injury Scale

17-yo girl injured in an MVC. Grade II injury with laceration involving less than 3 cm of parenchymal depth

AAST Splenic Injury Scale

18-yo boy injured playing football. Lacerations involving more than 3 cm of parenchymal depth radiating from splenic hilum -grade III laceration

AAST Splenic Injury Scale

16-yo boy injured playing hockey. Fractured spleen involving more than 25%, Grade IV splenic laceration

AAST Splenic Injury Scale

12-yo boy pedestrian struck by MV. Fractured spleen with hilar devascularization. Grade V injury.

Splenic Trauma • Complications • Pseudoaneurysms • Often asymptomatic and resolve over time • If treatment required, angiographic embolization may be used • Also occur in liver trauma

A. Splenic pseudoaneurysm (arrowheads) after nonoperative treatment of blunt splenic injury. B. Successful angiographic embolization The microcatheter used to deploy the coils is marked by the arrowheads and the embolic coils are marked by the arrows.

Splenic Trauma • Complications • Pseudocysts • Rare: 0.44% • May become large and painful • Tx: laparoscopic excision and marsupialization

Splenic Trauma • Immunocompetence • Vaccination practices vary • Adult trauma evidence s

immunocompetence in healed grade IV injuries

Splenic Trauma • If splenectomy is indicated • Pt requires vaccinations prior to discharge • Streptococcus pneumoniae • Pneumovax 23 • Haemophilus influenzae type B • Hib vaccine • Neisseria meningitidis • Quadravalent meningococcal/diphtheria

conjugate • Prophylactic antibiotics controversial

• Most centers use penicillin

Splenic Trauma • Treatment • Nonoperative failure rate 2% • Risks for increased nonoperative failure rate

• Bicycle-related injury mechanism • More than one solid organ injury

• Peaks at 4 hrs, declines at 36hrs after ission

Contrast Blush - Spleen

Blunt Splenic Injury • 216 Pts – 7 yrs • 26 Pts – Contrast blush on CT scan • Lower HgB • More likely to need op (22% vs 4%) • Not a definite indication for operation, but indicates subset of pts who have active bleeding and may need transfusion and/or operation

Liver Trauma • Blunt trauma is most common cause of injury to liver • High risk due to: • Large organ, friable

parenchyma, ligamentous attachments

AAST Liver Injury Grading

Grade I

Grade IV

Types of Injury • Parenchymal damage/laceration • Subcapsular hematoma/contusion • Hepatic vascular disruption – contrast extravasation • Bile duct injury

Diagnosis • Physical exam – • ±tachycardia, ±hypotention,

peritoneal irritation

• FAST – • better for unstable patients

not stable enough for CT1

• CT w contrast • determine grade and look for

active extravasation 1Coley

et al. J Trauma 2000

Contrast Blush - Liver

• 105 pts – blunt liver injury – 6 yrs • 75 pts – Grade III – V • 22 pts – Contrast blush • transfusion req. • mortality (23% vs 4%) • ISS also • Mortality may be related to the other injuries

Indication for Intervention • Operate for continued blood loss with hypotension, tachycardia, decreased urine output, decreasing Hg unresponsive to IVF and pRBC • Operative rates • 3-11% for multiple injuries • 0-3% for isolated liver injury

• Angioembolization – not used as commonly as in adults

Bile Duct Injury • With nonoperative management, 4% risk of persistent bile leak • HIDA with delayed images if bile duct injury suspected • ER with decompression and stenting – can be diagnostic and therapeutic

• 72 pts • 30 – Liver • 44 – Spleen • Liver vs spleen – • Longer recovery period • Nine complications • Greater use of resources J Pediatr Surg 43:2264-2267, 2008

APSA Guidelines APSA guidelines for hemodynamically stable children with isolated spleen or liver injury

CT GRADE

I

II

III

IV

Days in ICU

None

None

None

1 day

Hospital stay

2 days

3 days

4 days

5 days

Predischarge imaging

None

None

None

None

Postdischarge imaging

None

None

None

None

3 weeks

4 weeks

5 weeks

6 weeks

Activity restrictions

From Stylianos S, and APSA Trauma Committee: Evidence-based guidelines for resource utilization in children with isolated spleen or liver injury.

J Pediatr Surg 35:164-169, 2000

• Prospective study all pts with BSLI • No exclusions • Bedrest : Grade I – II inj – 1 night Grade III – V inj – 2 nights J Pediatr Surg 46:173-177, 2011

Prospective Study - BSLI • 131 pts (spleen only 72, liver only 55 • 1 splenectomy (Grade V inj) • Transfusions – 24 (18 due to BSLI)

• Mean injury grade – 2.6 • Mean bed rest – 1.6 days

• Need for bed rest limiting factor in duration of hospital in 86 pts (66%) J Pediatr Surg 46:173-177, 2011

Prospective Study – BSLI An abbreviated protocol of 1 night for Grade I – II injuries and 2 nights for Grade III or higher in hemodynamically stable pts is safe and significantly decreases hospitalization c/w previous APSA recommendations.

Solid Organ Injury • Treatment • > 90% of hemodynamically stable pts

successfully managed non-operatively • Less than 10% require transfusion

References •

Coley BD, Mutabagani KH, Martin LC, Zumberge N, Cooney DR, Caniano DA, Besner GE, Groner JI, Shiels WE 2nd. Focused abdominal sonography for trauma (FAST) in children with blunt abdominal trauma. J Trauma. 2000 May;48(5):902-6.

•

Holcomb GW III, Murphy JP. Ashcraft’s Pediatric Surgery. 5th ed. Philadelphia, PA: Saunders An Imprint of Elsevier, 2010.

•

Lynn KN, Werder GM, Callaghan RM, Sullivan AN, Jafri ZH, Bloom DA. Pediatric blunt splenic trauma: a comprehensive review. Pediatr Radiol (2009) 39:904-916.

•

Moore EE, Cogbill TH, Jurkovich GJ, et al: Organ injury scaling: Spleen and liver (1994 revision). J Trauma 38:323-324, 1995

•

Sabiston DC II, Townsend CM III. Sabiston Textbook of Surgery. 18th ed. Philadelphia, PA: Saunders An Imprint of Elsevier, 2007.

•

Stylianos S. Evidence-based guidelines for resource utilization in children with isolated spleen or liver injury. The APSA Trauma Committee. J Pediatr Surg. 2000 Feb;35(2):164-7.

•

Tataria M, Nance ML, Holmes JH 4th, Miller CC 3rd, Mattix KD, Brown RL, Mooney DP, Scherer LR 3rd, Grooner JI, Scaife ER, Spain DA, Brundage SI. Pediatric blunt abdominal injury: age is irrelevant and delayed operation is not detrimental. J Trauma 2007 Sep;63(3):608-14.
