Packet Tracer - Packet Tracer Physical View
Objectives Step 1 - Open the Physical View of Packet Tracer Step 2 - Apply a Physical View Background Image Step 3 - Edit and Move Between Containers Step 4 - Add Devices to a Wiring Closet Step 5 - Experiment
Background / Scenario In this activity, you will use the Physical view of Packet Tracer to add backgrounds, containers, and network devices.
Step 1: Open the Physical View of Packet Tracer a. Launch Packet Tracer.
© 2017 Cisco and/or its s. All rights reserved. This document is Cisco Public.
Page 1 of 12
Packet Tracer – The Physical View When Packet Tracer opens, the default view is the Logical view.
b. Change to the Physical view. Click the Physical view button to change to the Physical view. The Physical view button is behind the Logical view button in the top left portion of the workspace.
© 2017 Cisco and/or its s. All rights reserved. This document is Cisco Public.
Page 2 of 12
Packet Tracer – The Physical View The default Physical view is the Intercity.
Step 2: Apply a Physical View Background Image a. the estate image from pixabay. Navigate to the pixabay web site at https://pixabay.com and type world map into the All images search window. Click a map image in the result and save the image. b. Load the saved image into Packet Tracer. Make sure that Intercity is selected in the Physical view tool bar.
© 2017 Cisco and/or its s. All rights reserved. This document is Cisco Public.
Page 3 of 12
Packet Tracer – The Physical View Click Set Background at the top of the Packet Tracer window and in the Set Background Image window, click the Browse button to navigate to the saved image. Select the image and then click Apply. Close the Set Background Image window.
© 2017 Cisco and/or its s. All rights reserved. This document is Cisco Public.
Page 4 of 12
Packet Tracer – The Physical View After you click Apply, the image is saved as the Physical view background.
Step 3: Edit and Move Between Containers a. Relocate the Home City. In the Intercity view is a Home City container. The Home City container can be moved to any location in the Physical view. Click and drag the Home City container to any place on the world map background. b. Apply a background image to the Home City. Click the Home City container. Notice that the view changes and what is on the workspace now is the default Home City background. Zoom out by clicking the magnifying glass with the minus sign so that the whole background is visible.
© 2017 Cisco and/or its s. All rights reserved. This document is Cisco Public.
Page 5 of 12
Packet Tracer – The Physical View
c. Repeat Step 2 to a city image from https://pixabay.com and apply it to the Home City background. Navigate to the pixabay web site at https://pixabay.com and type city image into the All images search window. Click a map image in the result and save the image. Click Set Background at the top of the Packet Tracer window and in the Set Background Image window, click the Browse button to navigate to the saved image. Select the image and then click Apply. Close the Set Background Image window. You may need to zoom in and recenter the background so it is fully visible in the workspace.
© 2017 Cisco and/or its s. All rights reserved. This document is Cisco Public.
Page 6 of 12
Packet Tracer – The Physical View
If you click the Back menu item in the Physical view tool bar, you can see that the city background you applied is also now used on the Home City container in the Intercity view.
© 2017 Cisco and/or its s. All rights reserved. This document is Cisco Public.
Page 7 of 12
Packet Tracer – The Physical View Click the Home City text and change the name of the Home City container. In this example, the name is changed to Atlanta. This also changes the name of the Home City in the Physical view tool bar.
Click the Home City container to return to the Home City view.
Step 4: Add Devices to a Wiring Closet a. Enter the Corporate Office view.
© 2017 Cisco and/or its s. All rights reserved. This document is Cisco Public.
Page 8 of 12
Packet Tracer – The Physical View There is a Corporate Office container on the Home City background.
Click the Corporate Office container and zoom out so that the default corporate office background is visible.
The Corporate Office background includes another container called Main Wiring Closet. Click the Main Wiring Closet container.
© 2017 Cisco and/or its s. All rights reserved. This document is Cisco Public.
Page 9 of 12
Packet Tracer – The Physical View The Main Wiring Closet container has a blank workspace.
b. Add devices to the Main Wiring Closet. In the Main Wiring Closet view, add a router to the workspace just as you would in the Logical view by clicking a router in the device window and then clicking the workspace. Because we are in Physical view, Packet Tracer shows a rack with the router installed in the rack.
© 2017 Cisco and/or its s. All rights reserved. This document is Cisco Public.
Page 10 of 12
Packet Tracer – The Physical View c. Add more devices to the wiring closet. Add a network switch, a generic server, and a cable modem to the wiring closet.
b. Add cabling to the devices to the Main Wiring Closet. To add cabling to the devices, switch back to the Logical view in Packet Tracer. You may need to zoom in and re-center the workspace to see the devices. The devices are randomly placed in the Logical view workspace.
© 2017 Cisco and/or its s. All rights reserved. This document is Cisco Public.
Page 11 of 12
Packet Tracer – The Physical View Organize and connect the devices together using the appropriate cable types in the Logical view.
Switch back to the Physical view. You may need to zoom in. There are now physical cables connected to the interfaces of the devices.
Hover the mouse pointer over the cable ends to see information about each cable and interface.
Step 5: Experiment Now that you know how to navigate the Physical view and add containers and network devices, experiment by adding additional containers to your Home City and to your Corporate Office. Try building more complex network wiring closets by adding additional types of devices.
© 2017 Cisco and/or its s. All rights reserved. This document is Cisco Public.
Page 12 of 12
